Logitech F0133B, F0131B, F0134B, F0132B Users Manual

Setup Installation Instalación
Logitech
®
Mobile Cordless Headset
Safety
1
English
Safety
1
English
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Caution: risk of electric shock. Do not open mains operated device.
• Do not use apparatus near water.
• Clean only with a dry cloth.
• Install in accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized plug. A polarized plug has two blades with one wider than the other. The wide blade is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Use only the power adapter provided or recommended by Logitech. For details, contact Logitech using the contact information in this manual.
• Unplug this apparatus when unused for long periods of time or during lightning storms.
• Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
• Refer all servicing to qualified service personnel.
• The appliance shall be disconnected from the mains by pulling the mains power plug. The socket - outlet shall be installed near the equipment and shall be easily accessible.
• Batteries built into device are NOT user replaceable. Discard used batteries according to the manufacturer’s instructions.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE OR SNOW.
IMPORTANT SAFETY INFORMATION – FOR POWER SUPPLY ONLY
CAUTION
ELECTRIC SHOCK HAZARD
This product operates in a frequency range that is not EU harmonized. Refer to specific country approvals marked on the packaging, prior to selling/operating in a designated country.
Features
3
English
Introduction
2
English
Introduction
Congratulations! Your new Mobile Cordless Headset will provide hours of hands-free convenience wherever you use your mobile phone.
1. Cordless Headset
2. Durable carrying case/charging station
3. Receiver for phone
Features
A. Noise canceling microphone B. Ear clip for comfortable, firm fit. C. Multi-function button. Use this
button to power on/off, and answer/end calls (if supported by
your phone). D. Earclip adjuster E. Convenient volume control and
mute button F. Indicator LED G. Rotating arm/mini-boom H. Protective carrying case and
charger
The battery may not be fully charged when purchased. For instructions on charging your headset, please see “Re-charging your headset” on page 7.
1
2
3
Note: The receiver for your phone may be different.
A
B
D
E
G
H
C
F
Charging Your Headset
5
English
Installation
4
English
Installation
Headset cl ips to ear by pressing the earclip adjuster and sliding over ear. Place microphone so it is pointing toward the corner of your mouth, but approximately 2 cm away from your face.
Receiver connects to bottom/top/side of phone (your receiver may look different than the one shown).
Charging Your Headset
Receiver and headset fit into carry case to charge.
Plug included adapter into carry case and into wall outlet, or plug car charger (sold separately at www.logitech.com) into your automobile’s power outlet.
abc def
1C23
jklghi mno
4 56
tuvpqrs wxyz
7 89
abc
0
abc def
1C23
jklghi mno
4 56
tuvpqrs wxyz
7 89
abc
0
Using Your Headset
Re-charging Your Headset
7
English
6
English
Re-charging Your Headset
Your carrying case also doubles as a charger for your Mobile Cordless Headset. Charging your headset is simple if you follow these steps (see diagram on page 5):
1. Place the receiver and headset in the appropriate spots in the charger. Make sure that all
contacts are snug.
2. Plug the power adapter into the charger.
3. Connect the power adapter to a nearby electrical outlet.
4. The LED lights will be red if charging. If the LED is orange, the connection is not sufficient.
Tighten the connection until the LED turns red (or green, if the headset is already fully
charged).
5. When the LED turns green, your headset is fully charged. It should only take approximately
2 hours to fully charge your headset.
6. Remove both the receiver and the headset from the charger.
7. Once charged, gently connect the receiver to your mobile phone. The Logitech logo
should be facing the same direction as your phone keys.
Headset and receiver LED
There are two LED lights, one on the receiver and another on the headset. They will flash
at different speeds and display different colors according to certain conditions. The list
below describes what these mean.
Talk Mode Flash Rate
On Slow
Muted Fast
Off No Flash
Operation Mode Color
GREEN Normal or Fully Charged
ORANGE Lost Connection or Problem with Charging
RED Low Battery or Charging
Using Your Headset
Turning the headset on and off
Pushing the multi-function button and holding for 2 seconds will turn on the headset. To turn the headset off, simply push the multi-function button and hold for 2 seconds. This feature will work even if your phone does not support the multi-function call answer/end feature.
Automatic power down
The headset will power down and turn off after 5 minutes of no activity. If the headset doesn't detect a signal from the receiver for 30 seconds, then the headset will also turn itself off. This will help conserve power.
Answering/ending a call
To answer or end (hang-up) a phone call, simply push the multi-function button. When pushing the button, do NOT hold the button; release it after pushing. Holding the button for 2 seconds will turn off your headset. NOTE: Not all phones support the call answer/end feature.
Adjusting call volume
There are eight volume settings. To adjust the headset’s volume, simply push the “+” button to raise it, or the “ - ” to lower it. A tone will sound indicating the change in volume. NOTE: When the headset is turned OFF, the current volume level is saved and stored. When the headset is turned back on, the saved volume level is engaged.
Muting a call
The headset can be muted by pushing both the “+” and “ - ” buttons at the same time. To stop muting, simply push either the “+” or the “ - ” buttons. When your headset is muted, the LED will flash at a faster rate than normal.
Adjusting the mini-boom
The mini-boom should be stored in its “closed” position, with the boom arm’s microphone element resting just above the headset’s multi-function button. To adjust, swivel the mini­boom gently and stop where the microphone element is as close to your mouth as possible. IMPORTANT: DO NOT FORCE THE MINI-BOOM. IF YOU FEEL THE MINI-BOOM “STOPPING”, DO NOT FORCE THE MINI-BOOM. FORCING THE MINI-BOOM PAST THE HARD STOP IN EITHER DIRECTION WILL DAMAGE YOUR HEADSET.
Synchronizing the headset with the receiver
This will be done automatically after turning on the headset. Follow the directions for turning on your headset. The headset will then send out a signal to the receiver. The receiver will “wake-up” and search for the headset every second. If the LED lights are green, then they are synchronized with each other. As long as the headset continues to send the signal, the receiver will be synchronized with the headset.
Frequently Asked Questions
9
English
Frequently Asked Questions
8
English
Does my Ericsson® receiver have a battery?
No, the Ericsson® receiver actually draws power from the mobile phone and does not have
its own battery. Therefore, the receiver will not need to be re-charged. However, the
Ericsson® headset does have a battery and will need to be re-charged. The receiver can still
be stored in the carr ying case.
Is there a power saving mode for my headset?
Yes. If the headset is not used for 5 minutes, the device will turn itself off to conserve
power.
Is the signal from my headset to my mobile phone private?
Yes. Each headset and receiver are assigned a unique identification number. This unique ID
is part of the signal from the headset to receiver. The process of encoding the signal and
assigning each packet an ID unique to the headset protects the user from having their
signal intercepted.
What if there is interference or a poor signal on my headset?
Refer to the LED color chart on page 7 for information about what the LED colors mean.
That will help you determine what could be causing the problem. There are a few things
that could be happening:
1. Your headset is too far away from your phone and receiver. You need to be within 10 feet of your phone.
2. Your headset or receiver could be low on power. If this is the case, simply re-charge them.
3. You may be in a location where there’s a strong signal interfering with your headset’s signal. In this case you will probably have to change locations until the interference is no longer a problem.
Frequently Asked Questions
Can I use my headset on a plane?
No. Any wireless/RF device can not be used on an airplane.
How long (approximately) should it take to fully charge my headset?
It should take approximately 2 hours to charge your headset. The LED will turn green as charging nears completion, and a trickle charge will continue for an additional 22 minutes.
What happens if the signal from the headset to the receiver is lost?
A lost signal between the headset and receiver could be caused either by a low battery or if the receiver is out of the headset’s range. If this occurs, return the headset to within 10 feet of the receiver. If the battery is low, re-charge the headset and receiver at your next opportunity.
Should the headset be stored in the charger and charging while not in use?
It can be. No damage will occur by storing the unit in the case. The charge will stop if the headset is fully charged, so it is fine to store the headset in the charger.
Does it matter if phone is off or on while attaching the receiver?
No. If the phone is off, there will be no data to transfer to the headset and no data from the headset can be transferred to the phone. When the phone is turned on it will detect that the receiver is present and everything will work fine.
What phones are my cordless headset compatible with?
You need the receiver that works with your particular mobile phone. There are two items to look at when determining which receiver and headset you’ll need. First is the manufacturer, and second is the model. For example, if you own a Nokia® 5160 mobile phone, you’ll need the appropriate Nokia® receiver and headset, since that receiver and headset supports all 5100 series Nokia® phones.
What if my phone doesn’t support the multi-function button?
Unfortunately, not all 2.5mm phones will support the multi-function button on your headset. If this is the case, simply use your mobile phone to answer and end calls. All phones will support the volume control feature. The multi-function button can still be used to power on/off your headset.
Where should I place the mini-boom?
For optimal audio quality, place the microphone at the end of the mini-boom as close to your mouth as possible, and adjust it to approximately 2 cm away from your face.
Is there a car adapter available?
Yes. You can find it at www.logitech.com.
Mobile CordlessManualNAFTA.qxd 5/2/03 6:00 PM Page 10
Warranty
11
English
Technical Specifications
10
English
Technical Specifications
Expected Battery life
This is simply a guide to how long your headset battery is expected to last before needing to be re-charged.
Mode Battery Life On >6 hrs
Off >300 hrs
North American headsets
• Full duplex (bi-directional communication)
• Rechargeable lithium ion battery
• Designer charging case 4.2 V.D.C.
• Broadcasting range of 10 feet
• Operates in North American (902MHz-928MHz) frequency bands
• Telephone voice quality speech transmission
• Security ID for communications between transmitter and receiver boards
• 20mA maximum current draw
• Talk time up to 6 hours, standby time of 300+ hours
• Multi-channel solution with automatic channel switching assures a better signal
European headsets
• Full duplex (bi-directional communication)
• Rechargeable lithium ion battery
• Designer charging case 4.2 V.D.C.
• Broadcasting range up to 3 meters
• Operates in European (433MHz or 863-865 MHz) frequency band
• Telephone voice quality speech transmission
• Security ID for communications between transmitter and receiver boards
• 20mA maximum current draw
• Talk time up to 6 hours, standby time of 300+ hours
Limited Warranty
Logitech warrants that any hardware product accompanying this documentation shall be free from significant defects in material and workmanship for a period of two (2) years from the date of purchase. Logitech’s limited warranty is nontransferable and is limited to the original purchaser. This warranty gives you specific legal rights, and you may also have other rights which vary under local laws.
Remedies. Logitech’s entire liability and your exclusive remedy for any breach of warranty shall be, at Logitech’s option, to: (a) repair or replace the hardware, provided that the hardware is returned to the point of purchase or such other place as Logitech may direct, with a copy of the sales receipt, or (b) refund the price paid. Any replacement hardware will be warranted for the remainder of the original warranty period or thirty (30) days, whichever is longer. These remedies are void if failure of the hardware has resulted from accident, abuse, misapplication, or any unauthorized repair, modification or disassembly. Upon request from Logitech, you must prove the date of original purchase of the hardware by a dated bill of sale or dated itemized receipt.
DISCLAIMER OF WARRANTY. THE WARRANTIES EXPRESSLY SET FORTH IN THIS AGREEMENT REPL ACE ALL OTHER WARRANTIES. LOGITECH AND ITS SUPPLIERS EXPRESSLY DISCLAIM ALL OTHER WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD-PARTY RIGHTS WITH RESPECT TO THE HARDWARE. NO LOGITECH DEALER, AGENT, OR EMPLOYEE IS AUTHORIZED TO MAKE ANY MODIFIC ATION, EXTENSION, OR ADDITION TO THIS WARRANT Y. Some jurisdictions do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
LIMITATION OF LIABILITY. IN NO EVENT WILL LOGITECH OR ITS SUPPLIERS BE LIABLE FOR ANY COSTS OF PROCUREMENT OF SUBSTITUTE PRODUCTS OR SERVICES, LOST PROFITS, LOSS OF INFORMATION OR DATA, OR ANY OTHER SPECIAL, INDIRECT, CONSEQUENTIAL, OR INCIDENTAL DAMAGES ARISING IN ANY WAY OUT OF THE SALE OF, USE OF, OR INABILITY TO USE ANY LOGITECH PRODUCT OR SERVICE, EVEN IF LOGITECH HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO C ASE SHALL LOGITECH’S AND ITS SUPPLIERS’ TOTAL LIABILITY EXCEED THE ACTUAL MONEY PAID FOR THE LOGITECH PRODUCT OR SERVICE GIVING RISE TO THE LIABILIT Y. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. The above limitations will not apply in case of personal injury where and to the extent that applicable law requires such liability.
FCC and IC Statements
This device complies with ICC Rules and part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: The manufacturer is not responsible for ANY interference, for example R ADIO OR TV interference, caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.
Mobile CordlessManualNAFTA.qxd 5/2/03 6:00 PM Page 12
