Netgear MR1100EE Data Sheet
Nighthawk® Mobile Hotspot Router Data Sheet
Introducing the World’s First Gigabit Class LTE Mobile Hotspot Router
Advance the way you WiFi on-the-go – the Nighthawk Mobile Hotspot Router by
NETGEAR is the world’s first commercial Gigabit Class LTE Mobile Hotspot Router
to achieve maximum download speeds of 1 Gbps, bringing our mobile broadband
experience to unparalleled new heights. Combining ultrafast download speeds,
support for Cat. 16 LTE Advanced and 4-band Carrier Aggregation into one
device, this premium Mobile Hotspot Router provides the best Internet connection
experience possible whether it is used on-the-go, at home, or during your travels.
As an ultimate Mobile Hotspot Router fit for travels, the Nighthawk Mobile Hotspot
Router can provide a secure LTE connection to share with up to 20 WiFi devices in
your family, stream and play multimedia to keep everyone entertained, and work as
a portable base station with Arlo security cameras to monitor your surroundings at
Key Features and Benefits
• Always-on connection you can count
on and share with up to 32 WiFi devices
on-the-go
• Supports LTE CAT 16, LTE Advanced
4-band Carrier Aggregation, 4x4 MIMO,
256QAM
• Increase network performance and
reduce interference with 802.11ac and
Dual-Band 2.4GHz/5GHz dual concurrent
WiFi
• Media Streaming from microSD, USB
or external hard drive to all connected
devices
• Supports the Arlo Smart Home Security
System as the base station for
Arlo camera
• Travel Router with WiFi/Ethernet
ooading capabilities
• Superfast Mobile Broadband Internet to
deliver incredible download speeds up to
1 Gbps and upload speeds up to 150Mbps
• Parental controls to protect or guard
access to online content
• Simple, intuitive NETGEAR app-driven
user experience to monitor data usage,
manage device and network settings
• Powerful, long-lasting battery for all day
continuous use
• Improved JumpBoost feature to charge
smartphones and small portable USB
devices
• Two TS-9 connectors available for
optional 4G/3G antennas
• Simple setup with no soware to
install – just power on and connect
any destination. With a simple and intuitive app-driven user experience, parental
control options, an improved JumpBoost feature and a long-lasting battery for all day
continuous use, the Nighthawk Mobile Hotspot Router meets Gigabit LTE class at its
fullest potential, and delivers a mobile broadband experience like never before.
Technical Specifications
Technology/Bands
• Max 1 Gbps download speeds, and 150
Mbps upload speeds
• LTE CAT 16, 4-band CA and 4x4 MIMO
• Up to 4X Carrier Aggregation and support
for LAA in future firmware upgrades
• LTE: 1, 3, 7, 8, 20, 28, 38, 40, 41
• WCDMA: 1, 2, 5, 8
Chipset
• Qualcomm MDM9x50
WiFi
• Full Dual-Band/Dual-Concurrent WiFi
• WiFi 802.11 b/g/n 2.4 GHz;
WiFi 802.11 a/n/ac 5 GHz
Data Usage Meter
• Manage your data and how much you use
Media
• microSD with Media Server/
NAS capabilities
Max Theoretical Downlink Speed
• 1 Gbps
Dimensions
• 105.5 (L) x 105.5 (W) x 20.35 (H) mm
Weight
• 240 g (with battery)
External Display
• 2.4” LCD panel
Battery Life
• All day & Night - 5040mAh battery
for all day use
External Ports
• Ethernet Port
• USB-C Port
• Dual TS-9 external
3G/4G antennas connectors
Package Contents
• NETGEAR Nighthawk Mobile hotspot Router
• Removable Lithium Ion (Li-ion) Battery
• AC charger and USB Type-C cable
• Quick Start Guide
Page 1 of 3
©2017 NETGEAR, Inc. NETGEAR, the NETGEAR Logo, Nighthawk and Arlo are trademarks of NETGEAR, Inc. EE, the EE logo and all of the EE marks contained herein are
trademarks of EE Intellectual Property and /or EE aliated companies. Other brand names mentioned herein are for identification purposes only and may be trademarks of their respective
holder(s). NETGEAR, Inc., 350 E. Plumeria Drive, San Jose, CA, 95014 USA. Information is subject to change without notice.
Nighthawk® Mobile Hotspot Router Data Sheet
USB Type-C
TS-9
Connector
(Main)
USB Type-A
TS-9
Connector
(Se co nda ry)Ethernet
As your ultimate travel router, the Nighthawk
Mobile Hotspot Router is a premium mobile
WiFi router, plus MORE
SUPER FAST WIRELESS
INTERNET
PARENTAL CONTROL
ARLO SUPPORT
TRAVEL ROUTER
ALL D AY
MEDIA STREAMING
LONG LASTING BATTERY
DUAL BAND DUAL
CONCURRENT WIFI
IMPROVED JUMPBOOST
SIMPLE INTUITIVE APP
DRIVEN USER EXPERIENCE
