Motorola C381P J2ME Technical Manual

Technical Manual

Motorola C381p Handset J2ME™ Developer Guide

Version 01.00

Table of Contents

TABLE OF CONTENTS ............................................................................................................................... 2

TABLE OF FIGURES.................................................................................................................................. 6

INDEX OF TABLES....................................................................................................................................7

TABLE OF CODE SAMPLES...................................................................................................................... 9

1 INTRODUCTION .................................................................................................................................... 10

PURPOSE.................................................................................................................................................... 10

AUDIENCE .................................................................................................................................................. 10

DISCLAIMER .............................................................................................................................................. 10

REFERENCES .............................................................................................................................................. 11

REVISION HISTORY .................................................................................................................................. 12

DEFINITIONS, ABBREVIATIONS, ACRONYMS........................................................................................... 12

DOCUMENT OVERVIEW ................................................................................................................................13

2 J2ME INTRODUCTION......................................................................................................................... 15

THE JAVA 2 PLATFORM, MICRO EDITION (J2ME).............................................................................. 15

THE MOTOROLA J2ME PLATFORM............................................................................................................. 16

MIDP 1.0 ............................................................................................................................................... 16

RESOURCES AND API’S AVAILABLE........................................................................................................ 17

3 DEVELOPING AND PACKAGING J2ME APPLICATIONS............................................................. 18

GUIDE TO DEVELOPMENT IN J2ME.......................................................................................................... 18

4 DOWNLOADING APPLICATIONS........................................................................................................ 20

METHOD OF DOWNLOADING......................................................................................................................... 20

ERROR LOGS.............................................................................................................................................. 21

OTA AND DOWNLOAD ................................................................................................................................. 22

5 APPLICATION MANAGEMENT............................................................................................................. 24

DOWNLOADING A JAR FILE WITHOUT A JAD.......................................................................................... 24

MIDLET UPGRADE ..................................................................................................................................... 24

INSTALLATION AND DELETION STATUS REPORTS.................................................................................... 25

SYSTEM MENU............................................................................................................................................ 25

6 JAD ATTRIBUTES................................................................................................................................27

JAD / MANIFEST ATTRIBUTE IMPLEMENTATIONS .................................................................................. 27

7 JAVA.LANG IMPLEMENTATION........................................................................................................ 29

Table of Contents

JAVA.LANG SUPPORT................................................................................................................................. 29

8 NETWORK APIS .................................................................................................................................... 30

NETWORK CONNECTIONS............................................................................................................................. 30

USER PERMISSION .................................................................................................................................... 32

HTTPS CONNECTION ................................................................................................................................32

9 JSR 135 MOBILE MEDIA API........................................................................................................ 35

JSR 135 MOBILE MEDIA API............................................................................................................... 35

TONECONTROL............................................................................................................................................ 36

GUICONTROL............................................................................................................................................. 37

VOLUMECONTROL ........................................................................................................................................37

STOPTIMECONTROL.................................................................................................................................... 38

MANAGER CLASS ........................................................................................................................................38

AUDIO MEDIA............................................................................................................................................ 38

10 JSR 120 – WIRELESS MESSAGING API .................................................................................. 41

WIRELESS MESSAGING API (WMA)........................................................................................................ 41

SMS CLIENT MODE AND SERVER MODE CONNECTION.............................................................................. 41

SMS PORT NUMBERS................................................................................................................................. 42

SMS MESSAGE TYPES............................................................................................................................... 43

SMS MESSAGE STRUCTURE ....................................................................................................................... 43

SMS NOTIFICATION ................................................................................................................................. 43

11 PHONEBOOK ACCESS API............................................................................................................... 49

PHONEBOOK ACCESS API ......................................................................................................................... 49

PHONEBOOK ACCESS API PERMISSIONS.................................................................................................. 49

12 TELEPHONY API................................................................................................................................54

DIALER CLASS.......................................................................................................................................... 54

CLASS DIALEREVENT................................................................................................................................54

CLASS DIALER.......................................................................................................................................... 56

getDefaultDialer........................................................................................................................ 57

setDialerListener ..................................................................................................................... 57

startCall ........................................................................................................................................ 58

sendExtNo ........................................................................................................................................ 58

endCall............................................................................................................................................. 59

INTERFACE DIALERLISTENER................................................................................................................... 59

SAMPLE DIALERLISTENER IMPLEMENTATION ........................................................................................... 59

notifyDialerEvent ..................................................................................................................... 61

CLASS HIERARCHY .................................................................................................................................... 61

INTERFACE HIERARCHY............................................................................................................................. 61

13 SERIAL PORT ACCESS.................................................................................................................... 62

14 SMS MESSAGING AS GSM EXTENSION ....................................................................................... 63

CREATING A MESSAGE............................................................................................................................... 63

SENDING A MESSAGE ................................................................................................................................63

VIEWING A MESSAGE ................................................................................................................................64

DELETING A MESSAGE............................................................................................................................... 64

15 USER DISPLAY INTERFACE .......................................................................................................... 65

Table of Contents

ANVAS FUNCTIONALITY........................................................................................................................... 65

HARDWARE MAPPING .................................................................................................................................. 67

16 ONE-CLICK APPLICATION ACCESS............................................................................................ 71

APPLICATION RESOURCES......................................................................................................................... 71

APPLICATION KEYS .................................................................................................................................. 71

APPLICATION ICONS ................................................................................................................................71

SOFTKEY LABELS ...................................................................................................................................... 72

EFFECT OF MASTER CLEAR OR MASTER RESET....................................................................................... 72

DELETING THE MIDLET/APPLICATION.................................................................................................... 72

17 DOWNLOAD MIDLET THROUGH BROWSER..................................................................................... 73

STAR ACTIVE BROWSER SESSION FROM MAIN MENU............................................................................... 74

FIND A LOCATION WITH J2ME APPLICATION ........................................................................................ 74

DOWNLOADING MIDLETS............................................................................................................................ 75

DIFFERENT ERROR CHECKS ...................................................................................................................... 77

Memory Full.................................................................................................................................... 77

Memory Full during installation process................................................................ 80

Application version already exists:........................................................................... 81

Newer Application Version Exists: ............................................................................... 82

18 LIGHTWEIGHT WINDOWING TOOLKIT.......................................................................................... 84

19 UDP SUPPORT .................................................................................................................................... 85

20 SHARED JAD URLS........................................................................................................................... 86

OVERVIEW .................................................................................................................................................. 86

TELL-A-FRIEND OPTION......................................................................................................................... 86

Accessing Tell-A-Friend from SMM.................................................................................. 87

Downloading through Browser.............................................................................................. 88

Downloading from PC (Via serial/USB)........................................................................ 88

Downloading through MMS....................................................................................................... 89

21 GET URL FROM FLEX API............................................................................................................. 90

OVERVIEW .................................................................................................................................................. 90

FLEXIBLE URL FOR DOWNLOADING FUNCTIONALITY................................................................................ 90

SECURITY POLICY .................................................................................................................................... 91

22 MULTIPLE KEY PRESS.................................................................................................................... 92

23 ITAP.....................................................................................................................................................94

INTELLIGENT KEYPAD TEXT ENTRY API................................................................................................ 94

24 LCDUI................................................................................................................................................... 95

LCDUI API............................................................................................................................................. 95

25 AUTO LAUNCH OF MIDLETS ........................................................................................................ 100

SCENARIOS INVOLVED IN LAUNCHING MIDLET....................................................................................... 100

26 BACKGROUND APPLICATIONS...................................................................................................... 101

BACKGROUND ATTRIBUTE......................................................................................................................... 101

BACKGROUND JAVA APPLICATION LIFECYCLE ....................................................................................... 101

BACKGROUND MIDLET.............................................................................................................................. 101

FLIP BEHAVIORS .................................................................................................................................... 102

Table of Contents

27 JAVA SYSTEM MENU....................................................................................................................... 103

MIDLET MANAGER MENU ......................................................................................................................... 103

View MIDlet Suite Information....................................................................................... 104

DELETING MIDLET SUITES.................................................................................................................... 104

28 INVISIBLE NET FOR J2ME ........................................................................................................ 107

INTRODUCTION ........................................................................................................................................ 107

J2ME INVISIBLE NET OPTIONS.......................................................................................................... 107

J2ME Component Options ....................................................................................................... 107

J2ME Context-Sensitive Menu Options......................................................................... 109

29 DOWNLOAD MIDLET THROUGH PC............................................................................................... 111

ESTABLISHING CONNECTION................................................................................................................... 111

30 OPERATOR APPS PROVISIONING............................................................................................... 112

31 MIDP 2.0 SECURITY MODEL...................................................................................................... 113

UNTRUSTED MIDLET SUITES.................................................................................................................. 114

UNTRUSTED DOMAIN ................................................................................................................................114

TRUSTED MIDLET SUITES ..................................................................................................................... 115

PERMISSION TYPES CONCERNING THE HANDSET .................................................................................... 115

USER PERMISSION INTERACTION MODE................................................................................................. 115

IMPLEMENTATION BASED ON RECOMMENDED SECURITY POLICY............................................................. 116

TRUSTED 3

PARTY DOMAIN.................................................................................................................. 116

TRUSTED MIDLET SUITES USING X.509 PKI................................................................................... 117

SIGNING A MIDLET SUITE.................................................................................................................... 117

SIGNER OF MIDLET SUITES.................................................................................................................. 118

MIDLET ATTRIBUTES USED IN SIGNING MIDLET SUITES.................................................................. 118

CREATING THE SIGNING CERTIFICATE ................................................................................................. 118

INSERTING CERTIFICATES INTO JAD .................................................................................................. 119

CREATING THE RSA SHA-1 SIGNATURE OF THE JAR ........................................................................ 119

AUTHENTICATING A MIDLET SUITE ...................................................................................................... 119

VERIFYING THE SIGNER CERTIFICATE ................................................................................................. 119

VERIFYING THE MIDLET SUITE JAR................................................................................................... 120

APPENDIX A: AUDIO MIX TABLE.................................................................................................... 122

APPENDIX B: KEY MAPPING............................................................................................................. 123

KEY MAPPING FOR THE C381P ............................................................................................................. 123

APPENDIX C: MEMORY MANAGEMENT CALCULATION.................................................................. 125

AVAILABLE MEMORY ................................................................................................................................125

APPENDIX D: FAQ................................................................................................................................126

ONLINE FAQ........................................................................................................................................... 126

APPENDIX E: HTTP RANGE ............................................................................................................... 127

GRAPHIC DESCRIPTION........................................................................................................................... 127

APPENDIX F: SPEC SHEET ............................................................................................................... 128

C381P SPEC SHEET .............................................................................................................................. 128

Table of Figures

Figure 1 Java Platform.........................................................................................15

Figure 2 Active Global Commands - Back, Cancel, OK, Help & Stop

........................................................................................................................................69

Figure 3 Active Global Commands - Cancel, Screen, OK, Help & Stop

........................................................................................................................................69

Figure 4 Starting Active Browser Session from Main Menu .................74

Figure 5 Downloading and Installing J2ME Application (MIDlets) ..75 Figure 6 Application does not have Mandatory Attributes in ADF ..77

Figure 7 Memory full error................................................................................79

Figure 8 Mot-Data-Space & Mot-Program-Space attributes are not

present or are incorretct ..................................................................................80

Figure 9 Memory Full help message during installation process.....81

Figure 10 Same Version of Application already exists on the

handset.........................................................................................................................82

Figure 11 Latest (Newer) Version of Application exists....................83

Figure 12 the MIDlet Manager and the context-sensitive menus.......88

Figure 13 Java service menu for a MIDlet with background

attributes.................................................................................................................102

Figure 14 Viewing MIDlet Suite Information............................................104

Figure 15 Deleting MIDlet Suites.................................................................105

Figure 16 Description of HTTP Range...........................................................127

Index of Tables

Table 1 Error Logs .................................................................................................22

Table 2 JAD file information............................................................................23

Table 3 Application management feature/class support for MIDP 2.0

........................................................................................................................................25

Table 4 Java System menu ....................................................................................26

Table 5 MIDlet Attributes, descriptions, and JAD and/or JAR

location.......................................................................................................................28

Table 6 Network API feature/class support for MIDP 2.0....................31

Table 7 Multimedia File formats .....................................................................38

Table 8 List of audio MIME types...................................................................39

Table 9 Multimedia feature/class support for JSR 135........................39

Table 10 Messaging features/classes supported.......................................44

Table 11 Interface Summary................................................................................54

Table 12 Class Summary.........................................................................................54

Table 13 Field Summary.........................................................................................55

Table 14 Constructor Summary............................................................................55

Table 15 Field Details.........................................................................................56

Table 16 Method Summary ......................................................................................57

Table 17 Key Ranking Priority..........................................................................68

Table 18 Performed on a suite..........................................................................87

Table 19 Gaming and keypad feature/class..................................................93

Table 20 ITAP feature/class..............................................................................94

Table 21 Interfaces supported by Motorola implementation ...............95

Table 22 Specific classes supported by Motorola implementation ..96

Table 23 LCDUI feature/class............................................................................99

Table 24 Function Describes..........................................................................103

Table 25 Midlet Manager Menu Description..............................................103

Index of Tables

Table 26 Security feature/class support for MIDP 2.0...................... 114

Table 27 Protected Functionality fot top line of prompt ...............117

Table 28 Dialog Prompts for MIDP 2.0 Permission Types....................117

Table 29 Actions performed upon completion of signer certificate

verification ............................................................................................................120

Table 30 MIDlet suite verification.............................................................121

Table 31 Audio Mix ...............................................................................................122

Table of Code Samples

Code Sample 1 Java.lang support .....................................................................29

Code Sample 2 Socket Connection .....................................................................32

Code Sample 3 HTTPS Connection .......................................................................34

Code Sample 4 JSR 135 Mobile Media API ......................................................36

Code Sample 5 JSR 120 Wireless Messaging API .........................................48

Code Sample 6 Phonebook API..............................................................................53

Code Sample 7 DialerListener Implementation ...........................................60

1 Introduction

Purpose

Introduction

This document describes the applicat ion program interfaces used to develop Motorola compliant Java™ 2 Platform, Micro Edition (J2ME™) applications for the C381p handset.

Audience

This document is intended for premium J2ME developers and specific carriers involved with the development of J2ME applications for the C381p handset.

Disclaimer

Motorola reserves the right to make changes without notice to any products or services described herein. “Typical” parameters, which may be provided in Motorola Data sheets and/or specifications can and do vary in different a pplications and actual performance may vary. Customer’s technical experts will validate all “Typicals” for each customer application.

Motorola makes no warranty with regard to the products or services contained herein. Implied warranties, including without limitation, the implied warranties of merchantability and fitness for a particular purpose, are given only if specifically required by applicable law. Otherwise, they are specifically excluded.

No warranty is made as to coverage, availability, or grade of service provided by the products or services, whether through a service provider or otherwise.

No warranty is made that the software will meet your requir ements or will work in combination with any hardware or applications software products provided by third parties, that the operation of the software products will be uninterrupted or error free, or that all defects in the software products will be corrected.

In no event shall Motorola be liable, whether in contract or tort (including negligence), for any damages resulting form use of a product or service described herein, or for any indirect, incidental, special or consequential damages of any kind, or loss of revenue or profits, loss of business, loss of information or data, or othe r financial loss arising out of or

1 Introduction

in connection with the ability or inability to use the Products, to the full extent these damages may be disclaimed by law.

Some states and other jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, or limitation on t he length of an implied warranty, so the above limitations or exclusions may not apply to you.

This warranty gives you specific legal rights, and you ma y also have other rights, which vary from jurisdiction to jurisdiction.

Motorola products or services are not designed, i ntended, or authorized for use as components in systems intended for surgical implant into the body, or other applications intended to support or sustain life, or for any other application in which the failure of the Motorola product or service could create a situation where personal injury or death may occur.

Should the buyer purchase or use Motorola products or services for any such unintended or unauthorized application, buyer shall release, indemnify and hold Motorola and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that Motorola was negligent regarding the designing or manufacture of the product or service.

Motorola recommends that if you are not the sole author or creator of the graphics, video, or sound, you obtain sufficient license rights, including the rights under all patents, trademarks, trade names, copyrights, and other third party proprietary rights.

References

Reference Link

RFC 2068 http://ietf.org/rfc/rfc2068.txt SAR http://www.wapforum.org MIDP 2.0 http://java.sun.com/products/midp/ JSR 118 http://www.jcp.org JSR 120 http://www.jcp.org JSR 135 http://www.jcp.org Sun MIDP 2.0 SDK http://java.sun.com/products/midp/ TLS protocol version 1.0 http://www.ietf.org/rfc/rfc2246.txt SSL protocol version 3.0 http://home.netscape.com/eng/ssl3/draft302.txt GSM 03.38 standard http://www.etsi.org GSM 03.40 standard http://www.etsi.org RFC 2437 http://ietf.org/rfc/rfc2437.txt Sun J2ME http://java.sun.com/j2me/).

1 Introduction

Revision History

Version Date Name Reason

00.01 November 09, 2004 C.E.S.A.R. Initial Draft

Definitions, Abbreviations, Acronyms

Acronym

AMS Application Management Software API Application Program Interface. CLDC Connected Limited Device Configuration GPS Global Positioning System IDE Integrated Development Environment ITU International Telecommunication Union JAD Java Application Descriptor JAL Java Application Loader JAR Java Archive. Used by J2ME applications for compression and packaging. J2ME Java 2 Micro Edition JSR 120 Java Specification Request 120 defines a set of optional APIs that provides

JVM Java Virtual Machine KVM Kilo Virtual Machine LWT Lightweig ht Windowing Toolkit

Description

standard access to wireless communicatio n resources.

MIDP Mobile Information Device Profile MMA Multimedia API MT Mobile Terminated OEM Original Equip m ent Manufacturer OTA Over The Air RMS Record Management System

1 Introduction

RTOS Real Time Operating System SDK Software Development Kit SMS Short Message Service SMSC Short Messaging Service Center SU Subscribe Unit UI User Interface URI Unified Resource Identifier VM Virtual Machine WMA Wireless Messaging API

Document Overview

This developer’s guide is organized int o the following chapters and appendixes: Chapter 1 – Introduction: this chapter has general information about th is document,

including purpose, scope, references, and def initions. Chapter 2 – J2ME Introduction: this chapter describes the J2ME platform and the

available resources on the Motorola C381p handset. Chapter 3 – Developing and Packaging J2ME Applications: this chapter describes

important features to look for when selecting tools and emu lation environments. It also describes how to package a J2ME application, how to package a MIDlet, and generate JAR and JAD files properly.

Chapter 4 – Downloading Applications: this chapter describes the process for downloading applications.

Chapter 5 – Application Management: this chapter describes the lifecycle, installation/de-installation, and updatin g process for a MIDlet suite.

Chapter 6 – JAD Attributes: this chapter describes what attributes are supported. Chapter 7 – Java.lang Implementation: this chapter describes the java.lang

implementation.

Chapter 8 – Networking APIs: this chapter describes the Java Networking API. Chapter 9 – JSR 135 Mobile Media: this chapter describes image types and supported

formats. Chapter 10 – JSR 120 Wireless Messaging API: this chapter describes JSR 120

implementation. Chapter 11 -- Phonebook Access API: this chapter describes the Phonebook Access

API.

Chapter 12 – Telephony API: this chapter describes the Telephony API. Chapter 13 – Serial Port Access: this chapter describes the Serial Port Access.

1 Introduction

Chapter 14 – SMS Messaging as GSM Extension: this chapter describes the SMS Access API.

Chapter 15 – User Display Interface: this chapter describes the J2ME specific Canvas, Hardware Mapping and External Event Interaction functionality.

Chapter 16 – One-Click Application Access: this chapter describes the used Java applications via the soft keys, navigation keys or smart keys

Chapter 17 – Download MIDlet Through Browser: this chapter describes the performing any downloads on the hands et.

Chapter 18 – Lightweight Windowing Toolkit: this chapter describes the capabilities to include a component-level API through which developers can control the co i ntents and layout of their screens.

Chapter 19 – UDP Support: this chapter describes how to enable J2ME applications access to Generic UDP Transport Service.

Chapter 20 – Shared JAD URLS: this chapter describes briefly a new fea ture that allows users to share their downloaded J2ME ap plication URLs with others.

Chapter 21 – Get URL from Flex API: this chapter describes the way to access URL stored in FLEX by a java application.

Chapter 22 – File System Access API: this chapter describes the File System API. Chapter 23 – Multiple Key Press: this chapter describes the Multiple Key Press. Chapter 24 – ITAP: this chapter describes iTAP support. Chapter 25 – LCDUI: this chapter describes the LCDUI. Chapter 26 – Auto Launch of Midlet: this chapter describes the Auto Lanch of Mid let. Chapter 27 – Background Applications: this chapter describes the. Chapter 28 – Java System Menu: this chapter describes the Java System Menu. Chapter 29 – Invisible net for J2ME: this chapter describes the Invisible net for J2ME. Chapter 30 – Download MIDlet Through PC: this chapter describes the any downloads

on the handset. Chapter 31 – MIDP 2.0 Security Model: this chapter describes the MIDP 2.0 default

security model. Appendix A – Key Mapping: this appendix describes the key map ping of the Motorola

C381p handset, including the key name, key code, and game action of all Motorola keys.

Appendix B –

Memory Management Calculation: this appendix describes the memory

management calculations.

Appendix C – FAQ: this appendix provides a link to the dynamic online FAQ. Appendix D – HTTP Range: this appendix provides a graphic description of HTTP

Range. Appendix E – Spec Sheet: this appendix provide s the spec sheet for the Motorola C381p

handset.

2 J2ME Introduction

J2ME Introduction

The Motorola C381p handset includes the Java™ 2 Platform, Micro Edition, also known as the J2ME platform. The J2ME platform enables developers to easily create a variety of Java applications ranging from business ap plications to games. Prior to its inclusion, services or applications residing on small consumer devices like cell phones could not be upgraded or added to without significant effort. By implementing the J2ME platform on devices like the Motorola C381p handset, servic e providers, as well as customers, can easily add and remove applications allowing for quick and easy personalization of each device. This chapter of the guide presents a quick overview of the J2ME environment and the tools that can be used to develop applic ations for the Motorola C381p handset.

The Java 2 Platform, Micro Edition (J2ME)

The J2ME platform is a new, very small application environment. It is a framework for the deployment and use of Java technology in small devices such as cell phones and pagers. It includes a set of APIs and a virtual machine that is designed in a modular fashion allowing for scalability among a wide range of devices.

The J2ME architecture contains three layers cons isting of the Java Virtual Machine, a Configuration Layer, and a Profile Layer. Th e Virtual Machine (VM) supports the Configuration Layer by providing an interface to the host operating system. Above the VM is the Configuration Layer, which can be thought of as the lowest common denominator of the Java Platform available across devices of the same “horizontal market.” Built upon this Configuration Layer is the Profile Layer, typically encompassing the presentation layer of the Java Platform.

Native

MIDP-Compliant

Apps

MIDP

CLDC

CLDC Native System Software

Native System Software

OEM

OEM Apps

Apps

OEM

OEM Classes

Classes

Native Apps

Apps

Mobile Information Device

Figure 1 Java Platform

2 J2ME Introduction

The Configuration Layer used in the Motorola C381p handset is the Connected Limited Device Configuration 1.1 (CLDC 1.1) and th e Profile Layer used is the Mobile Information Device Profile 2.0 (MIDP 2.0). Together, the CLDC and MIDP provide common APIs for I/O, simple math functionality, UI, and more.

For more information on J2ME, see the Sun™ J2ME documentation (http://java.sun.com/j2me/).

The Motorola J2ME Platform

Functionality not covered by the CLDC and MIDP APIs is left for individual OEMs to implement and support. By adding to the standard APIs, manufacturers can allow developers to access and take advantage of the unique functionality of their handsets. The Motorola C381p handset contains OEM APIs for extended functionality ranging from enhanced UI to advanced data security. While the Motorola C381p handset can run any application written in standard MIDP, it can also run applications that take advantage of the unique functionality provided by these APIs. These OEM APIs are described in this guide.

MIDP 1.0

J2ME is the version of Java that the mobile device will support. It was developed to support devices with limited memory, i.e mobile devices, pagers, SIM cards. J2ME maintains the qualities that Java technology has become famous for:

• built-in consistency across products in terms of running anywhere, any time, over any device

• portability of the code

• leveraging of the same Java programming langua ge

• safe network delivery

• applications written with J2ME are upwardly scalable to work with J2SE and

J2EE.

J2ME enables device manufacturers, service providers, and content creators to deploy compelling new applications and servic es to their customers rapidly and cost-effectively while capitalizing on new revenue streams. In using J2ME, the handset must be MIDP 1.0 and CLDC 1.0 compliant. To assure this compliance, the handset must pass the Technology Certification K it, TCK, provided by Sun.

2 J2ME Introduction

Resources and API’s Available

MIDP 2.0 will provide support to the following functional areas on the Motorola C381p handset:

MIDP 2.0

• Application delivery and billing

• Application lifecycle

• Application signing model and privileged security model

• End-to-end transactional security (HTTPS)

• Networking

• Persistent storage

• Sounds

• Timers

• User Interface

• File Image Support (.PNG, .JPEG, .GIF)

Additional Functionality

• WMA (JSR 120)

• MMA (JSR 135)

• Phonebook API

• Telephony API

3 Developing and Packaging J2ME Applications

Developing and Packaging

J2ME Applications

Guide to Development in J2ME

Introduction to Development

This appendix assumes the reader has previous experience in J2ME development and can appreciate the development process for Java MIDlets. This appendix will provide some information that a beginner in devel op m ent can use to gain an understanding of MIDlets for J2ME handsets.

There is a wealth of material on this subject on websites maintained by Motorola, Sun Microsystems and others. Please refer to the following URLs for more information:

 http://www.motocoder.com

http://www.java.sun.com/j2me



http://www.corej2me.com/



http://www.javaworld.com/



As an introduction, brief details of J2ME are explaine d below.

The MIDlet will consist of two core specifications, namely Connected, Limited Device Configuration (CLDC) and Mobile Informat ion Device Profile (MIDP). Both of these specifications (Java Specification Reque s ts) can be located at the reading.

 For MIDP 1.0; JSR 37 should be reviewed.  For MIDP 2.0; JSR 118 should be reviewed.  For CLDC 1.0.4; JSR 30 should be reviewed.

http://www.jcp.org/ site for

 For CLDC 1.1; JSR 139 should be reviewed.

To determine what implementation is on Motorola handset, review the “Jav a System” details through the menu on the Motorola handset (located under Java Settings).

For beginning development, key points to remember are memory size, processing power, screen capabilities and wireless networ k characteristics. These all play an important part

3 Developing and Packaging J2ME Applications

in development of a MIDlet. The specifications listed above are designed to work upon devices that have these characteristics.

Network conditions would only apply for n etworked applications such as streaming tick ers, email clients, etc.

In addition to the specifications, an array of tools is available to assist the development cycle. These range from the command line tools provided with Software Development Kits (SDK) from Sun (as of writing 1.4.1_04) to Integrated Develo pment Environments (IDEs) which can be free or purchased. These IDEs come from a range of sources such as Sun, IBM, Metrowerks and Borland to name a few.

For a look at such environments, review the “M otorola T720 Handset Developer Guide” which is available from the MOTOCODER website.

In addition to the IDEs and Sun SDK for development, Motorola offers access to our own SDK which contains Motorola device emulators. From here, a MIDlet can be built and then deployed onto an emulated target handset. This will enable debugging and validation of the MIDlet before deployment to a real, physical hands et. The latest Motorola SDK can be downloaded from the MOTOCODER website.

Please refer to the product specifications at the back of this guide for detailed information on each handset.

4 Downloading Applications

Downloading Applications

Method of Downloading

The option open to the developer for deploying the MIDlet to a physical Motorola device is OTA (over -the-air) downloading.

OTA

To use the OTA method, the developer will have a connection through a wireless network to a content server. This content server could be, for example, Apache

(http://httpd.apache.org) which is free to use, deployable on multiple operating systems,

and has extensive documentatio n on how to configure the platform.

The required file will be downloaded (eith er .jad and/or .jar) by issuing a direct URL request to the file in question or it could be a URL r equest to a WAP page and a hyperlink on that page to the target file. This request will be made through the OPERA Browser. In MIDP 2.0, the need for a JAD file before download is not required, so the JAR file can be downloaded directly. The information about the MI Dlet will be pulled from the manifest file.

The transport mechanism used to download the file will be one of two depending on the support from the network operators WAP Gateway and the size of file requested.

 HTTP Range – see specification RFC 2068 at http://www.rfc-editor.org/rfc.html

content greater than 30k in size. Below is a ladder diagram showing the flow through HTTP range transfer, although recall use of the .JA D is optional.

 SAR (Segmentation & Reassembly) – see specification of wireless transaction

protocol at the http://www.wapforum.org

During a download of the application, the use r will see the OPERA browser displaying a progress dialog.

A complete guide for setting up an OTA server can be obtained through the MOTOCODER website (http://www.motocoder.com the server and also example WAP pages.

The following error codes are supported:

 900 Success  901 Insufficient Memory  902 User Cancelled  903 Loss Of Service

if less than 100k in size.

). This includes details of configuring

4 Downloading Applications

 904 JAR Size Mismatch  905 Attribute Mismatch  906 Invalid Descriptor  907 Invalid JAR  908 Incompatible Configuration or Profile  909 Application Authentication Failur e  910 Application Authorization Failure  911 Push Registration Failure  912 Deletion Notification  913 Required package not supporte d by device  999 Other errors

Please be aware that the method used by the handset, as per the specifications, is POST. Using a GET (URL encoding) style for the URL will fail. This is not the correct use of the MIDlets JAD parameters.

Possible Screen Messages Seen With Downloading:

 If JAR -file size does not match with specified size, it will display a dialog stating

 When downloading is done, the handset displays a transient notice “Download

 Upon completing installation, the handset displays a dialog “Install complete”. To

 If the MANIFEST file is wrong, the handset displays a dialog stating “Installation

 If JAD does not contain mandatory attributes, “Installation failed. Package

“Installation failed. Package in valid.” To dismiss this dialog, press “O K”.

Completed” and starts to install the application.

dismiss this dialog, press “OK”.

failed. Package invalid.” To dismiss this dialog, press “OK”.

invalid.” notice appears.

Error Logs

The Table 1 represents the error logs associ ated with downloading applications.

Error Logs Scenario Possible Cause Error Dialog

906 Invalid Descriptor.

904 JAR Size OTA JAR The received JAR size does not Download Failed

JAD Download Missing or incorrectly formatted

Failed: Invalid File mandatory JAD attributes Mandatory: MIDlet-Name (up to 32 symbols) MIDlet-Version MIDlet-Vendor (up to 32 symbols) MIDlet-JAR-URL (up to 256 symbols) MIDlet-JAR_Size JAD signature verification failed Unknown error during JAD validation

4 Downloading Applications

Mismatch . Download match the size indicated in JAD 902 User Cancelled. 903 Loss of Service. 901 Insufficient Memory. 905 Attribute Mismatch 901 Insufficient Memory.

OTA JAR

User cancelled download Cancelled:

Download OTA JAR

Browser lost connection with server Installation Failed

Download OTA JAR Download

Insufficient space to install the MIDlet suite

Installation Mandatory attributes are not identical

in JAD & Manifest

Installation Insufficient Space to install MIDlet

suite

907 Invalid JAR. Installation Class references non-existent class

or method Security Certificate verification failure Checksum of JAR file is not equal to Checksum in MIDlet-JAR-SHA attribute Application not authorized

MIDlet

Launching

MIDlet

Execution

Security Certificates expired or removed Authorization failure during MIDlet execution Incorrect MIDlet

Table 1 Error Logs

Insufficient Storage

Installation failed.

Package invalid.

Insufficient Storage

Installation failed. Package

invalid.

Application Expired

Application Error

OTA and Download

• Comply with “OTA User Initiated Provisioning Specifications” in MIDP 2.0.

• The user MUST be prompted if the midlet is char geable.

• Terminals should compare and predict the application program that will be

downloaded is

• the latest or old versions and give indicatio n to users.

• Check the available memory before any downloads.

• Users should be able to terminate the download process any time by pressing

END key.

• Before downloading the following JAD file information must be displayed first:

Contents Maximum

Application program name (Midlet name) 32 Bytes Max Application program version number 16 Bytes Max Vendor Name 32 Bytes Max

length

4 Downloading Applications

• End user should be able to delete the appl ications downloaded.

URL of JAR file Not specified Size of JAR file 8 Bytes Max Applicable Terminal Type not specified Application program introduction (Midlet

512 Bytes Max description) Information Fee (Media price). 32 Bytes Max

Table 2 JAD file information

5 Application Management

Application Management

The following sections describe the application management scheme for the Motoro la C381p handset. This chapter will discuss the following

• Downloading a JAR without a JAD

• MIDlet upgrade

• Installation and Deletion Status Reports

• System Menu

Downloading a JAR file without a JAD

In Motorola’s MIDP 2.0 implementation, a JAR file can be downloaded without a JAD. In this case, the user clicks on a link for a JAR file, the file is downloaded, and a confirmation will be obtained before the installation begi ns. The information presented is obtained from the JAR manifest instead of the JAD.

MIDlet Upgrade

Rules from the JSR 118 will be followed to help determine if the data from an old MIDlet should be preserved during a MIDlet upgrade. When th ese rules cannot determine if the RMS should be preserved, the user will be given an option to preserve the data.

The following conditions are used to determine if data can be saved:

• If the cryptographic signer of the new MIDlet suite and the original MIDlet suite are identical, then the RMS record stores MUST be r etained and made available to the new MIDlet suite.

• If the URL of the new MIDlet suite is identical to the URL the original MIDlet suite was downloaded from, then the RMS MUST be retained and made available to the new MIDlet suite.

• If the above statements are false, then the dev ice MUST ask the user whether the data from the original MIDlet suite should be ret ained and made available to the new MIDlet suite.

5 Application Management

If the user decides to save the data from the current MIDlet, the d ata will be preserved during the upgrade and the data wil l be made available for the new application. In any case, an unsigned MIDlet will not be allowed to update a signed MIDlet.

Installation and Deletion Status Reports

The status (success or failure) of an installation, upgra de, or deletion of a MIDlet suite will be sent to the server according to the JSR 118 specification. If the status report cannot be sent, the MIDlet suite will still be enabled and the user will be allowed to use it. Upon successful deletion, the handset will send the status code 912 to the MIDlet-Delete-Notify URL. If this notification fails, the MIDlet suite will still be deleted. If this notification cannot be sent due to lack of network connectivity, the notification will be sent at the next available network connection.

Refer to the Table 3 for application management feature/class support for MIDP 2.0:

Feature/Class

Application upgrades performed directly through the AMS When removing a MIDlet suite, the user will be pr ompted to confirm the entire MIDlet suite will be removed Prompt for user approval when the user has chos en to download an application that is identical to, or an different version of an application currently in the handset Unauthorized MIDlets will not have access to any restricted function call AMS will check the JAD for security indicated every time a installation is initiated Application descriptor or MIDlet fails the security check, the AMS will prevent the installation of that application and notify the user that the MIDlet could not be installed Application descriptor and MIDlet pa ss the security check , the AMS will install the MIDlet an d grant it the permissions specified in the JAD A method for launching Java application that mainta ins the same look and feel as other features on the device will be provided User will be informed of download and installation w ith progress indicator and will be given an opportunity to cancel the process User will be prompted to launch the MIDlet after installation A no forward policy on DRM issues, included but not limited to transferring the application over-the-air, IRDA, Bluetooth, I/O Cables, External storage devices, etc until further guidance is provided

Table 3 Application management feature/class support for MIDP 2.0

System Menu

The Java System Menu can be found under the Java Settings menu under the Main Menu. The Java System menu allows the user to see what version of MIDP and CLDC is being used in the handset. It also shows the user th e free data space available, program space available, and the heap size being used. The following table describes each function in detail.

5 Application Management

Refer to the Table 4 Java System menu:

Action

Description

CLDC Version This displays the CLDC version that is being used in the handset. MIDP Version This displays the MIDP version that is being used in the handset. Data Space This displays the amount of free memory available for d ata used by the

applications, i.e. phone book entries, g ame high scores..

Program Space This displays the amount of free memory available for a pplications. Heap Size This is the amount of runtime memory availabl e in the handset for J2ME

applications.

Table 4 Java System menu

6 JAD Attributes

JAD Attributes

JAD / Manifest Attribute Implementations

The JAR manifest defines attributes to be used by the application management software (AMS) to identify and install the MIDlet suite. These attributes may or may not be found in the application descriptor.

The application descriptor is used, in conjunction with the JAR manifest, by the application management software to manage the MIDlet. The application descriptor is also used for the following:

• By the MIDlet for configuration specific attributes

• Allows the application management software on the handset to verify the MIDlet

is suited to the handset before loading the JAR file

• Allows configuration-specific attributes (parameters) to be supplied to the MIDlet(s) without modifying the JAR file.

Motorola has implemented the follo wing support for the MIDP 2.0 Java Application Descriptor attributes as outlined in the JSR-118. The Table 5 ists all MIDlet attributes, descriptions, and its location in the JAD and/or JAR manifest that are supported in the Motorola implementation.

Attribute Name Attribute Description JAR Manifest JAD

MIDlet-Name The name of the MIDlet suite that identifies

the MIDlets to the user

MIDlet-Version The version number of the MIDlet suite Yes Yes

Yes Yes

MIDlet-Vendor The organization that provides the MIDlet

suite.

MIDlet-Icon The case-sensitive absolute name of a

PNG file within the JAR used to represent the MIDlet suite.

MIDlet-Description The description of the MIDlet suite.

Yes Yes

6 JAD Attributes

MIDlet-Info-URL A URL for information further describing

the MIDlet suite.

MIDlet-<n> The name, icon, and class of the nth

MIDlet in the JAR file. Name is used to identify this MIDlet to the

Yes, or no if included in the JAD.

Yes, or no if included in the JAR Manifest.

user. Icon is as stated above. Class is the name of the class extending the javax.microedition.midlet.MIDletclass.

MIDlet-Jar-URL The URL from which the JAR file can be

Yes

loaded. MIDlet-Jar-Size The number of bytes in the JAR file. Yes MIDlet-Data-Size The minimum number of bytes of

persistent data required by the MIDlet. MicroEdition-Profile The J2ME profiles required. If any of the

profiles are not implemented the

installation will fail. MicroEdition-Configuration The J2ME Configuration required, i.e

CLDC 1.0

MIDlet-Permissions Zero or more permissions that are critical

Yes, or no if included in the JAD.

Yes, or no if included in the JAR Manifest.

to the function of the MIDlet suite. MIDlet-Permissions-Opt Zero or more permissions that are non-

critical to the function of the MIDlet suite. MIDlet-Push-<n> Register a MIDlet to handle inbound

connections MIDlet-Install-Notify The URL to which a POST request is sent

to report installation status of the MIDlet

suite. MIDlet-Delete-Notify The URL to which a POST request is sent

to report deletion of the MIDlet suite. MIDlet-Delete-Confirm A text message to be provided to the user

when prompted to confirm deletion of the

MIDlet suite. Background MIDlets with this Motorola specific attribute

will continue to run when not in focus.

Table 5 MIDlet Attributes, descriptions, and JAD and/or JAR location

7 Java.lang Implementation

Java.lang Implementation

java.lang support

Motorola implementation for the java.lang.System.g etProperty method will support additional system properties beyond what is outlined in the JSR 118 specification and is controlled by a flex bit. These additional system properties can only be access ed by trusted MIDlets.

The additional system properties are as follows:

• Cell ID: The current Cell ID of the device will be returned during implementation.

• IMEI: The IMEI number of the device will be returned during implementation.

The Code Sample 1 shows java.lang support:

System.getProperty("phone.mcc") System.getProperty("phone.mnc") System.getProperty("phone.imei") System.getProperty("phone.cid") System.getProperty(“phone.lai”) System.getProperty(“phone.ta”)

Code Sample 1 Java.lang support

8 Network APIs

Network Connections

The Motorola implementation of Networking APIs will support several network connections. The network connections necessary for Motorola implementation are the following:

• CommConnection for serial interface

Network APIs

• HTTP connection

• HTTPS connection

• Socket connection

• SSL

Refer to the Table 6 for Network API feature/class support for MIDP 2.0:

Feature/Class Implementation

All fields, methods, and inherited methods for the Connector class in the javax.microedition.io package Mode parameter for the open () method in the Connector class the javax.microedition.io package The timeouts parameter for the open () method in the Connector clas s of the javax.microedition.io package HttpConnection interface in the javax.microedition.io p ackage Supported HttpsConnection interface in the javax.microeditio n.io package Supported SecureConnection interface in the javax.microedition.io package Supported SecurityInfo interface in the javax.microedition.io package Supported ServerSocketConnection interface in the javax.microedition.io package Supported UDPDDatagramConnection interface in the javax.microedition.io package Connector class in the javax.microedition.io.package Supported Dynamic DNS allocation through DHCP Supported

HttpConnection interface in the javax.microedition.io.package. Supported

Supported READ, WRITE, READ_WRITE Supported

Supported

HttpsConnection interface in the javaxmicroedition.io.package Supported

8 Network APIs

SecureConnection interface in the javax.microedition.io.package Supported SecurityInfo Interface in the javax.microedition.io.package Supported ServerSocketConnection interface in the javax.microedition.io.package Supported UDPDatagramConnection interface in the

javax.microedition.io.package

Table 6 Network API feature/class support for MIDP 2.0

The Code Sample 2 shows the implementation of Socket Connection:

Socket Connection

import javax.microedition.io.*; import java.io.*; import javax.microedition.midlet.*;

….

try { //open the connection and io streams sc = (SocketConnection)Connector.open("socket://www.myserver.com :8080", Connector.READ_WRITE, true); is = sc[i].openInputStream(); os = sc[i].openOutputStream();

} catch (Exception ex) { closeAllStreams(); System.out.println("Open Failed: " + ex.getMessage()); } } if (os != null && is != null) { try { os.write(someString.getBytes()); //write some data to server

int bytes_read = 0; int offset = 0; int bytes_left = BUFFER_SIZE;

//read data from server until done do { bytes_read = is.read(buffer, offset, bytes_left);

if (bytes_read > 0) { offset += bytes_read; bytes_left -= bytes_read; }

Supported

8 Network APIs

} while (bytes_read > 0);

} catch (Exception ex) { System.out.println("IO failed: "+ ex.getMessage()); } finally { closeAllStreams(i); //clean up } }

User Permission

The user of the handset will explicitly grant permission to add additional network connections.

Code Sample 2 Socket Connection

HTTPS Connection

Motorola implementation supports a HTTPS con ne c tion on the Motorola C381p handset. Additional protocols that will be supported are the following:

• TLS protocol version 1.0 as defined in http://www.ietf.org/rfc/rfc2246.txt

• SSL protocol version 3.0 as defined in

http://home.netscape.com/eng/ssl3/draft302.txt

The Code Sample 3 shows the implementation of HTTPS:

HTTPS

import javax.microedition.io.*; import java.io.*; import javax.microedition.midlet.*; …

try { hc[i] =

(HttpConnection)Connector.open(“https://” + url[i] + "/");

} catch (Exception ex) { hc[i] = null; System.out.println("Open Failed: " +

ex.getMessage()); }

if (hc[i] != null) {

8 Network APIs

try { is[i] = hc[i].openInputStream();

byteCounts[i] = 0; readLengths[i] = hc[i].getLength();

System.out.println("readLengths = " + readLengths[i]);

if (readLengths[i] == -1) { readLengths[i] = BUFFER_SIZE; }

int bytes_read = 0; int offset = 0; int bytes_left = (int)readLengths[i];

do { bytes_read = is[i].read(buffer, offset,

bytes_left); offset += bytes_read; bytes_left -= bytes_read; byteCounts[i] += bytes_read; } while (bytes_read > 0);

System.out.println("byte read = " + byteCounts[i]);

} catch (Exception ex) { System.out.println("Downloading Failed: "+

ex.getMessage()); numPassed = 0; } finally { try { is[i].close(); is[i] = null; } catch (Exception ex) {} } } /** * close http connection */ if (hc[i] != null) { try { hc[i].close();

8 Network APIs

} catch (Exception ex) { } hc[i] = null; }

Code Sample 3 HTTPS Connection

9 JSR 135 Mobile Media API

JSR 135 Mobile Media API

The JSR 135 Mobile Media APIs feature sets are defined for five different types of media. The media defined is as follows:

• Tone Sequence

• Sampled Audio

• MIDI

When a player is created for a particular type, it will follow the guidelines and control types listed in the sections outlined below.

The Code Sample 4 shows the implementation of the JSR 135 Mobile Media API:

JSR 135

Player player;

// Create a media player, associate it with a stream containing media data

try { player =

Manager.createPlayer(getClass().getResourceAsStream("MP3.mp3 "), "audio/mpeg");

} catch (Exception e) { System.out.println("FAILED: exception for createPlayer:

" + e.toString()); }

// Obtain the information required to acquire the media resources

try { player.realize(); }

9 JSR 135 Mobile Media API

catch (MediaException e) { System.out.println("FAILED: exception for realize: " +

e.toString()); }

// Acquire exclusive resources, fill buffers with media data try { player.prefetch(); } catch (MediaException e) { System.out.println("FAILED: exception for prefetch: " +

e.toString()); }

// Start the media playback try { player.start(); } catch (MediaException e) { System.out.println("FAILED: exception for start: " +

e.toString()); }

// Pause the media playback try { player.stop(); } catch (MediaException e) { System.out.println("FAILED: exception for stop: " +

e.toString()); }

// Release the resources

player.close();

Code Sample 4 JSR 135 Mobile Media API

ToneControl

ToneControl is the interface to enable playback of a user-defined monotonic tone sequence. The JSR 135 Mobile Media API will implement public interface ToneControl.

9 JSR 135 Mobile Media API

A tone sequence is specified as a list of non-tone duration pairs and user-defined sequence blocks and is packaged as an array of bytes. The setSequence() method is used to input the sequence to the ToneCo ntrol.

The following is the available method for ToneControl:

-setSequence (byte[] sequence): Sets the tone sequence

GUIControl

GUIControl extends control and is defined for controls that provide GUI functionalities. USE_GUI_PRIMITIVE defines a mode on how the GUI is displayed. initializes the mode on how the GUI is displayed.

When USE_GUI_PRIMITIVE is specified for initDisplayMode, a GUI primitive will be returned. This object is where the GUI of this control will be displ ayed. It can be used in conjunction with other GUI objects and conforms to the GUI behaviors specified.

VolumeControl

VolumeControl is an interface for manipu lating the audio volume of a Player. The JSR 135 Mobile Media API will implement public int erface VolumeControl.

The following describes the different volume settings fo und within VolumeControl:

• Volume Settings - allows the output volume to be specified using an integer value that varies between 0 and 100.

• Specifying Volume in the Level Scale - specifies v olume in a linear scale. It ranges from 0 – 100 where 0 represents silence and 100 represents the highest volume available.

• Mute – setting mute on or off does not change the vol ume level returned by the getLevel. If mute is on, no audio signal is produced by the Player. If mute is off, an audio signal is produced and the volume is restored.

The following is a list of available methods with regar ds to VoumeControl:

-getLevel: Get the current volume setting.

-isMuted: Get the mute state of the signal associated with this VolumeControl.

-setLevel (int level): Set the volume using a linear point scale with values

between 0 and 100.

-setMute (Boolean mute): Mute or unmute the Player associated with this VolumeControl.

9 JSR 135 Mobile Media API

StopTimeControl

StopTimeControl allows a specific preset sleep timer for a player. The JSR 135 Mobile Media API will implement public interface StopTimeControl.

The following is a list of available methods with regards to StopTimeControl:

-getStopTime: Gets the last value successfully by setStopTime.

setStopTime (long stopTime): Sets the media time at which you want the

Player to stop.

Manager Class

Manager Class is the access point for obtaining system dependant resources such as players for multimedia processing. A Player is an object used to control and render media that is specific to the content type of the data. Manager provides access to an implementation specific mechanism for constructing P layers. For convenience, Manager also provides a simplified method to generate simple tones. Primarily, the Multimedia API will provide a way to check available/su pported content types.

Audio Media

The Table 7 depicts the multimedia file formats are supported:

File Type CODEC

WAV PCM SP MIDI General MIDI MIDI Type 1 General MIDI MP3 MPEG-1 layer III MIDI Type 0 General MIDI

Table 7 Multimedia File formats

The Table 8 depicts a list of audio MIME types supported:

Category Description MIME Type

Audio/Video/Image

Wav MP3 Audio

Audio/x-wav Audio/mpeg

MIDI Audio SP MIDI Audio

Audio/midi Audio/sp-midi

9 JSR 135 Mobile Media API

Tone Sequences

Audio/x-tone-sequence

Audio

Table 8 List of audio MIME types

Refer to the Table 9 for multimedia feature/class support for JSR 135:

Feature/Class Implementation

Media package found Supported Media control package Supported Media Protocol package Supported Control interface in javax.microedition.medi a Supported All methods for the Controllable interface in

Supported

javax.microedition.media.control All fields, methods, and inherited methods for the Player interface in

Supported

javax.microedition.media All fields and methods for the PlayerListener interface in

Supported

javax.microedition.media PlayerListener OEM event types for the PlayerListener interface Standard types only All fields, methods, and inherited methods for the Manager Class in

Supported

javax.microedition.media TONE_DEVICE_LOCATOR support in the Manager class of

Supported

javax.microedition.media TONE_DEVICE_LOCATOR content type will be audio/x-tone-seq Supported TONE_DEVICE_LOCATOR media locator will be device://tone Supported All constructors and inherited methods in

Supported

javax.microedition.medi.MediaException All fields and methods in the StopTimeControl int erface in

Supported

javax.microedition.media.control All fields and methods in the ToneControl interface in

Supported

javax.microedition.media.control All methods in the VolumeControl interface in

Supported

javax.microedition.media.control Max volume of a MIDlet will not exceed the maximum speaker setting

Supported

on the handset All fields and methods in the GUIControl interface in

Supported

javax.microedition.media.control Multiple SourceStreams for a DataSource 2

Table 9 Multimedia feature/class support for JSR 135

9 JSR 135 Mobile Media API

Note: If two wave plays have the same frequency, they can mix. See Appendix A – mix audio table.

Player number limitation <=4 and MIDI size limitation is 150K MP3 stream size has the limitation

10 JSR 120 – Wireless Messaging API

JSR 120 – Wireless Messaging

API

Wireless Messaging API (WMA)

Motorola has implemented certain features that are defined in the Wireless Messaging API (WMA) 1.0. The complete specification document is defined in JSR 120.

The JSR 120 specification states that developers can be provided access to send (MO – mobile originated) and receive (MT – mob ile terminated) SMS (Short Message Service) on the target device.

A simple example of the WMA is the ability of two J2ME applications using SMS to communicate game moves running on the handsets. This can take the form of chess moves being passed between two players via the WMA.

Motorola in this implementation of the specif ication supports the following features.

 Creating a SMS  Sending a SMS  Receiving a SMS  Viewing a SMS  Listening to a SMS

SMS Client Mode and Server Mode Connection

The Wireless Messaging API is based on the Generic C on nection Framework (GCF), which is defined in the CLDC specification 1.0. The use of the “Connection” framework, in Motorola's case is “

MessageConnection can be opened in either server or clie nt mode. A server

The connection is opened by providing a URL that specifies an identifier (port number) for an application on the local device for incoming messages.

MessageConnection”.

10 JSR 120 – Wireless Messaging API

(MessageConnection)Connector.open("sms://:6000"); Messages received with this identifier will then be delivered to the application by this

connection. A server mode connection can be used for both sending and receiving messages. A client mode connection is opened by providing a URL which points to another device. A client mode connection can only be used for sending messages.

(MessageConnection)Connector.open("sms://+441234567890 :6000");

SMS Port Numbers

When a port number is present in the address, the TP-User-Data of th e SMS will contain a User-Data-Header with the application port addressing scheme information element. When the recipient address does not contain a port number, the TP-User-Data will not contain the application port addressing header. The J2ME MIDlet cannot receive this kind of message, but the SMS will be handled in the usual manner for a standard SMS to the device.

When a message identifying a port number is sent from a server type

MessageConnection, the originating port number in the messag e is set to the port

number of the the message that will be received by this

However, when a client type with a port number, the originating port number is set to an implementation specific value and any possible messages received to this port number are not delivered to the

MessageConnection. Please refer to the section A.4.0 and A.6.0 of the JSR 12 0.

When a MIDlet in server mode requests a port number (identifier) to use and it is the first MIDlet to request this identifier it will be allocated. If other applications apply for the same identifier then an

MessageConnection is made. If a system application is using this identifier, the

MIDlet will not be allocated the identifier. The port numbers allowed for this request are restricted to SMS messages. In addition, a MIDlet is not allowed to send mess ages to certain restricted ports a

JSR 120 Section A.6.0 Restricted Ports: 2805, 2923, 2948, 2949, 5502, 5503, 5508, 5511, 5512, 920 0, 92 01, 9202, 9203, 9207, 49996, 49999.

If you intend to use SMSC numbers then please revie w A.3.0 in the JSR 120 specification. The use of an SMSC would be used if th e MIDlet had to determine what recipient number to use.

MessageConnection. This allows the recipient to send a response to

IOException will be thrown when an attempt to open

MessageConnection.

MessageConnection is used for sending a message

SecurityException will be thrown if this is attempted.

10 JSR 120 – Wireless Messaging API

SMS Message Types

The types of messages that can be sent are TEXT or BINARY, the method of encoding the messages are defined in GSM 03.38 standard (Part 4 SMS Data Coding Scheme). Refer to section A.5.0 of JSR 120 for more information.

SMS Message Structure

The message structure of SMS will comply with GSM 03.40 v7.4.0 Digital cellular telecommunications system (Phase 2+); Technical realization of the Short Message Service (SMS) ETSI 2000.

Motorola’s implementation uses the concatenation feature specified in sections 9.2.3.24.1 and 9.2.3.24.8 of the GSM 03.40 standard for mess ages that the Java application sends that are too long to fit in a single SMS protocol message.

This implementation automatically concatenates the received SMS protocol messages and passes the fully reassembled message to the application via the API. The implementation will support at least three SMS messages to be received and concatenated together. Also, for sending, support for a minimum of three messages is supported. Motorola advises that developers should not send messages that will take up more than three SMS protocol messages unless the recipient’s device is known to support more.

SMS Notification

Examples of SMS interaction with a MIDlet would be the following:

 A MIDlet will handle an incoming SMS message if the MIDlet is registered to

receive messages on the port (identifier) and is running.

 When a MIDlet is paused and is registered to receive messages on the port

number of the incoming message, then the user will be queried to launch the MIDlet.

 If the MIDlet is not running and the Java Virtual Machine is not initialized, then a

Push Registry will be used to initialize the Virtual Machine and launch the J2ME MIDlet. This only applies to trusted, signed MIDlets.

 If a message is received and the untrusted unsigned application and the KVM

are not running then the message will be discarded.

The Table 10 depicts list of Messaging features/classes s upported in the device.

10 JSR 120 – Wireless Messaging API

Feature/Class Implementation

JSR-120 API. Specifically, APIs defined in the

Supported javax.wireless.messaging package will be implemented w ith regards to the GSM SMS Adaptor

All fields, methods, and inherited methods for the C onnector Class in

Supported the javax.microedition.io package

All methods for the BinaryMessage interface in the

Supported javax.wireless.messaging package

All methods for the Message interface in the javax.wire less.messaging

Supported package

All fields, methods, and inherited methods for the MessageConnection

Supported interface in the javax.wireless.messaging package

Number of MessageConnection instanc es in the

5 javax.wireless.messaging package

All methods for the MessageListener interface in the

Supported javax.wireless.messaging package

All methods and inherited methods for the TextMessage inte rface in

Supported the javax.wireless.messaging package

Number of concatenated messages. 40 messages in inbox, each can

be concatenated from 10 parts at

max.

No limitation on outbox

(immediately transmitted)

Table 10 Messaging features/classes supported

The Code Sample 5 shows the implementation of the JSR 120 Wireless Messaging API:

Creation of client connection and for calling of method ‘numberOfSegments’ for Binary message:

BinaryMessage binMsg; MessageConnection connClient; int MsgLength = 140;

/* Create connection for client mode */ connClient = (MessageConnection) Connector.open("sms://" +

outAddr);

/* Create BinaryMessage for client mode */ binMsg =

(BinaryMessage)connClient.newMessage(MessageConnection.BINARY _MESSAGE);

/* Create BINARY of 'size' bytes for BinaryMsg */ public byte[] createBinary(int size) { int nextByte = 0;

10 JSR 120 – Wireless Messaging API

byte[] newBin = new byte[size];

for (int i = 0; i < size; i++) { nextByte = (rand.nextInt()); newBin[i] = (byte)nextByte; if ((size > 4) && (i == size / 2)) { newBin[i-1] = 0x1b; newBin[i] = 0x7f; } } return newBin; }

byte[] newBin = createBinary(msgLength); binMsg.setPayloadData(newBin);

int num = connClient.numberOfSegments(binMsg);

Creation of server connection:

MessageConnection messageConnection = (MessageConnection)Connector.open("sms://:9532");

Creation of client connection with port number:

MessageConnection messageConnection = (MessageConnection)Connector.open("sms://+18473297274:9532");

Creation of client connection without port number:

MessageConnection messageConnection = (MessageConnection)Connector.open("sms://+18473297274");

Closing of connection:

MessageConnection messageConnection.close();

Creation of SMS message:

Message textMessage = messageConnection.newMessage(MessageConnection.TEXT_MESSAGE);

Setting of payload text for text message:

((TextMessage)message).setPayloadText("Text Message");

Getting of payload text of received text message:

receivedText = ((TextMessage)receivedMessage).getPayloadText();

Getting of payload data of received binary message:

BinaryMessage binMsg; byte[] payloadData = binMsg.getPayloadData();

Setting of address with port number:

message.setAddress("sms://+18473297274:9532");

10 JSR 120 – Wireless Messaging API

Setting of address without port number:

message.setAddress("sms://+18473297274");

Sending of message:

messageConnection.send(message);

Receiving of message:

Message receivedMessage = messageConnection.receive();

Getting of address:

String address = ((TextMessage)message).getAddress();

Getting of timestamp for the message:

Message message; System.out.println("Timestamp: " +

message.getTimestamp().getTime());

Creation of client connection, creation of binary message, setting of payload for binary message and calling of method ‘numberOfSegments(Message)’ for Binary message:

BinaryMessage binMsg;

MessageConnection connClient;

int MsgLength = 140;

/* Create connection for client mode */

connClient = (MessageConnection) Connector.open("sms://" +

outAddr);

/* Create BinaryMessage for client mode */

binMsg =

(BinaryMessage)connClient.newMessage(MessageConnection.BINARY

_MESSAGE);

/* Create BINARY of 'size' bytes for BinaryMsg */

public byte[] createBinary(int size) {

int nextByte = 0;

byte[] newBin = new byte[size];

for (int i = 0; i < size; i++) {

nextByte = (rand.nextInt());

newBin[i] = (byte)nextByte;

if ((size > 4) && (i == size / 2)) {

newBin[i-1] = 0x1b;

newBin[i] = 0x7f;

}

return newBin;

}

10 JSR 120 – Wireless Messaging API

byte[] newBin = createBinary(msgLength);

binMsg.setPayloadData(newBin);

int num = connClient.numberOfSegments(binMsg);

Setting of MessageListener and receiving of notifications about incoming messages:

public class JSR120Sample1 extends MIDlet implements

CommandListener {

…

JSR120Sample1Listener listener = new JSR120Sample1Listener();

…

// open connection

messageConnection =

(MessageConnection)Connector.open("sms://:9532");

…

// create message to send

…

listener.run();

…

// set payload for the message to send

…

// set address for the message to send

messageToSend.setAddress("sms://+18473297274:9532");

…

// send message (via invocation of ‘send’ method)

…

// set address for the message to receive

receivedMessage.setAddress("sms://:9532");

…

// receive message (via invocation of ‘receive’ method)

…

class JSR120Sample1Listener implements MessageListener,

Runnable {

private int messages = 0;

public void notifyIncomingMessage(MessageConnection

connection) {

System.out.println("Notification about incoming message

arrived");

messages++;

}

public void run() {

try {

messageConnection.setMessageListener(listener);

} catch (IOException e) {

result = FAIL;

System.out.println("FAILED: exception while setting listener:

10 JSR 120 – Wireless Messaging API

" + e.toString());

}

Code Sample 5 JSR 120 Wireless Messaging API

11 Phonebook Access API

Phonebook Access API

Using the Phonebook Access API, an application will be able to locate and update contact

information on the handset. This contact info rmation includes phone numbers, email

addresses, and any other directory information related to individuals, groups, or

organizations. The database used to store phonebook information wil l be unique an d

integrated for native phonebook, SIM card, and other applications using Phonebook API.

The primary goal of the Phonebook Access API is to be simple and thin to fit in resource-

limited devices like the Motorola C381p handset. This API will specify a base storage

class for all types of contacts items presente d in the vCard specification (RFC2426 –

vCard MIME Directory Profile – vCard 3.0 Specification). In addition, schema strings used

in querying and storing contact information are those specified in the RFC2426

specification.

The Phonebook Access API will perform the following functions:

• Allow multiple phone numbers and em ail addresses for each contact

• Store new entries

• Retrieve entries

• Edit existing entries

• Delete entries

• Check memory status

• Order and sort contact parameters

• Support standard schema strings

Phonebook Access API Permissions

Prior to a MIDlet accessing the Phonebook API for all Pho nebook operations, the

implementation will check the Phonebook permissions granted to the application.

11 Phonebook Access API

In the Motorola C381p, Phonebook API permissions have been added to the MIDP 2.0

security framework “com.motorola.phon ebook.” The behavior is up to the domain setting

where the MIDlet falls in. For an untrusted MIDlet, the permission for the API is “Oneshot”.

The Code Sample 6 shows the implementation of the Phonebook API:

Sample of code to create object of PhoneBookRecord class:

PhoneBookRecord phbkRecEmpty = new PhoneBookRecord();

String name = “Name”;

String telNo = “9999999”;

int type = PhoneBookRecord.MAIN;

PhoneBookRecord phbkRec = new PhoneBookRecord(name, telNo, type,

PhoneBookRecord.CATEGORY_GENERAL);

Sample of code for calling of ‘add(int sortOrder)’ method:

int index = phbkRec.add(PhoneBookRecord.SORT_BY_NAME);

Sample of code for calling of ‘update(int index, int sortOrder)’ method:

phbkRec.type = PhoneBookRecord.HOME;

int newIndex = phbkRec.update(index, PhoneBookRecord. SORT_BY_NAME);

Sample of code for calling of ‘delete(int index, int sortOrder)’ method:

PhoneBookRecord.delete(index, PhoneBookRecord. SORT_BY_NAME);

Sample of code for calling of ‘deleteAll()’ method:

PhoneBookRecord.deleteAll();

Sample of code for calling of ‘getRecord(int index, int sortOrder)’ method:

phbkRec.getRecord(index, PhoneBookRecord.SORT_BY_NAME);

Sample of code for calling of ‘findRecordByTelNo(String tel, int sortOrder)’ method:

index = phbkRec.findRecordByTelNo(telNo,

PhoneBookRecord.SORT_BY_NAME);

Sample of code for calling of ‘findRecordByName(char firstChar, int sortOrder)’ method:

index = PhoneBookRecord.findRecordByName('N',

PhoneBookRecord.SORT_BY_NAME);

Sample of code for calling of ‘findRecordByEmail(String email, int sortOrder)’ method:

String email = “email@mail.com”;

index = phbkRec.findRecordByEmail(email,

PhoneBookRecord.SORT_BY_NAME);

11 Phonebook Access API

Sample of code for calling of ‘getNumberRecords(int device)’ method:

// get total number of records

int numberRecsInPhone =

PhoneBookRecord.getNumberRecords(PhoneBookRecord.PHONE_MEMORY);

int numberRecsInSim =

PhoneBookRecord.getNumberRecords(PhoneBookRecord.SIM_MEMORY);

int numberRecsAll =

PhoneBookRecord.getNumberRecords(PhoneBookRecord.ALL_MEMORY);

Sample of code for calling of ‘getAvailableRecords(int device)’ method:

// get number of available records

int numberRecsAvalPhone =

PhoneBookRecord.getAvailableRecords(PhoneBookRecord.PHONE_MEMORY);

int numberRecsAvalSim =

PhoneBookRecord.getAvailableRecords(PhoneBookRecord.SIM_MEMORY);

int numberRecsAvalAll =

PhoneBookRecord.getAvailableRecords(PhoneBookRecord.ALL_MEMORY);

Sample of code for calling of ‘getUsedRecords(int device, int sortOrder)’ method:

// get number of used records

int numberRecsUsedPhone =

PhoneBookRecord.getUsedRecords(PhoneBookRecord.PHONE_MEMORY,

PhoneBookRecord.SORT_BY_NAME);

int numberRecsUsedSim =

PhoneBookRecord.getUsedRecords(PhoneBookRecord.SIM_MEMORY,

PhoneBookRecord.SORT_BY_NAME);

int numberRecsUsedAll =

PhoneBookRecord.getUsedRecords(PhoneBookRecord.ALL_MEMORY,

PhoneBookRecord.SORT_BY_NAME);

Sample of code for calling of ‘getNumberRecordsByName(String name)’ method:

int num = PhoneBookRecord.getNumberRecordsByName(name);

Sample of code for calling of ‘getMaxNameLength(int device)’ method:

int maxNameLengthPhone =

PhoneBookRecord.getMaxNameLength(PhoneBookRecord.PHONE_MEMORY);

int maxNameLengthSim =

PhoneBookRecord.getMaxNameLength(PhoneBookRecord.SIM_MEMORY);

int maxNameLengthAll =

PhoneBookRecord.getMaxNameLength(PhoneBookRecord.ALL_MEMORY);

Sample of code for calling of ‘getMaxTelNoLength (int device)’ method:

int maxTelNoLengthPhone =

PhoneBookRecord.getMaxTelNoLength(PhoneBookRecord.PHONE_MEMORY);

11 Phonebook Access API

int maxTelNoLengthSim =

PhoneBookRecord.getMaxTelNoLength(PhoneBookRecord.SIM_MEMORY);

int maxTelNoLengthAll =

PhoneBookRecord.getMaxTelNoLength(PhoneBookRecord.ALL_MEMORY);

Sample of code for calling of ‘getMaxEmailLength ()’ method:

int maxEmailLength =

PhoneBookRecord.getMaxEmailLength();

Sample of code for calling of ‘getIndexBySpeedNo(int speedNo, int sortOrder)’ method:

int speedNo = 1;

index = PhoneBookRecord.getIndexBySpeedNo(speedNo, PhoneBookRecord.

SORT_BY_NAME);

Sample of code for calling of ‘getNewSpeedNo(int num, int device)’ method:

int speedNo = 1;

int speedNo_phone =

PhoneBookRecord.getNewSpeedNo(speedNo,

PhoneBookRecord.PHONE_MEMORY);

int speedNo_sim =

PhoneBookRecord.getNewSpeedNo(speedNo,

PhoneBookRecord.PHONE_MEMORY);

int speedNo_all =

PhoneBookRecord.getNewSpeedNo(speedNo,

PhoneBookRecord.PHONE_MEMORY);

Sample of code for calling of ‘getDeviceType(int speedNo)’ method:

int speedNo = 1;

int type = PhoneBookRecord.getDeviceType(speedNo);

Sample of code for calling of ‘setPrimary(int index, int sortOrder)’ method:

int index = 1;

PhoneBookRecord.setPrimary(index, PhoneBookRecord.SORT_BY_NAME);

Sample of code for calling of ‘resetPrimary(int index, int sortOrder)’ method:

int index = 1;

PhoneBookRecord.resetPrimary(index, PhoneBookRecord.SORT_BY_NAME);

Sample of code for calling of ‘isPrimary(int speedNo)’ method:

int speedNo = 1;

boolean res = PhoneBookRecord.isPrimary(speedNo);

Sample of code for calling of ‘fromVFormat(InputStream in, int device)’ method:

11 Phonebook Access API

buffer = new String("BEGIN:VCARD\r\nN:;" + new String(name) +

"\r\nTEL;TYPE=WORK:1\r\nEND:VCARD\r\n");

int num =

PhoneBookRecord.fromVFormat((InputStream)(new

ByteArrayInputStream(buffer.getBytes())),

PhoneBookRecord.PHONE_MEMORY);

Sample of code for calling of ‘toVFormat(OutputStream out, int

index, int outFormat, int sortOrder)’ method:

int index = 1;

ByteArrayOutputStream outStream = new ByteArrayOutputStream();

PhoneBookRecord.toVFormat(outStream, index,

PhoneBookRecord.VCARD_3_0,

PhoneBookRecord.SORT_BY_NAME);

System.out.println("***** Contents of the output stream: *****");

System.out.print(new String(outStream.toByteArray()));

Code Sample 6 Phonebook API

12 Telephony API

Telephony API

The Telephony API allows a MIDlet to make a voice call, however, the user needs to

confirm the action before any voice call is ma de. The reason for the confirmation is to

provide a measure of security from rogue appli cations overtaking the handset.

Unlike standard TAPI, the wireless Telephony API provide simple function and simple

even listener: startCall (), send ExtNo (), and endCall (), DialerListener.

The Tables 11 and 12 describe the Interface and Class Summary:

Interface Summary

DialerListener The DialerListener interface provides a mechanism for the application to

be notified of phone call event.

Table 11 Interface Summary

Class Summary

Dialer The Dialer class defines the basic functionality for start and end phone

call.

DialerEvent The DialerEvent class defines phone call events.

Table 12 Class Summary

Dialer Class

The dialer Class can be used to start and end a phone call and user listener to receive an

event. The applications use a Dialer to make a phone call and use DialerListener to

receive event.

Class DialerEvent

The DialerEvent class defines phone call events. The Table 13 describes the Field

Summary:

12 Telephony API

Summary

static byte PHONE_VOICECALL_CONNECT

Phone call was connected event

static byte PHONE_VOICECALL_DISCONNECT

Phone call was disconnected event

static byte PHONE_VOICECALL_DTMF_FAILURE

Send extension number error event

static byte PHONE_VOICECALL_FAILURE

start phone call error event

static byte PHONE_VOICECALL_HOLD

Current java phone call was held by native phone event

static byte PHONE_VOICECALL_INIT

Phone start dial-up event

static byte PHONE_VOICECALL_TIMEOUT

Phone process timeout event

static byte PHONE_VOICECALL_UNHOLD

Current java phone call was unheld event

Table 13 Field Summary

The Table 14 describes the Constructor Summary:

Constructor Summary

DialerEvent()

Table 14 Constructor Summary

The following methods are inherited from class java.lang.Object:

• equals

• getClass

• hashCode

• notify

• notifyAll

• toString

• wait

The Table 15 describes the Field Details:

Field Detail Definition

PHONE_VOICECALL_INIT

public static final byte PHONE_VOICECALL_INIT

Phone start dial-up event

PHONE_VOICECALL_FAILURE

public static final byte PHONE_VOICECALL_FAILURE

Start phone call error event

12 Telephony API

PHONE_VOICECALL_CONNECT

PHONE_VOICECALL_DISCONNECT

PHONE_VOICECALL_TIMEOUT

PHONE_VOICECALL_HOLD

PHONE_VOICECALL_UNHOLD

PHONE_VOICECALL_DTMF_FAILURE

public static final byte PHONE_VOICECALL_CONNECT

public static final byte PHONE_VOICECALL_DISCONNECT

public static final byte PHONE_VOICECALL_TIMEOUT

public static final byte PHONE_VOICECALL_HOLD

public static final byte PHONE_VOICECALL_UNHOLD

public static final byte PHONE_VOICECALL_DTMF_FAILURE

Table 15 Field Details

Phone call was connected event

Phone call was disconnect ed event

Phone process timeout event

Current java phone call was held by native phone event

Current java phone call was unheld event

Send extension number error event

Class Dialer

The Dialer class defines the basic functionali t y for starting and ending a phone call. The

Table 16 describes the Method Summary:

Method Summary

void

static Dialer

endCall() end or cancel a phone call getDefaultDialer()

12 Telephony API

void void void void

sendExtNo(String extNumber) send extension number. setDialerListener(DialerListener listener) Registers a DialerListener object. startCall(String telenumber) start a phone call using given telephone number. startCall(String teleNumber, String extNo) start a phone call using given telephone number and extension number.

Table 16 Method Summary

The following methods are inherited from java.lang.object:

• equals

• getClass

• hashCode

• notify

• notifyAll

• toString

• wait

getDefaultDialer

public static Dialer getDefaultDialer()

Get a Dialer instance.

setDialerListener

public void setDialerListener(DialerListener listener)

Registers a DialerListener object.

The platform will notify this listener object when a phone event has been received to this

Dialer object.

There can be at most one listener object registered for a Di aler object at any given point in

time. Setting a new listener will implicitly de-register the possibly previ ously set listener.

Passing null as the parameter de-registers the curr ently registered listener, if any.

Parameters:

listener - DialerListener object to be registered. If null, the possibly currently

registered listener will be de-register ed and will not receive phone call event.

12 Telephony API

startCall

public void startCall(String telenumber)

startCall

throws

IOException

start a phone call using given telephone number.

Parameters:

telenumber - the telephone number to be call.

extNo - the extension number to be send.

Throws:

IOException - if the call could not be created or because of network failure

NullPointerException - if the parameter is null

SecurityException - if the application does not have permission to start the call

public void startCall(String teleNumber,

String

throws IOException

extNo)

start a phone call using given telephone number and extension number.

Parameters:

telenumber - the telephone number to be call.

extNo

- the extension number to be send.

Throws:

sendExtNo

IOException - if the call could not be created or because of network failure

NullPointerException

SecurityException - if the application does not have permission to start the call

- if the parameter is null

public void sendExtNo(String extNumber)

throws

IOException

send extension number.

Parameters:

sendExtNo - the extension number to be send.

Throws:

IOException - if the extension could not be send or because of network failure

12 Telephony API

endCall

public void endCall()

throws

IOException

end or cancel a phone call

Throws:

IOException - if the call could not be end or cancel.

Interface DialerListener

public interface DialerListener

DialerListener interface provides a mechanism for the application to be notified

The

of phone call event.

When an event arrives, the

notifyDialerEvent() method is called

The listener mechanism allows applications to receive TAPI voice call event without

needing to have a listener thread

If multiple event arrive very closely together in time, the imp lementation has calling this

listener in serial.

Sample DialerListener Implementation

Dialer listener program

import java.io.IOException; import javax.microedition.midlet.*; import javax.microedition.io.*; import com.motorola.*;

public class Example extends MIDlet implements DialerListener { Dialer dialer;

// Initial tests setup and execution.

public void startApp() { try { dialer = Dialer.getDefaultDialer();

// Register a listener for inbound TAPI voice call events. dialer.setDialerListener(this); dialer.startCall("01065642288");

} catch (IOException e) { // Handle startup errors }

12 Telephony API

} Asynchronous callback for receive phone call event

public void notifyDialerEvent(Dialer dialer, byte event) { switch (event) { case DialerEvent.PHONE_VOICECALL_INIT: // your process break; case DialerEvent.PHONE_VOICECALL_FAILURE: // your process break; case DialerEvent.PHONE_VOICECALL_CONNECT: // your process break; case DialerEvent.PHONE_VOICECALL_DISCONNECT: // your process break; case DialerEvent.PHONE_VOICECALL_TIMEOUT: // your process break; case DialerEvent.PHONE_VOICECALL_HOLD: // your process break; case DialerEvent.PHONE_VOICECALL_UNHOLD: // your process break; case DialerEvent.PHONE_VOICECALL_DTMF_FAILURE: // your process break; } }

// Required MIDlet method - release the connection and // signal the reader thread to terminate.

public void pauseApp() { try { dialer.endCall(); } catch (IOException e) { // Handle errors } }

// Required MIDlet method - shutdown. // @param unconditional forced shutdown flag

public void destroyApp(boolean unconditional) { try { dialer.setDialerListener(null); dialer.endCall(); } catch (IOException e) { // Handle shutdown errors. } } }

Code Sample 7 DialerListener Implementation

12 Telephony API

notifyDialerEvent

public void notifyDialerEvent(Dialer dialer,

byte event)

Called by the platform when a phone call event was received by a Dialer object where the

application has registered this liste ner object.

This method is called once for each TAPI voice call event to the Dialer object.

NOTE: The implementation of this method MUST return quickly and MUST NOT perform

any extensive operations. The application SHOULD NOT receive and handle the

message during this method call. Instead, it should act only as a trigger to start the activity

in the application's own thread.

Parameters:

dialer - the Dialer where the TAPI voice call event has arrived

event - the TAPI voice call event type.

Class Hierarchy

• class java.lang.Object

o class com.motorola.phone.D ialer o class com.motorola.phone.D ialerEvent

Interface Hierarchy

• interface com.motorola.phone.DialerListener

13 Serial Port Access

The Serial Port RS232 API is incorporated into any J2ME device allowing connection to

the J2ME serial port communication stream.

Opening the port requires the form Connector.open("comm:/name;parameters) where

name is the name of the serial port. (A comma separated l ist of supported names can be

obtained by calling System.getProperty("serialport.name");)

The API should allow the J2ME application to query for the available device connections

(data cable), as well as the available d ata speeds.

Serial Port Access

This API should be in-line with the CLDC javax.microedition.io Version 1.02. In addition,

the following changes must be added over the CLDC standard:

• Automatic baud rate detection.

• Addition of more parity options; specifically m ark a nd space.

• Support for 1.5 stop bits as a common UART feature.

• Changes to port names, as opposed to the "open by port number option". The

use of actual port names are more meaningful to th e user.

• The mode parameter for Connector.open() is not ignored. A MIDlet should not be allowed to write a connection which is specified as READ only.

14 SMS Messaging as GSM Extension

SMS Messaging as GSM

The SMS APIs for J2ME environment enable the followi ng functionality:

• Creating an SMS message

• Sending an SMS message

Extension

• Viewing an SMS message

• Deleting an SMS message

The SMS APIs support the following contents to be sent over SMS:

• Text message

• Audio files: .au, .midi. .wav, .mp3

• Image files: .png, .gif

The SMS messages for each MIDlet are managed by the MIDlet.

Creating a Message

The API enables creating of SMS messages. The addressing is compliant with the standard SMS addressing as specified in the GSM standards. The content of the message can be constructed using one or more of the content types specified in chapter 10 of this document.

Sending a Message

The SMS API provides a way to send a message to the appropriate SMS address. Any errors while sending the message should b e ha ndled appropriately.

14 SMS Messaging as GSM Extension

Viewing a Message

The APIs should provide a way to get a list of messages that is associated with a specific application and to view the messages.

Deleting a Message

The API should provide a way to delete SMS messag es.

15 User Display Interface

User Display Interface

The J2ME standard allows specific Canvas, Hardware Mapping and External Event Interaction functionality.

Canvas Functionality

The J2ME standard specifies that the Canvas class is available to the J2ME application. The J2ME Canvas functionality controls the rendering of objects on the entire display. In

addition, the J2ME Canvas requirements a minimum display size and functional soft key area for use by the application.

• There is a minimum of 96 x 54 pixels screen size to be available to the J2ME application.

• The lower 10 pixels are reserved for two soft keys and the menu icon. These 10 pixels are not counted in the 54 pixels reserved for the J2ME Canvas display.

• The soft keys and menu icon, located in the 10 pixel reserved area, are rendered in 11 high font.

• The soft keys and menu icon follow noted below:

o MIDlet UI design can be designated in the J2ME Style Guide or

Developer Guide but implementation is still decided by the developer.

The application supports the Portable Network Graphic (PNG) Image Format.

• Implementations are required to support images stored in the PNG format. All of the 'critical' chunks specified by PNG must be supported, with the following considerations:

o The IHDR chunk. MIDP devices must handle the following values in the

IHDR chunk:

 All positive values of width and height are supported; however,

a very large image may not be readable because of memory constraints.

15 User Display Interface

 All color types are supported, although the appearance of the

image will be dependent on the capabilities of the device's screen. Color types that include alpha channel data are supported; however, the implementation may ig nore all alpha channel information and treat all pixels as opaque.

 All bit depth values for the given color type ar e supported.  Compression method 0 (deflate) is the only sup ported

compression method. This is the same compression method that is used for jar files, and so the decompression (inflate) code may be shared between the jar decoding and PNG decoding implementations.

 The filter method represents a series of e ncoding schemes

that may be used to optimize compression. The PNG spec currently defines a single filter method (method 0) that is an adaptive filtering scheme with five basic filter types. Filtering is essential for optimal compression since it allows the deflate algorithm to exploit spatial similarities with in the image. Therefore, MIDP devices must support all five filter types defined by filter method 0.

 MIDP devices are required to read PNG images that are

encoded with either interlace method 0 (None) or interlace method 1 (Adam7). Image loading in MIDP is sync hro nous and cannot be overlapped with image rendering. There is no advantage for an application to use interlace method 1. Support for decoding interlaced images is required for compatibility with PNG and for the convenience of developers who may already have interlaced images available.

o The PLTE chunk. Palette-based images must be supported. o The IDAT chunk. Image data may be e ncoded using any of the 5 filter

types defined by filter method 0 (None, Sub, Up, Avera ge, Path).

o The IEND chunk. This chunk must be found in order for the image to be

considered valid.

o Ancillary chunk support. PNG defi nes several 'ancillary' chunks that

may be present in a PNG image but are not critical for image decoding. A MIDP implementation may (but is not required to ) support any of these chunks. The implementation should sil ently ignore any unsupported ancillary chunks that it encounters. The defined ancillary chunks are:

 bKGD cHRM gAMA hIST iCCP iTXt pHYs sBIT sPLT sRGB

tEXt tIME tRNS zTXt

o All MIDlets will be displ ayed in the ZOOM OUT mode. Once the MIDlet

is exited, the handset will return to the user’s pre-defined ZOOM IN/OUT state.

15 User Display Interface

Hardware Mapping

The J2ME standard provides a minimum key set that is determined to be available on a ll devices. These key sets are to be mapped by the individual hardware manufacturers to a specified command set for application use. In addition, if other hardware keys are available, it is left to the manufacturer to determine the functionality of these keys. The following sections detail the standard J2ME required keys and the Motorola propriet ary reserved key sets.

J2ME Standard Key Set

If present on the device specific hardware, the followi ng keys are to be available to the J2ME application. The J2ME application can assign actions to these key inputs per the design of the application.

• Keys 0 through 9, the * key and the # key shall be available to the application for use. The J2ME application can either retain the standard functionality (i.e. a key press of 6 indicates the use of the number value six) or the application can map these keys to application specific use (i.e. the number 6 could map to a right action key).

Motorola Standard Key Set

The following keys are not available to the J2ME application and are retained by the handset for Motorola specific usage regardle ss of J2ME application processing. These keys and associated actions will always retain a higher priority than the J2ME application. This will ensure that some minimal level of control is always available to the handset user, regardless of the actions of a J2ME application.

End Key

The End key shall always terminate the current J2ME application and return the user b ack to the mobile idle state.

Send Key

The Send key shall always remain independent of any J2ME applications. When a telephone number from a J2ME application is displayed, the handset shall attempt to place the call if the Send key is pressed.

Left, Right and Menu Soft Keys

The J2ME standard allows for a global command set to be available to the applicatio n developers. This complete command list is: SCREEN, BACK, CANCEL, OK, HELP, STOP, EXIT, MENU AND ITEM. For all other global commands, the handset shall use the default label (which will be the same name as the command) if a label is not supplied. If a command label supplied by the J2ME application is too long, it should be truncated.

15 User Display Interface

The handset controls the rendering and positioning of these global commands, but the J2ME application determines the actual availability and functionality of these commands. For example, J2ME application1 may indicate to the KVM that only four of the global commands are to be used/displayed, where as J2ME application2 may indicate that all nine global commands are to be use d/displayed.

Each of global commands in Table 17 has a priority ranking.

Rules:

Example 1:

Upon start-up, the J2ME application indicate s that the following global commands are

active: BACK, CANCEL, OK, HELP and STOP. The handset display woul d look like this:

Global Command Soft Key Position Priority

SCREEN RIGHT 1 BACK LEFT 2 CANCEL LEFT 3 OK RIGHT 4 HELP RIGHT 5 STOP RIGHT 6 EXIT LEFT 7 OPTIONS (menu) RIGHT 8 ITEM RIGHT 9 FIRE RIGHT 10

Table 17 Key Ranking Priority

• If no global command is specified from the J2ME application, the handset shall always display the BACK command on the left soft key position. The MENU icon and Right soft key shall remain blank. If the BACK key is pressed, the J2ME application is destroyed an d the handset shall return back to the J2ME Application Manager screen.

• If the global command list is populated, but does not contain one of the following commands, BACK / CANCEL / EXIT, then the handset shall always display the BACK command on the left soft key position. If the global command list is populated with commands that occupy both left and right side soft keys, then the highest priority command sha ll occupy the appropriate softkey. The remaining global commands will be displayed if the menu soft key is pressed. The remaining global commands shall be displayed in ascending order based on the priority value of the above table.

15 User Display Interface

Example 2: Upon start-up, the J2ME application indicate s that the following global commands are

active: SCREEN, CANCEL, HELP, OK, and STOP. The handset display woul d look like this:

Figure 3 Active Global Commands - Cancel, Screen, OK, Help & Stop

Power Key

When the Power key is pressed and held down, it should always override all applications and power down the handset.

Figure 2 Active Global Commands - Back, Cancel, OK, Help & Stop

15 User Display Interface

Volume Key

Volume keys will not be supported in the first release of J2ME, Java 1.0. In following releases, when the Volume key (s) is pressed and held down, it should always control the speaker/ accessory volume regardless of application.

Game Key Mapping

Games require the use of UP/DOWN/LEFT/RIGHT and FIRE as a basic set of keys in order to play. For handsets that have a four direction navigational device (joystick), UP/DOWN/LEFT/ RIGHT should be mapped to that. Otherwise, the keypad should return game action by mapping the 2 key to UP comman d, 8 key to DOWN command, 4 key to LEFT command, and 6 key to RIGHT command. In addition, the FIRE key should be mapped to the SELECT key if present otherwise to the right soft key and the 5 key. Additional game action keys exist, these are the GAME A, GAME B, GAME C, and GAME D keys. They perform different game actions de pending on the game being played. GAME A should be mapped to the 1 key. GAME B should be mapped to the 3 key. GAME C should be mapped to the 7 key. GAME D should be mapped to the 9 key. For hardware implementations that support multiple key presses, such as Talon, the following keys must be supported when pressed simultaneously: Four direction navigational device (i.e. joystick), 1, 3, 5, 7, & 9 keys.

16 One-Click Application Access

One-Click Application Access

The one-click access to J2ME applications Implementation allows the user to more readily access frequently used Java applications via the soft keys, navigation keys or smart keys. The key requirement is to allow MIDlets to behave as if they were Main Menu applications. Allowing J2ME application to be moved from the My JavaApps menu to the Main Menu, although this would be ideal, it will not be implemented until native applications are capable of being moved up and down the menu structure in different 'folders' and 'sub-menus'.

Application Resources

The DRM application resources table must be updated to p rovide for the display of the following.

• Small icon (no deletion)

• Large icon (no deletion)

• Softkey name

• Common name

Application Keys

J2ME applications must be able to be assigned to the app lication keys of the device. The options for application keys will be dependent on the device being used. This includes devices that have Smartkeys or four-way navigation keys that can be associated to applications. The applications executed from the application keys must also be accessible from the My JavaApps menu.

Application Icons

J2ME applications must be representable via icons of multiple sizes. This is especially required for devices that have multiple methods for displaying applications.

16 One-Click Application Access

• Large Icons - Until a better solution can be implemented, a generic large animated icon must be created for display on the idle screen.

• Small Icons - A 15 x 15 pixels (Must be used in the Personalize list views).

Softkey Labels

The softkey name of the app must be truncated (if the name is too long) a fter all available space is used. In the rare occasion that there are two applications with the same name (ex. two calculator apps: basic and advanced), the s econd application name must be truncated followed by the number ‘2’)

 The MIDlet-icon JAD attribute specifies the directory name for the

icon(PNG image)

 MIDlets with the MIDlet-icon attribute have the ca pability to display a

PNG image

 Next to the MIDlet name in the personalize list view.  MIDlets that do not have this attribute will have a standard PNG image

displayed

 Next to the MIDlet name.

Effect of Master Clear or Master Reset

The one-click keys that are associated to a J2ME appli cation must be replaced by default settings if a Master Clear or Master Reset is performed.

Deleting the MIDlet/Application

Deleting the J2ME MIDlet/application from the My JavaApps list must reset the application keys to their defaults.

17 Download MIDlet Through Browser

Download MIDlet Through

The Download MIDlet Through Browser requires the br owser to be connected before performing any downloads on the hands et.

The example shows How user may acces s the Browser application by any of the following methods:

Browser

• Selecting “Browser” from the Main Menu.

• Pressing a dedicated “Browser” key o n the keypad (if available on the handset).

• Pressing a “Browser” soft key from the idle display (if assigned).

• Using “Browser” shortcut (if assigned).

• Selecting URL from a message.

• Selecting GetJavaApps from the Main Menu or Java Settings.

17 Download MIDlet Through Browser

Star Active Browser Session from Main Menu

The Figure 4 describes Staring Active Browser Sessi on from Main

Menu:

Figure 4 Starting Active Browser Session from Main Menu

GetJavaApps is a feature that allows an operator to insert a WAP designated URL that links to a J2ME site with MIDlet suites. This feature can be found under Java Settings or in the Main Menu as it is flexible for either menu item.

Find a location with J2ME Application

Once connected to the WAP browser, different locations may be visited where J2ME Applications may be downloaded. From here, a MIDlet may be selected to download to the handset.

Handset initially receives information from the Java Application Descriptor (JAD) file. The JAD includes information about MIDlet-name, version, vendor, MIDlet-Jar-URL, MIDletJar-size, and MIDlet-Data-size. Two additional JAD attribut es will be Mot-Data-SpaceRequirements and Mot-Program-Space-Requirements. These attribute will help the KVM determine whether there is enough memory to download and install the selected MIDlet suite. If there is not enough memory, “Memory Full” dialog will be dis play ed before the download begins.

17 Download MIDlet Through Browser

Downloading MIDlets

The Figure 5 represents J2ME Application (MIDlets) Download and Installation.

Figure 5 Downloading and Installing J2ME Application (MIDlets)

Steps to Download and Install J2ME Application:

• BACK shows previous screen to the user.

• If the SELECT softkey is selected, the handset shows display the application

size, time to install and version. If an error occurs with the descriptor file, the handset then displays the transient notice “Failed Invalid File.” Upon Time-out, the handset goes back to browser.

• If the CANCEL softkey is selected, it shows the Browser Application Card from where the application was selected.

17 Download MIDlet Through Browser

• If the DOWNLD softkey is selected, the handset starts downloading the application. The handset displays “Downloading...% Complete” along with the percentage of downloading complet ed at a time. “Downloading...% Complete” shall use static dots, not dynamic.

• Before downloading the MIDlet, handset checks for available memory. Mot-Data- Space-Requirements and Mot-Program-Space-Requirements are two JAD attributes that will help the KVM determine whether there is enough memory to download and install the selected MIDlet suite. If there is not enough memory, “Insufficient storage” transient dialog will be displayed before the download begins. Upon time-out, the handset goes back to browser.

• If an error occurs during download, such as a loss of serv ice, then the transient notice “Download Failed” must be displayed. Upon time-out, the handset goes back to idle state.

• A downloading application can be cancelled by pressing the END key. The transient notice, “Download Cancelled, “ displays. Upon time-out, handset goes back to browser.

• If JAR -file size does not match with specified size, it disp lays “Failed Invalid File”. Upon time-out, the handset goes back to browser.

• When the downloading application is cancelled, handset cleans up all files, including any partial JAR files and temporary files created during the download process.

• When downloading is done, the handset displays a transient notice “Download Completed”. The handset then starts to install the application.

• The handset displays “Installing...”.

• After an application is successfully downloa ded, a status message must be sent

back to the network server. This allows for charging of the downloaded application.

• Charging is per the Over the Air User Initiated Provisionin g specification. The status of an install is reported by means of an HTTP POST request to the URL contained in the MIDlet-Install-Notify attribute. The only protocol that MUST be supported is “http://”.

• If the browser connection is interrupted/en ded during the download/installation process, the device will be unable to send the HTTP POST with the MIDlet-Instal l Notify attribute. In this case, the MIDlet will be deleted to insure the user d oe s not get a free MIDlet. The use case can occur when a phone call is accepted and terminated during the installation process, because then the browser will not be in the needed state in order to return the MIDlet Install Notify attribute.

• Upon completing Installation, the handset displays a transient notice “Installed to Games & Apps”.

• Upon time-out, the handset goes back to Browser.

• During Installation if the MANIFEST file is wrong, the handset displays a

transient notice “Failed File Corrupt”. Upon time-out, the hands et goes back to Browser.

17 Download MIDlet Through Browser

• During the installation process, if the flip is closed on a flip handset, the installation process will continue and the handset will not return to the idle display. When the flip is opened, the “Installing...” dialogue should appear on the screen and should be dynamic.

• During download or install of applicat ion, voice record, voice commands, voice shortcuts, and volume control will not be supported. However, during this time, incoming calls and SMS messages are able to b e received.

• The handset must support sending and receivi ng at least 30 kilobytes of data using HTTP either from the server to the client or the client to the server, per Over the Air User Initiated Provisioning specification.

• If JAD does not contain mandatory attributes, “Failed Invalid File” notice appears.

If JAD does not contain mandatory attributes, “Failed Invalid File” notice appears.

Figure 6 Application does not have Mandatory Attributes in ADF

Different Error Checks

Memory Full

There are two distinct cases when a Memory Full error can occur during the download process. Memory Full will be displayed when the device does not have enough memory to completely download the MIDlet. The JAD of the MIDlet has two attributes, Mot-DataSpace-Requirements and Mot-Pro gram-Space-Requirements. If an application developer adds these attributes to their JAD file, a Motorola device can determine if enough memory exists on the phone before the MIDlet is downloaded. These attributes may or may not be

17 Download MIDlet Through Browser

provided in all MIDlets. Two separate prompts will be displayed depending on whether these attributes are present.

In cases where there is not enough memory to download the application, the user MUST be given a message to delete existing applications in order to free additional memory. The following messages and screen flows will be displayed depending on whether specific JAD attributes are present or not:

17 Download MIDlet Through Browser

Figure 7 Memory full error

Rules:

•

If Mot-Data-Space-Requirements and Mot-Program-Space-Requirements

attributes are present in the JAD, the above noted prompt should be displayed. This value takes into account the memory requirements of th e MIDlet and the current memory usage on the phone, in order to tell the user exactly how much memory to free. The memory usage is based in kilobyte units.

• “Data Space:” and the value of the dat a space should be on separate lines. “Prog. Space:” and the value of the program space should be on separate lines.

• The download process is canceled when this error condition occurs.

• The Memory Full error will no longer be a transient prompt but a dialog screen

with a Help softkey and a Back softkey will be disp layed.

• DETAILS will give the user the above detailed Help screen describing the memory required to be able to download the MIDlet.

• The Help dialog will include a "More" right softkey label (for those products in which not all the help data can be displayed on a single screen). This label should disappear when the user has scrolled to the bottom of the dialog.

• BACK from this message will take the user back to the browser page from which the user selected the MIDlet to download.

17 Download MIDlet Through Browser

Figure 8 Mot-Data-Space & Mot-Program-Space attributes are not present or are incorretct

Rules:

• If Mot-Data-Space-Requirements and Mot-P r ogram-Space-Requirements JAD attributes are not present in the JAD file, the handset can not determine how much memory to free and will display the above help dialog.

• All rules stated in the previous figure must also be followed for the above stated prompt.

Memory Full during installation process.

Once the MIDlet is successfully downloaded, the installation process begins. During the installation of the MIDlet, the phone may determine there is insufficient memory to complete the installation. This error can occur whether the Mot-Data-Space-Requirements and Mot-Program-Space-Requirements JAD attrib utes are present or not. The following message and Figure 9 must be displayed:

17 Download MIDlet Through Browser

Figure 9 Memory Full help message during installation process

Rules:

• The installation process is canceled when this error condition occurs.

• The Memory Full error will no longer be a transient prompt but a dialog screen

with a Help softkey and a Back softkey will be disp layed.

• DETAILS will give the user the above Help screen explaining that additional memory is required to be able to install the MIDlet.

• BACK from this message will take the user back to the browser page from which the user selected the MIDlet to download.

Application version already exists:

Compares the version number of the applica tion with that already present on the handset. If the versions are the same, the following message is displayed. The error occurred can be queried by selecting DETAILS.

17 Download MIDlet Through Browser

Figure 10 Same Version of Application already exists on the handset

Rules:

• Handset checks for MIDlet-Name, MIDlet-vendor, and version number. If they are the same, a dialog “Application Already Exists” is displayed.

• To know more about this error, select the DETAILS softkey.

• Handset displays the new version of the application, as well as the existing

application.

Newer Application Version Exists:

If the application version on the handset is newer than the downloaded version of application, the following message is displayed. The error occurred can be queried by selecting DETAILS.

17 Download MIDlet Through Browser

Figure 11 Latest (Newer) Version of Application exists

Rules:

• If the latest or newer version of application is already present on the handset, it cannot be downloaded

18 Lightweight Windowing Toolkit

Lightweight Windowing Toolkit

LWT integrate with the LCDUI API within the MIDP and enhance the capabilities to include a component-level API through which developers can control the contents and layout of their screens. These components are graphical user interface elements such as buttons, check boxes, text fields, images, etc. LWT also allow d eve lopers to create new imaginative components or change the look and feel of existing components.

Those MIDlets taking advantage of the added capabilities of LWT will only run on those handsets that incorporate the LWT LOC.

LWT extends the MIDP class hierarchy by extending the LC DUI Canvas class. The ComponentScreen is a subclass of Canvas, which means it can be easily added to a MIDP implementation and minimize dep endencies and maintenance overhead. Th is also allows standard MIDlets to mix both MIDP screens and LWT screens i n th eir MIDlets.

LWT is designed to use MIDP low-level graphics routines exclusively, which adds to the ease of implementation. Although no device-specific modifications are required, an LWT implementation may be tailored to match the rest of the device’s user interface. The text components in LWT may be integrated with the device’s data entry mechanisms, such as handwriting recognition or predictive keypa d input.

LWT implementation requires the handset to be MIDP compliant and have approximately 30KB of flash memory.

LWT does not expose any additional native interfaces and only relies on mechanisms specified by MIDP 1.0. LWT can be safely exposed to untrusted MIDlets.

Once LWT is implemented, the LWT TCK must be compl eted and pass successfully.

19 UDP Support

UDP Support

This functionality is to enable J2ME applicati ons access to Generic UDP Transport Service.

• This enhancement allows for J2ME applications to utilize the UDP header compression format for data applications over IP.

• The API should follow the guidelines of the User Datagr am Protocol standard, IETF RFC 768, J. Postel, August 28, 1981.

• This functionality should be available for both CSD and GPR S connections.

20 Shared JAD URLs

Overview

Actually, users are able to download J2ME applications. The first step is to download the JAD file and, after a confirmation, the site is launched to downl oad the application. If they want to forward the JAD link to someone else, it’s imp ossible.

The Share JAD URLs is a feature that resolves the prior problem, it allows users to share their downloaded J2ME application URLs with others. When J2ME applications are downloaded, the browser shall provide the Java Application Manager (JAM) with the JAD URL address. When J2ME applications are downloaded via PC or MMS, a new JAD attribute shall specify the JAD URL address.

Shared JAD URLs

Tell-A-Friend Option

When entering the J2ME application context-sensitiv e menu, a Tell-A-Friend option will be provided. Upon selecting this option, the standard SMS messaging form will appear. The link to the URL where the application JAD file can be found and its name will be prepopulated into the message body. This allows the user to send messages to friends, telling them where to download the application.

Upon receipt of a Tell-A-Friend message, a Motorol a handset user should be able to use the browser’s GOTO functionality. Selecting GOTO will cause the download of JAD to occur. The remaining download steps will occur as normal.

20 Shared JAD URLs

Accessing Tell-A-Friend from SMM

The MIDlet Manager menu lets the user perf orm certain actions on the selected MIDlet suites. The Table 18 describes the various ac tions that can be performed on a suite.

Action Description

Tell-A-Friend Populates a message with the link to the application’s JAD URL

inserted into the message body, following messag ing standard behavior for pre-populated messages.

Details Displays the information about the suite. This includes MIDlet suite

name, vendor, version, number of apps in suite, flash us age, both data and program space of the application.

Delete

Lets the user delete a suite. A confirmation is requested before the application is deleted.

Table 18 Performed on a suite

Rules:

• If the application does not have an associated JAD URL, the Tell-A-Friend option will not appear in the context-sens itive menu.

• If the URL plus the application name size exceed the maximum size allowed for an SMS message, the following rules shall be applied, in this order, to truncate the link:

o Remove application name from link, (i.e.: “GP

http://www.mot.com/games/gp.jad

” shall be truncated to

“http://www.mot.com/games/gp.jad”).

o Remove path to the JAD fi le, keeping only server’s URL and application

name. (i.e.: “GP http://www.mot.com/games/gp.jad” shall be truncated to “GP http:// www.mot.com”).

• If server’s URL cannot be kept, Tell-A-Friend option shall be disabled.

• J2ME applications downloaded through a PC can specify JAD URL using

new JAD attribute Mot-Midlet-URL. If this JAD attribute is pr esent, JAM will use the JAD URL specified by this attribute to ena ble the Tell-A-Friend option.

• J2ME applications downloaded through MMS (when this functionality is available on the phone) can specify JAD URL using new JAD attribute MotMidlet-URL. If this JAD attribute is present, JAM will use the JAD URL specified by this attribute to enable Tell-AFriend option.

•

The Figure 12 illustrates the MIDlet Manager and the context-sensitive menus:

20 Shared JAD URLs

Figure 12 the MIDlet Manager and the context-sensitive menus

Downloading through Browser

Rules:

• When downloading a J2ME application, the browser shall provide JAM with the URL of the JAD file. This URL shall override the URL specified by MotMidlet-URL attribute in case of conflict.

Downloading from PC (Via serial/USB)

Rules:

• When downloading an application, JAM sh all use the JAD attribute Mot- Midlet-URL if present to get the JAD URL.

20 Shared JAD URLs

Downloading through MMS

Rules:

• When downloading an application via MMS, JAM shall use the JAD attribute Mot-Midlet- URL if present to get the JAD URL.

21 Get URL from Flex API

Overview

This feature allows accessing URL stored in FLEX by a J ava application. Carriers flex the URL, which is used for content download, into the phone just like any invisible net URL. So, this feature would allow Java application s to read and display the URL stored in flex for users that would like to download new levels of Game. The existing functionality allows current Java Applications use a dedicated URL to inform users about the location which a new level of game can be downloaded. This new functionality allows carriers to specify the URL for content download.

Get URL from Flex API

Flexible URL for downloading functionality

The URL is flexed using RadioComm or using OTA provisioning. The URL will follow the rules mentioned below:

• All URLs used shall follow the guidelines o utlined in RFC1738: Uniform Resource Locators (URL). Refer to http://www.w3.org/addressing/rfc1738.txt for more information.

• URLs are limited to 128 characters.

This feature enables Java applications to read the URL stored at the predefined location in flex table. The default URL may be “http://www.hellomoto.com”.

The Java Application will be able to access the flexed URL by System.getProperty method. The key for accessing the URL is “com.mot.carri er.URL”. The method System.getProperty will return NULL if no URL is flexed.

21 Get URL from Flex API

Security Policy

Only trusted applications will be granted permission to access this property.

22 Multiple Key Press

Multi-button press support enhances the gaming experience for the user. Multi-button press support gives the user the ability to press two (2) keys simultaneously and the corresponding actions of both keys will occur simultaneously. An example of this action would be the following:

Multiple Key Press

• If Left + Fire were pressed at the same time, the Java object (e.g C anvas) will receive Left Pressed + Fire Pressed. In the same way, when the 2 keys are released, Java object (e.g. Canvas) will recei ve Left Released + Fire Released.

The following sets of keys will support multi-button press support on the Motorola C381p handset. Multi-button press within each set will be supported, while multi-button press across these sets or with other keys will not be supported. Set 1 – Nav (Up), Nav (Down), Nav (Right, Nav (Left) Refer to the Table 19 for gaming and keypad feature/cl ass support for MIDP 2.0:

Feature/Class Implementation

lcdui.game package Supported setBacklight as defined in javax.microedition.lcdui.Display Supported setVibrator as defined in javax.microedition.lcdui.Display Supported

All constructors and inherited classes for the IllegalStateException in java.lang All constructors, methods, and inherited classes for the Timer class in java.util All the constructors, methods, and inherited classes for the TimerTask class in java.util All fields, constructors, methods, inherited fields and inherited methods for the GameCanvas class in javax.microe dition.lcdui.game Map the UP_PRESSED field in

javax.microedition.lcdui.game.GameCanvas to the top position of the

Supported

22 Multiple Key Press

key. Map the DOWN_PRESSED field in javax.microedition.lcdui.GameCanvas to the bottom position of the key Map the LEFT_PRESSED field in javax.microedition.lcdui.GameCanvas to the left position of the key Map the RIGHT_PRESSED field in javax.microedition.lcdui.GameCanvas to the right position of the key All methods and inherited methods for the Layer class in javax.microedition.lcdui.game All constructors, methods, and inherited methods for the LayerManager class in javax.microedition.lc du i.game. La yer All fields, constructors, methods, and inherited methods for the Sprite Class in javax.microedition.lcdui.game Sprite Frame height will not be allowed to exceed the height of the view window in javax.microedition.lcdui.Layer Sprite frame width will not be allowed to exceed the width view of the view window in javax.microedition.lcdui.Layer Sprite recommended size All constructors, methods, and inherited methods for the Ti ledLayer class in javax.microedition.lcdui.game

Supported

Supported Any, limited by heap size

only

Any, limited by heap size only

16*16 or 32*32 Supported

MIDlet Queries to keypad hardware Supported Alpha Blending Transparency only

Table 19 Gaming and keypad feature/class

23 iTAP

Intelligent Keypad Text Entry API

When users are using features such as SMS (short message service), or “Text Messaging”, they can opt for a predictive text entry method from the handset. The J2ME environment has the ability to use SMS in its API listing. The us e of a predictive entry method is a compelling feature to the MIDlet.

iTAP

This API will enable a developer to access iTAP, Numeric, Symbol and Browse text entry methods. With previous J2ME products, the only metho d available was the standard use of TAP.

Predictive text entry allows a user to simply type in the letters of a word using only one key press per letter, as apposed to the TAP method that can require as many as four or more key presses. The use of the iTAP method can greatl y decrease text-entry time. Its use extends beyond SMS text messaging, but into other functions such as phonebook entries.

The following J2ME text input components will support iTAP.

 javax.microedition.lcdui.TextBox

The TextBox class is a Screen that allows the user to edit and enter text.

 javax.microedition.lcdui.TextField

A TextField is an editable text component that will be placed into a Form. It is given a piece of text that is used as the initial value.

Refer to the Table 20 for iTAP feature/class support for MIDP 2.0:

Feature/Class

Predictive text capability will be offered when the constraint is set to ANY User will be able to change the text input method during the input process when the constraint is set to

ANY (if predictive text is available) Multi-tap input will be offered when the constraint on the text input is s et to EMAILADDR, PASSWORD, or

URL

Table 20 ITAP feature/class

24 LCDUI

LCDUI

LCDUI API

The Table 21 lists the specific interfaces supported by Motorola implementation:

Interface Description

Choice Choice defines an API for user interface components implementing

selection from a predefined number of choices.

CommandListener This interface is used by applications which need to receive high-level

events from implementation

ItemCommandListener A listener type for receiving notification of commands that have been

invoked on Item

ItemStateListener This interface is used by applications which need to receive events that

indicate changes in the internal state of the interactive items within a Form

Table 21 Interfaces supported by Motorola implementation

The Table 22 lists the specific classes supported by Motorola implementation:

Classes Description

Alert An alert is a screen that shows data to the user and waits for a certain

period of time before proceeding to the next Displayable. AlertType The AlertType provides an indication of the nature of alerts. Canvas The Canvas class is a base class for writing applications that need to

handle low-level events and to issue gra phics calls for drawing to the

display. ChoiceGroup A ChoiceGroup is a group of selectable elements intended to be

placed within a Form.

screen.

231

objects

286

Command The Command class is a construct that encapsulates the semanti c

CustomItem A CustemItem is customizable by sub classing to introduce new

information of an action.

24 LCDUI

visual and interactive elements into Forms. DateField A DateField is an editable component for presenting date and time

(calendar) information that will be placed into a Form. Display Display represents the manager of the display an d input devices of

the system. Displayable An object that has the capability of being placed on the display. Font The Font class represents fonts and font metrics. Form A Form is a Screen that contains an arbitrary mixture of items:

images, read-only text fields, editable text fields, editable date fields,

gauges, choice groups, and custom items. Gauge Implements a graphical display, such as a bar graph of an integer value. Graphics Provides simple 2D geometric rendering capability. Image The Image class is used to hold graphical image data. ImageItem An item that can contain an image. Item A superclass for components that car be added to a Form

231

. List A Screen containing a list of choices. Screen The common superclass of all high-level user interface classes. Spacer A blank, non-interactive item that has a settable minimum size. StringItem An item that can contain a string. TextBox The TextBox class is a Screen that allows the user to enter and edit

data.

TextField A TextField is an editable text component that will be place d into a

Form.

Ticker Implements a “ticker-tape”, a piece of text that runs continuously across

the display.

Table 22 Specific classes supported by Motorola implementation

Refer to Table 23 for LCDUI feature/class support for MIDP 2.0:

Feature/Class Implementation

All fields, constructors, methods, and inherited method s for the Alert

Supported

class in the javax.microedition.lcdui package All fields, constructors, methods, and inherited methods for the

AlertType class in the javax.microedition.lcdui package Will provide and play an audible sound when the play Sound() method

is called with an AlertType of ALARM Will provide and play an audible sound when the play Sound() method

is called with an AlertType of ERROR

Supported

24 LCDUI

Will provide and play an audible sound when the play Sound() method is called with an AlertType of WARNING

Will provide and play an audible sound when the play Sound() method is called with an AlertType of CONFIRMATION

Will provide and play an audible sound when the play Sound() method is called with an AlertType of INFO

All fields, constructors, methods, and inherited methods for the Canvas Class in the javax.microedition.lcdui. package

Status indicators out of full-screen mode will cons ume a portion of the display

UP field in javax.microedition.lcdui.Canvas to the top position of the key

DOWN field in javax.microedition.lcdui.Canvas to the bottom position of the key

LEFT field in javax.microedition.lcdui.Canvas to the left position of the key

RIGHT field in javax.microedition.lcdui.Canvas to the right p ositi on of the key

All fields and methods for the Choice interfac e in the javax.microedition.lcdui package

Supported

Truncate an image in a Choice object if it exceeds the capacity of the

Supported

device display Truncation of very long elements will not occur in a Choice object Text in forms is wrapped and

scrolled

Will display a portion of long elements to display and provide a means

Supported

for the user to view all of the parts of the element Truncation in elements w/line breaks will not occur in a Choice object Supported Portion of line break elements to display and provide a means for the

Supported

user to view all parts of the element All constructors, methods, inherited fields, and inherited methods for

Supported

the ChoiceGroup class in the javax.microedition.lcdui package All constructors, methods, and inherited methods for the Command

Supported

class in the javax.microedition.lcdui package All methods for the CommandListener interface in the

Supported

javax.microedition.lcdui package All fields, constructors, methods, inherited fields, and inherited

Supported methods for the CustomItem abstract class in the javax.microedition.lcdui package

All fields, constructors, methods, inherited fields, and inherited

Supported methods for the DateField class in the javax.microedition.lcdui

24 LCDUI

package All fields, methods, and inherited methods for the D isplay class in the

Supported javax.microedition.lcdui package

Maximum colors for the numColors() method in javax.microedition.lcdui.Display

All methods and inherited methods for the Displayable class in the

64K colors

supported

Supported javax.microedition.lcdui package

Adding commands to soft buttons before placing it i n a menu for the

Supported addCommand() method in javax.microedition.lcdui.Displayable

All fields, methods, and inherited methods for the Fo nt class in the

Supported javax.microedition.lcdui package

All constructors, methods, and inherited methods for the FORM class

Supported in the javax.microedition.lcdui package

All fields, constructors, methods, inherited fields, and inherited

Supported methods for the Gauge class in the javax.microedition.lcdui package

All fields, methods, and inherited methods for the Graphics class in the

Supported javax.microedition.lcdui package

DOTTED stroke style Supported SOLID stroke style Supported All methods and inherited methods for the Image class in the

Supported javax.microedition.lcdui package

All fields, constructors, methods, inherited fields, and inherited

Supported methods for the ImageItem class in the javax.microedition.lcdui package

All fields, methods, and inherited methods for the Item cl ass in the

Supported javax.microedition.lcdui package

Label field Supported All methods for the ItemCommandListener interface in the

Supported javax.microedition.lcdui package

All methods ItemStateListener interface in the javax.microedition.lcdui

Supported package

All fields, constructors, methods, inherited fields, and inherited

Supported methods for the List class in the javax.microedition.lcdui package

All constructors, methods, inherited fields, and inherited methods for

Supported the Spacer class in the javax.microedition.lcdui package

All constructors, methods, and inherited methods for the StringItem

Supported class in the javax.microedition.lcdui package

All constructors, methods, and inherited methods for the TextBox class

Supported in the javax.microedition.lcdui package

24 LCDUI

All fields, constructors, methods, inherited fields, and inherited

Supported methods for the TextField class in the javax.microedition.lcdui package

Visual indication with UNEDITABLE field set will be provided Supported All constructors, methods, and inherited methods for the Ti cker class

Supported in the javax.microedition.lcdui package

OEM Lights API providing control to the lights present on the handset Supported, Fun Lights API All fields, constructors, methods, inherited fields, and inherited

Supported methods for the TextField class in the havax.microedition.lcdui package

Table 23 LCDUI feature/class

25 Auto Launch of Midlets

The Java framework on the device must provide a mec ha nism to automatically launch midlets based on specific message. The message may be generated by several clients including a push message coming from the network. Once the KVM received the message, it takes the appropriate action of launc hing the midlet the message is intended for.

Auto Launch of Midlets

Scenarios involved in launching midlet

There are three possible scenarios when KVM has to pass the message to a midlet.

• The midlet is currently actively running: In this case, the KVM simply passes the message to the midlet. The client originating the request is notified that the midlet is already running.

• No midlets are active: In this case, the KVM must launch the midlet the message is intended for. Upon successfully starting, KVM should inform the client that the launch has been successful.

• The KVM is currently busy either running another midlet or installing another midlet. Since the KVM will support only one midlet at a time, the client originating the message should be notified that KVM is currently running application. The client then has the option of having KVM terminate the current midlet and launching another one.

NOTE: If the installation is terminated, appropriate cleanup actions should be performed. The midlets that were being installed should be left at an uninstalled state.
