Logitech HARMONY 885 VERSION 1.1 User Manual

Harmony 885	User Manual

Click here to download and print the PDF version of this manual.

885 Harmony Remote User Manual

Congratulations on the purchase of your Harmony remote! True system control is now at your fingertips. This User Manual will introduce you to the basic online setup process, customizations and main features of your Harmony remote.

The Harmony remote web site is constantly updated to improve your experience. If in doubt, follow the information and instructions on the web site. Select a topic from the following list to learn more about your Harmony remote:

INTRODUCTION

•Getting to Know Your Harmony Remote

•Begin the Setup Process

!Step 1: Create your Harmony Login

!Step 2: Complete the Online Setup Process

USING YOUR HARMONY REMOTE

•Using the Glow Button

•Recharging the Battery

•Removing the Remote From the Base Station

•Selecting an Activity

•Viewing the Status and Navigation Bars

•Displaying On-screen (LCD) Help on Your Harmony Remote

!Types of On-Screen (LCD) Help Available

!Using the Harmony Assistant

•Controlling Individual Devices

•Using the Teletext Buttons

•Using System Options

CUSTOMIZING YOUR HARMONY REMOTE

•Customizing the Screen (LCD) on Harmony Remote

!Adding your Favorite Channel Icons

!Changing the Behavior of Buttons within an Activity

page 1

v. 1.0

Harmony 885	User Manual

!Adding Custom-Labeled Buttons

•Changing the Settings for your Harmony Remote

•Teaching Infrared (IR) Commands

!Using the Infrared Sensor

!Naming an Infrared Command

GETTING ADDITIONAL HELP

!Finding Answers to Your Questions

!Troubleshooting Your Harmony Remote

Back to Top

v. 1.0

page 2

Harmony 885	User Manual

Introduction

The Harmony remote is an Internet-powered universal remote control. Your Harmony remote can control most devices that understand infrared (IR) signals.

The configuration of your Harmony remote is simple:

•You will be prompted to answer questions about your entertainment devices to create your own personal Harmony remote configuration.

•Your answers will provide us with a description of the entertainment devices you want to control, how they are set up, and your preferences for controlling them.

•If one of your devices is not in the Harmony remote web site's database, the Harmony web process will learn about your device and add it to your configuration.

•Once you have told us about your devices, you will then be guided through setting up Activities. Creating Activities is simple: you will be prompted to indicate the devices you use within an Activity and how you want to control specific features, such as the volume, within that Activity.

An Activity is a set of commands the Harmony remote sends to your entertainment system to turn on the necessary devices. Once you have selected an Activity, the functionality of each button on your Harmony remote is automatically configured for that Activity. Additionally, the screen (LCD) buttons will give you access to other commands for that Activity, which cannot be set to the standard buttons. This is known as Activity mode.

Example

For the Watch Television Activity, the Harmony remote sends commands to your entertainment system to turn on the necessary devices so you can watch television. The remote will automatically be configured for the Activity based on the answers you selected during the online setup process for the Activity.

At the end of the setup process, you will have your own configuration loaded in your Harmony remote and your own personal Harmony member home page.

Return to your Harmony home page as often as you like to:

•Customize any of your Harmony remote’s features.

•Add more entertainment devices.

•Add more Activities.

Back to Top

page 3

v. 1.0

Harmony 885	User Manual

Getting to Know Your Harmony Remote

Many of the Harmony remote's buttons are standard remote buttons. However, there are buttons and other hardware that may not be so familiar to you. The extra buttons and hardware give you access to the special features of the Harmony remote.

USB Connector: Downloads your configuration from the Harmony web site. OFF: Turns all devices off with one button press.

HELP: Asks you simple questions so that your Harmony remote can fix problems you are having within an Activity.

Activities: Press Activities to view a list of Activities you have added. Press the screen (LCD) button next to the Activity you want and the Harmony remote will set up your entertainment system.

Screen (LCD): Displays help, infrared (IR) commands and any available listings.

Screen (LCD) Buttons: Use the buttons at the side of the screen to select the corresponding command. Use the right arrow button to display more commands.

Device: Lists all your devices on the screen (LCD), and allows you to select and fully control any device directly.

Teletext Buttons: This is a service provided by the television provider. Use the Teletext buttons to access this service; however, your TV set must be equipped with a Teletext decoder. While Teletext is the default setting for these buttons in the Watch TV Activity, you can customize these buttons to send different commands.

Guide: Gives user access to view program listings, if you have a device with this feature.

Media: In the Watch TV Activity press this button to view your Favorite Channels on the screen (LCD).

Left/Right Arrows: Shows more choices in the screen (LCD). Glow: Backlight glow.

Infrared Learning Port: Use this port to teach the Harmony remote commands from your original remote.

Back to Top

v. 1.0

page 4

Harmony 885	User Manual

Begin the Setup Process

Step 1: Create your Harmony Login

If the Harmony remote web site is not automatically launched, go to the Harmony remote web site and create an account.

Step 2: Complete the Online Setup Process

Once you have created your Harmony login, the online setup process begins. You will guided through a series of question-and-answer steps to complete each of the five main steps of the online setup process:

1.Identification: Requires you to create a login on our member web site.

2.Check Connection: Ensures your computer and your Harmony remote are communicating properly.

3.Set up Devices: Helps you set up a description of your personal home theater system.

4.Set up Activities: Helps you set up a description of the connections for devices that allow you to perform Activities (e.g. Watch Television Activity).

5.Update Remote: Updates your remote with your personal configuration.

The Harmony remote provides you with several features to guide you through the online setup and customization process:

Tool	Location	Description
Web setup	Harmony remote web	Provides instructional help to guide the user
	site	through a series of question-and-answer steps to
		accomplish a task.
FAQs (Frequently-	Harmony remote web	A searchable list of customer questions, with
Asked Questions)	site	answers provided by Harmony's support center.
Help button	Harmony remote web	Provides specific online help for the page you are
	site	on.

Back to Top

page 5

v. 1.0
