LG KG200 User Manual
KG200 USER GUIDE
Some of contents in this manual may differ from
your phone depending on the software of the
phone or your service provider.
ENGLISH
Contents
General information .............................................................4
Contents
Battery care ............................................................................4
Access codes ........................................................................
Care and Maintenance ........................................................
Important safety information ..............................................
Your phone ............................................................................10
Standby mode ......................................................................12
Getting Started .....................................................................13
Installing the SIM card and the battery ........................13
Charging the battery ...........................................................
Switching the phone on and off ......................................
Call functions .......................................................................15
Making a call ........................................................................15
Answering or rejecting an incoming call ......................
Call waiting ...........................................................................
Tips for call options .............................................................
Input method ........................................................................17
Listing of Functions ............................................................
2
Browser .................................................................................
WAP [Menu 1-1] ..................................................................20
4
Data account [Menu 1-2] ..................................................
5
Call history ............................................................................24
6
All calls [Menu 2-1] .............................................................24
Missed calls [Menu 2-2] ....................................................
Dialled calls
Received calls [Menu 2-4] ................................................
Delete call log [Menu 2-5] .................................................
Call time [Menu 2-6] ...........................................................
13
Call cost [Menu 2-7] ...........................................................
14
Text message counter [Menu 2-8] ..................................
GPRS counter [Menu 2-9] .................................................26
Tools .......................................................................................27
15
Calendar [Menu 3-1] ..........................................................27
15
To do [Menu 3-2] ..................................................................
16
Alarm [Menu 3-3] ................................................................
World clock [Menu 3-4] .....................................................
Calculator [Menu 3-5] ........................................................
18
Unit converter [Menu 3-6] .................................................
Currency converter [Menu 3-7] .......................................
Health [Menu 3-8] ...............................................................
STK [Menu 3-9] ....................................................................
[Menu 2-3] .....................................................24
20
23
24
25
25
25
25
25
27
28
28
28
29
29
29
30
Multimedia ............................................................................31
Games [Menu 4-1] ..............................................................31
Camera [Menu 4-2] .............................................................
Image viewer [Menu 4-3] ..................................................
Video recorder [Menu 4-4] ...............................................
Video player [Menu 4-5] ....................................................
Music player [Menu 4-6] ...................................................
Voice recorder [Menu 4-7] ...............................................
Melody composer [Menu 4-8] .........................................
FM radio [Menu 4-9] ...........................................................
Schedule FM record
Messaging ............................................................................40
Text message [Menu 5-1] ..................................................40
Multimedia Message
Chat [Menu 5-3] ...................................................................
Voice mail server [Menu 5-4] ...........................................
Broadcast Message [Menu 5-5] .....................................
My stuff ..................................................................................50
Profiles ...................................................................................
[Menu 4-10] ..................................39
[Menu 5-2] ...................................42
Contacts ................................................................................
Search [Menu 8-1] ..............................................................53
31
New contact
32
Caller group
33
Speed dial
35
Extra number [Menu 8-5] ..................................................
36
Copy [Menu 8-6]
36
Delete [Menu 8-7] ...............................................................
37
Move [Menu 8-8] .................................................................
38
Settings [Menu 8-9] ............................................................
Settings ..................................................................................57
Time & Date [Menu 9-1] ....................................................57
Display [Menu 9-2] ..............................................................
Phone [Menu 9-3] ...............................................................
48
Call [Menu 9-4] .....................................................................
49
Network [Menu 9-5] ...........................................................
49
Security [Menu 9-6] ............................................................
Restore factory settings [Menu 9-7] ..............................
Troubleshooting ...................................................................64
51
Emergency calls ..................................................................
Accessories .........................................................................
Technical data .....................................................................
[Menu 8-2] ...................................................54
[Menu 8-3] ....................................................54
[Menu 8-4] ........................................................55
.................................................................55
53
55
55
55
56
58
58
59
61
62
63
67
68
69
| Contents
3
General information
Battery care
General information
Your phone is powered by a rechargeable battery.
• The battery can be charged and discharged hundreds
of times but it will eventually wear out. When the
operating time (talk-time and standby time) is
noticeably shorter than normal, you should buy a new
battery at the time.
• Unplug the charger when not in use, and don’t leave
the battery connected to a charger for longer than a
week, since overcharging may shorten its lifetime.
• Overcharging may shorten its lifetime, and if left
unused a fully charged battery may discharge itself
over time.
• Temperature extremes can affect the ability of your
battery to charge.
• Do not use any charger or battery that is damaged in
any way.
• Use the battery only for its intended purpose.
• Extreme temperatures will affect the charging
capacity of your battery.
4
• Do not leave the battery in hot or cold places, such as
in a car in summer or winter condition.
• Do not short-circuit the battery. Short-circuiting the
terminals may damage the battery or the connecting
object.
• Dispose of batteries according to local regulations.
Always recycle. Do not dispose of batteries in a fire.
Access codes
PIN code
The PIN (Personal Identification Number) code protects
your SIM card against unauthorized. Your SIM card
usually supplies the PIN code.
! Note
You may need to obtain the password from your service
provider.
! Note
If you key in an incorrect PIN code three times in
succession, you may need to key in PUK code.
PIN2 code
The PIN2 code may be supplied with the SIM card.
Some functions will require PIN2 support, such Set
tariff.
! Note
You may need to obtain the password from your service
provider.
PUK
The PUK (Personal Unblocking Key) code is required to
change a blocked PIN code. The PUK code is required
to change a blocked PIN2 code.
! Note
You may need to obtain the password from your service
provider.
! Note
If you key in an incorrect PIN2 code three times in
succession, you may need to key in PUK2 code.
! Note
If you key in an incorrect PUK code ten times in succession,
the SIM card cannot be used anymore. Contact your service
provider for a new card.
Phone code
Phone code protects the phone against unauthorized
use. It is not on when you buy the phone. You can
change the phone code (0000) to any four to eight-digit
personal codes.
Care and Maintenance
Read this information before using your mobile phone.
Your mobile phone is a highly sophisticated electronic
device. When using your phone, battery, charger or any
accessory, please read this first.
Product care
• Keep your mobile phone and all its parts out of young
children’s reach.
• Keep your mobile phone dry.
• Avoid exposing your mobile phone to extreme hot or
cold temperatures.
• Avoid placing your mobile phone close to lit
cigarettes, naked flames or any heat source.
| General information
5
General information
• Do not attempt to disassemble it. Non-expert handling
General information
of the device may damage it.
• Do not drop, knock or shake it. Rough handling can
break internal circuit boards.
• Do not paint your mobile phone as the paint could
obstruct the earphone, microphone or any moveable
parts and prevent normal use.
• Treat your mobile phone with care, keep it in a clean
and dust free place.
• Do not use the phone if the antenna is damaged. If a
damaged antenna contacts skin, it may cause a light
burn. Please contact an LG Authorized Service Center
to replace the damaged antenna.
• Do not touch the antenna unnecessarily when the
phone is switched on. Contact with the antenna
affects call quality and may cause the phone to
operate at a higher power level that needed and
shorten talk and standby times.
• Hold the phone as you speak to any other telephone.
While speaking directly into the microphone, angle
the antenna in a direction up and over your shoulder.
If the antenna is extendable/retractable, it should be
extended during the call.
6
Important safety information
Radio frequency energy
Your mobile phone is a radio transmitter and receiver.
When the phone is turned on, it receives and transmits
radio frequency (RF) energy. Depending on the type
of mobile phone you posses, it operates on different
frequency ranges and employs commonly used
modulation techniques. The system that handles your
call when you are using your phone controls the power
level at which your phone transmits.
Specific Absorption Rate (SAR) information.
Your phone has been designed to comply with
applicable safety requirement for exposure to radio
waves. This requirement is based on scientific
organizations through periodic and thorough evaluation
of scientific studies. These guidelines include safety
margins designed to assure this safety of all persons,
regardless of age and health.
• The radio wave exposure guidelines employ a unit
of measurement known as the Specific Absorption
Rate, or SAR. Tests for SAR are conducted using
standardized method with the phone transmitting at
this highest certified power level in all used frequency
bands.
• While there may be differences between the SAR
levels of various LG phone models, they are all
designed to meet the relevant guidelines for exposure
to radio waves.
• The SAR limit recommended by the international
Commission on Non-Ionizing Radiation Protection
(ICNIRP), which is 2W/kg averaged over then (10)
gram of tissue.
• This highest SAR value for this model phone tested by
Sporton for use at the ear is 0.967 W/kg (10g).
SAR data information for residents in countries/regions
that have adopted the SAR limit recommended by the
Institute of Electrical and Electronics Engineers (IEEE),
which is 1.6 W/kg averaged over one (1) gram of tissue.
Electronic devices
Most modern electronic equipment is shielded from RF
energy. However, certain electronic equipment may not
be shielded against the RF signals from your wireless
phone, therefore:
• Don not use your mobile phone near medical
equipment without requesting permission.
Pacemaker
Mobile phones may affect the operation of some
implanted cardiac pacemakers and other medically
implanted equipment. Pacemaker manufacturers
recommend that a minimum separation of 20 cm
(6 inches) be maintained between a hand-held wireless
phone and a pacemaker to avoid potential interference
with the pacemaker.
These recommendations are consistent with the
independent research by and recommendations
of Wireless Technology Research. Persons with
pacemakers:
| General information
7
General information
• Should always keep the phone more than 20 cm (6
General information
inches) from their pacemaker when the phone is
switched on;
• Should not carry the phone in a breast pocket;
• Should use the ear opposite the pacemaker to
minimize the potential for interference.
• If you have any reason to suspect that interference is
taking place, switch off your phone immediately.
Hearing aids
Some hearing aids might be disturbed by mobile
phones. In the event of such disturbance, you may want
to consult your service provider, or call the customer
services line to discuss alternatives.
Aircraft
• Turn off your mobile phone before boarding any
aircraft.
• Do not use it on the ground without crew permission
To prevent interference with communication systems,
you must not use your mobile phone while the plane is
in the air.
8
Potentially explosive atmospheres
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. It is rare, but your phone or its
accessories could generate sparks. Sparks in such
areas could cause an explosion or fire resulting in
bodily injury or even death. Areas with a potentially
explosive atmosphere are often, but not always,
clearly marked. They include fuelling areas, such as
petrol station, below deck on boats, fuel or chemical
transfer or storage facilities, and areas where the air
contains chemicals or particles, such as grain, dust, or
metal powders.; and any other area where you would
normally be advised to turn off your vehicle engine.
Driving
Check the laws and regulations on the use of mobile
phones in the areas where you drive. If you are going to
use your phone while driving, please:
• Give full attention to driving
• Use handsfree. Law in many countries requires
vehicle handsfree.
• Pull off the road and park before making or answering
a call if driving conditions so require.
RF energy may affect some electronic systems in motor
vehicles such as car stereo, safety equipment etc. in
addition, some vehicle manufacturers do not allow use
of mobile phones, unless the installation is supported
by a handsfree kit with an external antenna in their
vehicles. Check with your vehicle manufacturer’s
representative to be sure that your mobile phone will
not affect the electronic systems in your vehicle.
| General information
9
Your phone
Your phone
Main display
Navigation key
Left soft key
Talk key / Yes key
Right soft key
Power on/End call
Volume key
Earphone Jack
10
* key
# key
Microphone &
miniUSB
Camera
MicroSD slot
1. Side key
During a call, adjusts the earpiece volume.
2. Camera Q
The side key is used to make image capture when in
DSC mode.
3. Soft key <>
The current functions are displayed in the bottom line of
LCD. Access main menu and phonebook accordingly.
4. Off Hook S
To make phone call after dialling phone number or to
pick up a phone call
5. On Hook E
• To end a call
• Or power on/off use.
6. Navigation key
In standby mode, quick access to
• Up key: Write Message
• Left key: Profile
• Right key: Shortcuts
• Down key: Contact List
7. Number key
Input number or characters
| Your phone
123
456
789
*0#
11
Your phone
Standby mode
In the main display, you may see several icons shown on your status bar.
Your phone
The meaning of icons are explained below
12
The signal strength of the cellular network
at your current location.
The battery charge level.
Phone locked
Phone is in general profile
Phone is in meeting profile
Phone is in outdoor profile
Phone is in vibrate profile
Phone is in Silent profile
Phone is in Headset profile
The alarm clock is to set on.
You are in roaming.
When missing the incoming call.
Received one or several messages.
All your calls are diverted to another
number.
Chat Room 1
Chat Room 1
Speaker turns on
You are in the internet.
Getting Started
1
2
Installing the SIM card and the battery
You need to insert the SIM card and charge the battery
before using the phone.
• Keep all miniature SIM cards out of the reach of little
children.
• Be careful to handle, insert or remove the SIM card
since the SIM card and its contacts can easily be
damaged by scratched or bending.
• Before installing/removing the SIM card, always
make sure that the phone is switched off.
1. Press the back cover release button (1) and lift the
battery away (2).
(1) (2)
➞
2. Insert and slide the SIM card (3) and battery (4).
(3)
(4)
Charging the battery
You must fully charge the battery before using your
phone for the first time.
1. Connect the lead from the travel adapter to the
socket on the bottom of your phone (A).
(A)
2. Connect the charger to an AC wall outlet.
| Getting Started
13
Getting Started
! Note
You can use the phone while the charger is connected but
Getting Started
14
charging is suspended during that time.
! Note
When the battery is weak indicated by “ ”on the display,
you will hear a warning sound. When the battery becomes
too weak indicated by “ ” on the display, it switched off
automatically.
Switching the phone on and off
• Press and hold E key.
! Note
If the phone shows “Insert SIM” when SIM card is properly
inserted, contact your network operator or service provider.
! Note
You can also use the phone without SIM card. The workable
function would include multimedia, profiles, tools& time and
date except the dialing out and receiving the phone call.
• If the phone asks PIN code, key in the PIN code, and
press < left soft key (LSK) to confirm.
! Note
Do not switch the phone on when wireless phone use is
prohibited or when it may cause interference or danger.
Call functions
This gives you the information about all calling services
that are supported in your phone.
Making a call
In standby mode, key in the number, including the area
code, press S key.
Making a call from the Contacts
1. In standby mode, press > right soft key (RSK) to
enter Contacts, select one name from Search, and
follow by pressing S key to call.
2. You could also press Menu and choose to enter
Contacts submenu to make a call.
3. Or, you can press navigation key down to enter
Search submenu to make a call quickly.
Making an international call
1. For international calls, long press 0 key for the
international prefix (character +).
2. Key in the country code, area code and the phone
number.
3. Press S to call.
Answering or rejecting an incoming call
To answer the incoming call
Press S to answer the call.
To reject the incoming call
Press E to reject the call.
Call waiting
You can answer another incoming call while you have a
call in progress.
1. During a call, press < left soft key (LSK) to enter
option menu to hold a call.
Making a conference call
You can make conference call while you have mulit
calls in progress.
1. Make a call to the first participant.
2. Call the second participant as explained in Make a
new call during a call.
| Call functions
15
Call functions
3. Press < LSK and select Conference. This joins the
calls to the conference.
4. Repeat step 2 and 3 to allow new participants to be
Call functions
connected to the conference call.
5. Press Options and select End all to end the call. Or
press
E.
6. Any call (participant) can be disconnected by press
Options and select End single
.
Tips for call options
A call can be connected to any single caller by pressing
Options key. When you press Options during active call,
you would have following functions as listed in below:
1. Hold: put a call on
2. End: End a call.
3. New call: make a new call during an active call.
4. Contacts: shortcut to Contacts menu.
5. Text message : shortcut to Messaging menu.
6. Sound recorder: to record your conversation during
an active phone call.
16
7. Mute on/off: set On/ Off to mute the call during the
conversation.
8. DTMF: set On/Off for DTMF (Dual Tone MultiFrequency) tone dialing system.
9. Retrieve: reconnect a holding call
10. Retrieve all: reconnect all holding call.
11. Swap: switch between calls on hold and active.
12. Conference: make a multi-party conversation.
13. Transfer: transfer a call.
14. End single: end one of conference call.
15. End all: end a multi-party call.
16. H-Free/H-Held: to choose either Hands free or held
when multi-party call.
17. Split: to suspend the multi-party call.
Input method
You can key in text by using the traditional method
or predictive smart input. Your phone is designed to
support English.
To select input method
1. When key in text, press Option and select Input
method.
Quick way to change input method
• Short Press # to change the input method
To insert a space
In T9Abc, you could use 0 key to insert spaces.
Traditional English input
Your phone provides Multi-tap function. For example,
press 2 key twice to display the letter B, and press
three times to display the letter C.
Characters table
English
Key Unshifted Characters Shifted Characters
1
. , - ? ! ' @ : 1 ) ( ; * / & . , - ? ! ' @ : 1
2
a b c 2 A B C 2
3
d e f 3 D E F 3
4
g h i 4 G H I 4
5
j k l 5 J K L 5
6
m n o 6 M N O 6
7
p q r s 7 P Q R S 7
8
t u v 8 T U V 8
9
w x y z 9 W X Y Z 9
0
0 0
Text entry with “T9”
“T9” uses a built-in dictionary to recognize the most
commonly used word for every sequence of key
presses.
The selected input method icon will be shown in the
indication bar. You can choose to turn on or off your T9
input method in option list.
T9 Abc T9 Smart Abc (English Smart mode)
T9 abc T9 Smart abc
T9 ABC T9 Smart ABC
123 Numberic
Abc Multitap Abc (English)
abc Multitap abc
ABC Multitap ABC
| Input method
17
Listing of Functions
Browser [Menu 1]
Listing of Functions
1. WAP
2. Data account
Call history [Menu 2]
1. All calls
2. Missed calls
3. Dialled calls
4. Received calls
5. Delete call log
6. Call time
7. Call cost
8. Text message counter
9. GPRS counter
18
Tools [Menu 3]
1. Calendar
2. To do
3. Alarm
4. World clock
5. Calculator
6. Unit converter
7. Currency converter
8. Health
9. STK
Multimedia [Menu 4]
1. Games
2. Camera
3. Image viewer
4. Video recorder
5. Video player
6. Music player
7. Voice recorder
8. Melody composer
9. FM radio
10. Schedule FM record
Messaging [Menu 5]
1. Text message
2. Multimedia Message
3. Chat
4. Voice mail server
5. Broadcast Message
My stuff [Menu 6]
Profiles [Menu 7]
Contacts [Menu 8]
1. Search
2. New contact
3. Caller group
4. Speed dial
5. Extra number
6. Copy
7. Delete
8. Move
9. Settings
| Listing of Functions
Settings [Menu 9]
1. Time & Date
2. Display
3. Phone
4. Call
5. Network
6. Security
7. Restore factory settings
19
Browser
Services described in the following are supported by
your service provider. If you cannot connect either one
of those services, you can contact your service provider
for further information.
WAP [Menu 1-1]
Browser
Your phones support Web Browser. You can obtain
various services such as up-to date news, weather,
sport, and other information as well as use e-mail and
other Internet services. These services are designed
and maintained by WAP service providers.
The WAP service uses Wireless Markup Language
(WML) on their WAP pages. You may not view the
Internet web pages on your phone.
! Note
To activate WAP service, you may need to contact your
service provider.
! Note
Do not switch on the phone when wireless phone use is
prohibited or when it may cause interference or danger.
20
Homepage [Menu 1-1-1]
To access the browser from the standby mode, go to
WAP in Service and press Homepage. Once connected,
the homepage is displayed. The content depends on the
service provider.
To exit the browser, press
E key.
Bookmarks [Menu 1-1-2]
You can use this menu to save URL addresses to quick
access a website.
Your phone also provides you for the following
selections for your option.
• Goto: Allow you to link the website.
• Edit: Allow you to edit URL address.
• Delete: Allow you to delete the selected bookmark.
• Delete all: Allow you to delete all bookmarks at once.
• Add bookmark: Allow you to add URL address.
Recent pages [Menu 1-1-3]
You can view the recent pages you have visited. Press
Goto to connect the selected page.
Enter address [Menu 1-1-4]
You can key in the URL address and enter the address
followed by selecting Done. Your phone will connect the
URL you just keyed in. After the address is entered, you
may select the URL and press OK to connect next time.
Service Inbox [Menu 1-1-5]
Your phone is able to receive service message sent
by your service provider. Service messages are
notifications of headlines or content, and they may
contain address of a WAP service. You can get updated
news or new WAP settings from your service provider.
The received WAP push message will be stored in the
service inbox. You can press Option to either Accept or
Delete the push message(s).
Settings [Menu 1-1-6]
GPRS (General Packet Radio Service) is a technology
that is used for sending and receiving data over the
mobile network. The applications that use GPRS are
WAP services, MMS and SMS messaging and GPRS
dial-up (such as Internet and e-mail). You can set the
phone to automatically register to a GPRS network
when you switch the phone on.
WAP setting
• If the settings have been made by the service
provider, you may begin immediately.
• If access profiles have been assigned by your service
provider, select a profile and activate it.
• Otherwise you may key in setting manually. For
appropriate settings, contact your network operator
or service provider.
| Browser
21
Browser
Key in the service settings manually
1. In WAP menu, choose Edit profile in Settings, press
.
OK
2. Choose a profile, press OK, choose Edit profile, press
Edit to start setting.
You need to key in the information in Homepage, Data
Browser
account, Username, Password and IP address in your
phone. To get the information, you may need to contact
your operator.
! Note
In most cases, you only need to use one of the default
profiles to access the Internet. The settings are different
from operator to operator. Please consult your operator or
service provider for the correct settings and proceed with
care. Wrong settings will cause the connection to fail.
Activate WAP settings
After you complete all WAP settings (see WAP settings
function), in WAP Profile mode, please choose Activate
profile, then press OK.
22
Browser options
You can set the timeout value for the browser. The
purpose is to stop the browser connecting the website
if the website does not respond within the timeout.
Also, you can choose either On or Off the image while
browsing.
Service message settings
You can choose either receive or not receive the
service message which saved in the service inbox sent
by your service provider.
Clear cache
The information or date you have accessed is all stored
in the cache of the phone. A cache is a file buffer used
to store date only temporarily. You can clear the history
by selecting this option.
Clear cookies
Under the consideration of privacy and security issue,
we would suggest you to clear cookies which may
contain sensitive information just in case your phone is
misplaced, lost or stolen.
Trusted certificates
This function is to indicate your trusted certificate when
browsing and also adding the trust list into the browser
if needed.
Data account [Menu 1-2]
Default data accounts based on major operators at the
time this phone is manufactured are provided.
You can access WAP via GSM or GPRS
• To get the analogue number or ISDN number
information, you may need to contact your operator
for the service.
• To get the access point of GPRS, you may need to
contact your operator for the service.
GSM data
Press Edit to change the data account settings,
including: Account name, Number, User name,
Password, Line Type, Speed and DNS.
GPRS
Press Edit to change the data account settings,
including: Account name, APN, User name, Password
and Auth. type.
.
| Browser
23
Loading...
