Miele CS10121G, CS10121LP Specifications

Double Gas Burner
CombiSet

CS 1012-1

™

8mieleusa.com

CS 1012-1 Double Gas Burner

SPECIFICATIONS

CS 1012-1 — Item

Item LP: 27101252LP

Overall Unit Width 115/16” (288mm)

Overall Height 2

Overall Depth 20

Cut-Out

Minimum Cut-Out Width 10

Minimum Cut-Out Depth 19

Minimum Base Support 17 lbs

Additional Cut-outs Required No

CS 1012-1 Features:

• 2 completely sealed burners:
(1) 6,800 BTU normal burner (front)
(1) 10,230 BTU high-speed burner (rear)

• Available in natural or LP gas

congurations

• Electric spark ignition

• Grate design allows easy movement

of pots and pans

• Cast iron grate

• Enamelled burner components and

pot rests

• Rapid ignition

Electrical

Electrical Requirements 120V 15A 60Hz

Power Cord

Electrical Rating 25W (120V) only during Ignition

BTU Rating of Front Burner 5,460 BTU

BTU Rating of Rear Burner 10,230 BTU

Fuel Source Natural Gas or LP ( Model Specific)

Maximum Gas Pressure Prior to Regulator 1/2” PSI (3.5kPa)

Shipping

Shipping Weight 21 lbs

Shipping Dimensions

Support

Call 800.843.7231

20/20

Gas: 27101253G

1

/4” (57mm)

1

/2” (520mm)

11

/16” (272mm)

11

/16” (500mm)

Yes - Molded NEMA 5-15 plug
120V power cord (5’ - 1.5m) length

24” (610 mm)L x 16” (406 mm) W x
8” (203 mm) H

82020technologies.com

• Automatic reignition

• Gas tap shut-off after unsuccessful

reignition attempts

• Integrates beautifully with other

™

CombiSet

models

CS 1012-1
