Nokia 1606 Fold, RH-109 Service Manual

1606 fold RH-109
Service Manual Level 1&2
SERVICE MANUAL
Level 1&2
RH-109
Transceiver characteristics
Band:
RH-109 : CDMA200 1XRTT tri-band Cell, PCS, AWS
Display: Main display: 1.77” 128x160 pixel, 262k true color
internal display
Secondary/hidden display: 0.97” 96x32 pixel, white monochrome external display
Operating System: L4
Connections: Micro USB port for charging and data transfer (USB
2.0+)
Transceiver with BL-4B battery pack
Talk time Standby Note
Up to 3.5 hours 10 days Depend
network parameters and phone setting
ISSUE 1
Copyright @ 2008 NOKIA. All rights reserved
Confidential
1606 fold RH-109
Service Manual Level 1&2
Change history ..............................................................................................................................................................3
1.
2. Copyright .........................................................................................................................................................................4
3. Warnings and cautions ..............................................................................................................................................5
3.1 Warnings .................................................................................................................................................................5
3.2 Cautions ...................................................................................................................................................................5
4. ESD protection ...............................................................................................................................................................6
5. Care and maintenance ...............................................................................................................................................7
6. Battery information.....................................................................................................................................................8
7. Exploded view ...............................................................................................................................................................9
8. Service devices…………………………………………………………………………………………………………………….…..….…..10
9. SW-update…………………………………………………………………………………………………………………………………...…..11
10. Disassembly instruction……………………………………………………………………………………………………….…………12
11. Assembly hints…………………………………………………………………………………………................................................18
12. Solder components………………………………………………………………………………………………………..……….………22
ISSUE 1
Copyright @ 2008 NOKIA. All rights reserved
Confidential
1606 fold RH-109
Service Manual Level 1&2
1. CHANGE HISTORY
Status Version No. Date Comments
Issue 0.1 2008.05.13 Michelle Wang Initial draft Issue 0.2 2008.07.17 Michelle Wang Updated version Issue 0.3 2008.07.24 Michelle Wang Updated version Issue 0.4 2008.08.27 Michelle Wang Update Exploded View Issue 0.5 2008.09.04 Michelle Wang Update Page 1-8 Heading
Issue 1.0 2008.09.16 Michelle Wang Template update
The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA service suppliers, and the content of it is confidential. Please note that NOKIA provides also other guidance documents (e.g. Service Bulletins) for service suppliers, follow these regularly and comply with the given instructions.
While every endeavor has been made to ensure the accuracy of this document, some errors may exist. If you find any errors or if you have further suggestions, please notify NOKIA using the address below:
CMO Operation & Logistics Training and Vendor Development Multimedia Creation & Support
mailto:Service.Manuals@nokia.com
Please keep in mind also that this documentation is continuously being updated and modified, so watch always out for the newest version.
ISSUE 1
Copyright @ 2008 NOKIA. All rights reserved
Confidential
1606 fold RH-109
Service Manual Level 1&2
2. COPYRIGHT
Copyright © 2008 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, and Nokia X and Y are trademarks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided “as is”. Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.
The availability of particular products may vary by region.
IMPORTANT
This document is intended for use by qualified service personnel only.
ISSUE 1
Copyright @ 2008 NOKIA. All rights reserved
Confidential
1606 fold RH-109
Service Manual Level 1&2
3. WARNINGS AND CAUTIONS
Please refer to the phone’s user guide for instructions relating to operation, care and maintenance including important safety information. Note also the following:
3.1 Warnings
1. CARE MUST BE TAKEN ON INSTALLATION IN VEHICLES FITTED WITH ELECTRONIC
ENGINE MANAGEMENT SYSTEMS AND ANTI–SKID BRAKING SYSTEMS. UNDER CERTAIN FAULT CONDITIONS, EMITTED RF ENERGY CAN AFFECT THEIR OPERATION. IF NECESSARY, CONSULT THE VEHICLE DEALER/MANUFACTURER TO DETERMINE THE IMMUNITY OF VEHICLE ELECTRONIC SYSTEMS TO RF ENERGY.
2. THE HANDPORTABLE TELEPHONE MUST NOT BE OPERATED IN AREAS LIKELY TO
CONTAIN POTENTIALLY EXPLOSIVE ATMOSPHERES, EG PETROL STATIONS (SERVICE STATIONS), BLASTING AREAS ETC.
3.2 Cautions
3. OPERATION OF ANY RADIO TRANSMITTING EQUIPMENT, INCLUDING CELLULAR
TELEPHONES, MAY INTERFERE WITH THE FUNCTIONALITY OF INADEQUATELY PROTECTED MEDICAL DEVICES. CONSULT A PHYSICIAN OR THE MANUFACTURER OF THE MEDICAL DEVICE IF YOU HAVE ANY QUESTIONS. OTHER ELECTRONIC EQUIPMENT MAY ALSO BE SUBJECT TO INTERFERENCE.
1. Servicing and alignment must be undertaken by qualified personnel only.
2. Ensure all work is carried out at an anti–static workstation and that an anti–static
wrist strap is worn.
3. Use only approved components as specified in the parts list.
4. Ensure all components, modules screws and insulators are correctly re–fitted after
servicing and alignment.
5. Ensure all cables and wires are repositioned correctly
ISSUE 1
Copyright @ 2008 NOKIA. All rights reserved
Confidential
1606 fold RH-109
Service Manual Level 1&2
4. ESD PROTECTION
Nokia requires that service points have sufficient ESD protection (against static electricity) when servicing the phone. Any product of which the covers are removed must be handled with ESD protection. The SIM card can be replaced without ESD protection if the product is otherwise ready for use. To replace the covers ESD protection must be applied. All electronic parts of the product are susceptible to ESD. Resistors, too, can be damaged by static electricity discharge. All ESD sensitive parts must be packed in metallized protective bags during shipping and handling outside any ESD Protected Area (EPA). Every repair action involving opening the product or handling the product components must be done under ESD protection. ESD protected spare part packages MUST NOT be opened/closed out of an ESD Protected Area. For more information and local requirements about ESD protection and ESD Protected Area, contact your local Nokia After Market Services representative.
ISSUE 1
Copyright @ 2008 NOKIA. All rights reserved
Confidential
1606 fold RH-109
Service Manual Level 1&2
5. CARE AND MAINTENANCE
This product is of superior design and craftsmanship and should be treated with care. The suggestions below will help you to fulfil any warranty obligations and to enjoy this product for many years.
Keep the phone and all its parts and accessories out of the reach of small children.
Keep the phone dry. Precipitation, humidity and all types of liquids or moisture
can contain minerals that will corrode electronic circuits.
Do not use or store the phone in dusty, dirty areas. Its moving parts can be
damaged.
Do not store the phone in hot areas. High temperatures can shorten the life of
electronic devices, damage batteries, and warp or melt certain plastics.
Do not store the phone in cold areas. When it warms up (to its normal
temperature), moisture can form inside, which may damage electronic circuit boards.
Do not drop, knock or shake the phone. Rough handling can break internal circuit
boards.
Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the
phone.
Do not paint the phone. Paint can clog the moving parts and prevent proper
operation.
Use only the supplied or an approved replacement antenna. Unauthorised
antennas, modifications or attachments could damage the phone and may violate regulations governing radio devices.
All of the above suggestions apply equally to the product, battery, charger or any accessory.
ISSUE 1
Copyright @ 2008 NOKIA. All rights reserved
Confidential
