Lippert Components On-the-Go User Manual

Quick Start Guide

4G LTE

Wireless Hotspot

CCD-0001336

06/08/18

The WiFi On-the-Go™ was designed and engineered
for the mobile lifestyle. The weatherproof, external
cellular antenna array increases your signal range
far beyond a simple “o󰀨-the-shelf” mobile hotspot.
WiFi On-the-Go™ utilizes Direct Link Technology specically
designed to go wherever you go. Direct Link Technology
provides the fastest 4G LTE connectivity available, up to
150Mbps per second, so you’re connected wherever the
road may take you.

Key Features:

• Direct Link Technology provides the fastest 4G LTE connectivity available,
up to 150Mbps

• Weatherproof externally mounted 4G antenna provides superior coverage

• Designed and engineered for the mobile lifestyle

• 2.4 GHz WiFi antennas designed to provide coverage at a longer range.

• More secure connection than open WiFi networks

• Dual power options; 120V AC/DC adapter or 12V DC/DC adapter

• Four additional Ethernet ports connecting additional devices

• MiMo technology for use with multiple devices

• Compatible with 4G LTE Bands 2, 4 and 12 (AT&T and T-Mobile)

06/08/18

Additional Information Sources

06/08/18

WiFi On-the-Go™ is compatible with AT&T® and T-Mobile® cellular
service using LTE bands 2,4 & 12. In order to activate your
WiFi On-the-Go™ hotspot, the owner will need to purchase their
own AT&T® or T-Mobile® nano Sim card and plan. The AT&T® and
T-Mobile® trade names and logos are registered trademarks of AT&T®
and T-Mobile® US, Inc. respectively.

Additional information about this product can be obtained from

lci1.com/support or by using the myLCI app. Replacement components

can be ordered from https://store.lci1.com/ or by using the myLCI app.
The myLCI app is available for free on iTunes® for iPhone® and iPad®
and also on Google Play™ for Android™ users. iTunes®, iPhone® and iPad®
are registered trademarks of Apple Inc. Google Play™ and Android™ are
trademarks of Google Inc.

Safety Information

Parts List

A

A

C

Fig.1

Letter Part# Description Qty

A 715645 Coax Cable, 10’ 2

B 722255 External Cellular Antenna 1

C 383635 #8 x 3/4” Stainless Steel Pan Head Screw 10

D 722251 2.4 GHz WiFi Antenna 2

E 722252 4.0G Cellular Antenna 2

F 716722 12V DC/DC In-line Power Supply 1

G 722250 Cellular Gateway 1

H 722253 120V AC/DC Adapter 1

B

F

G

E

D

H

4 5

Preparation

06/08/18

The WiFi On-the-Go is a portable device but can be fastened to a mounting
surface if desired. If the external cellular antenna is not a permanent mount
there are a number of methods of temporary mounting that can be utilized
at the retail customer’s discretion, i.e. hook and loop material, two sided tape,
etc. Use the method best suited for the temporary mounting surface.
If the external cellular antenna is not permanently attached with all weather
sealant, the antenna should not be exposed to water.

The 12V DC/DC power adapter (Fig.1F) can be used to ensure a smooth
power supply to the cellular router when connected to various 12V batteries
or systems such as vehicle, solar power bank, etc. The user will need
to determine which connection type they will need to add to the red/black
wires, such as a cigarette lighter adapter or banana clips, to suit their

specic application.

For immediate use of WiFi On-the-Go™:

1. Attach the two, 4.0G cellular antennae (Fig.1E) to the corresponding
ports of the cellular gateway (Fig.1G).

2. Attach the two 2.4GHz WiFi antennae (Fig.1D) to the

ports of the cellular gateway.

3. Plug the 120V AC/DC (Fig.1F) or 12V DC/DC (Fig.1H) adapter’s
power supply barrel connector into the back of the cellular gateway.

4. Plug the 120V AC/DC adapter into a wall outlet or connect the red
and black wires of the 12V DC/DC adapter to a 12V power source.

5. See Activation and Operation sections to complete the process.

NOTE: For more comprehensive instructions and various options, visit

Lippert Components website at https://www.lci1.com/assets/content/support/manuals/
Electronics/WiFi_On_the_Go_ _ _ _Aftermarket_Manual.pdf

corresponding

Activation

Before visiting AT&T® or T-Mobile®, make sure to have the IMEI
(International Mobile Equipment Identity) number available.
The IMEI number is printed on the WiFi On-the-Go™ label (Fig.2A).

The IMEI number is a unique 15-digit serial number given to every
device which can then be used to check information such as the device’s
Country of Origin, the Manufacturer and its Model Number.

Whether currently an AT&T® or T-Mobile® Wireless customer or not,
contact AT&T® or T-Mobile® customer service or visit the nearest AT&T®
or T-Mobile® Wireless corporate store to purchase a nano SIM card.

Fig.2

A

6 7

System Requirements

06/08/18

WiFi On-the-Go™ parts needed to activate the system:

• Assembled WiFi On-the-Go™ cellular gateway with antennae

• AT&T® or T-Mobile® nano SIM card

• Android, iOS smart device or personal computer

Activation Using AT&T or T-Mobile SIM Card

.

1. Disconnect the 120V AC/DC adapter or the 12V DC/DC power source
from the cellular gateway (Fig.3A).

2. Locate the SIM card slot on the side of the cellular gateway (Fig.3B).

3. Gently push in on the edge of the nano SIM card adapter (Fig.3B)

and release, the SIM card adapter will pop out.

4. Position the SIM card adapter’s beveled edge on the top right hand
corner (Fig.4C), insert the nano SIM card (Fig.4B) purchased from AT&T
or T-Mobile at the same position, into the nano SIM card adapter (Fig.4A).

NOTE: Take caution when inserting the SIM card adapter into the SIM
card slot opening to ensure that the adapter is NOT inserted below the
SIM card slot opening.

C

C

A

B

A

B

Fig.3

8 9

Fig.4

5. Insert the nano SIM card adapter with the nano SIM card into

06/08/18

the SIM card slot (Fig.3B) until a “click” sound is heard.

NOTE: The “click” sound means the SIM card is now securely latched

into the SIM slot.

6. After making sure the SIM card is rmly seated, connect the 120V
AC/DC adapter or the 12V DC/DC adapter to the cellular gateway (Fig.3A).

C. When prompted, enter the following default username and password
(Fig.5A) and click Login (Fig.5B).

I. Username: root
II. Password: admin

7. Verify power and connectivity with the Wi On-The-Go™ LEDs
(Fig.3C). Lights will ash when connected.

A

B

Operation

After successful activation of Wi On-The-Go™, use a mobile device

to connect to the 4G LTE wireless hotspot.

Connecting to Wi On-The-Go™

1. From the device’s wi- settings, select Wi On_the_Go_9d84.
The password will be blank.

2. To rename the hotspot (ESSID) and set the security settings with
a login password:

A. Open a web browser.
B. Type 192.168.1.1 into the address bar.

10 11

Fig.5

3. After entering the default username and password, from the top menu
bar select the “Network” dropdown menu (Fig.6A).

4. Next, click on “Wi” (Fig.6B).

A

B

Fig.6

A. Click on the Edit button under the “Wireless Overview” section

06/08/18

(Fig.7), then scroll to the bottom of the page.

Fig.7

B. If preferred, rename the hotspot (ESSID) here (Fig.8A) and click Save
(Fig.9A).

A

A

Fig.8

C. Click on the “Wireless Security” tab (Fig.10A) to ensure Wi-Fi security.

I. From the menu, select the desired level of security. LCI recommends
WPA2-PSK (Fig.11A).

A

Fig.10

12 13

Fig.9

Fig.11

A

II. Enter a new password in the “Key” eld (Fig.12A). The password
MUST be at least eight characters.

NOTE: For easy retrieval of a forgotten password, it is recommended to write

down and store the new password in a secure location or use a password
management encrypted database that may be located on your personal
computer or mobile device.

III. Click on “Save & Apply” button (Fig.12B).

A

Fig.12

NOTE: “Waiting for changes to be applied” may be visible until sign in is
completed.

5. Sign into the hotspot, again.
NOTE: This will be the default hotspot name or the new name given in

step 4B.

6. Select the hotspot from your mobile device’s Wi-Fi settings.
A. If the security password was not changed, no password will be

required to join the hotspot.
B. If the security password was changed (step 4CII), enter the new

password.

B

FCC 15B statement:

06/08/18

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee th at interference will not occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment o󰀨 and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit di󰀨erent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

NOTE: Do not press “RESET” on the back of the cellular gateway unless
directed by Lippert Customer Service. Reset will take the device back to
factory settings and make the device inoperable.

Notes

FCC Part 15 compliance statement:

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.

IC User manual notice:

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:

1. This device may not cause interference.

2. This device must accept any interference, including interference that may cause undesired

operation of the device.

Non-modication Warning

Any chan ges or mo dic ations t o this device not expressly approved by the par ty re spons ible for c ompli ance c ould voi d

the user ’s autho rity to o perate this equipment .

RF Exposure Statement

This equ ipment c ompli es with FC C/IC radiation exposure limits set for th for a n uncontrolle d enviro nment an d meets
the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules. This
equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body.

14 15

Should you have any questions, please do not
hesitate to contact us at [phone] or by
email at [e-mail]. Self-help
tips, technical documents, product videos and a
training class schedule are available at lci1.com
or by downloading the MyLCI app.

Contact

Lippert Components Incorporated

part no. 722050
