VL500
Wet/Dry Vacuums
Smart cleaning.
A Nilfisk-Advance Brand
VL500
Wet/Dry Vacuums
Ideal applications include:
• Schools and Universities
• Grocery Stores
• Retail Outlets
• Arenas and Stadiums
• Automobile Dealerships
Reliable, cost-efficient cleaning!
Versatile performance and superior filtration deliver a cost-efficient cleaning solution
The new line of Advance VL500™ wet/dry vacuums is
designed to accommodate virtually any cleaning
requirement. Available in three models—9, 14 and 19 gallon tank congurations—the VL500 wet/dry
vacuum applications range from small office environments to large education and healthcare facilities. Designed with a superior filtration system, easy-to-use features and multiple accessories, operators are guaranteed to find a wet/dry vacuum to fit their cleaning program.
Flexible operation
With three unique models to select from, the VL500
series delivers unprecedented cleaning flexibility.
Equipped with a front-mount squeegee and 19 gallon tank, the VL500-75 is ideal for picking up wet matter
when stripping with floor stripper and a floor machine.
Plus, an exclusive ERGO “tip n pour” design makes wet pick-up and emptying easy. For emergency spills and
floods, the VL500-55 delivers the power and functionality
when you need it. Featuring a hose, wand, squeegee
floor tool, brush floor tool and optional front-mount
squeegee, you can quickly clean up any unwanted
messes. When dirt or dust is the primary issue, the
VL500-35 offers quality ltration and dust capture, in
addition to crevice and dusting tools. Operators can also employ the VL500-35 for wet applications.
Superior filtration
Featuring a unique lter system, the VL500 series offers
one solution for both wet and dry filtration. Designed with three durable components, the filter completely seals the entry to the motor, protecting the motor from dust, debris,
water or other liquids. Once the job is complete, the lter
can be easily lifted out of the vacuum for a simple rinse,
then replaced and ready for the next job in a matter
of minutes.
Easy operation
The VL500 wet/dry vacuums offer simple and reliable operation. The 14 and 19 gallon congurations feature a
balanced wide stance for superior maneuverability, while
the lightweight design of the 9 gallon model ensures easy transportation. For enhanced performance, the VL500
series offers a variety of standard and optional accessories,
ranging from hoses and wands to squeegees and
dusting tools.
Filter system allows for both
wet and dry filtration, with full motor protection
ERGO “tip n pour”
design allows for easy tank emptying
Powerful 1,000 W motor enhances cleaning capacity
Hinge motor head lifts off for quick access to the
motor and tank
Handle hanger for
cord storage
Adjustable handle increases
operator comfort
Simple foot pedal for squeegee engagement
Balanced wide stance
ensures easy maneuverability
*VL500-75 shown
Unique lter system protects the motor from water, while ensuring complete wet and dry ltration. It is designed with the following components:
• Dry cartridge lter keeps water away from the motor and is waterproof and washable for increased durability
• Red panel holds oater and prevents water overow
• Blue panel mesh wet lter
dissipates foam
The VL500-75 features an easily adjustable handle to match operator height and maximize comfort.
Front-mount squeegee is easy to install, and enables easy cleaning in both forward and backward directions. With a break­away design, the squeegee can be quickly engaged via the foot pedal.
* Standard on VL500-75; optional on VL500-55; not available on VL500-35.
Hinged-motor head on the VL500-75 quickly lifts off for machine cleaning or maintenance.
The VL500-75 and patent pending ERGO “tip n pour” design allows operators to easily empty the tank with 80% reduced effort. Standard “tip n pour” is available on the VL500-55 model.
The VL500 series features a variety of standard and optional accessories, including: hose, wand, squeegee oor tool, brush oor tool, crevice tool, dusting tool and front-mounted squeegee.
Technical Specifications
Model VL500™ 35 VL500™ 55 VL500™ 75
Power 120 V / 60 Hz Power Cord Length 50 ft (15 m) Power PMAX 1,100 W Suction Power End of Tube 220 W 185 W Airflow 101 CFM (45 L/Sec) 101 CFM (48 L/Sec) 101 CFM (48 L/Sec) Vacuum at Nozzle 72 inches of H2O (20 kPa) 72 inches of H2O (18 kPa) 72 inches of H2O (18 kPa) Sound Pressure Level 81 dB A 82 dB A Tank Capacity 9 gal (35 L) 14 gal (55 L) 19 gal (75 L) Dust Bag Capacity – Dry 4 gal (18 L) 6 gal (28 L) 9 gal (44 L) Wet Filter Area 163 in2 (1,051 cm2) 285 in2 (1,840 cm2) Cartridge Filter Area 321 in2 (2,070 cm2) 683 in2 (4,410 cm2) Hose Length 6 ft (1.9 m) 8 ft (2.5 m) Hose Inlet ~1.25 in (32 mm) Length x Width x Height 19 in x 17 in x 29 in
(46 cm x 42 cm x 73 cm) Weight 25 lb (11.5 kg) 52 lb (23.5 kg) 61 lb (27.5 kg) Tube Holder included included included Drain Hose included included Accessory Storage included included included Adjustable Handle included Folding Transport Handle included Dust Filter System included included included Ergo Tip Design included Part Number 107409094 107409093 56383408
Specifications are subject to change without notice.
34 in x 24 in x 40 in
(84 cm x 62 cm x 100 cm)
~
1.5 in (40 mm) 26 in x 24 in x 41 in
(66 cm x 62 cm x 103 cm)
Productivity
With superior flexibility, high power and cost-efficient performance, the VL500™
series exceeds the cleaning expectations of the wet/dry vacuum market.
Accessories and options
• Squeegee Complete
(Standard on VL500-75; optional on VL500-55;
not available on VL500-35.)
• Floor Nozzle Rubber Strip
• Floor Nozzle Brush
• Crevice Tool
• Extension Tube / Wand
• Hose
• Cartridge Filter
• Wet Filter
• Tubeholder
Smart cleaning.
Our products are designed using innovative
technologies that increase productivity and
drive down the cost to clean.
Maintain peak performance with Nilfisk
Genuine OEM Parts.
SNAP
IT!
14600 21st Avenue North
Plymouth, MN 55447-3408
www.advance-us.com
Phone 800-850-5559 Fax 800-989-6566
240 Superior Boulevard Mississauga, Ontario, Canada L5T 2L2
www.nilfisk-advance.ca
Phone 800-668-8400 Fax 800-263-5111
©2013 Nilfisk-Advance, Inc. Form L3316A 9-9-13
