LINKSYS RE3000WV2 User Manual

User

Guide

RE3000W

V2

Introduction

This User Guide can help you connect the extender to your network and solve common setup
issues. You can find more help from our award-winning, 24/7 customer support at
Linksys.com/support.

Contents

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

How to install the range extender................ 2

How to access the browser-based utility .......... 5

Using Wi-Fi Protected Setup..................... 7

How to use Site Survey.......................... 9

Troubleshooting................................ 10

Specifications.................................. 13

Overview

Power Light

Status/ description

Blinking Green

 Powered on
 Resetting to factory defaults
 Upgrading its firmware

Solid Green

 Ready to use

Solid amber

 Weak connection with the router

Fix: Unplug the extender, and move
it closer to the router

Blinking Orange

 Cannot establish a connection
 Other error

Fix: Unplug the extender, plug it back
in, wait two seconds, reconnect to your
network

Front

The light on the front of the range extender gives you information about power and Wi-Fi
Protected Setup. Use Wi-Fi Protected Setup to automatically and securely connect compatible
wireless devices such as wireless printers.

Side

Power Switch European versions only.

Wi-Fi Protected Setup Button Use Wi-Fi Protected Setup to automatically and securely add

compatible wireless devices to your network. Refer to Using Wi-Fi Protected Setup on page 7.

Reset Press and hold for about five seconds to reset to factory defaults. You can also restore
the defaults from the Administration > Factory Defaults screen in the extender’s browser- based
utility.

Bottom

Ethernet (blue) Connect wired devices to your wireless network with Ethernet (network) cables.

The green light turns on when an Ethernet device is connected and active on this port. The light
blinks when the extender is sending or receiving data over the Ethernet port.

How to install the range extender

Before setup, unplug or disconnect any range extenders on the network.

1. Plug in the range extender midway between your router and the area without Wi-Fi.
Be sure you have at least 50% of your router’s Wi-Fi signal at that point on the device
you will use for setup. The setup software will help you find the best spot if you have
trouble.

2. Wait for a solid light on the cover of the range extender. It could take up to two minutes.
On a computer, phone or tablet, connect to the Wi-Fi network “Linksys Extender Setup.”
 Windows 7 and Windows 8 will ask you, “Do you want to set up your network?” Click

the link, “Connect to network without setting it up.”

3. If setup doesn’t start automatically, open a browser to http://extender.linksys.com

TIP

You can also connect the range extender by using Wi-Fi Protected Setup. For more
information, see “Using Wi-Fi Protected Setup” on page 7.

How to access the browser-based utility

After setting up the extender use the extender’s browser-based utility to change any
settings.

Windows XP:

TIP

To follow these instructions, enable UPnP:

1. Click Start, Control Panel, Add or Remove Program, then click Add/Remove
Windows Components.

2. Select Network Services, then click Details.

3. Select UPnP User Interface, then click OK.

1. Open Windows Explorer. Click My Network Places on the left panel.

2. Look for the RE3000W icon on the right panel. (You might be required to change the firewall

settings to allow the display of networked computers. Refer to your operating system’s help
for instructions.)

3. Double-click the RE3000W icon. A web browser will open and prompt you to enter your User

name and Password.

4. Leave the User name field blank, and enter the default password “admin.”

5. Click OK.

Windows 8, Windows 7, or Vista:

1. Open Windows Explorer (File Explorer in Windows 8). Click Network. Look for the RE3000W

icon on the right panel. (You might be required to change the firewall settings to allow the
display of networked computers. Refer to your operating system’s help for instructions.)

2. Right-click the RE3000W icon. Click Properties. Click on the address link in Device

webpage. A web browser will open and prompt you to enter a User name and Password.

3. Leave the User name blank, and enter the default password “admin.”

4. Click OK.

Mac OS X:

1. Open Safari. Click the book icon. Click Bonjour on the left panel. Look for the RE3000W
icon on the bottom right panel.

2. Double-click the RE3000W icon.

3. Leave the User name blank, and enter the default password “admin.”

4. Click OK.

Using range extender settings

Click Help on the right side of the screen for additional information on the screen’s
options.

Changes to settings will not be effective until you click Save Settings at the bottom of
the screen. You also can click Cancel Changes to clear any changes.
