OWNER’S MANUAL
LG Wi-Fi
Sound Bar
Please read this manual carefully before operating your set and retain it for future reference.
MODEL
SL10YG (SL10YG, SPL8-W)
www.lge.com
1902_Rev02 |
Copyright © 2019 LG Electronics Inc. All Rights Reserved. |
1
Started Getting
Safety Information |
product identification and supply ratings, please refer |
|||
|
|
|
NOTICE: For safety marking information including |
|
|
|
|
to the main label on the bottom or the other surface |
|
|
|
|
of the product. |
|
|
CAUTION |
|
||
|
|
|
||
|
RISK OF ELECTRIC SHOCK |
|
CAUTION concerning the Power Cord |
|
|
DO NOT OPEN |
|
||
|
|
The Power Plug is the disconnecting device.In case |
||
CAUTION: TO REDUCE THE RISK OF ELECTRIC |
||||
of an emergency, the Power Plug must remain readily |
||||
SHOCK DO NOT REMOVE COVER (OR BACK) |
||||
accessible. |
||||
NO USER-SERVICEABLE PARTS INSIDE REFER |
||||
Check the specification page of this owner’s manual |
||||
SERVICING TO QUALIFIED SERVICE PERSONNEL. |
||||
to be certain of the current requirements. |
||||
|
|
|
This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous
voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying the product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING: Do not install this equipment in a confined space such as a book case or similar unit.
CAUTION: Do not use high voltage products around this product. (ex. Electrical swatter)This product may malfunction due to electrical shock.
CAUTION: The apparatus should not be exposed to water (dripping or splashing) and no objects filled with liquids, such as vases, should be placed on the apparatus.
CAUTION: Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from over heating. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface.This product shall not be placed in a builtin installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s instruction has been adhered to.
Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire. Periodically examine the cord of your device, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the device, and have the cord replaced with an exact replacement part by an authorized service center. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the device.
CAUTION: No naked flame sources, such as lighted candles, should be placed on the apparatus.
Getting Started |
3 |
|
|
Symbols
~Refers to alternating current (AC).
0 |
Refers to direct current (DC). |
1 |
||
|
Refers to classII equipment. |
|
Getting |
|
1 |
Refers to stand-by. |
|
||
|
|
|
Started |
|
! |
Refers to “ON” (power). |
|||
|
|
|||
|
Refers to dangerous voltage. |
|
|
|
|
|
|
|
4 Table of Contents
Table of Contents
1 |
Getting Started |
|
2 |
Connecting |
2 |
Safety Information |
16 |
Network connection |
|
6 |
Introduction |
16 |
– Installing “Google Home” App |
|
7 |
Front panel |
17 |
– Launch the app to connect Wi-Fi |
|
9 |
Rear panel |
18 |
Organizing cables |
|
10 |
Remote control |
18 |
Wireless subwoofer and rear speaker (Sold |
|
13 Installing the sound bar |
|
Separately) connection |
||
14 Mounting the main unit on a wall |
18 |
– Wireless subwoofer connection |
||
|
|
|
20 |
– Rear speakers connection (Sold |
|
|
|
|
Separately) |
|
|
|
21 |
– Surround sound |
|
|
|
24 |
– How to Affix the Ferrite Core |
|
|
|
25 |
Connecting to your TV |
|
|
|
25 |
– Using an OPTICAL cable |
|
|
|
25 |
– LG Sound Sync |
|
|
|
27 |
– Using an HDMI cable |
|
|
|
27 |
– ARC (Audio Return Channel) function |
|
|
|
27 |
– What is SIMPLINK? |
|
|
|
28 |
– Additional information for HDMI |
|
|
|
29 |
Optional equipment connection |
|
|
|
29 |
– DOLBY ATMOS® |
|
|
|
29 |
– DTS:X™ |
|
|
|
30 |
– HDMI IN connection |
|
|
|
30 |
– OPTICAL IN connection |
|
|
|
31 |
– USB connection |
Table of Contents |
5 |
|
|
3 |
Operating |
4 |
Troubleshooting |
||
|
|
|
|
|
|
34 |
USB operation |
47 |
Troubleshooting |
||
35 |
How to use the Google Assistant |
47 |
– General |
||
35 |
– Talk to the Google Assistant |
49 |
– Network |
||
37 |
– Reference site for Google Assistant Help |
49 |
– Application |
||
38 |
Control your TV and Sound Bar with Voice |
50 |
– NOTES to use wireless |
||
|
command |
50 |
– NOTES to release Demo mode |
||
38 |
– Available voice commands |
|
|
|
|
40 |
“LG Wi-Fi Speaker” |
5 |
Appendix |
||
40 |
– Installing “LG Wi-Fi Speaker” App |
||||
|
|
|
|||
41 |
Using a Bluetooth Wireless Technology |
51 |
File requirement |
||
41 |
– About Bluetooth |
51 |
Trademarks and licenses |
||
41 |
– Bluetooth profiles |
52 |
Specifications |
||
41 |
– Listening to Music of a Bluetooth Device |
54 |
Handling the Speaker |
||
44 |
Other operations |
54 |
Important Information Relating to Network |
||
44 |
– Using your TV remote control |
|
|
Services |
|
44 |
– AUTO POWER On/Off |
55 |
TERMS OF USE |
45– Auto function change
46Standby mode
46 – Standby mode
46 – Networked standby mode
46 Reset the Speaker
1
2
3
4
5
1
Started Getting
6 Getting Started
Symbol used in this manual
,,Note
Indicates special notes and operating features.
>>Caution
Indicates cautions for preventing possible damages from abuse.
Getting Started |
7 |
|
|
1
Started Getting
A Microphone |
|
||
1 (Standby) |
|
||
-- |
Switches the unit ON or OFF. |
|
|
F (Function) |
|
||
-- |
Select the function and input source by pressing F repeatedly. |
||
|
|
|
|
|
Input source / Function |
Display |
|
|
|
|
|
|
Wi-Fi |
WI-FI |
|
|
|
|
|
|
Bluetooth |
BT |
|
|
|
|
|
|
Optical |
|
|
|
ARC |
OPT/HDMI ARC |
|
|
LG Sound Sync (Wired) |
|
|
|
|
|
|
|
HDMI IN 1 |
HDMI1 |
|
|
|
|
|
B |
HDMI IN 2 |
HDMI2 |
|
|
|
||
USB |
USB |
||
|
|||
|
|
|
,You can use Bluetooth function after making Wi-Fi network connection by using Google Home app.
o/p(Volume)
-- Adjusts volume level.
N
-- Starts playback. / Pauses playback.
>(Mic mute)
-- Disables the detect voice recognition by pressing >. All the Google Assistant LED turns amber and “The mic is muted.” is heard.
To cancel it, press >again. Google Assistant LED turns off and “The mic is back on.” is heard.
-- Enables Google Assistant to receive your voice commands. To cancel it, pressagain. (Page 35)
1
Started Getting
8 Getting Started
C Remote sensor
Google Assistant LED
-- Changes LED status according to Google Assistant performance.
LED |
Status |
Description |
D |
All four LEDs are on. |
Ready to listen to your voice |
|
command. |
|
|
All four LEDs blink. |
Responds to your voice command. |
|
Microphone is off and the solid |
Voice recognition is disable |
|
amber LED will be on. |
|
Display Window
E -- Display window will be darkened automatically if there is no key input for 15 seconds. When you press any button, the display window will brighten.
Precautions in using the touch buttons
yy Use the touch buttons with clean and dry hands.
-- In a humid environment, wipe out any moisture on the touch buttons before using.
. yy Do not press the touch buttons hard to make it work.
-- If you apply too much strength, it can damage the sensor of the touch buttons. yy Touch the button that you want to work in order to operate the function correctly.
yy Be careful not to have any conductive material such as metallic object on the touch buttons.It can cause malfunctions.
This unit will turn itself off to save electric consumption when the main unit is not connected to an external device and is not used for 15 minutes.
Remove foreign materials between the grill and the case by using a cotton swab.
,
Getting Started |
9 |
|
|
1
Started Getting
USB Port
A-- Connect USB memory device to the USB port on the back of the unit.
OPTICAL IN
B-- Connect the OPTICALIN jack on the back of the unit to OPTICAL OUT jack on theTV.
HDMI OUT (TV ARC)
C-- Connect the HDMI OUT (TV ARC) jack on the back of the unit to ARC jack on theTV.
HDMI IN (1)/HDMI IN (2)
D-- Connect HDMIIN jack on the back of the unit to HDMI OUT jack on the external device. You can enjoy the sound and picture from HDMI connection on an external device.
1
Started Getting
10 Getting Started
Replacement of Battery
Remove the battery cover on the rear of the remote control, and insert the battery with 4 and 5 matched correctly.
1 (Standby)
-- |
Switches the unit ON or OFF. |
A yy |
Networked standby: It allows the unit to switch to standby mode. |
|
To turn on Networked standby function, Press 1. |
|
To turn off Networked standby function, press 1 for about 3 seconds. |
VOL (Volume) o/p |
|
B -- |
Adjusts speaker volume. |
Getting Started 11
SOUND EFFECT |
|
|
-- |
Selects a sound effect mode by using SOUND EFFECT. |
|
|
|
|
|
On Display |
Description |
|
|
|
|
ASC (Adaptive Sound Control) |
Analyzes the property of the input sound and provides the |
|
sound optimized for the content in real time. |
|
|
|
|
|
|
|
|
BASS BLAST or BASS BLAST+ |
Reinforces the bass and powerful sound. |
|
|
|
|
STANDARD |
You can enjoy premium sound with MERIDIAN technology. |
|
|
|
|
MOVIE |
You can enjoy more immersive and cinematic surround sound. |
|
|
|
C |
MUSIC |
You can enjoy more good sound for music source. |
|
|
|
, When this unit detects DOLBY ATMOS or DTS:X stream, you cannot change sound effect to any |
||
|
other.In this case, even though you press SOUND EFFECT, this unit does not respond. And you can |
|
|
see only “NOT SUPPORTED” on the display window. |
|
yy |
TV remote: It allows you to control the volume of this unit by yourTV remote control even by other |
|
|
company’s product. (Page 44) |
|
|
To turn on or off theTV Remote function, press and hold SOUND EFFECT for about 3 seconds and |
|
|
press it again. |
|
, SupportedTV brands
LG |
Panasonic |
Philips |
Samsung |
Sharp |
Sony |
Toshiba |
Vizio |
|
|
|
|
|
|
|
|
C/V(Skip)
D-- Press Cor Vto go to next or previous file.
N(Play/Pause)
E-- Starts playback. / Pauses playback.
(Sound tuning)
-- Adjusts sound level of each speaker.
Select the speaker you want to adjust by usingand adjust the sound level by using VOL o/p.
, Adjusting rear speakers level is applied only when the rear speakers are connected.
|
|
Speaker |
Display |
|
Range |
|
|
|
|
|
|
|
|
Sub Woofer |
WF |
|
-15 ~ 6 |
|
|
|
|
|
|
|
|
Center |
C |
|
-6 ~ 6 |
F |
|
|
|
|
|
|
Overhead Volume Control |
OVC |
|
-6 ~ 6 |
|
|
|
|
|||
|
|
|
|
|
|
|
|
Side |
S |
|
-6 ~ 6 |
|
|
|
|
|
|
|
|
Rear |
R |
|
-6 ~ 6 |
|
|
|
|
|
|
|
|
Treble |
TRE |
|
-5 ~ 5 |
|
|
|
|
|
|
|
|
Bass |
BAS |
|
-5 ~ 5 |
|
|
|
|
|
|
|
yy Surround sound: It allows you to enjoy surround sound with rear speakers. (Page 21) |
||||
|
To turn on or off the surround sound, press and hold |
for about 3 seconds and press it again. |
1
Started Getting
1
Started Getting
12 |
Getting Started |
|
|
|
8 (Night time) |
G |
-- It is useful when you want to watch movies at low volume late at night.It makes to reduce the |
|
sound intensity and improve fineness and softness. |
|
Press 8 to activate Night time mode.To cancel it, press 8 again. |
F (Function)
H-- Select the function and input source by pressing F repeatedly.
[(Mute)
I-- Press [to mute your unit.To cancel it, press [again.
-- Enables Google Assistant to receive your voice commands while watching TV (not necessary when
Jlistening to music through Wi-Fi or Bluetooth, you can just say “Hey Google”).
To cancel it, pressagain. (Page 35)
>(Mic mute)
-- Disables the detect voice recognition by pressing >. All the Google Assistant LED turns amber and
K“The mic is muted.” is heard.
To cancel it, press >again. Google Assistant LED turns off and “The mic is back on.” is heard.
J(Information)
-- You can display various information of the input source by pressing J. -- Wi-Fi: Connected Application name
-- BT (Bluetooth): Connected Bluetooth device name
L-- OPT (Optical)/ARC/HDMI1/HDMI2 (HDMIIN 1/HDMIIN 2): Audio format -- USB: File information contained on a USB.
yy Auto Power ON/OFF: It allows the unit to turn on and off automatically by input signals: Optical (Page 44)
To turn on or off AUTO POWER function, press and hold Jfor about 3 seconds and press it again.
REPEAT
M-- Press REPEAT to select desired repeat or random mode.
FOLDER W/S
N-- Searches a folder on USB device.
You can hear the sound by connecting the unit to the other device:TV, Blu-ray disc player, DVD player, etc.
Place the unit in front of theTV and connect it to the device you want. (Pages 25 - 31)
You can place the wireless subwoofer anywhere in your room. But it is better to place the subwoofer near the main unit.Turn it slightly toward the center of the room to reduce the wall reflections.
For the best surround sound, place the speakers as shown below.
,,Note
yy The illustration above may differ from actual units.
yy You can enjoy surround sound by using Wireless Rear Speaker kit. Wireless Rear Speakers Kit sold separately (SPK8-S).
>>Caution
yy For best performance of wireless connection such as Bluetooth or wireless subwoofer, do not install the unit on Metallic furniture because wireless connection communicates through a module positioned on the bottom of the unit.
yy Be careful not to make scratches on the surface of the Unit /Subwoofer when installing or moving them.
Getting Started 13
1
Started Getting
1
Started Getting
14 Getting Started
Mounting the main unit |
|
install guide with the bottom ofTV and attach to |
|||||||||||
on a wall |
1. Match theTV’s BOTTOM EDGE of Wall bracket |
||||||||||||
|
the position. |
||||||||||||
|
|
|
|
||||||||||
You can mount the main unit on a wall. |
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2. When you mount it on a wall (concrete), use the wall plugs. You should drill some holes. A guide sheet (Wall bracket install guide) is supplied to drill. Use the sheet to check the point to drill.
>>Caution
Because it is difficult to make a connection after installing this unit, you should connect the cables before installation.
Preparation materials
Unit
Wall bracket install guide Wall bracket
Screws
(Not supplied)
Screws (A)
Wall plug
3.Remove the Wall bracket install guide.
4.Fix the brackets with screws (A) as shown in the illustration below.
,,Note
Screws (A) and Wall Plugs are not supplied for mounting the unit. We recommend the Hilti (HUD-1 6 x 30) for the mounting.
5.Put the unit on the brackets to match screw holes on the bottom of the unit.
6. Fix the unit with the screws firmly.
,,Note
To detach the unit, perform it in reverse order.
>>Caution
yy Do not install this unit upside down.It can damage the parts of this unit or be the cause of personal injury.
yy Do not hang onto the installed unit and avoid any impact to the unit.
yy Secure the unit firmly to the wall so that it does not fall off.If the unit falls off, it may result in an injury or damage to the product.
yy When the unit is installed on a wall, please make sure that a child does not pull any of connecting cables, as it may cause it to fall.
Getting Started 15
1
Started Getting
2
16 Connecting
You can enjoy various functions of this sound bar by connecting to network and your smart device with “Google Home” app.
Modem
Media Server
Router
The “Google Home” app allows you to use various functions of this speaker through your smart device.
Requirements before setup
yy A wireless router must be connected to the internet. A smart device such as Android or iOS devices must be connected to the wireless router via Wi-Fi connection.
yy It needs Google account to use this app. During connect Wi-Fi, this app may request to create Google account.
Through “Google Play” or “App Store”
1.Tap the“Google Play Store” icon or “App Store” icon on your smart device.
2.Type in “Google Home” in the search bar and tap “Search” on “Google Play” or “App Store”
3.Select “Google Home” in the search result list to download.
The “Google Home” app is required to connect the sound bar wirelessly to the network.
,,Note
In a network environment (Router,Internet andInternet Service Provider) that supports bothIPv4 andIPv6, the network automatically connects toIPv4 orIPv6 when connecting to the network.
You can check the each network status by selecting the settings of My Speakers
([Settings]>[IPInfo.]) on the “LG Wi-Fi Speaker” app.
Google Home
,,Note
yy Depending on the device version, “Google Home” app may not work.
yy For more information, visit the web site. https://www.google.com/cast/setup/
Connecting 17
Make sure your smart device Wi-Fi feature is turned on. Once a connecting operation is performed, it does not need to be performed again.
,,Note
In case of iOS devices, it should be turned on Bluetooth setting on your smart device.
1. Tap the “Google Home” icon to launch the app.
2.Follow the screen on app to set speaker. Follow these instructions in order.
3.When the speaker is properly connected to Wi-Fi, “CONNECTED” will appear on the display window with sound.
,,Note
yy Depending on wireless router status, it might not work well Wi-Fi connection.
yy It is recommended that you use Wi-Fi Group Play with less than 5 speakers.
yy “Google Home” app is provided by Google.It might be revised by a change of Google Policy.
yy For more information (Set up, Usage, Help etc.), research “Google Assistant Help” or visit the web site. http://support.google.com/ assistant
yy The speaker is not available for use on some functions from the “Google Assistant Help” site. (ex. Call etc.) (Page 37)
,,Note
yy Use the same Wi-Fi connection to set the speaker and your smart device.
yy If the Bluetooth setting turned on your smart device, it will be easy to connect Wi-Fi.
yy During installation, you should create a speaker name.It is needed when pairing the Bluetooth device. You can check and edit the speaker name. Follow the “Edit speaker name”.(Page 43)
yy For more information on the setup, visit the web site. https://support.google.com/ assistant/answer/7538816
2
Connecting
2
Connecting
18 Connecting
You can organize the cable with cable ties.
1.Hold the cables together with cable ties as shown below.
2.Tighten cable ties.
,,Note
After all connections are completed, you can arrange cables as needed.
LED indicator of wireless subwoofer
LED Color |
Status |
|
|
Green |
The connection is trying. |
(Blink) |
|
|
|
Green |
The connection is completed. |
|
|
Red |
The wireless subwoofer is in |
|
standby mode or the connection |
|
is failed. |
|
|
Off (No |
The power cord of wireless |
display) |
subwoofer is disconnected. |
|
|
Setting up the wireless subwoofer for the first time
1.Connect the power cord of the sound bar and the wireless subwoofer to the outlet.
2.Turn on the sound bar.The sound bar and
the wireless subwoofer will be automatically connected.
-- Pairing is completed.The green LED on the rear of the wireless subwoofer turns on.
