Miele CVA6805G, CVA6805B Installation and Operation Guide

Operating and installation instructions Built-in coffee machine

To avoid the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time.

en – AU, NZ M.-Nr. 10 499 950

Packaging material / Disposal of old machine

Disposal of the packing material

The transport and protective packing has been selected from materials which are environmentally friendly for disposal, and can normally be recycled.

Recycling the packaging reduces the use of raw materials in the manufacturing process and also reduces the amount of waste in landfill sites. Ensure that any plastic wrappings, bags etc. are disposed of safely and kept out of the reach of babies and young children. Danger of suffocation.

Disposing of your old appliance

Electrical and electronic appliances often contain materials which, if handled or disposed of incorrectly, could be potentially hazardous to human health and to the environment. They are, however, essential for the correct functioning of your appliance. Therefore, please do not dispose of your old appliance with your household waste.

Please dispose of it at your local community waste collection / recycling centre.

Ensure that your old appliance presents no danger to children while being stored for disposal.

Contents

Packaging material / Disposal of old machine .................................................. 2

Warning and Safety instructions.......................................................................... 6

Guide to the appliance ....................................................................................... 17

Exterior view.......................................................................................................... 17

Accessories ......................................................................................................... 19

Operating principles............................................................................................ 20

Touch display ........................................................................................................ 20

Operating actions.................................................................................................. 21

Symbols in the display .......................................................................................... 24

Using for the first time ........................................................................................ 25

Before using for the first time................................................................................ 25

Switching on for the first time ............................................................................... 25

Water hardness ..................................................................................................... 26

Filling the water container.................................................................................. 28

Filling the coffee bean container .......................................................................29

Switching the coffee machine on and off .........................................................30

Spout adjustment ................................................................................................ 31

Making drinks ...................................................................................................... 32

Making a coffee drink............................................................................................ 32

Dispensing a double portion ................................................................................. 33

Cancelling preparation .......................................................................................... 33

Preparing several cups of coffee - Coffee pot ...................................................... 33

Drinks made with ready ground coffee ................................................................. 34

Drinks with milk ..................................................................................................... 35

Preparing hot water............................................................................................... 37

Preparing User profile drinks................................................................................. 37

After a drink has been prepared............................................................................ 38

Coffee the way you like it ................................................................................... 39

Grinder setting....................................................................................................... 39

Changing the parameters of a drink...................................................................... 40

Amount of coffee................................................................................................... 40

Brewing temperature ............................................................................................. 40

Pre-brewing ground coffee.................................................................................... 41

Portion size .......................................................................................................... 42

Contents

Resetting drink settings...................................................................................... 43

User profiles......................................................................................................... 44

Calling up User profiles ......................................................................................... 44

Creating a User profile........................................................................................... 44

Selecting a User profile ......................................................................................... 44

Changing a name .................................................................................................. 44

Deleting a profile ................................................................................................... 44

Changing a User profile......................................................................................... 45

User profiles: Creating and editing your own drinks ....................................... 46

Creating a drink..................................................................................................... 46

Changing a drink: Changing the portion sizes, drinks parameters and names .... 46

Deleting drink ........................................................................................................ 46

MyMiele ................................................................................................................ 47

Settings ................................................................................................................ 48

Open the Settings menu ....................................................................................... 48

Changing and saving settings ............................................................................... 48

Overview of available settings............................................................................... 49

Language............................................................................................................... 51

Time of day............................................................................................................ 51

Date ....................................................................................................................... 51

Timer ..................................................................................................................... 52

Eco mode .............................................................................................................. 54

Lighting.................................................................................................................. 54

Start screen ........................................................................................................... 55

Info (display information) ....................................................................................... 55

Locking the coffee machine (System lock) ....................................................... 55

Water hardness ..................................................................................................... 56

Display brightness................................................................................................. 56

Volume................................................................................................................... 56

Activating and deactivating mains water connection............................................ 56

Warming drawer .................................................................................................... 56

Spout adjustment.................................................................................................. 57

Factory default....................................................................................................... 57

Showroom programme (Demo mode)................................................................... 57

Cleaning and care ............................................................................................... 58

Quick guide ........................................................................................................... 58

Cleaning by hand or in the dishwasher ................................................................. 59

Drip tray................................................................................................................. 61

Drip tray cover....................................................................................................... 62

Contents

Water container ..................................................................................................... 62

Waste container .................................................................................................... 63

Central spout......................................................................................................... 63

Sensor cover ......................................................................................................... 66

Maintenance of the milk valve............................................................................... 67

Milk flask with lid ................................................................................................... 67

Interior and appliance door ................................................................................... 69

Central spout connector........................................................................................ 69

Brew unit ............................................................................................................... 70

Removing and cleaning the brew unit by hand................................................70

Maintenance programmes..................................................................................... 71

Opening the "Maintenance" menu ................................................................... 71

Rinsing the appliance............................................................................................ 72

Rinsing the milk pipework ..................................................................................... 72

Cleaning the milk pipework ................................................................................... 73

Degreasing the brew unit ...................................................................................... 74

Descaling the machine ....................................................................................... 76

Problem solving guide ........................................................................................79

Messages in the display........................................................................................ 79

Unusual performance of the coffee machine ........................................................ 82

Unsatisfactory results............................................................................................ 87

Problems when heating up or frothing milk........................................................... 88

Replacing the angled connector ........................................................................... 90

After sales service and warranty .......................................................................92

Saving energy ...................................................................................................... 93

Mains water connection .....................................................................................94

Electrical connection ..........................................................................................96

Installation............................................................................................................ 97

Building-in and combination options .................................................................... 97

Ventilation.............................................................................................................. 98

Building in the coffee machine .............................................................................. 99

Adjusting the door hinges ................................................................................... 100

Warning and Safety instructions

This coffee machine conforms to current safety requirements. Improper use of the appliance can, however, present a risk of both personal injury and material damage.

To avoid the risk of accidents and damage to the appliance, please read these instructions carefully before installation and before using it for the first time. They contain important notes on the installation, safety, operation and care of the appliance. Miele cannot be held liable for damage caused by non-compliance with these Warning and Safety instructions.

Keep the instructions in a safe place and pass them along to any future owner.

Warning and Safety instructions

Correct application

 This appliance is designed for domestic use and for use in similar

environments by guests in hotel or motel rooms, bed & breakfasts and other typical living quarters. This does not include common/ shared facilities or commercial facilities within hotels, motels or bed & breakfasts.

 The coffee machine is not suitable for outdoor use.  The machine is intended only for the preparation of coffee based

drinks such as espresso, cappuccino, latte macchiato etc. Any other usage is at the owner's risk.

 This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning its use by a person responsible for their safety, and are able to recognise the dangers of misuse.

Warning and Safety instructions

Safety with children

 Caution! Danger of burning and scalding on the dispensing spouts. Children's skin is far more sensitive to high temperatures than that of adults.

Ensure children do not touch hot surfaces of the coffee machine or place parts of their body under the dispensing spouts.

 Install the coffee machine out of reach of children.  Young children must not be allowed to use this appliance.  Older children may only use the coffee machine unsupervised if

they have been shown how to use it safely and recognise and understand the consequences of incorrect operation.

 Children should be supervised when they are near the coffee

machine. Do not allow them to play with it or to use the controls.

 Cleaning may only be carried out by older children under the

supervision of an adult.

 Remember that coffee and espresso are not suitable drinks for

children.

 Risk of suffocation!

Children may be able to wrap themselves in packing material or pull it over their heads with the risk of suffocation. Keep children away from any packing material.

Warning and Safety instructions

Technical safety

 Repairs and installation work by unqualified persons could be

dangerous. The manufacturer cannot be held liable for unauthorised work. Installation work and repairs to electrical appliances must only be carried out by a Miele approved service technician.

 A damaged appliance is dangerous. Check it for any visible

damage. Never install or attempt to use a damaged appliance.

 Before connecting the appliance to the mains supply, make sure

that the rating on the data plate corresponds to the voltage and frequency of the household supply. This data must correspond in order to avoid the risk of damage to the appliance. Consult a qualified electrician if in any doubt.

 The electrical safety of this appliance can only be guaranteed

when continuity is complete between it and an effective earthing system. It is most important that this basic safety requirement is present and tested regularly and, where there is any doubt, the household wiring system should be inspected by a qualified electrician.

 Reliable and safe operation of the coffee machine can only be

guaranteed if it is connected to the mains electrical supply.

 Do not connect the machine to the mains electricity supply by a

multi-socket adapter or an extension lead. These do not guarantee the safety of the appliance (e.g. danger of overheating).

 This appliance must not be installed and operated in mobile

installations (e.g. on a ship).

 For safety reasons, this appliance may only be used when it has

been built in.

 If the coffee machine is to be built in above another appliance,

there must be a full-width, closed shelf between them (except in combination with a built-in plate warmer).

Warning and Safety instructions

 The second electrical connection socket on the back of the

machine may only be used for connecting a Miele EGW4000-14,-29, EGW5000-14 plate warming drawer or an ESW6x14, ESW6x29 food warming drawer.

 Only use the coffee machine in rooms where the ambient

temperature is between +10°C and +38°C.

 Do not cover or block the ventilation gaps.

This would prevent adequate ventilation. Condensation can damage the coffee machine or the furniture housing unit.

 Ensure that there is sufficient ventilation around the coffee

machine. Otherwise condensate may form and the appliance or the furniture unit may be damaged. The ventilation cut-out area in the furniture unit and the space underneath the ceiling must amount to at least 200 cm2.

 If the coffee machine is installed behind a kitchen furniture door, it

may only be used with the furniture door open. This will prevent the formation of heat and humidity and subsequent damage to the appliance and/or furniture unit. Do not close the furniture door while the coffee machine is in use. Ensure the coffee machine has cooled down completely before closing the furniture door.

 Repairs may only be carried out by a Miele authorised service

technician. Repairs by unqualified persons can cause considerable danger to the user.

 Before any repair work is carried out, the appliance must be

completely disconnected from the electricity supply. The appliance is only completely isolated from the electricity supply when:

– the mains fuse is disconnected, or

– it is switched off at the circuit breaker, or

Warning and Safety instructions

– the mains connection cable is disconnected from the power

supply. Pull the plug, not the cord, to disconnect the appliance from the power supply.

 The manufacturer's warranty will be invalidated if the appliance is

not repaired by a Miele approved service technician.

 Faulty components must only be replaced by genuine Miele

Original spare parts. The manufacturer can only guarantee the safety of the appliance when Miele replacement parts are used.

 Never open the outer casing of the machine. Tampering with

electrical connections or components and mechanical parts is highly dangerous to the user and can cause operational faults or electric shock.

 Use only Miele Original spare parts. If spare parts or accessories

from other manufacturers are used, the warranty will be invalidated, and Miele cannot accept liability.

Warning and Safety instructions

Mains water connection

 Do not connect the coffee machine to a warm water connection.  The non-return valve must be easily accessible when the coffee

machine is built in.

 The protective sleeve of the water inlet hose must not be

damaged or become kinked. This will cause it to leak.

 The integrated Waterproof System offers protection from water

damage, provided the following conditions are met:

– The machine is correctly installed (connected to the electricity

supply) and plumbed in.

– The machine is properly maintained and parts are replaced where

it can be seen that this is necessary.

– The tap has been turned off when the appliance is not going to be

used for a longer period of time (e.g. during holidays).

Warning and Safety instructions

Correct use

 The dispensing spouts present a danger of burning or scalding. The liquids and steam dispensed are very hot.

 Please note:

– Keep well away from the area underneath the spouts when hot

liquids and steam are being dispensed.

– Heating surfaces have residual heat after use. Do not touch hot

components.

– Hot liquid or steam could spatter from the nozzles. Ensure that

the central spout is clean and fitted correctly.

– Water in the drip tray can also be very hot. Take care when

emptying it.

 Never look directly at the lighting or use optical instruments to look at it.

 Please note the following regarding water:

– When using the water container: Fill the water container only with

fresh, cold tap water. Hot or warm water or other liquids could damage the coffee machine.

– Change the water every day to prevent a build-up of bacteria.

When using a mains water connection: Empty the water container once a day.

– Do not use mineral water. Mineral water will cause serious

limescale deposits to build up in your machine and damage it.

– Do not use water from reverse osmosis units. The machine could

be damaged.

 Only fill the bean container with roasted espresso/coffee beans.

Do not fill the bean container with coffee beans which have been treated with additives or with ground coffee. Do not fill the bean container with any type of liquid.

Warning and Safety instructions

 Do not use green (unroasted) coffee beans or mixtures of coffee

beans which contain green coffee beans. Green coffee beans are very hard and still contain a certain amount of residual moisture. These can damage the coffee machine grinder as soon as grinding begins.

 Do not use coffee beans which have been treated with caramel,

sugar or other substances. Sugar will damage the coffee machine.

 Only add ground coffee or cleaning tablets to the ground coffee

chute.

 Do not use any caramelised ready ground coffee. The sugar in the

coffee will stick to and block the brew unit of the coffee machine. The cleaning tablets for degreasing the brew unit will not remove this type of deposit.

 Only use milk without additives. Additives in milk usually contain

sugar and this will stick to the milk pipework.

 If using cow's milk, only use pasteurised milk to prevent a build-

up of bacteria in the appliance.

 Do not place any alcohol mixtures which are alight underneath the

central spout. The flames could ignite plastic components and cause them to melt.

 Do not swing from or hang anything on the appliance door when it

is open as this could damage the hinges on the coffee machine.

 The seal on the central spout connector is lubricated with silicone

grease. Try to avoid getting this grease on your clothing when removing and inserting containers or other components.

 The machine must not be used for cleaning objects.

Warning and Safety instructions

Cleaning and care

 It is important to switch off the coffee machine before any

cleaning or maintenance.

 Clean the coffee machine and the milk flask before using for the

first time (see "Cleaning and care").

 All parts of the milk system need to be cleaned thoroughly and

regularly. Milk contains bacteria which proliferate rapidly with inadequate cleaning.

 Do not clean the machine with a steam cleaner or immerse it in

water as this will damage the machine. Steam or water could reach the electrical components and cause a short circuit.

 Avoid spillage on appliance connectors.  Descale the coffee machine regularly depending on the water

hardness level in your area. Descale the machine more frequently in areas with very hard water. Miele cannot be held liable for damage arising from insufficient descaling, the use of incorrect descaling agent or the use of descaling agent which is not of the appropriate concentration.

 Degrease the brew unit regularly with Miele cleaning tablets.

Depending on the natural oil content of the coffee used, the brew unit can become blocked quite quickly.

 Used coffee grounds should be disposed of with the organic

rubbish or on the compost heap. Do not empty them down the sink, as they could block it.

Warning and Safety instructions

The following applies to appliances with stainless steel surfaces:

 Do not adhere stickers, adhesive tape or any other adhesive

materials to stainless steel surfaces. The coating on the stainless steel surfaces will become damaged and lose its protective properties against soiling.

 Stainless steel scratches very easily and even magnets can cause

damage to the surface.

Exterior view

Guide to the appliance

On/Off sensor

Touch display

"Back" sensor

Door handle

Steam and hot water spout

Drip tray cover

Automatic height-adjustable central spout with lighting

Milk flask with lid

Guide to the appliance

Interior view

Ground coffee chute cover

Brew unit

Ground coffee chute

Slide control for the grinder setting

Coffee bean container

Water container with inlet device in the lid

Drip tray with grid

Waste container

Drip tray inside machine door

Central spout connector

Service flap

Accessories

These products and other useful accessories can be ordered via the Miele webshop or directly from Miele (see back cover for contact details).

Accessories supplied

– Measuring spoon

For ground coffee

– Milk flask with lid

For storing milk and preparing drinks with milk

– Compact lid

For storing the milk flask in the refrigerator

– Cleaning agent for milk pipework

For cleaning the milk system (starter set)

– 2 cleaning containers (large and

small) For cleaning and maintenance of the machine

– Descaling tablets

For descaling the water pipework (starter set)

Optional accessories

Miele also offers a range of optional accessories, as well as cleaning and conditioning products for your coffee machine.

– Original Miele all purpose

microfibre cloth

For removing finger marks and light soiling

– Milk flask with lid

For storing milk and preparing drinks with milk

– Cleaning agent for milk pipework

For cleaning the milk system

– Descaling tablets

For descaling the water pipework

– Cleaning tablets

For degreasing the brew unit

– Silicone grease

For lubricating the seal on the central spout connector

– Test strips

For determining the water hardness level

– Silicone grease

For lubricating the seal on the central spout connector

– Cleaning brush

For cleaning the milk pipework

– Central spout connector cap

Spare part

– Milk pipework elbow connector

Spare part

Operating principles

  Espresso

  Coffee

  Long coffee

  Cappuccino

  Latte macchiato

Edit User profiles

DrinksMain menu

Touch display

The display can be scratched by pointed or sharp objects, e.g. pens. Only touch the touch display with your fingertips.

Touching the display with your finger creates a tiny charge which releases an electrical impulse. This impulse is recognised by the touch display. The touch display does not react if you touch it with an object.

If your fingers are cold, the Touch display may not react.

The touch display is divided into three sections:

The top row shows you where you are, with the menu you are in highlighted in white. Open the menu you want by touching the menu name. The time of day is shown in the top right-hand corner.

The middle row shows the current menu and options. You can scroll to the right or left by swiping your finger across the display to the right or left.

The  and  arrow sensors at the bottom of the screen are used for scrolling to the left or right. The number of small squares between the arrows indicates the number of pages available and your position within the current menu.

Operating principles

Operating actions

Each time you touch a possible option the relevant field lights up orange.

Selecting or calling up a menu

 Touch the field you want with your finger.

Scrolling through menus

You can scroll to the right or the left. Some options allow you to scroll up and down too.

 Swipe the screen, i.e. place your finger on the Touch display and swipe it in the

direction you want. Or:

 Using your finger, touch the and arrows to scroll to the left or right.

Exiting a menu ("Back" sensor)

 Touch to return to the previous screen. All selected entries which have not been confirmed with OK will not be saved. Touching the sensor three times in succession will take you to the drinks menu.

Touching the sensor in the User profiles menu will take you step by step back to the beginning.

Entering numbers

You can enter numbers by scrolling through and touching the roller, or by using the numerical keypad.

The altered setting will only be saved once the roller appears grey again.

 Touch .

Operating principles

The numerical keypad will appear.

 Touch the numbers you want. Once you have entered an accepted value, OK will light up green.  Touch OK.

Entering letters

You can enter names for your own User programmes or drinks using a keyboard. Try to use short, concise names.

 Touch the letters or characters you want.  Touch Save.

Operating principles

Help

Helpful information is available when maintenance programmes are selected. Help will appear in the bottom row.

To display information in text and pictures,  touch Help.

To return to the maintenance programme,  touch Close.

Operating principles

Symbols in the display

The following symbols may also appear in the display in addition to the text and drinks symbols:

Symbol Explanation

 Some settings, e.g. display brightness and buzzer/keypad

volume, are selected using a bar chart.

 This symbol indicates that there is additional information

and advice about using the coffee machine. Select OK to confirm the information.

 The system lock is activated (see "Settings – Locking the

coffee machine (System lock)"): The coffee machine cannot be operated.

 The timer is activated for Switch on at (see "Settings –

Timer"). The symbol and the desired switching on time appear in the display 23:59 hours before the coffee machine is due to switch on, as long as On or Night dimming is selected for the time display.

 This symbol appears during the Clean the milk pipework

maintenance programme. (The symbol is also found on the water container: fill up to this mark).

 This appears while the appliance is being descaled.

(This symbol can also be found on the water container: fill up to this mark).

Using for the first time

Before using the coffee machine for the first time, please read these instructions and make yourself familiar with the appliance and its controls.

Before using for the first time

 Install the coffee machine and

connect it to the electricity supply (see "Electrical connection" and "Installation").

 Remove any protective foil from the

front of the machine.

Clean the appliance thoroughly before filling it with water and coffee beans (see "Cleaning and care").

Switching on for the first time

When the coffee machine is switched on for the first time, you will be asked to set the following settings:

– Language and country

– Date

– Time of day

– Display (time display)  Touch the On/Off sensor. "Miele - Willkommen" appears briefly in

the display.

Setting the language

 Select the language and then

touchOK.

 Select the country and then

touchOK.

The setting is now saved.

Setting the date

 Enter the current date and touchOK.

The setting is now saved.

Setting the time of day

 Enter the current time of day and

touchOK.

The setting is now saved.

Display

You can choose one of the following options:

– On: The time and date are always

visible in the display when the appliance is switched off.

– Off: The display is dark when the

machine is switched off.

– Night dimming: The date and the time

are only displayed between the hours of 5:00 and 23:00.

 Touch the option you want and

thenOK.

Depending on the setting selected, the coffee machine may use more energy. A message will appear in the display to inform you of this.

Using for the first time

Selecting the water supply (Mains water)

The coffee machine is intended to be plumbed into the mains water supply. You can select one of the following options:

– On: The water container will be filled

automatically via the mains water supply.

– Off: The water container must be

filled manually. A message to this effect will appear in the display.

 Select the water supply option you

want and touchOK.

The setting is now saved.

The coffee machine is now successfully set up for use.

 Fill the water container with fresh,

cold tap water.

Water hardness

The water hardness level indicates how much calcium is dissolved in the water. The higher the calcium content, the harder the water, and the harder the water, the more often the coffee machine will need to be descaled.

The coffee machine measures the amount of water and steam used. Depending on the level of water hardness set, more or fewer drinks can be dispensed before the appliance needs to be descaled.

Programme the coffee machine to the water hardness level of your area so that it functions correctly and does not get damaged. At the correct time a prompt will then appear in the display to descale the appliance.

The machine has four programmable levels:

Water hardness Water

0 - 8.4 °dH (0 -1.5 mmol/l)

8.4 - 14 °dH (1.5 - 2.5 mmol/l)

14 - 21 °dH (2.5 - 3.7mmol/l)

> 21°dH (> 3.7mmol/l)

hardness level in your area

Soft Soft 1

Medium Medium 2

Hard Hard 3

Hard Very hard 4

Setting (water hardness level)

The machine is programmed ex-works to hardness level 3.

Measuring water hardness

You can measure the water hardness yourself using the enclosed test strip. Alternatively, your local water authority will be able to tell you the hardness of water in your area.

 Dip the test strip in your drinking

water for approximatelyonesecond, then shake off any excess water. The result will be evident after about aminute.

Using for the first time

Setting the water hardness level

 Touch  Settings.  Swipe the display until Water hardness

appears and touch this option.

 Select the hardness level you want

and thenOK.

The setting is now saved.

Filling the water container

 Change the water every day to

prevent a build-up of bacteria.

If the coffee machine is connected to a plumbed water supply and this setting is selected, the water container fills automatically when the machine is switched on.

The inlet device in the lid ensures that water flows into the water container quietly.

If the coffee machine has not been used to make any drinks for a long time, there will be water left in the inlet hose.

This can impair the taste of the coffee.

Discard the first full container of water.

You can also fill the container manually if you are not using the plumbed in water supply (see "Settings - Mains water connection")

If filling the water container manually: Only use fresh, cold tap water.

Hot or warm water or other liquids can damage the coffee machine.

Do not use mineral water. Mineral water will cause serious limescale deposits to build up in your machine and damage it.

 Open the appliance door.

 Pull the water container out to

remove it.

 Remove the lid and fill the water

container with fresh, cold tap water up to the "max." marker.

 Push the water container into the

machine until it clicks into place.

If the water container is a little high or not pushed in all the way, check whether the surface that the water container sits on is dirty. If the water container is not sitting correctly, the drainage valve will not be sealed. Clean the surface if necessary.

Filling the coffee bean container

Fill the coffee bean container with roasted coffee or espresso beans if you want to use freshly ground coffee beans for each cup of espresso or coffee.

Alternatively, you can make coffee or espresso with ready ground coffee (see "Making coffee or espresso using ready ground coffee").

Important! Risk of damage to the grinder.

Only put roasted coffee or espresso beans in the container. Anything else, including ground coffee, will damage the grinder.

Do not fill the bean container with any type of liquid.

Important! Sugar damages the coffee machine.

Do not use coffee beans that have been treated with sugar, caramel, or other substances and do not put liquids containing sugar in the coffee bean container.

Do not use green (unroasted) coffee beans or mixtures of coffee beans which contain green coffee beans. Green coffee beans are very hard and still contain a certain amount of residual moisture. These can damage the coffee machine grinder as soon as grinding begins.

Useful tip: You can use a nut or seed grinder to grind green coffee beans. These types of grinder generally have a rotating stainless steel blade. You can then add the ground green coffee portion by portion to the ground coffee chute and make the desired coffee drink (see "Making drinks with ready ground coffee").

 Pull out the coffee bean container.  Push back the lid and fill the

container with coffee beans.

 Slide the lid back into place.  Push the coffee bean container back

into the coffee machine and close the appliance door.

Switching the coffee machine on and off

Switching on

When the coffee machine is switched on, it heats up and rinses the pipework. This not only cleans the pipework, but also warms it before coffee is prepared.

If the coffee machine still has an operating temperature which is higher than 60°C, rinsing will not take place.

 Touch the On/Off sensor.

The appliance will begin rinsing after the heating-up phase. Hot water will come out of the central spout.

You can now prepare drinks.

Useful tip: Tip: If you do not want the water from the rinsing process to flow into the drip tray, place a suitable container (e.g. the small cleaning container) underneath the central spout before preparing the first coffee of the day.

Switching off

 Touch the On/Off sensor.

If coffee has been dispensed, the coffee machine will rinse the coffee pipework automatically before switching off.

Switching off for longer periods of time

If the coffee machine is not going to be used for a longer period of time, e.g. whilst on holiday:

 Empty the drip tray, the waste

container and the water container.

 Clean all components thoroughly,

including the brew unit, the central spout connector and the small drip tray located inside the door.

 Switch off the appliance.

If the appliance door is to be left open for a long time, it is advisable to switch off at the wall or the fuse to save energy.

The height of the central spout cannot be manually adjusted.

Before making the drink, the central spout moves to the optimum height for the cups or glasses used.

Switching the spout adjustment on and off

The Drinks menu is visible in the display.

 Touch Main menu or.  Touch  Settings.  Swipe the display and select Spout

adjustment.

 Select the required setting to switch

spout adjustment on or off.

 Touch OK.

The setting is now saved.

Spout adjustment

Making drinks

 The dispensing spouts present a

danger of burning or scalding. The liquids and steam dispensed are very hot.

Keep well away from the area underneath the spouts when hot liquids and steam are being dispensed.

Do not touch hot components.

The following drinks can be made: – Espresso is a strong, aromatic

coffee with a thick hazelnut brown coloured layer of froth - known as the crema - on top. When making espresso, use espresso roasted coffee beans.

– Coffee differs from espresso by

the increased amount of water and the roast of the beans. Use coffee beans of the correct roast to make coffee.

– Long coffee is a coffee with

considerably more water.

Making a coffee drink

 Place a cup under the central spout.  Select the type of coffee you want.

Preparation will begin and the coffee will be dispensed into the cup from the central spout.

To ensure that any coffee residues from the factory testing process are removed from the brewing system, please throw away the first two cups of coffee when using the coffee machine for the first time.

Making drinks

Dispensing a double portion

You can dispense two portions of espresso or coffee at once either into one cup or two separate cups.

To fill two cups at the same time:

 Place one cup under each of the

coffee spouts.

 Touch the double symbol for the

required drink.

Two portions of the desired drink will be dispensed from the central spout.

Cancelling preparation

 TouchStop or Cancel.

Preparing several cups of coffee - Coffee pot

You can make several cups of coffee one after the other automatically with the  Coffee pot function (max. 1litre). Up to eight cups can be made in this way.

The Drinks menu is visible in the display.  Place a sufficiently large container

under the central spout.

 Select  Coffee pot.  Touch the number of portions you

want to dispense (3 to 8).

 Follow the instructions in the display.

Each portion will be ground, brewed and dispensed individually. The display will inform you about the progress.

You can interrupt preparation at any time:

 Touch Cancel or Stop.

You can use the  Coffee pot function twice in a row. After this the coffee machine will need a longer cooling down time of an hour in order to avoid it being damaged.

Making drinks

Drinks made with ready ground coffee

To make espresso or coffee using ready ground coffee, add a portion of ground coffee to the ground coffee chute. This gives you the option of preparing a cup of decaffinated coffee, for example, even though the coffee bean container is filled with roasted coffee beans.

The coffee machine will recognise automatically that ready ground coffee has been added to the ground coffee chute.

Only one portion can be prepared at a time when using ready ground coffee or espresso.

Adding ready ground coffee

Do not add more than one level scoop of ground coffee to the coffee chute. If too much is added, the brew unit will not be able to process the coffee.

 Open the appliance door.

 Remove the coffee chute cover and

open the lid of the coffee chute.

 Add one level scoop of ready ground

coffee to the chute.

 Close the lid, push the coffee chute

cover into the machine and close the appliance door.

Prepare ground coffee? appears in the

display.

The coffee machine will use all the ground coffee which has been added to the chute to make the next coffee.

Use the measuring spoon supplied so that the correct amount is used.

Making drinks

Making drinks with ready ground coffee

If you want to make a drink with ready ground coffee:

 Touch Yes.

You can now select which type of drink you would like to make with ready ground coffee.

 Place a cup under the central spout.  Select a drink.

The coffee machine will now prepare the desired drink.

If you do not want to use ground coffee to make the drink:

 Touch No.

The ground coffee will be directed into the waste container.

If no drink is selected within15seconds, the ground coffee will be directed into the waste container.

Drinks with milk

 Danger of burning and scalding

on the central spout. The liquids and steam dispensed are

very hot.

Do not use milk with additives. Most additives contain sugar which will adhere to the milk pipework and damage the machine.

If using cow's milk, only use pasteurised milk to prevent a buildup of bacteria in the appliance.

The following drinks with milk can be made:

– Cappuccino consists of approx.

2/3 milk froth and 1/3 espresso.

– Latte macchiato consists of 1/3

each of hot milk, milk froth and espresso.

– Caffè latte consists of hot milch

and espresso.

Hot milk or milk froth can also be made.

Making drinks

Notes on the milk flask

Milk is not cooled in the milk flask. Therefore, place the milk flask in the refrigerator if you are not going to use milk for a while. Good milk froth can only be achieved when cold milk (below 10 °C) is used.

 Push the milk flask into the coffee

machine.

Preparing drinks with milk

The Drinks menu is visible in the display.  Place a suitable vessel underneath

the central spout.

Lid

Milk sensor

Milk suction tube

Glass milk flask

 Fill the milk flask up to max.2cm

below the rim. Seal the milk flask with the lid.

It is important to keep the opening and neck of the milk flask clean (whilst filling it and carrying it). Any soiling can lead to a malfunction of the flask in the machine.

 Select the drink you want.

The coffee machine will now prepare the selected drink.

Making drinks

Preparing hot water

Danger of burning and scalding on the hot water spout. The water dispensed is very hot.

The Drinks menu is visible in the display.

Please note that the water prepared by the machine is not boiling and is therefore not suitable for preparing tea.

 Place a suitable vessel underneath

the hot water spout.

 Select Hot water.

Hot water will be dispensed into the vessel under the hot water spout.

To cancel preparation:  Touch Stop orCancel.

Preparing User profile drinks

If you have already created a User profile (see "User profiles"), you can select it before preparing a drink.

 Touch User profiles and select the

profile you want..

The name of the User profile and the created drinks will appear in the display.

You can now prepare the drink you want.

Making drinks

After a drink has been prepared

If you have made a drink with milk, Start

the rinsing programme will appear in the

display after a while.  Touch OK.

The milk pipework will now be rinsed.

Even if you do not confirm the message with "OK", the coffee machine will rinse the pipework after a while automatically.

Useful tip: Remove the milk flask and rinse the lid under running water. Then fit the small lid to the milk flask and store the flask in the fridge until it is needed again. You can only achieve good quality milk froth with milk which is cold (<10°C).

Coffee the way you like it

In order to customise the coffee machine to the type of coffee being used, you can

– change the grinder setting,

– change the amount of coffee,

– set the brewing temperature, or

– pre-brew the coffee powder.

Grinder setting

When the beans are ground correctly, the coffee or espresso will flow evenly into the cup with a good crema. The crema should have an even nutbrown colour.

The grinder setting you select will be used for all coffee drinks.

There are various ways to tell whether the coffee grinder is set correctly.

The coffee has been too coarsely ground if:

– Espresso or coffee flows into the cup

too quickly.

To avoid damaging the grinder, please note the following:

Only adjust the grinder one setting at a time.

Grind the coffee beans again if you want to adjust the grinder to the next setting.

 Open the appliance door.

 Push the slide control one setting to

the left (for finer grinding) or one setting to the right (for coarser grinding).

 Close the appliance door.

– The crema is very pale and uneven.

Set a finer grinder setting.

The coffee has been too finely ground if:

– Espresso or coffee only trickles into

the cup.

– The crema is dark brown.

Set a coarser grinder setting.

 Dispense a coffee.

Then you can adjust the grinder setting with the slide control again.

The altered grinder setting will not be used until after the second coffee has been dispensed.

Coffee the way you like it

Changing the parameters of a drink

You can change the amount of coffee, pre-brewing and the brewing temperature for each drink.

The Drinks menu is visible in the display.

 Touch Edit or select Make drinks.  Touch Change drink.  Select a drink.  Touch Drink parameters.

For this drink you can now

– change the amount of coffee,

– set the brewing temperature, and

– switch on the "Pre-brewing" option.

Amount of coffee

The coffee machine can grind and brew 6-14g of coffee beans per cup. The greater the quantity, the stronger the coffee.

There are various ways to tell whether the amount of coffee is set correctly.

The amount of coffee is too low if:

– Espresso or coffee flows into the cup

too quickly.

– The crema is very pale and uneven.

– The espresso or coffee lacks body.

Increase the amount of coffee so that more ground coffee is brewed.

The amount of coffee is too high if:

– Espresso or coffee only trickles into

the cup.

– The crema is dark brown.

– The espresso or coffee tastes bitter.

Decrease the amount of coffee so that less ground coffee is brewed.

 Touch Amount of coffee.  Select the amount of coffee you want

using the bar chart and then touchOK.

The setting is now saved.

Useful tip: If the coffee is too strong for you or it tastes bitter, try a different type of bean.

Brewing temperature

The ideal brewing temperature will depend on

– the type of coffee being used,

Coffee the way you like it

– whether an espresso or a coffee is

being prepared, and

– the altitude of the region.

If the coffee machine is located at more than 2000 metres above sea level, the brewing temperature needs to be set lower due to the change in pressure. This is because the boiling point for water at a high altitude above sea level is lower than the boiling point for water at sea level.

Useful tip: Not all types of coffee can withstand a high temperature. Certain types are too delicate - the crema on top would not be as good and the taste would be impaired.

The coffee machine has five brewing temperatures.

 Swipe the screen in the Brew

temperature field until the setting you

want appears.

 Touch OK.

Pre-brewing ground coffee

When the pre-brewing function is switched on, the freshly ground coffee is first moistened with a little hot water. Then the remaining water is forced through the moistened coffee at high pressure. This helps release the flavour of the coffee.

You can set pre-brewing for a normal length of time or an extra long length of time. Alternatively, you can switch off the "Pre-brewing" function. The machine is supplied with the "Prebrewing" function switched off.

 Swipe the screen in thePre-brewing

field until the setting you want appears.

 Touch OK.

The setting is now saved.

Portion size

The flavour of the coffee produced depends not just on the type of coffee used, but also on the amount of water used. You can programme the amount of water to suit the size of your cups and the type of coffee you are using.

For coffee drinks that use milk you can also set the amount of milk or milk froth to be dispensed with these drinks. Additionally, you can set the portion sizes for hot milk and milk froth alone.

Each type of drink has a maximum portion size that can be programmed into the machine. The coffee machine halts preparation of the coffee once this portion size has been reached. The maximum possible portion size for this type of drink is then saved in the machine.

The changed portion size is always saved in the current User profile. The name of the current User profile appears in the top-left of the display.

If the water container becomes empty during the preparation of a drink, the programming of the portion size will be cancelled. The portion size will not be saved.

The Drinks menu is visible in the display.  Place the desired cup under the

central spout.

 Touch Edit and then Change drink.  Select a drink.  Touch Change the portion size.

The desired drink will be made and Save will appear in the display.

 When the cup is filled up to the level

you want, touch Save.

If you want to change the portion size for coffee specialities made with milk (e.g. Cappuccino), the ingredients (components) which make up the drink will be saved one after the other while the drink is being made.

 When the quantity for each ingredient

reaches the level you want, touch

Save.

The combination programmed in and the total portion size will now be dispensed every time that particular drink is selected.

You can reset drink portions and parameters for all drinks to the factory default.

The Drinks menu is visible in the display.  TouchEdit and then Reset drinks.

Reset all drinks to default settings? appears

in the display.  Touch Yes.

Resetting drink settings

User profiles

In addition to the Miele profile, you can enter individual profiles to cater for different tastes and preferences.

For each profile you can adjust the settings for drinks individually (portion size, grinder setting, brew temperature and pre-brewing).

The name of the current User profile is shown in the top left of the display.

Calling up User profiles

 Touch User profiles in Main menu or in

theDrinks menu.

You can now create a User profile.

If you have allocated a profile in addition to the Miele standard profile, you have the following options:

– Select profile from the User profiles

that have already been allocated.

– Change name if the name of a User

profile needs to be changed.

– Delete profile if you want to delete a

User profile.

Creating a User profile

 Touch Create profile.

The editor will open in the display.  Enter the name you want and then

touchOK.

Selecting a User profile

 Select the User profile you want.

The name of the current User profile is shown in the top left of the display.

Changing a name

 Select Edit and then Change name.  Select the profile you want and then

touch OK.

 Enter the name you want and then

touchOK.

Deleting a profile

 Select Edit and then Delete profile.  Select the profile you want and then

touchOK.

– Change profile to set whether the

coffee machine automatically always reverts to the Miele standard profile or retains the last selected profile.

Changing a User profile

You can set up the coffee machine so that after each use it automatically reverts back to the Miele standard profile, or it retains the last selected User profile.

 Select Edit and then Change profile.

You now have the following options:

– Manual: The selected User profile

remains active until you select another User profile.

– After each use: The machine will

change back to the Miele standard profile automatically after a drink is dispensed.

– When switched on: Each time the

machine is switched on it will automatically select the Miele standard profile regardless of which User profile was set before the machine was last switched off.

User profiles

 Select the option you want and then

touchOK.

User profiles: Creating and editing your own drinks

You can create your own drinks for each User profile and for each drink you can individually adjust the portion size and other parameters, e.g. amount of coffee or temperature.

You can also change the names of your drinks and delete any unwanted drinks from your User profile. A maximum of nine drinks can be saved under one User profile.

First open the required User profile:  Select Main menu  User profiles or

touch User profiles in theDrinks menu.

 Select the User profile you want.

The name of the current User profile is shown in the top left of the display.

Creating a drink

You can create new drinks while using the drinks already available as a basis. A maximum of nine drinks can be saved under one User profile.

 Touch Edit.

 Enter a name for the new drink

(maximum 8characters) and touch

Save.

The new drink will appear in the current User profile.

Changing a drink: Changing the portion sizes, drinks parameters and names

 Touch Edit.  Select Change drink.  Select a drink.

Now you can adjust the portion sizes, change the parameters or change the names.

Deleting drink

 Touch Edit.  Select Delete drink.  Select the drink you want and touch

OK.

 Touch Create drink.

Make a selection from the standard drinks available:

 Select a drink.  Change the drink parameters and

portion size for this drink according to your preferences (see "Coffee the way you like it" and "Changing the portion size").

Drink preparation will be begin and you can save the portions of each component as desired.

MyMiele

You can display drinks you make frequently, drinks from profiles and maintenance programmes in the MyMiele screen.

The MyMiele screen can be set to appear as the start screen (see "Settings - Start screen"). The MyMiele screen will then appear when the coffee machine is switched on.

Opening the MyMiele menu

 Touch Main menu MyMiele.

You can now configure MyMiele.

If you have already added some entries, you can carry out the following under

Edit:

– Sort entries

– Delete entries

Adding an entry

 Touch Add entry.

Deleting an entry

 Touch Edit.  Select Delete entry.  Select the entry you want and then

touchOK.

The entry will be deleted.

Sorting entries

If you have added more than four entries, you can sort them.

 Touch Edit.  Select Sort entry.  Select the entry you want to move

and the position you want to move it to.

 Confirm the new position with OK.

You can select options listed in the following categories:

– Drinks – User profiles – Maintenance  Select the entry you want and then

touchOK.

A box will appear next to the selected option together with the menu it comes from.

Settings

You can use the "Settings" menu to customise the coffee machine to suit your individual requirements.

Open the Settings menu

The Drinks menu is visible in the display.

 Touch Main menu or.  Select  Settings.

You can now check or make alterations to settings. The settings which are currently selected will have a coloured frame around them.

Touching  takes you back to the previous menu.

Changing and saving settings

 Touch Main menu or.  Select  Settings.  Select the option you want to

change.

 Change the setting and touchOK.

The setting is now saved.

Overview of available settings

The factory default for each option is indicated by *.

Menu option Available settings

Select language  deutsch and other languages

Country

Time Display

– Off* / On / Night dimming

Clock type

– Analogue / Digital*

Clock format

– 12 h (am/pm) / 24 h*

Set Date Set Timer Timer 1

– Set : Switch on at / Switch off after (00:30)* / Switch off at – Days of the week: Monday / Tuesday / Wednesday /

Thursday / Friday / Saturday / Sunday

Settings

– Activate : Switch on at (Yes / No*) / Switch off at (Yes /

No*)

Timer 2

– Set : Switch on at / Switch off at – Days of the week: Monday / Tuesday / Wednesday /

Thursday / Friday / Saturday / Sunday

– Activate : Switch on at (Yes / No*) / Switch off at (Yes /

No*) Eco mode On* / Off Lighting Brightness

Switch off after

Settings

Menu option Available settings

Start screen Main menu

Drinks User profiles MyMiele

Info Number of drinks

– Total coffee drinks / Espresso / Coffee / Long coffee /

Cappuccino / Latte macchiato / Caffè latte / Milk froth / Hot

milk / Hot water

No. of portions until

Descale appliance / Degrease the brew unit System lock  On / Off* Water hardness Soft 1

Medium 2

Hard 3*

Very hard 4 Volume Buzzer tones

Keypad tone Spout adjustment On / Off* Mains water On / Off* Showroom programme Demo mode (On / Off*) Factory default Settings

MyMiele

Settings

Language

You can select a language and country for all display texts.

Useful tip: If you select the wrong language by mistake, you can find the "Language" option by following the flag symbol .

Time of day

You can set the clock type, when the time appears in the display after switching off, the clock format and the time.

Display (time display)

You can choose one of the following options:

– On: The time and the date will appear

in the display all the time, even when the coffee machine is switched off.

– Off: The time and the date will not

appear in the display when the coffee machine is switched off.

– Night dimming: The date and time are

displayed from 5:00 to 23:00.

Depending on the setting selected, the coffee machine may use more energy. A message will appear in the display to inform you of this.

Clock type

The time can be displayed as

Analogue or

Digital.

Clock format

You can select: – 24-hour display (24 h) – 12-hour display (12 h (am/pm))

Setting the time of day

Set the hours and then the minutes.

Date

Set the day, month and year.

Settings

Timer

There are two timers with the following timer functions:

The coffee machine

– switches on at a particular time, e.g.

in the morning for breakfast (Switch on

at).

– switches off at a particular time

(Switch off at).

– switches off after a particular length

of time if none of the sensors has been touched or a drink has not been made (Switch off after; Timer 1 only).

You can allocate the timer functions to individual days of the week.

For Switch on at and Switch off at, the timer must be activated and at least one day of the week allocated.

Selecting a timer

You can select: – Timer 1: Switch on at, Switch off at,

Switch off after

Switch on at

The coffee machine will not switch on at the required time if you have activated the system lock. The timer settings are deactivated.

If the coffee machine has switched itself on three times via the Switch on at timer function and no drinks have been dispensed, the machine will not switch itself on again automatically. This prevents the coffee machine from switching itself on unnecessarily, for example, whilst you are away on holiday. The programmed times will, however, remain in memory and will be reactivated after manually switching the machine on again.

Switch off at

In the event of a longer absence the programmed times will remain in memory and will be reactivated after manually switching the machine on again (see "Switch on at").

– Timer 2: Switch on at, Switch off at

Settings

Switch off after

The Switch off after timer function is only available in Timer 1.

If none of the sensors has been pressed or no drink has been prepared, the coffee machine will switch itself off after 30 minutes to save energy.

You can change this pre-setting to a time of between 15 minutes and 9 hours.

Allocating days of the week

Select the day of the week you want. The selected day of the week will be marked by .

When all required days of the week are marked:

 Touch OK.

Activating and deactivating the timer

For the time display, you have selected

On or Night dimming:

If the timer for Switch on at has been activated, the symbol  and the desired switch-on time appear in the display 23:59 hours ahead of time.

When the system lock is activated, the

Switch on at option for the timer cannot

be selected.

Select the required timer function. The selected timer function will be marked by .

 Touch OK.

Settings

Eco mode

Eco mode is an energy-saving mode. The steam system heats up when a coffee drink or steam for hot milk / milk froth is requested.

If Eco mode is switched off, milk froth and hot milk, as well as coffee and espresso, can be made one after another. The steam system remains heated up and much more energy is used.

The coffee machine will indicate that the energy consumption has been altered.

Lighting

The following options are available:

– Set the brightness of the lighting

when the appliance is switched on.

– Set the brightness of the lighting

when the appliance is switched off.

– You can specify when the lighting

should switch off (Lighting: Switch off

after).

Set the brightness of the display

First select:

– Appliance switched on

– Appliance switched off

Setting the switching off time for the lighting (Switch off after)

You can set how long the lighting should remain on after switching off the coffee machine.

While the appliance is switched on, the lighting will remain on for 10minutes after the last activity. This time cannot be changed.

Settings

Start screen

You can choose which screen appears when the coffee machine is switched on.

– Main menu – Drinks – User profiles – MyMiele

Info (display information)

In the Info option you can choose to display the number of prepared portions for each type of drink.

You can also see whether more than 50portions can be dispensed before the machine needs to be descaled or before the brew unit needs to be degreased (No. of portions until ...).

To return to the previous display:  Touch OK.

Locking the coffee machine (System lock)

You can lock the coffee machine to prevent it being used without your knowledge, by children, for example.

Activating and deactivating the system lock

When the system lock is activated, the

Switch on at option for the timer is

deactivated. The coffee machine will

not switch on at the time set.

Overriding the system lock

While the message Press for seconds to

unlock appliance is in the display,

 touch the lock symbol.

As soon as you switch the coffee machine off, the system lock will be activated again and the coffee machine is locked once more.

Settings

Water hardness

See "Setting up and using the coffee machine" for information about water hardness.

Display brightness

You can set the display brightness using the bar chart.

Volume

You can set the volume of buzzer and keypad tones using the bar chart.

Activating and deactivating mains water connection

The coffee machine is designed to be operated with a mains water connection. If this option is activated, the water container will be filled automatically via the mains water hose. If mains water connection is deactivated, the water container must be filled manually.

Warming drawer

You can connect a warming drawer directly to the coffee machine with a special connection cable (optional accessory). Suitable warming drawers for this coffee machine are listed earlier in these operating instructions. You can also contact Miele should you require further information.

The special connection cable needed can be purchased by contacting Miele.

After connecting the appliance to the electricity supply, you need to activate the warming drawer in Settings.

You can choose one of the following options:

– Automatic: The warming drawer will

switch on and off together with the coffee machine.

If you have programmed the Switch on

at timer, the warming drawer will

switch on approx. 30 minutes before the coffee machine switches on in order to pre-heat your cups.

– On: You can switch the warming

drawer on or off at any time independently of the coffee machine.

– Off: The warming drawer cannot be

switched on (the pre-requisite for this option is that the warming drawer must be connected to the coffee machine via the connection cable).

The warming drawer is set to Off at the factory.

Settings

Spout adjustment

You can find information on adjusting the height of the spout in the "Spout adjustment" section of this booklet.

Factory default

You can reset the settings back to the ones which were set when the coffee machine was delivered - the factory default settings.

When you do this, the language and time settings will not be deleted. The number of drinks dispensed and the coffee machine status (number of uses until descaling/degreasing the brew unit) will not be reset either.

Please refer to the "Overview of available settings" chart for the factory settings which are shown in bold.

The following settings can be reset separately:

– MyMiele

Showroom programme (Demo mode)

Do not activate this function for domestic use.

The appliance can be presented in Miele Centers or retail stores with the

Showroom programme function. The

lighting will come on but drinks cannot be dispensed and other actions cannot be carried out.

If you activate the Demo mode, you cannot switch the appliance off with the On/Off sensor.

– Profiles and their drinks: see "User

profiles" and "User profiles: Creating and editing your own drinks"

– (Standard) Miele Profile portion sizes

and parameters: see "Resetting drinks"

Cleaning and care

 Clean the coffee machine regularly to avoid a build-up of bacteria.

Quick guide

Recommended frequency What do I need to clean / maintain?

Every day

(at the end of the day)

Once a week (more often if heavily soiled)

Once a month Lubricate the cap on the central spout connector

When prompted Milk pipework (with the Original Miele cleaning agent for

Milk flask and lid

Water container

Waste container

Drip tray and drip tray cover

Central spout

Sensor cover

Clean the milk valve with the cleaning brush

Interior

Drip tray inside the machine door

Brew unit

Appliance front (especially important straight after descaling)

Coffee bean container

milk pipework)

Brew unit (degrease with the cleaning tablets)

Descaling the machine

Cleaning and care

Cleaning by hand or in the dishwasher

The following components must only be cleaned by hand:

– Central spout cover

– Brew unit

– Bean container and lid

– Service flap

Some components of the coffee machine are dishwasher safe. However, cleaning these in the dishwasher frequently can cause them to become discoloured due to regular contact with food residues (e.g. tomatoes) in the dishwasher. The surface of these components can also become damaged.

The following components are dishwasher safe:

– Drip tray and grid

 Danger of burning and scalding

on hot components or by hot liquids. Always allow the coffee machine to

cool down before cleaning it. Caution: Water in the drip tray can be very hot.

Do not use a steam cleaner to clean this machine. Steam could reach the electrical components and cause a short circuit.

It is important to clean the machine regularly as the used coffee grounds will soon go mouldy. Milk residue can spoil and the milk pipework can become blocked.

The central spout connector cap is lubricated with silicone grease.

Take care not to get this on your clothes when removing or replacing the containers or other components.

– Drip tray cover

– Water container

– Waste container

– Central spout (without stainless steel

cover)

– Sensor cover

– Milk flask with lid

– Drip tray inside machine door

Cleaning and care

All external surfaces are susceptible to scratching. Scratches on glass surfaces could even cause a breakage. Contact with unsuitable cleaning agents can discolour the external surfaces. Wipe up any spillages or splashes of descaling agent immediately.

To avoid damaging the surfaces of your appliance, do not use:

– cleaning agents containing soda,

ammonia, acids or chlorides,

– solvent-based cleaning agents,

– cleaning agents containing descaling

agents,

– stainless steel cleaning agents,

– dishwasher cleaner,

– glass cleaning agents,

– oven cleaner,

– abrasive cleaning agents, e.g.

powder cleaners and cream cleaners,

– hard, abrasive sponges, e.g. pot

scourers, brushes or sponges which have been previously used with abrasive cleaning agents,

– dirt erasers,

– sharp metal tools.

Drip tray

 Danger of burning!

If the rinsing process has just finished, wait a while before removing the drip tray as the water used for rinsing will run out of the coffee spouts.

Clean the drip tray every day to avoid unpleasant smells and mildew.

A prompt will appear in the display when the drip tray is full and needs to be emptied. Empty the drip tray at the latest when this prompt appears.

Cleaning and care

 Clean the metal contact discs and the

space between them carefully. Dry everything thoroughly.

The discs will not be able to detect that the drip tray is full if they are damp or dirty. Check this area once a week, if necessary.

 Clean the area underneath the drip

tray.

 Open the machine door and carefully

remove the drip tray from the machine.

The grid in the drip tray prevents the water from spilling out of the tray when it is being carried.

 Clean the drip tray and the grid with

hot water and a little washing-up liquid applied a soft cloth, or in the dishwasher, and dry with a cloth.

 Push the drip tray back into the

coffee machine.

Make sure that the drip tray is pushed right into the coffee machine as far as it will go.

Cleaning and care

Drip tray cover

 Remove the drip tray cover.  The drip tray cover can be cleaned in

the dishwasher, or by hand using hot water and a little washing-up liquid applied with a soft cloth

 Dry the drip tray thoroughly.

 Refit the cover in the drip tray. Make

sure the drip tray cover sits flush at the front.

Water container

Change the water every day to prevent a build-up of bacteria.

Make sure that the valve, the underside of the water container and the surface the water container sits on are clean. Otherwise the water container will not sit correctly.

 The water container can be cleaned

in the dishwasher, or by hand using hot water and a little washing-up liquid applied with a soft cloth. After cleaning, dry the water container.

 Carefully clean and dry the surface

the water container sits on, particularly the slots.

Cleaning and care

Waste container

After a certain period of time a reminder to empty the waste container will appear in the display. The waste container must be cleaned when this message appears. However, it is better to clean the waste container every day to prevent coffee grounds from turning mouldy.

There will probably also be some water in the waste container left over from the rinsing process.

 Clean the waste container with hot

water and a little washing-up liquid or in the dishwasher, and dry with a soft cloth.

 Also thoroughly clean the now

accessible area in the machine where the waste container sits.

Central spout

With the exception of the stainless steel cover, all parts of the central spout should be cleaned in the dishwasher at least once a week. This will remove coffee deposits effectively.

Clean the stainless steel central spout cover by hand only using warm water and a little washing-up liquid, applied with a soft cloth.

The central spout must move into the maintenance position before cleaning. Once in the maintenance position, all parts can be removed.

If there is a cup or container underneath the central spout, make sure that you remove this as it would prevent the central spout from moving into the maintenance position.

 Touch Main menu or.  Select  Maintenance and then Clean

the central spout.

 Follow the instructions in the display.

The central spout will move into the maintenance position.

Cleaning and care

 Remove the cover by pulling it

towards you.

 Press the catch upwards, grasp

the dispensing unit by the handle and pull this forwards and off .

 Hold the unit at the sides and pull it

forwards to release it.

 Turn the top connection piece and

pull it upwards to remove it. Remove the lower connection piece in the same way.

 Remove the dispensing spouts.

The Y-shaped piece should not be removed.

 Clean all parts thoroughly.

Cleaning and care

Useful tip: Place the dispensing unit

vertically in the upper basket of the dishwasher. Place the connecting pieces and the dispensing spouts in the cutlery tray.

 Clean the surfaces of the central

spout with a damp cloth.

Cleaning and care

 Reassemble the spout unit in the

reverse order. Make sure the top connection piece engages with a click. Firmly push the spout jets onto the dispensing unit.

Make sure that all parts are tightly connected to one another.

 Refit the dispensing unit in the central

spout and touchOK.

Sensor cover

The sensor cover for the cup protection switch-off is located at the base of the central spout. If the automatic spout adjustment sensors do not properly recognise a cup, the cup protection switch-off will stop the central spout from lowering.

Clean the sensor cover once a week in the dishwasher or by hand using warm water and a little washing-up liquid, applied with a soft cloth.

 Then refit the cover and touchOK.

The central spout will now be rinsed through.

 To remove the sensor cover, press

and hold the cover  between the two dispensing spouts. Then press the sides of the central spout  at the back.

The sensor cover will come off.

To refit it:  Insert both hooks at the back and

press the sensor cover upwards.

Cleaning and care

Maintenance of the milk valve

The milk valve should be cleaned once a week to ensure good quality milk froth and prevent sputtering.

The Drinks menu is visible in the display.

 Touch Main menu or.  Select  Maintenance and then Clean

the central spout.

The central spout and the milk valve will move into the maintenance position.

You must remove the cleaning brush before confirming the OK message in the display. Otherwise the coffee machine will be damaged.

Milk flask with lid

Soiling can cause a fault in the machine.

It is important to keep the neck and flange of the flask clean (whilst filling it and carrying it).

 Clean the milk flask holder on the

coffee machine with a damp cloth.

 Clean the glass milk flask in the

dishwasher or by hand using hot water and a little washing-up liquid applied with a soft cloth. Dry the milk flask thoroughly.

Before placing the lid of the milk flask in the dishwasher:

 Insert the brush in the milk valve and

move it back and forth.

 Touch OK.

The milk valve will move into the initial position and the milk pipework will be rinsed.

 Rinse the milk pipework in the lid

under running water.

If water does not run out of the milk pipework,

 dismantle the milk flask lid and clean

it with the cleaning brush supplied.

Cleaning and care

Dismantling the milk flask lid and cleaning it with the cleaning brush

Milk fat deposits can collect in the milk flask lid. These will cause the milk to sputter when milk froth is being made.

 Pull the milk suction tube out of the

milk flask lid. Make sure you remove the seal as well.

 Clean both parts under warm running

water. Insert the cleaning brush supplied in the stainless steel tube and move it back and forth until all milk residues have been removed.

 Also use the cleaning brush to clean

the milk pipework in the lid from above and below.

To reassemble the lid:  First insert the seal in the lid.

Make sure you do not fit the slanted end of the milk intake tube into the seal. This would damage it.

 Fit the milk intake tube into the seal.

Cleaning and care

Interior and appliance door

 First take out all removable parts and

then clean the interior and the machine door with a mild solution of hot water and washing-up liquid.

Useful tip: Use your vacuum cleaner to remove dry ground coffee residues.

A small drip tray is located inside the lower part of the machine door.

 Remove the drip catcher and clean it

in the dishwasher or by hand using warm water and a little washing-up liquid applied with a soft cloth.

Central spout connector

The part which connects the brew unit and the central spout is located on the inside of the machine door.

 Clean this connection regularly with a

damp cloth, taking care not to wipe the grease off the cap.

 Lubricate the cap at least once a

month with the silicone grease supplied.

Do not forget to refit this small drip tray.

Cleaning and care

Brew unit

Removing and cleaning the brew unit by hand

Clean the brew unit by hand only using warm water. Do not use washing-up liquid.The moving parts of the brew unit are lubricated. Washing-up liquid will damage the brew unit.

The brew unit can be removed for cleaning. It should be cleaned once a week.

 Open the appliance door.  Remove the water container, waste

container and the coffee chute cover.

If you cannot remove the brew unit or can only do so with difficulty, the brew unit is not in the correct position (See "Problem solving guide").

When you take the brew unit out of the machine, do not change the position of the brew unit handle, as this would cause the brew unit to be out of alignment and you will not be able to push it back into the coffee machine.

 Clean the brew unit by hand under

warm running water without using

washing-up liquid.

 Press the button under the handle of

the brew unit  and, whilst doing so, turn the handle clockwise .

 Press the catch in front of the brew

unit downwards, and pull the brew unit carefully out of the machine.

 Carefully pull the brew unit out of the

coffee machine.

 Wipe any remaining coffee off the two

filters. One filter is located in the funnel and the other to the left of the funnel.

 Dry the funnel to prevent ground

coffee sticking to it the next time a coffee is prepared.

 Clean the inside of the coffee

machine. Use your vacuum cleaner to remove dry coffee grounds.

Cleaning and care

To refit the brew unit:  Proceed in the reverse order: push

the brew unit back into the coffee machine, making sure it goes in straight.

 Press the button under the handle of

the brew unit and, whilst doing so, turn the handle to the anticlockwise.

 Close the appliance door.

Maintenance programmes

The coffee machine has the following maintenance programmes:

– Rinsing the appliance

– Rinsing the milk pipework

– Cleaning the milk pipework

– Degreasing the brew unit

– Descaling the machine

Carry out the relevant maintenance programme when the prompt to do so appears in the display. Please see the following pages for more information.

Opening the "Maintenance" menu

The Drinks menu is visible in the display.

 Touch Main menu or.  Select  Maintenance.

You can now select a maintenance programme.

Cleaning and care

Rinsing the appliance

After a coffee has been dispensed, the machine is rinsed before it switches off. This removes any residual coffee grounds.

The Drinks menu is visible in the display.

 Touch Main menu or.  Select  Maintenance and then Rinse

appliance.

The pipework will be rinsed and the water used for rinsing will come out of the central spout.

Rinsing the milk pipework

The milk pipework can become blocked with milk residue. If you have prepared a drink using milk, the coffee machine will automatically rinse the milk pipework after a few minutes.

The Drinks menu is visible in the display.

 Touch Main menu or.  Select  Maintenance and then Rinse

milk pipework.

The milk pipework will now be rinsed.

Cleaning and care

Cleaning the milk pipework

Ensure that all components in which milk is transported are cleaned on a regular basis. Milk naturally contains bacteria that rapidly multiply if the milk pipework is not cleaned properly. Soiling in the appliance may be dangerous to health.

The milk pipework must be cleaned at least once a week. The coffee machine will prompt you at the correct time. Clean the milk pipework in

days will appear in the display three

days before the coffee machine is due to be cleaned. Each time the coffee machine is switched on the number of days until the milk pipework needs to be cleaned will appear in the display.

 Confirm the message with OK.

When the number of days remaining reaches 0, Clean the milk pipework will appear in the display. You cannot make drinks with milk until cleaning has been carried out.

You can then only prepare espresso, coffee, long coffee and hot water. You can only prepare drinks containing milk after the milk pipework has been cleaned.

 Confirm the message with OK.

Carrying out the milk pipework cleaning process

The cleaning process cannot be cancelled once it has started. The process has to be completed through to the end.

The Clean the milk pipework maintenance programme lasts for approx.13minutes.

The Drinks menu is visible in the display.

 Touch Main menu or.  Select  Maintenance and then Clean

the milk pipework.

The process begins and various messages appear in the display.

 Follow the instructions in the display. When Fill water container with lukewarm

water and cleaning agent up to the  symbol and insert appears in the display,

proceed as follows.

Making a cleaning solution

We recommend using the Miele cleaning agent for milk pipework for cleaning the milk pipework. This has been specially developed for use with Miele coffee machines and prevents subsequent damage.

The milk pipework cleaning agent is available to order from Miele or via the internet at www.miele-shop.com (depending on country).

 Add one sachet of the cleaning agent

for milk pipework to the water container.

Cleaning and care

 Fill the water container to the

marker with lukewarm water and stir the solution.

Please adhere to the mixing ratio. It is important that you do not fill the water container with too little water, otherwise cleaning will be incomplete.

 Insert the water container and close

the appliance door.

 Follow the instructions in the display.

When prompted to by the display:  Carefully rinse the water container

with clean water. Ensure that no cleaning agent residue remains in the water container. Then fill the water container with fresh tap water.

The cleaning process is finished when

Process finished appears in the display.

Degreasing the brew unit

Depending on the natural oil content of the coffee used, the brew unit can become blocked quite quickly. It must be degreased regularly in order to ensure aromatic coffee and trouble-free operation of the coffee machine.

We recommend using Miele cleaning tablets to clean the brew unit. These have been specially developed for use with Miele coffee machines and prevent subsequent damage. Miele cleaning tablets can be ordered via the Miele webshop or directly from Miele (see back cover for contact details).

The maintenance programme for degreasing the brew unit lasts for approx.11minutes.

After 200 portions have been dispensed, Degrease the brew unit will appear in the display.

 Confirm the message with OK.

This message will not go out until the brew unit has been degreased.

Carrying out the "Degrease the brew unit" process

 Switch the machine on with the On/

Off sensor.

 Touch Main menu or .

The cleaning process cannot be cancelled once it has started. The process has to be completed through to the end.

 Select  Maintenance and then

Degrease the brew unit.

 Follow the instructions in the display. When Place a cleaning tablet in the ground

coffee chute and close the chute appears

in the display:

 Remove the coffee chute cover and

open the lid of the coffee chute.

 Place a cleaning tablet in the coffee

chute.

 Close the lid, replace the coffee chute

cover and close the machine door.

Cleaning and care

 Follow the further instructions given

in the display.

When Process finished appears in the display:

 Touch OK.

The brew unit is now degreased.

Descaling the machine

Important! When descaling the machine, cover delicate surfaces and natural flooring to prevent damage from splashes of descaling solution.

Ensure that any splashes of descaling solution are wiped up immediately.

Limescale builds up in the coffee machine through use. How often the appliance needs to be descaled will depend on the water hardness level in your area. The machine should be descaled regularly to ensure that it functions correctly.

The appliance will guide you through the descaling process. Various messages will appear in the display, e.g. you will be prompted to empty the drip tray or fill the water container.

The descaling process is essential and takes approx.20minutes.

The coffee machine prompts you when it needs to be descaled. No. of portions

until appliance needs descaling: 50 appears

in the display. Each time a drink is prepared, the coffee machine displays the number of portions remaining until descaling must be carried out.

 Confirm the message with OK.

When the number of remaining portions reaches 0, the coffee machine will lock out. Then Descale will appear in the display.

You can switch off the coffee machine if you do not want to descale it at this point in time. However, you will be able to prepare drinks only after descaling has been carried out.

Descaling after prompt appears in the display

Descale appears in the display.

The descaling programme cannot be cancelled once you have touched OK. The programme has to be completed through to the end.

 Touch OK.

The process will start.  Follow the instructions in the display. When Fill water container with lukewarm

water and descaling solution up to the  symbol and insert appears in the display,

proceed as follows.

Creating the descaling solution

We recommend using Miele descaling tablets for optimum results. These have been specially developed for use with Miele coffee machines and prevent subsequent damage.

Other descaling agents, which contain other acids besides citric acid and/or other undesirable substances, such as chlorides for example, could damage the coffee machine. Moreover, the descaling effect required could not be guaranteed if the descaling solution was not of the appropriate concentration.

Miele descaling tablets are available to order via the Miele webshop or directly from Miele (see back cover for contact details).

You will need 2 descaling tablets for the descaling process.

 Fill the water container to the

marker with lukewarm water.

 Drop 2 descaling tablets in the water.

Follow the instructions for the mixing ratio carefully. It is important that you do not fill the water container with too much or too little water. Otherwise the descaling process will be cancelled prematurely.

Descaling the machine

Carrying out descaling

 Insert the water container and close

the appliance door.

 Follow the further instructions given

in the display.

When Fill the water container with fresh tap

water up to the descaling symbol 

appears in the display:  Carefully rinse the water container

with clean water. Ensure that no descaling solution residue remains in the water container. Fill the water container to the marker with fresh tap water.

The descaling programme is finished at the end of the rinsing cycle and drinks can be made again.

To protect the machine and surrounding surfaces from damage, make sure you wipe up any spillages or splashes of descaling agent immediately.

Descaling the machine

Descaling when not prompted by a message

 Touch Main menu or.  Select Maintenance.

The descaling programme cannot be cancelled once you have touched OK. The programme has to be completed through to the end.

 Select Descale.

The descaling programme will begin.

Problem solving guide

Most problems that occur during daily use can be easily corrected. With the help of the following guide, you will be able to find the causes of problems and rectify them.

 Important! Never open the casing of the appliance.

Unauthorised or incorrect repairs could cause personal injury or damage to the appliance.

Repairs should only be carried out by technicians approved by Miele.

If you can't remedy the problem yourself, please call Miele. Please note that a callout charge will be applied to unnecessary service visits where the problem could have been rectified as described in these operating instructions.

Messages in the display

Error messages must be confirmed with OK, otherwise the message can reappear in the display even though the problem has been remedied.

Follow the instructions which appear in the display to remedy the problem.

If the fault message appears in the display again, contact Miele.

Message Possible cause and remedy

F1, F2, F3, F4, F80, F81, F82, F83

F74, 77 F225, F226 F235, F236

There is a fault inside the appliance.  Switch the machine off with the On/Off sensor.

Wait for 1hour before switching it back on again.

There is a fault inside the appliance.  Switch the machine off with the On/Off sensor.

Wait for 2minutes before switching it back on again.

Problem solving guide

Message Possible cause and remedy

F73 or

Check the brew unit

F227, F228, F229, F230 F233

The brew unit cannot be positioned correctly, or it is dirty and the coffee cannot be processed.

 Check whether you can remove the brew unit (see

"Cleaning and care - Brew unit").

 Clean the brew unit if it can be removed (see

"Cleaning and care – Brew unit").

 Push the coffee ejector of the brew unit into the

correct position (see diagram).

 Push the waste container and the water container

back in the machine. Do not insert the brew unit. Close the door and switch the machine on with the On/Off sensor.

This will initialise the brew unit motor and put it back into the start position.

 When Insert the brew unit appears in the display,

open the door and refit all parts in the machine. Close the door.

If the brew unit cannot be removed:  Switch the machine off with the On/Off sensor.

Wait for approx.2minutes before switching it back on again.

There is a fault with the automatic spout adjustment.  Confirm the message with OK.

Automatic spout adjustment during drink preparation is deactivated as long as the appliance remains switched on. You can continue to prepare drinks.

Problem solving guide

Message Possible cause and remedy

F234 Cup protection switch-off has been activated three

times since switching on the coffee machine. The cups or glasses being used are not recognised by the automatic spout adjustment.

 Use suitable drinking vessels for automatic spout

adjustment.

There is a fault with the automatic spout adjustment.  Switch the machine off with the On/Off sensor.

Wait for approx.2minutes before switching it back on again.

Too much ground coffee There is too much ground coffee in the coffee chute.

If more than one level scoop of ground coffee is added to the coffee chute, the brew unit cannot process the coffee. The ground coffee will be directed into the waste container and the fault message will appear in the display.

 Switch the machine off with the On/Off sensor.  Remove and clean the brew unit (see "Cleaning

and care – Brew unit").

 Remove the ground coffee inside the coffee

machine, e.g. with a vacuum cleaner.

 Use the coffee spoon supplied to add ground

coffee to the ground coffee chute. Add only one portion of ground coffee to the chute.

Check water intake There is a problem with the mains water inlet.

 Check whether the inlet hose is kinked or the tap

is not turned on completely.

 Remove and empty the water container.  Push the water container back in the machine,

making sure it is positioned correctly.

Push the water container in until it engages

The water container is not in the correct position.  Remove the water container and push it back in

again.

This fault message also appears if the water container was not correctly filled and fitted for descaling.

 Fill the water container to the descaling symbol

and restart the descaling programme.

Problem solving guide

Unusual performance of the coffee machine

Problem Possible cause and remedy

The display remains dark when the coffee machine is switched on using the On/Off sensor.

The lighting remains off after the coffee machine is switched on.

The coffee machine switches off suddenly.

The coffee machine is switched on. The lighting switches off suddenly.

The sensors do not react to touch. The appliance cannot be operated.

The On/Off sensor was not touched for long enough.

 Touch the On/Off sensor for at least 3seconds.

The plug is not correctly inserted into the socket.  Insert the plug into the socket correctly.

The mains fuse has tripped because the coffee machine, mains voltage or another appliance is defective.

 Switch off at the wall socket and remove the plug.  Contact a qualified electrician or Miele.

The lighting has been switched off.  Switch the lighting on (see "Settings - Lighting").

The lamp needs to be replaced.  Call Miele.

The switch-off time programmed using the timer has been reached.

 If required, you can select a new switch-off time

(see "Settings - Timer").

The plug is not correctly inserted into the socket.  Insert the plug into the socket correctly.

The lighting switches off 10minutes after the coffee machine was last used.

There is a fault inside the appliance.  Open the appliance door.

The process currently running will be stopped.  Disconnect the electricity supply by switching off

at the wall socket and withdrawing the plug, or switching off the mains circuit breaker.

Problem solving guide

Problem Possible cause and remedy

The coffee machine does not switch itself on, although the Switch

on at setting has been

activated for the timer.

The display is hard to see or not able to be read.

Fill and replace the water container appears after

switching on even though the container is filled and fitted in the machine. The appliance does not rinse.

Empty the drip tray

appears in the display, even though the drip tray is empty.

The system lock has been activated.  You need to deactivate the system lock (see

"Settings - System lock").

A day of the week has not been selected.  Check the timer settings and change them if

required (see "Settings - Timer").

The machine was not used after being switched on automatically three times in succession.

 Switch the machine on and dispense a drink.

The display brightness has been set too low.  Change this setting (see "Settings").

The coffee machine needs descaling.  Switch the machine off with the On/Off sensor.

Wait approx.1hour.

 Then switch the machine on again. As soon as

Heat-up phase appears in the display,

touchMaintenance at the bottom right-hand corner and then select Descale.

 Descale the coffee machine. You may need to

repeat the descaling process.

The drip tray doesn't sit correctly in the appliance.  Push the drip tray all the way into the appliance.

The sensors on the drip tray are not working properly. The contacts are dirty.

 Clean the contacts and dry everything thoroughly

(see "Cleaning and care - Drip tray").

Problem solving guide

Problem Possible cause and remedy

The machine door will not close.

The door is difficult to open and close.

The coffee machine does not rinse itself when turned on.

The containers are not pushed all the way in.  Check the containers.

The door hinges are not correctly aligned.  Adjust the door hinges (see "Installation -

Adjusting the door hinges").

The cap on the central spout connector has either not been lubricated or is not lubricated sufficiently.

 Check the silicone cap for damage. If necessary,

replace it with the extra cap supplied.

 Lubricate the cap with the silicone grease

supplied.

Lubricate the cap on the central spout connector regularly once a month.

This is not a fault. If the coffee machine still has an operating temperature higher than 60°C, rinsing will not take place.

Problem solving guide

Problem Possible cause and remedy

When rinsing, no water or noticeably less water than usual runs out of the central spout. No coffee or noticeably less coffee than usual is dispensed from the central spout. The display and the noise when coffee is being made remain the same. There is noticeably more "coffee water" in the waste container.

Drink preparation has been cancelled.

The descaling programme was started by mistake.

The central spout is not fitted correctly.  Check whether the central spout has been

assembled as described (see "Cleaning and care – Central spout").

The cap is no longer securely fitted to the central spout connector (see "Guide to the appliance").

 Check the cap on the central spout connector.

Lubricate the cap with the silicone grease supplied.

The cap on the central spout connector is damaged or missing.

 Replace the cap with the extra cap supplied.  Lubricate the cap with the silicone grease

supplied.

There is a problem with the mains water inlet.  Check whether the inlet hose is kinked or the tap

is not turned on completely.

The water container has emptied during drink preparation, but Mains water - On is selected and the coffee machine is not connected to the mains water supply.

 Check the mains water connection settings (see

"Settings - Mains water").

If the water container or the milk flask becomes empty while a drink is being made, after the water container or the milk flask is filled and replaced the message Continue? will appear in the display. If you do not confirm with Yes within 5 minutes, the drink will be cancelled.

The descaling programme cannot be stopped once the OK sensor has been touched. Descaling must be continued through to completion. This is a safety precaution to make sure the machine is descaled correctly. This is important for the longevity and functional efficiency of your coffee machine.

 Descale the coffee machine (see "Descaling").

Problem solving guide

Problem Possible cause and remedy

Loud noises are heard during the descaling programme.

Please wait or Heat-up phase appears in the

display all the time. Drinks cannot be made.

The display lights up but the coffee machine does not heat up and no drinks are made.

The drinking vessel being used is repeatedly not recognised by the automatic spout adjustment. The central spout lowers until it touches the top of the cup or glass and cup protection switch-off is activated.

Cup protection switchoff does not work. The central spout lowers until it touches the top of the vessel and the cleaning container or another vessel gets caught between the central spout and the drip tray.

This is not a fault. These noises occur when water is flushed through the machine at a high pressure.

Mains water: On is probably selected and the coffee

machine has not been plumbed into the mains water supply.

 Fill the water container.  Then check the mains water setting (see "Settings

- Mains water").

The Demo mode of the coffee machine for Miele Centers or Chartered Agents has been activated.

 Deactivate the Demo mode (see "Settings - Demo

mode").

The container is unsuitable for the cup sensing system.

 Use cups or glasses that are suitable for automatic

spout adjustment.

There is a fault with the automatic spout adjustment.  Switch the machine off with the On/Off sensor.

Wait for approx.2minutes before switching it back on again.

 Use another drinking vessel and prepare a drink.  If cup protection switch-off is activated again or

the central spout lowers until it touches the top of the cup or glass again, please contact Miele.

If the cleaning container is sitting too close to the panel behind the central spout, or even touches it, the rim of the container will not be properly recognised by the automatic spout adjustment.

 Move the cleaning container forwards a little.

Problem solving guide

Unsatisfactory results

Problem Possible cause and remedy

The coffee is not hot enough.

The heating-up time is getting longer, the amount of water being dispensed is incorrect and the coffee machine is not performing properly.

Coffee is not being dispensed from both spouts evenly. Milk may be sputtering when being heated up.

The coffee grinder makes a louder noise than usual.

The coffee flows too quickly into the cup.

The cup has not been pre-heated. The smaller the cup and the thicker its walls, the more important it is to pre-heat it.

 Pre-heat the cup, for example, with hot water.

The brewing temperature has been set too low.  Set a higher brewing temperature (see "Brewing

temperature").

The filters in the brew unit are blocked.  Remove and clean the brew unit by hand (see

"Cleaning and care – Brew unit").

 Degrease the brew unit (see "Cleaning and care -

Brew unit").

The coffee machine needs descaling.  Descale the coffee machine.

Coffee deposits in the central spout are obstructing dispensing.

 Dismantle the central spout and clean the

components – with the exception of the stainless steel cover – in the dishwasher (see "Cleaning and care – Central spout"). The central spout should be cleaned once a week.

The coffee bean container has become empty during the grinding process.

 Fill the container with fresh beans.

There may be stones in amongst the coffee beans.  Switch the coffee machine off immediately. Call

Miele.

The coffee is too coarsely ground.  Set the grinder to a finer setting (see "Setting the

coffee grinder").

Problem solving guide

Problem Possible cause and remedy

The coffee trickles too slowly into the cup.

The crema on the coffee or espresso is not as it should be.

Problems when heating up or frothing milk

Problem Possible cause and remedy

The milk sputters when it is dispensed. Hissing noises can be heard when milk is being heated up or frothed. Although the milk should be frothed, only hot milk is dispensed from the central spout.

The coffee is too finely ground.  Set the grinder to a coarser setting (see "Setting

the coffee grinder").

The grinder setting is not correct.  Set the grinder to a finer or coarser setting (see

"Setting the coffee grinder").

The brewing temperature is too high for this type of coffee.

 Set a lower brewing temperature (see "Brewing

temperature").

The coffee beans are no longer fresh.  Add fresh coffee beans to the coffee bean

container.

The milk temperature is too high. Good milk froth can only be achieved when cold milk (<10°C) is used.

 Check the temperature in the milk flask.

The milk flask has not been fitted correctly and so air as well as milk is being sucked in.

 Push the milk flask in until it clicks into position.

The central spout is not fitted correctly.  Check whether the central spout has been

assembled correctly.

The milk pipework in the milk flask lid is dirty.  Dismantle the milk flask lid and clean it with the

cleaning brush (see "Cleaning and care – Milk flask").

 Clean the central spout and the milk valve with the

cleaning brush (see "Central spout" and "Maintenance of the milk valve").

The angled connector is blocked and must be replaced.

 Replace the angled connector (see "Replacing the

angled connector").

Problem solving guide

Problem Possible cause and remedy

Fill and insert milk flask

appears in the display even though the milk flask has been filled and inserted in the machine.

The milk flask lid could be dirty. Therefore, the sensing mechanism doesn't function correctly.

 Clean the milk flask lid and the milk flask

thoroughly. Dismantle the lid and clean it with the cleaning brush supplied (see "Cleaning and care – Milk flask and lid").

Problem solving guide

Replacing the angled connector

If, instead of being frothed, the milk is only being heated up, check the following first:

– Is the milk in the milk flask cold

(<10°C)?

– Have the central spout and the milk

flask lid been cleaned carefully?

– Is the central spout correctly fitted?

If after checking the above, milk still cannot be frothed, replace the angled connector as follows.

You will need the replacement angled connector supplied with the coffee machine.

Do not use a needle or similar implement. This would damage the components.

 First pull the air intake tube out of

the opening. Then pull off the elbow connector.

 Pull both tubes out of the elbow

connector.

 Clean the air intake tube under

running water with the cleaning brush supplied. "Blowing through" can help to dislodge blockages.

 Insert the brush in the milk tube.

Move the brush back and forth as far as possible until all milk residues have been removed.

 Open the service flap on the back of

the appliance door.

 Take the new angled connector (You

can dispose of the old angled connector with normal household waste).

 Push the tubes onto the angled

connector and fit it in the coffee machine. Make sure that the crosspiece on the angled connector is facing downwards.

 Re-insert the air intake tube in the

opening.

 Replace the service flap and close

the door.

Problem solving guide

After sales service and warranty

After sales service

In the event of a fault which you cannot correct yourself, please contact Miele.

The contact details for Miele are given at the back of these instructions.

When contacting Miele, please quote the model and serial number of your coffee machine. These are visible on the data plate inside the machine.

Warranty

This appliance has a manufacturer's warranty period of 2 years.

For further information, please refer to your warranty booklet.

If the settings of the following functions are altered from the factory default, energy consumption will increase:

– Eco mode

– Lighting

– Time of day display

– Timer

Saving energy

Mains water connection

Notes on connecting to the mains water supply

Connection to the mains water supply should only be carried out by a qualified and competent person in accordance with national and local regulations.

Before plumbing the appliance in, ensure that it is disconnected from the mains electricity supply.

Turn off the water supply at the tap before connecting the water intake hose to the coffee machine.

IMPORTANT Australia and New Zealand. This appliance must be installed according to AS/NZS 3500.1 and AS/NZS 3500.2. Backflow prevention is already integrated in the appliance.

The water quality must conform to the requirements for drinking water in the country in which the appliance is being installed.

This appliance meets the requirements of IEC 61770 and ATS 5200.105.

All devices used for connecting the appliance to the mains water supply must comply with the current national and local safety regulations in the country in which the appliance is being installed.

The machine is only suitable for connection to a cold water line that

– is directly connected to the fresh

water mains in order to ensure sufficient circulation and therefore good water quality.

Avoid connection to a water supply in which the water might stagnate. This will affect the taste of drinks prepared with the coffee machine.

– The machine is constructed to

comply with the relevant DIN standard and may be connected to the mains drinking water supply without a non-return valve if national regulations permit.

– The water inlet must be able to

withstand the required operating pressure.

– The water flow pressure needs to be

between 1 and 10 bar (105 and 10 Pa).

– The stainless steel hose supplied is

1.5m long. The hose may not be lengthened as too much water would then remain in the hose, adversely affecting the quality of the coffee.

– National and local hygiene

regulations must be complied with.

– A tap must be provided between the

stainless steel hose and the household water supply to ensure that the water supply can be cut off if necessary.

The tap should be easily accessible after the machine has been built in.

Mains water connection

If the stainless steel hose supplied is damaged, it must only be replaced with an original Miele replacement hose, available from Miele or at www.miele-shop.com (depending on country). Make sure the hose is suitable for carrying drinking water.

Fitting the stainless steel hose to the appliance

Make sure that the stainless steel hose is not kinked or damaged. The stainless steel hose must not be shortened.

 Remove the cover cap from the

bottom of the back panel of the machine.

 Take the angled end of the stainless

steel hose and check whether there is a washer. Fit one, if not.

 Screw the stainless steel hose

coupling nut onto the threaded union.

 Ensure that all connections are water

tight.

Connection to the water inlet

Before making plumbing connections, ensure the appliance is disconnected from the mains electricity supply.

Connection to the water supply should be carried out by a qualified plumber and should incorporate a tap with a 3/4" thread.

 Check that the filter/sealing ring is

present. The filter/sealing ring must be present before connecting the hose to the tap.

 Connect the stainless steel hose to

the tap.

Use the stainless steel hose supplied with the machine. Old or used hoses must not be connected to the coffee machine.

 Ensure that it is screwed into position

correctly.

 The connection point is subject to

mains water pressure. Turn on the tap slowly and check for leaks. Correct the position of the seal and union if necessary.

You can now continue with the installation of the coffee machine in its furniture unit (see "Installation").

Electrical connection

Before connecting the appliance to the mains supply, make sure that the connection data on the data plate corresponds to the voltage and frequency of the household supply. This data must correspond in order to avoid the risk of damage to the appliance. Consult a qualified electrician if in any doubt.

The necessary connection information is given on the data plate inside your appliance.

Danger of injury! All electrical work should be undertaken by a suitably qualified and competent person. Installation, repairs and other work by unqualified persons could be dangerous. Miele cannot be held liable for unauthorised work. Ensure power is not supplied to the appliance until after installation or repair work has been carried out. The appliance is supplied with a mains connection cable and plug for connection to AC50Hz, 230V.

in the system can cause the safety switch off mechanism to be triggered. This can damage the electronic unit.

The machine must not be used with socalled energy saving plugs either. These reduce the amount of energy supplied to the machine causing it to overheat.

The fuse rating must be at least 16A.

Connection should be made via a fused plug and suitable switched socket which is easily accessible after installation. If the mains socket is not accessible after the appliance has been built in, a separator for each terminal must be present. There must be an allpole contact gap of at least 3mm in the switch (including switch, fuses and relays according to EN60335).

Do not connect the machine to an inverter such as those used with an autonomous energy source e.g. Solar power. When switched on, peak loads

Building-in and combination options

The appliance is designed to be built into a tall unit.

Installation

It can also be combined with other Miele built-in appliances. If the coffee machine is to be built in above another appliance, there must be a full-width, closed shelf between them. Exception: When built in above a warming drawer.

You can connect the warming drawer directly to the coffee machine with a special connection cable (optional accessory). This enables the warming drawer to be switched on at the same time as the coffee machine.

Only connect a Miele warming drawer to the coffee machine. You can find out the suitable warming drawers for this coffee machine by contacting Miele.

Installation

Ventilation

Condensate can damage the coffee machine or the housing unit.

The ventilation gaps given must be observed.

Do not cover or block the ventilation gaps.

Dust the ventilation gaps regularly.

Steam which is created when water is heated up can condense on the interior and the inside of the front of the coffee machine.

During installation, ensure there is sufficient ventilation at the rear of the appliance so that steam and warm air are able to escape without hindrance.

The housing unit should be configured as follows:

– A ventilation gap of at least 40mm

depth must be allowed for behind the appliance for air to circulate.

– The ventilation cross-sections in the

plinth, housing unit and above the appliance must amount to at least

200cm2 to ensure that air can circulate without hindrance.

Top ventilation cross-section

The top ventilation cross-section can be achieved in various ways:

– Air intake  occurs via the plinth at

the bottom of the machine and the air escapes at the top  at the rear of the housing unit.

directly above the coffee machine with a ventilation grille (free air flow

of at least 200cm2)

in between the housing unit and the ceiling

through a suspended ceiling.

Installation

Building in the coffee machine

Before installation make sure that there is no power supply to the machine. This also applies should it ever need to be taken out of its housing unit.

The machine may only be operated when built-in and in an ambient temperature range between +10°C to +38°C.

You will need two Allen keys (size 3 and 5) for installing the machine.

To align the machine front with the furniture front, ensure that there is a sealing strip provided all the way around the building-in niche or around the coffee machine.

Useful tip: Tip: We recommend providing a place to sit the coffee machine which is the same height as the building-in niche. This will make it easier to connect the machine to the electricity supply and the water inlet.

 Using the large allen key, unscrew all

four feet out by about 2mm.

The feet can be unscrewed by up to approx. 10mm.

 Connect the appliance to the water

inlet hose (see "Mains water connection").

 If the housing unit niche is not fitted

with a sealing strip, you should fit a Miele sealing strip to the machine before installing it. This is fitted from the back of the machine.

The sealing strip is available to order from Miele.

 Connect the appliance to the

electricity supply.

Take care not to damage the electrical connection or the plumbing connection when pushing the coffee machine into the niche.

 Push the coffee machine all the way

into the building-in niche.

 Check the height of the coffee

machine to make sure that it is sitting centrally in the niche and that it is level. If this is not the case, realign the machine using the four feet.

Installation

The appliance comes with four M5 socket screws to help you align and secure it in the building-in niche.

 Open the appliance door, and

partially tighten the side socket screws.

 Carefully turn the lower socket

screws to centre the machine in the niche.

 Tighten both upper socket screws by

hand to secure the machine in the unit. Do not overtighten them.

Adjusting the door hinges

If the appliance door becomes difficult to open or close after installation, you can adjust the hinges to realign it (TX20):

 Tighten the screw to align it flush

with the furniture front.

 Tighten the screw to align the door

horizontally and vertically.

100

Miele CVA6805G, CVA6805B Installation and Operation Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Warning and Safety instructions

Correct application

Safety with children

Technical safety

Mains water connection

Correct use

Cleaning and care

The following applies to appliances with stainless steel surfaces:

Exterior view

Guide to the appliance

Interior view

Accessories

Accessories supplied

Optional accessories

Operating principles

Touch display

Operating actions

Selecting or calling up a menu

Scrolling through menus

Entering numbers

Entering letters

Help

Symbols in the display

Using for the first time

Before using for the first time

Switching on for the first time

Setting the language

Setting the date

Setting the time of day

Display

Water hardness

Measuring water hardness

Setting the water hardness level

Filling the water container

Filling the coffee bean container

Switching the coffee machine on and off

Switching on

Switching off

Switching off for longer periods of time

Switching the spout adjustment on and off

Spout adjustment

Making drinks

Making a coffee drink

Dispensing a double portion

Cancelling preparation

Preparing several cups of coffee - Coffee pot

You can interrupt preparation at any time:

Drinks made with ready ground coffee

Adding ready ground coffee

Making drinks with ready ground coffee

If you do not want to use ground coffee to make the drink:

Drinks with milk

Notes on the milk flask

Preparing drinks with milk

Preparing hot water

Preparing User profile drinks

After a drink has been prepared

Coffee the way you like it

Grinder setting

Changing the parameters of a drink

Amount of coffee

Brewing temperature

Pre-brewing ground coffee

Portion size

Resetting drink settings

User profiles

Calling up User profiles

Creating a User profile

Selecting a User profile

Changing a name

Deleting a profile

Changing a User profile

User profiles: Creating and editing your own drinks

Creating a drink

Changing a drink: Changing the portion sizes, drinks parameters and names

Deleting drink
