Nec 50XR5, PX-61XR4A, PX-50XR5A, 61XR4, PX-42XR4A Operation Manual

Operation Manual

(Enhanced split screen Model)

Operation Manual

Manual de funcionamiento

NEC Solutions (America), Inc.

Mode d’emploi

Manual de operação

202

Operation Manual

(Enhanced split screen Model)

For the specifications of your plasma
monitor, refer to “Model Information”.

ENGLISH

IMPORTANT SAFETY INSTRUCTIONS

Read before operating equipment

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation openings. Install in
accordance with the manufacturers instructions.

8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and third grounding prong.The wide
blade or third prong are provided for your safety. When
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.

11. Only use attachments/accessories specified by the
manufacturer.

12. Use only with a cart, stand, tripod, bracket,

or table specified by the manufacturer, or sold
with the apparatus.When a cart is used, use
caution when moving the cart/apparatus

combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when
unused for long periods of time.

14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been
dropped.

15. This product may contain lead or mercury. Disposal of
these materials may be regulated due to environmental
considerations.
For disposal or recycling information, please contact your
local authorities or the Electronic Industries Alliance:
www.eiae.org.

16. Damage Requiring Service - The appliance should be
serviced by qualified service personnel when:
A. The power supply cord or the plug has been damaged;

or

B. Objects have fallen, or liquid has been spilled into

the appliance; or

C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally

or exhibits a marked change in performance; or

E. The appliance has been dropped, or the enclosure

damaged.

17. Tilt/Stability - All televisions must comply with
recommended international global safety standards for
tilt and stability properties of its cabinets design.

• Do not compromise these design standards by

applying excessive pull force to the front, or top, of
the cabinet which could ultimately overturn the
product.

• Also, do not endanger yourself, or children, by placing

electronic equipment/toys on the top of the cabinet.
Such items could unsuspectingly fall from the top of
the set and cause product damage and/or personal
injury.

18. Wall Mounting - The appliance should be mounted to a
wall only as recommended by the manufacturer.

19. Power Lines - An outdoor antenna should be located
away from power lines.

20. Outdoor Antenna Grounding - If an outside antenna is
connected to the receiver, be sure the antenna system is
grounded so as to provide some protection against
voltage surges and built up static charges.
Section 810 of the National Electric Code, ANSI/NFPA
No. 70- 1984, provides information with respect to proper
grounding of the mats and supporting structure
grounding of the lead-in wire to an antenna-discharge
unit, size of grounding connectors, location of antenna­discharge unit, connection to grounding electrodes and
requirements for the grounding electrode.

21. Objects and Liquid Entry - Care should be taken so that
objects do not fall and liquids are not spilled into the
enclosure through openings.

Apparatus shall not be exposed to dripping or splashing
and that no objects filled with liquids, such as vases, shall
be placed on apparatus.

WARNING

To reduce the risk of fire or electric shock, do not expose
this apparatus to rain or moisture.

En-2

Important Information

Precautions

Please read this manual carefully before using your plasma monitor and
keep the manual handy for future reference.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER. NO USER-SERVICEABLE
PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

This symbol warns the user that uninsulated voltage
within the unit may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous to make any
kind of contact with any part inside of this unit.

This symbol alerts the user that important literature
concerning the operation and maintenance of this unit
has been included.
Therefore, it should be read carefully in order to avoid
any problems.

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS
UNIT TO RAIN OR MOISTURE. ALSO DO NOT USE THIS UNIT’S
POLARIZED PLUG WITH AN EXTENSION CORD RECEPT ACLE OR
OTHER OUTLETS, UNLESS THE PRONGS CAN BE FULLY
INSERTED. REFRAIN FROM OPENING THE CABINET AS THERE
ARE HIGH-VOLTAGE COMPONENTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.

Warnings and Safety Precaution

This plasma monitor is designed and manufactured to provide
long, trouble-free service. No maintenance other than cleaning
is required. Please see the section “Plasma monitor cleaning
procedure”.
The plasma display panel consists of fine picture
elements (cells) with more than 99.99 percent active cells. There
may be some cells that do not produce light or remain lit.
For operating safety and to avoid damage to the unit, read
carefully and observe the following instructions.
To avoid shock and fire hazards:

1. Provide adequate space for ventilation to avoid internal heat build­up. Do not cover rear vents or install the unit in a closed cabinet or
shelves.
If you install the unit in an enclosure, make sure there is adequate
space at the top of the unit to allow hot air to rise and escape. If the
monitor becomes too hot, the overheat protector will be activated and
the monitor will be turned off. If this happens, turn off the power to the
monitor and unplug the power cord. If the room where the monitor is
installed is particularly hot, move the monitor to a cooler location, and
wait for 60 minutes to cool the monitor. If the problem persists, contact
your dealer for service.

2. Do not use this unit’s polarized plug with extension cords or outlets
unless the prongs can be completely inserted.

3. Do not expose the unit to water or moisture.

4. Avoid damage to the power cord, and do not attempt to modify the
power cord.

5. Unplug the power cord during electrical storms or if the unit will
not be used over a long period.

6. Do not open the cabinet which has potentially dangerous high voltage
components inside. If the unit is damaged in this way the warranty will
be void. Moreover, there is a serious risk of electric shock.

7. Do not attempt to service or repair the unit. The manufacturer is not
liable for any bodily harm or damage caused if unqualified persons
attempt service or open the back cover. Refer all service to authorized
Service Centers.

8. This equipment shall be connected to a MAIN outlet with a protective
earth-ground connection.

9. The outlet shall be installed near the equipment and shall be easily
accessible.

To avoid damage and prolong operating life:

1. Use only with 100-240V 50/60Hz AC power supply. Continued
operation at line voltages greater than 100-240 Volts AC will shorten
the life of the unit, and might even cause a fire hazard.

2. Handle the unit carefully when installing it and do not drop.

3. Set the unit away from heat, excessive dust, and direct sunlight.

4. Protect the inside of the unit from liquids and small metal objects. In
case of accident, unplug the power cord and have it serviced by an
authorized Service Center.

5. Do not hit or scratch the panel surface as this causes flaws on the surface
of the screen.

6. For correct installation and mounting it is strongly recommended to
use a trained, authorized dealer.

7. As is the case with any phosphor-based display (like a CRT monitor,
for example) light output will gradually decrease over the life of a Plasma
Display Panel.

8. To avoid sulfurization it is strongly recommended not to place the unit
in a dressing room in a public bath or hot spring bath.

9. Do not use in a moving vehicle, as the unit could drop or topple over
and cause injuries.

10. Do not place the unit on its side, upside-down or with the screen facing
up or down, to avoid combustion or electric shock.

Plasma monitor cleaning procedure:

1. Use a soft dry cloth to clean the front panel and bezel area. Never use
solvents such as alcohol or thinner to clean these surfaces.

2. Clean plasma ventilation areas with a vacuum cleaner with a soft brush
nozzle attachment.

3. To ensure proper ventilation, cleaning of the ventilation areas must be
carried out monthly. More frequent cleaning may be necessary
depending on the environment in which the plasma monitor is installed.

Recommendations to avoid or minimize image retention:

Like all phosphor-based display devices and all other gas plasma displays,
plasma monitors can be susceptible to image retention under certain
circumstances. Certain operating conditions, such as the continuous
display of a static image over a prolonged period of time, can result in
image retention if proper precautions are not taken. To protect your
investment in this plasma monitor, please adhere to the following
guidelines and recommendations for minimizing the occurrence of image
retention:

* Always enable and use your computer’s screen saver function

during use with a computer input source.
* Display a moving image whenever possible.
* Change the position of the menu display from time to time.
* Always power down the monitor when you are finished using it.

If the plasma monitor is in long term use or continuous operation take the
following measures to reduce the likelihood of image retention:

* Lower the Brightness and Contrast levels as much as possible without

impairing image readability.
* Display an image with many colors and color gradations (i.e.

photographic or photo-realistic images).
* Create image content with minimal contrast between light and dark

areas, for example white characters on black backgrounds. Use

complementary or pastel color whenever possible.
* Avoid displaying images with few colors and distinct, sharply defined

borders between colors.

Plasma monitor driving sound

The panel of the Plasma monitor is composed of extremely fine pixels and
these pixels emit light according to received video signals. This principle
may cause you to hear a buzz or electrical hum coming from the Plasma
monitor. Also note that the rotation speed of the cooling fan motor increases
when the ambient temperature of the Plasma monitor becomes high. You
may hear the sound of the motor at that time.

Note:

The following items are not coverd by the warranty.

• Image retention

• Panel generated sound, examples: Fan motor noise, and electrical
circuit humming /glass panel buzzing.

Contact your dealer for other recommended procedures that will best
suit your particular application needs.

En-3

Contents

IMPORTANT SAFETY INSTRUCTIONS

Read before operating equipment ................. En-2

Important Information.................................. En-3

Contents ...................................................... En-4

Contents of the Package ........................................ En-4

Options .............................................................. En-4

Installation .................................................. En-5

Ventilation Requirements for enclosure mounting ......En-5

Cable Management.............................................. En-6

Using the remote control ....................................... En-6

Battery Installation and Replacement ..................... En-6

Operating Range .................................................... En-6

Handling the remote control................................... En-6

Part Names and Function .............................. En-7

Front View .......................................................... En-7

Rear View/ Terminal Board ...................................En-8

Remote Control .................................................. En-10

Basic Operations......................................... En-11

POWER ............................................................ En-11

To turn the unit ON and OFF: .............................. En-11

VOLUME .......................................................... En-11

To adjust the sound volume:................................. En-11

MUTE ............................................................... En-11

To mute the audio: ............................................... En-11

DISPLAY ............................................................En-11

To check the settings:........................................... En-11

DIGITAL ZOOM .................................................En-11

OFF TIMER ........................................................En-11

To set the of f timer:.............................................. En-11

To check the remaining time: ............................... En-11

To cancel the off timer: ........................................ En-11

WIDE Operations......................................... En-12

Wide Screen Operation (manual) ........................ En-12

When viewing videos or digital video discs ......... En-12

Wide Screen Operation with Computer Signals ..... En-13

SPLIT SCREEN Operations ............................. En-14

Showing a couple of pictures on the screen at the same

time .............................................................. En-14

Operations in the Side-by-side mode.................... En-14

Operations in the Picture-in-picture mode ............ En-15

Selecting the input signals to be displayed ........... En-15

Zooming in on a specific input ............................. En-15

Adjusting the OSM controls................................. En-15

OSM (On Screen Menu) Controls ................... En-16

Menu Operations ............................................... En-16

Menu Tree ......................................................... En-17

Picture Settings Menu.......................................... En-19

Storing picture settings......................................... En-19

Adjusting the picture............................................ En-19

Reducing noise in the picture ............................... En-19

Setting the color temperature ............................... En-20

Adjusting the color to the desired level ................ En-20

Setting the picture to suit the movie ..................... En-20

Setting the picture mode according to the brightness of

the room ............................................................ En-20

Changing the Gamma Curve ................................ En-21

Making the Low T one adjustments ...................... En-21

Adjusting the pedestal level (black level) ............. En-21

Adjusting the colors ............................................. En-21

Audio Settings Menu .......................................... En-22

Adjusting the treble, bass and left/right balance and audio

input select ........................................................ En-22

Setting the allocation of the audio and DVD/HD

connectors ......................................................... En-22

Image Adjust Settings Menu ................................ En-22

Adjusting the Position, Size, Fine Picture,

Picture Adj ........................................................ En-22

SET UP Settings Menu .........................................En-23

Setting the language for the menus....................... En-23

Checking the signal being transmitted to DVD/HD1

terminal ............................................................. En-23

Checking the signal being transmitted to PC/RGB

terminal ............................................................. En-23

Setting high definition images to the suitable screen

size .................................................................... En-23

Setting a computer image to the correct RGB select

screen ................................................................ En-23

Setting the black level for HDMI signal ............... En-24

Setting the video signal format............................. En-24

Setting the background color when no signal is being

input .................................................................. En-24

Setting the gray level for the sides of the screen ... En-25

Setting the screen size for S1/S2 video input........ En-25

Turning on/off the menu display .......................... En-25

Setting the position of the menu ........................... En-25

Remote ID ........................................................... En-26

Resetting to the default values.............................. En-26

Function Settings Menu ....................................... En-26

Setting the menu mode ........................................ En-26

Setting the power management for computer

images ............................................................... En-26

ON/ST ANDBY indicator ..................................... En-27

Setting the Input Skip........................................... En-27

Removing the sub screen area when there is no input

signal detected for the sub screen ...................... En-27

Displaying the entire image during DIGIT AL ZOOM

operations .......................................................... En-27

Displaying still images in the sub screen .............. En-27

Reducing image retention .................................... En-28

Setting Closed Caption ........................................ En-29

Reducing the brightness of Closed Caption .......... En-30

Setting the power on mode................................... En-30

Signal Information Menu ..................................... En-30

Checking the frequencies, polarities of input signals,

and resolution .................................................... En-30

External Control ......................................... En-31

Application ....................................................... En-31

Connections ...................................................... En-31

Type of connector: D-Sub 9-pin male .................. En-31

Communication Parameters ................................. En-31

External Control Codes (Reference) ...................... En-31

Pin Assignments ......................................... En-31

mini D-Sub 15-pin connector (Analog) ................. En-31

Troubleshooting.......................................... En-32

Limited Warranty

Plasma Monitors ..................... En-33

Contents of the Package

䡺 Plasma monitor
䡺 Power cord
䡺 Remote control with two AAA Batteries
䡺 Manuals (Model Information and Operation)
䡺 Ferrite cores
䡺 Cable clamps

Options

• Wall mount unit

• Ceiling mount unit

• Tilt mount unit

• Tabletop Stand

• Attachable speakers

En-4

50mm (2")

50

mm

(2") 50

mm

(2")

Wall

Wall

50mm (2")

50mm (2")

Installation

You can attach your optional mounts or stand to the plasma monitor in one of the following two ways:
* While it is upright. (See Drawing A)
* As it is laid down with the screen face down (See Drawing B). Lay the protective sheet, which was wrapped around the

monitor when it was packaged, beneath the screen surface so as not to scratch the screen face.

* Do not touch or hold the screen face when carrying the unit.

• This device cannot be installed on its own. Be sure to use a stand or original mounting unit. (Wall
mount unit, Stand, etc.)

• For correct installation and mounting it is strongly recommended to use a trained, authorized
dealer.

Failure to follow correct mounting procedures could result in damage to the equipment or injury
to the installer.

Product warranty does not cover damage caused by improper installation.

* Use only a mounting kit or stand recommended by the manufacturer and listed as an accessory.

Drawing A

Drawing B

Ventilation Requirements for
enclosure mounting

T o allow heat to disperse, leave space between surrounding
objects as shown on the diagram when installing.

En-5

Cable Management

Using the cable clamps provided with the plasma display;
Bundle the signal and audio cables at the back of the unit
to connect to the display.

42 inch

Back of the unit

mounting holes

50-61 inch

Back of the unit

mounting holes

3.Replace the cover.

Operating Range

* Use the remote control within a distance of about 7 m/

23ft. from the front of the monitor’s remote control sensor
and at horizontal and vertical angles of up to approximately
30°.

* The remote control operation may not function if the

monitor’s remote control sensor is exposed to direct
sunlight or strong artificial light, or if there is an obstacle
between the sensor and the remote control.

ON/STANDBY

To attach

1. 2.

clamp

cables

mounting hole

To detach

Using the remote control

Battery Installation and Replacement

Insert the 2 “AAA” batteries, making sure to set them in
with the proper polarity.

1.Press and open the cover.

Approx.

7m/23ft

Handling the remote control

• Do not drop or mishandle the remote control.

• Do not get the remote control wet. If the remote control
gets wet, wipe it dry immediately.

• Avoid heat and humidity.

• When not using the remote control for a long period,
remove the batteries.

• Do not use new and old batteries together, or use dif ferent
types together.

• Do not take apart the batteries, heat them, or throw them
into a fire.

2.Align the batteries according to the (+) and (–) indication
inside the case.

En-6

Part Names and Function

Front View

MENU

MENU INPUT/EXITVOLUME

7

INPUT /EXITVOLUME

6

5

q Power

Turns the monitor’s power on and off.

w Remote sensor window

Receives the signals from the remote control.

e ON/STANDBY indicator

When the power is on ............................. Lights green.

When the power is in the standby mode ... Lights red.

r INPUT / EXIT

Switches the input.
Functions as the EXIT buttons in the On-Screen Menu
(OSM) mode.

4

1

t and



Enlarges or reduces the image. Functions as the
CURSOR (
(OSM) mode.

y VOLUME ▼ and ▲

Adjusts the volume. Functions as the CURSOR (▼/
▲) buttons in the On-Screen Menu (OSM) mode.

u MENU

Sets the On-Screen Menu (OSM) mode and displays
the main menu.

ON/STANDBY

ON/STANDBY

3



/ ) buttons in the On-Screen Menu

2

WARNING

The Power on/off switch does not completely
disconnect power from the display.

En-7

Rear View/ Terminal Board

42 inch

DBA

DVD/HD

1

Y Cb/Pb Cr/Pr

AUDIO

2

R

(

)

L

MONO

VIDEO AUDIO

1

2

1

R

(

)

MONO

L

CE F G H IJK

VIDEO AUDIO

DVD/HD

2

Y Cb/Pb Cr/Pr

1

DVD/HD1DVD/HD

Cb/Pb Cr/Pr L/R Y Cb/Pb Cr/PrL/R Y

DVD/HD3DVD/HD

AUDIO

2

2

PC/RGB

4

AUDIO

3

PC/RGB

L/R

AUDIO
R

(

MONO

L

3

)

REMOTE

EXTERNAL CONTROL

IN OUT

DVD/HD3DVD/HD

HDMI

4

EXTERNAL CONTROL

HDMI

REMOTE

IN

OUT

A AC IN

Connect the included power cord here.

B EXT SPEAKER L and R

Connect speakers (optional) here. Maintain the correct
polarity. Connect the

(positive) speaker wire to the

EXT SPEAKER terminal and the (negative)

speaker wire to the

EXT SPEAKER terminal on
both LEFT and RIGHT channels.
Please refer to your speaker’s owner’s manual.

C VIDEO1, 2 (RCA, S-Video)

Connect VCR’s, DVD’s or Video Cameras, etc. here.

D AUDIO1, AUDIO2, AUDIO3

These are audio input terminals.
The input is selectable. Set which video image
corresponds to the audio input from the audio menu
screen.

E DVD/HD1

Connect DVD’s, High Definition or Laser Discs, etc.
here.

F DVD/HD2

Y ou can connect DVDs, High Definition sources, Laser
Discs, etc. here.

H DVD/HD3, DVD/HD4 (HDMI)

Connect a digital signal from a source with a HDMI
output. See “Specifications” on “Model Information”.

I EXTERNAL CONTROL (D-Sub)

This terminal is used when operating and controlling
the monitor externally with a control system (by RS­232C).

J REMOTE IN* (DC +5V)
K REMOTE OUT* (C-MOS DC +5V)

Use these terminals to control external equipment.

Connection Example: Connecting a TV tuner

PLASMA DISPLAY

VIDEO
IN

VIDEO
OUT

REMOTE
OUT

TV T uner
Remote Control
Carrier fHz: 38kHz

TV T uner

REMOTE
IN

G PC/RGB (D-Sub)

Connect an analog RGB signal from a computer, etc.
here.

* The 1/8 Stereo Mini cable must be purchased separately.

HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.

En-8

G

Rear View/ Terminal Board

50/61 inch

C

E

F

H

K

D

3

4

I

J

AB

A AC IN

Connect the included power cord here.

B EXT SPEAKER L and R

Connect speakers (optional) here. Maintain the correct
polarity. Connect the

(positive) speaker wire to the

EXT SPEAKER terminal and the (negative)

speaker wire to the

EXT SPEAKER terminal on
both LEFT and RIGHT channels.
Please refer to your speaker’s owner’s manual.

C VIDEO1, 2 (RCA, S-Video)

Connect VCR’s, DVD’s or Video Cameras, etc. here.

D AUDIO1, AUDIO2, AUDIO3

These are audio input terminals.
The input is selectable. Set which video image
corresponds to the audio input from the audio menu
screen.

E DVD/HD1

Connect DVD’s, High Definition or Laser Discs, etc.
here.

F DVD/HD2

Y ou can connect DVDs, High Definition sources, Laser
Discs, etc. here.

H DVD/HD3, DVD/HD4 (HDMI)

Connect a digital signal from a source with a HDMI
output. See “Specifications” on “Model Information”.

I EXTERNAL CONTROL (D-Sub)

This terminal is used when operating and controlling
the monitor externally with a control system (by RS­232C).

J REMOTE IN* (DC +5V)
K REMOTE OUT* (C-MOS DC +5V)

Use these terminals to control external equipment.

Connection Example: Connecting a TV tuner

PLASMA DISPLAY

VIDEO
IN

VIDEO
OUT

REMOTE
OUT

TV T uner
Remote Control
Carrier fHz: 38kHz

TV T uner

REMOTE
IN

G PC/RGB (D-Sub)

Connect an analog RGB signal from a computer, etc.
here.

* The 1/8 Stereo Mini cable must be purchased separately.

HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.

En-9

Remote Control

q POWER ON/STANDBY

Switches the power on/standby.
(This does not operate when the ON/STANDBY
indicator of the plasma is off.)

w OFF TIMER

Activates the off timer for the unit.

e DISPLAY

Displays the source settings on the screen.

r WIDE

Automatically detects the signal and sets the aspect
ratio.
Wide button is not active for all signals.

t MENU/ENTER

Press this button to access the OSM controls.
Press this button during the display of the main menu
to go to the sub menu.



y CURSOR (▲ / ▼ /

Use these buttons to select items or settings and to
adjust settings or switch the display patterns.

u EXIT

Press this button to exit the OSM controls in the main
menu. Press this button during the display of the sub
menu to return to the previous menu.

/ )

i MUTE

Mutes the audio.

o VOLUME (+ /–)

Adjusts the audio volume.

!0 ZOOM (+ /–)

Enlarges or reduces the image.

!1 SINGLE

Cancels the split screen mode.

!2 SIDE BY SIDE

Press this button to show a couple of pictures in the
side-by-side mode.

!3 PICTURE IN PICTURE

Press this button to show a couple of pictures in the
picture-in-picture mode.

!4 ACTIVE SELECT

Press this button to make the desired picture activate
during split screen mode.
When the PICTURE FREEZE function is operating,
this button can be used to display still images on the
sub screen.

!5 VIDEO1, 2

Press this button to select VIDEO as the source.
VIDEO can also be selected using the INPUT/EXIT
button on the monitor.

!6 DVD/HD1, 2, 3, 4

Press this button to select DVD/HD as the source.
DVD/HD can also be selected using the INPUT/EXIT
button on the monitor.

!7 PC/RGB

Press this button to select PC/RGB as the source.
PC/RGB can also be selected using the INPUT/EXIT
button on the monitor.

!8 PICTURE MEMORY

Switches sequentially between picture memory settings
1 to 6.

!9 Remote control signal transmitter

Transmits the remote control signals.

En-10

Basic Operations

POWER

To turn the unit ON and OFF:

1. Plug the power cord into an active AC power outlet.

2. Press the Power button (on the unit).
The monitor’s ON/ST ANDBY indicator turns red and the
standby mode is set.

3. Press the POWER ON button (on the remote control) to
turn on the unit.
The monitor’s ON/STANDBY indicator will light up
(green) when the unit is on.

4. Press the POWER STANDBY button (on the remote
control) or the Power button (on the unit) to turn off the
unit.
The monitor’s ON/ST ANDBY indicator turns red and the
standby mode is set (only when turning off the unit with
the remote control).

VOLUME

To adjust the sound volume:

1. Press and hold the VOLUME button (on the remote
control or the unit) to increase to the desired level.

2. Press and hold the VOLUME
control or the unit) to decrease to the desired level.

button (on the remote

MUTE

To mute the audio:

Press the MUTE button on the remote control to mute the
audio; press again to restore.

DISPLAY

To check the settings:

1. The screen changes each time the DISPLAY button is
pressed.

2. If the button is not pressed for approximately three seconds,
the menu turns off.

DIGITAL ZOOM

Digital zoom specifies the picture position and enlarges
the picture.

1. (Be sure ZOOM NAV is of f.)
Press the ZOOM (+ or -) button to display magnifying

glass. (

To change the size of the picture:

Press the ZOOM+ button and enlarge the picture.
A press of the ZOOM- button will reduce the picture
and return it to its original size.

To change the picture position:

Select the position with the ▲▼

2. Press the EXIT button to delete the pointer .

)

 

buttons.

OFF TIMER

To set the off timer:

The off timer can be set to turn the power off after 30, 60,
90 or 120 minutes.

1. Press the OFF TIMER button to start the timer at 30
minutes.

2. Press the OFF TIMER button to the desired time.

3. The timer starts when the menu turns off.

→ 30 → 60 → 90 → 120 → 0

OFF TIMER 30

To check the remaining time:

1. Once the off timer has been set, press the OFF TIMER
button once.

2. The remaining time is displayed, then turns off after a few
seconds.

3. When five minutes remain the remaining time appears
until it reaches zero.

OFF TIMER 28

To cancel the off timer:

1. Press the OFF TIMER button twice in a row.

2. The off timer is canceled.

OFF TIMER 0

Note:

After the power is turned off with the off timer ...
A slight current is still supplied to the monitor. When you
are leaving the r oom or do not plan to use the system for a
long period of time, turn off the power to the monitor.

En-11

WIDE Operations

Wide Screen Operation

With this function, you can select one of six screen sizes.

(manual)

When viewing videos or digital video discs

1. Press the WIDE button on the remote control.

2. Within 3 seconds ...
Press the WIDE button again.
The screen size switches as follows:

→ NORMAL → ANAMORPHIC → STADIUM → ZOOM → 2.35:1 → 14:9

When a 720P or 1080I signal is input:

ANAMORPHIC ↔ 2.35:1

When displaying enhanced split screen:

NORMAL ↔ ANAMORPHIC

NORMAL size screen (4:3)

The picture is expanded in the horizontal and vertical
direction, maintaining the original proportions.
* Use this for theater size (wide) movies, etc.

2.35:1 size screen



Original image

Information is lost on both sides.

The squeezed film image is expanded to fulfill the entire
screen at a ratio of 2.35:1. Black bands do not appear at
the top and bottom but information is lost on the left and
right margins.

• This feature is available when the input signal is video,
component (480I, 480P, 576I, 576P, 720P, 1080I) or RGB
(525P or 625P signal from a scan converter).

* If black bands appear on the top and bottom in the full size

screen, select the 2.35:1 size screen to fill the screen and
avoid image retention.

14:9 size screen

The normal size screen is displayed.
* The picture has the same size as video pictures with a 4 : 3

aspect ratio.

ANAMORPHIC size screen

The image is expanded in the horizontal direction.
* Images compressed in the horizontal direction (“squeezed

images”) are expanded in the horizontal direction and
displayed on the entire screen with correct linearity.
(Normal images are expanded in the horizontal direction.)

STADIUM size screen

The image is displayed at a 14:9 aspect ratio.
* This feature is available when the input signal is video,

component (480I, 480P , 576I, 576P) or RGB (525P or 625P
signal from a scan converter).

Note:

Do not allow 4:3 content to be displayed for extended
periods of time without using gray bars. This can cause
image retention.

The picture is expanded in the horizontal and vertical
directions at different ratios.
* Use this for watching normal video programs (4:3) with a

wide screen.

ZOOM size screen

En-12

Wide Screen Operation with
Computer Signals

Switch to the wide screen mode to expand the 4 : 3 image
to fill the entire screen.

1.Press the WIDE button on the remote control.

2.Within 3 seconds ...
Press the WIDE button again.

The screen size switches as follows:

→ NORMAL → ANAMORPHIC → ZOOM

When displaying enhanced split screen:

NORMAL ↔ ANAMORPHIC

NORMAL size screen (4:3 or SXGA 5:4)

The picture has the same size as the normal computer
image.

Information

 Supported resolution

See page En-3 of Model Information for details on the
display output of the various VESA signal standards
supported by the monitor.

 When 852 (848) dot  480 line wide VGA*
signals with a vertical frequency of 60 Hz and
horizontal frequency of 31.7 (31.0) kHz are in­put

Select an appropriate setting for RGB SELECT mode
referring to the“Table of Signals Supported” on page
En-3 of Model Information.

* “VGA”, “SVGA” and “SXGA” are registered

trademarks of IBM, Inc. of the United States.

Note:

Do not allow 4:3 content to be displayed for extended
periods of time without using gray bars. This can cause
image retention.

ANAMORPHIC size screen

The image is expanded in the horizontal direction.

ZOOM size screen

When wide signals are input.

ANAMORPHIC size screen

En-13

SPLIT SCREEN Operations

VIDEO1 RGB/PC

AB

VIDEO1

RGB/PC

BA

VIDEO1 RGB/PC

AB

VIDEO1

RGB/PC

AB

Showing a couple of pictures on the
screen at the same time

* There may be some RGB-input signals that may not be

displayed as not all signals are supported.

1. Press the button to select a screen mode from among single

mode, side-by-side, and picture-in-picture.

VIDEO1

SINGLE
button

SIDE BY SIDE
button

VIDEO1 RGB/PC

AB

A

PICTURE IN PICTURE
button

SIDE BY SIDE
button

PICTURE IN
button

VIDEO1

Sub

screen

Note:

Picture A and B on the above screen ar e not always of the
same height.

SINGLE
button

RGB/PC

Main screen

Operations in the Side-by-side mode

B



button

B



To change the picture size, press the cursor   or
button.

VIDEO1 RGB/PC

A

B

Side-by-Side2-R



button

VIDEO1 RGB/PC

A

B

Side-by-Side4-R



button



button

VIDEO1



button

Side-by-Side1 Side-by-Side2-L



button



button

VIDEO1 RGB/PC



button

Side-by-Side3 Side-by-Side4-L

RGB/PC

AB

AB



button



button



button



button



button

VIDEO1 RGB/PC

A



button

VIDEO1 RGB/PC

A

To swap the picture on the right and the left, press the



cursor

button.



button

Information

Split screen operations may not function depending on
the combination of input signals. In the table below,
“” means Yes, “” means No.

Pictures displayed on the right/main screen (Select1)

VIDEO1

VIDEO2

DVD/HD1

Pictures

displayed on

the left/sub

screen

(Select2)

VIDEO1

VIDEO2

DVD/HD1

DVD/HD2

HDMI1

HDMI2

RGB/PC

DVD/HD2











































HDMI1





























HDMI2















RGB/PC















 Split screen operations may not function

depending on the frequency of the RGB
signals.

To make the desired picture active, press the ACTIVE
SELECT button.

ACTIVE SELECT
button

En-14

Operations in the Picture-in-picture mode

T o move the position of the sub screen, press the cursor
or  button.



VIDEO1 RGB/PC

A

B

Top Left



button

VIDEO1

A

Bottom Left Bottom Right

B



button

RGB/PC

button



button



button



button

VIDEO1



button

VIDEO1 RGB/PC

To change the size of the sub screen, press the

VIDEO1 RGB/PC

B

Top Right

B



RGB/PC

A



button

A

button.

B

A

VIDEO1

RGB/PC

Selecting the input signals to be displayed



1. Press the ACTIVE SELECT button to make the desired
picture active.

2. Press the PC/RGB, VIDEO1, 2 or DVD/HD1, 2, 3, 4
button to change the selection of the input signal.
The INPUT/EXIT button on the monitor can also be used
to change the selection.

Zooming in on a specific input

1. Press the ACTIVE SELECT button to make the desired
picture active.

2. Use the ZOOM ( or ) button to enlage the picture.
For details, see “DIGITAL ZOOM” on page En-11.

Adjusting the OSM controls

1. Press the ACTIVE SELECT button to make the desired
picture active.

2. Press the MENU/ENTER button to display the MAIN
MENU.

3. Adjust the setting to your preference.
For details, see “OSM (On Screen Menu) Controls” on
page En-16.

B

 button

A

VIDEO1

RGB/PC

B

 button

A

VIDEO1 RGB/PC

B

 button

 button

To make the desired picture active, press the ACTIVE
SELECT button.

VIDEO1 RGB/PC

B

A

ACTIVE
SELECT
button

A

VIDEO1 RGB/PC

B

A

Note:

During enhanced split screen, some functions of OSM
controls ar e not available.

En-15

OSM (On Screen Menu) Controls

Menu Operations

The following describes how to use the menus and the
selected items.

1. Press the MENU/ENTER button on the remote control to
display the MAIN MENU.

MAIN MENU


AUDIO

IMAGE ADJ.

MENU/ENTER

SEL.

2. Press the cursor buttons ▲ ▼ on the remote control to
highlight the menu you wish to enter.

3. Press the MENU/ENTER button on the remote control to
select a sub menu or item.

PICTURE MEMORY
CONTRAST
BRIGHTNESS
SHARPNESS
COLOR
TINT
NR
COLOR TEMP.
CINEMA MODE
PICTURE MODE


SIGNAL INFO.

OK

: OFF

: OFF
: MIDDLE
: ON
: NORMAL

SET UP

FUNCTION

EXIT

EXIT

: 52
: 32
: 16
: 32

GR

: 32

Information

 Advanced menu mode

When “ADVANCED OSM” is set to “ON” in the
FUNCTION menu, full menu items will be shown.

PICTURE MEMORY
CONTRAST
BRIGHTNESS
SHARPNESS
COLOR
TINT
NR
COLOR TEMP.
CINEMA MODE
PICTURE MODE
GAMMA
LOW TONE
SET UP LEVEL
COLOR TUNE

SEL. ADJ. RETURN


: OFF

: OFF
: MIDDLE
: ON
: NORMAL
: 2.2
: AUTO
: 0%

MENU/ENTER

OK

EXIT

: 52
: 32
: 16
: 32

GR

: 32

* The actual screen may be different from the ones

in this manual.

SEL. ADJ. RETURN

MENU/ENTER

OK

EXIT

4. Adjust the level or change the setting of the selected item
by using the cursor buttons

CONTRAST

 

on the remote control.

:

10

5. The adjustments or settings are then stored in memory.
The change is stored until another change is made.

6. Repeat steps 2 – 5 to adjust an additional item, or press
the EXIT button on the remote control to return to the
main menu.

* When adjusting using the bar at the bottom of the screen,

press the  or  button within 5 seconds. If not, the current
setting is stored and the previous screen appears.

Note:

The main menu disappears by pressing the EXIT

button.

En-16

Menu Tree

: Shaded areas indicate the default value.

←→

: Press the

: Menu items in a ruled box are available when the ADVANCED OSM is set to ON.



or  button to adjust.

Main menu Sub menu Sub menu 2 Sub menu 3 Sub menu 4 RESET

PICTURE PICTURE MEMORY OFF/MEMORY1-6 YES En-19

Main menu Sub menu Sub menu 2 Sub menu 3 Sub menu 4 RESET

AUDIO BASS ←→ 0←13→26 YES En-22

CONTRAST ←→ 0←52→72 YES En-19
BRIGHTNESS ←→ 0←32→64 YES En-19
SHARPNESS ←→ 0←16→32 YES En-19
COLOR ←→ 0←32→64 YES En-19
TINT R←→G 0←32→64 YES En-19
NR OFF/NR-1/NR-2/NR-3 YES En-19
COLOR TEMP. LOW/MIDDLE LOW/MIDDLE/HIGH YES En-20
WHITE BALANCE GAIN RED ←→ 0←40→70 YES En-20

GAIN GREEN ←→ 0←40→70 YES En-20
GAIN BLUE ←→ 0←40→70 YES En-20
BIAS RED ←→ 0←40→70 YES En-20
BIAS GREEN ←→ 0←40→70 YES En-20
BIAS BLUE ←→ 0←40→70 YES En-20
RESET OFF←→ON YES En-20

CINEMA MODE ON←→OFF YES En-20
PICTURE MODE DEFAULT/THEATER1/THEATER2/NORMAL/BRIGHT YES En-20
GAMMA 2.1←→2.2←→2.3←→2.4 YES En-21
LOW TONE *
SET UP LEVEL 0%←→3.75%←→7.5% YES En-21
COLOR TUNE RED Y←→M0←32→64 YES En-21

TREBLE ←→ 0←13→26 YES En-22
BALANCE L←→R -22←0→+22 YES En-22
AUDIO INPUT1 VIDEO 1-2 / DVD/HD 1-4 / RGB YES En-22
AUDIO INPUT2 VIDEO 1-2 / DVD/HD 1-4 / RGB YES En-22
AUDIO INPUT3 VIDEO 1-2 / DVD/HD 1-4 / RGB YES En-22
DVD/HD3 INPUT INPUT 1-3 / HDMI YES En-22
DVD/HD4 INPUT INPUT 1-3 / HDMI YES En-22

3

AUTO←→1←…→3 YES En-21

GREEN C←→Y0←32→64 YES En-21
BLUE M←→C0←32→64 YES En-21
YELLOW G←→R0←32→64 YES En-21
MAGENTA R←→B0←32→64 YES En-21
CYAN B←→G0←32→64 YES En-21
RESET OFF←→ON YES En-21

REFERENCE

REFERENCE

Main menu Sub menu Sub menu 2 Sub menu 3 Sub menu 4 RESET

IMAGE ADJUST ASPECT MODE ZOOM/NORMAL/ANAMORPHIC/STADIUM/14:9/2.35:1 — En-22

Main menu Sub menu Sub menu 2 Sub menu 3 Sub menu 4 RESET

SET UP LANGUAGE ENGLISH/DEUTSCH/FRANÇAIS/ESPAÑOL/ITALIANO/SVENSKA/У/PORTUGUÊS NO En-23

V-POSITION ←→ -64←0→+64 YES En-22
H-POSITION ←→ -128←0→+127 YES En-22
V-HEIGHT ←→ 0←→64 YES En-22
H-WIDTH ←→ 0←→64 YES En-22
AUTO PICTURE ON←→OFF*
FINE PICTURE*
PICTURE ADJ.*

DVD/HD1 INPUT COMPONENT YES En-23
D-SUB INPUT RGB YES En-23
HD SELECT 1080I/1035I/540P NO En-23
RGB SELECT AUTO YES En-23
HDMI SET UP LOW←→HIGH NO En-24
COLOR SYSTEM AUTO/PAL/PAL-M/PAL-N/PAL 60/SECAM/4.43 NTSC/3.58NTSC NO En-24
BACK GROUND BLACK/GRAY YES En-24
GRAY LEVEL 0←…→3←…→15 YES En-25
S1/S2 AUTO←→OFF YES En-25
DISPLAY OSM ON←→OFF YES En-25
OSM ADJ. TOP LEFT←→TOP CENTER←→TOP RIGHT←→BTM LEFT←→BTM CENTER←→BTM RIGHT YES En-25
REMOTE ID ALL←→1←…→4 YES En-26
ALL RESET ON←→OFF — En-26

1

←→*20←→64 YES En-22

1

←→*20←→128 YES En-22

2

NO En-22

REFERENCE

REFERENCE

En-17

Main menu Sub menu Sub menu 2 Sub menu 3 Sub menu 4 RESET

FUNCTION ADVANCED OSM ON←→OFF YES En-26

POWER MGT. ON←→OFF YES En-26
INPUT SKIP ON←→OFF YES En-27
SUB. PICTURE SUB. P DETECT OFF←→AUTO YES En-27

DISPLAY FADE←→NORMAL YES En-27

SUB. P RATE 20%←…→100% YES En-27
ZOOM NAV OFF←→S BY S←→BTM LEFT←→BTM RIGHT←→TOP RIGHT←→TOP LEFT YES En-27
PICTURE FREEZE OFF←→S BY S1←→S BY S2←→BTM LEFT←→BTM RIGHT←→TOP RIGHT←→TOP LEFT YES En-27
PDP SAVER MANUAL/AUTO PEAK BRIGHT 100%/75%/50%/25% YES En-28

ORBITER OFF/AUTO1/AUTO2 YES En-28
INVERSE/WHITE OFF/INVERSE/WHITE YES En-29
SCREEN WIPER ON/OFF YES En-29
SOFT FOCUS OFF/LEVEL1-4 YES En-29
OSM ORBITER ON/OFF YES En-29

OSM CONTRAST LOW/NORMAL YES En-29
CLOSED CAPTION OFF/CAPTION1-4/TEXT1-4 YES En-29
CAPTION CONT. LOW/NORMAL YES En-30
PWR. ON MODE INPUT LAST / VIDEO 1 / VIDEO 2 / DVD/HD 1-4 / RGB / MULTI YES En-30

VOLUME LAST←→0←…→44 YES En-30

REFERENCE

Main menu Sub menu Sub menu 2 Sub menu 3 Sub menu 4 RESET

SIGNAL INFO. — En-30

REFERENCE

*1 Only when AUTO PICTURE is OFF.
*2 RGB/PC only
*3 “LOW TONE” is only for 50 and 61 inch types.

Information

 Restoring the factory default settings

Select “ALL RESET” under the SET UP menu. Note that this also restores other settings to the factory defaults.

En-18

Picture Settings Menu

Storing picture settings

This function allows you to store in memory the current
input signal and PICTURE menu settings and to recall
these settings when necessary.
There are six picture memories, and notes of up to 15
characters can be added to each.

Example: Storing picture settings at MEMORY1

On “PICTURE MEMORY” of “PICTURE” menu, select
“MEMOR Y1”, then press the MENU/ENTER button.

The “PICTURE MEMOR Y” screen appears.

PICTURE MEMORY

MEMORY1 SET RESET

INPUT : DVD/HD1
SIGNAL : 480P
NOTE : DVD/STAR WARS

MEMORY2

INPUT : —
SIGNAL : —
NOTE : —

MEMORY3

INPUT : —
SIGNAL : —
NOTE : —

NEXT PAGE

MENU/ENTER

SEL.

EXIT

RETURN

OK

1 / 2

PICTURE MEMORY

PREVIOUS PAGE

MEMORY4 SET RESET

INPUT : —
SIGNAL : —
NOTE : —

MEMORY5

INPUT : —
SIGNAL : —
NOTE : —

MEMORY6

INPUT : —
SIGNAL : —
NOTE : —

SEL.

ADJ. RETURN

EXIT

Information

 PICTURE MEMORY Settings

OFF: Picture memory not used.
MEMORY1 to 6: Picture memory with the specified

number used. Maximum memories are 6, not depending
on inputs.

 Setting the memory

• Use the ▲ and ▼ button to select the desired memory

place, MEMORY1 to MEMORY6.



• Use the

and  buttons to select “SET”, then press

the MENU/ENTER button.

• If necessary, input a note.

 Resetting the memory

Use the ▲ and ▼ button to select the desired memory
place, MEMORY1 to MEMORY6, then use the



buttons to select “RESET”, and finally press the
MENU/ENTER button.
The memory is cleared, and “—” is displayed in the
“INPUT”, “SIGNAL” and “NOTE” columns.

 Inputting notes



• Use the

and  buttons to select “NOTE”, then press

the MENU/ENTER button.

• Input the note.

Use the ▲ and ▼ button to select the character.

Use the



and  buttons to move the cursor.
Use the EXIT button to delete the character at the
cursor position.

• When you have finished inputting the note, press the
MENU/ENTER button.



2 / 2

and

Adjusting the picture

The contrast, brightness, sharpness, color and tint can be
adjusted as desired.

Example: Adjusting the contrast

On “CONTRAST” of “PICTURE” menu, adjust the contrast.

PICTURE MEMORY
CONTRAST
BRIGHTNESS
SHARPNESS
COLOR
TINT
NR
COLOR TEMP.
CINEMA MODE
PICTURE MODE
GAMMA
LOW TONE
SET UP LEVEL
COLOR TUNE

SEL. ADJ. RETURN

Note:


: OFF

: OFF
: MIDDLE
: ON
: NORMAL
: 2.2
: AUTO
: 0%

EXIT

: 52
: 32
: 16
: 32

GR

: 32

CONTRAST

If “CAN NOT ADJUST” appears ...

:

10

When trying to enter the PICTURE submenu, make sure
PICTURE MODE is not set to DEFAULT.

Information

 Picture adjustment screen

CONTRAST: Changes the picture’s white level.
BRIGHTNESS: Changes the picture’s black level.
SHARPNESS: Changes the picture’s sharpness.

Adjusts picture detail of VIDEO display.

COLOR: Changes the color density.
TINT: Changes the picture’s tint. Adjust for natural

colored skin, background, etc.

 Adjusting the computer image

Only the contrast and brightness can be adjusted when
a computer signal is connected.

 Restoring the factory default settings

Select “DEFAULT” under the “PICTURE MODE”
settings.

Reducing noise in the picture

Use these settings if the picture has noise due to poor
reception or when playing video tapes on which the picture
quality is poor.

Example: Setting “NR-3”

On “NR” of “PICTURE” menu, select “NR-3”.

PICTURE MEMORY
CONTRAST
BRIGHTNESS
SHARPNESS
COLOR
TINT
NR
COLOR TEMP.
CINEMA MODE
PICTURE MODE
GAMMA
LOW TONE
SET UP LEVEL
COLOR TUNE

SEL. ADJ. RETURN


: OFF

: OFF
: MIDDLE
: ON
: NORMAL
: 2.2
: AUTO
: 0%

EXIT

: 52
: 32
: 16
: 32

GR

: 32

:

NR

NR-3

Information

 NR

* “NR” stands for Noise Reduction.
* This function reduces noise in the picture.

 Types of noise reduction

There are three types of noise reduction. Each has a
different level of noise reduction.
The effect becomes stronger as the number increases
(in the order NR-1 → NR-2 → NR-3).

OFF: Turns the noise reduction function off.

En-19

Setting the color temperature

Use this procedure to set color tone produced by the plasma
display.

Example: Setting “HIGH”

On “COLOR TEMP .” of “PICTURE” menu, select “HIGH”.

PICTURE MEMORY
CONTRAST
BRIGHTNESS
SHARPNESS
COLOR
TINT
NR
COLOR TEMP.
CINEMA MODE
PICTURE MODE
GAMMA
LOW TONE
SET UP LEVEL
COLOR TUNE

SEL. ADJ. RETURN


: OFF

: OFF
: HIGH
: ON
: NORMAL
: 2.2
: AUTO
: 0%

EXIT

: 52
: 32
: 16
: 32

GR

: 32

Information

 Setting the color temperature

LOW: More red
MIDDLE LOW: Slightly red
MIDDLE: Standard (slightly bluer)
HIGH: More blue

Adjusting the color to the desired level

Use this procedure to adjust the white balance for each
color temperature to achieve the desired color quality.

Example: Adjusting the “GAIN RED” of “HIGH” color
temperature

On “COLOR TEMP .” of “PICTURE” menu, select “HIGH”,
then press the MENU/ENTER button.
The “WHITE BALANCE” screen appears.

On “GAIN RED”, adjust the white balance.

WHITE BALANCE

COLOR TEMP. HIGH

GAIN RED
GAIN GREEN
GAIN BLUE
BIAS RED
BIAS GREEN
BIAS BLUE
RESET

SEL. ADJ. RETURN

: OFF

EXIT

: 20
: 40
: 40
: 40
: 40
: 40

GAIN RED

:

20

Information

 Adjusting the white balance

GAIN R/G/B: White balance adjustment for white level
BIAS R/G/B: White balance adjustment for black level
RESET: Resets settings to the factory default values.



Use

and  buttons to select “ON”, then press the

MENU/ENTER button.
 Restoring the factory default settings
Select “RESET” under the WHITE BALANCE menu.

Setting the picture to suit the movie

The film image is automatically discriminated and
projected in an image mode suited to the picture.
[NTSC, PAL, PAL60, 480I (60Hz), 525I (60Hz), 576I
(50Hz), 625I (50Hz), 1035I (60Hz), 1080I (60Hz) only]

Example: Setting the “CINEMA MODE” to “OFF”

On “CINEMA MODE” of “PICTURE” menu, select “OFF”.

PICTURE MEMORY
CONTRAST
BRIGHTNESS
SHARPNESS
COLOR
TINT
NR
COLOR TEMP.
CINEMA MODE
PICTURE MODE
GAMMA
LOW TONE
SET UP LEVEL
COLOR TUNE

SEL. ADJ. RETURN


: OFF

: OFF
: MIDDLE
: OFF
: NORMAL
: 2.2
: AUTO
: 0%

EXIT

: 52
: 32
: 16
: 32

GR

: 32

Information

 CINEMA MODE

ON: Automatic discrimination of the image and
projection in cinema mode.
OFF: Cinema mode does not function.

Setting the picture mode according to the
brightness of the room

There are four picture modes that can be used effectively
according to the environment in which you are viewing
the display.

Example: Setting the “THEATER1” mode

On “PICTURE MODE” of “PICTURE” menu, select
“THEATER1”.

PICTURE MEMORY
CONTRAST
BRIGHTNESS
SHARPNESS
COLOR
TINT
NR
COLOR TEMP.
CINEMA MODE
PICTURE MODE
GAMMA
LOW TONE
SET UP LEVEL
COLOR TUNE

SEL. ADJ. RETURN


: OFF

: OFF
: MIDDLE
: ON
: NORMAL
: 2.2
: AUTO
: 0%

EXIT

: 52
: 32
: 16
: 32

GR

: 32

:

PICTURE MODE

THEATER1

Information

 Types of picture modes

THEA TER1, 2: Set this mode when watching video in a
dark room.
This mode provides darker, finer pictures, like the screen
in movie theaters.
For a darker image, select THEATER2.
NORMAL: Set this mode when watching video in a bright
room.
This mode provides dynamic pictures with distinct
differences between light and dark sections.
BRIGHT: This mode provides brighter pictures than
NORMAL.
DEFAULT : Use this to reset the picture to the factory
default settings.
ISF-DA Y and ISF-NIGHT : This mode is displayed only
when an ISF dealer performs a maintenance. Please
contact NEC Solutions (America), Inc. for details.

En-20

Changing the Gamma Curve

This feature adjusts the brightness of the midtone areas
while keeping shadows and highlights unchanged.

Example: Setting “2.3”

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

On “GAMMA” of “PICTURE” menu, select “2.3”.

PICTURE MEMORY
CONTRAST
BRIGHTNESS
SHARPNESS
COLOR
TINT
NR
COLOR TEMP.
CINEMA MODE
PICTURE MODE
GAMMA
LOW TONE
SET UP LEVEL
COLOR TUNE

SEL. ADJ. RETURN


: OFF

: OFF
: MIDDLE
: ON
: NORMAL
: 2.3
: AUTO
: 0%

EXIT

: 52
: 32
: 16
: 32

GR

: 32

Information

 GAMMA settings

The picture becomes darker as the number increases
(in the sequence of 2.1, 2.2, 2.3, 2.4).

* These values are approximate.

Making the Low Tone adjustments

This feature allows more detailed tone to be reproduced
especially in the dark area.
* This function is available only for 50 and 61 inches.

Example: Setting “2”

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

On “LOW TONE” of “PICTURE” menu, select “2”.

PICTURE MEMORY
CONTRAST
BRIGHTNESS
SHARPNESS
COLOR
TINT
NR
COLOR TEMP.
CINEMA MODE
PICTURE MODE
GAMMA
LOW TONE
SET UP LEVEL
COLOR TUNE

SEL. ADJ. RETURN


: OFF

: OFF
: MIDDLE
: ON
: NORMAL
: 2.2
: 2
: 0%

EXIT

: 52
: 32
: 16
: 32

GR

: 32

Information

 LOW TONE settings

AUTO: Will automatically appraise the picture and
make adjustments.

1: W ill apply the dither method suitable for still pictures.
2: Will apply the dither method suitable for motion

pictures.
3: Will apply the error diffusion method.

Adjusting the pedestal level (black level)

This feature adjusts the video black level in a video image.

Example: Setting “3.75%”

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

On “SET UP LEVEL” of “PICTURE” menu, select “3.75%”.

PICTURE MEMORY
CONTRAST
BRIGHTNESS
SHARPNESS
COLOR
TINT
NR
COLOR TEMP.
CINEMA MODE
PICTURE MODE
GAMMA
LOW TONE
SET UP LEVEL
COLOR TUNE

SEL. ADJ. RETURN


: OFF

: OFF
: MIDDLE
: ON
: NORMAL
: 2.2
: AUTO
: 3.75%

EXIT

: 52
: 32
: 16
: 32

GR

: 32

Information

 SET UP LEVEL settings

0%: Normal status

3.75%: 3.75% lower than normal

7.5%: 7.5% lower than normal

Adjusting the colors

Use this procedure to adjust hue and color density for red,
green, blue, yellow, magenta and cyan without changing
the white point.
You can accentuate the green color of trees, the blue of
the sky, etc.

Example: Adjusting the color tune for blue

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

On “PICTURE” menu, select “COLOR TUNE”, then press
the MENU/ENTER button.
The “COLOR TUNE” screen appears.

On “BLUE” of “COLOR TUNE”, adjust the color tune.

COLOR TUNE

RED
GREEN
BLUE
YELLOW
MAGENTA
CYAN
RESET

SEL. ADJ. RETURN

Y
C
M
G
R
B

: OFF

EXIT

M
Y
C
R
B
G

: 32
: 32
: 20
: 32
: 32
: 32

Information

 COLOR TUNE settings

RED: Adjusts hue of Red
GREEN: Adjusts hue of Green
BLUE: Adjusts hue of Blue
YELLOW: Adjusts hue of Yellow
MAGENTA: Adjusts hue of Magenta
CYAN: Adjusts hue of Cyan
RESET: Resets settings to the factory default value.



and  buttons to select “ON”, then press the

Use
MENU/ENTER button.

En-21

Audio Settings Menu

Adjusting the treble, bass and left/right
balance and audio input select

The treble, bass and left/right balance can be adjusted to
suit your tastes.

Example: Adjusting the bass

On “BASS” of “AUDIO” menu, adjust the bass.

AUDIO

: VIDEO1
: DVD/HD1
: RGB
: HDMI
: HDMI

EXIT

Note :

BASS
TREBLE
BALANCE
AUDIO INPUT1
AUDIO INPUT2
AUDIO INPUT3
DVD/HD3 INPUT
DVD/HD4 INPUT

SEL. ADJ. RETURN

If “CAN NOT ADJUST” appears...

Set “AUDIO INPUT” on the AUDIO menu correctly.

Information

䡵 Audio settings menu

BASS: Controls the level of low frequency sound.
TREBLE: Controls the level of high frequency sound.
BALANCE: Controls the balance of the left and right

channels.

Setting the allocation of the audio and DVD/
HD connectors

Setting the AUDIO1-3 and DVD/HD3-4 connectors to the
desired input.

Example: Setting “AUDIO INPUT1” to “VIDEO 2”

On “AUDIO INPUT1” of “AUDIO” menu, select
“VIDEO2”.

The available sources depend on the settings of input.

BASS
TREBLE
BALANCE
AUDIO INPUT1
AUDIO INPUT2
AUDIO INPUT3
DVD/HD3 INPUT
DVD/HD4 INPUT

SEL. ADJ. RETURN

AUDIO

: VIDEO2
: DVD/HD1
: RGB
: HDMI
: HDMI

EXIT

Information

An input cannot be selected as the channel for more
than one input terminal.

: 23
: 13

RL

: 0

: 13
: 13

RL

: 0

Image Adjust Settings Menu

Adjusting the Position, Size, Fine Picture, Picture Adj

The position of the image can be adjusted and flickering
of the image can be corrected.

Example: Adjusting the vertical position in the normal
mode

On “V -POSITION” of “IMAGE ADJUST” menu, adjust the
position.

䊴

The mode switches as follows each time the
pressed:

NORMAL ↔ ANAMORPHIC

* The mode can also be switched by pressing the WIDE

button on the remote control.

* The settings on the IMAGE ADJUST menu are not preset

at the factory.

ASPECT MODE
V-POSITION
H-POSITION
V-HEIGHT
H-WIDTH
AUTO PICTURE
FINE PICTURE
PICTURE ADJ.

IMAGE ADJUST

: NORMAL

: OFF

SEL. ADJ. RETURN

EXIT

: 0
: 0
: 0
: 0

: 0
: 0

V-POSITION

Information

䡵 When “AUTO PICTURE” is “OFF”

ASPECT MODE
V-POSITION
H-POSITION
V-HEIGHT
H-WIDTH
AUTO PICTURE
FINE PICTURE
PICTURE ADJ.

IMAGE ADJUST

SEL. ADJ. RETURN

: ANAMORPHIC

: OFF

EXIT

When Auto Picture is off, the Fine Picture and the
Picture ADJ. items are displayed so that you can adjust
them.

䡵 Adjusting the Auto Picture

ON: The Picture ADJ., Fine Picture and Position
adjustments are made automatically.
Not available for digital ZOOM.
OFF: The Picture ADJ., Fine Picture and Position
adjustments are made manually.

* If FINE PICTURE can’t be adjusted, set Auto Picture

to OFF and adjust manually.

䡵 Adjusting the position of the image

V-POSITION: Adjusts the vertical position of the
image.
H-POSITION: Adjusts the horizontal position of the
image.
V-HEIGHT: Adjusts the vertical size of the image. (Not
available for STADIUM mode)
H-WIDTH: Adjusts the horizontal size of the image.
(Not available for STADIUM mode)

FINE PICTURE*: Adjusts for flickering.
PICTURE ADJ.*: Adjusts for striped patterns on the

image (i.e. vertical banding).
* The Picture ADJ. and Fine Picture features are available

only when the “Auto Picture” is off.

* The AUTO PICTURE, FINE PICTURE and PICTURE

ADJ. are available only for RGB signals.
But, these features are not available for moving pictures
on VIDEO, DVD/HD or RGB.

or 䊳 button is

: 0
: 0
: 0
: 0

: 0
: 0

:

-30

En-22

SET UP Settings Menu

Setting the language for the menus

The menu display can be set to one of eight languages.

Example: Setting the menu display to “DEUTSCH”

On “LANGUAGE” of “SET UP” menu, select “DEUTSCH”.

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

SEL. ADJ. RETURN

SET UP

: DEUTSCH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: ALL
: OFF

EXIT

Checking the signal being transmitted to PC/
RGB terminal

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

Use this to confirm the signal being transmitted to the PC/
RGB terminal.
It is set to RGB and can not be adjusted.

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

CAN NOT ADJUST

SET UP

: ENGLISH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: ALL
: OFF

Information

䡵 Language settings

ENGLISH ........English

DEUTSCH.......German

FRANÇAIS...... French

ESPAÑOL ....... Spanish

ITALIANO.......Italian

SVENSKA ......Swedish

У .......... Russian

PORTUGUÊS .....

Portuguese

Checking the signal being transmitted to
DVD/HD1 terminal

Set “ADV ANCED OSM” to “ON” in the FUNCTION menu.

Use this to confirm the signal being transmitted to DVD/
HD1 terminal.

It is set to COMPONENT and can not be adjusted.

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

CAN NOT ADJUST

SET UP

: ENGLISH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: ALL
: OFF

Setting high definition images to the suitable
screen size

Use this procedure to set whether the number of vertical
lines of the input high definition image is 1080I or 1035I
or 540P.

Example: Setting the “HD SELECT” mode to “1035I”

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

On “HD SELECT” of “SET UP” menu, select “1035I”.

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

SEL. ADJ. RETURN

SET UP

: ENGLISH
: COMPONENT
: RGB
: 1035I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: ALL
: OFF

EXIT

Information

䡵 HD SELECT modes

These 3 modes are not displayed in correct image
automatically.

1080I: Standard digital broadcasts
1035I: Japanese “High Vision” signal format
540P: Special Digital broadcasts (for example :

DTC100)

Setting a computer image to the correct RGB
select screen

With the computer image, select the RGB Select mode
for a moving image such as (video) mode, wide mode or
digital broadcast.

Example: Setting the “RGB SELECT” mode to
“852⳯480 ”

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

On “RGB SELECT” of “SET UP” menu, select “852⳯480”.

SET UP

: ENGLISH
: COMPONENT
: RGB
: 1080I
: 852⳯480
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: ALL
: OFF

EXIT

En-23

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

SEL. ADJ. RETURN

Information

䡵 RGB SELECT modes

AUTO: Select the suitable mode for the specifications
of input signals as listed in the table “Computer input
signals supported by this system” on page En-3 of
Model Information.
The others: The available resolutions are shown.

See page En-3 of Model Information for the details of the
above settings.

Setting the black level for HDMI signal

Set the black level.

Example: Setting the “HDMI SET UP” mode to “LOW”

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

On “HDMI SET UP” of “SET UP” menu, select “LOW”.

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

SEL. ADJ. RETURN

SET UP

: ENGLISH
: COMPONENT
: RGB
: 1080I
: AUTO
: LOW
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: ALL
: OFF

EXIT

Information

䡵 HDMI SET UP settings

LOW: When connected to the PC signal.
HIGH: When connected to the SET TOP BOX, DVD

etc. Change “HIGH” into “LOW” if the black level
appears gray.

Setting the video signal format

Use these operations to set the color systems of composite
video signals or Y/C input signals.

Example: Setting the color system to “3.58 NTSC”

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

On “COLOR SYSTEM” of “SET UP” menu, select
“3.58NTSC”.

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

SEL. ADJ. RETURN

SET UP

: ENGLISH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: 3.58NTSC
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: ALL
: OFF

EXIT

Information

䡵 Video signal formats

Different countries use different formats for video signals.
Set to the color system used in your current country .
AUTO: The color systems are automatically identified
and the format is set accordingly.
PAL: This is the standard format used mainly in the
United Kingdom and Germany.
SECAM: This is the standard format used mainly in
France and Russia.

4.43 NTSC, P AL60: This format is used for videos in
countries using PAL and SECAM video signals.

3.58 NTSC: This is the standard format used mainly
in the United States and Japan.
PAL-M: This is the standard format used mainly in
Brazil.
PAL-N: This is the standard format used mainly in
Argentina.

Setting the background color when no signal
is being input

The color displayed on the background when there is no
signal can be set to gray.

Example: Setting “BACK GROUND” to “BLACK”

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

On “BACK GROUND” of “SET UP” menu, select
“BLACK”.

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

SEL. ADJ. RETURN

SET UP

: ENGLISH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: AUTO
: BLACK
: 3
: OFF
: ON
: TOP LEFT
: ALL
: OFF

EXIT

Information

䡵 BACK GROUND Settings

BLACK: Sets the background color to black.
GRAY: Sets the background color to gray.

Setting this makes it easier to see that there is no signal.

En-24

Setting the gray level for the sides of the screen

Use this procedure to set the gray level for the parts on the
screen on which nothing is displayed when the screen is
set to the 4:3 size.

Example: Setting “GRAY LEVEL” to “5”

Set “ADV ANCED OSM” to “ON” in the FUNCTION menu.

On “GRAY LEVEL” of “SET UP” menu, select “5”.

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

SEL. ADJ. RETURN

SET UP

: ENGLISH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: AUTO
: GRAY
: 5
: OFF
: ON
: TOP LEFT
: ALL
: OFF

EXIT

Information

䡵 GRAY LEVEL settings

This adjusts the brightness of the black (the gray level)
for the sides of the screen.
The standard is 0 (black). The level can be adjusted
from 0 to 15. The factory setting is 3 (dark gray).

Setting the screen size for S1/S2 video input

If the S-video signal contains screen size information, the
image will be automatically adjusted to fit the screen when
this S1/S2 is set to AUTO.
This feature is available only when an S-video signal is
input via the VIDEO2 terminal.

Example: Setting “S1/S2” to “AUTO”

Set “ADV ANCED OSM” to “ON” in the FUNCTION menu.

On “S1/S2” of “SET UP” menu, select “AUTO”.

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

SEL. ADJ. RETURN

SET UP

: ENGLISH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: AUTO
: ON
: TOP LEFT
: ALL
: OFF

EXIT

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

SEL. ADJ. RETURN

SET UP

: ENGLISH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: OFF
: TOP LEFT
: ALL
: OFF

EXIT

Information

䡵 DISPLAY OSM settings

ON: The informations on screen size, volume control,
etc. will be shown.
OFF: The informations on screen size, volume control,
etc. will not be shown.
The DISPLAY button on the remote control will not
function either.

Setting the position of the menu

Adjusts the position of the menu when it appears on the
screen.

Example: Set the position to “TOP CENTER”

Set “ADV ANCED OSM” to “ON” in the FUNCTION menu.

On “OSM ADJ.” of “SET UP” menu, select “TOP CENTER”.

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

SEL. ADJ. RETURN

SET UP

: ENGLISH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP CENTER
: ALL
: OFF

EXIT

Information

䡵 OSM ADJ. settings

TOP

LEFT

BTM

LEFT

TOP

CENTER

BTM

CENTER

TOP

RIGHT

BTM

RIGHT

Information

䡵 S1/S2 settings

AUTO: Adjusts the screen size automatically according
to the S1/S2 video signal.
OFF: Turns the S1/S2 function off.

T urning on/off the menu display

When this is set to OFF , the menu will not displayed even
if you press the MENU/ENTER button.

Example: Turning the DISPLAY OSM off

Set “ADV ANCED OSM” to “ON” in the FUNCTION menu.

On “DISPLAY OSM” of “SET UP” menu, select “OFF”.

En-25

Remote ID

Set the remote code to adapt the plasma monitor to the
remote control.

Example: Setting to “1”

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

On “REMOTE ID” of “SET UP” menu, select “1”.

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

SEL. ADJ. RETURN

SET UP

: ENGLISH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: 1
: OFF

EXIT

• Press and hold the POWER ON button, and release the
button when the indication saying that the code is set is
displayed. Or, press and hold the POWER STANDBY
button, and release the button when the power is turned
off.

Information

䡵 REMOTE ID setting

ALL: The remote code is not set.
1 to 4: The specified remote code is applied.

Resetting to the default values

Use these operations to restore all the settings (PICTURE,
AUDIO, IMAGE ADJUST, SET UP, etc) to the factory
default values.

Refer to page En-17 for items to be reset.

On “ALL RESET” of “SET UP” menu, select “ON”, then
press the MENU/ENTER button.

LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET

SEL. ADJ. RETURN

SET UP

: ENGLISH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: ALL
: ON

EXIT

ALL RESET

SETTING NOW

When the “SETTING NOW” screen disappears, then all the
settings are restored to the default values.

Function Settings Menu

Setting the menu mode

This allows you to access the complete menu.

Example: Setting “ON”

On “ADVANCED OSM ” of “FUNCTION” menu, select
“ON ”.

ADVANCED OSM
POWER MGT.
INPUT SKIP
SUB. PICTURE
ZOOM NAV
PICTURE FREEZE
PDP SAVER
CLOSED CAPTION
CAPTION CONT.
PWR. ON MODE

SEL. ADJ. RETURN

Information

䡵 ADVANCED OSM settings

ON: All of the menu items are available for advanced
users.
OFF: Some of the menu items are not available
(e.g.FUNCTION).

Setting the power management for computer
images

This energy-saving (power management) function
automatically reduces the monitor’s power consumption
if no operation is performed for a certain amount of time.

Example:

Turning the power management function on

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

On “POWER MGT.” of “FUNCTION” menu, select “ON”.

ADVANCED OSM
POWER MGT.
INPUT SKIP
SUB. PICTURE
ZOOM NAV
PICTURE FREEZE
PDP SAVER
CLOSED CAPTION
CAPTION CONT.
PWR. ON MODE

SEL. ADJ. RETURN

Information

䡵 Power management function

* The power management function automatically reduces

the monitor’s power consumption if the computer’s
keyboard or mouse is not operated for a certain amount
of time. This function can be used when using the
monitor with a computer.

* If the computer’s power is not turned on or if the

computer and selector tuner are not properly connected,
the system is set to the off state.

* For instructions on using the computer’s power

management function, refer to the computer’s operating
instructions.

䡵 Power management settings

ON: In this mode the power management function is
turned on.
OFF: In this mode the power management function is
turned off.

䡵 Power management function and ON/
STANDBY indicator

The ON/ST ANDBY indicator indicates the status of the
power management function. See En-27 for indicator
status and description.

FUNCTION

: ON
: OFF
: OFF

: BTM LEFT
: S BY S1
: MANUAL
: OFF
: LOW

FUNCTION

: OFF
: ON
: OFF

: BTM LEFT
: S BY S1
: MANUAL
: OFF
: LOW

EXIT

EXIT

En-26

ON/STANDBY indicator

Power
management
mode

On

Off

ON/
STANDBY
indicator

Green

Red

Power
management
operating status

Not activated.

Activated.

Description

Horizontal and vertical
synchronizing signals
are present from the
computer.

Horizontal and/or
vertical synchronizing
signals are not sent
from the computer.

Turning the picture
back on

Picture already on.

Operate the keyboard or
mouse. The picture
reappears.

Setting the Input Skip

When this is ON, signals which are not present will be
skipped over and only pictures whose signals are being
transmitted will be displayed.
This setting is valid only for the INPUT/EXIT button on
the unit.

Example: Set to “ON”

Set “ADV ANCED OSM” to “ON” in the FUNCTION menu.

On “INPUT SKIP” of “FUNCTION” menu, select “ON”.

ADVANCED OSM
POWER MGT.
INPUT SKIP
SUB. PICTURE
ZOOM NAV
PICTURE FREEZE
PDP SAVER
CLOSED CAPTION
CAPTION CONT.
PWR. ON MODE

SEL. ADJ. RETURN

FUNCTION

: OFF
: OFF
: ON

: BTM LEFT
: S BY S1
: MANUAL
: OFF
: LOW

EXIT

Information

 INPUT SKIP settings

OFF: Regardless of the presence of the signal, scan
and display all signals.
ON: If no input signal is present, skip that signal.

* “SETTING NOW” will appear during the input search.

Removing the sub screen area when there is
no input signal detected for the sub screen

This function automatically removes the black frame of
the sub screen when there is no sub screen input signal.
This feature is available only when the picuture-in-picuture
mode is selected.

Example: Setting “DISPLAY” to “FADE”

Set “ADV ANCED OSM” to “ON” in the FUNCTION menu.

On “SUB. PICTURE” of “FUNCTION” menu, press the
MENU/ENTER button.

The “SUB. PICTURE” screen appears.
Adjust the items.

OFF: Turns off the SUB. PICTURE function.

 DISPLAY setting

NORMAL: The sub screen is displayed consistently.
FADE: The sub screen fades in.

 SUB. P RATE setting

Set the transparency of the sub screen.

Displaying the entire image during DIGITAL
ZOOM operations

Use this function to display the entire image within the
sub screen together with an enlarged image on the main
screen.

Example: Setting “ZOOM NAV” to “S BY S”

Set “ADV ANCED OSM” to “ON” in the FUNCTION menu.

On “ZOOM NAV” of “FUNCTION” menu, select “S BY
S”.

ADVANCED OSM
POWER MGT.
INPUT SKIP
SUB. PICTURE
ZOOM NAV
PICTURE FREEZE
PDP SAVER
CLOSED CAPTION
CAPTION CONT.
PWR. ON MODE

SEL. ADJ. RETURN

FUNCTION

: OFF
: OFF
: OFF

: S BY S
: S BY S1
: MANUAL
: OFF
: LOW

EXIT

Information

 ZOOM NAV Function

* This feature does not function during multi screen mode.
* This feature does not function while PICTURE FREEZE

is operating.

* Providing a 2-screen display will cancel this function.

 ZOOM NAV settings

OFF: Will not show the entire image on the sub screen.
S BY S: Will show the entire image on the sub screen

of side-by-side mode.
BTM LEFT~TOP LEFT: Will show the entire image
on the sub screen of picture-in-picture mode.

Side-by-Side Picture-in-Picture

RGB/PC

Zoom+/- button

RGB/PC

SUB. P DETECT
DISPLAY
SUB. P RATE

SEL. ADJ. RETURN

SUB. PICTURE

: AUTO
: FADE
: 100%

EXIT

Information

 SUB. PICTURE Function

* Loss of the input signal means a condition in which the

video signal and the sync signal are not present.

* Under conditions in which the sub screen has

disappeared, the ZOOM NA V and PICTURE FREEZE
functions will not work. The WIDE button will not
function either.

 SUB. P DETECT setting

AUTO: The black frame disappears 3 seconds after the
input signal is lost.

SINGLE button

Displaying still images in the sub screen

This feature enables display in the sub screen of still images
captured by pressing the ACTIVE SELECT button.

Example: Setting “PICTURE FREEZE” to “BTM
LEFT”

En-27

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

On “PICTURE FREEZE” of “FUNCTION” menu, select
“BTM LEFT”.

ADVANCED OSM
POWER MGT.
INPUT SKIP
SUB. PICTURE
ZOOM NAV
PICTURE FREEZE
PDP SAVER
CLOSED CAPTION
CAPTION CONT.
PWR. ON MODE

SEL. ADJ. RETURN

FUNCTION

: OFF
: OFF
: OFF

: BTM LEFT
: BTM LEFT
: MANUAL
: OFF
: LOW

EXIT

Information

 PICTURE FREEZE Function

* This feature does not function during multi screen mode.
* Digital zoom is not available while this function is

operating.

* A further press of the ACTIVE SELECT button while

this function is operating will cancel this function.

* Providing a 2-screen display will cancel this function.

 PICTURE FREEZE settings

OFF: Will not show the still image.
S BY S1, 2: The still images captured by pressing the

ACTIVE SELECT button will be shown on the sub
screen of side-by-side mode.
BTM LEFT~TOP LEFT: The still images captured by
pressing the ACTIVE SELECT button will be shown
on the sub screen of picture-in-picture mode.

Side-by-Side Picture-in-Picture

RGB/PC

RGB/PC

PEAK BRIGHT
ORBITER
INVERSE/WHITE
SCREEN WIPER
SOFT FOCUS
OSM ORBITER
OSM CONTRAST

SEL. ADJ. RETURN

PDP SAVER

: 100%
: AUTO1
: OFF
: OFF
: OFF
: ON
: LOW

EXIT

Information

 When set to AUTO

Set automatically, as described below.

PEAK BRIGHT: 100%
ORBITER: AUTO1 or AUTO2
INVERSE/WHITE: OFF
SCREEN WIPER: OFF
SOFT FOCUS: OFF
OSM ORBITER: ON
OSM CONTRAST: LOW

PEAK BRIGHT

Use this to activate the brightness limiter.

Example: Setting “PEAK BRIGHT” to “75%”

On “PEAK BRIGHT” of “PDP SA VER” menu, select “75%”.

PDP SAVER

PEAK BRIGHT
ORBITER
INVERSE/WHITE
SCREEN WIPER
SOFT FOCUS
OSM ORBITER
OSM CONTRAST

SEL. ADJ. RETURN

: 75%
: AUTO1
: OFF
: OFF
: OFF
: ON
: LOW

EXIT

ACTIVE
SELECT
button

RGB/PC

RGB/PC

ACTIVE
SELECT
button

S BY S1

RGB/PC

RGB/PC

or

S BY S2

RGB/PC

RGB/PC

Reducing image retention

The brightness of the screen, the position of the picture,
positive/negative mode and screen wiper are adjusted to
reduce image retention.

Set “ADVANCED OSM” to “ON” in the FUNCTION menu.

On “PDP SAVER” of “FUNCTION” menu, select
“MANUAL”, then press the MENU/ENTER button.
The “PDP SAVER” screen appears.

Information

 PEAK BRIGHT settings

100%: The brightness of the screen is adjusted
automatically to suit the picture quality.
75%, 50%, 25%: Sets maximum brightness.
The brightness level decreases in the order of 75%,
50%, 25%. 25% provides minimum brightness.

* These values are approximate.

ORBITER

Use this to set the picture shift.

Example: Setting “ORBITER” to “AUTO2”

On “ORBITER” of “PDP SAVER” menu, select “AUTO2”.

PDP SAVER

PEAK BRIGHT
ORBITER
INVERSE/WHITE
SCREEN WIPER
SOFT FOCUS
OSM ORBITER
OSM CONTRAST

SEL. ADJ. RETURN

: 100%
: AUTO2
: OFF
: OFF
: OFF
: ON
: LOW

EXIT

Information

 ORBITER settings

OFF: Orbiter mode does not function.
This is the default setting when RGB is input.
AUTO1: The picture moves around the screen
intermittently, making the picture smaller. This is the
default setting when a Video or a DVD/HD signal is
input. Set to “OFF” when these signals are not used.

AUTO2: The picture moves around the screen

En-28
