Logitech 915-000099 User Manual
User
User
Manual
Manual
Version 1.1
Version 1.0
Contents
Introduction .........................................................................................................................5
Getting to know your remote ...........................................................................................5
How your Harmony One works .....................................................................................5
Activities, devices, and inputs .......................................................................................5
The buttons on yourHarmony One ...............................................................................6
What’s on the Harmony One’s screen ..........................................................................7
Using your Harmony One ................................................................................................... 9
Viewing your touch screen menus ...............................................................................9
Selecting an Activity ......................................................................................................9
Switching between Activities .......................................................................................9
Turning off your devices ................................................................................................9
Using the Help button ................................................................................................10
Using your favorite channels ......................................................................................11
Controlling your devices individually .........................................................................11
Charging your remote .................................................................................................11
Setting the date and time ...........................................................................................12
Setting the backlight timing .......................................................................................12
Setting up your Harmony One for the rst time ..........................................................13
Overview of the setup process ...................................................................................13
1. Creating your user account .............................................................................14
2. Connecting your Harmony One to your computer ........................................14
3. Setting up the devices you want to control ...................................................15
4. Setting up Activities for your Harmony One ...................................................15
5. Updating the remote .......................................................................................16
Testing your setup ............................................................................................................17
Changing your setup ........................................................................................................18
Adding and changing your Activities .........................................................................18
Renaming an Activity ...................................................................................................18
Adding and changing your devices ............................................................................18
Adding an extra device (passthrough) to an Activity ................................................19
2
Changing how buttons work in an Activity ................................................................20
Customizing the on-remote help ...............................................................................20
Controlling the Remote Assistant ...............................................................................21
Viewing the on-remote tutorial ..................................................................................21
Personalizing your Harmony One ...................................................................................22
Changing the order of Activities on your Harmony One’s screen ............................22
Selecting or changing a theme on your Harmony One ............................................22
Adding custom-labeled buttons to an Activity ..........................................................22
Adding a slideshow to your Harmony One’s screen ..................................................23
Viewing a slideshow on your Harmony One’s screen ...............................................23
Adding additional features to your Harmony One ......................................................24
Teaching your Harmony One new commands using your old remote ............................24
Naming a new command your remote learned ........................................................24
Types of delays or speed settings ...............................................................................25
Adjusting the delay between IR commands (speed settings) ...................................26
Maintaining your Harmony One .....................................................................................27
Upgrading your Harmony One rmware ...................................................................27
Testing your remote settings after a software upgrade ...........................................27
Upgrading to a new Harmony remote .......................................................................27
Troubleshooting problems with your Harmony One...................................................28
Figuring out which inputs your system uses ................................................................30
Figuring out which type of input control you have...................................................30
Step 1— Turn on all your devices ...............................................................................31
Step 2 — Watch the TV ...............................................................................................32
Step 3 — Listen to the sound .....................................................................................32
Getting help with your Harmony One ............................................................................33
Contacting Customer Support ...................................................................................33
Finding answers to questions .....................................................................................33
Getting help with your online setup ..........................................................................33
Using the On-Remote Help .........................................................................................34
Logitech’s Harmony Remote user forums ..................................................................34
3
Appendix A - Device Information ....................................................................................35
Appendix B - Glossary ........................................................................................................36
Appendix C - Product Specication ................................................................................39
4
Introduction
The Harmony Advanced Universal Remote is your answer to effortless home
entertainment. The Activities button puts control for all your devices in one convenient
location. You can go from watching TV to watching a DVD to listening to music with the
touch of a button. You no longer need to type in codes to get your remote working with
your entertainment system. The guided online setup walks you through the step-by-step
conguration of your Harmony One with your entertainment system and then you’ll be
ready to sit back and enjoy!
Whether you’re new to Harmony products or you consider yourself an expert, this User
Manual provides you with useful information to get you going.
Getting to know your remote
How your Harmony One works
The Harmony One is an Activity-based infrared (IR) universal remote control. Using the
Harmony Remote Software, you can congure the Harmony One to control up to 15 devices.
The Harmony One delivers powerful Activity-based control by using Smart State Technology®. This technology allows the Harmony One to keep track of the devices it controls,
so it always knows which of your devices are on. Using Smart State Technology®, the Harmony One switches effortlessly from watching a DVD to listening to music on the stereo
with the touch of a button.
Activities, devices, and inputs
Activities are the basis for how the Harmony One works. Things like watching a DVD,
listening to radio, playing a game are all examples of Activities you can set up for your
remote using the Harmony Remote Software.
When you select an Activity, your Harmony One sends a series of commands to your
entertainment system to turn on the necessary devices and congure them for the
selected Activity. After you select an Activity, your Harmony One assigns the buttons on
your remote so they control the proper devices and the screen displays other commands
for that Activity.
For information on how to select an Activity, or how to switch between Activities, see
Selecting an Activity.
Devices are the components of your entertainment system. They’re things like your TV,
cable box, DVD player, or game system.
Inputs are how your devices are connected. For example, if your DVD player is connected
to your TV using the Component 1 input, then the TV needs to be set to Component 1 to
display the DVD picture properly.
5
The buttons on your Harmony One
My Activities
1/2 pages Tue 4:51
Options
Devices
Activities
Menu Info
Guide
Exit
OK
Vol
Replay
Skip
Ch
+
+
Help
1
4
7
2
5
8
0
3
6
9
E
abc
def
ghi
jkl
mno
pqrs
tuv
wxyz
clear enter
Off
Options
Devices
Guide
OK
Replay
Skip
clear
+
Exit
1
4
7
2
5
8
0
3
6
9
abc
def
ghi
jkl
mno
pqrs
tuv
wxyz
Off
Menu
Info
Ch
+
Vol
+
E
enter
Help
Activities
The Harmony One’s
buttons may have
different functions or
control different devices
depending on which
Activity you’re in. For
more information, see
Changing how buttons
work in an Activity.
The system off button turns off all the devices in the current
Activity.
The arrow keys help you page through items on the touch screen.
The function buttons are dynamic and select different functions
on the remote or the Activity.
The Activities button returns you to the Activities starting point.
The Help button starts the on-remote help.
The Menu button opens the on-screen menu for the device
selected. For information on selecting devices, see
The page up and page down arrows help you navigate through
your on-screen guide or menu.
The Info button opens the information section of your on-screen
guide.
The Exit button closes your on-screen menu or guide.
The Guide button opens your on-screen guide.
The volume button changes the volume.
The navigation pad arrows allow you to move through menus or
on-screen guides.
The channel button changes the channels.
The mute button mutes the sound.
The previous channel buttons returns you to the last channel you
were on.
The play area puts your play, pause, skip and other buttons in one
area for quick access.
+
The number pad has the digits 0-9.
6
The enter button enters a selection from the number pad.
The clear button clears an entry from the number pad.
What’s on the Harmony One’s screen
Fav. Channels
1/2 pages Tue 4:51
Current
Activity
Devices
NBS
D B C
TALKTV
T
Off
My Activities
1/2 pages Tue 4:51
Options
Devices
Watch TV
Watch a DVD
Listen to Music
Off
My Activities
1/2 pages Tue 4:51
Options
Devices
Watch TV
Watch a DVD
Listen to Music
Off
Watch a DVD
1/2 pages Tue 4:51
Devices
Chptr+
Aspect
Chptr-
Frame
Advance
Angle
Zoom
Off
Devices
1/2 pages Tue 4:51
Activities
TV
DVD
Off
Commands common to your Activity
When you select an Activity, your Harmony One’s screen
displays all the commands related to that Activity, not
just the ones related to the primary device of that
Activity. For example, if you’re watching a DVD, your
screen displays functions and commands for your DVD
and other devices you use in the Watch a DVD Activity.
Favorite channels
You can set up your favorite channels on your Harmony
so that you’ve quick access to the channels you watch
the most. You can also add your own icons to customize
the screen for your favorite channels.
Activities
The Activities screen is your starting point on the
Harmony One. From this screen, you can select your
Activities.
Devices
When you press the Devices button, the Harmony One’s
screen displays a list of your devices. From this screen,
you can control individual devices.
Options
When you press the Options button, the Harmony
One’s screen displays a list of remote options so you
can customize certain features and functions on the
remote.
7
My Activities
1/2 pages
Options
Devices
Off
A
B
C
Tue 4:51
Status icons
The status indicator ashes whenever
an IR command is being sent from your
A
Harmony One.
The battery indicator shows you the status
of the battery. To ensure your Harmony
B
stays properly charged, see Charging your
remote.
The current date and time display on your
remote screen. To set the date and time
on your remote, see Setting the date and
C
time.
8
Using your Harmony One
My Activities
1/2 pages Tue 4:51
Watch TV
Watch a DVD
Listen to Music
Off
My Activities
1/2 pages Tue 4:51
Options
Devices
Off
Watch TV
Watch a DVD
Listen to Music
Viewing your touch screen menus
The arrow keys help you page through each
menu.
The arrow keys illuminate only if there are
multiple pages.
Selecting an Activity
The Activities screen displays the Activities you
have created for the remote. You can start an
Activity by touching the item on the screen.
Switching between Activities
To select a new Activity, press the Activities button, and select the Activity you want to
enjoy.
The Harmony One will take care of powering on the needed devices, and powering off the
ones not needed.
Turning off your devices
Press the system off button to power off all the devices used in the Activity.
You don’t need to press the system off button when switching
between Activities. The Harmony One ensures the proper
devices for the Activity are On or Off.
9
Using the Help button
Because obstacles or distance can interfere with the signals the Harmony One sends
when it starts an Activity (for example, someone walks between your Harmony One and
the TV when you press Watch TV, or you’re very far away from the system when you start
an Activity), your Harmony One can become “out of sync” with your devices.
To x the problem, use the help feature on your Harmony One.
On the remote, press the Help button.
1.
Answer the questions on the Harmony One’s screen by selecting Yes or No.
2.
Based on your answers, the Harmony One re-sends the necessary commands to
synchronize with your devices.
When you’re done with this process, the Harmony One will be “in sync” with your
devices.
Before using the Help button, be sure you’ve addressed the cause of
the problem, such as removing any obstacles from the line of sight.
10
Using your favorite channels
Off
To set up your favorite channels, and to add your own icons, go to the Harmony Remote
Software:
Select the Activities tab.
1.
Under Watch TV, click Options.
2.
Select Set up Favorite Channels and follow the online instructions.
3.
When you have favorite channels set up on your Harmony One, a Favorites button
appears at the lower end of your remote’s screen when your’re in the Watch TV Activity.
To use your favorite channels:
Press the Favorites button.
1.
The favorite channels you’ve added appear on the remote’s screen.
2.
To select a channel, simply press the button associated with the channel.
3.
Controlling your devices individually
In some cases, you may need to control a device individually. You can use the device
feature of the Harmony One to control devices one-by-one.
When you press the Device button, the Harmony One’s screen displays a list of your
devices. Select the device you wish to control. After you select a device, the Harmony
One controls only that device. You have access to all the commands for the device
included in your Harmony One conguration.
Once you’ve nished, return to Activities for the optimal control of your entertainment
system.
Charging your remote
Your Harmony One comes with a
charging station. The charging station
plugs into a wall outlet and charges the
battery every time you put the remote
on it. All you need to do is pick up the
Harmony One, use it, and place it back
on the charging station when you’re
done to ensure it stays charged.
11
Setting the date and time
You can change the date and time that appears on the Harmony One’s screen.
To set or change the date and time, follow these steps:
To set the date and time on your Harmony:
On your Harmony One’s screen, select Options.
1.
Select Set the Current Time.
2.
Setting the backlight timing
The Harmony One senses when you pick it up, and lights up the display and buttons.
To set the length of time the backlight stays on, follow these steps:
From your Harmony Remote Software:
Select Remote Settings.
1.
Select Display Settings.
2.
12
Loading...
