Miele PWM 507 Operating instructions

Operating and installation Instructions Washing machine

To avoid the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time.

en-AU, NZ M.-Nr. 11 213 000

Contents

Caring for the environment .............................................................................. 6

Warning and Safety instructions...................................................................... 7

Operating the washing machine ...................................................................... 15

Control panel....................................................................................................... 15

Symbols on the control panel ............................................................................. 16

Symbols in the display ........................................................................................ 17

Sensor controls and touch display with sensor controls .................................... 18

Main menu........................................................................................................... 18

Examples on how to operate the appliance........................................................ 19

Using for the first time ...................................................................................... 20

1. Preparing the laundry.................................................................................... 24

2. Loading the washing machine ..................................................................... 25

3. Selecting a programme ................................................................................ 26

4. Selecting programme settings..................................................................... 27

5. Adding detergent........................................................................................... 29

Adding fabric softener or liquid starch separately.......................................... 30

Adding starch separately................................................................................ 30

6. Starting the programme - the end of the programme ............................... 33

Delay start .......................................................................................................... 34

Programme chart .............................................................................................. 35

Special programmes ........................................................................................... 37

Programme packages ......................................................................................... 39

Extra options...................................................................................................... 46

Pre-wash....................................................................................................... 46

Soak .............................................................................................................. 46

Pre-rinse........................................................................................................ 46

Pre-ironing ...................................................................................................... 46

Rinse plus ..................................................................................................... 46

Special features in the programme sequence................................................ 47

Spinning .............................................................................................................. 47

Anti-crease .......................................................................................................... 47

Contents

Changing the programme sequence............................................................... 48

Changing a programme....................................................................................... 48

Cancelling a programme ..................................................................................... 48

Switching on the washing machine after an interruption to the power supply ... 48

Adding or removing laundry ................................................................................ 49

Cleaning and care ............................................................................................. 50

Cleaning the external casing and fascia panel.................................................... 50

Cleaning the detergent dispenser drawer ........................................................... 50

Cleaning the drum, suds container and drainage system................................... 52

Cleaning the filters in the water inlet ................................................................... 52

Problem solving guide ...................................................................................... 54

The programme does not start............................................................................ 54

Programme cancellations and fault messages ................................................... 55

A fault message appears in the display .............................................................. 56

An unsatisfactory wash result ............................................................................. 57

General problems with the washing machine ..................................................... 58

The door will not open......................................................................................... 60

Opening the door in the event of a blocked drain outlet and/or power cut ........ 61

After sales service............................................................................................. 64

Contact in case of fault ....................................................................................... 64

Optional accessories........................................................................................... 64

Installation.......................................................................................................... 65

Front view............................................................................................................ 65

Rear view............................................................................................................. 66

Installation locations............................................................................................ 67

Installation notes ................................................................................................. 67

Transporting the washing machine to its installation site.................................... 68

Installation surface .............................................................................................. 69

Removing the transit bars ................................................................................... 69

Refitting the transit bars ...................................................................................... 71

Aligning the washing machine............................................................................. 71

Securing the washing machine to the plinth .................................................. 72

External control equipment ................................................................................. 72

Payment system............................................................................................. 72

Water connection ................................................................................................ 73

Cold water connection .................................................................................. 73

Hot water connection*.................................................................................... 74

Contents

Drainage .............................................................................................................. 75

Drain valve...................................................................................................... 75

Drain pump..................................................................................................... 75

Electrical connection ........................................................................................... 76

Technical data.................................................................................................... 77

Supervisor level ................................................................................................. 78

Code-based access ............................................................................................ 78

Changing the code.............................................................................................. 78

Opening the Supervisor level .............................................................................. 78

Exiting the Supervisor level ................................................................................. 78

Language............................................................................................................. 79

Brightness ........................................................................................................... 79

Clock display....................................................................................................... 79

Finish tone volume .............................................................................................. 79

Keypad tone ........................................................................................................ 79

Welcome tone volume......................................................................................... 79

Fault alarm........................................................................................................... 79

Memory ............................................................................................................... 79

Anti-crease .......................................................................................................... 80

Suds cooling........................................................................................................ 80

Delay start ........................................................................................................... 80

Programme name................................................................................................ 80

Pre-wash water ................................................................................................... 81

Main wash water ................................................................................................. 81

First rinse water................................................................................................... 81

Final rinse water .................................................................................................. 81

Low water pressure............................................................................................. 82

Empty sensor ...................................................................................................... 82

Early warning counter.......................................................................................... 82

Water level Cottons............................................................................................. 82

Water level Minimum iron.................................................................................... 82

Pre-wash temp. Cottons ..................................................................................... 82

Wash time pre-wash............................................................................................ 83

Wash time Cottons.............................................................................................. 83

Wash time Minimum iron..................................................................................... 83

Pre-rinse Cottons ................................................................................................ 83

Pre-rinse Minimum iron ....................................................................................... 83

Pre-wash Cottons/Min. iron ................................................................................ 83

Contents

Cottons rinses ..................................................................................................... 83

Minimum iron rinses ............................................................................................ 84

Disinfection rinse................................................................................................. 84

Programme packages ......................................................................................... 84

Temperature reduction ........................................................................................ 85

Disinfection prog. code ....................................................................................... 85

Auto load control................................................................................................. 85

CapDosing........................................................................................................... 85

Pre-ironing........................................................................................................... 85

Automatic dispensing.......................................................................................... 86

Peak load signal .................................................................................................. 86

Peak load prevention........................................................................................... 86

Alternating current............................................................................................... 86

Heater.................................................................................................................. 86

Payment system.................................................................................................. 87

Settings for payment systems........................................................................ 87

Feedback signal to pay system ...................................................................... 87

Payment system lock ..................................................................................... 88

Clear paid signal............................................................................................. 88

FOC programmes........................................................................................... 88

Caring for the environment

Disposal of the packing material

The transport and protective packaging has been selected from materials which are environmentally friendly for disposal, and can normally be recycled.

Recycling the packaging reduces the use of raw materials in the manufacturing process and also reduces the amount of waste in landfill sites. Ensure that any plastic wrappings, bags etc. are disposed of safely and kept out of the reach of babies and young children. Danger of suffocation.

Disposing of your old appliance

Electrical and electronic appliances often contain valuable materials. They also contain specific materials, compounds and components, which were essential for their correct function and safety. These could be hazardous to human health and to the environment if disposed of with your domestic waste or if handled incorrectly. Please do not, therefore, dispose of your old appliance with your household waste.

Please dispose of it at your local community waste collection / recycling centre for electrical and electronic appliances. You are also responsible for deleting any personal data that may be stored on the appliance prior to disposal. Please ensure that your old appliance poses no risk to children while being stored prior to disposal.

Warning and Safety instructions

This washing machine complies with all current local and national safety requirements. However, inappropriate use can lead to personal injury and damage to property.

Read the operating instructions carefully before using the washing machine. They contain important information on safety, installation, use and maintenance of the appliance. This prevents both personal injury and damage to the washing machine.

In accordance with standard IEC60335-1, Miele expressly and strongly advises that you read and follow the instructions in “Installation”, as well as in the “Warning and Safety instructions”.

Miele cannot be held liable for injury or damage caused by noncompliance with these instructions.

Keep these operating instructions in a safe place and pass them on to any future owner.

When instructing other people how to use the washing machine, they must be made aware of these Warning and Safety instructions.

Correct application

 The washing machine is only suitable for washing fabrics with a

care label stating that they are suitable for machine washing. Any other applications may be dangerous. The manufacturer cannot be held liable for damage resulting from incorrect or improper use or operation of the machine.

 This washing machine must be used as described in the operating

instructions and must be checked on a regular basis to make sure it is functioning correctly. Maintenance must be carried out when necessary.

 The washing machine is not suitable for outdoor use.

Warning and Safety instructions

 This washing machine is intended for commercial use in small

businesses, care homes, sports clubs, hospitals and other similar commercial environments. This machine may also be operated by lay persons in public areas such as laundrettes, communal laundry rooms or similar.

 This washing machine is not intended for use by persons

(including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning its use by a person responsible for their safety.

 Young children must not be allowed to use this appliance.  Older children may only use the appliance when its operation has

been clearly explained to them and they are able to use it safely. They must be able to understand and recognise the possible dangers caused by incorrect operation.

 Cleaning or maintenance on the washing machine may only be

carried out by older children under the supervision of an adult.

 Always supervise any children in the vicinity of the washing

machine. Never allow children to play with the washing machine.

 Disinfection programmes must not be interrupted, as this can

have a limiting effect on the disinfection result. It is the operator's responsibility to ensure that the standard of disinfection in thermal as well as chemo-thermal procedures is maintained by carrying out suitable validation tests.

Warning and Safety instructions

Technical safety

 Before installing and operating the washing machine, check it for

any visible exterior damage. Do not set up or use a damaged washing machine.

 The electrical safety of this washing machine can only be

guaranteed when continuity is complete between it and an effective earthing system which complies with current local and national safety regulations. It is most important that this basic safety requirement is present and regularly tested and, when there is any doubt, the on-site wiring system should be inspected by a qualified electrician. Miele cannot be held liable for the consequences of an inadequate earthing system (e.g. electric shock).

 Unauthorised repairs could result in unforeseen dangers for the

user, for which the manufacturer cannot accept liability. Repairs must only be carried out by a Miele authorised service technician, otherwise any subsequent damage will not be covered by the warranty.

 Do not make any alterations to the machine, unless authorised to

do so by Miele.

 In the event of a fault or for cleaning purposes, the washing

machine must be isolated from the electricity supply. It is only completely isolated if:

– it is switched off at the wall socket and the plug is withdrawn, or

– the mains fuse is disconnected, or

– it is switched off at the mains circuit breaker.

For further information see “Installation - Electrical connection”.

Warning and Safety instructions

 If the electrical connection cable is faulty, it must only be replaced

by a Miele authorised service technician to protect the user from danger.

 The washing machine must be connected to the water supply

using the new hose set supplied with the appliance. Old hose sets should not be re-used. Check the hose regularly for signs of wear. Replace it in good time to avoid the risk of leaks and water damage.

 Faulty components must only be replaced by genuine Miele

original spare parts. Miele can only guarantee the safety standards of the machine when Miele replacement parts are used.

 Do not connect the machine to the mains electricity supply by a

multi-socket adapter, extension lead or similar. These do not guarantee the required safety of the machine (fire hazard due to the risk of overheating).

 The machine must not be installed and operated in mobile

locations (e.g. on a ship).

 Please observe the instructions in “Installation” and “Technical

data”.

 If the washing machine is equipped with a mains plug, it must be

easily accessible after installation so that the machine can be disconnected from the electricity supply if necessary.

Warning and Safety instructions

 If the appliance is hard wired, an on-site dual circuit breaker must

be accessible at all times in order to disconnect the washing machine from the mains supply. The means of disconnection must be incorporated in the fixed wiring in accordance with the wiring rules.

 This washing machine is supplied with a special lamp to cope

with particular conditions (e.g. temperature, moisture, chemical resistance, abrasion resistance, and vibration). This special lamp must only be used for the purpose for which it is intended. It is not suitable for room lighting. Replacement lamps may only be installed by a Miele authorised technician or by Miele.

 Reliable and safe operation of this washing machine is only

ensured if it has been connected to the mains electricity supply.

Correct use

 The maximum load is 7.0kg (dry laundry). See the “Programme

chart” for the maximum recommended loads for individual programmes.

 Do not install your washing machine in a room where there is a

risk of frost. Frozen hoses may burst or split, and the reliability of the electronic control unit may be impaired at temperatures below freezing point.

 Before using the machine for the first time, check that the transit

bars at the rear of the washing machine have been removed (see “Installation and connection – Removing the transit bars”). During spinning, transit bars which are still in place can cause damage to both the machine and adjacent furniture or appliances.

 Turn off the tap if the machine is to be left for any length of time

(e.g. while on holiday), especially if there is no floor drain (gully) in the immediate vicinity.

Warning and Safety instructions

 If the ventilation openings are in the base of the washing

machine, ensure that they are not obstructed by deep-pile carpet or similar.

 Danger of flooding! If hooking the drain hose into a laundry

washtub, check that the water can drain away fast enough to prevent the laundry tub from overflowing. Secure the drain hose against slipping. The force of the water flowing out of the hose can dislodge it.

 Make sure that no foreign objects (e.g. nails, pins, coins, paper

clips) find their way into the machine with the laundry. Foreign objects can damage components of the machine (e.g. suds container, drum). Damaged components can, in turn, result in damage to the laundry.

 If the correct amount of detergent is dispensed, the machine

should not need to be descaled. If, however, you do wish to descale it, only use special non-corrosive descaling agents and strictly observe the instructions on the packaging. Special descaling agent is available from your Miele dealer or from Miele. Strictly observe the instructions for the packaging.

 For textiles that have been treated with solvent-based cleaning

agents, always check whether they can be washed in a washing machine. To check whether this is possible, refer to safety notes, information concerning the product's environmental compatibility, and other information.

 Never use solvent-based detergents, e.g. those containing

benzine, in this washing machine. This may result in damage to component parts and create toxic fumes. Risk of fire and explosion!

 Gasoline, petroleum, kerosene, paraffin, or any easily flammable

liquid must not be stored or used near the washing machine. Risk of fire and explosion!

Warning and Safety instructions

 Only use dyes suitable for use in a washing machine. Always

observe the manufacturer's instructions carefully.

 Dye removers contain sulphur compounds which can cause

damage such as corrosion. Dye removers must not be used in the washing machine.

 Avoid contact between stainless steel surfaces (front, lid, casing)

and liquid detergents or disinfecting agents which contain chlorine or sodium hypochlorite. These agents can cause corrosion on stainless steel. Aggressive vapours containing chlorine can also be corrosive. Do not store open containers of these agents near the machine.

 Do not use a high-pressure cleaner or water jet to clean the

washing machine.

 It is particularly important to observe the manufacturer's

instructions when using a combination of cleaning agents and special application products. Products must only be used for applications approved by the manufacturer to avoid any material damage or the occurrence of strong chemical reactions.

 If detergent has come into contact with the eyes, rinse out

immediately with plenty of lukewarm water. If detergent has accidentally been ingested, seek medical advice immediately. People with damaged or sensitive skin should avoid contact with detergent.

 When adding or removing laundry during the main wash, your skin

may come into contact with detergent, particularly if the detergent is dispensed externally. Take care when placing your hands inside the drum. If suds have come into contact with the skin, rinse off immediately with lukewarm water.

Warning and Safety instructions

Accessories

 Only use genuine Miele spare parts and accessories with this

machine. Using spare parts or accessories from other manufacturers will invalidate the warranty, and Miele cannot accept liability.

 Miele tumble dryers and Miele washing machines can be installed

as a washer-dryer stack. This requires a Miele washer-dryer stacking kit which can be purchased separately. Please ensure that the washer-dryer stacking kit is suitable for your Miele tumble dryer and your Miele washing machine.

 If installing the machine on a Miele plinth (available as an optional

accessory), please make sure you order the correct one for this washing machine.

Miele cannot be held liable for damage caused by non-compliance with these Warning and Safety instructions.

Control panel

Operating the washing machine

Language  sensor control

For selecting the current user language. The operating language is displayed again at the end of the programme.

Touch display with sensor controls

Displays the selected programme. The programme settings are selected using the sensor controls in the touch display.

Back  sensor control

Takes you back one level in the menu.

Start/Stop sensor control For starting the selected programme and cancelling a programme that has already started.

Programme selector

For selecting the wash programme. The programme selector can be turned clockwise or anti-clockwise.

 button For switching the washing machine on and off. The washing machine switches itself off automatically to save energy. This occurs 15 minutes after the end of the programme/anti-crease phase, or after being switched on if no further selection is made.

Operating the washing machine

Symbols on the control panel

 Cottons

PRO Cottons PRO

 Special programmes  Express  Minimum iron  Delicates  Cottons / Drain/Spin

Symbols in the display



























Temperature: Use the Temperaturesensor control to set the temperature of the wash programme.

Spin speed: Use the Spin speedsensor control to set the spin speed of the wash programme.

Extras: Use the Extrassensor control to add Extras to a wash programme.

Pre-wash: Use the Pre-washsensor control to select the Pre-washExtra for a wash programme.

Pre-ironing: Use the Pre-ironingsensor control to select the Pre- ironingExtra for a wash programme.

Soak: Use the Soaksensor control to select the SoakExtra for a wash programme.

Rinse plus: Use the Rinse plussensor control to add an additional rinse cycle to a wash programme.

Further selections: Use the Further selectionssensor control to select further options.

Operating the washing machine

CapDosing: Use the CapDosingsensor control to dispense detergent via

a capsule.

Supervisor level: Use the Supervisor levelsensor control to alter the washing machine's settings.

Delay start: Use the Delay startsensor control to set the start time of a wash programme...

...or the finish time

...or the time until the programme starts.

Operating the washing machine



1600

 

Coloured items

60°C

0:59



1000

 

Sportswear

0:37



60°C

Sensor controls and touch display with sensor controls

The, andStart/Stopsensors and the sensor controls in the display react to finger contact. Every touch of a sensor is confirmed by an audible tone. You can adjust the volume of the keypad tone or switch it off (see “Supervisor level”).

The control panel with the sensor controls and the touch display can be scratched by pointed or sharp objects, e.g. pens.

Only touch the display with your fingers.

Main menu

The main menu of a wash programme displays different values depending on the programme.

For programmes with a fixed temperature setting:

– the selected programme with the set

temperature

– the programme duration

– the spin speed set

– the selectable Extras

– further options available and the

settings in the Supervisor level

For programmes with a variable temperature setting:

– the selected programme

– the programme duration

– the temperature set

– the spin speed set

– the selectable Extras

– further options available and the

settings in the Supervisor level

Operating the washing machine



Language





deutsch

čeština

english

(AU)

dansk



Spin speed

800

1000

400

1200

1600

Finish

(today)











25:

Examples on how to operate the appliance

Selection lists

The andarrows on the right of the display indicate that further choices are available.

The list scrolls down when the sensor control is touched. The list scrolls up when the sensor control is touched.

The scroll bar indicates that further options follow.

The currently selected value is marked with a frame.

Touch the required value to select it.

Setting numerical values

To change a numerical value, use the andarrows above or below the numbers you want to change.

Touch theandarrows and confirm with the OK sensor.

Exiting a submenu

Select the backsensor to exit a submenu.

If a value is selected in a submenu but not confirmed with OK, this value is discarded by selecting the sensor control.

Single selection

If there are no arrows, the selection is limited to the displayed values.

The currently selected value is marked with a frame.

Touch the required value to select it.

Using for the first time



Language





deutsch

čeština

english

(AU)

dansk

 Damage resulting from incorrect

installation and connection. Installing and connecting the

washing machine incorrectly will cause serious damage to property.

Please observe the instructions in “Installation and connection”.

Emptying the drum

A swivel elbow for the drain hose and/ or assembly material may be stored in the drum.

When commissioning the washing machine for the first time, you will have to define the settings for the daily use of the appliance. Some settings can only be configured during the initial commissioning process. After that, they must be changed by Miele.

Complete the initial commissioning process.

These settings are also described in “Supervisor level”.

Setting the display language

You will be asked to select the language for the display. You can change the language at any time (see “Supervisor level - Language”).

 Pull open the door.  Remove the swivel elbow and

assembly material.

 Shut the door with a gentle swing.

Switching on the washing machine

 Press the  button.

The welcome screen will light up.

 Touch the orsensor until the

language you want appears in the display.

 Touch the sensor for the required

language.

The selected language is marked with a frame and the display will change to the next setting.

Using for the first time

Brightness

–



Yes No

Should the clock display not

be shown?

Time











05:



Programme

packages





Sport

Outerwear





Sport





Trainers

Confirm selection

Setting the display brightness

 Set the desired brightness with the –

and + sensors and confirm your selection with the OKsensor.

The display will change to the next setting.

Confirming the time query

 Touch the Yes or No sensor. If you select Yes, the system will skip

the Clock displaysetting. If you select No, the display will switch

to the Clock displaysetting.

Setting the time of day

 Use the andsensor controls to

enter the time and confirm your entry with the OK sensor.

The display will change to the next setting.

Selecting programme packages

 Touch the orsensor control until

the programme package you want appears in the display.

 Touch the sensor control of the

programme package.

The display will show the associated programmes.

The activated programmes are marked with a frame.

 Touch the sensors for the

programmes.

Using for the first time



Programme

packages





Disinfection



Continue





Payment

system





No payment system

Programme control



Pre-wash

water

Cold

Hot



Main wash

water

Cold

Hot

The programmes are activated (framed) or deactivated (no frame).

 Confirm with the OK sensor.

The display switches back to the programme packages.

 Select other programme packages or

confirm your selection with the

Nextsensor control.

The display will change to the next setting.

Setting up a payment system

If you wish to set up a payment system, read the chapter “Supervisor level Payment system”.

If you do not wish to set up a payment system, you can skip this step.

Selecting pre-wash water

 Touch the Coldsensor if the washing

machine is only connected to the cold water supply, or touch Hotif the washing machine is connected to both cold and hot water.

The display will change to the next setting.

Selecting main wash water

 Touch the Coldsensor if the washing

machine is only connected to the cold water supply, or touch Hotif the washing machine is connected to both cold and hot water.

 Touch the No payment system sensor.

The display will change to the next setting.

Further information will appear in the display.

Using for the first time



1600

 

Coloured items

60°C

0:59

Removing the transit bars

The display will remind you to remove the transit bars.

 Damage resulting from failure to

remove the transit bars. Failure to remove the transit bars can

result in damage to the washing machine and to adjacent cabinetry or appliances.

Remove the transit bars as described in “Installation and connection”.

 Confirm that the transit bars have

been removed with the OKsensor.

The following appears in the display:

Continue setting up as described in the Operating instructions

 Confirm the message with the OK

sensor.

Completing the commissioning process

To complete commissioning, the Cottons 60°Cprogramme must be run without laundry and without detergent.

If the power is interrupted prior to the start of the first wash programme (e.g. if the machine is switched off with the  button), the initial commissioning process can be completed again. Once a wash programme has been running for over 20minutes, the initial commissioning process does not need to be performed again.

 Turn on the water taps.  Turn the programme selector

toCottons 60°C.

 Touch the Start/Stop sensor.

When the programme has finished, your machine is ready for use for the first time.

If you have activated disinfection programmes, you must complete the Thermal disinfectionprogramme as the first programme; make sure you use a suitable detergent but do not load the machine.

1. Preparing the laundry

Emptying all pockets

 Empty all pockets.

 Damage due to foreign objects.

Foreign objects (e.g. nails, coins, paper clips etc.) can cause damage to garments and to components in the machine.

Check the laundry before washing and remove any foreign objects.

Sorting the laundry

 Sort the laundry by colour and by

care label. Most garments have a textile care label in the collar or side seam.

Pre-treating stains

 Clean badly soiled areas and stains

on the textiles before washing. Spillages should be carefully dabbed off using a soft, colourfast cloth.

 Damage due to solvent-based

cleaning agents. Cleaning agents containing benzine,

stain remover, etc., can damage plastic parts.

When pre-treating garments, make sure that any plastic parts (e.g. buttons) do not come into contact with cleaning agent.

 Risk of explosion due to solvent-

based cleaning agents. If solvent-based cleaning agents are

used, an explosive mixture can form. Never use solvent-based cleaning

agents in the washing machine.

General tips

– Do not wash any items in this

machine which are specified by the manufacturer as not washable on the care label ( symbol).

– Curtains: Remove lead weights first

or place in a laundry bag.

– Remove or sew in any loose

underwiring in bras or shirt collar stiffeners.

– Turn garments inside out, if

recommended by the manufacturer.

– Close any zips and Velcro fasteners

before washing.

– Fasten duvet covers and pillow cases

to prevent small items from being rolled up inside them.

– Please refer to the Programme chart

for more tips.

2. Loading the washing machine

Opening the door

 Reach under the door grip and pull

the door open.

Check the drum for pets or foreign objects before loading it with laundry.

 Unfold the laundry and load loosely in

the drum.

Mixing both large and small items gives better wash results and helps distribute the load evenly during spinning.

Closing the door

 Make sure that no items are caught

between the door and the seal.

The most efficient use of energy and water is achieved when a full load is washed. However, do not overload as this reduces cleaning efficiency and causes creasing.

 Shut the door with a gentle swing.

3. Selecting a programme



Special

progs





Sportswear

SportMicrofibre

Switching on the washing machine

 Press the  button.

The interior drum lighting will come on.

The drum lighting will go out automatically after five minutes or after the programme start.

Selecting a programme

Selecting standard programmes with the programme selector

Selecting special programmes via the programme selector position

 Turn the programme selector to the

position.

You can select the required programme via the display.

 Turn the programme selector to the

required programme.

The selected programme will be shown in the display. The display will then change to the main menu for that programme.

 Touch the orsensor control until

the programme you want appears in the display.

 Touch the sensor for that programme.

The display will change to the main menu for that programme.

4. Selecting programme settings



Temp.

40°C 60°C30°C



Spin speed

800

1000

400

1200

1600



Extras

Pre-wash

Rinse plus





Selecting the temperature

You can alter the preset temperature of certain programmes.

 Touch the Temperaturesensor.

The following will appear in the display:

 Select the desired temperature.

The selected temperature is marked with a frame.

Selecting the spin speed

You can alter the preset spin speed.  Touch the Spin speedsensor.

The following will appear in the display:

Selecting Extras

You can select Extras for the wash programmes.

For some programmes, an Extra is offered directly in the main menu.

 Touch the sensor of the Extra to

activate it.

For some programmes, you select Extras in the Extrassubmenu.

 Touch the Extrassensor.

 Select one or two of the available

Extras in succession.

Not all Extras can be selected with every programme. If an Extra is not listed, it is not permitted for use with this wash programme.

 Select the desired spin speed.

The selected spin speed is marked with a frame.

4. Selecting programme settings



Further

selections





CapDosing

Finish at





Selecting further options

You can activate CapDosing, select a delay start time or change the settings of the washing machine.

 Touch the sensor.

The following will appear in the display:

 Select the desired option.

The display will change to the submenu for that option.

Delay startand CapDosingare not possible for some programmes.

5. Adding detergent

There are several options for adding detergent.

Detergent dispenser drawer

Any detergent suitable for automatic front loading washing machines can be used with this appliance.

Detergent dispensing

Please follow the detergent manufacturer's instructions in relation to dosage.

Adding too much detergent will lead to excessive foaming.

Avoid adding excess detergent.

The amount to dispense will depend on:

– the amount of laundry

– the degree of soiling of the laundry

– the water hardness

Water

hardness

range

soft (I) 0-1.5 0-8.4

medium (II) 1.5-2.5 8.4-14

hard (III) above 2.5 above 14

Check with your local water supplier if you do not know the water hardness in your area.

Hardness in

mmol/l

German scale

°dH

Adding detergent

 Pull out the detergent dispenser

drawer and add detergent to the compartments.

 Detergent for the pre-wash

(divide the total recommended amount as follows: ⅓ to compartment and ⅔ to compartment )

 Detergent for the main wash /Fabric softener, liquid starch or

capsules

For disinfection programmes, the andcompartments can be filled with detergent for the main wash if you have not selected Pre-wash.

5. Adding detergent

Adding fabric softener or liquid starch separately

 Select the Separate rinseprogramme.  Change the spin speed if necessary.

 Add the fabric softener or the liquid

starch to the compartment. Do not exceed the maximum level mark.

 Touch the Start/Stopsensor.

This will be automatically dispensed in the final rinse. At the end of the wash programme a small amount of water remains in the  compartment.

Adding starch separately

 Prepare the starch solution in

accordance with the manufacturer’s instructions on the packaging.

 Select the Starchprogramme.  Add the prepared starch to the

compartment.

 Touch the Start/Stopsensor.

Useful tip: If starching separately or automatically, thoroughly clean the detergent dispenser compartment, especially the siphon, regularly.

Dye removers and dyes

 Damage due to colour run/dye

removers. Colour run and dye removers can

cause corrosion in the washing machine.

Do not use colour run or dye removers in this washing machine.

Only use dyes suitable for use in a washing machine. The manufacturer's instructions on the packaging must be observed.

5. Adding detergent

CapDosing

Three different types of capsules are available:

 = Fabric care (e.g. fabric

softener, proofing agent)

 = Additives (e.g. detergent

enhancers)

 = Detergent (for the main wash

only)

Only one capsule can be selected per wash programme.

Depending on the setting selected, the detergent, additive, or fabric care agent will be dispensed via the capsule for this wash programme.

Each capsule contains the correct amount for one wash cycle.

Capsules are available to order from Miele or from the Miele online shop (see the end of this booklet for contact details).

Activating CapDosing

 Touch the Further

selectionssensor control.

 Touch the CapDosing sensor.

The types of capsules which can be used with the programme will appear in the display.

 Select the type of capsule you want

to use.

The display switches to the main menu and shows the selected capsule.

Inserting a capsule

 Open the detergent dispenser drawer.

 Capsules pose a health risk.

The ingredients of capsules can be hazardous to health if they are swallowed or come into contact with skin.

Keep capsules out of the reach of children.

 Open the lid of the /

compartment.

5. Adding detergent

The wash programme will dispense the contents of the capsule at the correct time.

Water intake to the  compartment is solely via the capsule.

When using capsules do not add fabric softener to the compartment.

 Remove the empty capsule at the

end of the wash programme.

 Press the capsule in firmly.

 Close the lid and press it firmly shut.  Close the detergent dispenser

drawer.

The capsule is opened by the act of inserting it in the detergent dispenser compartment. The contents can run out of the capsule if you remove it before it has been used.

Dispose of opened capsules.

For technical reasons a small amount of water will remain in the capsule.

Deactivating or changing CapDosing

CapDosing can only be deactivated or changed prior to programme start.

 Touch the sensor.  Select CapDosingand disable the

selected capsule.

External dispensing

The washing machine is pre-equipped for connection to an external detergent dispensing system. A separate conversion kit for external dispensing systems is required. This must be fitted by a Miele authorised service technician.

6. Starting the programme - the end of the programme

Payment system

If your machine is connected to a payment system, the amount of payment required will appear in the display.

Do not cancel the programme once it has started. Depending on the settings, credit added in the payment system may be lost when the programme is cancelled.

Starting a programme

The programme can be started once the Start/Stop sensor is flashing on and off.

 Touch the Start/Stop sensor. The door will lock ( symbol) and the

wash programme will start.

If a delay start time has been selected, this will count down in the display until the programme starts.

At the end of the delay start time or immediately after the programme has started, the programme duration will appear in the display. The programme sequence is also shown in the display.

Useful tip: Touch the sensor control to display the set temperature, spin speed and any set Extras.

At the end of the programme

The door remains locked during the anti-crease phase. However, the door can be unlocked at any time by touching the Start/Stop sensor.

Removing the laundry

 Pull open the door.  Remove the laundry.

Items left in the drum could discolour other items in the next wash or become discoloured themselves.

Remove all items from the drum.

 Check the folds in the door seal for

any small articles, e.g. buttons, which might be lodged there.

Useful tip: For safety reasons, close the door when the washing machine is not in use. Otherwise there is a danger of objects being placed inadvertently in the drum. If these remain unnoticed and were washed in the next load, they could damage the laundry. An open door is also a danger to pets and children.

 Switch the washing machine off with

the  button.

 If applicable, remove the used

capsule from the detergent dispenser drawer.

Useful tip: Leave the detergent dispenser drawer slightly open to allow it to dry.

Delay start

Add laundry

Cancel

programme

Start programme

immediately

The Delay start function can be used to set the time until the programme starts or the programme finish time (see “Supervisor level - Delay start”).

Selecting Delay start

 Touch the Further

selectionssensor.

 Select the Finish at, Start at or

Start inoption.

 Use the andsensors to enter the

hours and minutes and confirm your entry with the OKsensor.

The minutes entry moves to the next “full quarter of an hour” and can then be adjusted in 15-minute increments.

Starting Delay start

 Touch the Start/Stopsensor.

The door will lock and the time remaining until the programme starts will appear in the display.

Cancelling or changing Delay start

 Touch the Start/Stop sensor.

The following will appear in the display:

 Touch the Start programme immediately

sensor.

The wash programmes starts immediately.

or  Touch the Cancel programme sensor.

The programme start is cancelled and the Start/Stopbutton flashes on and off.

Programme chart

Standard programmes

Cottons 20°C to 90°C Max. load 7.0 kg

Items Cotton, linen, and mixed fibre textiles

Notes – Select the temperature according to the instructions on the care

label, the detergent, the type of soiling and the hygiene requirements.

– For dark coloured fabrics use a colour detergent or liquid

detergent.

1600 rpm Extras: Pre-wash  Rinse cycles: 1-5*

Cottons PRO 60°C Max. load 7.0 kg

Items Mixed fibre textiles (50% cotton and 50% polyester)

Notes – Extra energy-efficient wash programme for commercial cotton

or cotton/synthetic blend textiles with moderate levels of soiling, e.g. workwear.

1400 rpm Extras: Pre-wash  Rinse cycles: 2  Cottons / Max. load 7.0 kg

Items Cottons, linens or cotton mix fabrics. e. g. table linen, towelling, T-

shirts, underwear

Notes – These settings are the most efficient in terms of energy and

water consumption for washing cottons.

– With, the actual wash temperature reached is lower than

60°C although the wash performance is the same as with the standard Cottons 60°C programme.

1600 rpm Extras: Pre-wash  Rinse cycles: 2 Express 30°C Max. load 3.5 kg

Items Cotton garments that have hardly been worn or are only very

lightly soiled

1400 rpm Extras: Rinse plus  Rinse cycles: 1

*You can alter the number of rinse cycles carried out via the Supervisor level.

Programme chart

Minimum iron 30°C to 40°C Max. load 3.5 kg

Items Synthetic, mixed fibre and easy care cotton fabrics

Notes – Reduce the final spin speed for fabrics which crease easily. 1200 rpm Extras: Pre-wash, Pre-ironing Rinse cycles: 2-4* Delicates 30°C Max. load 2.5 kg

Items Delicate garments made from synthetic fibres, mixed fibre, rayon

and viscose

Notes – Deselect the final spin speed for fabrics which crease easily. 600 rpm Extras: Pre-wash, Pre-ironing Rinse cycles: 2 / Drain/Spin Max. load 7.0 kg

Notes – Make sure you select the appropriate spin speed.

– Select the Rinse plusExtra for an additional rinse cycle.

– Drain only: Select 0 rpm for the spin speed.

1600 rpm Extras: Rinse plus 

*You can alter the number of rinse cycles carried out via the Supervisor level.

Programme chart

Special programmes

Towelling 40°C to 60°C Max. load 7.0 kg

Items Towels and bathrobes made from terrycloth

Notes – Use a colour detergent for dark textiles. 1400 rpm Extras: Pre-wash  Rinse cycles: 2

Shirts 20°C to 60°C Max. load 2.5 kg

Items Shirts and blouses

Notes – Pre-treat collars and cuffs if necessary.

– Wash silk shirts and blouses in the Silks programme.

– Reduce the maximum load quantity by half if you have selected

the Pre-ironingExtra.

800 rpm Extras: Pre-ironing Rinse cycles: 2

Dark garments 30°C to 60°C Max. load 3.5 kg

Items Black and dark garments made from cotton or mixed fibres

Notes – Wash inside out.

1000 rpm Rinse cycles: 3

Denim 30°C to 60°C Max. load 3.5 kg

Items Denim shirts, blouses, trousers, skirts and jackets

Notes – Wash denim inside out.

– Denim often contains excess dye and may run during the first

few washes. Wash light and dark coloured items separately.

1000 rpm Rinse cycles: 3

Woollens Cold to 30°C Max. load 2.5 kg

Items Machine-washable woollens and woollen blends

Notes – Use detergent formulated for woollens.

1200 rpm Rinse cycles: 2

Silks Cold to 30°C Max. load 2.5 kg

Items Silks and hand-washable textiles which do not contain wool

Notes – Observe the instructions on the care label.

– Place stockings and bras in a laundry bag.

600 rpm Extras: Rinse plus  Rinse cycles: 2

Programme chart

Separate rinse Max. load 7.0 kg

Items Fabrics that only need to be rinsed and spun

Notes – Reduce the spin speed for items which crease easily. 1400 rpm Extras: Rinse plus  Rinse cycles: 2

Starch Cold to 40°C Max. load 3.5 kg

Items For starching table cloths, serviettes and workwear

Notes – Laundry that is to be starched should be washed but not treated

with fabric softener.

– Reduce the spin speed for items which crease easily.

1400 rpm Rinse cycles: 1

Clean machine 70°C No load

For cleaning the suds container and the drainage system.

– Add universal detergent to the  compartment.

– Use the Clean machineprogramme regularly if you frequently

use disinfection programmes.

Programme chart

Programme packages

You can select various programmes packages. The programmes selected from the programme packages are displayed under the Special programmeslist.

Sport

Sportswear 30°C to 60°C Max. load 3.0 kg

Items Sports and leisure wear, such as jersey shirts and trousers made

from synthetic fibres or mixed blends

Notes – Do not use fabric softener.

– Observe the instructions on the care label.

1000 rpm Extras: Pre-wash  Rinse cycles: 2

SportMicrofibre 30°C to 60°C Max. load 3.0 kg

Items Clothing for sport and fitness such as jersey shirts, trousers and

base layers made from microfibre

Notes – Do not use fabric softener.

– Observe the instructions on the care label.

800 rpm Extras: Rinse plus  Rinse cycles: 2

Trainers 30°C to 60°C Max. 2 pairs

Items Trainers (no leather shoes), shin pads, elbow protectors and

Outdoor

Down Items 30°C to 60°C Maximum 1item

Items Outdoor jackets, sleeping bags, pillows and other down-filled

items

Notes – Do not use fabric softener.

– Remove any air before washing. To do this, either push the

items into a narrow laundry bag to compress them or tie the items together with a washable strap.

– Observe the instructions on the care label.

– The items are spun after wetting to remove any air.

1400 rpm Extra options: Pre-wash, Rinse plus Rinse cycles: 2

Outerwear Cold to 40°C Max. load 3.0 kg

Items Performance outerwear (e.g. outdoor jackets and pants) made

from membrane fabrics such as Gore-Tex®, SYMPATEX®, WINDSTOPPER® etc.

Notes – Close any zips and Velcro fasteners before washing.

– Do not use fabric softener.

– To maintain the water repellency of the textiles, it may be

necessary to proof them again after washing. Select the Proofingprogramme for this purpose.

– Wash down-filled items with the Down Itemsprogramme.

1000 rpm Extra options: Pre-wash, Rinse plus Rinse cycles: 2

Proofing 30°C to 40°C Max. load 3.0 kg

Items To refresh the proofing of water-repellent textiles, e.g. rainwear, ski

wear or other textiles.

Notes – Add proofing agent to the compartment.

– The items should be freshly laundered and spun or dried before

proofing.

– For best results, the items should be heat-treated afterwards

either in a tumble dryer or by ironing.

800 rpm Rinse cycles: 1

Programme chart

Wellness/Hair salons

Towels 40°C Max. load 5.5 kg

Items Lightly soiled cotton towelling

Notes – Use a colour detergent for dark textiles.

1400 rpm Rinse cycles: 2

Towels plus 40°C to 80°C Max. load 5.5 kg

Items Heavily soiled cotton towelling

Notes – Use a colour detergent for dark textiles. 1400 rpm Extras: Pre-wash  Rinse cycles: 2

Capes Cold to 30°C Max. load 2.0 kg

Items Lightly soiled hairdressers' capes made from synthetic fibres

Notes – Select the Rinse plusExtra for particularly good wash results 600 rpm Extras: Rinse plus  Rinse cycles: 2

Programme chart

Hotel

Bed linen 40°C to 90°C Max. load 7.0 kg

Items Cotton or mixed fibre bed linen

Notes – The items are always soaked after the start.

– Use a colour detergent for coloured textiles.

1200 rpm Extras: Pre-wash, Pre-ironing Rinse cycles: 2

Table linen 40°C to 75°C Max. load 3.5 kg

Items Tablecloths and napkins made from cotton, linen, and mixed fibres

Notes – Select Pre-wash for stubborn stains. Use detergent with

enzymes for the pre-wash.

– The items are always soaked after the start.

1200 rpm Extras: Pre-wash, Pre-ironing Rinse cycles: 2

Kitchen laundry 60°C to 85°C Max. load 7.0 kg

Items Cotton or linen kitchen laundry, e.g. chef's jackets and trousers,

chef's hats, cleaning cloths

Notes – Select Pre-wash for stubborn stains. Use detergent with

enzymes for the pre-wash.

– The pre-wash cycle removes any coarse soiling.

1400 rpm Extras: Pre-wash  Rinse cycles: 3

Programme chart

Home textiles

Lightweight curtains Cold to 40°C Max. load 3.5 kg

Items Curtains specified as machine-washable by the manufacturer

Notes – For curtains which crease easily, deselect the spin speed. 600 rpm Extras: Pre-wash, Rinse plus Rinse cycles: 2

Down bedding 40°C to 75°C 1 duvet

or 1–2 pillows*

Items Down-filled pillows and duvets

Notes – Remove any air before washing. To do this, either push the

items into a narrow laundry bag to compress them or tie the items together with a washable strap.

– Observe the instructions on the care label.

– The items are spun after wetting to remove any air.

1400 rpm Extra options: Soak, Rinse plus Rinse cycles: 2

Synthetic bedding 40°C to 75°C Max.7.0kg

or 1 duvet

or 1–2 pillows*

Items Bed linen made from microfibre, pillows and duvets with a

synthetic filling

Notes – Observe the instructions on the care label.

– Use liquid detergent.

800 rpm Extras: Pre-wash, Rinse plus Rinse cycles: 2

* 1 pillow (80x80cm) or 2 pillows (40x80cm)

Programme chart

Workwear

Oil/fat special 60°C to 90°C Max. load 7.0 kg

Items Work coats, work jackets, hats, cleaning cloths made from cotton

or mixed fibres

Notes – Activate Pre-wash for heavy soiling.

– Use liquid detergent.

1400 rpm Extras: Pre-wash  Rinse cycles: 3

Dust/flour special 40°C to 90°C Max. load 7.0 kg

Items Cotton or mixed fibre workwear, table cloths, or cleaning cloths

soiled with dust or flour

Notes – The automatic pre-rinse removes any coarse soiling. Add a

second pre-rinse for very heavy levels of soiling.

– Select Pre-wash for stubborn stains.

1400 rpm Extras: Pre-wash , Pre-rinse  Rinse cycles: 3

Intensive wash 40°C to 90°C Max. load 7.0 kg

Items Heavily soiled workwear made from cotton, linen, and mixed fibres

Notes – A particularly good wash and rinse result is achieved by a high

water level.

1400 rpm Extras: Pre-wash  Rinse cycles: 2

Programme chart

Disinfection

Disinfection 85°C/15min Max. load 7.0 kg

Items Cotton or mixed fibre textiles

Notes – Thermal disinfection with a 15-minute holding time at 85°C.

– A second disinfection rinse can be activated via the Supervisor

level.

– No water inlet via the fabric softener compartment.

1400 rpm Extras: Pre-wash, Rinse plus Rinse cycles: 2 Disinfection 60°C/20min Max. load 7.0 kg

Items Workwear or disinfection clothing, sorted by colour, provided the

items are suitable for disinfection.

Notes – Chemo-thermal disinfection with a 20-minute holding time at

60°C.

– A second disinfection rinse can be activated via the Supervisor

level.

– No water inlet via the fabric softener compartment.

1400 rpm Extras: Pre-wash, Rinse plus Rinse cycles: 2 Disinfection 40°C/20min Max. load 7.0 kg

Items Workwear or disinfection clothing, sorted by colour, provided the

items are suitable for disinfection.

Notes – Chemo-thermal disinfection with a 20-minute holding time at

40°C.

– No water inlet via the fabric softener compartment.

– Due to the particularly gentle washing process, even more

delicate textiles can be washed in this programme.

1400 rpm Extras: Pre-wash, Rinse plus Rinse cycles: 2

Extra options

You can supplement the wash programmes with Extras.

Not all Extras can be selected with every programme. If an Extra is not listed, it is not permitted for use with this wash programme.

Selecting Extras

For some programmes, an Extra is offered directly in the main menu.

 Touch the sensor of the Extra to

activate it.

For some programmes, Extras are selected in the Extrassubmenu.

 Touch the Extrassensor.  Select one or two of the Extras

available.

Pre-wash

A pre-wash can be added for heavily soiled laundry. Coarse soiling is loosened and removed before the main wash.

Pre-rinse

The laundry is rinsed before the main wash to remove larger quantities of soiling, e.g. dust, sand.

Pre-ironing 

In order to reduce creasing, the laundry undergoes a smoothing process at the end of the programme. For optimal smoothing reduce the maximum load by 50%. Small loads achieve a better result.

The textiles must be suitable for drying in a tumble dryerand suitable for ironing.

Rinse plus

An additional rinse cycle can be activated to achieve a particularly good wash result.

Soak

For heavily soiled fabrics with protein stains. The soaking time is 10minutes.

Special features in the programme sequence

Spinning

Final spin speed

When a programme is selected, the maximum spin speed for this wash programme is shown in the display.

You can reduce the final spin speed.

However, you cannot select a final spin speed higher than that shown in the chart.

Interim spin

There is a spin cycle after the main wash and between the rinses. A reduction in the final spin speed will also reduce the interim spin speed accordingly.

Deselecting the interim spin and the final spin

 Select the programme setting Spin

speed 0.

After the last rinse cycle, the water will be pumped away and the anti-crease phase will switch on.

Anti-crease

At the end of the programme, the drum continues to turn at intervals for up to 30minutes to help prevent creasing. The door can be opened at any time during the anti-crease phase.

There is no anti-crease phase at the end of some programmes.

Changing the programme sequence

A programme cannot be cancelled or changed when operating a payment system.

Changing a programme

After the start of a programme, it is no longer possible to select a different programme.

You will need to cancel the current programme before you can select a different one.

If the programme selector is changed,

Programme change not possible will

appear in the display. The text disappears when the programme selector is set to the original programme.

Cancelling a programme

You can cancel a programme at any time after it has started.

Disinfection programmes can only be cancelled with a PIN code.

 Touch the Start/Stopsensor.  Select Cancel programme.

The suds will be pumped away. The programme is cancelled. The door lock is released.

If you want to select a different programme:

 Close the door.  Select the required programme.  Add detergent to the detergent

dispenser drawer, if necessary.

 Touch the Start/Stopsensor.

The new programme will start.

Switching on the washing machine after an interruption to the power supply

If the washing machine is switched off with the button during a wash programme, the programme will be interrupted.

 Switch it back on with the  button.  Note the message in the display.  Touch the Start/Stopsensor.

The programme will also be interrupted if power is interrupted by a power cut.

 When power is restored, confirm the

message in the display with OK.

 Touch the Start/Stopsensor.

The programme will continue.

 Pull open the door.  Remove the laundry.

Changing the programme sequence

Add laundry

Cancel

programme

Adding or removing laundry

You can add or remove items during the first few minutes after the programme has started.

 Touch the Start/Stopsensor.

The following will appear in the display:

 Touch the Add laundry sensor.

The programme will stop and the door will unlock.

 Risk of chemical burns from

detergent. When adding or removing laundry

during the main wash, your skin may come into contact with detergent, particularly if the detergent is dispensed externally.

Take care when placing your hands inside the drum.

If suds have come into contact with the skin, rinse off immediately with lukewarm water.

Once a programme has started successfully, the washing machine cannot recognise any adjustment to the load.

For this reason, if laundry is added or removed after the start of a programme, the machine will always complete the programme cycle assuming a full load.

The door cannot be opened, if:

– The suds temperature is above 55°C.

The safety lock will remain activated if the temperature in the drum is above 55°C. The lock will not deactivate until the temperature has dropped to below 55°C.

 Pull open the door.  Add laundry or remove individual

items.

 Close the door.  Touch the Start/Stopsensor.

The wash programme will continue.

Cleaning and care

 Risk of electric shock!

Only ever perform cleaning and maintenance work when the appliance is disconnected from the power.

Disconnect the washing machine from the mains electricity supply.

Cleaning the external casing and fascia panel

 Damage caused by cleaning

agents. Solvent based cleaning agents,

abrasive cleaners, glass cleaners or multi-purpose cleaning agents can cause damage to plastic surfaces and other parts.

Do not use any of these cleaning agents.

 Risk of damage due to ingress of

water. The pressure of a water jet can

cause water to get into the washing machine, resulting in damage to components.

Do not spray the washing machine with a water jet.

Cleaning the detergent dispenser drawer

Washing at low temperatures and the use of liquid detergent can lead to a build-up of mould and bacteria in the detergent dispenser drawer.

 For hygiene reasons, clean the entire

drawer at regular intervals.

 Pull out the detergent dispenser

drawer until a resistance is felt. Press down the release button and at the same time pull the drawer right out of the machine.

 Clean the detergent dispenser drawer

with warm water.

 Clean the casing and control panel

with a mild cleaning agent or soap and water and dry both with a soft cloth.

 The drum and other stainless steel

parts can be cleaned using a suitable stainless steel cleaning agent.

Cleaning and care

Cleaning the siphon and the channel

 Pull the siphon out of the 

compartment. Clean the siphon under warm running water. Clean the siphon tube in the same way.

 Refit the siphon.

Cleaning the detergent dispenser drawer housing

 Use a bottle brush to remove

detergent residues and limescale from the jets inside the detergent dispenser drawer housing.

 Replace the detergent dispenser

drawer.

Useful tip: Leave the detergent dispenser drawer slightly open to allow it to dry.

 Clean the fabric softener channel

using a brush and warm water.

Cleaning and care

Cleaning the drum, suds container and drainage system

The drum, suds container, and drainage system can be cleaned if necessary.

 Start the Clean machine programme.  Add powder detergent to the 

compartment in the detergent drawer.

 At the end of the programme, check

the inner drum and remove any coarse residues.

Use the Clean machineprogramme regularly if you frequently use disinfection programmes.

Cleaning the filters in the water inlet

The washing machine has filters to protect the water inlet valves. Check these filters about every 6 months or more often if there are frequent interruptions to the external water supply.

Cleaning the filters in the inlet hoses

 First turn off the tap.  Unscrew the inlet hose.  Remove the rubber seal from the

recess.

 Using combination or pointed pliers,

take hold of the plastic filter bar and remove the filter.

 Clean the plastic filter.  Reassemble the filter and seal in the

reverse order and reconnect the hose.

Make sure there is no water leaking from the threaded union.

Tighten the threaded union.

Cleaning the filters in the water inlet valves

 Using pliers, carefully loosen the

ribbed plastic nut on the inlet valve and unscrew.

 Withdraw the filter at the bar with

pointed pliers and rinse it clean under running water. Reassemble the filter and seal in the reverse order and reconnect the hose.

Replace the filters after cleaning.

Cleaning and care

Problem solving guide

With the help of the following guide, minor faults in the performance of the appliance, some of which may result from incorrect operation, can be remedied without contacting Miele. This will save you time and money because you will not need a service call.

Please note, however, that a call-out charge will be applied to unnecessary service visits where the problem could have been rectified as described in these operating instructions.

The programme does not start

Problem Possible cause and remedy

The display remains dark and the Start/Stop sensor does not light up or flash.

The following appears in the display:  Door will not lock. Call

Miele.

The programme does not start when Spin is selected.

The display is dark and the Start/Stop sensor is flashing slowly.

There is no power to the machine.  Check whether the washing machine is switched

on.

 Check whether the washing machine is connected

to the electricity supply.

 Check whether the circuit breaker has tripped.

The washing machine has switched off automatically to save energy.

 Switch it back on with the  button.

The door is not closed properly. The door lock could not engage.

 Close the door again.  Start the programme again.

If the fault message appears again, contact Miele.

You have not yet completed the initial commissioning process.

 Follow the instructions in the section Completing

the commissioning process in these instructions.

The display has switched off automatically to save energy.

 Touch any sensor. The display will switch on again.

Problem solving guide

Programme cancellations and fault messages

Problem Possible cause and remedy

 Drainage fault. Clean

drain filter and pump. Check the drain hose.

 Water intake fault.

Turn on the tap.

 Waterproof system

activated

 Disinfection

temperature not reached

 Fault F. If restart

fails, call Miele.

The water outlet is blocked or restricted. The drain hose has been fixed too high.

 Clean the filters and the drain pump.  The maximum drain height is 1m.

The water inlet is blocked or restricted.

 Check whether the tap is turned on properly.  Check whether the inlet hose is kinked.

The water pressure is too low.  Switch on the Low water pressuresetting (see

“Supervisor level - Low water pressure”).

The filters in the water inlet are blocked.  Clean the filters (see “Cleaning and care - Cleaning

the filters”).

The water protection system has reacted.

 Turn off the tap.  Call Miele.

The required temperature was not reached during the disinfection programme.

 The washing machine has not carried out the

disinfection cycle correctly.

 Start the programme again.

There is a fault.  Disconnect the washing machine from the mains

electricity supply.

 Wait at least 2 minutes before reconnecting the

washing machine to the electricity.

 Then switch the washing machine on again.  Start the programme again.

If the fault message appears again, contact Miele.

Problem solving guide

A fault message appears in the display

Problem Possible cause and remedy

 Dispenser container

empty

One of the detergent containers for external dosing is empty.

 Refill the detergent containers.

 Container 1 empty

External detergent container 1 is almost empty. The message can refer to containers 1 to 6.

 Refill the detergent container.  Reset the container's early-warning counter (see

“Supervisor level - Early-warning counter”).

 Check hot water

intake

The hot water supply is blocked or restricted.  Check whether the hot water tap is turned on

properly.

 Check whether the inlet hose is kinked.

 Align the machine.

Laundry not properly spun.

The selected spin speed was not reached during the final spin due to excessive imbalance.

 Check that the washing machine is standing level.  Start the spin cycle again.

 Machine is leaking

The washing machine or the drain valve is leaking.

 Turn off the tap.  Call Miele.

The messages will appear at the end of the programme and when the washing machine is switched on and need to be confirmed with the OKsensor.

Problem solving guide

An unsatisfactory wash result

Problem Possible cause and remedy

Liquid detergent does not give the required result.

White residues which look like powder detergent are seen on dark textiles after washing.

Textiles that were very greasy are not properly clean.

Liquid detergents usually contain no bleaching agents. They do not remove fruit, coffee and tea stains.

 Use a general purpose powder detergent

containing a bleaching agent.

 Add stain removers to compartment of the

detergent dispenser drawer and fill liquid detergent into a dispenser ball.

 Never put stain removers and liquid detergent

together in the dispenser drawer.

The detergent contains compounds (zeolites) to aid water softening which are not soluble in water. These have ended up on the laundry.

 Try to brush off the residues with a soft brush once

the laundry is dry.

 Wash dark textiles using a detergent which

contains no zeolites. Liquid detergents do not usually contain zeolites.

 Select a programme with pre-wash. Use liquid

detergent for the pre-wash.

 Continue to use universal powder detergent for the

main wash.

Grey, greasy particles cling to washed laundry.

The use of heavy-duty detergent is recommended in the main wash for very heavily soiled work clothing. Please seek advice from the detergent manufacturer.

Insufficient amounts of detergent were used. The laundry was heavily soiled with grease (oils, ointments).

 Use more detergent or liquid detergent with this

type of soiled laundry.

 Before washing the next load, run a 60°C

programme with liquid detergent but without a load.

Problem solving guide

General problems with the washing machine

Problem Possible cause and remedy

The machine shakes during the spin cycle.

The pump makes strange noises.

Large amounts of detergent residue remain in the detergent dispenser drawer.

Fabric softener is not completely dispensed or too much water remains in the  compartment.

The display is in a different language.

The washing machine did not spin the laundry as usual. The laundry is still wet.

At the end of the programme there is still liquid in the capsule.

The machine feet are not level.  Level the machine and adjust the feet correctly.

This is not a fault. Slurping noises occur at the end of the pump sequence as a normal part of operation.

The water pressure is too low.  Clean the filters in the water inlet.

Powder detergent used in conjunction with water softeners tends to become sticky.

 Clean the detergent dispenser drawer and, in the

future, add washing powder to the dispensing drawer first, and then add the water softener.

The siphon tube is not correctly positioned or clogged.

 Clean the siphon (see “Cleaning and care -

Cleaning the detergent dispenser drawer”).

A different language has been selected.  Switch the washing machine off and then on

again.

The set operator language will appear in the display.

The operator language has been changed.  Select the language you require (see “Supervisor

level - Language”).

The machine detected an imbalance during the final spin and reduced the spin speed automatically.

 Include both large and small items in the load as

this will give better distribution.

The small pipe in the detergent dispenser drawer onto which the capsule is placed is blocked.

 Clean the small pipe.

This is not a fault. For technical reasons a small amount of water will remain in the capsule.

Problem solving guide

Problem Possible cause and remedy

There is water next to the capsule in the fabric softener compartment.

The drum remains stationary but the programme keeps running.

The CapDosing sensor was not activated or an empty capsule was not removed at the end of the last wash programme.

 Activate the CapDosing sensor when a capsule is

used the next time.

 Remove and dispose of the empty capsule at the

end of each programme.

The small pipe in the detergent dispenser drawer onto which the capsule is placed is blocked.

 Clean the small pipe.

 Switch the washing machine off and then back on

with the  button.

 Note the message in the display.  Touch the Start/Stopsensor.

The programme will continue and the drum will spin.

Problem solving guide

The door will not open

Problem Possible cause and remedy

The door cannot be pulled open during a programme.

 Programme cancelled

appears in the display at the end of a programme or after a programme has been cancelled.

The following appears in the display:

The door lock is jammed.

Call Miele.

The door is locked during the washing process.

 Touch the Start/Stop sensor.  Select Cancel programme or Add laundry.

The door will unlock and you will be able to pull it open.

There is still water in the drum and the machine is unable to drain.

 Clean the drain system as described in “Opening

the door in the event of a blocked drain outlet and/ or power cut”.

For safety reasons, the door cannot be opened if the suds temperature is higher than 55°C.

 Wait until the temperature in the drum has

decreased and the message has gone out in the display.

The door lock has jammed.  Call Miele.

Problem solving guide

Opening the door in the event of a blocked drain outlet and/ or power cut

 Risk of electric shock!

Only ever perform cleaning and maintenance work when the appliance is disconnected from the power.

Disconnect the washing machine from the mains electricity supply.

 Open the access panel to the drain

system.

Blocked drain outlet

If the drain outlet is blocked, a larger quantity of water (max. 30 l) can remain in the washing machine.

 Risk of scalding due to hot suds.

Escaping suds will be hot if laundry has been washed at high temperatures shortly before.

Drain the suds carefully.

Emptying the drum

....in machines with a drain pump

 Place a suitable container under the

access flap.

Remove the drain filter, though not completely.

 Slowly and carefully unscrew the filter

to let the water out. Be careful not to release too much water at once. If the flow of water is too strong, some water can seep into the washing machine base and activate the water protection float switch. This will prevent the washing machine from functioning.

 Tighten the drain filter back up again

if you need to interrupt the flow of water.

Problem solving guide

Cleaning the drain filter

Once the flow of water ceases:

 Remove the drain filter completely.  Clean the drain filter thoroughly.

 Risk of water damage.

Make sure the drain filter is securely tightened. Otherwise there is a risk of water leakage during use.

Replace the drain filter correctly and tighten it securely.

Opening the door

 Danger of injury due to rotating

drum! Reaching into a moving drum is

extremely dangerous. Danger of injury!

Always make sure that the drum is stationary before reaching in to remove laundry.

 Check the drain pump impellers to

make sure they can rotate freely.

 Remove any foreign objects (e.g.,

buttons, coins etc.) and clean the interior.

 Put the drain filter back in place and

secure it.

 Use a screwdriver to unlock the door

of the washing machine as shown.

 Pull open the door.

Problem solving guide

Emptying the drum

...in machines with a drain valve

 Push the emergency drain lever

downwards and hold until no more water runs out.

Opening the door

 Danger of injury due to rotating

drum! Reaching into a moving drum is

extremely dangerous. Danger of injury!

Always make sure that the drum is stationary before reaching in to remove laundry.

 Use a screwdriver to unlock the door

of the washing machine as shown.

 Pull open the door.

After sales service

Contact in case of fault

In the event of any faults which you cannot remedy yourself, please contact Miele.

Contact information for Miele can be found at the end of this booklet.

Please quote the model and serial number of your appliance when contacting Miele. This information can be found on the data plate.

The data plate is found above the porthole glass when the washing machine door is opened:

Optional accessories

Optional spare parts and accessories for this washing machine are available from Miele.

*INSTALLATION*

Front view

Installation

Cold water inlet hose

Hot water inlet hose

Electrical connection

Control panel

Detergent dispenser drawer

Door

Access to drain filter, drain pump or valve and emergency release

Height-adjustable feet

*INSTALLATION*

Installation

Rear view

Electrical connection

Interface for communicating with external devices

Socket for external dispensing system

Drain hose (DP version)

Inlet hose (cold water)

Inlet hose (hot water), if fitted

Safety caps for transit bars

Transport clips for hoses

Drain pipe (DV version)

Module slot (for external communication module)

Holder for removed transit bars

*INSTALLATION*

1132

850

1100

714

min. 300

1702

Installation

Installation locations

Side view

Washer-dryer stack

Installation on a raised plinth

The washing machine can be installed on a steel plinth (open or closed, available as an optional Miele accessory) or on a concrete plinth.

 Injury can occur if the washing

machine has not been adequately secured.

When installed on a plinth, there is a risk that the washing machine will move and fall from the plinth during spinning.

Secure the washing machine using the clamps supplied.

Installation notes

This washing machine is not suitable for building under.

 Risk of damage due to moisture

ingress. Moisture can damage electrical

components. Do not install the machine near or

directly above an open gully or floor drain.

This washing machine can be installed with a Miele tumble dryer on top of it. A stacking kit (APCL001, optional accessory) is required for this.

*INSTALLATION*

Installation

Transporting the washing machine to its installation site

 Danger of injury from incorrect

transport. If the washing maching tips over,

there is a danger of injury to people and damage to property.

When transporting the machine, make sure that it is stable.

Transporting the washing machine with a hand trolley

Transporting the washing machine to its installation site

The protruding lid can be used for holding the machine during transport.

 Danger of injury due to

unsecured lid. Make sure the fixings at the back of

the lid are secure. They may become brittle due to external circumstances. There is a danger of the lid being pulled off when carrying the appliance.

Before carrying the appliance, check that the lid is secure where it protrudes at the back.

 If transporting the washing machine

with a hand trolley, make sure only its left or right side is resting on the trolley.

 Risk of damage from incorrect

transport. The front or back of the washing

machine may be damaged if the machine is transported on a hand trolley.

Always transport the washing machine on its side on a hand trolley.

 Carry the washing machine by the

front feet and by the lid where it protrudes at the back of the appliance.

*INSTALLATION*

Installation

Installation surface

A concrete floor is the most suitable installation surface. It is far less prone to vibration during the spin cycle than wooden floorboards or a carpeted surface.

 The machine must be level and

securely positioned.

 To avoid vibrations during spinning,

the machine should not be installed on soft floor coverings.

If installing on a wooden joist floor:  Install the machine on a plywood

base (at least 70x60x3cm). The base should span several joists and be bolted to the joists and not only to the floorboards.

Useful tip: If possible, install the machine in a corner of the room. This is usually the most stable part of the floor.

Removing the transit bars

 Remove the left and right covers.

1. Pull off the transit bar covers and

2. and use a screwdriver to release the catches at the top and bottom.

 Using the spanner supplied, turn the

left-hand transit bar 90°.

*INSTALLATION*

Installation

 Then pull the transit bar out.

 Turn the right-hand transit bar 90°.

 Then pull the transit bar out.

 Risk of injury from sharp edges!

There is a risk of injury when reaching into holes that are not covered.

The holes for the transit bars must be covered after the transit bars have been removed.

 Fit the stoppers onto the two holes.

*INSTALLATION*

 Secure the transit bars to the back of

the washing machine.

Useful tip: Make sure that the holes  are fitted over the retainers .

 Risk of damage from incorrect

transport. The washing machine may be

damaged if moved without the transit bars in place.

Keep the transit bars in a safe place. Fit them again if the machine is to be transported (e.g. when moving house).

Refitting the transit bars

Refitting is carried out by reversing the procedure.

Installation

Aligning the washing machine

The washing machine must stand perfectly level on all four feet to ensure safe and proper operation.

Incorrect installation may increase electricity and water consumption and may cause the machine to move about.

Screwing out and adjusting the feet

The four adjustable screw feet are used for levelling the washing machine. All four feet are screwed in when the appliance is delivered.

 Using the spanner supplied, turn

counter nut 2 in a clockwise direction. Then turn counter nut 2 together with foot 1 to unscrew.

*INSTALLATION*

Installation

 Use a spirit level to check that the

washing machine is standing level.

 Hold foot 1 securely with a pipe

wrench. Turn counter nut 2 again using the spanner supplied until it sits firmly up against the housing.

 Risk of damage due to

incorrectly aligned washing machine. There is a danger of the washing

machine moving about if the feet are not secured.

Turn all four counter nuts for the feet until they sit firmly up against the housing. Please also check this for the feet which did not need adjustment.

Securing the washing machine to the plinth

 Secure the two front feet of the

washing machine using the clamps supplied.

 Follow the installation instructions

supplied.

External control equipment

The XCI box accessory is needed to connect external control equipment, such as payment systems, dispensing systems or peak load control units.

Payment system

This machine can be fitted with a payment system (optional accessory).

The necessary reprogramming must be carried out by Miele.

Coins/tokens must be removed from the coin box regularly. Otherwise, the payment system will become blocked.

*INSTALLATION*

Installation

Water connection

Cold water connection

The washing machine must be connected to a mains water supply in accordance with current local and national safety regulations.

The flow pressure must amount to a minimum of 100kPa (1bar) and must not exceed an overpressure of 1000kPa (10bar). If it is higher than 1000kPa, a pressure reduction valve must be installed.

Connection to the mains water supply should incorporate a water tap with a ¾" threaded union. If this is not available, only a qualified plumber may connect the washing machine to the mains water supply.

The connection point is subject to mains water pressure.

Turn on the tap slowly and check for leaks. Correct the position of the washer and union if necessary.

Switching to cold water operation

If the washing machine is not connected to a hot water tap, you will have to configure the settings Main

wash water, Pre-wash water and Rinse water to cold (see “Supervisor level”).

 Unscrew the hot water hose.  Screw on the stopper provided.

Maintenance

Only use a genuine Miele hose should you ever need a replacement.

A filter is located in the open end of the inlet hose and another in the intake point to protect the inlet valve.

Neither filter may be removed.

Hose extension

Longer hoses with a length of 2.5 m or

4.0 m are available from Miele as

optional accessories (depending on country).

The inlet hose for cold water is not intended to be used for a hot water connection.

*INSTALLATION*

Installation

Hot water connection*

The hot water temperature must not exceed 70°C. To minimise energy consumption during operation with hot water, the washing machine should be connected to a suitable hot water ring circuit. So-called “transmission pipes” (single pipes to hot water generators) can result in cooling down of the water remaining in the pipes if not in constant use. More energy would then be consumed to heat the suds up again.

The same connection requirements as for cold water also apply to hot water.

The inlet hose (hot = red stripes) is connected to the water tap.

It is not possible to connect the washing machine to a hot water connection only.

* Some machine versions do not come with a hot water hose.

Switching to hot water operation

If the washing machine is to be connected to hot water, you will have to configure the settings Main wash water, Pre-wash water and Rinse water to

warm (see “Supervisor level”).

 Screw on the hot water hose.

IMPORTANT Australia and New Zealand

This appliance must be installed according to AS/NZS 3500.1 and AS/ NZS 3500.2. This washing machine has been supplied with a separate backflow prevention device.

 Disconnect mains power (switch off

or unplug the plug).

 Turn off the water tap.  Place the seals on both sides of the

non-return valve.

 Connect the female end of the non-

return valve to the water tap.

 Connect the hose to the male end of

the non-return valve.

 Turn on the tap gradually to test for

leaks.

If there is a leak, the connection might not be on securely, or it may have been screwed on a an angle. Unscrew and reconnect the water correctly before tightening it.

 Unscrew the stopper from the hot

water valve.

*INSTALLATION*

Drainage

Drain valve

The washing machine is drained using a motorised drain valve. A DN70 angle connector can be used for draining the machine via an on-site floor drain (gully with odour trap).

Drain pump

The suds are drained through a drain pump with a 1m delivery head. For the water to drain freely, the hose must be free of kinks. An elbow piece (accessory) can be hooked onto the end of the hose.

Drain hose connection options

1. Connected securely to a trapped waste pipe.

Installation

2. Connected over the rim of the laundry trough or into the sud-saver pipe of the laundry trough.

3. Connected securely to a floor drain (gully).

If required, the hose can be extended to a length of up to 5m. The necessary parts can be ordered from Miele (depending on country).

For a delivery head of more than 1 m (up to a max. of 1.6 m) a replacement drain pump will need to be fitted. Please contact Miele for advice.

Waste water discharge from commercial clothes washing machines may require pre-treatment as determined by the utility operator.

*INSTALLATION*

Installation

Electrical connection

This description applies to washing machines both with and without a mains plug.

The following applies to washing machines with a mains plug:

– The washing machine is ready to be

connected.

– The electrical socket must be easily

accessible after installation so that the machine can be disconnected from the electricity supply if necessary.

 Damage caused by incorrect

supply voltage. The data plate indicates the nominal

power consumption and the appropriate fuse rating.

Compare the specifications on the data plate with those of the mains electricity supply.

The washing machine may only be connected to a permanent electrical system that conforms to the national and local codes and regulations.

Do not connect the machine to an extension lead or multi-socket adapter as they do not guarantee the required safety of the appliance (e.g. danger of overheating).

If the appliance is hard wired, a dual circuit breaker must be provided on site. When switched off, there must be an all-pole contact gap of at least 3mm in the isolator switch (including circuit breakers, fuses, and relays according to

AS/NZS 3000). This connection must be carried out by a qualified and competent electrician.

The plug connector or isolator switch should be easily accessible at all times.

 Risk of electric shock!

If the washing machine is disconnected from the power supply, protective measures must be taken to ensure that the point of disconnection cannot accidentally be switched on again.

Make sure the isolator is lockable or the point of disconnection is monitored at all times.

New connections, modifications to the system, or servicing of the protective earthing conductor, including determining the correct fuse rating, must be carried out by a qualified and competent electrician, as they are familiar with the pertinent regulations and the specific requirements of the electric utility company.

If converting the washing machine to an alternative voltage, ensure that the connection data on the data plate (voltage, frequency and fuse rating) match the mains electrical supply. Observe the instructions in the wiring diagram. Conversion may only be performed by Miele or a Miele authorised service technician.

Height 850mm

Width 596mm

Technical data

Width (for appliances with a stainless steel lid)

Depth 714mm

Depth with door open 1,132mm

Weight Approx. 100kg

Maximum floor load in operation 3,000Newton

Capacity 7.0kg dry laundry

Supply voltage See data plate on back of machine

Rated load See data plate on back of machine

Fuse rating See data plate on back of machine

A-rated sound emissions LpA in accordance with ENISO11204/11203

Minimum water flow pressure 100kPa (1bar)

Maximum water flow pressure 1,000kPa (10bar)

Intake hose length 1.55m

Power cord length 1.80m

Maximum drain height (drain pump) 1.00m

LEDs Class 1

605mm

<70dB re 20µPa

Product safety standard AS/NZS 60335

Test certificates awarded See data plate

Supervisor level



Supervisor

level

Access via code

Change code

Enter code









Supervisor

level





Language

Brightness

The settings menu in the Supervisor level is locked against unauthorised access. The menu can be unlocked with a code.

Code-based access

The Supervisor level is accessed using a code.

The code is 000 (factory default).

Changing the code

You can change the Supervisor level access code to protect the washing machine from unauthorised access.

 Enter the individual numbers and

confirm each selection with OK.

The Supervisor level settings are opened.

Please inform Miele if you have forgotten your new code. Miele will have to reset the code.

Make a note of your new code and store it in a safe place.

Opening the Supervisor level

 Touch the sensor.

The symbol appears in the display e.g. if you turn the programme selector to the Drain/Spinprogramme.

 Select Access via code.

 Select the desired setting.

Some settings are only visible if external devices are connected via the XCI box.

Exiting the Supervisor level

 Touch the sensor or switch off the

washing machine.

Supervisor level

Language

The display can be set to appear in one of several different languages. You can selected the permanent operator language via the Language submenu.

When a programme is running, you can change the user language using the sensor control.

Brightness

The brightness of the display can be set in intervals of ten from 10% to 100%.

Factory setting: 70%

Clock display

After selecting the clock format, you can set the time of day.

Clock format

– 24 h clock (factory setting)

– 12h clock

– Clock off

Set

– The time can be set.

Finish tone volume

The volume for the signal tone that sounds at the end of the programme can be changed.

The tones can be set to one of 7 different levels or switched off altogether.

Factory setting: Off

Keypad tone

The volume of the tone that sounds when a sensor is touched can also be changed.

The tones can be set to one of 7 different levels or switched off altogether.

Factory setting: Normal

Welcome tone volume

The volume of the welcome tone that sounds when the washing machine is switched on can be changed.

The tones can be set to one of 7 different levels or switched off altogether.

Factory setting: Normal

Fault alarm

The signal tone that sounds in the event of a fault can be switched on or off.

Factory setting: Off

Memory

The washing machine will save the latest settings (temperature, spin speed and some of the options) which have been selected for a programme after the programme has started.

When the programme is selected again, the saved settings will appear in the display.

Factory setting: Off

Supervisor level

Anti-crease

The anti-crease function helps prevent creasing if laundry is not going to be removed immediately after the end of the programme.

The drum continues to turn at intervals for up to 30minutes after the end of the programme. The door can be opened at any time during the anti-crease phase.

Factory setting: On

Suds cooling

Additional water flows into the drum at the end of the main wash to cool the suds down.

Suds cooling takes place when a programme with a temperature of 70°C or higher is selected.

Suds cooling should be activated:

– to prevent the danger of scalding if

the drain hose is hooked over the edge of a sink or basin.

– where the drainage pipe is rated less

than 70°C.

Factory setting: On

Delay start

The type of time input for the Delay start function can be changed or switched off.

– Off

The Delay start function is not available for selection.

– End of programme (factory setting)

With the Delay start function, you specify at what time the wash programme should finish.

– Start of programme

With the Delay start function, you specify at what time the wash programme should start.

– Time until start

With the Delay start function, you specify after how many hours a programme should start (up to 96h).

Programme name

When selecting a standard programme, the name of the selected programme is shown in the display.

– On (factory setting)

When a programme is selected, the programme name is displayed for a few seconds before the display shows the main menu.

– Off

The main menu is displayed immediately.

Supervisor level

Pre-wash water

You can select the type of water for the pre-wash.

– Cold

Only cold water is used for the prewash.

– Hot

Hot water is also added for the prewash. Hot water can only be added if the wash temperature is above 30°C.

Main wash water

You can select the type of water for the main wash.

– Cold

Only cold water is used for the main wash.

– Hot

Hot water is also added for the main wash. Hot water can only be added if the wash temperature is above 30°C.

First rinse water

You can select the water type for the first rinse in some programmes.

– Cold (factory setting)

Only cold water is used for the first rinse.

– Hot

Hot water is also added for the first rinse.

Final rinse water

You can select the water type for the final rinse in some programmes.

– Cold (factory setting)

Only cold water is used for the final rinse.

– Hot

Hot water is also added for the final rinse (only possible for programmes with a temperature of at least 60°C).

If the washing machine is not connected to hot water, programme durations will be longer and may deviate from the remaining runtimes displayed.

Supervisor level

Low water pressure

If the water pressure is below 100kPa (1bar), the programme will be cancelled and the fault message

Check water inlet will appear.

If the on-site water pressure cannot be increased, activating the Low water

pressure setting will prevent the

programme from being cancelled.

Factory setting: Off

Empty sensor

A suction lance contact can be used to detect whether external liquid detergent containers are empty. A message will appear if a container is empty.

– Off (factory seeting)

The empty container sensing function is switched off.

– Normally open contact

The siphons are equipped with a normally open contact.

– Normally closed contact

The siphons are equipped with a normally closed contact.

Early warning counter

An internal counter reports when an external dispenser container is almost empty. The counter in question then has to be reset.

Water level Cottons

In the Cottonsprogramme, you can increase the water level for the main wash.

– + 0 mmWS (factory setting)

– + 10 mmWS

– + 20 mmWS

– + 30 mmWS

Water level Minimum iron

In the Minimum ironprogramme, you can increase the water level for the main wash.

– + 0 mmWS (factory setting)

– + 10 mmWS

– + 20 mmWS

– + 30 mmWS

Pre-wash temp. Cottons

In the Cottonsprogramme, you can select the temperature for the prewash.

– 30°C (factory setting)

– 35°C

– 40°C

– 45°C

Supervisor level

Wash time pre-wash

In the Cottonsprogramme, you can extend the duration of the pre-wash.

– + 0 min (factory setting)

– + 6 min

– + 9 min

– + 12 min

Wash time Cottons

In the Cottonsprogramme, you can extend the duration of the main wash.

– + 0 min (factory setting)

– + 10 min

– + 20 min

– + 30 min

– + 40 min

Wash time Minimum iron

In the Minimum ironprogramme, you can extend the duration of the main wash.

– + 0 min (factory setting)

– + 5 min

– + 10 min

– + 15 min

– + 20 min

Pre-rinse Cottons

In the Cottons programme, a pre-rinse can be activated.

Factory setting: Off

Pre-rinse Minimum iron

In the Minimum iron programme, a pre-rinse can be activated.

Factory setting: Off

Pre-wash Cottons/Min. iron

In the Cottons and Minimum iron programmes, you can choose whether a pre-wash is permanently activated or whether it can be selected during programme selection.

Factory setting: Menu selection

Cottons rinses

In the Cottonsprogramme, you can change the number of rinse cycles that are carried out.

– 1 rinse cycle

– 2 rinse cycles (factory setting)

– 3 rinse cycles

– 4 rinse cycles

– 5 rinse cycles

Supervisor level

Minimum iron rinses

In the Minimum ironprogramme, you can change the number of rinse cycles that are carried out.

– 2 rinse cycles (factory setting)

– 3 rinse cycles

– 4 rinse cycles

Disinfection rinse

Additional rinse cycles can be activated in disinfection programmes with a temperature of at least 60°C.

Rinsing is carried out with hot water. The programme duration is extended.

The laundry may feel hot at the end of the programme.

Take care when removing items.

Factory setting: Off

Programme packages

The selection of programmes can be extended by activating single programmes from the target group programme packages.

The programmes selected from the programme packages are displayed under Special programmes.

– Sport

– Outdoor

– Wellness/Hair salons

– Hotel

– Home textiles

– Workwear

– Disinfection

After selecting the programme packages, the individual programmes from the list are activated. Activated programmes are marked with a frame. The selection must then be confirmed.

Supervisor level

Temperature reduction

The suds temperature can be reduced to prevent the suds from boiling too early in high-altitude locations.

Factory setting: Off

Disinfection prog. code

A code needs to be entered to cancel a disinfection programme. The code can be changed.

The code is: 0 0 0

Useful tip: Make a note of your new code if you ever change it.

Auto load control

The washing machine is equipped with an automatic load control. In some programmes, the water levels and the programme cycle times are adapted to the load. If the automatic load control is deactivated, the machine will always carry out the programme sequence based on a full load.

Factory setting: On

CapDosing

You can choose whether CapDosingis displayed in the Further selectionslist.

Factory setting: On

Pre-ironing

You can choose whether Pre-ironingis displayed in the Extraslist.

Factory setting: On

Supervisor level

Automatic dispensing

Automatic dispensing via an external dispensing system can be activated.

Factory setting: Off

Peak load signal

The peak-load cut-off function enables the washing machine to be connected to an energy management system. When a signal is registered, the washing machine's heater is switched off for a short period. The washing machine may only be operated with a peak-load system if this system is connected to the washing machine via the Miele XCI box.

– No function (factory setting)

– Peak load with 230V

– Peak load with 0V

Peak load prevention

The peak-load cut-off function can be deactivated for disinfection programmes. When a signal is registered, the washing machine's heater is not switched off.

Factory setting: Off

Alternating current

The time remaining displayed depends on the electrical connection. If a single-phase connection is used, the setting must be switched to No.

Factory setting: Yes

Heater

The heater can be switched off and the Thermostop step is skipped. In addition, heater fault monitoring is deactivated.

Factory setting: On

Supervisor level

Payment system

External hardware is connected via the Miele XCI box.

If you wish to change the settings later, please contact Miele.

Settings for payment systems

You would like to connect a payment system.

– No payment system

The next settings are skipped and initial commissioning can be completed.

– Programme operation

The machine is operated using a coin box. The user purchases a wash programme.

– Time operation

The machine is operated using a coin box. The user purchases a timecontrolled programme.

– Timed operation with pulse counter

Feedback signal to pay system

Setting the feedback signal for the payment system.

– Factory setting: Off

– Programme end

The feedback signal is sent at the end of the programme.

– Release of the start button

The feedback signal is sent when the start button is released.

– Start and end of programme

The feedback signal is sent at the start and end of the programme.

– Running programme

The feedback signal is sent continuously from the start until the end of the programme.

For payment systems where the usage time is increased each time a coin is inserted.

Supervisor level

Payment system lock

To avoid tampering, a programme lock can be set up in programme operation. If the lock is applied, the programme is interrupted and payment credit is lost as soon as the door is opened.

To offer the possibility to add laundry, the time when the lock activates can be adjusted.

– Off

– As soon as the programme starts

– 1 minute after the start of the

programme

– 2 minutes after the start of the

programme

– 3 minutes after the start of the

programme (factory setting)

– 4 minutes after the start of the

programme

Clear paid signal

The “Paid” signal in payment system mode can be applied until the end of the programme or discarded if the programme has not been started after 5minutes.

Factory setting: Off

FOC programmes

In payment system mode, you can decide whether the Drain/Spin programme can be used for free.

Factory setting: Off

– 5 minutes after the start of the

programme

Miele Australia Pty. Ltd.

ACN 005 635 398 ABN 96 005 635 398

1 Gilbert Park Drive Knoxfield, VIC 3180 Telephone: 1300 731 411 service.prof@miele.com.au

Melbourne:

www.miele-professional.com.au sales@miele-professional.com.au

Miele New Zealand Limited

IRD 98 463 631 Level 2, 10 College Hill Freemans Bay Auckland 1011 New Zealand Telephone:
