Nilfisk PM-6 DRAGONFLY User Manual

PM-6
User's Manual
6-CHANNEL MIXING CONSOLE
DRAGONFLY
WITH DIGITAL EFFECTS
LTO
www.altoproaudio.com
Version 1.1 April 2005
R
SAFETY RELATED SYMBOLS
CAUTION
RISK OFELECTRIC SHOCK
DO NOTOPEN
This symbol, wherever used, alerts you to the pre­sence of un-insulated and dangerous voltages with­in the product enclosure. These are voltages that may be sufficient to constitute the risk of electric shock or death.
This symbol, wherever used, alerts you to impo­rtant operating and maintenance instructions. Please read.
Protective Ground Terminal
AC mains (Alternating Current)
Hazardous Live Terminal
ON: Denotes the product is turned on.
OFF: Denotes the product is turned off.
WARNING
Describes precautions that should be observed to prevent the possibility of death or injury to the user.
CAUTION
Describes precautions that should be observed to prevent damage to the product.
WARNING
Power Supply
Ensure that the mains source voltage (AC outlet) matches the voltage rating of the product. Failure to do so could
result in damage to the product and possibly the user. Unplug the product before electrical storms occur and when unused for long periods of time to reduce the risk of
electric shock or fire.
External Connection
Always use proper ready-made insulated mains cabling (power cord). Failure to do so could result in shock/death or fire. If in doubt, seek advice from
a registered electrician.
the recommended fuse type as indicated in this manual. Do not short-circuit the fuse holder. Before replacing the fuse, make sure that the product is OFF and disconnected from the AC outlet.
Protective Ground
Before turning the product ON, make sure that it is connected to Ground. This is to prevent the risk of electric shock.
Never cut internal or external Ground wires. Likewise, never remove Ground wiring from the Protective Ground Terminal.
Operating Conditions
Always install in accordance with the manufacturer's instructions.
To avoid the risk of electric shock and damage, do not subject this product to any liquid/rain or moisture. Do not use this product when in close proximity to water.
Do not install this product near any direct heat source.
Do not block areas of ventilation. Failure to do so could result in fire.
Keep product away from naked flames.
IMPORTANT SAFETY INSTRUCTIONS
Read these instructions
Follow all instructions
Keep these instructions. Do not discard.
Heed all warnings.
Only use attachments/accessories specified by the manufacturer.
Power Cord and Plug
Do not tamper with the power cord or plug. These are designed for your safety.
Do not remove Ground connections!
If the plug does not fit your AC outlet seek advice from a qualified electrician.
Protect the power cord and plug from any physical stress to avoid risk of electric shock.
Do not place heavy objects on the power cord. This could cause electric shock or fire.
Do Not Remove Any Covers
Within the product are areas where high voltages may present. To reduce the risk of electric shock do not remove any covers unless the AC mains power cord is removed.
Covers should be removed by qualified service personnel only.
No user serviceable parts inside.
Fuse
To prevent fire and damage to the product, use only
Cleaning
When required, either blow off dust from the product or use a dry cloth.
Do not use any solvents such as Benzol or Alcohol. For safety, keep product clean and free from dust.
Servicing
Refer all servicing to qualified service personnel only. Do not perform any servicing other than those instructions contained within the User's Manual.
1
PREFACE
Dear Customer:
Thank you for choosing the LTO PM-6 DRAGONFLY 6-Channel Mixing Console with Digital Effects, which is the result of our
AUDIO TEAM's endeavours.
LTO
For the LTO AUDIO TEAM, music and audio are more than a profession, it is a passion and an obsession!
We have, in fact, been designing professional audio products for a number of years in cooperation with many of the world's major brands. The LTO line represents unparalleled analogue and digital products made by musicians, for musicians. With our design centres in Italy, the Netherlands, and the United Kingdom we provide you with world-class designs, while our software development teams continue to develop an impressive range of audio specific algorithms.
By purchasing our LTO products you become the most important member of our LTO AUDIO TEAM. We would like to share with you our passion for what we design and invite you to make suggestions, which will aid us in develop­ing future products for you. We guarantee you our commitment for quality, continual research and development, and of course the best prices.
The LTO PM-6 is an extremely flexible, ultra-low noise 6-Channel Mixing Consol with Digital Effects, which is the smallest among our range of mixing consoles with digital effects. It is configured with 2 mono and 2 stereo input channels, each channel is equipped with a variety of key features including a warm, natural sounding EQ, Peak LED and PAN/BAL control etc..seeing is believing, let's meet the LTO PM-6
We would like to thank all the people who made the LTO PM-6 DRAGONFLY 6-Channel Mixing Console with Digital Effects possible, especially to our designers and LTO staff. It is their passion for music and professional audio that has made it possible for us to offer you, our most important team member, our continued support.
Thank you very much
LTO AUDIO TEAM
2
TABLE OF CONTENTS
1. ...................................................................................................................................4INTRODUCTION
2. FEATURES............................................................................................................................................4
3. READY TO .............................................................................................................................START ...4
4. ..........................................................................................................................7CONTROL ELEMENTS
5. INSTALLATION AND CONNECTION..................................................................................................12
6. FOR THE EXPERTS WHO WANTS TO KNOW MORE.......................................................................14
7. PRESET LIST ....................................................................................................................................15
8. BLOCK DIAGRAM...................................................................... ........................................16...............
9. TECHNICAL SPECIFICATION.............................................................................................................17
10. WARRANTY......................................................................................................................................18
3
1. INTRODUCTION
Thank you very much for expressing your confidence in LTO products by purchasing PM-6 DRAGONFLY 6-Channel
Mixing Console with Digital Effects. The PM-6 is a professional compact mixer, which Provides the state of the art digital amplifier technology specifically. You will get the smooth, accurate more natural and open sound from this apparatus, and it is really ideal for small gigs, recording and fixed PA installations. The PM-6 DRAGONFLY 6-Channel Mixing Console with Digital Effects is packed with features that can not be found in other consoles of it size: 2 mono (these are provided With ultra low noise microphone preamplifiers and Phantom Power at +18 Volt) and 2 stereo input channels, and each of them is provided with a 3 bands equalizer for HI, MID and LOW controls; built-in high efficiency power amplifier and effects processor; highly accurate 6-segment bar graph meters and 2-Track inputs assignable to main mix, control room / headphone outputs. Your PM-6 DRAGONFLY is very easy to operate but we advise you to go through each section of this manual carefully. In this way you will get the best out of your PM-6 DRAGONFLY.
2. FEATURES
The PM-6 DRAGONFLY 6-Channel Mixing Console with Digital Effects is designed for professional application. It provides the following features:
Built-in high efficiency power amplifier and digital effects processor 2 MIC input channels with gold plated XLR and balanced LINE inputs 2 stereo input channels with balanced TRS jacks Ultra-low noise discrete MIC pre-amps with +18V phantom power Extremely high headroom offering more dynamic range Warm, natural 3-band EQ on each channel Peak LED on each channel
AUX control per channel for external and internal onboard effect. 2-Track inputs assignable to main mix, control room / headphone outputs Highly accurate 6-segment bar graph meters DYNAMIC POWER:2 80W@4Ohm
3. READY TO START
3.1 There is a small black box provided with your PM-6 DRAGONFLY. This is the specific power supply box. Connect the proper terminal into your PM-6 DRAGONFLY and the power supply box into an AC socket.
3.2 Be sure the main power switch is turned off before connecting the Mixer to the power supply box. Also, you should
make Sure that all Input and Output Controls are turned down. This will avoid damages to your speakers and avoid excessive noise.
3.3 Before connecting and disconnecting the power supply box always turn off your external power amplifier (if used in a sound system).
3.4 Do not use solvents to clean your PM-6 DRAGONFLY. A dry and clean cloth will be OK.
4
3.5 Possible System Connection Mode for Live Sound Application
Passive Speakers
LR
Control Room Monitor
THIS CONNECTION FOR ALTO POWER SUPPLYONLY!
POWER IN
LR
Vocal MIC
Other
line level signal
LEFT
RIGHT
SPEAKERS
TIP
SLEEVE
ATTENTION! MIN. LOAD 4
Effect Equipment
MIC 1
12
3
BAL OR UNBAL
LINE IN 1
TRIM
+15dB -30dB LINE
0dB 44dB MIC
DYNAMIC POWER: 2 80W@4
MIC 2
12
3
BAL OR UNBAL
LINE IN 2
TRIM
+15dB -30dB LINE
0dB 44dB MIC
MODEL
SERIAL
WARNING: SHOCK HAZARD AVIS:RISQUE DE CHOC ELECTRIQUE
CAUTION:
REPLACE WITH THE SAMETYPE FUSEAND RATING DISCONNECT SUPPLY CORD B EFORE CHANGING FUSE
STEREO AUX RETURNS
LEFT
LINE IN 3/4
LEFT (MONO)
RIGHT
CAUTION
RISKOF ELECTRIC SHOCK
DONOT OPEN
-DO NOT OPEN
AUX SENDS
PHONES
LINE IN 5/6
LEFT (MONO)
RIGHT
-NE PAS OUVRIR
CONTROL ROOM OUTPUT
LEFT
RIGHTRIGHT
MAIN MIX OUTPUT
LEFT
RIGHT
LTO
PM-6
6-CHANNEL MIXING CONSOLE
WITH DIGITAL EFFECTS
R
2-TRACK IN/OUT
L
POWER AMP
R
TAPE IN
TAPE OUT
PHANTOM PWR
LR
Amplifier
LR
Headphone
onoff
CD Player or
Cassette Deck etc.
0
12kHz
+15+15-15-15
0
2.5kHz
+12-12
0
+15+15-15-15
0
AUX
D F X
POST (PRE)
8
-+15
PAN
LEFT
RIGHT
PEAK
8
-+10 -+108-+108-+10
LEVEL
EQ
MID
LOW 80Hz
HI
0
0
0
0
D F X
8
-+15
LEFT
LEVEL
+15+15-15-15
+12-12
+15+15-15-15
RIGHT
EQ
12kHz
MID
2.5kHz
LOW 80Hz
AUX
POST (PRE)
PAN
PEAK
HI
0
0
0
0
D F X
8
-+15
LEFT
LEVEL
+15+15-15-15
+12-12
+15+15-15-15
RIGHT
EQ
12kHz
MID
2.5kHz
LOW 80Hz
AUX
POST (PRE)
BAL
PEAK
HI
0
0
0
0
D F X
8
-+15
LEFT
8
LEVEL
+15+15-15-15
+12-12
+15+15-15-15
RIGHT
12 5/63/4
EQ
15
14
HI
13
12kHz
12
11
MID
2.5kHz
LOW 80Hz
FX LEVEL REVERB LEVEL
AUX
POST (PRE)
-+15
AUX RTN (DFX)
BAL
-
PEAK
-
PHONES /
CONTROL ROOM
5
1
16
10
9
PRESETS
0
0
8
0
8
2TK IN
8
LR
2
1 VIBRAFLANGE
3
2 FUNKY 3 ROCKABILLY
4
4 BIGSTAGE
5
5
VIBRATO
8
6
9
7
8
10
FLANGER
12 13
CHORUS
16
100
PEAK
Amplifier
LR
POWERPHANTOMPHANTOM
CLIP
2TK TO
CTRL ROOM
2TK TO MIX
MAX
MAX
10
0
-4
-10
-30
L
R
OUTPUT LEVEL
0
8
-+10
MAIN MIX
LEVEL
4. CONTROL ELEMENTS
MIC 1
12
3
BAL OR
UNBAL
LINE IN 1
TRIM
+15dB -30dB LINE
0dB 44dB MIC
0
EQ
12kHz
+15+15-15-15
0
MID
2.5kHz
+12-12
0
HI
MIC 2
12
3
BAL OR UNBAL
LINE IN 2
TRIM
+15dB -30dB LINE
0dB 44dB MIC
0
EQ
12kHz
+15+15-15-15
0
MID
2.5kHz
+12-12
0
STEREO AUX RETURNS
LEFT
LINE IN 3/4
LEFT (MONO)
RIGHT
0
HI
0
0
AUX SENDS
PHONES
CONTROL ROOM OUTPUT
LEFT
LTO
PM-6
R
6-CHANNEL MIXING CONSOLE
WITH DIGITAL EFFECTS
RIGHTRIGHT
LINE IN 5/6
MAIN MIX OUTPUT
2-TRACK IN/OUT
L
LEFT (MONO)
RIGHT
EQ
HI
12kHz
+15+15-15-15
MID
2.5kHz
+12-12
0
+15+15-15-15
0
+12-12
0
EQ
HI
12kHz
MID
2.5kHz
LEFT
RIGHT
14
13
12
16
15
11
10
PRESETS
1
9
R
TAPE IN
2
3
4
6
7
8
5
TAPE OUT
1 VIBRAFLANGE 2 FUNKY 3 ROCKABILLY 4 BIGSTAGE 5
VIBRATO
8 9
FLANGER
12 13
CHORUS
16
LOW
80Hz
+15+15-15-15
0
D
F
X
8
-+15
AUX
POST (PRE)
D F X
8
-+15
PAN
LEFT
RIGHT
PEAK
-+108-+108-+108-+10
LEVEL
LEFT
LEVEL
0
+15+15-15-15
RIGHT
LOW 80Hz
AUX
POST (PRE)
PAN
PEAK
+15+15-15-15
0
D F X
8
-+15
LEFT
RIGHT
LEVEL
LOW
80Hz
AUX
POST (PRE)
BAL
PEAK
+15+15-15-15
0
D F X
8
-+15
LEFT
RIGHT
8
LEVEL
1 2 5/63/4
LOW
80Hz
AUX
POST (PRE)
BAL
PEAK
10
0
FX LEVEL REVERB LEVEL
0
8
-+15
8
-
MAX
PHONES /
CONTROL ROOM
100
PEAK
POWERPHANTOMPHANTOM
CLIP
10
0
-4
-10
-30
L
OUTPUT LEVEL
0
8
-+10
MAIN MIX
LEVEL
R
4.1 The MONO MIC/LINE CHANNELS
1
These are Channel 1 and Channel 2. You can connect a balanced, low impedance microphone to the XLR socket. ON the 1/4" phone jack you can
connect either a microphone or a line level instrument. You shall never connect an unbalanced microphone to the XLR socket if you do not want to damage both the Microphone and the Mixer.
18 Volt Phantom power
It is available only to the XLR input sockets. Do not connect non­phantom equipment to the MIC input when phantom power is on. Before turning phantom power on, make sure that all faders are all the way down. In this way you will protect your stage monitors and main loudspeakers.
MIC 1
3
12
BAL OR
UNBAL
1
4.2 INPUT LEVEL SETTING
2
This control is provided with 2 different indication rings: one is for the microphone and the other for the LINE input. When you use a Microphone you shall read the OUTSIDE ring (0~44dB); when you use a line level instrument you shall read the INSIDE ring (+1 ~-305
optimum operation you shall set this control in a way thatdB). For
LED will blink only occasionally in order to avoid distortionthe PEAK
input channel.on the
4.3 STEREO INPUT
3
These are channel 3 though 6 . They are organised in stereo pair and provided with 1/4"TRS phone sockets. If you connect only the left jack, the input will operate in mono mode.
LINE IN 3/4
LEFT (MONO)
RIGHT
LINE IN 1
TRIM
+15dB -30dB LINE
0dB 44dB MIC
LINE IN 5/6
LEFT (MONO)
RIGHT
2
3
7
4.4 3-BAND EQUALIZER
3-band equaliser is provided for all input channels with a wide range of frequency adjustment.
-HI
4
This is the treble control. You can use it to get rid of high frequency noises or to boost the sound of cymbals or the high harmonics of the human voice. The gain range goes from -15dB to +15dB with a center frequency of 12kHz.
- MID
5
This is the midrange control. It can affect most fundamental frequencies of all musical instruments and human voice. An attentive use of this control will give you a very wide panorama of sound effects. The gain range goes from -12dB to +12dB and the center frequency is 2.5kHz.
- LOW
6
This is the bass control. Boost male voice or kickdrum and bass guitar. Your system will sound much bigger than what it is. The gain range goes from -15dB to +15dB and the center frequency is 80Hz.
4.5 AUX
7
This control is used to adjust the level of respective channel signal sent to the Auxiliary Bus. The configuration is post-fader so the signal sent to the AUX Bus will be affected by the LEVEL control of that particular channel. In this typical compact unit, the channel signal is not only assigned to external effect or processor equipment directly but also to internal onboard effect module.
0
EQ
HI
12kHz
+15+15-15-15
0
MID
2.5kHz
+12-12
0
LOW 80Hz
+15+15-15-15
4
5
6
Note: There is the possibility to configure this AUX Send as Pre-fader as we will explain later in this manual.
4.6 PAN
8
This is the PANORAMA control, or balance control. You can adjust the stereo image of the signal via this control. Keep this control in center position and your signal will be positioned in the middle of stage. Turn this control fully counterclockwise and the signal will be present only on the left speaker and vice-versa. Of course a large number of intermediate positions is available.
4.7 PEAK LED
9
Inside your mixer the audio signal is monitored in several different stages and then sent to the PEAK LED. When this LED blinks, it warns you that you are reaching signal saturation and possible distortion. The PEAK LED will blink with a level that is 6dB before actual clipping.
0
D F X
8
-+15
LEFT
RIGHT
88
-+10
LEVEL
1
AUX
POST (PRE)
PAN
PEAK
7
8
9
10
4.8 LEVEL
10
This control will adjust the overall level of this channel and set the amount of signal sent to the Main output.
8
4.9 MASTER SECTION
- MAIN MIX LEVEL
11
This control sets the amount of signal simultaneously sent to the MAIN MIX OUTPUT and TAPE OUT.
- PHONES/CONTROL ROOM
This control sets the amount of signal simultaneously sent to the CONTROL ROOM OUTPUT and PHONES.
- LED METER
13
This stereo 6 segments LED Meter will indicate the signal level sent to CONTROL ROOM and PHONES outputs.
- 2-TRACK signal path
14
If you push down the 2TK TO CONTROL ROOM button, the 2 TRACK IN signal will be routed into the CONTROL ROOM OUTPUT and the level will be adjusted by the PHONES/CONTROL ROOM knob. If you push down the 2TR TO MIX button, the 2 TRACK IN signal will be routed into the MAIN MIX OUTPUT and will be adjusted by the MAIN MIX LEVEL knob.
12
16
15 17
0
8
-+15
AUX RTN (DFX)
8
-MAX 2TK IN
8
-
MAX
2TK TO
CTRL ROOM
2TK TO MIX
PHONES /
CONTROL ROOM
12
14
L
OUTPUT LEVEL
-+10
MAIN MIX
LEVEL
CLIP
10
0
-4
-10
-30
0
8
11
18
POWERPHANTOMPHANTOM
13
R
Note: you can push down these two buttons simultane­ously, the 2 TRACK IN signal will be routed into both CONTROL ROOM OUTPUT and MAIN MIX OUTPUT, and the level of two output signals will be adjusted by respective control knob.
- AUX RTN
15
This control is used to adjust the level of signal coming from external/internal effect processor. The signal of AUX RETURN will be sent to MAIN MIX OUTPUT.
- 2TK IN
16
This control is used to adjust the level of 2TK IN, which can be varied form - to MAX.
- PHANTOM LED
17
This LED indicates when the PHANTOM POWER is switched on.
the
- POWER LED
18
This LED indicates when the Power is on in your PM-6 DRAGONFLY.
9
- 24 BIT DIGITAL EFFECTS
- PRESETS
19
Adjust this knob to select the right effect you wish to perform. There are total 16 options for you: Vibraflange, Funky, Rockabilly, Bigstage, Vibrato, Flanger and Chorus etc.
19
20
14
13
12
16
15
11
10
PRESETS
1
2
3
4
5
6
7
8
9
1 VIBRAFLANGE 2 FUNKY 3 ROCKABILLY 4 BIGSTAGE 5
VIBRATO
8 9
FLANGER
12 13
CHORUS
16
- FX LEVEL control
20
10
0
FX LEVEL REVERB LEVEL
100
PEAK
This control is used to adjust the output level of FX signal, which can be varied from 0dB to 10dB.
21 22
- REVERB LEVEL control
This control is used to adjust the output level of REVERB signal, which can be varied from 0dB to 10dB.
- PEAK LED
22
This LED lights up when the input signal is too strong.
- MAIN MIX OUTPUT
This stereo output is controlled by the MAIN MIX LEVEL and will send the audio signal to an external amplifier. The output level can be varied from ­to +1 dB
23
21
MAIN MIX OUTPUT
LEFT
2-TRACK IN/OUT
L
R
POWER AMP
277
onoff
- 2-TRACK IN/OUT
TAPE IN
24
RIGHT
TAPE IN
TAPE OUT
PHANTOM PWR
Use the Tape input if you wish to listen to your mixer from a Taper Recorder or DAT. You can send the signal coming form the Taper Recorder(or DAT) either to CONTROL ROOM
23
24
25
26
OUTPUT and/or to the MAIN MIX OUTPUT by using relative 2TK TO select button.
TAPE OUT
25
These RCA jacks will route the main mix signal into a tape recorder.
- PHANTOM PWR
26
This switch is used to apply +18 Volt Phantom Power only to the 2 XLR inputs sockets. When these sockets are connected with devices that do not require Phantom Power,
Please make sure the Phantom Power is turned off,
otherwise, this may damage the device and mixer.
- POWER AMP
27
This control is used to turn ON or OFF the built-in power amplifier.
10
STEREO AUX RETURNS
AUX SENDS
CONTROL ROOM OUTPUT
R
LEFT
PHONES
LEFT
RIGHTRIGHT
LTO
PM-6
6-CHANNEL MIXING CONSOLE
WITH DIGITAL EFFECTS
28 29 30 31
- STEREO AUX RETURNS
Use these stereo 1/4" phone sockets to return the sound of an effect unit to the Main Mix. Alternatively you can use them as an extra auxiliary input.
- AUX SENDS
29
This 1/4" phone socket is used to send out the signal from the AUX bus to external devices such as effects and sound processors.
28
- PHONES
This socket will be used to send the signal to a headphone.
- CONTROL ROOM OUTPUT
These 1/4" phone sockets will be used to send the signal to Studio Monitor speakers or to a second set of PA.
4.10 REAR PANEL
THIS CONNECTION FOR ALTO POWER SUPPLY ONLY!
30
POWER IN
32
33
LEFT
RIGHT
SPEAKERS
31
TIP
SLEEVE
DYNAMIC POWER: 2 80W @4
MODEL
SERIAL
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: SHOCK HAZARD AVIS: RISQUE DE CHOC ELECTRIQUE
- DO NOT OPEN
- NE PAS OUVRIR
CAUTION:
REPLACE WITH THE SAME TYPE FUSE AND RATING DISCONNECT SUPPLY CORD BEFORE CHANGING FUSE
- POWER IN
32
Used to connect the power supply box.
- SPEAKER OUTPUT
33
These 1/4" phone sockets are used to connect passive speakers directly, only these output signals through
SPEAKER OUTPUT sockets are amplified by built-in power amplifier.
11
4.11 The Power Supply Box
37 36 35
ON
DC OUTPUT
- POWER CORD
OFF
POWER
34
34
AC INPUT 210-240V 50Hz POWER CONSUMPTION 130W
You can connect the plug of POWER CORD to the mains. Please check the voltage accepted by the unit and the voltage available from your AC sockets before connecting the unit to the mains.
- DC OUTPUT
35
You can connect the cable from DC OUTPUT to POWER IN on rear panel. Thus, the power supply box will provide
±24V DC voltage to your mixing console.
- POWER Switch
This switch turns the Mixing console ON and OFF. When you turn on the Mixing console, both the power indicator
In the box and the power indicator(18) on the panel will light on.
-FAN
37
The fan can accelerate the flow of air to lower the temperature inside power supply. The inside temperature determines the fan speed which controls the inside air flowing speed.
36
12
5. INSTALLATION AND CONNECTION
Ok, you have got to this point and you are now in the position to successfully operate your PM-6 DRAGONFLY. However, we advise you to read carefully the following section to be the real master of your own Mixer. Not paying enough attention to the input signal level, to the routing of the signal and the assignment of the signal will result in unwanted distortion, a corrupted signal or no sound at all. So you should follow these procedures for every single channel:
1). Before connecting mics or instruments, make sure that the power of all your systems components including the mixer is turned off. Also, make sure that all input and output controls are turned down. This will avoid damage to your speakers and excessive noise.
2). Properly connect all external equipments such as microphone, power amplifier, speakers etc.
3). Now, turn on the power of any peripheral devices, then connect the 24V DC power supply box to the mixer and main power.
Note: the power amplifier or powered monitors shall be turned on after the mixer and off before the mixer.turned
4). Set the output level of your mixer or the connected power amplifier at no more than 75%.
5). Set the CONTROL ROOM/PHONE level at no more than 50%.
6). Position HI, MID and LOW EQ controls on middle postion.
7). Position panoramic (PAN/BAL) control on center position.
8). While speaking into the mic(or playing the instrument), adjust the channel Level control so that the PEAK LED
will blink occasionally, in this way you will maintain good headroom and ideal dynamic range.
9). You can shape the tone of each channel by adjusting the equalizer controls as desired.
10). Now repeat the same sequence for all input channels. The Main LED Meter could move up into the red section. in this case you can adjust the overall output level through the MAIN MIX control.
±
13
5.1. Some Final Tips on Wiring Configuration
You can connect unbalanced equipment to balanced inputs and outputs. Simply follow these schematics.
Strain Clamp
Strain Clamp
Sleeve
Tip
Ring
Sleeve=Ground/Screen
Use for Headphone, Stereo Return
Ring=Right Signal
1/4" Stereo (TRS) Jack Plug
Sleeve
Use for Mono Line In, Mono 1/4"Jack Plugs
Tip
Sleeve=Ground/Screen
1/4" Mono (TS) Jack Plug
Tip=Left Signal
Tip=Signal
2
2=Hot(+)
Use for Balanced Mic Inputs
(For unbalanced use, connect pin 1 to 3)
1
3
3=Cold(-)
1=Ground/Screen
3-pin XLR Male Plug
(seen from soldering side)
2
2=Hot(+)
Use for Main output
(For unbalanced use, leave pin 3 unconnected)
3
3=Cold(-)
1
1=Ground/Screen
3-pin XLR Line Socket
(seen from soldering side)
14
6. FOR THE EXPERTS WHO WANTS TO KNOW MORE
As we have told you previously in this manual, the Aux Send Control both on mono and stereo channels is factory wired as POST-FADER. If you are skilled in electronic components soldering you can modify this setting and have all your AUX sends configured as PRE-FADER.
(PRE)
POST
Aux
(PRE)
Disconnect the POST route
POST
Before
Modification on mono and stereo channels
Aux
Solder the PRE route
After
15
7. PRESET LIST
No. Preset
VibraFlange
1
Funky
2
Rockabilly
3
Big stage
4
5
Vibrato 4
6
Vibrato 3
7
Vibrato 2
8
Vibrato 1
Description
Slight pitch variation with Flanger effect.
Large pitch variation with heavy Flanger effect.
Simulate a stage space with slight Flanger effect
Simulate a stage space of the sound.
Slight variation of pitch resulting from the free oscillation of the vocal cords.
Slight variation of pitch resulting from the free oscillation of the vocal cords.
Slight variation of pitch resulting from the free oscillation of the vocal cords.
Slight variation of pitch resulting from the free oscillation of the vocal cords.
parameter
Mod Level : 90%
Mod Level : 68%
Rate : 0.1 Hz
Decay time : 5.4s
Rate : 4.8 Hz
Rate : 3.8 Hz
Rate : 3.0 Hz
Rate : 2.0 Hz
9
10
11
12
13
14
15
16
Flanger 4
Flanger 3
Flanger 2
Flanger 1
CHORUS 4
CHORUS 3
CHORUS 2
CHORUS 1
Simulate to play with another person carrying out same the notes on the same instrument
Simulate to play with another person carrying out same the notes on the same instrument
Simulate to play with another person carrying out same the notes on the same instrument
Simulate to play with another person carrying out same the notes on the same instrument
Recreate the illusion of more than one instrument from a single instrument sound
Recreate the illusion of more than one instrument from a single instrument sound
Recreate the illusion of more than one instrument from a single instrument sound
Recreate the illusion of more than one instrument from a single instrument sound
Rate : 4.9 Hz
Rate : 3.21 Hz
Rate : 0.9 Hz
Rate : 0.56 Hz
Rate : 3.6 Hz
Rate : 1.79 Hz
Rate : 0.82 Hz
Rate : 0.39 Hz
16
8. BLOCK DIAGRAM
17
9. TECHNICAL SPECIFICATION
Mono input channels
Stereo input channels
Impedances
Equalization
DSP SECTION
Microphone input
Frequency response
Distortion (THD & N)
Gain range 0dB to 44dB (MIC) SNR (Signal to Noise Ratio)
Line input
Frequency response
Distortion (THD & N)
Sensitivity range Line input
Frequency response
Distortion (THD & N)
Microphone input
All other inputs
Tape out
All other output
Hi shelving
Mid bell
Low shelving
A/D and D/A converters
DSP resolution
Type of effects
electronically balanced, discrete input configuration
10Hz to 55kHz, + 3dB
0.005% at 4dBu, 1kHz+
>100dB
electronically balanced
10Hz to 55kHz, 3dB
0.005% at 4dBu, 1kHz+
+
15dBu to +/ 30dBu Balanced 10Hz to 55kHz, 3dB
0.005% at +4dBu, 1kHz
1.4kOhm
+
+
10kOhm or greater
1kOhm
120Ohm
+
15dB @12kHz
12dB @2.5kHz
+
15dB @80Hz
+
24 bit
24 bit
Vibraflange, Funky, Rockabilly, Bigstage, Vibrato 1-4
Flanger 1-4, Chorus 1-4
Main Mix Section
Power AMP section
Power supply (AC/DC)
Physical
Presets
Controls
Noise (Bus noise)
Max output
AUX Returns gain range
AUX Sends max out
Power AMP
output(Dynamic Power)
Main voltage
Max Power Consumption
Dimension (W D H)
Net weight(with power supply)
Shipping weight 3.49kg (7.70 lb)
16
16-position PRESET Selector, FX level, REVERB
level, CLIP LED
Fader 0 dB, channels muted: 100dBr (ref.:+4dBu)
Fader 0dB, all input and set to UNITY gain: -90dBr
(ref.: +dBu) channels assigned
+22dBu unbalanced, 1/4" jacks
- to +15dB
+22dBu
2 80W@4Ohm
USA/Canada 100 - 120V ~, 60Hz
Europe 210 - 230V ~, 50Hz
U.K./Australia 240V ~, 50Hz 130 watts
185mm 247mm 72mm
2.95kg (6.50 lb)
18
10. WARRANTY
1. WARRANTY REGISTRATION CARD
To obtain Warranty Service, the buyer should first fill out and return the enclosed Warranty Registration Card within 10 days of the Purchase Date.
All the information presented in this Warranty Registration Card gives the manufacturer a better understanding of the sales status, so as to purport a more effective and efficient after-sales warranty service.
Please fill out all the information carefully and genuinely, miswriting or absence of this card will void your warranty service.
2. RETURN NOTICE
2.1 In case of return for any warranty service, please make sure that the product is well packed in its original shipping carton, and it can protect your unit from any other extra damage.
2.2 Please provide a copy of your sales receipt or other proof of purchase with the returned machine, and give detail
information about your return address and contact telephone number.
2.3 A brief description of the defect will be appreciated.
2.4 Please prepay all the costs involved in the return shipping, handling and insurance.
3. TERMS AND CONDITIONS
3.1 warrants that this product will be free from any defects in materials and/or workmanship for a period
LTO
of 1 year from the purchase date if you have completed the Warranty Registration Card in time.
3.2 The warranty service is only available to the original consumer, who purchased this product directly from the
retail dealer, and it can not be transferred.
3.3 During the warranty service, may repair or replace this product at its own option at no charge to you for
LTO
parts or for labor in accordance with the right side of this limited warranty.
3.4 This warranty does not apply to the damages to this product that occurred as the following conditions:
Instead of operating in accordance with the user's manual thoroughly, any abuse or misuse of this product.
Normal tear and wear.
The product has been altered or modified in any way.
Damage which may have been caused either directly or indirectly by another product / force / etc.
Abnormal service or repairing by anyone other than the qualified personnel or technician.
And in such cases, all the expenses will be charged to the buyer.
3.5 In no event shall be liable for any incidental or consequential damages. Some states do not allow the exclu-
LTO
sion or limitation of incidental or consequential damages, so the above exclusion or limitation may not apply to you.
3.6 This warranty gives you the specific rights, and these rights are compatible with the state laws, you may also
have other statutory rights that may vary from state to state.
19
SEIKAKU TECHNICAL GROUP LIMITED
SEKAKU ELECTRON INDUSTRY (H.K.) CO., LTD.
No. 1, Lane 17, Sec. 2, Han Shi West Road, Taichung 40151, Taiwan
http://www.altoproaudio.com Tel: 886-4-22313737
email: alto@altoproaudio.com Fax: 886-4-22346757
All rights reserved to ALTO. All features and content might be changed
without prior notice. Any photocopy, translation, or reproduction of part of this
c
manual without written permission is forbidden. Copyright
2005 SEIKAKU GROUP
NF02047-1.0
Loading...
