Operating and Installation Instructions
Heat-Pump Dryer
Always read the operating instructions before setting up, installing, and
commissioning the appliance. This prevents both personal injury and
damage to the appliance.
en-US M.-Nr. 11 226 870
Contents
Caring for the environment ................................................................................. 7
IMPORTANT SAFETY INSTRUCTIONS ................................................................ 8
Operating the tumble dryer ................................................................................ 16
Control panel......................................................................................................... 16
Sensor controls and touch display with sensor controls ...................................... 17
Main menu............................................................................................................. 17
Examples of how to operate the appliance........................................................... 18
Operating a laundromat machine.......................................................................... 20
Initial commissioning .......................................................................................... 21
Switching on the tumble dryer .............................................................................. 21
Reference to external appliances.......................................................................... 22
Setting the display brightness............................................................................... 22
Setting the date..................................................................................................... 22
Selecting program packages ................................................................................ 23
Completing the commissioning process............................................................... 25
1. Notes on correct laundry care .......................................................................26
Washing................................................................................................................. 26
Drying .................................................................................................................... 26
Understanding the care-label symbols ................................................................. 26
2. Loading the tumble dryer ............................................................................... 27
3. Selecting a program........................................................................................ 28
Switching on the tumble dryer .............................................................................. 28
Selecting a program .............................................................................................. 28
4. Selecting program settings ............................................................................ 29
Main menu for a program...................................................................................... 29
Selecting the drying level ................................................................................. 29
Selecting the duration (timed programs) ......................................................... 29
Selecting extra options.......................................................................................... 30
Gentle ............................................................................................................... 30
Anti-crease ....................................................................................................... 30
5. Starting a program .......................................................................................... 31
6. End of program – removing the laundry........................................................ 32
End of program...................................................................................................... 32
Removing the laundry ........................................................................................... 32
Observing the care notes ...................................................................................... 32
Timer..................................................................................................................... 33
2
Contents
Program chart...................................................................................................... 34
Label...................................................................................................................... 34
Program packages ................................................................................................ 35
Standard................................................................................................................ 35
Sport...................................................................................................................... 39
Soft furnishings ..................................................................................................... 40
Hygiene ................................................................................................................. 41
WetCare................................................................................................................. 42
Flatwork................................................................................................................. 42
Special programs .................................................................................................. 43
Changing the program sequence ...................................................................... 44
Changing a program once it has started............................................................... 44
Canceling a program............................................................................................. 44
Reselecting a canceled program...................................................................... 44
Adding laundry ...................................................................................................... 44
Fragrance flacon.................................................................................................. 45
Inserting a fragrance flacon................................................................................... 45
Opening the fragrance flacon................................................................................ 47
Closing the fragrance flacon ................................................................................. 47
Removing/replacing the fragrance flacon ............................................................. 48
Cleaning and care ...............................................................................................49
Observing the cleaning intervals ........................................................................... 49
1. When to clean the lint filter........................................................................... 49
2. When to clean the filter in the toe-kick......................................................... 50
3. When to clean the grille in the bottom right/heat exchanger for heat
dissipation ........................................................................................................ 51
Cleaning the lint filters........................................................................................... 52
Removing the fragrance flacon ........................................................................ 52
Removing visible lint......................................................................................... 52
Cleaning the lint filters and air-flow openings thoroughly................................ 53
Cleaning instructions when using fabric softener sheets................................. 55
Cleaning the toe-kick filter .................................................................................... 56
Removing the lint filter...................................................................................... 56
Cleaning the lint filter with water ...................................................................... 57
Replacing the toe-kick filter.............................................................................. 57
Cleaning the filter insert (in the toe-kick)............................................................... 59
Removing the filter insert ................................................................................. 59
Checking the cooling fins on the heat exchanger............................................ 60
Reinstalling the filter insert (in the toe-kick) ..................................................... 61
Reinstalling the lint filter (in the toe-kick)............................................................... 61
Cleaning and closing the lint-filter flap.................................................................. 62
3
Contents
Cleaning the bottom-right grille/heat exchanger................................................... 63
Removing the grille........................................................................................... 63
Cleaning the cooling fins.................................................................................. 64
Replacing the grille........................................................................................... 64
Cleaning the tumble dryer ..................................................................................... 65
Frequently Asked Questions .............................................................................. 66
The display indicates the following messages or faults........................................ 66
Unsatisfactory drying results................................................................................. 70
The drying-cycle duration is very long .................................................................. 71
General problems with the tumble dryer............................................................... 72
Reactivating the plinth filter................................................................................... 73
Technical Service................................................................................................. 74
Contact in case of fault ......................................................................................... 74
Optional accessories............................................................................................. 74
IMPORTANT SAFETY INSTRUCTIONS .............................................................. 76
Installation and connection ................................................................................ 78
Front view.............................................................................................................. 78
Rear view............................................................................................................... 79
Installation locations.............................................................................................. 80
Side view .......................................................................................................... 80
Steel toe-kick ................................................................................................... 80
View from above............................................................................................... 80
Washer-dryer stack .......................................................................................... 80
Transporting the tumble dryer to its installation site ............................................. 81
Installation ............................................................................................................. 82
Downtime after installation............................................................................... 82
Leveling the tumble dryer................................................................................. 82
Room ventilation .............................................................................................. 83
External control equipment .............................................................................. 83
Drain hose for condensed water ........................................................................... 84
Inserting the drain hose into a standpipe......................................................... 84
Electrical connection ............................................................................................. 85
Technical data...................................................................................................... 86
Supervisor level ................................................................................................... 87
Opening the supervisor level................................................................................. 87
Access via code .................................................................................................... 87
Change code......................................................................................................... 87
Closing the settings menu..................................................................................... 87
4
Contents
Controls / Display.................................................................................................. 87
Language.......................................................................................................... 87
Language entry ................................................................................................ 88
Set languages................................................................................................... 88
Display brightness............................................................................................ 88
Clock display.................................................................................................... 89
Date .................................................................................................................. 89
Volume.............................................................................................................. 89
Res. moisture display....................................................................................... 89
Visibility parameters ......................................................................................... 89
"Display" off status........................................................................................... 90
"Machine" off status......................................................................................... 90
Delay start ........................................................................................................ 90
Memory ............................................................................................................ 91
Temperature unit............................................................................................... 91
Weight unit ....................................................................................................... 91
Logo ................................................................................................................. 91
Change code.................................................................................................... 91
Program selection ................................................................................................. 92
Controls............................................................................................................ 92
Program packages ........................................................................................... 93
Favorite programs ............................................................................................ 94
Special programs ............................................................................................. 95
Sort programs .................................................................................................. 96
Program color allocation .................................................................................. 96
Process technology............................................................................................... 97
Anti-crease ....................................................................................................... 97
Drying levels ..................................................................................................... 97
Additional cooling............................................................................................. 97
Cooling down temperature............................................................................... 97
Service................................................................................................................... 98
Clean out the airways....................................................................................... 98
Service interval ................................................................................................. 98
External applications ............................................................................................. 99
Peak load signal ............................................................................................... 99
Peak load prevention........................................................................................ 99
Select KOM module ......................................................................................... 99
WiFi................................................................................................................... 99
Network time .................................................................................................. 100
Remote........................................................................................................... 100
Remote Update .............................................................................................. 100
SmartGrid ....................................................................................................... 101
5
Contents
Machine parameters............................................................................................ 102
Legal Information............................................................................................ 102
Payment system.................................................................................................. 102
Setting for payment systems ......................................................................... 102
Time / impulse................................................................................................ 103
Feedback sig. to pay system.......................................................................... 103
Payment system lock ..................................................................................... 103
Clear paid signal............................................................................................. 103
Debounce time ............................................................................................... 104
Pay system override time............................................................................... 104
Duration Cool air ............................................................................................ 104
Duration Warm air........................................................................................... 104
FOC programs................................................................................................ 104
6
Caring for the environment
Disposal of the packing material
The cardboard box and packing
materials protect the appliance during
shipping. They have been designed to
be biodegradable and recyclable.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of children.
Danger of suffocation!
Disposal of your old appliance
Electrical and electronic appliances
contain valuable materials. They also
contain certain substances, compounds
and components which were essential
for the proper functioning and safe use
of the equipment. Handling these
materials improperly by disposing of
them in your household waste can be
harmful to your health and the
environment. Therefore, please do not
dispose of your old appliance with
regular household waste and follow
local regulations on proper disposal.
Consult with local authorities, dealers or
Miele in order to dispose of and recycle
electrical and electronic appliances.
Miele assumes no responsibility for
deleting any personal data left on the
appliance being disposed. Please
ensure that your old appliance is kept
away from children until removal.
Observe safety requirements for
appliances that may tip over or pose an
entrapment hazard.
7
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electric shock, or injury to persons when
using your appliance, follow basic precautions, including the
following:
It is essential to read all instructions before using the appliance.
Do not allow children to play on or in the appliance. Close
supervision is necessary when the appliance is used near children.
Always close the door after use to prevent child hazards.
Before this appliance is removed for service or discarded, remove
the door to the drying compartment.
Do not install or use a dryer with visible damage.
Do not reach into the dryer if the drum is moving.
Do not install or store this appliance where it will be exposed to
the weather.
Do not tamper with the controls.
Do not repair or replace any part of the appliance or attempt any
servicing unless specifically recommended in these operating
instructions. Repairs to electrical appliances should only be
performed by qualified personnel. Incorrectly repaired machines may
pose a considerable risk to the user.
8
IMPORTANT SAFETY INSTRUCTIONS
Important information regarding use of fabric softener sheets:
We do not recommend use of fabric softener sheets. Use of fabric
softener sheets can clog the surfaces of the lint filters, extending the
drying time and increasing energy consumption. During subsequent
cleaning, the plastic and surfaces of the lint filters can be damaged!
The best results are obtained by using liquid fabric softener in the
washing machine. Follow the manufacturer's instructions.
If you still wish to use fabric softener sheets, be sure to follow the
cleaning instructions under “Cleaning and care” in the “Cleaning
instructions when using fabric softener sheets” section.
Tip:
Using a fragrance capsule (optional accessory) will add a pleasant
fragrance to your laundry.
When a fragrance capsule is used, the fragrance is acquired by the
entire load of laundry. The disadvantage of fabric softener sheets is
that under certain circumstances the fragrance is acquired by only a
few items of laundry, especially when drying a full load.
When you use a fragrance capsule, always follow the
warnings in this section as well as those under “Fragrance
capsule”.
9
IMPORTANT SAFETY INSTRUCTIONS
To prevent the risk of fire, the following textiles must not be dried
in this dryer:
– items which have not been washed.
– items, such as work-wear, exposed to grease, oils, or other
deposits (such as lotions or cosmetics) in your dryer. If these
items have not been thoroughly cleaned there is a danger that
they may contribute to a chemical reaction that could cause the
laundry to ignite when heated even after being removed from the
dryer.
– items that have been previously cleaned, washed, soaked or
spotted with gasoline, dry-cleaning solvents or other flammable
or explosive substances. They may give off vapors that could
ignite or explode.
– items treated with flammable cleaning agents or items containing
acetone, alcohol, gas, stain remover, wax or chemicals from
buffing, etc.
– items which have been splashed with hair spray, nail polish
remover, etc.
When washing heavily soiled items ensure that sufficient
detergent is used with a high temperature. If in doubt wash the
item several times.
– items containing foam rubber or similarly textured rubber-like
materials.
– items with padding or filling (e.g. pillows or jackets) which have
been damaged. Loose filling could catch fire.
10
IMPORTANT SAFETY INSTRUCTIONS
Do not place items exposed to cooking oils in your dryer. Items
contaminated with cooking oils may contribute to a chemical
reaction that could cause a load to catch fire. To reduce the risk of
fire due to contaminated loads, the final part of a tumble dryer cycle
occurs without heat (cool down period). Avoid stopping a tumble
dryer before the end of the drying cycle unless all items are quickly
removed and spread out so that the heat is dissipated.
Allow the dryer to complete each stage of the program selected,
including the cooling down phase. This will ensure that the items
being removed are not too hot to handle.
Clean the lint filter before or after each load.
Keep the area around the air intake (toe kick) and adjacent
surrounding areas free from lint, dust and dirt.
The interior of the machine should be cleaned periodically by
qualified personnel.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of malfunction or
breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for electric current. This
appliance is equipped with a cord having an equipment grounding
conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
WARNING – Improper connection of the equipment-grounding
conductor can result in a risk of electric shock. Contact a qualified
electrician if you are in doubt as to whether the appliance is properly
grounded.
11
IMPORTANT SAFETY INSTRUCTIONS
Do not modify the plug provided with the appliance: if it will not fit
the outlet, have a proper outlet installed by a qualified electrician.
Before installation, disconnect the tumble dryer from the electrical
supply by shutting off the power main, unplugging the power cord or
tripping the circuit breaker. Do not restore power until the installation
is complete.
Miele Tumble Dryers and Miele Washing Machines can be
installed as a washer-dryer stack. This requires a Miele WasherDryer Stacking Kit which can be purchased separately. Please
ensure that the washer-dryer stacking kit is suitable for the Miele
Tumble Dryer and the Miele Washing Machine.
If you order a plinth for this tumble dryer (available from Miele as
an optional accessory), make sure it is the correct one.
The maximum dry laundry weight is 17.6 lb (8 kg) kg. See the
“Program chart” for the maximum recommended loads for individual
programs.
Do not place shoes inside the drum for drying. Placing shoes
inside the drum for drying can cause the belt to tear, requiring a
service call.
You must always use the dryer basket (optional accessory) when
drying/airing shoes. Follow the additional operating instructions for
the dryer basket.
12
IMPORTANT SAFETY INSTRUCTIONS
This tumble dryer is supplied with a special lamp to cope with
particular conditions (e.g., temperature, moisture, chemical
resistance, abrasion resistance, and vibration). This special lamp
must only be used for the purpose for which it is intended. It is not
suitable for room lighting. Replacement lamps should only be fitted
by a Miele authorized person or by Miele Technical Service.
Information on the heat pump and refrigerant
– This tumble dryer uses refrigerant gas which is not flammable and
not explosive.
– The humming noises caused by the heat pump during the drying
process are normal. They do not impair the efficient functioning of
the tumble dryer.
Damage to the tumble dryer by switching it on too soon.
This can damage the heat pump.
After setting up the tumble dryer, wait for at least one hour before
switching it on.
– This tumble dryer contains fluorinated greenhouse gases.
Hermetically sealed.
Designation of refrigerant: R134a
Amount of refrigerant: 0.61kg
Global-warming potential of refrigerant: 1430kg CO2 e
Global-warming potential of appliance: 872kg CO2 e
13
IMPORTANT SAFETY INSTRUCTIONS
Using a fragrance capsule (optional accessory)
Only use genuine Miele original fragrance capsules.
Store the fragrance capsule in its original packaging.
Make sure that you always keep the fragrance flacon or the lint
filter with the flacon inserted in it in a horizontal position when
carrying, and do not tip or place it down on any surface. The
fragrance can leak out of the flacon.
Use an absorbent cloth to wipe up any fragrance which has
leaked out of the capsule onto the floor, the dryer or any dryer
components (e.g. the lint filter) immediately.
If fragrance comes in contact with the body: Wash skin thoroughly
with soap and water. Flush eyes with clean water for at least
15minutes. If swallowed, rinse mouth thoroughly with clean water.
Seek medical attention if the fragrance comes in contact with the
eyes or is swallowed!
Immediately change clothes that have come in contact with the
fragrance. Thoroughly wash clothing or fabric using a large amount
of water and detergent.
There is the risk of fire or damage to the tumble dryer if the
following instructions are not observed:
– Never refill a capsule with fragrance or any other substance.
– Never use a faulty fragrance capsule.
Dispose of an empty fragrance capsule properly and never use it
for any other purpose.
Please also observe the information supplied with the fragrance
capsule.
14
IMPORTANT SAFETY INSTRUCTIONS
FCC Declaration of Conformity
This appliance complies with Part 15 of the FCC regulations. This
appliance has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules and is
subject to the following conditions: This appliance does not cause
harmful interference. The appliances may be interconnected as
desired.
FCC Radiation Exposure Statement
This appliance complies with FCC RF radiation exposure limits set
forth for an uncontrolled environment. These appliances should be
installed and operated with a minimum distance of 8" (20cm)
between the radiator and body.
Industry Canada Statement
This digital device does not exceed the Class B limits for radio
noise emissions from digital devices specified in the radio
regulations of the Canadian Radio-television and
Telecommunications Commission. This appliance complies with the
Class B specification of the Canadian ICES-003.
SAVE THESE INSTRUCTIONS
15
Operating the tumble dryer
Control panel
a
Language sensor control
For selecting the current user
language.
The operating language is displayed
again at the end of the program.
b
Back sensor control
Takes you back one level in a menu.
c
Touch display
d
Sensor control Start/Stop
For starting the selected drying
program and canceling a program
once it has started. The program
selected can be started as soon as
the sensor control starts flashing.
e
Optical interface
For Technical Service.
f
Button
For switching the tumble dryer on
and off. The tumble dryer switches
off automatically to save energy. This
occurs 15minutes after the end of
the program/anti-crease phase, or
after being switched on if no further
selection is made.
16
Operating the tumble dryer
11:02
Programs Favorites Supervisor
Help
Sensor controls and touch display with sensor controls
The,, andStart/Stopsensor
controls and the sensor controls in the
display react to finger-tip contact. Every
touch of a sensor control is confirmed
with an audible keypad tone. You can
adjust the volume of the keypad tone or
switch it off (see “Supervisor level”).
The control panel with sensor
controls and the touch display can
be scratched by pointed or sharp
objects, e.g., pens.
Only touch the display with your
fingers.
Main menu
After switching on the tumble dryer, the
main menu will appear in the display.
You can access all the important submenus from the main menu.
Touch the sensor control at any
time to return to the main menu.
Values set previously are not saved.
Programs
For selecting drying programs.
Favorites
For selecting one of 12 favorite drying
programs which can be set up and
saved by the supervisor (see “Favorite
programs” under “Supervisor level”).
Supervisor
You can alter the tumble dryer's
electronic to suit changing requirements
in the supervisor level (see “Supervisor
level”).
17
Operating the tumble dryer
11:02
ShirtsCottons Express
DenimDelicates
Programs
Minimum iron
11:02
Gentle tumble
Anti-crease
Extras
OK
OK
12 00
11 59
10 58
13 01
14 02
Clock display
Examples of how to operate the appliance
Option lists
Program menu (single-option list)
You can scroll to the right or the left by
swiping your finger across the screen.
To do this, place your finger on the
touch display and swipe it in the
direction you want.
The orange bar under the pictures
shows that there are further options to
choose from.
Touch a program name to select the
drying program.
Options menu (multiple selection)
Touch one or several Options to select
it/them.
Currently selected Options are
highlighted in orange.
To deselect an Option, simply touch the
Option again.
Use the OKsensor control to activate all
selected Options.
Setting numerical values
You can set numerical values in some
menus.
The display will change to the standard
menu for that program.
18
Enter the numbers by swiping upward
or downward. Place your finger on the
number that you want to change and
move your finger in the direction you
want. Use the OKsensor control to
accept the set numerical value.
Tip: For some settings, depending on
OK
12 00
11 59
10 58
13 01
14 02
Clock display
OK
12:00
3
4
21
Clock display
5 6
7
8
0
9
11:02
Cottons
Status
Time left
h2:27
Drying
the value range and increments, the
value can also be set using a numerical
keypad. Briefly touching the numbers
will bring up the numerical keypad.
Once a valid number has been entered,
the OKsensor control will be
highlighted in green.
Briefly touch a number between the
two lines.
The numerical keypad will appear.
Operating the tumble dryer
If an orange bar appears at the top of
the screen in the middle of the display,
you can open the pull-down menu.
Touch the bar and drag down with your
finger.
Exiting a menu
Tap the sensor control to return to
the previous screen.
Entries made before this which have not
been confirmed withOK will not be
saved.
Help display
With some menus, Help appears along
the bottom line of the display.
Touch the numbers and confirm with
OK.
Pull-down menu
The pull-down menu can be used to
display information, e.g., about a drying
program.
Touch the Helpsensor control to
display the text.
Touch the Closesensor control to
return to the previous screen.
19
Operating the tumble dryer
11:02
Cottons
Help Additional
Cottons Cottons
11:02
Help
Cottons
Delicates
Cottons
Cottons
11:02
Help
Operating a laundromat machine
The entry menu will vary depending on
the programming status (see
“Controls” under “Supervisor level”).
Shortcuts are the easiest way to
operate the machine. Operating staff
are unable to change pre-set programs.
Laundromat ext. (12 prog)
The first 3 programs can be selected
directly. The remaining programs are
selected via another list.
Laundromat, basic (4 prog)
Symbols in the display
Drying levels
Extra Dry
Normal Plus
Normal
Hand Iron Plus
Hand Iron
Machine Iron
Laundromat basic int. time/ Laundromat basic ext. time
4time programs with different
temperature levels are available.
– Temperature level cold
4 programs can be selected directly.
20
– Temperature level low
– Temperature level medium
– Temperature level high
Laundromat basic ext. time: The
tumble dryer only functions correctly
when it is provided with external time
information by an external unit.
Risk of injury or damage to
deutsch
Language
OK
english (AU)
english (CA)
english (GB) español
english (US)
property due to improper installation.
Incorrect installation of the tumble
dryer can lead to personal injury or
damage to property.
Before commissioning the tumble
dryer for the first time, make sure it
has been installed and connected
correctly. See “Installation and
connection”.
Damage caused by switching the
appliance on too soon.
This can damage the heat pump in
the tumble dryer.
After setting up the tumble dryer,
wait for at least one hour before
switching it on.
Follow all the steps required for initial
commissioning.
During the commissioning process,
you will need to define the settings for
daily use of the tumble dryer. Some of
the settings can only be configured
during the initial commissioning
process. After that, they must only be
changed by Miele Technical Service.
Initial commissioning
Switching on the tumble dryer
Press the button.
The welcome screen will light up.
Setting the display language
You will be asked to select the display
language. You can change the language
at any time (see “Language” under
“Supervisor level”).
Scroll to the left or the right until the
language you want appears.
Touch the sensor control for the
language you want.
The selected language will be
highlighted in orange and the display
will change to the next setting.
These settings are also described under
“Supervisor level”.
21
Initial commissioning
OK
Display brightness
Darker Brighter
OK
Date
21
22
24
25
2021
2020
201923 July
August
September
June
May
2018
Reference to external appliances
A reference to external hardware
appears.
Confirm with the OKsensor control.
Before initial commissioning, connect
the XCI box or slide a communication
module into the slot on the back of the
tumble dryer. The tumble dryer must
be disconnected from the power
supply for this process. Then start the
commissioning process.
Setting the display brightness
You will be asked to select the
brightness of the display.
Setting the date
Place your finger on the value that
you want to change and move your
finger in the direction you want.
Once all values have been selected,
confirm with the OKsensor control.
The display will change to the next
setting.
Touch the segment bars until you
reach the required level of brightness.
The selected brightness level will be
highlighted in orange.
Confirm with OK.
The display will change to the next
setting.
22
Initial commissioning
OK
12 00
11 59
10 58
13 01
14 02
Clock display
11:02
Cottons Cottons Express
Cottons PRO Delicates
Program packages
Label Standard
Minimum iron
OK
Confirming the time request
The following question appears in the
display:
Remove the clock display?
Touch the Yes or Nosensor control.
If you select Yes, the system will skip
the Clock displaysetting.
If you select No, the display will switch
to the Clock displaysetting.
Setting the time
Place your finger on the number that
you want to change and move your
finger in the direction you want.
Confirm with the OKsensor control.
The display will change to the next
setting.
Selecting program packages
You can select various programs from
the program packages.
Any programs already active are
highlighted in orange.
Scroll right until you reach a program
that is not highlighted in orange.
Touch the sensor control for the
required program.
The selected program is highlighted in
orange; this means that the program is
active.
You can select further programs.
Tip: You can disable a selected
program by touching the program's
sensor control again.
Exception: The Cottons and
CottonsPRO programs cannot be
disabled.
If you do not want to select any more
programs, confirm with OK.
The display will change to the next
setting.
23
Initial commissioning
11:02
No payment
system
Payment system
OK
Program
control
Timed
operation
Timed impulse
counter
KOM module
Setting up a payment system
If you wish to set up a payment system,
read the “Payment system” section of
the “Supervisor level” chapter. These
settings can only be changed during
the initial commissioning process. If you
wish to change the settings after the
commissioning process, please contact
Miele Technical Service.
If you do not wish to set up a payment
system, you can skip this stage.
Touch the No payment systemsensor
control.
The display will change to the next
setting.
24
Initial commissioning
11:02
Automatic
plus
Timed drying
warm air
Basket - Low
temperature
Microfiber
Timed drying
cool air
Basket
program
Programs
OK
00 20
02 59
01 58
01 21
02 22
Duration
h
11:02
Reset
Completing the commissioning process
The commissioning process is
complete when a program lasting
longer than 20minutes has been
carried out in full.
If the power is interrupted prior to the
start of the first drying program (e.g., if
the machine is switched off with the
button), the initial commissioning
process can be completed again.
Once a drying program has been
running for over 20minutes, the initial
commissioning process cannot be
performed again.
Confirm with OK.
In the main menu, touch
theProgramssensor control.
Place your finger on the number that
you want to change and move your
finger in the direction you want.
Select a duration of 20minutes.
Confirm with OK.
Touch the flashing Start/Stopsensor
control.
After this program has finished, the
tumble dryer is ready for use.
Select the Timed drying cool air
program.
Touch the Durationsensor control.
25
1. Notes on correct laundry care
Washing
– Heavily soiled laundry must be
washed particularly thoroughly. Use
sufficient detergent and select a high
temperature. If in doubt, wash the
items several times.
– New, colored items must be washed
thoroughly and separately. Do not dry
these items with light-colored
garments. There is the risk of colors
running and discoloring other
garments or even plastic components
in the tumble dryer. Dark-colored
fibers can also settle on light-colored
garments and vice versa.
Drying
Damage due to foreign objects
which were not removed from the
laundry.
Foreign objects can melt, burn, or
explode.
Ensure that any foreign objects (e.g.,
detergent dispensing balls, lighters,
etc.) have been removed from the
laundry.
– Sew in or remove underwiring from
bras.
Understanding the care-label symbols
Drying
Normal/higher temperature*
Low temperature*
* In this tumble dryer, items with these
symbols can be dried together thanks
to the gentle drying process.
Do not tumble dry
Ironing
Very hot
Hot
Warm
Do not iron
Risk of fire due to incorrect use
and operation.
The laundry can burn and destroy
the tumble dryer and the
surroundings.
Read and observe the “IMPORTANT
SAFETY INSTRUCTIONS”.
– Check seams and stitching to ensure
that padding and linings are intact.
This way you will avoid the danger of
fillings coming out and causing a fire.
26
2. Loading the tumble dryer
Loading the laundry
Textiles may be damaged.
Before loading, read “1. Notes on
correct laundry care”.
Open the door.
Load the laundry.
Textiles may be damaged.
When closing the door, make sure
that laundry does not get trapped in
the door opening.
Socket for the fragrance flacon
The “Fragrance flacon” chapter
describes how to use the fragrance
flacon.
If you are not using a fragrance flacon:
Push the tab down completely (see
arrow) so that the socket is closed.
Otherwise, lint will accumulate here.
Closing the door
Do not overload the drum.
Overloading can cause unnecessary
wear and tear to the laundry and
cause a disappointing drying result. It
can also cause more creasing.
Shut the door gently.
27
3. Selecting a program
11:02
Programs Favorites Supervisor
Help
11:02
ShirtsCottons Express
DenimDelicates
Programs
Minimum iron
11:02
Cottons
Favorites
Delicates
Cottons
Cottons
Switching on the tumble dryer
Press the button.
The drum lighting will come on.
The drum lighting will automatically go
out after a few minutes and/or after
the start of a program to save energy.
Selecting a program
There are different ways to select a
program.
Touch the Programssensor
control.
Alternatively, you can select a program
via: Favorites*.
* The pre-set programs under
Favorites cannot be changed.
Touch the Favoritessensor control.
Scroll to the right in the display until
the program you want appears.
Touch the sensor control for that
program.
The display will change to the standard
menu for that drying program.
Scroll to the right in the display until
the program you want appears.
Touch the sensor control for that
program.
The display will change to the standard
menu for that drying program.
28
4. Selecting program settings
OK
Overview
not selected
Cottons
11:02
kg
Drying level
Extras
1:56h
Weight
Normal8,0
11:02
Machine iron
Hand iron
plus
Normal plus
Hand iron Normal Extra dry
Drying levels
OK
Overview
not selected
Timed drying
warm air
h0:20
11:02
Duration
Extras
h0:208,0 kg
Weight
OK
00 20
02 59
01 58
01 21
02 22
Duration
h
11:02
Reset
Main menu for a program
Selecting the drying level
The pre-set drying level for many
programs can be changed if required.
Different drying levels are available
depending on the program.
Touch the Drying levelsensor control.
The drying-level selection menu opens.
Selecting the duration (timed programs)
You can select the program duration
yourself.*
* The time frame for the selected
program duration can be limited by
Technical Service.
– Timed drying warm air = 00:20–
2:00hours
– Timed drying cool air = 00:10–
2:00hours
– Basket program/Basket -Low
temperature = 00:20–1:30hours
– Timed, warm air hygiene = 00:50–
2:00hours
Touch the sensor control for the
drying level you want.
Touch the Durationsensor control.
The duration-setting menu opens.
Select a duration.
Only press OK when the option
appears on the display.
29
4. Selecting program settings
OK
Overview
not selected
Cottons
11:02
kg
Drying level
Extras
1:56h
Weight
Normal8,0
11:02
Gentle tumble
Anti-crease
Extras
OK
Selecting extra options
The drying programs can be
augmented with various extra options.
Touch the Extrassensor control.
Touch the sensor control for the
option you want.
Anti-crease
After the program has finished, the
drum will continue to rotate in a certain
rhythm, depending on the selected
program. This helps to prevent creasing
after the program has ended.
The anti-crease function is switched off
as the factory default setting. It can be
switched on in the supervisor level with
a variable duration of up to 12hours.
Only press OK when the option
appears on the display.
The relevant symbol for the selected
option or lights up.
Not all extra options can be selected
with every program, only those
programs for which it makes sense.
Gentle
Sensitive items are dried with less
mechanical movement (fewer drum
rotations).
30
5. Starting a program
Payment system
Tip: If your machine is connected to a
payment system, the amount of
payment required will appear in the
display.
Once the program has started, do not
open the door or cancel the program.
Depending on the settings, money
may be lost in the payment system.
Starting a program
The program can be started as soon as
the Start/Stopsensor control is flashing
on and off.
Touch the Start/Stopsensor control.
If a delay-start period has been
selected, this will appear in the display.
The program duration will appear in the
display either straight away or once the
delay-start period has elapsed. The
program sequence is also shown in the
display.
Program duration/Estimated time remaining
The program duration depends on the
quantity of laundry, the type of fabric,
and the residual moisture in the laundry
or also the water hardness. The running
time for drying-level programs can
therefore vary or “jump”. The tumble
dryer's electronic adapts to these
factors and then adjusts the displayed
program duration with increasing
accuracy.
Tip: In the pull-down menu, you can
view the selected drying level or
duration and the selected options.
31
6. End of program – removing the laundry
End of program
The laundry will be cooled down shortly
before the end of the program. The
laundry can now be unloaded.
– Finish lights up
If Anti-crease* has been selected,
the drum rotates in intervals. This
reduces creasing if the laundry cannot
be removed straight away.
* The anti-crease function is switched
off as the factory default setting.
The tumble dryer will switch off
automatically 15minutes after the end
of a program.
Removing the laundry
Open the door.
Remove everything from the drum.
Items left in the dryer could be
damaged by over-drying when the
dryer is used the next time.
Always remove all items from the
drum.
32
Switch the tumble dryer off.
Observing the care notes
This tumble dryer requires regular
maintenance, particularly if it is used
on a continuous basis.
Tip: Please see “Cleaning and care” for
details. Read the “Cleaning the
appliance at the correct intervals”
section first.
Timer
TheDelay start must be activated in
theSupervisor level so that the timer
can be selected.
Before the program starts, theTimer
can be used to select a program start
time or program end time.
Setting the timer
Touch the Timersensor control.
Select theFinish at, Start in, orStart
atoption.
Set the hours and the minutes and
confirm your entry with the OKsensor
control.
Changing the timer
The selected delay-start period can be
changed before the program starts.
Touch the,, or sensor
control.
If required, change the specified time
and confirm with the OKsensor
control.
Starting the timer
Touch the Start/Stopsensor control.
The door will lock and the time until the
program starts will appear in the
display.
After the program has started, the
selected delay-start period can only
be changed by interrupting the
program.
The program can be started
immediately at any time.
Touch the Start immediatelysensor
control.
Deleting the timer
The selected delay-start period can be
canceled before the program starts.
Touch the,, or sensor
control.
The selected delay-start period will
appear in the display.
Touch the Deletesensor control.
Confirm with the OKsensor control.
The selected delay-start period is
deleted.
33
Program chart
All weights marked with * are based on the weight of dry laundry.
Label
Cottons Eco Maximum 17.6 lb (8 kg)*
Items Cotton items such as those described under Cottons, Normal with
normal residual moisture.
Note – Items are dried to a Normal level only in this program.
– The Cottons program is the most energy-efficient for drying
cotton items with normal residual-moisture levels.
Note for
test
institutes
Cottons PRO Maximum 17.6 lb (8 kg)*
Items Cotton items such as those described under Cottons, Normal with
Note Items are dried to a Normal level only in this program.
Test program in accordance with Regulation392/2012/EU,
measured in accordance with EN61121.
normal residual moisture.
34
Program chart
Program packages
You can select various programs from the program packages. The programs will
appear in the program list.
Standard
Cottons Maximum 17.6 lb (8 kg)*
Extra Dry, Normal Plus, Normal
Items – Single and multi-layered cotton items.
– Towels, bathrobes, T-shirts, underwear, jersey bed linen, baby
clothes.
– Workwear, jackets, cotton blankets, overalls, dish towels, bed
linen, towels, boil-proof table linens/drapes.
Note – Select Extra Dry for multi-layered and very thick fabrics.
– Do not use Extra Dry for jersey fabrics (e.g., T-shirts, underwear,
baby clothes) because they can shrink.
Handironplus, Handiron, Machineiron
Items – Cotton and linen fabric.
– Table linens/drapes, bed linen, starched laundry.
Tip To prevent laundry from drying out, it should be rolled up until you
are ready for ironing.
Minimum iron Maximum 8.8 lb (4kg)*
Normal Plus, Normal, Hand iron
Items – For wrinkle-free items made of cotton, synthetic, or mixed fiber.
– Workwear, overalls, pullovers, dresses, pants, table linens/drapes,
tights.
Note is automatically selected.
Express Maximum 8.8 lb (4kg)*
Extra Dry, Normal Plus, Normal, Handiron plus, Handiron, Machineiron
Items Garments suitable for the Cottonsprogram
Note Shorter program duration
35
Program chart
Delicates Maximum 8.8 lb (4kg)*
Normal Plus, Normal, Hand iron plus
Items – Delicate synthetic, cotton ,or mixed-fiber fabrics.
– Lightweight pullovers, dresses, pants, overalls, table cloths, dress
shirts, and blouses.
– Lingerie and appliquéd fabrics.
Note Less creasing occurs in this program.
Tip Reducing the load will reduce creasing even further.
Dress Shirts Maximum 4.4 lb (2kg)*
Normal, Hand iron plus
Items Shirts and blouses.
Denim Maximum 7.7 lb (3.5kg)*
Normal, Hand iron plus
Items Denim garments, e.g., jeans, jackets, skirts, shirts.
Woolens Maximum 4.4 lb (2kg)*
Items Woolen garments and fabric containing wool blends, e.g., pullovers,
cardigans, tights.
Note – Wool and wool-blend items are only fluffed up; they are not dried
completely.
– Remove garments as soon as the program has finished and leave
to finish drying at room temperature.
Silks Maximum 2.2 lb (1kg)*
Items Silk garments which are suitable for tumble drying, e.g., blouses and
shirts
Note – Program for reduced creasing.
– Items are not dried completely in this program.
– Remove the garments as soon as the program has finished.
36
Program chart
Toweling Maximum 17.6 lb (8 kg)*
Items Large quantities of single-layered and multi-layered toweling items.
These include, for example, towels, bath towels, bath robes, face
flannels, flannel bed linen.
Note Items are dried to a Normal Plus level only in this program.
Gentle Smoothing Maximum 2.2 lb (1kg)*
Normal, Hand iron plus
Items – Cotton and linen fabrics.
– For wrinkle-free items made of cotton, synthetic, or mixed fiber.
For example, pants, jackets, and shirts.
Note – This program smoothes out creasing caused during the spin cycle
in the washing machine.
– Items are not dried completely. Remove garments as soon as the
program has finished and leave to finish drying at room
temperature.
– Also suitable for dry laundry that is smoothed for a fixed time
interval.
Automatic Plus Maximum 11 lb (5kg)*
Normal Plus, Normal, Hand iron plus
Items Mixed loads of garments suitable for the Cottons and Minimum iron
programs.
Microfiber Maximum 15.4 lb (7kg)*
Normal Plus, Normal
Items Microfiber mops and cleaning cloths.
37
Program chart
Timed drying warm air Maximum 17.6 lb (8 kg)*
Items – Voluminous items such as jackets, pillows, sleeping bags, and
padded items.
– Fabrics made up of multiple layers, e.g., heavy cotton table cloths.
– Individual items of laundry, e.g., towels, swimwear, dish towels.
Note – For airing multi-layered fabrics or large items that dry unevenly
due to their make-up.
– For drying a small number of individual garments.
– Do not select the longest drying time to start with. Check the
items as you are drying them to find the optimum time.
Timed drying cool air Maximum 17.6 lb (8 kg)*
Items Any item that only needs airing.
Basket Basket load 7.7 lb (3.5kg)
Basket – Low temperature Basket load 7.7 lb (3.5kg)
Fabric
type/items
Note – These programs may only be used with the Miele Dryer Basket
38
– Always follow the operating instructions for the dryer basket.
– These programs must only be used to dry or air items which are
suitable for drying in a tumble dryer but which are not suitable for
drying using mechanical action.
(optional accessory).
– Select Basket – Low temperature for temperature-sensitive items.
– The dryer drum does not turn.
– A satisfactory drying result cannot be achieved without the dryer
basket.
– Always follow the operating instructions for the dryer basket.
Program chart
Sport
Sportswear Maximum 6.6 lb (3kg)*
Items Sportswear that is suitable for drying in a tumble dryer.
Note Items are dried to a Normal level only in this program.
Outdoor Maximum 5.5 lb (2.5kg)*
Normal, Hand iron plus
Items Outdoor clothing which is suitable for drying in a tumble dryer.
Proofing Maximum 5.5 lb (2.5kg)*
Textiles For drying microfiber fabrics, skiwear, outdoor wear, fine close
weave-cotton garments (poplin), and table linens which are suitable
for drying in a tumble dryer.
Note – This program includes an additional proofing-fixing phase.
– Only use proofing agents that are stated by the manufacturer as
being “suitable for use on membrane textiles”. These agents
contain fluorochemical compounds.
– Do not dry items which have been treated with proofing agents
containing paraffin. This substance is a fire risk.
– Items are dried to a Normal level only in this program.
Reactivation Maximum 5.5 lb (2.5kg)*
Items Outdoor clothing which is suitable for drying in a tumble dryer.
Note – The drying process revitalizes the fibers, which improves the
water-repelling effect.
– Items are dried to a Normal level only.
39
Program chart
Soft furnishings
Down bedding Maximum 4.4 lb (2kg)*
Items Bedding suitable for tumble drying (duvets or pillows filled with
down or feathers).
Note Items are dried to a Normal level only in this program.
Tip Feathers have a tendency of developing a strong odor when they are
warm. Allow bedding to air outside the tumble dryer after drying.
Synthetic bedding Maximum 4.4 lb (2kg)*
Items Bedding suitable for tumble drying (duvets or pillows with a
synthetic filling).
Note Items are dried to a Normal level only in this program.
Large items Maximum 8.8 lb (4kg)*
Normal Plus, Normal, Hand iron, Machine iron
Items Robust, larger items for the Cottons program. These include, for
example, blankets, multi-layered covers, large voluminous items.
40
Program chart
Hygiene
Cottons hygiene Maximum 8.8 lb (4kg)*
Items Cotton or linen items that come into direct contact with the skin.
These include, for example, underwear, baby clothes, hand towels,
bath towels, bathrobes, spa towels, and flannels.
Note Items are dried to a Normal level only in this program.
Minimum iron hygiene Maximum 8.8 lb (4kg)*
Items – For wrinkle-free items made of cotton, synthetic, or mixed fiber.
– Workwear, overalls, pullovers, dresses, pants, table linens/drapes,
tights.
Note Items are dried to a Normal level only in this program.
Timed drying hygiene Maximum 8.8 lb (4kg)*
Items – Voluminous items such as jackets, pillows, sleeping bags, and
padded items.
– Fabrics made up of multiple layers, e.g., heavy cotton table cloths.
– Individual items of laundry, e.g., towels, swimwear, dish towels.
Note – For airing multi-layered fabrics or large items that dry unevenly
due to their make-up.
– For drying a small number of individual garments.
– Do not select the longest drying time to start with. Check the
items as you are drying them to find the optimum time.
In the hygiene programs, items will be dried with a temperature that is constant
over an extended period (longer temperature-holding time). This kills off microorganisms such as germs or dust mites and reduces allergens in the laundry.
If a hygiene program is canceled early, micro-organisms will not be killed.
Do not cancel this program.
41
Program chart
WetCare
WetCareSensitive Maximum 5.5 lb (2.5kg)*
Items Non-washable outerwear
Note The garment is briefly dried and fluffed up
WetCareSilks Maximum 5.5 lb (2.5kg)*
Normal, Handironplus, Handiron
Items Non-washable silk garments which crease easily
WetCareIntensive Maximum 5.5 lb (2.5kg)*
Normal Plus, Normal, Hand iron, Handiron plus, Machineiron
Items Washable outerwear
Flatwork
Cottons 40% residual moisture Maximum 17.6 lb (8 kg)*
Cottons 25% residual moisture Maximum 17.6 lb (8 kg)*
Minimum iron 20% residual moisture Maximum 8.8 lb (4kg)*
Items – Hotel, care-home, or hospital laundry that requires further
processing (hand ironing, machine ironing, folding).
– This includes cottons and minimum-iron fabrics, such as bedding,
table linens/drapes, or towels.
Note – The residual moisture is absorbed by the fabric fibres, which
makes them easier to smooth.
– These programs only dry to Machineiron.
Tip – To prevent laundry from drying out, it should be rolled up until you
are ready for ironing.
– Shake the laundry before ironing.
42
Program chart
Special programs
You can put together 5 special
programs and assign your own program
names. Enter these into the tables.
Load: Maximum 17.6 lb (8 kg)kg
(weight of dry items)
Example
[Special program 1]Dry+
Res. moisture program
– Final residual moisture: - 6%
– Extra drying time: 30min
– Temperature: 140°F
(60°C)
(1)
–
–
–
–
–
–
–
(2)
–
–
–
–
–
–
–
(3)
–
–
–
–
–
–
–
(4)
–
–
–
–
–
–
–
(5)
–
–
–
–
–
–
–
43
Changing the program sequence
Payment system
Opening the door or canceling the
program after it has started may cause
a loss of credit (depending on how the
tumble dryer was set up*).
* Either during the commissioning
process or subsequently, Technical
Service can reset the payment system
so that programming changes can be
made.
Changing a program once it has started
You cannot change to another program
once a program has started (this
prevents unintentional alterations). You
will need to cancel the current program
before you can select a new one.
Risk of fire due to incorrect use
and operation.
The laundry can burn and destroy
the tumble dryer and the
surroundings.
Read and observe the “IMPORTANT
SAFETY INSTRUCTIONS”.
Canceling a program
Touch the Start/Stopsensor control.
A message will appear in the display
asking if you wish to cancel the
program.
Adding laundry
Open the door.
Risk of burns by touching hot
laundry in the drum.
You could burn yourself.
Let the laundry cool down and
remove it carefully.
Add items.
Close the door.
Start the program.
Interruption to the power supply
If the power supply is interrupted
because the tumble dryer has been
switched off with the button:
Switch the tumble dryer on.
Touch the Start/Stopsensor control.
If the power supply is interrupted by a
power cut:
When power is restored, confirm with
OK.
Touch the Start/Stopsensor control.
Time left
Altering the program sequence can
cause the program duration shown in
the display to be adjusted.
Touch the Yessensor control.
Reselecting a canceled program
Open and close the door.
Select and start a new program.
44
Fragrance flacon
Inserting a fragrance flacon
Fragrance flacons (optional
accessories) can be used to give your
laundry a pleasant scent.
Risk of fire and damage to the
health if fragrance flacons are used
incorrectly.
The leaked fragrance can damage
your health if it comes into contact
with your body. Leaked fragrance
can cause fire.
Before using a fragrance flacon,
please read “IMPORTANT SAFETY
INSTRUCTIONS”, “Using the
fragrance flacon (optional
accessory)”.
Only hold the fragrance flacon as
illustrated. Do not hold it at an angle
or tip it as the fragrance will leak out
of it.
The fragrance flacon is inserted in the
upper lint filter. The socket is next to
the recessed grip.
If you are not using a fragrance
flacon, the cover to the unused
socket must remain closed to
prevent the build-up of lint.
Push the tab on the cover to the
bottom (see arrow).
Open the cover using the tab until the
tab is right at the top.
Hold the fragrance flacon securely so
that you do not open it by mistake.
Pull off the protective seal.
Open the door of the tumble dryer.
45
Fragrance flacon
Insert the fragrance flacon as far it will
go into the socket.
The markers and must line up
with one another.
Turn the outer ring clockwise a
little.
The fragrance flacon may slip out.
Turn the outer ring in such a way that
the markers and line up.
46
Fragrance flacon
Opening the fragrance flacon
Before drying, you can select the
intensity of the fragrance.
Turn the outer ring clockwise: The
further you open the fragrance flacon,
the more intense the fragrance.
Damp laundry and longer drying
durations with sufficient heat transfer
are needed for the fragrance to be
released into the laundry effectively.
The fragrance will also be noticeable in
the room air during the process. The
Timed drying cool air program will not
generally apply fragrance.
Closing the fragrance flacon
After drying, the fragrance flacon should
be closed to prevent the fragrance from
escaping needlessly.
Turn the outer ring counterclockwise
until markerb is in position_.
If you wish to dry without the
fragrance occasionally: Remove the
fragrance flacon and store it in its
original packaging.
Replace the fragrance flacon with a
new one when the intensity of the
fragrance is no longer sufficient.
47
Fragrance flacon
Removing/replacing the fragrance flacon
Turn the outer ring counterclockwise
until markersa andb line up.
The fragrance can leak out of the
flacon. Do not lay the fragrance
flacon down.
Replace the fragrance flacon with a
new one.
When not in use, you can store the
fragrance flacon in its original
packaging.
Fragrance flacons are available to
order from Miele dealers, Miele
Technical Service, or online.
48
– If you are keeping the fragrance
flacon in its original packaging, do
not store the packaging upright on its
edge or upside down. Otherwise, the
fragrance will leak out.
– Always store in a cool, dry place
away from direct sunlight.
– When purchasing new fragrance
flacons, only remove the protective
seal just before use.
Cleaning and care
Observing the cleaning intervals
This tumble dryer is equipped with a
multi-stage filter system, which
consists of lint filters (1.) and a filter in
the toe-kick (2.).
This filter system collects all lint
generated during the drying process.
Failure to clean the filter regularly could
increase drying times.
Fire hazard due to irregular
maintenance.
Too many lint deposits in the filter
system and tumble dryer will result in
a risk of fire.
Check the filter system and airsupply area on a regular basis. Clean
the filter if you find any lint deposits.
Damage caused by a missing or
damaged filter system.
Too many lint deposits in the filter
system and tumble dryer will result in
a risk of appliance malfunctions and
a risk of fire.
Never use the tumble dryer without
the filter system. Always replace a
damaged filter system immediately.
1. When to clean the lint filter
The lint filters are located in the drumloading area.
Clean the filters after every program
and always clean them when the
following prompt appears in the
display: Clean out the airways.
To delete the message: Touch the
OKsensor control.
49
Cleaning and care
2. When to clean the filter in the toekick
The filter in the toe-kick is behind the
lint-filter flap on the bottom left.
With normal use
Clean the filter when this prompt
appears in the display: Clean out the
airways.
With continuous use
Clean once a day and also when the
prompt appears in the display.
Damage caused by insufficient
cleaning or by operation with a worn,
damaged filter in the toe-kick.
There is insufficient flow of air and
heat in the heat exchanger due to
clogging. This requires a visit from
the Technical Service department.
This can be avoided by following the
advice in these operating
instructions.
The surface of the filter in the filter
insert is visible after removing the lint
filter. This filter surface also has to be
cleaned.
To delete the message: Touch the
OKsensor control.
50
3. When to clean the grille in the bottom right/heat exchanger for heat dissipation
Clean when Open bottom right grille,
clean the heat exchanger appears in
the display.
The bottom-right grille can be removed.
This covers the heat exchanger for heat
dissipation.
Keep the room where the tumble
dryer is located free from dust and
lint. Doing so will mean that you will
rarely have to clean the grille.
See “Bottom-right grille/heat
exchanger”.
Cleaning and care
Also check and clean the filter in the
toe-kick and the surfaces of the lint
filters.
To delete the message: Touch the
OKsensor control.
51
Cleaning and care
Cleaning the lint filters
This tumble dryer has 2 lint filters in
the loading area. The upper and lower
lint filters trap lint produced during the
drying process.
Removing the fragrance flacon
The intensity of the fragrance will be
diminished if the lint filters and the toekick filter are not cleaned.
Remove the fragrance flacon as
described in “Removing/replacing the
fragrance flacon” under “Fragrance
flacons”.
Removing visible lint
Remove any lint after every drying
cycle.
Tip: You can also use a vacuum cleaner
so that you can remove the lint without
touching it.
Open the door.
Remove the lint (see arrows).
Remove the lint (see arrows) from the
filter surface of all the lint filters and
the perforated laundry deflector.
Push the upper lint filter back into
position until it clicks.
Close the door.
Pull the upper lint filter forward to
remove it.
52
Cleaning the lint filters and air-flow openings thoroughly
If the drying duration has become
longer or the surface of the filters is
visibly compacted with lint, you should
carry out the following cleaning
procedure.
Cleaning the lint filters while dry
Pull the upper lint filter forward to
remove it.
Cleaning and care
Use a vacuum cleaner with a long
crevice nozzle attached to remove
any visible lint from the upper air-flow
openings.
Turn the yellow knob until it clearly
engages.
Pull the lint filter forward to remove it.
53
Cleaning and care
Cleaning the lint filters with water
Rinse the filter surfaces through
under warm running water.
Wipe the smooth plastic surfaces of
both lint filters with a damp cloth to
clean them.
Wet lint filters could cause
operational faults while drying.
Shake the lint filters thoroughly and
then dry them carefully.
Push the lower lint filter in completely
and lock it with the yellow knob.
Push the upper lint filter in
completely.
Close the door.
54
Cleaning and care
Cleaning instructions when using fabric softener sheets
If you are using fabric softener sheets,
please follow these warnings and
instructions.
First, clean the filters as
described in “Cleaning the lint filters
with water”.
If the surfaces of the lint filters are
still strongly compacted with lint,
then follow these measures.
Please note the plastic and surfaces
of the lint filters can be damaged by
the cleaning process described
below.
If the surfaces of the lint filters
are not cleaned, this can extend the
drying time and increase the energy
consumption.
Try the following 3 cleaning instructions
to determine the one that achieves the
best results.
Option 3
Wet the surfaces of the lint filters with
a liquid color detergent (e.g., Miele
Ultra Color Liquid Laundry Detergent).
Leave it on for approx. 2 hours.
Risk of fire!
Then rinse the filter surfaces
thoroughly with warm water to
remove all residues.
Option 1
Wipe the surfaces of the lint filters
several times with a cleaning cloth
with an alcohol base until you have
removed the impurities/obstructions.
Risk of fire!
Then rinse the filter surfaces
thoroughly with warm water to
remove all residues.
Option 2
Clean the lint filters in the dishwasher
without any other dishes. Use a hightemperature program.
55
Cleaning and care
Cleaning the toe-kick filter
The lint filter in the toe-kick collects
finer lint, hair, and detergent residues
that have got through the surfaces of
the lint filters.
Removing the lint filter
Reach behind the catch with your
finger.
Pull the lint filter out at an angle.
Open the lint-filter flap.
Use the handle to pull out the lint
filter at an angle
right.
56
forward and to the
Pull the handle out of the lint filter.
Cleaning and care
Cleaning the lint filter with water
Clean the filter thoroughly under
running water.
Squeeze the filter very carefully
several times as you rinse it.
Rinse the filter until all visible residues
have been removed.
Damage caused by a
insufficiently cleaned or damaged lint
filter.
If the filter has not been properly
cleaned or is damaged, the heat
exchanger will be clogged. There will
be an insufficient flow of air and heat
in the heat exchanger. This will
require a visit from the Technical
Service department.
Before and after cleaning, check the
toe-kick filter in accordance with the
description in “Replacing the toekick filter”. The toe-kick filter must be
perfectly functional and undamaged
after cleaning.
Replacing the toe-kick filter
Filter wear caused by continuous
tumble-dryer use.
If the tumble dryer is in continuous
use and is being cleaned regularly,
the toe-kick filter can begin to show
signs of wear after a while. This can
clog up the heat exchanger.
Replace the filter immediately if you
see the following signs of wear
before or after cleaning (optional
accessory).
Poor fit
Use a damp cloth to remove any lint
from the handle.
The edges of the filter do not sit
properly and the filter is deformed. Lint
will blow into the heat exchanger
unfiltered through edges that do not sit
properly. This will cause a permanent
obstruction in the heat exchanger.
57
Cleaning and care
Deformation
Deformations indicate that the filter has
become blocked and worn by
continuous use.
Cracks, tears, indentations
White residues or residues of other
colors
Residues arise from laundry fibers and
traces of detergent components which
can clog the filter. They can be found
on the front and side edges of the filter.
In extreme cases, they can form
stubborn crust.
Residues are a sign that the filter no is
longer a snug fit at the sides, even if it
appears to be perfect: Lint is getting in
unfiltered at the edges.
If these residues appear on the filters
again soon after cleaning, the filter must
be replaced.
Lint will blow into the heat exchanger
through cracks and tears and will cause
obstruction.
Indentations indicate that the filter has
become blocked and worn by
continuous use.
58
Cleaning and care
Cleaning the filter insert (in the toe-kick)
The surface of the filter in the filter
insert is visible after removing the lint
filter in the toe-kick. This filter surface
must only be cleaned if there is a visible
accumulation of lint.
Carefully vacuum up any visible lint or
soiling. Use a dusting brush or the
narrow crevice nozzle.
If there are visible blockages or other
residues after cleaning: Remove the
filter insert and clean it under running
water. If stubborn residues are not
removed, these can lead to faults
over time.
Removing the filter insert
If the filter insert is clogged up and
soiled, it must be removed and cleaned
under running water.
Use the handle to pull out the filter
insert at an angle
right.
forward and to the
Then pull the filter insert out at an
angle.
Rinse the filter surface of the insert
under warm running water.
Wet lint filters could cause
operational faults while drying.
Shake the filter insert thoroughly and
then dry it carefully.
59
Cleaning and care
Checking the cooling fins on the heat exchanger
Danger of injury caused by
touching the cooling fins.
You could cut yourself.
Do not touch the cooling fins with
your hands.
After removing the filter insert, visually
check the cooling fins on the heat
exchanger. Check for any accumulation
of lint.
If you notice any visible soiling,
carefully vacuum it up with a vacuum
cleaner. Use a dusting brush or the
narrow crevice nozzle.
Risk of damage if cooling fins are
cleaned incorrectly.
The cooling fins can suffer damage
or distortion. This could hinder the
operational performance of the
tumble dryer.
Clean using a vacuum cleaner with a
dusting brush attached. Only pass
the vacuum cleaner dusting brush
over the heat-exchanger fins lightly,
without applying any pressure.
60
Reinstalling the filter insert (in the toe-kick)
Use the handle on the right to slide
the filter insert at an angle
edge.
behind the
Cleaning and care
Press the frame of the filter insert in
at the positions marked PUSH until it
audibly engages.
Reinstalling the lint filter (in the toe-kick)
Then press on the left handle until
the filter insert is secured in position.
Place the lint filter back on the
handle. Make sure it is the correct
way round.
61
Cleaning and care
Use the handle on the right to slide
the lint filter at an angle
edge.
behind the
Cleaning and closing the lintfilter flap
Use a damp cloth to remove any lint.
Make sure that you do not damage
the rubber seal when doing this.
Then press on the handle until the
lint filter is secured in position.
62
Close the lint-filter flap.
The toe-kick filter must be inserted
and the lint-filter flap must be closed
to ensure the system is correctly
sealed and that the tumble dryer will
function correctly.
Cleaning and care
Cleaning the bottom-right grille/heat exchanger
The heat exchanger's cooling fins
behind the grille can become blocked
with dust and dirt drawn in from the
surrounding area.
Removing the grille
Open the lint-filter flap.
Open the bottom-right grille, e.g.,
using a spoon handle.
Open the grille from left to right and
pull it off at an angle to the front.
Insert a spoon handle underneath the
grille (under the recess).
Press and lever the grille gently until it
opens on the left-hand side.
63
Cleaning and care
Cleaning the cooling fins
Check whether the cooling fins are
clogged.
Danger of injury caused by
touching the cooling fins.
You could cut yourself.
Do not touch the cooling fins with
your hands.
If there is visible soiling:
Carefully vacuum up any visible lint or
soiling. Use a dusting brush or the
narrow crevice nozzle.
Replacing the grille
Insert the grille on the right-hand
side.
Press the grille firmly on the left-hand
side.
Risk of damage if cooling fins are
cleaned incorrectly.
The cooling fins can suffer damage
or distortion. This could hinder the
operational performance of the
tumble dryer.
Clean using a vacuum cleaner with a
dusting brush attached. Only pass
the vacuum cleaner dusting brush
over the heat-exchanger fins lightly,
without applying any pressure.
64
Cleaning and care
Cleaning the tumble dryer
Disconnect the tumble dryer from the
electrical supply.
Damage caused by the use of
unsuitable care products.
Unsuitable care products could
damage plastic surfaces and other
parts.
Do not use any solvents, abrasive
cleaners, glass cleaners, or allpurpose cleaners.
Danger of electric shock caused
by water.
There is a risk of electric shock if
water runs over or into the tumble
dryer.
Never spray the tumble dryer with
water. Only ever clean the appliance
with a slightly damp, soft cloth.
The drum and other stainless steel
parts can be cleaned with a suitable
stainless steel cleaner.
Clean the tumble dryer and the seal
on the inside of the door with a
slightly damp soft cloth, a mild
solution of liquid dish soap, and
water.
Dry all the parts with a soft cloth.
65
Frequently Asked Questions
With the help of the following guide minor faults in the performance of the
machine, some of which may result from incorrect operation, can be remedied
without contacting the Service Department.
This guide may help you to find the reason for the fault, and how to correct it.
The display indicates the following messages or faults
Message Possible cause and solution
The drum is empty
or the laundry is too
dry.
lights up after a
program has
been canceled.
Power outage. Pro-
gram stopped
Open bottom right
grille, clean the heat
exchangerlights
up at the end of a
program.
This is not a fault.
In some programs, if the drum has been underloaded
or is empty, the program will be canceled. This can
also happen if the items are already dry.
Open the door and check the laundry.
Add items if necessary.
Close the door to resume drying.
Dry individual items using the Time Dry program.
There has been a power outage.
When power is restored, confirm with OK.
Touch the Start/Stopsensor control.
The heat exchanger's cooling fins behind the grille
can become blocked with dust and dirt drawn in from
the surrounding area and the airways can become
blocked with lint.
Clean as described in “Bottom-right grille/heat
exchanger” under “Cleaning and care”.
Check and clean the filters in the loading area and
in the toe-kick.
To delete the message: Touch the OKsensor
control.
66
Frequently Asked Questions
Message Possible cause and solution
Clean out the air-
wayslights up at
the end of a program.
The tumble dryer is not working correctly or
economically. Possible causes could be clogging
caused by lint or detergent residue.
Normally, all you have to do is clean the lint filter.
Also check the toe-kick filter and clean it if
necessary.
If you have removed the toe-kick filter, also check
the filter insert behind it. Clean it if necessary.
Please see “Cleaning and care” for notes on
cleaning.
To delete the message: Touch the OKsensor
control.
67
Frequently Asked Questions
Message Possible cause and solution
Clean the lint filter.
Check the airways.lights up af-
ter a program
has been canceled.
Clean the lint filter.
Check the airways.continues
to light up after a
program has
been canceled,
despite thorough
cleaning.
You have attempted to dry only a few items of
varying size. A smaller item has been sucked into the
loading area in the door and is clogging the holes in
the laundry deflector.
To delete the message: Touch the OKsensor
control.
Open the tumble-dryer door.
Remove the item that is blocking the holes.
Always dry small, individual items together with
larger items.
If you are able to exclude these issues a different
problem has occurred. See below.
The system has been clogged by lint or detergent
residue.
Clean all lint filters and air channels.
Check whether the lint filters in the loading area
and toe-kick are free from damage and in good
working order.
If you have removed the toe-kick filter, also check
the filter insert behind it. Clean it if necessary.
If you have removed the filter insert, also check the
heat exchanger behind it. Clean it if necessary.
Please see “Cleaning and care” for notes on
cleaning. Damaged, deformed, or uncleanable lint
filters must be replaced.
To delete the message: Touch the OKsensor
control.
The plinth filter looks clean after thorough cleaning.
However, the program terminates and the error
message appears again. It is likely that there is still
underlying residue that could not be removed.
To delete the message: Touch the OKsensor
control.
Replace the plinth filter with a new one.
You can reactivate the removed, “old” plinth filter
in the washing machine. Follow the instructions
described in “Frequently Asked Questions –
Reactivating the plinth filter”.
68
Frequently Asked Questions
Message Possible cause and solution
Check water drain
lights up after a
program has
been canceled.
The condensate drain is faulty.
Check that the drain hose is in good working order
and is not bent.
To delete the message: Open and close the door
while the tumble dryer is switched on.
Plinth filter not fitted.
Please fit it.
Fault F. If restart
fails, contact Service.
lights up after a
program has
been canceled.
Obstruction de-
tected. Untangle
laundry and restart
lights up after a
program has
been canceled.
Finish/Cooling downlights
up and the drying
process is not yet finished.
The toe-kick filter has not been inserted.
Check the filter in the toe-kick.
Removing the filter during a drying program will
result in the program being canceled.
There is no obvious cause.
Note the prompt in the display.
Touch the OKsensor control.
If the program terminates again with the same error
message, then there is a fault. Contact Miele
Technical Service.
The laundry is unevenly distributed or has rolled up.
Open the door and loosen the laundry. Take out
some of the laundry if necessary.
Close the door.
Start a program.
This is not a fault. The laundry is still being cooled.
The program is just about to end.
You can remove the laundry and spread it out to
cool down or leave it in the tumble dryer to cool
down until the end of the program.
69
Frequently Asked Questions
Unsatisfactory drying results
Problem Possible cause and solution
The laundry is not sufficiently dry.
Large items of laundry
have rolled up, causing
a problem. The individual items of laundry are
still damp.
The laundry or featherfilled pillows develop a
smell after drying.
Items made of synthetic
fibers are charged with
static electricity after
drying.
Lint is caused by tumble
drying.
The load consisted of different types of fabric.
Finish drying using the Timed drying warm air
program.
The laundry could not be untangled in the program
you selected. Smaller items have rolled up into one.
Untangle the laundry.
Select the Large items program.
If the Large items program does not appear in the
display for selection, you can activate it later.
How to activate a program later is described in
“Supervisor level” – “Opening the Supervisor level” and
“Program selection/Program packages”.
The laundry was washed with insufficient detergent.
Feathers have a tendency of developing a strong
odor when they are warm.
Laundry: Use sufficient detergent.
Pillows: Take out of the tumble dryer and air them.
Synthetic fibers tend to attract static charge.
Static charge can be reduced by adding a fabric
softener to the final rinse in the washing program.
Lint is principally the result of friction when garments
are being worn and to some extent when they are
being washed. Machine drying hardly causes any lint
to form.
Lint is collected by the lint filters and fine filter and
can be easily removed.
See “Cleaning and care”.
70
Frequently Asked Questions
The drying-cycle duration is very long
Problem Possible cause and solution
The drying process
goes on too long or
even switches off*.
The room where the tumble dryer is located is too
warm.
Ventilate the room thoroughly.
Detergent residues, hair, and fine lint can clog the
filters.
Clean the lint filters and the filter in the toe-kick.
See “Cleaning and care” for an in-depth
description.
If you have removed the toe-kick filter, also check
the filter insert behind it. Clean it if necessary.
If you have removed the filter insert, also check the
heat exchanger behind it. Clean it if necessary.
The cooling fins behind the bottom-right grille are
soiled.
Clean as described in “Bottom-right grille/airways”
under “Cleaning and care”.
The laundry is too damp.
Spin using a higher spin speed in the washing
machine.
The drum is too full.
Do not exceed the maximum load for the program
selected.
Metallic components, e.g., zippers, have prevented
the dryer from registering the correct moisture level.
Open the zippers next time.
If the problem recurs, dry these items using the
Timed drying warm air program.
* Switch the tumble dryer off and on again before starting a new program.
71
Frequently Asked Questions
General problems with the tumble dryer
Problem Possible cause and solution
You can hear buzzing or
humming operating
noises.
The drum lighting does
not come on.
The display is in a different language.
This is not a fault. The compressor (heat pump) is
operating.
These noises are quite normal and can be heard
when the compressor is operating.
The drum lighting switches off automatically when
the door is closed.
To save energy, the drum lighting will switch off
after a few minutes if the door is left open for an
extended period.
The drum lighting will come on when the door is
opened if the tumble dryer is switched on.
A different language has been selected.
Set the language you want. The flag symbol will
guide you.
72
Reactivating the plinth filter
You can reactivate one or more dirty
plinth filters in the washing machine.
You will then be able to use the plinth
filter again for a reasonable period of
time.
Wash the plinth filter(s) separately,
not with any laundry items. Do not
add any detergent.
Tip: Select a short wash program with a
maximum temperature of 104°F (40°C)
and a maximum spin speed of 600rpm.
Select the Separate Rinse program,
for example.
You can re-insert the plinth filter once
the wash and spin cycle is complete.
You can continue to use a reactivated
plinth filter provided that it does not
show any signs of wear.
You must stop using a reactivated
plinth filter if it shows signs of wear
or deformation.
Please see “Cleaning and care –
Replacing the plinth filter” for details.
Frequently Asked Questions
73
Technical Service
Contact in case of fault
In the event of a fault which you cannot
remedy yourself, please contact your
Miele dealer or Miele Technical Service.
Contact information for Miele
Technical Service can be found at the
end of this document.
Please quote the model and serial
number of your appliance when
contacting Miele. Both pieces of
information can be found on the data
plate.
Open the door of your tumble dryer to
find the data tag:
Optional accessories
Optional accessories for this tumble
dryer are available from your Miele
dealer or Miele Technical Service.
74
Installation instructions
Alteration rights reserved.
Visit our website for all the current product specifications, technical appliance
information, and warranty information.
To avoid accidents or damage to the appliance, please read these instructions
before installing and/or using it.
75
IMPORTANT SAFETY INSTRUCTIONS
, WARNING - Risk of Fire
To reduce the risk of severe injury or death, follow all installation
instructions.
Clothes dryer installation must be performed by a qualified
installer.
Install the clothes dryer according to the manufacturer's
instructions and local codes.
Repair and maintenance work should be performed by a Miele
authorized service technician. Work by unqualified persons could be
dangerous and could void the warranty.
Before installation, disconnect the tumble dryer from the electrical
supply by shutting off the power main, unplugging the power cord or
tripping the circuit breaker. Do not restore power until the installation
is complete.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of malfunction or
breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for electric current. This
appliance is equipped with a cord having an equipment grounding
conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
WARNING – Improper connection of the equipment-grounding
conductor can result in a risk of electric shock. Contact a qualified
electrician if you are in doubt as to whether the appliance is properly
grounded.
Do not modify the plug provided with the appliance: if it will not fit
the outlet, have a proper outlet installed by a qualified electrician.
Do not use an extension cord to connect this appliance to the
power supply. Extension cords do not guarantee the required safety
of the appliance (e.g. danger of overheating).
76
IMPORTANT SAFETY INSTRUCTIONS
The installation of this unit in non stationary locations (e.g. ships)
must be performed by a qualified installer or service agency, in strict
accordance with national and local safety regulations and standards.
Do not install the machine in rooms where temperatures below
freezing may occur.
This dryer is not intended for wall-insert.
If there is any doubt concerning installation, contact Miele’s
Technical Service Department.
1-800-999-1360 TechService@mieleusa.com
SAVE THESE INSTRUCTIONS
77
*INSTALLATION*
Installation and connection
Front view
a
Drain hose for condensed water
b
Control panel
c
Lint-filter flap for the filter in the toe-
kick
– (open only when a prompt appears
in the display)
d
4height-adjustable screw feet
78
e
Power cord
f
Door
g
Bottom-right grille = Air-cooling
opening
– (open only when a prompt appears
in the display)
*INSTALLATION*
Installation and connection
Rear view
a
Interface for communicating with
external appliances
b
Power cord
c
Recesses under the protruding lid for
transporting the appliance
d
Module slot (for external
communication module)
e
Drain hose for condensed water
79
*INSTALLATION*
Installation and connection
Installation locations
All measurements in inch (mm)
Side view
Steel toe-kick
View from above
Washer-dryer stack
Steel toe-kick* (open or closed bases, e.g.
APCL002, APCL003, APCL005,
APCL007, APCL 011 or APCL 012)
80
A stacking kit (APCL001)* is needed. This
must be installed by a Miele authorized
service technician.
* Miele accessory available to order
*INSTALLATION*
Installation and connection
Transporting the tumble dryer to its installation site
Damage caused by incorrect
transportation of the tumble dryer.
If the tumble dryer tips over, there is
a danger of injury to people and
damage to property.
Ensure that the tumble dryer is stable
during transportation.
Transporting the tumble dryer
Transporting the tumble dryer to its installation site
Danger of injury due to unsecure
lid.
The fixings at the back of the lid may
become brittle due to external
circumstances. There is a danger of
the lid being pulled off when carrying
the appliance.
Before carrying the appliance, check
that the lid is secure where it
protrudes at the back of the
appliance.
If the tumble dryer is being
transported on its side, it must be
tipped onto its left or right side.
If the tumble dryer is being
transported upright, always transport
it on a sack truck with its left or right
side resting on the truck.
Carry the tumble dryer by the front
feet and by the lid where it protrudes
at the back of the appliance.
81
*INSTALLATION*
Installation and connection
Installation
Ensure that no closeable door,
sliding door, or an oppositely hinged
door is installed that would hinder
the door of the dryer being opened in
any way.
Downtime after installation
Damage caused by switching the
appliance on too soon.
This can damage the heat pump.
After setting up the tumble dryer,
wait for at least one hour before
switching it on.
Leveling the tumble dryer
The screw feet can be adjusted to
compensate for unevenness in the floor.
This tumble dryer is not suitable for
building under.
Never block the ventilation slots on
the tumble dryer. Do not block the
gap between the bottom of the
tumble dryer and the floor with toekicks, deep pile carpet, etc. This
would hinder a sufficient flow of air
to the tumble dryer.
The tumble dryer must stand perfectly
level to ensure safe and proper
operation.
82
*INSTALLATION*
Installation and connection
Room ventilation
– Air drawn in for use in the drying
process will be warm when it is
expelled back into the room. You
must therefore ensure that the room
is sufficiently ventilated, particularly if
the dryer is located in a small room.
– Make sure that the room temperature
is not too high. If there are other
heat-producing appliances in the
room in which the dryer is located,
make sure the room is well ventilated
and switch the other appliances off.
Otherwise running times and energy
consumption could be increased.
External control equipment
The XCI box accessory is needed to
connect external control equipment,
such as payment systems or peak-load
control units.
Payment system
This tumble dryer can be equipped with
a payment system (optional Miele
accessory). Therefore Miele Technical
Service needs to program a setting in
the dryer's electronic and connect the
payment system.
Coins/tokens must be removed from
the coin box regularly. Otherwise, the
payment system will become blocked.
83
*INSTALLATION*
Installation and connection
Drain hose for condensed water
The condensed water is pumped away
through the drain hose which is
located at the back of the dryer.
Laying the drain hose
Damage to the drain hose due to
incorrect handling.
The drain hose can suffer damage
and leak.
Do not pull on the drain hose and do
not stretch it or allow it to become
kinked.
Tip: Use the bow-shaped guide to
prevent the drain hose from becoming
kinked.
Drain-hose length: 5 1/8" (1400mm)
Drain height: 39 3/8" (1000mm)
Inserting the drain hose into a standpipe
Insert the end of the drain hose into
the standpipe.
Risk of damage from leaking
water.
Should the end of the hose come
loose, overflowing water can cause
damage.
Secure the drain hose carefully (e.g.,
by tying it) to make sure it cannot
slip.
Pull the drain hose out of the clips.
84
*INSTALLATION*
Installation and connection
Electrical connection
This description applies to tumble
dryers both with and without an
electrical plug.
The following applies to tumble dryers
with an electrical plug:
– This tumble dryer is supplied with a
power cord and plug ready for
connection.
– The electrical socket must be easily
accessible so that the tumble dryer
can be disconnected from the
electricity supply.
Damage caused by incorrect
supply voltage.
The data tag indicates the nominal
power consumption and the
appropriate fuse rating.
Compare the specifications on the
data tag with those of the domestic
electrical supply and make sure that
they match.
The washing machine may only be
connected to a permanent electrical
system that conforms to the national
and local codes and regulations.
The plug connector or isolator switch
should be easily accessible at all times.
Risk of electric shock.
If the tumble dryer is disconnected
from the electrical supply, protective
measures must be taken to ensure
that the point of disconnection
cannot accidentally be switched on
again.
Make sure the isolator is lockable or
the point of disconnection is
monitored at all times.
New connections, modifications to the
system, or servicing of the ground
conductor, including determining the
correct fuse rating, must be carried out
by a qualified electrician, as they are
familiar with the pertinent regulations
and the specific requirements of the
electric utility company.
The tumble dryer must not be
connected to devices such as timers
which would switch it off
automatically.
The tumble dryer should never be
connected by an extension cable, e.g.,
power strips, to avoid the risk of fire.
If the machine is hard-wired, a dual
circuit breaker must be provided onsite. When switched off there must be
an all-pole contact gap of at least 3mm
in the isolator switch (including circuit
breakers, breakers, and relays
according to IEC/EN60947). This
connection process must be performed
by a qualified electrician.
85
Technical data
Height 2' 9 7/16" (850mm)
Width 1' 11 7/16" (596mm)
Width (only for appliances with a
stainless steel lid)
Depth 2' 3 9/16" (777mm)
Depth with door open 3' 10 7/8" (1191mm)
Weight 165 lb (75kg)
Drum volume 34.3 gal (130l)
Load quantity 17.6 lb (8 kg) (weight of dry laundry)
Hose length 4' 7 1/8" (1400mm)
Wire length 6' 6 3/4" (2000mm)
Connection voltage See data tag on back of machine
Rated load See data tag on back of machine
Fuse rating See data tag on back of machine
Test certificates awarded See data tag on back of machine
LEDs Class 1
Designation of refrigerant R134a
Refrigerant quantity 0.61kg
Refrigerant global-warming potential 1430kgCO2 e
1' 11 13/16" (605mm)
Appliance global-warming potential 872kgCO2 e
Max. floor load during operation 925N
A-rated sound emissions LpA in
accordance with ENISO11204/11203
86
<70dBre20μPa
Supervisor level
11:02
Programs Favorites Supervisor
Help
Opening the supervisor level
Touching the sensor control takes
you to the supervisor level.
Access via code
The supervisor level is accessed using
a code.
Factory default: The code is 000.
Change code
You can alter the supervisor-level
access code to protect the tumble
dryer from unauthorized access.
Carefully enter a new code.
Please inform Technical Service if
you have forgotten your new code.
Technical Service will have to reset
the code.
Make a note of your new code and
store it in a safe place.
Closing the settings menu
Touch the sensor control.
The display will then go back to the
previous menu level.
Touch the sensor control.
The display will change to the main
menu.
Controls / Display
Language
The display can be set to appear in
one of several different languages. To
select the language you want, go to
the Languagessub-menu.
You can change the language as
follows:
– Permanently using the supervisor
level (=“Supervisor language”).
– For the duration of the current
program only using the sensor
control. The supervisor language is
displayed again at the end of the
program.
87
Supervisor level
Language entry
The display can be set to one of
several different user languages. This
setting allows you to determine how
languages can be selected.
You can change the language as
follows:
International
6 languages are available. The
sensor control is not active. Note
the setting Set languages.
Language setting
The sensor control can be used
to select a language. All languages are
available (factory default).
You can change the order of the first 4
languages. These slots are allocated to
the most commonly used languages.
Standard language
The user language cannot be changed.
The user language is the same as the
supervisor language. The sensor
control is not active.
Set languages
The languages for the setting
Language entryInternationalcan be
changed.
6 languages can be selected. All
languages are available.
If you wish to add a new language to
the language menu:
First select the language you want to
replace.
All available languages are displayed.
Select and confirm the language to
replace the previous language.
The new language appears instead of
the old one.
Display brightness
The brightness of the display can be
altered. The setting depends on the
various lighting conditions in the place
of installation.
– It can be set to one of 10 different
levels.
88
Supervisor level
Clock display
After selecting the clock format, you
can set the time of day.
Clock format
– Factory default: 24-hour display
– 12-hour display
– No clock
Set
– The time can be set.
Date
The date can be set after selecting the
date format.
– Date format
The date can be shown starting with
the day, month, or year.
– Date
The date is set.
Volume
The volume for various sounds can be
changed.
The volume can be changed.
– Finish tone
– Keypad tone
– Welcome tone
– Fault alarm
The volume cannot be changed here.
Res. moisture display
In addition to displaying the drying
level, the residual moisture can also
be indicated as a percentage.
– Factory default setting:Without %
value
– With % value
Visibility parameters
Various parameters are offered/
displayed when a program is selected.
You can decide which parameters
should not be displayed. These
parameters can then not be edited
during program selection.
– Residual moisture
– Duration(only timed programs)
– Load size
– Gentle tumble
– Anti-crease
89
Supervisor level
"Display" off status
The display switches off to save
energy; only the Start/Stopsensor
control flashes slowly. You can change
this setting.
Changing this setting leads to increased
energy consumption.
– Off
No switching off
– On (10 min.) Not curr.prog.
The display will remain on while the
program is running but will go out
10minutes after the end of the
program.
– Logo (10 min.) Not curr. prog.
The display will remain on while the
program is running but the logo will
light up 10minutes after the end of
the program.
– Factory default: On after 10 min.
The display is switched off after
10minutes.
"Machine" off status
In order to save energy, the tumble
dryer will switch off automatically after
the end of the program or if no further
selection is made. You can change
this setting.
Changing this setting leads to increased
energy consumption.
– No switch off
– Factory default: Switch off after
15minutes
– Switch off after 20minutes
– Switch off after 30minutes
Delay start
The delay start (timer) can be
activated or deactivated.
– Factory default: Off
– On
– On (30 min.) Not curr.prog.
The display will remain on while the
program is running but will go out
30minutes after the end of the
program.
– Logo (30 min.) Not curr.prog.
The display will remain on while the
program is running but the logo will
light up 30minutes after the end of
the program.
– On after 30 min.
The display will go out after
30minutes.
90
Supervisor level
Memory
The tumble dryer saves the settings
that were selected last for a drying
program (drying level and/or extra
option, or the duration for some
programs).
– Factory default: Off
– On
Temperature unit
You can select the unit for the
temperature display.
– Factory default: °C
– °F
Weight unit
You can decide whether load
quantities are displayed in “kg” or “lb”.
– Factory default: kg
– lb
Change code
You can alter the access code to the
supervisor level.
Enter the current code.
Enter a new code.
Logo
You can choose whether the “Miele
Professional” logo or your own logo
appears in the display.
For the Controlssetting, the Laundromat
ext. (12 prog), Laundromat basic int. time ,
or Laundromat basic ext. time option must
be selected.
– Miele Professional logo
– Customer logo
91
Supervisor level
Program selection
Controls
You can select whether the tumble
dryer is operated as a “laundromat”
machine. Shortcuts are the easiest
way to operate the machine.
Operating staff are unable to change
pre-set programs.
Tip: Start by configuring all necessary
settings and changes to the tumble
dryer before adjusting any of the
options below.
Caution: When activating any of
these options, the supervisor level
will no longer be available.
You will no longer be able to access
the supervisor level via the display.
Please follow the instructions below
if you wish to change any other
settings.
Opening the supervisor level
(laundromat version)
Switch the tumble dryer on and open
the dryer door.
Touch the Start/Stopsensor control
and hold it down while carrying out
steps–.
Close the tumble-dryer door.
Wait until the Start/Stopsensor
control, which will now be flashing
quickly, lights up constantly...
...and then release the Start/
Stopsensor control.
92
Supervisor level
– Standard
Factory default: All (selected)
programs are available.
– Laundromat, basic (4 prog)
4 programs are available.
Under Favorite programs, you can set
which 4 programs to select/modify.
– Laundromat ext. (12 prog)
12 programs are available.
Under Favorite programs, you can set
which 12 programs to select/modify.
The first 3 programs can be selected
directly. The remaining programs are
selected via another list.
– Laundromat basic ext. time
4 time programs* with different
temperature levels are timecontrolled via an external payment
system. The maximum laundry
weight is 17.6 lb (8 kg).
The set value indicates the running
time and cannot be modified by the
user.
This option is only available with an
external payment system.
* The maximum running time is
specified during initial
commissioning.
– Laundromat basic int. time
4 time programs* with different
temperature levels are timecontrolled via the tumble dryer's
electronic. The maximum laundry
weight is 17.6 lb (8 kg).
The set value indicates the maximum
running time and can be modified by
the user.
* The maximum running time is
specified during initial
commissioning.
– External prog. selection
A communication module can be
used to select the program from an
external terminal.
Program packages
This allows you to specify the scope
of the tumble dryer's program. You
can select all of the programs or
individual programs from the relevant
program packages.
The program packages are described in
detail under “Program overview”.
93
Supervisor level
Favorite programs
After switching on, you can also select
a program via: Favorites.
12 programs can be stored as
favorites based on your own priorities
and requirements.
These favorites will also be made
available in the control options
– Laundromat ext. (12 prog)
– Laundromat, basic (4 prog) (the first 4
of the 12 favorites).
The control options can be defined
under Control.
Tip: You can assign a different color to
each program. In this case, the Program
color allocationsetting must be set to
On.
Changing favorite programs
Select the program you wish to
change or replace.
Confirm the program or the setting to
be changed.
Another menu opens, enabling you to
select a new program or change the
parameters.
Confirm using the Savesensor
control.
Your selection is now active.
94
Supervisor level
Special programs
You can put together 5 special
residual-moisture or time-controlled
programs and assign your own
program names.
First, enter the program name.
Select the special program you want
to change.
The Save asmenu opens.
Use the letters and symbols below
the line to enter the name.
Touch the Savesensor control.
You can now enter the parameters for
aRes. moisture
programorTimed drying.
The 5 special programs are preprogrammed at the factory. You can
change these special programs.
The special programs are added to the
program packages. Enter the name
and settings of your special program
into the “Special programs” table in
the “Program overview” chapter.
Res. moisture program
– Final residual moisture:
-6%(dry) – 40%(damp)
– Extra drying time:
0–60minutes
– Temperature(Process air):
cold – 158°F (70°C)
– Drum rotation main direction:
0–600seconds
– Drum reversal:
0–600seconds
– Holding phase
– Holding time:
0–60minutes
– Holding temperature(Process air):
cold – 158°F (70°C)
– Cooling down temp.(Process air):
104-131°F (40–55°C)
– Anti-crease
– Drum rotation main direction:
0–500seconds
– Drum reversal:
0–500seconds
– Pause:
100–3000seconds
Timed drying
– Running time:
1–120minutes
– Temperature(Process air):
cold – 158°F (70°C)
– Drum rotation main direction:
0–600seconds
– Drum reversal:
0–600seconds
95
Supervisor level
– Cooling down temp.(Process air):
104-131°F (40–55°C)
– Anti-crease
– Drum rotation main direction:
0–500seconds
– Drum reversal:
0–500seconds
– Pause:
100–3000seconds
Sort programs
Programs can be moved within the
program list and in the Favorites list.
– Factory default: Off
– On
Moving programs/favorites
You can move/change the order of the
programs (program menu – single
option list). You can also move and
change the order of the favorites that
you edit in the Supervisor level under
Favorite programs.
Program color allocation
You can assign a specific color to a
favorite program. In the list of
favorites, each favorite program is
given a colored frame, which can be
adjusted.
– Factory default: Off
– On
Touch the program that you wish to
move.
Press and hold the sensor control
until the frame changes.
Drag the program to the required
place.
96
Supervisor level
Process technology
Anti-crease
At the end of the program, the drum
will continue to rotate at intervals if the
laundry is not removed immediately.
Changing this setting leads to increased
energy consumption.
The setting can be switched off or a
time between 1and 12hours can be
selected.
Factory default: Off
Drying levels
Changing this setting leads to increased
energy consumption.
You can alter the drying levels for the
Cottons, Minimum iron, and Automatic
plus programs.
It can be set to one of 7different levels.
Factory default: Normal
Additional cooling
Before the end of the program, the
temperature of the dried laundry is
monitored and the cooling phase at
the end of the program is extended if
necessary.
Changing this setting leads to increased
energy consumption.
– Factory default: Off
– On
Cooling down temperature
The laundry will be cooled down
automatically before the end of the
program. The automatic cooling-down
phase which takes place before the
end of a program can be set at a
cooler level for all programs. This
means that the cooling phase is
extended.
Changing this setting leads to increased
energy consumption.
The Machine irondrying level in the
Cottonsprogram can be individually
adapted.
You can change the residual moisture in
this program to one of 11 levels from
16% (more dry) to 26% (more moist).
Factory default: 20%
The setting can be changed from
104-131°F (40°C–55°C).
Factory default: 131°F (55°C)
97
Supervisor level
Service
Clean out the airways
The tumble dryer's electronic
calculates the degree at which lint or
detergent residue in the lint filters and
air ducts are impairing performance. A
message to check the contamination
appears. You can decide at what level
of lint this reminder should be emitted.
This prompt, which you can configure,
is displayed: Clean out the airways
– Off
The reminder does not appear.
However, if there is a very severe
blockage in the ducting, the program
will be canceled and the reminder will
appear in the display regardless of
this option.
– Heavy
The reminder only appears when
there is a heavy build-up of lint.
– Factory default: Normal
– Sensitive
The reminder appears when there is
only a small build-up of lint.
Your message is displayed at the end of
the program and can be acknowledged
with OK. The same message appears at
the end of the next program.
Settings
This setting allows you to determine the
interval (by hours or date) at which the
message appears.
– Factory default: Off
– By time
You can then select a time interval
from 1–9999hours.
– By date
You can enter a date.
Message text
Enter your message for your planned
maintenance work. You can edit one,
two, or all three of the 1/2/3 messages.
Resetting the display
The message appears until the display
is permanently reset. The message then
appears again once the next interval is
reached.
Service interval
The tumble dryer shows a custom
message at a selected interval to
prompt you to undertake specific
maintenance tasks.
3 different messages can be created:
1/2/3. Each message is created in the
language and alphabet of the current
supervisor language.
98
Supervisor level
External applications
Peak load signal
External hardware is connected via the
Miele XCI Box.
The peak-load negotiation function
enables the tumble dryer to be
connected to an energy-management
system. When a signal is registered,
the tumble dryer's heater is switched
off for a short period or the appliance
is prevented from being switched on.
The tumble dryer may only be
operated with a peak-load system if
this system is connected to the tumble
dryer via the Miele XCI Box.
– Factory default: No function
– Peak load with 230V
– Peak load with 0V
Peak load prevention
With this function, the application of a
hygiene program is not amended
when a peak-load signal is in place.
The heater stays switched on.
– Factory default: Off
– On
Select KOM module
This tumble dryer is equipped with an
integrated WiFi module. However, the
tumble dryer can also be equipped
with an external module.
– Off
– Internal module (factory default)
The internal WiFi module is used.
– External module
An XKMmodule or RS232module is
inserted into the module slot.
WiFi
Control the networking of your tumble
dryer.
– Setup
This message only appears if the
tumble dryer has not yet been
connected to a WiFi network.
– Deactivate (visible when the network
is activated)
The network remains set up; the WiFi
function is switched off.
– Activate (visible when the network is
deactivated)
The WiFi function is reactivated.
– Connection status (visible when the
network is activated)
The following values are displayed:
– The quality of WiFi reception
– The network name
– The IP address
– Reset (visible when set up)
Resets the WiFi login (network) to
immediately re-establish a new
connection.
– Reset (visible if already set up)
The network is no longer set up. A
new connection has to be
established in order to use the
network again.
– The WiFi is switched off
– The WiFi connection will be reset
to the factory default setting
99
Supervisor level
Network time
The date and time can be
synchronized over the network.
– Off
The date and time are not
synchronized over the network.
– As master
The machines are in a network but
are not connected to the Internet. A
machine is declared as the master
and sends data to the slave
appliances.
– As slave
The machines are in a network and
are connected to the Internet. All
machines are configured as slaves.
Data is synchronized over the
Internet.
Remote
Programs are selected on an external
terminal.
Factory default: Off
Remote Update
The RemoteUpdate function is used for
updating the software in your tumble
dryer.
The RemoteUpdate function is
deactivated as standard.
If you do not install a RemoteUpdate,
you can continue to use your tumble
dryer in the usual way. However, Miele
recommends installing RemoteUpdates.
Activation
The RemoteUpdate menu option is
only displayed and can only be
selected if you have added your
tumble dryer to your WiFi network.
Miele’s RemoteUpdate function can
only be used if the tumble dryer is
connected to a WiFi network and you
have an account in the Miele
Professional app. The tumble dryer
must be registered in the app.
100
See the Miele Professional app for
terms and conditions of use.
Some software updates can only be
carried out by Miele Technical Service.
