LG KG189 User Manual

11:57PM	Jan 20
Menu	Call rec.

KG189 USER GUIDE

- ENGLISH

TABLE OF CONTENTS

CONTENTS OF TABLE

UNPACKING	5
FOR YOUR SAFETY	6
YOUR PHONE	11
Phone Components
Your Phone’s Features	12
Display Information	13

GETTING STARTED	14
Installing the SmartChip
Charging the Battery	15
Turning Your Phone
On and Off	17
Access Codes

GENERAL FUNCTIONS	18
Making a Call
Adjusting the Volume	19
Answering a Call
Entering Text	20
SELECTING FUNCTIONS	23
AND OPTIONS

IN-CALL MENU	24
During a Call
Conference Calls	25
MENU TREE	27
CONTACTS	29
Contacts
New Contact
Speed Dial List
Caller Groups
Copy All Contacts	30
SIM to Phone
Phone to SIM
Delete All Contacts	30
Settings
Set Memory
Set View Detail
Information	31

Service Dial Number

Check Memory

My Numbers

CALL REGISTER	32
Missed Calls
Dialed Calls
Received Calls
Delete Recent Calls
CALL Duration	32
Last Call
Dialed Calls	33
Received Calls
All Calls
Data Information	33
Web Data
Data Call
Total Data

TOOLS	34
Voice Memo
Calculator
Notepad	35
World Clock

2

Unit Converter	36
Tip Calculator

ORGANIZER	37
Alarm Clock
Calendar
MESSAGES	39
New Message
Text
Multimedia
Inbox	40
Drafts	41
Outbox
Sent	42
LISTEN VOICEMAIL
Info Service	42
Receive
Inbox
Topics	43
Alert
Auto Display

Languages	43
Templates	43
Text
Multimedia	44
Business Card
Settings	44
Text Message
Multimedia Messages	45
Voicemail Number
Download Messages	46
Check Memory

MULTIMEDIA	47
Camera
Photo Album	49
Check Memory	50
SETTINGS	51
Vibrate Only

Silent

General

Loud

Headset	51
Display	53
Wallpaper
Menu Colour
Backlight Timer
Contrast
Languages
Date & Time	53
Set Date
Date Format
Set Time
Time Format	54
Call	54
Call Forwarding
Answer Mode
Send My Number
Call Waiting	55
Minute Minder
Auto Redial
Closed User Group

CONTENTS OF TABLE

3

TABLE OF CONTENTS

		Send DTMF	56
TABLE
		Security	56
		PIN Code Request
OF		Phone Lock
		Auto Key Lock
CONTENTS
		Change Codes	57
		Call Barring Services
		Fixed Dial Number	58
		Connection	58
		Network Selection
		Change Freqency Band	59
		GPRS Attach	60
		Network Profile	61
		Reset Network Profile
		Reset Default

BROWSER	62
Home
Favorites	63
Go To URL

Settings	63
Profiles
Cache Check	64
Clear Cache
Security Certificates
WAP Information

ORGANISER	65
Games & Apps
Games & Apps
Favorites
Information
Audio	67
Graphics	68
Q&A	69
ACCESSORIES	71
SAFETY GUIDELINES	72
GLOSSARY	89

4

UNPACKING

Important Information

G N I K C A P N U

11:57PM	Jan 20
Menu	Call rec.

Handset

Standard Battery

Travel Adapter

5

			FOR YOUR SAFETY
			IMPORTANT INFORMATION
	FOR
			This user guide contains important information on the
	YOUR		use and operation of this phone. Please read all the
			information carefully for optimal performance and to
	SAFETY		prevent any damage to or misuse of the phone. Any
			changes or modifications not expressly approved in
			this user guide could void your warranty for this
			equipment.
			BEFORE YOU START
			Safety Instructions
				WARNING! To reduce the possibility of electric shock,
				do not expose your phone to high humidity areas, such as
				the bathroom, swimming pool, etc.
			Always store your phone away from heat. Never
			store your phone in settings that may expose it to
			temperatures less than 32°F or greater than 104°F,
			such as outside during extreme weather conditions or
			in your car on a hot day. Exposure to excessive cold or
			heat will result in malfunction, damage and/or
			catastrophic failure.
			Be careful when using your phone near other

electronic devices. RF emissions from your mobile phone may affect nearby in adequately shielded electronic equipment. You should consult with manufacturers of any personal medical devices such as pacemakers and hearing aides to determine if they are susceptible to interference from your mobile phone. Turn off your phone in a medical facility or at a gas station. Never place your phone in a microwave oven as this will cause the battery to explode.

IMPORTANT! Please read the TIA SAFETY INFORMATION on page 78 before using your phone.

Safety Information

Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this user guide.

•Never use an unapproved battery since this could damage the phone and/or battery and could cause the battery to explode.

•Never place your phone in a microwave oven as it will cause the battery to explode.

•Do not dispose of your battery by fire or with hazardous or flammable materials.

6

•Make sure that no sharp-edged items come into contact with the battery. There is a risk of this causing a fire.

•Store the battery in a place out of reach of children.

•Be careful that children do not swallow any parts such as rubber plugs (earphone, connection parts of the phone, etc.). This could cause asphyxiation or suffocation.

•Unplug the power cord and charger during lightning storms to avoid electric shock or fire.

•When riding in a car, do not leave your phone or set up the hands-free kit near to the air bag. If wireless equipment is improperly installed and the air bag is activated, you may be seriously injured.

•Do not use a hand-held phone while driving.

•Do not use the phone in areas where its use is prohibited. (For example: aircraft).

•Do not expose the battery charger or adapter to direct sunlight or use it in places with high humidity, such as a bathroom.

•Never store your phone in temperatures less than- 4°F or greater than 122°F.

•Do not use harsh chemicals(such as alcohol, benzene, thinners, etc.) or detergents to clean your phone. There is a risk of this causing a fire.

•Do not drop, strike, or shake your phone severely. Such actions may harm the internal circuit boards of the phone.

•Do not use your phone in high explosive areas as the phone may generate sparks.

•Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if it is loose as it may cause a fire or electric shock.

•Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as it may cause fire or electric shock.

•Do not handle the phone with wet hands while it is being charged. It may cause an electric shock or seriously damage your phone.

•Do not disassemble the phone.

•Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause electric shock or fire.

SAFETY YOUR FOR

7

FOR YOUR SAFETY

• Only use the batteries, antennas, and chargers

	FOR	provided by LG. The warranty will not be applied to
		products provided by other suppliers.
	YOUR
		• Only authorized personnel should service the phone
	SAFETY	and its accessories. Faulty installation or service may
		result in accidents and consequently invalidate the
		warranty.
		• Do not hold or let the antenna come in contact with
		your body during a call.
		• An emergency call can be made only within a service
		area. For an emergency call, make sure that you are
		within a service area and that the phone is turned on.

FCC RF Exposure Information

WARNING! Read this information before operating the phone.

In August 1996, the Federal Communications (FCC) of he United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters.

Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies.

The design of this phone complies with the FCC guidelines and these international standards.

CAUTION

Use only the supplied and approved antenna. Use of unauthorized antennas or modifications could impair call quality, damage the phone, void your warranty and/or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with skin, a minor burn may result. Contact your local dealer for a replacement antenna.

Body-worn Operation

This device was tested for typical body-worn operations with the back of the phone kept 0.6 inches (1.5cm) between the user’s body and the back of the phone.

To comply with FCC RF exposure requirements, a minimum separation distance of 0.6 inches(1.5cm)

8

must be maintained between the user s body and the back of the phone. Third-party belt-clips, holsters, and similar accessories containing metallic components should not be used. Body-worn accessories that cannot maintain 0.6 inches(1.5cm) separation distance between the user's body and the back of the phone, and have not been tested for typical bodyworn operations may not comply with FCC RF exposure limits and should be avoided.

Vehicle Mounted External Antenna (optional, if available)

A minimum separation distance of 8 inches (20cm) must be maintained between the user/bystander and the vehicle mounted external antenna to satisfy FCC RF exposure requirements. For more information about RF exposure, visit the FCC website at www.fcc.gov

FCC Part 15 Class B Compliance

This device and its accessories comply with part 15 of FCC rules. Operation is subject to the following two conditions:

(1) This device and its accessories may not cause harmful interference, and (2) this device and its accessories must accept any interference received, including interference that may cause undesired operation.

Cautions for Battery

•Do not disassemble.

•Do not short-circuit.

•Do not expose to high temperature: 60°C (140°F).]

•Do not incinerate.

Battery Disposal

•Please dispose of your battery properly or bring to your local wireless carrier for recycling.

•Do not dispose in fire or with hazardous or flammable materials.

SAFETY YOUR FOR

9

			FOR YOUR SAFETY
			Adapter (Charger) Cautions
	FOR
			• Using the wrong battery charger could damage your
	YOUR		phone and void your warranty.
			• The adapter or battery charger is intended for
	SAFETY		indoor use only.
			direct sunlight or use it in places with high humidity,
			Do not expose the adapter or battery charger to
			such as the bathroom.

10

Phone Components

1. Earpiece

2. Left soft key

11:57PM	Jan 20
Menu	Call rec.

3. Send key

4. Alphanumeric keys

5. Microphone

YOUR PHONE

PHONE YOUR

6.Display screen

7.Navigation key

8.Camera key

9.Right soft key

10.Message key

11.End/Power key

12.Clear key

11

YOUR PHONE

			Your Phone’s Features
	YOUR
			1. Earpiece
	PHONE		2, 9. Left soft key/Right soft key: Each of these
			keys perform the functions indicated by the text
			on the display immediately above them.
			3. Send key: You can dial a phone number and
			answer incoming calls. Press this key in standby
			mode to quickly access the most recent incoming,
			outgoing and missed calls.
			4. Alphanumeric keys: These keys are used to dial a
			number in standby mode and to enter number or
			characters in edit mode.
			5. Microphone: Can be muted during a call for
			privacy.
			6. Display screen: Displays phone status icons, menu
			items, Web information, pictures and more in full
			color.
			7. Navigation key: Use for quick access to phone
			functions.

8.Camera key: Long pressing this key to use the camera feature. Directly goes to the camera mode.

10.Message key: Use to retrieve or send text messages.

11.End/Power key: Allows you to power the phone on or off, end calls, or return to Standby Mode.

12.Clear key: Allows you to delete the characters entered or return you to the previous screen.

12

DISPLAY INFORMATION

					Icon area
					Text and graphic area
11:57PM	Jan 20
Menu	Call rec.				Soft key indications
Area					Description
First line				Displays various icons.

Dispaly messages, instructions and any Middle lines information that you enter, such as

number to be dialed.

Shows the functions currently assigned

Last line

to the two soft keys.

On-Screen Icons

The table below describes various display indicators or icons that appear on the phone s display screen.

Icon Description

Indicates the strength of the network signal.

Indicates a call is in progress.

Indicates that GPRS service is available.

Indicates the alarm has been set and is on.

Indicates the status of the battery charge.

Indicates the receipt of a text message.

Indicates the receipt of a MMS message.

Indicates the receipt of a voice mail.

Indicates that the vibration has been set for alert.

Indicates the silent has been set for alert.

Indicates the volume when using a headset.

Indicates Ring has been set for alert.

Indicates the speakerphone has been activated.

Indicates that you received new download message.

Indicates the Schedule function.

PHONE YOUR

13

GETTING STARTED

INSTALLING THE SMARTCHIP

	GETTING	When you subscribe to a cellular network, you are
		provided with a plug-in SIM loaded with your
	STARTED	subscription details, such as your PIN, any optional
		services available and many others.
		Important!

]The plug-in SIM and its contacts can be easily damaged by scratches or bending, so be careful when handling, inserting or removing the card. Keep all SIM out of the reach of small children.

1.If necessary, switch off the phone by holding down

the key until the power-off image displays.

2. Remove the battery. To do so:

1 Pull and hold the battery lock above the battery toward the top of the phone.

2 Lift the battery away, as shown.

3.Slide the SIM into the SIM socket so that it locks the card into place. Make sure that the notched corner is bottom left and the gold contacts of the card face into the phone.

Note

When you need to remove the SmartChip, slide it, as shown, and take it out of the socket.

14

4.To insert the battery, align the golden contacts of the battery with the corresponding connectors on the battery compartment. Press down on the opposite end of the battery until it snaps into place.

5.Attach back cover by sliding up into position until it clicks.

CHARGING THE BATTERY

Use of unauthorized accessories could damage your phone and void your warranty.

To use the travel charger provided with your phone:

1.With the battery in position on the phone, connect the lead from the travel charger to the bottom of the phone. Check that the arrow on the lead connector is facing towards the front of the phone.

STARTED GETTING

15

GETTING STARTED

		2. Connect the travel charger to a standard AC wall
	STARTEDGETTING	outlet. Only use the travel charger that comes
		included with the package.

Warning

The travel charger must be unplugged before you remove the battery, otherwise, the phone could the damaged.

3. When charging is finished, disconnect the travel charger from the phone pressing on the gray tabs on both sides of the connector while pulling the connector out.

Notice

]If your phone is powered on while charging, you’ll see the bars in the battery indicator icon cycle. When the battery is fully charged, the bars in the battery indicator icon will flash on and off.

16

If the battery fails to charge completely:

]After turning the phone on and off, please attempt to recharge the battery.

]After detaching and reattaching the battery, please attempt to recharge the battery.

TURNING YOUR PHONE

ON AND OFF

1.Hold down the [END] key until the phone switches on.

2.If the phone asks for a PIN, enter the PIN and press the key.

The phone searches for your network and after finding it goes to the idle screen as illustrated below. From the idle screen, you can make or receive a call.

11:57PM	Jan 20
Menu	Call rec.

Note

The display language is preset to Automatic at the factory. To change the language, use the Languages menu option (Menu 7.2.5).

3.When you wish to switch the phone off, hold down

the [END] key until the power-off image displays.

ACCESS CODES

You can use the access codes described in this section to avoid unauthorized use of your phone. The access codes can be changed by using the Change Codes feature (Menu 7.5.6).

Security code (4 digits)

The security code protects the unauthorized use of your phone. The default security code is set to ‘0000’ and the security code is required to delete all phone entries and to activate the Restore Factory Settings menu. The security code default setting can be modified from the Security Settings menu.

STARTED GETTING

17

GENERAL FUNCTIONS

MAKING A CALL

	GENERAL	1. Make sure your phone is powered on.
		2. Enter a phone number including the area code. To
	FUNCTIONS	edit a number on the display screen, simply press
		the	key to erase one digit at a time.
		] Press and hold the			key to erase the entire
		number.
		3. Press the		[SEND] key to call the number.

4. When finished, press the [END] key.

Making a Call by Send Key

1. Press the [SEND] key, and the most recent incoming, outgoing and missed phone numbers will be displayed.

2.Select the desired number by using the navigation key.

3. Press the [SEND] key.

Making International Calls

1.Press and hold the key and the international access character ‘+’ will appear.

2.Enter the country code, area code, and the phone number.

3.Press the [SEND] key.

Ending a Call

When you have finished a call, press the [END] key.

Making a Call From the Contacts

You can store names and phone numbers dialed frequently in the SmartChip as well as in the phone memory known as the Contacts.

You can dial a number by simply selecting a name in the contacts and pressing the [SEND] key.

18

ADJUSTING THE VOLUME

During a call, if you want to adjust the earpiece volume, use the side keys of the phone.

In idle mode, you can adjust the ring volume using the side keys.

ANSWERING A CALL

When you receive a call, the phone rings and the flashing phone icon appears on the screen. If the caller can be identified, the caller’s phone number (or name if stored in your Address Book) is displayed.

1.Open the Slide and press the [SEND] key or the left soft key to answer an incoming call. If Any Key has been set as the answer mode (Menu 9.4.2), any key press will answer a call except for the [END] key or the right soft key.

2.End the call by closing the phone or pressing the [END] key.

Notice

You can answer a call while using the Address Book or other menu features.

Using the Speakerphone

You can use the integrated Speakerphone during a call by pressing the [OK] key . The loudspeaker is automatically deactivated when you end the call.

Warning

Due to higher volume levels, don’t place the phone near your ear while the speakerphone is enabled.

Vibrate Mode (Quick)

Vibrate Mode can be activated by pressing and holding down the[Star] key.

FUNCTIONS GENERAL

19

		GENERAL FUNCTIONS
		Signal Strength
	GENERAL
		your signal by the signal indicator on your phone’s
		If you are inside a building, being near a window may
	FUNCTIONS	give you better reception. You can see the strength of
		display screen.
		ENTERING TEXT
		You can enter alphanumeric characters by using the
		phone’s keypad. For example, storing names in the
		Address Book, writing a message, or creating
		scheduling events in the calendar all require entering
		text. The following text input methods are available in
		the phone.
		T9 Mode
		This mode allows you to enter words with only one
		keystroke per letter. Each key on the keypad has more
		than one letter. The T9 mode automatically compares
		your keystrokes with an internal linguistic dictionary
		to determine the correct word, thus requiring far fewer
		keystrokes than the traditional ABC mode.

ABC Mode

This mode allows you to enter letters by pressing the key labeled with the required letter once, twice, three or four times until the letter is displayed.

123 Mode (Numbers Mode)

Type numbers using one keystroke per number.

To change to 123 mode in a text entry field, press key until 123 mode is displayed.

A long press changes mode to 123.

Symbolic Mode

This mode allows you to enter special characters.

20

Changing the Text Input Mode

Change the text input mode by pressing . You can check the current text input

mode in the upper right corner of the screen.

Using the T9 Mode

The T9 predictive text input mode allows you to enter words easily with a minimum number of key presses. As you press each key, the phone begins to display the characters that it thinks you are typing based on a built-in dictionary. As new letters are added, the word changes to reflect the most likely candidate from the dictionary.

1. When you are in the T9 predictive text input mode, start entering a word by pressing keys ABC to WXYZ Press one key per letter.

]The word changes as letters are typed - ignore what’s on the screen until the word is typed completely.

]If the word is still incorrect after typing completely, press the [Star] key once or more to cycle through the other word options.

]If the desired word is missing from the word choices list, add it by using the ABC mode.

2.Enter the whole word before editing or deleting any keystrokes.

3.Complete each word with a space by pressing the

key or the right navigation key.

To delete letters, press	.
Press and hold down	to erase the letters

continuously.to erase entire words.

Notice

To exit the text input mode without saving your input, press the [END] key.

Using the ABC Mode

Use the keypad keys to enter your text.

1.Press the key labeled with the required letter:

] Once for the first letter

] Twice for the second letter

] And so on

FUNCTIONS GENERAL

21

GENERAL FUNCTIONS

		2. To insert a space, press the		key once. To
	GENERAL
		delete letters, press the		key. Press and hold
		down the	key to erase the letters continuously.

	FUNCTIONS		Notice
			Refer to the table below for more information on
			the characters available using the keys.
			Key		Characters in the Order Display
					Upper Case	Lower Case
			1		. , - ¿ ? ¡ ! @ 1	. , - ¿ ? ¡ ! @ 1
			2		A B C Á Ã Ç 2	a b c á ã ç 2
			3		D E F É 3	d e f é 3
			4		G H I Í 4	g h i í 4
			5		J K L 5	j k l 5
			6		M N O Ó Ñ 6	m n o ó ñ 6
			7		P Q R S 7	p q r s 7
			8		T U V Ú Ü 8	t u v ú ü 8
			9		W X Y Z 9	w x y z 9
			0		Space Key, 0	Space Key, 0
					(Long press)	(Long press)

Using the 123 (Numbers) Mode

The 123 Mode enables you to enter numbers in a text message (a telephone number, for example) more quickly.

Press the keys corresponding to the required digits before manually switching back to the appropriate text entry mode.

Using the Symbol Mode

The Symbol Mode enables you to enter various symbols or special characters.

To enter a symbol, press the[Star] key. Use the navigation keys to select the desired symbol and press the [OK] key.

22

SELECTING FUNCTIONS AND OPTIONS

Your phone offers a set of functions that allow you to customize the phone. These functions are arranged in menus and sub-menus, accessed via the two soft keys marked the left soft key and the right soft key. Each menu and sub-menu allows you to view and alter the settings of a

particular function.

The soft key functions vary depending on the mode of the phone. The label on the bottom of the display screen immediately above the soft keys indicates current function.

11:57PM		Jan 20
Menu		Call rec.

Press the left soft		Press the right soft
key to access the		key to access the
available Menu.		available Call register.

OPTIONS AND FUNCTIONS SELECTING

23

		IN-CALL MENU
		Your phone provides a number of control functions
	IN	that you can use during a call. To access these
	-	functions during a call, press the right soft key
	CALL
		[Options].
	MENU
		DURING A CALL
		The menu displayed on the handset screen during a
		call is different than the default main menu displayed
		when in idle screen, and the options are described
		below.
		Making a Second Call
		You can select a number you wish to dial from the
		Address Book to make a second call. Press the right
		soft key then select Contacts.
		Swapping Between Two Calls
		To switch between two calls, press the right soft key
		or the	[SEND] key, and then select Swap.

Answering an Incoming Call

To answer an incoming call when the handset is ringing, simply press the [SEND] key. The handset is also able to warn you of an incoming call while you are already on a call. A tone sounds in the earpiece, and the display will show that a second call is waiting. This feature, known as Call Waiting, is only available if your network supports it.

If Call Waiting is on, you can put the first call on hold and answer the second call, by pressing the [SEND] key.

Rejecting an Incoming Call

You can reject an incoming call without answering by simply pressing the [END] key.

During a call, you can reject an incoming call by pressing the [END] key.

Muting the Microphone

You can mute the microphone during a call by pressing the [Options] key then selecting Mute or the left soft key [Mute]. The handset can be unmuted by pressing

24

the Unmute menu or the left soft key [Unmute]. When the handset is muted, the caller cannot hear you, but you can still hear the caller.

CONFERENCE CALLS

The conference service provides you with the ability to have a simultaneous conversation with more than one caller. The conference call feature can be used only if your network service provider supports this feature. The conference call can only be set up when you have one call active and one call on hold, meaning both calls must have been answered. Once a conference call is set up, calls may be added, disconnected or separated (that is, removed from the conference call but still connected to you) by the person who set up the conference call. These options are all available from the In-Call menu. The maximum number of callers in a conference call is five. Once started, you are in control of the conference call, and only you can add calls to the conference call.

Making a Second Call

You can make a second call while currently on a call simply by entering the second number and pressing

the [SEND] key. When the second call is connected, the first call is automatically placed on hold. You can swap between calls, by pressing the [SEND] key.

Setting Up a Conference Call

To set up a conference call, place one call on hold, conference in the second active call by pressing the right soft key and select the Join Calls sub menu option from the Conference Call menu.

Activate the Conference Call on Hold

To activate a conference call on hold, press the [SEND] key.

Adding Calls to the Conference Call

To add a call to an existing conference call, press the right soft key, and then select the Join Calls sub menu from the Conference Call option.

MENU CALL - IN

25

IN-CALL MENU

MENU CALL - IN

Private Call in a Conference Call

To have a private call with one caller from a conference call, press the right soft key and select the Private Menu from the Conference Call option. When the numbers of the callers are displayed, select the one you wish to speak in private.

Ending a Conference Call

Currently active conference call can be disconnected by pressing the [END] key.

26

MENU TREE

The following illustration shows the available menu structure and indicates the:

] Number assigned to each menu option.

] Page where you can find the feature description.

1. Contacts		3. Tools		5. Messages
1.1 Contacts		3.1 Voice Memo		5.1 New Message
1.2 New Contact		3.2 Calculator		5.2 Inbox
1.3 Speed Dial List		3.3 Notepad		5.3 Drafts
1.4 Caller Groups		3.4 World Clock		5.4 Outbox
1.5 Copy All Contacts		3.5 Unit Converter		5.5 Sent
1.6 Delete All Contacts		3.6 Tip Calculator		5.6 Listen Voicemail
1.7 Settings				5.7 Info Service
1.8 Information				5.8 Templates
				5.9 Settings
2. Call register		4. Organizer
				5.0 Check Memory
2.1 Missed Calls		4.1 Alarm Clock
2.2 Dialed Calls		4.2 Calendar

2.3Received Calls

2.4Delete Recent Calls

2.5Call Duration

2.6Data Information

TREE MENU

27
