Welcome to the TRAKTOR KONTROL Z2 Setup Guide
What Is Included in the Box?
1 Welcome to the TRAKTOR KONTROL Z2 Setup Guide
Thank you for purchasing the TRAKTOR KONTROL Z2. On behalf of the entire Native Instruments team, we hope you are truly inspired by this product. This Setup Guide covers the following topics:
▪ How to install the TRAKTOR software on your computer (↑2, Software Installation)
▪ How to activate your TRAKTOR version using the Service Center application (↑3, Product
Activation With Service Center)
▪ How to connect the devices and get your TRAKTOR KONTROL Z2 system up and running
(↑4, Setting Up Your TRAKTOR KONTROL Z2 System)
▪ How to proceed once your TRAKTOR KONTROL Z2 system is up and running (↑5, What's
Next?)
▪ How to solve common problems (↑6, Troubleshooting and FAQ), and where to find further
product support (↑7, Support)
1.1 What Is Included in the Box?
The TRAKTOR KONTROL Z2 box contains the following items:
▪ The TRAKTOR KONTROL Z2
▪ A power cable
▪ A USB cable
▪ Two Control Vinyls
▪ Two Control CDs
▪ A registration flyer with your TRAKTOR SCRATCH PRO 2 software serial number, your
TRAKTOR KONTROL Z2 hardware serial number, and a link to the hardware registration
page, where you can register your hardware and download the TRAKTOR software
▪ A safety instructions flyer
▪ A TRAKTOR sticker sheet
TRAKTOR KONTROL Z2 - Setup Guide - 7
Welcome to the TRAKTOR KONTROL Z2 Setup Guide
Document Conventions
1.2 Document Conventions
This document uses particular formatting to point out special facts and to warn you of potential issues. The icons introducing the following notes let you see what kind of information can
be expected:
Whenever this exclamation mark icon appears, you should read the corresponding note
carefully and follow the instructions and hints given there if applicable.
This light bulb icon indicates that a note contains useful extra information. This information may often help you to solve a task more efficiently, but does not necessarily apply to
the setup or operating systems you are using; however, it's always worth a look.
Furthermore, the following formatting is used:
▪ Text appearing in (drop-down) menus (such as Open…, Save as…) and paths to locations
on your hard drive or other storage devices is printed in italics.
▪ Text referring to elements appearing on the screen (labels of buttons, controls, text next
to checkboxes, etc.) is printed in light blue. Whenever you see this formatting applied,
you will find the same text appearing on your computer screen.
▪ Text referring to elements printed on hardware is formatted orange. Whenever you see this
formatting applied, you will find the same text appearing on the hardware.
▪ Important names and concepts are printed in bold.
Single instructions are introduced by this play button type arrow.
►
Results of actions are introduced by this smaller arrow.
→
TRAKTOR KONTROL Z2 - Setup Guide - 8
Software Installation
Read Before Installing
2 Software Installation
2.1 Read Before Installing
Before starting the TRAKTOR software installer, here are some points to be aware of:
▪ Make sure you have downloaded the TRAKTOR software to your computer by following the in-
structions on the registration page:
www.native-instruments.com/go-z2
If you have already registered your device but need to download the installer again, you
can find the relevant downloads in the "My Account" section of the NI website:
https://www.native-instruments.com/en/my-account/my-products-serials
▪ Please carefully review the installer screens and the suggested installation paths in order to
avoid that any unwanted folders are created on your hard disk.
▪ Moving any folders related to Native Instruments software after installation is not recom-
mended. Future software updates rely on the directory locations set during initial installa-
tion.
2.2 Installation on Mac OS X
At the end of the installation process, you will need to restart your computer. Please save your
work and close all applications before proceeding.
2.2.1 Locate and Start the Installation Program
1. Locate and unpack the downloaded installer package file on your computer.
2. Double-click the Traktor 2 Installer.mpkg file to start the installation procedure.
3. Follow the on-screen instructions.
TRAKTOR KONTROL Z2 - Setup Guide - 9
Software Installation
Installation on Mac OS X
2.2.2 Select the Components to Install
After you have accepted the software license agreement, the installer window displays the
components available for installation.
There is no dedicated entry for your TRAKTOR KONTROL Z2 in the components selection
screen as the Z2 does not require a dedicated driver under MAC OS X. It is recommended
to keep all remaining drivers selected unless you have a specific reason to deselect one
(such as if the driver is already installed on your computer, or you are very sure you will
never use the device with TRAKTOR).
This installer screen also contains information about how much disk space the individual components will use.
The components selection screen of the installation program.
TRAKTOR KONTROL Z2 - Setup Guide - 10
Software Installation
Installation on Mac OS X
Basic Installation: This installs the TRAKTOR software along with its documentation. This component cannot be deselected. It also installs the Service Center application (required for activation of your product) and the Controller Editor application, which allows you to configure the
controllerʼs MIDI assignments for using the controller with other applications than TRAKTOR.
Audio 8/4/2 DJ Drivers: This installs drivers for the AUDIO 8 DJ, AUDIO 4 DJ and AUDIO 2 DJ
audio interfaces by Native Instruments. If you do not intend to use any of these audio interfaces, you can deactivate the checkboxes.
Traktor Kontrol S4: This installs the driver for the TRAKTOR KONTROL S4 controller. If you do
not intend to use a TRAKTOR KONTROL S4 controller on your computer, you can deactivate
the checkbox.
Traktor Kontrol S2: This installs the driver for your TRAKTOR KONTROL S2 controller. If you do
not intend to use a TRAKTOR KONTROL S2 controller on your computer, you can deactivate
the checkbox.
Traktor Audio 2/6/10 Drivers: This installs the drivers for the TRAKTOR AUDIO 2, TRAKTOR
AUDIO 6 and TRAKTOR AUDIO 10 audio interfaces by Native Instruments. If you do not intend to use any of these audio interfaces, you can deactivate the checkboxes.
Traktor Kontrol X1: This installs the driver for the TRAKTOR KONTROL X1 controller. If you do
not intend to use a TRAKTOR KONTROL X1 controller on your computer, you can deactivate
the checkbox.
Background Components
These components are not displayed in the installer window, but are installed depending on
your system configuration:
Controller Editor: The Controller Editor application allows you to configure your controller for
use as a MIDI controller with applications other than the TRAKTOR software. This component
will automatically be installed unless a newer version of Controller Editor already exists on your
computer.
Service Center: The Service Center application is required for activation of the TRAKTOR software. It will be installed independent of the selected drivers (unless a newer version of Service
Center already exists on your computer).
TRAKTOR KONTROL Z2 - Setup Guide - 11
Software Installation
Installation on Mac OS X
It is strongly recommended to install the TRAKTOR software to the default location. If you still
need to change the install location, click on the folder icon in the Location column and select
the desired folder.
After you have customized the installation as required, click Continue and then follow the
►
on-screen instructions.
2.2.3 Enter Your Password
Before installing the selected components, the installer will prompt you to enter your Mac OS X
password. This is a standard behavior on Mac OS X that makes sure you are aware of the
changes the installer is about to make.
The Mac OS X user account you are using needs to have Administrator privileges.
The Mac OS X password prompt.
To proceed, enter your password and click OK.
►
The selected components will be installed.
→
2.2.4 Complete the Installation
After the components have been installed, you need to restart your computer.
TRAKTOR KONTROL Z2 - Setup Guide - 12
Software Installation
Installation on Mac OS X
The final screen of the installation program.
On the last screen of the installation program, click Restart to restart your computer and
►
complete the software installation.
Your computer will immediately restart.
→
After your computer has restarted, continue reading in chapter ↑3, Product Activation
►
With Service Center of this Setup Guide for information about product activation.
TRAKTOR KONTROL Z2 - Setup Guide - 13
Software Installation
Installation on Windows
2.3 Installation on Windows
If you are installing the TRAKTOR software on Windows Vista or Windows 7, you may need to
turn off Windows User Account Control (UAC) before you can proceed. In addition to this, it
may be necessary to disable your anti-virus software during installation. For further information
on this, please refer to ↑6.2, User Account Control and Internet Security.
2.3.1 Locate and Start the Installation Program
1. Locate and unpack the downloaded installer package file on your computer.
2. Double-click the Traktor 2 Setup.exe file to start the installation procedure.
3. Follow the on-screen instructions.
2.3.2 Confirm the Features to Install
After you have accepted the software license agreement, the installer window displays the features available for installation.
TRAKTOR KONTROL Z2 - Setup Guide - 14
The components selection screen of the installation program.
Software Installation
Installation on Windows
Basic Installation: This installs the TRAKTOR software along with its documentation. This component cannot be deselected.
Background Components
These components are not displayed in the installer window, but are installed depending on
your system configuration:
Controller Editor: The Controller Editor application allows you to configure your controller for
use as a MIDI controller with applications other than the TRAKTOR software. This component
will automatically be installed unless a newer version of Controller Editor already exists on your
computer.
Service Center: The Service Center application is required for activation of the TRAKTOR software. It will be installed independent of the selected drivers (unless a newer version of Service
Center already exists on your computer).
TRAKTOR KONTROL Z2 - Setup Guide - 15
Click Continue and then follow the on-screen instructions.
►
2.3.3 Confirm the Application Installation Path
Software Installation
Installation on Windows
The software installation path screen of the installation program.
It is strongly recommended to install the TRAKTOR software to the default location. If you still
need to change the install location, click Change to open a Folder Selection dialog and select
the desired destination folder.
You will be asked to select and confirm an installation path for the TRAKTOR software.
Click Next to proceed.
►
TRAKTOR KONTROL Z2 - Setup Guide - 16
Software Installation
Installation on Windows
2.3.4 Select Your Hardware Drivers
After defining/confirming the program's installation path, you will be presented with a driver
selection screen. It is recommended to select all drivers from the driver selection screen unless
you have a specific reason to deselect a driver (such as if the driver is already installed on your
computer, or you are very sure you will never use the device with TRAKTOR).
1. Make sure to select the TRAKTOR KONTROL Z2 driver from the driver selection screen.
2. Click Next to proceed.
2.3.5 Complete the Software Installation
Once you have selected the driver and confirmed your selection, you will be forwarded to the
last screen of the installation program.
The final screen of the installation program.
TRAKTOR KONTROL Z2 - Setup Guide - 17
On the last screen of the installation program, click Finish to complete the installation
►
and exit the installation program.
Continue reading in chapter ↑3, Product Activation With Service Center of this Setup
►
Guide for information about product activation.
Software Installation
Installation on Windows
TRAKTOR KONTROL Z2 - Setup Guide - 18
Loading...
