Product information
PM7000N
INTEGRATED STEREO AMPLIFIER WITH HEOS BUILT-IN
Discover the PM7000N, the first Marantz Current Feedback integrated Hi-Fi amplifier with HEOS Built-in technology. The ideal choice for audio connoisseurs,
the PM7000N includes high-grade audio components, Marantz own HDAMs, a toroidal transformer and a high-speed instantaneous current power supply.
Stream your favourite music and enjoy high-resolution digital audio files up to 192kHz/24bit or DSD5.6. Switch to the high quality Phono MM input to listen
to your beloved vinyls as never before.
Highlights Your Benefits
Integrated Current Feedback Amplifier with 2x 60W / 8 ohm rms Wide bandwidth reproduction to fill your room with renowned Marantz sound
Marantz proprietary HDAM-SA3 circuit Wide dynamic range and famous Marantz soundstage
Shielded Toroidal Transformer Delivering high level of clean power for pure amplification without distortion
Built-in Bluetooth and AirPlay 2 Access to almost unlimited music sources via your smartphone
HEOS Built-in wireless music streaming Play nearly unlimited music from your favourite streaming services like
Spotify Free and Premium, Amazon Music, Deezer, TuneIn Internet Radio and
more with the comfortable HEOS app
Wide range of connectivity Four analogue inputs, one coaxial input, two optical digital inputs and
one USB-A for high resolution audio files
High-performance, high-resolution audio playback Supports high-resolution audio ALAC, FLAC and WAV lossless files
up to 24-bit/192-kHz – plus, DSD 2.8MHz and 5.6MHz tracks for
high-resolution listening
Play vinyl with exceptional clarity Integrated phono input with newly designed FET input stage to improve
signal purity and improve sound
Fully shielded digital and network section with the option to deactivate Minimises the risk of interference by digital section to achieve highest
audio performance and a pure analogue experience
Premium Marantz SPKT-1+ speaker terminals Improved connection to speakers for high quality playback
MODE
PM7000N
INTEGRATED STEREO AMPLIFIER WITH HEOS BUILT-IN
FEATURES PM7000N
AUDIO
Channels 2
Current Feedback Topology •
Phono EQ OP amp + FET input stage
HDAM version HDAM-SA3, SA2
Power Transformer Toroidal
High Grade Audio Components
Customised Components •
Symmetric PCB Layout •
Aluminium Extrusion Heat Sink •
Shield Case for Digital Circuit •
Tone Control (Bass / Treble) •
Source Direct / Balance • / •
Pure Modes 3
INPUTS/OUTPUTS
Audio Inputs 4
Phono Input: MM •
Optical / Coaxial 2 / 1
USB-A 1 (rear)
Recorder Out •
Pre-out Subwoofer
Gold Plated Cinch •
Speaker Terminals Marantz SPKT-1+
Number of Terminals 1 pair
Remote Control Bus Terminal •
Headphone Out • (Front)
NETWORK
HEOS Multi-Room and Streaming / Network Audio Streaming
Lossy Formats: MP3 / WMA / AAC • / • / •
Lossless Formats: FLAC / ALAC / WAV • / • / •
FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 • / • / •
DSD Audio Streaming up to DSD5.6
Gapless Playback • (FLAC, WAV, ALAC, DSD)
AirPlay2 Audio Streaming •
Internet Radio (Tune In) • (TuneIn)
Spotify Connect, Deezer, TIDAL, Napster, Soundcloud* • / • / • / • / •
Supported Voice Agents: Alexa/Google Assistant/Siri • / • / •
Compatible with Remote APP (iOS/Android) HEOS
Ethernet / Wi-Fi • / • (dual antenna/dual band)
Bluetooth •
•
• / •
SPECIFICATIONS
Power Output (8 ohm) 60 W
Power Output (4 ohm) 80 W
Frequency Response 5 Hz – 100 kHz ±3 dB
Total Harmonic Distortion (8 ohm, 20 Hz - 20 kHz) 0.02%
Damping Factor (8 ohm, 20 Hz - 20 kHz) 100 and over
Input Sensitivity: MM 2.0 mV / 47 kΩ/kohms
Signal to Noise Ratio: MM 87 dB (5 mV input, 1 W output)
Input Sensitivity: High Level 220 mV/18 kΩ
Signal to Noise Ratio: High Level 115 dB (2 V input, rated output)
OTHERS
FL Display 3 line OLED
Variable Cross Over (subwoofer) • (40/60/80/100/120Hz)
IR Learning for TV remote •
Auto Power On / Off Optical In 1 / Optical In 2 / Coaxial In
Sleep Timer •
GENERAL
Available Colours
Metal Front Panel •
Power Consumption 220W
Standby Consumption (network control on) 4.6W
Standby Consumption 0.3W
Detachable Power Cable •
Remote Control •
System Remote Function •
Maximum Dimensions (W x D x H) 440 x 379 x 125mm
Dimensions Packed (W x D x H) 547 x 469 x 235mm
Weight 10.8kg
Weight packed 12.3kg
EAN
EU
UK
PM7000N/N1B
PM7000N/N1SG
PM7000N/T1B
PM7000N/T1SG 4951095071139 Silver-Gold
4951035071045
4951035071052
4951095071122
(Default: OFF)
Black / Silver-Gold
*excluding antennas
Black
Silver-Gold
Black
Sound United Europe
A Division of D&M Europe B.V.
Beemdstraat 11
5653 MA Eindhoven
The Netherlands
www.marantz.eu
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by D&M Holdings Inc. is under license. The Spotify software is subject to third party licenses found here:
www.spotify.com/connect/third-party-licenses. Other trademarks and trade names are those of their respective
owners. Marantz is a trademark or registered trademark of D&M Holdings, Inc.
*Design and specifications are subject to change by Marantz without notice.
