AUTO-SCANNING WITH DIGITAL CONTROL
COLOR DISPLAY MONITOR
USER’S GUIDE
For future reference, record the serial
number of your display monitor in the
space below:
SERIAL No.
The serial number is located on the
rear cover of the monitor.
Internet Home Page: http://www.mitsubishi-electric.com.au/
Supplying Windows
product information, etc.
®
95/98/2000 INF File download service, new
- ii -
RADIO INTERFERENCE REGULATIONS STATEMENT FOR U.S.A.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
THIS PRODUCT HAS BEEN TESTED AND FOUND
TO COMPLY WITH THE LIMITS. USE IT TO REDUCE THE POSSIBILITY OF CAUSING INTERFERENCE TO RADIO, TELEVISION, AND OTHER
ELECTRIC DEVICES.
NO USER SERVICEABLE PARTS INSIDE. DO
NOT ATTEMPT TO MODIFY THIS EQUIPMENT. IF
MODIFIED, YOUR AUTHORITY TO OPERATE THIS
EQUIPMENT MIGHT BE VOIDED BY FCC.
- iii -
Congratulations!
You have just purchased a TCO’99 approved and labelled
product! Your choice has provided you with a product
developed for professional use. Your purchase has also
contributed to reducing the burden on the environment and
also to the further development of environmentally adapted
electronics products.
Why do we have environmentally labelled computers?
In many countries, environmental labelling has become an
established method for encouraging the adaptation of
goods and services to the environment. The main problem,
as far as computers and other electronics equipment are
concerned, is that environmentally harmful substances are
used both in the products and during their manufacture.
Since it is not so far possible to satisfactorily recycle the
majority of electronics equipment, most of these potentially
damaging substances sooner or later enter nature.
There are also other characteristics of a computer, such as
energy consumption levels, that are important from the
viewpoints of both the work (internal) and natural (external)
environments. Since all methods of electricity generation
have a negative effect on the environment (e.g. acidic and
climate-influencing emissions, radioactive waste), it is vital
to save energy. Electronics equipment in offices is often left
running continuously and thereby consumes a lot of energy.
What does labelling involve?
This product meets the requirements for the TCO’99 scheme
which provides for international and environmental labelling
of personal computers. The labelling scheme was developed
as a joint effort by the TCO (The Swedish Confederation of
Professional Employees), Svenska Naturskyddsforeningen
(The Swedish Society for Nature Conservation) and Statens
Energimyndighet (The Swedish National Energy
Administration).
Approval requirements cover a wide range of issues:
environment, ergonomics, usability, emission of electric
and magnetic fields, energy consumption and electrical
and fire safety.
The environmental demands impose restrictions on the
presence and use of heavy metals, brominated and
chlorinated flame retardants, CFCs (freons) and chlorinated
solvents, among other things. The product must be prepared
for recycling and the manufacturer is obliged to have an
environmental policy which must be adhered to in each
country where the company implements its operational
policy.
The energy requirements include a demand that the
computer and/or display, after a certain period of inactivity,
shall reduce its power consumption to a lower level in one
or more stages. The length of time to reactivate the computer
shall be reasonable for the user.
Labelled products must meet strict environmental demands,
for example, in respect of the reduction of electric and
magnetic fields, physical and visual ergonomics and good
usability.
Below you will find a brief summary of the environmental
requirements met by this product. The complete
environmental criteria document may be ordered from:
TCO Development
SE-114 94 Stockholm, Sweden
Fax: +46 8 782 92 07
Email (Internet): development@tco.se
Current information regarding TCO’99 approved and
labelled products may also be
obtained via the Internet, using the address:
http://www.tco-info.com/
Environmental requirements
Flame retardants
Flame retardants are present in printed circuit boards,
cables, wires, casings and housings. Their purpose is to
prevent, or at least to delay the spread of fire. Up to 30% of
the plastic in a computer casing can consist of flame
retardant substances. Most flame retardants contain
bromine or chloride, and those flame retardants are
chemically related to another group of environmental toxins,
PCBs. Both the flame retardants containing bromine or
chloride and the PCBs are suspected of giving rise to
severe health effects, including reproductive damage in
fish-eating birds and mammals, due to the bio-accumulative
processes. Flame retardants have been found in human
blood and researchers fear that disturbances in foetus
development may occur.
The relevant TCO’99 demand requires that plastic
components weighing more than 25 grams must not contain
flame retardants with organically bound bromine or chlorine.
Flame retardants are allowed in the printed circuit boards
since no substitutes are available.
Cadmium
**
Cadmium is present in rechargeable batteries and in the
colour-generating layers of certain computer displays.
Cadmium damages the nervous system and is toxic in high
doses. The relevant TCO’99 requirement states that
batteries, the colour-generating layers of display screens
and the electrical or electronics components must not
contain any cadmium.
Mercury
**
Mercury is sometimes found in batteries, relays and
switches. It damages the nervous system and is toxic in
high doses. The relevant TCO’99 requirement states that
batteries may not contain any mercury. It also demands
that mercury is not present in any of the electrical or
electronics components associated with the labelled unit.
CFCs (freons)
The relevant TCO’99 requirement states that neither CFCs
nor HCFCs may be used during the manufacture and
assembly of the product. CFCs (freons) are sometimes
used for washing printed circuit boards. CFCs break down
ozone and thereby damage the ozone layer in the
stratosphere, causing increased reception on earth of
ultraviolet light with e.g. increased risks of skin cancer
(malignant melanoma) as a consequence.
**
Lead
Lead can be found in picture tubes, display screens,
solders and capacitors. Lead damages the nervous system
and in higher doses, causes lead poisoning. The relevant
TCO´99 requirement permits the inclusion of lead since no
replacement has yet been developed.
*
Bio-accumulative is defined as substances which
accumulate within living organisms
**
Lead, Cadmium and Mercury are heavy metals which
are Bio-accumulative.
*
- iv -
CAUTION
The power cord provided with this monitor is designed for safety and must be used with a properly
grounded outlet to avoid possible electrical shock.
Do not remove the monitor cabinet as this can
expose you to very high voltages and other hazards.
CONTENTS
1. INTRODUCTION ................................................... 2
1.1 Features ...................................................... 2
1.2 Internal Preset Memory Capability .............. 3
1.3 Power Management Function ..................... 3
1.4 DDC ............................................................ 3
1.5 Location Considerations ............................. 3
1.6 Cleaning Your Monitor ................................ 3
1.7 Unpacking ................................................... 4
1.8 Tilt/Swivel Base........................................... 4
Screen Position Adjustment ........................ 4
1.9 Quick Operation Chart ................................ 4
2. PART NAME.......................................................... 5
2.1 Control Names ............................................ 5
2.2 Function ...................................................... 5
3. INSTALLATION AND CONNECTION ................... 6
3.1 AC Power Connection................................. 6
3.2 Signal Cable Connection ............................ 6
3.2.1 Connecting to any IBM VGA Compatible
System ................................................. 6
3.2.2 Connecting to an Apple Macintosh
Computer ............................................. 6
WARNING!
This product is not designed for use in life support
devices and Mitsubishi Electric Australia Pty. Ltd.
makes no representations to the contrary. Life support
devices are those devices which are used to measure,
diagnose, or evaluate the tissue, systems or functions
of the human body; or other devices employed to
support or sustain life or good health.
Trademark
IBM, PC, PS/2, PS/V, Personal System/2 are registered trademarks of International Business Machines Corp.
Apple Macintosh is a registered trademark of Apple Computer, Inc.
Quadra is a trademark of Apple Computer, Inc.
UNIX is a registered trademark in the United States and other
countries, licensed exclusively through X/Open Company Limited.
ENERGY STAR is a U.S. registered mark.
4. OSD(On Screen Display) FUNCTIONS ................ 7
4.1 How to adjust the screen ............................ 7
4.2 Adjustment Items ........................................ 8
5. TROUBLESHOOTING .......................................... 9
6. SPECIFICATIONS................................................. 11
7. WARRANTY .......................................................... 12
© 2001 Mitsubishi Electric Australia Pty. Ltd.
- 1 -
1
INTRODUCTION
1
Congratulations on your purchase of this high resolution
color monitor. We designed this monitor to provide you
with years of reliable trouble-free operation.
This guide tells you how to connect, adjust and care for your
monitor. This guide also provides technical specifications
and instructions for troubleshooting any basic problems
you may experience with your monitor.
1.1 Features
This monitor is a 43cm/17" (41cm/16" Viewable Image
Size) intelligent, microprocessor-based monitor compatible with most analog RGB (Red, Green, Blue) display
standards.
It provides crisp text and vivid color graphics with both PC
and Macintosh platforms.
• The monitor’s wide auto-scanning compatibility range
makes it possible to upgrade video cards or software
without purchasing a new monitor.
• Digitally controlled auto-scanning is done using an
internal microprocessor, for horizontal scan frequencies between 31kHz and 70kHz, and vertical scan
frequencies between 55Hz and 120Hz. The microprocessor-based intelligence allows the monitor to operate in each frequency mode with the precision of a fixed
frequency monitor.
• The monitor complies with Video Electronics Standards
Association (VESA) DDC1/2B(EDID) specification. If
your computer is Plug & Play compliant setup will be
done automatically.
• The CRT provides fine 0.25mm variable aperture grille
pitch/Maximum addressable resolution of 1280x1024.
• The monitor contains resident memory for pre-programmed screen display standards and is also capable
of storing additional user adjustment parameters.
• The monitor is capable of producing a non-interlaced
maximum addressable resolution format of 1280 dots
x 1024 lines. This display is well suited for windowing
environments.
• Because of the analog signal inputs, the monitor can
display an unlimited palette of colors that can be
manually adjusted to suit your specific needs.
• The monitor has a power management function accorded to VESA-DPMS-standard. To save energy, the
monitor must be connected to a system compliant with
the VESA-DPMS
and/or video card instructions for proper operation.)
• To ensure ease of installation and ongoing use, the
monitor features On Screen Display (OSD) of all monitor set-up and adjustment functions.
• For use in a variety of applications, the monitor complies with UL 1950, CSA C22.2 No.950 and EN60950
for safety, FCC Class-B, EN55022 Class-B and AS/
NZS 3548 Class-B for EMI, MPR-II, ISO 9241-3,
ISO9241-7 and ISO9241-8 for ergonomics. The monitor also complies with TCO’99 guideline for environmental safe use.
-
standard. (Refer to your computer
• This monitor features the new standard in CRT technology, the DIAMONDTRON NF with improved focus and
convergence for super-sharp and pure displayed images.
- 2 -
1.2 Internal Preset Memory Capability
1.5 Location Considerations
To minimize adjustment needs, the factory has preset
popular display standards into the monitor, as shown in
Table 1. If any of these display standards are detected, the
picture size and position are automatically adjusted. All of
the factory presets may be overwritten by adjusting the user
controls. This monitor is capable of automatically storing up
to 24 additional display standards. The new display information must differ from any of the existing display standards by at least 1kHz for the horizontal scan frequency or
4Hz for the vertical scan frequency or the sync signal
polarities must be different.
Table 1. Memory Buffer Factory Presets
PRESET
TIMING
640 x 400 N.I.
640 x 480 N.I.
640 x 480 N.I.
640 x 480 N.I.
800 x 600 N.I.
800 x 600 N.I.
800 x 600 N.I.
1024 x 768 N.I.
1024 x 768 N.I.
1024 x 768 N.I.
1024 x 768 N.I.
1280 x 1024 N.I.
Fh(kHz)
31.5
31.5
37.5
43.3
37.9
46.9
53.7
48.4
56.5
60.0
68.7
64.0
Fv(Hz)
70.1
59.9
75.0
85.0
60.3
75.0
85.0
60.0
70.1
75.0
85.0
60.0
Polarity
H
-
-
-
+
+
+
-
+
+
+
V
+
-
-
+
+
+
-
+
+
+
When setting up and using the monitor, keep the following
in mind:
• For optimum viewing, avoid placing the monitor
against a bright background or where sunlight or
other light sources may reflect on the display area of
the monitor. Place the monitor just below eye level.
• Place the monitor away from strong magnetic or
electromagnetic fields, such as high capacity transformers, electric motors, large current power lines,
steel pillars, etc....
Magnetism can cause distortion in the picture and/or
colour purity.
• Avoid covering the slots or openings of the monitor.
Allow adequate ventilation around the monitor so the
heat from the monitor can properly dissipate. Avoid
putting the monitor into any enclosure that does not
have adequate ventilation.
• Avoid exposing the monitor to rain, excessive mois-
ture, or dust, as this can cause a fire or shock hazard.
• Avoid placing the monitor, or any other heavy object,
on the power cord. Damage to the power cord can
cause a fire or electrical shock.
• When transporting the monitor, handle it with care.
1.3 Power Management Function
The monitor has a power management function which
reduces the power consumption of the monitor when not
in use.
The power saving mode is invoked by a VESA DPMScompliant computer. Check your computer's manual for
setting this function.
Mode Power Power-On Indicator
Normal 73 W Green
Power Saving Mode 5 W Orange
<
=
1.4 DDC
The monitor includes the VESA DDC1 and DDC2B feature.
DDC (Display Data Channel) is a communication channel
over which the monitor automatically informs the computer
system about its capabilities (e.g. each supported resolution with its corresponding timing).
DDC is routed through previously unused pins of the 15-pin
VGA connector.
The system will “Plug and Play” if both monitor and computer implement the DDC protocol.
1.6 Cleaning Your Monitor
When cleaning the monitor, please follow these guidelines:
• Always unplug the monitor before cleaning.
• Wipe the screen and the front and sides of the
cabinet with a soft, dry cloth.
• If the screen requires more than dusting, apply a
household window cleaner to a soft cloth to clean
the monitor screen.
CAUTION
• Do not use benzene, thinner or any volatile sub-
stances to clean the unit as the finish may be
permanently marked.
• Never leave the monitor in contact with rubber or
vinyl for an extended time period.
• Do not spray directly on the screen as cleaner may
drip into the monitor and damage the circuitry.
• Never use an abrasive cleaner on the screen sur-
face as this will damage the anti-reflection coating.
- 3 -
1.7 Unpacking
1.9 Quick Operation Chart
After you unpack the box you should have all of the items
indicated in Figure 1. Save the box and packing materials
in case you transport the monitor.
1
2
3
Figure 1
To summarize the steps in connecting your computer
with the color monitor and setting the necessary controls
and switches, refer to the chart below.
Connect the color monitor and computer with
the necessary cords and cables.
See
Section 3. INSTALLATION AND CONNECTION
Turn on the color monitor.
Turn on the computer.
1. Color Monitor
2. AC Power Cord
3. User's Guide
(this document)
1.8 Tilt/Swivel Base
The monitor comes with a tilt/swivel base. This enables you
to position the monitor at the best angle and tilt for
maximum viewing comfort.
Screen Position Adjustment
Adjust the tilt and rotation of the monitor by placing your
hands at opposite sides of the case. You can adjust the
monitor 90 degrees right or left, 10 degrees up or 5 degrees
down, as shown below.
90°
10°
90°
5°
OK
Set the controls.
See
Section 4. OSD(On Screen
Display) FUNCTIONS
If a problem appears.
OK
See Section 5. TROUBLESHOOTING
If the problem persists.
Call for your authorized Product Support.
Figure 2
CAUTION
Keep your fingers away from the pivot area of the tilt/swivel
base.
- 4 -
2
2
2.1 Control Names
See Figures 3 and 4 for the location of the user controls,
indicator and connectors.
Each part is identified by number and is described
individually.
PART NAME
FRONT
SELECT
RESET
Figure 3
REAR
Figure 4
2.2 Function
1. POWER SWITCH: A push-on / push-off switch for AC
power.
2. POWER-ON INDICATOR: This indicator illuminates
green when AC power is on, and illuminates orange
when the monitor is in the power management modes.
3. - / + BUTTON:
•With item select screen, push to select the item icon.
•With item adjustment screen, push to adjust the image
on the screen.
•Without OSD screen, push to adjust the contrast.
4. SELECT BUTTONS:
•Push to turn on the OSD screen.
•With item select screen, push to proceed the adjust-
ment screen.
5. AC POWER CONNECTOR
6. SIGNAL INPUT CONNECTOR: DB9-15P
- 5 -
3
INSTALLATION AND
3
CONNECTION
On the back of the monitor two kinds of plug-in connections
are provided: AC power connector for the AC input, DB915P connector for video signal input.
3.1 AC Power Connection
One end of the AC power cord is connected to the AC
power connector on the back of the monitor. The other end
is plugged into a properly grounded three-prong AC outlet.
The monitor’s auto-sensing power supply can automatically detect 100-240V AC and 50 or 60Hz.
3.2 Signal Cable Connection
The DB9-15P(VGA) connector is provided for compatible
analog RGB outputs from your computer. Apple Macintosh
computers can also be interfaced with using the optional
Macintosh adapter.
3.2.1 Connecting to Any IBM VGA Compatible System
Figure 5 shows the signal cable connection to the Video
Graphics Array (VGA) port in an IBM Personal System/2
series, or any VGA compatible system.
1. Power off, both the monitor and the computer.
2. Connect the one end of the signal cable to the
DB9-15P connector on the VGA controller card.
3. Power on the monitor, then the computer.
4. After using the system, power off the monitor, then
the computer.
3.2.2 Connecting to An Apple Macintosh Computer
Figure 6 shows the signal cable and Adapter (option) to the
video port in an Apple Macintosh.
The Macintosh Adapter is available that converts the 2 row
D-sub video connector on legacy Macintosh computers to
a 3 row D-sub(VGA) connector compatible with your
Mitsubishi monitor. The Macintosh Adapter is not needed
on G3 (ice and blue) and later version of the Macintosh.
Macintosh Adapters are available from Mitsubishi Electric
Australia. Should your system require an Adapter, please
contact your computer dealer.
1. Power off, both the monitor and the computer.
2. Set the DIP switches of Macintosh Adapter according
to the setting chart.
3. Connect the 15-pin (DB-15P) end of the Adapter to
the straight 15-pin connector on the Macintosh video
port on the computer or on the video board.
4. Connect the sub-miniature 15-pin (DB9-15P) end of
the Adapter to the signal cable.
5. Power on the monitor, then the Macintosh.
6. After using the system, power off the monitor, then the
Macintosh.
Computer
Apple Macintosh
Computer
Computer
VGA
Compatible
System
DB9-15P
Power Cord
CAUTION
The socket-outlet shall be installed near the equipment
and shall be easily accessible. During servicing, disconnect the plug from the socket-outlet.
Signal Cable
Figure 5
DB9-15P
Power Cord
• For the Apple Macintosh Computers having a VGA
compatible port, steps 2 through 4 are not necessary.
Connect the end of the signal cable to the port directly.
• If you have an Apple Macintosh G3 series, use the
Control Panel in the Apple Menu to select a resolution.
If the resolution is selected from the Control Strip, the
screen may go blank and the computer may freeze.
- 6 -
Signal Cable
Figure 6
Macintosh
Adapter
(Option)
4
OSD (On Screen Display)
4
FUNCTIONS
4.1 How to adjust the screen
The monitor has an OSD(On Screen Display) function.
The following procedure shows how to adjust the screen using the OSD function.
SELECT
(1) Turn on the monitor by pressing
(2) Display the OSD screen by pressing
(3) Select the item icon on item select screen by pressing
(4) Display the item adjustment screen by pressing
(5) Adjust by pressing
(6) To turn the OSD screen off, select "exit" and press button
RESET
SELECT
SELECT
SELECT
If you don't press a button during 10 seconds, the OSD will turn off automatically.
- 7 -
4.2 Adjustment Items
X: Available
Item
Icon
Item
Brightness
Contrast
Red Color Control
Green Color Control
Blue Color Control
Horizontal position
Vertical position
Horizontal size
Vertical size
Press the Minus Button
To decrease the brightness.
To decrease the contrast.
To increase the brightness.
To increase the contrast.
NOTE
Without OSD screen, push to adjust the contrast.
To decrease the red contrast.
To decrease the green contrast.
To decrease the blue contrast.
To move the image on the screen to
the left.
To move the image down.
To narrow the width of the image on
the screen.
To narrow the height of the image on
the screen.
To increase the red contrast.
To increase the green contrast.
To increase the blue contrast.
To move the image on the screen to
the right.
To move the image up.
To expand the width of the image on
the screen.
To expand the height of the image on
the screen.
Press the Plus Button
BA
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Pincushion / Barrel
Trapezoid
To contract the center of the image.
To decrease the width at the top of the
screen image and to increase the
width at the bottom.
Parallelogram
Bow
(Pincushion Balance)
Rotates
To make the screen slant to the left.
To move the top and bottom of the
screen image to the right.
To rotate the image counterclockwise.
Select the degauss icon on "Item select screen" and push "SELECT" button.
It will eliminate the stray magnetic field and correct the scan of the electron beam,
Degauss
which affect the purity, focus and convergence.
NOTE
Allow a minimum interval of 20 minutes to elapse between uses of the degauss function.
Color Temperature
OSD
EXIT
Select the Color Temperature icon on "Item select screen" and push "SELECT"
button.
There are 3 background colors (Blue, Black, and White).
These can be selected by "SELECT" button after the selection of "OSD" on "Item select
screen"
To exit OSD screen. Select EXIT on "Item select screen",
then push "SELECT" button.
NOTE
A. Press and button together, to restore to the factory preset.
B. Set data does not change by the change of the signal timing.
To expand the center of the image.
To increase the width at the top of the
screen image and to decrease the width
at the bottom.
To make the screen slant to the right.
To move the top and bottom of the
screen image to the left.
To rotate the image clockwise.
X
X
X
X
X
X
X
X
–
–
–
X
–
X
–
–
- 8 -
5
5
TROUBLESHOOTING
Before calling your Authorized Product Support, please
check that the items below are properly connected or set.
In case of using a non-standard signal, please check the
pin assignments and the signal timing of your computer
with the specification outlined in Section 6. SPECIFICATIONS.
PROBLEM
LED On
(Green)
LED Off
No
LED On
(Orange)
LED Blinking
(Orange)
Display is missing, center shifts,
or too small or too
large of a display
size
ITEMS TO CHECK
•
Contrast and brightness controls
•
Power switch
•
AC power cord disconnected
•
Signal cable disconnected
•
Computer power switch
•
Power management function is active.
•
Power switch
Due to fine dusts existing in the inside of CRT, a discharge may occur at the CRT. When the
discharge occur, the monitor may turn off automatically. This is by an internal protection circuit
operated and it is to avoid electrical components broken.
•
Press "-" and "+" button together, to restore to the factory
preset.
•
Adjust Horizontal size, Vertical size, Horizontal position,
and Vertical position with non - standard signals.
•
Monitor may not be able to get full-screen image depend on
signal. In this case, please select other resolution, or other
vertical refresh timing.
•
Make sure you wait a few seconds after adjusting the size
of the image before changing or disconnecting the signal.
•
•
•
•
•
•
•
•
•
LOCATION
Front (OSD)
Front
Rear
Rear
Computer
Press any key on the keyboard
or move the mouse.
Front
Front (OSD)
Front (OSD)
Black vertical
lines are visible
on the screen.
Abnormal picture
•
Thin vertical black lines on one or both sides of the
screen. This minor condition is caused by grille element
overlap which can occur during shipping.
•
Position an open white window over the affected area of
the screen and maximize the brightness and contrast
controls. This will cause localized heating of the overlap
which will clear in a few minutes. Be sure to readjust the
brightness and contrast controls back to the normal
viewing levels after this procedure.
- 9 -
PROBLEM
Two fine horizontal
lines are visible on
the screen.
ITEMS TO CHECK LOCATION
•
The 2 very faint thin lines across the screen are normal.
They are caused by the aperture grille stabilization
filaments(Damper Wires) which are required for all
aperture grille CRTs’.
Aperture Grille
Electrn Gun
Damper Wires
Shadow of
Damper Wires
Shadow of Damper Wires
A buzzing sound
when power on.
Aperture Grille Type
A brief vibration or hum sound that is heard just after power
•
up is normal. This is caused by the automatic degaussing
function. This sound will be heard each time the monitor is
powered up from a cold start and each time the manual
degauss button is used.
- 10 -
6 SPECIFICATIONS
6
Size 43cm/17" (41cm/16" Viewable Image Size)
Mask type Aperture grille
Gun In-line
Deflection angle 90°
CRT Phosphors Red, Green, Blue EBU (medium short persistence)
Aperture grille pitch 0.25mm
Face Plate Anti-glare, Anti-reflection and Anti-static film
Focusing method Dynamic Beam Forming (DBF)
INPUT SIGNAL
SIGNAL INTERFACE
SCANNING Horizontal 31 - 70kHz
FREQUENCY Vertical 55 - 120Hz
RESOLUTION (HxV) 1280 dots x 1024 lines Non-Interlaced maximum addressable resolution format at 75Hz
WARM-UP TIME 30 minutes to reach optimum performance level
BRIGHTNESS 100cd/m2, standard full white video signal at 9300K (+ 8MPCD)
BLANKING TIME
DISPLAY SIZE 310mm x 232mm(typ.) ratio 4:3
COLOUR 5000K~9300K
POWER SOURCE
OPERATING Temperature 10 - 35°C
ENVIRONMENT Humidity 30 - 80%RH (without condensation)
DIMENSIONS (W)15.9inch x (H)16.5inch x (D)16.5inch / (W) 403mm x (H) 420mm x (D) 420mm
WEIGHT Approx. 16.4kg / 36.2lbs.
TILT/SWIVEL Tilt Angle -5° - +10°
BASE Swivel Angle ±90°
REGULATIONS X-Ray DHHS, HWC, Röv vom 8.1, 1987
Video 0.7V analog RGB
Sync Separate H, V sync., or Composite sync
Input Connectors DB9-15P
Input Impedance 75Ω (video), 2.2kΩ(sync.)
Horizontal 3.6 µsec (typ.)
Vertical 530 µsec (typ.)
AC100-240V±10% 50/60Hz 73W (typ.)
Safety UL1950 (UL), CSA C22.2 No.950 (C-UL)
EMC FCC Class-B, DOC Class-B
Other CE-Marking, MPR-II/TCO'91
<
=
<
=
EN60950 (TÜV-GS)
EN55022 Class-B, AS/NZS 3548 Class-B
EN50082-1, EN61000-3-2, EN61000-3-3, EN55024
ISO9241-3, ISO9241-7, ISO9241-8 (TÜV-GS)
TCO '99
International E
NERGY STAR Program
This monitor is registered / certified with Model No. N0701.
*
- 11 -
7 WARRANTY
