SIMPLE MANUAL
Wireless
Rear Speakers
Kit
Please read this manual carefully before operating your set
and retain it for future reference.
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
SPK8-S
www.lg.com
Copyright © 2018-2021 LG Electronics Inc. All Rights Reserved.
Wireless Receiver Connection2Rear Speakers Connection1
Speaker design and connection method may be
different according to models.
Transparent
Black stripe
Rear speaker
(Left)
Wireless
Receiver
Black stripe
Transparent
Rear speaker
(Right)
a Connect the speaker cables to rear speakers
correctly.
b Connect the Wireless Receiver and the rear
speakers (Grey: right, Blue: left) with the speakers
cables.
c Turn on the Surround function to enjoy surround
sound.
a Connect the power cord of the wireless receiver
to the AC outlet.
b Turn on the unit: The unit and wireless receiver
will be automatically connected. The receiver's
yellow - green LED turns on
Wireless Receiver Connection Manually
If the rear speakers do not make sound, try to
connect manually.
a Press PAIRING button on the rear of the
wireless receiver.
yThe yellow - green LED on the wireless receiver
blinks quickly.
b Turn on the main unit.
c Pairing is completed.
yThe yellow - green LED on the wireless receiver
turns on.
Set the distance between the sound
bar and the wireless receiver as close as
possible and keep them away from the
device (ex. wireless router, microwave
oven, etc.) over 1 m to prevent wireless
interference.
> 1 m
!P
Surround Sound On/Off
When you turn on surround function, you can enjoy
magnificent surround sound for all the input sound
source with rear speakers.
The initial setting for the surround function is
OFF, turn the surround function ON to use it.
SK5Y
Surround On: Press and hold REAR
o button on the
remote control about 2 seconds.
Surround Off: Press and hold REAR
p button on the
remote control about 2 seconds.
SK10Y/SK9Y/SK8Y/SK6Y
Surround On: Press and hold AUTO VOL button on the
remote control about 2 seconds and then press AUTO
VOL button repeateadly to select ON - SURROUND in
the display window.
Surround Off: Press and hold AUTO VOL button on the
remote control about 2 seconds and then press AUTO
VOL button repeateadly to select OFF - SURROUND in
the display window.
SL4Y/SL5Y/SL5YF/SL6Y/SL6YF/SL7Y/SL7YF/SL8Y/
SL8YG/SL9Y/SL9YG/SL10Y/SL10YG/
SN10Y/SN10YG/DSN10YG/SN9Y/SN9YG/
DSN9YG/SL8Y/SL8YG/DSN8YG/SN7Y/DSN7Y/
SN7CY/DSN7CY/SN6Y/DSN6Y/SN5Y/DSN5Y/GX/
G1
Surround On: Press and hold
button on the remote
control about 3 seconds and then press button
repeateadly to select ON - SURROUND in the display
window.
Surround Off: Press and hold
button on the remote
control about 3 seconds and then press button
repeateadly to select OFF - SURROUND in the display
window.
SP9YA/DSP9YA/SP8YA/DSP8YA/SP7Y/DSP7Y/
SPD7Y/SP70Y/DSPD7Y/SPD75YA/DSPD75YA/
SP60Y
Press Settings
button. The product enters the
setting mode and you can see “OFF-AUTO POWER” or
“ON-AUTO POWER”.
While the “OFF-AUTO POWER” or “ON-AUTO
POWER” is scrolling in the status display, press Left/
Right button to select the surround sound setting.
You can see the status of the surround sound, “OFFSURROUND” or “ON-SURROUND”.
While the “OFF-SURROUND” or “ON-SURROUND” is
scrolling in the status display, press Up/Down button to
turn on or off the surround sound.
Additional Information
Specication of Wireless receiver
Power
requirement
Power
consumption
Dimensions
(W x H x D)
Design and specications are subject to change
without notice.
About Ferrite Core (Optional)
twice
Refer to the main label on the
wireless receiver.
Refer to the main label on the
wireless receiver.
Approx.
60.0 mm x 220.0 mm x
175.0 mm
