WARNINGS AND SAFETY INFORMATION
Verify that the electrical circuits have appropriate grounding and
overload protection.
Verify there is adequate ventilation around the device, and that ambient
temperatures meet equipment operation specifi cations.
The XVW-P30 is designed for indoor use only. DO NOT place this outdoors.
DO NOT install in or near hot or humid places, such as a kitchen or
bathroom. Take care to minimize exposure to excessive heat or moisture.
Small parts and plastic bags used for packaging may be harmful to small
children. KEEP All ACCESSORIES OUT OF THE REACH OF CHILDREN!
The XVW-P30 may become hot when in use for extended
time periods. This is normal and is not a malfunction. DO NOT install where
it will be exposed to paper, cloth or other fl ammable materials.
REGULATORY COMPLIANCE
The device complies with internationally recognized standards covering human
exposure to electromagnetic fi elds from radio devices. This equipment also
complies with FCC radiation exposure set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency
exposure limits, human proximity to the antenna shall not be less than 20 cm (8
inches) during normal operation.
Unauthorized antennas, modifi cations, or attachments could cause damage and
may violate regulatory approvals. Any
changes or modifi cations not expressly approved by the party responsible for
compliance could void the authority to operate the equipment.
Equipment version marketed in the U.S. is restricted to usage of channels 1-11 only.
7
Health and Safety Recommendations
Warnings for the use of Wireless Devices: Please observe all warning notices
with regard to the usage of wireless devices
Potentially Hazardous Atmospheres: You are reminded of the need to
observe restrictions on the use of radio devices in fuel depots, chemical
plants etc. and areas where the air contains chemicals or particles (such
as grain, dust, or metal powders).
Safety in Hospitals: Wireless devices transmit radio frequency energy
and may affect medical electrical equipment. When installed adjacent to
other equipment, it is advised to verify that the adjacent equipment is not
adversely affected.
RF Exposure Guidelines
Safety Information: The device complies with internationally recognized standards covering human exposure to electromagnetic fi elds from radio devices.
Warning: Exposure to Radio Frequency (RF) Radiation:
The radiated output of this device is below the FCC radio frequency exposure
limits. Nevertheless, the device should be used in such a manner that the
potential for human contact during normal operation is minimized.
The end user must avoid any extended human RF exposure directly in front
of the device, up to a distance of 20cm, when unit is on.
When servicing the equipment and selecting a location for the antennas, it
is important to note that a minimum distance of 20cm is required between
personnel and the device or antenna to comply with the radio frequency
exposure limit.
The antenna used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located
or operating in conjunction with any other antenna or transmitter.
8
The following safety precautions should be observed:
Do not hold any component containing the radio such that the antenna is
very close or touching any exposed parts of the body, especially the face or
eyes, while transmitting.
FCC Statement—Wireless FCC 2.4GHz 802.11bgn
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
FCC Caution: Any changes or modifi cations not expressly approved by the
party responsible for compliance could void the user’s authority to operate
this equipment.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
9 10
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
NOTE: (1)The manufacturer is not responsible for any
radio or TV interference caused by unauthorized
modifi cations to this equipment.(2) To avoid
unnecessary radiation interference, it is
recommended to use a shielded RJ45 cable
Industry Canada (RSS-Gen Issue 2)
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2)this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux
appareilsradio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1)l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur
de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
The device meets the exemption from the routine evaluation limits in section
2.5 of RSS 102 and compliance with RSS-102 RF exposure, users can obtain
Canadian information on RF exposure and compliance.
Le dispositif rencontre l’exemption des limites courantes d’évaluation dans la
section 2.5 de RSS 102 et la conformité à l’exposition de RSS-102 rf, utilisateurs
peut obtenir l’information canadienne sur l’exposition et la conformité de rf.
This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter. This equipment should be installed and
operated with a minimum distance of 20 centimeters between the radiator
and your body.
Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps
qu’aucune autre antenne ou émetteur. Cet équipement devrait être installé et
actionné avec une distance minimum de 20 centimètres entre le radiateur et
votre corps.
CAN ICES-3 (B) /NMB-3 (B)
Industry Canada ICES-003 Compliance Label:
CAN ICES-3 (*) /NMB-3 (*)
CE Declaration of Conformity:
Hereby, Luxul, 14203 Minuteman Drive, Suite 201, Draper, Utah,
84020, declares that this Luxul XVW-P30-E is in compliance
with the essential requirements and other relevant provisions
of Directive 1999/5/EC.
For a copy of this report send a self addressed stamped
envelope to: Luxul CE, 14203 Minuteman Drive, Suite 201,
Draper, Utah, 84020.
14203 Minuteman Drive, Ste 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450
© 2014 Luxul. All Rights Reserved.
Other trademarks and registered trademarks are the property of their respective owners
LUX-QIG-XVW-P30-v2 1113140428
Quick Install Guide
Wireless Range Extender/Bridge
Use the XVW-P30 to:
Extend the Coverage Area of an
Existing Wi-Fi Network
Create a bridge to connect
Ethernet devices to your network
Deliver Reliable Wi-Fi Performance
at Speeds up to 300Mbps
Simplify Wi-Fi Expansion while
Minimizing Setup Time and Costs
Simply Connected
XVW-P30/XVW-P30-E
Quick Install Guide
Model Number: XVW-P30/XVW-P30-E Wireless Range Extender/Bridge
FCC ID: W59XVWP30 IC: 8584A-XVWP30
© 2014 Luxul. All Rights Reserved.
No part of this publication may be modifi ed or adapted in any way, for any
purposes without permission in writing from Luxul. The material in this manual
is subject to change without notice. Luxul reserves the right to make changes
to any product to improve reliability, function, or design. No license is granted,
either expressly or by implication or otherwise under any Luxul intellectual
property rights. An implied license only exists for equipment, circuits and
subsystems contained in this or any Luxul product.
FCC COMPLIANCE
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
DOCUMENT CONVENTIONS
The following alert is used to indicate notable situations:
NOTE: Tips, hints, or special requirements that you
should take note of.
CAUTION: Care is required. Disregarding a caution can
WARNING!: Indicates a condition or procedure that
result in data loss or equipment malfunction.
could result in personal injury or
equipment damage.
CONTACT LUXUL
Sales
P: 801-822-5450
E: sales@luxul.com
Technical Support
P: 801-822-5450
E: support@luxul.com
PACKAGE CONTENTS
The following items should be included in the box:
One: XVW-P30 or XVW-P30-E
One: Quick Install Guide
NOTE: If any of the listed items are missing or damaged,
please contact the reseller from whom you
purchased for return/replacement.
HARDWARE DESCRIPTION
XVW-P30: U.S. Plug (Type A)
XVW-P30-E: Euro Plug (Type C)
View of the Ethernet Ports, USB Ports and LEDs. XVW-P30 shown.
2
LEDs
This device has two LEDs, positioned on the front lower right corner.
The LEDs are labeled: Power, Status.
LED Indicators
Indicator Name Description
Power/Green On The power is on
Off No Power check connections
Status/Blue
Green
Green The device is confi gured and
Blue The device is not confi gured but
Flashing
Blue/
Green
attached to a wireless network
is broadcasting and ready for
confi guration
Repeater is not connected to the
wireless router/AP. Check password
or status of wireless router/AP
Ethernet Ports
With 2 Ethernet ports, this device provides a simple method for
creating an Ethernet Bridge Link.
Bottom Ports
3 4 5 6
USB Port and Reset
The right panel has the Reset/Factory Default Button and
USB charging port.
Right Port and Reset
USB Charging Port
The USB on the right panel is a Charge Only Port.
NOTE: Please note this should charge most USB
powered devices but is not certifi ed by any device
manufacturer. (May not support some tablets).
Reset/Factory Default Button
The Reset button is used to clear the current settings and restore
factory default settings.
To Restore the Default Settings: With the XVW-P30/XVW-P30-E
powered on, press and hold the Reset button for 6 seconds. The
Status LED turns off, after a few seconds when the reset button is
released and after a the blue LED will begin to blink. The power LED
will stay solid. The device will be reset to factory defaults.
INSTALLATION
System and Power Requirements
Computer or wireless device supporting TCP/IP and equipped
with a Web browser. Supported Web browser versions include
the most current versions of Firefox, Safari, Chrome, and Opera.
The Web browser is used for confi guration.
Available power outlet
Confi guration
Plug XVW-P30/XVW-P30-E into power outlet.
Wireless Confi guration: Connect your wireless client device
to the Wireless network SSID: Luxul-XVW-P30.
Wired Confi guration: Connect an Ethernet cable from your
client device to an RJ-45 port on the XVW-P30/XVW-P30-E.
Open a web browser and enter the IP address 192.168.0.11
Select the mode you want to use: Range Extender or Bridge
Range Extender: Extends wireless coverage of your existing
2.4GHz network and allows devices to be connected to the
XVW-P30/XVW-P30-E Ethernet ports for network access.
NOTE: Range Extender mode may reduce the wireless
data rates of your network.
Bridge: Allows Ethernet devices to be connected to the
RJ-45 ports on the XVW-P30/XVW-P30-E without extending
the wireless network.
You will be presented with a list of SSIDs of available Networks
to which the XVW-P30/XVW-P30-E may be connected. If you do
not see the wireless router/AP you’re looking for, press the Scan
button to refresh the list.
You will be prompted to enter the password of the wireless
router/AP to which the XVW-P30/XVW-P30-E is connected.
After entering the password, it will take approximately 30
seconds to fi nish the setup. Check the Status LED on the device.
Solid green: the device has been successfully installed and
is now working.
Flashing blue/green: there was a problem with the setup
process, (most likely the password was not entered correctly).
Reset/Factory Default the wireless range extender and repeat
setup process.
Loading...
