IP3093-L

Communicator mini

Quick Start Guide

Copyright © 2013, All Rights Reserved.

Ver: R04 D/C: 102-1210

Page 2

MOCET IP3093-L Communicator mini Quick St art Guide

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:

 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

 Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.

CE Declaration of Conformity

This equipment complies with the requirements relating to electromagnetic compatibility, EN55022
class B for ITE and EN 50082-1. This meets the essential protection requirements of the European
Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to
electromagnetic compatibility.

C-Tick Declaration of Conformity

This equipment passed tests performed according to AS/NZS CISPR 22:2009/A1:2010 Class B at
Sporton International Inc. Lab. Certificate No. AI381226.

Environment

The device you have purchased, as well as any used batteries must not be disposed of with
household waste. You should return these to your distributor if they are to replaced or dispose of
them in an approved recycling center.

Trademarks

iPad™, iPad mini™, iPhone™, iDevice™, iPod™, iTunes™, iOS™, Safari™ and Facetime™ are
registered trademarks of Apple Inc., USA. Android is a trademark of Google Inc., USA. Skype™ and
Lync2013™ are registered trademarks of Microsoft. Viber, Line and others as well as Unified
Communications (UC) apps, like CounterPath™ Bria™, Cisco™ Jabber™, Avaya™ Flare™,
Radvision™ Scopia™, Polycom™ RealPresenc™ or others are registered trademarks of their
respective owners.

WARNING! ▼

1. Read these installation instructions carefully before connecting the device to its power.

2. To reduce the risk of electric shock, do not remove the cover from the device or attempt to

!

Page 3

MOCET IP3093-L Communicator mini Quick St art Guide

dismantle it. Opening or removing covers may expose you to dangerous voltage levels.
Equally, incorrect reassembly could cause electric shock on re-use of the appliance.

3. Do not expose the device to Fire, direct sunlight or excessive heat.

4. Do not expose the device to rain or moisture and do not allow it to come into contact with

water.

5. Do not install the device in an environment likely to present a THREAT OF IMPACT.

6. You may clean the device using a fine damp cloth. Never use solvents (such as

trichloroethylene or acetone), which may damage the device’s plastic surface. Never spray
the device with any cleaning product whatsoever.

7. The device is designed to work in temperatures from 5

o

C to 40oC.

8. The device must be installed at least 1 meter from radio frequency equipment, such as TVs,

radios, hi-fi or video equipment (which radiate electromagnetic fields).

9. Do not attempt to upgrade device in an unstable power environment. This could cause

unexpected issues.

10. Do not work on the system or connect or disconnect cables during lightning storms.

11. Children do not recognize the risks of electrical appliances. Therefore use or keep the device

only under supervision of adults or out of the reach from children.

12. No repair can be performed by the end user, if you experience trouble with this equipment,

for repair or warranty information, please contact your supplier.

Page 4

MOCET IP3093-L Communicator mini Quick St art Guide

Introduction

The MOCET™ Communicator mini™ is an innovative audio accessory that enables you to
use your Apple™ iPad mini, or iPhone 5, 5s or 5c as a desktop phone with popular Social
Networking apps such as FaceTime, Skype, Viber, Line and others. Additionally, Unified
Communications (UC) apps, such as CounterPath Bria iPad Edition, Cisco Jabber for iOS,
Avaya Flare, Radvision Scopia, Polycom RealPresence, Microsoft Lync2013, and others,
available from the Apple™ App Store™

The high definition audio-enabled handset and speakerphone on the Communicator mini
dramatically enhances your communications and ensures privacy and comfort. For a large
office or small to medium sized conference room, there is even an optional desktop
microphone set available to ensure all participants in the room can be heard clearly on the
call. For a more enjoyable multimedia experience, there is an optional external speaker to
play high quality stereo audio when listening to music or watching movies or YouTube
videos.

The Communicator mini stand is adjustable between 0º and 125º, allowing you to find the
most convenient viewing angle for watching movies or participating in video conferencing
calls at your desk. The Communicator mini has a built-in fast charger so you can play and
work all day, and when you leave your iPad mini or iPhone will be fully charged and ready
to go. Using the built-in USB host port, you can even charge a second phone or mobile
device.

Because it pairs using Bluetooth, Android, Windows Mobile and other Bluetooth-enabled
devices can also benefit from the Communicator mini’s HD handset and speakerphone for
better call quality and comfort as well.

What’s In the Package?
