NEC 5800-120Rh-2, N8100-1126F, N8100-1100F, N8100-1125F, N8100-1063F User Manual

N8100-1061F/1062F/1063F/1100F/1125F/1126F

NEC Express5800/120Rh-2
User's Guide

5th Edition

5-2006

ONL-4133eN-120Rh2-100-99-0604

PROPRIETARY NOTICE AND LIABILITY DISCLAIMER

The information disclosed in this document, including all designs and related materials, is the
valuable property of NEC Corporation (NEC) and /or its licensors. NEC and/or its licensors, as
appropriate, reserve all patent, copyright and other proprietary rights to this document, including all
design, manufacturing, reproduction, use, and sales rights thereto, except to the extent said rights are
expressly granted to others.

The NEC product(s) discussed in this document are warranted in accordance with the terms of the
Warranty Statement accompanying each product. However, actual performance of each such
product is dependent upon factors such as system configuration, customer data, and operator control.
Since implementation by customers of each product may vary, the suitability of specific product
configurations and applications must be determined by the customer and is not warranted by NEC.

To allow for design and specification improvements, the information in this document is subject to
change at any time, without notice. Reproduction of this document or portions thereof without
prior written approval of NEC is prohibited.

First Printing, May 2005
Fifth Printing, April 2006

Revised, December 2006

Copyright 2005, 2006

NEC Corporation

7-1 Shiba 5-Chome, Minato-Ku

Tokyo 108-8001, Japan

All Rights Reserved

Printed in Japan

Keep this User's Guide at hand for quick reference at anytime necessary.

SAFETY INDICATIONS

Follow the instructions in this User's Guide for your safety to use the server.

The server contains components with possible danger, hazards that may cause by ignoring warnings,
and preventive actions against such hazards.

Server components with possible danger are indicated with a warning label placed on or around them
as well as described in this User's Guide.

In the User's Guide or warning labels, "WARNING" or "CAUTION" is used to indicate a degree of
danger. These terms are defined as follows:

WARNING

CAUTION

Precautions and notices against hazards are presented with one of the following three symbols. The
individual symbols are defined as follows:

This symbol indicates the presence of a hazard if the instruction is ignored.
An image in the symbol illustrates the hazard type. (Attention)

This symbol indicates prohibited actions. An image in the symbol illustrates a
particular prohibited action. (Prohibited Action)

This symbol indicates mandatory actions. An image in the symbol illustrates a
mandatory action to avoid a particular hazard. (Mandatory Action)

(Example)

Indicates the presence of a hazard that may result in death or serious
personal injury if the instruction is ignored.
Indicates the presence of a hazard that may cause minor personal injury,
including burns, or property damage if the instruction is ignored.

Symbol to draw attention

Term indicating a degree of danger

CAUTION

Hot surface
Immediately after the server is powered off, its internal components such as
hard disk drives are very hot. Leave the server until its internal components
fully cool down before installing/removing any component.

Symbol indicating a prohibited
action (may not always be
indicated)

Description of a danger

SYMBOLS USED IN THIS USER'S GUIDE AND WARNING LABELS

Attentions

Indicates that improper use may cause an electric shock.

Indicates that improper use may cause personal injury.

Indicates that improper use may cause fingers to be caught.

Indicates that improper use may cause fumes or fire.

Indicates a general notice or warning that cannot be specifically identified.

Indicates that improper use may cause loss of eyesight due to laser beam.

Prohibited Actions

Indicates a general prohibited action that cannot be specifically identified.

Do not disassemble, repair, or modify the server. Otherwise, an electric shock or fire
may be caused.

Mandatory Action

Unplug the power cord of the server. Otherwise, an electric shock or fire may be
caused.

Indicates a mandatory action that cannot be specifically identified. Make sure to
follow the instruction.

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.

CE Statement

Warning: This is a Class A product. In domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures (EN55022).

BSMI Statement

Trademarks

NEC DianaScope, NEC ESMPRO and NEC EXPRESSBUILDER are trademarks of NEC Corporation.
Microsoft, Windows, Windows Server, Windows NT, and MS-DOS are registered trademarks or trademarks of
Microsoft Corporation in the United States and other countries.
Intel, Pentium, and Xeon are registered trademarks of Intel Corporation.
Datalight is a registered trademark of Datalight, Inc.
ROM-DOS is a trademark of Datalight, Inc.
LSI-Logic, MegaRAID, MegaRAID Storage Manager and Power Console Plus are registered trademarks or
trademarks of LSI Logic Corp.
Novell and NetWare are registered trademarks of Novell, Inc. of the United States.
AT is a registered trademark of International Business Machines Corporation in the United States and other
countries.
Adaptec and its logo is a registered trademark of Adaptec, Inc. of United States.
SCSISelect is a trademark of Adaptec, Inc. of the United States.
Adobe, Adobe logo, and Acrobat are trademarks of Adobe Systems Incorporated.
DLT and DLTtape are trademarks of Quantum Corporation of the United States.
All other product, brand, or trade names used in this publication are the trademarks or registered trademarks of
their respective trademark owners.

Windows XP stands for Microsoft® Windows® XP Professional operating system and Microsoft® Windows®
XP Home Edition operating system. Windows 2000 stands for Microsoft® Windows® 2000 Server operating

system and Microsoft® Windows® 2000 Advanced Server operating system, and Microsoft® Windows® 2000

Professional operating system. Windows 2003 stands for Microsoft® Windows Server 2003 operating

system and Microsoft® Windows Server 2003 Standard Edition and Enterprise Edition. Windows Me stands
for Microsoft® Windows® Millennium Edition operating system. Windows 98 stands for Microsoft
Windows®98 operating system. Windows 95 stands for Microsoft® Windows®95 operating system.

®

Momentary voltage drop prevention:

This product may be affected by a momentary voltage drop caused by lightning. To prevent a
momentary voltage drop, an AC uninterruptible power supply (UPS) unit should be used.

Notes:

(1) No part of this manual may be reproduced in any form without the prior written permission of

NEC Corporation.

(2) The contents of this User's Guide may be revised without prior notice.

(3) The contents of this User's Guide shall not be copied or altered without the prior written

permission of NEC Corporation.

(4) All efforts have been made to ensure the accuracy of all information in this User's Guide. If

you notice any part unclear, incorrect, or omitted in this User's Guide, contact the sales agent
where you purchased this product.

(5) NEC assumes no liability arising from the use of this product, nor any liability for incidental or

consequential damages arising from the use of this User's Guide regardless of Item (4).

(6) If you find any missing pages or pages out of order in this manual, please contact your dealer

for a replacement.

PREFACE

Welcome to the NEC Express5800/120Rh-2 server.

The NEC Express5800 server holds powerful performance and employs the latest technology to
implement a computer for the next generation. With its potential capabilities, the server may be
used as the workstation PC that configures a client-server system and provides high-speed
processing and superior reliability.

Read this User's Guide thoroughly to fully understand handling of the server and appreciate its
functions to the maximum extent.

i

ii

ABOUT THIS USER'S GUIDE

This User's Guide is a guide for proper setup and use of the server.
This User's Guide also covers useful procedures for dealing with difficulties and problems that may
arise during setup or operation of the server.
Keep this manual for future use.
The following describes how to proceed with this User's Guide.

How to Use This User's Guide

To aid you in finding information quickly, this User's Guide contains the following information:

Chapter 1 Notes on Using Your Server

includes information that needs attention to use the server. Make sure to read this chapter
before setting up and using the server. It also includes requirements and advisory information
for transfer and disposal of the server.

Chapter 2 General Description

includes information necessary to use the server, such as names and functions of its
components, handling of the floppy disk and CD-ROM drives.

Chapter 3 Setting Up Your Server

tells you how to select a site, unpack the system, assemble the rack-mount subsystem, make
cable connections, and power on your system.

Chapter 4 Configuring Your Server

tells you how to configure the system and provides instructions for running the BIOS Setup
Utility and the Adaptec Configuration Utility, which is used to configure SCSI devices in your
system. This chapter also provides information on mother board jumper settings.

Chapter 5 Installing the Operating System with Express Setup

describes how to install the operating system.

Chapter 6 Installing and Using Utilities

describes how to install the utilities for the server. It also includes a description on using the
attached CD-ROM "NEC EXPRESSBUILDER".

Chapter 7 Maintenance

provides you with all the information necessary to maintain successful operation of the server.
This chapter also includes a description on relocating and storing the server.

Chapter 8 Troubleshooting

contains helpful information for solving problems that might occur with your system.

Chapter 9 Upgrading Your Server

provides you with instructions for upgrading your system with an additional processor, optional
memory, optional add-in cards, hard disk drives, peripheral devices, and power supply.

Appendix A Specification

provides specifications for your server.

Appendix B Other Precautions

provides supplementary notes on using the server.

Appendix C IRQ and I/O Port Address

provides a list of factory-set IRQs and I/O port addresses assigned.

Appendix D Installing Windows Server 2003 x64 Editions

describes how to install Microsoft Windows Server 2003 x64 Editions without using Express
Setup. Using the Express Setup tool is recommended for installing Windows Server 2003 x64
Editions. See Chapter 5 for details.

Appendix E Installing Windows Server 2003

describes how to install Microsoft Windows Server 2003 without using Express Setup. Using
the Express Setup tool is recommended for installing Windows Server 2003. See Chapter 5
for details.

Appendix F Installing Windows 2000

describes how to install Microsoft Windows 2000 without using Express Setup. Using the
Express Setup tool is recommended for installing Windows 2000. See Chapter 5 for details.

Appendix G Product Configuration Record Table

provides a table to be filled with your server configuration.

Text Conventions

The following conventions are used throughout this User's Guide. For safety symbols, see
"SAFETY INDICATIONS" provided earlier.

iii

IMPORTANT:

NOTE:

Items that are mandatory or require attention when using the server

Helpful and convenient piece of information

IN THE PACKAGE

The carton contains various accessories, as well as the server itself. See the packing list to make
sure that you have everything and that individual components are not damaged. If you find any
component missing or damaged, contact your sales agent.

 Store the provided accessories in a designated place for your convenience. You will need

them to install an optional device or troubleshoot the server, as well as to set it up.

 Make a backup copy of each provided floppy disk, if any. Store the original disk as the

master disk in a designated place, and use its copy.

 Improper use of any provided floppy disk or CD-ROM may alter your system

environment. If you find anything unclear, immediately ask your sales agent for help.

iv

CONTENTS

Preface ..............................................................................................................................................i

About This User's Guide..................................................................................................................ii

In the Package................................................................................................................................ iii

Chapter 1 Notes on Using Your Server........................................................................ 1-1

Warning Labels ............................................................................................................................ 1-2

Safety Notes................................................................................................................................. 1-3

General .................................................................................................................................... 1-3

Power Supply and Power Cord Use......................................................................................... 1-5

Rack......................................................................................................................................... 1-6

Installation, Relocation, Storage, and Connection................................................................... 1-7

Cleaning and Working with Internal Devices.......................................................................... 1-9

During Operation................................................................................................................... 1-10

For Proper Operation ..................................................................................................................1-11

Transfer to Third Party............................................................................................................... 1-13

Disposal and Consumables ........................................................................................................1-14

User Support .............................................................................................................................. 1-15

Chapter 2 General Description ..................................................................................... 2-1

Overview...................................................................................................................................... 2-1

External View .......................................................................................................................... 2-2

Front View with Front Bezel Closed ....................................................................................... 2-3

Front View with Front Bezel Removed ................................................................................... 2-4

Rear View ................................................................................................................................ 2-6

Internal View ........................................................................................................................... 2-8

Mother Board .......................................................................................................................... 2-9

Status Indicators......................................................................................................................... 2-10

POWER LED ....................................................................................................................... 2-10

STATUS LED ....................................................................................................................... 2-10

DISK ACCESS LED ............................................................................................................ 2-12

ACT LED ............................................................................................................................. 2-12

UID LED (UID) .................................................................................................................... 2-12

Disk Access LED................................................................................................................... 2-12

Hard Disk Drive LED............................................................................................................ 2-13

LAN Connector LEDs........................................................................................................... 2-14

AC POWER LED.................................................................................................................. 2-15

Standard Features....................................................................................................................... 2-16

Power Supplies ...................................................................................................................... 2-17

Peripheral Bays...................................................................................................................... 2-17

SAF-TE Logic............................................................................................................................ 2-18

System Board Features ...............................................................................................................2-18

Processor ................................................................................................................................2-18

Memory..................................................................................................................................2-18

PCI Riser Slots .......................................................................................................................2-19

Video ......................................................................................................................................2-19

SCSI Controller......................................................................................................................2-19

Network Controller ................................................................................................................2-20

Keyboard and Mouse .............................................................................................................2-20

ACPI.......................................................................................................................................2-20

Remote Management Card (RMC) ........................................................................................2-21

Degradation Feature ...................................................................................................................2-22

Remote Power-On Feature (Wake On LAN) ..............................................................................2-22

AC-Link Feature.........................................................................................................................2-22

System Security ..........................................................................................................................2-23

Security with Mechanical Locks and Monitoring ..................................................................2-23

Software Locks via the BIOS Setup Utility............................................................................2-23

NEC EXPRESSBUILDER.........................................................................................................2-27

NEC ESMPRO ...........................................................................................................................2-28

Off-line Maintenance Utility ......................................................................................................2-28

System Diagnostic Utility...........................................................................................................2-28

NEC DianaScope........................................................................................................................2-28

Using Your Server.......................................................................................................................2-29

Front Bezel.............................................................................................................................2-29

POWER Switch......................................................................................................................2-31

Identification of Servers (UID Switch) ..................................................................................2-36

Floppy Disk Drive..................................................................................................................2-37

CD-ROM Drive......................................................................................................................2-39

v

Chapter 3 Setting Up Your Server ................................................................................ 3-1

Setup Flow....................................................................................................................................3-2

Selecting Server Site.....................................................................................................................3-3

Unpacking the System ..................................................................................................................3-5

Installing the Server......................................................................................................................3-5

Restricted Access Location ......................................................................................................3-6

ESD Precaution ........................................................................................................................3-6

Checking Components .............................................................................................................3-6

Required Tools .........................................................................................................................3-6

Installation Procedure for NEC Rack/Third Vendor's Rack .....................................................3-7

Removing the Server from the Rack Assembly......................................................................3-14

Connecting Peripheral Devices...................................................................................................3-16

Connecting Power Cord..............................................................................................................3-18

Turning On the Server ................................................................................................................3-20

Installing Operating System .......................................................................................................3-22

Installing Utilities .......................................................................................................................3-22

Making Backup Copies of System Information..........................................................................3-22

vi

Chapter 4 Configuring Your Server.............................................................................. 4-1

System BIOS (SETUP)................................................................................................................ 4-1

Starting SETUP Utility ............................................................................................................ 4-2

Description on On-Screen Items and Key Usage .................................................................... 4-3

Menu and Parameter Descriptions........................................................................................... 4-4

SCSI BIOS (SCSISelect) ........................................................................................................... 4-19

Using SCSISelect Utility ....................................................................................................... 4-19

Configuring SCSI Controller on Mother Board .................................................................... 4-19

Configuring SCSI Controller on Optional Board .................................................................. 4-25

RAID BIOS ............................................................................................................................... 4-26

RAID Configuration .................................................................................................................. 4-27

RAID Configuration of SCSI Hard Disk Drive..................................................................... 4-27

Configuring Mother Board Jumpers .......................................................................................... 4-44

Chapter 5 Installing the Operating System with Express Setup ............................... 5-1

About Express Setup.................................................................................................................... 5-2

Microsoft Windows Server 2003 ................................................................................................. 5-3

Installation Notice ................................................................................................................... 5-3

The Flow of Setup ................................................................................................................... 5-8

Installing the Windows Server 2003........................................................................................ 5-9

Installing and Setting Device Drivers.................................................................................... 5-14

Setting for Solving Problems................................................................................................. 5-24

Installing Maintenance Utilities............................................................................................. 5-28

Updating the System - Installing Service Pack - ................................................................... 5-29

Making Backup Copies of System Information .................................................................... 5-29

Exceptional Setup.................................................................................................................. 5-30

Microsoft Windows 2000........................................................................................................... 5-31

Installation Notice ................................................................................................................. 5-31

The Flow of Setup ................................................................................................................. 5-36

Installing the Windows 2000 ................................................................................................. 5-37

Installing and Setting Device Drivers.................................................................................... 5-42

Setting for Solving Problems................................................................................................. 5-48

Installing Maintenance Utilities............................................................................................. 5-51

Updating the System - Installing Service Pack - ................................................................... 5-52

Making Backup Copies of System Information .................................................................... 5-52

Exceptional Setup.................................................................................................................. 5-53

HostRAID .................................................................................................................................. 5-54

Overview of HostRAID......................................................................................................... 5-54

Notes...................................................................................................................................... 5-55

HostRAID Setup Flow .......................................................................................................... 5-56

Migration of Hard Disk Drive (Migration)............................................................................ 5-56

vii

Chapter 6 Installing and Using Utilities ....................................................................... 6-1

NEC EXPRESSBUILDER...........................................................................................................6-2

NEC EXPRESSBUILDER for DOS-Based with Local Console.............................................6-4

NEC EXPRESSBUILDER for DOS-based with Remote Console ..........................................6-9

Starting ...................................................................................................................................6-10

NEC EXPRESSBUILDER for Windows-Based (Master Control Menu)..............................6-13

Configuration Diskette Creator...................................................................................................6-14

NEC ESMPRO ...........................................................................................................................6-18

Functions and Features...........................................................................................................6-18

Adaptec Storage Manager - Browser Edition..........................................................................6-19

Adaptec Storage Manager.......................................................................................................6-20

MegaRAID Storage Manager (Server)....................................................................................6-21

Setup with Express Setup.......................................................................................................6-21

Manual Setup .........................................................................................................................6-21

MegaRAID Storage Manager (Management PC) ...................................................................6-21

Power Console Plus....................................................................................................................6-22

Major Functions .....................................................................................................................6-22

Components............................................................................................................................6-22

Server Setup ...........................................................................................................................6-24

Management PC Setup...........................................................................................................6-25

NEC DianaScope........................................................................................................................6-26

Chapter 7 Maintenance.................................................................................................. 7-1

Making Backup Copies ................................................................................................................7-1

Cleaning........................................................................................................................................7-2

Cleaning the Server ..................................................................................................................7-3

Cleaning the Interior.................................................................................................................7-4

Cleaning the Keyboard/Mouse.................................................................................................7-5

Cleaning CD-ROM ..................................................................................................................7-6

System Diagnostics.......................................................................................................................7-7

Test Items .................................................................................................................................7-7

Starting and Ending the System Diagnostics............................................................................7-8

Relocating/Storing The Server....................................................................................................7-11

Chapter 8 Troubleshooting ........................................................................................... 8-1

System Viewers ............................................................................................................................8-2

LEDs.............................................................................................................................................8-3

Error Messages .............................................................................................................................8-4

Error Messages after Power-on................................................................................................8-4

POST Error Messages ..............................................................................................................8-5

Beep Codes...............................................................................................................................8-9

Solving Problems........................................................................................................................8-10

Problems with the Server .......................................................................................................8-10

Problems with Windows Server 2003 x64 Editions ...............................................................8-17

Problems with Windows Server 2003 R2...............................................................................8-18

Problems with Windows Server 2003 and Windows 2000.....................................................8-19

Problems with NEC EXPRESSBUILDER ............................................................................8-21

Problems with Express Setup.................................................................................................8-22

Problems with Master Control Menu .....................................................................................8-25

viii

Problems with Configuration Diskette Creator ..................................................................... 8-26

Problems with Disk Array Configuration .............................................................................. 8-26

Collecting Event Log ................................................................................................................. 8-27

Collecting Configuration Information........................................................................................ 8-28

Collecting Dr. Watson Diagnostic Information.......................................................................... 8-29

Memory Dump........................................................................................................................... 8-29

Preparing for Memory Dumping ........................................................................................... 8-29

Saving the Dump File............................................................................................................8-30

Recovery for Windows 2000 System......................................................................................... 8-31

Off-Line Maintenance Utility ....................................................................................................8-34

Starting the Off-line Maintenance Utility.............................................................................. 8-35

Features of Off-line Maintenance Utility............................................................................... 8-36

Resetting the Server ................................................................................................................... 8-37

Forced Shutdown ....................................................................................................................... 8-38

Chapter 9 Upgrading Your Server ................................................................................9-1

Safety Notes................................................................................................................................. 9-2

Anti-static Measures .................................................................................................................... 9-3

Preparing for Installation and Removal ....................................................................................... 9-4

Confirmation after Installation/Removal ..................................................................................... 9-5

Device Installation or Removal Procedure .................................................................................. 9-6

Hard Disk Drive ...................................................................................................................... 9-6

Power Supply Unit ................................................................................................................ 9-12

Server (Pull-out from the Rack) ............................................................................................ 9-16

Drive Cover ........................................................................................................................... 9-17

Logic Cover........................................................................................................................... 9-18

DIMM.................................................................................................................................... 9-19

Processor (CPU) .................................................................................................................... 9-23

PCI Board.............................................................................................................................. 9-30

Disk Array Controller Board ................................................................................................. 9-38

Backup Device....................................................................................................................... 9-49

Redundant Hot Swap-fan....................................................................................................... 9-55

Remote Management Card (RMC)........................................................................................ 9-58

Appendix A Specifications ........................................................................................... A-1

Appendix B Other Precautions .................................................................................... B-1

Transfer Rate of the On-board LAN Controller ......................................................................B-1

Server Management Software .................................................................................................B-1

Floppy Disk .............................................................................................................................B-1

CD-ROM.................................................................................................................................B-4

Tape Media ..............................................................................................................................B-4

Keyboard .................................................................................................................................B-5

Mouse ......................................................................................................................................B-6

Appendix C IRQ............................................................................................................. C-1

ix

Appendix D Installing Windows Server 2003 x64 Editions........................................D-1

Before Installing Windows Server 2003 x64 Editions.................................................................D-1

Optional Board Supported by NEC EXPRESSBUILDER......................................................D-1

Updating System .....................................................................................................................D-2

Re-installing to the Hard Disk Drive which has been upgraded to Dynamic Disk .................D-2

Manual Installation when N8103-80F/81F and SCSI HostRAID Keeps Connection.............D-2

MO Device..............................................................................................................................D-2

Partition Size ...........................................................................................................................D-3

Installing Windows Server 2003 x64 Editions.............................................................................D-4

Creating "Windows Server 2003 x64 Edition OEM-DISK for NEC EXPRESSBUILDER".. D-4

Windows Server 2003 x64 Editions Clean Installation ...........................................................D-6

Reinstallation to Multiple Logical drives................................................................................D-8

Updating the System .............................................................................................................D-10

Driver Installation and Advanced Settings ................................................................................D-11

PROSet..................................................................................................................................D-11

Network Driver .....................................................................................................................D-12

Optional Network Board Driver............................................................................................ D-13

Adapter Fault Tolerance (AFT)/Adaptive Load Balancing (ALB)........................................D-14

Re-install the Network Driver ............................................................................................... D-14

Graphics Accelerator Driver.................................................................................................. D-15

Installing SCSI Controller Driver (N8103-56/-75/-95/N8190-126)......................................D-15

Installing RAID Controller Driver (N8103-80F/81F)...........................................................D-16

Setting for Collecting Memory Dump (Debug Information).....................................................D-16

Appendix E Installing Windows Server 2003 .............................................................. E-1

Before Installing Windows Server 2003 ...................................................................................... E-1

Optional Board Supported by NEC EXPRESSBUILDER...................................................... E-1

Disk Array Controller (N8103-91).......................................................................................... E-2

Installing Service Pack ............................................................................................................ E-2

Updating System ..................................................................................................................... E-2

Re-installing to the Hard Disk Drive which has been upgraded to Dynamic Disk ................. E-2

Manual Installation when N8103-80F/81F/86 and SCSI HostRAID Keeps Connection........ E-2

MO Device.............................................................................................................................. E-2

Partition Size ........................................................................................................................... E-3

About the Upgrade to Windows Server 2003 R2 .................................................................... E-4

Installing Windows Server 2003..................................................................................................E-5

Creating "Windows Server 2003 OEM-DISK for NEC EXPRESSBUILDER" ..................... E-5

Windows Server 2003 Clean Installation ................................................................................ E-7

Upgrade Installation ................................................................................................................ E-9

Reinstallation to Multiple Logical drives.............................................................................. E-12

Updating the System - Installing Service Pack -................................................................... E-14

x

Driver Installation and Advanced Settings................................................................................. E-15

PROSet .................................................................................................................................. E-15

Network Driver...................................................................................................................... E-16

Re-install the Network Driver ...............................................................................................E-17

Graphics Accelerator Driver.................................................................................................. E-17

Installing SCSI Controller Driver (N8103-65F).................................................................... E-18

Installing SCSI Controller Driver (N8103-75) ......................................................................E-19

Installing SCSI Controller Driver (N8103-56/-95/N8190-126) ............................................E-19

Installing Disk Array Controller Driver (N8103-80F/81F) ................................................... E-20

About Windows Activation ...................................................................................................E-21

Available Switch Options for Windows Server 2003 Boot.ini File ....................................... E-23

Setting for Collecting Memory Dump (Debug Information) .....................................................E-24

Appendix F Installing Windows 2000 ........................................................................... F-1

Before Installing Windows 2000..................................................................................................F-1

Optional Board Supported by NEC EXPRESSBUILDER...................................................... F-1

Disk Array Controller (N8103-91) .......................................................................................... F-2

Installing Service Pack ............................................................................................................F-2

Updating System ..................................................................................................................... F-2

Re-installing to the Hard Disk Drive which has been upgraded to Dynamic Disk.................. F-2

Manual Installation when N8103-80F/81F/86 and SCSI HostRAID Keeps Connection ........ F-2

MO Device .............................................................................................................................. F-2

Partition Size ........................................................................................................................... F-3

Installing Windows 2000 ............................................................................................................. F-4

Creating "Windows 2000 OEM-DISK for NEC EXPRESSBUILDER"................................. F-4

Windows 2000 Clean Installation............................................................................................ F-6

Reinstallation to Multiple Logical Drives ............................................................................... F-7

Updating the System - Installing Service Pack - ..................................................................... F-9

Driver Installation and Advanced Settings................................................................................. F-10

PROSet .................................................................................................................................. F-10

Network Driver...................................................................................................................... F-11

Re-install the Network Driver ............................................................................................... F-12

Graphics Accelerator Driver.................................................................................................. F-13

USB 2.0 Driver...................................................................................................................... F-13

Installing SCSI Controller Driver (N8103-65F/75)............................................................... F-14

Installing SCSI Controller Driver (N8103-56/-95/N8190-126) ............................................ F-14

Installing RAID Controller Driver (N8103-80F/81F) ........................................................... F-15

Available Switch Options for Windows 2000 Boot.ini File................................................... F-15

Setting for Collecting Memory Dump (Debug Information) ..................................................... F-16

Appendix G Product Configuration Record Table..................................................... G-1

Hardware .................................................................................................................................G-1

Software...................................................................................................................................G-3

Chapter 1

Notes on Using Your Server

This chapter includes information necessary for proper and safe operation of the server.

1-2 Notes on Using Your Server

WARNING LABELS

The warning label is attached to components with possible danger or their vicinity in your server to
inform the user that a hazardous situation may arise when operating the server. (Do not
intentionally remove or damage any of the labels.)

If you find any labels totally/partially removed or illegible due to damage, contact your service
representative.

Notes on Using Your Server 1-3

SAFETY NOTES

This section provides notes on using the server safely. Read this section carefully to ensure proper
and safe use of the server. For symbols, see "SAFETY INDICATIONS" provided earlier.

General

WARNING

Do not use the server for services where critical high availability may directly
affect human lives.

Your server is not intended to be used with or control facilities or devices
concerning human lives, including medical devices, nuclear facilities and
devices, aeronautics and space devices, transportation facilities and devices;
and facilities and devices requiring high reliability. NEC assumes no liability for
any accident resulting in personal injury, death, or property damage if the server
has been used in the above conditions.

Do not use the server if any smoke, odor, or noise is present.

If smoke, odor, or noise is present, immediately turn off the server and
disconnect the power plug from the outlet, then contact your service
representative. Using the server in such conditions may cause a fire.

Keep needles or metal objects away from the server.

Do not insert needles or metal objects into ventilation holes in the server or
openings in the floppy disk or CD-ROM drive. Doing so may cause an electric
shock.

Do not use the server in any unapproved place.

Install the server on a standard EIA 19-inch rack assembly. Do not install the
rack containing the server in a place inappropriate to the rack installation
environment.
Failure to follow these instructions may cause some bad influences to be
imposed on the server and other systems installed on the rack and also a fire or
personal injury due to falling of the rack may occur. For the detailed
explanation on the place where the server should be installed and the
earthquake-resistant construction for the rack, refer to the manual attached to
the rack or contact you service representative.

Always install the server on a rack conforming to the relevant standard.

Install the server on a rack confirming to the EIA standard for the Server to be
used. Do not use the server with installed on any other rack than standard EIA
19-inch rack or without the installation on a proper rack. Failure to follow these
instructions may cause the server to operate incorrectly and/or personal injury or
damages of surrounding devices to occur. Contact your service representative
for the racks available for the server.

1-4 Notes on Using Your Server

Keep water or foreign matter away from the server.

Do not let any form of liquid (water etc.) or foreign matter (e.g., pins or paper
clips) enter the server. Failure to follow this warning may cause an electric
shock, a fire, or a failure of the server. When such things accidentally enter the
server, immediately turn off the power and disconnect the power plug from the
outlet. Do not disassemble the server. Contact your service representative.

CAUTION

Power Supply and Power Cord Use

Do not hold the power plug with a wet hand.

Do not disconnect/connect the plug while your hands are wet. Failure to follow
this warning may cause an electric shock.

Do not connect the ground wire to a gas pipe.

Never connect the ground wire to a gas pipe. Failure to follow this warning
may cause a gas explosion.

Plug in to a proper power source.

Use a proper wall outlet. Use of an improper power source may cause a fire or
a power leak.
Do not install the server where you need an extension cord. Use of a cord that
does not meet the power specifications of the server may heat up the cord and
cause a fire.

Do not connect the power cord to an outlet that has an illegal number of
connections.

The electric current exceeding the rated flow overheats the outlet, which may
cause a fire.

Insert the power plug into the outlet as far as it goes.

Heat generation resulting from a halfway inserted power plug (imperfect contact)
may cause a fire. Heat will also be generated if condensation is formed on
dusty blades of the halfway inserted plug, increasing the possibility of fire.

Use the authorized power cord only.

Use only the power cord that comes with your server. Use of an unauthorized
power cord may cause a fire when the electric current exceeds the rated flow.
Also, observe the following to prevent an electric shock or fire caused by a
damaged cord.

 Do not stretch the cord harness.
 Do not pinch the power cord.
 Do not bend the power cord.
 Keep chemicals away from the

power cord.

 Do not twist the power cord.
 Do not place any object on the

power cord.

 Do not bundle power cords.

Do not use the attached power cord for any other devices or usage.

The power cord that comes with your server is designed aiming to connect with
this server and to use with the server, and its safety has been tested. Do not use
the attached power cord for any other purpose. Doing so may cause a fire or an
electric shock.

Notes on Using Your Server 1-5

WARNING

CAUTION

 Do not alter, modify, or repair the

power cord.

 Do not secure the power cord with

staples or equivalents.

 Do not use any damaged power

cord. (Replace a damaged power
cord with a new one of the same
specifications. Ask your service
representative for replacement.)

1-6 Notes on Using Your Server

Rack

Do not carry or install the server only by a single person.

More than one person is required to carry or install the rack. Failure to follow
this instruction may cause the rack to fall to result in personal injury and/or
breakages of surrounding devices. In particular, a high rack (such as 44U
rack) is unstable if it is not fixed by stabilizers. More than one person must
always carry or install the rack while they support it.

Do not install the server so that the load may be concentrated on a specific
point.

Install stabilizers on the rack so that the total load of the rack and devices
mounted on the rack is not concentrated on a singe point or join more than one
rack with each other to distribute the load. Failure to follow this instruction may
cause the rack to fall to result in personal injury.

Do not install components on the server only by a single person.

CAUTION

More than one person is required to install parts including the doors and trays for
the rack. Failure to follow this instruction may cause some parts to fall to be
broken and/or to result in personal injury.

Do not pull out a device from the rack if the rack is unstable.

Always pull out a device from the rack in the state that the rack is made stable
(by the installation of stabilizers or earthquake-resistant construction).

Do not leave more than one device being pulled out from the rack.

Pulling out more than one device from the rack may cause the rack to be fallen.
Only pull out a single device from the rack at a time.

Do not provide the wiring for the server to exceed the rating of the power supply.

To prevent burns, fires, and device damages, the power supplied to the power
supply in the rack shall not exceed the rating load of the power branch circuit.
Contact your electric constructor or the local power company for the
requirements on the wiring and installation of electric facilities.

Notes on Using Your Server 1-7

Installation, Relocation, Storage, and Connection

WARNING

Disconnect the power cord(s) before installing or removing the server.

Make sure to power off the server and disconnect the power cord(s) from a
power outlet before installing/removing the server. All voltage is removed only
when the power cords are unplugged.

CAUTION

Never attempt to lift the server only by yourself.

The server weighs max. 30 kg (depending on its hardware configuration).
Carrying the server only by yourself may strain your back. Hold the server
firmly by its bottom with another person to carry it. Do not hold the front door to
lift the server. The front door may be disengaged from the server, causing
personal injury.

Do not install the server in any place other than specified.

Do not install the server in the following places or any place other than specified
in this User's Guide. Failure to follow this instruction may cause a fire.

 a dusty place
 a humid place such as near a boiler
 a place exposed to direct sunlight
 an unstable place

Do not install the server on a rack with leaving covers removed.

Do not install the server on a rack with the cover being removed. Failure to
follow this instruction may reduce the cooling effect in the server to result in
some malfunction and/or dusts to enter the server to result in a fire or electric
shock.

Do not pinch your finger with rails or other components.

Note sufficiently that your fingers may not be caught between a rail and another
mechanical part or cut by a rail at installation or removal of the server from the
rack.

Do not apply any load on the server pulled out from the rack.

Do not apply any load on the server pulled out from the rack. Doing so bends
the frame of the server. Consequently, the server cannot be pushed back into
the rack. Placing an object on the server may also cause personal injury if the
server drops.

1-8 Notes on Using Your Server

Do not connect any interface cable with the power cord of the server plugged to
a power source.

Make sure to power off the server and unplug the power cord from a power
outlet before installing/removing any optional internal device or
connecting/disconnecting any interface cable to/from the server. If the server
is off-powered but its power cord is plugged to a power source, touching an
internal device, cable, or connector may cause an electric shock or a fire
resulted from a short circuit.

Do not use any unauthorized interface cable.

Use only interface cables provided by NEC and locate a proper device and
connector before connecting a cable. Using an authorized cable or connecting
a cable to an improper destination may cause a short circuit, resulting in a fire.
Also, observe the following notes on using and connecting an interface cable.

 Do not use any damaged cable connector.
 Do not step on the cable.
 Do not place any object on the cable.
 Do not use the server with loose cable connections.

CAUTION

Cleaning and Working with Internal Devices

WARNING

Do not disassemble, repair, or alter the server.

Never attempt to disassemble, repair, or alter the server on any occasion other
than described in this User's Guide. Failure to follow this instruction may cause
an electric shock or fire as well as malfunctions of the server.

Do not look into the CD-ROM drive.

A laser beam is used in the CD-ROM drive. Do not look into or insert a mirror
into the drive while the drive is powered. If a laser beam is caught in your eyes,
you may lose your eyesight (the laser beam is invisible).

Do not remove the lithium battery.

The server contains the lithium battery. Do not remove the battery. Placing
the lithium close to a fire or in the water may cause an explosion.

Notes on Using Your Server 1-9

When the server does not operate appropriately due to the dead lithium battery,
contact your service representative. Do not disassemble the server to replace
or recharge the battery by yourself.

Disconnect the power plug before cleaning the server.

Make sure to power off the server and disconnect the power plug from a power
outlet before cleaning or installing/removing internal optional devices.
Touching any internal device of the server with its power cord connected to a
power source may cause an electric shock even of the server is off-powered.

Disconnect the power plug from the outlet occasionally and clean the plug with a
dry cloth. Heat will be generated if condensation is formed on a dusty plug,
which may cause a fire.

CAUTION

Avoid installation in extreme temperature conditions.

Immediately after the server is powered off, its internal components such as
hard disk drives are very hot. Leave the server until its internal components
fully cool down before installing/removing any component.

Make sure to complete board installation.

Always install a board firmly. An incompletely installed board may cause a
contact failure, resulting in smoking or fire.

1-10 Notes on Using Your Server

During Operation

Do not pull out or remove the server from the rack unnecessarily.

Do not pull out or remove the server from the rack unnecessarily. Pulling out or
removing the server from the rack may cause not only the server to operate
incorrectly but also the server to fall on people to make them injured.

Stay away from the fan.

Keep your hand or hair away from the cooling fan on the rear of the server.
Failure to follow this warning may get your hand or hair caught in the fan,
resulting in injury.

Avoid contact with the server during thunderstorms.

Disconnect the power plug from the outlet when a thunderstorm is approaching.
If it starts thundering before you disconnect the power plug, do not touch any
part of the server including the cables. Failure to follow this warning may cause
a fire or an electric shock.

CAUTION

Keep animals away from the server.

Failure to follow this warning may cause a fire or an electric shock.

Do not place any object on top of the server.

The server may fall and cause property damage to the surroundings.

Do not leave the server with its CD-ROM tray ejected.

Dust may enter the server through openings and cause malfunctions of the
server. Any person may also bump it and get injured.

Do not use a cellular phone or pager around the server.

Turn off the cellular phone or pager. Radio interference may cause
malfunctions of the server.

Notes on Using Your Server 1-11

FOR PROPER OPERATION

Observe the following notes for successful operation of the server. Use of the server ignoring the
notes will cause malfunctions or failures of the server.

 Install the rack assembly in a place that meets requirements for successful operation. For

details, see Chapter 3, "Setting Up Your Server."

 The server is intended for installation in a Restricted Access Location, mounted above a

non-combustible material.

 Do not delete the hard disk partition exclusively provided for maintenance of the server

although it may appear on the OS.

 Make sure to power off the server before connecting or disconnecting cables between the

server and peripheral devices.

 Verify that the access LED on the server is unlit before turning off the server or ejecting

the floppy disk.

 The server management logic on your system board monitors and logs system voltage

changes. When plugging the power cord to the system, you may experience 10 seconds
delay from the time you press the POWER switch on the front panel. This is normal
system operation and is required by the server management logic.

 Do not turn off the server until the POST (Power On Self-Test) completes. See Chapter 2

for details of POST.

 When you have just turned off the server, wait at least 30 seconds before turning it back

on.

 Turn off the power and unplug the power cord from the outlet before relocating the server.

 Clean the server on a regular basis. (See Chapter 7 for cleaning.) Regular cleaning

proactively prevents various failures of the server.

 Lightning may cause a momentary voltage drop. To prevent this problem, it is

recommended to use of an uninterruptible power supply unit.

 Check and adjust the system clock before the operation if any of the following conditions

is applicable.

– After carriage of device

– After storage of device

– After the device is entered into the pause state under the environmental condition

enduring device operation (temperature: 10°C - 35°C, humidity: 20% - 80%)

 Check the system clock at the rough rate of once per month. When the system clock is

installed in a system requiring high time precision, it is recommended to use a time server
(NTP server).
If the system clock is remarkably delayed or advanced as the passage of time in spite of
adjustment, contact your service representative to ask maintenance.

1-12 Notes on Using Your Server

 Store the unit under the storage condition (temperature: –10°C - 55°C, humidity: 20% -

80%, without condensation) to allow built-in devices and the unit to operate correctly in
the next operation.

 Make sure to use optional devices supported by the server. Some non-supported devices

may be physically installed/connected but cause failures of the server as well as a
malfunction of the server.

 NEC recommends you use NEC's genuine products. Some third-party products claim

that they support the server. However, repair of the server due to a failure or damage
resulted from use of such third-party products will be charged.

Notes on Using Your Server 1-13

TRANSFER TO THIRD PARTY

The following must be observed when you transfer (or sell) the server or software provided with the
server to a third party:

Server Hardware

Make sure to provide this User's Guide along with the server to a third party.

Provided Software

To transfer or sell any software application that comes with the server to a third party, the following
requirements must be satisfied:

 All provided software applications must be transferred and no backup copies must be

retained.

 Transfer requirements listed in "Software License Agreement" that comes with each

software application must be satisfied.

 Software applications that are not approved for transfer must be uninstalled before

transferring the server.

1-14 Notes on Using Your Server

DISPOSAL AND CONSUMABLES

 Dispose the server, all the internal devices, floppy disks, and CD-ROMs according to all

national laws and regulations.

IMPORTANT: For disposal (or replacement) of the battery on the

mother board of the server, consult with your service representative.

 The server contains some components that are only good for a limited period of time and

require replacement, such as fans, internal batteries, the internal CD-ROM drive, the
floppy disk drive, and the mouse. For stable operation of the server, NEC recommends
you replace these components on a regular basis. Consult with your service
representative for replacement or the product lives.

WARNING

Do not remove the lithium battery.

The server contains the lithium battery. Do not remove the battery. Placing
the lithium or nickel cadmium battery close to a fire or in the water may cause an
explosion.

When the server does not operate appropriately due to the dead lithium battery,
contact your service representative. Do not disassemble the server to replace
or recharge the battery by yourself.

Mother board

Notes on Using Your Server 1-15

USER SUPPORT

Before Asking for Repair, do the following when the server appears to fail:

1. Check if the power cord and the cables to other devices are properly connected.

2. See Chapter 8 to find if your problem fits the description. If it does, take the

recommended measure for it.

3. Check if the software required for operation of the server is properly installed.

If the server still appears to fail after you have taken the above actions, consult with your service
representative immediately. Take notes on LED indications of the server and alarm indications on
the display unit before consultation, which may provide a significant help to your sale agent.

1-16 Notes on Using Your Server

Advice for Health

The longer you keep using the computer equipment, the more you become
tired, which may cause disorders of your body. When you use a
computer, observe the following to keep yourself from getting tired:

Good Working Posture

You have good posture if the following are satisfied when you use a
computer:

• You sit on a chair with your back straight.

• Your hands are parallel with the floor when you put them on the

keyboard.

• You look at the screen slightly lower than your eye height.

You have "good working posture" as described in the above when no part
of your body is under excess strain, in other words when your muscles are
most relaxed.

You have "bad posture" when you sit with your back hunched up or you
operate a display unit with your face close to the screen. Bad working
posture may cause eye strain or poor eyesight.

Adjustment of Display Unit Angles

Most display units are designed for adjustment of the horizontal and
vertical angles. This adjustment is important to prevent the screen from
reflecting bright lights and to make the display contents easy to see. You
will not be able to keep "good working posture" and you will feel more tired
than you should if you operate a display unit without adjusting horizontal
and vertical angles.

Adjustment of Screen Brightness and Contrast

The display unit has brightness and contrast adjustment functions. The
most suitable brightness and contrast depend on the individual and the
working environment (well-lighted room or insufficient light). Adjust
brightness and contrast so that the screen will be easy to see. An
extremely bright or dark screen will give a bad effect to your eyes.

Adjustment of Keyboard Angle

The keyboard provided with the server is designed for adjustment of an
angle. Adjust the keyboard angle at which the keyboard is easy to
operate. The adjustment assists in reducing strain on your shoulders,
arms, and fingers.

Cleaning of Equipment

Clean equipment regularly. It is difficult to see the display contents on a
dusty screen. Keeping equipment clean is also important for your sight.

Fatigue and Rest

If you feel tired, you should stop working and do light exercises.

Chapter 2

General Description

This chapter provides information that you should be familiar with before using the server. It
includes names and functions of the components and features of the server.

OVERVIEW

Your server is a modular, multiprocessing server based on the Intel Xeon microprocessor. It is
a solid performer and offers the latest technology. The combination of compute performance,
memory capacity, and integrated I/O provides a high performance environment for many server
market applications. These range from large corporations supporting remote offices to small
companies looking to obtain basic connectivity capability such as file and print services, e-mail,
web access, web site server, etc.

Your server is housed and available as a rack-mount system. Your server conveniently installs into
a standard EIA 19-inch rack assembly.

Your server includes a 3.5-inch diskette drive, a CD-ROM drive, six hot-swap SCSI hard disk drive
bays, and a removable media device bay. The hot-swap SCSI hard disk drive bays support up to
six 1.0-inch SCSI hard disk drives that can be swapped in or out of the system without powering it
down, if RAID functionality is configured in the system.

The removable media drive bay may be used for installation of a high-speed tape drive.

As application requirements increase, you can expand your server with an additional processor,
additional memory, add-in boards and peripheral devices: tape devices, CD-ROM, and hard disk
drives.

2-2 General Description

External View

1

7

2

3456

1 Drive cover

2 Logic cover

3 Switches, indicators, and front I/Os

4 Optical disk drive (CD-ROM drive)

5 Floppy disk drive

6 Backup file device bay

7 SCSI hot-plug hard disk drive bay

Front View with Front Bezel Closed

The following figure shows the location of the front system features.

General Description 2-3

7

4-1

6

1

1 Front bezel

The front bezel is a cover protecting the front devices during daily operation. A security key
is provided to lock the cover.

2Key slot

Insert the security key into this slot when unlocking the front bezel.

3 STATUS LED (green/amber) (on the front panel)

This LED indicates the server status. The LED is green during normal operation. The LED
turns amber or flashes when the server enters the abnormal state.

4 ACT LED (green)

This LED is on while the system is connected to the network. The number "1" on the icon
indicates LAN port 1, and the number "2" indicates LAN port 2.

5 DISK ACCESS LED (green/amber)

This LED is green during access to the internal hard disk drives. The LED turns amber when
even one of the internal hard disk drives fails.

6 POWER LED (green)

This LED turns green when the power is turned on.

7 UID LED (blue)

This LED goes on when the UID switch is pressed. (The LED also goes on or blinks when
software issues a command.)

ID

3

4-2

5

2

2-4 General Description

Front View with Front Bezel Removed

14

14

14

23-0 3-1 3-2 43-3 3-4 3-5

1

1 Captive thumb screws (1 at the right and left each)

The screws secure the server to the rack.

2 Handles (1 at the right and left each)

Hold the handles when dismounting/mounting the server from/in the rack.

3 Hard disk drive bays

Mount hard disk drives in the bays. Each number following the bold-faced number indicates
the SCSI ID or SAS port number. In the standard configuration, the hard disk drive trays are
mounted in all the bays.

4 DISK LED (green/amber)

Hard disk drive LED. Each hard disk drive LED is green during access to the hard disk drive.
The LED turns amber when the hard disk drive fails. The LED flashes switching back and
forth between green and amber during build processing (in only disk array configuration).

5 CD/FD bay

A CD-ROM or floppy disk drive is mounted.

6 CD-ROM drive

This drive reads data from the CD-ROM.

6-1 Disk access LED
6-2 CD tray eject button
6-3 Emergency hole

7 USB connectors (2 ports)

Connect device compliant with the USB interface to the connectors.

5

10-1 10-2 10-3 98 7

6-1 6-2 6-3

11

12

13

2

1

General Description 2-5

8 Serial port B (COM B) connector

Used to communicate with the remote console via direct connection.

9 Backup device bay

Mount an optional DAT or AIT drive in this bay.

10 3.5-inch floppy disk drive

This drive reads/writes data from/to the 3.5-inch floppy disk.

10-1 Disk access LED
10-2 Disk slot
10-3 Eject button

11 UID (Unit ID) switch

Press this switch to turn on/off the UID LEDs on the front and rear panels of the server.
Pressing the switch once turns on the LEDs. Pressing it again turns them off.

12 POWER switch

Press this switch to turn on/off the power. Pressing the switch once turns on the power, and
the POWER LED goes on. Pressing it again turns off the power. Keep pressing the switch
for 4 seconds or more forcibly turns off the power.

13 DUMP switch (NMI switch)

Press this switch to dump memory.

14 LEDs (See the previous page for the six LEDs.)

2-6 General Description

Rear View

123 4

15 14-1 13 12 11 10 9 8 7 6 5

16 18 16 17-2 1817-1

1 Low-profile PCI board extension slots

Mount PCI boards of the low-profile type into the slots. The slots are called 3C, 2C, and 1C
from top.

2 Captive thumbscrew

Secure the logic cover.

3 Full-height PCI board extension slots

Mount PCI boards of the full-height type in the slots. The slots are called 3B, 2B, and 1B
from top.

4 AC inlet

Connect the attached power cord to this socket.

5AC POWER LED

This LED turns green and flashes when the server receives AC power from the power cord.
The LED turns green when the server power switch is turned on, and it turns amber when a
power failure occurs.

6 Power supply unit (power supply slot 1)

This unit supplies power to the server.

7 Power supply unit extension slot (power supply slot 2)

Mount an optional power supply unit in this slot. The slot is protected with the blank cover
in the standard status.

8 Mouse/keyboard connectors

Connect the mouse and keyboard to the connectors through the provided relay cables.

9 SCSI connector

Connect external SCSI device to this connector.

10 UID LED (blue)

This LED goes on when the UID switch is pressed. (The LED also goes on when software
issues a command.)

14-2

General Description 2-7

11 UID (Unit ID) switch

Press this switch to turn on/off the UID LEDs on the front and rear panels of the server.
Pressing the switch once turns on the LEDs. Pressing it again turns them off.

12 DUMP switch

Press this switch to dump memory.

13 Serial port A (COM A) connector

Connect device having a serial interface to this connector. Use COM B connector to
communicate with the remote console. A leased line cannot be connected directly to this
connector.

14 USB connectors

Connect device compliant with the USB interface to this connector.

15 VGA connector

Connect the display unit to this connector.

16 LINK/ACT LED (green)

This LED indicates the access status of the LAN.

17 LAN connectors

Connect network systems on the LAN to the connectors.
The number "1" following the bold-faced number indicates LAN port 1, and the number "2"
indicates LAN port 2.

18 Speed LED (amber)

This LED indicates the transmission speed of the LAN.

2-8 General Description

Internal View

13-1

13-2

12-1 2-2 34

5

6

13-3

13-4

FRONT REAR

910112-32-412

1 SCSI backplane

2 Cooling fans

2-1: FAN1
2-2: FAN2

3 Support arm

4 Power supply unit

5 Remote management card

6 Mother board

7 Riser card

8 Chassis intrusion switch

9 DIMM (Two DIMMs are mounted as standard in slots #7 and #8.)

10 Processor (mounted under the CPU and heat sink)

11 Processor duct (dashed-line)

12 Front panel board

13 Optional redundant fan slots

13-1: FAN5
13-2: FAN6

2-3: FAN3
2-4: FAN4

13-3: FAN7
13-4: FAN8

7

8

Mother Board

14

13-1

13-2

General Description 2-9

1

234 5 6 78

9

FRONT

11

12

1 Main power connector
2 Lithium battery
3 CMOS clear jumper switch
4 Hard disk drive access LED pin header

(Connect the LED relay cable of an additional SCSI/RAID controller.)

5 Remote management card socket
6 SCSI 1 connector (for SCSI hard disk drives)
7 SCSI 2 connector (for backup file device)
8 Password clear jumper switch
9 Connectors for external device

10 PCI riser card slot

(For full-height boards. 100 MHz/64-bit, 3.3V, PCI-X)

11 PCI riser slot

(For only low-profile boards. 66MHz/64-bit, 3.3V, PCI-X)

12 DIMM sockets (for the interleave type)

(The sockets are called #1, #2, #3, #4, #5, #6, #7, and #8 sequentially from top.)

13 Processor sockets

13-1 Processor #1 (CPU #1) 13-2 Processor #2 (CPU #2)

14 Redundant fan jumper switch

10

REAR

2-10 General Description

STATUS INDICATORS

This section explains the indication and meanings of the server LEDs.

POWER LED ( )

The green POWER LED lights to indicate normal operation while the server is powered. When
the server is off-powered, the POWER LED stays unlit.

The POWER LED indicates that the server is running in the power-saving mode (sleep mode). If
the OS supports the power-saving mode such as Windows Server 2003, running a command blinks
the POWER LED in green and place the server in the power-saving mode. Press the POWER
switch to turn out the POWER LED and place the server back in the normal mode.

The power-saving mode is only available when the OS supports the power-saving feature. Some
OS's allow you to set the server to automatically turn in the power-saving mode when no access is
made to the server for a certain period of time or to select the power-saving mode with a command.

STATUS LED ( )

The STATUS LED is on (green) while the server is operating normally. (The rear panel also has
the STATUS LED on it.) If the STATUS LED is off or turns amber and flashes, it indicates that
the server is in abnormal state.

The table below explains the STATUS LED indication, the meanings, and the procedures.

NOTES:

 If NEC ESMPRO or the offline maintenance utility is installed, you

can confirm the cause of a failure by referring to the error log.

 If shutdown processing can be performed through the operating

system when you want to restart the system after turning the power
off, restart the system by performing shutdown processing. If
shutdown processing cannot be performed, restart the system by
resetting, forcibly turning the power off, or disconnecting and then
connecting the power cord.

General Description 2-11

STATUS LED
indication

Description Procedure

On (green) The server is operating normally. –
Flashing

(green)

• The server is operating with the

memory, CPU in degraded state.

• An uncorrectable memory error

has often occurred.

Off

The power is off. –
POST is in progress. Wait for a while. The STATUS LED

A CPU error occurred.
A CPU temperature alarm was

detected. (IERR)
A timeout occurred when the time

set for the watchdog timer arrived.
A CPU bus error occurred.
A memory dump request is made. Wait until the memory dump is

On (amber)

A temperature alarm was detected. Check if the internal fans are clean

A voltage alarm was detected.
All the power supply units failed.

Flashing
(amber)

Either of the following was detected
in the redundant power
configuration:

• AC power not supplied to one of

the two power supply units

• Failure of one of the two power

supply units

A fan alarm was detected. Check if the fan units are firmly

A temperature warning was
detected.

A voltage warning was detected.

Check the AC POWER LED indication
on the rear panel of the server.
Identify the device in degraded state
by using the BIOS setup utility
"SETUP," and replace it as soon as
possible.

turns green when POST is completed.
Turn the power off and then turn it on.

If the POST screen displays an error
message, take notes of the message,
and contact your service
representative.

completed.

and if the fan units are firmly
connected.
If the STATUS LED indication does not
change when the fans are normal,
contact your service representative.

Contact your service representative.

Connect the power cord to supply
power. If the power supply unit is
faulty, contact your service
representative.

connected.
If the STATUS LED indication does not
change when the fans are normal,
contact your service representative.
Check if the internal fans are clean

and if the fan units are firmly
connected.
If the STATUS LED indication does not
change when the fans are normal,
contact your service representative.

2-12 General Description

DISK ACCESS LED ( )

The DISK ACCESS LED indicates the status of the hard disk drive mounted in the 3.5-inch disk
bay.

The LED turns green each time access is made to the hard disk drive.

When the DISK ACCESS LED turns amber, it indicates that a hard disk drive failure has occurred.
Check the hard disk drive LED for the status of the failing hard disk drive.

IMPORTANT: If a hard disk drive in the server is connected to the
internal disk array controller (which is additionally mounted), the
access LED signal cable (connected to the connector on the mother
board) must be connected from the disk array controller to the mother
board.

ACT LED ( )

The ACT LED is green while the server is connected to the LAN. The LED flashes while the
server is accessed via the LAN (during transmission/reception of packets). The number next to the
icon indicates the network port number on the rear panel of the server.

UID LED (UID)

Pressing the UID switch toggles the front panel UID LED (blue) and the mother board UID LED on
and off. The mother board UID LED is visible through the rear of the chassis and allows you to
locate the server you're working on from the rear of the servers on a rack.

Disk Access LED

The disk access LED of the floppy disk drive or CD-ROM drive is on while the drive is accessed.

General Description 2-13

Hard Disk Drive LED

The disk LED mounted in the 3.5-inch disk bay indicates the following depending on the status:

LED

 Flashing (green)

The LED indicates that the hard disk drive is accessed.

 On (amber)

The LED indicates a failure of a hard disk drive mounted in disk array configuration.

NOTE: Even if one of the hard disk drives fails in disk array
configuration (RAID1 or RAID5), the server can continue operation.
However, replace the disk as soon as possible, and perform
reconstruction (rebuild) processing. (The failing disk can be replaced
in hot swap mode.)

 Flashing switching back and forth between green and amber

The LED indicates that reconstruction (rebuild) processing is being performed for the hard
disk drive. (This flashing does not indicate a failure.) When a failing hard disk drive is
replaced in disk array configuration, the system automatically rebuilds the data. (Auto­rebuild function) The LED switches back and forth between green and amber during
rebuild processing.

The LED goes off when the rebuild processing has terminated. It turns amber when the
rebuild processing fails.

IMPORTANT: If the server is turned off during rebuild processing, the
processing is stopped. Restart the server, mount the new hard disk
drive in hot swap mode, and then perform rebuild processing again.
Observe the following notes on using the auto-rebuild function.

 Do not turn the power off. (Once the power is turned off, the auto-

build function does not start.)

 Let 90 seconds or more pass between when dismounting a failing

hard disk drive and when mounting the new one.

 Do not replace a failing hard disk drive while rebuild processing is

being performed for another hard disk drive.

2-14 General Description

LAN Connector LEDs

There are two LEDs for each of the two LAN ports (connectors) on the rear panel.

Speed LEDs

LINK/ACT LEDs

LINK/ACT LED



Each LINK/ACT LED indicates the status of the standard network port of the server.
While power is supplied to the server and HUB and the connection is correct, the LED is
on (green). The LED turns green and flashes while the network port is
transmitting/receiving data.

If the LED does not go on when the LINK state is placed, check if the network cable is in
normal state and if it is connected correctly. If the LED does not go on yet when the
network cable is normal, the network (LAN) controller may be faulty. In this case,
contact your service representative.

 Speed LED

This LED indicates whether each of the network ports normally equipped with the server
is operated through the 1000BASE-T, 100BASE-TX or 10BASE-T network interface. If
the LED is lit amber, the network port is operated through 1000BASE-T. If the LED is
lit green, the network port is operated through 100BASE-TX. If the LED is off, the
network port is operated through 10BASE-T.

General Description 2-15

A

AC POWER LED

There is an AC POWER LED for the power supply unit on the rear. The LED turns green and
flashes when the power supply unit receives AC power from the power cord, which is connected to
the AC inlet.

The LED turns green when the server power switch is turned on. If the LED does not go on when
the server power switch is turned on or if it turns or blinks amber, the power supply unit is probably
faulty. In this case, contact your service representative to replace the power supply unit.

C inlet

Power supply
slot 2

AC POWER LED

NOTE: If one power supply unit fails while an optional power supply
is mounted, the system can continue operation with the other power
supply unit. (Redundant function) The failing power supply unit can
be replaced in hot swap mode (with the power on) without the system
being stopped.

Power supply
slot 1

2-16 General Description

STANDARD FEATURES

High performance Expandability

 Intel

 High-speed network interface

 High-speed disk access

 High-speed memory access (DDR2-400)

High-reliability Many Available Features

 Memory monitoring feature (error

 CPU/memory degradation feature (logical

 Memory chipkill feature
 Bus parity error detection
 Temperature detection
 Error notification
 Internal fan monitoring feature
 Internal voltage monitoring feature
 Redundant power supply (hot-swap)
 Onboard RAID 0/1
 Auto-rebuild feature (hot-swappable)
 BIOS password feature
 Mechanical security lock
 Remote Management Card
 Redundant fans (option)

Management Utilities Easy and Fine Setup

 NEC ESMPRO
 NEC DianaScope

Maintenance Features

 Off-line Maintenance Utility
 Memory dump feature using the DUMP

 Xeon Processor

(3.20DGHz / 3.20GHz / 3.40GHz /

3.60GHz / 3.80GHz)

(1000Mbps/100Mbps/10Mbps supported)

(Ultra320 SCSI)

correction/error detection)

isolation of a failed device)

switch

 Three full-length, full-height 64-bit/100

MHz PCI-X riser slots and three low
profile 64-bit/66 MHz riser slots

 Large memory of up to 16 GB
 Six hot-swap SCSI hard disk drive bays
 Up to two multi-processors are available

for upgrade.

 One backup file bay
 USB2.0 interface (A USB-support driver

is required.)

 Two network ports

 Graphic accelerator "ATI RADEON 7000"

support

 El Torito Bootable CD-ROM (no

emulation mode) format support

 POWER switch mask
 Software power-off
 Remote power-on feature
 AC-Link feature
 Consoleless feature

Self-diagnosis

 Power On Self-Test (POST)
 Test and Diagnosis (T&D)

 NEC EXPRESSBUILDER (system setup

utility)

 Configuration Parameter Diskette Creator
 SETUP (BIOS setup utility)
 SCSISelect (SCSI device utility)

General Description 2-17

Power Supplies

The power supply consists of the power supply bay and one power supply module. A second power
supply module can be purchased to provide a redundant, 1+1 system. With either configuration, the
power supply provides 600 watts of power and is designed to minimize EMI.

The power subsystem supports implementation of remote management features including remote
enable that permits power to be activated from a variety of sources.

Peripheral Bays

Your server supports a variety of standard PC AT-compatible peripheral devices. The chassis
includes these peripheral bays:

 An optional removable media front panel bay for mounting a half-height 3.5-inch

peripheral device such as an optional tape drives

 Depending on your configuration, your server includes six hot-swap SCSI hard disk drive

bays for mounting hard disk drives installed in easily removable drive carriers.

NOTE: The hot-swap SCSI hard disk drive bays contain a hot-swap
back plane that require an 80-pin single connector attachment (SCA)
connector on the drives that you install.

 The CD/FD bay includes the standard CD-ROM/FDD module.

2-18 General Description

SAF-TE LOGIC

NOTE: SAF-TE Logic is in systems that include the hot-swap SCSI

disk drive cage. SAF-TE Logic is not available in systems that
include the standard SCSI disk drive cage.

The SCSI backplane includes SAF-TE (SCSI Accessed Fault Tolerant Enclosure) logic that provides
an interface to the disk subsystem that supports status signals, hot swapping drives, and enclosure
monitoring.

The transport mechanism for the standardized alert detection and status reporting is the SCSI bus.
Disk drives, power supplies, cooling fans, and temperature are continually monitored and the
conditions then reported over the SCSI bus to the system. When used with RAID management
software the user can be alerted of impending or imminent disk conditions requiring attention.
This allows the user to react to conditions that could normally go unnoticed until data loss.

SYSTEM BOARD FEATURES

The following subsections describe the system board major components.

Processor

The system board accommodates one or two Intel Xeon processors with 1MB cache in the
INT3/FCPGA socket package. This processor uses the .13 micron technology and offers advanced
performance. The processor external interface operates at a maximum of 800 MHz.

Memory

The system board contains six 240-pin DIMM slots each supporting 72-bit ECC (64-bit main
memory plus ECC) registered SDRAM DIMMs (DDR2 400 compatible). Memory is two-way
interleaved and partitioned in three groups. You may install a minimum of 1GB (512MB × 2) and as
much as 16 GB.

The controller automatically detects, sizes, and initializes the memory array, depending on the type,
size, and speed of the installed DIMMs, and reports memory size and allocation to the server via
configuration registers.

NOTE: Use DIMMs that have been tested for compatibility with the
server board.
Contact your service representative or dealer for a current list of
approved memory modules.

General Description 2-19

PCI Riser Slots

The mother board has two PCI riser slots. Riser slot B provides the following features:

 Bus speed up to 100 MHz

 184 pin, 5 volt keyed, 64-bit expansion slot connector

 Support for a 3-slot PCI riser card

 Support for both full length and low profile PCI cards

Riser C provides the following features:

 Bus speed up to 66 MHz

 184 pin, 5 volt keyed, 64-bit expansion slot connector

 Support for a 3-slot PCI riser card

 Support for only low profile PCI cards

Video

The mother board uses an ATI RADEON 7000 PCI graphics accelerator with 8 MB of video
SDRAM. The embedded SVGA video subsystem supports:

 Resolutions up to 1600 x 1200 under 2D and 1024 x 768 under 3D

 CRT and LCD monitors up to 100 Hz vertical refresh rate

The mother board supports disabling of the onboard video through the BIOS setup menu or when a
plug in video card is installed in any of the PCI slots.

SCSI Controller

The SCSI version of the server board includes an embedded Adaptec AIC-7902 controller providing
dual Ultra320 Low Voltage Differential (LVD) SCSI channels.

The SCSI bus is terminated on the server board with active terminators that cannot be disabled. The
onboard device must always be at one end of the bus. The device at the other end of the cable must
also be terminated. LVD devices generally do not have termination built-in and need to have a
termination source provided. Non-LVDs devices generally are terminated through a jumper or
resistor pack on the device itself.

2-20 General Description

Network Controller

NOTE: To ensure EMC product regulation compliance, the system

must be used with a shielded LAN cable.

The mother board uses a dual-channel Ethernet Controller and supports 10Base-T/100Base­TX/1000Base-T network subsystems.

The network controller supports the following features:

 64-bit, 100 MHz PCI-X interface

 Integrated IEEE 802.3 10Base-T, 100Base-TX, and 1000Base-T compatible PHY

 IEEE 820.3u auto-negotiation support

 Chained memory structure similar to the 82559, 82558, 82557 and 82596

 Full duplex support at both 10 Mbps, 100 Mbps, and 1000 Mbps operation

 Low power +3.3 V device

On the system board, NIC 1 can be used as both a network interface and server management
interface.

Keyboard and Mouse

The keyboard/mouse controller is PS/2-compatible. A Y-cable can be used if both a PS/2 mouse and
keyboard are required at the same time.

ACPI

The mother board supports the Advanced Configuration and Power Interface (ACPI) as defined by
the ACPI 2.0 specifications. An ACPI aware operating system can put the system into a state where
the hard drives spin down, the system fans stop, and all processing is halted. However, the power
supply will still be on and the processors will still be dissipating some power, so the power supply
fans will still run.

The system board supports sleep states s0, s1, s4, and s5:

 s0: Normal running state.

 s1: Processor sleep state. No context will be lost in this state and the processor caches will

maintain coherency.

 s4: Hibernate or Save to Disk: The memory and machine state are saved to disk. Pressing

the power button or other wakeup event will restore the system state from the disk and
resume normal operation. This assumes that no hardware changes have been made to the
system while it was off.

 s5: Soft off: Only the RTC section of the CSB and the BMC are running in this state. No

context is saved by the OS or hardware.

IMPORTANT: The system is off only when the AC power cord is
disconnected.

General Description 2-21

Remote Management Card (RMC)

Server management is concentrated in the Remote Management Card (RMC). The RMC and
associated circuitry are powered from a 5Vdc standby voltage, which remains active when system
power is switched off, but the ac power source is still on and connected.

The RMC supports the NEC DianaScope, which allows remote server management through
networks. Events monitored by the manager system include over-temperature and over-voltage
conditions, fan failure, or chassis intrusion.

Information on NEC DianaScope may be found in the NEC EXPRESSBUILDER CD-ROM.

One major function of the RMC is to autonomously monitor system management events, and log
their occurrence in the nonvolatile System Event Log (SEL). The events being monitored include
overtemperature and overvoltage conditions, fan failure, or chassis intrusion. To enable accurate
monitoring, the RMC maintains the nonvolatile Sensor Data Records (SDRs), from which sensor
information can be retrieved. The RMC provides an ISA host interface to SCR sensor information,
so that software running on the server can poll and retrieve the server's current status.

The RMC performs the following:

 Monitors server board temperature and voltage*

 Monitors processor presence and controls Fault Resilient Boot (FRB)

 Detects and indicates baseboard fan failure*

 Manages the SEL interface

 Manages the SDR Repository interface

 Monitors the SDR/SEL timestamp clock

 Monitors the system management watchdog timer

 Monitors the periodic SMI timer

 Monitors the event receiver

 Controls secure mode, including video blanking, diskette write-protect monitoring, and

front panel lock/unlock initiation

 Controls Wake On LAN via Magic Packet support.

*Also, NEC ESMPRO supports these features.

2-22 General Description

DEGRADATION FEATURE

The degradation feature automatically isolates a failed DIMM or processor to assure continuous
operation of the server when the POST (Power On Self-Test, self-diagnosis program after power on)
detects such a DIMM or processor.

NOTE: The degradation feature is only available when at least two

DIMMs or processors are installed.

Failed DIMMs and processors may be identified on the screen that the POST displays, or with the
BIOS setup utility of the server, "SETUP." They may also be identified on the system that has the
NEC ESMPRO installed.

REMOTE POWER-ON FEATURE (WAKE ON LAN)

The remote power-on function turns on the server through a network. It sends a special packet
from the management computer to a remote server to turn it on if the server is off-powered.

To enable this feature, use the BIOS setup utility, "SETUP." (See Chapter 4.)

The remote power-on feature is not available in the following cases. Press the POWER switch
once to start the OS, and turn off the server in an appropriate procedure.

 Abnormal previous system shut-down

 No power supply to the server (due to turned-off breaker, disconnected power cord, power

blackout, etc.)

AC-LINK FEATURE

When the power cord of the server is connected to an uninterruptible power supply (UPS) unit, the
server supports the power linkage feature that enables control over the power supply from the UPS
to the server. The AC-Link feature can be enabled or disabled with the Server menu of the BIOS
setup utility, "SETUP." (See Chapter 4.)

General Description 2-23

SYSTEM SECURITY

To help prevent unauthorized entry or use of the system, the system includes a full lockable front
bezel and Server Management software that monitors the front bezel intrusion switch.

Security with Mechanical Locks and Monitoring

To unlock the bezel, insert the key in the lock and turn the lock counterclockwise until it stops
(about a quarter turn). The bezel is now unlocked and can be opened again.

To lock the bezel, insert the key in the lock. Turn the lock clockwise until it stops (about a quarter
turn). The bezel is now locked and cannot be opened.

Software Locks via the BIOS Setup Utility

The BIOS Setup Utility provides a number of security features to prevent unauthorized or accidental
access to the system. Once the security measures are enabled, you can access the system only after
you enter the correct password(s). For example:

 Enable the keyboard lockout timer so that the server requires a password to reactivate the

keyboard and mouse after a specified time out period – 1 to 120 minutes.

 Set and enable a supervisor password.

 Set and enable a user password.

 Set secure mode to prevent keyboard or mouse input and to prevent use of the front panel

reset and power switches.

 Activate a hot key combination to enter secure mode quickly.

 Disable writing to the diskette drive when secure mode is set.

 Disable access to the boot sector of the operating system hard disk drive.

2-24 General Description

Using Passwords

You can set either the user password, the supervisor password, or both passwords. If only the user
password is set, you:

 Must enter the user password to enter BIOS Setup.

 Must enter the user password to boot the server if Password on Boot is enabled in the

BIOS Setup.

 Must enter the user password to exit secure mode.

If only the supervisor password is set, you:

 Must enter the supervisor password to enter BIOS Setup.

 Must enter the supervisor password to boot the server if Password on Boot is enabled in

the BIOS Setup.

 Must enter the supervisor password to exit secure mode.

If both passwords are set, you:

 May enter the user password to enter BIOS Setup. However, you will not be able to

change many of the options.

 Must enter the supervisor password if you want to enter BIOS Setup and have access to all

of the options.

 May enter either password to boot the server if Password on Boot is enabled in either the

BIOS Setup.

 May enter either password to exit secure mode.

Secure Mode

Configure and enable the secure boot mode by using the BIOS Setup. When secure mode is in
effect:

 You can boot the server and the operating system will run, but you must enter the user

password to use the keyboard or mouse.

 You cannot turn off system power or reset the server from the front panel switches.

Secure mode has no effect on functions enabled via remote server management or power control via
the watchdog timer.

Taking the server out of secure mode does not change the state of system power. That is, if you
press and release the power switch while secure mode is in effect, the system will not be powered
off when secure mode is later removed. However, if the front panel power switch remains depressed
when secure mode is removed, the server will be powered off.

General Description 2-25

Summary of Software Security Features

The table below lists the software security features and describes what protection each offers. In
general, to enable or set the features listed here, you must run the BIOS Setup and go to the Security
Subsystem Group, menu. The table also refers to the Setup utility.

Software Security Features

Feature Description

Secure mode How to enter secure mode:

• Setting and enabling passwords automatically places the system in

secure mode.

• If you set a hot-key combination (through Setup), you can secure the

system simply by pressing the key combination. This means you do not
have to wait for the inactivity time-out period.

When the system is in secure mode:

The server can boot and run the operating system, but mouse and
keyboard input is not accepted until the user password is entered.

At boot time, if a CD is detected in the CD-ROM drive or a diskette in drive
A, the system prompts for a password. When the password is entered, the
server boots from CD or diskette and disables the secure mode.

If there is no CD in the CD-ROM drive or diskette in drive A, the server
boots from drive C and automatically goes into secure mode. All enabled
secure mode features go into effect at boot time.

To leave secure mode: Enter the correct password(s).

Disable writing to
diskette

Set a time out period
so that keyboard
and mouse input are
not accepted.

Also, screen can be
blanked, and writes
to diskette can be
inhibited

Control access to
using the BIOS
Setup: set
supervisor password

In secure mode, the server will not boot from or write to a diskette unless a
password is entered.

To write protect access to diskette whether the server is in secure mode or
not, use the Setup main menu, Floppy Options, and specify Floppy Access
as read only.

Specify and enable an inactivity time out period of from 1 to 120 minutes.

If no keyboard or mouse action occurs for the specified period, attempted
keyboard and mouse input will not be accepted.

The monitor display will go blank, and the diskette drive will be write
protected (if these security features are enabled through Setup).

To resume activity: Enter the correct password(s).

To control access to setting or changing the system configuration, set a
supervisor password and enable it through Setup.

If both the supervisor and user passwords are enabled, either can be used
to boot the server or enable the keyboard and/or mouse, but only the
supervisor password will allow Setup to be changed.

To disable a password, change it to a blank entry in the Change Password
menu of the Supervisor Password Option menu found in the Security
Subsystem Group.

To clear the password if you cannot access Setup, change the Clear
Password jumper (see Chapter 4).

2-26 General Description

Feature Description

Control access to
the system other
than BIOS Setup:
set user password

Boot without
keyboard

Specify the boot
sequence

To control access to using the system, set a user password and enable it
through Setup.

To disable a password, change it to a blank entry in the Change Password
menu of the User Password Option menu found in the Security Subsystem
Group.

To clear the password if you cannot access Setup, change the Clear
Password jumper (see Chapter 4).

The system can boot with or without a keyboard. During POST, before the
system completes the boot sequence, the BIOS automatically detects and
tests the keyboard if it is present and displays a message.

The sequence that you specify in setup will determine the boot order. If
secure mode is enabled (a user password is set), then you will be
prompted for a password before the server fully boots. If secure mode is
enabled and the “Secure Boot Mode” option is also enabled, the server will
fully boot but will require a password before accepting any keyboard or
mouse input.

General Description 2-27

NEC EXPRESSBUILDER

The CD-ROM that comes with the server contains a setup utility called "NEC
EXPRESSBUILDER."

The major functions of the NEC EXPRESSBUILDER are:

 To install the Operating System.

"Express Setup" helps you to install the Windows Operating System. (See Chapter 5)

 To diagnose the system.

NEC EXPRESSBUILDER includes the System Diagnostics to check your server. (See
Chapter 6)

 To create a support disk.

Use this function to create the support disks used to boot the utilities from the floppy disk,
or the OEM floppy disk used for a manual installation of Windows. (See Chapter 6)

 To update the BIOS.

Use this function to update the system BIOS or firmware of the server. (See Chapter 6)

 To update the Windows System*

"Update Express5800 system" in Master Control Menu(Windows-based NEC
EXPRESSBUILDER feature) updates the several resources of Microsoft Windows Server
2003, Microsoft Windows 2000. (See Chapter 6)

 To install the utilities.

NEC EXPRESSBUILDER includes some management software for Windows (NEC
ESMPRO, NEC DianaScope and so on) and maintenance utilities for DOS (System
diagnostics, Off-line Maintenance Utility and so on).
You can install the applications for Windows from Master Control Menu and install the
utilities for DOS from Tools menu. (See Chapter 6)

 To read the online documents*

You can refer to the online documents from Master Control Menu. (See Chapter 6)

* These functions are available under the Windows system.

NOTE: Some features among those listed above can be used from the

remote computer via cross cable (COM), or LAN. See Chapter 6 for
details.

2-28 General Description

NEC ESMPRO

The NEC ESMPRO is server management software that runs on the OS. The NEC ESMPRO
includes the NEC ESMPRO Manager for the server monitoring terminal and the NEC ESMPRO
Agent for the server.

NOTE: For details of major functions of the NEC ESMPRO, system

configuration and setups with the NEC ESMPRO, see Chapter 6.
Available functions of the NEC ESMPRO depend on the OS you install.
Ask your service representative for details.

OFF-LINE MAINTENANCE UTILITY

The Off-line Maintenance Utility is used for maintenance and fault analysis of the server. This
utility is usually used by the service representative.

Refer to Chapter 8 for details.

SYSTEM DIAGNOSTIC UTILITY

The system diagnostic utility contained in the NEC EXPRESSBUILDER is useful to detect
hardware failures. See Chapter 7 for details.

NEC DianaScope

The NEC DianaScope is a software for the remote management of the NEC Express5800 series.
The NEC DianaScope can control the managed server even if OS is not running on the managed
server.

See Chapter 6 and online document in the NEC EXPRESSBUILDER.

General Description 2-29

USING YOUR SERVER

This section describes basic operations of the server including how to use devices such as the floppy
disk drive and the CD-ROM drive. See Appendix B for notes on using the floppy disk, CD-ROM,
and accessories including the keyboard and the mouse.

Front Bezel

Remove the front bezel to power on/off the server, to access the floppy disk drive, CD-ROM drive,
and a removable media device, and to install/remove hard disk drives to the 3.5-inch disk bays.

IMPORTANT:

 To open the front door, you must unlock the door with the provided

security key.

 Pay attention not to press the POWER switch when you install or

remove the front bezel.

Installing or Removing the Front Bezel

When turning the power of the server on/off, accessing to the floppy disk drive, CD-ROM drive, or
a removable media device, or installing or removing a hard disk drive on or from the 3.5-inch disk
bay, first remove the front bezel.

IMPORTANT: The front bezel can be opened only when you unlock

it by using the attached security key.

1. Insert the attached security key into the key slot and turn the key to the front bezel side

with it pressed lightly to release the lock.

Unlock Lock

2. Hold the right end of the front bezel lightly to pull it toward you.

2-30 General Description

3. Slide the front bezel to the left a little to remove the tab from the frame and then remove

the front bezel from the server.

To install the front bezel, latch the tab at the left side of the front bezel on the server frame.
After the installation, lock the front bezel by using the key for security.

Frame

Ta b

1

2

POWER Switch

Use the POWER switch to turn on/off the server.

Power On

Press the POWER switch on the front of the computer chassis.

The POWER LED lights in green.

General Description 2-31

POWER LED

IMPORTANT:

 If the power cord is connected to a power control device such as a

UPS (Uninterruptive Power Supply), make sure that the power
control device is powered.

 The server management logic on your system board monitors and

logs system voltage changes. When plugging the power cord to
the system, you may experience 10 seconds delay from the time you
press the POWER switch on the front panel. This is normal
system operation and is required by the server management logic.

POWER

switch

 Always allow POST to complete before powering down your

system.

2-32 General Description

POST

POST (Power On Self-Test) is the self-diagnostic program stored in the system memory.

When you power on the server, the system automatically runs POST to check the mother board,
ECC memory module, CPU module, keyboard, and mouse. POST also displays messages of the
BIOS setup utility, such as the start-up message, while in progress.

With the factory setup of the server, the NEC logo appears on the display unit while POST is in
progress. (To display the POST check results, press Esc.)

NOTE: You can set the POST check results to appear on the display

unit without pressing Esc. To do so, select "Enabled" for "Boot-time
Diag Screen" under the Advanced menu of the BIOS SETUP utility.

The POST check results should be checked in the following cases.

 When the server is used for the first time.

 When the server appears to fail.

 When the server beeps for many times between power-on and OS start-up.

 When an error message appears on the display unit.

General Description 2-33

POST Execution Flow

The following describes the progress of POST in the chronological order.

IMPORTANT:

 Do not make key entries or perform mouse operations while POST

is in progress.

 Some system configurations may display the message "Press Any

Key" to prompt a key entry. This message is driven by BIOS of an
installed optional board. Make sure to read the manual that comes
with the optional board before any key entry.

 Powering on the server, after you installed or removed an optional

PCI board or moved it to another slot, may display the message that
indicates incorrect board configuration and suspend POST.
In such a case, press F1 to continue POST. Board configuration
can be made using the utility described later.

1. After a few seconds from power-on, POST starts checking the memory. The count

message of the basic and expansion memory appears at top left on the display unit screen.
The memory check may takes a few minutes to complete depending on the memory size
of the server. Also, it may take approximately one minute for the screen display to
appear after rebooting the server.

2. Some messages appear upon completion of the memory check. These messages appear

to indicate that the system has detected the CPU, keyboard, and mouse.

3. POST then detects the internal SCSI controller and display the message prompting you to

launch the SCSI device utility. (Ignore the message. POST will automatically proceed
a few seconds later.)

Press <Ctrl> <A> for SCSISelect(TM) Utility!

To launch the SCSI device utility, press Ctrl and A. See Chapter 4 for setup and
parameters.

You need to use the SCSI device utility in the following cases:

– When new SCSI device is installed in a backup device bay.

– When an external SCSI device connection is changed.

– When the internal SCSI device connection is changed.

– When the internal hard disk drives are configured with HostRAID.

The server automatically restarts POST all over again when you exit the SCSI device
utility.

If the system drive is to be connected to a RAID controller, connect it to the PCI slot that
has a highest boot priority than the PCI slots connected with the other RAID controller.
Refer to "PCI Board" in chapter 9 for the boot order for the RAID controller.

2-34 General Description

4. POST displays SCSI ID numbers used by the connected SCSI devices on the screen.

5. After a few seconds, POST displays the following message prompting you to launch the

BIOS setup utility, SETUP, stored in the system memory of the server. This message
appears at bottom left on the screen.

Press <F2> to enter SETUP

Launch the BIOS setup utility when you need to change the settings to meet the
requirements for the server. As long as the above message is not displayed with an error
message, you don't have to launch the utility. (Ignore the message. POST will
automatically proceed.)

To launch the SETUP utility, press F2 while the above message is displayed. See
Chapter 4 for setup and parameters.

The server automatically restarts POST all over again when you exit the SETUP utility.

6. If the server has an optional RAID controller installed, POST displays the message

prompting you to launch the RAID configuration utility and the RAID BIOS setup utility.

Refer to the manual supplied with the RAID controller for detail instructions.

POST will automatically proceed a few seconds later.

7. If you set a password using the BIOS setup utility, SETUP, the password entry screen

appears upon successful completion of POST.

Up to three password entries will be accepted. Three incorrect password entries disable
the server to boot. In such a case, turn off the power and wait about ten seconds before
turning on to boot the server.

IMPORTANT: Do not set a password before installing an OS.

8. The OS starts when POST completes.

General Description 2-35

POST Error Messages

When POST detects an error, it displays an error message on the display unit screen. See Chapter
8 for POST error codes.

IMPORTANT: Take a note on the messages displayed before

consulting with your service representative. Alarm messages are
useful information for maintenance.

Power Off

Follow the procedure below to power off the server. If the power cord of the server is connected to
a UPS, refer to the manual that comes with the UPS or the manual for the application that controls
the UPS.

IMPORTANT: Always allow POST to complete before turning off

the server.

1. Shut down the OS.

2. Press the POWER switch on the front of the server.

The POWER LED goes off.

3. Power off peripheral devices.

2-36 General Description

Identification of Servers (UID Switch)

An "UID (Unit ID) LED" is provided on the front panel and rear panel. If more than one server is
mounted in a single rack, the LED identifies the server you are going to maintain.

The UID LED goes on when the UID (Unit ID) switch on the front panel is pressed. It goes off
when the switch is pressed again.

Maintenance from the rear of the rack has to be carried out in a dark, narrow space. The interface
cable of a server or power supply unit in normal state may be disconnected by accident in this
situation. To prevent this problem, you should start maintenance after confirming the target server
by using the UID switch.

UID LED

UID

switch

FRONT

REAR

UID switch

UID LED

General Description 2-37

Floppy Disk Drive

The server is provided with the 3.5-inch floppy disk drive on its front to write/read data to/from a
floppy disk.

The server supports the following 3.5-inch floppy disks:

 2HD floppy disk (double-sided high-density track type)

Stores data of 1.44MB.

 2DD floppy disk (double-sided double-density track type)

Store data of 720KB.

Make sure that the server is powered (the POWER LED is lit) before inserting a floppy disk into the
floppy disk drive.

When you completely insert the floppy disk into the floppy disk drive, the drive clicks and the eject
button on the floppy disk is slightly pushed out.

NOTES:

 When an unformatted floppy disk is inserted, the message notifying

that date read is not available and the message prompting formatting
are displayed. Refer to the manual that comes with the OS to
format the floppy disk.

 If the floppy disk contains a system, powering on or restarting the

server with the floppy disk inserted boots the system from the
floppy disk.

To eject the floppy disk from the floppy disk drive, press the eject button.

NOTE: Make sure that the floppy disk access LED is unlit before

ejecting the floppy disk. Ejecting the disk when the access LED is lit
may destroy the disk data.

2-38 General Description

NOTE: Use of the floppy disk

The floppy disk is an important data storage media with delicate
structure and requires care. Keep the following notes in mind to use
it:

 Insert the floppy disk into the floppy disk drive gently as far as it

goes.

 Attach the label to the correct position.

 Do not write anything directly onto the disk surface with a pencil or

ball-point pen.

 Do not open the shutter.

 Do not use the floppy disk in a dusty place.

 Do not place anything on the floppy disk.

 Do not leave the floppy disk in a high-temperature place (e.g., place

exposed to direct sunlight or close to a heater).

 Keep the floppy disk away from cigarette smoke.

 Keep the floppy disk away from any liquid (e.g., water) and

chemicals.

 Keep the floppy disk away from any magnetic objects (e.g.,

magnet).

 Do not pinch the floppy disk with a paper clip or drop it.

 Keep the floppy disk in a floppy disk case that protects it from

magnetism and dust.

 A floppy disk has a write-protect switch that prevents the stored data

from accidental erasure. You can read data from a write-protected
floppy disk, but you cannot save data into the floppy disk or format
it. NEC recommends that you should write-protect any floppy disk
containing valuable data unless you are about to save data. To
write-protect a 3.5-inch floppy disk, use the write-protect switch
provided on its back.

Write-protect switch

Write

disable

 The floppy disk is a very delicate storage media. Dust or thermal

Write

enable

changes, as well as operator's misconduct or sever failures, may
cause loss of data. To avoid loss of data, NEC recommends that
you should make a back-up copy of your valuable data on a regular
basis. (Make sure to make a back-up copy of every floppy disk
provided with the server.)

General Description 2-39

CD-ROM Drive

The server is provided with the CD-ROM drive on its front to read data from a CD-ROM (read-only
compact disk). The CD-ROM provides larger and faster data read than the floppy disk.

CAUTION

Observe the following instructions to use the server safely. Failure to follow
these instructions may cause a fire, personal injury, or property damage. See
pages 1-3 to 1-8 for details.

 Do not leave the tray ejected from the CD-ROM drive.

Set a CD-ROM on the CD-ROM drive in the following procedure.

1. Confirm that the power of the server is on (with the POWER LED being lit in green)

before setting the CD-ROM on the CD-ROM drive.

2. Press the Eject button on the front of the CD-ROM drive.

The tray comes out a little.

3. Hold the tray lightly and pull it out toward you until the tray stops.

4. Put the CD-ROM on the tray carefully and securely with the character printed surface

facing upward.

2-40 General Description

r

5. As shown in the figure below, hold the tray with a hand and press the CD-ROM with

fingers of another hand to make the hole of the CD-ROM fit to the rotor at the center of
the tray.

Roto

Press this part of CD-ROM.

6. Push the front of the tray lightly to retract it into the drive.

IMPORTANT: If a noisy sound in driving the CD-ROM drive occurs

after setting a CD-ROM, set it again correctly.

To take out the CD-ROM from the CD-ROM drive, press the Eject button in the similar way in
setting the CD-ROM to make the tray go out.

If the access LED is lit in orange, the CD is being accessed. Confirm that the access LED is not lit
before pressing the Eject button.

As shown in the figure below, hold the tray with a hand and take the end of the CD-ROM lightly by
the fingers of another hand with the suppression of the rotor at the center of the tray to remove the
CD-ROM from the tray.

General Description 2-41

After taking out the CD-ROM, return the tray into the drive.

When you fail to eject the CD-ROM tray with the Eject button and take out the CD-ROM from the
server, follow the procedure below.

Emergency hole

1. Press the POWER switch to power off the server. (The POWER LED goes off.)

2. Insert a metal pin of approximately 1.2 mm in diameter and 100 mm in length (a

straightened large paper clip will make a substitute) into the emergency hole on the right
front of the CD-ROM drive and gently push it in until the tray is ejected.

IMPORTANT:

 Do not use a toothpick or plastic stick that is easy to break.

 If the above procedure does not let you take out the CD-ROM,

contact your service representative.

3. Hold the tray and pull it out.

4. Take out the CD-ROM.

5. Push the tray back into position.

2-42 General Description

NOTE: Use of the CD-ROM

Keep the following notes in mind to use the CD-ROM for the server:

 For the disk which does not conform to the CD standard, the

playback of such a disk with the CD drive is not guaranteed.

 Do not drop the CD-ROM.

 Do not place anything on the CD-ROM or bend the CD-ROM.

 Do not attach any label onto the CD-ROM.

 Do not touch the signal side (nothing is printed on this side) with

your hand.

 Place the CD-ROM with its printed side upward and gently put it on

the tray.

 Do not scratch the CD-ROM or write anything directly on it with a

pencil or ball-point pen.

 Keep the CD-ROM away from cigarette smoke.

 Do not leave the CD-ROM in a high-temperature place (e.g., place

exposed to direct sunlight or close to a heater).

 When dust or fingerprints are attached on the CD-ROM, wipe the

CD-ROM from its center to edge with a dry soft cloth slowly and
gently.

 Use the CD cleaner to clean the CD-ROM. Do not use record

spray/cleaner, benzene, or thinner.

 Keep the CD-ROM in a CD-ROM case when not in use.

 If the CD-ROM emits large noise in the CD-ROM drive, remove the

CD-ROM and insert it back again.

Chapter 3

Setting Up Your Server

This chapter describes how to set up the server appropriate for your system, on a step-by-step basis.

3-2 Setting Up Your Server

SETUP FLOW

Follow the flowchart below to set up the server.

Selecting the server site

Select a suitable site for the server. Assemble the 19-inch rack assembly.

Unpacking the system

Unpack the server and accessories from the chipping carton box.

Installing the server

Install the server into the rack assembly.

Connecting peripheral devices

Connect peripheral devices to the server.

Connecting the power cord

Connect the power cord to the server.

Turning on the server

Power on the server to start software setups. Setups depend on the optional internal
devices installed and the peripheral devices connected.

Installing the operating system

Install an operating system to the server. See Chapter 5.

Installing the utilities

Install the utilities in the provided NEC EXPRESSBUILDER CD-ROM.
See Chapter 6.

Making backup copies of system information

After all the system setup procedures are completed, make backup copies of system
information.
System information is required for recovering the server from the trouble or after
replacing the system board.

Setting Up Your Server 3-3

SELECTING SERVER SITE

To use the server, install it on a standard EIA 19-inch rack assembly.

Refer to the documentation attached to the rack or contact your service representative for the
installation of the server on the rack.

WARNING

Observe the following instructions to use the server safely. Failure to follow
these instructions may result in death or serious personal injury. See pages 1­3 to 1-8 for details.

 Do not use the server in any unapproved place.
 Do not connect the ground line to a gas pipe.

CAUTION

Observe the following instructions to use the server safely. Failure to follow
these instructions may cause a fire, personal injury, or property damage. See
pages 1-3 to 1-8 for details.

 Do not carry or install the server only by a single person.
 Do not install the server where the load may be concentrated on a specific

point.

 Do not install any component on the server only by a single person.
 Do not pull out a device from the rack if the rack is unstable.
 Do not leave more than one device being pulled out from the rack.
 Do not provide the wiring exceeding the rating power.

3-4 Setting Up Your Server

Do not install the rack in the places listed below. Installing the rack or mounting the server on the
rack in such a place may cause some malfunction to occur.

 Narrow space from which devices cannot be pulled out from the rack completely

 Place that cannot bear the total weights of the rack and devices mounted on the rack

 Place where stabilizers cannot be installed or where the rack can be installed only after the

practice of proper earthquake-resistant construction

 Place of uneven or slanting floor

 Place of drastic temperature change (near a heater, air conditioner, or refrigerator)

 Place where intense vibration may be generated

 Place where corrosive gas is generated, chemicals are nearby, or chemicals may be

accidentally sprayed over

 Place where a carpet not subject to anti-static process is laid.

 Place where some objects may be fallen on the rack

 Place near a device generating intense magnetic field (such as a TV, radio,

broadcast/communication antenna, power transmission wire, and electromagnetic crane) is
placed (If unavoidable, contact your service representative to request proper shield
construction.)

 Place where the power cord of the server must be connected to an AC outlet that shares

the outlet of another device with large power consumption.

 Place near equipment that generates power noise (e.g., contact spark at power-on/power-

off of commercial power supply through a relay). If you must install the server close to
such equipment, request your service representative for separate power cabling or noise
filter installation.

Setting Up Your Server 3-5

UNPACKING THE SYSTEM

When you receive your system, inspect the shipping containers prior to unpacking. If the shipping
boxes are damaged, note the damage, and if possible, photograph it for reference. After removing
the contents of the containers, keep the cartons and the packing materials. If the contents appear
damaged when you unpack the boxes, file a damage claim with the carrier immediately.

INSTALLING THE SERVER

This subsection provides the instructions for the rack-mount server unit into a standard EIA 19-inch
rack cabinet.

Also this subsection describes the removal procedures for the rack-mount server unit from the 19­inch rack cabinet.

WARNING

Observe the following instructions to use the server safely. Failure to follow
these instructions may result in death or serious personal injury. See pages 1­3 to 1-8 for details.

 Do not use any rack which does not conform to the relevant standard.
 Disconnect the power cord(s) before installing or removing the server.

CAUTION

Observe the following instructions to use the server safely. Failure to follow
these instructions may cause a fire, personal injury, or property damage. See
pages 1-3 to 1-8 for details.

 Do not leave more than one device being pulled out from the rack.
 Do not lift the server only by a single person.
 Always install the server in the specified place.
 Do not install the server on the rack leaving the cover removed.
 Do not pinch your finger with mechanical components.

3-6 Setting Up Your Server

Restricted Access Location

The server is intended for installation in a restricted access location, mounted above a non­combustible material.

ESD Precaution

An electrostatic discharge (ESD) can damage disk drives, option boards, and other components. You
can provide some ESD protection by wearing an antistatic wrist strap attached to chassis ground
when handling system components.

Electronic devices can be easily damaged by static electricity. To prevent damage, keep them in
their protective packaging when they are not installed in your system.

Checking Components

Confirm that the following tools or components are provided to install the server on the rack.

M5 screw M5 core nut

Required Tools

You may only prepare a Phillips screwdriver to install the server on the rack.

Setting Up Your Server 3-7

Installation Procedure for NEC Rack/Third Vendor's Rack

This server can be installed in either the NEC rack or a third vendor's rack. Take the following
procedure to install the server in the rack:

IMPORTANT: When installing the optional cable arm, see the

instruction manual provided with the cable arm.

Preparation before Installation

The slide rail is fixed with the screw to prevent from falling off during transportation. Remove the
left and right core nuts from the front of the server before you install the server in the rack.

Set screw

Core nut

Hold the core nut, and rotate the set screw to remove the core nut.
Keep the removed core nuts for future use.

Removing the Rail Assemblies

Remove the sliding rails from the server.

Hold the rails and slowly slides them toward the rear of the server until a "click" is heard. The
click indicates that the rails are locked.

Push the release levers on the right and left sides of the server, and remove the rail assemblies from
the server while unlocking.

Release lever

3-8 Setting Up Your Server

Only the inner rails remain screwed to the server when the rail assemblies have been removed.

Inner rails

IMPORTANT: The removed rail assemblies are to be installed on the

inner rails later. To install each rail assembly on the correct inner rail,
make a mark on the assemblies. Similarly, when installing more than
one server, distinguish between the pairs of inner rails and rail
assemblies of the servers by making marks.

Setting Up Your Server 3-9

Installing the Core Nuts

Install three core nuts on the front of the rack for each of the right and left sides and also two core
nuts on the rear of the rack for each of the right and left sides.

Install three core nuts in 1U (the minimum unit of rack height). Three slots (angle holes) are
opened per 1U of a rack. Install the core nuts at the three slots. (For any NEC rack, round marks
are put in the unit of 1U.) For two core nuts installed on the front of the rack, the upper and lower
nuts are used to fix the front of the rail assembly, and the center is used to support the set screw of
the server. The core nuts installed on the rear of the rack are used to fix the rear of the rail
assemblies.

Hang either clip of a core nut on a square hole on the rack and insert another clip into the hole by
using a tool such as a flat tip screwdriver.

NOTE: Confirm that all the core nuts are installed at the level.

3-10 Setting Up Your Server

Installing the Rail Assemblies

Make sure of the right side rail assembly or the left one when installing it. See the figure below.

Front Rear

Left side rail assembly

Right side rail assembly

1. Loosen a screw securing the rail assembly.

Screws

2. Align the front and rear frames of rail assembly to the location where the core nuts are

installed.

Locate the rail assembly so that the frame of the rack is located between core nuts and
frames of rail assembly.

NOTE: Confirm that the portion of the frame to fix the rail assembly is

located in front of the rack frame.

3. Firmly secure the rail assembly.

Setting Up Your Server 3-11

Installing the Server

CAUTION

Observe the following instructions to use the server safely. Failure to follow
these instructions may cause a fire, personal injury, or property damage. See
pages 1-3 to 1-8 for details.

 Do not lift the server only by a single person.
 Do not pinch your finger with mechanical components.

1. Pull out the sliding rails of the right and left rail assemblies until they are locked.

3-12 Setting Up Your Server

2. At least two persons are required to install the server. Securely hold the server and

install it in the rack.

Firmly fit the inner rails on the sides of the server into the rail assemblies that are installed
on the rack, and then slowly push the server into the rack.

If the server is locked on its way into the rack, slowly push it in while pressing the release
levers on the right and left sides of the server.

When the server is installed for the first time, the mechanical parts are rather hard to slide.
You may feel strong friction when pushing in the server. In this case, strongly push it in.

Release lever

3. Confirm that the sliding rails work normally by pulling the server out of the rack and

pushing it in several times.

NOTE: Confirm that the sliding rails work normally. If the sliding

rails are stuck to the rack frame and do not come out, reinstall them.

Setting Up Your Server 3-13

Securing the Server

Captive thumb screws

1. Push the server into the rack as far as it will go.

2. Tighten the right and left captive thumb screws on the front panel to secure the server to

the rack.

3. Install the front bezel.

This completes the installing of the server.

3-14 Setting Up Your Server

Removing the Server from the Rack Assembly

The server should be removed from the rack by at least two persons.

WARNING

Observe the following instructions to use the server safely. Failure to follow
these instructions may result in death or serious personal injury. See pages
1-3 to 1-8 for details.

 Do not lift the server only by a single person.
 Do not pinch your finger with mechanical components.
 Note high temperature.
 Do not pull out a device from the rack if the rack is unstable.
 Do not leave more than one device being pulled out from the rack.

1. Release the security lock to remove the front bezel.

Security lock

2. Confirm that the power of the server is OFF, and disconnect the power cable and all the

interface cables connected to the server.

3. <This step is required only when the optional cable arm is mounted.>

Remove the two screws securing the cable arm, and dismount the cable arm from the
server.

4. Loosen the two captive thumb screws.

Setting Up Your Server 3-15

5. Hold the handle and pull out the server from the rack slowly and carefully.

The server clicks to be latched.

Captive thumb screws

Handles

6. Pull out the server from the rack with the right and left release lever pressed to release the

latch.

IMPORTANT:

 Pull out the server slowly holding the bottom of the server by at

least two persons.

 Do not apply any load on the server pulled out from the rack.

Doing so may cause personal injury if the server drops.

To remove some mechanical parts of the rack, see the installation procedure.

Release lever

3-16 Setting Up Your Server

CONNECTING PERIPHERAL DEVICES

Connect peripheral devices to the server. The server is provided with connectors for wide variety
of peripheral devices on its front and rear. The figure on the next page illustrates available
peripheral devices for the server in the standard configuration and locations of the connectors for the
devices.

CAUTION

Observe the following instructions to use the server safely. Failure to follow
these instructions may cause a fire, personal injury, or property damage. See
pages 1-3 to 1-8 for details.

 Do not connect any interface cable with the power cord of the NEC Express

Server plugged to a power source.

 Do not use any unauthorized interface cable.

IMPORTANT:

 Power off the server and a peripheral device before connection.

Connecting a powered peripheral device to the powered server will
cause malfunctions and failures.

 To connect a third-party peripheral device or interface cable to the

server, consult with your service representative for availability of
such a device or cable. Some third-party devices may not be used
for the server.

 The total length of a cable (including the connection cable in SCSI

device) is limited by the SCSI standard. Ask your service
representative for details.

 A leased line cannot be connected directly to the serial port

connectors.

 Secure the power cord(s) and interface cables with a tie wrap.

 Form the cables in such a way that they will not come into contact

with the door or the guide rails on the sides of the server.

 Form the power cord with a slight slack at the AC inlet of the server.

This is to prevent the power cord from coming off when the server
is pulled out from the rack.

 Do not apply any pressure to the plug of the power cord.

Setting Up Your Server 3-17

y

FRONT

Hub

(multiport repeater)

1 2

Device with the

serial interface

A

*2

Keyboard

Device with the serial interface
(e.g., Management PC)

*2

B

Mouse

*3

USB device

*1

REAR

USB device

Display unit

*1

Device with the

SCSI interface

*5

*1 Any USB keyboard and mouse are not supported.
*2 A leased line cannot be connected directly to this connector.

The console of a management PC can be connected to only serial port B. (BIOS setup required.)
*3 Use the provided branch cable.
*4 Connect the power cord to a circuit breaker of 15 A or less.
*5 Used exclusivel

with onboard SCSI connector.

Finally connect the provided
power cord to the receptacle.
If connecting the server to UPS,
see the explanation below.

*4

3-18 Setting Up Your Server

CONNECTING POWER CORD

Connect the provided power cord to the server.

Observe the following instructions to use the server safely. Failure to follow
these instructions may result in death or serious personal injury. See pages 1­3 to 1-8 for details.

 Do not hold the power plug with a wet hand.
 Do not connect the ground wire to a gas pipe.

Observe the following instructions to use the server safely. Failure to follow
these instructions may cause a fire, personal injury, or property damage. See
pages 1-3 to 1-8 for details.

 Do not plug the power cord in to an improper power source.
 Do not connect the power cord to an outlet that has an illegal number of

connections.

 Insert the power plug into the outlet as far as it goes.
 Use the authorized power cord only.

WARNING

CAUTION

1. Plug the provided power cord into the power receptacle on the rear of the server.

2. Plug the other end of the power cord into the wall outlet.

IMPORTANT: Secure the power cord with an AC cord holder that

comes with your server.

Setting Up Your Server 3-19

(

)

(

)

To connect the power cord from the server to an uninterruptive power supply (UPS), use service
outlets on the rear of the UPS.

The UPS service outlets are categorized into two groups: SWITCH OUT and UN-SWITCH OUT.
(They may be called "OUTPUT1" and "OUTPUT2".)

To control power supply with an application (NEC ESMPRO/UPSController) that controls the UPS,
connect the power cord to an SWITCH OUT outlet.

For constant power supply, connect the power cord to a UN-SWITCH OUT outlet. (Connect the
modem that is in service for 24 hours to this outlet.)

<Example>

2

(UNSWITCH OUT)

UN-SWITCH OUT

OUTPUT 2

OUTPUT

AC100V 50/50HZ

OUTPUT(SWITCH OUT)

SWITCH OUT

OUTPUT 1

When the power cord from the server to a UPS, change the BIOS setup of the server to link with
power supply from the UPS.

To power on the server from the UPS (Uninterruptible Power Supply), select [Server] - [AC-LINK]

- [Power On].

Change a parameter for "AC-LINK" under the Server menu of the BIOS SETUP utility. See
Chapter 4 for details.

3-20 Setting Up Your Server

TURNING ON THE SERVER

Turn on the server and follow the on-screen instructions for setup.

IMPORTANT: Before turning on the server:

 Some optional boards require setups with the SETUP utility before

installation. If the server has a PCI board with the PCI-to-PCI
bridge installed, the SETUP utility is enabled to launch. Check on
the board specifications to find out whether it requires pre­installation setups before actually installing the board.

 Some installed optional devices or connected peripheral devices

require setups before proceeding to the next step.

To use the server with no optional devices installed besides the graphic
board, install a desired OS to the server.

1. Make sure all external devices, such as a video display, keyboard, and mouse (optional)

have been connected, and the power cords are connected.

2. Power on the video display and any other external devices.

3. Make sure that the floppy disk drive contains no floppy disk and the CD-ROM drive

contains no bootable CD-ROM.

4. Open the front bezel.

5. Press the POWER switch.

NOTES:

 If the power cord is connected to the power control unit such as the

UPS, turn on the power control unit.

 If a remote management card (RMC) is installed in your server,

connect the power cord and wait a few seconds before pressing the
POWER switch. The POWER switch does not work in a few
seconds after connecting the power cord due to RMC firmware
start-up.

Setting Up Your Server 3-21

POWER

POWER LED

switch

The POWER LED on the front of the server comes on.

In a few seconds, the NEC logo appears on the screen and the Power On Self-Test (POST)
begins.

The POST runs automatically when you power on the server or reset it with a keyboard
operation (Ctrl + Alt + Delete). The POST runs diagnostics, initializes the server, sets
interrupt vectors, detects installed peripheral devices, and boots the operating system (if
installed). See Chapter 2 for detailed description on POST.

If the server halts before completing the POST, the POST emits a beep code indicating a
fatal system error requiring immediate attention. (See Chapter 8, "Troubleshooting," for
troubleshooting information.)

During memory test, the POST displays the amount of memory it was able to access and
test. Depending on the amount of installed memory, it may take several minutes to
complete the memory test.

NOTE: The factory-set is defined to hide the POST screen with the

NEC logo screen. You can always change the NEC logo screen to the
POST screen by pressing Esc. To change the start-up screen, use the
BIOS setup utility, "SETUP." (See Chapter 4 for details.)

During the POST, you will see the banner message to prompt you to launch the BIOS SETUP utility
stored in ROM on system board or on an installed option board.

Start the BIOS SETUP utility appropriate to your system environment to change the BIOS setup.
For the BIOS SETUP for the server, see Chapter 4. For the BIOS SETUP for the option board,
refer to the manual that comes with the option board.

3-22 Setting Up Your Server

INSTALLING OPERATING SYSTEM

See Chapter 5 for installing the Microsoft Windows Server 2003 or Microsoft Windows 2000
operating systems.

To install the other operating system listed above, contact your service representative.

IMPORTANT: Before installing the operating system, adjust the

system date and time by using the BIOS setup utility "SETUP." See
the next chapter for detail.

INSTALLING UTILITIES

Install the utilities that come with the server. See Chapter 6 for details.

MAKING BACKUP COPIES OF SYSTEM INFORMATION

The system information includes the current BIOS settings and any specific information for the
server.

Save the information after completing the system setup.

Without the backup data, you will not be able to recover the information.

You can save the information by the following process.

1. Insert the NEC EXPRESSBUILDER CD-ROM into the CD-ROM drive and reboot the

system.

2. Select [Tools].

3. Select [Off-line Maintenance Utility].

4. Select [System Information Management].

5. Insert a floppy disk into the floppy disk drive.

6. Select [Save].

Chapter 4

Configuring Your Server

Configuration and setup utilities are used to change your system configuration. You can configure
your system, as well as option boards you may add to your system, using the BIOS Setup Utility.
Several unique system parameters are configured using the BIOS Setup, which is stored in the
system FLASH memory.

The Adaptec Configuration Utility detects the SCSI host adapters on the system board. Use this
utility if you need to configure the two SCSI controllers in your system, to configure the hard disk
drives connected to a SCSI controller as a RAID drive, or to perform a SCSI disk format or verify
disk operation on the SCSI disk drives. The Adaptec Configuration Utility is also used to configure
any SCSI removable media devices installed in your system.

If your system has been factory configured, the BIOS Setup or Adaptec Configuration Utility do not
need to be run unless you want to change the password or security features, add certain types of
option boards or devices, or upgrade your system board.

This chapter also provides information on several system configuration parameters that are set by
jumpers on the system board. However, these parameters do not usually require change.

SYSTEM BIOS (SETUP)

The SETUP utility is used to change system configuration parameters. This utility is pre-installed in
the flash memory of the server and ready to run.

The server is configured with the correct parameters using the SETUP utility and shipped in the best
conditions. Thus, you don't need to use the SETUP utility in most cases. However, you might
wish to use the SETUP utility in the cases described below.

IMPORTANT:

 The SETUP utility is intended for system administrator use only.
 The SETUP utility allows you to set a password. The server is

provided with two levels of password: Supervisor and User. With
the Supervisor password, you can view and change all system
parameters of the SETUP utility. With the User password, system
parameters available for viewing and changing are limited.

 Do not set any password before installing the OS.
 The server contains the latest version of the SETUP utility. Dialog

boxes appear on your SETUP utility, thus, may differ from
descriptions in this manual. If you find anything unclear, see the
online help or ask your service representative.

 Use the Exit menu when exiting the SETUP utility. Exiting the

utility with the POWER switch or reset operation causes the stored
parameters to lose.

4-2 Configuring Your Server

Starting SETUP Utility

Powering on the server starts POST (Power On Self-Test) and displays its check results. If the
NEC logo is displayed, press Esc.

After a few seconds, the following message appears at bottom left on the screen.

Press <F2> to enter SETUP

Press F2 to start the SETUP utility and display its Main menu.

If you have previously set a password with the SETUP utility, the password entry screen appears.
Enter the password.

Enter password:[ ]

Up to three password entries will be accepted. If you fail to enter the password correctly for three
consecutive times, the server halts. (You can no longer proceed.) Power off the server.

NOTE: The server is provided with two levels of password:

Administrator and User. With the Administrator password, you can
view and change all system parameters. With the User password,
system parameters available for viewing and changing are limited.

Configuring Your Server 4-3

Description on On-Screen Items and Key Usage

Use the following keyboard keys to work with the SETUP utility. (Key functions are also listed at
the bottom of the screen.)

Indicates the current menu.

Indicates there
are submenus.

Setup item
menu*

Online help
window

Explanation of key
functions menu

* The menus displayed in gray indicates the information only or unchangeable secured by BIOS

password.

Cursor (↑, ↓):

Selects an item on the screen. The highlighted item is currently

Parameter (high-lights upon selection) menu

selected.

Cursor (←, →):

– and +:

Selects the Main, Advanced, Security, Server, Boot, or Exit menu.

Changes the value (parameter) of the selected item. When a
submenu option (an option preceded by "

³") is selected, these

keys are disabled.

Enter Press Enter to select (determine) parameters.

Esc

F9:

Exit SETUP and return to the previous screen.

Sets the parameter of the currently displayed item back to the
factory set parameter.

F10:

Save and exit the SETUP utility.

4-4 Configuring Your Server

Menu and Parameter Descriptions

The SETUP utility has the following six major menus:

 Main

 Advanced

 Security

 Server

 Boot

 Exit

To set minute functions, select a submenu from the above menus. The following describes
available functions and parameters, as well as the factory-set, for each menu.
