Whole Home AC2200 Tri-band WiFi System
Data Sheet
CBK43
Overview
This Orbi WiFi System comes with an
Orbi Router with a built-in Cable Modem
and two Satellites. Easily set up and create
a whole home mesh WiFi system that
delivers unparalleled WiFi coverage.
It covers homes up to 6,000 square feet
with strong WiFi signals. Innovative
Tri-Band WiFi helps maximize the Internet
speeds available in your home.
Enjoy better WiFi. Everywhere.
Features
The Savings Add Up.
$
Save up to $168 per year by
eliminating monthly cable
modem rental fees†.
Your Home & Yard. Covered.
This kit of three delivers super-fast
2.2Gbps WiFi for homes up to
6,000sqft†.
CableLabs® DOCSIS® 3.0 Certied.
Up to 32X faster Internet than
DOCSIS® 2.0 for smooth,
uninterrupted connections.
One WiFi Network.
Enjoy the convenience of a single
WiFi name for your whole home.
Replace Your Existing Cable Modem.
Better WiFi with two-in-one Cable Modem
+ WiFi Router that eliminates cable modem
rental fees.
Manage Your Kids’ Screen Time.
Circle® Smart Parental Controls let you
easily manage content & time online
on any device2.
PAGE 1 OF 4
Whole Home AC2200 Tri-band WiFi System
House Diagram
6,000 Square Feet of Orbi WiFi Coverage
DEDI CATE D
CON NE C TION
Orbi Router
Orbi Satellite
DEDI CATE D
CON NE C TION
Data Sheet
CBK43
Orbi Satellite
1
Internet plan and devices that support
these speeds are required.
CableLabs® DOCSIS® 3.0 Certied to work with US Cable Internet
Providers like XFINITY® from Comcast, Spectrum®, Cox® & more.
This product is not compatible with Cable bundled voice services.
INTERNET
NETGEAR Armor empowers you to eliminate
vulnerabilities or simply know the status of your home
network and devices, anytime, anywhere. Get instant
notications when malicious threats are detected, block
unknown devices from joining your Orbi home network
or take action on vulnerabilities as they are discovered
easily through the Orbi App.
Advanced Cyber Security for All Your Devices
NETGEAR Armor™ | Powered by Bitdefender
®
>100Mbps Internet speed
up to 6,000 sq ft range
1
Get Started
with the Orbi app
Use the Orbi app to setup
and manage your Orbi WiFi.
Available on Google Play
and Apple App Store.
PAGE 2 OF 4
Whole Home AC2200 Tri-band WiFi System
Orbi Cable Modem Router (CBR40) Orbi Satellite (RBS20)
Data Sheet
CBK43
Sync Power on/off
Cable Coaxial port
Gigabit Ethernet ports
Sync Power on/off
Gigabit Ethernet ports
PAGE 3 OF 4
Whole Home AC2200 Tri-band WiFi System
Data Sheet
CBK43
What’s In the Box?
• One (1) Orbi Cable Modem Router (CBR40)
• Two (2) Orbi Satellites (RBS20)
• One (1) 2m Ethernet cable
• One (1) 12V /3.5 A power adapter
• Two (2) 12 V / 1.5A power adapters
• Quick start guide
What Do I Need for Orbi to Work?
• High-speed Cable Internet connection
• This product is not compatible
with Cable bundled voice services
Physical Specications
• Orbi Cable Modem Router (CBR40)
- Dimensions: 6.7 x 3.1 x 8.9in
- Weight: 2.15lb
• Orbi Satellite (RBS20) each
- Dimensions: 5.6 x 2.4 x 6.6in
- Weight: 1.05lb
Technical Specications
• Orbi AC2200 Cable Modem Router & Satellite
(866 + 866 + 400Mbps)
• AC2200 Simultaneous Tri-band WiFi
- Radio 1: 400Mbps @ 2.4GHz: Supports 256QAM
- Radio 2: 866Mbps @ 5GHz: Supports 256QAM
- Radio 3: 866Mbps @ 5GHz: Supports 256QAM
†
• Tx /Rx: 2x2 (2.4 GHz) + 2x2 (5 GHz) + 2x2 (5 GHz)
dedicated backhaul
• IEEE® 802.11 a/b/g/n/ac
• Built-in high-speed 32x8 CableLabs®
certied DOCSIS® 3.0 Modem
• Channel Bonding enables up to 1.4 Gbps†
download speed
• MU-MIMO capable for simultaneous
data streaming
• Implicit & Explicit Beamforming
for 2.4GHz & 5GHz bands
• Ports — Orbi Cable Modem Router
- Four (4) 10/100/1000Mbps Gigabit Ethernet
LAN ports
- One (1) Cable/Coaxial port
• Ports — Orbi Satellite (each)
- Two (2) 10/100/1000Mbps Gigabit
Ethernet LAN ports
• Power On/Off switch
• Security
- Comprehensive anti-virus & data theft protection
for your PC, Mac® and mobile devices with
NETGEAR Armor
™
- Standards-based WiFi Security
(802.11i, 128-bit AES encryption with PSK)
- Guest WiFi Network is easy to setup
separate & secure Internet access for guests
• Voice Control
- Amazon Alexa
™
- The Google© Assistant
• Circle® Smart Parental Controls let you easily manage
content & time online on any device2.
This product comes with a limited warranty that is valid only if purchased from a NETGE AR authorized reseller.
* 90- day complimentary technical support following purchase from a NETGEAR authorized reseller.
†
Maximum rate is derived from DOCSIS® 3.0 specications and ac tual throughput will var y depending on the MSO provisioning and speed tier subscription. Check your cable
Internet service provider web site for data speed tier compatibility. Customer-owned modems may not be compatible with certain cable networks. Please check with your cable
provider to conrm this NETGEAR modem is allowed on your cable network . This produc t not compatible with Cable bundled voice services.
1
Internet plan and devices that support these speeds are required.
2
NETGE AR Armor™ is free during the trial period. A yearly subscription, after the trial period, protects all of your connected devices. V isit www.netgear.com/armor
For indoor use only.
3
Circle® Smart Parental Controls include the Free Basic Plan. Fees apply for a Premium Plan. Visit netgear.com/circle for more information. For indoor use only.
For regulatory compliance information, visit http://www.NETGEAR.com/about/regulatory
NETGE AR, the NETGEAR Logo, Armor, and Orbi are trademarks o f NETGEAR, Inc. Apple and the Apple logo are t rademarks of Apple Inc., regis tered in
the U.S . and other coun tries. App Store is a ser vice mark of Apple Inc., registered in the U. S. and other countries. Google Play and the Google Play logo are trademarks of G oogle Inc.
Any other trademarks on this package are for reference purposes only. © 2020 NETGEAR, Inc.
PAGE 4 OF 4
