BASIC SPECIFICATIONS
Manufacturer's Part Number
60003294
EAN
5028695108806
Product Description
NEC MultiSync EA223WM - LED monitor - 22"
Device Type
LED-backlit LCD monitor - 22"
Colour
Black
Built-in Devices
Stereo speakers, USB Hub
Dimensions (WxDxH)
50.4 cm x 21.8 cm x 38.4 cm - with stand
Weight
5.6 kg
Response Time
5 ms
Compliant Standards
FCC Class B certified, CSA, UL, TUV GS, GOST, cUL, DDC-2B, MPR III, PCT, TUV Ergo, DDC/CI,
RoHS, ISO 9241-307, GEEA, TCO Displays 5.2
Manufacturer Warranty
3 years warranty
Environmental Standards
ENERGY STAR Qualified
Colour Support
16.7 million colours
Aspect Ratio
Widescreen - 16:10
Native Resolution
HD 1680 x 1050 at 60 Hz
Brightness
250 cd/m2
Contrast Ratio
1000:1 / 25000:1 (dynamic)
Page 2
Display Position Adjustments
Height, pivot (rotation), swivel, tilt
Speakers
Integrated
Input Connectors
DVI-D, VGA, DisplayPort
Pixel Pitch
0.282 mm
Panel Type
TN
GENERAL
Display Type
LED-backlit LCD monitor / TFT active matrix
Diagonal Size
22"
Built-in Devices
Stereo speakers, USB Hub
Panel Type
TN
Aspect Ratio
Widescreen - 16:10
Native Resolution
HD 1680 x 1050 at 60 Hz
Pixel Pitch
0.282 mm
Brightness
250 cd/m2
Contrast Ratio
1000:1 / 25000:1 (dynamic)
Colour Support
16.7 million colours
Response Time
5 ms
Vertical Refresh Rate
75 Hz
Horizontal Refresh Rate
Page 3
82.3 kHz
Horizontal Viewing Angle
178
Vertical Viewing Angle
178
Backlight Technology
WLED
Controls & Adjustments
Volume, brightness, contrast, colour temperature
Features
Infrared user sensor, ambient light sensor, No Touch Auto Adjust, Intelligent Power Manager (IPM),
power off timer, sRGB colour management, Eco-Mode, ControlSync
Colour
Black
Dimensions (WxDxH)
50.4 cm x 21.8 cm x 38.4 cm - with stand
Weight
5.6 kg
MISCELLANEOUS
Features
Security lock slot (cable lock sold separately), cable organizer
Cables Included
1 x USB cable ¦ 1 x audio cable ¦ 1 x VGA cable ¦ 1 x DVI cable
Compliant Standards
FCC Class B certified, CSA, UL, TUV GS, GOST, cUL, DDC-2B, MPR III, PCT, TUV Ergo, DDC/CI,
RoHS, ISO 9241-307, GEEA, TCO Displays 5.2
POWER
Power Supply
Internal
Power Consumption Operational
25 Watt
Power Consumption Stand by / Sleep
0.5 Watt
ENVIRONMENTAL PARAMETERS
Min Operating Temperature
5 °C
Page 4
Max Operating Temperature
35 °C
Humidity Range Operating
20 - 80%
MANUFACTURER WARRANTY
Service & Support
3 years warranty
Service & Support Details
Limited warranty - 3 years ¦ Limited warranty - backlight - 3 years
ENVIRONMENTAL STAN D ARDS
ENERGY STAR Qualified
Yes
AUDIO
Type
Speakers - stereo - integrated
Output Power / Channel
2 Watt
CONNECTIVITY
Interfaces
DVI-D ¦ VGA ¦ 4 x USB 2.0 downstream ¦ USB 2.0 upstream ¦ DisplayPort ¦ Audio line-in
MECHANI C AL
Display Position Adjustments
Height, pivot (rotation), swivel, tilt
Tilt Angle
35
Swivel Angle
240
Rotation Angle
90
Height Adjustment
130 mm
Flat Panel Mount Interface
100 x 100 mm
