Page 1
Programme overview
Commercial washing machine
PWM909
Always read the operating instructions before
setting up, installing and commissioning the machine. This prevents both personal injury and
damage to the machine.
en-GB
M.-Nr. 12 341 780
Page 2
Contents
Programme summary.................................................................................................................. 3
Selectable extras...........................................................................................................................
Selectable extras for liquid dispensing.......................................................................................
Basic programmes ........................................................................................................................
Whites programmes................................................................................................................. 4
Delicates/Shirts/Woollens programmes .............................................................................. 6
Separate rinse programme...................................................................................................... 7
Spin............................................................................................................................................. 7
Drain ........................................................................................................................................... 7
Starch programme.................................................................................................................... 7
Clean machine .......................................................................................................................... 8
Programme chart - Hotel/Restaurant/Catering........................................................................
Bed linen/towelling programme............................................................................................. 9
Mattress protectors programme............................................................................................ 9
Spa towelling programme ....................................................................................................... 10
Bathrobes programme............................................................................................................. 10
Kitchen linen.............................................................................................................................. 11
Table linen programme............................................................................................................. 11
Bedding/Curtains..........................................................................................................................
Curtains...................................................................................................................................... 12
Bedding ...................................................................................................................................... 13
Bedding load sizes.................................................................................................................... 13
Disinfection - general information...............................................................................................
What is disinfection? ............................................................................................................... 14
Thermal disinfection................................................................................................................. 14
Chemo-thermal disinfection ................................................................................................... 14
RKI list (Robert Koch Institute) .............................................................................................. 14
Disinfection process according to areas of impact ............................................................. 14
VAH list ...................................................................................................................................... 15
Avoidance of contamination or recontamination................................................................. 15
Cleaning dispensing drawers and siphons............................................................................ 15
Water connection for variants with reduced heater rating (RH)........................................ 15
Water connection for variants with external heating (EH).................................................. 15
Disinfection ....................................................................................................................................
Buildings maintenance .................................................................................................................
Mop ............................................................................................................................................ 20
Mats/Pads programmes.......................................................................................................... 25
Cleaning cloth programmes.................................................................................................... 26
Fire brigade programme overview ..............................................................................................
Protective clothing programmes ............................................................................................ 30
Masks programmes.................................................................................................................. 32
Rescue clothing programmes................................................................................................. 33
WetCare..........................................................................................................................................
Outerwear programme overview ................................................................................................
Equestrian.......................................................................................................................................
Sport................................................................................................................................................
Workwear .......................................................................................................................................
Sluice programme overview (Healthcare HTM 01-04)...........................................................
Programme sequence Sluice.................................................................................................. 42
Programme overview: Eco programmes....................................................................................
12
14
16
19
30
35
36
37
39
40
41
43
3
3
4
9
2
Page 3
Programme summary
Selectable extras
Extra Symbol Description
Pre-rinse Pre-rinse before the wash processes start
Pre-wash Pre-wash before starting the main wash
Soak Block to start main wash, 30°C, little movement
Water plus Increase amount of water in main wash
Intensive Extension of the main wash after the temperature stop
Rinse plus Additional rinse block
Fill stop Stop at the start of the last rinse, before water is supplied
Rinse hold Hold at the end of the last rinse, before water is drained
Selectable extras for liquid dispensing
Selecting these extras may deselect the relevant detergent component for the next wash
cycle.
Extra Symbol Description
Detergent Detergent component is deselected
Additives No dispensing of the additive component (e.g. stain
booster)
Care product No dispensing of the care product component (e.g. fabric
conditioner, proofing agent)
3
Page 4
Programme summary
Basic programmes
The wash time is the minimum main wash time after the set temperature is reached. The
times for water intake, dispensing, heating, intermediate spinning, etc. are not included.
Whites programmes
Whites 90°C (70°C to 90°C) Load ratio/Load
size
Fabric Cotton, linen and mixed fibre fabrics, e.g. bed
linen and towelling
Programme sequence
Main wash up to 90°C, wash time 11min
Cool down can be activated in the Miele Benchmark Programming Tool
2 rinse cycles
1:9
PWM909 – 9kg
Last rinse cycle hot*
Final spin
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
plus, Fill stop, Rinse hold
* The standard programmes Whites and Coloured items are programmed with hot water rinse cycles. If hot water is
available, we recommend using hot water for the final rinse:
–There is less residual moisture in the laundry after spinning.
–The laundry is already warmed.
–This saves time and energy if the laundry is immediately either dried in a tumble dryer or ironed with an ironer.
4
Page 5
Programme summary
Coloured items programmes
Coloured items 60°C (Cold to 60°C) Load ratio/load
size
Fabric Normally soiled cotton, linen and mixed fibre fab-
rics, e.g. bed linen and towelling
Programme sequence
Main wash up to 60°C, wash time 11min
2rinse cycles
Last rinse cycle hot*
Final spin
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
plus, Fill stop, Rinse hold
1:9
Colours intensive 60°C (Cold to 60°C)
PWM909 – 9kg
Fabric Heavily soiled cotton, linen or mixed fibre fabrics,
e.g. bed linen and towelling, workwear
Programme sequence
Main wash up to 60°C, wash time 8min
2rinse cycles
Last rinse cycle hot*
Final spin
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
plus, Fill stop, Rinse hold
Colours Eco short 50°C (Cold to 60°C) Load ratio/load
size
Fabric Lightly soiled cotton, linen and mixed fibre fabrics,
e.g. bed linen and towelling
Programme sequence
Main wash up to 60°C, wash time 5min
2rinse cycles
Final spin
1:9
PWM909 – 9kg
Extras Pre-wash, Water plus, Rinse plus, Fill stop, Rinse
hold
* The standard programmes Whites and Coloured items are programmed with hot water rinse cycles. If hot water is
available, we recommend using hot water for the final rinse cycle:
–There is less residual moisture in the laundry after spinning.
–The laundry is already warmed.
–This saves time and energy if the laundry is immediately either dried in a tumble dryer or ironed with an ironer.
Minimum iron programmes
Minimum iron 40°C (Cold to 60°C) Load ratio/Load
size
Fabric Normally soiled synthetic and mixed fibre fabrics
Programme se-
quence
Main wash up to 60°C, wash time 7min
2 rinse cycles
Final spin
1:20
PWM909 – 4kg
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
plus, Fill stop, Rinse hold
5
Page 6
Programme summary
Delicates/Shirts/Woollens programmes
Delicates 30°C (Cold to 60°C) Load ratio/Load
size
Fabric Synthetic and artificial fibre fabrics
Programme se-
quence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Shirts 40°C (Cold to 60°C)
Fabric Shirts and blouses made of cotton and mixed
Programme sequence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Woollens 30°C (Cold to 40°C)
Fabric Machine washable woollens and wool mixtures
Programme sequence
Main wash up to 60°C, wash time 12min
Wash rhythm “gentle”
2 rinse cycles
Final spin
Rinse hold
fibre
Main wash up to 60°C, wash time 7min
2 rinse cycles
Final spin
Rinse hold
with a woollens care label
Main wash up to 40°C, wash time 6min
Wash rhythm “very gentle”
2 rinse cycles
Final spin
1:25
PWM909 –
3.2kg
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Rinse hold
Handwash. woollens 30°C (Cold to 40°C)
Fabric Washable woollens and wool mixtures with a
woollens care label
Programme sequence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Main wash up to 40°C, wash time 6min
Wash rhythm “extra gentle”
2 rinse cycles
Final spin
Rinse hold
6
Page 7
Programme summary
Separate rinse programme
Separate rinse Load ratio/Load
size
Fabric Items which only need to be rinsed and spun
Programme se-
quence
1 rinse cycle
Final spin
PWM909 – 9kg
1:9
Extras Fill stop, Rinse hold
Spin
Spin Load ratio/Load
size
Fabric Items which have been washed and only need to
Programme se-
be spun in the machine
Final spin
PWM909 – 9kg
1:9
quence
Drain
Drain
Programme se-
Drainage
quence
Starch programme
Starch 30°C (Cold to 40°C) Load ratio/Load
size
Fabric For starching freshly laundered items such as ta-
ble cloths, serviettes and workwear
1:10
Programme sequence
1 rinse cycle*
Final spin
PWM909 – 8kg
Extras Rinse hold
* Starch concentrates can be added to the front right and/or back right dispenser drawer compartment before the programme starts. Large quantities of starch solution can be added manually with the water using the dispenser compartments or.
7
Page 8
Programme summary
Clean machine
Clean machine 70°C (70°C to 90°C)
Fabric No load
Programme se-
quence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop
+ Intensive button: additional main wash up to
90°C, wash time 6min
2 rinse cycles
Drainage
8
Page 9
Programme summary
Programme chart - Hotel/Restaurant/Catering
A multitude of textiles with widely varying degrees of soiling fall into this area. These programmes are suitable for washing lightly soiled bedding and towels, through heavily soiled
table linen to very heavily soiled kitchen linen.
Bed linen/towelling programme
Bed linen/towelling 60°C (Cold to 90°C) Load ratio/Load
size
Fabric Linen and mixed fibre coloured and white bed
linen and towelling
Programme sequence
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
* Wash with maximum load.
Mattress protectors programme
Mattress protectors 60°C (Cold to 90°C) Load ratio/Load
Fabric Synthetic waterproof mattress protectors
Programme se-
quence
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
Main wash up to 90°C, wash time 10min
Cool down can be activated in the Miele Benchmark Programming Tool
2 rinse cycles
Final spin
plus, Fill stop, Rinse hold
Main wash up to 90°C, wash time 6min
2 rinse cycles
Final spin
plus, Fill stop, Rinse hold
1:10*
PWM909 – 8kg
size
1:13
PWM909 –
6.2kg
9
Page 10
Programme summary
Spa towelling programme
Spa towelling 50°C (Cold to 90°C) Load ratio/Load
size
Fabric Coloured and white cotton, linen and mixed fibre
fabrics, e.g. bed linen and towelling, with heavy oil
and grease stains
Programme sequence
Main wash up to 90°C, wash time 6min
Extra main wash 75°C**
2 rinse cycles
1:13*
PWM909 –
6.2kg
Final spin
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Rinse hold
* Wash with maximum load.
** In case of heavy soiling, e.g. by creams, massage oils, a second main wash at 75°C can be added via the “Intensive”
extra. In the case of coloured stains, additional bleach can be dispensed.
Bathrobes programme
Bathrobes 60°C (Cold to 90°C) Load ratio/Load
size
Fabric Cotton and mixed fibre bathrobes (select Pre-
wash 40°C for heavily soiled items)
Programme sequence
Main wash up to 90°C, wash time 6min
2 rinse cycles
Final spin
1:13*
PWM909 –
6.2kg
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
plus, Fill stop, Rinse hold
* Wash with maximum load.
10
Page 11
Programme summary
Kitchen linen
Kitchen linen 90°C (Cold to 90°C) Load ratio/Load
size
Fabric Cotton, linen and mixed fibre kitchen linen
Programme se-
quence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Table linen programme
Table linen 60°C (Cold to 90°C) Load ratio/Load
Fabric White and coloured cotton, linen and mixed fibre
Programme sequence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Pre-rinse
Main wash up to 90°C, wash time 10min
Cool down can be activated in the Miele Benchmark Programming Tool
3 rinse cycles
Final spin
Rinse hold
table linen
Main wash up to 90°C, wash time 10min
Cool down can be activated in the Miele Benchmark Programming Tool
2 rinse cycles
Final spin
Rinse hold
1:13
PWM909 –
6.2kg
size
1:10
PM909 – 8kg
11
Page 12
Programme summary
Bedding/Curtains
Curtains
Curtains 40°C (Cold to 60°C) Load ratio/Load
size
Fabric Synthetic and artificial fibre fabrics
Programme se-
quence
Extras Pre-rinse, Pre-wash, Soak, Water plus, Intensive,
Lightweight curtains 40°C (Cold to 60°C)
Fabric Synthetic and artificial fibre fabrics
Programme se-
quence
Extras Pre-rinse, Pre-wash, Soak, Water plus, Intensive,
Programme sequence without spin:
Press the “Rinse hold”button.
Main wash up to 60°C, wash time 14min
3 rinse cycles
Final spin
Rinse plus, Fill stop, Rinse hold
Pre-rinse
Main wash up to 60°C, wash time 6min
3 rinse cycles
Final spin
Rinse plus, Fill stop, Rinse hold
1:25
PWM909 –
3.2kg
12
Page 13
Programme summary
Bedding
These programmes are suitable for washing down, natural fibre and synthetic filling quilts,
unquilted and quilted duvets.
These wash programmes are only suitable for washing items with a care label stating that
they are suitable for machine washing.
Down duvets 40°C (Cold to 60°C) Load ratio/Load
size
Fabric Normally to heavily soiled down and feather-filled
duvets and pillows
Programme sequence
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
Synthetic duvets 40°C (Cold to 90°C)
Fabric Normally to heavily soiled synthetic duvets and
Programme sequence
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
Natural hair bedding 25°C (Cold to 40°C)
Fabric Machine-washable natural fibre quilts and
Programme sequence
De-aerating
Main wash up to 60°C, wash time 8min
2 rinse cycles
Final spin
plus, Fill stop, Rinse hold
pillows
Main wash up to 90°C, wash time 8min
2 rinse cycles
Final spin
plus, Fill stop, Rinse hold
blankets
Main wash up to 40°C, wash time 6min, wash
rhythm “extra gentle”
2 rinse cycles
Final spin
See “Bedding load
sizes”
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Rinse hold
Bedding load sizes
The maximum load sizes are set out in the chart below. The loads given are approximate
only and vary depending on the size and thickness of the bedding.
Model Quantity*
PWM909 1–2pillows
13
Page 14
Programme summary
Disinfection - general information
What is disinfection?
Deactivation and reduction in number of pathogens transmitting diseases to such an extent
that the transmission of diseases and infection is no longer to be anticipated.
Thermal disinfection
Thermal disinfection is carried out by the action of a defined temperature over a holding
time. In the list, according to §18 of the German infection control legislation, this is 90°C
over 10min or 85°C over 15min. With a load-to-liquor ratio of 1–4 to 1–5 with the activity
range AB (see “Disinfection process according to areas of impact”).
The thermal disinfection is independent of the detergent used, which does not have to be
classified.
Chemo-thermal disinfection
Chemo-thermal disinfection differs from thermal disinfection by a lower liquor temperature
during the disinfection phase. A compensation for the low temperature is ensured by the
correspondingly listed washing and disinfecting components.
It is important that these products are used exactly according to the listings. The liquor
temperature, the load-to-liquor ratio and the time of dispensing must be strictly adhered to.
For disinfection wash programmes there are two lists in which the necessary process parameters with regard to cleaning agents and disinfectants are listed.
RKI list (Robert Koch Institute)
Describes procedures for disinfection according to §18 German infection control legislation. These processes are only required when a health authority prescribes the use of disinfection in the event of the outbreak of an epidemic relating to a notifiable, transferable disease where there is a risk of items being contaminated. The RKI lists thermal disinfection
processes as well as chemo-thermal methods.
Disinfection process according to areas of impact
Disinfection procedure is divided into areas of impact A, B and C.
- Area of impact A:
Suitable for the destruction of vegetative germs, including mycobacteria, mould fungi and
fungal spores.
- Area of impact B:
Suitable for deactivating viruses.
- Area of impact C:
To deactivate anthrax spores.
14
Page 15
Programme summary
VAH list
VAH=Association for Applied Hygiene
(previously DGHM=German Society for Hygiene and Microbiology)
The VAH/DGHM list describes the procedures required for routine prophylactic disinfection, and in particular for the prevention of infection in hospitals, doctors' offices, public
areas and other areas where there may be the risk of infection spreading.
With respect to an officially directed disinfection, §18 of the Infection Protection Act is invoked.
Special validated procedures and machines are to be used for surgical textiles as medical
devices. The procedures and machines listed here are not medical devices.
Avoidance of contamination or recontamination
Disinfect your hands before using the machine.
Use clean/disinfected transport containers.
Dispense cleaning agents and disinfectants in accordance with instructions.
Observe regulations regarding the wearing of protective clothing.
Ensure that water is bacteria-free when using water from water treatment units.
Clean detergent drawers, detergent compartments and siphons before use.
Cleaning dispensing drawers and siphons
The detergent drawer is subject to constant moisture. It needs to be cleaned regularly to
prevent the build-up of water-borne bacteria.
Clean the detergent drawer, detergent compartments and siphon thoroughly with hot wa-
ter as required to remove detergent residues and encrustation.
It is the supervisor’s responsibility to ensure that the standard of disinfection in thermal as
well as chemo thermal procedures is maintained (from the list, in accordance with §18
German infection control legislation) by carrying out suitable validation tests. The procedures should be checked at regular intervals, thermoelectrically by means of loggers or bacteriologically using bio-indicators. The supervisor must pay particular attention to observing the process parameters temperature and, in the case of chemo-thermal programmes, the concentration. Disinfection programmes must not be interrupted, as this
can have a limiting effect on the disinfection result.
Water connection for variants with reduced heater rating (RH)
The appliance should be connected to cold and hot water supplies. A minimum hot water
temperature of 80°C is recommended in order to use all programmes. Lower temperatures
may result in longer programme running times or cause programmes to be interrupted. Water inlet temperatures below 60°C are not permitted, as they can lead to significantly
longer programme running times.
Water connection for variants with external heating (EH)
The appliance should be connected to cold and hot water supplies. A minimum hot water
temperature of 80°C is recommended. The use of disinfection programmes is not possible
due to the absence of additional heating. The permissible wash temperatures are determined by the inlet temperature.
15
Page 16
Programme summary
Disinfection
Thermal disinfection and chemo-thermal disinfection are programmes for disinfecting
textiles.
Thermal or chemo-thermal disinfection is carried out. Suitable detergents are to be used
for the chemo-thermal disinfection.
All programmes are locked. This means that after 1minute into a programme, they can
only be cancelled, stopped or parts skipped by entering the “Expert code” (see operator
level).
To avoid recontamination, the water inlet for the rinse cycles in the disinfection programmes is not supplied via the detergent drawer.
To disinfect contaminated mains water, a disinfection rinse can be activated instead of
the last rinse cycle. In this rinse, the rinse water is heated to 65°C to deactivate waterborne bacteria. The programme running time is extended and the door can only be opened
once the temperature in the machine has fallen below 50°C.
If “Pre-wash” is selected, place the detergent directly in the drum. If necessary, the
and compartments can be used to add detergent in the main wash cycle.
16
Page 17
Programme summary
Thermal disinfection 90°C Load ratio/Load
size
Fabric Cotton, linen e.g. bed linen, towelling
Programme se-
quence
Disinfection 90°C, holding time 10min
Cool down and/or disinfection rinse can be activated in the Miele Benchmark Programming Tool
2 rinse cycles
Final spin
Extras Pre-wash, Soak, Intensive, Rinse plus, Fill stop,
Rinse hold
Ch.-thermal disin. 10 min 70°C
Fabric Cotton, linen e.g. bed linen, towelling
Programme se-
quence
Disinfection 70°C*, holding time 10min
2 rinse cycles (optional disinfection rinse can be
activated)
Final spin
Extras Pre-wash, Soak, Intensive, Rinse plus, Fill stop,
Rinse hold
Ch.-thermal disin. 20 min 60°C
Fabric Cotton, linen e.g. bed linen, towelling
Programme se-
quence
Disinfection 60°C*, holding time 20min
2 rinse cycles (optional disinfection rinse can be
activated)
Final spin
1:9
PWM909 – 9kg
1:10
PWM909 – 8kg
Extras Pre-wash, Soak, Intensive, Rinse plus, Fill stop,
Rinse hold
* The disinfection parameters for chemo-thermal disinfection (temperature, temperature holding time and dispensing
quantities) must be set on site to suit detergents and disinfectants.
17
Page 18
Programme summary
Ch-th. disin. gentle 20 min 40°C Load ratio/Load
size
Fabric Cotton, mixed fibre, curtains
Programme se-
quence
Disinfection 40°C*, holding time 20min
Wash rhythm “gentle”
2 rinse cycles (optional disinfection rinse can be
activated)
Final spin
Extras Pre-wash, Soak, Intensive, Rinse plus, Fill stop,
Rinse hold
Incontinence 90°C
Fabric Washable incontinence nappy systems
Programme se-
quence
Pre-rinse bath
Pre-wash up to 40°C
Disinfection 90°C, holding time 10min
Cool down and/or disinfection rinse can be activated in the Miele Benchmark Programming Tool
3 rinse cycles
Final spin
Extras Pre-rinse, Soak, Intensive, Rinse plus, Fill stop,
Rinse hold
Incontinence laundry 90°C
1:10
PWM909 – 8kg
1:13
PWM909 –
6.2kg
Fabric Heavily soiled personal clothing, cotton
Programme se-
quence
2 pre-rinse baths
Pre-wash up to 40°C
Disinfection 90°C, holding time 10min
3 rinse cycles (optional disinfection rinse can be
activated)
Final spin
Extras Soak, Intensive, Rinse plus, Fill stop, Rinse hold
* The disinfection parameters for chemo-thermal disinfection (temperature, temperature holding time and dispensing
quantities) must be set on site to suit detergents and disinfectants.
18
Page 19
Programme summary
Buildings maintenance
These programmes are suitable for washing, disinfecting and finishing (at different humidity levels) cotton or mixed fibre mops, floor mats, polishing pads and cleaning cloths used
in facility management.
Cleaning textiles can even come out of the machine finished and ready for use (ready to
use – rtu).
To avoid recontamination, the water for the rinse cycles in the disinfection programmes is
not supplied via the detergent drawer.
With the Mops. . .+ready to use (rtu) programme, the mops are ready to use and
already impregnated with cleaning agent or detergent and disinfectant. To achieve this, following washing or disinfection there is a finishing stage and then a final spin. The desired
humidity level of the mops can vary by setting the residual moisture via the extra “ –
” (moist, damp, wet, dripping wet).
The dispensing quantities must be set on site and the standard of disinfection must be
checked.
19
Page 20
Programme summary
Mop
To prevent coarse soiling in the machine, shake out the mops before putting them in.
Standard mops 60°C (Cold to 90°C) Load ratio/Load
size
Fabric Cotton, viscose, polyester and microfibre mops
Programme se-
quence
Extras Pre-rinse, Soak, Water plus, Intensive, Rinse plus,
Standard mops + rtu 60°C (Cold to 90°C)
Fabric Cotton, viscose, polyester and microfibre mops
Programme se-
quence
Extras Pre-rinse, Soak, Water plus, Intensive, Rinse plus,
Pre-spin
Pre-rinse bath
2ndpre-rinse bath can be activated via extra
“Pre-rinse”
Main wash up to 90°C, wash time 6min
Cool down can be activated in the Miele Benchmark Programming Tool
2 rinse cycles
Final spin
Fill stop, Rinse hold
Same programme sequence as Mops standard,
then set the residual moisture via the extra “ –
” (moist, damp, wet, dripping wet)
The pre-set residual moisture is 2drops (damp)
Fill stop, Rinse hold
1:9
PWM909 – 9kg
For number,
see
“Mops load size”
chart
20
Page 21
Programme summary
Mops thermal disinfection 90°C Load ratio/Load
size
Fabric Cotton, viscose, polyester and microfibre mops
Programme se-
quence
Extras Pre-rinse, Soak, Water plus, Intensive, Rinse plus,
Mops thermal disinf + rtu 90°C
Fabric Cotton, viscose, polyester and microfibre mops
Programme se-
quence
Extras Pre-rinse, Soak, Water plus, Intensive, Rinse plus,
Pre-spin
Pre-rinse bath
2ndpre-rinse bath can be activated via extra
“Pre-rinse”
Disinfection 90°C, holding time 10min
Cool down and/or disinfection rinse can be activated in the Benchmark Tool
3 rinse cycles
Final spin
Fill stop, Rinse hold
Same programme sequence as Mops thermal
disinfection,
then set the residual moisture via the extra “ –
” (moist, damp, wet, dripping wet)
The pre-set residual moisture is 2drops (damp)
Fill stop, Rinse hold
1:9
PWM909 – 9kg
For number,
see
“Mops load size”
chart
21
Page 22
Programme summary
Mops ch-th disinf 10 min 70°C Load ratio/Load
size
Fabric Cotton, viscose, polyester and microfibre mops
Programme se-
quence
Pre-spin
Pre-rinse bath
2ndpre-rinse bath can be activated via extra
“Pre-rinse”
Disinfection* 70°C, holding time 10min
3 rinse cycles (optional disinfection rinse can be
activated)
Final spin
Extras Pre-rinse, Soak, Intensive, Rinse plus, Fill stop,
Rinse hold
Mops ch-th disinf 20 min 60°C
Fabric Cotton, viscose, polyester and microfibre mops
Programme se-
quence
Pre-spin
Pre-rinse bath
2ndpre-rinse bath can be activated via extra
“Pre-rinse”
Disinfection* 60°C, holding time 20min
3 rinse cycles (optional disinfection rinse can be
activated)
Final spin
1:10
PWM909 – 8kg
Extras Pre-rinse, Soak, Intensive, Rinse plus, Fill stop,
Rinse hold
Mops ch-th dis 10 min+rtu 70°C
Fabric Cotton, viscose, polyester and microfibre mops
Programme se-
quence
Programme sequence as for Mops chemothermal disinfection*,
then set the residual moisture via the extra “ –
” (moist, damp, wet, dripping wet)
The pre-set residual moisture is 2drops (damp)
Extras Pre-rinse, Soak, Intensive, Rinse plus, Fill stop,
Rinse hold
* The disinfection parameters for chemo-thermal disinfection (temperature, temperature holding time and dispensing
quantities) must be set on site to suit detergents and disinfectants.
22
Page 23
Programme summary
Mops ch-th dis 20min+rtu 60°C Load ratio/Load
size
Fabric Cotton, viscose, polyester and microfibre mops
Programme se-
quence
Programme sequence as for Mops chemothermal disinfection*,
then set the residual moisture via the extra “ –
” (moist, damp, wet, dripping wet)
The pre-set residual moisture is 2drops (damp)
Extras Pre-rinse, Soak, Intensive, Rinse plus, Add agent,
Rinse hold
Mops rtu
Fabric Cotton, viscose, polyester and microfibre mops
Programme se-
quence
1 rinse cycle
then set the residual moisture via the extra “ –
” (moist, damp, wet, dripping wet)
The pre-set residual moisture is 2drops (damp)
Extras Fill stop, Rinse hold
New mops 60°C (Cold to 90°C)
Fabric For washing new mops
Programme se-
quence
Main wash up to 90°C, wash time 4min
Cool down can be activated in the Miele Benchmark Programming Tool
2 rinse cycles
Final spin
1:10
PWM909 – 8kg
1:9
PWM909 – 9kg
For number,
see
“Mops load size”
chart
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Rinse hold
* The disinfection parameters for chemo-thermal disinfection (temperature, temperature holding time and dispensing
quantities) must be set on site to suit detergents and disinfectants.
23
Page 24
Programme summary
The Mops rtu programme is suitable for the subsequent finishing of clean and dry mops. A
disinfecting agent is applied during finishing.
The dispensing quantities must be set on site and the standard of disinfection must be
checked.
Mop load size (cotton) applies to the load ratio 1:9
Mop size/
weight
40cm
190g/
mop
50cm
220g/
mop
60cm
280g/
mop
80cm
360g/
mop
110cm
510g/
mop
130cm
610g/
mop
160cm
720g/
mop
PWM909 47 41 32 25 18 15 13
Tip: When using microfibre mops, the load size is higher due to the lower mop weight.
Mop load size (microfibre) applies to the load ratio 1:9
Mop size/weight 40cm
120g/mop
50cm
170g/mop
PWM909 75 53
A reduced number may apply to particularly high-volume, light-weight mops.
24
Page 25
Programme summary
Mats/Pads programmes
Mats 40°C (Cold to 60°C) Load ratio/Load
size
Fabric Door mats
Programme se-
quence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Heavily soiled mats 60°C (Cold to 60°C)
Fabric Heavily soiled door mats
Programme se-
quence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Pads 40°C (Cold to 60°C)
Fabric Polishing pads
Programme se-
quence
Pre-rinse
Main wash up to 60°C, wash time 8min
3 rinsing baths
Final spin
Rinse hold
Pre-rinse
Pre-wash up to 40°C
Main wash up to 60°C, wash time 12min
3 rinsing baths
Final spin
Rinse hold
Pre-rinse bath
2ndpre-rinse bath can be activated via extra
“Pre-rinse”
Main wash up to 60°C, wash time 10min
3 rinse cycles
Final spin
1:15
PWM909 –
max. 5.4kg
1:50
PWM909 –
1.6kg
Extras Pre-rinse, Soak, Water plus, Intensive, Rinse plus,
Fill stop, Rinse hold
Tip: The mats load size may vary depending on the size, stiffness and thickness of the
mats.
25
Page 26
Programme summary
Cleaning cloth programmes
These programmes are suitable for washing, disinfecting and finishing (at different humidity levels) cleaning cloths made of cotton, mixed fibre or microfibre fabric used in facility
management.
Standard cloths 60°C (Cold to 90°C) Load ratio/Load
size
Fabric Cotton, viscose, polyester and microfibre clean-
ing cloths
Programme sequence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Standard cloths + rtu 60°C (Cold to 90°C)
Fabric Cotton, viscose, polyester and microfibre clean-
Programme sequence
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
Pre-rinse
Pre-wash up to 30°C
Main wash up to 90°C, wash time 6min
3 rinsing baths
Final spin
Rinse hold
ing cloths
Same programme sequence as Cloths standard
then set the residual moisture via the extra “ –
” (moist, damp, wet, dripping wet)
The pre-set residual moisture is 2drops (damp)
plus, Fill stop, Rinse hold
1:18
PWM909 –
4.6kg
For number,
see
“Cleaning cloths
load size” chart
26
Page 27
Programme summary
Cloths therm. disinfection 90°C Load ratio/Load
size
Fabric Cotton, viscose, polyester and microfibre clean-
ing cloths
Programme sequence
Extras Soak, Intensive, Rinse plus, Fill stop, Rinse hold
Cloths therm. disinf + rtu 90°C
Fabric Cotton, viscose, polyester and microfibre clean-
Programme sequence
Extras Pre-wash, Soak, Intensive, Rinse plus, Fill stop,
Cloths ch-th disinf 10 min 70°C
Pre-rinse
Pre-wash up to 30°C
Disinfection 90°C, holding time 10min
Cool down and/or disinfection rinse can be activated in the Miele Benchmark Programming Tool
3 rinsing baths
Final spin
ing cloths
Same programme sequence as Cloths thermal
disinfection
then set the residual moisture via the extra “ –
” (moist, damp, wet, dripping wet)
The pre-set residual moisture is 2drops (damp)
Rinse hold
1:18
PWM909 –
4.6kg
For number,
see
“Cleaning cloths
load size” chart
Fabric Cotton, viscose, polyester and microfibre clean-
ing cloths
Programme sequence
Extras Soak, Intensive, Rinse plus, Fill stop, Rinse hold
Pre-rinse
Pre-wash up to 30°C
Disinfection 70°C, holding time 10min
3 rinsing baths (optional disinfection rinse can be
activated)
Final spin
27
Page 28
Programme summary
Cloths ch-th disinf 20 min 60°C Load ratio/Load
size
Fabric Cotton, viscose, polyester and microfibre clean-
ing cloths
Programme sequence
Extras Soak, Intensive, Rinse plus, Add agent, Rinse hold
Cloths ch-th dis 10min+rtu 70°C
Fabric Cotton, viscose, polyester and microfibre clean-
Programme sequence
Extras Pre-wash, Soak, Intensive, Rinse plus, Fill stop,
Cloths ch-th dis 20min+rtu 60°C
Fabric Cotton, viscose, polyester and microfibre clean-
Pre-rinse
Pre-wash up to 30°C
Disinfection 60°C, holding time 20min
3 rinsing baths (optional disinfection rinse can be
activated)
Final spin
ing cloths
Programme sequence as for Cloths chemo-
thermal disinfection,
then set the residual moisture via the extra “ –
” (moist, damp, wet, dripping wet)
The pre-set residual moisture is 2drops (damp)
Rinse hold
ing cloths
1:18
PWM909 –
4.6kg
For number,
see
“Cleaning cloths
load size” chart
Programme sequence
Extras Pre-wash, Soak, Intensive, Rinse plus, Fill stop,
Programme sequence as for Cloths chemothermal disinfection,
then set the residual moisture via the extra “ –
” (moist, damp, wet, dripping wet)
The pre-set residual moisture is 2drops (damp)
Rinse hold
28
Page 29
Programme summary
Cloths rtu Load ratio/Load
size
Fabric Cotton, viscose, polyester and microfibre clean-
ing cloths
Programme sequence
Extras Fill stop, Rinse hold
Cleaning cloths load size applies to the load ratio 1:18
Cleaning cloths
size/weight
PWM909 290 210 105
The Standard cloths programme is also suitable for cleaning cloths that are not to be
used immediately after washing, but are to be stored after drying.
With the Cloths. . .+rtu programmes, the cloths are ready to use and already impregnated with detergent and disinfectant. To achieve this, following washing or disinfection
there is a finishing stage and then a final spin. The desired humidity level of the cleaning
cloths can vary by setting the residual moisture via the extra “ – ” (moist, damp, wet,
dripping wet). The dispensing quantities must be set on site and the standard of disinfection must be checked.
1 rinse cycle
then set the residual moisture via the extra “ –
” (moist, damp, wet, dripping wet)
The pre-set residual moisture is 2drops (damp)
16g/cloth 22g/cloth 43g/cloth
“Cleaning cloths
load size” chart
1:18
PWM909 –
4.6kg
For number,
see
The Cloths rtu programme is suitable for the subsequent finishing of clean and dry cleaning cloths. A disinfecting agent is applied during finishing. The dispensing quantities must
be set on site and the standard of disinfection must be checked.
29
Page 30
Programme summary
Fire brigade programme overview
These programmes are suitable for washing and proofing Nomex fire-fighting apparel, jackets and trousers, breathing masks and chemical protective suits.
Protective clothing programmes
Protective clothing 60°C (Cold to 60°C) Load ratio/Load
size
Fabric Nomex fire-fighting apparel, jackets, trousers
Programme se-
quence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Protective cloth. + proof 60°C (Cold to 60°C)
Fabric Nomex fire-fighting apparel, jackets, trousers
Programme se-
quence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Proof protect. clothing 40°C
Fabric Nomex fire-fighting apparel, jackets, trousers
Programme se-
quence
Pre-cleaning up to 40°C
Main wash up to 60°C, wash time 6min
3 rinse cycles, Final spin
Rinse hold
Pre-cleaning up to 40°C
Main wash up to 60°C, wash time 6min
2 rinse cycles
Proofing bath 40°C
Final spin
Rinse hold
1 rinsing bath
Reproofing bath 40°C
Final spin
See
“Protective
clothing load size”
chart
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Rinse hold
Protective clothing load size
Model Quantity
PWM909 Approx. 1suit (or 2jackets)
30
Page 31
Programme summary
Preparing Protective clothing for washing
Do not staple labels to the items.
Remove carabiner hooks if possible, or enclose them in a side pocket.
Close Velcro fasteners or cover them with Velcro tape.
Wash sheepskin linings separately.
Do not wash garments inside out.
Observe the load sizes.
Protective clothing is a programme for washing fire-fighting apparel. It is not suitable for
washing garments containing wool as lining material.
Tip: Detergent: We recommend using a liquid detergent with reduced pH that is particu-
larly effective for dissolving grease and pigmentation stains.
The proofing agent must be suited to the special requirements of this area of use.
31
Page 32
Programme summary
Masks programmes
Masks are programmes for washing and disinfecting breathing masks with head straps.
Put the head bands over the masks to protect the visors before loading the machine.
Put each mask into its own protective bag and fasten it.
The protective bags are available to order from the Miele Customer Service Department.
Remove the masks from the bags after reprocessing.
Spin damp, empty protective bags using the Spin bags programme.
Masks 60°C Load ratio/Load
size
Load Breathing masks with head straps
Programme se-
quence
Disinfection* 60°C, holding time 20min
4 rinse cycles (optional disinfection rinse can be
activated)
Extras Soak, Intensive, Rinse plus, Fill stop, Rinse hold
Masks with pre-wash 60°C
Load For heavily soiled breathing masks with head
PWM909 –
4masks
straps
Programme sequence
Pre-cleaning 30°C
Disinfection* 60°C, holding time 20min
4 rinse cycles (optional disinfection rinse can be
activated)
Extras Soak, Intensive, Rinse plus, Fill stop, Rinse hold
Spin wash bags
Load Mask bags
Programme se-
Spin
1:20
quence
* The disinfection parameters for chemo-thermal disinfection (temperature, temperature holding time and dispensing
quantities) must be set on site to suit detergents and disinfectants.
To avoid recontamination, the water inlet for the rinse cycles in the disinfection programmes is not supplied via the detergent drawer.
Do not wash masks with connections for helmet-mask combinations.
The clasps are likely to scratch visors.
Use a suitable detergent. Observe the manufacturer’s instructions.
32
Page 33
Programme summary
Rescue clothing programmes
Helmets* 60°C (Cold to 60°C) Load ratio/load
size
Fabric Firefighter helmets
Programme se-
quence
Pre-wash up to 40°C
Main wash up to 60°C, wash time 16min
3rinse cycles
PWM909 –
3helmets
Extras Soak, Rinse plus
* The safety helmet manufacturer must allow the helmet to be washed or dried by machine.
Before loading the machine, push the sliding visor, if applicable, into the safety helmet.
Place one helmet in each of the padded protective bags provided and close them.
The protective bags are available to order from the Miele Customer Service Department.
Remove easily removable attachments from the helmet and wash in a separate washing
net.
Gloves 40°C (Cold to 40°C) Load ratio/load
size
Fabric Gloves with and without leather trim
Programme se-
quence
Main wash up to 40°C, wash time 9min
3rinse cycles
Final spin
Leather care 40°C
PWM909 –
17gloves
Final spin
Extras Soak, Water plus, Rinse plus
After washing, air-dry the gloves with and without leather trim. Before drying, roll the
leather gloves or gloves with leather trim through your hands to maintain the elasticity of
the leather.
Belts* 40°C (Cold to 40°C) Load ratio/load
size
Fabric Fire brigade belts also with aluminium compon-
ents and leather trim
Programme sequence
Main wash up to 40°C, wash time 8min
3rinse cycles
PWM909 –
6belts
Final spin
Extras Pre-wash, Rinse plus
* The belt manufacturer must allow the belt to be washed by machine.
If there are aluminium attachments on the belts, we recommend using a liquid delicates detergent with reduced pH value
which is particularly effective for dissolving pigmentation stains.
Place 2–3belts (safety belts) in each of the padded protective bags provided and close
them.
33
Page 34
Programme summary
The protective bags are available to order from the Miele Customer Service Department.
After washing, air-dry the belts. Before drying, roll the leather components through your
hands and, if necessary, treat them with a suitable leather refatting agent to maintain the
elasticity of the leather.
Emergency services clothing is a programme for disinfecting. It is not suitable for washing
garments containing wool as lining material.
Do not wash garments inside out.
Disin. rescue clothing* 60°C Load ratio/load
size
Fabric Nomex and cottons
Programme se-
quence
Pre-wash up to 40°C
Disinfection* 60°C, holding time 20min
2 rinse cycles
Final spin
Extras Soak, Rinse plus
Dis./proof rescue cloth.* / ** 60°C
Fabric Nomex and cottons
Programme se-
quence
Pre-wash up to 40°C
Disinfection* 60°C, holding time 20min
“Emergency ser-
vices clothing load
See
size” chart
2 rinse cycles
Proofing bath** 40°C
Final spin
Extras Soak, Rinse plus
* The disinfection parameters for chemo-thermal disinfection (temperature, temperature holding time and dispensing
quantities) must be set on site to suit detergents and disinfectants.
** The proofing agent must be suited to the special requirements of this area of use.
Emergency services clothing load size
Model Quantity
PWM909 Approx. 3suits
34
Page 35
Programme summary
WetCare
WetCare “wet cleaning” is a very gentle cleaning process using water and special care
products for clothing that could previously only be cleaned chemically.
WetCare sensitive 25°C (Cold to 30°C) Load ratio/Load
size
Fabric Non-washable outerwear
Programme se-
quence
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
WetCare silks 30°C (Cold to 30°C)
Fabric For non-washable outerwear which creases easily
Programme se-
quence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
WetCare intensive 40°C (Cold to 40°C)
Fabric Washable outerwear
Programme se-
quence
Main wash up to 30°C, wash time 2min
Waterproof finish 25°C
Final spin
plus, Fill stop, Rinse hold
Main wash up to 30°C, wash time 6min
Waterproof finish 25°C
Final spin
Rinse hold
Main wash up to 40°C, wash time 6min
Rinse cycle
Waterproof finish 25°C
Final spin
1:15
PWM909 –
5.4kg
1:20
PWM909 – 4kg
1:15
PWM909 –
5.4kg
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
plus, Fill stop, Rinse hold
In the textile cleaning programmes, no hot water valves are activated. The incoming water
must not exceed a temperature of 30°C.
35
Page 36
Programme summary
Outerwear programme overview
Outerwear 40°C (Cold to 40°C) Load ratio/Load
size
Fabric Polyamide and membrane items
Programme se-
quence
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
Wash/proofing 40°C
Fabric Polyamide and membrane items
Programme se-
quence
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
Rinse/proofing 40°C
Fabric Polyamide and membrane items
Programme se-
quence
Main wash up to 40°C, wash time 6min
2 rinse cycles
Final spin
plus, Fill stop, Rinse hold
Main wash up to 40°C, wash time 6min
2 rinse cycles
Proofing up to 40°C
Final spin
plus, Fill stop, Rinse hold
2 rinse cycles
Proofing 40°C
Final spin
1:15
PWM909 –
5.4kg
Extras Rinse plus, Fill stop, Rinse hold
Down jackets 40°C (Cold to 60°C)
Fabric Down-filled items
Programme se-
quence
Extras Pre-rinse, Soak, Water plus, Intensive, Rinse plus,
Main wash up to 60°C, wash time 7min
2 rinse cycles
Final spin
Fill stop, Rinse hold
1:25
PWM909 –
3.2kg
36
Page 37
Programme summary
Equestrian
This programme is suitable for washing and proofing horse blankets, saddle cloths, gaiters,
hoof boots, bandages, textile halters.
Horse blankets 60°C (Cold to 60°C) Load ratio/Load
size
Fabric Horse blankets, saddle cloths, gaiters, hoof
boots, bandages, textile halters
Programme sequence
Extras Pre-rinse, Soak, Water plus, Intensive, Rinse plus,
Woollen horse blankets 30°C (Cold to 40°C)
Fabric Horse blankets containing wool
Programme se-
quence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Pre-rinse
2ndpre-rinse can be activated via extra “Prerinse”
Pre-wash up to 40°C
Main wash up to 60°C, wash time 6min
3 rinse cycles
Final spin
Fill stop, Rinse hold
Pre-rinse
Pre-wash up to 30°C
Main wash up to 40°C, wash time 8min
Wash rhythm “Gentle+”
2 rinse cycles
Final spin
Rinse hold
1:13
See
“Horse blankets
load size” chart
Horse blank. + proofing 60°C (Cold to 60°C)
Fabric Horse blankets, saddle cloths, gaiters, hoof
boots, bandages, textile halters
Programme sequence
Extras Pre-rinse, Soak, Water plus, Intensive, Rinse plus,
Pre-treatment
Remove coarse soiling from very heavily soiled blankets with a strong water jet or a vacuum
cleaner.
Pre-rinse
2ndpre-rinse can be activated via extra “Prerinse”
Pre-wash up to 30°C
Main wash up to 60°C, wash time 6min
2 rinse cycles
Proofing 30°C
Final spin
Fill stop, Rinse hold
37
Page 38
Programme summary
Detergent
For washing, a detergent without bleaching agent and optical brighteners should be used.
For woollen blankets, products with slightly reduced pH should be used. It is also possible
to add enzyme-containing products.
It needs to be ensured that no proteases are used as these enzymes attack and damage the
wool.
Horse blankets load size
Model Load, maximum ¾ of the total recommended load
Saddle cloths Summer blankets Winter blankets
PWM909 4 1 -
Buckles
Metal buckles, hooks and eye fasteners must be covered to protect the drum.
Special bags for this purpose are available to order from Miele.
38
Page 39
Programme summary
Sport
Sportswear 40°C (Cold to 60°C) Load ratio/Load
size
Fabric Polyester or polyamide with and without spandex
Programme se-
quence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Sport Microfibre 40°C (Cold to 60°C)
Fabric Polyester, polyamide
Programme se-
quence
Extras Soak, Water plus, Intensive, Rinse plus, Fill stop,
Trainers 40°C (Cold to 60°C)
Fabric Washable trainers (no leather shoes), shin pads,
Programme sequence
Main wash up to 60°C, wash time 6min
3 rinse cycles
Final spin
Rinse hold
Main wash up to 60°C, wash time 6min
2 rinse cycles
Final spin
Rinse hold
elbow protectors and similar items
Main cleaning up to 60°C, wash time 6min
2 rinse cycles
Final spin
1:20
PWM909 – 4kg
Extras Pre-rinse, Pre-wash, Soak, Water plus, Intensive,
Rinse plus, Fill stop, Rinse hold
39
Page 40
Programme summary
Workwear
Oil/fat 60°C (Cold to 90°C) Load ratio/Load
size
Fabric Cotton or mixed fibre workwear, table cloths or
cleaning cloths soiled with oil or grease
Programme sequence
Extras Pre-rinse, Soak, Water plus, Intensive, Rinse plus,
Dust/flour 60°C (Cold to 90°C)
Fabric Cotton or mixed fibre workwear, table cloths or
Programme sequence
Extras Pre-rinse, Soak, Water plus, Intensive, Rinse plus,
Pre-wash up to 40°C
Main wash up to 90°C, wash time 10min
3 rinse cycles
Final spin
Fill stop, Rinse hold
cleaning cloths soiled with dust or flour
Pre-wash up to 40°C
Main wash up to 90°C, wash time 10min
2 rinse cycles
Final spin
Fill stop, Rinse hold
1:10
PWM909 – 8kg
40
Page 41
Programme summary
Sluice programme overview (Healthcare HTM 01-04)
The sluice programmes are for extremely heavily soiled personal clothing, as well as heavily soiled towelling and bed linen.
Disinfection according to provisions of British National Health Service (GB). There are two
different disinfection options: 65°C for 10min or 71°C for 3min.
Sluice low* 65°C Load ratio/Load
size
Fabric Heavily soiled personal clothing, towelling and
bed linen
Programme sequence
Extras Soak, Intensive, Rinse plus, Fill stop, Rinse hold
Sluice high* 71°C
Fabric Heavily soiled personal clothing, towelling and
Programme sequence
Extras Soak, Intensive, Rinse plus, Fill stop, Rinse hold
* Only included in the DV (drain valve) model
2 pre-rinse cycles
Pre-wash 60°C, 5min
Disinfection 65°C, holding time 10min
3 rinse cycles
Final spin
bed linen
2 pre-rinse cycles
Pre-wash 60°C, 5min
Disinfection 71°C, holding time 3min
3 rinse cycles
Final spin
1:15
PWM909 –
5.4kg
41
Page 42
Programme summary
Programme sequence Sluice
Sluice low65°C
Programme
stage
Load-to-
liquor ratio *
Thermostop Temperature Temperature
holding time
(wash time
Programmed
wash time
approx.
2)
Pre-rinse1 1:7 No Cold - 5min
Pre-rinse2 1:7 No Cold - 4min
Pre-wash 1:7 Yes 60°C 5min 1-minute spin at 500rpm
Disinfection 1:5 Yes 65°C 10min - **
2-minute spin at 800rpm
Rinse1 1:5 No Cold - 5min
1-minute spin at 800rpm 5min
Rinse2 1:5 No Cold - 5min
1-minute spin at max. speed
Rinse3 1:4 No Cold - 5min
5-minute spin at max. speed
Sluice71°C
Pre-rinse1 1:7 No Cold - 5min
Pre-rinse2 1:7 No Cold - 4min
Pre-wash 1:7 Yes 60°C 5min 1-minute spin at 500rpm
Disinfection 1:5 Yes 71°C 3min - **
2-minute spin at 800rpm
Rinse1 1:5 No Cold - 5min
1-minute spin at 800rpm
Rinse2 1:5 No Cold - 5min
1-minute spin at max. speed
Rinse3 1:4 No Cold - 5min
5-minute spin at max. speed
* Depending on load and fabric type
** Depending on type of heating and, with hot water connection, the hot water temperature
42
Page 43
Programme summary
Programme overview: Eco programmes
The Eco programmes are optional programmes that can be downloaded online.
Colours Eco 40°C (Cold to 40°C) Load ratio/load
size
Fabric Lightly soiled cotton, linen and mixed fibre fabrics,
e.g. bed linen and towelling
Programme sequence
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
Colours Eco intensive 40°C (Cold to 40°C) Load ratio/load
Fabric Normally soiled cotton, linen and mixed fibre fab-
Programme sequence
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
Main wash up to 40°C, wash time 11min
2rinse cycles
Last rinse cycle cold
Final spin
plus, Fill stop, Rinse hold
rics, e.g. bed linen and towelling
Main wash up to 40°C, wash time 26min
2rinse cycles
Last rinse cycle cold
Final spin
plus, Fill stop, Rinse hold
1:9
PWM909 – 9kg
size
1:9
PWM909 – 9kg
43
Page 44
Programme summary
Minimum iron Eco 30°C (Cold to 30°C) Load ratio/load
size
Fabric Lightly soiled synthetic and mixed fibre fabrics
Programme se-
quence
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
Minimum iron Eco intensive 30°C (Cold to 30°C) Load ratio/load
Fabric Lightly soiled synthetic and mixed fibre fabrics
Programme se-
quence
Extras Pre-wash, Soak, Water plus, Intensive, Rinse
Main wash up to 30°C, wash time 7min
2rinse cycles
Final spin
plus, Fill stop, Rinse hold
Main wash up to 30°C, wash time 22min
2rinse cycles
Final spin
plus, Fill stop, Rinse hold
1:20
PWM909 – 4kg
size
1:20
PWM909 – 4kg
44
Page 45
45
Page 46
Malaysia
Miele Sdn Bhd
Suite 12-2, Level 12
Menara Sapura Kencana Petroleum
Solaris Dutamas No. 1, Jalan Dutamas 1
50480 Kuala Lumpur, Malaysia
Phone: +603-6209-0288
Fax: +603-6205-3768
Miele New Zealand Limited
IRD 98 463 631
8 College Hill
Freemans Bay, Auckland 1011, NZ
Tel: 0800 464 353
Internet: www.miele.com.au/professional
E-mail: professional.sales@miele.com.au
New Zealand
Miele Pte. Ltd.
29 Media Circle, #11-04 ALICE@Mediapolis
Singapore 138565
Tel: +65 6735 1191, Fax: +65 6735 1161
E-Mail: info@miele.com.sg
Internet: www.miele.sg
Singapore
Miele (Pty) Ltd
63 Peter Place, Bryanston 2194
P.O. Box 69434, Bryanston 2021
Tel: (011) 875 9000, Fax: (011) 875 9035
E-mail: info@miele.co.za
Internet: www.miele.co.za
South Africa
Miele Appliances Ltd.
Showroom 1, Eiffel 1 Building
Sheikh Zayed Road, Umm Al Sheif
P.O. Box 114782 - Dubai
Tel. +971 4 3044 999, Fax. +971 4 3418 852
800-MIELE (64353)
E-Mail: info@miele.ae
Website: www.miele.ae
United Arab Emirates
United Kingdom
Miele Co. Ltd., Fairacres, Marcham Road
Abingdon, Oxon, OX14 1TW
Professional Sales, Tel: 0845 365 6608
E-mail: professional@miele.co.uk
Internet: www.miele.co.uk/professional
Miele Australia Pty. Ltd.
ACN 005 635 398, ABN 96 005 635 398
Level 4, 141 Camberwell Road, Hawthorn East, VIC 3123
Tel: 1300 731 411
Internet: www.miele.com.au/professional
E-mail: professional.sales@miele.com.au
Australia
Miele Electrical Appliances Co., Ltd.
1-3 Floor, No. 82 Shi Men Yi Road
Jing' an District, 200040 Shanghai, PRC
Tel: +86 21 6157 3500, Fax: +86 21 6157 3511
E-mail: info@miele.cn, Internet: www.miele.cn
China Mainland
Miele (Hong Kong) Ltd.
41/F - 4101, Manhattan Place
23 Wang Tai Road, Kowloon Bay, Hong Kong
Tel: (852) 2610 1025, Fax: (852) 3579 1404
Email: customerservices@miele.com.hk
Website: www.miele.hk
Hong Kong, China
Miele India Pvt. Ltd.
1st Floor, Copia Corporate Suites,
Commercial Plot 9, Mathura Road, Jasola,
New Delhi - 110025
E-mail: customercare@miele.in, Website: www.miele.in
India
Miele Ireland Ltd.
2024 Bianconi Ave., Citywest Business Campus,
Dublin 24
Tel: (01) 461 07 10, Fax: (01) 461 07 97
E-Mail: info@miele.ie, Internet: www.miele.ie
Ireland
Manufacturer: Miele & Cie. KG, Carl-Miele-Straße 29, 33332 Gütersloh, Germany
Alteration rights reserved / Publication date: 2023-12-19 M.-Nr. 12 341 780 / 01
Loading...
