MIPRO ACT-50T User Manual

User Guide

2 CE 3 4 6 C

ACT-50T Bodypack Transmitters

All rights reserved.
Do not copy or forward without prior approvals MIPRO.
Specifications and design subject to change without notice.

MN 014/07

Bodypack Transmitter Bodypack Transmitter

Contents

1 Bodypack Controls and Indicators

3 O

4 LCD

5 T

12 Battery Status

13

15 AF

16 B

perating Instructions

Display Screen

ransmitter Parameters

MUTE Control Set-Up

Input Connections

attery Removal and Installation

Bodypack Controls and Indicators

1

2

3

4

5

6
7

8

9

10

11

CH GRP

CH GRP

07 03

07 03

12

13

1

Audio Input Connector: TA4F mini 4-pin
connector accepts any MIPRO lavalier,
instrument and headset microphones and
cables. (See 5 ways of connection on AF Input
Connections)

2

MUTE Button: To mute and un-mute the audio
signal temporary.

0

1

Bodypack Transmitter Bodypack Transmitter

3

Antenna: Flexible 1/4 wave transmitting
antenna.

4

Transmitter Housing: Holds PCB board and
wires.

5

LCD Panel: Display transmitter parameters.

6

SET Button: Parameter selection button.

7

MODE Button: Allows access to 7 available
functions displaying in LCD panel.

8

Power Button: Press and hold 2 seconds to
power ON or OFF.

9

ACT IR Port: Align and syncs the transmitter
and receiver frequency automatically.

10

Battery Compartment: Holds 2 'AA' batteries.

11

Battery Cover: Hinged cover opens to provide
access to 2 'AA' batteries.

12

External Mute Connector: When an external
mute switch cable, MJ-70 (optional) is
connected, user can manually mute and un­mute the audio temporary.

13

Belt Clip: Detachable and reversible design
allows the transmitter to be worn on a belt,
waistband, or guitar strap ( .Figure 1)

Operating Instructions

! The audio gain level is factory preset at

Microphone-Low level. Guitar setting is
recommended at LINE level.

!!Insert the lavalier, headset microphone or

instrument cable into the audio input connector
before power ON the transmitter.

Tighten the connector screw clockwise direction
as shown in (Figure 2) for a secured fit.

Capsule Connector
Headset

Lavalier

The ridge on the
connector must align and
match the indentation on
the socket when inserting
for a proper fit.

(Figure 2)

(Positive Wear)

(Figure 1)

(Opposite Wear)

2

3

Bodypack Transmitter Bodypack Transmitter

07 03

CH GRP

LCD Display Screen Transmitter Parameters

!

MODE button

Press “MODE” button to access one of the
7 parameters below.

SET button

!

Press “SET” button then the changeable
functions will twinkle. Change to the desired
parameters during the above twinkle by pressing
“SET” button.

MODE
SET

A1

A2

A1

LCD Screen

A2

AF (audio) MUTE

A3

Transmitter Battery Meter

AF MUTE

CH GRP

07 03

A3

A

GRP CH

07 03

A

Group and Channel

B

Frequency

C

Sensitivity Level

D

RF Output Power

E

Frequency Band

F

MUTE Mode

G

Parameters Lock & Unlock Status

4

5

MODE

SET LOCK

UNLOCK

B

FREQUENCY

802.000MHz

G

C

AF GAIN

MIC-L

MODE MODE

F

MUTE MODE

MANUAL

MODE

BAND

8A

D

RF POWER

RF-LOW

E

MODEMODE MODE
