Marantz AV7702mkg Quick Start Manual

AV Pre Tuner

AV7702mk

g

Bitte zuerst lesen... / Lisez-moi en premier.... / Nota preliminare.... /

Lea esto primero.... / Lees mij eerst... / Läs detta först... /

Прочитайте в первую очередь... / Przeczytaj to najpierw....

Quick Start Guide

Read Me First....

Kurzanleitung / Guide de démarrage rapide / Guida di Avvio Rapido /

Guía de inicio rápido / Snelhandleiding / Snabbstartsguide /
Краткое руководство пользователя / Skrócona instrukcja obsługi

ENGLISH

DEUTSCH

FRANÇAIS

ITALIANO

ESPAÑOL

NEDERLANDS

SVENSKA

РУССКИЙ

POLSKI

1

Thank you for choosing a Marantz Pre
Tuner. This guide provides step-by-step
instructions for setting up your Pre Tuner.

Please do not return this unit to the
store – call for assistance.
If you need help… :

If you need additional help in solving
problems, contact Marantz customer
service in your area.
www.marantz.com

Welcome Before You Begin

Required for Setup

TV RCA cables XLR cables

HDMI cable Power amplifier Speaker systems /

Speaker cables

Optional

LAN cable Wi-Fi router

• When connecting this unit to a device that is compatible with the Deep Color, 4K and ARC
functions, use a “High Speed HDMI cable with Ethernet” that displays the HDMI logo.

• These drawings are for illustrative purposes only and may not represent the actual product(s).

or

or

2

What’s In the Box

Quick Start Guide FM indoor antenna

Owner’s Manual AM loop antenna

Safety Instructions Sound calibration

microphone

Notes on radio Sound calibration

microphone stand

Cable labels Remote control unit

Pre Tuner R03/AAA batteries

Power cord External antennas

for Bluetooth/
wireless connectivity

The supplied Sound calibration microphone stand is convenient for use when
performing Speaker Calibration. Using your own tripod or the supplied Sound
calibration microphone stand enables settings to be automatically configured to
the optimum listening environment, providing exceptionally high performance.

3

Important: External Antennas

The removable external antennas are required for both
Bluetooth and Wireless network connectivity. Please make
sure to connect the antennas before attempting to use the
Bluetooth or Wi-Fi features of the AV7702mkg.

n Connecting the external antennas for

Bluetooth/Wireless connectivity

For each of the two antennas:
q

Place the antenna evenly over the antenna terminal
located at the upper left or right corner of the rear panel.

w

Turn the antenna clockwise until it is fully connected. Do
not over tighten.

e Rotate the antenna upwards for the best possible reception.

q w e

4

1

Installing batteries in the
remote control unit

R03/AAA batteries

There are three steps to the setup
process.

1

Installing batteries in the remote control unit

2

Connecting the Pre Tuner, Power Amplifier
and your TV

3

Following the On-Screen Setup Assistant

Setup

5

2

Connecting the Pre Tuner, Power Amplifier and your TV

2.1) Place the Pre Tuner and Power
Amplifier near your TV and connect
the power cord.

TV

Pre Tuner

Power Amplifier

TV

Pre Tuner

Power cord
(supplied)

Connect to household
power outlet
(AC 230 V, 50/60 Hz)

6

2.2) Connect to the network.

Wired LAN

When connecting cables (wired connection), connect a LAN
cable between your Pre Tuner and your network router.

Internet

Modem

Router

To WAN side

To LAN port

Wireless LAN

When connecting to wireless LAN (Wi-Fi), follow the
instructions in “Connecting the external antennas for
Bluetooth/Wireless connectivity” and connect the antennas.

Router with
access point

To WAN side

Internet

Modem

7

2.4) Turn on the TV.

TV remote control unit

2.5) Select the appropriate HDMI input
on your TV.

HDMI

TV/

VIDEO

INPUT

or

TV remote control unit

2.3) Connect the Pre Tuner to your TV
with an HDMI cable.

(ARC)

HDMI IN

(ARC)

HDMI OUT

MONITOR 1

HDMI cable

Pre Tuner (Rear panel)

ARC (Audio Return Channel) :

If your TV supports ARC, your TV can send audio back to the AV pre tuner
when you are using your TV’s built-in video sources (TV tuner, Smart TV
streaming services, etc…) ARC requires that you enable HDMI CEC on
your TV. Please refer to your TV’s Owner’s Manual for instructions on how
to setup HDMI CEC. Note that some TV manufacturers use other names
for the HDMI CEC function.

8

2.6) Turn on the Pre Tuner.

• Press X to turn on the Pre Tuner.

2.7) Verify the connection.

• Verify that you can see this screen on your TV.

AV Preamp Setup Assistant

Please select a language...

Deutsch

Français

English

Italiano

Español

Nederlands

Svenska

Pусский

Polski

If this screen is not displayed, please go back and
retry the steps again in the recommended sequence.

9

3

Following the On-Screen Setup Assistant

The Setup Assistant will walk you through connecting and
configuring your Power Amplifier and components to your
Marantz Pre Tuner. Please use the remote control and
follow the on-screen instructions.

AV Preamp Setup Assistant

Please select a language...

Deutsch

Français

English

Italiano

Español

Nederlands

Polski

Pусский

Svenska

10

n Printable Version

Access the print version of the owner's manual from the

included CD-ROM or select the “PDF Download” link
from the Online Version.

Insert the disc into
your PC.

Follow the screen or double click on

the PDF le.

1

2

Owner’s Manual

n Online Version

Enter the following URL into your web browser:
manuals.marantz.com/AV7702MK2/EU/EN/

PDF

Overview

Connections

Playback

Settings

Tips

Appendix

PDF Download

AV Pre Tuner

AV Pre Tuner

WEB Manual
