QU IC K RE FE RENCE G UI DE
2006 MURANO
Sh ift_style
04
CRUISE CONTROL
03
STEERING WHEEL SWITCHES
FOR AUDIO CONTROL
09
CLIMATE CONTROLS
08
CONTROL PANEL DISPLAY
HOOD RELEASE
02
HEADLIGHT AIMING
CONTROL SWITCH
01
HEADLIGHT AND
TURN SIGNAL CONTROL
05
WINDSHIELD WIPE R/
WASHER SWITCH
06
AWD LOCK SWITCH
07
AUDIO SYSTEM
01
HEADLIGHT CONTROL AND TURN
SIGNAL CONTROL
HEADLIGHT SWITCH
Turn the headlight switch to the
position
to turn on the front parking, tail, license plate and
instrument panel lights.
Turn the headlight switch to the
position to
turn on the headlights. All other lights remain on.
AUTOMATIC HEADLIGHT OPERATION
(if so equipped)
The autolight system allows the headlights to be set so they turn on and off
automatically. The autolight system can:
Turn on the headlights, front parking, tail, license plate and instrument panel lights
automatically when it is dark.
Turn off all the lights when it is light.
Keep all the lights on for 45 seconds after you turn the key to OFF and all doors
are closed.
TO ACTIVATE THE AUTOLIGHT SYSTEM:
Turn the headlight switch to the AUTO position, then turn the ignition switch to ON.
TO DEACTIVATE THE AUTOLIGHT SYSTEM:
Turn the headlight switch to the OFF, or position.
FOG LIGHT SWITCH (if so equipped)
To turn the fog lights on, turn the headlight switch to the
fog light switch to the
position. To turn them off, turn the fog light switch to the
position, then turn the
OFF position. The headlights must be on and the low beams selected for the fog
lights to operate.
02
HEADLAMP AIMING CONTROL SWITCH
(with Xenon headlamps, if so equipped)
Depending on the number of occupants in the
vehicle and the load it is carrying, the headlight axis
may be higher than desired. If the vehicle is traveling
on a hilly road, the headlights may directly hit the
rearview mirror of the vehicle ahead or the windshield
of the oncoming vehicle. The light axis can be
lowered with the operation of the switch.
The larger the number designated on the switch, the lower the axis.
When traveling without a heavy load or on a flat road, select position 0.
03
STEERING WHEEL SWITCHES FOR
AUDIO CONTROL (if so equipped)
To turn on the steering wheel audio system,
press PWR (power).
To choose FM, AM, SAT (if so equipped),
CD and Tape (if so equipped), press MODE
repeatedly.
< >
The
switch can be used to perform
the following:
• While in one of the preset radio station banks (A, B or C), push the
switch for less than 1.5 seconds to change to a preset station.
• Push the
broadcasting radio station.
• Push the
change tracks.
• Push the
forward or rewind the tape.
• Push the
< >
switch for more than 1.5 seconds to seek the next or previous
< >
switch for less than 1.5 seconds while playing a CD or tape to
< >
switch for more than 1.5 seconds while playing a tape to fast
< >
switch for less than 1.5 seconds to cancel the fast forward or
rewind function and resume tape play.
• If the vehicle is equipped with a CD changer, push the
than 1.5 seconds to change between CDs.
Push the VOL control switch up or down to increase or decrease volume.
< >
switch for more
< >
04
CRUISE CONTROL
To turn on the cruise control, push the main
(ON/OFF) switch on. The indicator light in the
instrument panel comes on.
To set cruising speed, accelerate the vehicle
to the desired speed, push the COAST/SET
switch and release it. The SET indicator light in
the instrument panel comes on.
To reset at a faster cruising speed, push and
hold the ACCEL/RES switch. When the vehicle reaches the speed you desire,
release the switch.
To reset at a slower cruising speed, push and hold the COAST/SET switch.
Release the switch when the vehicle slows to the desired speed.
To resume a preset speed, push and release the ACCEL/RES switch. The
vehicle returns to the last set cruising speed when the vehicle speed is over 24
MPH (38 km/h).
To cancel cruise control, push the CANCEL switch or tap the brake pedal. The
SET indicator light in the instrument panel will go out.
To turn off cruise control, push the main (ON/OFF) switch. Both the CRUISE
indicator light and the SET light in the instrument panel will go out.
05
WINDSHIELD WIPER/WASHER SWITCH
The ignition switch must be in the ON position
to activate the windshield wipers.
Push the lever down to operate the windshield
wipers.
Switch operation includes:
Intermittent – Wipers operate intermittently and can be adjusted by
INT
turning the time control.
LO
Low speed – Wipers operate at a continuous low speed.
HI
High speed – Wipers operate at a continuous high speed.
MIST
Mist – Lift the lever up for one sweep operation of the wiper.
Wash – Pull the lever toward you. Wipers automatically wipe several
times.
Rear wiper and washer switch – The rear window wiper and washer operates
when the ignition switch is in the ON position. Switch operation includes:
INT
On – Wipers operate at a continuous speed.
Intermittent (not adjustable) – Wipers operate intermittently.
ON
Wash – Push the lever away from you. Wipers automatically wipe
several times.
06
AWD LOCK SWITCH (if so equipped)
Each time you push the lower part of the switch,
the AWD mode will switch as follows: AUTO
LOCK AUTO.
Push the lower part of the AWD LOCK switch
to select AUTO or LOCK mode, depending on
the driving conditions.
LOCK MODE
• For driving on rough roads.
• Push the lower part of the switch when the vehicle is stopped or driving
less than 6 MPH (10 km/h). The AWD LOCK indicator light will come on.
• LOCK mode will change to AUTO mode automatically when the vehicle is
accelerated or the vehicle speed is over approximately 6 MPH (10 km/h).
AUTO MODE
• For driving on paved or slippery roads.
• Push the lower part of the switch. The AWD LOCK indicator light will go off.
01
03
02
04
05
06 07 08
09 10
11
12
07
FM/AM/SAT* RADIO WITH CASSETTE PL AYER AND COMPACT DISC (CD)
CHANGER (if so equipped)
LOAD BUTTON
01
LOAD A SINGLE DISC CD - To insert a CD in the CD changer, push the LOAD button for less than 1.5
seconds. Select the loading slot by pushing the CD select button (1 to 6), then insert the CD.
LOAD UP TO 6 DISCS - To insert a CD in the CD changer, push the LOAD button for less than 1.5
seconds. The inserted slot numbers will illuminate on the display.
SEEK /TR ACK BUT TON
02
For radio, press to seek stations. For CD, press to select previous/next tracks.
STATION AND CD SE LECT BUTTON
03
To store a radio station in a preset first select A, B, or C memory bank by pressing the PRESET A•B•C button
and tuning to the desired AM, FM, or SAT* station. Then press the desired station select button for at least
2 seconds. When the preset indicator illuminates, a beep will sound, indicating memorization is complete. To
retrieve a previously set station, select the memory bank where the preset was set, then press the corresponding
station select button.
SCAN BUT TON
04
Push the SCAN button to tune from low to high frequencies and stop at each broadcasting station for 5
seconds. If listening to a CD, each track will play for about 10 seconds.
CAT FOLDER BUTTON CATEGORY (CAT)
05
When the CAT button is pushed for more than 1.5 seconds during FM (SAT*) mode, the PTY (PROGRAM
TYPE) (if so equipped) name of the current tuned station is displayed. Certain program types may include
ROCK, COUNTRY, JAZZ, CLASSICAL, etc.
MP3 PLAYBACK (if so equipped)
In addition to playing audio CDs, the audio system can play MP3 files recorded on CD-ROM, CD-R, and
CD-RW discs. Eacha disc can have a maximum of 8 folder levels and 255 folders. A total of 512 MP3 files can
be played back. During MP3 playback, some recorded ID3 tag information can be displayed by pressing the
DISP button. Use the CAT FOLDER button to navigate the MP3 files.
DISP (display) BUT TON
06
Press to display CD or radio text.
PRESET A•B•C BUT TON
07
Press the PRESET A•B•C button until you reach the desired setting. The radio is equipped with three separate
banks of 6 station presets (18 total station presets). You may store any combination of AM, FM, or SAT* radio
presets on each bank.
CD SELE CT BUTTON
08
Press to activate CD functions.
RADIO BAND SE LECT
09
Press the RADIO band select button to change the band as follows:
Without satellite radio: AM FM1 FM2 AM
With satellite radio: AM FM1 FM2 SAT1 SAT2 AM
TAPE BUTTON
10
Press the TAPE button. The system will come on and the tape will play.
RPT (repeat) / RDM (random) BUTTON
11
Change tape or CD play patterns.
TUNING AND AUDIO CONTROL KNOB
12
To manually tune the radio, turn the TUNE knob. Adjust the Bass, Midrange, Treble, Fade, Balance, and Speed
Sensitive Volume (SSV) (if so equipped) by presing the AUDIO knob until the desired mode appears in the
display. Then turn the TUNE knob to adjust to the desired level.
*SAT presets are only available on SAT equipped vehicles.
Please see reverse side for 08 and 09.
08
CONTROL PANEL DISPLAY
(with Navigation System,
if so equipped)
TRIP BUTTON
When the TRIP button is pressed,
the following modes will display on
the screen:
Warning message (if there
are any)
TRIP 1 (Elapsed Time, Driving
Distance, Average Speed)
TRIP 2 (Elapsed Time, Driving Distance, Average Speed)
FUEL ECONOMY (Average Fuel Economy, Distance to Empty)
MAINTENANCE (Engine Oil, Tire Rotation)
OFF
MAINTENANCE ITEMS
You can set the engine oil and the tire rotation interval. To display the setting of the
maintenance interval, select the ENGINE OIL or TIRE ROTATION key using the
joystick and press the ENTER button.
To set the maintenance interval, select the MAINTENANCE SCHEDULE key by
using the joystick and pushing the joystick to the right or left. To reset the
maintenance interval, select the RESET key using the joystick and press the ENTE R
button.
SETTING THE CLOCK
The clock on the display screen can be adjusted using the joystick and the following
procedure.
Press the SETTING button, then select SYSTEM SETTINGS from the menu on
the display screen.
Next select CLOCK to enter the CLOCK SETTINGS mode.
Then select the HOURS or MINUTES key and hold the joystick left or right to
adjust the time. After the desired time is shown on the display screen, press the
BACK button to store.
Refer to both the Navigation System Owner’s Manual and your Owner’s Manual for
additional information.
01
02
03
04
05 06
07
09
AUTOMATIC CLIMATE CONTROL
01
AUTO BUTTON
Press the AUTO button
01
08
for automatic cooling and/or dehumidified heating. The
09
indicator light on the button will come on when the system is activated.
02
FRESH AIR BUTTON
Press the fresh air button
to draw outside air into the passenger compartment. The
indicator light on the button will come on when the system is activated.
03
AIR RECIRCULATION BUTTON
Press the air recirculation button to recirculate air inside the vehicle.
Press the air recirculation button again to turn air recirculation off.
The air recirculation mode cannot be selected if the air flow control dial is in the defrost
position.
04
DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Push the front window defroster switch on. The indicator light on the button will
come on.
Turn the driver’s side temperature control dial
left for cold air or right for hot air to
07
set the desired temperature. To set the defroster on high, turn the manual fan speed
control dial
05
DEFROSTING/DEFOGGING REAR WINDOW
Push the rear window defroster switch
to set fan speed to maximum.
on. The indicator light on the button will come
on. Push the switch again to manually turn off the defrost. NOTE: The rear window
defroster automatically turns off in approximately 15 minutes.
06
MODE BUTTON
The MODE button allows you to select the air flow outlets.
Air flows from the center and side vents.
Air flows from the center, side, and foot vents.
Air flows mainly from the foot vents.
Air flows from the defroster and foot vents.
07
DRIVER’S TEMPERATURE CONTROL DIAL
Turn the driver’s temperature control dial left for cold air or right for hot air. The driver’s
temperature control dial adjusts the temperature for both driver and passenger when the
DUAL button
is not activated.
DUAL TEMPERATURE CONTROL ON/OFF BUTTON
08
Press the DUAL button
to turn the passenger’s side temperature controls on or off.
This will allow the passenger’s side temperature to be adjusted independently from the
driver’s side control.
09
PASSENGER’S TEMPERATURE CONTROL DIAL
Turn the passenger’s side air control dial to the left for cold air or right for hot air.
ADDITIONAL FEATURES (continued)
REMOTE KEYLESS ENTRY SYSTEM
LOCK DOORS
Press the LOCK button to lock all doors.
UNLOCK DOORS
Press the UNLOCK button once to unlock the
driver’s door only. Press the button again within
5 seconds to unlock all doors.
USING THE PANIC ALARM
Press and hold the PANIC button for longer
than 0.5 seconds. The panic alarm will sound
and headlights will stay on for 25 seconds.
The panic alarm stops when it has run for 25 seconds or when any button is
pressed on the keyfob.
HORN BEEP FEATURE
The horn beep feature can be deactivated. Refer to the “Display screen, heater, air
conditioner and audio systems” section in your Owner’s Manual for the procedure.
INTELLIGENT KEY SYSTEM
This system allows you to lock or unlock your vehicle and
start the engine with an Intelligent Key unit which may be
carried in a pocket or purse.
(if so equipped)
NOTE: It’s important to make sure the Intelligent Key is
“on your person” (i.e., pocket or purse) when locking or
unlocking the doors.
Locking the vehicle - Push any door handle Request
Switch once.
Unlocking the vehicle - Push any door handle Request
Switch once. The corresponding door will unlock. Push
the door handle Request Switch again within 5 seconds; all other doors will unlock.
NOTE: The operating range of the door and lift gate lock/unlock function is approximately
31 in (0.8 m).
Starting the engine - Push in on the ignition “KNOB,” confirm the Intelligent Key
Warning Light is illuminated “green,” then turn the ignition KNOB to start the engine.
FUEL-FILLER DOOR
The fuel-filler door automatically unlocks when the driver’s
door is unlocked.
With the driver’s door unlocked, push the right side of
the fuel-filler door to open.
To lock, close the fuel-filler door and lock the
driver’s door.
AUTOMATIC DRIVER POSITIONER (if so equipped)
The automatic driver positioner system has two features:
Memory storage function.
Entry/exit function.
MEMORY STORAGE FUNCTION
Two positions for the driver’s seat, accelerator and brake pedals,
and outside mirrors can be stored in the automatic driver positioner
memory. Follow these procedures to set driver preferences.
SET THE DESIRED POSITIONING
1. Set the automatic transmission lever to the P (Park) position.
2. Turn the ignition on and adjust the driver’s seat, accelerator and brake pedals, and outside
mirrors to the desired positions.
3. Press the SET (memory) button and within 5 seconds press the position button (1 or 2) for
at least 1 second until the indicator light illuminates. The position is now stored in memory.
LINK TO KEYFOB
Within 5 seconds of setting the memory position (indicator light is on and ignition is on),
press the button on the remote.
A keyfob can be linked to each memory button.
If memory positioning is re-set to a new location, it will be necessary to re-link the keyfob.
RECALLING A MEMORY SETTING FROM THE MEMORY PAD
With the ignition on and automatic transmission lever in the P (Park) position, press the
position button (1 or 2) for at least 1 second.
FROM THE KEYFOB
If properly linked, operation of the button will automatically return the driver’s seat,
accelerator and brake pedals, and outside mirrors to the memorized position.
ENTRY/EXIT FUNCTION
The driver’s seat automatically moves to allow the driver to get into and out of the driver’s seat
more easily. The driver’s seat slides backward when:
The driver’s door is opened with the key turned to LOCK.
The key is turned from ACC to LOCK with the driver’s door open and the automatic
transmission lever is in the P (Park) position.
The driver’s seat returns to the previous position when:
The key is inserted into the ignition switch.
The driver’s door is closed with the key turned to LOCK.
The key is turned from ACC to ON while the automatic transmission lever is in the P (Park)
position.
SUNROOF CONTROLS (if so equipped)
03
01
TILTING THE SUNROOF
To tilt the sunroof up, push the tilt switch to the
01
position. If the roof is open, it will automatically
close and then tilt up.
To tilt the sunroof down, push the tilt switch to the
position.
02
04
02
SLIDING THE SUNROOF
To open the roof, slide the switch to the 03 position. If the roof is tilted up, it will
automatically tilt down and then open.
To close the roof, slide the switch to the
04
position.
The position of the sliding roof lid can be chosen by the position of the sliding switch.
To fully open or close the roof, move the switch completely to the or position.
XTRONIC CONTINUOUSLY VARIABLE
TRANSMISSION
The Xtronic CVT™ does not produce a gear change
sensation like traditional automatic transmissions.
(CVT) ™
P (Park)
R (Reverse) – Use for backing up.
N (Neutral) – Neither forward or reverse is engaged.
D (Drive) – Use for normal forward driving.
S (Second) – Use for improved acceleration and
engine braking.
L (Low) – Use for maximum engine braking.
The transmission in your Murano requires a special fluid (NS-2) available only at your NISSAN
dealer. No other fluid will meet the exacting requirements of the new Xtronic CVT™.
MANUAL SHIFT MODE (if so equipped)
When the transmission lever is shifted from D (Drive) to the manual shift gate, the
transmission enters the manual shift mode.
In the manual shift mode, shift range is displayed on the position indicator in the meter.
When shifting up, move the transmission lever to the + (up) side. (Shifts to higher gear.)
When shifting down, move the transmission lever to the - (down) side. (Shifts to lower gear.)
In manual shift mode, the transmission automatically shifts down to M1 (first) before the
vehicle comes to a stop. When accelerating again, it is necessary to shift to the desired gear.
When canceling the manual shift mode, return the transmission selector lever to the D (Drive)
position. The transmission returns to the normal driving mode.
REAR VIEW MONITOR (with Navigation, if so
equipped)
When the automatic transmission lever is moved to the R
(Reverse) position, the monitor display will automatically
change to show the area behind the vehicle.
The colored lines on the display screen indicate
approximate distances to objects.
Red 1.5 feet
Yellow 3 feet
Green 7 and 10 feet
POWER SEAT AND PEDAL ADJUSTMENTS
(if so equipped)
01
02
03
PEDAL POSITION ADjUSTMENT (if so equipped)
Push the switch forward or backward to move the
brake and accelerator pedal to the desired position.
04
Only adjust the pedals when the automatic
transmission selector lever is in P (Park.)
01
SEAT POSITION ADjUSTMENT
Move the control forward or backward to adjust the seat cushion forward or backward.
Pull up to raise the seat cushion; press down to lower the cushion.
02
02
SEAT RECLINING ADjUSTMENT
Push the switch forward to move the seatback forward; push it back to move the seatback
backward.
03
LUMBAR SUPPORT (if so equipped for driver’s seat)
Push each side of the switch
to adjust the lumbar support.
04
FRONT-PASSENGER AIR BAG STATUS LIGHT
This vehicle is equipped with the Nissan Advanced
Air Bag system. Under some conditions, depending
on pressure detected on the passenger seat and how
the seat belt is used, the front-passenger air bag is
designed to automatically turn OFF. When the frontpassenger air bag is OFF, the front-passenger air bag
status light will illuminate*. For example:
When the system detects that the front-passenger’s seat is occupied by a small
adult, child or child restraint as outlined in the Owner’s Manual, the
will
illuminate to indicate that the front-passenger air bag is OFF and will not inflate in
a crash.
When the front-passenger’s seat is occupied and the passenger meets the
conditions outlined in the Owner’s Manual, the
will not illuminate to indicate
that the front-passenger air bag is operational.
*When the system detects that the front-passenger’s seat is unoccupied, the
passenger air bag status light will not illuminate even though the front-passenger
air bag is OFF.
Refer to the Owner’s Manual for detailed information regarding the Nissan Advanced Air
Bag System.
FOLDING DOWN THE REAR SEATS
To fold the seats flat, disconnect and secure the
center seat belt and tongues from the retractor base.
Remove the head restraints and close the tonneau
sub cover (if so equipped).
Fold the seatback forward by either using the pull
strap located on the outside edge of the rear seat or
pulling on the release lever beside the cargo area.
TIRE PRESSURE MONITORING SYSTEM (if so equipped)
This system monitors tire pressure. Please remember, this
system does not detect a sudden drop in tire pressure (for
example, a blowout while driving). It also does not monitor the
air pressure in the spare tire.
Tire pressure is affected by temperature. Low outside
temperature causes lower tire pressure. This may cause the
low tire pressure warning light to illuminate.
If the low tire pressure warning light comes on, check the tire pressure in all four tires.
Adjust the low tire pressure to the
recommended COLD tire pressure shown on the Tire and Loading Information label to
turn the low tire pressure warning light off.
If TPMS is not functioning properly, the low tire pressure warning light will flash for
approximately 60 seconds when the key is turned on. The light will remain on after the 60
seconds. Have the system checked by a NISSAN dealer.
ADDITIONAL FEATURES
SEAT BELT WARNING LIGHT AND CHIME
The light and chime remind you to fasten your seat belts. The light
illuminates whenever the ignition key is turned to the ON or START
position and remains illuminated until the driver’s seat belt is
fastened. At the same time, the chime sounds for about 6 seconds
unless the driver’s seat belt is securely fastened.
The seat belt warning light may also illuminate if the front passenger’s
seat belt is not fastened when the front passenger’s seat is occupied (if so equipped).
For 5 seconds after the ignition switch is in the ON position, the system does not
activate the warning light for the front passenger.
Refer to the Owner’s Manual for detailed information regarding seat belt usage.
This easy-to-use Quick Reference Guide is intended to help you more fully appreciate
some of the unique features and functions of your new vehicle. However, it is not
intended to replace your Owner’s Manual. The Owner’s Manual contains more detailed
information to help you better understand the important safety warnings, features,
operation, and maintenance of your vehicle.
Sh ift_
Nissan, the Nissan Brand Symbol, “SH IFT_” tagline, Z and Nissan model names are Nissan trademarks.
©2005 Nissan North America, Inc.
QR6E-0Z50U1 Printing: December 2005 (10)
Loading...
