Miele CS 1421 Operating instructions

Operating and installation instructions
Salamander

To avoid the risk of accidents or damage to the appliance it is essential
to read these instructions before it is installed and used for the first time.

en-GB M.-Nr. 07 180 450

Contents

Warning and Safety instructions.......................................................................... 4

Caring for the environment ................................................................................ 13

Guide to the appliance........................................................................................ 14

Salamander ........................................................................................................... 14

Indicators............................................................................................................... 14

Using for the first time ........................................................................................ 15

Cleaning the CombiSet for the first time ............................................................... 15

Switching on the CombiSet for the first time ........................................................ 15

Operation.............................................................................................................. 16

Raising and lowering the browning unit ................................................................ 16

Switching on.......................................................................................................... 16

Switching off.......................................................................................................... 16

Residual heat indicator.......................................................................................... 16

To brown or crisp food .......................................................................................... 17

Keeping warm ....................................................................................................... 17

After use ................................................................................................................ 18

Safety features..................................................................................................... 19

Thermal retraction stop sensor ............................................................................. 19

Height recognition ................................................................................................. 19

Overheating protection.......................................................................................... 19

Obstruction sensor................................................................................................ 19

Cleaning and care ............................................................................................... 20

Stainless steel ....................................................................................................... 21

Operating controls................................................................................................. 21

Standing surface ................................................................................................... 21

Trough.................................................................................................................... 21

Ceramic surface of the browning unit ................................................................... 22

Problem solving guide ........................................................................................23

Optional accessories ..........................................................................................25

Safety instructions for installation..................................................................... 26

Safety distances .................................................................................................. 27

Installation notes ................................................................................................. 29

Building-in dimensions ......................................................................................30

2

Contents

Installation............................................................................................................ 31

Building-in several CombiSets........................................................................... 35

Electrical connection ..........................................................................................37

After sales service, data plate, guarantee ........................................................39

3

Warning and Safety instructions

This salamander complies with all relevant safety requirements. In­appropriate use can, however, lead to personal injury and damage
to property.

To avoid the risk of accidents and damage to the salamander,
please read these instructions carefully before installation and be­fore using it for the first time. They contain important notes on in­stallation, safety, use and maintenance.
Miele cannot be held liable for damage caused by non-compliance
with these instructions.

Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.

4

Warning and Safety instructions

Correct application

 This salamander is designed for domestic use and for use in sim-

ilar environments.

 This salamander is not intended for outdoor use.
 This salamander is intended for domestic use only to cook food

and keep it warm. Any other use is not supported by the manufac­turer and could be dangerous.

 This salamander can only be used by people with reduced phys-

ical, sensory or mental capabilities or lack of experience and know­ledge if they are supervised whilst using it. They may only use it un­supervised if they have been shown how to use it in a safe way and
understand the hazards involved.

5

Warning and Safety instructions

Safety with children

 Children under 8 years of age must be kept away from the sala-

mander unless they are constantly supervised.

 Children 8 years and older may only use the salamander unsuper-

vised if they have been shown how to use it safely and recognise
and understand the consequences of incorrect operation.

 Children must not be allowed to clean the salamander unsuper-

vised.

 Please supervise children in the vicinity of the salamander and do

not let them play with it.

 The salamander gets hot when in use and remains hot for a while

after being switched off. Keep children well away from the appliance
until it has cooled down and there is no danger of burning.

 Danger of burning.

Do not store anything which might arouse a child's interest in stor­age areas above or next to the salamander. Otherwise they could be
tempted into climbing onto the appliance.

 Danger of burning and scalding.

Take care that children are not able to pull hot dishes down onto
themselves from the appliance.

 Danger of suffocation. Packaging, e.g. plastic wrappings, must be

kept out of the reach of babies and children. Whilst playing, children
could become entangled in packaging or pull it over their head and
suffocate.

 The heating element in the browning unit glows very brightly. Do

not allow children to look directly at the heating element

6

Warning and Safety instructions

Technical safety

 Unauthorised installation, maintenance and repairs can cause

considerable danger for the user. Installation, maintenance and re­pairs must only be carried out by a Miele authorised technician.

 A damaged salamander can be dangerous. Check it for visible

signs of damage. Do not use a damaged appliance.

 Reliable and safe operation of the salamander can only be as-

sured if it has been connected to the mains electrical supply.

 The electrical safety of this salamander can only be guaranteed

when correctly earthed. It is essential that this standard safety re­quirement is met. If in any doubt please have the electrical installa­tion tested by a qualified electrician.

 Before connecting the salamander to the mains supply, ensure

that the connection data on the data plate (voltage and frequency)
match the mains electricity supply.
This data must be checked before connecting the appliance. Consult
a qualified electrician if in any doubt.

 Do not connect the salamander to the mains electricity supply by

a multi-socket unit or an extension lead. These do not guarantee the
required safety of the appliance (fire hazard).

 For safety reasons, this salamander may only be used after it has

been built in.

 This salamander must not be used in a non-stationary location

(e.g. on a ship).

 Never open the casing of the salamander.

Touching or tampering with electrical connections or components
and mechanical parts is highly dangerous to the user and can cause
operational faults.

7

Warning and Safety instructions

 While the salamander is under guarantee, repairs should only be

undertaken by a Miele authorised service technician. Otherwise the
guarantee is invalidated.

 Miele can only guarantee the safety of the appliance when genu-

ine original Miele replacement parts are used. Faulty components
must only be replaced by Miele spare parts.

 The salamander is not intended for use with an external timer

switch or a remote control system.

 If the plug is removed from the connection cable or if the cable is

supplied without a plug, the salamander must be connected to the
electrical supply by a suitably qualified electrician.

 If the connection cable is damaged, it must be replaced by a suit-

ably qualified electrician with a special connection cable of type H
05 VV-F (pvc insulated). See "Electrical connection".

 During installation, maintenance and repair work, the salamander

must be completely disconnected from the mains electricity supply.
Depending on country this is done in one of several different ways:

– disconnect the mains fuse, or

– completely unscrew the screw-out fuse (in countries where this is

applicable), or

– switch off at the wall socket and withdraw the plug from the

socket. Pull by the plug and not by the mains connection cable to
disconnect from the mains electricity supply.

 Danger of electric shock.

Do not use the salamander if it is faulty. Switch it off immediately,
disconnect it from the mains electricity supply and contact Miele.

8

Warning and Safety instructions

 If the salamander is installed behind a furniture panel (e.g. a door),

ensure that the door is never closed whilst the salamander is in use.
Heat and moisture can build up behind a closed furniture panel and
cause subsequent damage to the salamander, the housing unit and
the floor. Do not close the door until the residual heat indicators have
gone out.

9

Warning and Safety instructions

Correct use

 The salamander gets hot when in use and remains hot for some

time after being switched off. The risk of burning is present until the
residual heat indicators have gone out.

 Do not use the salamander to heat up the room.

Due to the high temperatures radiated, objects left near the salaman­der could catch fire.

 Overheated fat and oil can ignite and catch fire. Never leave the

salamander unattended. Do not attempt to extinguish burning oil or
fat with water.
Switch the appliance off and carefully smother the flames with a fire
blanket or a damp tea towel

 Do not heat up food in closed containers e.g. tins or sealed jars

on the salamander, as pressure will build up in the container which
could cause it to explode.

 When the salamander is switched on either deliberately or by mis-

take, or when there is residual heat present, there is the risk of any
metal items left on the salamander heating up, with the danger of
burning. Depending on the material, other items left on the appliance
could also melt or catch fire. Do not use the salamander as a resting
place. Switch the salamander off after use.

 You could burn yourself on the hot salamander. Protect your

hands with heat-resistant pot holders or gloves when handling hot
pots and pans. Do not let them get wet or damp, as this causes heat
to transfer through the material more quickly with the risk of scalding
or burning yourself.

 When using an electrical appliance, e.g. a hand-held food blender,

near the salamander, ensure that the cable of the electrical appliance
cannot come into contact with the hot salamander. The insulation on
the cable could become damaged.

10

Warning and Safety instructions

 Salt, sugar and grains of sand, e.g. from cleaning vegetables, can

scratch the surface. Keep surfaces clean at all times.

 Rough bases will scratch the ceramic surface. Only use dishes

with smooth bases. Lift dishes to move them to prevent the risk of
scratches and marks on the surface.

 Plastic dishes melt at high temperatures. Use heat-resistant

crockery made from porcelain or glass.

 To prevent the risk of scratches to the surface of the browning

unit, do not place items on it.

 Where several CombiSets are installed side by side:

Hot objects can damage the seal of the cover strip between the ap­pliances. Do not place hot pans near or on the cover strip.

11

Warning and Safety instructions

Cleaning and care

 Do not use a steam cleaning appliance to clean this salamander.

The steam could reach electrical components and cause a short cir­cuit.

12

Caring for the environment

Disposal of the packing mater­ial

The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.

Recycling the packaging reduces the
use of raw materials in the manufactur­ing process and also reduces the
amount of waste in landfill sites.

Disposing of your old appli­ance

Electrical and electronic appliances of­ten contain valuable materials. They
also contain specific materials, com­pounds and components, which were
essential for their correct function and
safety. These could be hazardous to hu­man health and to the environment if
disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.

Please dispose of it at your local com­munity waste collection / recycling
centre for electrical and electronic ap­pliances, or contact your dealer or
Miele for advice. You are also respons­ible by law for deleting any personal
data that may be stored on the appli­ance being disposed of. Please ensure
that your old appliance poses no risk to
children while being stored prior to dis­posal.

13

Guide to the appliance

Salamander

a

Browning unit, motor driven

b

Standing surface, removable

c

Indicators

Indicators

f

In-operation indicator

g

Residual heat indicator

14

Control knobs:

d

For setting the power level

e

For setting the height of the browning
unit

Using for the first time

 Please stick the extra data plate for

the appliance supplied with this doc­umentation in the space provided in
the "After sales service, data plate,
guarantee" section of this booklet.

 Remove any protective wrapping and

stickers.

Cleaning the CombiSet for the first time

 Wipe all surfaces with a damp cloth

and then dry them.

Switching on the CombiSet for the first time

The metal components have a protect­ive coating which when heated for the
first time will give off a slight smell and
possibly some vapours.

The smell and any vapours given off do
not indicate a faulty connection or ap­pliance and they are not hazardous to
health.

15

Operation

Raising and lowering the browning unit

Raising the unit

 To raise the browning unit, turn the

left-hand control to .

The browning unit will extend up to its
full height, even if you release the con­trol knob back to the  symbol.
You can select any height you wish for
the browning unit by turning the con­trol briefly to.

The salamander only heats up when
the browning unit is raised to at least
70 mm.

Lowering the unit

 To lower the browning unit, turn the

left-hand control to  and hold it un­til the browning unit is at the required
height or until it is fully lowered.

Do not lower the browning unit com­pletely until the residual heat indicator
has gone out.

Switching on

 Fire hazard.

Do not leave the salamander unat­tended whilst it is being used.

 Turn the right hand control clockwise

or anti-clockwise to the required
power level.

The in-operation indicator will light up.
The residual heat indicator will light up
after a certain temperature has been
reached.

Switching off

 Turn the right hand control clockwise

or anti-clockwise to 0.

Residual heat indicator

The residual heat indicator will light up
when the browning element is switched
off if the ceramic plate in the browning
element is still hot. The residual heat in­dicator will not go out until the ceramic
plate in the browning element is cool
enough to touch.

16

 Danger of burning! Do not touch

the ceramic plate while the residual
heat indicator is on.

Operation

To brown or crisp food

 Raise the browning unit.
 Place the dish containing food to be

browned on the standing surface.

 Lower the browning unit until the dis-

tance between the food and the heat­ing element is approx. 3-5 cm.

 Turn the control to setting 12. Make

sure that the marker on the control is
pointing to the 12.
Gratinating takes between 3-5
minutes depending on the level of
browning required.

Only one dish of food can be browned
at a time.

Tip: The salamander is perfect for
browning and crisping food topped with
cheese (e.g. meat and pasta dishes,
croque monsieur, vegetable gratin) and
caramelised sweet dishes such as
crème brûlée.

Keeping warm

The salamander is not suitable for re­heating cold food.
Hot food can be kept warm for a few
minutes after it has been cooked.

 Raise the browning unit.
 Place the dish containing food to be

browned on the standing surface.

 Lower the browning unit until the dis-

tance between the food and the heat­ing element is approx. 10 cm.

 Turn the control to a medium setting.

17

Operation

After use

 Switch the salamander off.
 Clean the salamander after each use

while it is still warm to the touch (see
"Cleaning and care").

 Do not lower the browning unit until

the residual heat indicator has gone
out.

The salamander is not switched off
until the browning unit has been
completely retracted.

18

Safety features

Thermal retraction stop sensor

Your salamander is fitted with a thermal
retraction stop sensor to prevent dam­age to the appliance when lowering the
browning unit. This ensures that the
browning unit can only be fully lowered
once the appliance has cooled down
sufficiently, i.e. once the residual heat
indicator has gone out.

Height recognition

The salamander only heats up when the
browning unit is raised to at least 70
mm.

Overheating protection

The halogen heating element in the
browning unit is fitted with overheating
protection. This switches off the heating
element automatically before the
ceramic surface overheats. Once the
ceramic surface has cooled down to a
safe level, the heating element will auto­matically switch back on again. You can
tell that the overheating protection has
activated because the heating switches
on and off even when the highest set­ting is selected.

Obstruction sensor

If the browning unit meets an obstruc­tion (e.g. a dish) whilst it is being
lowered, it stops immediately and rises
again by approx. 10 mm.

19

Cleaning and care

 Danger of burning.

Before cleaning the salamander
make sure that you have switched it
off and that it has cooled down.

 Danger of injury.

The steam from a steam cleaning ap­pliance could reach electrical com­ponents and cause a short circuit.

Do not use a steam cleaner to clean
the salamander.

The use of unsuitable cleaning
agents can cause the surfaces to
discolour or alter.

All surfaces are susceptible to
scratching.

Remove any residual cleaning agent
immediately.

Allow the CombiSet to cool down
before cleaning.

 The CombiSet and accessories

should be cleaned after each use.

 Dry the CombiSet after using water to

clean it. This helps prevent limescale
deposits.

Unsuitable cleaning agents

To avoid damaging the surfaces, do not
use:

– cleaning agents containing soda, am-

monia, acids or chlorides

– cleaning agents containing descaling

agents

– stain or rust removers

– abrasive cleaning agents, e.g.

powder cleaners and cream cleaners

– solvent-based cleaning agents

– dishwasher cleaner

20

– grill and oven cleaners

– glass cleaning agents

– hard, abrasive brushes or sponges,

e.g. pot scourers, brushes or
sponges which have been previously
used with abrasive cleaning agents

– melamine eraser blocks

Cleaning and care

Stainless steel

 Clean the control panel and all stain-

less steel surfaces with a solution of
warm water and a little washing-up li­quid applied with a soft sponge.

You can also use a ceramic and stain­less steel cleaning agent. We recom­mend also using a stainless steel condi­tioning agent to help prevent resoiling
(see "Optional accessories).

Do not use ceramic and stainless
steel cleaner or stainless steel condi­tioning agent on the printing.

This would rub the printing off.
These areas should be only cleaned

with a solution of warm water and a
little washing-up liquid applied with a
soft sponge.

Operating controls

 Clean the control(s) with a solution of

warm water and a little washing-up li­quid applied with a soft sponge.
Stubborn soiling should be soaked
first.

 Dry the control(s) with a clean cloth.

Standing surface

 Clean standing surfaces with a solu-

tion of warm water and a little wash­ing-up liquid applied with a soft
sponge. In the case of stubborn
dried-on soiling, soak first.Finally, dry
with a soft cloth.

The standing surface must not be
cleaned in a dishwasher.

The standing surface can be taken out
in order to clean the standing surface
and the trough beneath it.
When replacing the standing surface
make sure it goes back in correctly. If
it is not correctly positioned you will
not be able to lower the browning ele­ment completely.

Trough

 Clean the trough regularly. Remove

any food deposits or liquid immedi­ately. Clean the trough with warm wa­ter and a little washing-up liquid ap­plied with a soft sponge. Dry thor­oughly with a soft cloth.

21

Cleaning and care

Ceramic surface of the brown­ing unit

 Remove coarse soiling with a damp

cloth.

 Then clean the surface with a suitable

ceramic and stainless steel hob
cleaner (see "Optional accessories")
applied with paper towel or a clean
cloth.
Do not apply cleaner whilst the sur­face is still hot, as this could result in
marking. Please follow the cleaning
agent manufacturer's instructions.

Do not use washing-up liquid on the
browning unit ceramic surface.

 Finally, wipe the surface with a damp

cloth, then polish dry with a clean,
soft cloth. Ensure that all cleaning
agent residues are removed.
Residues can burn onto the surface
the next time it is heated up and
cause damage.

22

Problem solving guide

With the aid of the following guide, minor problems can be easily corrected
without contacting Miele.
If having followed the suggestions below, you still cannot resolve the problem,
please contact Miele (see end of this booklet for contact details).

 Danger of injury. Installation, maintenance and repairs may only be carried

out by a suitably qualified and competent person.
Repairs and other work by unqualified persons could be dangerous. Miele can­not be held liable for unauthorised work.
Do not attempt to open the casing of the CombiSet yourself.

Problem Cause and remedy

You cannot raise the
browning unit.

The salamander does
not heat up

The heating element is
switching on and off.

When setting '12' is se­lected, the appliance
does not become hot
enough for the food to
start browning

Food deposits have hardened or something has be­come stuck in the gap around the browning unit.

 Clean the browning unit.

The mains fuse has tripped.
 If it has, contact a qualified electrician or Miele

Service.

The browning unit is not in the correct position.
 Check that the browning unit is raised sufficiently.

It must be raised by at least 70 mm.

 Make sure the standing surface has been inserted

and is positioned correctly.

There was an interruption to the power supply during
operation, and the heating has switched itself off.

 To operate the appliance again, turn the control

"0".
Lower the browning unit fully.

This takting is quite normal and does not indicate in­correct operation or a fault with the appliance.

The appliance operates at a lower power level when
the control is positioned between the "12" and the
"0".

 Check that the mark on the control is exactly posi-

tioned at the "12".

23

Problem solving guide

Problem Cause and remedy

The browning unit can­not be lowered.

Every time the browning
unit is lowered it rises
again slightly after­wards.

The browning unit has not cooled down sufficiently.
 The residual heat indicator must have gone out.

The standing surface has not been positioned cor­rectly.

 Reposition it correctly.

There is an object between the browning unit and the
standing surface.

 Check whether there is an object between the

browning unit and the standing surface (see
"Safety features / Obstruction sensor").

24

Optional accessories

Miele offer a comprehensive range of
useful accessories as well as cleaning
and conditioning products for your
Miele appliances.

These products can be ordered through
the Miele Webshop.

These can also be ordered from Miele
(see end of this booklet for contact de­tails) or from your Miele dealer.

Ceramic and stainless steel hob cleaner 250 ml

Removes heavy soiling, limescale de­posits and aluminium residues

Stainless steel conditioning
agent 250ml

Removes water marks, flecks and finger
prints. Helps keep the appliance looking
good for longer.

Microfibre cloth

Removes finger marks and light soiling

25

Safety instructions for installation

Fit the wall units and cooker hood before fitting the CombiSet to avoid dam­aging it.

 The veneer or laminate coatings of worktops (or adjacent kitchen

units) must be treated with 100°C heat-resistant adhesive which will
not dissolve or distort. Any backmoulds must be of heat-resistant
material.

 The Salamander must not be installed directly next to a grill

(CS1312/CS1322) or a Tepanyaki (CS1326/CS1327). It is essential
to maintain a distance of at least 150 mm between these two appli­ances.

 When installing the CombiSet, make sure that the connection

cable cannot come into contact with hot appliance parts.

 The electrical cable of the CombiSet must not come into contact

with any moving kitchen component (e.g. a drawer) or be subject to
any mechanical action which could damage it.

 Observe carefully the safety clearances listed on the following

pages.

All dimensions are given in mm.

26

Safety distance above the CombiSet

A minimum safety distance must be
maintained between the CombiSet and
the cooker hood above it. See the
cooker hood manufacturer's operating
and installation instructions for details.
If the manufacturer's instructions are
not available for the cooker hood a min­imum safety distance of at least
760mm must be maintained, or if any
flammable objects (e.g. utensil rails,
wall units etc) are installed above the
CombiSet, a minimum safety distance
of at least 760mm must be maintained
between them and the CombiSet be­low.

Safety distances

When two or more CombiSets which
have different safety distances are
installed together below a cooker
hood, you should observe the
greatest safety distance.

27

Safety distances

Safety distances to the sides and back of the hob

The CombiSet may be installed with a
wall at the rear and a tall unit or wall to
one side (right or left) (see illustrations).

Minimum distance between the back
of the worktop cut-out and the rear
edge of the worktop:
50mm

Minimum distance between the
worktop cut-out and a tall unit or wall to
the right or left of it:

40 mm CS 1212 / CS 1212-1

CS 1221 / CS 1221-1
CS 1234 / CS 1234-1
CS 1223
CS 1222

50 mm CS 1112

CS 1122
CS 1134
CS 1326
CS 1327
CS 1411

Not allowed

Recommended

100 mm CS 1012 / CS 1012-1

150 mm CS 1421

CS 1312
CS 1322

200 mm CS 1034 / CS 1034-1

250 mm CS 1011 / CS 1021

28

Not recommended

Not recommended

Installation notes

Seal between the CombiSet and the worktop

Do not use sealant between the
CombiSet and the worktop. This
could result in damage to the
CombiSet or the worktop if the
CombiSet ever needs to be removed
for servicing.
The sealing strip under the edge of
the top part of the appliance
provides a sufficient seal for the
worktop.

Tiled worktop

Grout lines and the hatched area un­derneath the CombiSet frame must be
smooth and even. If they are not the
CombiSet will not sit flush with the
worktop and the sealing strip under­neath the top part of the appliance will
not provide a good seal between the
appliance and the worktop.

29

Building-in dimensions

a

Spring clamps

b

Front

c

Casing depth

d

Casing depth including mains connection box with mains connection cable, L =
2000 mm

e

Browning unit, height-adjustable

30

Preparing the worktop

 Make the worktop cut-out as shown

in "Building-in dimensions" or as cal­culated (see Building-in several
CombiSets). Observe the safety dis­tances (see "Safety distances").

Wooden worktops

 Seal the cut surfaces with a suitable

sealant to avoid swelling caused by
moisture. The sealant must be heat­resistant.

Make sure that the sealant does not
come into contact with the top of the
worktop.

Installation

 Position the spring clamps and

spacer bars on or at the top edge
of the cut-out in the positions shown.

 Secure the spring clamps and

spacer bars with the 3.5x25 mm
wood screws supplied.

31

Installation

Natural stone worktops

You will need heavy duty double-side
tape (not supplied) to secure the
spring clamps and spacer bars.

 Stick the tape to the top edge of

the cut-out in the positions shown in
the diagram.

 Position the spring clamps and

spacer bars on or at the top edge
of the cut-out and press them firmly
into place.

32

 Apply silicone to the side and lower

edges of the spring clamps and
the spacer bars.

 Then fill gap between spacer

bar and the worktop with silicone.

Installation

Installing the CombiSet

 Feed the mains connection cable

down through the cut-out.

 Starting at the front, position the

CombiSet in the worktop cut-out.

 Using both hands, press down evenly

on the edges of the CombiSet until it
clicks into position. When doing this
make sure that the seal underneath
the appliance sits flush with the work­top. This is important to ensure an ef­fective seal with the worktop.

Do not use sealant (e.g. silicone).

If the seal does not meet the worktop
correctly on the corners, the corner ra­dius (≤R4) can be carefully scribed to
suit.

Building in several CombiSets

 Push the built-in CombiSet to the

side until the holes in the spacer bar
can be seen.

 Fit cover strip  into the holes in

spacer bar .

 Starting at the front, position the next

CombiSet in the worktop cut-out.

 Proceed as described previously.

33

Installation

Connecting the CombiSet

 Connect the CombiSet(s) to the

mains.

 Check that each CombiSet works.

Removing the CombiSet

If the CombiSet cannot be accessed
from below, you will need a special
tool to remove it.

 If the CombiSet can be accessed

from below, push it out from below.
Push the rear side out first.

34

Example: 3 CombiSets

Building-in several CombiSets

a

Spring clamps

b

Spacer bars

c

Gaps between spacer bars and worktop

d

Cover strips

e

CombiSet width minus 8 mm

f

CombiSet width

g

CombiSet width minus 8 mm

h

Worktop cut-out

35

Building-in several CombiSets

Calculating the worktop cut-out

The frames of the CombiSets overlap the worktop at the outside right and left by
8mm on each side.

 Add up the widths of the CombiSets and subtract 16mm from this figure.

Example:
288 mm + 288 mm + 380 mm = 956 mm - 16 mm = 940 mm

The CombiSets are 288mm, 380mm or 576mm wide depending on model (see
"Building-in dimensions").

Spacer bars

When building-in several CombiSets a spacer bar must be fitted between each
CombiSet. The position for securing the spacer bar will depend on the width of the
CombiSet.

36

Electrical connection

All electrical work should be carried out
by a suitably qualified and competent
person in strict accordance with current
local and national safety regulations
(e.g. BS 7671 in the UK). Connection
should be made via a switched socket.
This will make it easier for service tech­nicians should the appliance need to be
repaired. The electrical socket must be
easily accessible after installation.

 Danger of injury.

Miele cannot be held liable for unau­thorised installation, maintenance
and repair work as this can be dan­gerous to users.
Miele cannot be held liable for dam­age or injury caused by incorrect in­stallation, maintenance or repair
work, or by an inadequate or faulty
earthing system (e.g. electric shock).

If the plug is removed from the con­nection cable or if the cable is sup­plied without a plug, the appliance
must be connected to the electrical
supply by a suitably qualified electri­cian.

If the switched socket is not access­ible after installation, or if the appli­ance is to be hard-wired, an addi­tional means of disconnection must
be provided for all poles. When
switched off, there must be an all­pole contact gap of at least 3mm in
the switch (including switch, fuses
and relays). Connection data is
shown on the data plate. It must
match the mains electrical supply.

After installation ensure that all elec­trical components are shielded and
cannot be accessed by users.

Total power rating

See data plate

Connection

AC 230 V, 50 Hz

The connection data is quoted on the
dataplate. It must match the household
supply.

Residual current device

For extra safety, it is advisable to pro­tect the CombiSet with a suitable resid­ual current device (RCD) with a trip
range of 30 mA.

37

Electrical connection

Disconnecting from the mains

 Danger of electric shock.

After disconnection, ensure the ap­pliance cannot be switched back on
by mistake.

To disconnect the appliance from the
mains power supply, do one of the fol­lowing depending on installation:

Safety fuses

 Completely remove fuses

Automatic circuit breakers

 Press the (red) button until the middle

(black) button springs out.

Built-in circuit breakers

 Circuit breakers, type B or C: switch

the on-off switch from 1 (on) to 0 (off).

Residual current device (RCD)

 Switch the main switch from 1 (on) to

0 (off) or press the test button.

Connecting the mains cable

 Danger of electric shock.

The mains connection cable must be
fitted by a suitably qualified and
competent person in accordance
with current local and national safety
regulations. (e.g. BS 7671 in the UK).

If the mains cable needs to be replaced
it must be replaced with a special con­nection cable, type H05VV-F (PVC-in­sulated), available from Miele.

The connection data is quoted on the
data plate.

38

After sales service, data plate, guarantee

After sales service

In the event of any faults which you cannot easily remedy, please contact

– your Miele Dealer, or

– Miele Service.

See end of this booklet for contact details.

Please note that telephone calls may be monitored and recorded for training pur­poses.

N.B. A call-out charge will be applied to service visits where the problem could
have been resolved as described in these instructions.

When contacting your Dealer or Miele, please quote the model and serial number
of your appliance.

Data plate

Space in which to stick the extra data plate supplied with the appliance. Ensure
that the model number is the same as the one on the back page of these instruc­tions.

Guarantee: UK

The appliance is guaranteed for 2 years from the date of purchase.
