NEC AccuSync PV46-AVT Setup Guide

AccuSync PV Series External Control Device Setup

< Back panel of the set >

1
2
3

8
7
6

45

Connect the RS-232 input jack to a control device (such as a
computer or an A/V control system) in order to control the set’s
functions externally.

RJ-45 8PIN CONNECTOR

Connect External Equipment

NO. PIN NAME
1 RXD(RECEIVE DATA)
2 TXD(TRANSMIT DATA)
3
4 GND
5
6 NO CONNCETION
7 NO CONNCETION
8 NO CONNCETION

Communication Parameters

• Baud rate : 9600bps (UART)

• Data length : 8bits

• Parity : None

• Stop bit : 1bit

• Communication code : HEX code

(L) AUDIO (R)

Y Pb

Pr

COMPONENT IN

S-VIDEO IN

RS-232

SERVICE

1
2
3

4

...

Connect the serial port of the control device to the RS-232 jack on
the set.

RS-232 connection cables are not supplied with the Monitor.

The Monitor remote control and front panel controls (except main
power) will not be functional if the set is controlled by a PC
computer or other external device.

2
1

3, 4

GND

NO CONNCETION

1

External Control Device Setup

Hyper Terminal Setting

1. Run ‘Start > Programs > Accessories > Communications > Hyper Terminal’.

2. Enter a name and chose an icon for the connection.

2

External Control Device Setup

Hyper Terminal Setting

3. Enter your Serial(RS-232) Port number.
(For example, ‘set to COM1, COM2 or etc.)

4. Set up the port setting as below

- Bits per second : 9600

- Data bits : 8

- Parity : None

- Stop bits : 1

- Flow control : None

Then Click ‘OK’.

3
