Marantz ST6003 User Manual

РУССКИЙ

ENGLISHFRANÇAISDEUTSCHNEDERLANDSESPAÑOLITALIANOSVENSKA

Tuner

ST6003

ENGLISH

DEUTSCH

ESPAÑOL

SVENSKA

WARRANTY

For warranty information, contact your local Marantz
distributor.

RETAIN YOUR PURCHASE RECEIPT

Your purchase receipt is your permanent record
of a valuable purchase. It should be kept in a safe
place to be referred to as necessary for insurance
purposes or when corresponding with Marantz.

IMPORTANT

When seeking warranty service, it is the responsibility
of the consumer to establish proof and date of
purchase. Your purchase receipt or invoice is
adequate for such proof.

FOR U.K. ONLY

This undertaking is in addition to a consumer's
statutory rights and does not affect those rights in
any way.

FRANÇAIS

GARANTIE

Pour des informations sur la garantie, contacter le
distributeur local Marantz.

CONSERVER L'ATTESTATION D'ACHAT

L'attestation d'achat est la preuve permanente
d'un achat de valeur. La conserver en lieu sur pour
s'y reporter aux fi ns d'obtention d'une couverture
d'assurance ou dans le cadre de correspondances
avec Marantz.

IMPORTANT

Pour l'obtention d'un service couvert par la garantie,
il incombe au client d'établir la preuve de l'achat
et d'en corroborer la date. Le reçu ou la facture
constituent des preuves suffi santes.

GARANTIE

Bei Garantiefragen wenden Sie sich bitte an Ihren
Marantz-Händler.

HEBEN SIE IHRE QUITTING GUT AUF

Die Quittung dient Ihnen als bleibende Unterlage
für Ihren wertvollen Einkauf Das Aufbewahren der
Quittung ist wichtig, da die darin enthaltenen Angaben
für Versicherungswecke oder bei Korrespondenz mit
Marantz angeführt werden müssen.

WICHTIG!

Bei Garantiefragen muß der Kunde eine Kaufunterlage
mit Kaufdatum vorlegen. Ihren Quittung oder
Rechnung ist als Unterlage ausreichend.

NEDERLANDS

GARANTIE

Voor inlichtingen omtrent garantie dient u zich tot
uw plaatselijke Marantz.

UW KWITANTIE, KASSABON E.D. BEWAREN

Uw kwitantie, kassabon e.d. vormen uw bewijs
van aankoop van een waardevol artikel en dienen
op een veilige plaats bewaard te worden voor evt,
verwijzing bijv, in verbend met verzekering of bij
correspondentie met Marantz.

BELANGRIJK

Bij een evt, beroep op de garantie is het de
verantwoordelijkheid van de consument een
gedateerd bewijs van aankoop te tonen. Uw
kassabon of factuurzijn voldoende bewijs.

GARANTIA

Para obtener información acerca de la garantia
póngase en contacto con su distribuidor Marantz.

GUARDE SU RECIBO DE COMPRA

Su recibo de compra es su prueba permanente de
haber adquirido un aparato de valor, Este recibo
deberá guardarlo en un lugar seguro y utilizarlo
como referencia cuando tenga que hacer uso del
seguro o se ponga en contacto con Marantz.

IMPORTANTE

Cuando solicite el servicio otorgado por la garantia
el usuario tiene la responsabilidad de demonstrar
cuándo efectuó la compra. En este caso, su recibo
de compra será la prueba apropiada.

ITALIANO

GARANZIA

L’apparecchio è coperto da una garanzia di buon
funzionamento della durata di un anno, o del periodo
previsto dalla legge, a partire dalla data di acquisto
comprovata da un documento attestante il nominativo
del Rivenditore e la data di vendita. La garanzia sarà
prestata con la sostituzione o la riparazione gratuita
delle parti difettose.
Non sono coperti da garanzia difetti derivanti da
uso improprio, errata installazione, manutenzione
effettuata da personale non autorizzato o, comunque,
da circostanze che non possano riferirsi a difetti di
funzionamento dell’apparecchio. Sono inoltre esclusi
dalla garanzia gli interventi inerenti l’installazione e
l’allacciamento agli impianti di alimentazione.
Gli apparecchi verranno riparati presso i nostri Centri
di Assistenza Autorizzati. Le spese ed i rischi di
trasporto sono a carico del cliente.
La casa costruttrice declina ogni responsabilità per
danni diretti o indiretti provocati dalla inosservanza
delle prescrizioni di installazione, uso e manutenzione
dettagliate nel presente manuale o per guasti dovuti
ad uso continuato a fi ni professionali.

GARANTI

För information om garantin, kontakta Marantz
lokalagent.

SPAR KVITTOT

Kvittot är ett inköpsbevis på en värdefull vara. Det skall
förvaras säkert och hänvisas till vid försäkringsfall
eller vidkorrespondens mod Marantz.

VIKTIGT

Fö att garantin skall gälla är det kundens sak att
framställa bevis och datum om köpet. Kvitto eller
faktura är tillräokligt bevis fö detta.

РУССКИЙ

ГАРАНТИЯ

Относительно информации о гарантии
обращайтесь к Вашему местному дистрибьютору
Marantz.

СОХРАНИТЕ ВАШУ КВИТАНЦИЮ О ПОКУПКЕ

Ваша квитанция о покупке является документом,
свидетельствующим о дорогостоящей покупке.
Ее необходимо хранить в безопасном месте и
в случае необходимости использовать в целях
страхования или при обращении в компанию
Marantz.

ВАЖНО

При обращении за гарантийным обслуживанием
обязанностью потребителя является
подтверждение факта и даты покупки. Для
такого доказательства достаточно предъявить
квитанцию о покупке или счет.

ТОЛЬКО ДЛЯ СОЕДИНЕННОГО КОРОЛЕВСТВА

Это используется в дополнение к законным
правам потребителя и ни в коей мере не
ущемляет эти права.

English

Nederlands

Español

Русский

The ST6003 is in conformity with the EMC directive and low-voltage directive.

Français

Le ST6003 est conforme à la directive EMC et à la directive sur les basses tensions.

Deutsch

Das Modell ST6003 entspricht den EMC-Richtlinien und den Richtlinien für
Niederspannungsgeräte.

De ST6003 voldoet aan de EMC eisen en de vereisten voor laag-voltage.

El ST6003 está de acuerdo con las normas EMC y las relacionadas con baja tensión.

Italiano

Il ST6003 è conforme alle direttive CEE ed a quelle per i bassi voltaggi.

Svenska

Le ST6003 est conforme à la directive EMC et à la directive sur les basses tensions.

Модель ST6003 соответствует директиве EMC и директиве о низковольтных
устройствах.

CE MARKING

English

WARNINGS

- Do not expose the equipment to rain, moisture,
dripping or splashing.

- Do not remove the cover from the equipment.

- Do not insert anything into the equipment through
the ventilation holes.

- Do not handle the mains cord with wet hands.

- Do not cover the ventilation with any items such as
tablecloths, newspapers, curtains, etc.

- No naked fl ame sources, such as lighted candles,
should be placed on the equipment.

- When disposing of used batteries, please comply
with governmental regulations or environmental
public instruction’s rules that apply in your country
or area.

- Make a space of about 0.1 meter around the unit.

- No objects fi lled with liquids, such as vases, shall
be placed on the equipment.

- When the switch is in the OFF position, the
equipment is not completely switched off from
MAINS.

- The equipment shall be installed near the
power supply so that the power supply is easily
accessible.

- Do not expose the unit and batteries to excessive
heat such as direct sunlight, fi re or the like.

Français

-

Ne pas exposer l’appareil à la pluie, à l’humidité, à
l’égouttement ou aux éclaboussures.

- Ne pas essayer de retirer le boîtier de l’appareil.

- Ne rien insérer dans l’appareil par les orifi ces de
ventilation.

- Ne pas manipuler le cordon d’alimentation avec
les mains mouillées.

- Ne pas recouvrir les ouïes de ventilation avec un
objet quelconque comme une nappe, un journal,
un rideau, etc.

- Ne placer aucune source de fl amme nue, comme
une bougie allumée, sur l'appareil.

- Pour mettre au rebut les piles usées, respecter les
lois gouvernementales ou les règlements offi ciels
concernant l’environnement qui s'appliquent à
votre pays ou région.

- Veiller à ce qu’aucun objet ne soit à moins de 0,1
mètre des côtés de l'appareil.

- Aucun objet rempli de liquide, un vase par exemple,
ne doit être placé sur l'appareil.

- Lorsque l'interrupteur est sur la position OFF,
l'appareil n'est pas complètement déconnecté du
SECTEUR (MAINS).

- L'appareil sera installé près de la source
d'alimentation, de sorte que cette dernière soit
facilement accessible.

- N'exposez pas l'appareil et les piles à une chaleur
excessive, comme par exemple aux rayons directs
du soleil, au feu, etc.

AVERTISSEMENTS

Deutsch

WARNHINWEISE

- Das Gerät nicht Regen, Feuchtigkeit, Tropf- oder
Spritzwasser aussetzen.

- Die Abdeckung nicht vom Gerät abnehmen.

- Keine Gegenstände durch die Belüftungsschlitze
stecken.

- Das Netzkabel nicht mit feuchten oder nassen
Händen anfassen.

- Decken Sie die Lüftungsöffnungen nicht mit einem
Tischtuch, einer Zeitung, einem Vorhang usw. ab.

- Es dürfen keine Gegenstände mit offener Flamme,
wie etwa brennende Kerzen, auf dem Gerät
aufgestellt werden.

- Beachten Sie bei der Entsorgung der verbrauchten
Batterien alle geltenden lokalen und überregionalen
Regelungen.

- Auf allen Geräteseiten muß ein Zwischenraum
von ungefähr 0,1 meter vorhanden sein.

- Auf das Gerät dürfen keine mit Flüssigkeiten
gefüllte Behälter, wie etwa eine Vase, gestellt
werden.

- Wenn der Schalter ausgeschaltet ist (OFF­Position), ist das Gerät nicht vollständig vom
Stromnetz (MAINS) abgetrennt.

- Das Gerät sollte in der Nähe einer Netzsteckdose
aufgestellt werden, damit es leicht an das
Stromnetz angeschlossen werden kann.

- Setzen Sie das Gerät und die Batterien keiner
übermäßigen Wärme aus, z.B. durch Aufstellung
in direkter Sonneneinstrahlung, in der Nähe eines
offenen Feuers usw.

Nederlands

WAARSCHUWINGEN

- Stel het apparaat niet bloot aan regen, vocht,
druppels of spetters.

- Verwijder de afdekplaat van het apparaat niet.

- Duw niets door de ventilatieopeningen in het
apparaat.

- Raak het netsnoer niet met natte handen aan.

- Bedek de ventilatieopeningen niet met enige
voorwerpen, zoals tafelkleden, kranten, gordijnen,
enz.

- Plaats geen brandende voorwerpen, zoals
kaarsen, op het apparaat.

- Volg bij het weggooien van verbruikte batterijen de
overheidswetgeving of milieuvoorschriften op die
van kracht zijn in het land of de regio waarin u zich
bevindt.

- Zorg dat er 0,1 meter vrije ruimte rond het toestel
is.

- Plaats geen voorwerpen met een vloeistof erin,
zoals een bloemenvaas, op het apparaat.

- Als de schakelaar op OFF staat, is het apparaat
niet volledig losgekoppeld van de netspanning
(MAINS).

- De apparatuur wordt in de buurt van het stopcontact
geïnstalleerd, zodat dit altijd gemakkelijk
toegankelijk is.

- Stel het apparaat en de batterijen niet bloot
aan grote warmte, zoals direct zonlicht, vuur en
dergelijke.

Español

ADVERTENCIAS

- No exponga el equipo a la lluvia, la humedad,
goteos o salpicaduras.

- No extraiga la tapa del equipo.

- No introduzca nada en el interior del equipo a
través de los orifi cios de ventilación.

- No maneje el cable de alimentación con las
manos mojadas.

- No cubra la ventilación con objetos como manteles,
periódicos, cortinas, etc.

- No deben colocarse sobre el equipo elementos
con fuego, por ejemplo velas encendidas.

- Cuando se eliminen baterías usadas, deben
cumplirse las reglamentaciones oficiales o las
normas de protección medioambiental aplicables
en su país o en su zona.

- Deje un espacio de unos 0,1 metro alrededor de la
unidad.

- No se deben colocar sobre el aparato recipientes
que contengan líquidos, como por ejemplo
jarrones.

- Cuando el interruptor está en la posición OFF, el
equipo no está completamente desconectado de
la alimentación MAINS.

- El equipo se instalará cerca de la fuente de
alimentación de manera que resulte fácil acceder
a ella.

- No exponga la unidad y las pilas a un calor
excesivo, tal como el derivado de la luz directa del
sol, el fuego, o alguna fuente térmica similar.

Italiano

AVVERTENZE

- Non esporre l’apparecchio alla pioggia, all’umidità,
al gocciolamento o agli spruzzi.

- Non rimuovere il coperchio dell’apparecchio.

- Non introdurre oggetti all’interno dell’apparecchio
attraverso i fori di ventilazione.

- Non toccare il cavo di alimentazione con le mani
bagnate.

- Non coprire le fessure di ventilazione con tovaglie,
giornali, tende od oggetti analoghi.

- Non posare sull'apparecchio sorgenti di fi amme
scoperte quali candele accese.

- Smaltire le pile usate in conformità alle norme
governative o disposizioni ambientali vigenti nel
proprio paese o zona.

- Lasciare 0,1 metro liberi tutto intorno l'unità.

- Non mettere sull'apparecchiatura alcun contenitore
di liquido, come ad esempio dei vasi.

- Quando l'interruttore è nella posizione OFF,
l'apparecchiatura non è completamente scollegata
da MAINS.

- L’apparecchio va installato in prossimità della
fonte di alimentazione, in modo che quest’ultima
sia facilmente accessibile.

- Non esporre l'unità e le batterie a calore eccessivo
come la luce diretta del sole, il fuoco o così via.

Svenska

VARNINGAR

- Utsätt inte utrustningen för regn, fukt, droppande
vatten eller vattenstänk.

- Ta inte bort utrustningens hölje.

- För inte in föremål i utrustningen genom
ventilationshålen.

- Hantera inte nätsladden med våta händer.

- Täck inte för ventilationsöppningarna med
några föremål som till exempel bordsdukar,
dagstidningar, gardiner e.d.

- Inga föremål med öppen låga, som till exempel
tända stearinljus, bör placeras på utrustningen.

- Följ de lagar och miljöskyddsråd som gäller i det
land eller område där du bor när du gör dig av med
batterier.

- Se till att det fi nns omkring 0,1 meter fri plats runt
omkring enheten.

- Inga objekt som är fyllda med någon vätska,
till exempel blomstervaser, bör placeras på
apparaten.

- Även om strömbrytaren står i det avstängda läget
OFF, så är utrustningen inte helt bortkopplad från
det elektriska nätet (MAINS).

- Utrustningen ska vara installerad nära strömuttaget
så att strömförsörjningen är lätt att tillgå.

- Utsätt inte enheten och batterierna för kraftig
värme, såsom direkt solljus, eld eller liknande.

РУССКИЙ

ПРЕДУПРЕЖДЕНИЯ

- Не подвергайте оборудование воздействию
дождя, влаги, капель или брызг.

- Не снимайте крышку с оборудования.

- Не вставляйте ничего в оборудование через

вентиляционные отверстия.

- Не берите сетевой кабель мокрыми руками.

- Не закрывайте вентиляционные отверстия

никакими предметами, например, скатертями,
газетами, занавесками и т.д.

- Нельзя устанавливать на оборудование
источники открытого огня, например,
зажженные свечи.

- При утилизации использованных батареек,
пожалуйста, соблюдайте государственные
положения или муниципальные нормы охраны
окружающей среды, которые действуют в
вашей стране или вашем регионе.

- Обеспечьте вокруг устройства свободное
пространство около 0,1 метра.

- На оборудование нельзя устанавливать
предметы, заполненные жидкостями,
например, вазы.

- Когда выключатель находится в положении
ВЫКЛ, оборудование еще не полностью
выключено из СЕТИ.

- Оборудование следует устанавливать вблизи
источника питания для облегчения доступа к
нему.

- Не подвергайте аппарат и батарейки
чрезмерному нагреванию, например, из-за
воздействия прямого солнечного света, огня
или т.п.

TU_080602N1

РАДИО-ТЮНЕР

Marantz ST6003

(РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ)

Вы приобрели устройство радиоприемное производства компании "D&M Холдингс Инк", Япония ("D & M Holdings Inc.", Japan). Модель ST6003 является стерео­фоническим радио-тюнером и предназначена для приема радиовещания в домашних аудиосистемах. Это изделие широко известно в кругах истинных ценителей
высококлассного звука. Качество и безопасность подтверждены множеством тестов, проведенных как зарубежными, так и российскими испытательными лабо­раториями.

Изготовитель в течение 3 лет (срок службы) после выпуска данного изделия обеспечивает наличие комплектующих в целях возможности проведения ремонта
и технического обслуживания, по истечении которого эксплуатация и техническое обслуживание продолжается в соответствии с действующими нормативными
документами. Изделие остается безопасным для жизни, здоровья человека и окружающей среды в течение всего срока эксплуатации. Гарантийный срок - 1 год.

Информация о Российской сертификации

46

No сертификата

соответствия

РОСС JP.АЯ46.B15274 РОСТЕСТ-МОСКВА ГОСТ Р МЭК 60065-2005

См. в конце инструкции

ВНИМАНИЕ: Если Вы приобрели аудиоаппаратуру надлежащего качества, то, по Российским законам, она не подлежит возврату или обмену на аналогичный товар других
размера, формы и т.д.

Орган по

сертификации

Нормативные документы Наименование сертифицированной продукции

Устройства радиоприемные (AV/CD-ресиверы) До 10.06.2011
ГОСТ 5651-89 (Табл. 1 (поз. 11),
табл. 2 (поз. 6.7))
ГОСТ 22505-97
ГОСТ Р 51515-99
ГОСТ Р 51317.3.2-99
ГОСТ Р 51317.3.3-99

Основные технические характеристики

Срок действия

сертификата

D&M Холдингс Инк

Здание D&M, 2-1 Ниссин-тё

Кавасаки-ку, Кавасаки-си, Канагава

2108569, Япония

D&M Holdings Inc.

D&M Building, 2-1 Nisshin-Cho

Kawasaki-Ku, Kawasaki-Shi, Kanagawa

2108569, Japan

ENGLISH

INTRODUCTION

Thank you for purchasing the Marantz ST6003 Tuner.
This remarkable component has been engineered to provide you with many years of listening enjoyment.
Please take a few minutes to read this manual thoroughly before you connect and operate the ST6003.
As there are a number of connection and confi guration options, you are encouraged to discuss your own
particular system setup with your Marantz authorized dealer.

ACCESSORIES CHECK

Before use, check the below accessories were included in the package.

Audio Connecting Cord

User Guide

TABLE OF CONTENTS

INTRODUCTION ....................................1

ACCESSORIES CHECK ....................................................1

TABLE OF CONTENTS .........................1

FEATURES ............................................. 2

BEFORE USE .........................................2

NAMES AND FUNCTIONS ....................3

FRONT PANEL .................................................................. 3

FL DISPLAY ........................................................................ 3

REAR PANEL .....................................................................4

BASIC CONNECTIONS .........................4

CONNECTING THE AMPLIFIER .......................................4

CONNECTING THE ANTENNA TERMINALS ...................5

CONNECTING THE AC POWER CABLE .........................5

BASIC OPERATION ...............................6

TURNING ON THE UNIT ...................................................6

LISTENING TO THE TUNER .............................................6

AUTO TUNING ...................................................................6

MANUAL TUNING .............................................................. 6

(FM) TUNING MODE (AUTO STEREO OR MONO) .........6

ADVANCED OPERATION ......................6

PRESET MEMORY ............................................................6

RDS OPERATION ..............................................................8

OTHER OPERATION .........................................................8

REMOTE CONTROLLER OPERATION ............................ 9

TROUBLESHOOTING .........................10

FRONT KEY (BUTTON) LOCK OF THE UNIT ................10

GENERAL MALFUNCTION .............................................10

HOW TO RESET THE UNIT ............................................10

OTHERS ...............................................11

TECHNICAL SPECIFICATIONS ......................................11

CLEANING OF EQUIPMENT EXTERNAL SURFACES

REPAIRS...........................................................................11

...11

FUNCTIONS

NAMES AND

BASIC

CONNECTIONS

BASIC

OPERATION

ADVANCED

OPERATION

AM Loop Antenna

FM Antenna

AC Power Cable

Remote control connecting cord

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable
and can be reused. This product and the
accessories packed together are the applicable
product to the WEEE directive except batteries.
Please dispose of any materials in accordance
with your local recycling regulations.
When discarding the unit, comply with your local
rules or regulations.
Batteries should never be thrown away or
incinerated but disposed of in accordance with
your local regulations concerning chemical
wastes.

TROUBLESHOOTING

OTHERS

1

ENGLISH

NAMES AND

FUNCTIONS

FEATURES

■ 50 stations AM/FM random preset memory

■ Sleep timer

CONNECTIONS

■ Dimmer control

BASIC

■ RDS function
Radio Data System (RDS) provides information

on FM broadcasts.

■ Remote operation by Marantz Remote Control
Bus

OPERATION

BASIC

OPERATION

ADVANCED

BEFORE USE

This section must be read before any connection is
made to the mains supply.

EQUIPMENT MAINS WORKING SETTING

Your Marantz product has been prepared to comply
with the household power and safety requirements
that exist in your area.
ST6003 can be powered by 230V AC only.

COPYRIGHT

Recording and playback of any material may
require consent. For further information refer to the
following:

— Copyright Act 1956
— Dramatic and Musical Performers Act 1958
— Performers Protection Acts 1963 and 1972
— Any subsequent statutory enactments and

orders

DO NOT LOCATE IN THE FOLLOWING PLACES

To ensure long-lasting use, do not locate the unit where:

• Exposed to direct sunlight.

• Near to sources of heat such as heaters.

• Highly humid or poorly ventilated.

• Dusty.

• Subjected to mechanical vibrations.

• On wobbly, inclined or otherwise unstable
surfaces

• Radiated heat is blocked such as in cramped
audio racks.

To ensure proper heat radiation, ensure the below
clearance from walls and other equipment.

0.1 m or more

0.1 m or more

TUNER ST6003

0.1 m or more

Noise or disturbance of the picture may be generated
if this unit or any other electronic equipment using
microprocessors is used near a tuner or TV.
If this happens, take the following steps:

• Install this unit as far as possible from the tuner or
TV.

• Set the antenna wires from the tuner or TV away
from this unit’s mains cord and input/output
connection cords.

• Noise or disturbance tends to occur particularly
when using indoor antennas or 300 Ω/ohms
feeder wires. We recommend using outdoor
antennas and 75 Ω/ohms coaxial cables.

Note:

For heat dispersal, do not install this equipment in a
confi ned space such as a book case or similar unit.

TROUBLESHOOTING

OTHERS

2

0.1 m or more

NAMES AND FUNCTIONS

ENGLISH

FRONT PANEL

q

w e

q POWER ON/STANDBY button

When it is pressed, the display window lights up, and
the power comes on. When it is pressed again, the
display window is extinguished, and goes into the
standby status.

STANDBY indicator

Lights up in red color while standby status.

w INFRARED receiving sensor

window

This window receives infrared signals from the
remote control.

e RDS indicator

This indicator illuminates when receiving RDS
broadcasts, and fl ashes during the RDS search.

r DISPLAY button

Press this button to change the FL display mode.
(See page 8)

TUNER ST6003

rtyuo!0!1!2 i

u T-MODE button

Press this button to select the auto stereo mode or
mono mode when the FM band is selected.
“AUTO” indicator will be illuminated in the display.
(See page 6)

i TUNING/PRESET 34 (UP/DOWN)

button

This button used for tuning in the desired broadcasting
stations or to preset in the desired broadcasting
stations.

o BAND button

Press this button to switch between FM and AM in
the TUNER mode.

!0 F (Frequency)/P (Preset) button

During reception of AM or FM, you can change
the function of the UP/DOWN buttons for scanning
frequencies or selecting preset stations by pressing
this button.

FL DISPLAY

dsafg

DISP AUTO TUNED ST

SLEEP

a DISP (Display Off) indicator

This indicator is illuminated when this unit is in the
display off mode.

s SLEEP timer indicator

This indicator is illuminated when the sleep timer
function is active.

d AUTO indicator

This indicator illuminates when the tuner’s Auto
mode is in use.

h

f TUNED indicator

This indicator illuminates when the tuner receives a
suffi ciently strong radio signal.

g STEREO indicator

This indicator illuminates when an FM station is
being tuned into stereo condition.

h Main Information Display

A variety of information is displayed on this indicator.
Frequency, PS, PTY, RT, stations name by manual
fi ling. etc.

FUNCTIONS

NAMES AND

BASIC

CONNECTIONS

BASIC

OPERATION

ADVANCED

OPERATION

TROUBLESHOOTING

OTHERS

t CLEAR button

Press this button to cancel the tuner preset station or
preset scan tuning. (See page 7)

y MEMORY button

Press this button to enter the tuner preset memory
numbers or station names. (See page 6)

!1 DIMMER button

When this button is pressed once display is dimmed.
When this button is pressed twice, the display is
turned off and the “DISP” indicator lights up.
Press this button again to turn on the display again.

!2 SLEEP button

This button is used for setting the sleep timer.

3

NAMES AND

SPEAKER SYSTEMS

REMOTE

CONTROL

R

OUT

IN

OUT

IN

L

R

L

SYSTEM B

SYSTEM A

R L

R L

AC IN

R

L

MODEL NO.

PM5003

PHONO

TUNERCDCD

AUX /

DVD

IN

OUT

RECORDER 2

(

MD /

TAPE

)

RECORDER 1

(

CD-R

)

PM5003N

MODEL NO.

PM5003

PHONO

GND

FUNCTIONS

REAR PANEL

ENGLISH

BASIC CONNECTIONS

w e r

CONNECTIONS

BASIC

OPERATION

BASIC

q FM antenna terminal (75 ohms)

Connect an external FM antenna with a coaxial
cable, or a cable network FM source.

OPERATION

ADVANCED

w AM antenna and ground terminals

Connect the supplied AM loop antenna. Use the
terminals marked “AM” and “GND”. The supplied AM
loop antenna will provide good AM reception in most

TROUBLESHOOTING

areas. Position the loop antenna until you hear the
best reception.

e AUDIO OUT connectors

The audio signals are output from these connectors.

OTHERS

tq

r REMOTE CONTROL IN and OUT

connectors

Using the supplied remote control connecting cord,
these connectors enable this unit to be connected to
a Marantz component equipped with remote control
connectors. These connections make it possible to
control an entire system that centers on the amplifi er
or other such component.

t AC INLET

Plug the supplied mains cord into this AC INLET and
then into the power outlet on the wall.
ST6003 can be powered by 230V AC only.

CONNECTING THE AMPLIFIER

Use the audio connecting cord to connect the unit with a stereo amplifi er or AV amplifi er.

Cautions:

• Do not connect the unit to the PHONO input connectors on the amplifier.

• When making the connections, insert the plugs securely into the connectors. Failure to insert the plugs

securely may result in noise.

ST6003

(Red) (White)

Audio connecting cord (supplied)

:

Signal fl ow

(Red) (White)

PHONO

GND

PHONO

TUNER

AUX

DVD

RECORDER 1

IN

MODEL NO.

MODEL NO.

CD-R

OUT

RECORDER 2

MD

IN

PM5003

PM5003

SPEAKER SYSTEMS

SYSTEM A

TAPE

OUT

SYSTEM B

Marantz Stereo Amplifi er

REMOTE

CONTROL

IN

OUT

PM5003N

AC IN

4

Notes:

• Do not plug in the mains cord until all connections have been completed.

• When making connections, also refer to the operating instructions of the other components.

• Be sure to connect the left and right channels properly (left with left, right with right).

• Note that binding pin-plug cords together with mains cords or placing them near a power transformer will result in
generating hum or other noise.

ENGLISH

CONNECTING THE ANTENNA TERMINALS

FM

Antenna

ASSEMBLING THE AM LOOP ANTENNA

1.

Release the vinyl tie and take out the connection
line.

FM External

Antenna

AM Loop

Antenna

Insert the hook at the bottom of the loop part

3.

into the slot at the base part.

AM External

Antenna

CONNECTING THE SUPPLIED ANTENNAS

Connecting the supplied FM antenna

The supplied FM antenna is for indoor use only.
During use, extend the antenna and move it in various
directions until the clearest signal is received.
Fix it with push pins or similar implements in the
position that will cause the least amount of distortion.
If you experience poor reception quality, an outdoor
antenna may improve the quality.

Connecting the supplied AM loop antenna

The supplied AM loop antenna is for indoor use
only.
Set it in the direction and position it to where you
receive the clearest sound. Put it as far away as
possible from the unit, televisions, speaker cables,
and power cords.
If you experience poor reception quality, an outdoor
antenna may improve the quality.

Press and hold down the lever of the AM antenna

1.

terminal.

2. Insert the bare wire into the antenna terminal.
Release the lever.

3.

CONNECTING AN FM OUTDOOR ANTENNA

Notes:

• Keep the antenna away from noise sources (neon
signs, busy roads, etc.).

• Do not put the antenna close to power lines. Keep it
well away from power lines, transformers, etc.

• To avoid the risk of lightning and electrical shock,
grounding is necessary.

CONNECTING THE AC POWER CABLE

1. Plug the supplied AC power cable to the AC IN

socket on the rear panel of the main unit.

2. Plug the power cable into an AC outlet.

FUNCTIONS

NAMES AND

BASIC

CONNECTIONS

BASIC

OPERATION

ADVANCED

OPERATION

TROUBLESHOOTING

2. Bend the base part in the reverse direction.

4. Place the antenna on stable surface.

CONNECTING AN AM OUTDOOR ANTENNA

An outdoor antenna will be more effective if it is
stretched horizontally above a window or outside.

Notes:

• Do not remove the AM loop antenna.

• To avoid the risk of lightning and electrical shock,
grounding is necessary.

OTHERS

5

ENGLISH

NAMES AND

FUNCTIONS

BASIC OPERATION

ADVANCED OPERATION

TURNING ON THE UNIT

1. Connect the AC power cable to the wall outlet.

CONNECTIONS

Press the ON/STANDBY button on the unit to

2.

BASIC

OPERATION

BASIC

turn on the power of the unit.

Turn on the power of the audio equipment

3.

connected to this unit. Set the input selector on
the audio equipment to this unit.

• Each time the button is pressed, the power of the
unit is switched between on and standby mode.

LISTENING TO THE TUNER

Frequency scan step for AM is selectable.
Default setup is 9 kHz step, if your country’s standard
is 10 kHz step, Press BAND button more than 6

OPERATION

ADVANCED

seconds. Scan step will change.

Note:

Preset memory for the tuner will clear by changing
this setup.

TROUBLESHOOTING

AUTO TUNING

1. 2.

TUNER ST6003

OTHERS

To select tuner and desired band (FM or AM),

1.

press the BAND button on the front panel.

Press the TUNING/PRESET

2.

the front panel for more than 1 second to start
the auto tuning function.

Automatic searching begins then stops when a

3.

station is tuned in.

If tuning does not stop at the desired station, use to
the “Manual tuning” operation.

3 or 4 buttons

MANUAL TUNING

1. 2.

TUNER ST6003

To select tuner and desired band (FM or AM),

1.

press the BAND button on the front panel.

Press the TUNING/PRESET

2.

the front panel to select the desired station.

(FM) TUNING MODE (AUTO STEREO OR MONO)

TUNER ST6003

When in the auto stereo mode, AUTO indicator will
be illuminated on the display.
The “ST” indicator is illuminated when a stereo
broadcast is tuned in.
At open frequencies, the noise is muted and the
“TUNED” and “ST” indicators are not illuminated.
If the signal is weak, it may be diffi cult to tune into
the station in stereo. In such a case, press the
T-MODE button on the front panel.
“AUTO ” indicator is not illuminated, if FM stereo
broadcasts are received in monaural and the “ST”
indicator is not illuminated.

on

To return to auto stereo mode, press the T-MODE
button again. AUTO indicator is illuminated on the
display.

3 or 4 buttons

PRESET MEMORY

With this unit you can preset up to 50 FM/AM stations
in any order.
For each station, you can memorize the frequency
and reception mode if desired.

AUTO PRESET MEMORY

This function automatically scans the FM and AM
band and enters all stations with proper signal
strength into the memory.

1. 3. 2. 4. 5.2.

on

To select FM, press the BAND button on the

1.

front panel.

While pressing the MEMORY button, press the

2.

TUNING 3 button.

“AUTO PRESET” will appear on the display,

and scanning starts from the lowest frequency.

Each time the tuner fi nds a station, scanning

3.

will pause and the station will be played for fi ve
seconds.

During this time, the following operations are

possible.
The band can be changed by the BAND button.

If no button is pressed during this period, the

4.

current station is memorized in location Preset

01.

If you wish to skip the current station, press

the 3 button during this period, this station is
skipped and auto presetting continues.

Operation stops automatically when all 50

5.

preset memory positions are fi lled or when auto
scanning attains the highest end of all bands.
If you desire to stop the auto preset memory at
anytime, press the CLEAR button.

Note:

It is possible that existing preset memory positions
will be overwritten.

TUNER ST6003

MANUAL PRESET MEMORY

3.

2.4.

TUNER ST6003

Tune into the radio station you desire (Refer to

1.

the “MANUAL TUNING” or “AUTO TUNING”
section).

Press the MEMORY button on the front panel.

2.

“– –“ (preset number) starts blinking on the
display.

Select the preset number by pressing the

3.

TUNING 3 or 4 buttons, while this indicator is
still blinking (approx. 5 seconds)

Press the MEMORY button again to enter. The

4.

display stops blinking.

The station is now stored in the specified

preset memory location.

6

ENGLISH

RECALLING A PRESET STATION

1.1.

TUNER ST6003

Select the desired preset station by pressing

1.

the F/P and TUNING 3 or 4 button on the front
panel.

CLEARING STORED PRESET STATIONS

You can remove preset stations from the memory
using the following procedure.

2. 3.

TUNER ST6003

Recall the preset number to be cleared with

1.

the method described in “Recalling” a preset
station.

Press the MEMORY button on the front panel.

2.

The stored preset number blinks in the display

3.

for 5 seconds. While blinking, press the CLEAR
button on the front panel.

“xx CLEAR” appears on the display to indicate

4.

that the specified preset number has been
cleared.

Note:

To clear all stored preset stations, press and hold the
CLEAR and the F/P buttons on the front panel for
two seconds.

SORTING PRESET STATIONS

TUNER ST6003

If you have stations memorized, and there is a gap in
the sequential order:
I.e. the stations are stored as follows

1) 87.5 MHz

2) 93.1 MHz

3) 94.7 MHz

10) 105.9 MHz
Since there are no stations programmed for presets
4-9, you can have preset 10 become preset 4.
To sort the numbers, press the TUNING 4 button
while pressing the MEMORY button.
“PRESET SORT” will appear on the display and
sorting will be done.

NAME INPUT OF THE PRESET STATION.

This function allows the name of each preset channel
to be entered using alphanumeric characters.
Before name inputting, you need to store preset
stations with the preset memory operation.

4.5.

TUNER ST6003

Recall the preset number to be inputted name

1.

with the method described in “Recalling” a
preset station.

Press the MEMORY button on the front panel

2.

for more than 3 seconds.

The left most column of the station name

3.

indicator fl ashes, indicating the character entry
ready status.

When you press the TUNING 3 or 4 buttons

4.

on the front panel, alphabetic and numeric
characters will be displayed in the following
order:

A → B → C ... Z → 1 → 2 → 3 ..... 0 → – → +

→ / → (Blank) → A

UP →
← DOWN

After selecting the fi rst character to be entered,

5.

press the MEMORY button.

The entry in this column is fi xed and the next

column starts to fl ash. Fill the next column the
same way.

To move back and forth between the characters,

press the F/P button and press the TUNING 3
or 4 buttons.

Note:

Unused columns should be fi lled by entering blanks.

To save the name, press the MEMORY button

6.

on the front panel for more than 2 seconds.

2.5.6.5.

FUNCTIONS

NAMES AND

BASIC

CONNECTIONS

BASIC

OPERATION

ADVANCED

OPERATION

TROUBLESHOOTING

OTHERS

7

ENGLISH

NAMES AND

FUNCTIONS

RDS OPERATION

Now in use in many countries, RDS (Radio Data
System) is a description of the station’s programming
hidden space in the FM signal.
This unit is equipped with RDS to assist in the
selection of FM stations using station and network

CONNECTIONS

names, rather than broadcast frequencies. Additional
RDS functions include the ability to search for

BASIC

programme types.

RADIO TEXT

Some RDS stations broadcast RADIO TEXT, which is

OPERATION

additional information on the station and programme

BASIC

being broadcast.
RADIO TEXT information appears as ‘running’ text
in the display. RADIO TEXT is transmitted character
by the radio station. As a result of that it may take
some time until the entire text has been completely
received.

OPERATION

ADVANCED

RDS DISPLAY

When this unit is tuned to an FM station that is
transmitting RDS data, the Front Panel Information

TROUBLESHOOTING

Display will automatically show the station name or
RADIO TEXT in place of the typical display of the
station’s broadcast frequency.
To change the display, press the DISPLAY button.

TUNER ST6003

OTHERS

RT (

RADIO TEXT

PS (

Program Service Name

) Frequency

)

PROGRAMME TYPE (PTY) DISPLAY

The RDS system categorizes programmes according
to their genre into different programme type (PTY)
groups. To display the programme type information
of the current station, press the F/P button for 3
seconds or more.

TUNER ST6003

PTY AUTO SEARCH

This unit is equipped to automatically search for
stations transmitting any of 29 different programme
types. To search for a PTY, follow these procedures:

2.1.3.4.

TUNER ST6003

Press the F/P button for 3 seconds or more.

1.

The current station’s PTY will be displayed,
or the currently selected PTY group will be
displayed in blinking if no station or RDS data
is present.

To change to a new PTY type, press the

2.

button on the front panel until the desired PTY
is shown in the display.

Once the desired PTY group or type has

3.

been selected, press the F/P button while
the display blink (approx. 5 seconds). The
PTY Auto search will start, and the tuner will
pause at each station broadcasting RDS PTY
information corresponding to the selected
choice.

To advance to the next RDS station with the

4.

desired PTY, press the F/P button again within
5 seconds.

3 or 4

NUMBER DISPLAY PROGRAMME TYPE

1 POP M Pop Music

2 ROCK M Rock Music

3 EASY M Easy Listening Music

4 LIGHT M Light classical

5 CLASSICS Serious classical

6 NEWS News

7 AFFAIRS Current Affairs

8 INFO Information

9 SPORT Sport

10 EDUCATE Education

11 DRAMA Drama

12 CULTURE Culture

13 SCIENCE Science

14 VARIED Varied

15 OTHER M Other Music

16 WEATHER Weather

17 FINANCE Finance

18 CHILDREN Children’s programmes

19 SOCIAL Social Affairs

20 RELIGION Religion

21 PHONE IN Phone In

22 TRAVEL Travel

23 LEISURE Hobbies

24 JAZZ Jazz Music

25 COUNTRY Country Music

26 NATION M National Music

27 OLDIES Oldies Music

28 FOLK M Folk Music

29 DOCUMENT Documentary

OTHER OPERATION

USING THE SLEEP TIMER

TUNER ST6003

To program this unit for automatic standby, press the
SLEEP button.
Each press of the button will increase the time before
shut down in the following sequence.

OFF 10 20 30 50

120 90 80 70 60100110

The sleep time will be shown for a few seconds in the
display on the front panel, and it will count down until
the time has elapsed.

40

When the programmed sleep time has elapsed, the
unit will automatically turn off.
Note that the SLEEP indicator on the display will
illuminate when the Sleep function is programmed.
To cancel the Sleep function, press the SLEEP
button until the display shows “SLEEP OFF” and the
SLEEP indicator will disappear.

DISPLAY MODE

TUNER ST6003

You can select the display mode for the front display
of the unit in the Station Display Mode.
When the DISPLAY button is pressed, the display
mode is switched within 2 seconds.

Station Display Mode

Press the DISPLAY button.

Frequency Display Mode

2 seconds

8

ENGLISH

SPEAKER SYSTEMS

REMOTE

CONTROL

R

OUT

IN

OUT

IN

L

R

L

SYSTEM B

SYSTEM A

R L

R L

AC IN

R

L

MODEL NO.

PM5003

PHONO

TUNERCDCD

AUX /

DVD

IN

OUT

RECORDER 2

(

MD /

TAPE

)

RECORDER 1

(

CD-R

)

PM5003N

MODEL NO.

PM5003

PHONO

GND

REMOTE CONTROLLER OPERATION

This unit can be controlled by the remote controller supplied with Marantz integrated amplifi er.
You can perform following operations using the remote controller.
When you operate this unit with the remote controller that is supplied with a Marantz integrated amplifi er,
connect the REMOTE CONTROL connector of this unit to the REMOTE CONTROL terminal of the amplifi er
using the supplied cords without fail.

When the TUNER button is pressed, the buttons in

(Example : the remote controller
supplied with PM5003)

TUNER function as indicated in the table below.

BUTTON NAME FUNCTION

SOURCE POWER

P.SCAN/A.TUNE

3/TUNE+

4/TUNE-

1/PRESET-

2/PRESET+

BAND

0-9

CLEAR

MEMO

DISPLAY

POWER ON and OFF
Starts preset scan
Tuning (frequency) increase
Tuning (frequency) decrease
Preset stations forward feed
Preset stations backward

feed
Selects the band
Inputs the numeric
Clears the inputting
Enters the tuner preset

memory numbers
Selects the display mode in

RDS
Displays the programme type

PTY

information of the current
station

F.DIRECT

T.MODE

Selects the "frequency direct
input"

Selects the auto stereo mode
or mono mode

CONNECTING THE REMOTE CONTROL JACKS

Connect the AUDIO OUT and REMOTE CONTROL IN connectors to their corresponding terminals on a
Marantz stereo amplifi er using audio connecting cord and remote control connectiong cord.

Note:

Turn power to the stereo amplifi er OFF before making the connections.

ST6003

Audio connecting cord (supplied) Remote control connecting cord (supplied)

Marantz Stereo Amplifi er

PHONO

GND

PHONO

TUNER

MODEL NO.

PM5003

MODEL NO.

PM5003

AUX

DVD

RECORDER 1

IN

RECORDER 2

MD

TAPE

CD-R

OUT

OUT

IN

SPEAKER SYSTEMS

SYSTEM A

SYSTEM B

REMOTE

CONTROL

IN

OUT

PM5003N

AC IN

FUNCTIONS

NAMES AND

BASIC

CONNECTIONS

BASIC

OPERATION

ADVANCED

OPERATION

TROUBLESHOOTING

OTHERS

9

ENGLISH

NAMES AND

FUNCTIONS

TROUBLESHOOTING

In case of trouble, check the following before calling for service:

1. Are the connections made properly ?

2. Are you operating the unit properly following the user’s guide ?

CONNECTIONS

OPERATION

OPERATION

3. Are the power amplifi ers and speaker working properly ?

BASIC

If the unit does not operate properly, check items shown in the following table.
If your trouble cannot be recovered with the remedy actions listed in the following table, malfunction of the
internal circuitry is suspected; immediately unplug the power cable and contact your dealer, nearest Marantz
authorized dealer or the Marantz Service Center in your country.

SYMPTOM CAUSE REMEDY

Power does not turn on when POWER

BASIC

ON/STANDBY switch is pressed.

Hissing noise is heard on FM
broadcasts.

ADVANCED

Hissing or buzzing sound is heard on AM
broadcasts.

Booming sound (humming) is heard in AM
broadcasts.

TROUBLESHOOTING

I can not get any sound. Power connected amplifi er not turned on. Connection leads to amplifi er not made

Mains cord’s plug is not plugged into
wall outlet.

Antenna cable is not properly
connected.

Antenna is not pointing in the right
direction.

Radio waves are weak. Install an outdoor antenna.

Noise from a TV or interference in the
signals sent from the broadcast station.

Signals transmitted over the main cord
are modulated by the power source
frequency.

Plug the mains cord in properly.

Connect the leads properly.

Point the antenna in the right direction.

Turn off the TV.
Change the position of the loop antenna.
Install an outdoor antenna.

Insert the plug in the opposite direction.
Install an outdoor antenna.

correctly.

SLEEP F/P T.MODE DISPLAY

TUNER ST6003

FRONT KEY (BUTTON) LOCK OF THE UNIT

If the F/P and T.MODE buttons on the front panel are
both pressed at the same time for three seconds or
more, all the buttons on the front panel (excluding
the POWER ON/OFF button), will become locked.
“F-KEY LOCK!” will appear in the display.
Release the lock by pressing the same two keys
again at the same time for three seconds or more.
“F-KEY UNLOCK” will appear in the display, and the
keys will unlock.

GENERAL MALFUNCTION

If the equipment malfunctions, this may be because
an electrostatic discharge or AC line interference has
corrupted the information in the equipment memory
circuits. Therefore:

- disconnect the plug from the AC line supply

- after waiting at least three minutes, reconnect
the plug to the AC line supply

- re-attempt to operate the equipment

HOW TO RESET THE UNIT

Should the operation or display seem to be abnormal,
reset the unit with the following procedure.
The unit is turned on, press and hold the SLEEP
and DISPLAY buttons simultaneously for 3 seconds
or more.
Remember that the procedure will reset the settings
of the TUNER PRESET etc., to their initial settings.

OTHERS

10

Memory backup

• In case a power outage occurs or the power
cord is accidentally unplugged, this unit is
equipped with a backup function to prevent
memory data such as the preset memory
from being erased.

ENGLISH

OTHERS

TECHNICAL SPECIFICATIONS

FM TUNER SECTION

Frequency Range ................................ 87.5 – 108.0 MHz

Usable Sensitivity .............................IHF 1.8 µV/16.4 dBf

Signal to Noise Ratio ................... Mono/Stereo 75/70 dB

Distortion .......................................Mono/Stereo 0.2/0.3%

Stereo Separation ......................................... 1 kHz 45 dB

A.C.S ......................................................±300 kHz 60 dB

Image Rejection .........................................98 MHz 70 dB

Tuner Output Level ............. 1 kHz, ±40 kHz Dev 500 mV

AM TUNER SECTION

Frequency Range ................................... 531 – 1602 kHz

Usable Sensitivity .................................... Loop 400 µV/m

Signal to Noise Ratio .............................................. 50 dB

Distortion ....................................400 Hz, 30% Mod. 0.5%

Selectivity ..................................................±18 kHz 70 dB

GENERAL

Power Requirement ...........................AC 230 V 50/60 Hz

Power Consumption .................................................. 9 W

Weight ...................................................................4.1 Kg

ACCESSORIES

FM Antenna ................................................................... 1

AM Loop Antenna .......................................................... 1

AC Power Cable ............................................................ 1

Audio connecting cord ................................................... 1

Remote control connecting cord .................................... 1

Specifi cations subject to change without prior notice.

DIMENSIONS

440 mm

TUNER ST6003

10 mm

341 mm

328.5 mm

2 mm

90.5 mm

104.5 mm

14 mm

CLEANING OF EQUIPMENT EXTERNAL
SURFACES

The exterior fi nish of your unit will last indefi nitely with
proper care and cleaning, Never use scouring pads,
steel wool, scourging powders or harsh chemical
agents (e.g., lye solution), alcohol, thinner, benzine,
insecticide or other volatile substances as these wil
mar the fi nish of the equipment. Likewise, never
use cloths containing chemical substances. If the
equipment get dirty, wipe the external surfaces with
a soft, lint-free cloth.
If the equipment becomes heavily soiled:

• dilute some washing up liquid in water, in a ratio of
one part detergent to six parts water.

• dip a soft, lint free in the solution and wring the it is
damp.

• wipe the equipment with the damp cloth.

• dry the equipment by wiping it with a dry cloth.

REPAIRS

Only the most competent and qualified service
technicians should be allowed to service the
factory-trained warranty station personnel have
the knowledge and special facilities needed for
repair and calibration of this precision equipment.
After the warranty period has expired, repairs will
be performed for a charge if the equipment can be
returned to normal operation.
In the event of diffi culty, refer to your dealer or write
directly to the nearest location to you that is listed on
the Marantz Authorized Service Station list. If writing,
please include the model and serial number of the
equipment together with a full description of what you
think is abnormal about the equipment’s behaviour.

FUNCTIONS

NAMES AND

BASIC

CONNECTIONS

BASIC

OPERATION

ADVANCED

OPERATION

TROUBLESHOOTING

OTHERS

11

www.marantz.com

You can find your nearest authorized distributor or dealer on our website.

is a registered trademark.

06/2008 541110124038M mzh-dPrinted in China
