Moultrie L20 User Manual

Instructions for L20

Page 7

Resolution
Resolutions

LOW 1280 x 960

(1.3MP)

HIGH 1600 x 1200

(2.0MP)

Approximate photos stored 1GB SD card

LOW 3800
HIGH 1500

SD Memory Card

4 GB Max
(not included)

Optical Field of View

60 degrees

Batteries

4 Alkaline C-cell
(not included)

Xenon Flash Range

Up to 20 feet

Approximate Detection Range

30 +/-5 feet

GameSpy Digital Camera

GAMESPY OVERVIEW (continued)

THANK YOU for your purchase of the Game Spy L20 Camera. Please read this
booklet before using the unit. If you should have any questions about this product
or any other Moultrie product, please contact us using the information on the back
page. Please register your product at www.moultriefeeders.com TO ACTIVATE
YOUR WARRANTY.

BACK VIEW

Auto

Date

Delete All

Time

Quality

Delay

Multi-shot

reset

Function Switch

Up, Enter, and Down Buttons

ON/OFF Switch

USB Port

SD Card Slot

LCD Display

ENTER

ON/OFF

Battery Compartment

Four Alakaline C Cells

SIDE VIEW

ON / OFF SWITCH

Used for turning On and turning Off the camera.

FUNCTION SWITCH

The Function Switch selects one of the seven functions of the camera: Auto, Date,
Time, Photo Quality, Photo Delay, Multi-shot, and Delete All. When a function is
selected, the ENTER button will activate a setting adjustment and the UP and
DOWN buttons will step through the options. Refer to the FUNCTION SWITCH
DETAILS section of this manual for more information. The software version of the
camera is displayed when the Function Switch is rotated all the way in the
clockwise direction.

SD MEMORY CARD SLOT

The SD Memory Card Slot accepts up to a 4GB SD Card for photo storage. If there
is no SD Card in the slot then the LCD screen will display “NO CARD”.

USB PORT

Download still pictures and video onto your computer by connecting the provided
cable. Refer to the Advanced Information section of this manual for details.

BATTERY COMPARTMENT

The Camera is powered by four (4) C size alkaline batteries.

BATTERY LEVEL INDICATOR

When the batteries get to a low level, the LCD screen will display the Low Battery
Indicator Icon. When the batteries get to a critical level, the camera will not
function, but the Low Battery Indicator Icon will still be visible on the LCD Screen.
The batteries will last approximately 90 days (based on 5 daytime and 5 nighttime
pictures per day).

RESET

The reset button will cause the camera to reset to default values.

Lock

Opening

Open the back panel of the Camera and remove the battery compartment

Page 5

FUNCTION SWITCH DETAILS (cont.)

PHOTO QUALITY

The camera’s current PHOTO QUALITY setting will be displayed by the LCD
when the FUNCTION SWITCH is set to PHOTO QUALITY. Use the Up and
Down buttons to select the desired setting. Press the ENTER button to confirm
the new setting.
The Photo Quality settings are:

- Low: 1280 x 960 (1.3MP)

- High: 1600 x 1200 (2.0MP)

PHOTO DELAY

The camera’s current PHOTO DELAY setting will be displayed by the LCD
when the FUNCTION SWITCH is set to PHOTO DELAY. The camera will
wait a specified number of minutes between each picture. Use the UP and
DOWN buttons to select the desired setting. Press the ENTER button to
confirm the new setting.
The Photo Delay settings are:

- 1min

- 5min

- 10 min

- 30 min

- 60 min

MULTI-SHOT

The camera’s current MULTI-SHOT setting will be displayed by the LCD when
the FUNCTION SWITCH is set to MULTI-SHOT. The camera will
automatically take the specified number of photos, with a 5 second delay
between photos. Use the UP and DOWN buttons to select the desired setting.
Press the ENTER button to confirm the setting.
The Multi-Shot settings are:

- 1-Shot

- 2-Shots

DELETE ALL

The camera’s current DELETE ALL setting will be displayed by the LCD when
the FUNCTION SWITCH is set to DELETE ALL. This function will clear all
contents on the SD Card. Use the UP and DOWN buttons to select the desired
setting. Press the ENTER button to confirm the Delete All function.

cover. Install four (4) C size alkaline batteries with polarities as indicated in
the Battery Compartment. Re-install the Battery Compartment Cover.

Thread the provided Mounting Strap through the Eyelets on the back of the
camera and secure to a tree or pole approximately 36" from the ground as
shown.

Turn Camera on by sliding ON/OFF switch to the ON position.

Rotate the FUNCTION SWITCH to DATE and set the date by pressing the
ENTER button and UP/DOWN buttons to adjust selected field. Rotate the
FUNCTION SWITCH to TIME and set the date by pressing the ENTER
button and UP/DOWN buttons to adjust selected field.

Rotate the FUNCTION SWITCH to AUTO. Your Camera will now
automatically take pictures whenever an animal is detected in range -based
on the default settings below

FUNCTION SWITCH DETAILS

AUTO MODE

The camera’s LCD screen will display the number of photos taken follow by the
pictures remaining when the FUNCTION SWITCH is set to AUTO. This is the
camera’s normal state for taking pictures. During this mode, the camera will
sleep and use a minimal amount of battery life. When the PIR motion sensor
detects an animal, it will wake up the camera and immediately take a picture.

When in AUTO MODE, press the ENTER button and the camera will
immediately take a picture.

DATE

The camera’s current date setting will be displayed by the LCD when the
FUNCTION SWITCH is set to DATE. Press the ENTER button and the Month
digits of the date will flash. Use the UP and DOWN buttons to adjust the
Month. Press the ENTER button to advance to the Day digits and repeat the
process. Press the ENTER button to set Year. Press the ENTER button to
confirm the new settings.

TIME

The camera’s current time setting will be displayed by the LCD when the
FUNCTION SWITCH is set to TIME. Press the ENTER button and the Hour
digits of the Time will flash. Use the UP and DOWN buttons to adjust the
hour. Press the ENTER button to advance to the Minute digits and repeat the
process. Press the ENTER button to set AM or PM. Press the ENTER button
again to confirm the new settings.

Pressing and holding the Up or Down Buttons will cause the digits to increase or
decrease at double speed.

MFH-DGS-L20

Function Setting

Photo Quality
Photo Delay after each photo is taken 1 minute

Multi Shot Count

High

1-Shot
