READ ME FIRST
QUICK INSTALL GUIDE
12-Port/8 PoE+ Gigabit
Managed Switch
XMS-1208P
Includes:
XMS-1208P 12-Port/8 PoE+ Switch
Rack Mount Kit
Rubber Feet
Power Cord
INSTALLATION AND SETUP
Physical Installation
1
The XMS-1208P can easily be installed in a standard 19” rack. Two mounting ears
are included for installing and stabilizing the switch. When attaching the mounting
ears and installing the switch in a rack, please refer to the following illustration:
Rack-mounting the XMS-1208P
Use the included screws to attach the mounting ears to each side
of the switch.
Mount the switch in the rack with the LEDs facing outwards. Be sure the
switch is level and properly secured in the rack.
Desktop Setup
For use as a desktop device, position and apply the included rubber feet to the
bottom of the XMS-1208P.
Connecting Ethernet and Power
2
Ethernet and Power Connections
Use one of the ten Ethernet ports to connect the XMS-1208P to any Ethernetenabled device, including servers, routers, or other switches. No crossover cable
is necessary.
The XMS-1208P supports 10/100/1000 Mbps Ethernet; 10/100 Mbps half/
full-duplex mode and 1000 Mbps full-duplex mode. Ports 1-8 are PoE+ and
are enabled by default. Ports 9 and 10 are Gigabit Ethernet only (non PoE),
while ports 11 and 12 are Gigabit SFP ports.
Use the included power cable to connect the XMS-1208P to a surgeprotected outlet. The AC input socket is on the rear panel. The built-in
power supply supports 100~240VAC at 50-60Hz.
Network Cabling
Luxul recommends at least Cat-5e unshielded twisted pair (CAT5e UTP)
cabling. To ensure best performance and stable data transmission at 1000
Mbps, use Category-6 unshielded twisted pair (CAT6 UTP).
If you intended to use optical fiber to extend the network beyond the 300foot limit of twisted pair Ethernet, SFP modules are required (not included).
c CAUTION: Multiple Uplink channels can create loops, resulting in
network failure. Ensure only one Uplink channel exists
between switches or between the XMS-1208P and a router.
n NOTE: When powering up, the port LEDs may take a moment to
initialize. This is normal as the XMS-1208P initialization and
startup sequence completes.
n NOTE: The XMS-1208P has an internal 130W power supply. Do not
exceed 25.5W each or 130W combined consumption of all
external PoE devices.
Preparing for Access
3
IP Addressing
If the XMS-1208P is connected to a network with a 192.168.0.X address
scheme, and your computer shares a similar address on the same network,
you can skip to the next step, Access and Setup
n Note: If another device on your network shares the address
192.168.0.3, you’ll need to temporarily reassign or remove
that device while you configure the XMS-1208P.
If your network uses an address scheme other than 192.168.0.X, you’ll need
to set a temporary static IP address on the computer you’re using for
configuration. To do so, set the IP address of your computer to an address
in the 192.168.0.X range, then set the Gateway/Router address to 192.168.0.3
(the default IP address of the XMS-1208P).
Once you’re finished configuring the switch, you can return your computer’s IP configuration to normal, typically “Obtain Automatically/DHCP.”
n Note: Visit http://luxul.com/ip-addressing to learn more about
changing your computer’s IP address and getting connected.
Access and Setup
4
Getting Connected
Use an Ethernet cable to connect your computer to the XMS-1208P, then
power on the switch.
.
Logging In
To access the XMS-1208P web configuration, open your web browser and
enter the switch’s default 192.168.0.3 IP address in the address field. Log in to
the switch using the default user name and password:
Default IP: 192.168.0.3
Username: admin
Password: admin
Select the menu items on the left to view and/or modify the configuration.
Hardware Operation
5
Front Panel
The front panel of the XMS-1208P includes 1 console port, 10 Gigabit RJ-45 ports,
and 2 Gigabit SFP ports as well as LED status indicators for each port. A mode/
reset button switches the display between Link/Activity and PoE modes.
XMS-1208P Front Panel View
LED Indicators
The LED indicators on the XMS-1208P include System, Link/Act and PoE LEDs,
and an LED for each port. These LED indicators show the operating status of
the XMS-1208P and each port connection.
Mode/Reset Button to Change LED Functionality
Tapping the Mode/Reset button briefly switches the port indicators between
displaying port link speed and PoE status.
The following chart shows the LED indicators of the XMS-1208P along with an
explanation of the indicator’s properties:
Indicator
Name
System
Port Link/
Act Status
1-12
Port PoE
Status 1-8
Note: At startup, the port LEDs will flash briefly during a self-test.
Description
Flashing Indicates normal operation.
On Indicates a malfunction. Contact support.
O Indicates startup/initialization process or
that power is not on.
Green 1000Mbps device connected to the port.
Yell o w 10/100Mbps device connected to the port.
Flashing Port receiving or transmitting data.
O Nothing connected to the port.
Green Switch is providing PoE power to a device.
Yell o w PoE is o due to a fault or because the
connected device is exceeding power limit.
O Port disconnected or link failed.
Mode/Reset Button to Reset/Restore
The Reset button (located at the center of the front panel) is
used to reset (reboot) the switch, or to restore the switch to factory
default settings.
X
To Reboot/Reset the Switch: With the XMS-1208P powered on, press
the Reset button for approximately three seconds until the Link/Act and
PoE LEDs both light, then release the button.
c CAUTION: Do not hold the button for more than four seconds.
Doing so could erase all settings and restore
factory defaults.
X
To Restore Default Settings: With the XMS-1208P powered on, press
and hold the Reset button approximately eight seconds, until both the
Link/Act and PoE LEDs turn o, then release the Reset button and the
switch automatically restores factory default settings and reboots. Once
the System LED starts flashing again, the XMS-1208P is running with
factory defaults.
c CAUTION: Please note that restoring Default Settings will remove
any/all custom configuration.
