M-SERIES CONTRACTOR GUIDE
INTRODUCING MXZ-C H2i
®
MITSUBISHI ELECTRIC IS A WORLD
LEADER IN PRODUCTS THAT HELP
PEOPLE MAKE COMFORT PERSONAL
When it comes to providing personalized comfort in every room of every building, we are here to help.
No other company is as committed to creating environmentally friendly and affordable technology
that’s ideal for today’s home and work environments no matter the size or shape. With over 30 years
of industry leadership, we are proud to be America’s #1 selling brand of ductless technology.
QUALITY
Mitsubishi Electric is consistently recognized by HVAC contractors as the #1 preferred brand with the
highest quality rating among manufacturers. Our products provide extraordinary service life extending
years beyond the norm.
PERFORMANCE
We deliver a complete range of compact and powerful cooling and heating products that are also
intelligent, energy-efficient and quiet.
TRAINING
We provide comprehensive product and applications instruction through our regional training centers
across the United States.
SUPPORT
We offer national TV and digital campaigns, co-op and advertising assistance, social media exposure
and training, meSync apps for iPhone and iPad and the most experienced sales, engineering and
service professionals.
GROWTH
With nearly 20 years of consistent double-digit percentage growth, we continue to lead the market’s
growth acceleration. Our products and services provide opportunities for distributors and contractors
to enhance and grow their businesses.
TABLE OF CONTENTS
PRODUCT OVERVIEW ............................................................................................................................................... 4
PRODUC T F E AT URES
H2i® Technology ................................................................................................................................................... 5
Energy Ecient ....................................................................................................................................................6
ENERGY STAR® Systems .................................................................................................................................... 7
INVERTER Technology ....................................................................................................................................... 8
Healthier and Cleaner Air ..................................................................................................................................9
Hand-held Wireless Comfort Control ...........................................................................................................10
kumo cloud™ and i-see Sensor™ 3D ............................................................................................................... 11
Wall-mounted Wireless and Wireless Control ............................................................................................12
BEST PRACTICES ...................................................................................................................................................... 17
MULTI-ZONE PRODUCTS ....................................................................................................................................... 19
SINGLE-ZONE PRODUCTS .....................................................................................................................................23
M-SERIES ACCESSORIES .......................................................................................................................................25
M-SERIES PRODUCT SPECIFICATIONS ...............................................................................................................31
ADDITIONAL M-SERIES INFORMATION .............................................................................................................52
PRODUCT OVERVIEW
Horizontal-ductedFloor-mounted Ceiling-recessedWall-mounted Outdoor UnitMulti Position
Features Benefits
INVERTER-DRIVEN COMPRESSORS
EASY INSTALLATION
COMPLETE ZONE CONTROL
PERSONAL COMFORT CONTROL
CLEANER AIR WITH WASHABLE,
ANTI-ALLERGEN FILTERS
HYPER-HEATING INVERTER® (H2I®) HEAT PUMPS
ULTIMATE ENERGY EFFICIENCY
Maximizes energy savings by using only the energy needed to
perfectly cool or heat an area
Installs quickly and easily, without the need for major
construction and remodeling
Realizes maximum control and energy efficiency by cooling
and heating only those spaces in use
Complete comfort control of temperature, fan speed, and air
direction in each room or zone
Improves air quality and saves money
Provides instant warmth even in extreme climates
(down to -13° F)
With higher SEER and HSPF ratings
4 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
HEAT AND LOTS OF IT
*
Includes correction for defrost.
NOTE: Low ambient temperature conditions may
require base pan heater (MSZ-GE and MSZ-FE 1:1 systems)
0
20
40
60
80
100
120
-13 -4 0 5 10 17 25 30 35 40 47
Outdoor Temperature Degrees FWB
% Heating Capacity
MUZ-FH12NA H2i HEATING CAPACITY
AT LOW TEMPERATURES*
*
Includes correction for defrost.
NOTE: Low ambient temperature conditions may
require base pan heater (MSZ-GE and MSZ-FE 1:1 systems)
0
20
40
60
80
100
120
-13 -4 0 5 10 17 25 30 35 40 47
Outdoor Temperature Degrees FWB
% Heating Capacity
MUZ-FH12NA H2i HEATING CAPACITY
AT LOW TEMPERATURES*
*
Includes correction for defrost.
NOTE: Low ambient temperature conditions may
require base pan heater (MSZ-GE and MSZ-FE 1:1 systems)
0
20
40
60
80
100
120
-13 -4 0 5 10 17 25 30 35 40 47
Outdoor Temperature Degrees FWB
% Heating Capacity
STANDARD HEAT PUMP HEATING
CAPACITY AT LOW TEMPERATURES*
*
Includes correction for defrost.
NOTE: Low ambient temperature conditions may
require base pan heater (MSZ-GE and MSZ-FE 1:1 systems)
0
20
40
60
80
100
120
-13 -4 0 5 10 17 25 30 35 40 47
Outdoor Temperature Degrees FWB
MXZ-C-NAHZ
Standard Heat Pump
% Heating Capacity
100%
93%
76%
H2i MXZ HEATING CAPACITY
AT LOW TEMPERATURES*
78%
Mitsubishi Electric Hyper-Heating INVERTER® systems feature the most advanced heat pump
technology for delivering exceptional heating performance. Single zone and multi-zone systems
give you year-round comfort control of one room to every room of the home.
H2i MXZ HEATING CAPACITY
AT LOW TEMPERATURES*
120
93%
100
80
60
76%
40
20
% Heating Capacity
0
-13 -4 0 5 10 17 25 30 35 40 47
Includes correction for defrost.
*
NOTE: Low ambient temperature conditions may
require base pan heater (MSZ-GE and MSZ-FE 1:1 systems)
100%
78%
Outdoor Temperature Degrees FWB
HEATING
Even when it's -13° F
outdoor ambient,
producing up to 100%
heating capacity
at 5° F.
MXZ-C-NAHZ
Standard Heat Pump
YEAR-ROUND
COMFORT
in extreme climates
without the need for
energy-consuming
indoor supplemental
heating devices.
MUZ-FH H2i HEATING CAPACITY
AT LOW TEMPERATURES*
120
100
78%
80
60
60%
40
20
% Heating Capacity
0
-13 -4 0 5 10 17 25 30 35 40 47
Outdoor Temperature Degrees FWB
Includes correction for defrost.
*
NOTE: Low ambient temperature conditions may
require base pan heater (MSZ-GE and MSZ-FE 1:1 systems)
100%
MUZ-FH
Standard Heat Pump
HOT-START
TECHNOLOGY
provides warmth from
the start, reducing drafts.
MINIMAL
MAINTENANCE
thanks to easily accessible
filters, little or no ductwork
to clean, and simple wiring
between the indoor and
outdoor units.
QUIETER THAN A HUMAN WHISPER
Do you hear that? No? Mitsubishi Electric systems operate
at low sound levels. Our indoor units produce decibels barely
at a whisper level. Compare to other common sounds:
Ambulance siren
Circular saw
Vacuum cleaner
Normal conversation
Whisper
Our indoor units
Did you hear that? We hope you did.
Source: National Institute for Occupational Safety and Health
*Smallest to largest capacity indoor unit at low speed
30 decibels
120 decibels
110 decibels
80 decibels
60 decibels
19-34 decibels*
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 5
ENERGY EFFICIENT AND ENVIRONMENTALLY FRIENDLY
M-Series systems utilize green technologies, and are much more ecient. Homeowners
never have to sacrifice comfort over worries about high-energy costs.
▶ INVERTER-driven compressor technology results in substantial energy and utility savings
for homeowners.
▶ Zone control for improved comfort and decreased energy usage.
®
▶ Many ENERGY STAR
▶ SEER ratings as high as 33.1 – dramatically better than conventional systems.
▶ Local and state utility rebates and incentive opportunities.
▶ Environmentally friendly R410A refrigerant with zero Ozone Depletion Potential (ODP).
▶ 83% of system components are recyclable.
▶ Washable filters made from natural materials.
certified systems.
Visit dsireusa.org for information on available local rebate
opportunities from state or utility companies.
Savings Opportunities
Mitsubishi Electric split-zoning, cooling-only and heat pump systems are so energy efficient
that a majority of our INVERTER-driven systems have received ENERGY STAR® certification.
This can mean big savings. Add in the federal tax credit and local government and utility
rebates, and you have an opportunity to enjoy comfort at substantial savings.
For details on qualifying systems, go to www.mitsubishicomfort.com/taxcredit, or visit
www.dsireusa.org for information on available local rebate opportunities from state
governments or utility companies.
6 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
ENERGY STAR® CERTIFIED SYSTEMS
RESIDENTIAL AIR CONDITIONER
AHRI Reference # Outdoor Indoor EER 95 F SEER HSPF
8715778
87157 79
8715780
8715781
8715782
AHRI Reference #
8797130
7002062
7002063
7002444 MUZ-FH15NA MS Z-FH15NA 12.50 22.00 12.00
8797133
8856678
8715783
8715784
8715785
8715786 MU Z-GL24NA- U1 MSZ-GL24NA-U1 12.50 20.50 10.00
3837470
3837467
3837469
4415252 SU Z-K A12NA SLZ-K A12NA 12.00 15.40 9.60
3837466
44150 24
7505787
7434482
7434477
74519 69
7432 92 7
7432 944
74517 9 4
8063926
3577580
3589025
3885922
389618 0
3949963
7434486
MUY-GL09NA-U1 MSY-GL09NA-U1 15.40 24.60 N/A
MU Y- G L12NA-U 1 MSY-GL12NA-U1 13.00 2 3 .10 N/A
MU Y- G L15NA-U 1 MSY-GL15NA-U1 13.00 21.60 N/A
MU Y- G L18 N A-U1 MSY-GL18NA-U1 13.40 20.50 N/A
MU Y-GL 24 NA- U1 MSY-GL24NA-U1 12.50 20.50 N/A
RESIDENTIAL HEAT PUMP
Outdoor Indoor EER 95 F
MUZ-FH06NA MSZ-FH06NA 19.00 3 3.10 13.50
MUZ-FH09NA MSZ-FH09NA 16.10 30.50 13.50
MUZ-FH12NA MS Z-FH12NA 13.80 26 .10 12. 50
MUZ-FH18NA2 MS Z-FH18 N A 2 12.50 21. 00 12.0 0
MUZ-GL09NA-U8 MSZ-GL09NA-U1 15.4 0 24.60 12.8 0
MU Z-GL12N A-U1 MSZ-GL12NA-U1 13.00 2 3.10 12.50
MU Z-GL15NA- U1 MSZ-GL15NA-U1 13.0 0 21.60 11.70
MU Z-GL18NA- U1 MSZ-GL18NA-U1 13.4 0 20.50 11.20
SU Z-K A18 N A SE Z- KD18N A 12.50 17.5 0 10.0 0
SU Z-K A12NA SE Z- KD12 N A 12.50 16.00 10.00
SU Z-K A15 NA SE Z- KD15 N A 12.00 15.50 10.00
SUZ-KA09NA SEZ-KD09NA 12.0 0 15 .00 10.00
SUZ-KA09NA SLZ-KA09NA 12.0 0 15.00 9.60
MX Z-3C24NA Non-Ducted Indoor Units 13.60 20.00 9.80
MXZ-4C36NAHZ Non-Ducted Indoor Units 14.00 19 .10 11.3 0
MXZ-5C42NAHZ Non-Ducted Indoor Units 13.4 0 19.0 0 11.00
MX Z-3C24NAHZ Non-Ducted Indoor Units 13.50 19.00 10.00
MX Z-8C 48NA Non-Ducted Indoor Units 12.0 0 18.9 0 11.4 0
MX Z-8C 48NAH Z Non-Ducted Indoor Units 12.0 0 18.9 0 11.0 0
MXZ-3C30NAHZ Non-Ducted Indoor Units 12. 50 18.0 0 11.00
MX Z-3C24NA Mixed Ducted and Non-ducted Indoor Units 12.40 18.00 9.50
MX Z-2B2 0NA Non-Ducted Indoor Units 12.00 18.00 8.90
MX Z-2B2 0NA Specific 12.50 18.00 8.90
MXZ-3B24NA Non-Ducted Indoor Units 12.0 0 17. 50 9.30
MXZ-3B24NA Specific 12.50 17.5 0 9.30
MXZ-3B24NA Specific 12.50 17.5 0 9.30
MXZ-4C36NAHZ Mixed Ducted and Non-ducted Indoor Units 12.65 17.4 5 10.70
SEER HSPF
7434481
74519 74
81117 31
81117 31
Note: List is current as of this printing.
MXZ-5C42NAHZ Mixed Ducted and Non-ducted Indoor Units 12 .10 17.0 0 10.55
MXZ-2C20NAHZ Non-Ducted Indoor Units 13.50 17.00 9.80
MXZ-2C20NAHZ Mixed Ducted and Non-ducted Indoor Units 12. 25 16.00 9.65
MXZ-2C20NAHZ
Mixed Ducted and Non-ducted Indoor Units 12.25 16.00 9.65
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 7
PUT COMFORT ON CRUISE CONTROL
INVERTER TECHNOLOGY
72°
Set Temperature
INVERTER System
Automatically adjusts instantly
for consistent comfort
Conventional System
Constantly uctuates, wasting
energy and causing drafts
Time
Sophisticated, electronic control systems detect any change in zone temperature
and—like a car’s cruise control—automatically adjust the speed of the outdoor unit's
INVERTER-driven compressor for precise capacity and temperature control.
Electronic LEVs exactly control refrigerant flow to regulate coil temperature.
8 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
MULTIPLE FILTERS FOR CLEANER, HEALTHIER AIR
Our indoor units use a sophisticated multi-part filtration system to reduce contaminants such
as allergens, viruses and bacteria from the air. This combination of filters provides a healthier,
breathing environment for the home.
1
NANO PLATINUM FILTER:
• Ceramic and platinum nanoparticles are
incorporated into the filter material to provide
antibacterial and deodorizing characteristics
to improve air quality.
DEODORIZING FILTER:
2
AVAILABLE ON MSZ-FH
Features a ceramic surface absorption element
and uses nanotechnology for
high-power odor absorption.
• Periodic cleaning, following the
recommended procedures, will maintain filter
effectiveness.
3
ELECTROSTATIC ANTI-ALLERGY
ENZYME FILTER:
AVAILABLE ON MSZ-FH09/12/15NA AND MSY/Z-GE06/09/12/15/18
• Reduces germs, bacteria and viruses.
• Helps trap dust, pollens, mites and other particles.
• Utilizes an enzyme catalyst to help break down the sulfur atom bonds
in allergen proteins, transforming them into non-allergen proteins, and,
effectively cleaning the air (filter should be cleaned regularly to maintain
effectiveness).
1
2
3
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 9
HAND-HELD COMFORT CONTROL
Mitsubishi Electric hand-held controllers can adjust temperature, fan speed, and more.
Operation Select (Heat, Cool, Auto, Dry)
Econo Cool
Smart Set Button
Reset
Sliding Cover
CONTROLLER FEATURES INCLUDE:
Fan Speed
Timer
Vane Control
HR/MIN (Time Set)
Clock Set
▶ MODE: HEAT, COOL, AUTO, and DRY.
▶ FAN: Adjusts fan speed.
▶ STOP/START: A 12-hour ON/OFF timer .
▶ ECONO COOL: Energy ecient cooling option.
▶ VANE: Sets horizontal vane position.
▶ TIME: Power o timer and clock adjustment.
▶ SMART SET: Programs multiple settings into one
quick-press feature. Programs heating set back.
Included with M-Series wall-mounted and floor-mounted systems.
Optional wall-mounted wireless full functional (MHK1) and wall-mounted
wired controllers are available (PAR-32MAA & PAC-YT53CRAU requires
MAC-333IF-E interface for MSZ/Y and MFZ indoor units).
10 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
Additional features available on certain models:
• "Powerful Mode" function permits system to temporarily run
at a lower/higher temperature with an increased fan speed,
which quickly brings the room to the optimum comfort level
• Wide Vane setting provides a wider Whorizontal air distribution
on select models with wider cabinets
Features are determined by the indoor unit selected. Not all
features are on all controllers or indoor units.
KUMO CLOUD™
kumo cloud is a cloud service hosted by Mitsubishi Electric Cooling & Heating to remotely
or locally control your Mitsubishi Electric indoor units. This is achievable by installing the wireless Interface
(PAC-WHS01WF-E) in each indoor unit. The interface requires a wireless router that has WPS (Wireless
Protected Setup) feature as well as Internet access. kumo cloud app can monitor, control, and schedule
multiple indoor units in multiple locations across Apple, Android, and Amazon Fire devices.
Specifications and requirements
• Allows Mitsubishi Electric indoor unit to be controlled
remotely or locally with the kumo cloud™ app and
web service.
• Available in:
- Apple App Store iOS
®
8.0 and newer.
- Google Play Android™ 4.0 and newer.
- Amazon Apps 4.1 and newer.
• Web access at kumocloud.com.
• Availability to group units together.
• Organize groups into sites.
• Batch command units.
• Program in events to schedule the units.
• Available in Fahrenheit or Celcius.
• Error and Filter popup.
• Manual setup to add units.
• Must have a wireless router with WPS capability.
• Internet access is required for initial setup and
scheduling.
• A Mitsubishi Electric Wireless Interface (
WHS01WF-E
) installed by a professional contractor.
PAC-
• Smart Phone with kumo cloud (app required).
Wireless Interface
Enable remote access and control over your
MitsubishiElectric M- & P-Series systems with the
Wi-Fi Interface and kumo cloud app. The Wireless
Interface is an integral part of the kumo cloud
solution, allowing a Mitsubishi Electric indoor unit
to communicate with the web-based app and web
service. Through a wireless connection over the local
network, the Wireless Interface establishes a remote
connection with the cloud and provides remote control
and management of your system.
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 11
MHK1 WIRELESS REMOTE CONTROLLER KIT
Includes Wireless Wall-mounted Remote Controller, Wireless Receiver and Cable.
Portable Central Controller and Outside Air Sensor are optional accessories.
Wireless Wall-mounted Remote
Controller and Wireless Receiver
• Installs anywhere with simple wall-mounted design.
• Large, backlit, easy-to-read display.
• Dual set-point control with system changeover.
• Both controller and receiver enabled with
RedLINK
™
reliability.
The basic MHK1 Wireless Remote Controller Kit
includes a Wireless Wall-mounted Remote Controller
and a Wireless Receiver located with the indoor wallor ceiling-mounted unit. You may choose to enhance
your control convenience and flexibility with an optional
Portable Central Controller, Outside Air Sensor and the
new RedLINK
™
Internet Gateway.
MHK1 FEATURES
FUNCTION DESCRIPTION
ON/OFF On/Off operation for a single indoor unit
Operation Mode Cool / Drying / Auto / Heat / Fan operation modes dependent on connected system
Temperature Setting Set temperature from 40° F - 99° F depending on operation mode and connected system
System Changeover Deadband Value 2° F - 8° F
Schedule Operation 5-2, 5-1-1
Eliminates the guesswork when setting your schedule. Allows the remote controller to “learn"
Optimal Start
Fan Speed Setting Hi/Mid-2/Mid-1/Low/Auto Available fan speed settings dependent on connected system
Airflow Direction Setting
Permit/Prohibit Function
Space Temperature Displays the measured space temperature
Error Indication Displays error code
Display Outside Temperature and Humidity Requires optional MOS1 Outside Air Sensor
Dimensions - (W x D x H) Remote Controller: 5-3/16" x 1-1/2" x 3-9/16" Receiver: 3-1/4" x 1-5/16" x 6-7/16"
Operating Ambient Temperature Remote Controller: 32° F – 120° F Receiver: -40° F – 165° F
Operating Ambient Humidity Remote Controller: 5% - 90% RH (non-condensing) Receiver: 5% - 90% RH (non-condensing)
Power Supply 2 AA batteries (included)
Note: MHK1 Compatible with current INVERTER-driven M-Series as noted in data charts.
how long your split-zoning system takes to reach programmed temperature setting, so the
temperature is reached at the time you set
Airflow angles: 100° - 80° - 60° - 40° and oscillate available airflow direction settings dependent
on connected system
Individual prohibit operations for each remote controller function (ON/OFF, Set Temperature
and Operation Mode)
12 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
Optional MCCH1 Portable
Central Controller
Optional MOS1 Outside
Air Sensor
• Control up to 16 RedLINK™ devices.
• Requires MHK1 per indoor unit.
• Monitor and control On/Off, Mode
and Set Temperature.
• Schedule override capability.
• Does not interfere with other
wireless devices.
• Displays outside air temperature and
humidity when used with MOS1 Outside Air Sensor.
• Monitors outside air temperature
and humidity.
• Displays on MHK1 Remote
Controller and MCCH1 Portable
Central Controller.
OPTIONAL PAC-US444CN-1 THERMOSTAT INTERFACE
Our Thermostat Interface allows HVAC thermostats or input/output
controllers to control Mitsubishi Electric Cooling & Heating indoor
units through our CN105 connector. Any indoor unit that can be
controlled by an MHK1 can now be controlled by a third party
HVAC thermostat or input/output controller.
This allows Mitsubishi Electric systems to take advantage of the
capabilities of third party thermostats including but not limited
to: geo fencing, automatic scheduling, humidity control, weather
forecasting and more.
Our patent-pending algorithm allows the outdoor unit's INVERTER-driven compressor to vary its capacity for
greater energy savings. The preferred system setup is to use a conventional system control with two stages of
cooling and heating (W1, W2, Y1, and Y2) to provide personal comfort and energy savings. The interface can
also be setup to accept only one stage of cooling and heating (W1 and Y1).
The Mitsubishi Electric Thermostat Interface also allows for fan speed control. Third party thermostats or input/
output controllers can control the indoor unit's fan speed to three different levels: high, medium, and low.
Specifications
• Allows an HVAC Thermostat or I/O Controller to
control a Mitsubishi Electric Cooling & Heating
[M-Series or P-Series] indoor unit.
• One Thermostat Interface required per indoor unit.
• Indoor unit modes available: Cool, Heat, Fan, and
Off.
• Provides 3 input terminals to control fan speed
control: High, Medium, and Low.
• No addressing required.
• Connection: CN105 – Active IT Terminal.
• Dimensions: (H x W x D) 3.96 in x 3.17 in x 0.93 in.
• Thermostats Tested:
- Nest
®
- Honeywell® Lyric™
- INNCOM® by Honeywell® with High and Low
fan speed control.
• Terminal Block: 20-30 VAC Rated.
• Required: Active CN105 on Mitsubishi Electric
indoor unit control board.
• Required: HVAC Thermostat or I/O Controller (field
supplied).
• Required: 24VAC transformer needed (field
supplied).
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 13
M- and P-SERIES
Model: PAR-31MAA
BACKLIT MA REMOTE CONTROLLER (PAR-31MAA)
SPECIFICATIONS
• Controls group operation for up to 16 indoor units in a single group
• Features selectable multi-lingual LCD (English, Spanish, and
French)
• Supports both Fahrenheit and Celsius
• User functions allow user to set
- On/Off
- Operation modes cool, heat, dry, fan
- Set temperature
- Fan speed setting
- Airow direction
• Timer Operation:
- Weekly Timer: On/Off/Temperature setting up to 8 times per day of
the week in 1-minute increments
- Simple Timer: On and Off time can be set once within 72-hour
period in 1-hour increments
- Auto-off Timer: Turns indoor unit Off based on countdown time up
A3 Rev.
2. Schedule and timer setting
Item Description Setting Display
Timer ON/OFF timer
Turns ON and OFF daily at a set time.
• Time can be set in 5-minute increments.
• It is also possible to set the ON time only or the OFF time only.
Auto-OFF timer
Turns off the unit after a certain period of operation.
• Operation time can be set to a value from 30 to 240 minutes in
10-minute increments.
Weekly timer Weekly ON/OFF times and set temperatures can be set.
• Time can be set in 5-minute increments. Up to 8 schedule
patterns can be set per day of the week.
* Not valid when the ON/OFF timer is set.
Night setback The temperature range and the start/stop times can be set.
:Each group
:Not available
3. Restriction settings
Item Description Setting Display
Allows/disallows
The following operation can be prohibited by making certain
:Each group
:Not available
Advanced Features
• Delayed off adjustable setting.
• Static pressure adjustable setting.
• CN24 operation during defrost.
• Fan speed during thermal off heating mode.
• Two-stage heat and cool thermostat operation.
• Conventional 2H/2C system operation (preferred).
• Conventional 1H/1C system operation.
• Auto recovery after power failure.
• Thermostat detects room temperature.
• Transformer (VPL24-210).
PAR-32MAA BACKLIT MA REMOTE CONTROLLER
• Room Temperature: Displays
room temperature sensed either
at the indoor unit (default) or at
the remote controller.
• Set Temperature Range Limit:
From the Backlit MA Controller,
the allowable set temperature
Room
Set temp.
Cool Auto
Mode Temp. Fan
Fri
range can be reduced for cool
and heat modes.
• Function Lock Out: Prohibits
all functions or all functions
except On/Off from the backlit
MA controller.
PAC-YT53CRAU SIMPLE MA CONTROLLER
Controls group operation for up to 16 indoor units in a single group
• Set temperature range limit: Simple MA allowable set temperature range can
be reduced for cool and heat modes.
• Room temperature can be sensed either at the indoor unit (default) or at the
remote controller.
• Grouping: Same group use only with other PAC-YT53CRAU Simple MA Controllers,
PAR-32MAA Backlit MA Remote Controller, and PAR-FL/A32MA Wireless MA
Remote Controllers with up to two remote controllers per group.
• Wiring: Uses two-wire, stranded, non-polar control wire for connecting TB15
connection terminal on the indoor unit. Requires crossover wiring for grouping
across indoor units.
• Dimensions: 2-3/4 x 9/16 x 4-3/4" (70 x 14.5 x 120mm).
• Requires MAC-333IF-E to use with M-Series.
14 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
• Wiring: connects using twowire, stranded, non-polar
control wire to indoor unit
connection terminal or control
adapter (MAC-333IF for
M-Series) requires crossover
wiring for indoor unit grouping.
• Dimensions: 4-3/4 x 3/4 x 4-3/4"
(120 x 19 x 120 mm).
• Requires MAC-333IF-E to use
with M-Series.
• Setting screen for 3D i-see
sensor, draft reduction mode.
MAC-333IF-E SYSTEM CONTROL INTERFACE
• Allows M-Series indoor units to communicate with the CITY MULTI Controls Network via M-Net.
• Provides an input to allow remote On/Off control of indoor unit (3-Wire plug adapter included).
• Allows the M-Series indoor units to connect to MHK1 Wall-Mounted Wireless Remote Controller
when using other MAC-333IF-E functions. (Note: External 12VDC power supply is required when
adding the MHK1 to the MAC-333IF-E).
• Allows the M-Series indoor units to connect to a MA remote controller.
• Power: 12V DC (supplied from indoor unit).
• Indoor unit connecting cable: Dedicated 5-wire cable included.
OPTIONAL REDLINK INTERNET GATEWAY
(AVAILABLE THROUGH SELECT DISTRIBUTORS)
• Connects any RedLINK Comfort System to the Internet to provide remote access
from PC, smartphone or tablet.
• No monthly fee, free app download.
• Remotely monitor and control your cooling and heating system, at any time, from
any place.
• View/change system settings and access multiple systems/zones.
• Provides over 90° temperature/comfort alerts through a dedicated website.
• Upgrades automatically as new features become available.
TM
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 15
DETECT AND CONTROL TEMPERATURE FLUCTUATIONS
TM
All M-Series systems detect room temperature fluctuations and automatically adjust
performance for ultimate comfort in any room.
▶ All indoor models feature a return air sensor that constantly monitors and maintains
room temperature.
▶ Continuous fan operation ensures temperature consistency.
▶ Systems with and i-see Sensor™ 3D scan the room looking for humans with a particular
heat signature. The i-see feature senses floor temperature and delivers conditioned air to
those areas by double-vane airflow. (MSZ-FH09/12/15NA models).
▶ Auto changeover feature automatically switches between cooling and heating modes
as needed to maintain a consistent temperature—just set it and forget it (MUZ and SUZ
outdoor units).
▶ Seven horizontal airflow directions provide 150° of lateral airflow for greater conditioned
air circulation (wide vane or swing mode, available on the MSZ-FH09/12/15, MSZ/Y-GE24
and MSZ/Y-D30/36NA).
Detects human locations
and temperature variations
and controls the airflow for
ultimate comfort
This amazing technology constantly monitors and adjusts
temperatures for maximum comfort and efficiency.
• Measures infrared radiation generated from surrounding
walls and surface angles
• Efficiently adjusts temperatures to ideal comfort levels
for occupants
16 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
INSTALLATION BEST PRACTICES
Look for opportunities to use Mitsubishi Electric systems on every job!
Single and Multi-zone systems for Hot and Cold Spots, Living Rooms, Bedrooms, Kitchens, Allergy
Problems, Renovations, Energy Savings Opportunities, Media Rooms, Basements, Combination with
Traditional System, Whole Floor, Whole Home, New Homes…and more!
Properly installed systems heat and cool homes for a fraction of the cost of traditional systems.
By following installation best practices and providing homeowner education, you will help to insure customer
satisfaction, and increase referrals and sales. Visit a Mitsubishi Electric 2-day training course for more
information. Ask your Mitsubishi Electric distributor for details.
Outdoor Unit (Compressor)
• Set the unit on a stable, level surface.
• Use adjustment risers to prevent debris and snow
build-up and allow better drainage.
• Secure outdoor units to the pad, risers and/or
surface using bolts and/or adhesives.
Line Set Insulation and Protection
• Insulation must cover entire line set length to
avoid condensation and decreased efficiency.
• Once insulated, protect the outdoor portion of
the line set with Line Hide to avoid premature
insulation damage.
• Add UV tape as needed on areas without Line
Hide to ensure entire length is protected.
Refrigerant Charge
• Adjust refrigerant charge ONLY IF NECESSARY;
most installations do not require adjustments.
• Gauges are not needed to verify refrigerant levels.
Only if adjustments are necessary, be sure to use
a scale when adding/removing refrigerant.
Condensate Drain
• Must slope downhill and can be routed with line
set and run to a suitable termination point, away
from crawl spaces and walkways.
Cold Climate Recommendations
• Use a pan heater to avoid defrost discharge
freezing inside the compressor.
• Increase clearance under the outdoor unit to
promote easy drainage and reduce snow and
ice buildup.
• Consider wall-mount brackets to maximize
outdoor unit clearance.
Tools
• Ratchet Flaring Tool
• Programmable Refrigerant Charging Scale
• Torque Wrench
• R410A Gauge and Hose Set
Installation Tips for Maximum Efficiency—Indoors
• For homes with electric furnaces, consider shutting off the furnace at the breaker or set back
the furnace thermostat so that it does not compete with the Mitsubishi Electric system.
• For homes with zonal electric heat, consider shutting off the heaters at the breaker or set back
the zonal heater thermostats so they do not compete with the Mitsubishi Electric system.
• For temperature set back, set programmable thermostat to HEAT with the fan in ON position
for air distribution and setting the temperature 4° F below the Mitsubishi Electric system.
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 17
Homeowner Education
Educate homeowners about their Mitsubishi Electric system to reduce callbacks and generate referrals:
• Use the Mitsubishi Electric system as the primary heating and cooling system to maximize benefits,
maintain comfort and ensure that the unit performs most efficiently.
• Secondary heating and cooling systems should remain off until your comfort is compromised. If your
comfort is compromised, supplement with your secondary system until your comfort requirements
are met.
• In extremely cold weather, you can temporarily:
» Increase the temperature setting of the Mitsubishi Electric system.
» Increase the fan speed.
» Close doors to unoccupied portions of the house; and/or
» Increase the thermostat setting on secondary heating systems as needed.
• Cleaning the filters several times a year optimizes the performance of the Mitsubishi Electric system.
Monthly cleaning is ideal for systems that are used regularly.
For technical information including submittals, parts, installation, service and more please
visit www.mylinkdrive.com
18 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
MULTI-ZONE PRODUCTS
M-SERIES MULTI-ZONE PRODUCTS AND FEATURES
Total zone control: individually controlled rooms (up to 8) with a single outdoor system.
With the MXZ-C multi-zone standard and H2i® systems your customers can enjoy ideal levels of comfort
in the rooms you use most while reducing their energy costs. Each zone operates independently.
People in different rooms –like the kitchen, master bedroom or living room – can set temperatures for
personalized comfort.
THE MULTI-ZONE SYSTEM FEATURES INCLUDE:
• Mix and match flexibility of indoor unit styles and
combinations.
• A wide range of indoor unit capacities that match
the room size and requirements.
• Flexible options to tackle the most challenging
MXZ-2C20
MXZ-3C24
MXZ-3C30
MXZ-4C36
MXZ-5C42
MXZ-8C48
multi-room installations.
• High efficiency, multiple ENERGY STAR®
combinations.
• Hyper-Heating INVERTER® models available for
colder climate applications.
• Simple, quick, and cost-effective installation.
• Four-ton outdoor unit can support up to eight
indoor units using branch boxes.
• Advanced microprocessor control.
• Auto restart following a power outage.
• Self-check function offering integrated diagnostics.
• Wired and wireless control options.
WALL-MOUNTED INDOOR UNITS FOR
MULTI-ZONE SYSTEMS
Cooling and Heating
Slim, wall-mounted units provide enhanced, industry-leading
performance for the single-zone ductless product category.
MSZ-GL Heat Pumps l 06, 09, 12, 15, 18, 24
• Washable long life filters.
• Auto restart and auto cooling/heating changeover.
• 24 hour timer.
• Multiple fan speeds: 5 speeds (GL06 - GL18) and 4
speeds (GL24 only).
• Vertical air swing on all units.
• All models ENERGY STAR® qualified.
- Horizontal swing on GL18 and GL24 only
• Compatible with kumo cloud™ control app and
- Wide airflow on GL24 only.
Thermostat Interface.
• Wireless hand-held controller.
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 19
WALL-MOUNTED INDOOR UNITS FOR MULTI-ZONE SYSTEMS (CONT'D)
MSZ-FH High Efficiency Heat Pumps | 06, 09, 12, 15, 18
• Industry-leading efficiency of 33.1 SEER (MSZ-FH06NA) and 30.5 SEER (MSZ-
FH09NA).
• Hyper-heating performance down to -13° F outdoor ambient. (use the degree
symbol)
• 100% heating capacity at 5° F outdoor ambient. (use degree symbol)
• Triple-action filtration including anti-allergen enzyme filter.
• Double-vane air delivery for enhanced circulation.
• i-see SensorTM (superscript the TM) 3D senses human heat signatures.
• NEW multi-function wireless controller.
• Optional Thermostat Interface (PAC-US444CN-1) to allow for operation with third-
party thermostats.
• Compatible with Mitsubishi Electric kumo cloud™ programmable thermostat app
(PAC-WHS01WF-E).
FLOOR-MOUNTED INDOOR UNITS FOR MULTI-ZONE SYSTEMS
Floor-mounted indoor unit mounts on the floor or up to 5" above floor and has front panel
access to the filter for ease of cleaning. It is perfect for difficult areas that may be smaller
or don’t have usable space on the walls.
MFZ Heat Pumps | 09, 12, 18
• T op and bottom discharge vanes.
• Hot-start technology.
• Quiet operation.
• Wireless remote control with smart set feature.
CEILING-RECESSED INDOOR UNITS FOR MULTI-ZONE SYSTEMS
SLZ 2'x2' ceiling-recessed cassette units offer a wide airflow pattern for better air
distribution in a less obtrusive style. Install SLZ in a hard ceiling (with an access panel
for servicing) or in 2'x2' drop ceiling.
SLZ Heat Pumps | 09, 12, 15
• Ventilation air knockouts.
• Built-in condensate lift mechanism (up to 20").
• Multiple airflow settings.
HORIZONTAL-DUCTED HEAT PUMPS FOR MULTI-ZONE SYSTEMS
SEZ ducted units provide comfort and efficiency while staying hidden either in the
ceiling or beneath the floor.
SEZ Heat Pumps | 09, 12, 15, 18
• Built-in condensate lift mechanism (up to 21-11-16").
• Static capability up to 0.20" WG.
• Optional filter box with MERV-8 filters.
Note: Select PL A, PCA, PEAD models are also compatible with select multi-zone MXZ-C systems.
For full MX Z-C combinations list, visit www.mitsubishipro.com/multizone
20 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
MULTI-ZONE SYSTEM POSSIBILITIES
For a complete list of the MXZ-C Series approved combinations,
visit www.mitsubishipro.com/multizone
MULTI-POSITION DUCTED UNIT FOR MULTI-ZONE SYSTEMS
• Performance: One inch foam R4.2, fiberglass free insulation
reduces condensation and boosts efficiency.
• Quality: durable, powder coated cabinet.
• Serviceability: easily removable fan provides access for coil
cleaning.
• Flexibility: true multi-position, requiring no additional kits for
downflow configuration.
• Installation: quality construction with disassembly in mind to
make fitting through tight access points simple.
• Comfort: DC motor ensures quiet and efficient operation year
MVZ-A12AA4
MVZ-A18AA4
MVZ-A24AA4
MVZ-A30AA4
MVZ-A36AA4
round.
• Low Impact: Fully RoHS compliant to reduce carbon footprint.
• Air Quality: Positively pressurized cabinet and tested air leakage
less than 1%.
MXZ-5C42NA (2:1, 3:1, 4:1, 5.1) Outdoor Unit*
MFZ-KA09NA
Indoor Unit
SEZ-KD12NA
Indoor Unit
SLZ-KA 2'x2'
Cassette Unit
MSZ-GL09NA
Indoor Unit
MSZ-GL09NA
Indoor Unit
MXZ-8C48NA-R1 (2:1, 8:1) Outdoor Unit*
Branch Box
(Minimum of
one required
with MXZ-8B)
SEZ-KD09NA Indoor Unit
*Illustration purposes only.
Mini mum of t wo Indoor U nits m ust b e conn ected to all MXZ- C Outd oor Un its . Mini mum i nsta lle d capa cit y can not be l ess th an 12, 00 0 Btu/ h.
MVZ-A18AA4
Two MSZ-GL06NA
Indoor Units
MFZ-KA12NA Indoor Unit
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 21
MULTI-ZONE SYSTEM POSSIBILITIES
For a complete list of the MXZ-C
Series approved combinations, visit
www.mitsubishipro.com/multizone
MXZ AND INDOOR UNIT COMPATIBILITY CHART
6,9 ,12,15
18
û
ü
û
INDOOR UNIT
9,12,15
18
û
9,12,15
18
û
9,12
ü
ü
9,12
ü
15
15
û û û
û
û
12,24,30,36,42
24
ü
30,36,42
û
12,30,36
12,18, 24,30,36
û
12,18, 24,30,36
û
12,18, 24,30,36
û
ü
û û û
û
û
12,24,30,36,42
24
ü
30,36,42
û
12,30,36,42
24
ü
30,36,42
û
12,30,36,42
24
ü
30,36,42
û
12,30,36,42
12,18,24,30,36
û
18
18,2 4
42
42
42
18
18,2 4
18,2 4
18,2 4
42
ü
û
ü
û
24,30,36
ü
û
24,30,36
ü
û
24,30,36
ü
û
ü
û
ü
30,36,42
û
ü
30,36,42
û
ü
30,36,42
û
24,30,36
ü
û
MULTI-ZONE
OUTDOOR UNIT
MXZ-2C20NAHZ
MXZ-3C24NAHZ
MXZ-3C30NAHZ
MXZ-4C36NAHZ
MXZ-5C42NAHZ
HYPER-HEATING EQUIPMENT
MXZ-8C48NAHZ
MXZ-2B20NA-1
MXZ-3C24NA
MXZ-3C30NA
MXZ-4C36NA
STANDARD EQUIPMENT
MXZ-5C42NA
MXZ-8C48NA
nformat ion is cu rrent as of this pr inting. Minimum insta lled capacity cannot be les s than 12,000 Btu/ h.
PLA-A12BA can NOT be connected w ith MXZ-C models only. MVZ is co mpatible with M XZ-C mode ls only a nd only 1 M VZ maybe u sed on any system. Wh en an MV Z is
connected, tota l conne cted cap acit y must be 100% or l ess, and no P-Ser ies ind oor uni ts can be used (PCA, PLA , or PEAD).
BRANCH
BOX
—
—
—
MVZ MSZ-GL MFZ-KA MSZ-FH SEZ-KD SLZ PCA PLA PEAD
12
12,18
24,30,36
12,18,24
30,36
6,9 ,12,15
ü
18, 24
û
6,9 ,12,15,18
ü
û
ü
û
24
6,9 ,12,15,18
24
û
9,12
ü
ü
ü
ü
18
û
ü ü ü ü
ü ü ü ü
ü ü ü ü ü ü ü
ü ü ü ü ü ü ü
ü ü ü ü ü ü ü
ü
û
û
û
û
ü
ü
ü
6,9 ,12,15
18, 24
û
6,9 ,12,15,18
24
û
ü ü ü ü ü
ü ü ü ü ü
6,9 ,12,15,18 ü
24
û
—
—
—
—
—
û
12,18
24,30,36
12,18,24
30,36
12,18,24
30,36
12,18,24
30,36
9,12
ü
ü
ü
18
û
ü ü ü ü
ü ü ü ü
ü ü ü ü ü ü ü
û
24
ü
ü
42
û
ü
42
û
ü
42
û
û
24
ü
û
24
ü
û
24
ü
û
ü
42
û
22 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
SINGLE-ZONE PRODUCTS
M-SERIES SINGLE-ZONE PRODUCTS AND FEATURES
Total control for total comfort: single rooms can now have ultimate comfort with the
power of precise control over hot and cold spots.
SINGLE-ZONE, WALL-MOUNTED HEAT PUMPS Cooling and Heating
Slim, wall-mounted indoor units provide zone comfort control. INVERTER-driven compressors and
electronic LEVs provide higher efficiency with controlled power usage. The indoor unit is powered by the
outdoor unit and should a power outage occur, the system is automatically restored when power returns.
MSZ/MUZ-GL/D Heat Pumps | 1,500 - 33,200 Btu/h Capacity Range
• 100% heating at 5°F.
• 14.5 - 24.6 SEER, 8.2 - 12.8 HSPF, INVERTER-driven compressor.
• Auto restar t and auto cooling/heating changeover
• Vertical air swing on all units
• Compatible with kumo cloud ™ control app and Thermostat Interface.
• All models ENERGY STAR ® qualified.
.
Cooling Only
MSZ/MUZ-FH High Efficiency Heat Pumps | 1,700 - 21,000 Btu/h Capacity Range
• Industry-leading efficiency of 33.1
SEER (MSZ-FH06NA and 30.5 SEER
(MS Z- F H 09 N A ).
• Hyper-heating performance down to -13° F
outdoor ambient.
• Triple-action filtration.
-Nano-platinum filter.
-Electrostatic anti-allergen enzyme filter.
-Deodorizing filter.
• Double-vane air delivery for enhanced
circulation.
- Option to set each vane separately.
- Indirect or direct setting option.
- Natural flow setting that creates air
movement like a natural breeze.
• i-see Sensor™ 3D.
- Infrared human sensing technologies
to measure location of human heat
signatures.
MSY/MUY Air Conditioners | 1,500–34,600 Btu/h Capacity Range
- i-see sensing floor temperature to
deliver conditioned air to those areas
by double-vane airflow.
• NEW multi-function wireless controller.
• Optional controllers.
- Connects with Thermostat Interface
(PAC-US444CN-1) to allow for
operation with third-party thermostats.
-Compatible with Mitsubishi Electric
kumo cloud™ programmable
thermostat app (PAC-WHS01WF-E).
- MHK1 wireless wall-mounted controller
(compatible with Honeywell Remote
Internet Gateway for iPhone, Android,
smart device control via the internet).
- Wired wall-mounted controller
(PAR-31MAA requires MAC-333IF).
- Simple MA remote controller
(PAC-YT53CRAU requires MAC-333IF).
• 15.1 – 24.6 SEER, INVERTER compressor.
• Offers a wide vane for a wider angle of airflow, 150° from left to right.
• Motorized vertical vanes on GL24/D30/D36 models.
®
• All GL models ENERGY STAR
M-Series systems are not recommended for critical room and low ambient cooling applications.
Use com merc ial gr ade P- Seri es with f ull coo ling c apac ity dow n to 0° F with wind baf fle.
qualified.
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 23
SINGLE-ZONE PRODUCTS (CONTINUED)
SINGLE-ZONE, CEILING-RECESSED, CASSETTE HEAT PUMPS
Cooling and Heating
SLZ 2'x2' ceiling-recessed cassette units offer a wide airflow pattern for better air
distribution in a less obtrusive style. Install SLZ in a hard ceiling (with an access
panel for servicing) or in 2'x2' drop ceiling.
SLZ/SUZ Heat Pumps | 3,100–17,700 Btu/h Capacity Range
• 15–16 SEER, 9.6 HSPF, INVERTER-driven compressor.
• Provides cooling and heating in a wide range of capacities.
• SLZ/SUZ-KA09/12 1:1 systems are ENERGY STAR
• Ventilation air knockouts.
• Built-in condensate lift mechanism (up to 20").
• Multiple airflow adjustments.
®
rated.
SINGLE-ZONE, HORIZONTAL-DUCTED HEAT PUMPS Cooling and Heating
SEZ ducted units provide comfort and efficiency while staying hidden either in the
ceiling or beneath the floor. All 1:1 systems are ENERGY STAR
®
certified.
SEZ/SUZ Heat Pumps | 3,800–19,000 Btu/h Capacity Range
• 15–17.5 SEER, 10 HSPF, INVERTER-driven compressor.
• Provides cooling and heating in a wide range of capacities.
• Built-in condensate lift mechanism (up to 21-11/16").
• Static capability up to 0.20" WG.
• Optional filter box with MERV-8 filters.
24 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
M-SERIES ACCESSORIES
CN-24RELAY-KIT-CM3 RELAY KIT
The CN-24RELAY-KIT-CM3 connects to the CN24 connector on the
P-Series, SEZ and SLZ indoor unit control board to enable external
supplemental heating equipment. The CN-24RELAY-KIT-CM3 also
connects to the MAC-333IF-E System Control Interface to provide
the same function for M-Series indoor units.
• Coil Voltage: 12V DC.
• Power Consumption: 0.9 W or less.
• Maximum Distance from indoor unit to relay: 32' (10m).
• Wire Size: 18 to 22 AWG.
BASE PAN HEATERS
Base Pan Heaters limit ice build-up by preventing freezing before water drains from the base pan. The heater installs in
the bottom of the Base Pan and connects to the Indoor Control Board on FE and GE models.
• For installations where outdoor ambient temperatures are
expected to be below freezing for periods longer than 72
hours straight.
• Heater is energized when unit is in defrost.
• E12913527 for A models requires change of power
board—included—to operater heater.
DPLS2 DIAMONDBACK™ DRAIN PAN LEVEL SENSOR/CONTROL
A condensate sensor designed to fit the Mitsubishi Electric M-Series, P-Series and almost all of CITY MULTI® indoor
unit drain pans. DPLS2 shuts down the indoor unit when high condensate levels are detected in the drain pan.
• Meets the intent of International Mechanical Code “allowed exception to the secondary drain pan requirement”.
• All solid state—no floats or other moving parts—draws power from indoor unit.
• Compact size with no additional energy consumption.
• Includes harnesses for M-Series, P-Series and CITY MULTI indoor units.
• Does not disrupt communications between the outdoor unit, compressor, and indoor unit.
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 25
PART SAE A B C D E ØF
NUMBER FLARE
BV14FFSI 1/4" 6.26 2.67 1.81 1.23 1.42 1.10
BV38FFSI 3/8" 6.30 2.67 1.81 1.23 1.42 1.10
BV12FFSI 1/2" 6.51 2.67 1.81 1.23 1.42 1.10
BV58FFSI 5/8" 6.64 2.67 1.81 1.23 1.42 1.10
B
C
D
E
PART SAE A B C D E ØF
NUMBER FLARE
BV14FFSI 1/4" 6.26 2.67 1.81 1.23 1.42 1.10
BV38FFSI 3/8" 6.30 2.67 1.81 1.23 1.42 1.10
BV12FFSI 1/2" 6.51 2.67 1.81 1.23 1.42 1.10
BV58FFSI 5/8" 6.64 2.67 1.81 1.23 1.42 1.10
0.74 ANCHO
PLANO
ABOCINADO
MACHO SAE
ABOCINADO
HEMBRA SAE
(TUERCA LOCA)
ABOCINADO MACHO SAE
DE 1/4 PULG. C/CONEXIÓN DE ACCESO
SEGÚN ARI 720 (INCLUYE NÚCLEO
DE VÁLVULA Y TAPA DE SELLO)
BALL VALVES
ABOCINADO
MACHO SAE
0.74 ANCHO
PLANO
C
D
E
ØF
B
PLATFORM STANDS
DIAMONDBACK™ BV-SERIES BALL VALVES
Diamondback BV-Series ball valves include the following features:
• Engineered for mini-split and multi-split HVAC units.
• Full port design with flare connections.
• 700 PSIG rated.
• Flare or brazed connections.
Other important information:
• Size available: 1/4", 3/8", 1/2", 5/8".
• Fully factory assembled.
• Furnace brazed and pressure tested.
• Each ball valve is equipped with Schrader® Valve for refrigerant service.
• Temperature range: -40˚ F to +325˚ F (-40˚ C to +149˚ C).
• Forged brass body and seal cap.
• Polytetrafluroethylene (PTFE) seals and gaskets (no synthetic O-rings).
ABOCINADO
HEMBRA SAE
• Seal cap design permits valve operation without removal of seal cap.
(TUERCA LOCA)
• One-year limited materials and workmanship warranty on ball valves.
Part Number SAE Flare A B C D E F
BV14FFSI2
BV38FFSI2
BV12FFSI2
BV58FFSI2
1/4" 6.26 2.67 1.81 1.23 1.42 1.10
3/8" 6.30 2.67 1.81 1.23 1.42 1.10
1/2" 6.51 2.67 1.81 1.23 1.42 1.10
5/8" 6.64 2.67 1.81 1.23 1.42 1.10
Ball valves come with an insulation piece.
*
DIAMONDBACK PLATFORM STANDS
Lift the outdoor unit to new heights.
• Easy to install.
• Available for all sizes of mini-split or multi-split systems.
• Color matched to the outdoor units.
• One-year warranty.
FILTER BOXES
FILTER BOXES
FB Series filter boxes are available in compatible sizes for all M-Series
horizontal ducted indoor units. FBL1 filter boxes include 1" thick pleated
MERV 8 filter(s) installed. Filters are tested in accordance with ANSI/
ASHRAE Standard 52.2 and Rated Class 2 under U.L. Standard 900.
The cabinet is constructed of non-insulated 20 gauge, G-60 galvanized
steel with a foam gasket and provides an air-tight connection to the
indoor unit and access door. Gasket material complies with UL 723
requirements. In addition, a screw-through cabinet design for secure
attachment to indoor unit and return connection in rear is easily converted
to bottom return.
Part
Number
FBL1-1
FBL1-2
FBL1-3
Model DSD-400N
L: 15 3/4"
W: 3 1/4"
H: 3 1/4"
Part Description
FB Series Filter Box for SEZ-KD09NA4
FB Series Filter Box for SEZ-KD12/15NA4
FB Series Filter Box for SEZ-KD18NA4
26 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
LINESETS
Caps On
DIAMONDBACK LINESETS
Diamondback linesets include the
following features:
• Quick, efficient, and economical field
installation using factory applied Twin Lube
insulation and flare connections with flare
nuts mounted.
• Correct lengths for reducing waste and time.
• Quality, consistency, and economy.
• All Diamondback lineset tubing is tested in
accordance with ASTM E243.
• One year warranty.
“TWIN-TUBE” LINESET
INSULATION DESIGN
• Balanced outside diameter for uniform
coil/uncoil position stability.
• Minimum 1/2" insulation thickness
on both tubes.
• Meets UL94 and ASTM E84 Standard.
Lineset
Part Number
MLS143812T-15
MLS143812T-30
MLS143812T-50
MLS143812T-65
MLS141212T-15
MLS141212T-30
MLS141212T-50
MLS141212T-65
MLS141212T-100
MPLS385812T-10
MPLS385812T-15
MPLS385812T-30
Applied
Models
MSZ-GL06 MSZ/Y-
GL09/12, MSZ-FH09/12,
SEZ-KD09/12, MFZ-
KA09/12
MSZ-GL06, MSZ/Y-
GL09/12, MSZ-FH09/12,
SEZ-KD09/12, MFZ-
KA09/13
MSZ-GL06, MSZ/Y-
GL09/12, MSZ-FH09/12,
SEZ-KD09/12, MFZ-
KA09/14
MSZ-GL06, MSZ/Y-
GL09/12, MSZ-FH09/12,
SEZ-KD09/12, MFZ-
KA09/15
MSZ/Y-GL15/18, MFZ-
KA18, SEZ-KD15/18,
SLZ-KA15
MSZ/Y-GL15/18, MFZ-
KA18, SEZ-KD15/18,
SLZ-KA15
MSZ/Y-GL15/18, MFZ-
KA18, SEZ-KD15/18,
SLZ-KA15
MSZ/Y-GL15/18, MFZ-
KA18, SEZ-KD15/18,
SLZ-KA15
MSZ/Y-GL15/18, MFZ-
KA18, SEZ-KD15/18,
SLZ-KA15
MSZ-FH18, MSZ/Y-GL24,
MSZ/Y-D30/36
MSZ-FH18, MSZ/Y-GL24,
MSZ/Y-D30/36
MSZ-FH18, MSZ/Y-GL24,
MSZ/Y-D30/36
Tube Size
(IN.)
1/4 x 3/8 15 1/2"
1/4 x 3/8 30 1/2"
1/4 x 3/8 50 1/2"
1/4 x 3/8 65 1/2"
1/4 x 1/2 15 1/2"
1/4 x 1/2 30 1/2"
1/4 x 1/2 50 1/2"
1/4 x 1/2 65 1/2"
1/4 x 1/2 100 1/2"
3/8 x 5/8 10 1/2"
3/8 x 5/8 15 1/2"
3/8 x 5/8 30 1/2"
Length
(FT.)
Insul.
MPLS385812T-50
MPLS385812T-65
MPLS385812T-100
MSZ-FH18, MSZ/Y-GL24,
MSZ/Y-D30/36
MSZ-FH18, MSZ/Y-GL24,
MSZ/Y-D30/36
MSZ-FH18, MSZ/Y-GL24,
MSZ/Y-D30/36
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 27
3/8 x 5/8 50 1/2"
3/8 x 5/8 65 1/2"
3/8 x 5/8 100 1/2"
QUICKSLING STANDS
Strong and reliable, Mini-split Stands are the mount of choice for
all M-Series outdoor units. Quick and easy to assemble, Mini-split
Stands are manufactured with heavy gauge, high-grade steel featuring
a color-matched thermally fused polyester powder coat finish that
meets ASTM D3451-06 standards. Each Mini-split Stand is provided
with galvanized mounting hardware and meets all ASCE 7 overturning
safety requirements, leading to a long service life. Designed and
manufactured in the United States, Mini-split Stands set the standard
for pre-engineered M-Series outdoor unit mounting systems.
M-Series Mini-split Stands
P-Series
Outdoor Units
MUY/Z-D30NA-1
MUY/Z-D36NA-1
MUZ-FH06NA
MUZ-FH09NA-1
MUZ-FH12NA-1
MUZ-FH15NA
MUZ-FH18NA2
MUY/Z-GL06NA-U1
MUY/Z-GL09NA-U8
MUY/Z-GL12NA-U1
MUY/Z-GL15NA-U1
MUY/Z-GL18NA-U1
MUY/Z-GL24NA-U1
SUZ-KA09NA
SUZ-KA12NA
SUZ-KA15NA
SUZ-KA18NA
MXZ-3C24NA
MXZ-3C30NA
MXZ-4C36NA
MXZ-5C42NA
MXZ-8C48NA
MXZ-2C20NAHZ
MXZ-3C24NAHZ
MXZ-3C30NAHZ
MXZ-4C36NAHZ
MXZ-5C42NAHZ
MXZ-8C48NAHZ
QSMS1201M QSMS1202M QSMS1801M QSMS1802M QSMS2401M QSMS2402M
X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X X
X X
28 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
M-SERIES ACCESSORIES
PART NUMBER DESCRIPTION FOR USE WITH
MAC-856SG-E
MAC-886SG-E
MAC-889SG
MAC-891DS
PAC-SH95AG-E
PAC-SH96SG-E
BV12FFSI2
BV14FFSI2
BV38FFSI2
BV58FFSI2
BRP-1
BRP-2
BRP-3
PAC-MKA30BC Three Port Branch Box MXZ Systems with two Branch Boxes
PAC-MKA50BC Five Port Branch Box MXZ Systems with two Branch Boxes
MSDD-50BR-E
MSDD-50AR-E
C13-103
C13-192
C21-014
F10-010 Blue Diamond Rubber Foot Pads MaxiBlue and Mega Blue Blue Diamond Pumps
DPLS2
SI30-115
SI30-230
X87-721
X87-711
X87-831
X87-835
ETC-211000MIT
MCCH1
MHK1
MOS1 Outdoor Air Sensor - reads both outside temperature and humidity displayed on MRCH1 and MCCH1 if installed All M-Series indoor units equipped with MHK1 Controller
PAC-IF01MNT-E System Control Interface MXZ-2C,3C,4C,5C outdoor units
PAC-YT53CRAU
PAC-YU25HT-G External Fan / Heater control relay adapter Use CN24RELAY-KIT-CM3
PAC-735 Adaptor - Fan Speed Indicator All MVZ Multi-position AHU
PAC-740
MAC-333IF-E
TAZ-MS303
CN24RELAY-KIT-CM3
PAC-715AD
PAC-725AD
PAC-SE41TS-E
PAC-SF40RM-E
PAR-FA32MA
PAR-FL32MA
Outdoor air outlet guide for directing discharge air away from other outdoor unit SUZ-KA18 outdoor units
Outdoor air outlet guide for directing discharge air away from other outdoor unit MUZ/Y-FH15/18, MUZ/Y-GL18/24/, SUZ-KA18 outdoor units
Outdoor air outlet guide for directing discharge air away from other outdoor unit MUZ/Y-GL09/12/15, MUZ-FH06/09/12, SUZ-KA09/12/15 outdoor units
Outdoor air outlet guide for directing discharge air away from other outdoor unit MXZ-2B20 outdoor units
Air Protection Guide All MXZ-8C and MXZ H2i 4C,5C outdoor units
Outdoor air outlet guide for directing discharge air away from other outdoor unit All MXZ outdoor models
Refrigeration Ball Valve-Flare/Schrader/Insulated - 1/2" size All MXZ outdoor models and branch boxes
Refrigeration Ball Valve-Flare/Schrader/Insulated - 1/4" size All MXZ outdoor models and branch boxes
Refrigeration Ball Valve-Flare/Schrader/Insulated - 3/8" size All MXZ outdoor models and branch boxes
Refrigeration Ball Valve-Flare/Schrader/Insulated - 5/8" size All MXZ outdoor models and branch boxes
Bottom Return Plate (Converts low profile ducted indoor unit from rear return to bottom return) SEZ-KD09 indoor unit
Bottom Return Plate (Converts low profile ducted indoor unit from rear return to bottom return) SEZ-KD12/15 indoor units
Bottom Return Plate (Converts low profile ducted indoor unit from rear return to bottom return) SEZ-KD18 indoor unit
Brazed Connections for connecting two branch boxes MXZ-8C outdoor units
Flared Connections for connecting two branch boxes MXZ-8C outdoor units
Blue Diamond Sensor Extension Cable - 15 Ft. MaxiBlue and Mega Blue Blue Diamond Pumps
Blue Diamond Alarm Sxtension Cable - 6.5 FT. MaxiBlue and Mega Blue Blue Diamond Pumps
Blue Diamond MultiTank - collection tank for use with multiple pumps All Blue Diamond Pumps
Drain Pan Level Sensor/Control for indoor unit shut off to prevent Drain Pan Overflow All M-Series indoor units
Mini-Condensation pump - 115 volt application All MSZ/Y, MFZ indoor units
Mini-Condensation pump - 230 volt application All MSZ/Y, MFZ indoor units
Advanced Blue Diamond Mini-Condensation pump w/ Resevoir & Sensor - 208/230 volt application All M-Series Indoor Units up to 30,000 BTU
Advanced Blue Diamond Mini-Condensation pump w/ Resevoir & Sensor - 110 volt application All M-Series Indoor Units up to 30,000 BTU
Advanced Blue Diamond Mini-Condensation pump w/ Resevoir & Sensor - 110 volt application All M-Series Indoor Units up to 30,000 BTU
Advanced Blue Diamond Mini-Condensation pump w/ Resevoir & Sensor - 208/230 volt application All M-Series Indoor Units up to 30,000 BTU
Electic Heat Lockout Control All MVZ Multi-position AHU
Portable Central Controller (PCC) - controls up to 16 RedLINK Zones - requires an MHK1 on each indoor unit All M-Series indoor units equipped with MHK1 Controller
Wireless wall-mounted remote controller (MRCH1) with a signal receiver (MIFH1) and cable (MRC1) all in one kit All M-Series indoor units
Simple MA Remote Controller (requires MAC-333IF-E interface for MSY/Z and MFZ indoor units) All MSZ/Y, MFZ, SEZ, SLZ indoor units
Adaptor - ERV Control All MVZ Multi-position AHU
System Control Interface - MA, Contact terminal, and M-NET Control Adapter, Supplemental heat and humidifier adaptor All MSZ, MSY, MFZ, SEZ, and SLZ
3-Pole Disconnect Switch 30 Amps 600 volts rated for interupting power supply at/near indoor unit - fits 2 X 4 utility box All M-Series Indoor Units
Relay Kit for external heater adapter connects to CN24 on indoor control board All SEZ indoor units, MVZ Multi-position AHU
Wire for Remote on/off with CN32 connector All SEZ, SLZ indoor units
Connector and wire for Operation status/error, booster fan control for fresh air using CN51 All SEZ, SLZ indoor units
Remote temperature sensor for indoor units All SEZ, SLZ indoor units
Remote Operation Adapter with wire terminals for remote on/off and operation status/error All SEZ, SLZ indoor units
Wireless Signal Receiver used with PAR-FL32MA All SEZ, SLZ indoor units
Wireless Remote Controller used with PAR-FA32MA All SEZ, SLZ indoor units
AIR OUTLET GUIDE
BALL VALVES
BOTTOM RETURN PLATE
Branch Box
CONDENSATE
CONTROL
AIR OUTLET GUIDE
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 29
RCMKP1CB
PAC-SH97DP-E
MAC-640BH-U
MAC-641BH-U
MAC-642BH-U
MAC-645BH-E
MAC-811DS
MAC-851DS
MAC-860DS
PAC-SG60DS-E
PAC-SG61DS-E
EH05-MPA-S
EH03-MPA-S
EH08-MPA-S
EH08-MPA-M
EH10-MPA-M
FBL 1-1
FBL 1-2
FBL 1-3
MAC-1415FT-E
MAC-2310FT-E
MAC-3000FT-E
MAC-408FT-E
MAC-415FT-E
DSD-400P
ULTRILITE1
ULTRILITE2
QSMS1201M
QSMS1801M
QSMS2401M
QSMS1202M
QSMS1802M
QSMS2402M
MAC-A454JP-E
MAC-A455JP-E
MAC-A456JP-E
PAC-493PI
PAC-SG76RJ-E
QSMS2000M-1
QSMS2000SS
Lockdown Bracket for wireless, hand-held, remote controllers All M-Series indoor units
DRAIN PAN
External drain pan used for stacking Outdoor Units. Prevents drain water from dripping on the lower units All MXZ-8C and MXZ H2i 4C,5C outdoor units
DRAIN PAN HEATER
Outdoor Unit Drain Pan Heater used during defrost cycle MUZ-GL09/12/15, MUZ-FH06/09/12, SUZ-KA09/12/15 outdoor
Outdoor Unit Drain Pan Heater used during defrost cycle SUZ-KA18 outdoor units
Outdoor Unit Drain Pan Heater used during defrost cycle MUZ-GL18/24, MUZ-FH12/18 outdoor units
Outdoor Unit Drain Pan Heater used during defrost cycle MXZ-2C,3C,4C,5C outdoor units
DRAIN SOCKET
Outdoor drain pan socket - Provides pipe connection to route condensate out of drain pan All MUZ/Y-D outdoor units
Outdoor drain pan socket - Provides pipe connection to route condensate out of drain pan MUZ-GL18/24, MUZ-FH15/18 outdoor units
Outdoor drain pan socket - Provides pipe connection to route condensate out of drain pan MUZ-FH06/09/12, MUY/MUZ-GL-24/SUZ-KA09/12/15, MXZ-
Outdoor drain pan socket - Provides pipe connection to route condensate out of drain pan MXZ-2C,3C,4C,5C outdoor units
Outdoor drain pan socket - Provides pipe connection to route condensate out of drain pan MXZ-8C48NA outdoor units
ELECTRIC KIT HEATS
Electric Heat Kit for Multi-position AHU Use with MVZ-A12/18/24 Multi-position AHU
Electric Heat Kit for Multi-position AHU Use with MVZ-A12/18/24 Multi-position AHU
Electric Heat Kit for Multi-position AHU Use with MVZ-A12/18/24 Multi-position AHU
Electric Heat Kit for Multi-position AHU Use with MVZ-A18/24 Multi-position AHU
Electric Heat Kit for Multi-position AHU Use with MVZ-A30/36 Multi-position AHU
FILTER BOX
FB SERIES Filter Box with MERV 8 Filters SEZ-KD09 indoor units
FB SERIES Filter Box with MERV 8 Filters SEZ-KD12/15 indoor units
FB SERIES Filter Box with MERV 8 Filters SEZ-KD18 indoor units
FILTERS
Anti-Allergy Enzyme Filter (qty of 2) All MSZ/Y-D indoor units
Anti-Allergy Enzyme Filter (qty of 2) MSZ/Y-GL24 indoor units
Deodorizing Filter All MSZ-FH indoor units
Anti-Allergy Enzyme Filter (qty of 2) MSZ/Y-GL06/09/12/15/18 indoor units
Anti-Allergy Enzyme Filter All MFZ-KA indoor units
OUTDOOR UNIT MOUNTING PAD
Outdoor Unit 3-1/4 inch Mounting Base (Pair) - Plastic All M-Series outdoor units
Condensing Unit Mounting Pad 16" x 36" x 3" All MU,MUY/Z outdoor units, All SUZ outdoor units, and MXZ-
Condensing Unit Mounting Pad 24" x 42" x 3" MXZ-8C and All MXZ H2i 4C,5C,8C outdoor units
OUTDOOR UNIT STAND
Outdoor Unit Stand - 12" High Single Fan M-Series Outdoor Units
Outdoor Unit Stand - 18" High Single Fan M-Series Outdoor Units
Outdoor Unit Stand - 24" High Single Fan M-Series Outdoor Units
Outdoor Unit Stand - 12" High Two Fan M-Series Outdoor Units
Outdoor Unit Stand - 18" High Two Fan M-Series Outdoor Units
Outdoor Unit Stand - 24"High Two Fan M-Series Outdoor Units
PORT ADAPTOR
Port Adapter size: 3/8" X 1/2" All MXZ outdoor models and branch boxes
Port Adapter size: 1/2" X 3/8" All MXZ outdoor models and branch boxes
Port Adapter size: 1/2" X 5/8" All MXZ outdoor models and branch boxes
Port Adapter size: 1/4" x 3/8" All MXZ outdoor models and branch boxes
Port Adapter size: 3/8" x 5/8" All MXZ outdoor models and branch boxes
WALL BRACKET
Heavy Duty Wall Mounting Bracket for Outdoor Units - Coated Steel All M-Series outdoor units
Heavy Duty Wall Mounting Bracket for Outdoor Units - 316 Series Stainless Steel All M-Series outdoor units
units
2C,3C,4C,5C outdoor units
2C,3C,4C,5C outdoor units
30 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
M-SERIES PRODUCT SPECIFICATIONS
SINGLE-ZONE I MSY System
Cooling Only
Model Name
Indoor Unit MSY-GL09NA-U1 MSY-GL12NA-U1 MSY-GL15NA-U1 MSY-GL18NA-U1 MSY-GL24NA-U1
Outdoor Unit MUY-GL09NA-U1 MUY-GL12NA-U1 MUY-GL15NA-U1 MUY-GL18NA-U1 MUY-GL24NA-U1
Rated Capacity Btu/h 9,000 12,000 14,000 18,000 22,500
Capacity Range Btu/h 3,800 - 12,200 3,800 - 13,600 1,500 - 13,600 5,800-22,000 8,200-31,400
Cooling *1
Power Supply Phase, Cycle, Voltage 1 Phase, 60Hz, 208/230V *2
Voltage
Indoor Unit
Remote
Controller
Outdoor Unit
Refrigerant
Refrigerant
Pipe
Refrigerant Pipe
Length
Connection
Method
NOTES: Test conditions are based on AHRI 210/240.
*1. Rating conditions (cooling) - Indoor D.B. 80º F (27º C), W.B. 67º F (19º C); Outdoor: D.B. 95º F (35º C), W.B. 75º F (24º C).
*2. Indoor units receive power from outdoor units through field-supplied interconnected wiring.
Specifications are subject to change without notice.
LIMITED WARRANTY I Five years parts and seven years compressor.
Rated Total Input W 585 920 1,080 1,340 1800
Energy Efficiency SEER 24.6 23.1 21.6 20.5 20.5
Moisture Removal Pints/h 1.5 2.5 2.7 2.1 5.1
Sensible Heat Factor 0.820 0.740 0.800 0.870 0.750
Indoor - Outdoor S1 - S2 AC 208 / 230V
Indoor - Outdoor S2 - S3 DC ±24V
Indoor - Remote Controller Wireless Type (Optional Wired Controller: DC 12V)
MCA A 1.0
Blower Motor (ECM) F.L.A. 0.76 0.67 0.76
Airflow at Cooling
(Quiet-Lo-Med-Hi-Super Hi)*1
Sound Pressure Level at Cooling
(Quiet-Lo-Med-Hi-Super Hi)*1
External Finish Color Munsell 1.0Y 9.2 / 0.2
Dimension Unit
Weight Unit Lbs. 22 28 37
Field Drainpipe Size O.D. In. 5/8
Type Select from PAC-WHS01WF-E for kumo cloud™, PAC-US444CN-1, MHK1, PAR-31MAA, or PAC-YT53CRAU Remote Controllers
MCA A 7 9 14 17.1
MOCP A 15 20
Fan Motor (ECM) F.L.A. 0.50 0.93
Compressor
Airflow (Cooling) CFM 1,229/1,172 1,243/1,229 1,691/1,691 1,769/1,701
Refrigerant Control Linear Expansion Valve
Sound Pressure Level at Cooling *1 dB(A) 48 49 54 55
External Finish Color Munsell No. 3Y 7.8 / 1.1
Dimensions
Weight Lbs. 81 121 119
Type R410A
Charge Lbs., Oz. 2, 9 3, 7 4, 3
Oil Type (fl. oz.) FV50S (0.27) FV50S (0.35) FV50S (0.40)
Gas Side O.D. In. 3/8 1/2 5/8
Liquid Side O.D. In. 1/4 3/8
Height Difference (Max.) Ft.. 40 50
Length (Max.) Ft.. 65 100
Indoor/Outdoor Flared/Flared
DRY (CFM) 145-170-237-321-399 205-272-335-420-533 259-333-416-523-646 388-469-544-628-738
WET (CFM) 109-134-201-286-364 170-237-300-385-498 233-300-375-470-581 347-420-487-562-661
dB(A) 19-22-30-37-43 19-22-30-37-45 26-32-38-44-49 28-33-38-44-49 34-41-45-49-53
W: In. 31-7/16 36-5/16 43-5/16
D: In. 9-1/8 9-13/16 9-3/8
H: In. 11-5/8 12 12-13/16
Model
(Type)
R.L.A. 4.9 6.8 10.0 12.9
L.R.A. 6.1 8.5 12.5 16.1
W: In. 31-1/2 33-1/16
D: In. 11-1/4 13
H: In. 21-5/8 34-5/8
DC INVERTER-driven DC INVERTER-driven Twin Rotary
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 31
SINGLE-ZONE I MSY System
Cooling Only
Model Name
Indoor Unit MSY-D30NA-8 MSY-D36NA-8
Outdoor Unit MUY-D30NA-1 MUY-D36NA-1
Rated Capacity Btu/h 30,700 34,600
Capacity Range Btu/h 9,800-30,700 9,800-34,600
Cooling *1
Power Supply Phase, Cycle, Voltage 1-phase, 60Hz, 208 / 230V *2
Voltage
Indoor Unit
Remote
Controller
Outdoor Unit
Refrigerant
Refrigerant Pipe
Refrigerant Pipe Length
Connection Method Indoor/Outdoor Flared/Flared
NOTES: Test conditions are based on AHRI 210/240.
Total Input W 3,380 (620-3,380) 4,240 (620-4,240)
Energy Efficiency SEER 16 15.1
Moisture Removal Pints/h 9.9 11.9
Sensible Heat Factor 0.64 0.62
Indoor - Outdoor S1 - S2 AC 208 / 230V
Indoor - Outdoor S2 - S3 DC ±24V
Indoor - Remote Controller Wireless Type (Optional Wired Controller: DC 12V)
MCA A 1.0
Blower Motor (ECM) F.L.A. 0.76
Airflow at Cooling (Quiet-Lo-Med-HiSuper Hi or Lo-Med-Hi-Powerful)*1
Sound Pressure Level at Cooling
(Quiet-Lo-Med-Hi-Super Hi or
Lo-Med-Hi-Powerful) *1
External Finish Color Munsell No. 1.0Y 9.2 / 0.2
Dimension Unit
Weight Unit Lbs. 40
Field Drainpipe Size O.D. In. 5/8
Type
MCA A 21
MOCP A 25
Fan Motor (ECM) F.L.A. 0.93
Compressor
Airflow (Cooling) CFM 1,941
Refrigerant Control Linear Expansion Valve
Sound Pressure Level at Cooling *1 dB(A) 55 56
External Finish Color Munsell No. 3Y 7.8 / 1.1
Dimensions
Weight Lbs. 126
Type R410A
Charge Lbs., Oz. 4
Oil Type (fl. oz.) NE022 (29.4)
Gas Side O.D. In. 5/8
Liquid Side O.D. In. 3/8
Height Difference (Max.) Ft.. 50
Length (Max.) Ft.. 100
DRY (CFM) 389-639-848-887
WET (CFM) 350-576-763-798
dB(A) 32-42-49-51
W: In. 46-1/16
D: In. 11-5/8
H: In. 14-3/8
Select from PAC-WHS01WF-E for kumo cloud™, PAC-US444CN-1, MHK1, PAR-32MAA,
Model (Type) DC INVERTER-driven Twin Rotary
R.L.A. 16
L.R.A. 20
W: In. 33-1/16
D: In. 13
H: In. 33-7/16
or PAC-YT53CRAU Remote Controllers
*1. Rating conditions (cooling) - Indoor D.B. 80º F (27º C), W.B. 67º F (19º C); Outdoor: D.B. 95º F (35º C), W.B. 75º F (24º C).
*2. Indoor units receive power from outdoor units through field-supplied interconnected wiring.
Specifications are subject to change without notice.
LIMITED WARRANTY I Five years parts and seven years compressor.
32 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
SINGLE-ZONE I MSZ Indoor Unit I Heat Pump
Model Name
Indoor Unit MSZ-FH06NA MSZ-FH09NA MSZ-FH12NA MSZ-FH15NA
Outdoor Unit MUZ-FH06NA MUZ-FH09NA-1 MUZ-FH12NA-1 MUZ-FH15NA
Rated Capacity Btu/h 6,000 9,000 12,000 15,000 17,200
Capacity Range Btu/h 1,700 - 9,000 1,700-12,000 2,500-13,600 6,450 -19,000 6,450-21,000
Cooling *1
Heating
at 47° F *2
Heating
at 17° F *3
Heating
at 5° F
Power
Supply
Voltage
Indoor Unit
Remote Controller Type
Outdoor Unit
Refrigerant
Refrigerant Pipe
Refrigerant
Pipe Length
Connection Method Indoor/Outdoor Flared/Flared
NOTES: Test conditions are based on AHRI 210/240.
*1. Rating conditions (cooling)-Indoor: D.B. 80º F (27º C), W.B. 67º F (19º C);
Outdoor: D.B. 95º F (35º C), W.B. 75º F (24º C).
*2. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C);
Outdoor: D.B. 47º F (8º C), W.B. 43º F (6º C).
Rated Total Input W 315 560 870 1,200 1,375
Energy Efficiency SEER 33.1 30.5 26.1 22.0 21.0
Moisture Removal Pints/h 0.2 0.6 1.9 4.0 4.8
Sensible Heat Factor 0.960 0.920 0.830 0.700 0.690
Rated Capacity Btu/h 8,700 10,900 13,600 18,000 20,300
Capacity Range Btu/h 1,600 - 14,000 1,600-18,000 3,700-21,000 5,150 - 24,000 5,150-30,000
Rated Total Input W 545 710 950 1,300 1,720
HSPF (IV) Btu/h/W 13.5 13.5 12.5 12.0 12.0
Rated Capacity Btu/h 5,900 6,700 8,000 11,000 13,700
Rated Total Input W 500 600 720 1,020 1,320
Maximum Capacity Btu/h 10,700 12,200 13,600 18,000 20,300
Maximum Capacity Btu/h 8,700 10,900 13,600 18,000 20,300
Phase, Cycle, Voltage 1 Phase, 60Hz, 208/230V *4
Indoor - Outdoor S1 - S2 AC 208 / 230V
Indoor - Outdoor S2 - S3 DC ±24V
Indoor - Remote Controller Wireless Type (Optional Wired Controller: DC12V)
MCA A 1.0
Blower Motor (ECM) F.L.A. 0.67
Airflow at Cooling
(Quiet-Low-Med.-HighSuper Hi) *1
Airflow at Heating
(Quiet-Low-Med.-High-Super Hi) *2
Sound Pressure Level at Cooling
(Quiet-Low-Med.-High-Super Hi) *1
Sound Pressure Level at Heating
(Quiet-Low-Med.-High-Super Hi) *2
External Finish Color Munsell No. 1.0Y 9.2 / 0.2
Dimension Unit
Weight Unit Lbs. 29
Field Drainpipe Size O.D. In. 5/8
MCA A 11 16 15
MOCP A 15 20
Fan Motor (ECM) F.L.A. 0.50 0.93
Compressor
Airflow (Cooling/Heating) CFM 1,150/1,280 1,074/1,202 1,190/1,320 1,692/1,634
Refrigerant Control Linear Expansion Valve
Defrost Method Reverse Cycle
Sound Pressure Level
at Cooling *1
Sound Pressure Level
at Heating *2
External Finish Color Munsell No. 3Y 7.8 / 1.1
Dimensions
Weight Lbs. 81 124
Type R410A
Charge Lbs., Oz. 2 , 9 3, 7
Oil Type (cc) FV50S (350) FV50S (400)
Gas Side O.D. In. 3/8 1/2
Liquid Side O.D. In. 1/4
Height Difference (Max.) Ft. 40 50
Length (Max.) Ft. 65 100
DRY (CFM) 137-167-221-304-381 137-167-221-304-381 137-167-221-304-398 225-262-304-355-411
WET (CFM) 117-143-190-261-328 117-143-190-261-328 117-143-190-261-342 194-225-261-305-354
DRY (CFM) 140-167-225-325-437 140-167-225-325-437 140-167-225-325-454 201-254-317-394-497
dB(A) 20-23-29-36-40 20-23-29-36-40 21-24-29-36-41 27-31-35-39-47
dB(A) 20-24-29-36-42 20-24-29-36-42 21-24-29-36-42 25-29-34-39-46
W: In. 36-7/16
D: In. 9-3/16
H: In. 12(+11/16)
Select from PAC-WHS01WF-E for kumo cloud™, PAC-US444CN-1,
MHK1, PAR-31MAA, or PAC-YT53CRAU Remote Controllers
Model
(Type)
R.L.A. 8.2 12.0 10.0
L.R.A. 10.3 15.0 12.5
dB(A) 47 48 49 51 52
dB(A) 48 49 51 55 55
W: In. 31-1/2 33-1/16
D: In. 11-1/4 13
H: In. 21-5/8 34-5/8
*3. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C);
*4. Indoor units receive power from outdoor units through field-supplied interconnected wiring.
Specifications are subject to change without notice.
LIMITED WARRANTY I Five years parts and seven years compressor.
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 33
DC INVERTER-driven Twin Rotary
Outdoor: D.B. 17º F (-8º C), W.B. 15º F (-9º C).
MSZ-
FH18NA2
MUZ-
FH18NA2
225-262-304-
355-459
194-225-261-
305-395
201-254-317-
394-514
20-23-29-
36-40
20-24-29-
36-42
SINGLE-ZONE
MSZ System I Heat Pump
I
Model Name
Rated Capacity Btu/h 9,000 12,000 14,000 18,000 22,400
Capacity Range Btu/h 3,600 - 12,200 1,500 - 13,600 3,100 - 18,200 5,800 - 22,000 8,200 - 31,400
Cooling *1
Heating at 47°
F *2
Heating at 17°
F *3
Heating at 5° F Maximum Capacity Btu/h 7,600 9,700 13,700 14,500 21,160
Power Supply Phase, Cycle, Voltage 1 Phase, 60Hz, 208/230V *4
Voltage
Indoor Unit
Remote
Controller
Outdoor Unit
Refrigerant
Refrigerant Pipe
Refrigerant Pipe
Length
Connection
Method
NOTES: Test conditions are based on AHRI 210/240.
*1. Rating conditions (cooling)-Indoor: D.B. 80º F (27º C), W.B. 67º F (19º C);
Outdoor: D.B. 95º F (35º C), W.B. 75º F (24º C).
*2. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C);
Outdoor: D.B. 47º F (8º C), W.B. 43º F (6º C).
Rated Total Input W 585 920 1,080 1,340 1,800
Energy Efficiency SEER 24.6 23.1 21.6 20.5 20.5
Moisture Removal Pints/h 1.5 2.5 2.7 2.1 5.1
Sensible Heat Factor 0.820 0.740 0.800 0.870 0.750
Rated Capacity Btu/h 10,900 14,400 18,000 21,600 27,600
Capacity Range Btu/h 4,500 - 14,100 5,500 - 18,100 4,800 - 20,900 5,400 - 25,000 7,500 - 36,900
Rated Total Input W 720 1,100 1,600 1,680 2,340
HSPF (IV) Btu/h/W 12.8 12.5 11.7 11.2 10.0
Rated Capacity Btu/h 7,000 12,000 16,400 18,200 24,600
Rated Total Input W 620 9,200 12,200 13,800 16,000
Maximum Capacity Btu/h 9,400 1,240 1,850 2,150 3,290
Indoor - Outdoor S1 - S2 AC 208 / 230V
Indoor - Outdoor S2 - S3 DC ±24V
Indoor - Remote Controller Wireless Type (Optional Wired Controller: DC12V)
MCA A 1.0
Blower Motor (ECM) F.L.A. 0.76 0.67 0.76
Airflow at Cooling
(Quiet-Lo-Med-Hi-Super Hi) *1
Airflow at Heating
(Quiet-Lo-Med-Hi-Super Hi) *2
External Static Pressure In. WG
Sound Pressure Level at Cooling
(Quiet-Lo-Med-Hi-Super Hi) *1
Sound Pressure Level at Heating
(Quiet-Lo-Med-Hi-Super Hi) *2
External Finish Color Munsell 1.0Y 9.2 / 0.2
Dimension Unit
Weight Unit Lbs. 22 28 37
Field Drainpipe Size O.D. In. 5/8
Type Select from PAC-WHS01WF-E for kumo cloud™, PAC-US444CN-1, MHK1, PAR-31MAA, or PAC-YT53CRAU Remote Controllers
MCA A 9 10 14 17.1
MOCP A 15 20
Fan Motor (ECM) F.L.A. 0.5 0.93
Compressor
Airflow (Cooling/Heating) CFM 1,229/1,172 1,229 / 1,172 1,243 / 1,229 1,691 / 1,691 1,769 / 1,701
Refrigerant Control Linear Expansion Valve
Defrost Method Reverse Cycle
Sound Pressure Level at Cooling *1 dB(A) 48 49 54 55
Sound Pressure Level at Heating *2 dB(A) 50 51 55
External Finish Color Munsell No. 3Y 7.8 / 1.1
Dimensions
Weight Lbs. 81 121 119
Type R410A
Charge Lbs., Oz. 2, 9 3, 7 4, 3
Oil Type (fl. oz.) FV50S (0.35) FV50S (0.40)
Gas Side O.D. In. 3/8 1/2 5/8
Liquid Side O.D. In. 1/4 3/8
Height Difference (Max.) Ft. 40 50
Length (Max.) Ft. 65 100
Indoor/Outdoor Flared/Flared
Indoor Unit MSZ-GL09NA-U1 MSZ-GL12NA-U1 MSZ-GL15NA-U1 MSZ-GL18NA-U1 MSZ-GL24NA-U1
Outdoor Unit MUZ-GL09NA-U8 MUZ-GL12NA-U1 MUZ-GL15NA-U1 MUZ-GL18NA-U1 MUZ-GL24NA-U1
DRY (CFM) 145-170-237-321-399 205-272-335-420-533 259-333-416-523-646 388-469-544-628-738
WET (CFM) 109-134-201-286-364 170-237-300-385-498 233-300-375-470-581 347-420-487-562-661
DRY (CFM) 145-170-237-321-406 205-247-304-367-463 296-384-469-563-646 388-469-544-628-738
dB(A) 19-22-30-37-43 19-22-30-37-45 26-32-38-44-49 28-33-38-44-49 34-41-45-49-53
dB(A) 19-22-30-37-43 19-22-30-37-43 26-30-35-40-46 28-33-38-43-48 32-41-45-49-52
W: In. 31-7/16 36-5/16 43-5/16
D: In. 9-1/8 9-13/16 9-3/8
H: In. 11-5/8 12 12-13/16
Model
(Type)
R.L.A. 6.2 6.6 7.4 10.0 12.9
L.R.A. 7.7 8.2 9.3 12.5 16.1
W: In. 31-1/2 33-1/16
D: In. 11-1/4 13
H: In. 21-5/8 34-5/8
*3. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C);
*4. Indoor units receive power from outdoor units through field-supplied interconnected wiring.
Specifications are subject to change without notice.
LIMITED WARRANTY I Five years parts and seven years compressor.
DC INVERTER-driven Twin Rotary
Outdoor: D.B. 17º F (-8º C), W.B. 15º F (-9º C).
34 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
SINGLE-ZONE I MSZ System I Heat Pump
Model Name
Rated Capacity Btu/h 30,700 33,200
Capacity Range Btu/h 9,800-30,700 9,800-33,200
Cooling *1
Heating
at 47º F *2
Heating
at 17º F *3
Heating at 5º F Maximum Capacity Btu/h 16,305 19,090
Power Supply Phase, Cycle, Voltage
Voltage
Indoor Unit
Remote Controller Type
Outdoor Unit
Refrigerant
Refrigerant Pipe
Connection Method Indoor/Outdoor Flared/Flared
NOTES: Test conditions are based on AHRI 210/240.
*1. Rating conditions (cooling)-Indoor: D.B. 80º F (27º C), W.B. 67º F (19º C);
Outdoor: D.B. 95º F (35º C), W.B. 75º F (24º C).
*2. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C);
Outdoor: D.B. 47º F (8º C), W.B. 43º F (6º C).
*3. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C);
Total Input W 3,850 (620-3,850) 4,360 (620-4,360)
Energy Efficiency SEER 14.5
Moisture Removal Pints/h 9.9 11.3
Sensible Heat Factor 0.64 0.62
Rated Capacity Btu/h 32,600 35,200
Capacity Range Btu/h 8,700-34,000 8,700-36,000
Total Input W 3,360 (520-3,600) 3,840 (520-4,100)
HSPF (Region IV) Btu/h/W 8.2
Rated Capacity Btu/h 19,500 21,800
Rated Total Input W 2,620 *5 3,000 *5
Maximum Capacity Btu/h 20,800 22,800
Indoor - Outdoor S1-S2 1 Phase, 60Hz, 208 / 230V *4
Indoor - Outdoor S2-S3 AC 208-230V
Indoor - Remote Controller DC ±24V
MCA A 1.0
Blower Motor (ECM) F.L.A. 0.76
Airflow at Cooling (Lo-Med-Hi-Super HI-Powerful) *1
Airflow at Heating (Lo-Med-Hi-SuperHI-Powerful) *2 DRY (CFM) 445-639-848-887
Sound Pressure Level (Cooling) (Lo-Med-Hi-Super HI-Powerful) *1
Sound Pressure Level (Heating) (Lo-Med-Hi-Super HI-Powerful) *2 34-42-49-50
External Finish Color Munsell No. 1.0Y 9.2 / 0.2
Dimension Unit
Weight Unit Lbs. 40
Field Drainpipe Size O.D. In. 5/8
MCA A 21
MOCP A 25
Fan Motor (ECM) F.L.A. 0.93
Compressor
Airflow CFM 1,941
Refrigerant Control Linear Expansion Valve
Defrost Method Revese Cycle
Sound Pressure Level at Cooling *1 dB(A) 55 56
Sound Pressure Level at Heating *2 dB(A) 57
External Finish Color Munsell No. 3Y 7.8/1.1
Dimensions
Weight Lbs. 141
Type R410A
Charge Lbs., Oz. 4, 10
Oil Type (Fl. Oz.) NE022 (29.4)
Gas Side O.D.
Liquid Side O.D. 3/8
Height Difference (Max.)
Length (Max.) 100
Indoor Unit MSZ-D30NA-8 MSZ-D36NA -8
Outdoor Unit MUZ-D30NA-1 MUZ-D36NA-1
DRY (CFM) 389-639-848-887
WET (CFM) 350-576-763-798
dB(A)
W: In. 46-1/16
D: In. 11-5/8
H: In. 14-3/8
Select from PAC-WHS01WF-E for kumo cloud™, PAC-US444CN-1, MHK1, PAR-32MAA,
Model (Type) DC INVERTER-driven Twin Rotary
R.L.A. 16
L.R.A. 20
W: In. 33-1/16
D: In. 13
H: In. 33-7/16
In.
Ft.
Outdoor: D.B. 17º F (-8º C), W.B. 15º F (-9º C).
*4. Indoor units receive power from outdoor units through field-supplied interconnected wiring.
*5. Maximum Total Input
Specifications are subject to change without notice.
LIMITED WARRANT Y I Five years par ts and seven years comp ressor.
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 35
32-42-49-51
or PAC-YT53CRAU Remote Controllers
5/8
50
SINGLE-ZONE I SEZ System I Heat Pump
Model Name
Rated Capacity Btu/h 8,100 11,500 14,100 17,200
Capacity Range Btu/h 3,800-10,900 3,800-13,300 3,800-17,000 3,800-19,000
Cooling *1
Heating at 47° F *2
Heating at 17° F *3
Power Supply Phase, Cycle, Voltage 1 Phase, 60Hz, 208 / 230V *4
Voltage
Indoor Unit
Remote Controller Type
Outdoor Unit
Refrigerant
Refrigerant Pipe
Refrigerant Pipe Length
Connection Method Indoor/Outdoor Flared/Flared
Total Input W 670 920 1,170 1,380
Energy Efficiency SEER 15 16 15.5 17.5
Moisture Removal Pints/h 1.5 2.4 2.6 3.4
Sensible Heat Factor 0.80 0.76 0.80 0.79
Rated Capacity Btu/h 10,900 13,600 18,000 21,600
Capacity Range Btu/h 4,800-14,100 4,800-16,400 4,800-21,100 4,800-24,900
Total Input W 1,020 1,140 1,500 1,700
HSPF (IV) Btu/h/W 10.0
Rated Capacity Btu/h 6,700 9,000 11,900 13,100
Rated Total Input W 810 920 1,200 1,350
Maximum Capacity Btu/h 6,700 9,000 11,900 13,100
Indoor - Outdoor S1 - S2 AC 208-230V
Indoor - Outdoor S2 - S3 DC ±24V
MCA A 1
Blower Motor (ECM) F.L.A. 0.51 0.57 0.74
Airflow at Cooling/Heating (Lo-Med-Hi)
External Static Pressure *3 In. W.G. 0.02-0.06-0.14-0.20
Sound Pressure Level (Lo-Med-Hi) dB(A) 23-26-30 23-28-33 30-34-37 30-34-38
External Finish Galvanized-Steel Sheets
Dimension Unit
Weight Unit Lbs. 42 50 54 62
Drain-lift Mechanism H: In. 21-11/16
Field Drainpipe Size O.D. In. 1-1/4
MCA A 12 14
MOCP A 15
Fan Motor (ECM) F.L.A. 0.50 0.93
Compressor
Airflow (Cooling/Heating) CFM 1,151/1,225 1,229/1,172 1,243/1,229 1,730/1,659
Refrigerant Control Linear Expansion Valve
Defrost Method Reverse Cycle
Sound Pressure Level at Cooling *1 dB(A) 46 49 54
Sound Pressure Level at Heating *2 dB(A) 50 51 56
External Finish Color Munsell No. 3Y 7.8/1.1
Dimensions
Weight Lbs. 66 77 80 119
Type R410A
Charge Lbs., Oz. 2 2, 9 4
Oil Type (fl. oz.) NEO22 (10.8) NEO22 (15.2)
Gas Side O.D. In. 3/8 1/2
Liquid Side O.D. In. 1/4
Height Difference (Max.) Ft. 40 50
Length (Max.) Ft. 65 100
Indoor Unit SEZ-KD09NA4 SEZ-KD12NA4 SEZ-KD15NA4 SEZ-KD18NA4
Outdoor Unit SUZ-KA09NA SUZ-KA12NA SUZ-KA15NA SUZ-KA18NA
DRY (CFM) 194-247-317 247-317-388 353-441-529 423-529-635
WET (CFM) 174-222-285 222-285-349 317-396-476 381-476-572
W: In. 31-1/8 39 46-7/8
D: In. 27-9/16
H: In. 7-7/8
Select from PAC-WHS01WF-E for kumo cloud™, PAC-US444CN-1, MHK1, PAR-32MAA, or PAC-YT53CRAU
Model (Type) DC Inverter DC Inverter Twin Rotary
R.L.A. 6.6 7.4 10
L.R.A. 8.2 9.3 12.5
W: In. 31-1/2 33-1/6
D: In. 11-1/4 13
H: In. 21-5/8 33-7/16
Remote Controllers
NOTE S: Test condi tions are based on A HRI 210/240.
*1. Rating conditions (cooling)-Indoor: D. B. 80º F (27º C), W.B. 67 º F (19º C);
Outdoo r: D.B. 9 5º F (35º C), W.B. 75 º F (24º C).
*2. Rat ing condi tions (heating)-Ind oor: D.B . 70º F (21º C), W.B. 60 º F (16º C);
Outdoo r: D.B. 47 º F (8º C), W.B. 43º F ( 6º C).
*3. Rat ing condi tions (heating) -Indoor: D.B. 7 0º F (21º C ), W.B. 60 º F (16º C);
Outdoo r: D.B. 17º F (- 8º C), W.B. 15º F (-9º C ).
*4. Indoor units receive power f rom outdoor unit s through field-supplied int erconnected wiring.
36 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
Specifications are subject to change without notice.
LIMITED WARRANTY I Five years parts and seven years compressor.
SEZ STATIC PERFORMANCE CURVES
Presión estática externa [pulg.WG]
SEZ-KD09NA4
(Presión estática externa de 0.06[pulg.WG]) 208/230V 60Hz
0
Tasa de flujo de aire [pies3/min]
[141][176] [212][247] [282][318] [353]
Presión estática externa [pulg.WG]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
Medio
Baja
Alta
Límite
Punto nominal
0
Tasa de flujo de aire [pies3/min]
Presión estática externa [pulg.WG]
SEZ-KD09NA4
(Presión estática externa de 0.02[pulg.WG]) 208/230V 60Hz
Medio
Baja
Alta
Rated point
Límite
[0.16]
[0.12]
[0.08]
[0.04]
[141] [176] [212] [247] [282] [318] [353][141] [176] [212] [247] [282] [318] [353]
0
Presión estática externa [pulg.WG]
SEZ-KD09NA4
(Presión estática externa de 0.20[pulg.WG]) 208/230V 60Hz
Tasa de flujo de aire [pies3/min]
[141] [176] [212] [247] [282] [318] [353]
Medio
Baja
Alta
Límite
Punto nominal
[0.32]
[0.28]
[0.24]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
[353]
Presión estática externa [pulg.WG]
SEZ-KD09NA4
(Presión estática externa de 0.06[pulg.WG]) 208/230V 60Hz
0
Tasa de flujo de aire [pies3/min]
[141][176] [212][247] [282][318] [353]
Presión estática externa [pulg.WG]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
Medio
Baja
Alta
Límite
Punto nominal
Presión estática externa [pulg.WG]
Presión estática externa [pulg.WG]
][
][
SEZ-KD12NA4
(Presión estática externa de 0.06[pulg.WG]) 208/230V 60Hz
0
Presión estática externa [pulg.WG]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
Tasa de flujo de aire [pies3/min]
[212][282][247][353] [388][318][424]
Medio
Baja
Alta
Límite
Punto nominal
SEZ-KD12NA4
(Presión estática externa de 0.02[pulg.WG]) 208/230V 60Hz
0
Presión estática externa [pulg.WG]
[0.16]
[0.12]
[0.08]
[0.04]
Tasa de flujo de aire [pies3/min]
[212] [282][247] [353] [388][318] [424]
Medio
Baja
Alta
Límite
Punto nominal
0
SEZ-KD12NA4
(Presión estática externa de 0.20[pulg.WG]) 208/230V 60Hz
Presión estática externa [pulg.WG]
[0.32]
[0.28]
[0.24]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
Tasa de flujo de aire [pies3/min]
[212][282][247][353] [388][318][424]
Medio
Baja
Alta
Límite
Punto nominal
Presión estática externa [pulg.WG]
[424]
SEZ-KD12NA4
(Presión estática externa de 0.06[pulg.WG]) 208/230V 60Hz
0
Presión estática externa [pulg.WG]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
Tasa de flujo de aire [pies3/min]
[212][282][247][353] [388][318][424]
Medio
Baja
Alta
Límite
Punto nominal
Presión estática externa [pulg.WG]
][
][
Presión estática externa [pulg.WG]
SEZ-KD15NA4
(Presión estática externa de 0.06[pulg.WG]) 208/230V 60Hz
0
Presión estática externa [pulg.WG]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
Tasa de flujo de aire [pies3/min]
[282][318] [353][388] [424][494][459][530] [565]
Alta
Límite
Punto nominal
Medio
Baja
SEZ-KD15NA4
(Presión estática externa de 0.02[pulg.WG]) 208/230V 60Hz
Tasa de flujo de aire [pies3/min]
0
Presión estática externa [pulg.WG]
[0.16]
[0.12]
[0.08]
[0.04]
[282] [318] [353] [388] [424] [494][459] [530] [565]
Middle
Baja
Alta
Límite
Punto nominal
SEZ-KD15NA4
(Presión estática externa de 0.20[pulg.WG]) 208/230V 60Hz
0
10
20
30
40
50
60
70
80
Presión estática externa [pulg.WG]
[0.32]
[0.28]
[0.24]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
Tasa de flujo de aire [pies3/min]
[282][318] [353][388] [424][494][459][530] [565]
Medio
Baja
Alta
Límite
Punto nominal
Presión estática externa [pulg.WG]
SEZ-KD15NA4
(Presión estática externa de 0.06[pulg.WG]) 208/230V 60Hz
0
Presión estática externa [pulg.WG]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
Tasa de flujo de aire [pies3/min]
[282][318] [353][388] [424][494][459][530] [565]
Alta
Límite
Punto nominal
Medio
Baja
Presión estática externa [pulg.WG]
Presión estática externa [pulg.WG]
SEZ-KD18NA4
(Presión estática externa de 0.06[pulg.WG]) 208/230V 60Hz
0
10
20
30
40
50
Presión estática externa [pulg.WG]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
[318] [353] [388] [424] [494][459] [530] [565] [600] [671][636]
Medio
Baja
Alta
Límite
Punto nominal
Tasa de flujo de aire [pies3/min]
SEZ-KD18NA4
(Presión estática externa de 0.02[pulg.WG]) 208/230V 60Hz
Tasa de flujo de aire [pies3/min]
0
Presión estática externa [pulg.WG]
[0.16]
[0.12]
[0.08]
[0.04]
[318] [353] [388] [424] [494][459] [530] [565] [600] [671][636]
Medio
Baja
Alta
Límite
Punto nominal
SEZ-KD18NA4
(Presión estática externa de 0.20[pulg.WG]) 208/230V 60Hz
0
Presión estática externa [pulg.WG]
[0.32]
[0.28]
[0.24]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
[318] [353] [388] [424] [494][459] [530] [565] [600] [671][636]
Medio
Límite
Punto nominal
Baja
Alta
Tasa de flujo de aire [pies3/min]
Presión estática externa [pulg.WG]
SEZ-KD18NA4
(Presión estática externa de 0.06[pulg.WG]) 208/230V 60Hz
0
10
20
30
40
50
Presión estática externa [pulg.WG]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
[318] [353] [388] [424] [494][459] [530] [565] [600] [671][636]
Medio
Baja
Alta
Límite
Punto nominal
Tasa de flujo de aire [pies3/min]
Presión estática externa [pulg.WG]
SEZ-KD09NA4
(Presión estática externa de 0.06[pulg.WG]) 208/230V 60Hz
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
SEZ-KD12NA4
(Presión estática externa de 0.06[pulg.WG]) 208/230V 60Hz
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
SEZ-KD15NA4
(Presión estática externa de 0.06[pulg.WG]) 208/230V 60Hz
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
SEZ-KD18NA4
(Presión estática externa de 0.06[pulg.WG]) 208/230V 60Hz
Baja
0
[141][176] [212][247] [282][318] [353]
0
[212][282][247
0
[282][318] [353][388] [424][494][459][530] [565]
50
[0.20]
40
[0.16]
30
[0.12]
20
[0.08]
10
[0.04]
0
[318] [353] [388] [424] [494][459] [530] [565] [600] [671][636]
Tasa de flujo de aire [pies3/min]
Baja
Tasa de flujo de aire [pies3/min]
Baja
Tasa de flujo de aire [pies3/min]
Baja
Tasa de flujo de aire [pies3/min]
Medio
Medio
Medio
Medio
SEZ-KD09NA4
(Presión estática externa de 0.14[pulg.WG]) 208/230V 60Hz
80
Límite
Alta
Punto nominal
Límite
Alta
Punto nominal
353] [388][318
Límite
Alta
Punto nominal
Límite
Alta
Punto nominal
[0.32]
70
[0.28]
60
[0.24]
50
[0.20]
40
[0.16]
30
[0.12]
20
[0.08]
10
[0.04]
0
[141] [176] [212] [247] [282] [318]
SEZ-KD12NA4
(Presión estática externa de 0.14[pulg.WG]) 208/230V 60Hz
[0.32]
[0.28]
[0.24]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
0
[212] [282][247] [353] [388][318]
424]
SEZ-KD15NA4
(Presión estática externa de 0.14[pulg.WG]) 208/230V 60Hz
[0.32]
[0.28]
[0.24]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
SEZ-KD18NA4
(Presión estática externa de 0.14[pulg.WG]) 208/230V 60Hz
[0.32]
[0.28]
[0.24]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
0
[282] [318] [353] [388] [424] [494][459] [530] [565]
0
[318] [353] [388] [424] [494][459] [530] [565] [600] [671][636]
Baja
Tasa de flujo de aire [pies3/min]
Baja
Tasa de flujo de aire [pies3/min]
Baja
Tasa de flujo de aire [pies3/min]
Baja
Tasa de flujo de aire [pies3/min]
SEZ-KD09NA4
(Presión estática externa de 0.20[pulg.WG]) 208/230V 60Hz
[0.32]
[0.28]
[0.24]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
0
[141] [176] [212] [247] [282] [318] [353]
SEZ-KD12NA4
(Presión estática externa de 0.20[pulg.WG]) 208/230V 60Hz
[0.32]
[0.28]
[0.24]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
0
[212][282][247
SEZ-KD15NA4
(Presión estática externa de 0.20[pulg.WG]) 208/230V 60Hz
80
[0.32]
70
[0.28]
60
[0.24]
50
[0.20]
40
[0.16]
30
[0.12]
20
[0.08]
10
[0.04]
0
[282][318] [353][388] [424][494][459][530] [565]
SEZ-KD18NA4
(Presión estática externa de 0.20[pulg.WG]) 208/230V 60Hz
[0.32]
[0.28]
[0.24]
[0.20]
[0.16]
[0.12]
[0.08]
[0.04]
0
[318] [353] [388] [424] [494][459] [530] [565] [600] [671][636]
Medio
Baja
Tasa de flujo de aire [pies3/min]
Baja
Tasa de flujo de aire [pies3/min]
Baja
Tasa de flujo de aire [pies3/min]
Baja
Tasa de flujo de aire [pies3/min]
Medio
Medio
Límite
Punto nominal
Punto nominal
Medio
Medio
Alta
Límite
Alta
Límite
Alta
Punto nominal
Límite
Alta
Punto nominal
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 37
Límite
Punto nominal
Medio
Medio
Alta
Límite
Punto nominal
353] [388][318
Límite
Punto nominal
Límite
Medio
Alta
424]
Alta
Alta
Punto nominal
SINGLE-ZONE
SLZ System
I
Heat Pump
I
Model Name
Rated Capacity Btu/h 8,400 11,100 15,000
Capacity Range Btu/h 3,100-10,900 3,400-13,300 3,800-17,700
Cooling *1
Heating at 47° F *2
Heating at 17° F *3
Power Supply Phase, Cycle, Voltage 1 Phase, 60Hz, 208 / 230V *4
Voltage
Indoor Unit
Remote Controller Type
Outdoor Unit
Refrigerant
Refrigerant Pipe
Refrigerant Pipe Length
Connection Method Indoor/Outdoor Flared/Flared
Total Input W 700 920 1,460
Energy Efficiency SEER 15 15.4 16
Moisture Removal Pints/h 1.2 2.3 4.5
Sensible Heat Factor 0.84 0.77 0.67
Rated Capacity Btu/h 10,900 13,600 18,000
Capacity Range Btu/h 3,100-14,100 3,100-17,100 3,100-22,000
Total Input W 930 1,180 1,950
HSPF (IV) Btu/h/W 9.6
Rated Capacity Btu/h 6,200 8,300 10,200
Rated Total Input W 740 930 1,310
Maximum Capacity Btu/h 6,200 8,300 12,000
Indoor - Outdoor S1 - S2 AC 208-230V
Indoor - Outdoor S2 - S3 DC ±24V
MCA A 1
Fan Motor (ECM) F.L.A. 0.23 0.28 0.28
Airflow at Cooling/Heating (Lo-Med-Hi)
Sound Pressure Level dB(A) 29-32-38 30-34-39 31-35-40
External Finish Galvanized-Steel Sheets; Grille: Munsell 6.4Y 8.9/0.4
Dimension Unit (Grille)
Weight Unit (Grille) Lbs. 36 (7)
Drain-lift Mechanism (Included) H: In. 19-11/16
Field Drainpipe Size O.D. In. 1-1/4
MCA A 12
MOCP A 15
Fan Motor (ECM) F.L.A. 0.50
Compressor
Airflow (Cooling/Heating) CFM 1,151/1,225 1,229/1,172 1,243/1,229
Refrigerant Control Linear Expansion Valve
Defrost Method Reverse Cycle
Sound Pressure Level at Cooling *1 dB(A) 46 49
Sound Pressure Level at Heating *2 dB(A) 50 51
External Finish Color Munsell No. 3Y 7.8/1.1
Dimensions
Weight Lbs. 66 77 80
Type R410A
Charge Lbs., Oz. 2 2, 9
Oil Type (fl. oz.) NEO22 (10.8) NEO22 (15.2)
Gas Side O.D. In. 3/8 1/2
Liquid Side O.D. In. 1/4
Height Difference (Max.) Ft. 40
Length (Max.) Ft. 65
Indoor Unit SLZ-KA09NA SLZ-KA12NA SLZ-KA15NA
Outdoor Unit SUZ-KA09NA SUZ-KA12NA SUZ-KA15NA
DRY (CFM) 280-320-350 280-320-390 280-320-390
WET (CFM) 250-290-320 250-290-350 250-290-350
W: In. 22-7/16 (25-5/8)
D: In. 22-7/16 (25-5/8)
H: In. 9-1/4 (13/16)
Select from PAC-WHS01WF-E for kumo cloud™, PAC-US444CN-1, MHK1, PAR-32MAA, or PAC-
Model (Type) DC INVERTER-driven DC INVERTER-driven Twin Rotary
R.L.A. 6.6 7.4
L.R.A. 8.2 9.3
W: In. 31-1/2
D: In. 11-1/4
H: In. 21-5/8
YT53CRAU Remote Controllers
NOTES: Test conditions are based on AHRI 210/240.
*1. Rating conditions (cooling)-Indoor: D.B. 80º F (27º C), W.B. 67º F (19º C);
Outdoor: D.B. 95º F (35º C), W.B. 75º F (24º C).
*2. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C);
Outdoor: D.B. 47º F (8º C), W.B. 43º F (6º C).
*3. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C);
Outdoor: D.B. 17º F (-8º C), W.B. 15º F (-9º C).
*4. Indoor units receive power from outdoor units through field-supplied interconnected wiring.
38 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
Note: ESP at 208/230V, 60 Hz. See manual for Static Performance Curve, including at 0.02 in W.G.
Specifications are subject to change without notice.
LIMITED WARRANTY I Five years parts and seven years compressor.
MULTI-ZONE
MXZ-C
I
Heat Pump
I
Model Name Outdoor Unit MXZ-3C24NA *5 MXZ-3C30NA MXZ-4C36NA-1 *6 MXZ-5C42NA MXZ-8C48NA*8
Cooling *1 Nonducted/Ducted
Heating at 47° F
Indoor Unit
Power Supply Phase, Cycle, Voltage 1-phase, 60Hz, 208 / 230V *7
Voltage
Outdoor Unit *4
Indoor Unit No. of Units 2 2, 3 2, 3 2,3,4,5 2,3,4,5,6,7,8
Remote Controller Type Associated with the Indoor Unit
Refrigerant
Refrigerant Pipe
Max Refrigerant Line Length Height Difference (Max.) Ft. 230 492
Max. Piping Length for Each Indoor Unit 82 262
Max. Refrigerant
Pipe Height Difference
Connection Method Indoor/Outdoor Flared/Flared
NOTES: Test conditions are based on AHRI 210/240. One indoor unit is turned off during low-speed testing under the
new test conditions. Systems actually exhibit higher energy efficiencies during normal operation.
*1. Rating conditions (cooling)-Indoor: D.B. 80º F (27º C), W.B. 67º F (19º C);
Outdoor: D.B. 95º F (35º C), W.B. 75º F (24º C).
*2. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C);
Outdoor: D.B. 47º F (8º C), W.B. 43º F (6º C).
*3. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C);
Outdoor: D.B. 17º F (-8º C), W.B. 15º F (-9º C).
*4. Refer to pages 37-40 for Indoor Unit specifications.
*2 Non-ducted/
Ducted
Heating at 17° F
*3 Non-ducted/
Ducted
Heating at 5° F Maximum Capacity Btu/h 18,200 18,200 24,000 26,000 32,400
Rated Capacity Btu/h 22,000 / 23,600 28,400 / 27,400 35,400 / 34,400 40,500 / 37,500 48,000 / 48,000
Capacity Range Btu/h
Rated Total Input W 1,620 / 2,100 2,680 / 2,840 3,760 / 3,940 4,403 / 4,112 4,000 / 5,050
Rated Capacity Btu/h 25,000 / 24,600 28,600 / 27,600 36,000 / 34,400 45,000 / 41,000 54,000 / 54,000
Capacity Range Btu/h
Rated Total Input W 1,750 / 1,900 2,150 / 2,220 3,020 / 3,100 3,575 / 3,463 4,220 / 4,990
Rated Capacity Btu/h 14,000 / 14,000 16,000 / 15,100 22,200 / 20,300 24,400 / 23,000 36,600 / 36,600
Maximum Capacity Btu/h 19,600 / 19,600 21,000 / 21,000 26,600 / 26,600 30,500 / 29,100 36,600 / 36,600
Rated Total Input W 2,120 / 2,230 2,120 / 2,140 3,340 / 3,450 2,943 / 2,869 3,720 / 4,420
Indoor - Outdoor S1 - S2 AC 208 / 230V
Indoor - Outdoor S2 - S3 DC ±24V
MCA A 22.1 22.1 31.9 37
MOCP A 25 40 52
Fan Motor (ECM) F.L.A. 1.90 0.4+0.4
Compressor
Airflow (Cooling/Heating) CFM 1,485 / 1,640 2,068 / 1,605 1,365 / 1,605 2,118 / 2,542 3,885
Refrigerant Control Linear Expansion Valve
Defrost Method Reverse Cycle
Sound Pressure Level at
Cooling *1
Sound Pressure Level at
Heating *2
External Finish Color Munsell No. 3.0Y 7.8 / 1.1
Dimensions
Weight Lbs. 135 137 189 269
Type R410A
Charge Lbs., Oz. 6, 13 8, 13 10, 9
Oil Type (fl. oz.) FV50S (24.7) FV50S (37.4) FV50S (73)
Gas Side O.D. In. A: 1/2; B: 3/8 A: 1/2; B,C: 3/8 A: 1/2; B,C,D: 3/8 A: 1/2; B,C,D,E: 3/8 5/8
Liquid Side O.D. In. 1/4 3/8
If IDU is Above ODU Ft. 49 131
If IDU is Below ODU Ft. 49 164
Model (Type) DC INVERTER-driven Twin Rotary
12,600-22,000 / 12,600-
25,500
11,400-30,600 / 11,400-
29,400
R.L.A. 12 20 19
L.R.A. 13.7 28.8 22
dB(A) 51 52 54 56 51
dB(A) 55 56 58 54
W: In. 37-13/32 41-11/32
D: In. 13 13
H: In. 31-11/32 41-9/32 52-11/16
12,600-28,400 /
12,600-27,400
11,400-36,000 /
11,400-35,000
*5. Data from combination of two Indoor Units 6,000 Btu/h and one 9,000 Btu/h
(non-ducted) or three 9,000 Btu/h (ducted).
*6. Data from combination of four Indoor Units 9,000 Btu/h (non-ducted and ducted).
*7. Indoor units receive power from outdoor units through field-supplied interconnected wiring.
*8. MXZ-8C48NA require branch box for operation.
Specifications are subject to change without notice.
LIMITED WARRANTY | Five years parts and seven years compressor.
12,600-36,400 /
12,600-34,800
11,400-43,000 /
11,400-41,400
6,000 - 43,000 6,000-48,000
7,200 - 53,600 7,200 - 54,000
Model Name PAC-MKA30BC PAC-MKA50BC
Connectable No. of Indoor Units 3 5
Power Supply Phase, Cycle, Voltage 1 Phase, 60Hz, 208 / 230V
Power Input W 3
Current A 0.05
External Finish Galvanized-Steel Sheets
Width In. 17-2 3/32
Dimensions
Net Weight Lbs. 15 16
Refrigerant Pipe
Dimensions
Depth In. 11-1/32
Height In. 6-11/16
Outdoor Unit to
Branch Box
Branch Box to
Indoor Units
Gas (In.) 5/8
Liquid (In.) 3/8
Gas (In.) A,B,C: 3/8 A, B, C, D: 3/8; E: 1/2
Liquid (In.) A,B,C: 1/4 A, B, C, D, E: 1/4
PAC-MKA50BC
PAC-MKA30BC
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 39
MULTI-ZONE I MXZ-C I H2i Heat Pump
Model Name Outdoor Unit MXZ-2C20NAHZ MXZ-3C24NAHZ MXZ-3C30NAHZ MXZ-4C36NAHZ*6 MXZ-5C42NAHZ*6 MXZ-8C48NAHZ*6
Cooling *1 Nonducted/Ducted
Heating at 47° F
Indoor Unit
Power Supply Phase, Cycle, Voltage 1-phase, 60Hz, 208 / 230V *5
Voltage
Outdoor Unit *4
Indoor Unit No. of Units 2 2, 3 2, 3 2,3,4 2,3,4,5 2,3,4,5,6,7,8
Remote Controller Type Associated with the Indoor Unit
Refrigerant
Refrigerant Pipe
Max Refrigerant Line Length
Max. Piping Length for Each Indoor Unit 82 262
Max. Refrigerant
Pipe Height Difference
Connection Method Indoor/Outdoor Flared/Flared
NOTES: Test conditions are based on AHRI 210/240. One indoor unit is turned off during low-speed testing under the
new test conditions. Systems actually exhibit higher energy efficiencies during normal operation.
*1. Rating conditions (cooling)-Indoor: D.B. 80º F (27º C), W.B. 67º F (19º C);
Outdoor: D.B. 95º F (35º C), W.B. 75º F (24º C).
*2. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C);
Outdoor: D.B. 47º F (8º C), W.B. 43º F (6º C).
*3. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C);
Outdoor: D.B. 17º F (-8º C), W.B. 15º F (-9º C).
Connectable No. of Indoor Units 3 5
Power Supply Phase, Cycle, Voltage 1 Phase, 60Hz, 208 / 230V
Power Input W 3
Current A 0.05
External Finish Galvanized-Steel Sheets
Dimensions
Net Weight Lbs. 15 16
Refrigerant Pipe
Dimensions
LIMITED WARRANTY | Seven-year warranty on compressor. Five-year warranty on parts.
*2 Non-ducted/
Ducted
Heating at 17° F
*3 Non-ducted/
Ducted
Heating at 5° F Maximum Capacity Btu/h 22,000 25,000 28,600 45,000 48,000 54,000
Model Name PAC-MKA30BC PAC-MKA50BC
Width In. 17-2 3/32
Depth In. 11-1/32
Height In. 6-11/16
Outdoor Unit to
Branch Box
Branch Box to
Indoor Units
Rated Capacity Btu/h 18,000 / 20,000 22,000 / 23,600 28,400 / 27,400 36,000 / 36,000 42,000 / 42,000 48,000 / 48,000
Capacity Range Btu/h 6,000 - 20,000 6,000 - 23,600 12,600 - 28,400 6,000 - 36,000 6,000 - 42,000 6,000 - 48,000
Rated Total Input W 1,334 / 1,819 1,630 / 2,360 2,272 / 2,661 2,570 / 3,180 3,130 / 3,890 4,000 / 5,050
Rated Capacity Btu/h 22,000 / 22,000 25,000 / 24,600 28,600 / 27,600 45,000 / 45,000 48,000 / 48,000 54,000 / 54,000
Capacity Range Btu/h 7,400 - 25,500 7,200 - 30,600 11,400 - 36,000 7,200 - 45,000 7,200 - 48,000 7200 - 54,000
Rated Total Input W 1,612 / 1,748 1,725 / 1,871 2,096 / 2,187 3,340 / 4,250 3,430 / 4,350 4,220 / 4,990
Rated Capacity Btu/h 13,700 / 13,700 14,000 / 14,000 18,000 / 16,500 34,000 / 36,000 35,800 / 36,600 40,000 / 43,000
Maximum Capacity Btu/h 22,000 / 22,000 25,000 / 24, 600 28,600 / 27, 600 45,000 / 45,000 48,000 / 48,000 54,000 / 54,000
Rated Total Input W 1,450 / 1,588 1,622 / 1,635 1,991 / 1,993 3,500 / 4,590 3,650 / 4,290 4,340 / 5,250
Indoor - Outdoor S1 - S2 AC 208 / 230V
Indoor - Outdoor S2 - S3 DC ±24V
MCA A 29 30 42
MOCP A 40 52
Fan Motor (ECM) F.L.A. 1.90 0.4+0.4
Compressor
Airflow
(Cooling/Heating)
Refrigerant Control Linear Expansion Valve
Defrost Method Reverse Cycle
Sound Pressure
Level at Cooling *1
Sound Pressure
Level at Heating *2
External Finish Color Munsell No. 3.0Y 7.8 / 1.1
Dimensions
Weight Lbs. 187 189 276
Type R410A
Charge Lbs., Oz. 6, 13 10, 9
Oil
Gas Side O.D. In. A,B: 3/8 A: 1/2; B,C: 3/8 A: 1/2; B,C: 3/8 5/8
Liquid Side O.D. In. 1/4 3/8
Height Difference
(Max.)
If IDU is Above ODU Ft. 49 131
If IDU is Below ODU Ft. 49 164
Model
(Type)
R.L.A. 12 19
L.R.A. 28.8 22
CFM 2,118 / 2,542 2,118 / 2542 2,224 / 2,542 3,885 / 3,885
dB(A) 54 49 50 51
dB(A) 58 53 54 54
W: In. 37-13/32 41-11/32
D: In. 13
H: In. 41-9/32 52-11/16
Type
(fl. oz.)
Ft. 164 230 492
FV50S (24.7) FV50S (37.4) FV50S (73)
*4. Refer to pages 35-39 for Indoor Unit specifications.
*5. Indoor units receive power from outdoor units through field-supplied interconnected wiring.
*6. MXZ-4C36NAHZ, MXZ-5C42NAHZ and MXZ-8C48NAHZ require branch box for operation.
Specifications are subject to change without notice.
LIMITED WARRANTY | Five years parts and seven years compressor.
DC INVERTER-driven Twin Rotary
Only a single lineset is
needed from the outdoor
PAC-MKA50BC
unit to branch box.
Branch Boxes: (At least
one branch box required)
Gas (In.) 5/8
Liquid (In.) 3/8
Gas (In.) A,B,C: 3/8 A, B, C, D: 3/8; E: 1/2
Liquid (In.) A,B,C: 1/4 A, B, C, D, E: 1/4
PAC-MKA30BC
40 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 40
MULTI-ZONE I MSZ Indoor Units I Heat Pump
(FOR MXZ-C OUTDOOR UNITS)
Model Name Indoor Unit MSZ-FH06NA MSZ-FH09NA MSZ-FH12NA MSZ-FH15NA MSZ-FH18NA2
Cooling *1 Rated Capacity Btu/h 6,000 9,000 12,000 15,000 17,200
Heating at
47° F *2
Power Supply Phase, Cycle, Voltage 1-phase, 60Hz, 208 / 230V *3
Voltage
Fan
Rated Capacity Btu/h 8,700 10,900 13,600 18,000 20,300
Indoor - Outdoor S1 - S2 AC 208 / 230V
Indoor - Outdoor S2 - S3 DC ±24V
MCA A 1.0
Blower Motor F.L.A. 0.76 0.67
Airflow at Cooling
(Quiet-Lo-Med-HiSuper Hi)*1
DRY
(CFM)
WET
(CFM)
137-167-221-304-381 137-167-221-304-381 137-167-221-304-398 225-262-304-355-411 225-262-304-355-459
117-143-190-261-328 117-143-190-261-328 117-143-190-261-342 194-225-261-305-354 194-225-261-305-395
Airflow at Heating
(Quiet-Lo-Med-HiSuper Hi) *2
Sound Pressure Level at Cooling
(Quiet-Lo-Med-Hi-Super Hi) *1
Sound Pressure Level at Heating
(Quiet-Lo-Med-Hi-Super Hi) *2
External Finish Color Munsell 1.0Y 9.2 / 0.2
Dimension Unit
Weight Unit Lbs. 29
Field Drainpipe Size O.D. In. 5/8
Remote
Controller
Refrigerant Type R410A
Refrigerant Pipe
Connection
Method
NOTES: Test conditions are based on AHRI 210/240.
NOTES: Test conditions are based on AHRI 210/240.
*1. Rating conditions (cooling)-Indoor: D.B. 80º F (27º C), W.B. 67º F (19º C); Outdoor: D.B. 95º F (35º C), W.B. 75º F (24º C).
*2. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C); Outdoor: D.B. 47º F (8º C), W.B. 43º F (6º C).
*3. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C); Outdoor: D.B. 17º F (-8º C), W.B. 15º F (-9º C).
Specifications are subject to change without notice.
LIMITED WARRANTY I Five years parts and seven years compressor.
For data on specific indoor unit combinations, visit www.mitsubishipro.com/multizone.
Type Select from PAC-WHS01WF-E for kumo cloud™, PAC-US444CN-1, MHK1, PAR-31MAA, or PAC-YT53CRAU Remote Controllers
Gas Side O.D. In. 3/8 1/2
Liquid Side O.D. In. 1/4
Indoor/Outdoor Flared/Flared
DRY
(CFM)
dB(A) 20-23-29-36-40 20-23-29-36-40 21-24-29-36-41 27-31-35-39-47 20-23-29-36-40
dB(A) 20-24-29-36-42 20-24-29-36-42 21-24-29-36-42 25-29-34-39-46 20-24-29-36-42
W: In. 36-7/16
D: In. 9-3/16
H: In. 12(+11/16)
140-167-225-325-437 140-167-225-325-437 140-167-225-325-454 201-254-317-394-497 201-254-317-394-514
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 41
MULTI-ZONE I MSZ Indoor Units I Heat Pump
(FOR MXZ-C OUTDOOR UNITS)
Model Name Indoor Unit MSZ-GL06NA-U1 MSZ-GL09NA-U1 MSZ-GL12NA-U1 MSZ-GL15NA-U1 MSZ-GL18NA-U1 MSZ-GL24NA-U1
Cooling *1 Rated Capacity Btu/h 6,000 9,000 12,000 14,000 17,200 22,400
Heating at
47° F *2
Power Supply Phase, Cycle, Voltage 1-phase, 60Hz, 208 / 230V *3
Voltage
Rated Capacity Btu/h 7,200 10,900 14,400 18,000 21,600 27,600
Indoor - Outdoor S1 - S2 AC 208 / 230V
Indoor - Outdoor S2 - S3 DC ±24V
MCA A 1.0
Blower Motor F.L.A. 0.76 0.67 0.76
Airflow at Cooling
(Quiet-Lo-Med-Hi-
Fan
Sound Pressure Level at Cooling
(Quiet-Lo-Med-Hi-Super Hi) *1
Sound Pressure Level at Heating
(Quiet-Lo-Med-Hi-Super Hi) *2
External Finish Color Munsell 1.0Y 9.2 / 0.2
Dimension Unit
Weight Unit Lbs. 22 28 37
Field Drainpipe Size O.D. In. 5/8
Remote
Controller
Refrigerant Type R410A
Refrigerant Pipe
Connection
Method
Super Hi)*1
Airflow at Heating
(Quiet-Lo-Med-HiSuper Hi) *2
Type Select from PAC-WHS01WF-E for kumo cloud™, PAC-US444CN-1, MHK1, PAR-31MAA, or PAC-YT53CRAU Remote Controllers
Gas Side O.D. In. 3/8 1/2 5/8
Liquid Side O.D. In. 1/4 3/8
Indoor/Outdoor Flared/Flared
DRY (CFM) 145-170-237-321-399 145-170-237-321-399 205-272-335-420-533 259-333-416-523-646 388-469-544-628-738
WET
(CFM)
DRY
(CFM)
dB(A) 19-22-30-37-43 19-22-30-37-45 26-32-38-44-49 28-33-38-44-49 34-41-45-49-53
dB(A) 19-22-30-37-43 19-22-30-37-43 26-30-35-40-46 28-33-38-43-48 32-41-45-49-52
W: In. 31-7/16 36-5/16 43-5/16
D: In. 9-1/8 9-13/16 9-3/8
H: In. 11-5/8 12 12-13/16
109-134-201-286-364 109-134-201-286-364 170-237-300-385-498 233-300-375-470-581 347-420-487-562-661
145-170-237-321-406 145-170-237-321-406 205-247-304-367-463 296-384-469-563-646 388-469-544-628-738
NOTES: Test conditions are based on AHRI 210/240.
*1. Rating conditions (cooling)-Indoor: D.B. 80º F (27º C), W.B. 67º F (19º C); Outdoor: D.B. 95º F (35º C), W.B. 75º F (24º C).
*2. Rating conditions (heating)-Indoor: D.B. 70º F (21º C), W.B. 60º F (16º C); Outdoor: D.B. 47º F (8º C), W.B. 43º F (6º C).
*3. Indoor units receive power from outdoor units through field-supplied wiring.
Specifications are subject to change without notice.
LIMITED WARRANTY I Seven-year warranty on compressor. Five-year warranty on parts.
For data on specific indoor unit combinations, visit www.mitsubishipro.com/multizone.
42 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 42
SEZ Ducted Indoor Unit I Heat Pump
(FOR MXZ-C OUTDOOR UNITS)
Model Name Indoor Unit SEZ-KD09NA4 SEZ-KD12NA4 SEZ-KD15NA4 SEZ-KD18NA4
Cooling *1 Rated Capacity Btu/h 8,100 11,500 14,100 17,200
Heating at 47˚ F *2 Rated Capacity Btu/h 10,900 13,600 18,000 21,600
Power Supply Phase, Cycle, Voltage 1-Phase, 60Hz, 208 / 230V *4
Indoor - Outdoor S1-S2 AC 208-230V
Voltage
Fan
Sound Pressure Levels (Lo-Med-Hi) dB(A) 23-26-30 23-28-33 30-34-37 30-34-38
External Finish Galvanized-steel Sheets
Dimension
Weight Lbs. 42 50 54 62
Drain-lift Mechanism (Included) H: In. 21-11/16
Field Drainpipe Size O.D. In. 1-1/4
Remote Controller Type
Indoor - Outdoor S2-S3 DC ±24V
MCA A 1.0
Blower Motor (ECM) F.L.A. 0.51 0.57 0.74
Airflow at Cooling/Heating
(Lo-Med-Hi)
External Static Pressure *3 In. W.G. 0.02-0.06-0.14-0.20
CFM 194-247-317 247-317-388 353-441-529 423-529-635
W: In. 31-1/8 39 46-7/8
D: In. 27-9/16
H: In. 7-7/8
Select from PAC-WHS01WF-E for kumo cloud™, PAC-US444CN-1, MHK1, PAR-32MAA, or PAC-YT53CRAU Remote
Controllers
Refrigerant Type R410A
Refrigerant Pipe
Connection Method Flared/Flared
vvConnection Method Flared/Flared
NOTES: Test conditions are based on AHRI 210/240.
*1. Rating conditions (cooling)-Indoor: D.B. 80º F (26.7º C), W.B. 67º F (19.4º C); Outdoor: D.B. 95º F (35º C), W.B. 75º F (23.9º C).
*2. Rating conditions (heating)-Indoor: D.B. 70º F (21.1º C), W.B. 60º F (15.6º C); Outdoor: D.B. 47º F (8.3º C), W.B. 43º F (6.1º C).
*3. External static pressure is factory set to 0.06" W.G. Adjustable via remote controller.
*4. Indoor units receive power from outdoor units through field supplied interconnected wiring.
Specifications are subject to change without notice.
LIMITED WARRANTY I Five years parts and seven years compressor.
Gas Side O.D.
Liquid Side O.D. 1/4
In.
3/8 1/2
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 43
MVZ Multi-Position Air-Handling Unit I Heat Pump
(FOR MXZ-C OUTDOOR UNITS)
Model Name Indoor Unit MVZ-A12AA4 MVZ-A18AA4 MVZ-A24AA4 MVZ-A30AA4 MVZ-A36AA4
Cooling *1 Rated Capacity Btu/h 12,000 18,000 24,000 30,000 36,000
Heating at 47° F *2 Rated Capacity Btu/h 13,500 20,000 27,000 34,000 40,000
Power Supply Phase, Cycle, Voltage 1-phase, 60Hz, 208 / 230V
Indoor - Outdoor S1-S2 AC 208-230V
Voltage
Fan
Sound Pressure Level at Cooling/Heating
(Lo-Med-Hi) *1
External Finish Color High-gloss polyester powder coated
Dimension Unit
Weight Unit Lbs. 113 141
Refrigerant Type R410A
Refrigerant Pipe
Connection Method Indoor/Outdoor Flared/Flared
Indoor - Outdoor S2-S3 ±24VDC
MCA A 1.0
Airflow at Cooling/Heating
(Lo-Med-Hi)
External Static Pressure *3 In. W.G. 0.30-0.50-0.80
Gas Side O.D. In. 1/2 5/8
Liquid Side O.D. In. 1/4 3/8
CFM 280-340-400 410-497-585 515-625-735 613-744-875 767-931-1095
dB(A) 27-31-35 28-32-36 30-34-38 32-36-40 35-39-43
W: In. 50-1/4 54-1/4
D: In. 17 54-1/4
H: In. 21-5/8
NOTES: Test conditions are based on AHRI 210/240.
*1. Rating conditions (cooling)-Indoor: D.B. 80º F (26.7º C), W.B. 67º F (19.4º C); Outdoor: D.B. 95º F (35º C), W.B. 75º F (23.9º C).
*2. Rating conditions (heating)-Indoor: D.B. 70º F (21.1º C), W.B. 60º F (15.6º C); Outdoor: D.B. 47º F (8.3º C), W.B. 43º F (6.1º C).
*3. External static pressure is factory set to 0.05" W.G. at factory shipment.
Specifications are subject to change without notice.
LIMITED WARRANTY I Five years parts and seven years compressor.
44 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
MVZ MULTI-POSITION PERFORMANCE CURVES
MVZ-A12AA4
• Vertical, Horizontal Right, Horizontal Left • Downflow
External static pressure 0.30 [in.WG] (75Pa) 208/230V 60Hz
100
[0.40]
External static pressure 0.30 [in.WG] (75Pa) 208/230V 60Hz
100
[0.40]
[0.30]
[0.20]
Static pressure (Pa)[in.WG]
[0.10]
[0.60]
[0.50]
[0.40]
Static pressure (Pa)[in.WG]
[0.30]
[0.20]
75
50
Middle
High
Low
25
0
[0]
7
[247]
External static pressure 0.50 [in.WG] (125Pa) 208/230V 60Hz
150
125
100
10
[353]
Airflow rate (m
3
/min)[cfm]
High
Middle
75
Low
50
[247]
7
10
[353]
Airflow rate (m
3
/min)[cfm]
[494]
[494]
75
[0.30]
50
[0.20]
Static pressure (Pa)[in.WG]
25
[0.10]
0
[0.60]
[0.50]
[0.40]
[0]
[247]
150
125
100
14
Low
7
[353]
Airflow rate (m
External static pressure 0.50 [in.WG] (125Pa) 208/230V 60Hz
High
Middle
10
3
/min)[cfm]
[494]
14
High
Middle
75
[0.30]
Static pressure (Pa)[in.WG]
[247]
Low
7
10
[353]
Airflow rate (m
3
/min)[cfm]
[494]
14
50
[0.20]
25
14
[0.10]
[0.90]
[0.80]
[0.70]
[0.60]
Static pressure (Pa)[in.WG]
[0.50]
[0.40]
[0.30]
External static pressure 0.80 [in.WG] (200Pa) 208/230V 60Hz
225
200
175
150
High
Middle
125
100
75
[247]
Low
7
10
[353]
Airflow rate (m
3
/min)[cfm]
[494]
External static pressure 0.80 [in.WG] (200Pa) 208/230V 60Hz
225
[0.90]
200
[0.80]
[0.70]
[0.60]
175
150
High
Middle
Static pressure (Pa)[in.WG]
125
[0.50]
100
[0.40]
75
14
[0.30]
[247]
Low
7
10
[353]
Airflow rate (m
3
/min)[cfm]
[494]
14
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 45
MVZ MULTI-POSITION PERFORMANCE CURVES
MVZ-A18AA4
• Vertical, Horizontal Right, Horizontal Left • Downflow
External static pressure 0.30 [in.WG] (75Pa) 208/230V 60Hz
100
[0.40]
External static pressure 0.30 [in.WG] (75Pa) 208/230V 60Hz
100
[0.40]
[0.30]
[0.20]
Static pressure (Pa)[in.WG]
[0.10]
[0.60]
[0.50]
[0.40]
Static pressure (Pa)[in.WG]
[0.30]
[0.20]
75
50
Middle
High
Low
25
0
[0]
10
[353]
External static pressure 0.50 [in.WG] (125Pa) 208/230V 60Hz
150
125
100
Airflow rate (m
[530]
15
3
/min)[cfm]
High
Middle
75
50
10
[353]
Low
15
[530]
Airflow rate (m3/min)[cfm]
[706]
[706]
75
[0.30]
50
[0.20]
Static pressure (Pa)[in.WG]
25
[0.10]
[0.60]
[0.50]
[0.40]
[0]
150
125
100
20
Low
0
10
[353]
External static pressure 0.50 [in.WG] (125Pa) 208/230V 60Hz
Middle
Airflow rate (m
[530]
15
3
/min)[cfm]
High
High
[706]
20
Middle
75
[0.30]
Static pressure (Pa)[in.WG]
Low
50
[0.20]
25
[0.10]
20
[353]
10
Airflow rate (m
[530]
15
3
/min)[cfm]
[706]
20
External static pressure 0.80 [in.WG] (200Pa) 208/230V 60Hz
225
[0.90]
200
[0.80]
[0.70]
[0.60]
175
150
High
Middle
Static pressure (Pa)[in.WG]
125
[0.50]
100
[0.40]
[0.30]
75
[353]
Low
10
Airflow rate (m
[530]
15
3
/min)[cfm]
46 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
[706]
External static pressure 0.80 [in.WG] (200Pa) 208/230V 60Hz
225
[0.90]
200
[0.80]
175
[0.70]
150
[0.60]
Static pressure (Pa)[in.WG]
125
[0.50]
100
[0.40]
20
[0.30]
Low
75
10
[353]
Middle
Airflow rate (m
[530]
15
3
/min)[cfm]
High
[706]
20
MVZ MULTI-POSITION PERFORMANCE CURVES
MVZ-A24AA4
• Vertical, Horizontal Right, Horizontal Left • Downflow
External static pressure 0.30 [in.WG] (75Pa) 208/230V 60Hz
100
[0.40]
External static pressure 0.30 [in.WG] (75Pa) 208/230V 60Hz
100
[0.40]
[0.30]
[0.20]
Static pressure (Pa)[in.WG]
[0.10]
[0.60]
[0.50]
[0.40]
Static pressure (Pa)[in.WG]
[0.30]
[0.20]
150
125
100
75
50
Middle
High
Low
25
0
[0]
13
[459]15[530]
Airflow rate (m
3
/min)[cfm]
[706]
20
External static pressure 0.50 [in.WG] (125Pa) 208/230V 60Hz
High
Middle
75
Low
50
13
[459]15[530]
Airflow rate (m
3
/min)[cfm]
[706]
20
[847]
[847]
75
[0.30]
50
[0.20]
Static pressure (Pa)[in.WG]
Low
25
[0.10]
0
24
[0]
13
[459]15[530]
External static pressure 0.50 [in.WG] (125Pa) 208/230V 60Hz
150
[0.60]
125
[0.50]
100
[0.40]
Middle
Airflow rate (m
3
/min)[cfm]
[706]
High
20
[847]
24
High
Middle
75
[0.30]
Static pressure (Pa)[in.WG]
Low
50
[0.20]
25
24
[0.10]
13
[459]15[530]
Airflow rate (m
3
/min)[cfm]
[706]
20
[847]
24
[0.90]
[0.80]
[0.70]
[0.60]
Static pressure (Pa)[in.WG]
[0.50]
[0.40]
[0.30]
External static pressure 0.80 [in.WG] (200Pa) 208/230V 60Hz
225
200
175
150
Middle
125
100
Low
75
[459]
13
[530]
15
Airflow rate (m
3
/min)[cfm]
High
[706]
External static pressure 0.80 [in.WG] (200Pa) 208/230V 60Hz
225
[0.90]
3
/min)[cfm]
High
[706]
20
[777]
22
200
[0.80]
175
[0.70]
150
[0.60]
Static pressure (Pa)[in.WG]
125
[0.50]
100
[0.40]
[777]
22
20
[0.30]
Low
75
13
[459]
[530]
Middle
15
Airflow rate (m
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 47
MVZ MULTI-POSITION PERFORMANCE CURVES
MVZ-A30AA4
• Vertical, Horizontal Right, Horizontal Left • Downflow
External static pressure 0.30 [in.WG] (75Pa) 208/230V 60Hz
100
[0.40]
External static pressure 0.30 [in.WG] (75Pa) 208/230V 60Hz
100
[0.40]
[0.30]
[0.20]
Static pressure (Pa)[in.WG]
[0.10]
[0.60]
[0.50]
[0.40]
[0.30]
Static pressure (Pa)[in.WG]
[0.20]
75
50
Middle
High
Low
25
0
[0]
15
[530]
External static pressure 0.50 [in.WG] (125Pa) 208/230V 60Hz
150
125
100
20
[706]
Airflow rate (m
3
/min)[cfm]
High
Middle
75
Low
50
[883]
3
/min)[cfm]
High
High
[883]
25
[1024]
29
75
[0.30]
50
[0.20]
Static pressure (Pa)[in.WG]
[0.10]
25
[1024]
29
150
[0.60]
125
[0.50]
100
[0.40]
[0.30]
Static pressure (Pa)[in.WG]
Low
25
0
[0]
15
[530]
External static pressure 0.50 [in.WG] (125Pa) 208/230V 60Hz
75
Middle
20
[706]
Airflow rate (m
Middle
Low
50
[0.20]
[0.10]
[0.90]
[0.80]
[0.70]
[0.60]
Static pressure (Pa)[in.WG]
[0.50]
[0.40]
[0.30]
25
15
[530]
External static pressure 0.80 [in.WG] (200Pa) 208/230V 60Hz
225
200
175
150
20
[706]
Airflow rate (m
3
/min)[cfm]
High
Middle
125
100
Low
75
[530]
15
20
[706]
Airflow rate (m
3
/min)[cfm]
[883]
[883]
25
[0.10]
[0.90]
[0.80]
[0.70]
[0.60]
Static pressure (Pa)[in.WG]
[0.50]
[0.40]
[0.30]
15
[530]
External static pressure 0.80 [in.WG] (200Pa) 208/230V 60Hz
225
200
175
150
125
100
Low
75
15
[530]
25
25
[1024]
[1024]
29
29
20
[706]
Airflow rate (m
Middle
20
[706]
Airflow rate (m
3
/min)[cfm]
3
/min)[cfm]
High
[883]
[883]
28
[989]
27
25
[953]
25
48 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
MVZ MULTI-POSITION PERFORMANCE CURVES
MVZ-A36AA4
• Vertical, Horizontal Right, Horizontal Left • Downflow
External static pressure 0.30 [in.WG] (75Pa) 208/230V 60Hz
100
[0.40]
External static pressure 0.30 [in.WG] (75Pa) 208/230V 60Hz
125
[0.50]
[0.30]
[0.20]
Static pressure (Pa)[in.WG]
[0.10]
[0.60]
[0.50]
[0.40]
Static pressure (Pa)[in.WG]
[0.30]
[0.20]
75
Middle
50
Low
25
0
[0]
19
20
[671]
[706]
External static pressure 0.50 [in.WG] (125Pa) 208/230V 60Hz
150
125
100
25
[883]
Airflow rate (m
3
/min)[cfm]
Middle
75
Low
50
[671]
19
20
[706]
25
[883]
Airflow rate (m
3
/min)[cfm]
High
High
30
[1059]
[1059]
100
[0.40]
High
75
[0.30]
Middle
50
[0.20]
Static pressure (Pa)[in.WG]
Low
25
[0.10]
0
[0.70]
[0.60]
[0.50]
[0.40]
Static pressure (Pa)[in.WG]
[0.30]
[0.20]
[0.10]
[0]
19
20
[671]
[706]
External static pressure 0.50 [in.WG] (125Pa) 208/230V 60Hz
175
150
125
100
75
25
[883]
Airflow rate (m3/min)[cfm]
Middle
Low
50
25
[671]
19
20
[706]
25
[883]
Airflow rate (m
3
/min)[cfm]
High
30
[1059]
30
[1059]
[1130]
[1130]
32
32
33
[1165]
32
30
[1130]
[0.90]
[0.80]
[0.70]
[0.60]
Static pressure (Pa)[in.WG]
[0.50]
[0.40]
[0.30]
External static pressure 0.80 [in.WG] (200Pa) 208/230V 60Hz
225
200
175
150
125
100
Low
75
19
20
[671]
[706]
Middle
25
[883]
Airflow rate (m
3
/min)[cfm]
High
[1059]
External static pressure 0.60 [in.WG] (150Pa) 208/230V 60Hz
200
[0.80]
175
[0.70]
150
[0.60]
125
[0.50]
Static pressure (Pa)[in.WG]
100
[0.40]
75
[0.30]
32
30
[1130]
[0.20]
Low
50
19
20
[671]
[706]
Middle
25
[883]
Airflow rate (m
3
/min)[cfm]
High
30
[1059]
[1130]
32
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 49
MFZ Floor-mounted Indoor Unit I Heat Pump
(FOR MXZ-C OUTDOOR UNITS)
Model Name Indoor Unit MFZ-KA09NA MFZ-KA12NA MFZ-KA18NA
Cooling *1 Rated Capacity Btu/h 9,000 12,000 18,000
Heating at 47° F *2 Rated Capacity Btu/h 10,900 14,400 21,600
Power Supply Phase, Cycle, Voltage 1-phase, 60Hz, 208 / 230V *3
Indoor - Outdoor S1 - S2 AC 208 / 230V
Voltage
Fan
Sound Pressure Level at Cooling
(Lo-Med-Hi-Super Hi) *1
Sound Pressure Level at Heating
(Lo-Med-Hi-Super Hi) *2
External Finish Color Munsell No. 1.0Y 9.2/0.2
Dimension Unit
Weight Unit Lbs. 32
Field Drainpipe Size O.D. In. 5/8
Remote Controller Type
Indoor - Outdoor S2 - S3 DC ±24V
MCA A 1
Airflow at Cooling/Heating
(Lo-Med-Hi)
Airflow at Heating
(Lo-Med-Hi-Super Hi) *2
DRY (CFM) 169-205-251-314 177-215-261-321 251-279-325-394
WET (CFM) 163-197-241-303 170-207-252-309 241-269-313-379
(CFM) 177-198-219-332 184-201-219-335 261-275-297-434
dB(A) 25-30-35-40 26-31-36-41 35-38-42-46
dB(A) 25-30-35-40 28-31-36-41 35-38-42-47
W: In. 27-9/16
D: In. 7-7/8
H: In. 23-5/8
Select from PAC-WHS01WF-E for kumo cloud™, PAC-US444CN-1,
MHK1, PAR-32MAA, or PAC-YT53CRAU Remote Controllers
Refrigerant Type R410A
Refrigerant Pipe
Connection Method Indoor/Outdoor Flared/Flared
NOTES: Test conditions are based on AHRI 210/240.
*1. Rating conditions (cooling)-Indoor: D.B. 80º F (26.7º C), W.B. 67º F (19.4º C); Outdoor: D.B. 95º F (35º C), W.B. 75º F (23.9º C).
*2. Rating conditions (heating)-Indoor: D.B. 70º F (21.1º C), W.B. 60º F (15.6º C); Outdoor: D.B. 47º F (8.3º C), W.B. 43º F (6.1º C).
*3. Indoor units receive power from outdoor units through field supplied interconnected wiring.
Specifications are subject to change without notice.
LIMITED WARRANTY I Five years parts and seven years compressor.
Presently, there is no 1:1 system with the MFZ indoor unit.
Gas Side O.D. In. 3/8 1/2
Liquid Side O.D. In. 1/4
50 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
SLZ Ceiling-recessed Indoor Unit I Heat Pump
(FOR MXZ-C OUTDOOR UNITS)
Model Name Indoor Unit SLZ-KA09NA SLZ-KA12NA SLZ-KA15NA
Cooling *1 Rated Capacity Btu/h 8,400 11,100 15,000
Heating at 47° F *2 Rated Capacity Btu/h 10,900 13,600 18,000
Power Supply Phase, Cycle, Voltage 1-phase, 60Hz, 208 / 230V *3
Indoor - Outdoor S1 - S2 AC 208 / 230V
Voltage
Fan
Sound Pressure Level (Lo-Med-Hi) *2 dB(A) 29-32-38 30-34-39 31-35-40
External Finish Color Unit/Grille Galvanized-steel Sheets/Munsell 6.4Y 8.9 / 0.4
Dimension Unit (Grille)
Weight Unit (Grille) Lbs. 36 (7)
Drain-lift Mechanism (Included) H: In. 19-11/16
Field Drainpipe Size O.D. In. 1-1/4
Indoor - Outdoor S2 - S3 DC ±24V
MCA A 1
Fan Motor (ECM) F.L.A. 0.23 0.28 0.28
Airflow at Cooling/
Heating (Lo-Med-Hi)
DRY (CFM) 280-320-350 280-320-390 280-320-390
WET (CFM) 250-290-320 250-290-350 250-290-350
W: In. 22-7/16 (25-5/8)
D: In. 22-7/16 (25-5/8)
H: In. 9-1/4 (13/16)
Remote Controller
Refrigerant Type R410
Refrigerant Pipe
Connection Method Indoor/Outdoor Flared/Flared
Connection Method Indoor/Outdoor Flared/Flared
NOTES: Test conditions are based on AHRI 210/240.
*1. Rating conditions (cooling)-Indoor: D.B. 80º F (26.7º C), W.B. 67º F (19.4º C); Outdoor: D.B. 95º F (35º C), W.B. 75º F (23.9º C).
*2. Rating conditions (heating)-Indoor: D.B. 70º F (21.1º C), W.B. 60º F (15.6º C); Outdoor: D.B. 47º F (8.3º C), W.B. 43º F (6.1º C).
*3. Indoor units receive power from outdoor units through field supplied interconnected wiring.
Specifications are subject to change without notice.
LIMITED WARRANTY I Five years parts and seven years compressor.
Gas Side O.D. In. 3/8 1/2
Liquid Side O.D. In. 1/4
Type
Select from PAC-WHS01WF-E for kumo cloud™, PAC-US444CN-1,
MHK1, PAR-32MAA, or PAC-YT53CRAU Remote Controllers
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 51
ADDITIONAL M-SERIES INFORMATION
PORT ADAPTERS PART NUMBERS
MAC-A454JP-E 3/8" x 1/2"
MAC-A455JP-E 1/2" x 3/8"
MAC-A456JP-E 1/2" x 5/8"
PAC-SG76RJ-E 3/8" x 5/8"
PAC-493PL 1/4" x 3/8"
PORT GAS LIQUID
A; B 3/8" 1/4"
A 1/2" 1/4"
B; C 3/8" 1/4"
A 1/2" 1/4"
B; C 3/8" 1/4"
A 1/2" 1/4"
B; C; D 3/8" 1/4"
A 1/2" 1/4"
B; C; D; E 3/8" 1/4"
A; B 3/8" 1/4"
A 1/2" 1/4"
B; C 3/8" 1/4"
A 1/2" 1/4"
B; C 3/8" 1/4"
MXZ-2B20NA-1
MXZ-3C24NA
MXZ-3C30NA
MXZ-4C36NA
MXZ-5C42NA
MXZ-2C20NAHZ
MXZ-3C24NAHZ
MXZ-3C30NAHZ
THE FOLLOWING M XZ UNITS
MUST UTILIZE AT LEAST ONE
BRANCH BOX
MXZ-8C48NA
MXZ-4C36NAHZ
MXZ-5C42NAHZ
MXZ-8C48NAHZ
BRANCH BOXES
PORT GAS LIQUID
PAC-MKA30BC [3-Port]
A; B; C 3/8" 1/4"
PAC-MKA50BC [5-Port]
A; B; C; D 3/8" 1/4"
E 1/2" 1/4'
Notes for application:
* Check the lineset sizes for your indoor selected models.
* Select the branch box or boxes needed for your
application.
* Compare indoor unit lineset sizes to branch box or outdoor
unit port sizes.
* *Connect 15K + indoor units to the larger 1/2" port on the
PAC-MKA50BC branch box or outdoor unit.
* Adapt lineset size with appropriate port adapter from above
list.
* *When using the PLA-A24BA6, PEAD-A24AA5, PEAD-
A30A A5, PEAD-A36AA5, MSZ-GL24NA two port adapters
will be needed
1-MAC-A456JP-E (1/2" x 5/8") or 1-PAC-SG76RJ-E (3/8" x
5/8") and 1 - PAC-493Pl (1/4" x 3/8").
PORT ADAPTER GUIDE
AVAILABLE INDOOR UNITS LINE SET SIZE
MSZ Wall-mounted
MSZ-GL06NA-U1 3/8" gas x 1/4" liquid
MSZ-GL09NA-U1 3/8" gas x 1/4" liquid
MSZ-GL12NA-U1 3/8" gas x 1/4" liquid
MSZ-GL15NA-U1 1/2" gas x 1/4" liquid
MSZ-GL18NA-U1 1/2" gas x 1/4" liquid
MSZ-GL24NA-U1 5/8" gas x 3/8" liquid
MSZ-FH06NA 3/8" gas x 1/4" liquid
MSZ-FH09NA 3/8" gas x 1/4" liquid
MSZ-FH12NA 3/8" gas x 1/4" liquid
MSZ-FH15NA 3/8" gas x 1/4" liquid
MSZ-FH18NA2 1/2" gas x 1/4" liquid
MFZ Floor-standing
MFZ-KA09NA 3/8" gas x 1/4" liquid
MFZ-KA12NA 3/8" gas x 1/4" liquid
MFZ-KA18NA 1/2" gas x 1/4" liquid
MVZ Multi-position
MVZ-A12AA4 1/2" gas x 1/4" liquid
MVZ-A18AA4 1/2" gas x 1/4" liquid
MVZ-A24AA4 5/8" gas x 3/8" liquid
MVZ-A30AA4 5/8" gas x 3/8" liquid
MVZ-A36AA4 5/8" gas x 3/8" liquid
PLA Ceiling-recessed
PLA-A12BA6 1/2" gas x 1/4" liquid
PLA-A18BA6 1/2" gas x 1/4" liquid
PLA-A24BA6 5/8" gas x 3/8" liquid
PLA-A30BA6 5/8" gas x 3/8" liquid
PLA-A36BA6 5/8" gas x 3/8" liquid
PCA Ceiling-suspended
PCA-A24KA6 5/8" gas x 3/8" liquid
SLZ Ceiling-recessed
SLZ-KA09NA 3/8" gas x 1/4" liquid
SLZ-KA12NA 3/8" gas x 1/4" liquid
SLZ-KA15NA 1/2" gas x 1/4" liquid
SEZ/PEAD Horizontal-ducted
SEZ-KD09NA4 3/8" gas x 1/4" liquid
SEZ-KD12NA4 3/8" gas x 1/4" liquid
SEZ-KD15NA4 1/2" gas x 1/4" liquid
SEZ-KD18NA4 1/2" gas x 1/4" liquid
PEAD-A24AA5 5/8" gas x 3/8" liquid
PEAD-A30AA5 5/8" gas x 3/8" liquid
PEAD-A36AA5 5/8" gas x 3/8" liquid
M-SERIES OPERATING CONDITIONS
INDOOR INTAKE AIR TEMPERATURE
MODELS CONDITIONS
SUZ
MXZ-2B20NA-1
MXZ-3C24/3C30/4C36/5C42NA
Maximum
Cooling
Minimum
MXZ-2C20/3C24/3C30NAHZ
MUZ/Y-GL/D
MUZ-FH
MXZ-8C48NA
MXZ-4C36/54C42/8C48NAHZ
MUZ/Y-GL/D
MUZ-FH
MXZ-2B20NA-1
MXZ-3C24/3C30/4C36/5C42NA
MXZ-2C20/3C24/3C30NAHZ
MXZ-8C48NA
MXZ-4C36/54C42/8C48NAHZ
95° F D.B., 71° F W.B.
90° F D.B., 73° F W.B.
67° F D.B., 57° F W.B.
52 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
M-SERIES OPERATING CONDITIONS (CONT.)
INDOOR INTAKE AIR TEMPERATURE
MODELS CONDITIONS
MUZ/Y-GL/D
MUZ-FH
SUZ
Maximum
Heating
Minimum
Maximum
Cooling
Minimum
Maximum
Heating
Minimum
MXZ-2B20NA-1
MXZ-3C24/3C30/4C36/5C42NA
MXZ-8C48NA
MXZ-2C20/3C24/3C30NAHZ
MXZ-4C36/54C42/8C48NAHZ
MUZ-GL/D
MUZ-FH
SUZ
MXZ-2B20NA-1
MXZ-3C24/3C30/4C36/5C42NA
MXZ-8C48NA
MXZ-2C20/3C24/3C30NAHZ
MXZ-4C36/54C42/8C48NAHZ
80° F D.B., 67° F W.B.
70° F D.B., 60° F W.B.
OUTDOOR INTAKE AIR TEMPERATURE
MODELS CONDITIONS
MUZ/Y-GL/D
MUZ-FH
SUZ
MXZ-2B20NA-1
MXZ-3C24/3C30/4C36/5C42NA
MXZ-8C48NA
MXZ-2C20/3C24/3C30NAHZ
MXZ-4C36/54C42/8C48NAHZ
MUZ/Y-GL/D
MUZ-FH
MXZ-2B20NA-1
MXZ-3C24/3C30/4C36/5C42NA
MXZ-2C20/3C24/3C30NAHZ
MXZ-8C48NA
MXZ-4C36/54C42/8C48NAHZ
MUZ/Y-GL/D
MUZ-FH
SUZ
MXZ-2B20NA-1
MXZ-3C24/3C30/4C36/5C42NA
MXZ-8C48NA
MXZ-2C20/3C24/3C30NAHZ
MXZ-4C36/54C42/8C48NAHZ
"MUZ-GL/D -13° F D.B., -14° F W.B.
MXZ-2C20/3C24/3C30NAHZ -12° F D.B., -13° F W.B.
MXZ-4C36/54C42/8C48NAHZ -13° F W.B.
MXZ-8C48NA -4° F W.B.
MUZ/Y-GL/D
SUZ
MUZ/Y-D 14° F D.B., 13° F W.B.
MXZ-2B20NA-1
MXZ-3C24/3C30/4C36/5C42NA
115° F D.B.
23° F D.B.
14° F D.B.
75° F D.B., 65° F W.B
70° F D.B., 59° F W.B
-4° F D.B., -5° F W.B.
6° F D.B., 5° F W.B.
REFRIGERANT LINE LENGTH FLARE/FLARE
Indoor Unit Outdoor Unit
Length
in Feet
MSZ-FH09NA MUZ-FH09NA 65 40
MSZ-FH12N A MUZ-FH12NA 65 40
MSZ-FH15N A MUZ-FH15NA 10 0 50
MSZ-FH18N A MUZ-FH18NA 10 0 50
MSY-GE09NA-9 MU Y-GE09N A 2 65 40
MSY-GE12NA-9 MU Y-GE12N A 2 65 40
MSY-GE15NA-9 MUY-GE15N A 2 65 40
MSY-GE18NA-9 MUY-GE18NA-1 100 50
MSY-GE24NA MUY- GE24N A 100 50
MSZ-GE09NA-9 MU Z-GE0 9NA2 65 40
MSZ-GE12NA-9 MUZ-GE12NA2 65 40
MSZ-GE15NA-9 MUZ-GE15NA2 65 40
MSZ-GE18NA-9 MUZ-GE18NA-1 100 50
MSZ-GE24NA MUZ- GE24NA 100 50
MSY-D30NA-8 MUY-D30NA-1 100 50
MSY-D36NA-8 MUY-D36NA-1 100 50
MSZ-D30NA-8 MUZ-D30NA-1 100 50
MSZ-D36NA-8 MUZ-D36NA-1 100 50
MSZ-FE09NA-8 MUZ-FE09NA-1 65 40
MSZ-FE12NA-8 MUZ-FE12NA-1 65 40
MSZ-FE18N A MUZ-FE18NA 100 50
SE Z-KD0 9NA4 SUZ-KA09NA 65 40
SE Z-KD12NA 4 SUZ-KA12NA 65 40
SE Z-KD15NA4 SUZ-KA15NA 65 40
SE Z-KD18NA4 SUZ-KA18NA 100 50
SLZ-KA09NA SUZ-KA09NA 65 40
SLZ-KA12NA SUZ-KA12NA 65 40
SLZ-KA15NA SUZ-KA15NA 65 40
MSZ-GE/FH; MFZ; SEZ; SLZ MXZ-2B20 N A-1 16 4 49*/33
MX Z-3C 24N A 230 49
MX Z-3C 30NA 230 49
MXZ-4C36NA 230 49
MSZ-GE / FH
MFZ
MVZ
SEZ
SLZ
MX Z-5C4 2NA 262 49
MXZ-8C48NA 492 131*/164
MX Z-2C20N AHZ 164 49
MXZ-3C24NAHZ 230 49
MXZ-3C30NAHZ 230 49
MXZ-4C36NAHZ 492 131*/164
MX Z-5C4 2NA HZ 492 131*/16 4
MXZ-8C48NAHZ 492 131*/164
*49' and 131' applies to installations where the outdoor unit is installed below the
indoor unit.
Vertical
Separation
in Feet
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 53
M-SERIES COOLING CAPACITY CORRECTION FACTOR
M-SERIES AIR OUTLET COVERAGE RANGE*
Model Refrigerant Piping Length (One Way)
25 Ft (Std) 40 Ft 65 Ft 100 Ft
MUZ-GE09N A 2
MUZ-GE12N A 2
MUZ-GE15N A 2
Capacity x 1.0
Capacity
x 0.954
Capacity
x 0.878
-
MUZ-GE18NA-1
MUZ-GE 24N A Capacity x 1.0 Capacity
x 0.954
MUZ-D30NA-1 Capacity x 1.0 Capacity
MUZ-D36NA-1
x 0.95
MUY-GE09N A2 Capacity x 1.0 Capacity
MUY-GE12N A2
x 0.954
MUY-GE15N A2
Capacity
x 0.878
Capacity
x 0.878
Capacity
x 0.878
Capacity
x 0.771
Capacity
x 0.713
-
MUY-GE18NA-1
MUY-GE 24 NA Capacity x 1.0 Capacity
x 0.954
MUY-D30NA-1 Capacity x 1.0 Capacity
MUY-D36NA-1
x 0.95
MUZ-FE09NA-1 Capacity x 1.0 Capacity
MUZ-FE12NA-1
MUZ-FE18NA
MUZ-FH09NA
MUZ-FH12NA
MUZ-FH15NA
MUZ-FH18NA
Capacity x 1.0
Capacity x 1.0
Capacity x 1.0
x 0.945
Capacity
x 0.945
Capacity
x 0.945
Capacity
x 0.945
Capacity
x 0.878
Capacity
x 0.878
Capacity
x 0.878
Capacity
x 0.878
Capacity
x 0.878
Capacity
x 0.878
Capacity
x 0.771
Capacity
x 0.713
-
Capacity
x 0.771
-
Capacity
x 0.771
SUZ-KA09NA
SUZ-KA12NA
SUZ-KA15NA
Capacity x 1.0
Capacity
x 0.954
Capacity
x 0.878
-
SUZ-KA18NA
M-SERIES SIZING
It is very important that all contractors follow proper procedure and size
units based on a Manual J calculation. A load calculation takes into
account all the factors that cause the building to lose heat in the winter
and gain heat in the summer. Some of the factors taken into consideration
are exposed walls, insulation, windows, doors, and even the direction
the building faces.
INVERTER-driven technology has changed the way heat pumps are used.
Because the inverter can vary the capacity of the system, we can now
size units based on the largest load, which in many cases may be the
heat load. When single speed compressors are sized on heat load and
changed over to cooling, the units can be grossly over-sized. The result
is very little dehumidification and comfort problems.
Using charts like the ones below from the technical service manual, you
can check the equipment capacity at the design temperatures for heating
and cooling. If these values fall within both the heating and cooling
capacity ranges of the system, you can select that system
with confidence.
Model Mode Function
MSZ/Y-GE06NA-9
MSZ/Y-GE09NA-9
MSZ/Y-GE12NA-9
MSZ/Y-GE15NA-9
MSZ/Y-GE18NA-9
MSZ/Y-GE24NA
MSZ/Y-D30NA-8
MSZ/Y-D36NA-8
MSZ-FE09NA-8
MSZ-FE12NA-8
MSZ-FE18N A
MSZ-FH09NA
MSZ-FH12N A
MSZ-FH15N A
MSZ-FH18N A
MFZ-KA09NA
MFZ-KA12NA
MFZ-KA18NA
SLZ-KA09NA
SLZ-KA12NA
HEAT DRY 406 29.5
COOL WET 286 21.0
HEAT DRY 463 33.5
COOL WET 385 28.0
HEAT DRY 512 36.9
COOL WET 385 28.0
HEAT DRY 738 36.9
COOL WET 661 33.2
HEAT DRY 848 45.0
COOL WET 763 40.7
HEAT DRY 381 27.7
COOL WET 307 22.4
HEAT DRY 420 30.4
COOL WET 350 25.4
HEAT DRY 738 36.9
COOL WET 661 33.2
HEAT DRY 437 29.8
COOL WET 328 22.5
HEAT DRY 454 31.0
COOL WET 342 23.5
HEAT DRY 497 33.8
COOL WET 354 2 4.1
HEAT DRY 514 23.0
COOL WET 376 16.7
HEAT DRY 332 15.4
COOL WET 303 14.2
HEAT DRY 335 15.6
COOL WET 309 14.5
HEAT DRY 434 20.0
COOL WET 379 17. 5
HEAT DRY 350 12 .1
COOL WET 320 1.1
HEAT DRY 390 13.5
COOL WET 350 12.1
Airflow
(CFM)
Coverage
(FT)
SLZ-KA15NA HEAT DRY 390 13.5
COOL WET 350 12.1
*Air coverage represents the distance with one ft/sec air speed when blowing out
horizontally from the unit operating at the High fan speed. This is only a general
guideline; actual coverage depends on size and layout of the room.
54 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
MULTI-ZONE EFFICIENCY RATINGS
Model Configuration SEER HSPF
Non-Ducted 18.00 8.90
MX Z-2B2 0 NA-1
MX Z-3C 24N A
MX Z-3C 30NA
MXZ-4C36NA
MX Z-5C4 2NA
MXZ-8C48NA
MX Z-2C20N AHZ
MXZ-3C24NAHZ
MXZ-3C30NAHZ
MXZ-4C36NAHZ
MX Z-5C4 2NA HZ
MXZ-8C48NAHZ
Mixed 16.75 8.70
Ducted 15.50 8.50
Non-Ducted 20.00 9.80
Mixed 18.00 9.50
Ducted 16.00 9.20
Non-Ducted 19.00 10.60
Mixed 17.60 10.10
Ducted 16.20 9.60
Non-Ducted 19.20 11.00
Mixed 16.00 10.40
Ducted 17. 4 5 9.80
Non-Ducted 19.70 10.30
Mixed 17.45 9.70
Ducted 15.20 9.10
Non-Ducted 18.90 11.40
Mixed 16.80 10.75
Ducted 14.70 10.10
Non-Ducted 17. 0 0 9.80
Mixed 16.00 9.65
Ducted 15.00 9.50
Non-Ducted 19.00 10.0 0
Mixed 17.25 9.50
Ducted 15.50 9.00
Non-Ducted 18.00 11.00
Mixed 17.00 10.70
Ducted 16.00 9.80
Non-Ducted 19.10 11.3 0
Mixed 17.45 10.70
Ducted 15.80 10.70
Non-Ducted 19.00 11.00
Mixed 17.00 10.55
Ducted 15.00 10.10
Non-Ducted 18.90 11.00
Mixed 16.80 10.50
Ducted 14.70 10.00
M-Series systems are not
recommended for critical room
and low ambient cooling applications.
Use commercial grade P-Series with
f
ll cooling capacity down to 0
u
o
F with
wind baffle.
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 55
MSZ AND MUZ-FH COOLING CAPACITY
Indoor Air
Model
IWB (˚ F)
71 7. 4 6.1 0.28 6.9 5.7 0.31 6.5 5.3 0.33 6 5 0.35 5.5 4.6 0.36
75 85 95 105 115
TC SHC TPC TC SHC TPC TC SHC TPC TC SHC TPC TC SHC TPC
COOLING CAPACITY
Outdoor Intake air D.B. Temperature (˚ F)
MUZ-FH06NA
MUZ-FH09NA-1
MUZ-FH12NA-1
MUZ-FH15NA
MUZ-FH18NA2
67 7 6.7 0.26 6.5 6.2 0.29 6 5.8 0.32 5.6 5.4 0.33 5 .1 4.9 0.35
63 6.5 7.2 0.25 6 .1 6.6 0.28 5.6 6.2 0.3 5.1 5.6 0.32 4.7 5.1 0.33
71 11 8.7 0.5 10.3 8.1 0.55 9.7 7. 6 0.59 9 7.1 0.62 8.3 6.5 0.64
67 10.4 9.6 0.47 9.7 8.9 0.52 9 8.3 0.56 8.4 7.7 0.59 7.7 7.1 0.62
63 9.8 10.3 0.45 9.1 9.6 0.5 8.5 8.9 0.53 7. 7 8.1 0.57 7 7.4 0.59
71 14 .7 10.2 0.77 13.7 9.6 0.85 12 .9 9 0.91 12 8.4 0.96 11 7.7 1
67 13.9 11.6 0.73 13 10.8 0.8 12 10 0.87 11.2 9.3 0.92 10.3 8.5 0.97
63 13 .1 12.6 0.7 12 .1 11.7 0.77 11.3 10.9 0.83 10.3 9.9 0.89 9.4 9 0.92
71 18 .4 10.4 1.07 17. 2 9.7 1.17 16.1 9.1 1.26 15 8.5 1.3 3 13.8 7. 8 1.38
67 17.4 12.2 1.01 16.2 11.3 1.11 15 10.5 1. 2 14 9.8 1.27 12.8 9 1.33
63 16.4 13.6 0.96 15.2 12. 6 1.06 14.1 11.8 1.15 12.8 10.7 1. 22 11.7 9.8 1.27
71 2 1.1 11.3 1.22 19.7 10.6 1.3 4 18.5 9.9 1.44 17.2 9.2 1.52 15.8 8.5 1.58
67 20 13.4 1.16 18.6 12.4 1.27 17.2 11.5 1.38 16 10.7 1.46 14.7 9.9 1.53
63 18.7 15.1 1.1 17.4 14 1.2 2 16.2 13 1.31 14.7 11.8 1.4 13.4 10.8 1.46
NOTE: 1. IWB: Intake air wet-bulb temperature
SHC: Sensible Heat Capacity (x103 Btu/h)
TC: Total Capacity (x103 Btu/h)
TPC: Total Power Consumption (kW )
2. SHC is based on 80˚ F of indoor Intake air DB temperature.
56 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
MSZ AND MUZ-FH HEATING CAPACITY
Indoor Air
Model
IDB (˚ F)
75 7. 4 0.32 5 0.41 6.3 0.48 7.5 0.53 8.5 0.56 8.7 0.57 9.9 0.59
TC TPC TC TPC TC TPC TC TPC TC TPC TC TPC TC TPC
HEATING CAPACITY
Outdoor Intake air D.B. Temperature (˚ F)
5 15 25 35 43 45 55
MUZ-FH06NA
MUZ-FH09NA-1
MUZ-FH12NA-1
MUZ-FH15NA
MUZ-FH18NA2
70 7 0.31 5.4 0.39 6.5 0.47 7.7 0.52 8.7 0.55 9 0.56 10.1 0.58
65 6.5 0.29 5.5 0.38 6.8 0.45 8 0.5 9 0.53 9.2 0.54 10.4 0.57
75 11 0.42 6.3 0.53 7. 9 0.62 9.4 0.69 10.6 0.73 11 0.74 12.4 0.77
70 10.4 0.4 6.7 0.51 8.2 0.61 9.6 0.67 10.9 0.71 11.2 0.72 12.7 0.75
65 9.8 0.38 6.9 0.49 8.6 0.59 10 0.66 11.2 0.69 11.6 0.7 13 0.74
75 14.7 0.56 7.9 0.71 9.9 0.83 11.8 0.93 13.3 0.97 13.7 0.99 15.5 1.03
70 13.9 0.54 8.4 0.68 10.2 0.81 12 0.9 13.6 0.95 14 0.97 15.8 1.01
65 13 .1 0.51 8.6 0.66 10.7 0.78 12.4 0.88 14 0.93 14.4 0.94 16.2 0.99
75 18.4 0.77 10.4 0.97 13.1 1.14 15.6 1.27 17.6 1.3 3 18.1 1.35 20.5 1.4
70 17.4 0.73 11.1 0.94 13.5 1.11 15.9 1. 24 18 1.3 18.5 1.33 21 1.38
65 16.4 0.7 11.3 0.9 14.1 1.07 16.5 1. 2 18.5 1.27 19.1 1. 29 21.4 1.35
75 2 1.1 1.01 11. 8 1.28 14.7 1.51 17. 6 1.68 19.8 1.76 20.4 1.79 23.1 1.86
70 20 0.97 12.5 1.24 15.2 1.47 18 1.63 20.3 1.72 20.9 1.75 23.6 1.82
65 18.7 0.93 12. 8 1.19 15.9 1.42 18.6 1.59 20.9 1. 68 21.5 1.7 24.2 1.79
NOTE: 1. IDB: Intake air dry-bulb temperature
TC: Total Capacity (x103 Btu/h)
TPC : Total Power Consumption (kW )
2. Above data is for heating operation without any frost.
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 57
NOTES
58 / MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS
Variable Refrigerant Flow
CATALOG
VARIABLE REFRIGERANT FLOW ZONING SYSTEMS
P-SERIES
INVERTER-driven
P-SERIES FULL LINE CATALOG
COMMERCIAL-G RADE APPLICATIONS
MITSUBISHI ELECTRIC Cooling & Heating / CITY MULTI / FC1
01.2016_REVISED I ©2016 MITSUBISHI ELECTRIC US, INC.
For more information on our
CITY MULTI VRF product line visit our website at
mitsubishipro.com
Smart, Ecient I NVERTER-driven
Ductless and Ducted Comfort Systems
P-SERIES CATALOG I 02.2016 REVISED I ©2016 MITSUBISHI ELECTRIC US, INC.
www.mitsubishipro.com
For more information on our
INVERTER- driven product line visit our website at mitsubishipro.com
MITSUBISHI ELECTRIC / M-SERIES / SPECIFICATIONS / 59
MAKE COMFORT
Mitsubishi Electric Cooling & Heating
1340 Satellite Boulevard, Suwanee, GA 30024
Phone: 800-433-4822
©2016 Mitsubishi Electric US, Inc. All rights reserved.
Mitsubishi Electric, Lossnay, and the three-diamond logo are trademarks of Mitsubishi Electric
Corporation. CITY MULTI, kumo cloud and H2i are trademarks of Mitsubishi Electric US, Inc. All other
product names mentioned herein are trademarks or registered trademarks of their respective owners.
ENERGY STAR and the ENERGY STAR mark are registered trademarks owned by the United States
Environmental Protection Agency.
Use of the AHRI Certied™ mark indicates a manufacturer’s participation in the certication program.
For verication of certication for individual products, go to www.ahridirectory.org.
Specications shown in this brochure are subject to change without notice. See complete warranty
for terms, conditions and limitations. A copy is available from Mitsubishi Electric.
For more information visit www.mitsubishipro.com
VERSION MSCG 04.2016 I REVISED I SKU: ME-1022 I ©2016 MITSUBISHI ELECTRIC US, INC.
Please Recycle
Loading...
