Mitsubishi Electronics 838 User Manual

3D DLP ™ HOME-CINEMA TELEVISION
®
MODELS
738 Series
838 Series
OWNER’S GUIDE
• For questions:
- E-mail us at MDEAservice@mdea.com.
- Call Consumer Relations at 800-332-2119.
• For information on System Reset, please see the back cover.
• To order replacement or additional remote controls or lamp cartridges, visit our website at
www.mitsuparts.com or call 800-553-7278.
• 838 Series. IR emitter cables for NetCommand home-theater control are available for
purchase from Mitsubishi. (two-ended cable) or part number 299P254020 (four-ended cable).
Call 800-553-7278 and
request either part number 242D483020
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user of the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to consti­tute a risk of electric shock to persons.
The exclamation point within an equilat-
eral triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the product.
MAINS DISCONNECTION: The mains plug is used as the disconnect device. The mains plug shall remain readily operable.
Stand Requirement
CAUTION: Use these Mitsubishi TV models only with the Mitsubishi stand models shown here. Other stands can result in instability and possibly cause injury.
TV Model Stand Model
WD-60738, WD-65738 WD-65838
WD-73738 WD-73838
82-inch TVs. Mitsubishi does not design, manufac­ture, or sell matching bases for 82-inch televisions (WD-82738, WD-82838). When selecting a stand, base, or other furniture to support the TV, please make sure it is designed with the appropriate dimensions for stabil­ity and to support the TV’s total weight as well as the weight of any additional equipment you plan to store.
TV WEIGHT: This TV is heavy. Exercise extreme care
when lifting or moving it. Lift or move the TV with a minimum of two adults. To prevent damage to the TV, avoid jarring or moving it while it is turned on. Always power off your TV, unplug the power cord, and discon­nect all cables before moving it.
MB-S60/65A
MB-S73A
FCC Declaration of Conformity
Product: Projection Television Receiver Models: WD-60738, WD-65738, WD-73738,
WD-82738 WD-65838, WD-73838, WD-82838
Responsible Party:
Telephone: (80 0) 3 3 2- 2 119
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
This device may not cause harmful interference,
(1)
and
(2) This device must accept any interference
received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential instal­lation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communica­tions. However, there is no guarantee that interfer­ence will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equip­ment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/
TV technician for help.
Changes or modifications not expressly approved by Mitsubishi could cause harmful interference and would void the user’s authority to operate this equipment.
Mitsubishi Digital Electronics America, Inc. 9351 Jeronimo Road Irvine, CA 92618-1904
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
WARNING: This product contains chemicals known to the State of California to cause cancer and/or birth defects or other reproductive harm.
For assistance call 1(800) 332-2119
Note: Features and specifications described in this
owner’s guide are subject to change without notice.
Contents
Important Information About Your TV
Installation and Operating Notes ............. 4
Important Safety Instructions ................ 5
1 Basic Setup and Operation
Package Contents ....................... 7
Before You Begin ........................ 8
First-Time Power-On ...................... 8
TV Controls ............................ 9
Remote Control ...................... 9
The TOOLS Key and Menu ............. 10
TV Control Panel .................... 11
The STATUS Indicator ................. 11
Setting Up TV Inputs..................... 12
Basic TV Operation...................... 14
Using the TV with a Personal Computer ....... 17
2 TV Connections
Before You Begin ....................... 19
Connection Types and Audio/Video Quality .... 19
Inputs and Outputs ...................... 20
H
DMI Device ............................ 22
Y Pb Pr Component Video Device ........... 23
DVI Video Device ....................... 23
Antenna or Cable TV Service ............... 24
Composite Video Device .................. 24
VCR or DVD Recorder to an Antenna or
Wall Outlet Cable ...................... 24
A/V Receiver .......................... 25
A/V Receiver with HDMI Output ............. 25
Supplemental Audio Connections ........... 26
3 TV Features
Sleep Timer ........................... 28
FAV (Favorite Channels) ................... 28
ChannelView Channel Listings .............. 29
Status Display ......................... 30
Using an External Sound System ............ 31
Picture Shape and Display Formats .......... 32
3D Video ............................. 33
Enhanced 3D Video Options ............ 33
Earlier 3D Video Options ............... 35
Camera Images and Music Files ............ 37
USB Source Devices (838 Series) ......... 37
Photos and Motion Video as
Composite Video ................... 39
Using an Audio-Only Device ............ 39
Wireless Audio Playback ............... 40
Sound Projector (838 Series) ............... 41
StreamTV™ Internet Media ................ 45
Introduction to Home-Theater Control ........ 48
4 TV Menus
Main Menu ............................ 49
Picture............................... 49
Sound
............................... 53
Captions ............................. 55
Setup ............................... 56
Inputs ............................... 59
Lock ................................ 61
5 NetCommand IR Control
About NetCommand IR Control
IR Emitters ............................ 65
NetCommand Setup ..................... 66
Operating NetCommand-Controlled Devices ... 67
6 NetCommand IR Control of an A/V Receiver
Controlling an A/V Receiver after NetCommand
Setup .............................. 70
Setting Up A/V Receiver Control
Power and Volume ................... 71
Automatic Audio/Video Switching Over
an HDMI Connection ................. 72
Appendices
Appendix A: Programming the Remote Control . 77
Appendix B: Bypassing the Parental Lock ..... 83
Appendix C: HDMI Control of CEC Devices .... 85
Appendix D: TV Care
Lamp-Cartridge Replacement ........... 88
Cleaning Recommendations ............ 90
Care of the Remote Control ............. 90
Appendix E: Troubleshooting .............. 91
Trademark and License Information .......... 98
Network Service Disclaimer ................ 98
Warranty ............................. 105
Index ................................ 107
............. 64
For assistance call 1(800) 332-2119
4

Important Information About Your TV

Internal Fans
For Your Records
Record the model number, serial number, and purchase date of your TV. The model and serial numbers are on the back of the TV. Refer to this page when requesting assistance with the TV.
MODEL NUMBER SERIAL NUMBER PURCHASE DATE RETAILER NAME LOCATION

Installation and Operating Notes

Custom cabinet installation must allow for proper air circulation around the television.
NOTE TO CATV SYSTEM INSTALLER: THIS REMINDER IS PROVIDED TO CALL THE CATV SYSTEM INSTALLER’S ATTENTION TO ARTICLE 820-40 OF THE NEC THAT PRO­VIDES GUIDELINES FOR THE PROPER GROUNDING AND, IN PARTICULAR, SPECIFIES THAT THE CABLE GROUND SHALL BE CONNECTED TO THE GROUNDING SYSTEM OF THE BUILDING, AS CLOSE TO THE POINT OF CABLE ENTRY AS PRACTICAL.
Internal cooling fans maintain proper operating tem­peratures inside the TV. It is normal to hear the fans when you first turn on the TV, during quiet scenes while viewing the TV, and for a short time after shutting off the TV. You may notice louder fan noise about 30 seconds after shutting off the TV and while using the
Bright Lamp Energy setting.
Lamp Replacement
For lamp-replacement instructions, see Appendix D.
To Order a Replacement Lamp Under Warranty
Call (800) 553-7278. Please have model number, serial number, and TV purchase date available.
To Purchase a Replacement Lamp After Warranty
Visit our website at www.mitsuparts.com or call (800) 553-7278. Order new lamp part number 915B441001.
Children and TV Viewing
The American Academy of Pediatrics discourages television viewing for children younger than two years of age.
TV Software
Do not attempt to update the software of this TV with software or USB drives not provided by or authorized by Mitsubishi Digital Electronics America, Inc. Non­authorized software may damage the TV and will not be covered by the warranty.
For assistance call 1(800) 332-2119
5

Important Safety Instructions

Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
E XA MP LE OF AN T E NNA G R O U NDING
AN TE NN A LE AD IN W IR E
G R OU ND CL AMP
E LE C TR IC S E R V IC E E QU IPM EN T
NE C — N AT IO NAL E LE C TR IC AL C OD E
AN TE NN A DIS C HA R G E UN IT (N E C A R TI CL E 81 0-20)
G R OU NDING C OND UC TO R S (N E C A R TI CL E 81 0-21)
G R OU ND CL AMP S
P OW E R S E R VIC E G RO UN DIN G E LE C TR O DE S YS T E M (N E C A R T 250, P AR T H)
Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the TV, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.
Replacement Parts
When replacement parts are required, be sure the service technician has used replacement parts speci­fied by the manufacturer or have the same character­istics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
For assistance call 1(800) 332-2119
6
Special Features of Your TV
Your new high-definition widescreen television has
many special features that make it the perfect center of your home entertainment system, including:
1080p High-Definition DLP Display System
Your Mitsubishi HDTV uses Texas Instruments Digital
Light Processing™ technology for rear-projection TVs to create the picture you see on screen. All images are displayed at 1080p. The TV uses Plush 1080p® 5G to convert lower-resolution signals to 1080p for display.
The TV can also accept 1080p original signals and main-
tain them at 1080p through all processing until displayed.
3D Television
All Mitsubishi 738 and 838 1080p home-Cinema HDTV’s can display 3D content originating in several different formats. This feature lets you experience the new 3D technologies applied to many recent movies and video games. Immerse yourself in your favorite video game, movie, or sporting event displayed in 3D.
16:9 Widescreen Picture Format
Enjoy a full theatrical experience in the comfort of your home. View pictures as film directors intended them. Digital TV broadcasts, DVDs and newer video game consoles support this widescreen format.
Integrated HDTV Tuner
Your widescreen Mitsubishi HDTV has an internal HDTV
tuner able to receive both over-the-air HDTV broad­casts (received via an antenna) and non-scrambled digital cable broadcasts, including non-scrambled HDTV cable programming.
High-Definition Video Inputs
• Component Video Inputs. Also called Y/Pb/Pr
inputs, these inputs receive standard analog video formats of 480i, 480p, plus 720p and 1080i high­definition signals. This provides a high level of flexibility when connecting DVD players/recorders, cable boxes, and satellite receivers.
• HDMI Inputs. HDMI® inputs provide additional
high-performance, high-definition connections for maximum flexibility in your choice of home theater products. These inputs accept digital 480i, 480p,
720p, 1080i, and 1080p video signals plus PCM
digital stereo signals. The HDMI inputs can also accept a variety of PC signals and resolutions.
These inputs support Deep Color (up to 36 bits)
and the x.v.Color™ extended color gamut. Used with an adapter, these HDMI inputs also
accept compatible digital DVI video signals. The HDMI inputs are HDCP copy-protection compatible.
Easy Connect Auto Input Sensing
Easy Connect™ Auto Input Sensing automatically rec­ognizes when you plug in a device and prompts you to assign a name to it. The TV ignores any unused inputs, so the result is an uncluttered menu where you can easily select devices by name.
Home-Theater Control
HDMI Control
All models. HDMI devices with Consumer Electronics Control (CEC) capabilities may be compatible with the TV’s HDMI Control feature. Compatible devices can receive control signals through the HDMI connection, allowing the TV’s remote control to operate some func­tions of these devices.
NetCommand with IR Learning
838 Series. Your Mitsubishi HDTV offers a new level of networking that seamlessly integrates selected older A/V products with new and future digital products. NetCommand® supports IR (infrared) control of prod­ucts such as DVD players, cable boxes, satellite receiv­ers, and VCRs. The necessary IR emitter cables are available for purchase separately from Mitsubishi.
Immersive Sound Technology
838 Series. Sound Projector technology uses the TV’s
bank of speakers to create a simulated surround sound effect by reflecting sound off the room walls.
StreamTV Internet
StreamT V™ brings many popular internet applications to your TV. Among them is the VUDU™ movie service, offer­ing the largest on-demand HD movie selection anywhere, featuring full 1080p and 5.1 surround sound. VUDU allows you to enjoy movies with no store visits, no mailing, no late fees and no subscriptions.
ENERGY STAR
The following TV models are ENERGY STAR® qualified: WD-65738, WD-73738, WD-82738 WD-65838, WD-73838, WD-82838
Products that earn the ENERGY STAR prevent greenhouse gas emissions by meeting strict energy efficiency guidelines set by the U.S. Environmental Protection Agency and the U.S. Department of Energy.
For assistance call 1(800) 332-2119

Basic Setup and Operation

1

Package Contents

7
Please take a moment to review the following list of items to ensure that you have received everything.
Remote Control
Two AA Batteries
Basic Owner’s Guide
Quick Setup Guide
Product Registration Card
AA
AA
Installing the Remote Control Batteries
1.
Remove the remote control’s back cover by gently pressing in the tab and lifting off the cover.
2.
Load the batteries, making sure the polarities (+) and (-) are correct. For best results, insert the negative (-) end first.
3.
Snap the cover back in place.
1
2
The remote control requires two AA alkaline batteries.
838 Series. Calibration Microphone
For assistance call 1(800) 332-2119
8 1. Basic Setup and Operation

Before You Begin

1.
Review the important safety, installation, and oper­ating information at the beginning of this book.
2.
Choose a location for your TV.
• Allowatleastfourinchesofspaceonallsides
of the TV to help prevent overheating. Over­heating may cause premature failure of the TV as well as shortened lamp life.
• Avoidlocationswherelightmayreflectoffthe
screen.
• Seethestandrequirementsonpage 2.
3.
Install the batteries in the remote control.
4.
Plug the TV into an AC power outlet.

First-Time Power-On

1.
Press the ensure that the remote control is in TV mode.
TV
key to
TV
TV
TV Tips
Turning the TV On or Off
• Point the bulb end of the remote control at the front of the TV and press the
• Press the panel.
If You Turn Off the TV by Mistake
• Press to have the TV come back on immediately.
• IIf the 60 seconds after you shut off power), wait a few moments for the indicator to stop flashing and press
• Controlling Sound Volume
• Press
• See also “Controlling A/V Receiver Sound
Volume” on page 31.
Changing Channels (antenna sources)
NOTE: Perform a channel scan to enable recep­tion of digital channels. See Setup > Channel, page 57.
POWER
button on the TV control
POWER
again, within about 60 seconds,
STATU S
indicator is flashing green, (about
POWER
to turn the TV on again.
VOL
to adjust the sound level.
POWER
key.
2.
Aim the bulb end of the remote control at the TV and press the for the Welcome screen.
3.
If you wish to change the menu language to Español, press .
4.
Press to highlight EXIT. Press menu.
POWER
ENTER
key . Wait
to clear the
• Enter the channel number using the number keys on the remote control and press For a two-part digital channel, such as 3-1,
press
• Press CH to change channels one channel at a time.
• Press and hold channels.
• Press channel.
• Press listings, highlight a channel, and press
• Use the Fav (Favorites) feature to tune to up to nine favorite channels. See page 28.
• Use the CH key to tune to preselected groups of channels using ChannelView custom channel banks. See page 29.
3
CANCEL
LAST
GUIDE
1 to include a dash (separator).
CH
to move quickly through
to return to the previously tuned
to display ChannelView channel
ENTER
ENTER
.
.
For assistance call 1(800) 332-2119
1. Basic Setup and Operation 9

TV Controls

Remote Control

For more on use and care of the remote control, see page 90.
Emitter (Bulb) End
MUTE
TOOLS
VOL
PAGE
ENTER
Sleep Timer, page 28
Number/letter keys
Channel tuning, page 14 Pass-code entry, page 61, page 46
Adds a separator in digital channel numbers. Clears some menu entries.
Mutes the TV speakers.
Displays shortcuts for frequently used features. Press to check if shortcuts are available for the current device. See the next page.
Controls volume of TV speakers.
CH
Changes channels; moves to another page in a menu or list.
Selects a channel number or menu item.
Navigation and adjustment controls
TV CAB/SAT DVD AUDIO VCR
P
ress the key for the device type to control. Leave in TV mode for normal TV viewing.
Powers TV on or off.
Returns to the previous channel;
LAST
moves back one menu
FAV
FO RMAT
INTERNET
INPUT
AUDIO
Displays up to nine favorite sources, page 28.
Changes picture shape, page 16
Connects to StreamTV internet content, page 45.
Press to select a TV input, page 14.
Audio settings, page 53
GUIDE
INFO
Record/Playback controls for external devices
When remote control is programmed, page 77 HDMI control, page 87
838 Series: With NetCommand, page 69
Note: To operate other audio/video devices using the
• SeeAppendix A, “Programming the Remote
• ForHDMIdevicescompatiblewiththeTV’sHDMI
ChannelView listings, page 29
TV status or TV help.
(
PAUSE) Freezes a broadcast TV picture.
TV’s remote control:
Control.”
Control feature, see Appendix C.
.
VIDEO
MENU
EXIT
F1–F4.
with NetCommand IR control of external devices. See page 66.
• 838 Series
- See page 64 for NetCommand IR “Learning” of device keys.
- For use of specific keys with NetCommand­controlled devices, see “Special Operation Methods,” page 67.
Video settings, page 49
Displays or clears the TV main menu (page 49). back one menu.
Clears all menus.
838
Series. Special keys for use
Also steps
For assistance call 1(800) 332-2119
10 1. Basic Setup and Operation
TV Controls, continued

The TOOLS Key and Menu

TOOLS
Press the for common functions. Press the number key to activate the shortcut. See the
TOOLS
sample menu below.
• Shortcuts specific to the current device are in the third column.
• Shortcuts may be available for a CEC-enabled device. See Appendix C,
• 838 Series. After setting up NetCommand control for a device, check the
TOOLS
key to check for shortcuts. The Tools menu lists shortcut keys
“HDMI Control of CEC Devices,” page 85.
Tools menu for shortcuts. See page 66.
Sample Tools menu
PICTURE SOUND
Picture Shortcuts
1 Picture Mode Brilliant page 49
4 Picture Mode Natural
838 Series. Select an
Advanced Picture Mode if previously set up.
7 3D Mode On/Off page 33
page 51
Tools
Device-Specific Shortcuts
Availability varies, depending on equip-
TV
Sound Shortcuts
2 838 Series. Subwoof
Turns on or off audio to a connected subwoofer.
5 Surround Sound Mode Surround
8 Stereo
Sound Mode Stereo
ment features and setup.
3 CC
Turns closed captions on/of f
page 55
page 54
page 53
For assistance call 1(800) 332-2119
1. Basic Setup and Operation 11
POWER
STATUS
TV Controls, continued

TV Control Panel

Buttons on the control panel duplicate some keys on the remote control.
• To display the main menu, press simultaneously for about 10 seconds. Press and hold
INPUT
and
VOL+ for 10 seconds to clear the
menu.
• Refer to upper labels when no TV menus are dis- played.
• Refer to lower labels when using TV menus or after activating a special function.
On some models, open the front cover to use buttons on the control panel.
Sample TV controls and STATUS indicator
System Reset
If the TV fails to respond to the remote control, the control-panel buttons, or will not power on/off, perform System Reset. Recent setting changes made before using System Reset may be lost.
To perform System Reset, press and hold the button on the control panel for ten seconds.
Panel-Lock Release
• To release the Panel Lock using the TV control panel, press and hold the control panel for ten seconds. If the TV is off, press the
POWER
button to have it power on.
• To activate the Panel Lock, use the Lock menu, page 63.
INPUT
INPUT
and
VOL+
POWER
button on the

The STATUS Indicator

Symbols Off Steady On
LED Color TV Condition
None
Green
Green
Green
Yell ow
Yell ow
Red
Red/ Yell ow
Slow Flashing Fast Flashing
TV is powered off. Normal operation.
TV is powered on. Normal operation.
TV powered off, auto-on TV Timer is set.
Normal operation. TV can be turned on at any time.
TV just powered off and lamp is cooling.
Sixty seconds after turning off TV, LED will start to flash. TV can be turned back on before flashing starts or after flash­ing stops, but not while the indicator is flashing. Normal operation.
TV is too hot.
warning message and shut off if it over­heats.
• Ambientroomtemperaturemaybe
too high. Turn off the TV and let the room temperature drop.
• Clearblockedairvents.Ensureat
least a four-inch clearance on all sides of the TV.
Lamp access door is not secure or no lamp installed.
TV will not operate until lamp access door is secured. See Appendix D.
Lamp failure. Replace the lamp. See Appendix D.
TV may require service.
• Hold power button on front panel for 10 seconds to reset TV.
• If LED continues to flash red and yellow after reset, turn off the TV and unplug it from the AC power source. Wait one minute and then plug the set back in.
• If LED continues to flash red and yellow, or call 1-800-332-2119 to receive Authorized Service Center informa­tion.
You may be asked to count how many times the LED flashes each color to aid in troubleshooting.
The TV will display a
go to www.mitsubishi-tv.com
For assistance call 1(800) 332-2119
12 1. Basic Setup and Operation

Setting Up TV Inputs

Using the ANT (Antenna) Input
If using an antenna or direct cable service (no cable box), connect the incoming coaxial cable to the TV’s
ANT
input. Refer to page 24.
You must perform a channel scan to enable recep­tion of digital channels. If you skip this step, the TV will receive only analog channels. The channel scan
will search for high-definition and standard-definition channels available in your area.
Memorizing Channels with Channel Scan
For the ANT input
To start channel memorization
1.
Power on the TV.
2.
Press
MENU
and open the Setup > Channel menu.
Start channel memorization from the Setup > Channel menu.
Setting Up Inputs with Auto Input Sensing
1.
Power on the TV.
2.
Power on the devices to ensure detection.
3.
Connect one device to the TV, making note of the TV input jack.
The TV will display the New Device Found screen if the connection type is detectable.
4.
Highlight the device type in the on-screen list and press
ENTER
. The name you select here will appear
in the Input Selection menu.
3.
Press to enter the Channel menu.
4.
Highlight Ant Air if connected to an over-the-air antenna. Highlight Ant Cable for service over direct cable (no cable box). Press check.
5.
Select the scan type.
• For first-time setup, highlight All channels.
• To scan for channels not already in memory,
highlight Add only new channels. Press ENTER
to add a check.
6.
Highlight Scan and press Channel memorization may take up to 15 minutes to complete.
To stop channel memorization before completion, press
At any time after Channel Scan,
• Use the Setup > Channel > Edit menu (page 57) to
• Perform an additive scan with the New only option
• Repeat the All channels scan if you move the TV
CANCEL
add or delete individual channels from memory.
to add channels not already in memory.
to a new geographic area with a different channel line-up or reposition the antenna.
.
ENTER
ENTER
to add a
.
Sample New Device Found screen.
Important Note for NetCommand Users 838 Series. Be sure to select the correct device
type here. Although you can change the device type later using the Inputs > Name menu, any “learned” NetCommand IR codes will be erased when you make the change.
5.
Press
EXIT
to close the New Device Found screen.
6.
Repeat the preceding steps for each for each addi­tional device you want to add.
For assistance call 1(800) 332-2119
1. Basic Setup and Operation 13
Setting Up TV Inputs, continued
About Auto Input Sensing
This TV’s Easy Connect™ Auto Input Sensing feature detects the following connections automatically:
• Analog video jacks from inputs 1, 2, and 3
• HDMI inputs (when powered on)
• 838 Series. USB device containing photo and
music files (JPG and MP3 formats).
Auto Input Sensing for Most Devices
When you first connect a device, the TV will:
a. Detect the connected device and automati-
cally switch to it. b. Prompt you to identify the device type. c. Repeat these steps for other newly detected
devices.
When You First Connect a Device
• Most Device Types. Select the device type from
the on-screen list. The device type you select here will appear as an icon in the Input Selection menu.
• A/V Receiver.
receiver, select AVR the A/V receiver is not recognized automatically.
• HDMI CEC Devices Compatible with the TV’s HDMI Control Feature.
CEC-enabled HDMI-equipped devices are often recognized automatically by the TV. may allow you to control some functions of a CEC­enabled device. See Appendix C, “HDMI Control of CEC Devices.”
For an HDMI-equipped A/V
from the list of device types if
Compatible
HDMI Control
Tips on Auto Sensing
• Choose a different name for each input.
• The antenna input (
although you can turn off the unused antenna input in the Inputs > Name menu.
• Change the device type displayed in the Input Selection menu by using the Inputs > Name
menu (page 59).
• Some HDMI devices can automatically tell the TV what name to use in the Input Selection menu and you will be unable to change the name.
• The TV is unable to detect a new connection if the current input is USB, Bluetooth® (838 Series), or internet. Switch to a different input before connecting.
• 838 series. Any “learned” NetCommand IR codes will be erased if you change the device type in the Inputs > Name menu.
Reactivating Auto Input Sensing for an HDMI Input
After you disconnect an HDMI device, Auto Input Sensing is temporarily disabled for that HDMI jack. Perform these steps:
1.
Disconnect the HDMI device.
2.
Delete the removed HDMI device in the Inputs > Name menu (see “Removing an HDMI Device,”
page 87).
3.
Connect the new device and the New Device Found screen will display.
ANT
) is never detected,
New Device Found screen for a device with HDMI control enabled. Select On if you want to enable the TV’s HDMI control of the device. In some cases, as in the example above, you will also be prompted to select a device name.
For assistance call 1(800) 332-2119
14 1. Basic Setup and Operation

Basic TV Operation

Selecting an Input to Watch
1.
Press
INPUT
.
2.
Press and to highlight an input icon.
Sample Input selection menu, DVD input selected
3.
Press
ENTER
to switch to the input.
4.
To control the input device, use the device’s remote
control or see “Introduction to Home-Theater Control,” page 48.
Note: In most cases, to see a named icon for a con-
nected device (as in the samples), you must first assign a name either
• Whenthedeviceisfirstconnectedandthe
New Device Found menu offers a choice of names.
• ByusingtheInputs > Name menu to assign or change a name at any time after the TV has detected the connection.
More About the Input Selection Menu
• Toassignhelpfulnamestotheicons,seethe
Inputs > Name menu, page 59.
• ToremoveunwantedAntenna,Bluetooth®, or HDMI
device icons from the Input Selection menu, see the Inputs > Name menu, page 59.
• Torearrangetheicons,seetheInputs > Order menu, page 60.
Watching Broadcast TV
TV Connected to an Antenna or Direct Cable Service (no cable box)
Note: Perform channel memorization to enable recep-
tion of digital channels. See page 12.
1.
Press
INPUT
to display the Input Selection menu.
2.
Highlight the antenna or cable icon and press
Sample Input Selection menu, antenna input selected
3.
To tune to a channel from the these methods.
• Enter the channel number using the number keys on the remote control and press
For a two-part digital channel, such as 3-1, press
• Press CH to change channels one channel at a time.
• Press and hold CH to speed through channels.
• Press
• Use the Fav (Favorites) feature to tune to up to
nine favorite channels. See page 28.
• Press listings, highlight a channel number, and press
ENTER
• Set up ChannelView custom channel banks and use the CH key to tune to predefined
groups of channels. See page 29.
3
LAST
GUIDE
to tune.
CANCEL
1 ENTER
to return to the previous channel.
to display ChannelView channel
ANT
input, use any of
.
ENTER
ENTER
.
.
For assistance call 1(800) 332-2119
1. Basic Setup and Operation 15
Basic TV Operation, continued
Picture Settings
1.
To get the best picture under different viewing con­ditions, set the Picture Mode first before changing other video settings. See page 49.
a. Press b. Press until Picture Mode
c. Press to make one of these selections:
2.
Press to display the name of another adjust­ment.
3.
Press to make the adjustment.
4.
Press
Additional picture options are available through these menus:
VIDEO.
displays.
Name When to Use
Brilliant Game
Bright For most daytime viewing Natural For most nighttime viewing
EXIT
to clear the display.
Under bright light
With gaming consoles (inputs named
Game
or PC only)
Basic Audio Controls
Controlling Sound Volume
VOL
• Press of the TV speakers.
• See also “Controlling A/V Receiver Sound Volume” on page 31.
• 838 Series. Control volume with an on-screen slider See page 53. Set Sound > Global > Subwoofer to On to make this adjustment available.
Changing Audio Settings (TV Speakers Only)
1.
Press
2.
Press to find the adjust­ment you want. See page 53.
3.
Press to change.
Changing the Audio Output
To switch from the internal TV speakers to an external sound system,
to adjust the sound level
subwoofer
AUDIO
.
.
Picture > Video 49
Picture > Picture Plus
Picture > Perfect
(838 series)
Picture > Advanced 51
Picture > 3D Mode 52, 33
50
51
General picture appear­ance.
Screensaver control and adjustments for movies
Color fine-tuning
Advanced ISF color controls
3D video settings
1.
Press
AUDIO
.
2.
Press to display the TV Speakers option.
3.
Press to change to Off.
TV Care
• Lamp Cartridge. When the lamp cartridge needs replacement, replace the lamp yourself and save the cost of a service call. See Appendix D for instructions.
• General Cleaning. See “Cleaning Recommenda­tions,” page 90.
Assistance
• For troubleshooting, service, and product support, see Appendix E, starting on page 91.
• For warranty information, see page 105.
For assistance call 1(800) 332-2119
16 1. Basic Setup and Operation
Basic TV Operation, continued
The FORMAT Key and Picture Shape
Repeatedly press the
FO RMAT
through displays for the current program. The TV will remember the format you last used on each input.
For details, see page 32
Black bars at the edges of the screen are common in HD pictures. Black bars are not a defect of the TV.
• Black bars are added by broad­casters to fill the 16:9 screen area while preserving the original aspect ratio of the picture.
• Your cable box, satellite receiver, or other device may also be altering the broadcast picture. If your device offers output in native format, try using it with Mitsubishi picture formats.
key to cycle
Important
Sample Uses of the
If you prefer to reduce of eliminate black areas at the edges of the picture, use the
Squarish 4:3 image is narrower than the 16:9 screen; unused areas at the sides are filled with black.
Wide 2.35:1 anamorphic DVD image; unused areas at the top and bottom are filled with black (letterbox effect).
FO RMAT
key.
FO RMAT
Key
Press
Wide Expand mode stretches the picture sideways to fill the screen.
Press
Zoom mode. The picture fills the screen. All four edges are cropped in this mode.
More TV Features
Feature
Parental controls (Lock menu) 61
Audio Lock (controls your sound system with
TV
the TV’s remote control left in
TV Clock. Set the TV Clock if you plan to use the TV Timer (page 56) or ChannelView (page 29).
Favorite channels or sources 28
ChannelView and custom channel collections 29
Changing the input names that appear in the Input Selection menu (Inputs > Name menu)
3D Video 33
StreamTV™ internet access 45
Programming the remote control to operate other A/V devices
mode.)
Page
78
56
59
77
Feature
Digital camera images as composite video 39
Controlling compatible devices using HDMI CEC control
838 Series. Controlling A/V devices with Net­Command
838 Series. Listening to a wireless audio device with the TV speakers
838 Series. Using an external subwoofer. 26
838 Series. Center and rear channel audio
output
Page
85
64
40
27
For assistance call 1(800) 332-2119
1. Basic Setup and Operation 17
1
2
3
HDMI
AUDIO OUTPUT
Pb Pr
INPUT 2
INPUT 1
DIGITAL
AUDIO
OUTPUT
DVI/PC
(480i / 480p / 720p / 1080i)
LR INPUT
AUDIO
Y/ VIDEO
Pb Pr
Y/ VIDEO
3D GLASSES EMITTER
ANT
AUDIO
LR
LR
LAN
1
HDMI
2
3
Computer with HDMI output
HDMI-to-HDMI cable
TV main panel
1
2
3
HDMI
AUDIO OUTPUT
Pb Pr
INPUT 2
INPUT 1
DIGITAL
AUDIO
OUTPUT
(480i / 480p / 720p / 1080i)
Y/ VIDEO
Pb Pr
Y/ VIDEO
3D GLASSES
EMITTER
ANT
AUDIO
LR
LR
LAN
1
HDMI
2
3
DVI/PC
LR INPUT
AUDIO
DVI/PC
L
R INPUT
AUDIO
DVI OUT
AUDIO
R
L
TV main panel
Computer with DVI and stereo audio outputs
DVI-to-HDMI cable
Stereo analog
audio cables

Using the TV with a Personal Computer

Connecting a Computer to the TV
Use one of the connection methods listed below based on your computer’s video output.
Computer Video Output
Video Connection
Digital DVI DVI-to-HDMI cable
or an HDMI cable with a DVI-to-HDMI adapter
HDMI HDMI-to-HDMI
cable
IMPORTANT
This TV accepts digital computer video signals only. This TV is not compatible with VGA (analog) computer video.
1.
Connect the computer’s digital video output to one of the TV’s HDMI jacks. See the connection diagrams on this page for the method suited to your equipment.
2.
Connect the computer’s audio output using one of these options:
• FordigitalDVIvideosignals,connectthe
analog audio output to the TV’s
INPUT
jack.
• ForHDMIsignals,noadditionalaudioconnec­tion is required.
Audio
Connection
Stereo audio cables
No additional audio connec­tion is required.
VGA
PC MONITOR OUT
DVI/PC AUDIO
H
DMI Connection
Mitsubishi recommends using high-speed HDMI cables to connect newer devices incorporating HDMI technology.
An HDMI-to-HDMI connection carries all video and
audio on a single cable.
HDMI and Digital Surround Sound
838 Series. The TV’s HDMI inputs can receive
digital surround sound from an HDMI device. Use an HDMI connection if you want to hear digital surround sound from the TV’s internal speaker array.
DVI Video Connection
Note: If you are unable to hear audio from the
3.
Power on the TV and computer. The TV will detect the connection and display the New Device Found screen.
4.
In the New Device Found screen, press to highlight PC in the list of device types. It is impor­tant to use the name PC so that the TV processes the PC signal correctly.
5.
Highlight EXIT and press Device Found screen.
Note:
computer, there may be an incompatibility in
the computer’s hardware, software, or internal settings. Consult a trained computer technician for advice.
If your computer provides digital audio output (coaxial or optical), you can connect it directly to a digital A/V receiver and bypass the TV.
ENTER
to close the New
A DVI connection from a personal computer requires a separate audio connection.
For assistance call 1(800) 332-2119
18 1. Basic Setup and Operation
Using the TV with a Personal Computer
Computer Video Adjustments
1.
Power on the computer.
2.
Select PC from the Input Selection menu. To do this, press move the highlight to the PC icon, and press
3.
Working from the computer, change the resolution of the computer image. View the computer image on the TV and maximize the computer resolution while maintaining a suitable aspect ratio for the image.
4.
Perform TV video adjustments. Press
VIDEO
adjustment options.
5.
Press picture shape best suited to the image. See the chart on this page showing how different computer reso­lutions can be displayed on the TV.
INPUT
to open the Input Selection menu,
repeatedly to access video-
FO RMAT
repeatedly to find the
Tip
Set the computer’s screen saver to display a pattern after several minutes of inactivity. This acts as a reminder that the TV is powered on and the lamp
ENTER.
is in use. The lamp is in use whenever the TV is powered on, even if the screen appears dark.
Computer Display Formats
Press
FO RMAT
for your computer’s video signal.
Computer Signal
Original Format
VGA 640 X 480
SVGA 800 X 600
repeatedly to cycle through the TV displays available
4 X 3
Standard
As Displayed on TV Screen
16 X 9
Standard
Zoom
Distortion in Computer Images
Computer images may show distortion when viewed on the TV, e.g., lines that should be straight may appear slightly curved.
Image Resolution
Your Mitsubishi TV can display the resolu­tions shown in the chart from standard VGA (640 x 480) through 1920 x 1080 signals at a refresh rate of 60 Hz.
In most cases, the computer will select the best resolution match to display on the TV. You can override this setting if you wish. Refer to your computer operating system’s instructions for information on changing the screen resolution.
You may need to restart the computer for changes to take effect.
Original Format Standard Zoom
XGA 1024 X 768
PC 720p 1280 X 720
WXGA 1360 X 768
SXGA 1280 X 1024
Original Format Standard Reduce
PC 1080p 1920 X 1080
For assistance call 1(800) 332-2119

TV Connections

2

Before You Begin

19
Auto Input Sensing
The TV’s Auto Input Sensing feature automatically rec­ognizes many connections and prompts you to identify the type of device connected. See page 13 for more on Auto Input Sensing.
Connection Types
Use the connection types available on your input devices that will give the best video quality. For example, choose HDMI over component video; choose component video over composite video.
Picture Quality
For best picture quality, route signals directly from the source device to the TV whenever possible.

Connection Types and Audio/Video Quality

Surround Sound
• For best surround sound audio quality from an external sound system, route audio-carrying cables from the source device directly to your sound system.
• 838 Series. To use the surround sound capabilities of the TV’s speaker array, you must connect your digital surround sound source to the TV on either
- An HDMI input
- The
Accessory items such as cables, adapters, splitters, or combiners required for TV connections are not supplied with the TV. These items are available at most electronics stores.
ANT
antenna input
IMPORTANT
VIDEO QUALITY
GOODBEST
Component
HDMI-to-DVIHDMI Video Video
Composite
HDMI
AUDIO QUALITY
GOODBEST
Digital
L/R Analog
AudioAudio
For assistance call 1(800) 332-2119
20 2. TV Connections
1
2
3
HDMI
AUDIO
OUTPUT
Pb Pr
INPUT 2
INPUT 1
DIGITAL
AUDIO
OUTPUT
DVI/PC
(480i / 480p / 720p / 1080i)
LR INPUT
AUDIO
Y/ VIDEO
Pb Pr
Y/ VIDEO
3D
GLASSES
EMITTER
ANT
AUDIO
LR
LR
IR-NetCommand Output/EXTERNAL CONTROLLER INPUT
CENTER
INPUT
SUB
WOOFER
OUTPUT
LAN
INPUT 2
INPUT 1
DVI/PC
LR INPUT
AUDIO
3D
GLASSES
EMITTER
ANT
AUDIO/SURROUND
OUTPUT
LR
USB HDMI 4
INPUT 3
AUDIO
L R
Pb
Y/ VIDEO
Pr

Inputs and Outputs

Main Connection Panel
CENTER INPUT
(838 series, page 53)
SUBWOOFER OUTPUT
(838 series, page 53)
DIGITA L AUDIO OUTPUT
(page 25)
DVI/PC AUDIO
INPUT
(page 23)
AUDIO
OUTPUT
(738 series,
page 25)
AUDIO/SURROUND OUTPUT
9b
(838 series, page 25,
page 53)
IR–NetCommand Output
14
(838 series, page 65)
1
HDMI
(page 22)
2a
USB
(738 Series: power or
wireless adapter, page 46;
(Ethernet, port
3
LAN
page 45)
838 Series: power only,
page 26 )
Auto Input Sensing
The TV’s Auto Input Sensing feature automatically recog­nizes some connections and prompts
you to identify the
device type. See page 13.
1113 12
4
AUDIO
analog stereo
input
video, page 24)
10
5
Y/VIDEO
(composite
9a
6 7
Y/VIDEO Pb Pr
(component
video, page 23)
3D GLASSES
EMITTER
(page 33)
8
ANT
(page 24)
Side Inputs
838 Series. A set of jacks is pro-
vided for a camcorder, game, or other audio/video device.
If you connect a DVI device to the side HDMI input, use the nearby audio jacks to send sound from the device to the TV.
For assistance call 1(800) 332-2119
6 5 1
Y/VIDEO Pb Pr
(component
video, page 23)
Y/VIDEO
(composite
video, page 24)
Sound Projector Calibration
Microphone Input (page 43)
4
AUDIO
analog
stereo
input
USB
(multi-use,
pages 26, 37,
2b
46)
HDMI
(page 22)
2. TV Connections 21
Inputs and Outputs, continued
1. HDMI® Inputs
(High-Definition
Multimedia Interface)
The HDMI inputs support uncompressed standard and
high-definition digital video formats, bitstream Dolby Digital 5.1, and PCM digital stereo audio. These inputs are HDCP (High-Bandwidth Digital Copy Protection) compliant.
Mitsubishi recommends you use high-speed HDMI cables to connect newer source devices incorporating
HDMI technology. High-speed cables bring you the full benefits of Deep Color and x.v.Color.
These HDMI inputs can also accept digital DVI video
signals. To connect a device’s DVI output to the TV’s HDMI input, use an HDMI-to-DVI adapter or cable plus an analog audio. Connect the audio cable to the
AUDIO INPUT
DVI device.
Use the HDMI inputs to connect to CEA-861 HDMI com­pliant devices such as a high-definition receiver or DVD player. These inputs support 480i, 480p, 720p, 1080i, and 1080p video formats.
The TV’s HDMI inputs are compatible with many DVI-D
and HDMI computer video signals.
HDMI Cable Categories
HDMI cables are available as Standard and High-Speed types.
• High-Speed HDMI Cables. Newer DVD
players, video games, and set-top boxes require High-Speed HDMI cables, suitable for clock frequencies up to 340 MHz or data rates of up to 10.2 gigabits per second. Use high-speed cables for 1080p HD signals carrying extended color encodings (i.e., 30 or more bits, also called Deep Color). High-Speed HDMI cables are also suitable for standard HDTV signals.
• Standard HDMI Cables. Standard HDMI
cables may be unmarked. They are suitable for standard HDTV 720p, 1080i, and 1080p signals with 8-bit color depth. Use Standard HDMI cables for clock frequencies up to 74.25 MHz or data rates of up to 2.23 gigabits per second.
jack on the TV to receive audio from your
DVI/PC
2a. USB (limited use)
Standard USB 5-volt, 500-milliamp power output you can use to supply power to an accessory device.
738 Series. Use this port for a wireless network
adapter. See
page 46.
2b. USB (838 Series)
• The TV can read JPEG photo files and mp3 music files from a USB storage device connected to this input.
• Connect a compatible wireless adapter to stream internet content to the TV (page 45).
• This USB port can be used to power accessory
devices.
3. LAN
Use the to the TV. See page 45 for setup.
LAN
Ethernet jack for streaming internet video
4. AUDIO
Analog stereo inputs for use in conjunction with adja-
cent composite or component video jacks.
5. Y/
VIDEO
Analog standard-definition video inputs. Use the adja-
cent
AUDIO R
the TV speakers.
(Composite Video)
and L inputs if you wish to send audio to
6. Y/VIDEO Pb Pr (Component Video)
Analog video inputs able to accept high-definition video
from a high-definition source device. Use the adjacent
AUDIO R
TV speakers.
and L inputs if you wish to send audio to the
7. 3D GLASSES EMITTER
Use this jack for the special IR emitter supplied with some 3D glasses. The emitter sends out an infrared signal that synchronizes your 3D glasses with the screen display. See page 33.
8. ANT (Antenna)
Connect your main antenna or direct cable service (without a cable box) to digital and analog over-the-air channels from a VHF/ UHF antenna or non-scrambled digital/analog cable source.
ANT
. The
ANT
input can receive
For assistance call 1(800) 332-2119
22 2. TV Connections
Inputs and Outputs, continued
9a. AUDIO OUTPUT
Sends analog audio of the current program to an analog A/V surround sound receiver or stereo system. Digital audio from digital channels and HDMI devices is converted to analog audio by the TV for output on this jack. This is the only audio connection needed to the
TV if using an analog A/V receiver or stereo system.
Note: If connecting headphones, set Sound > Global >
Analog Audio Out to Variable.
9b. AUDIO/SURROUND OUTPUT
838 Series. Sends out analog audio as described for
other models or can be set for rear surround sound. Connect external rear speakers to this output for a fuller surround sound effect from the TV’s speaker array, Set Sound > Global > Analog Audio Out to Rear (see
“External Rear Speakers” on page 44).
10. DVI/PC AUDIO INPUT
Connect a DVI device to one of the TV’s HDMI inputs and use this jack to send analog audio to the TV.
11. DIGITAL AUDIO OUTPUT
This output sends Dolby Digital or PCM digital audio
to your digital A/V surround sound receiver. Incoming
analog audio is converted by the TV to PCM digital audio. If you have a digital A/V receiver, this is the only audio connection needed between the TV and your A/V receiver.
12. SUBWOOFER OUTPUT
838 Series. Connect a powered subwoofer to this
input to complement effects from the TV’s speakers. Set Sound > Global > Subwoofer to On to enable this output (see “Adding a Subwoofer,” page 26).
13. CENTER INPUT
838 Series. Connect your A/V receiver’s center
channel output to this input to make the TV speakers output center-channel sound. Set Sound > Global >
Center Channel to On to enable this input. See “Using
the TV Speakers as a Center Channel,” page 27.
14. IR-NetCommand Output
838 Series
As an output: Connect IR emitters to this jack to send
NetCommand control signals to external IR-controlled devices.
As an input: Accepts control signals from an external
controller when set up by your professional installer.
H
DMI Device
Commonly used with an HDTV Cable Box, Satellite Receiver, or DVD/Blu-ray Player
Required: HDMI-to-HDMI cable.
Mitsubishi recommends using high-speed HDMI cables to connect newer devices incorporating HDMI technology. See “HDMI Cable Categories” on the previ-
ous page for more on HDMI cable types.
Connect an HDMI cable from the TV to the device’s HDMI output. HDMI-connectable devices provide video and audio through a single cable.
Note: The HDMI connection supports copy protection
(HDCP).
HDMI and Digital Surround Sound
738 Series. The TV’s HDMI inputs can receive
digital stereo audio signals only when using the TV speakers.
838 Series. The TV’s HDMI inputs can receive digital surround sound from an HDMI device. Use an HDMI connection if you want to hear digital surround sound from the TV’s internal speaker array.
HDMI
HDMI
2
2
1
1
TV main panel
DIGITAL
AUDIO
AUDIO
OUTPUT
OUTPUT
3
3
LAN
Y/ VIDEO
Y/ VIDEO
LR
AUDIO
HDMI-to-HDMI cable
Any HDMI device
DVI/PC
LR
Pb Pr
Pb Pr
(480i / 480p / 720p / 1080i)
ANT
AUDIO
LR INPUT
3D
GLASSES
INPUT 2
EMITTER
INPUT 1
For assistance call 1(800) 332-2119
2. TV Connections 23
1
2
3
HDMI
AUDIO OUTPUT
Pb Pr
INPUT 2
INPUT 1
DIGITAL
AUDIO
OUTPUT
DVI/PC
(480i / 480p / 720p / 1080i)
LR INPUT
AUDIO
Y/ VIDEO
Pb Pr
Y/ VIDEO
3D
GLASSES
EMITTER
ANT
AUDIO
LR
LR
LAN
Pb
Pr
Y/ VIDEO
– AUDIO –
L
R
Pb Pr
Y/ VIDEO
AUDIO
LR
PbY Pr
AUDIO
L
R
Incoming from
cable service or
satellite dish
Component video
device
TV main panel
Audio
cables
Component video cables
CABLE IN or
SATELLITE IN

Y Pb Pr Component Video Device

Commonly used with an HDTV Cable Box, Satellite Receiver, or DVD/Blu-ray Player
If your source device has an HDMI output, use the con­nections for HDMI devices described on the opposite page instead of component video.
Required:
• RCA-type component video cables
• Left/right analog audio cables.
Note:
To hear digital surround sound from an A/V receiv­er, connect the digital audio output from the device directly to your digital A/V receiver.

DVI Video Device

Commonly used with a Cable Box, Satellite Receiver, or DVD Player
Connect a DVI device (digital only) to one of the TV’s HDMI input jacks.
Required:
• Analog stereo audio cables
• DVI-to-HDMI cable or DVI/HDMI adapter and
HDMI cable
If you are using a DVI/HDMI adapter, it is important to connect the adapter to the DVI device for best perfor­mance.
Some devices require connection to an analog input first in order to view on-screen menus and to select DVI as the ouput. Please review your equipment instruc­tions for DVI connectivity and compatibility.
Note: The HDMI connection supports copy protection
(HDCP).
DIGITAL
DVI/PC
AUDIO
DVI/PC
AUDIO
AUDIO
OUTPUT
HDMI
HDMI
2
1
3
3
LAN
LR
AUDIO
LR INPUT
LR INPUT
Y/ VIDEO
Y/ VIDEO
(480i / 480p / 720p / 1080i)
OUTPUT
Pb Pr
DVI/PC R INPUT
Pb Pr
AUDIO
AUDIO
ANT
LR
3D
GLASSES
INPUT 2
EMITTER
L
INPUT 1
L
TV main panel
DVI-to-HDMI
DVI OUT
cable
R
L
AUDIO
Digital DVI device
Audio cables
For assistance call 1(800) 332-2119
24 2. TV Connections

Antenna or Cable TV Service

Connect the incoming cable to the TV’s
Direct cable (no cable box)
OUT
DIGITAL AUDIO OUTPUT
or
DVI/PC
AUDIO
LR
OUTPUT
Y/ VIDEO
Pb Pr
Pb Pr
Y/ VIDEO
(480i / 480p / 720p / 1080i)
LR
AUDIO
Cable TV
service
IN
Older cable box
Not recommeded. Other connection types provide better quality audio and video.
TV main panel
HDMI
2
1
3
LAN
ANT
input.
Antenna
or
ANT
AUDIO
LR INPUT
3D
GLASSES
INPUT 2
EMITTER
INPUT 1

VCR or DVD Recorder to an Antenna or Wall Outlet Cable

Required:
1. Video cables 1a. Component video cables (red/blue/green) or 1b. Composite video cable (usually yellow)
2. Left/right analog audio cables.
3. Two-way RF splitter
4. Two coaxial cables
Note:
• Usecompositevideoonlyifcomponent
video or HDMI are unavailable.
• Ifyourrecordingdevicehasananalog-only
tuner, you must use a digital converter box to enable recording of digital broadcasts.
ANT
ANT
TV main panel
HDMI
2
1
3
DIGITAL
AUDIO
OUTPUT
LAN
AUDIO
AUDIO
AUDIO
OUTPUT
Y/ VIDEO
Y/ VIDEO
Y/ VIDEO
LR
LR
DVI/PC
LR
Pb Pr
Pb Pr
Pb Pr
(480i / 480p / 720p / 1080i)
AUDIO
ANT
ANT
LR INPUT
3D
GLASSES
INPUT 2
EMITTER
INPUT 1
ANT

Composite Video Device

VCR or other device with composite video output
Required:
• Composite video cable (usually yellow)
• Analog stereo audio cables.
ANT
LR INPUT
Y/ VIDEO
3D
GLASSES
INPUT 2
L
R
AUDIO
EMITTER
INPUT 1
Composite video cable
HDMI
2
1
TV main panel
L
R
AUDIO OUT
COMPOSITE
VIDEO OUT
DIGITAL
AUDIO
OUTPUT
3
LAN
AUDIO
AUDIO
AUDIO
OUTPUT
Y/ VIDEO
Y/ VIDEO
Y/ VIDEO
LR
LR
DVI/PC
LR
Pb Pr
Pb Pr
(480i / 480p / 720p / 1080i)
AUDIO
Audio cables
VCR or other device with composite video output
Y/ VIDEO
Pb
1b.
2.
L
R
AUDIO OUT
Composite
COMPOSITE
VIDEO OUT
or
video cable
DVD Recorder or VCR
Incoming cable
Pr
1a.
COMPONENT
VIDEO OUT
3.
RF Splitter
ANTENNA
IN
4.
4.
For assistance call 1(800) 332-2119
2. TV Connections 25
Y/ VIDEO

A/V Receiver

Most setups require either a digital audio cable or analog stereo audio cables. To send audio from TV channels received on the nected directly to the TV, you must use one of the con­nections shown below.
The TV makes all audio available in digital and analog
formats:
• Analog audio coming into the TV is available as output in digital stereo format on the
AUDIO OUTPUT
• Digital incoming audio is available as analog output on the
AUDIO OUTPUT L
HDMI
2
1
3
TV main panel
Digital coaxial
cable (for a digital
A/V receiver)
jack.
ANT
input or devices con-
and R jacks.
DIGITAL
DIGITAL
DVI/PC
AUDIO
AUDIO
AUDIO
LR INPUT
Y/ VIDEO
Pb Pr
Pb Pr
Y/ VIDEO
(480i / 480p / 720p / 1080i)
LR
AUDIO
DIGITAL
LAN
AUDIO
OUTPUT
OUTPUT
OUTPUT
or
Stereo analog
cables (for an
analog A/V
DIGITA L
AUDIO
LR
OUTPUT
3D
GLASSES
INPUT 2
EMITTER
OUTPUT
INPUT 1
receiver)
AUDIO
ANT
LR

A/V Receiver with HDMI Output

Required: One HDMI-to-HDMI cable
This option allows you to view content from devices connected to an A/V receiver. The A/V receiver can send audio and video to the TV over a single HDMI cable. You can use an HDMI connection as described here in addition to an audio connection from the TV’s audio output. The optional audio connection allows you to hear, through the A/V receiver, devices connected to the TV only, e.g., an antenna on the
• You may be able to use the TV’s remote control (in TV mode) to operate connected CEC-enabled HDMI devices. Experiment with your equipment to determine which functions are available to the TV’s remote control. See Appendix C, page 85.
• 838 Series: This setup allows you to use NetCom­mand-controlled audio and video switching over the HDMI cable. See “Automatic Audio/Video Switch­ing Over an HDMI Connection” on page 72.
To use NetCommand to supplement HDMI control of a CEC-enabled A/V receiver, note the recommendations under “More About Using an HDMI Connection,” page 72.
DIGITAL
DIGITAL
AUDIO
AUDIO
OUTPUT
OUTPUT
HDMI
2
1
3
LAN
AUDIO
DVI/PC
AUDIO
Y/ VIDEO
DIGITAL
AUDIO
OUTPUT
Y/ VIDEO
LR
ANT
AUDIO
OUTPUT
LR INPUT
Pb Pr
Pb Pr
(480i / 480p / 720p / 1080i)
input.
LR
GLASSES
INPUT 2
EMITTER
INPUT 1
ANT
3D
AUDIO
OUTPUT
LR
OPTICAL
INPUT
COAXIAL
COAXIAL
INPUT
INPUT
A/V receiver back panel
Note:
• On rare occasions, an HDMI signal may be copy-restricted and cannot be output from the TV as a digital signal. To hear these copy­protected signals through the A/V receiver, use the connection for an analog A/V receiver.
• Check the A/V receiver’s Owner’s Guide for information concerning use of the digital input and switching between digital sound and analog stereo sound from the TV.
TV
HDMI cable
A/V receiver with
HDMI output
Any connection types
High-definition
DVD player
HDMI OUT
Cable box
Optional
analog or
digital audio
connection
DIGITAL
AUDIO IN
ANALOG AUDIO IN
DVD player
LR
VCR
For assistance call 1(800) 332-2119
26 2. TV Connections

Supplemental Audio Connections

838 Series. Add a subwoofer to complement the TV’s speaker array or use the TV’s speakers as a center channel for your external sound system.
Adding a Subwoofer
Add a subwoofer to complement the TV speakers with a fuller bass sound.
• After connecting a subwoofer, you must enable the TV’s subwoofer output in the TV’s Sound menu. Go to
Sound > Global > Subwoofer and set it to On.
• To control subwoofer volume, press the and then press to find the subwoofer volume slider. Press to change the volume.
Subwoofer with Audio Cable
Connect the subwoofer directly to the TV’s
OUTPUT
.
AUDIO
key
SUBWOOFER
Wireless Subwoofer
Mitsubishi recommends Polk Audio Wireless Subwoofer model PSW i8m. The transmitter module can be conveniently powered from the TV’s USB power port. Connect an audio cable to the transmitter to supply audio from the TV’s
Power-only
1
USB port
SUBWOOFER OUTPUT
SUB
SUB
CENTER
WOOFER
WOOFER
INPUT
OUTPUT
OUTPUT
DIGITAL AUDIO
IR-NetCommand Output/EXTERNAL CONTROLLER INPUT
HDMI
2
3
OUTPUT
LAN
AUDIO
AUDIO/SURROUND
OUTPUT
Y/ VIDEO
Y/ VIDEO
LR
LR
Pb Pr
Pb Pr
(480i / 480p / 720p / 1080i)
SUB WOOFER OUTPUT
.
DVI/PC
ANT
AUDIO
LR INPUT
3D
GLASSES
INPUT 2
EMITTER
INPUT 1
TV
USB/USB mini-plug
RCA/RCA audio cable
power cable
Polk Audio PSW i8m powered wireless subwoofer
SUB
SUB
CENTER
WOOFER
WOOFER
INPUT
OUTPUT
OUTPUT
DIGITAL
AUDIO/SURROUND
AUDIO
OUTPUT
LAN
OUTPUT
SUB
WOOFER
OUTPUT
Y/ VIDEO
Y/ VIDEO
LR
AUDIO
IR-NetCommand Output/EXTERNAL CONTROLLER INPUT
HDMI
2
1
3
Subwoofer with audio connection to TV.
LR
Pb Pr
Pb Pr
(480i / 480p / 720p / 1080i)
DVI/PC
ANT
AUDIO
LR INPUT
3D
GLASSES
INPUT 2
EMITTER
INPUT 1
Setup to send audio signals wirelessly to the subwoofer.
For assistance call 1(800) 332-2119
2. TV Connections 27
Supplemental Audio Connections, continued
4.
Using the TV Speakers as a Center Channel
If using an external surround sound system, you can make the TV’s speakers provide center channel sound. Your A/V receiver must have a center channel pre out that can supply an amplified center-channel signal to th e T V.
1.
Connect your A/V receiver’s HDMI output and center channel pre out to the TV as shown.
SUB
CENTER
CENTER
WOOFER
INPUT
INPUT
HDMI
2
1
A/V receiver
with HDMI
output
Surround sound
source device
OUTPUT
DIGITAL
AUDIO
IR-NetCommand Output/EXTERNAL CONTROLLER INPUT
3
OUTPUT
LAN
HDMI cable
AUDIO/SURROUND
OUTPUT
LR
Y/ VIDEO
Pb Pr
Y/ VIDEO
Pb Pr
(480i / 480p / 720p / 1080i)
LR
AUDIO
HDMI OUT
DVI/PC
ANT
AUDIO
LR INPUT
3D
GLASSES
INPUT 2
EMITTER
CENTER
INPUT
INPUT 1
RCA/RCA audio cable
CHANNEL
PRE OUT
CENTER
Enable the TV’s center channel mode: a. Go to Sound > Global and set Center Channel
to On.
b. Press the
AUDIO
key and press to display
the TV Speakers option. Press to select Center.
5.
To balance volume:
a. Power on the A/V receiver and TV. b. Compare the volume of the TV’s center channel
with the rest of the sound system. If the TV volume needs adjustment, i. Turn on the TV speakers. Press
AUDIO and
press to display the TV Speakers option. Press to select
ii.
Adjust TV volume using
On.
the
VOL key.
iii. Return the TV to center channel mode.
Press
AUDIO
and press to display the
TV Speakers option. Press to select Center.
iv. Compare the sound volume. Repeat this
adjustment if needed.
2.
Turn on the A/V receiver’s center channel pre out if needed. See the A/V receiver’s instruction manual.
3.
Press the
VOL key to adjust TV volume to about level
30.
For assistance call 1(800) 332-2119
28
3

TV Features

Sleep Timer

The Sleep Timer turns the TV off after the length of time you set. To set the TV to turn on at a certain time of day, see the Setup > Timer menu on page 56.
Setting the Sleep Timer
1.
Press
SLEEP
.
2.
Press
SLEEP
additional times to increase the time in 30-minute increments up to the maximum of 120 minutes.
3.
Press
EXIT
to clear the screen immediately erwise the screen will clear after five seconds of inactivity.
Viewing or Changing the Sleep Timer
1.
Press
SLEEP
to display the on-screen message.
2.
Press
SLEEP
additional times to change the time before the TV powers off. To cancel the Sleep Timer, press played.
SLEEP
repeatedly until OFF is dis-
.
Oth-

FAV (Favorite Channels)

FAV
The sources. Sources can be channels from the or devices connected to the TV. You can store up to nine favorites.
Sample Favorites menu. Switch to favorite channels or inputs using number keys.
key gives you quick access to favorite program
ANT
1. Press
2. Press the
3. Move the highlight to the number position
Adding
4. Press
INPUT
and switch the TV to the input you want to add. If adding a channel, switch to the
ANT
input and tune to the channel.
FAV
key.
you want to assign to the channel or input.
ENTER
.
input
For assistance call 1(800) 332-2119
1. While watching TV, press the
2. In the Favorites menu, highlight the channel
or input you want to remove.
Removing
3. Press
1. While watching TV, press the
2. Move the highlight to the item you want and
Selecting
CANCEL
press
ENTER
number key for the channel or input.
.
. For a shortcut, just press the
FAV
FAV
key.
key.
3. TV Features 29

ChannelView Channel Listings

ChannelView displays program descriptions sent by broadcasters. This information may be unavailable in some areas.
About ChannelView
ChannelView™ shows memorized channels on the ANT input. It displays channel names and program information for digital channels. No program information is displayed for analog channels. See “Memorizing Channels with Channel Scan,” page 12 if needed.
ChannelView allows you to set up three banks of custom channels for convenient access. You can save groups of channels by content (e.g., news, sports, children’s program­ming) or by TV user.
Note: You must first set the TV Clock (page 56) to
receive ChannelView listings.
ChannelView, “All” tab. Programs are listed on the right.
Using ChannelView Listings
Task Action
Display/hide ChannelView listings (ANT input only).
Move through channels one by one.
Move through channels quickly.
Jump to listings for a spe­cific channel.
Tune to a highlighted channel.
Update program informa­tion for a highlighted digital channel.
Display program descrip­tions, if available. The description will appear at the bottom of the screen.
Display more program description for the current channel (if available).
GUIDE.
Press
Press
Press
Enter the channel number. Press dash; press twice to clear the channel number.
Press
Press the screen may briefly go blank).
1. Press
2. Press to move
Press
or .
CH.
CANCEL
ENTER.
the program area.
between programs.
INFO.
to add a
INFO
key (the
to move into
ChannelView Custom Channel Banks
Select a channel bank to customize.
1.
Press
GUIDE
to display ChannelView.
2.
Press
MENU
to move the highlight to the bank
header.
3.
Press to select Bank 1, 2, or 3.
4.
With the bank name highlighted, press enter setup mode where you can select channels to include in the bank.
5.
Press
EXIT
when finished with setup.
Task Action
Move between banks
Move into the channel list
Add or delete a channel from the bank
Remove all channels from the selected bank
Enter or exit setup mode Press
Press Press
• Highlight the channel
• Press
Press
.
and press check indicates the channel has been added.
clear the check and remove the channel.
CANCEL.
MENU.
.
ENTER
ENTER
to
ENTER
. A
again to
Using Custom Channel Banks
• While watching TV, press CH. The TV will tune only to channels stored in the current bank.
• To change to a different channel bank:
1. Press
2. Press
3. Press .
4. Press
• To allow tuning to any channel in memory, select the All bank.
GUIDE. MENU.
EXIT.
For assistance call 1(800) 332-2119
30 3. TV Features

Status Display

Press the
INFO
key to see the on-screen status display. The most
1
2
common displays are shown here.
8
Sleep 30 min
Tuesday 9:10 PM
9
HD 1080i Standard
10
INFO
About Channel Numbers
Channel Numbers for Over-the-Air Reception or Reception by Direct Cable
Note: All signals are automatically
converted to 1080p for display.
Standard-Definition Analog Channels
Cable Reception
Cable 3
480i Stretch
Receiving Standard-Definition Analog Signal (48 0i)
Standard-Definition Digital Channels
Over-the-Air Antenna
Reception
Ant 7-1 KABC-SD
Channel 3
Main Channel 7 Sub-Channel 1
3
4
6
402-101 K ABC Monday Night Football
TV-PG DLSV St. Louis vs. Tampa Bay, played in Tampa for
5
13
English Surround
11
12
1. Current Input
2. Audio Indicator. Key:
TV speakers External sound system Mute
3. Channel number (antenna source only)
Digital channel includes major and sub-channel numbers.
4. Digital channel name (if broadcast); antenna source only.
V-Chip rating
5.
• Antenna source only for digital signal
• Antenna or
VIDEO
6. Program name (if broadcast); digital source only
7. Program description (if broadcast); digital source,
only. Press the
INFO
key additional times to see more of the
description.
8. Sleep Timer remaining time
9. Day and time
10. Signal type being received. See “Signal Definitions” on this
page.
11. Screen format in use
12. Program audio indicator (antenna source only)
13. Available language (digital source, antenna only)
14. Signal-strength indicator (digital source, antenna only)
7
Sample information from the on-screen status display
composite jack for
14
analog signal
antenna
SD 4:3 Stretch
Receiving Standard-Definition Digital Signal (SD)
High-Definition Digital Channels
Over-the-Air Antenna
Reception
Main Channel 7 Sub-Channel 1
Ant 7-1 KABC-HD
HD 16:9
Receiving High-Definition Digital Signal (HD)
Standard
For assistance call 1(800) 332-2119
Signal Definitions
480i: Standard-definition, older type interlaced signals from the ANT input,
composite VIDEO, component Y Pb Pr, or HDMI jacks.
480p: Standard-definition progressive-scan DVD signals on component Y Pb Pr or HDMI jacks.
720p and 1080i: High-definition signals received through component Y Pb
Pr or HDMI jacks. These signals are always 16:9 (widescreen).
1080p: High-definition signals from a PC or Blu-ray player; HDMI inputs only.
SD 4:3: Standard-definition squarish-screen-format signals from digital channels on the ANT input.
SD 16:9: Standard-definition widescreen-format signals from digital chan­nels on the ANT input.
HD 16:9: High-definition 16:9 widescreen signals from digital channels on the ANT input.
3. TV Features 31

Using an External Sound System

Redirecting Audio Output
Selecting the Audio Output
1.
Press
AUDIO.
2.
Press to show the TV Speakers option.
3.
Press to select either On (to hear sound from the TV speak­ers) or Off (to hear sound from an external sound system).
838 Series. Choose Center if using the TV speakers to supplement audio from an external sound system. See page 27.
Disconnecting an A/V Receiver
When you disconnect an A/V receiver, change the TV Speakers setting to On to hear sound from the TV
speakers. Use either the remote control’s the Sound > Audio > TV Speakers menu (page 53).
AUDIO
key or
Controlling A/V Receiver Sound Volume
Use one of the methods below to control sound volume from an A/V receiver.
With a Standard TV Setup
• Recommended Method: Program the TV’s
remote control for your A/V receiver and enable the Audio Lock feature. See page 78.
• Program the TV’s remote control for your A/V receiver and set the control mode to the control mode to TV to control the TV.
• Use the remote control that came with the A/V re c e iver.
With HDMI Control (CEC-Enabled HDMI A/V Receiver)
The TV’s remote control may control some functions of the A/V receiver. See Appendix C, “HDMI Control of CEC Devices,” page 85.
With NetCommand IR Control
838 Series. Set up NetCommand control of the A/V receiver’s volume functions in the Inputs > AVR menu. The TV’s remote will then control A/V receiver volume. See page 71.
AUDIO
. Return
For assistance call 1(800) 332-2119
32 3. TV Features

Picture Shape and Display Formats

Format Definitions
Note: See page 16 for use of the
the formats described here.
Standard: The full-screen format used by HDTV signals. Use this format to display anamorphic DVDs with a 1.78:1 or 1.85:1 aspect ratio. Anamorphic DVDs with a 2.35:1 aspect ratio are displayed correctly but with top and bottom black bars. Squarish (4:3) images are stretched evenly from side to side. Available for all signals.
Expand: Enlarges the picture to fill the screen by cropping the top and bottom; useful for reducing the letter box top and bottom bars of non-anamorphic DVD images.
FORMAT
key to apply
Effect of Mitsubishi Formats on Picture Types
Original Signal
TV Display Format
Non-anamorphic or SD 4:3
Standard
Expand
Zoom
Stretch
Stretch Plus
Narrow
Distorted; Not recommended.
Recommended for letterbox. See Note 1.
Distorted; Not recommended. See Note 1.
Recommended for standard broadcasts. See Note 1.
Recommended for standard broadcasts. See Note 1.
See Note 1 Distorted; not recom-
Note 1: Available for 480i, 480p, and digital SD 4:3 signals only.
Original Signal Display Formats
SD 16:9 or HD Digital 720p, 1080i, 1080p Signal
TV Display Formats. Press the
Wide Expand
Zoom
FO RMAT
different displays for the current program. Press the see the name of the format in use.
Original Signal
Anamorphic DVD
Recommended
Distorted; not recom­mended. See Note 1.
Recommended for anamorphic 2.35:1 images. See Note 1.
Distorted; not recom­mended. See Note 1.
Distorted; not recom­mended. See Note 1.
mended. See Note 1.
Recommended to re­move side bars.
Recommended to re­move bars from the top, bottom, and sides.
key repeatedly to see
INFO
Zoom: Enlarges the picture to fill the screen by crop-
ping the sides, top, and bottom to eliminate black bars.
• 480i/480p and SD 4:3 signals: Eliminates top and bottom bars on anamorphic DVDs with a 2.35:1 aspect ratio.
• 720p, 1080i, SD 16:9, and HD signals: Eliminates bars added to squarish 4:3 images.
Stretch: Stretches a squarish 4:3 image across the screen to display the entire image with less distortion than the Standard format.
Stretch Plus: Similar to Stretch, but minimizes distor­tion on the sides by expanding the picture to crop off portions of the top and bottom. Use
to adjust the
vertical position of the picture.
Narrow: Displays narrow 4:3 images in their origi­nal shape. Adds black side bars to fill the screen.
Wide Expand: Enlarges the picture, cropping the image on both sides. Removes or reduces black side bars added to narrow images converted to 16:9 signals for digital broadcast.
Note: All high-definition channels send wide­screen (16:9) signals, but not all programming was created for the widescreen format. The broad­caster may stretch the image or add side bars to fill the widescreen area.
DVD Image Definitions
Image information may be stated on the DVD case. Some DVDs support both formats described below.
Anamorphic (or Enhanced for WideScreen TV)
Indicates DVDs recorded to show widescreen images properly on 16:9 TV sets using the TV’s
Standard format mode (recommended).
Non-Anamorphic (or 4:3, 1.33:1, Letter Box, or Full Screen)
Indicates DVDs recorded for viewing on squar­ish TV screens. They may be full screen (4:3 or
1.33:1) which crops movies to fit the narrow TV, or letter box, which adds black top and bottom bars.
key to
For assistance call 1(800) 332-2119
3. TV Features 33
1
2
3
HDMI
AUDIO OUTPUT
Pb Pr
INPUT 2
INPUT 1
DIGITAL
AUDIO
OUTPUT
DVI/PC
(480i / 480p / 720p / 1080i)
LR INPUT
AUDIO
Y/ VIDEO
Pb Pr
Y/ VIDEO
3D
GLASSES
EMITTER
ANT
AUDIO
LR
LR
IR-NetCommand Output/EXTERNAL CONTROLLER INPUT
CENTER INPUT
SUB WOOFER OUTPUT
LAN
3D
GLASSES
EMITTER
ANT

3D Video

Important
This page describes enhanced 3D options offered with TV software versions 012.06 and later.
Instructions for earlier software are on page 33.

Enhanced 3D Video Options

(TV Software Versions 012.06 and later)
To display 3D gaming or 3D cinema content, your Mitsubishi TV requires:
• A compatible 3D source device outputting a 3D signal in one of these formats:
- Frame Packing 1080p/24 Hz or 720p/60 Hz
- Top-Bottom 1080p/24Hz or 720p/60 Hz
- Side-by-Side format, 1080p, 24/30/60 Hz; 720p, 60 Hz
- Checkerboard format, 1080p, 60-Hz; (lower resolutions may be supported but will not fill the screen)
• Active-shutter 3D glasses, DLP link type or IR emitter type with matching emitter
Initial Setup
1.
If your 3D glasses came with an emitter box, connect the emitter box to the
EMITTER
jack. Place the box in front of the TV
3D GLASSES
where there is a clear path to the glasses.
Note: If your glasses are marked DLP Link, skip this
step; no emitter box is required with DLP Link technology.
TV back panel
2.
Power on the TV and the source device.
3.
Connect the source device to the TV’s HDMI input.
4.
When the New Device Found screen displays, name the input.
5.
Press
EXIT
to close the New Device Found screen.
Off
• Turns off 3D images.
• Restores normal TV operation when viewing a
normal 2D signal.
Automatic
• When the TV detects a 3D signal from an HDMI 1.4a-compliant device, it switches automatically to 3D mode and selects the correct 3D format.
• When receiving a normal 2D signal, the TV automatically exits 3D mode.
Which Software Version Is in My TV?
MENU
Press
to see your TV’s software version dis­played in the lower left corner of the main menu. Versions 012.06 and later carry enhanced 3D video options.
Menu showing enhanced 3D options
Choice of Source Formats
If your device is non-HDMI 1.4a compliant, you must choose the correct setting from this list.
For assistance call 1(800) 332-2119
34 3. TV Features
3D Video, continued
Watching 3D Video
Note: Active 3D glasses are required
1.
Switch the TV to the 3D video device. Press INPUT then highlight the icon for the 3D video device. Press
ENTER
.
2.
Press
MENU
and select the Picture > 3D Mode
menu.
3.
For Glasses Control, select the control type for your 3D glasses, either IR Emitter or DLP Link.
4.
For Source Format, select Automatic and press ENTER
. Press
• If the image looks correct, the device is HDMI
1.4a compliant. Always keep the setting at Automatic for this device.
• For non-compliant 3D sources, open the Picture > 3D Mode menu and select a source format based on how the picture looks:
Side by Side
Screen split vertically
Top/Bottom
Screen split
EXIT
horizontally
to close the menu.
5.
Press
EXIT
to close the menu.
6.
If the image does not appear correct appear to be moving in instead of out),
Picture > 3D Mode menu and set Glasses L-R to Reverse.
7.
When finished watching 3D video:
• If you manually selected a source format in the Picture > 3D menu, open the menu and select Automatic or Off.
• If your 3D video device is HDMI1.4a compliant, keep the setting on Automatic.
Notes on Using 3D Video Settings
3D signals and 3D settings affect some TV functions. Switch to a non-3D source to regain full TV operation. If Source Format is set to Automatic or one of the named 3D formats OR Source Format is set to Off and the 3D video source is HDMI 1.4a compliant (picture may appear as 2D), the following limitations apply:
• Picture adjustments are limited. To make picture adjustments while watching normal 2D images from the device, temporarily set Source Format to Off to make the full range of adjustments accessible.
• The
• The
FO RMAT INTERNET
key is disabled.
key is disabled.
(e.g., objects
open the
Checkerboard
Blurry double image
(Checkerboard
setting is always
required for check-
erboard signals
Mitsubishi 738 series and 838 series 3D televi­sions (the “TVs”) will no longer require the use of an adapter when loaded with the software version of
012.06 (the “Software Update”). After the Software Update, the TVs will support the mandatory HDMI
1.4a 3D signals intended for the United States. Spe­cifically, the TVs will support the 3D signals known as Frame Packing 1080p/24Hz and 720p/60Hz (pri­marily from Blu-ray players and gaming consoles), Side-by-Side in 1080i/60Hz, 1080p/24Hz/30Hz/60Hz
)
Notice Concerning 3D Format Compatibility
(TV Software Versions 012.06 and later)
and 720p/60Hz, Top/Bottom in 1080p/24Hz and 720p/60Hz, and Checkerboard 1080p/60Hz. However, there may be some 3D sources that are not compatible with the TVs even after the Software Update. In all cases: (1) 3D sources must connect to the TVs using the HDMI inputs; and (2) Active Shutter 3D glasses with matching synchronization emitter or DLP Link Active Shutter 3D glasses are required in order to view 3D content.
For assistance call 1(800) 332-2119
3. TV Features 35
3D Video, continued
Original 3D Video Options
(TV Software Versions 012.05 and earlier)
Important
This page describes 3D options offered with TV software versions 012.05 and earlier.
• Toupgradeearliersoftwaretothecurrent
version, visit http://www.mitsubishi-tv.com/3Dupgrade.html
•
Instructions for later software are on page 35.
To display 3D gaming or 3D cinema content, your Mitsubishi TV requires:
• A compatible 3D source device outputting a 3D signal in one of these formats:
- Checkerboard format, 1080p, 60-Hz; (lower resolutions may be supported but will not fill the screen)
- Side-by-Side format, 1080p, 24/30/60 Hz; 720p, 60 Hz
• Active-shutter 3D glasses, DLP link type or IR emitter type with matching emitter
5.
Select the Source Format. If your source device outputs an unsupported signal format see “Notice Concerning 3D Format Compatibility” on this page.
6.
For Glasses Control, select the control type for your 3D glasses, either IR Emitter or DLP Link.
Use the Picture > 3D Mode menu to enable 3D video.
Initial Setup
See the instructions on page 33.
Watching 3D Video
Note: Active 3D glasses are required.
1.
Press
INPUT
.
2.
Highlight the icon for the 3D video device and press
ENTER
.
3.
Press
MENU
and select the Picture > 3D Mode
menu.
4.
Select On memorized for the current input when you exit this menu.
Press played in the lower left corner of the main menu. Versions 012.05 and earlier carry a limited choice of 3D video options.
for 3D Mode
Which Software Version Is in My TV?
MENU
to see your TV’s software version dis-
. The On setting will be
7.
Press
EXIT
to close the menu.
8.
If the image does not appear correct appear to be moving in instead of out),
Picture > 3D Mode menu and set Glasses L-R to Reverse.
Watching Regular (non-3D) Video
The 3D Mode setting is memorized for each input. When you want to watch non-3D video on the input selected above, you can
• Open the Picture > 3D Mode menu and set 3D Mode to Off.
• Press the
Notice Concerning 3D Format Compatibility
(TV Software Versions 012.05 and earlier)
Mitsubishi 3DTVs (738 and 838 series) currently support the side-by-side 3D signal format. For support of other 3D formats, such as top-bottom and frame packing (3D Blu-ray standard), Mitsubishi 3D TVs will require the use of a 3D source device that outputs the 3D checkerboard format or a 3D source device coupled with the Mitsubishi 3D adapter. In all cases an emitter and matching 3D active shutter glasses or DLP Link active shutter glasses are required in order to view 3D content.
TOOLS
key and select 3D option 7.
(e.g., objects
open the
For assistance call 1(800) 332-2119
36 3. TV Features
3D Video, continued
3D Safety Requirements
• 3D Glasses are NOT designed as sunglasses or safety glasses and do not provide protection. 3D glasses should be worn only when viewing 3D material.
• Do not wear the wireless glasses in any situations that require unimpaired visual perception.
• Children under the age of 5 should not view 3D programming.
Under normal conditions, 3D viewing is safe for your movies or games. Some people may experience dis­comfort, however. To minimize the potential for experi­encing visual problems or any adverse symptoms:
• Read and follow any and all safety warnings that accompany your 3D glasses or 3D source devices.
• Maintain a distance of no less than 2 to 2.5 times the screen height measurement away from the display. Viewing from too short a distance can strain your eyes.
• Take regular breaks, at least 5 minutes after every hour of 3D viewing.
If you experience any of the following symptoms, dis­continue 3D viewing until the symptoms go away:
• nausea, dizziness, or queasiness,
• headache, or eyestrain,
• blurry vision,
• double vision that lasts longer than a few seconds,
Do not engage in any potentially hazardous activity (for example, driving a vehicle) until your symptoms have completely gone away. If symptoms persist, discontinue use and do not resume 3D viewing without discussing your symptoms with a physician.
Do not use the glasses where loss of balance or limit­ing your field of vision may be dangerous to you.
Do not use near staircases, ledges or balconies. You may risk falling during or after use.
Epilepsy WARNING! IF YOU OR ANY MEMBER OF YOUR
FAMILY HAS A HISTORY OF EPILEPSY, CONSULT A PHYSICIAN BEFORE USING 3D VIDEO OR GAME PRODUCTS.
A small percentage of the population may experience epileptic seizures when viewing certain types of TV images or video games that contain flashing patterns of light.
The following people should consult a physician before viewing 3D Games or Video:
• Anyone with a history of epilepsy, or who has a family member with a history of epilepsy
• Anyone who has ever experienced epileptic sei­zures or sensory disturbances triggered by flashing light effects.
WARNING! SOME LIGHT PATTERNS MAY INDUCE SEIZURES IN PERSONS WITH NO PRIOR HISTORY
OF EPILEPSY. DISCONTINUE 3D VIEWING IF YOU EXPERIENCE ANY OF THE FOLLOWING SYMP­TOMS:
• Involuntary movements, eye or muscle twitching
• Muscle cramps
• Nausea, dizziness, or queasiness
• Convulsions
• Disorientation, confusion, or loss of awareness of
your surroundings
Do not engage in any potentially hazardous activity (for example, driving a vehicle) until your symptoms have completely gone away.
Do not resume 3D viewing without discussing the symptoms with your physician.
For assistance call 1(800) 332-2119
3. TV Features 37
USB HDMI 4
INPUT 3
AUDIO
L R
Pb
Y/ VIDEO
Pr

Camera Images and Music Files

• All Models. The TV can display still images or
motion video from a camera through the
Y/VIDEO
port. See page 39.
• All Models. To play music through the TV speak-
ers from an audio-only device, see “Using an Audio-Only Device,” page 39.
• 838 Series. The TV can read photo and music
files from a USB device. Photos must be in JPEG format and music files must be in mp3 format. To play music files while displaying a photo slide show, see “USB Media Setup Menu” on the next page.
• 838 Series. The TV can play music wirelessly
using Bluetooth® technology. See page 40.

USB Source Devices (838 Series)

The USB Media Player Menu
3.
When the USB Media Player icons display, high­light one of these choices and press
ENTER
.
Photos
View photos or play a slide show
Audio
Listen to audio tracks or a playlist.
Setup
Perform setup for a slide show or playlist. If music and image files are both present, lets you play a slide show with music.
Notes on Using the USB Port
• T
he TV ignores all commands while reading files.
• Largefilesorhigh-capacitystoragedevicesmay
take a long time to display.
• The TV can read files up to 10 MB in size with a maximum of 2,500 files stored on the device. The FAT16 or FAT32 file system is recommended.
• UseaUSBdriveinsteadofacardreader.
• BackupthedataonyourUSBdrivebeforecon-
necting it to the TV. Mitsubishi is not responsible for any file damage or data loss.
Note: Some manufacturers’ devices may be incom-
patible with the TV. If the TV is unable to dis­play your photos, you can:
• TransferfilestoadifferentUSBdevice.
USB Media menu, Photos option selected
• Useyourdigitalcamera’scompositevideo
output. See page 39.
Displaying the Menu
1.
Back up the data on your USB drive before con­necting it to the TV. Mitsubishi is not responsible for any file damage or data loss.
2.
Connect your USB drive to the TV’s USB port. The USB Media Player menu displays while files
are being read. Wait until icons appear in the menu before continuing.
Picture Files Compatible with the USB Port
• Stillimagesrecordedondigitalcamerasusingthe
Exchangeable Image File Format, version 2.1 (EXIF
2.1) standard for digital still cameras and Design Rules for Camera File Systems version 1.0 (DCF 1.0)
• Someimagesopenedandresavedonacomputer
may not play back or may not display in the thumb­nail list. This happens if the files were resaved in an incompatible format.
• Fullpathfilenamescanbenolongerthan50char­acters and must end in a .jpg extension. Only the first 20 of the 50 characters will display.
The TV can read JPEG files as created by the camera. If you edit a picture file on a computer and resave the image, the TV may be unable to read the resaved file.
838 series. The TV can read photo and music files from the USB port.
For assistance call 1(800) 332-2119
38 3. TV Features
Camera Images and Music Files, continued
Using the Photos and Audio Menus
USB Media Setup Menu
Use these keys with your photo and audio files.
Key For Photos or Audio Tracks
• Moves the highlight left/right through
or
ENTER
GUIDE
INFO
EXIT
icons to select Photos, Audio, or Setup.
• Moves the highlight from item to item. Plays the slide show or playlist starting
from the highlighted item.
Pauses a slide show or playlist.
Stops a slide show or playlist.
• Highlights the first or last item on the current page.
• Skips to the previous or next item during play.
• Displays the previous or next page of items.
• Skips immediately to the previous or next item during play.
Rotates an image clockwise in 90˚ incre­ments.
Displays the item name during play. Press
EXIT
to clear.
Clears file information from the screen.
Use the USB Media Setup menu to set up play of a slide show or playlist.
• IfJPEGimagefilesandmp3filesarebothonthe
USB device, choose from:
- Slideshow + Music
- Slideshow only
- Music only
• Interval. Select the type of time interval for display
of each slide. The intervals may be longer for larger files than for smaller ones.
• Frequency.
to play the complete slide show and/or playlist.
• Show File Names. Choose Automatic or Off.
• Press
EXIT
return to the USB Media Player menu.
Select the number of times (frequency)
to close the USB Media Setup menu and
MENU
INPUT
Always stop playback with a different TV input before disconnecting your USB device.
Displays the main menu; stops play.
Displays the play.
Input Selection menu; stops
IMPORTANT
(STOP) or change to
For assistance call 1(800) 332-2119
3. TV Features 39
Camera Images and Music Files, continued

Photos and Motion Video as Composite Video

All Models. Connect the camera to the TV using a
composite video cable and control the slide show or movie through the camera. The display resolution will be standard-definition (480i).
1.
Refer to the owner’s manual supplied with the camera for instructions needed for this setup.
2.
Set the camera’s output signal type to NTSC and put the camera into playback mode.
3.
With the camera still turned on, connect your digital camera’s composite video cable (usually yellow) to the TV’s camera’s audio output cable to the
Audio Cable
Y/VIDEO
HDMI
2
1
Optional
jack. To hear audio, connect the
AUDIO L
SUB
CENTER
WOOFER
INPUT
IR-NetCommand Output/EXTERNAL CONTROLLER INPUT
3
AUDIO
R
OUTPUT
L
LAN
Y/ VIDEO
DIGITAL AUDIO OUTPUT
AUDIO
AUDIO
AUDIO/SURROUND
OUTPUT
Y/ VIDEO
Y/ VIDEO
Y/ VIDEO
LR
LR
LR
Pb Pr
Pb Pr
(480i / 480p / 720p / 1080i)
DVI/PC
ANT
AUDIO
LR INPUT
3D
GLASSES
INPUT 2
EMITTER
INPUT 1
jack.

Using an Audio-Only Device

All Models. To use the TV speakers with an audio
device such as an MP3 or CD player with analog output, follow these steps.
1.
Insert an unused RCA-style connector into the
Y/VIDEO
input. The presence of this connector activates the TV’s auto-detection.
2.
When the TV detects the display the New Device Found screen. Name the new input CD/Audio or MP3 Player.
3.
Connect left (white) and right (red) audio cables from th e T V.
4.
Keep the connector in the the audio-only device.
Audio-only device
jack associated with the TV’s analog audio
AUDIO OUT
HDMI
2
1
Y/VIDEO
on the device to
VIDEO/Y
SUB
CENTER
WOOFER
INPUT
OUTPUT
DIGITAL AUDIO
LAN
AUDIO
OUTPUT
LR
IR-NetCommand Output/EXTERNAL CONTROLLER INPUT
3
connector, it will
AUDIO L and R
jack while using
AUDIO/SURROUND
DVI/PC
OUTPUT
LR
Y/ VIDEO
Pb Pr
Y/ VIDEO
Y/ VIDEO
Pb Pr
(480i / 480p / 720p / 1080i)
LR
LR
AUDIO
AUDIO
Y/ VIDEO
ANT
AUDIO
LR INPUT
3D
GLASSES
INPUT 2
EMITTER
INPUT 1
TV
Unused RCA-style plug (plug in first)
2.
on
Camera connection using a composite video cable
4.
When the New Device Found screen displays, assign the name Camcorder.
5.
Press
EXIT
to close the New Device Found screen.
6.
Highlight the icon for the camera input and press
ENTER
.
7.
If viewing photos, control the slideshow from the camera. Advance through the images manually or check if the camera can advance automatically.
1.
For assistance call 1(800) 332-2119
40 3. TV Features
Camera Images and Music Files, continued

Wireless Audio Playback

838 Series. The TV’s built-in speaker array can play
audio from a handheld device using Bluetooth® A2DP (stereo audio) wireless technology. The TV can be paired with only one device at a time.
Pairing the TV with an Audio Playback Device
1.
Turn on the wireless device you wish to use for playback.
2.
Press
INPUT
to display the Input Selection menu.
Bluetooth icon in Input Selection Menu
3.
Highlight the Bluetooth icon and press
4.
Wait for the pairing menu to display. Pair your device with the TV and then connect. Some devices pair and connect automatically, while others require you to enter the TV pass code dis­played.
ENTER
.
Tips for Wireless Playback
• Selecting the Bluetooth icon at a later time will
connect the TV again to the paired device.
• If the paired device is not available, the TV will accept pairing from a different device.
• Once connection is lost, the TV will power off after five minutes without receiving a signal.
• To clear a paired device, turn off the Bluetooth icon (Inputs > Name menu) or pair the TV with a differ­ent device.
• To remove the Bluetooth icon from the Input Selection menu, turn off the icon in the Inputs > Name menu.
Note: If you have difficulty pairing, turn off all other
Bluetooth wireless devices in the area.
5.
Use keys on the TV’s remote control to control play­back. Not all keys work for all devices.
Skip a track
Resetting Bluetooth Pairing or Connection
Perform this reset if the audio device does not connect properly to the TV.
1.
If the audio device has been previously paired with the TV, delete the TV from the device’s paired list.
2.
Go to the TV’s Inputs > Name menu and highlight the Bluetooth icon. Press
3.
Press
EXIT
.
4.
Go to the Inputs > Name menu and highlight the
Bluetooth icon. Press
5.
Press
EXIT
.
ENTER
ENTER
(
PAUSE
(
STOP
)
(
REVERSE
(
PL AY
)
(
FORWARD
to select Off.
to select On.
)
)
)
Remove the Bluetooth icon from the Input Selection menu by turning off Bluetooth in the Input > Name menu.
For assistance call 1(800) 332-2119
3. TV Features 41

Sound Projector (838 Series)

This setup is unnecessary if using the TV speakers as a center channel. See page 27.
Sound Projector Technology
838 Series. The TV’s built-in speaker array can be
adjusted to reflect sound off the room walls to create a surround sound effect. Setup can be performed either manually or automatically.
• To create the surround sound effect, the room walls must reflect sound and not be covered with sound­absorbent material.
• Repeat the setup procedure if you reconfigure the room’s walls or furnishings.
Before You Begin
Positioning the TV
• Center the seating area in front of the TV and at least six feet away from it.
• Arrangements that give good results:
Connecting the TV
To hear digital surround sound, the TV must be con­nected to a digital surround sound source. The TV can receive digital surround sound from:
• Any HDMI jack
• The
Other stereo connections will provide Dolby Pro Logic surround sound.
ANT
input (from some digital broadcasts)
Basic Manual Setup
Note: If you have already performed Auto setup, do
not make manual adjustments. Doing so will erase all settings created during Auto setup.
1.
Press
MENU
and go to Sound > SoundPro.
2.
Enter the room dimensions and layout information requested in the screen. To change measure­ments, press .
• If the room is an odd shape, locate the TV to take best advantage of wall reflections.
• Avoid locations that may distort sound reflections.
3.
Press
EXIT
to exit and save settings.
4.
Play some sample audio to check sound quality. If further adjustment is needed, use the Custom menu as described next.
Custom Menu
Use the Custom menu after defining the room layout.
For a room with large areas of curtains that might affect sound reflection, do the following:
a. Open the curtains fully to improve sound reflec-
tion.
b. Set angles by performing the procedure in
“Adjusting Beam Angles.”
c. Close the curtains. d. Set levels by performing the procedure in
“Adjusting Levels.”
1.
From the Sound > SoundPro menu go to the CUSTOM menu.
For assistance call 1(800) 332-2119
42 3. TV Features
Sound Projector (838 Series), continued
2.
Position yourself in your usual viewing location. Remain in this position, looking at the TV, while making the following adjustments.
3.
Adjusting Beam Angles a. Adjust Center Beam Angle until sound is
about equal in both ears.
b. Adjust Left Beam Angle to maximize sound
heard from the front left side.
c. Adjust Right Beam Angle to maximize sound
heard from the front right side.
d. Adjust Left Surround Beam Angle to where
the sound seems to come from the left rear side. If this cannot be achieved, make the setting the same as that for Left Beam Angle.
e. Adjust Right Surround Beam Angle to where
the sound seems to come from the right rear side. If this cannot be achieved, make the setting the same as that for Right Beam Angle.
How to Make Adjustments in the Custom Menu
• Press to select an audio beam; colors of the adjusters correspond to audio beams in the on­screen diagram.
• Press to redirect the audio beam or change the sound level.
Controls in the SoundPro > Custom menu adjust the direction and focus of the TV’s sound output.
At extreme beam angles, adjustment may be limited and the image on screen may not accurately represent the sound beams.
4.
Adjusting Levels a. Adjust Center Level to the mid level. b. Adjust the following levels one at a time so that
each one sounds about the same as the center level:
Left Level Right Level Left Surround Level Right Surround Level
c. Check all sound levels by quickly switching
between them using .
d. Readjust individual levels in small increments
and recheck as above until all sound levels seem about the same.
5.
Adjusting an External Subwoofer
Note: Set Sound > Global > Subwoofer to On to
make this adjustment available.
a. Play sample video or music containing low-
frequency bass sound.
b. Press
c. Press to adjust the subwoofer volume.
AUDIO
. Use to display the Sub-
woofer option.
Adjust the volume level of individual audio beams using sliders in the SoundPro > Custom menu.
Resetting Angle and Level Values in the Custom Menu
Follow these steps to return settings to the default values.
1.
Press
EXIT
to clear all menus.
2.
Press
MENU.
Go to the Sound > SoundPro menu
and press
3.
Change any setting (e.g., TV Location).
4.
Press
5.
Press and press
6.
Enter the correct values for the room layout.
7.
Return to the CUSTOM menu to adjust angles and levels.
ENTER
.
EXIT
to clear all menus.
MENU.
Go to the Sound > SoundPro menu
ENTER
.
For assistance call 1(800) 332-2119
3. TV Features 43
within three feet
six feet from the TV.
Sound Projector (838 Series), continued
Auto Setup
Auto setup uses the included calibration microphone to optimize Sound Projector performance for most room conditions.
Initial Preparation
1.
Position and connect the TV as described under “Before You Begin,” page 41.
2.
Power on the TV and external subwoofer, if any.
3.
Plug the microphone cable into the TV’s audio jack.
Connect microphone to the right (red) audio jack.
4.
Place the microphone as described in the guide­lines on this page.
Start Auto Setup
5.
Press
MENU
and go to Sound > AutoSP.
L R
L
AUDIO
AUDIO
INPUT 3
Microphone Placement
• Make sure there are no large obstacles between the TV and microphone.
• Place the microphone
- On a flat, level surface at least six feet away from the front of the TV.
- On a tripod or on the backrest of your seating.
- At the same height your ears would be when watching TV. The height must be within 3 vertical feet of the height of the TV’s speaker ar ray.
- Centered in front of the TV, not off to the side.
TV
6 ft. minimum
Maximum height above speakers
Microphone
Set the microphone on a level surface at ear height at least
Use a seat backrest or tripod so as to pick up sound from all directions.
6.
Highlight STA RT and press
7.
Quietly exit the room right away. The calibration sequence will start in a few seconds and may be loud. It is important to leave the room as your pres­ence will interfere with the calibration process.
ENTER
.
8. Wait for completion of setup before returning to the room.
9.
Play some sample audio material to check the sound quality.
Note: Do not perform manual adjustments after run-
ning Auto setup, as this will erase all settings defined during Auto setup.
10.
Store the microphone out of direct sunlight and away from heat.
Height of TV speakers
Be sure the
3 ft.
height of the microphone is
of the speaker height.
Microphone
Center the micro­phone in front of the TV.
For assistance call 1(800) 332-2119
44 3. TV Features
To TV audio
Sound Projector (838 Series), continued
External Rear Speakers
You may wish to supplement surround sound from the TV with external rear speakers. External speakers can fill in rear sound if your room lacks a rear wall suitable for reflecting sound. Mitsubishi recommends Polk Audio’s F/X Wireless Surround system.
Transmitter
Polk Audio F/X
Wireless Surround
speaker unit
Sample room layout without a back wall suitable for rear sound reflections
TV
SUB
CENTER
WOOFER
INPUT
OUTPUT
DIGITAL
DVI/PC
AUDIO
AUDIO
LR INPUT
IR-NetCommand Output/EXTERNAL CONTROLLER INPUT
HDMI
2
1
3
OUTPUT
Y/ VIDEO
LAN
Pb Pr
Y/ VIDEO
Pb Pr
(480i / 480p / 720p / 1080i)
LR
AUDIO
To left and right
Transmitter
audio inputs
Connecting the transmitter to the TV
AUDIO/SURROUND
OUTPUT
LR
GLASSES
INPUT 2
INPUT 1
AUDIO/SURROUND
OUTPUT
LR
ANT
3D
EMITTER
outputs
1.
Position the external speakers as needed for rear sound.
2.
Connect analog audio output from the TV to the Polk Audio F/X Wireless Surround transmitter.
3.
Power on the TV, speakers, and transmitter.
4.
Set Sound > Global > Analog Audio Out to Rear.
5.
Adjust the sound output. Go to the Sound > SoundPro > CUSTOM menu. Review the instruc-
tions in “Custom Menu,” page 41. a. Adjust beam angles for the left, right, and
center beams. Because the external speakers output left and right surround beams and they do not appear in the adjustment image.
b. Adjust volume levels for all audio beams.,
including the left and right surround beams.
Sound Projector adjustments when using external rear speakers.
6.
Play sample audio to check the sound. Repeat any of the adjustments as needed.
For assistance call 1(800) 332-2119
3. TV Features 45

StreamTV™ Internet Media

Internet services provided by VUDU™ Apps let you access many popular on-line applications. In addition to free content, VUDU’s movie service lets you buy and rent movies through the TV. Visit www.VUDU.com to learn more about available movie titles, prices, and ser­vices offered. For a list of recommended routers and switches, see the Support > Knowledge Database section at VUDU.com.
Note: From time to time you may notice changes to
the internet interface as new features are added.
Home Network Setup
Before using StreamTV internet media, you must connect the TV to the internet using one of these methods.
Note: Make sure the TV is on any input other than the
USB port or Bluetooth®. Press the change.
Ethernet Connection
DHCP (automatic)
1.
Connect the TV to your network router with a Category-5 Ethernet cable
(not supplied).
INPUT
key to
Required for StreamTV internet media:
• Broadband internet service (at least 2 Mbps for SD, 4 Mbps for HD, and 8 Mbps for 1080p HDX)
• Ethernet cable or
to connect wirelessly, an Azure-
Wave AW-NU231 USB wireless adapter.
• Computer access to the VUDU.com website (required for initial account activation).
• A credit card for rental and purchase transactions from VUDU’s movie service.
2.
Open the Setup > Network menu to review set­tings.
Incoming
internet
cable
SUB
CENTER
WOOFER
INPUT
OUTPUT
DIGITAL
AUDIO
IR-NetCommand Output/EXTERNAL CONTROLLER INPUT
HDMI
2
1
3
OUTPUT
LANLAN
TV Main Panel
Router or modem
providing high-speed
internet service
AUDIO/SURROUND
AUDIO
LR
OUTPUT
LAN
Y/ VIDEO
Pb Pr
PbPrY/ VIDEO
(480i / 480p / 720p / 1080i)
LR
AUDIO
ANT
OUTPUT
LR
3D
GLASSES
INPUT 2
EMITTER
INPUT 1
Setup > Network, DHCP connection
3.
Press
EXIT
to clear the menu.
Manual
Note: Manual setup is available only for a wired con-
nection.
Ethernet cable
1.
Connect the TV to your network router with a Category-5 Ethernet cable
2.
In the Setup > Network menu, highlight Manual and press
3.
Press to move to the Connection Data area.
4.
Input the connection data.
5.
After entering connection data, press
ENTER
.
(not supplied).
ENTER
to
connect.
6.
Change any of the following if needed:
• Default Gateway
• DNS
• Subnet Mask
For assistance call 1(800) 332-2119
46 3. TV Features
CENTER INPUT
SUB WOOFER OUTPUT
StreamTV™ Internet Media, continued
Wireless Connection
The TV requires an AzureWave AW-NU231 USB wireless adapter. The adapter is available from your Mitsubishi dealer.
1.
Disconnect the Ethernet cable if present.
2.
Connect the wireless adapter to the TV’s USB port as shown for your TV model.
3.
Open the Setup > Network menu. After a few moments, detected networks will appear listed on the screen in order of signal strength.
Setup > Network menu, manual connection
4.
Highlight the desired network and press
ENTER
connect. A check will appear next to the connected network. Press
CH/PAGE
to see more networks if the
list fills more than one screen.
IEEE 802.11n-compliant wireless network router providing high-speed internet service
Incoming internet cable
Setup > Network menu after connecting. The active network is checked and connection data displays.
5.
If connecting to a secure network, enter the network key or password when prompted. Special
to
remote control keys you may need:
Key Use for
1
CANCEL
LAST
DIGITAL
AUDIO
AUDIO
LR
OUTPUT
OUTPUT
IR-NetCommand Output/EXTERNAL CONTROLLER INPUT
HDMI
2
1
3
Y/ VIDEO
LAN
Pb Pr
PbPrY/ VIDEO
(480i / 480p / 720p / 1080i)
LR
AUDIO
Back of 738
AUDIO/SURROUND
OUTPUT
ANT
LR
3D
GLASSES
INPUT 2
EMITTER
INPUT 1
Series TV
Wireless adapter
OR
INPUT 3
L R
Pb
Y/ VIDEO
Pr
AUDIO
USB HDMI 4
838 Series
TV
Wireless adapter
Digit 1 and special characters
! @ # $ % ^ * _ - + = . SPACE ?
• Clears the password box of an old entry from a prior session.
• Deletes one character during pass­word entry.
Toggles between upper and lower case
For assistance call 1(800) 332-2119
6.
Press
ENTER
to connect.
Note: If you notice interference from the TV’s internal
wireless components, turn off the TV’s transmit­ter. Open the Setup > Network menu. Select
Off and press
ENTER
.
To reconnect later, open the Setup > Network menu, highlight the network, and press
ENTER
.
3. TV Features 47
StreamTV™ Internet Media, continued
Using StreamTV Internet Media
1.
After establishing internet connectivity as described in “Home Network Setup,” page 45, any input other than Bluetooth® or USB.
2.
Press the VUDU Apps.
3.
Highlight an application and press
INTERNET
key to display services from
switch the TV to
ENTER
to launch it.
Getting Started with VUDU Movies
1.
After establishing internet connectivity as described in “Home Network Setup,” page 45, any input other than Bluetooth® or USB.
2.
Press the VUDU Apps.
3.
Highlight the VUDU movie service and press
4.
Browse the VUDU movie catalog and offerings.
5.
When you are ready to rent or buy a movie, you will be prompted to activate your VUDU account. Follow the on-screen instructions and use a com­puter to go to www.VUDU.com/activation. A credit card is required for activation.
Once your account is activated, you can rent and buy movies using only the TV and the TV’s remote control.
INTERNET
key to display services from
switch the TV to
ENTER
Troubleshooting
If You Are Unable to Connect to the Internet
• Check all power and data connections.
• If you can reach the internet with a computer or
other device on the same internet service used by the TV, consult the router or modem owner’s guide for reset instructions.
• If you cannot reach the internet, contact your service provider. You may be asked for network information such as the TV’s IP address. Go to the Setup > Network menu to see connection data.
For Further Assistance
• If you are having trouble connecting your TV or
.
accessing internet applications, contact Mitsubishi Customer Care at 1-800-332-2119.
• If you are having difficulty with your VUDU account, contact VUDU Customer Care at www.VUDU.com/support.
• See more troubleshooting tips on page 93.
Using VUDU Apps and VUDU Movies
Navigate VUDU’s menus with the keys on the TV’s remote control. Browse the movie catalog, watch movie previews, set parental controls, and rent or buy movies.
CANCEL
text entry.
ENTER
• Selects a menu item.
• Launches an application from the VUDU
• In VUDU’s movie service, use
• Directional navigation
• In VUDU Apps, press to display
GUIDE.
the VUDU home menu.
INFO.
the VUDU for the current selection if available.
F2.
.
Acts like the backspace key during
Apps menu.
during
video playback to see options.
more applications.
In VUDU’s movie service, returns to
In VUDU’s movie service, works like
MORE
key. Displays more options
Displays the VUDU system menu if available.
TOOLS
LAST
INTERNET
TOOLS
. Use the Tools menu
while in VUDU movies or some VUDU Apps.
LAST
• Goes to the previous screen.
• Stops video playback and returns to the pre-
vious menu.
CH/PAGE
menu items.
INTERNET
menu. Switch the TV to any input other than
Bluetooth
EXIT
• Closes the internet menu.
• Goes to the VUDU home page.
In VUDU’s movie service:
PLAY/PAUSE
Starts or pauses video playback.
FAST FORWARD/REVERSE
• Press to search scenes forward or back.
• Press additional times to speed up search.
• Press opposite key to slow and pause search.
STOP
Stops video playback and returns to the previous menu.
.
Jumps to the previous or next page of
. Displays the VUDU Apps internet
® or USB before connecting to the internet.
. Depending on context:
to perform A/V reset
For assistance call 1(800) 332-2119
48 3. TV Features

Introduction to Home-Theater Control

This TV offers a choice of home-theater-control systems. This summary offers some examples of the control methods available using the TV’s remote control. You may wish to use one or more of these methods in your home theater after completing Auto Input Sensing.
Source device connected directly to the TV
Remote Control Programming (Any Connection Type)
Program the remote control to operate the A/V device. To control the device, set the remote control to the correct mode for the device type. See Appendix A, “Pro­gramming the Remote Control.” In the case of an A/V receiver, use the Audio Lock feature, page 78.
CEC-Enabled HDMI Device (HDMI Connection Only)
See Appendix C, “HDMI Control of CEC Devices,” page 85.
838 Series. NetCommand IR Control (Any Connection Type)
Set up NetCommand IR control of the device’s keys as desired. See “IR Emitters,” page 65, and “Initial NetCommand Setup,” page 66.
Any Connection Type
A/V
Device
CEC-Enabled
A/V Device
Any Connection Type
A/V
Device
Source device connected to an A/V receiver connected to the TV
CEC-Enabled
Source Device
CEC-Enabled HDMI A/V Receiver
The TV’s remote control may operate some functions of a connected A/V device. You can switch to the device by selecting its icon in the TV’s Input Selection men u. See Appendix C, “HDMI Control of CEC Devices,” page 85.
A/V Receiver
TV
HDMI
Cable
TV
TV
HDMI Cable
HDMI Cable
TV
838 Series: A/V Receiver with HDMI Output (no CEC)
1. Set up NetCommand IR control of the A/V receiver’s keys as desired. See “IR
Emitters,” page 65, and “Setting Up A/V Receiver Control,” page 71.
2. Set up NetCommand IR control of the source device’s keys as desired. See
“NetCommand Control of a Device Connected to an HDMI A/V Receiver,” page
74.
For assistance call 1(800) 332-2119
Source Device
A/V Receiver
TV
Any Con-
nection Type
HDMI
Cable
4

Main Menu

Press
MENU
on the remote control to open the main menu.


Sound
Captions

TV Menus

Picture settings. 49
Sound settings. 53
Closed captions on/and off; caption displays.
55
Setup
Inputs
Lock
Basic TV setup. 56
Name assignments for TV inputs, HDMI Control setup 838 Series. NetCommand IR “learning.”
Setting a pass code and restrictions TV use. Dis­abling the control-panel buttons.
59
61
49
Assign a name to the TV input before making video adjust­ments (use the New Device Found or Inputs > Name menu). Adjustments will be reset to the defaults if you rename the input after making adjustments.
Picture Video
Settings in this menu are saved for the current input only.
To make Video adjustments while watching TV and without using the menu:
1. Press the
2. Press to select a video option.
3. Press to change the setting.
Mode
VIDEO
key.
Brilliant
Game
Bright For most daytime viewing and x.v.Color sources
Natural For most nighttime viewing and x.v.Color sources
For use under bright light; unavailable when the current input is named
Optimizes video processing for gaming consoles. Available only when the name of the input is or PC.
Game
or PC.
Game
Set the Picture Mode first before changing other video settings, as some settings are stored independently for each Picture Mode. Use Picture Modes to get the best image under different viewing condi­tions.
Advanced Contact your professional installer for setup or see page 51.
738 series: 838 series: ISF Day/ADV1, ISF Night/ADV2
Special/ADV
For assistance call 1(800) 332-2119
50 4. TV Menus
Picture, continued
Contrast • Low contrast shows a variety of shades in darker images
• In most home lighting situations, medium contrast looks best.
• High contrast shows darker images more uniformly black and makes colors appear more vibrant. High contrast is good for brightly lit environments.
Brightness Adjusts overall picture brightness. Settings are stored independently for each Picture Mode.
Color Adjusts overall color intensity from monochromatic to fully saturated.
Tint Adjusts the red-to-green ratio.
Sharpness Adjusts picture detail and clarity.
Color Temp High
Low Gives white images a warm cast. Natural/Color
Video Noise
High, Medium, Low, Off
Gives white images a cool cast. May provide the most realistic picture under bright lighting.
Temp at the low setting displays video at approxi­mately the 6500K industry standard for NTSC pictures.
• High. For poor-quality signals.
• Medium.
• Low. For good-quality signals.
• Off. Leaves the picture unaltered.
For moderate noise reduction.
Adjusts the white-to-black level Settings are stored indepen­dently for each Picture Mode.
Adjusts the white balance. Settings are stored indepen­dently for each Picture Mode.
Reduces minor noise (graini­ness) in the picture.
EdgeEnhance
DeepField
Imager
On, Off EdgeEnhance™ adds special edge enhancements to make the image appear
sharper.
On, Off DeepField™ Imager dynamically enhances black levels in portions of the screen to
provide strong contrast with detail over mixed screen content.
Demo For comparison, displays a split picture to show On (right side) and Off (left side).
Picture Picture+ (Picture Plus)
Screensaver
Film Mode Auto, Off 480i and 1080i signals only.
Smooth 120
Test Picture
On, Off Select On to display a screensaver pattern while playing an audio-only input. To use
this feature, the input must either
• Be named as an audio source (e.g., CD, MP3 Player, Bluetooth) or
• Be the antenna input tuned to an audio-only signal.
coding correction to movies filmed at 24 frames per second. Try the show many jagged edges. Setting saved by input.
On, Off
Displays a test picture.
When
active
, reduces motion blur in action scenes but may show pixel structure during
slower motion or in still images. Works in conjunction with Film Mode.
In
Auto
, the TV automatically detects and applies film-de-
Off
setting if images
For assistance call 1(800) 332-2119
4. TV Menus 51
Picture, continued
Picture Reset
• Resets sound and picture adjustments for the current input. Highlight the Reset icon
and press
• Reset has no effect on universal settings (Balance, Liste n To, Language) or on Advanced picture settings.
Picture Perfect
(PerfectColor/PerfecTint, 838 series)
ENTER
twice to perform reset
.
PerfectColor Sliders
PerfecTint Sliders
Using PerfectColor:
Highlight the Perfect icon and press for each TV input.
Using PerfecTint:
• ToswitchbetweenPerfectColor™andPerfecTint™adjustments,highlightPerfectColor/PerfecTint and press
.
• Press to move from one color bar to the next.
• Press to change settings.
• Press
• Press
CANCEL MENU
to restore default settings.
to return to the main menu.
Adjusts the saturation (intensity) of six colors for the current image source.
Adjusts six hues for the current image source
ENTER
to display the PerfectColor menu. Settings are retained independently
Picture Advanced
Picture > Advanced allows you to save highly customized picture adjust­ments for each input. Mitsubishi recommends these adjustments be
made only by a trained professional installer.
1. Press
2. With Picture Mode (the first option) highlighted, press
3. Use
4. Press
5. Use
6. Press
MENU
. Under Picture, highlight the Advanced icon and press
838 Series: Choose
to
highlight an option you wish to change and press ENTER
to change settings.
to
navigate to additional options and press
MENU
to return to the Picture > Advanced menu and save the adjustments for the current input. Press
to close the menu
ADV1
.
(daytime settings) or
ENTER
ENTER
to change
ADV2 (nighttime settings).
to see the adjustment display.
to change settings
.
from blank (undefined)
.
to
ADV
.
EXIT
To use the custom Picture Mode at a later time
Press
MENU
and go to Picture > Video > Picture Mode and:
738 Series 838 Series
• Select
• Otherwise select ADV.
SPECIAL if settings were saved by your
professional installer.
• Sele your professional installer.
• Otherwise select ADV1 or ADV2.
ct ISF Day or ISF Night if settings were saved by
For assistance call 1(800) 332-2119
52 4. TV Menus
Picture, continued
To return to the default values for Advanced Display the Picture > Advanced menu and:
738 Series 838 Series
ENTER
Highlight RESET Pic Mode and press
3D
TV Software Version 012.06 and Later
Mode
See page 33 for use of this menu.
.
1. Highlight the Advanced mode to change.
2. Highlight RESET Pic Mode and press perform the reset separately for both ADV1 and ADV2
ENTER
. You must
Source Format
Glasses L-R
Glasses
Control
TV Software Version 012.05 and Earlier
3D Mode
Source Format
Glasses L-R
Glasses
Control
Off, Automatic, Side by Side, Top/Bottom, Checkerboard
Standard, Reverse
IR Emitter, DLP Link
Off, On Enables or disables 3D mode for the current input.
Checkerboard Side-by-Side
Standard, Reverse
IR Emitter, DLP Link
Enables or disables 3D mode for the current input.
Synchronizes left/right images to work with your 3D glasses.
Switches between control methods for 3D glasses.
3D formats supported by the TV.
Synchronizes left/right images to work with your 3D glasses.
Switches between control methods for 3D glasses.
For assistance call 1(800) 332-2119
4. TV Menus 53

Sound

Sound Audio
Settings in this menu are saved for the current input only with the exception of Balance and Subwoofer, which apply to all inputs.
To make Audio adjustments while watching TV and without using the menu:
1. Press the
2. Press to select an audio option.
3. Press to change the setting.
TV Speakers On Turns on the internal TV speakers.
AUDIO
key.
Off
Center (838 Series)
Turns off the internal TV speakers so you hear sound only from a connected A/V re c e iver. Note: When you disconnect an A/V receiver, be sure to change the TV Speakers setting to On to hear sound from the TV speakers.
Makes the TV’s speaker array act as a center channel. See “Using the TV Speakers as a Center Channel,” page 27.
Notes:
• Set Sound > Global > Center Channel to On to make this setting available.
• To de-activate the center channel, change this setting to On or Off.
Bass Controls volume of low-pitched sound from the TV speakers.
Treble Controls volume of high-pitched sound from the TV speakers.
Balance Controls audio balance between the right and left TV speakers
Subwoofer
(838 Series)
Sound Mode Stereo No special audio effects from the TV speakers
Level Sound On, Off Reduces differences in sound volume between programming segments, such as
Listen To
(applies only
to analog
channels from
ANT
the
input)
[Subwoofer level adjustment]
Surround Modifies audio from the TV speakers.
Music (838 Series)
Night (838 Series)
Stereo The TV plays stereo broadcasts in stereo and mono broadcasts in mono. The
Mono Reduces background noise. Use when receiving a weak stereo audio signal. All
SAP
(Second Audio Program)
Adjusts the volume level of a connected subwoofer. Note: Set Sound > Global > Subwoofer to On to make this adjustment avail­able.
• Formonaural(non-stereo)programs,createsasimulatedstereoeffect.
• Forstereoprograms,createsasimulatedsurround sound effect.
• 838 Series. The TV’s speaker array plays 5.1 surround sound if available.
Optimizes the TV’s speaker array for music listening.
Focuses the TV’s speaker array to a single point to limit sound heard by others outside the room. Press
the difference between regular broadcast programs and commercial segments.
word Stereo is displayed when you tune to a channel broadcasting in stereo.
audio is played as mono. Selects an additional monaural sound track not audible during normal TV viewing.
The SAP signal might be related to the program (such as a sound track in a foreign language), or it might be unrelated (such as a weather report). If an SAP signal is broadcast, the letters SAP are displayed when you tune to the channel.
ENTER
to adjust the focal point (Night Angle).
For assistance call 1(800) 332-2119
54 4. TV Menus
Sound, continued
Sound Global
Settings in this menu apply to all left and right inputs.
Analog Audio Out
Subwoofer 838 Series. Select On to turn on audio to a connected subwoofer. Set to Off if no subwoofer
Center Channel 838 Series. On allows the TV’s speakers to complement your external sound system as a
These settings affect audio from the AUDIO OUTPUT jacks.
Fixed Use with an analog A/V receiver. Control volume from the A/V receiver. The
volume of the audio output signal is fixed and is unaffected by the TV’s volume control.
Variable Use with headphones. Adjust headphone volume using the TV’s volume controls.
When set to Variable, the audio output signal is adjustable from the TV’s volume controls.
Rear 838 Series. Sends left and right rear audio to external speakers.
supplementing the TV’s speaker array with external rear speakers. See “External Rear Speakers,” page 44.
is connected.
center channel. Set to Off if not in use. See “Using the TV Speakers as a Center Channel,” page 27.
Use when
Sound Auto SP
838 Series. Performs auto calibration of the Sound Projector speaker array. See “Auto
Setup,” page 43.
Sound SoundPro
838 Series.
Lets you set up the Sound Projector speaker array manually. See page 41.
For assistance call 1(800) 332-2119
4. TV Menus 55

Captions

Captions on Digital Channels
The TV can decode captions from the ANT input only.
Broadcasters can send up to six different captioning selections or can send analog captions for a program that originated in analog format. A TV station may broad­cast only one or two types of captions or none at all
.
Captions on Analog Channels
The TV can decode captions from the
the composite either standard closed captions or text service. Standard closed captions follow the dialogue of the program and display in a small section of the screen. Text-service closed captions often conta news and cover a large portion of the screen.
VIDEO
jacks. Broadcast
in information such as weather or
ANT
input and
ers can send
• Thecontentofcaptionsisdeterminedbythe
broadcaster. If captions show strange char­acters, misspellings, or odd grammar, it is not a malfunction of the TV.
•
Closed-caption signals are not available through HDMI or component jacks. See the menus for devices connected to these inputs for closed­caption decoding.
• The Captions menu has no effect on captions displayed in programming received over the internet.
IMPORTANT
Captions Services
Service On if Mute, On, Off On if Mute: Displays digital closed-caption signal Caption 1 (digital) or CC1
(analog) when audio from the TV speakers is muted. While watching TV, press
MUTE
to turn closed captions on/off.
Digital
Caption 1–Caption 6
Caption signals sent by the broadcaster.
Analog
CC 1–CC 4 Tex t 1–Tex t 4
Captions Font
Style As Broadcast or
choice of font styles
Size
Large, Medium, Small
Captions Color
Font White, Black, Magenta, etc. Recommendations for digital captions:
Opacity
Background
Opacity
(Background
Translucent, Opaque, Flashing, Transparent
White, Black, Magenta, etc.
Translucent, Opaque, Flashing, Transparent
)
• CC 1–CC 4. Standard closed-caption signals
• Text 1–Text 4. Text-service signals
As Broadcast changes settings to those selected by the captions provider, or, if none, to the TV’s own caption defaults. Use one of the font styles to give digital captions a custom appearance.
Large is recommended.
• A white font on a black translucent back­ground makes an easy-to-read combination.
• Usecontrastingcolorsforcaptionsandback­ground.
For assistance call 1(800) 332-2119
56 4. TV Menus

Setup

Setup Language
Menu English
Spanish
Antenna
Digital
Audio
Selects the current language for a digital program from the include up to seven language choices or there may be no language choice offered.
Displays on-screen menus in either English or Spanish.
ANT
input. Each digital program may
Setup Clock
Set the TV clock to:
• Use the TV Timer to power on the TV automatically at a preset time
• Receive correct updates to ChannelView listings
Note: When the Daylight Saving Time change occurs, you must open this menu and set the TV’s clock ahead or back.
Time
Date
Time
Zone
Daylight
Savings
Highlight the Clock icon and press
• Press
• Press t
• Press
Eastern, Central, Mountain, Pacific, etc. The correct time zone is required for accurate ChannelView updates.
Off, On Select the setting for your area (required for accurate ChannelView updates).
ENTER
to select the item to change. o change values.
to move to another column.
ENTER
or to highlight the time. To edit time and date:
Setup Timer
The Timer tells the TV to power on automatically at a time you set. Use this menu to set a day, time, input, and channel for the Timer. If the TV is already on at the set time, the TV will automati­cally change to the designated channel or input.
• TheTVclockmustbesetbeforeyoucanusetheTimerfeature.
• AsareminderthattheTVTimerisset,theTV
•
When the Timer turns on the TV, press any key on the remote control to keep it from turning off after five minutes.
Timer On, Off Select On to enable the Timer.
Day Daily, Mon-Fri, (every) Sunday, (every) Monday,
(every) Tuesday, etc.
Time To set the time for the TV to come on:
1. Highlighted the time and press
2. Press t
Device Ant, DVD, VCR, etc.
Select the input you want displayed when the TV comes on. Choose from the defined and enabled inputs that appear in the Input Selection menu.
Channel
If the source is the
o change values.
ANT
input, press to select a channel number or press and hold to scroll quickly.
POWER
ENTER
Press
indicator flashes slowly while the TV is powered off.
Select the day or days of the week for the Timer to turn on the TV.
.
ENTER
to confirm entries.
For assistance call 1(800) 332-2119
4. TV Menus 57
Setup, continued
Setup Channel
Ant Air,
Ant Cable
All Channels, Add only new
channels
Scan
Edit After channel scan, Edit lets you add and delete memorized channels. Memorized channels are
Adding/Deleting Channels Using the Channel Edit Menu
• Channels marked with a check are in memory.
• To add or delete a channel from memory, highlight
the channel number and press
• To add a single digital channel not in the list, see
the notes under Scan on this page.
• Digital channels are listed by virtual channel number with the physical channel number shown in small gray text.
- Virtual Channel Number (digital channels
only). A channel number sent by a local broad­caster.
- Physical Digital Channel Number. The
channel number officially assigned to the actual broadcast frequency; shown on screen in gray text.
Notes on Scan and Channel Memorization
• Channelmemorizationmaytakeupto15minutesto
complete.
•
To stop channel memorization before completion, press
CANCEL. Channels already added are retained
• WhenwatchingTV,pressCH to move through
memorized channels. Press and hold CH to speed through channels.
You must perform a channel scan to receive digital channels. The scan searches for broad­cast channels and adds them to TV memory. To start channel scan:
1. Highlight one of the input selections based on your connection to the ANT input
• Air when connected to an indoor or outdoor antenna.
• Cable when connected to direct cable (no cable box)
2. Select the scan type.
• Select All Channels for an initial scan or after moving the TV to an new area with a differ-
ent channel line-up.
• Select Add only new channels to search for channels newly broadcasting since the
previous scan.
3. Press to highlight SCAN.
4. Press
See below for additional notes on Scan.
those you can tune using the
• Press
• Press to move through all channel numbers, one at a time.
ENTER
to start channel memorization.
CH
key. Edit the channel list to limit tuning to channels you watch.
CH/PAGE
to jump to the next or previous page of channel numbers.
ENTER
.
.
:
•
To add a digital channel that does not appear in the Edit menu without performing channel memorization:
1. Look up the physical channel number for
the new digital channel. See the website
www.antennaweb.org for help.
2. Press
3. Use the number and
The TV will search for a digital channel on the channel 36 frequency. When it finds the channel, it will:
• Rememorize channels if you move the TV to a different geographic area with a different channel line-up.
INPUT
and select the
physical channel number followed by “-1” and
ENTER
. For example, for physical channel 36,
3
6 1
a. Add the channel to memory. b. Change the channel number to the virtual
channel number sent by the broadcaster.
c. Add to memory any associated sub-chan-
nels.
CANCEL
ANT
input.
keys to enter the
ENTER
.
For assistance call 1(800) 332-2119
58 4. TV Menus
Setup, continued
Setup Energy
Lamp
Energy
Blue Glow
(838 series
Standard, Bright
On, Off Select On to see blue accent lighting when the TV is powered on.
)
Standard is for most viewing conditions. Use Bright in brightly lit rooms. You may notice increased fan noise when using the Bright setting.
Setup Network
See “Home Network Setup” on page 45 for use of this menu.
Ethernet Connection DHCP (automatic), Manual
[Connection Data]
Wireless Connection [Network ID]
[Connection Data]
Off. Turns off the radio receiver. Use this option if there is RF interference with other
devices.
For assistance call 1(800) 332-2119
4. TV Menus 59

Inputs

Inputs Name
INPUT and HDMI jacks: Cable box, Cam(corder), CD, DVD (DVD, DVD2, Blu-ray), DVR, Game (Game, PS, Xbox, Wii), Media Box, PC, Satellite, AVR On/Off (A NT,
INPUT CD/Audio, MP3 Player, VCR
HDMI
jacks
PC, AVR, Delete
General Notes for the Inputs > Name Menu
When you change an input name and then exit the Name menu:
• The name is changed
• The icon in the Input Selection menu is changed
• Audio and video settings are changed to the
defaults for the new device type.
• 838 Series: All previous NetCommand IR “learn-
ing” for the input is erased.
Notes for HDMI devices
• Disconnecting an HDMI device: When you discon-
nect an HDMI device, the icon remains in the Input Selection menu until you remove it. Select Delete in the Inputs > Name menu to remove an unwanted icon for an HDMI input.
jacks
Bluetooth
only:
only:
only)
• Lets you assign or change names of inputs appearing in the Input Selec- tion menu. Highlight an input and press
through the name choices.
• Lets you turn the Ant and Bluetooth inputs On/Off to display or hide them in the Input Selection menu; highlight the input and press between On and Off. A paired device is cleared from memory when the Bluetooth icon is turned off.
• Lets you delete unused HDMI inputs from the Input Selection menu.
• A CEC-enabled tuner can be named either Cable Box or Satellite.
• A CEC-enabled DVD player can be named DVD, DVD2, or Blu-ray.
ENTER
multiple times to cycle
ENTER
to switch
• If the New Device Found screen does not display as expected when you connect an HDMI device, see “Reactivating Auto Input Sensing for an HDMI Input,” page 13.
• HDMI Control and CEC-Enabled Devices: See Appendix C, “HDMI Control of CEC Devices,” page
85.
• In case of CEC conflicts: Turn off CEC signals in these ways:
- Turn off the TV’s HDMI Control signals to the device (Inputs > HDMI Control menu).
- Turn off each device’s internal CEC capability.
See Appendix C for the TV’s HDMI Control or, to turn on/off a specific device’s response to CEC signals, see the device owner’s manual.
Inputs Learn
Inputs AVR
HDMI
Inputs
Control
838
Series.
See “About NetCommand IR Control,” page 64.
838
Series.
See “NetCommand IR Control of an A/V Receiver” on page 70.
On, Off
Sets up or changes NetCommand IR control of the current device.
Sets up or changes NetCommand IR control of an A/V receiver.
Select On or Off to enable or disable the TV’s control of a CEC-enabled device. See Appendix C for use of this feature.
For assistance call 1(800) 332-2119
60 4. TV Menus
Inputs, continued
Inputs Order
Lets you rearrange icons in the Input Selection menu.
1. Press
2. Press
3. Press to drag the icon to the desired position.
4. Press
to highlight an input icon.
ENTER
to confirm the selection.
ENTER
to confirm the new position.
Inputs Demo
See demonstrations showcasing selected TV features.
For assistance call 1(800) 332-2119
4. TV Menus 61

Lock

TV Locks
Parental
Time
Channel Lock by Channel
Panel
Other
Lock by Program Ratings
Restricts access using U.S.-based ratings sent by broadcasters.
Lock by Time
Restricts TV use by time of day.
Blocks access to the channels you specify.
Lock Control Panel
Disables the buttons on the TV’s control panel. Use this feature if small children in the home try to press buttons on the control panel.
Lock by Other Program Ratings
Restricts access using new or non-U.S.­based ratings sent by broadcasters.
Pass Code
Setting a Pass Code
You are prompted to enter a pass code whenever you select Lock on the main menu. To set a pass code for the first time:
1. Press
2. Input a four-digit pass code using the number keys
3. Press
Resetting a Pass Code
See the procedure in Appendix B.
MENU.
Highlight Lock and press
screen prompting you for a pass code will display.
on the remote control.
• Press
• Press
CANCEL
back one space.
MENU
setting a pass code.
ENTER
to delete a number and move
or
EXIT
to close the menu without
to confirm the pass code.
ENTER
. A
Parental Menu
The TV comes from the factory with the rating locks turned off and with pre-set U.S. ratings TV-PG and movie rating PG. You must turn on blocking for U.S. ratings to activate these rating restrictions. Use the Lock > Parental menu to change the level of blocking with U.S. ratings.
Any time you change the channel or device, it may take up to five seconds for the rating restrictions to take effect.
Note: To set parental controls for programs from the
VUDU™ movies service, use the VUDU Info & Settings menu. The TV’s Parental menu does not control content received through VUDU.
Other Menu (Alternate Rating System)
This TV can recognize new rating systems that may come into effect in the future. The Other menu allows you to block digital programming when such systems come into effect. The Start Time and Stop Time options in the Parental menu apply to U.S.-based ratings only and do not affect alternate rating systems.
The first time you tune to a channel broadcasting an alternate rating system, the TV defaults to the most restrictive setting if the Lock menu > Other Lock option is set to On. Use this menu to change the allowed rating if you are unable to watch a program rated with an alternate system.
Bypassing TV Locks
• If you try to watch a blocked program or channel or the TV is locked by time, a notice will appear prompting you for a pass code. To use the TV, input your four-digit pass code and press
- To reactivate the locks after using a pass code, power the TV off and then on.
- To reactivate only the parent ratings lock, change to a different channel or device.
• If a program is blocked, you can still use the TV without entering a pass code. Change to a channel airing an allowed program or change to another device.
Important Notes on Rating Locks
•
Parental menu rating locks apply only to chan­nels and signals received on the ANT posite
• Other nels received on ANT
• Whenviewingacablebox,satellitereceiver,
or other device connected to the component
Y Pb Pr
owner’s guide for parental locks.
VIDEO
jacks.
menu rating locks apply only to digital chan-
.
or
HDMI
inputs, check the device’s
ENTER
and com-
.
For assistance call 1(800) 332-2119
62 4. TV Menus
Lock, continued
Lock Parental
Lock
TV Rating
Movie
Rating
Start Time/
Stop Time
TV Program Ratings
Disables or enables blocking based on V-Chip signals and the U.S. rating system.
Highlight the rating level you wish to change and press allow it (
You can apply supplemental content blocking to the age-based ratings by using the TV content categories. (FV, D, L, S, V)
Highlight the rating level you wish to change and press ENTER can apply supplemental blocking to the age-based ratings by using the TV content categories below.
Sets the time of day for enforcement of rating restrictions chosen in the Parental menu. To make rating restrictions active 24 hours a day, make Start Time and Stop Time the same.
1. Highlight the start time or stop time.
2. Press
3. Press to make changes.
4. Press
ENTER
).
ENTER
to start editing.
ENTER
to confirm changes.
to block it ( ) or
to block it ( ) or allow it ( ).
Movie Ratings
You
TV Age-Based Ratings
TV Content Categories
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
FV
D
L
S
V
Youth. For children under 7.
Youth 7 and older.
General Audience. For the entire family.
Parental Guidance. Parental Guidance
recommended; may not be suitable for some children.
Adolescent 14 and older. Not recommended for children under 14.
Mature Audience. For adults only.
Fantasy Violence. Applies to TV-Y7 only.
Sexual Dialog. Applies in differing
degrees to TV-PG and TV-14. Adult Language. A
degrees to TV-PG, TV-14, and TV-MA. Sexual Situations. Applies in differing
degrees to TV-PG, TV-14, and TV-MA. Violence (graphic or realistic). Applies in dif-
fering degrees to TV-PG, TV-14, and TV-MA.
pplies in differing
G
PG
PG-13
R
NC-17
X
Not
Rated
General Audience. Designed for the
entire family. Parental Guidance. Parental Guidance
recommended; may not be suitable for some children.
Parental Guidance, 13 and Older. Not recommended for children under
13. Restricted. Restricted in theaters to 17
years old and older unless accompanied by an adult.
No Children 17 or Under. Restricted in theaters to 18 years old and older.
Adult. Designed for and restricted in theaters to adult audiences only.
No MPAA rating assigned
For assistance call 1(800) 332-2119
4. TV Menus 63
Lock, continued
Lock Time
Blocks all use of the TV during the time period you specify. You must enter a pass code to use the TV when the time lock is in effect. After releasing the lock with the pass code, the lock does not go back into effect until the next time the TV is powered on.
Lock by
Time
Lock Time,
Unlock
Time
Enables/disables Lock by Time.
To set the lock and unlock times:
1. Highlight the lock or unlock time. ENTER
2. Press
3. Press to make changes.
4. Press
Note: T
to start editing.
to move to another column.
o make Lock by Time active 24 hours a day, make Start Time and Stop Time the same.
Lock Channel
The Channel Lock menu lists channels currently in memory (see page 57). Highlight a channel and press cleared the next time you perform a channel scan.
ENTER
to lock ( ) or allow ( ) the channel. Channels locks will be
Lock Panel
Off, On On locks and Off unlocks the buttons on the TV’s control panel. Use this option if small children try
to press TV buttons.
• To release the Panel Lock using the TV’s control panel, press and hold the
seconds. If the TV is powered off, press and hold to make the TV power on.
• To reactivate the lock, return to this menu and change the setting to On.
INPUT
for ten seconds and then press
INPUT
button for ten
POWER
Lock Other
Other Menu Options (alternate rating system)
This TV can recognize new rating systems that may come into effect in the future. Such alter­nate rating systems will apply only to digital programming received on the
Lock On, Off Enables/disables program blocking.
System
Group Rating groups available in the rating system shown on the screen. Rating groups are defined by the
Rating Rating restrictions available in the selected rating system and group. Highlight the rating and press
The rating system available for the channel
rating system in effect.
ENTER
to check (block) or uncheck (allow) rated content.
ANT
input.
For assistance call 1(800) 332-2119
64

NetCommand IR Control

5

About NetCommand IR Control

• NetCommand IR home-theater control is avail­able on 838 series TVs.
• IR emitter cables are available for purchase from Mitsubishi.
800-553-7278 and
- 242D483020 (two-ended cable)
- 299P254020 (four-ended cable).
• NetCommand setup is optional.
• You can perform NetCommand setup for a device
any time after the TV has detected the device.
• NetCommand operates by sending remote control signals from the TV to your other devices via the
Visit www.mitsuparts.com or call
request one of the following:
IR (infrared) emitters, telling the devices to play, record, change inputs, adjust volume, change chan­nels, or perform other functions. All this is accom­plished with the TV’s remote control left in TV mode.
• You may wish to use NetCommand IR control to supplement control of CEC-enabled devices.
Important Note on NetCommand
Be sure to connect the IR emitter cable to the TV and properly place the emitters so that NetCommand can control your devices.
For assistance call 1(800) 332-2119
5. NetCommand IR Control (838 Series) 65
On top of a single tall device
IR sensor
IR sensor
IR sensor
IR sensor
IR sensor

IR Emitters

6.
Placement
The NetCommand system uses emitters connected
to the IR– devices such as DVD players, cable boxes, satellite receivers, and VCRs.
IR emitter cables are available for purchase from Mitsubishi. Request either part number 242D483020
(two-ended cable) or part number 299P254020 (four­ended cable).
1.
2.
NetCommand Output
jack to control other
Connect the plug end of the IR emitter cable to the
IR—NetCommand Output
jack on the TV back panel.
When the New Device Found screen displays, highlight
IR—NetCommand Output.
Place any unused ends behind the devices to prevent stray signals from reaching the IR sensors.
SUB
CENTER
WOOFER
INPUT
OUTPUT
DIGITAL AUDIO
IR-NetCommand
IR-NetCommand Output/EXTERNAL
Output/EXTERNAL CONTROLLER INPUT
CONTROLLER INPUT
HDMI
2
1
3
OUTPUT
LAN
AUDIO
DVI/PC
AUDIO OUTPUT
Y/ VIDEO
Y/ VIDEO
LR
AUDIO
LR
Pb Pr
IR-NetCommand Output/EXTERNAL
Pb Pr
CONTROLLER INPUT
(480i / 480p / 720p / 1080i)
ANT
LR INPUT
3D
GLASSES
INPUT 2
EMITTER
INPUT 1
TV main panel
Other A/V Device
S
CH
DIG IT A L
SURRO U N D
A/V Receiver
The New Device Found screen displays when you
connect the IR emitter.
3.
Highlight EXIT and press
4.
Position the emitter end with the emitter bulb facing the device’s remote control sensor. The bulb emits
ENTER
.
infrared light in a cone-shaped pattern. Place the bulb far enough from the sensor to allow the cone pattern to reach the sensor.
In some cases, the emitter works better facing downward from the top of the device. Experiment to find what works best.
5.
Secure the emitter ends in place using double­sided tape.
IMPORTANT
Position IR emitters so that each device’s sensor “sees” the signal from only one emitter. Otherwise, a device receiving signals from multiple sources (remote controls, IR emitters) may not respond at all.
Connecting IR–NetCommand Output
IR sensor
IR sensor
In front of a single
average-sized device
On top of a single tall device
In front, shared by
two average-sized
devices
IR sensor
IR sensor
IR sensor
Place IR emitters so the signal can be “seen” by the IR sensor on each device.
If You are Unable to Locate a Device’s IR Sensor
• The IR sensor is usually behind the plastic window
of the front display panel. Using a flashlight, you may be able to see it as a round or square cutout.
• If you cannot see the sensor and the device’s
Owner’s Guide does not specify the location, do the following using the device’s remote control.
1. Starting at one end of the plastic window, hold
the device’s remote control about one-half inch from the front of the device and press the
POWER
key.
2. If the device does not respond, move the
remote control one inch toward the center and try again. Repeat until the device responds.
3. Repeat the previous steps starting at the other
end of the window. The sensor is between these two points.
For assistance call 1(800) 332-2119
66 5. NetCommand IR Control (838 Series)

NetCommand Setup

Initial NetCommand Setup
To perform this procedure, you need:
• The remote controls for both the TV and the device you want to control.
• An IR emitter cable available from Mitsubishi
Note: To set up an A/V receiver, see “Setting Up A/V
Receiver Control,” page 71.
1.
Connect and position the IR emitters for the devices you wish to control. See “IR Emitters” on the previous page.
2.
Set the TV’s remote control to TV mode and power on the TV.
NetCommand and Device-Specific Keys
Device-specific keys are those which have no equivalent on the TV’s remote control. Use any of these methods to set up NetCommand control for these keys.
.
3.
Switch the TV to the desired input to control. Press
INPUT
, highlight the input icon, and press
4.
Open the NetCommand Inputs > Learn menu.
5.
The first function highlighted in the Learn screen is always Power On. Aim the TV’s remote control at the TV and press function.
6.
When the
device’s
key until a check mark appears next to Power On.
• If the text stops flashing before the check mark
• To remove the key from NetCommand control,
• To verify the device’s response to the IR code,
Power On
remote control at the TV and hold the POWER
appears, repeat the previous step.
press the highlighted.
press
ENTER
ENTER
to begin learning for that
text starts flashing, aim the
CANCEL
key while the key name is
to send out the code.
ENTER
.
• TOOLS Menu. In some cases, the TV will, by default, assign a key to the TOOLS menu. See the table below.
Examples of Default NetCommand
Assignments in the TOOLS Menu
Cable Box, Sat­ellite Receiver
DVD, DVR, Blu-ray
VCR 3
A/V Receiver 3
NetCommand’s default setup assigns some device-specific keys to the TOOLS menu when “learned.” These key functions are accessible only with the
•
• Arbitrary Key Assignment. You can assign a
TOOLS
key.
F
Keys. There are four F keys, F1 through F4, which you can assign to any function on the device’s remote control. For a cable box, “learn” the F keys as the
device key arbitrarily to any “unlearned” key on the TV’s remote control. Make a note of the key name and function for later reference.
3
MENU
9
ON DEMAND
3
SETUP
6
TOP MENU
9
ANGLE MENU
6
INPUT MENU
6
SURROUND
A, B, C, D
keys.
Inputs > Learn screen. Key names marked with a check have been “learned.”
Some device-specific keys, such as only from the TOOLS menu after “learning.”
7.
Use navigation keys on the TV’s remote control to highlight other keys on the list. Repeat steps 5 and 6 for each additional function you wish to control through NetCommand.
8.
If the device has a separate navigation keys on the TV’s remote to highlight
Power Off. POWER OFF If the device has no
9.
Press current device.
Repeat the earlier steps to “learn” the
key.
POWER OFF
EXIT
to finish NetCommand “learning” for the
MENU
, are available
POWER OFF
key, skip this step.
key, use
For assistance call 1(800) 332-2119
5. NetCommand IR Control (838 Series) 67
NetCommand Setup, continued
Adding or Removing Device Keys from NetCommand Control
After performing initial setup, you can add or remove individual keys under NetCommand control.
1.
Switch the TV to the device. Press the device’s icon, and press
2.
Open the Inputs menu and highlight the Learn icon.
3.
When the Learn screen displays:
• To add keys: Continue as described earlier
under “Initial NetCommand Setup” on the opposite page.
• To delete keys: Highlight the name of the key
you wish to delete and press TV‘s remote control. Clears the check mark.
ENTER
INPUT
.
CANCEL
, highlight
on the

Operating NetCommand-Controlled Devices

Controlling Most Device Types
As an example of NetCommand control, if you are watching your cable box and you wish to tune to the next channel higher, press then sends the “learned” channel-up control signal to the cable box.
1.
Perform NetCommand setup for the device as described in this chapter.
2.
When you wish to use the device, press
3.
Highlight the icon for the device.
4.
Press
ENTER
to switch the TV to the device.
Note: if you have set up automatic input switching for
the A/V receiver, the A/V receiver will automati­cally switch to the correct input for the device.
5.
To operate the device using the TV’s remote control, press the TV key to put the remote control into TV mode.
6.
Point the remote control at the TV (not the device) and press the key for the desired function.
7.
Press the tions you may have “learned” for the device.
TOOLS
key to access additional key func-
CHANNEL UP
. NetCommand
INPUT
.
Special Operation Methods
Key Name in Learning Screen
Power On Manual Power On/Off
Power On
Power Off
Special Operation Description and Setup How to Use
Use for devices that have only one
Automatic Power On/Off
This feature is only for devices that have separate
POWER ON
remote controls. If your device does not have a separate Off learning position; use only the Manual Power ON/OFF method described above.
In the NetCommand Learn screen: a. “Learn” the Power On command in the
b. “Learn” the Power Off command in the
and
POWER OFF
POWER OFF
Power On learning position.
Power Off learning position.
key, do not use the Power
POWER
key.
keys on their original
1. Press
2. Highlight the icon for the device to be
3. With the Input Selection menu still dis-
Note: If you press
4. Press
• To Power On the Device
• To Power Off the Device
INPUT
.
powered on or off.
played, press signal; you may need to press
lection menu displayed, the TV will turn off.
ENTER
1. Press
2. Highlight the icon for the device to be
powered on or off.
3. Press
device and NetCommand will send the Power On command to the device.
When you turn the TV off, the TV sends all learned Power Off commands to all devices.
POWER
to send the power
POWER
POWER
without the Input Se-
to switch the TV to the device.
INPUT
.
ENTER
to switch the TV to the
twice.
For assistance call 1(800) 332-2119
68 5. NetCommand IR Control (838 Series)
Operating NetCommand-Controlled Devices, continued
Key Name in Learning Screen
Menu Displaying a Menu for the Current Device
Guide Displaying the On-Screen Program Guide
Enter ENTER-Key Functions (cable boxes, satellite receivers, etc.)
Special Operation Description and Setup How to Use
Press
TOOLS
MENU
“Learn” the
Menu learning position.
(cable box or satellite receiver)
1. “Learn” the the Guide learning position.
2. Learn the original remote in the Page Up and Page Down learning positions.
Some devices have two keys that have “enter” functions. One key is for menus and is often labelled
SELECT
or OK. A second key is for use with number keys for direct channel selection. NetCommand
uses the same
ENTER
When when the original remote control uses the same key for menus and channel selection:
Learn the NetCommand Enter learning position.
ENTER, SELECT,
key on the original remote in the
GUIDE
key on the original remote in
PAGE UP
has a menu or guide function or
and
PAGE DOWN
ENTER
key for both operations.
or OK key in the
keys of the
signal to the device.
1. While watching the device, press
display the guide.
2. Press
1. Press
2. Press
CH/PAGE
mands for the guide.
MENU
menu or guide.
ENTER
NetCommand will send the Enter signal for menus.
and number 3 to send the menu
GUIDE
to
to send the Page Up/Dn com-
or
GUIDE
to display the device’s
within the menu and
Enter (digits)
Cancel CANCEL as the Cancel or Exit Function
— (separator)
When
ENTER
is for channel changes, i.e., the origi­nal remote control has a separate this function):
Learn the the NetCommand Enter (digits) learning posi­tion. Use this learning position only if the original remote control has separate keys for Enter in menus and Enter for channel selection.
“Learn” the Cancel or Exit function in the NetCommand Cancel learning position
The symbol “—” can serve as the separator between a digital channel’s main and sub-channel digits, e.g., digital channel 12-1 (main channel is 12, sub-channel is 1).
“Learn” the channel separator function in the NetCommand – (separator) learning position.
ENTER
key for channel selection in
ENTER
key for
Press digit key(s) and then press NetCommand will send the Enter signal for channel selection.
MENU
or
GUIDE
1. Press
guide.
2. Press
Press digit key(s) and press NetCommand will send the channel-separator signal.
CANCEL
the Cancel or Exit signal.
and NetCommand will send
to display the menu or
ENTER
CANCEL
.
.
For assistance call 1(800) 332-2119
5. NetCommand IR Control (838 Series) 69
Operating NetCommand-Controlled Devices, continued
NetCommand Specialized Device Keys
Refer to this chart when “learning” device keys. See page 67 for more on keys marked in the “Special Operation Method” column.
Key Name in Learning Screen
Power On Power On or Power ON/OFF (toggle)
Guide On-Screen Program Guide or DVD Disc Menus
Channel +/Skip + Next Channel Higher/Skip Forward (Disc)
Channel –/Skip – Next Channel Lower/Skip Backward (Disc) Page Up Page Up in Guides
Page Dn Page Down in Guides
Last Last Channel Recall
Fav Favorites
Menu/Top Menu Menu
Up, Down, Left, Right Arrow up, arrow down, arrow left, arrow right
Enter Enter or Select (menus)
Cancel Cancel or exit (menus)
Info On-screen status display or information display
Play Start playback
Function
Name on TV
Remote
Control
GUIDE
LAST
FAV
TOOLS
, , ,
ENTER
INFO
See Special Op-
eration Method
Table
See TOOLS menu.
Two keypresses
Stop Stop playback
Forward Fast Forward
Rewind Rewind/Fast Reverse
Pause Pause playback
Record Start Recording
1, 2, 3, 4, 5, 6, 7, 8, 9, 0 Digits
Enter (digits) Use after entering digits to tune to a channel by number
- (separator)
On Demand
Setup
Angle
Input
List
Surround
F1
F2
F3
F4
Power Off Power Off
Adds channel separator between digital main and sub-channel numbers
On Demand (Cable/Satellite)
Setup (DVD player)
Angle (DVD player)
VCR
List (Cable/Satellite)
Surround (A/V Receiver)
Assign your
choice of
device-specific
functions.
Digits 0–9
ENTER
TOOLS
TOOLS
TOOLS
TOOLS
TOOLS
TOOLS
F1
F2
F3
F4
See TOOLS menu.
See TOOLS menu.
See TOOLS menu.
See TOOLS menu.
See TOOLS menu.
See TOOLS menu.
For assistance call 1(800) 332-2119
70
6

NetCommand IR Control of an A/V Receiver

NetCommand IR home-theater control is avail­able on 838 series TVs. See the description of NetCommand on “About NetCommand IR Control,” page 64.
Two levels of NetCommand A/V receiver control are available through the Inputs > AVR menu.
• Power and volume. See the opposite page.
• Automatic audio and video switching over
HDMI. See “Setup to Control Automatic Audio and Video Switching via HDMI,” page 73.
Note: To set up control of other device types, see
“Initial NetCommand Setup,” page 66.

Controlling an A/V Receiver after NetCommand Setup

Switching Audio to and from the A/V Receiver
1.
Press
AUDIO.
2.
Press to show the TV Speakers option.
3.
Press to select either On (sound through TV speakers) or Off (sound through A/V receiver).
Controlling A/V Receiver Power
Set up NetCommand control of the A/V receiver’s
POWER
key or keys to enable these methods.
With Any Connection Type
1.
Press
AUDIO.
2.
Press to show the TV Speakers option.
3.
Press to select Off.
4.
While the audio display is still on screen, point the remote control at the TV (not the A/V receiver) and press
POWER
to power the A/V receiver on or off.
With an HDMI Connection
1.
Press
INPUT
.
2.
Highlight the A/V receiver icon.
3.
Press
POWER
.
Controlling Other A/V Receiver Functions
• With the A/V receiver powered on and selected, the TV’s remote control operates the volume and mute functions.
• If you have performed setup to control A/V receiver switching over HDMI, when you switch to a device in the Input Selection menu, the A/V receiver will automatically switch to the correct audio input for the device.
• Press the able only form the Tools menu.
Note: Connect the HDMI cable between the TV
TOOLS
key for functions that may be avail-
and A/V receiver first before performing NetCommand setup for the A/V receiver. If you perform NetCommand setup and then later con­nect the cable, the NetCommand setup will be lost.
For assistance call 1(800) 332-2119
6. NetCommand Control of an A/V Receiver (838 Series) 71

Setting Up A/V Receiver Control

3.

Power and Volume

Perform this setup to control A/V receiver power and volume with the TV’s remote control.
To perform this setup you need:
• The remote controls for both the TV and the A/ V r e ceiver.
• An IR emitter cable available from Mitsubishi.
Before You Begin
1.
Connect your A/V receiver to the TV and any addi­tional devices.
2.
Connect the IR emitter cable to the TV and position the IR emitter where it can send signals to the A/V receiver. See “IR Emitters,” page 65.
3.
Set the TV’s remote control to TV mode.
Setup to Control A/V Receiver Power and Volume
1.
Open the Inputs > AVR menu.
2.
The first function highlighted in the AVR screen is always Power. Aim the TV’s remote control at the TV and press
ENTER
to begin learning for Power.
When the Power text starts flashing, aim the A/V receiver’s remote control at the TV and hold the
POWER
or
POWER ON
next to Power.
• If the text stops flashing before the check mark appears, repeat this step.
• To remove the key from NetCommand control, press the highlighted.
key until a check mark appears
CANCEL
key while the key name is
4. Press the key on the TV’s remote control to highlight
other keys in the list. Repeat steps 2 and 3 for each addi­tional function you wish to control through NetCommand.
5.
If the A/V receiver has a separate press on the TV’s remote to highlight Power Off. Repeat steps 2 and 3 to “learn” the
If the device has no
6.
When finished “learning” the power and volume keys, press NetCommand setup if using an HDMI connection.
See “Automatic Audio/Video Switching Over an HDMI Connection” on the next page
EXIT
POWER OFF
to watch TV or continue
POWER OFF
POWER OFF
key, skip this step.
key,
key.
Inputs > AVR screen. Perform NetCommand IR “learning” for A/V receiver power and volume keys.
For assistance call 1(800) 332-2119
72 6. NetCommand Control of an A/V Receiver (838 Series)
Setting Up A/V Receiver Control, continued

Automatic Audio/Video Switching Over an HDMI Connection

If your A/V receiver has an HDMI output, it may be convenient to send video to the TV over a single HDMI cable through the A/V receiver. The following setup enables the A/V receiver to switch automatically to the correct input when you select a device in the TV’s Input Selection menu. Depending on the capabilities of the A/V receiver, the connected source devices can be analog, digital, or a mixture or the two.
Connections of
any type
HDMI
Cable
TV
Blu-ray player
HDMI
Cable box
DVD player
VCR
Use NetCommand to switch an A/V receiver automatically to the correct audio and video inputs for a device (available only with an HDMI output to the TV as shown).
Output
A/V Receiver
More About Using an HDMI Connection
• Audio from devices connected directly to the TV can be heard from the TV speakers only. To send audio to the A/V receiver from such devices, use one of the optional audio con­nections shown in the diagram on the oppo­site page. For example, use an optional audio connection if you wish to use the A/V receiver speakers to hear audio from:
- The
- A game or camcorder connected directly
• To use NetCommand to supplement HDMI control of a CEC-enabled A/V receiver, the recommended setup sequence is:
1. Connect the HDMI cable.
2. Enable HDMI control (New Device Found
3. Connect the secondary digital audio
4. Perform NetCommand setup.
If you perform A/V receiver NetCommand setup first and then later connect an HDMI cable, the NetCommand setup will be lost.
• In some cases, audio from a device connected to the A/V receiver may not be passed over the HDMI cable to the TV speakers. In these cases you must use the A/V receiver speakers to hear audio.
ANT
input
to the TV.
screen).
cable, if desired.
For assistance call 1(800) 332-2119
6. NetCommand Control of an A/V Receiver (838 Series) 73
Y/ VIDEO
Setting Up A/V Receiver Control, continued
Before You Begin
To complete these steps you will need:
• The remote controls for both the TV and the A/ V r e ceiver.
• An IR emitter cable available from Mitsubishi.
• An HDMI-to-HDMI cable to connect the A/V
receiver to the TV and cables necessary to connect devices to the A/V receiver.
1.
Connect the A/V receiver to the TV with an HDMI­to-HDMI cable. Do not connect the optional audio cable at this time.
2.
If desired, enable HDMI Control of a CEC-enabled A/V receiver. See Appendix C, “HDMI Control of CEC Devices.”
3.
Connect your audio/video devices to the A/V receiver. Note the name of the device connected
DIGITAL
DIGITAL
DVI/PC
AUDIO
Y/ VIDEO
DIGITAL
AUDIO
Y/ VIDEO
AUDIO
OUTPUT
LR INPUT
Pb Pr
Pb Pr
(480i / 480p / 720p / 1080i)
LR
3D
AUDIO
GLASSES
INPUT 2
EMITTER
OUTPUT
INPUT 1
AUDIO
AUDIO
OUTPUT
OUTPUT
HDMI
2
1
3
LAN
AUDIO
OUTPUT
LR
to each A/V receiver input. This information will be needed later to set up NetCommand’s automatic input switching.
4.
If using an optional audio cable between the TV and A/V receiver, connect it. Set up NetCommand control of the A/V receiver’s TV audio input when setting up automatic switching in the next procedure.
5.
Connect the IR emitter cable to the TV and position the IR emitter where it can send signals to the A/V receiver. See “IR Emitters,” page 65.
Setup to Control Automatic Audio and Video Switching via HDMI
When this setup is complete, the “learned” A/V receiver input will appear in the TV’s Input Selection menu as a selectable input.
1.
Set the TV’s remote control to TV mode.
2.
Navigate to the Inputs > AVR menu.
ANT
LR
TV
Optional
HDMI cable
analog or
digital audio
connection
A/V receiver with
HDMI OUT
DIGITAL
AUDIO IN
ANALOG AUDIO IN
LR
HDMI output
Any connection types
VCR
High-definition
DVD player
DVD player
Cable box
Multiple video inputs through a single HDMI cable. The optional audio connection allows you to hear, through the A/V receiver, devices connected to the TV only, e.g., an antenna on the
ANT
input.
To set up A/V switching over HDMI, choose your A/V receiver input from a list.
3.
In the Inputs > AVR menu, highlight the name of the A/V receiver input to control. In this example, it is the DVD input.
4.
Press
ENTER
on the TV’s remote control.
5.
While the text DVD is flashing, press and hold the DVD INPUT
6.
When a check appears next to DVD, release the DVD INPUT
key on the A/V receiver’s remote control.
key.
• If the text stops flashing before the check mark appears, repeat this step.
• To erase the IR code just “learned,” press
CANCEL
7.
If using an optional audio cable between the TV and A/V receiver, “learn” the
while the name is highlighted.
TV AUDIO OUT
automatic switching of audio from sources con­nected to the TV only.
8.
If there are no more devices to set up, highlight
EXIT and press
ENTER
or continue to set up addi-
tional A/V receiver audio/video sources.
key to enable
For assistance call 1(800) 332-2119
74 6. NetCommand Control of an A/V Receiver (838 Series)
Setting Up A/V Receiver Control, continued
NetCommand Control of a Device Con­nected to an HDMI A/V Receiver
Use this setup to have NetCommand control a device sending audio and video through the A/V receiver to the TV via HDMI.
You must have already completed the procedure under “Setup to Control Automatic Audio and Video Switch­ing via HDMI” on the previous page. That procedure placed an icon in the Input Selection menu for the device (input) connected to the A/V receiver.
Source
Device
Any Connection
Type
A/V
Receiver
HDMI Cable
TV
1.
Set up NetCommand control of A/V receiver audio/ video switching via HDMI as described on the pre­vious page.
2.
Press
EXIT
to close any open menus and return to
normal TV viewing.
3.
Press
INPUT
.
4.
Highlight the icon for the device connected to the A/V receiver input you wish to control.
5.
Press
ENTER
to switch the TV to the A/V receiver
and the A/V receiver to the input.
6.
Open the Inputs > Learn menu.
7.
Perform NetCommand “learning” for the con­nected device by following the steps in “Initial NetCommand Setup,” page 66.
For assistance call 1(800) 332-2119

Appendices

Appendix A: Programming the Remote Control ........... 77
Appendix B: Bypassing the Parental Lock .............. 83
Appendix C: HDMI Control of CEC Devices .............. 85
Appendix D: TV Care ........................... 88
Appendix E: Troubleshooting ...................... 91
75
For assistance call 1(800) 332-2119
Appendices 77

Appendix A: Programming the Remote Control

This appendix explains programming the TV’s remote control to operate other A/V devices. This is distinct from NetCommand or HDMI CEC.
Functions Available for Other A/V Devices
The TV’s remote control can be programmed to operate other types and brands of A/V products. The func­tions performed in each device mode vary depending on the product. Not all functions work for all models. The most common functions available are listed on this page.
TV
AUDIO
CAB/SAT DVD
VCR
TV
CAB/SAT DVD
AUDIO
Control modes
To use the remote after programming, press the mode key to match the control mode to the device type.
VCR
VCRs and DVRs
•
CHANNEL UP/DN
•
POWER
•
SLEEP
• (
• (
• (
FAST FORWARD PAUSE PL AY
•
• (
• (
)
)
)
•
•
•
(
RECORD
) REVERSE STOP
)
GUIDE
(DVR only)
MENU
(DVR only)
0–9
Number Buttons
)
Mitsubishi VCRs are compatible with some additional keys.
Cable Boxes and Satellite Receivers
(not all functions for all models)
PAGE UP/DOWN
•
•
CANCEL
•
CHANNEL UP/DN
•
ENTER
•
GUIDE
•
POWER
•
•
LAST (ENTER
; for chan-
The record/playback keys:
• (
• (
• (
• (
• (
• (
FAST FORWARD PAUSE
)
PL AY
) RECORD REVERSE STOP
)
)
)
)
nels on some models)
•
0–9
Number Keys
•
F1–F4
(A, B, C, D keys
on some models)
A/V Receivers
•
•
•
•
•
MUTE POWER SLEEP VOLUME 0–9
Number Buttons
• DirectInputSelection
buttons: numbers and
LAST
(on some
Mitsubishi models)
IMPORTANT
Some manufacturers may change their products or they may use more than one remote control system. The TV’s remote control may be unable to operate your A/V equipment in these cases.
CD Players
(not all functions for all models)
•
SLEEP
• (
• (
• (
FAST FORWARD PAUSE
)
PL AY
)
)
•
• (
•
DVD Players
(not all functions for all models)
•
CANCEL
models)
•
CHANNEL UP/DN
track skip on some models)
•
ENTER
•
MENU
•
POWER
•
SLEEP
(on some
(for
• (
• (
• (
• (
• (
• (
•
•
(
REVERSE STOP
)
0–9
Number Buttons
FAST FORWARD PAUSE
)
PL AY
) RECORD
) REVERSE STOP
)
0-9
Number Keys
)
)
)
For assistance call 1(800) 332-2119
78 Appendices
Appendix A: Programming the Remote Control, continued
Programming the Remote Control
1.
Press one of the upper buttons on the remote control to change to the correct mode for the product you want to control. Refer to the table below. Only one of each device type can be con­trolled in each mode.
Mode Affected Device
CA B/SAT
VCR
DVD
AUDIO
2.
Press and hold several seconds until the key flashes twice and goes off.
3.
Release the
4.
Enter the first five-digit code listed for your equip­ment in the reference tables that follow.
If you need to start over or wish to exit programming mode, temporarily change to a different device mode.
5.
Point the remote control at the equipment and press
POWER
function, press a different key, such as (
(
STOP
),
• If the equipment responds, the remote control is properly programmed.
• If the equipment does not respond, repeat steps 4 and 5 with the next five-digit code listed for your equipment.
6.
Once you have found the correct code, write it in the space below for future reference.
Mode
CA BLE /SAT
VCR
DVD
Cable Box DTV Receiver Satellite Receiver
VCR DVR DVD Player/Recorder
DVD Player/Recorder DVR VCR
A/V Receiver Audio Amplifier CD Player
POWER
on the remote control for
POWER
key.
. If the product has no power on/off
VOLUME UP
, or
MUTE.
Device Type Code
PL AY
),
IMPORTANT
You may need to reprogram the remote control after changing the batteries. Record the codes for each
mode in the space provided to make this faster.
Code Verification
To determine the code programmed for any mode:
1.
Set the mode to the one you wish to verify.
2.
Press and hold several seconds until the off.
3.
Press keys
4.
Press 1 and count the flashes of the power key. Write down the number of flashes as the first digit of the code.
5.
Repeat step 4 for the other digits of the code. Press 2 to see flashes for the second digit, press 3 for the third digit, 4 for the fourth digit, and 5 for the fifth digit.
POWER
9 9 0
on the remote control for
key
flashes twice and goes
Audio Lock: Universal A/V Receiver Control
With Audio Lock enabled, the remote control oper­ates volume and mute on an A/V receiver in all control modes. Activate Audio Lock if you always use an A/V receiver with your TV and other A/V equipment.
1.
Program described in “Programming the Remote Control” on this page.
2.
With the remote control in on the remote control for several seconds until the key flashes twice and goes off.
3.
Press keys The
Lock is active.
To Reset the Remote Control to Operate Volume and Mute for the TV Speakers
1.
Press and hold flashes twice and goes off.
2.
Press keys The
Lock has cleared.
AUDIO
mode for your A/V receiver as
AUDIO
mode, hold
9 9 3 ENTER
POWER
key will flash twice to indicate Audio
POWER
for several seconds until it
9 9 3 VOLUME UP
POWER
key will flash four times to indicate Audio
.
POWER
AUDIO
For assistance call 1(800) 332-2119
Appendices 79
Appendix A: Programming the Remote Control, continued
Audio Amplifiers
Altec Lansing Anthem 42220 Bel Canto Design Cary Audio Design Classe 41461 Denon 42134 Durabrand 41561 Flextronics 41879 Halcro 41934 Harman/ Kardon Krell 42463, 418 37 Left Coast 40892 Lenoxx 41561 Lexicon 41802, 41145 Marantz 42138, 40892 Mark Levinson Parasound 42245, 41934 Philips 40892 Polk Audio 42242, 40892
Cable Boxes
Amino 11822, 116 0 2 Bright House 11877, 11376 Cable One 11877, 113 76 Cablevision 1187 7, 11376 Charter 1218 7, 1187 7, 113 76 Cisco 11982, 11877, 10877 Comcast 12576, 11982, 11877,
Cox 1187 7, 11376 Digeo 1218 7, 11187 Director 10476 General Instrument
Homecast 12301 i3 Micro 116 02 Insight 11877, 11376 Jerrold 10476 Knology 11877 Mediacom 11877, 11376 Motorola 11376, 11187, 10 476 Myrio 118 22, 116 02 Pace 119 82, 1187 7, 11376 Panasonic 119 8 2 Pioneer 11877, 10877 RCN 11376
41742
41583
41879
40892
42405, 414 8 3
11376
10476
Cable Boxes
Rogers 11877 Scientific Atlanta
Sejin 1160 2 Shaw 11376 Sony 110 06 Suddenlink 1187 7, 11376 Time Warner 12 1 8 7, 11877, 113 7 6 Tivo 12576
CD Players
Burmester 40420 California Audio Labs
DKK 40000 Garrard 40420 Harman/ Kardon
Integra 40101 JVC 4129 4, 40072 Kenwood 40626, 40028 KLH 41318 Koss 41317 LG 4120 8 Magnavox 40038 Marantz 40626, 40038, 40029 McIntosh 4170 3 MCS 40029 MGA 40083 Miro 40000 Mitsubishi 40098, 40083 MTC 40420 NAD 41208 Onkyo 41327, 40101 Optimus 40420, 40000 Panasonic 40752, 40388, 40029 Parasound 40420 Philips 40626 Pioneer 41087 Proceed 40420 Quasar 40029 RCA 40420, 40053 Realistic 40420 Rotel 40420 Sherwood 41950 Sony 41364, 40490, 40185,
Tascam 40420 TDK 41208 Teac 40420 Technics 40029
11877, 10877
40029
41202, 40173, 40083
40100, 40000
CD Players
Victor 40072 Wards 40053 Yamaha 41292, 40490, 40036
Audio Accessories
Apple 41115 Denon 42502 Vizio 42454 Yamaha 42458
Video Accessories
ADB 12586, 12254 Amino 12482, 11673, 11615,
114 81
AT&T 10858 Cisco 12517, 12345 KoolConnect 114 8 1 Motorola 12378, 10858 Scientific Atlanta
SureWest 114 81 Verizon 12378
A/V Receivers
Aiwa 41641, 41405, 41388 Alco 4139 0 AMC 41077 Anam 41609 Arcam 4118 9 Audiotronic 4118 9 Audiovox 41390 B & K 40820 Bose 41933, 41841, 41629,
Carver 41189 Denon 42857, 42279 Electrohome 42026 Harman/ Kardon
iLive 42013 Insignia 42175, 42169, 41893,
Integra 418 0 5, 41320, 41298 iSymphony 42258, 42018 JBL 41306 JVC 42331, 42239, 42040,
Kenwood 41570, 4156 9, 41313 KLH 41428, 41412, 4139 0 LG 42284, 42197, 41293 Magnavox 41514, 41269, 41189
12517, 12345, 10858
4125 3, 41229, 40639
42443, 42241, 41306, 41304, 40891
41077, 41030
4149 5, 41374
For assistance call 1(800) 332-2119
80 Appendices
Appendix A: Programming the Remote Control, continued
A/V Receivers
Marantz 42114, 41289, 41269,
41189
McIntosh 41289 Micromega 41189 Mitsubishi 41957, 41922, 419 21,
41920, 41393
Myryad 41189 Nakamichi 41313 Onkyo 418 0 5, 41531, 413 20,
41298, 40842
Optimus 41023 Panasonic 41763, 41633, 41548,
41518, 41316, 41308, 41288, 41275, 42967, 42452, 42221, 41764
Philips 42470, 42459, 42311,
41269, 41266, 41189, 40891
Pioneer 41935, 41384, 41023,
40630
Polk Audio 42270, 4128 9 Proscan 41254 RCA 420 41, 41609, 41511,
41390, 41254, 41023
Samsung 41868, 41500, 41304,
41295
Sherwood 42169, 41905, 41653,
41077 Sherwood Newcastle Sony 41759, 41758, 41658,
Stereophonics Sunfire 41313 Teac 41390 Technics 41518, 41308 Thorens 4118 9 Toshiba 4178 8 Venturer 4139 0 Yamaha 41476, 41376, 41375,
Zenith 41293
Satellite Receivers
Bell ExpressVu Crossdigital 11109
42169
41622, 41558, 41441,
41258, 41058, 42522,
42216, 42172, 41858,
41822
41023
41331, 41276, 41176,
40376, 40176, 42471,
42467, 42061, 41815
10775
Satellite Receivers
DirecT V 11749, 11377, 1114 2 ,
10749, 10639, 10566, 10392, 10247, 1856, 116 09, 11442, 11414 ,
1110 9, 110 7 6 Dish Network Syste m Dishpro 11775, 1150 5 , 107 75
Echostar 11775, 11505 , 10775 Expressvu 11775, 10775 GE 10566 General Instrument
GOI 11775, 10775 HTS 11775, 10775 Hughes Network Systems
Jerrold 10869 JVC 11775, 10775 LG 11414 Mitsubishi 1074 9 Motorola 10869 Next Level 10869 Panasonic 10701, 10247 Philips 1174 9 , 114 4 2 , 11142,
Proscan 10566, 10392 RadioShack 10869 RCA 10566, 10392, 10143 Samsung 1160 9 , 114 4 2 , 11377,
Sony 10639 Star Choice 10869 Tivo 1144 2, 11142 Toshiba 11749, 10790, 10749 Voom 10869 Zenith 118 56
VCRs
ABS 21972 Accurian 20000 Admiral 20048 Adventura 20000 Aiko 20278 Aiwa 20037, 20000 Alienware 21972 Allegro 20039 America Action
American High
11775, 1150 5 , 107 7 5
10869
11749, 11442, 11142,
10749
11076, 10749
11276, 1110 9
20278
20035
VCRs
Audiovox 20278, 20037 Calix 20037 Canon 20035 Carver 20081 CCE 20278 Citizen 20278, 20037 Craig 20037 Crosley 20081, 20000 Curtis Mathes
CyberPower 21972 Daewoo 20278, 20045 Dell 21972 Denon 20042 DirecT V 20739 Durabrand 20039, 20038 Dynatech 20000 Electrohome 20043, 20037 Electrophonic Emerex 20032 Emerson 21593, 20593, 20278,
Fuji 20035, 20033 Funai 21593, 20593, 20000 Garrard 20000 Gateway 21972 GE 20060, 20035 GFM 21593 Go Video 20 614 GoldStar 20038, 20037 Gradiente 20000 Harley Davidson
Harman/ Kardon Headquarter 20046 Hewlett Packard Hitachi 20042, 20000 Howard Computers HP 21972 Hughes Network Systems Humax 20739 Hush 21972 iBUYPOWER 21972 Instant Replay JVC 20067 KEC 20278, 20037 Kenwood 20067, 20038
20278, 20162, 20060, 20035
20037
20043, 20037, 20000
20000
20081, 20038
21972
21972
20739, 20042
20035
For assistance call 1(800) 332-2119
Appendices 81
Appendix A: Programming the Remote Control, continued
VCRs
Kodak 20037, 20035 Linksys 21972 Lloyd’s 20000 LXI 20037 Magnasonic 20593 Magnavox 21593, 20593, 20081,
20039, 20035, 20000
Marantz 20081, 20035 Marta 20037 Matsushita 20162, 20035 Media Center PC
MEI 20035 Memorex 20162, 20048, 20046,
MGA 20043 Microsoft 21972 Mind 21972 Minolta 20042 Mitsubishi 20173, 20067, 20043 Motorola 20048, 20035 MTC 20000 Multitech 20000 NEC 20067, 20038 Nikko 20037 Niveus Media
Northgate 21972 Olympus 20035 Optimus 21062, 20593, 20162,
Panasonic 21062, 20616, 20614,
Penney 20042, 20038, 20037,
Pentax 20042 Philco 20035 Philips 21181, 21081, 20739,
Pilot 20037 Pioneer 20067 Polk Audio 20081 Portland 20278 Presidian 21593 Proscan 20060 Pulsar 20039 Quarter 20046 Quartz 20046 Quasar 20162, 20035 RadioShack 20000 Radix 20037 Randex 20037
21972
20039, 20037, 20035, 20000
21972
20048, 20037
20162, 20035
20035
20618, 20081, 20035
VCRs
RCA 20880, 20060, 20042 Realistic 20048, 20046, 20037,
20035, 20000
ReplayTV 20616, 20614 Ricavision 21972 Runco 20039 Samsung 20739, 20045 Sanky 20048, 20039 Sansui 20067, 20000 Sanyo 20046 Scott 20045, 20043 Sears 20046, 20042, 20037,
20035, 20000
Sharp 20848, 20048 Sonic Blue 20616, 20614 Sony 21972, 21032, 20636,
20035, 20033, 20032, 20000
Stack 9 21972 STS 20042 Sylvania 21593, 20593, 20081,
20043, 20035, 20000
Symphonic 21593, 20593, 20000 Systemax 21972 Tagar Systems
Tashiko 20037 Teac 20000 Technics 20162, 20035 Teknika 20037, 20035, 20000 Thomas 20000 Tivo 20739, 20636, 20618 Toshiba 21972, 21008, 20045,
Totevision 20037 Touch 21972 Vector 20045 Vector Research
Video Con­cepts Videomagic 20037 Viewsonic 21972 Villain 20000 Voodoo 21972 Wards
XR-1000 20035, 20000 Yamaha 20038 Zenith 21139, 20039, 20037,
ZT Group 21972
21972
20043
20038
20045
20081, 20060, 20048, 20042, 20035, 20000
20033, 20000
DVD Players
Accurian 30675 Adcom 31094 Aiwa 30641 Akai 31089, 30770, 30695 Alco 30790 Allegro 30869 Apex Digital 31061, 31056, 31020,
31004, 30797, 30796, 30794, 30755, 30672
Arrgo 31023 Astar 31489 Audiovox 31041, 30790 B & K 30662 BBK 31224 Bel Canto Design
Blue Parade 30571 Broksonic 30695 California Audio Labs
Cinea 30831 CineVision 30869, 30833 Citizen 32116, 31587, 31277,
Coby 31628, 31351, 31177,
Craig 30831 Curtis Mathes
CyberHome 31537, 31502, 31129,
Daewoo 31172, 31169, 30869,
Denon 32258, 30634, 30490 Disney 31270, 30675 Durabrand 31127, 31023 DVD2000 30521 Electrohome 32116 Emerson 30675, 30591 Enterprise 30591 Fisher 30670 Funai 30675 Gateway 31077 GE 30815, 30522 GFM 30675 Go Video 31075, 31044, 30869,
GoldStar 30869, 30741 Grundig 30539
31571
30490
30695
31165, 31107, 31086, 30852, 30778
31087
31024, 31023, 30874, 30816
30833, 30784
30833, 30744, 30741, 30715
For assistance call 1(800) 332-2119
82 Appendices
Appendix A: Programming the Remote Control, continued
DVD Players
Harman/ Kardon Helios 32192, 32080 Hello Kitty 30831 Hitachi 30664, 30573 Hiteker 30672 Humax 31588, 31500 iLo 31472, 31348 Initial 31472 Insignia 32596, 32428, 32095,
Integra 32147, 31769, 30627,
JBL 30702 JVC 32365, 31602, 31550,
jWin 31049 Kawasaki 30790 Kenwood 30534, 30490 KLH 31020, 30790 Lenoxx 31127 LG 31602, 30869, 30741,
LiteOn 31656, 31058 Magnavox 31506, 31472, 31354,
Marantz 32414, 30539 McIntosh 31273 Memorex 32213, 31270, 30831,
Microsoft 32083, 30522 Mintek 31472 Mitsubishi 31521, 30521 Myryad 30894 NAD 32572, 30741 Norcent 31107, 31003 Olevia 32331 Onkyo 32147, 31769, 30627,
Oppo 32545, 32185, 31224,
Panasonic 31762, 31641, 31579,
Philco 30675 Philips
PianoDisc 31024
31229, 30702, 30582
30675
30571
31275, 31164, 30867, 30623, 30558
30591
31177, 30675, 30646, 30539, 30503
30695
30503
30575
30703, 30632, 30503, 30490
32084, 32056, 31340,, 31267, 30675, 30646, 30539, 30503, 31506, 31354
32434,
DVD Players
Pioneer 31571, 31512, 31460,
30632, 30631, 30571, 30525, 30142
32442 Polaroid 31086, 31061, 31020 Polk Audio 30539 Portland 30770 Presidian 30675 Proceed 30672 Proscan 30522 ProVision 30778 RCA 32213, 31769, 30822,
30790, 30571, 30522 Rio 30869
Rotel 31178, 30623 Sampo 30752 Samsung 32069, 31470, 31075,
31044, 30820, 30573,
30490, 30199
32556, 32489, 32369,
32329 Sansui 30695
Sanyo 30873, 30695, 30670 Schneider 30646 Sharp 32250, 31256, 30752,
30675, 30630 Sherwood 31077, 31043, 30770,
30633 Sherwood Newcastle Shinsonic 30533
Sonic Blue 30869 Sony 31633, 31536, 31516,
Sylvania 30675 Symphonic 30675 TAG McLaren
Teac 30790 Technics 30703, 30490 Theta Digital 30571 Tivo 31512, 31503 Toshiba 31769, 31588, 31515,
Urban Con­cepts Venturer 30790 Vizio 32563, 31226, 31064 Xbox 32083, 30522
31077
31431, 31070, 31033,
30864, 30533
30894
31510, 31503, 31154,
30695, 30503
32277, 32006, 31608
30503
DVD Players
Yamaha 32558, 32298, 30817,
30646, 30545, 30539, 30490
Zenith 30869, 30741, 30591,
30503
Blu-ray and HD-DVD
Denon 32258 Insignia 32596, 32428, 30675 Integra 32147, 31769 JVC 32365 LG 3160 2, 3 0 741 Magnavox 30675 Marantz 32414 Microsoft 32083 NAD 32572 Olevia 32331 Onkyo 32147, 31769 Oppo 32545 Panasonic 31641 Philips 32434, 32084 Pioneer 32442, 30142 RCA 3176 9 Samsung 30199 Sharp 32250 Sony 31516 Sylvania 30675 Toshiba 31769, 31515 Vizio 32563 Xbox 32083 Yamaha 32298
For assistance call 1(800) 332-2119
Appendices 83

Appendix B: Bypassing the Parental Lock

Mitsubishi Home Theater TV
738 Series 838 Series
Bypassing the Parental Lock
After you set the lock, you must use your pass code to:
• View a locked program
• View a locked channel
• View the locked TV
• Cancel the lock
• Enter the Lock menus
If you forget your pass code, you can view the locked TV without entering your pass code. When prompted for the pass code, press the number 9 and the TV remote control at the same time. This process temporarily unlocks the TV.
When entering the Lock menu, you will be prompted to enter a pass code.
• Tochangethepasscode,press9 and
same time. Either enter a new pass code to open the Lock menu and make changes or press close the menu.
LAST
LAST
keys on
at the
EXIT
to
Lock Bypass Instructions Have Been Filed for
Future Reference
IMPORTANT
Cut along the dotted line and file bypass instructions in a safe place for future reference.
• Ifanyofthelocksareturnedonandyouexitthe
menus when prompted for a new code, the old code and all lock settings will be retained.
• Ifalllocksareturnedoffandyouexitthemenus
when prompted for a new code, then the previous code will be erased.
IMPORTANT
When changing or deleting your pass code, you must use the remote control included with this TV. You cannot use a Mitsubishi remote control from another component or a “universal” remote.
For assistance call 1(800) 332-2119
84 Appendices
This page intentionally left blank
For assistance call 1(800) 332-2119
Appendices 85

Appendix C: HDMI Control of CEC Devices

Many new HDMI devices have a feature called Con­sumer Electronics Control (CEC) or HDMI Control. HDMI Control allows one device, such as the TV, to control other devices, such as an A/V receiver or disc player. Use of CEC is optional.
Each manufacturer chooses which CEC functions to support so it is difficult to predict which devices and features are compatible with Mitsubishi’s HDMI Control. You may find that CEC functions for a specific device are limited.
To use HDMI Control, you must enable it in both the TV and the device.
• In the TV. Enable HDMI control from the New
Device Found screen or from the Inputs > HDMI Control menu.
• I
n the Device. Most devices with HDMI CEC com-
patibility let you turn it on or off in the device menus, where it is typically listed as “HDMI Control.”
Enabling HDMI Control of CEC Devices
To ensure proper detection
• Power on HDMI devices before connecting them to th e T V.
• Connect and set up HDMI devices one at a time.
1.
Power on the device and allow it to complete the power-on sequence (boot up). Stop any playback.
2.
Connect the device to one of the TV’s HDMI inputs.
3.
When the TV detects the connection, the New Device Found screen will appear.
Note: See “If the New Device Found Screen Has No
HDMI Control Option” on this page if there is no HDMI Control option.
New Device Found screen with HDMI Control option. This screen displays only if the device’s HDMI Control is enabled
.
4.
If prompted for a name, highlight a name for the device and press add a check. The device itself may later override the name assigned.
5.
Highlight On and press ENTER
to add a check.
7.
Highlight EXIT and press Device Found screen.
Note: At any time after completing Auto Input Sens-
ing, you can set the TV’s HDMI control on or off in the Inputs > HDMI Control menu.
8.
838 Series. To supplement HDMI control with NetCommand IR control, see page 64.
ENTER
to
ENTER
to close the New
If the New Device Found Screen Has No HDMI Control Option
If the New Device Found screen shows no option for HDMI Control, one of these conditions applies:
• HDMI Control is turned off in the menus of the new device
Action:
a. Highlight EXIT and press
New Device Found screen.
b. Display the device’s setup menus and enable
the device’s CEC capabilities.
c. Wait for the TV’s New Device Found screen
to appear again.
d. If the New Device Found screen does not
appear, power off the device. Power on the device and wait for the New Device Found screen to display with the HDMI Control option.
• The HDMI cable cannot support CEC Action:
Upgrade your HDMI cable to one that supports CEC.
• The device does not have CEC compatibility Action:
- Control the device with its own remote control or program the TV’s remote control to operate the device.
- 838 Series. Use the TV’s NetCommand IR control (page 64).
ENTER
to close the
For assistance call 1(800) 332-2119
86 Appendices
Y/ VIDEO
Appendix C: HDMI Control of CEC Devices, continued
HDMI Control of an HDMI A/V Receiver and Connected Devices
Note: Connect the A/V receiver to the TV with an
HDMI cable before making other connections.
1.
Enable HDMI Control for the A/V receiver as described in “Enabling HDMI Control of CEC Devices” on the previous page.
2.
Power on the HDMI device you wish to connect to the A/V receiver (such as a disc player, cable box, or satellite receiver). Allow the device to complete the power-on sequence (boot up). Stop playback if the device starts playing.
3.
Connect the device to the A/V receiver with an HDMI cable.
4.
Select the device’s HDMI input on the A/V receiv­er’s front panel controls or remote control.
5.
When the TV detects the connection, the New Device Found screen will appear.
1
TV
HDMI
2
3
HDMI cable
DIGITAL
DIGITAL
DVI/PC
AUDIO
Y/ VIDEO
DIGITAL
OUTPUT
Y/ VIDEO
LR INPUT
Pb Pr
AUDIO
Pb Pr
(480i / 480p / 720p / 1080i)
AUDIO
OUTPUT
AUDIO
AUDIO OUTPUT
OUTPUT
LAN
LR
AUDIO
ANT
LR
3D
GLASSES
INPUT 2
EMITTER
INPUT 1
Optional analog or digital audio connection
Note: If the TV is unable to detect the device, either
the device’s CEC capability is not enabled or the device is not CEC compatible. Enable HDMI control through the device’s menus before continuing. You may need to temporar­ily connect the device directly to the TV to view device menus.
6.
Highlight On and press
ENTER
to
add a check.
7.
Highlight EXIT and press
ENTER
to close the New
Device Found screen.
8.
Optional: Connect the TV’s
OUTPUT
to an input on the A/V receiver. Use this
DIGITAL AUDIO
additional connection if:
• You want the ability to switch between the A/V receiver speakers and the TV speakers.
• You want to use the A/V receiver to listen to devices connected to the TV only, e.g., an antenna input or camcorder.
A/V receiver with
HDMI OUT
DIGITAL
AUDIO IN
HDMI output
Any connection
types
VCR
High-definition
DVD player
DVD player
Cable box
Connecting HDMI devices. The optional digital audio connection allows you to hear audio through the A/V receiver from devices connected to the TV only.
9.
838 Series. If desired, perform NetCommand IR Learning to supplement CEC functions. You must first connect and place IR emitters for the devices. See page 64.
For assistance call 1(800) 332-2119
Appendices 87
Appendix C: HDMI Control of CEC Devices, continued
Resolving CEC Conflicts
Because each manufacturer selects which CEC func­tions to support, some devices can conflict with other devices. If control conflicts arise, you can:
• Turn off TV control of an individual CEC-enabled device (see below).
• Turn off CEC in the setup menu of one of the devices.
Turning Off the TV’s HDMI Control of a CEC Device
1.
Press
MENU
on the TV remote control.
2.
Highlight Inputs > HDMI Control.
3.
Move to the device name and press Off to turn off the TV’s ability to control the device.
4.
Press
EXIT
to clear the menu.
Inputs > HDMI Control menu
Removing an HDMI Device
1.
Power off the device.
2.
Disconnect the HDMI cable.
3.
Press
MENU
on the TV remote control to enter the
TV main menu.
4.
Go to Inputs > Name.
5.
Highlight the HDMI input name and press select Delete.
6.
Press
EXIT
to clear the menus.
ENTER
to select
ENTER
to
Using HDMI Control
As an example of using HDMI Control, press the device itself to:
• Power on the TV
• Switch to the device (no need to display the
Input Selection menu)
• Begin play of the device
Direct Keys
Test your equipment with the TV’s remote control to find additional supported commands. See the table below for commands that may be available, depending on the individual device.
CEC-enabled VCR, DVD, and DVR functions that may be available:
Record/
Playback
If you have a CEC-enabled A/V receiver, CEC-enabled devices connected to the A/V receiver with an HDMI cable may also be controllable. They can be selected from the TV’s Input Selection menu.
CEC-enabled A/V receiver functions that may be available:
• Try the
• To open the A/V receiver menu, follow these steps:
1. While watching TV, press
2. Press until the TV Speakers option displays.
3. Press to select Off (to send audio to the A/V
receiver).
4. Press
in the Input Selection menu.
5. Press
6. Select Menu from the Tools menu.
Menu
Navigation
ENTER
CANCEL
(to cancel)
VOL, MUTE
INPUT
and highlight the A/V receiver icon
TOOLS
.
Channel
Tuning
CH GUIDE
Digits
0–9
,
CANCEL
, and menu-navigation keys.
ENTER
AUDIO
PL AY
on
Other
TOOLS
Check the TOOLS menu for supported functions.
.
Inputs > Name menu with Delete selected for HDMI-3.
For assistance call 1(800) 332-2119
88 Appendices

Appendix D: TV Care

Lamp-Cartridge Replacement

CAUTION: If the television is on, press POWER to turn it off. Unplug the television and allow it to cool for at least one hour before attempting to replace the lamp cartridge.
Lamp
The light source for this television is a lamp, which is part of a lamp cartridge assembly. The life of the lamp can vary, based on the lamp itself, the air temperature around the TV while it is operating, the selected lamp mode, and your viewing patterns. Warmer air or poor ventilation shorten the lamp life, as does setting and turning the television on and off frequently.
Mitsubishi warrants the lamp for one (1) year from the date of original TV purchase at retail.
To Order a New Lamp
To Receive a Replacement Lamp Under Warranty
• Visit our website at www.mitsuparts.com.
• Call (800) 553-7278. Please have model number, serial number,
To Purchase a Replacement Lamp After Warranty
Visit our website at www.mitsuparts.com or call (800) 553-7278. Order the following:
Lamp Energy
and TV purchase date available.
to
Bright
tridge housing. Keep lamp cartridge horizontal during removal. Do
BURN DANGER! HOT SURFACES INSIDE!
Touch lamp cartridge handle only. Do not touch lamp or lamp car-
not tilt as glass may come out and cause injury. Replace lamp car-
tridge only with the same part number 915B441001.
CAUTION
WARNING
THE ACCESS PANEL IS PROVIDED WITH AN INTERLOCK TO REDUCE THE RISK OF EXCESSIVE ULTRAVIOLET RADIATION. DO NOT DEFEAT ITS PURPOSE OR ATTEMPT TO SERVICE WITHOUT REMOVING PANEL COMPLETELY.
Lamp Part Number 915B441001
Lamp-Substitution Alert
MDEA recommends that you use only genuine Replacement Lamp Assemblies purchased directly from Mitsubishi or a Mitsubishi Authorized Dealer or Mitsubishi Authorized Service Center. MDEA advises that replacement lamps obtained separately from the Lamp Cartridge and/or Lamp Assemblies obtained from unauthorized sellers may be incorrect for your television, may not fit or perform properly and may even damage your television. MDEA can not be responsible for the performance, reliability or safety of any replacement lamps that are obtained from unauthorized sources.
WARNING
• Donotremovethelampcartridgeimmediatelyafterturningoffthetelevision.Youmaygetburnedbecausethe
lamp is very hot. Allow the television to cool for at least one hour before replacing the lamp cartridge.
• Donotremovethelampcartridgeexceptwhenreplacingit.Carelesstreatmentcanresultininjuryorfire.
• Donottouchthelampglasselement.Itmaybeveryhotandbreak,causinginjuriesorburns.
•
Be sure not to insert any metal or flammable object into the lamp cartridge opening, as it may cause fire or electrical shock. If a foreign object is inserted into the opening, unplug the AC cord of the TV and contact your dealer for service.
• Installthelampcartridgesecurely.Failuretodosomaycauseafire.
• Donottouchthelampglasselements.Oilsfromyourfingersmaycauseprematurelampfailure.
THE LAMP INSIDE THIS PRODUCT CONTAINS MERCURY AND MUST BE RECYCLED OR DIS-
Hg
= MERCURY
POSED OF ACCORDING TO LOCAL, STATE OR FEDERAL LAWS. For disposal or recycling infor­mation, please contact your local authorities or the Electronic Industries Alliance at www.eiae.org
For assistance call 1(800) 332-2119
Appendices 89
Appendix D: TV Care, continued
Lamp-Cartridge Replacement
Removing the Old Lamp Cartridge
1.
Turn off TV power and unplug the TV. Allow the lamp to cool for at least one hour before proceed­ing.
2.
After the lamp has cooled, remove the cover of the lamp compartment, located on the back of the TV.
Refer to figures 1 and 2. Use a #2 (medium) Phillips screwdriver to loosen the screw securing the cover. Keep the screw and cover for re-installation
3.
Wi
th a medium Phillips screwdriver, loosen the two screws securing the lamp cartridge until they dis­engage from the mating threads. These are captive screws and cannot be separated from the lamp cartridge.
4.
Fully open the bag supplied with the replacement lamp and set the opened bag aside.
5.
Gently grasp the handle of the lamp cartridge and pull the old cartridge straight out. See figure 3.
CAUTION: Do not tilt or rotate the cartridge, as small glass fragments may fall out.
6.
Without tilting or putting down the lamp cartridge, insert it into the opened bag. Close the bag while being careful not to let any glass particles fall out.
Installing the New Lamp Cartridge
1.
Do not touch the glass parts of the new lamp car­tridge. Insert the new cartridge into the TV in the same orientation as the old cartridge. Push on the cartridge housing until it is fully seated.
2.
Gently tighten the screws with the screwdriver. AVOID OVERTIGHTENING!
3.
Replace the plastic cover and retaining screws.
4.
WASH YOUR HANDS THOROUGHLY, AS THIS LAMP CONTAINS MERCURY.
Figure 2
Figure 3
Use only replacement lamp part number
915B441001.
Disposal of the Old Lamp Cartridge
Contact your local authorities or the Electronic Indus­tries Alliance at www.eiae.org for lamp-disposal or recycling instructions. Do not dispose of the old lamp with common trash.
Figure 1
For assistance call 1(800) 332-2119
90 Appendices
Appendix D: TV Care, continued

Cleaning Recommendations

Normally, light dusting with a dry, non-scratching duster will keep your TV clean. If cleaning beyond this is needed, please use the following guidelines:
First, turn off the TV and unplug the power cord from the power outlet.
Occasionally clean dust build-up from the air-intake grilles on the back and sides of the TV. Clean using a vacuum cleaner with a brush attachment.
Top and Sides of the TV
• Gently wipe down your TV with a soft, non-abrasive cloth such as cotton flannel, microfiber, or a clean cloth diaper, lightly moistened with water. Dry with a second dry, soft, non-abrasive cloth.
• For oily dirt, add a few drops of mild liquid deter­gent, such as dishwashing detergent, to the water used to moisten the cloth. Rinse with a second cloth moistened only with water. Dry with a third dry, soft, non-abrasive cloth.
Screen

Care of the Remote Control

Remote Control Tips
• For longer life, use alkaline batteries.
• Do not mix old and new batteries.
• Be within 20 feet of the equipment.
• Do not press two or more keys at the same time
unless instructed to do so.
• Do not allow the unit to get wet or become heated.
• Keep the unit out of direct sunlight.
• Avoid dropping on hard surfaces.
• Do not use harsh chemicals to clean. Use only a
soft, lightly moistened cloth.
Resetting the Remote Control
If TV mode is selected and the TV does not respond properly, reset the remote control.
1.
Press and hold indicator flashes twice and goes off.
2.
Release the
3.
Press keys twice when you finish entering the code. When entering the code, pause for a moment between each key press to ensure it is recognized.
Low-Battery Indicator
If you press a key and the indicator flashes five times, replace the remote control’s batteries.
POWER
for several seconds until the
POWER
key.
0 0 9 3 5
and the indicator will flash
• Follow the instructions for the top and sides, wiping gently in an up and down motion.
• Clean the entire screen evenly, not just sections of the screen.
• Do not allow liquid to drip down the screen, as some liquid may enter the TV through the gap between the screen and screen frame.
• You may purchase Mitsubishi Screen Cleaner, part number CLEANER-VSS, by calling (800) 553-7278.
General Cleaning Precautions
• DO NOT allow liquid to enter the TV through the ventilation slots or any crevice.
• DO NOT use any strong or abrasive cleaners, as these can scratch the surfaces.
• DO NOT use any cleaners containing ammonia, bleach, alcohol, benzene, or thinners, as these can dull the surfaces.
• DO NOT spray liquids or cleaners directly on the
TV’s surfaces.
• DO NOT scrub or rub the TV harshly. Wipe it gently.
For assistance call 1(800) 332-2119
Appendices 91

Appendix E: Troubleshooting

TV Reset Comparison Guide
You can resolve many common TV problems using the reset functions described in the following table. See also the troubleshooting suggestions later in this appendix.
IMPORTANT Before you change sound or picture settings: If
picture or sound settings seem wrong for a broadcast
Reset Name When to Use How to Use Resulting Action
Press
Format If the picture shape
seems incorrect, use
PerfectColor™/ PerfecTint™ Reset (838 Series)
(for the single input currently being watched)
FO RMAT
the change the shape of the picture.
When the color intensities seem out of balance, use the PerfectColor/PerfecTint reset to reset the color balances to the original factory settings. Both PerfectColor and PerfecTint are reset at the same time.
key to
FO RMAT
aspect ratios available for the signal.
1. While viewing the input being
reset, press
Picture > Perfect.
2. Press
PerfectColor adjustment screen.
3. Press
channel (a channel from the satellite receiver), first check other channels from the same input before changing settings. If most other channels from the same input seem correct, there is likely a problem with the broadcast rather than with the TV. Use care in this case, as changes you make to fix problems on individual channels also affect all other channels on the same input.
to cycle through the
MENU
and go to
ENTER
to display the
CANCEL
to reset the colors.
ANT
input, a cable box, or
The last-used format for a signal type is memorized for each input. The next time the same input and signal type are viewed, the last­used format will be recalled.
All PerfectColor/PerfecTint sliders are reset to the original center position. The PefectColor/ PerfecTint settings for other inputs remain unchanged.
A/V Memory Reset
(for the single current input)
When audio and/ or video settings for a single input seem incorrect, use A/V Memory Reset to return the input to the original factory settings.
During General TV Viewing
1. While viewing the input to reset,
press
Reset.
2. Press
3. Press
While Using VUDU Movies and Some VUDU Apps
Press
TOOLS
Service and Customer Support
Service
If you are unable to correct a problem with your TV, consult your Mitsubishi dealer or Mitsubishi Consumer Relations at (800) 332-2119.
• DONOTadjustanycontrolsotherthanthose
described in this Owner’s Guide.
• DONOTremovetheprotectivebackcoverofyour
TV.
All Audio and Video settings for the individual input are reset
MENU
and go to Picture >
ENTER
to highlight Reset.
ENTER
again to reset.
and 3.
Customer Support
• Toorderreplacementoradditionalremotecon­trols or lamp cart www.mitsuparts.com or call (800) 553-7278.
• Forquestions:
Call Consumer Relations at 800-332-2119. E-mail: MDEAservice@mdea.com Website: www.mitsubishi-tv.com
except for the global settings for audio Balance, Listen To, Language, and settings in the Picture > Advanced menu.
ridges,
visit our website at
For assistance call 1(800) 332-2119
92 Appendices
Appendix E: Troubleshooting, continued
Reset Name When to Use How to Use Resulting Action
A/V Reset
(for all inputs)
To reset audio and video adjustments for all inputs to the original factory settings.
While viewing the TV, press the
INPUT
control-panel buttons
VOLUME DOWN
least two seconds.
at the same time for at
and
All Audio and Video settings are returned to the original factory settings, including global settings including global settings not affected by Picture > Reset. Does not affect settings in the Picture > Advanced menu.
Channel Memorization
Lock Menu Pass Code
Control-Panel Lock Release
Auto Input Sensing for HDMI
System Reset If the TV does not turn
To erase and re-memorize channels
ANT
on the
To change your Lock menu pass code
To re-enable the control-panel buttons after activation of the Control-Panel Lock
If the New Device Found screen does not appear when you connect an HDMI device.
on or off, does not respond to the remote control or control­panel buttons, or has audio but no video.
input.
1. While viewing the TV, press MENU
to display the main menu.
2. Navigate to the Setup > Channel menu.
3. Highlight the reception mode, e.g. Ant Air.
4. Select All channels.
5. Highlight Scan.
6. Press
See the page 83.
Press and hold the the control panel for ten seconds. If the TV is powered off, you can then press the
1. Disconnect the HDMI device.
2. Delete the HDMI input in the
3. Power on and connect the new
Press and hold the the control panel for ten seconds.
ENTER
to start channel
memorization.
cutout page from Appendix B,
INPUT
button on
POWER
button to turn it on.
Inputs > Name menu (see page
59).
device.
POWER
button on
All previously memorized chan­nels for the antenna input are erased and a new set of memo­rized channels is created. All custom channel banks are cleared. To add or delete indi­vidual channels, see the Setup > Channel > Edit menu instruc­tions on page 57.
Allows establishment of a new code.
Allows the control panel to be unlocked if the remote control is misplaced.
The New Device Found screen will display.
The TV will turn off. Power on the TV and the green LED will flash quickly for about one minute. The changes you made most recently, before using SYSTEM RESET be lost.
, may
TV Reset
IMPORTANT:
Use this reset only if other troubleshooting has been unsuc­cessful.
To reset all consumer­accessible settings and all memories to the original factory defaults.
Use TV Reset if the TV can respond to con­trols but TV behavior is abnormal.
CAUTION: A ll owner­performed setups and adjustments will be erased.
1. While viewing the TV, press
2. With the main menu displayed,
3. READ THE ON-SCREEN
For assistance call 1(800) 332-2119
MENU
to display the TV main
menu.
press number keys 1 2 3 to display the Reset menu.
WARNING AND INSTRUC­TIONS.
• If you do not wish to use this
reset, press back out.
• If you do wish to use the
reset, press all memories and settings.
EXIT
or
ENTER
MENU
to
to erase
The TV will start the initialization process and then turn off. Power on the TV and the front green LED will start flashing. All memory and settings outlined in this Owner’s Guide will need to be set again.
Appendices 93
Appendix E: Troubleshooting, continued
Reset Name When to Use How to Use Resulting Action
VUDU
Reset VUDU Account Pass­word
You have forgotten your account pass­word.
Using a computer, go to www.VUDU.com.
Reset your account password from the VUDU website (requires access to e-mail).
VUDU
Reset Parental Controls Pass Code
General TV Operation
Symptom Remarks
1. A fan has continued running more than two
minutes after the TV was powered off. The fan gets louder after the TV is shut off.
2.
The TV remote control does not work. • Check that the batteries are fresh and installed correctly.
3.
4.
When I try to use the remote control, the key flashes five times.
5.
TV does not respond to the remote control or to control-panel buttons and TV will not power on or off.
When a device is selected from the Input
6.
Selection menu, the screen is blue or black (no signal source).
7.
You have forgotten your Lock menu pass code. See “Bypassing the Parental Lock”, Appendix B.
8.
Rating restrictions are not working.
9.
On-screen displays appear each time you change a function.
10. A warning message appeared on screen
stating, “TV will shut down in a few seconds. Please check if the air flow is blocked.”
You have forgotten your pass code.
Call VUDU Customer Care at 1-888-554-VUDU (8838).
The room is too warm. When the TV is off, internal components continue to draw power and must be cooled by the fan.
Normal operation. The fan speeds up to cool the lamp quickly after the TV has been shut off.
• Check that the control mode on the remote is set to TV.
• Be no more than 20 feet from the TV when using the remote control.
• Program the remote control to operate the TV or other device.
• Reset the remote control. See “Resetting the Remote Control,”
page 90.
POWER
Replace the batteries.
• Unplug the AC power cord for 10 seconds.
• Press and hold the
seconds to perform system reset.
• Makesuretheselecteddeviceisturnedon.
• Beginplayofthedevice.
Open the Lock > Parental menu and:
• Verifythattheratingslocksareactive.
• ChecktheLockTime/UnlockTimetocheckifratingrestric-
tions are disabled.
• RatingrestrictionsapplyonlytocontentontheANTinput.
Normal TV operation.
• InternalTVtemperaturehasexceededproperlevels.Cool
the room.
• TheTVhasoverheated.Clearblockedairventsandensure
at least four inches of clearance on all sides of the TV.
VUDU Customer Care will reset your pass code.
POWER
button on the control panel for 10
For assistance call 1(800) 332-2119
94 Appendices
Appendix E: Troubleshooting, continued
General TV Operation
Symptom Remarks
I have turned on CEC for my HDMI devices but
11.
control is erratic and I wish to disable it.
TV Channels
Symptom Remarks
The TV takes several seconds to respond to
1.
channel changes.
You cannot access a channel.
2.
3. When ChannelView list is displayed, informa-
tion appears incomplete
• First
• Disable CEC on the device itself. See the device’s instruc-
• If the problem persists, do the following:
• It is normal for digital channels to take longer to tune in.
• Press
• Use a 4-digit number for an over-the-air digital channel.
• Use a 6-digit number for digital cable channels if your cable
• Use number keys instead of CH.
• Be sure the channel you want to view is in memory.
• Check that the TV is switched to the correct device or
• Make sure the Lock > Parental menu lock is set to Off.
• If you cannot tune to a virtual digital channel even though the
• You may be trying to tune to an analog channel that is no
• Press
• Make sure the TV clock is set correctly. Program information
• Available information is sent from the broadcaster or cable
turn off the TV’s HDMI control for the specific device.
Open the Inputs > HDMI Control menu, select the device, select Off.
tions.
1. Disconnect the device from the TV.
2. Open the Inputs > Name menu and select Delete for
the device.
3. Reconnect the device to the TV and Auto Input Sensing
will recognize the device with CEC disabled.
ENTER
after entering a channel number to minimize
delays.
service is able to recognize 6-digit channel numbers.
antenna for that channel by pressing the
TV has already memorized digital channels, tune to the physi­cal channel number used by the broadcaster. The virtual channel will then be automatically added to memory.
longer broadcasting.
INFO
to update the display for the highlighted channel.
is displayed only for the currently tuned channel.
provider. No other data is available.
INPUT
key.
For assistance call 1(800) 332-2119
Appendices 95
Appendix E: Troubleshooting, continued
TV Power On/Off
Symptom Remarks
1. TV takes an excessively long time to power
on.
2. You cannot program the TV to turn on auto-
matically (Timer function)
3. TV turned itself off and the light on the front
panel started to flash.
4. TV will not power off. Press the
When powered on, the TV needs time to boot up, just as a com­puter does.
• The TV may be locked.
• The clock may not be set.
• Momentary power fluctuation can cause the TV to turn off
to prevent damage. Wait for the green light to stop flashing and turn the TV on again.
• If the TV does not stay on, press the control panel for ten seconds to perform System Reset. If this happens frequently, obtain an AC line power condi­tioner/surge protector.
• An unusual digital signal may have been received, triggering a protection circuit. Wait for the light to stop flashing and turn TV on.
POWER
button on the control panel for ten seconds to
perform System Reset.
POWER
button on the
Symptom Remarks
1. Picture does not look like a high-definition
picture.
2. TV has sound but no picture. • Press
3. Picture has become dimmer. • Thelampisnearingtheendofitslife.Orderanewlamp.
4. You cannot view a picture when playing a
VHS tape.
5. VCR or DVD player’s on-screen menus jitter
up and down.
6. When viewing a stopped VCR, white lines
are rolling on the screen.
Compare the picture to the TV’s test picture (Picture > Picture+ > Test Picture) to check if the source signal is supplying a lesser-quality image.
Not all signals are high-definition signals. To receive high-defini­tion programming from your cable or satellite provider, you must subscribe to the provider’s high-definition service. Some over­the-air broadcasts are in high-definition and can be received with a high-quality antenna suited to your location.
MENU
on the remote control. If the menu displays,
then there is a problem with the incoming signal.
• Check that all video inputs are plugged in firmly to the correct input jacks.
• Press and hold the seconds to perform System Reset.
• Adjustpicturebrightnessandcontrasttomaximumlevels.
• ChangeLamp Energy from Standard to Bright.
Check your VCR’s owner’s guide for further troubleshooting.
Stop playback. Possible cause: Many VCRs and DVD players provide on-screen menus at only half-resolution that may appear to jitter up and down.
• TurnoffvideomutefortheVCR.
• Beginplayingthetape.
• ChangetheVCRinputfromLine1totheVCRantennainput.
POWER
button on the control panel for ten
For assistance call 1(800) 332-2119
96 Appendices
Appendix E: Troubleshooting, continued
7. A color program appears as a black and
white image, or the colors are dim, or the screen is black.
8. Picture from an HDMI input is noisy (poor
quality).
9. The image from a computer appears dis-
torted when viewed on the TV.
Sound
Symptom Remarks
1. There is no sound even when the
volume is turned up.
2. The sound does not match the screen
picture.
3. The sound from my A/V receiver does
not match the screen picture (I should hear the correct audio from my A/V receiver).
4. Cannot select an audio-only device; it
does not appear in the Input Selection menu.
5.. Sound is coming from the TV speakers
instead of the A/V receiver.
• If using component video, check that the red, green, and blue input cables are correctly connected to the red, green, and blue component video jacks.
• If using composite video, check that the incoming cable is connected the TV’s green
• 838 Series. The PerfectColor color balance has been incor­rectly set. Reset the PerfectColor balance.
• Compare the picture to the TV’s test picture (Picture > Picture+ > Test Picture) to check if the noise is internal or
external to the TV.
• Upgrade a Category 1 (unmarked) HDMI cable to a newer type of high-speed HDMI cable.
• Normal TV operation. The TV does not correct distortion in the picture from a computer because the correction process may cut off the edges of the image.
• The aspect ratio may be wrong for the image. Press to change.
• Checkifthe
• TheTV’sanalog
program from the ANT input) but no SAP is being broadcast.
• CheckthattheSound > Audio > TV Speakers option is set to On to hear sound from the TV speakers. Possibly the option is nected.
• IfusinganA/Vreceiver,checkthattheSound > Audio > TV Speakers option is set to
speakers.
•
Press and hold the seconds to perform System Reset.
• The language selected in the Setup > Antenna Digital Audio menu is not being broadcast for the current program.
The TV’s analog from the ANT input)
• Check that
OUTPUT
re c e iver. Without this connection, devices connected only to the TV (and not the A/V receiver) can be heard only from the TV speakers. Note that this includes the camcorder) connected to the TV, and any other device sending audio to the TV only.
• If using a NetCommand-controlled A/V receiver, NetCommand may be selecting the wrong A/V receiver audio input. Check the A/V receiver’s NetCommand setup in the Inputs > AVR menu.
Plug an unused video plug into the Input Sensing. Assign the name CD/Audio or MP3 to make the audio device selectable in the Input Selection menu.
• Connect the TV’s
• Change TV Speakers setting to Off or Center.
MUTE
key is on.
Listen to
Off
or set to
Listen to
DIGITAL AUDIO OUTPUT
on TV’s connection panel is connected to the A/V
Center
POWER
setting
.
AUDIO OUT
Y/VIDEO
setting may be set to SAP (analog
but there is no A/V receiver con-
Off
to hear sound from the A/V receiver
button on the control panel for 10
may be set to SAP
ANT
input, a device (such as a
Y/VIDEO
to the A/V receiver.
jack.
TV Speakers
(analog program
and/or
AUDIO/SURROUND
jack to activate Auto
FO RMAT
For assistance call 1(800) 332-2119
Appendices 97
Appendix E: Troubleshooting, continued
Home Network
Symptom Remarks
1. I cannot connect the TV to the
network.
2. I plugged in a wireless USB adapter,
but the wireless connection is not working.
3. The
NetCommand IR Control (NetCommand-equipped models only) Symptom Remarks
1. NetCommand unable to learn specific device
2. The A/V receiver is the selected audio source
3. There is no sound or picture from the A/V
4. I’ve selected my DVD player or other sur-
5. I “learned” the
INTERNET
keys.
but there is no sound.
receiver for my DVD player or other device connected to the A/V receiver; the A/V receiver should be sending video to the TV over an HDMI cable.
A/V Receiver Set Up for Audio and Video
( Switching over HDMI)
round sound device in combination with the TV speakers but hear no sound from the TV speakers.
but when I pressed the DVR did not record anything.
key only goes to VUDU. Normal operation. The TV receives all internet services through VUDU
RECORD
key for my VCR/DVR
RECORD
key, the VCR/
Go to the Setup > Network menu. Obtain the TV MAC address and provide it to the router.
The network may be locked. Go to Setup > Network. Highlight the network name and supply the pass code.
Apps. The TV does not provide full internet access as does a web browser on a computer.
• A/V Device does not use IR format for remote control signal. ITT and RF formats cannot be learned.
• Room lighting may affect the signal. Have the remotes very close (6 inches or less) to the TV during Learning.
• Some, but not all, device key functions can be learned
POWER
and
PL AY
by NetCommand. For example, learned, but other functions may not.
• The signal from the remote control may not be strong enough. Insert fresh batteries and try Learning again.
• The key was “learned” correctly but can be accessed only from the Tools menu.
A/V Receiver Set Up for Audio and Video Switching over HDMI
- Check to see if the A/V Receiver power is turned on.
- If the device is connected only to the TV (e.g., on ANT or a front panel input), verify that the TV’s
OUTPUT
correct key has been “learned.”
- The A/V receiver is not switching properly because you have not learned the IR codes for the A/V receiver inputs to which your devices are connected.
The NetCommand A/V receiver setup is not switching audio and video inputs properly because you did not “learn” the A/V receiver’s IR codes for the device inputs. See “Automatic Audio/Video Switching Over an HDMI Connection,” page 72.
A/V Receiver Set Up for Audio and Video Switching over HDMI With your DVD player connected to the A/V receiver, only video is passed from the A/V receiver to the TV because of copy­protection restrictions on the HDMI signal
Check that the VCR or DVR is receiving a signal directly from your cable box or satellite receiver.
is connected to the A/V receiver and the
may be
AUDIO
For assistance call 1(800) 332-2119
98 Trademark and License Information

Trademark and License Information

Trademark and License Information
LICENSOR’S SUPPLIERS DO NOT MAKE OR PASS ON TO END USER OR ANY OTHER THIRD PARTY, ANY EXPRESS, IMPLIED OR STATUTORY WARRANTY OR REPRESENTATION ON BEHALF OF SUCH SUPPLIERS, INCLUDING, BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, TITLE, MERCHANTABIL­ITY OR FITNESS FOR A PARTICULAR PURPOSE.
Manufactured under license from Cambridge Mechatronics Ltd. Rapidfire and the 1... logo are trademarks of Cambridge Mechatronics Ltd
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by Mitsubishi Electric is under license. Other trademarks and trade names are those of their respective owners. Digital Light Processing Manufactured under license from Dolby Laboratories. Dolby is a trademark of Dolby Laboratories. ENERGY STAR® and the ENERGY STAR mark are registered U.S. marks. ENERGY STAR is a registered mark owned
by the U.S. government. HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries.
Imaging Science Foundation Certified Calibration Controls
®
and DLP® are registered trademarks of Texas Instruments.
The software in this TV is based in part on the work of the Independent JPEG Group, copyright © 1991-1998, Thomas
G. Lane, all rights reserved.
“x.v.Color” and the “x.v.Color” logo are trademarks of Sony Corporation.
VUDU™ is a trademark of VUDU, Inc. ChannelView™, DeepField™ Imager, Easy Connect™, EdgeEnhance™, NetCommand®, PerfectColor™, PerfecTint™,
Plush 1080p® 5G, Smooth120™, StreamTV™ are trademarks of Mitsubishi Digital Electronics America, Inc.

Network Service Disclaimer

Third party content and services, including without limitation home entertainment services by VUDU, Inc., are provided in accordance with whatever terms and conditions are established by the third party providers and agreed to by you. Mitsubishi Digital Electronics America (“MDEA”) has no control over any such third parties or any agreement you reach with them. MDEA has no control over the networks or transmission facilities by which content and services are provided by third parties. Your connection to the internet may vary in availability and quality. Customer service questions are to be directed to the third-party provider, not MDEA.
MDEA DOES NOT WARRANT CONTENT OR SERVICES PROVIDED BY ANY THIRD PARTY, EITHER EXPRESSLY OR IMPLIEDLY, FOR ANY PURPOSE. MDEA DOES NOT WARRANT THAT ANY THIRD PARTY SERVICE WILL REMAIN AVAILABLE FOR ANY PERIOD OF TIME OR THAT IT WILL BE SATISFACTORY, UNINTERRUPTED OR ERROR FREE. MDEA EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE WITH RESPECT TO ANY THIRD PARTY CONTENT AND SERVICES.
MDEA WILL NOT, UNDER ANY CIRCUMSTANCES, BE LIABLE, WHETHER IN CONTRACT OR TORT OR OTHER LEGAL THEORY, FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY FEES, EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR IN CONNECTION WITH, YOUR USE OF ANY CONTENT OR SERVICE THAT IS PROVIDED TO YOU BY ANY THIRD PARTY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
For assistance call 1(800) 332-2119
Trademark and License Information 99
Mitsubishi TV Software
END-USER LICENSE AGREEMENT FOR EMBEDDED SOFTWARE
IMPORTANT – READ CAREFULLY: This License Agreement is a legal agreement between you (either an individual or an entity) and
Mitsubishi Digital Electronics America, Inc. (MDEA) for all software pre installed and/or provided along with this television (“Software”). By utilizing this television and Software, you agree to be bound by the terms of this License Agreement.
The Software is protected by United States copyright laws and international treaty provisions, as well as other intellectual property laws
and treaties. The Software is licensed, not sold.
1. LICENSE GRANT. MDEA grants you a non-exclusive, non-transferable, limited right and license to use one copy of the Software
only with the Mitsubishi television model that included this owner’s guide and owned by you.
2. RIGHTS AND LIMITATIONS. Software Not for Resale. You may not resell or otherwise transfer for value the Software, except in conjunction with a sale of the TV that
Software has been pre installed. Prohibition on Reverse Engineering, Decompilation and Disassembly. The Software contains trade secrets or other proprietary material
in its human perceivable form and to protect them, you may not reverse engineer, decompile, or disassemble, or otherwise reduce the Software to any human perceivable form, except to the extent that the foregoing restriction is expressly prohibited by applicable law.
Separation of Components. The Software is licensed as a single product. Its component parts may not be separated for use on more than one TV.
No Rental. You may not rent, lease, lend, or sublicense the Software.
Trademarks. This License Agreement does not grant you any rights to any trademarks of MDEA.
3. VIOLATIONS. You understand that any use, copying or transfer of the Software, except as permitted pursuant to this License, may subject you to serious criminal and civil penalties including damages and an award to MDEA of attorneys’ fees in connection with any violation of this License. You further understand that you may be held legally responsible for any copyright infringement or other violation of intellectual property rights that is caused, encouraged, or induced by your failure to abide by the terms of the License. This license is effective until terminated, and will terminate immediately without notice from MDEA or judicial resolution if you fail to comply with any provision of this License.
4. COPYRIGHT. All title and intellectual property rights in and to the Software (including but not limited to any images, photographs,
animations, video, audio, music, text, and “applets” incorporated into the Software), and any accompanying printed materials are owned by or licensed to MDEA. All title and intellectual property rights in and to the content which may be accessed through use of the Software is the property of the respective content owner and may be protected by applicable copyright or other intellectual property laws and treaties. This License Agreement grants you no rights to use such content, except that you own the media on which the Software is recorded, but MDEA and its licensors retain ownership of the Software itself. All rights not expressly granted are reserved by MDEA.
5. EXPORT RESTRICTIONS. MDEA is licensing the Software for use within the United States. You agree that you will not export or re-export the Software. You specifically agree not to export or re-export the Software: (i) to any country to which the U.S. has embargoed or restricted the export of goods or services, which currently include, but are not necessarily limited to Cuba, Iran, Iraq, Libya, North Korea, Sudan, and Syria, or to any national of any such country, wherever located, who intends to transmit or transport the Software back to such country; (ii) to any person or entity who you know or have reason to know will utilize the Software in the design, development, or production of nuclear, chemical, or biological weapons; or (iii) to any person or entity who has been prohibited from participating in U.S. export transactions by any federal agency of the U.S. government. You warrant and represent that neither the BXA nor any other U.S. federal agency has suspended, revoked, or denied your export privileges.
6. DISCLAIMER OF WARRANT Y. EXCEPT AS OTHERWISE PROVIDED IN THIS LICENSE OR IN THE LIMITED WARRANTY
APPLICABLE TO THE TV, MDEA MAKES NO OTHER WARRANTIES OF ANY KIND WHATSOEVER REGARDING THE SOFTWARE AND HEREBY EXPRESSLY DISCLAIMS ALL WARRANTIES OF ANY KIND WHATSOEVER, EXPRESS OR IMPLIED, WITH RESPECT TO THE SOFTWARE. ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY EXPRESSLY DISCLAIMED BY MDEA. IN NO EVENT SHALL MDEA BE LIABLE TO YOU OR ANY THIRD PARTIES, IN CONTRACT, IN TORT OR OTHERWISE, FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY KIND OR NATURE. BECAUSE SOME
JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF IMPLIED WARRANTIES, THE ABOVE LIMITATION MAY
NOT APPLY TO YOU.
7. LIMITATION OF LIABILITY. MDEA SHALL NOT, UNDER ANY CIRCUMSTANCES BE LIABLE TO YOU OR ANY THIRD PARTIES FOR ANY DAMAGES OF ANY NATURE, WHETHER INDIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL OR OTHERWISE, INCLUDING, BUT NOT LIMITED TO, ANY CLAIMS FOR LOST PROFITS, LOSS OF GOOD WILL OR EXPENDITURES MADE OR COMMITTED FOR IN RELIANCE ON THE CONTINUATION OF THIS LICENSE. YOU AGREE THAT NEITHER MDEA’S BREACH OF THIS LICENSE NOR ITS FAILURE TO REPAIR A DEFECT, ERROR OR BUG SHALL CONSTITUTE A FAILURE OF THE ESSENTIAL PURPOSE OF THIS LICENSE. BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU. MDEA’s
liability to you for direct damages for any cause whatsoever and regardless of the form of the action, will be limited to the money
paid by you for the TV (based on fair market value of the TV) that caused the damages.
8. GENERAL. This License Agreement will be governed by the laws of the State of California.
WARNING: This product contains chemicals known to the State of California to cause cancer and/or birth defects or other reproductive harm.
For assistance call 1(800) 332-2119
100 Trademark and License Information
GNU GENERAL PUBLIC LICENSE
Version 3, 29 June 2007
Copyright © 2007 Free Software Foundation, Inc. <http://fsf.org/> Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.
Preamble
The GNU General Public License is a free, copyleft license for software and other kinds of works. The licenses for most software and other practical works are designed to take away your freedom to share and change the works. By contrast, the GNU General Public License is intended to guarantee your freedom to share and change all versions of a program--to make sure it remains free software for all its users. We, the Free Software Foundation, use the GNU General Public License for most of our software; it applies also to any other work released this way by its authors. You can apply it to your programs, too. When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for them if you wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new free programs, and that you know you can do these things. To protect your rights, we need to prevent others from denying you these rights or asking you to surrender the rights. Therefore, you have certain responsibilities if you distribute copies of the software, or if you modify it: responsibilities to respect the freedom of others. For example, if you distribute copies of such a program, whether gratis or for a fee, you must pass on to the recipients the same freedoms that you received. You must make sure that they, too, receive or can get the source code. And you must show them these terms so they know their rights. Developers that use the GNU GPL protect your rights with two steps: (1) assert copyright on the software, and (2) offer you this License giving you legal permission to copy, distribute and/or modify it. For the developers’ and authors’ protection, the GPL clearly explains that there is no warranty for this free software. For both users’ and authors’ sake, the GPL requires that modified versions be marked as changed, so that their problems will not be attributed erroneously to authors of previous versions. Some devices are designed to deny users access to install or run modified versions of the software inside them, although the manufacturer can do so. This is fundamen­tally incompatible with the aim of protecting users’ freedom to change the software. The systematic pattern of such abuse occurs in the area of products for individu­als to use, which is precisely where it is most unacceptable. Therefore, we have designed this version of the GPL to prohibit the practice for those products. If such problems arise substantially in other domains, we stand ready to extend this provision to those domains in future versions of the GPL, as needed to protect the freedom of users. Finally, every program is threatened constantly by software patents. States should not allow patents to restrict development and use of software on general-purpose computers, but in those that do, we wish to avoid the special danger that patents applied to a free program could make it effectively proprietary. To prevent this, the GPL assures that patents cannot be used to render the program non-free. The precise terms and conditions for copying, distribution and modification follow.
TERMS AND CONDITIONS
0. Definitions.
“This License” refers to version 3 of the GNU General Public License. “Copyright” also means copyright-like laws that apply to other kinds of works, such as semiconductor masks. “The Program” refers to any copyrightable work licensed under this License. Each licensee is addressed as “you”. “Licensees” and “recipients” may be individuals or organizations. To “modify” a work means to copy from or adapt all or part of the work in a fashion requiring copyright permission, other than the making of an exact copy. The resulting work is called a “modified version” of the earlier work or a work “based on” the earlier work. A “covered work” means either the unmodified Program or a work based on the Program. To “propagate” a work means to do anything with it that, without permission, would make you directly or secondarily liable for infringement under applicable copyright law, except executing it on a computer or modifying a private copy. Propagation includes copying, distribution (with or without modification), making available to the public, and in some countries other activities as well. To “convey” a work means any kind of propagation that enables other parties to make or receive copies. Mere interaction with a user through a computer network, with no transfer of a copy, is not conveying. An interactive user interface displays “Appropriate Legal Notices” to the extent that it includes a convenient and prominently visible feature that (1) displays an appropri­ate copyright notice, and (2) tells the user that there is no warranty for the work (except to the extent that warranties are provided), that licensees may convey the work under this License, and how to view a copy of this License. If the interface presents a list of user commands or options, such as a menu, a prominent item in the list meets this criterion.
1. Source Code.
The “source code” for a work means the preferred form of the work for making modifications to it. “Object code” means any non-source form of a work. A “Standard Interface” means an interface that either is an official standard defined by a recognized standards body, or, in the case of interfaces specified for a particular programming language, one that is widely used among developers working in that language. The “System Libraries” of an executable work include anything, other than the work as a whole, that (a) is included in the normal form of packaging a Major Component, but which is not part of that Major Component, and (b) serves only to enable use of the work with that Major Component, or to implement a Standard Interface for which an implementation is available to the public in source code form. A “Major Component”, in this context, means a major essential component (kernel, window system, and so on) of the specific operating system (if any) on which the executable work runs, or a compiler used to produce the work, or an object code interpreter used to run it. The “Corresponding Source” for a work in object code form means all the source code needed to generate, install, and (for an executable work) run the object code and to modify the work, including scripts to control those activities. However, it does not include the work’s System Libraries, or general-purpose tools or generally available free programs which are used unmodified in performing those activities but which are not part of the work. For example, Corresponding Source includes interface defini­tion files associated with source files for the work, and the source code for shared libraries and dynamically linked subprograms that the work is specifically designed to require, such as by intimate data communication or control flow between those subprograms and other parts of the work. The Corresponding Source need not include anything that users can regenerate automatically from other parts of the Corresponding Source. The Corresponding Source for a work in source code form is that same work.
2. Basic Permissions.
All rights granted under this License are granted for the term of copyright on the Program, and are irrevocable provided the stated conditions are met. This License explicitly affirms your unlimited permission to run the unmodified Program. The output from running a covered work is covered by this License only if the output, given its content, constitutes a covered work. This License acknowledges your rights of fair use or other equivalent, as provided by copyright law. You may make, run and propagate covered works that you do not convey, without conditions so long as your license otherwise remains in force. You may convey cov­ered works to others for the sole purpose of having them make modifications exclusively for you, or provide you with facilities for running those works, provided that you comply with the terms of this License in conveying all material for which you do not control copyright. Those thus making or running the covered works for you must do so exclusively on your behalf, under your direction and control, on terms that prohibit them from making any copies of your copyrighted material outside their relation­ship with you. Conveying under any other circumstances is permitted solely under the conditions stated below. Sublicensing is not allowed; section 10 makes it unnecessary.
3. Protecting Users’ Legal Rights From Anti-Circumvention Law.
No covered work shall be deemed part of an effective technological measure under any applicable law fulfilling obligations under article 11 of the WIPO copyright treaty adopted on 20 December 1996, or similar laws prohibiting or restricting circumvention of such measures. When you convey a covered work, you waive any legal power to forbid circumvention of technological measures to the extent such circumvention is effected by exercis­ing rights under this License with respect to the covered work, and you disclaim any intention to limit operation or modification of the work as a means of enforcing, against the work’s users, your or third parties’ legal rights to forbid circumvention of technological measures.
If you are interested in obtaining open source code for this product, please contact Mitsubishi at (800) 332-2119. A nominal handling and mailing charge may apply.
For assistance call 1(800) 332-2119
Loading...
