User’s Guide

Digital Video Baby Monitor

Models: MBP43, MBP43/2, MBP43/3, MBP43/4, MBP43-B

The features described in this User’s Guide are subject to modifications without prior notice.

Welcome...

to your new Motorola Baby Monitor!

Thank you for purchasing the Motorola Video Baby Monitor. Now you can see and hear your baby sleeping in another room or you can monitor your older children in their playroom.

Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage.

For product related questions, please call:

US and Canada 1-888-331-3383

Email: support@motorolamonitors.com

This User's Guide provides you with all the information you need to get the most from your product.

Before you can use the baby monitor, we recommend you insert and fully charge the battery in the parent unit, so that it continues to work if you disconnect it from the power supply to carry it to another location. Please read the Safety Instructions on page 7 before you install the units.

Got everything?

• Parent unit

• Camera unit(s)

• Rechargeable Ni-MH battery pack

• Power adapter for the Parent unit

• Power adapter(s) for the Camera unit In multi-camera packs, you will find one or more additional camera units with power adapter units.

Overview of the Parent Unit

10 12

1. Display (LCD screen)

2. Up Key +

Normal Mode: Tilt Up Menu Mode: Scroll Up

3. Down Key -

Normal Mode: Tilt Down Menu Mode: Scroll Down

4. Left Key <

Normal Mode: Pan Left Menu Mode: Left

5. Right Key >

Normal Mode: Pan Right Menu Mode: Right

6. Menu Key M

Press to open the Menu options

7. OK Key O

8. Video ON/OFF Key V

In monitor mode, press to turn OFF the LCD display Press again to turn ON the LCD display

9. Talk Ke y T

Press and hold to speak to your baby

10. Power Indicator LED

BLUE when mains adapter power on. RED when battery low.

11. Unit ON/OFF LED (Green)

12. Audio Level LED (Green, Orange,

Red, Red)

13. Microphone

14. Power Key P

Press and Hold to turn the unit ON/OFF

15. Antenna

Lift the antenna for optimal reception

16. Battery cover

17. Stand

18. Speaker

19. Power Adapter Socket

Parent unit menu icons

Signal Level (5 Levels)

No Signal

Night Vision Mode (Screen changes to Black/White)

Talk Mo de

Battery Level Control (4 Levels)

Pan Left

Pan Right

Til t Up

Til t Dow n

Volume Level Control (8 Levels)

Brightness Level Control (8 Levels)

Lullaby Control (5 Song Selections)

Zoom Level Control (1X, 2X)

Alarm Setting (6h, 4h, 2h, OFF)

A C

Cam Control (scan , view , add , del )

Temperature Reading (HH °C / °F or LL °C / °F) Icon & readings turn RED > 29°C / 84°F, and reading display HH °C / °F > 36°C / 97°F)

Icon & readings turn RED < 14°C / 57°F, and reading display LL °C / °F < 1°C / 34°F )

Overview of Your Baby Unit

1. Photo Sensor (Night Vision Mode)

2. Camera Lens

3. Infrared LEDs

4. Power LED

5. Microphone

7. ON/OFF Switch

8. Power Adapter Socket

9. Antenna

10. Pair Key

11. Temperature Sensor

6. Speaker

Important guidelines for installing your Baby Monitor

• To use your Video Monitor Baby and Parent Unit together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions.

• Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic doors or reinforced concrete between the Baby and Parent Unit may block the radio signal.

• The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches.

• Use of other 2.4 GHz products, such as wireless networks (Wi-Fi Bluetooth

systems, or microwave ovens, may cause interference with this product, so keep the baby monitor away at least 5ft (1.5m) from these types of products, or turn them off if they appear to be causing interference.

• If the signal is weak, try moving the Parent and/or the Baby Unit to different positions in the rooms.

routers),

Table of contents

1. Safety Instructions..................................................................................... 7

2. Getting Started..........................................................................................9

2.1 Baby Unit Power Supply..............................................................................9

2.2 Parent Unit Battery Installation.................................................................... 9

2.3 Parent Unit Power Supply......................................................................... 10

2.4 Registration (Pairing) ................................................................................ 11

3. Using the Baby Monitor........................................................................... 12

3.1 Setting up ..................................................................................................12

3.2 Pan and Tilt ................................................................................................ 12

3.3 Night Vision Mode .................................................................................... 12

3.4 Talk Mode.................................................................................................. 12

3.5 Video ON/OFF ......................................................................................... 12

3.6 Temperature Display ................................................................................13

4. Parent Unit Menu Options ......................................................................14

4.1 Volume......................................................................................................14

4.2 Brightness.................................................................................................. 14

4.3 Lullaby ....................................................................................................... 14

4.4 Zoom.........................................................................................................14

4.5 Alarm ......................................................................................................... 15

4.6 Camera Control........................................................................................ 15

4.6.1 Add (pair) a camera ..................................................................15

4.6.2 View a camera ........................................................................... 15

4.6.3 Delete a camera ........................................................................16

4.6.4 Scan the cameras ...................................................................... 16

4.7 Temperature ............................................................................................. 16

5. Disposal of The Device (environment) ...................................................17

6. Cleaning ..................................................................................................18

7. Help..........................................................................................................19

8. General Information ................................................................................ 21

6 Table of contents

1. Safety Instructions

WARNING:

STRANGULATION HAZARD - Keep the unit and adapter cord more than 3 feet from the crib out of baby’s reach. NEVER place camera or cords within the crib. Secure the cord more than 3 feet away from the baby’s reach. Never use extension cords with AC Adapters. Only use the AC Adapters provided.

CAMERA SET UP & USE:

● Determine a location for the CAMERA that will provide the best view of your baby in his crib.

● Place the CAMERA on a flat surface, such as a dresser, bureau, or shelf.

● NEVER place camera or cords within the crib.

WARNING

This baby monitor is compliant with all relevant standards regarding electromagnetic fields and is, when handled as described in the User's Guide, safe to use. Therefore, always read the ins tructions in this User's Guide carefully before using the device.

• Adult assembly is required. Keep small parts away from children when assembling.

• This product is not a toy. Do not allow children to play with it.

• This baby monitor is not a substitute for responsible adult supervision.

• Keep this user’s guide for future reference.

• Do not place the baby unit or cords in the crib or within reach of the baby (the unit should be 3 feet away).

• Keep the cords out of reach of children.

• Do not cover the baby monitor with a towel or blanket.

Safety Instructions 7

ENGLISH

• Never use extension cords with power adapters. Only use the power adapters provided.

• Test this monitor and all its functions so that you are familiar with it prior to actual use.

• Do not use the baby monitor near water.

• Do not install the baby monitor near a heat source.

• Only use the chargers and power adapters provided. Do not use other chargers or power adapters as this may damage the device and battery pack.

• Only insert a battery pack of the same type.

• Do not touch the plug contacts with sharp or metal objects.

CAUTION

Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.

8 Safety Instructions

2. Getting Started

Black Red

Small cross head or Flat end screwdriver

2.1 Baby Unit Power Supply

1. Connect the small plug of the power adapter to the baby unit and the other

end to the electrical outlet.

NOTE

Only use the enclosed power adapter (5.9V DC / 1000mA).

2. Slide the ON/OFF switch to the ON position. The power LED will light up in green.

3. Slide the ON/OFF switch to the OFF position to turn the Baby Unit off.

2.2 Parent Unit Battery Installation

1. Insert the wire tab of the rechargeable battery pack into the contact slot as

shown above and fit the battery pack into the compartment.

ENGLISH

2. Replace the battery cover over the compartment and gently tighten the

screw in a clockwise direction using a Small cross head or Flat end screwdriver.

Getting Started 9

2.3 Parent Unit Power Supply

IMPORTANT

Installing the rechargeable battery pack and charging it fully before use is recommended. This will allow the unit to operate on battery in the event of a power failure.

1. Connect the small plug of the power adapter to the parent unit and the other end to the electrical outlet. Only use the enclosed power adapter (6V DC/500mA).

2. Press and hold the the parent unit.

3. Once the baby and parent units are switched on, the display on the parent unit will show the video captured by the baby unit.

4. If there is no connection or you are out of range, the video display will go off and the icon will be shown on the LCD display, and the unit will beep every 5 seconds. Move the parent unit closer to the baby unit until the link is re-established.

5. Press and hold the finishes scrolling, to turn OFF the parent unit.

NOTE

The battery icon turns RED to indicate that the battery is low, and it needs to be recharged. The battery pack takes about 16 hours to charge fully.

When charging

1. If the parent unit is turned OFF, when the adapter is plugged in, a mains

plug logo will display briefly, followed by a large battery icon with internal segments cycling for 45 seconds. The Blue LED in the top left corner lights up to indicate the adapter is plugged in.

P POWER ON/OFF button for 1 second to turn ON

P POWER ON/OFF button, until the progress bar

10 Getting Started

2. If the parent unit is turned ON, when the adapter is plugged in, the battery

icon in the screen’s top right corner will show that the battery is charging by cycling the internal segments, The Blue LED in the top left corner lights up to indicate the adapter is plugged in.

2.4 Registration (Pairing)

The Baby monitor is pre-registered to your Parent Unit. You do not need to register it again unless the Baby Unit loses its link with the Parent Unit. To rere gist er yo ur B aby U nit, or re gis ter a new Baby Unit, follow the procedure below:

1. Press the

2. Press the

the /

3. Press the

button to confirm.

C 1 / C 2 / C 3 / C 4 will pop up, press the + UP button or - DOWN

button to select the desired CAM and press the OK button to start searching for a camera unit. The green audio level LED will flash rapidly while searching.

5. Press and hold the PAIR button underneath the baby unit until the parent

unit finds the camera, beeps and the video from the camera appears.

NOTE

If a particular Baby Unit was registered previously, registering this current Baby Unit again will overwrite the old registration.

M Menu button of the parent unit and the menu bar will pop up. < LEFT button or > RIGHT button until C is highlighted, and

+//

menu will pop up.

+ UP button or - DOWN button to select +, and press the OK

ENGLISH

Getting Started 11

3. Using the Baby Monitor

3.1 Setting up

• Place the baby unit in a convenient location (e.g. on a table) and point the

camera lens towards the area you want to monitor.

• Adjust the baby unit’s head angle by using the parent unit to pan and tilt the

camera up, down, left and right until you are satisfied with the image in the parent unit.

NOTE

Do not place the baby unit within the baby's reach! If there is interference with the picture or sound, try moving the units to different locations, and ensure they are not close to other electrical equipment.

3.2 Pan and Tilt

The camera can be remotely controlled from the parent unit when in normal video mode.

1. Press the

2. Press the

3.3 Night Vision Mode

The baby unit has 8 high-intensity infrared LEDs for picking up clear images in the dark. When the built-in photo sensor detects a low level of ambient light, the LEDs will automatically activate and the screen on the parent unit will display in black and white. The

3.4 Talk Mode

Press and hold the T TALK button on the parent unit to talk to your baby through the baby unit’s loudspeaker. The screen.

3.5 Video ON/OFF

Press the V VIDEO ON/OFF key to turn the LCD display on or off, but still leave the audio monitor on.

+ UP button or - DOWN button to tilt upward or downward. < LEFT button or > RIGHT button to pan left or right.

N icon will be displayed on the screen.

T icon will be displayed at the top of the LCD

12 Using the Baby Monitor

3.6 Temperature Display

The temperature reading from the temperature sensor at the back of the Baby Unit will be displayed at the top of the LCD screen. The readings will turn RED if the temperature goes above 29°C / 84°F or below 14°C / 57°F. The reading will change to and icon flashing in red if the temperature goes above 36°C / 97°F. The reading will change to and icon flashing in red if the temperature goes below 1°C / 34°F.

ENGLISH

Using the Baby Mon itor 13

4. Parent Unit Menu Options

4.1 Volume

1. Press the M Menu button and the menu bar will pop up.

2. If necessary, press the

highlighted.

3. Press the level from level 1~8. (The default volume level setting is level 4.)

+ UP button or - DOWN button to select the desired volume

4.2 Brightness

1. Press the M Menu button and the menu bar will pop up.

2. Press the

3. Press the

< LEFT button or > RIGHT button until & is highlighted.

+ UP button or - DOWN button to select the desired brightness

level from level 1~8. (The default brightness level setting is level 4.)

4.3 Lullaby

1. Press the M Menu button and the menu bar will pop up.

2. Press the

4. Press Menu to return to the normal camera view with the lullaby playing or

Note

If the TALK button is pressed, any lullaby will stop playing automatically.

< LEFT button or > RIGHT button until m is highlighted.

Press the + UP button or - DOWN button to select the desired song from the 5 lullabies available, or press to play all 5 songs in turn. If an individual song is selected it will play repeatedly. (The default setting is )

off, as selected.

4.4 Zoom

1. Press the M button and the menu option bar pop up.

2. Press the

3. Press the

default setting is 1X.)

< LEFT button or > RIGHT button until Z is highlighted.

+ UP button or - DOWN button to select the

< LEFT button or > RIGHT button until * is

or 2X zoom. (The

14 Parent Unit Menu Options

4.5 Alarm

1. Press the M Menu button and the menu bar will pop up.

2. Press the

3. Press the

If an alarm is set, the parent unit will beep for about 45 seconds after every 6, 4 or 2 hour period, and the alarm icon will flash red.

< LEFT button or > RIGHT button until A is highlighted. + UP button or - DOWN button to select the alarm time (

). (The default setting is Alarm .)

6h, 4h

4.6 Camera Control

4.6.1 Add (pair) a camera

1. Press the M Menu button and the menu bar will pop up.

2. Press the

the /

3. Press the

button to confirm.

C 1 / C 2 / C 3 / C 4 will pop up, press the + UP button or - DOWN

button to select the desired CAM, and press the OK button to start searching for a camera unit. The green audio level LED will flash rapidly while searching.

5. Press and hold the PAIR button under the baby unit until the parent unit

finds the camera, beeps and the camera picture appears.

NOTE

A camera can only be registered to one parent unit at a time.

4.6.2 View a camera

1. Press the M Menu button and the menu bar will pop up.

2. Press the

3. Press the

button to confirm.

C 1 / C 2 / C 3 / C 4 will pop up, press the + UP button or - DOWN

button to select desired CAM, and press the OK button to view the picture from that camera.

TIP

Press OK repeatedly for a quick way to View cameras without the menu.

< LEFT button or > RIGHT button until C is highlighted, and

+//

menu will pop up.

+ UP button or - DOWN button to select +, and press the OK

< LEFT button or > RIGHT button until C is highlighted and the

+//

menu pops up.

+ UP button or - DOWN button to select , and press the OK

ENGLISH

Parent Unit Menu Options 15

4.6.3 Delete a camera

1. Press the M Menu button and the menu bar will pop up.

2. Press the

the /

3. Press the button to confirm.

C 1 / C 2 / C 3 / C 4 will pop up, press the + UP button or - DOWN button

to select the desired CAM, and press the OK button to select.

5. Press the

to delete that registration.

< LEFT button or > RIGHT button until C is highlighted, and

+//

menu will pop up.

+ UP button or - DOWN button to select , and press the OK

+ UP or - DOWN button to select

, and press the OK button

4.6.4 Scan the cameras

1. Press the M Menu button and the menu bar will pop up.

2. Press the

the /

3. Press the button to confirm.

4. The screen will then display images from each registered camera in a loop, changing about every 12 seconds.

TIP

Press OK repeatedly for a quick way to go to mode without using the menu.

NOTE

If t he par ent u nit is in sc an mod e and o ne of the re gist ered c amera s is t urned off or out of range, the scan will stop at the missing camera, display "no signal check or del cam 1" (if camera 1 is missing), and emit a warning beep every 5 seconds.

WARNING

Check the camera and correct the fault immediately if you are using that camera to monitor your baby. If you want to continue in camera scan mode without that camera, delete the camera (see 4.6.3 Delete a camera) and start the scan again.

< LEFT button or > RIGHT button until C is highlighted, and

+//

menu will pop up.

+ UP button or - DOWN button to select , and press the OK

4.7 Temperature

1. Press the M Menu button and the menu bar will pop up.

2. Press the

3. Press the

< LEFT button or > RIGHT button until t is highlighted. + UP button or - DOWN button to select °C or °F.

16 Parent Unit Menu Options

5. Disposal of The Device (environment)

At the end of the product lifecycle, you should not dispose of this product with normal household waste. Take this product to a collection point for the recycling of electrical and electronic equipment. The symbol on the product, user's guide and/or box indicates this.

Some of the product materials can be reused if you take them to a recycling point. By reusing some parts or raw materials from used products you make an important contribution to the protection of the environment.

Please contact your local authorities in case you need more information on the collection points in your area.

Dispose of the battery pack in an environmentally-friendly manner according to your local regulations.

ENGLISH

Disposal of The Device (environment) 17

6. Cleaning

Clean the baby monitor with a slightly damp cloth or with an anti-static cloth. Never use cleaning agents or abrasive solvents.

Cleaning and care

• Do not clean any part of the product with thinners or other solvents and

chemicals -- this may cause permanent damage to the product which is not covered by the warranty.

• Keep your baby monitor away from hot, humid areas or strong sunlight, and

don't let it get wet.

• Every effort has been made to ensure high standards of reliability for your

baby monitor. However, if something does go wrong, please do not try to repair it yourself -- contact Customer Service for assistance.

18 Cleaning

7. Help

Display

No display

• Try recharging or replacing the battery pack.

• Reset the units. Disconnect the battery pack of the parent unit and unplug

both the units’ electrical power, then plug them back in.

• Is the unit turned on?

Press and hold the ON/OFF key

• Is the correct camera selected?

Change the camera number, if necessary.

• Is the video display turned on?

Press the VIDEO ON/OFF key

• When operating using batteries, only the Display will go blank after 2 minutes

to save power. The unit is still active and will give you audio alerts. You can reactivate the screen by pressing any key.

Registration

If the Baby Unit has lost its link with the Parent Unit

• Try recharging or replacing the battery pack.

• If the Baby Unit is too far away it may be going out of range, so move the

Baby Unit closer to the Parent Unit.

• Reset the units by disconnecting them from the battery and electrical power.

Wait about 15 seconds before reconnecting. Allow up to one minute for the Baby Unit and the Parent Unit to synchronize.

• See 2.4 Registration (Pairing), if there is a need to re-register the units.

P on the parent unit to turn it ON.

V to turn it on.

ENGLISH

Help 19

Interference

Noise interference on your parent unit

• Your baby and parent units may be too close. Move them farther apart.

• Make sure there is at least 3 to 6 feet (1 to 2 meters) between the 2 units to

avoid audio feedback.

• lf the baby unit is too far away it may be out of range, so move the baby unit

closer to the parent unit.

• Make sure the baby and parent units are not near other electrical equipment,

such as a television, computer or cordless/mobile telephone.

• Use of other 2.4 GHz products, such as wireless networks (Wi-Fi

Bluetooth

• If the signal is weak, try moving the Parent and/or Baby Unit to different positions in the rooms.

routers),

20 Help

8. General Information

lf your product is not working properly....

1. Read this User's Guide or the Quick Start Guide.

2. Contact Customer Service:

US and Canada 1-888-331-3383

Email: support@motorolamonitors.com

To order a replacement battery pack, contact customer service.

Consumer Products and Accessories Limited Warranty ("Warranty")

Thank you for purchasing this Motorola branded product manufactured under license by Binatone Electronics International LTD ("BINATONE").

What Does this Warranty Cover?

Subject to the exclusions contained below, BINATONE warrants that this Motorola branded product ("Product") or certified access ory ("Accessory") sold for use with this product that it manufactured to be free fr om defects in materials and workmanship under normal consumer usage for the period outlined below. This Warranty is your exclusive warranty and is not transferable.

Who is covered?

This Warranty extends only to the first consumer purchaser, and is not transferable.

What will BINATONE do?

BINATONE or its authorized distributor at its option and within a commercially reasonable time, will at no charge repair or replace any Products or Accessories that does not conform to this Warranty. We may use functionally equivalent reconditioned/ refurbished/ pre-owned or new Products, Accessories or parts.

What Other Limitations Are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

ENGLISH

General Information 21

PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE THE REPAIR OR REPLACEMENT PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL MOTOROLA OR BINATONE BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT OR ACCESSORY, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS OR ACCESSORIES TO THE FULL EXTENT. THESE DAMAGES MAY BE DISCLAIMED BY

LAW.

Some jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or limitation on the length of an implied warranty, so the above limitations or exclusions may not apply to you. This Warranty gives you specific legal rights, and you may also have other rights that vary from one jurisdiction to another.

22 General Information

Products Covered Length of Coverage

Consumer Products One (1) year from the date of the

products original purchase by the first consumer purchaser of the product.

Consumer Accessories Ninety (90) days from the date of the

accessories original purchase by the first

consumer purchaser of the product. Consumer Products and Accessories that are Repaired or Replaced

The balance of the original warranty or

for Ninety (90) days from the date

returned to the consumer, whichever is

longer.

Exclusions

Normal Wear and Tear. Periodic maintenance, repair and replacement of parts

due to normal wear and tear are excluded from coverage.

Batteries. Only batteries whose fully charged capacity falls below 80% of their rated capacity and batteries that leak are covered by this Warranty.

Abuse & Misuse. Defects or damage that result from: (a) improper operation, storage, misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the Products or Accessories for commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of MOTOROLA or BINATONE, are excluded from coverage.

Use of Non-Motorola branded Products and Accessories. Defects or damage that result from the use of Non-Motorola branded or certified Products or Accessories or other peripheral equipment are excluded from coverage.

ENGLISH

General Information 23

Unauthorized Service or Modification. Defects or damages resulting from service, testing, adjustment, installation, maintenance, alteration, or modification in any way by someone other than MOTOROLA, BINATONE or its authorized service centers, are excluded from coverage.

Altered Products. Products or Accessories with (a) serial numbers or date tags that have been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola branded housings, or parts, are excl uded from coverage.

Communication Services. Defects, damages, or the failure of Products or Accessories due to any communication service or signal you may subscribe to or use with the Products or Accessories is excluded from coverage.

How to Obtain Warranty Service or Other Information?

To obtain service or information, please call:

US and Canada 1-888-331-3383

Email: support@motorolamonitors.com

You will receive instructions on how to ship the Products or Accessories at your expense and risk, to a BINATONE Authorized Repair Center.

To obtain service, you must include: (a) the Product or Accessory; (b) the original proof of purchase (receipt) which includes the date, place and seller of the Product; (c) if a warranty card was included in your box, a completed warranty card showing the serial number of the Product; (d) a written description of the problem; and, most importantly; (e) your address and telephone number.

These terms and conditions constitute the complete warranty agreement between you and BINATONE regarding the Products or Accessories purchased by you, and supersede any prior agreement or representations, including representations made in any literature publications or promotional materials issued by BINATONE or representations made by any agent, employee or staff of BINATONE, that may have been made in connection with the said purchase.

24 General Information

FCC and IC regulations

FCC Part l5

NOTE: This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this device.

To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The Baby Unit shall be installed and used such that parts of the user’s body other than the hands are maintained at a distance of approximately 8 inches (20 cm) or more.

This Class B digital apparatus complies with Canadian ICES-003.

ENGLISH

General Information 25

WARNING

Changes or modifications, to this equipment not expressively approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Industry Canada

This device complies with Industry Canada licence-exempt RSS standard(s): Operation is subject to the following Two conditions:(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

The term "IC: " before the certification/registration number only signifies that the Industry Canada technical specifications were met. This product meets the applicable Industry Canada technical specifications.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

26 General Information

Technical Specifications

Baby unit (Model: MBP43BU)

Frequency 2.4 GHz to 2.48 GHz

Image sensor color CMOS 0.3M Pixels

Lens f 2.5mm, F 2.8

IR LED 8 pcs

Power Adapter: 5E-AD059100-U; Input: 100-240V,

50/60Hz 150mA; Output: 5.9V, 1000mA

Adapter: BLJ5W059100P; Input: 100-240V, 50/60Hz 150mA; Output: 5.9V, 1000mA

WARNING

Use only with provided power supply.

ENGLISH

General Information 27

Parent unit (Model: MBP43PU)

Frequency 2.4 GHz to 2.48 GHz

Display 3.5" diagonal TFT LCD

Display colors 16.7M color LCD

Brightness control 8 steps

Volume control 8 steps

Power Adapter: 5E-AD060050-U; Input: 100-240V,

50/60Hz 150mA; Output: 6.0V, 500mA

Adapter: BLJ5W060050P; Input: 100-240V, 50/60Hz 150mA; Output: 6.0V, 500mA

WARNING

Use only with provided power supply.

Battery: Model - DESAY, Ni-MH AAA 3.6V 900mAh rechargeable battery pack

WARNING

Do not use non-rechargeable batteries for the Parent Unit. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.

28 General Information

Manufactured, distributed or sold by Binatone Electronics International LTD., official licensee for this product. MOTOROLA and the Stylized M Logo, are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. and are used under license. All other trademarks are the property of their respective owners.

EN_US Version 2.0

Printed in China

Motorola MBP43PU, MBP43BU, MBP43-B, MBP43 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1. Safety Instructions

2. Getting Started

2.1 Baby Unit Power Supply

2.2 Parent Unit Battery Installation

2.3 Parent Unit Power Supply

2.4 Registration (Pairing)

3. Using the Baby Monitor

3.1 Setting up

3.2 Pan and Tilt

3.3 Night Vision Mode

3.4 Talk Mode

3.5 Video ON/OFF

3.6 Temperature Display

4. Parent Unit Menu Options

4.1 Volume

4.2 Brightness

4.3 Lullaby

4.4 Zoom

4.5 Alarm

4.6 Camera Control

4.6.1 Add (pair) a camera

4.6.2 View a camera

4.6.3 Delete a camera

4.6.4 Scan the cameras

4.7 Temperature

5. Disposal of The Device (environment)

6. Cleaning

7. Help

8. General Information
