intelligence everywhere™
AXU4100
Power is the name of the game for the Motorola AX Series™. The extra power helps to
carry the radio signal through and around physical obstructions such as adjacent buildings,
campus settings and multi-story buildings. At the touch of a button, the AX Series provides
one-to-one or group communication, you’ll be able to respond more quickly to daily workplace
issues, track your projects more efficiently, and keep up with your workforce. Additionally, every
AX Series radio offers a variety of useful features designed to keep even the busiest workforce
operating effectively.
CONSTRUCTIONCONSTRUCTIONCONSTRUCTION
As the construction industry becomes increasingly competitive, Motorola AX Series two-way
radios provide an ideal way to improve operations while controlling costs. Designed for
heavy-duty, everyday industrial use, the AX Series is perfectly suited for the construction and
contractor industries. Operating on FCC frequencies reserved exclusively for business use, these
powerful two-way radios help construction firms keep operations on schedule, coordinate
deliveries and work crews, and enhance security.
™
AAX X SSEERRIIEESSAX SERIES
Motorola Business Two-Way Radios
The power to be at your best!
Recommended for:
• Owners
• Foremen
• Project Managers
• Electricians
• Roofers
• HVAC Contractors
• Site Managers
• Plumbers
• Engineers
• General Contractors
BUSINESS BENEFITS
• Improve response time
• Enhance safety and security
• Reduce operational costs
• Empower employees to accomplish more in less time
• Increase overall service and satisfaction
• Save money monthly over alternative technologies
DESIGN DETAILS
• Variable power settings for longer battery life or greater range
• Designed to meet Military 810 C, D, E specifications
• 4 Front programmable buttons for quick access to features
• Advanced voice activation capability (optional accessory required)
• Cloning capabilities (via software)
• Dual pin accessory connection
Ideal for the Construction Industry
intelligence everywhere™
™
AAX X SSEERRIIEESSAX SERIES
MOTOROLA
MEANS BUSINESS
With 75 years of innovation
and engineering expertise,
it’s no wonder that Motorola
is the world leader in providing
businesses with on-site,
two-way radio communication
solutions. In fact, Motorola
recently received the
Malcolm Baldrige
Award for Quality.
MALCOLM
BALDRIGE
AWARD
FOR QUALITY
Motorola’s Commercial,
Government and
Industrial Solutions
Sector (CGISS) is a
recipient of the
prestigious 2002 Malcolm
Baldrige National Quality
Award, in recognition of its
commitment to performance
excellence and quality
achievement.
Motorola Business Two-Way Radios
PRODUCT DETAILS
Power (Low / High)................ 2W / 4W
Coverage*.................................. 300,000 sq.ft. or 30 floors
Channels....................................... Up to 10 channels
Codes............................................... 121 (83 digital, 38 analog)
Channel spacing.............................. 12.5 kHz / 25 kHz
Frequency range ...............................435 MHz – 480 MHz
Military specifications ....................... 810 C, D, E
Programmability................................... 4 front programmable buttons
.................................................................. for quick access to features such
.................................................................. as priority scan, power select,
................................................................... keypad lock and more
Battery life (based on 5/5/90 cycle)
High power (4W) .....................................Up to 8 hours
Low power (2W)...................................... Up to 11 hours
Battery type .............................................7.2V NiMH battery
Dimensions
(with battery, no antenna).................... 4.5”H x 2.2”W x 1.81”D
Weight (with battery)............................ 11.5 oz.
Advanced voice activation (VOX) .....Optional accessory required
Scan...................................................... Priority scan
Cloning capabilities.......................... Via software only
Charging capabilities ..................... Drop-in and plug-in capable
Display............................................ 8 character alphanumeric
Call tones .....................................3 plus OFF
Accessory connection............ Dual pin
LED
Indicator
On/Off
Volume
Knob
LCD Screen
Push-To-Talk
Button
Accessory/
Programming
Port
Toggle
Button
4 Front
Programmable
Buttons
Microphone
* Coverage will vary based on terrain and conditions
Speaker
COMPLEMENT YOUR AX SERIES RADIOS WITH OTHER MOTOROLA TWO-WAY BUSINESS PRODUCTS
RADIO COMPATIBILITY
The AXU4100 Two-Way Radio is compatible with
other two-way radios operating on the same UHF
business frequencies (FCC license required). Here
are other Motorola Business Two-Way Radio models
that are compatible with the AXU4100.
All UHF XTN
™
Series
Radios
All CLS
Series™ Radios
To enhance productivity even further without
increasing staff size, you can team the AXU4100
with the Motorola MOC4600i Wireless Message
Alert device. The MOC4600i
transmits a customizable voice
message to your two-way
radio-equipped staff.
MOC4600i
™
