Logitech 920-007917 Quick Start Guide

MK235

Setup Guide

AAA

AAA

Important information

AA

document

2

Languages

English . . . . . . . . . . . . . . . . . . . 4

简体中文 . . . . . . . . . . . . . . . . . . 8

繁體中文. . . . . . . . . . . . . . . . . . 13

한국어 . . . . . . . . . . . . . . . . . . . 17

3

1

2

3

USB USB

AAA

AAA

AA

4 English

Keyboard features

13

11 1210987654321

1514

Hotkeys

Access the functions below by pressing Fn + the respective hotkey:

1. Internet

2. Email

3. Search

4. Calculator

5. Music player

6. Backward

7. Play/Pause

8. Forward

9. Mute

10. Volume down

5 English

11. Volume up

12. Print screen

13. Scroll lock

14. Pause/Break

15. Menu

Mouse features

1

2

3

1. Left and right mouse buttons

2. Scroll wheel

Press the wheel down for middle
button (function can vary by
software application)

4

5

3. On /O slider switch

4. Battery door release

5. USB Nano-receiver storage

6 English

Help with setup: keyboard and mouse are not working

•

Check the orientation of the batteries
inside the keyboard and mouse,
or replace the batteries.

•

Is the USB receiver securely plugged
into a computer USB port? Try moving
the USB receiver to a USB port closer
to the keyboard and mouse.

•

If the USB receiver is plugged into
a USB hub, try plugging it directly
into your computer.

•

Remove and any metal object
between the receiver and the
keyboard/mouse that may interfere
with reception. Try using the mouse
on a dierent surface.

•

Restart the computer.

•

If these suggestions don’t work,
download the Reconnection
Utility from www.logitech.com/
connect_utility.

7 English
