NEC AccuSync LCD52V, AccuSync LCD73VX, AccuSync LCD73 VXM, AccuSync LCD93VXM, AccuSync LCD93VX Specifications

NEC AccuSync

Business Desktop

TM

Series

15" - 19" flat-panel monitors ideal for
small-to-medium businesses

High-quality LCD monitors don’t necessarily have to be associated with high-end price
tags. NEC AccuSync Series monitors have set a new standard in value for the flat-panel

monitor category, offering you a perfect opportunity to take advantage of the many ben­efits offered by the latest display technology without having to break your budget. The 15”
NEC AccuSync LCD52V, 17” NEC AccuSync LCD73VX and 19” NEC AccuSync LCD­93VX deliver ideal visual display solutions to small-to-medium-sized businesses and home
office users. The 17” NEC AccuSync LCD73VXM and 19” NEC AccuSync LCD93VXM,
which boast integrated, front-firing speakers, further expand your application possibilities
with their high-quality multimedia capabilities.

Wide compatibility for today and tomorrow. With Ambix® dual-input technology–which
utilizes both DVI-D and traditional 15-pin VGA connectors–you can bridge the gap
between analog and digital systems by allowing the same monitor to work seamlessly in
either environment. Featured on all models (except the AccuSync LCD52V), Ambix pro­vides compatibility with today’s computer systems and is on the forefront of tomorrow’s
digital output.

Enhanced screen performance. With contrast ratios as high as 800:1 (typical) and bright­ness quality at 300 cd/m2, outstanding LCD monitor front-of-screen visual performance is
NEC’s #1 goal. The AccuSync Series delivers vibrant colors and flicker-free images that
make your time in front of the monitor more comfortable and productive. NEC’s Rapid Re­sponseTM technology provides for uninterrupted display of full-motion video with response
times as quick as 5ms. This remarkably swift motion makes these models better than ever
for video applications such as presentations and streaming web video.

Series Features and Benefits

Exceptional screen performance provides a more

comfortable and productive visual experience
with crisp, sharp and accurate text and images

Ambix dual-input technology allows for digi­tal/analog compatibility with upgraded video
cards and software as well as connection to two
systems (all models except LCD52V)

Rapid Response technology delivers virtually
uninterrupted, undistorted viewing of high­speed, full-motion video

Built-in, front-firing multimedia speakers provide
quality sound (LCD73VXM, LCD93VXM)

On Screen Display (OSD®) puts you in complete
control of your screen setting adjustments

NaViSetTM software offers an expanded and

intuitive interface, allowing you to more easily
adjust display settings via mouse and keyboard

XtraView® provides for some of the widest view­ing angles available (all models except LCD52V)

Eco-Mode helps extend the life of the display
by allowing you to adjust the OSD, thereby con­serving energy (all models except LCD52V)

Enhanced cable management helps prevent
unattractive, space-consuming wire clutters

No Touch Auto AdjustTM reduces setup time

and provides optimal image settings upon initial
power-on

Wall/arm mounting capability adds flexibility
and comfort, while freeing up valuable desktop
space (using third-party product)

RoHS compliance ensures the displays are free
of lead, hex-chrome, cadmium, PBDE and PBB,
with reduced mercury

ENERGY STAR 4.0 compliance/low power
consumption reduces electrical costs and lowers

total cost of ownership

Windows® Vista certification maximizes the
monitor’s resolution capabilities

NEC Display Solutions’ quality and reliability
provide peace of mind with a 3-year limited parts
and labor warranty (including backlight) and 24/7
customer service and technical support

www.necdisplay.com

Model

Display
Viewable Image Size
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)

Response Time (typical)
Display Colors

Synchronization Range
Horizontal
Vertical

Input Signal
Video
Sync

Input

Resolutions Supported

Native Resolution

Additional Features

Touch-Capable

Voltage Rating

Power Consumption (typical)
On
Power Savings Mode

Dimensions (W x H x D)
Net (with stand)

Net (without stand)

Weight
Net (with stand)
Net (without stand)

VESA Hole Configuration
Specifications

Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude

Limited Warranty

Technical Support

AccuSync LCD52V

15”

0.297mm
86 @ native resolution

2

250 cd/m
400:1
110° Vert., 140° Hor.
(55U/55D/70L/70R) (CR>5)
Rapid Response (16ms)
More than 16 million

31.5 - 60 KHz (Analog)
56 - 76 Hz

Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level (Positive/Negative)

VGA 15-pin D-sub

720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz

1024 x 768 @ 75 Hz

Thin-frame (bezel), tilt, No Touch Auto
Adjust, touch screen compatible, cable
management, digital smoothing, digital
controls, AccuColor color control, On
Screen Display user controls, NaViSet
software, DDC/CI, Plug and Play (VESA
DDC2B), VESA DPMS power manage­ment, ISO 13406-2 Class II, Energy Star

4.0 Tier 2, RoHS complaint, WEEE compli­ant, Windows Vista certification

Designed for integration

AC 100 - 120V / AC 220 - 240V

21W
<2W

13.6 x 13.9 x 6.5 in. /

344.6 x 352.7 x 165mm

13.6 x 11.2 x 2.3 in. /

344.6 x 285 x 57.5mm

7.1 lbs. / 3.2 kg

6.2lbs. / 2.8 kg

100 x 100mm

5 - 35° C / 41 - 95° F
10 - 80%
3048m / 10,000 ft.

-10 - 60° C / 14 - 140° F
10 - 85%
12,192m / 40,000 ft.

3 year parts and labor, including backlight

24 hours/7 days

* Aside from integrated speakers, LCD73VXM specs are identical to those of the LCD73VX
** Aside from integrated speakers, LCD93VXM specs are identical to those of the LCD93VX

AccuSync LCD73VX/VXM*

17”

0.264mm
88 @ native resolution

2

280 cd/m
700:1
170° Vert., 170° Hor.
(85U/85D/85L/85R) (CR>5)
Rapid Response (5ms)
More than 16 million

31.5 - 81.1 KHz (Analog/Digital)
56 - 76 Hz

Analog 0.7 Vp-p / 75 Ohms
Separate Sync: TTL Level (Positive/Negative)

DVI-D and VGA 15-pin D-sub

720 x 400 @ 70 Hz
640 x 480 @ 60 - 75 Hz
800 x 600 @ 56 - 75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60 - 75 Hz
1152 x 864 @ 60 - 75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60 - 75 Hz

1280 x 1024 @ 60-75 Hz

Thin-frame (bezel), tilt, No Touch Auto
Adjust, cable management, Eco-Mode,
color temperature mode, digital smooth­ing, digital controls, color control, On
Screen Display user controls, NaViSet
software, DDC/CI, Plug and Play (VESA
DDC2B), VESA DPMS power management,
ISO 13406-2 Class II, Energy Star 4.0 Tier
2, RoHS complaint, WEEE compliant,
Windows Vista certification

No

AC 100 - 120V / AC 220 - 240V

28W
<2W

14.5 x 15 x 8.3 in. /
368 x 381.5 x 209.6mm

14.5 x 12.5 x 2.5 in. /
368 x 316.5 x 62.6 mm

9.5 lbs. / 4.3 kg

8.6 lbs. / 3.9 kg

100 x 100mm

5 - 35° C / 41 - 95° F
30 - 80%
3048m / 10,000 ft.

-10 - 60° C / 14 - 140° F
10 - 85%
12,192m / 40,000 ft.

3 year parts and labor, including backlight

24 hours / 7 days

AccuSync LCD93VX/VXM**

19”

0.294
80 @ native resolution

2

300 cd/m
800:1
170° Vert., 170° Hor.
(85U/85D/85L/85R) (CR>5)
Rapid Response (5ms)
More than 16 million

31.5 - 81.1 KHz (Analog/Digital)
56 - 76 Hz

Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level (Positive/Negative)

DVI-D and VGA 15-pin D-sub

720 x 400 @ 70 Hz
640 x 480 @ 60 - 75 Hz
800 x 600 @ 56 - 75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60 - 75 Hz
1152 x 864 @ 60 - 75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60 - 75 Hz

1280 x 1024 @ 60 - 75 Hz

Thin-frame (bezel), tilt, No Touch Auto
Adjust, cable management, Eco-Mode,
color temperature mode, digital smooth­ing, digital controls, color control, On
Screen Display user controls, NaViSet
software, DDC/CI, Plug and Play (VESA
DDC2B), VESA DPMS power manage­ment, ISO 13406-2 Class II, Energy Star

4.0 Tier 2, RoHS complaint, WEEE compli­ant, Windows Vista certification

No

AC 100 - 120V / AC 220 - 240V

33W
<2W

16 x 16 x 8.7 in. /

405.5 x 405.5 x 222mm
16 x 13.6 x 2.5 in. /

405.5 x 346 x 63.5mm

10.4 lbs. / 4.7 kg

9.5 lbs. / 4.3 kg

100 x 100mm

5 - 35° C / 41 - 95° F
30 - 80%
3048m / 10,000 ft.

-10 - 60° C / 14 - 140° F
10 - 85%
12,192m / 40,000 ft.

3 year parts and labor, including backlight

24 hours / 7 days

Ambix, OSD and XtraView are registered trademarks,
and AccuSync, NaViSet, No Touch Auto Adjust and
Rapid Response are trademarks of NEC Display Solu­tions. All other brand or product names are trademarks
or registered trademarks of their respective holders.
Product specifications subject to change. 12/07 ver. 12.

2007 NEC Display Solutions of America, Inc.

©

All rights reserved.

NEC Display Solutions

500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
