LG K4 LTE User Guide

Download

This booklet is printed with soy ink. Printed in China

This booklet is made from 98% post-consumer recycled paper.

User guide.

Guía del usuario.

MFL69500901 (1.0)

Important Customer Information

Before you begin using your new phone

Included in the box with your phone are separate information leaﬂets. These leaﬂets provide you with important information regarding your new device. Please read all of the information provided. This information will help you to get the most out of your phone, reduce the risk of injury, avoid damage to your device, and make you aware of legal regulations regarding the use of this device.

It’s important to review the Product Safety and Warranty Information guide before you begin using your new phone. Please follow all of the product safety and operating instructions and retain them for future reference. Observe all warnings to reduce the risk of injury, damage, and legal liabilities.

Table of Contents

Important Customer Information...............................................1

Table of Contents .......................................................................2

The Basics ...................................................................................5

Phone Overview .................................................................................................... 5

Help ........................................................................................................................7

Setting Up Your Phone ........................................................................................8

Removing the Battery and SIM Card ................................................................10

Inserting and Removing a Memory Card ...........................................................11

Charging Your Phone ..........................................................................................12

Optimizing Battery Life ...................................................................................... 13

Turning Your Phone On and Off ........................................................................15

Your Google Account .......................................................................................... 17

Anti-Theft Guide .................................................................................................18

Touch Screen .......................................................................................................19

Getting to Know the Home Screen ..................................................................20

Apps: How to View, Open, and Switch .............................................................26

Capturing a Screenshot .....................................................................................33

Phone’s Status Icons .........................................................................................34

Managing Notiﬁcations .....................................................................................36

Searching Your Phone and the Web .................................................................38

Setting Your Lock Screen ..................................................................................40

Connecting to Networks and Devices ................................... 44

Wi-Fi ....................................................................................................................44

Wi-Fi Direct ........................................................................................................45

Bluetooth .............................................................................................................45

PC Connections with a USB Cable ..................................................................46

PC Connections with a USB Cable for Mac OS X Users .............................. 47

Calls .......................................................................................... 48

Placing and Ending Calls ..................................................................................48

Answering or Rejecting Calls .............................................................................51

Working with the Recent Tab ............................................................................53

Calling Your Contacts......................................................................................... 55

Options During a Call ........................................................................................56

Managing Multiple Calls ....................................................................................56

Table of Contents

Web ........................................................................................... 58

Chrome ................................................................................................................58

Communication ........................................................................ 61

Contacts ...............................................................................................................61

Messaging ........................................................................................................... 67

Email .....................................................................................................................7 1

Gmail ................................................................................................................... 74

Hangouts ..............................................................................................................81

Entertainment .......................................................................... 84

Camera ................................................................................................................84

Music ................................................................................................................... 93

Play Store ............................................................................................................ 97

YouTube™ ............................................................................................................99

Tools ........................................................................................ 100

Capture+ ...........................................................................................................100

Clock .................................................................................................................. 102

Calculator .......................................................................................................... 103

Calendar ............................................................................................................ 104

Maps .................................................................................................................. 105

Voice Search ......................................................................................................107

Voice Recorder .................................................................................................108

File Manager ...................................................................................................... 110

Settings .....................................................................................111

Safety .......................................................................................130

Consumer Information About Radio Frequency Emissions ......................... 132

Consumer Information on SAR ......................................................................137

FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices . 138 Caution:

Avoid potential hearing loss. ........................................................................... 140

TIA Safety Information .................................................................................... 142

Safety Information ........................................................................................... 145

FDA Consumer Update ................................................................................... 149

Table of Contents

FAQ ..........................................................................................162

LIMITED WARRANTY STATEMENT ....................................168

Index ........................................................................................ 176

Phone Overview

Front View

Earpiece

The Basics

Proximity/Ambient

Light Sensor

Front Camera

Power/Lock Button

Back Button

NOTES • All screen shots in this guide are simulated. Actual displays may vary.

• Instructions to perform tasks in this guide are based on the default settings and may

change depending on the mode and software version on your phone.

Recent Apps Button

Home Button

1. Earpiece Lets you hear callers and automated prompts.

2. Back Button Returns to the previous screen. Also closes pop-up items, such as menus, dialog boxes and the on-screen keyboard.

3. Proximity/Ambient Light Sensor Senses proximity toward other objects (such as your head) so that tap commands are not accidentally activated during a call or when carried inside a pocket. It also employs an ambient sensor which measures the surrounding light and adjusts the LCD brightness to provide a vivid screen.

NOTE Don't block the sensor or near the sensor to avoid problems with the touch screen.

4. Front Camera Use to take pictures and record videos of yourself. You can also use this for video chatting. Keep it clean for optimal performance.

5. Power/Lock Button Press to turn off the screen backlight and lock the

screen, or turn the screen backlight back on. Press and hold to turn the phone on/off, restart it, and activate/deactivate Airplane mode.

The Basics

6. Recent Apps Button Displays recently used applications. If you touch and hold this key, it opens a menu of available options.

7. Home Button Return to the Home screen from any screen.

Rear View

Back Camera

Back Cover

Cutout

Speaker

Flash

Volume

8. Back Camera Use to take photos and record videos. Keep it clean for

optimal performance.

Back Cover Cutout Use to remove the back cover for access to the

battery, the SIM card slot, and the microSD card slot.

Speaker Use to listen to audio (e.g., music, videos, sound clips,

10.

speakerphone, etc.) from the rear speaker instead of the earpiece.

Flash Brightens up the captured image or recorded video when you

11.

turn on the ﬂash.

Volume Press to adjust the ringer, the media volumes, or the in-call

12.

volume during a call. They also access shortcuts when enabled in the Settings menu.

TIPS s With the screen backlight off (asleep), you can press either of the Volume Buttons

twice quickly to activate the Camera app.

s With the screen unlocked, press both of the Volume Buttons at the same time to

open the Capture+ app to write a memo.

Top and Bottom Views

The Basics

Microphone

Headset Jack

USB/Charging

Port

Microphone

13. Microphone Transmits your voice to the other caller. It's also used for

voice-activated functions.

Headset Jack Allows you to plug in an optional headset for convenient,

14.

hands-free conversations. You can also plug in headphones to listen to music.

USB/Charging Port Allows you to connect the phone and the USB

15.

cable for use with the charger adapter, or other compatible accessories.

16.

Microphone Transmits your voice to the other caller. It's also used for

voice-activated functions.

Help

The Help app allows you to quickly and conveniently view information about your phone, including how-to videos, Icon glossary, etc.

To access Help, tap the Home Button

> the Apps icon > Help .

The Basics

Setting Up Your Phone

Step 1. Remove the Back Cover

With the phone facing down, insert your ﬁngernail into the cutout located on the lower left of the back cover and lift the cover up gently.

Step 2. Insert the Battery

Insert the battery, making sure the gold contacts line up. Press down gently to secure.

The Basics

Step 3. Replace the Back Cover

Align the cover over the back of the phone, and then press down along the Flash edges to secure.

Step 4. Charge the Phone

Before turning on your phone, charge it fully. Plug the small end of the USB cable into the USB/charger port on your phone. Plug the other end into the charger and plug the charger into an outlet.

WARNING! Only use approved chargers with your device. Incompatible chargers or tampering

with the charging port could damage your device and void the warranty.

The Basics

Removing the Battery and SIM Card

Removing the battery

1. With the phone facing down, insert your ﬁngernail into the cutout located on the lower left of the back cover and lift the cover up gently.

2. Use the ﬁngertip cutout at the bottom of the battery compartment to lift the battery out.

Removing the SIM card

The SIM card is pre-installed in your smartphone. If you need to replace your SIM card, refer to the following instructions.

1. Turn the phone off, then remove the back cover and the battery (as demonstrated in the previous instructions).

2. Locate the slot for the SIM card (at the top of the battery compartment) and gently slide the SIM card out to remove it.

The Basics

Inserting and Removing a Memory Card

Inserting a microSD card

1. Remove the back cover (as demonstrated in the previous instructions).

2. Position the microSD card (sold separately) with the label side facing up and the gold contacts toward the slot (at the upper-left side of the phone), then carefully slide it into the slot until it's secured in place.

NOTE The microSD card can be easily damaged by

improper operation. Please be careful when inserting, removing, or handling it.

To remove the microSD card

1. Unmount the microSD card.

 Tap the Home Button

hold the Recent Apps Button

Settings > Storage > Unmount SD card.

2. The microSD slot is just mentioned in the previous instructions (its location is not pointed out unless you make my text suggestion).

3. Carefully pull the microSD card out to remove it.

> touch and

The Basics

To unmount the microSD card

It’s important to unmount the microSD card prior to removing it from the phone to avoid damage to it or the data saved on the card.

1. Tap the Home Button

> touch and hold the Recent Apps Button .

2. Tap Settings > Storage.

3. Tap Unmount SD card.

Charging Your Phone

Your phone comes with a USB cable and a charger adapter. You can connect them together and charge from a power outlet, or you can use the USB cable alone to charge from your computer. Correctly orient the plugs before insertion to avoid damaging your phone and cable.

NOTE Please only use an approved charging accessory to charge your LG phone. Improper

handling of the USB/Charging port, as well as the use of a incompatible charger, may cause damage to your phone and void the warranty.

1. Correctly orient the USB cable with the charger adapter and connect them. As shown below, both the USB logo on the USB cable and the LG logo on the adapter will face toward you.

USB Cable

Charger Adapter

2. The USB/Charging port is located at the bottom of the phone. Correctly orient the cable's plug with the port before plugging it in. As shown on the following page, the USB logo on the cable will face upward.

3. Plug the charger adapter into a power outlet to begin charging.

The Basics

Charging with the USB Cable

NOTE

Make sure to correctly orient the cable's plug with the port before plugging it in. When the phone is facing upward, the USB

USB Cable

logo on the cable will also face upward.

You can use your computer to charge your phone. To be able to charge with the USB cable, you need to have the necessary USB drivers installed on your PC ﬁrst. Connect one end of the USB cable to the USB/Charging port on your phone (as shown above) and connect the other end to a USB port on your PC. It’s best to use the rear USB port when connecting to a desktop PC. The USB hub should be powered by an external power source.

NOTE You may experience a slower charging rate when charging from your computer.

Optimizing Battery Life

You can extend your battery’s life between charges by turning off features that run in the background. You can also monitor how apps and system resources consume battery power.

Tips to extend the life of your battery

Reduce the screen brightness and set a shorter screen timeout.



Turn off radio communications (such as Wi-Fi, Bluetooth



you're not actively using. (Note that the GPS receiver is only turned on when an app that makes use of it is opened).

Turn off automatic syncing for Gmail, Calendar, Contacts, and other apps



if you don’t need it.

NOTES s Allowing other devices to use your device's hotspot connection will drain your battery

s If you accidently press the Power/Lock Key while the phone is in your pocket, the

more quickly.

proximity sensor prevents the screen from turning on in order to save battery power.

, GPS, etc.) that

The Basics

To check the battery charge level

Tap the Home Button > touch and hold the Recent Apps Button > Settings > Battery.

The battery level (as a percentage of fully charged) and the battery status



(Charging or Discharging) is displayed at the top of the screen.

Checkmark the Battery percentage on Status Bar checkbox to display



the remaining battery charge percentage on the Status Bar next to the battery icon.

Tap Battery saver to view and/or modify your Battery saver settings.



To monitor and control what uses the battery

The Battery usage screen allows you to see which apps are consuming the most battery power. Information on this screen allows you to identify downloaded apps you may want to turn off when not being used, so you can get the most out of your battery power.

Tap the



The top of the Battery usage screen displays a usage graph and below it,



Home Button > touch and hold the Recent Apps Button >

Settings

> Battery > Battery usage.

Tap the

Home Button >

Settings

> About phone > Battery > Battery usage.

battery usage times and details. All of the apps or services using battery power are listed from the greatest amount of energy used to the least amount.

Tap an app or service in the Battery usage screen to see details about its

power consumption. Different apps or services offer different kinds of information, and they may even include options to modify the settings so you can reduce power consumption by that app.

Tap Stop next to an app you want to stop running.

touch and hold the

Recent Apps Button >

The Basics

Battery saver

Battery saver changes certain settings to conserve battery power until you can recharge your phone. If you turn Battery saver on, it will automatically activate when the battery charge level drops to the level you set. If Battery saver is off, you’ll be prompted to turn on Battery saver when the battery reaches low levels.

Tap the Home Button



Settings

> Battery > From the Battery saver screen: Select to activate Battery saver immediately, or when the charge drops to 5% or 15%. If you turn off Battery saver, when the battery charge becomes low, a notiﬁcation prompts you to turn it on.

Mark the Restrict apps in background checkbox to restrict apps in the



background, as well as notiﬁcations, downloading, and streaming for apps when Battery saver is on.

After you modify the Battery saver settings to your preferences, tap the



switch

to toggle it On (blue) or Off (gray).

> touch and hold the Recent Apps Button >

Battery saver.

Turning Your Phone On and Off

Turning your phone on

Press and hold the Power/Lock Key



screen turns on.

Turning your phone off

1. Press and hold the Power/Lock Key until the Phone options menu appears.

2. Tap Power off in the Phone options menu.

3. Tap OK to conﬁrm that you want to turn off the phone.

for a couple of seconds until the

The Basics

Turning the screen on and off using the KnockON feature

The KnockON feature allows you to double-tap the screen to easily turn the screen on or off.

Quickly double-tap the center of the dark screen to turn on the backlight



and display the Lock screen.

Quickly double-tap the Status Bar, an empty area on the Home screen,



or the Lock screen to turn the screen off.

NOTES s The backlight will not turn on if the proximity sensor is covered.

s When the screen is off and you double-tap the upper portion of screen with Knock

Code activated, the Knock Code grid is displayed for you to enter your Knock Code.

Turning the screen on using the Knock Code feature

If your Lock screen unlock sequence is set to a Knock Code, tap your Knock Code on the darkened screen to automatically turn on the backlight and unlock the screen at the same time.

TIP When the screen is in timeout and a Knock Code is set, pressing the Power/Lock Key

displays the Lock screen (e.g., to check the time). You can tap your Knock Code to

unlock the screen or press the Power/Lock Key turn the backlight back off.

sIf you enter the incorrect Knock Code 6 times, you'll be prompted you to enter your

NOTES

s Use a ﬁngertip instead of a ﬁngernail to tap your Knock Code on the screen.

backup PIN to unlock your phone and the unlock sequence is automatically changed to Swipe.

again (or double-tap the Status Bar) to

Setting up the Knock Code feature

1. Tap the Home Button > touch and hold the Recent Apps Button > Lock screen settings.

2. Tap Select screen lock > Knock Code.

3. Tap the squares in a pattern (from 3 to 8 taps) to set your Knock Code, tap DONE, enter it again, then tap CONFIRM.

NOTE You'll be prompted to enter a backup PIN in case you forget your Knock Code.

The Basics

To unlock the phone

If you don’t use the phone for a while, the screen and backlight will turn off to conserve battery power. To unlock the phone’s default Lock screen:

NOTE The default Lock screen simply locks the screen to prevent

unintentional actions. For more security to guard against unauthorized use, you can set an unlock requirement (such as a Knock Code, pattern, PIN, or password) that will need to be entered to unlock it.

1. Turn the screen on.

 Press the Power/Lock Key

NOTE Avoid covering the proximity sensor when turning the screen

on. Doing so will prevent the screen from turning on.

 Quickly double-tap the center of the screen (KnockON).

2. From the center of the screen, swipe in any direction to unlock it.

Your Google Account

You must sign into a Google Account to use Gmail, Hangouts, Google Calendar, and other Google apps; to download apps from Play Store; to back up your settings to Google servers; and to take advantage of other Google services on your phone.

IMPORTANT

ţ If you don’t sign into a Google Account during setup, you're prompted to sign in or to

ţ If you have an enterprise account through your company or other organization, your IT

create a Google Account the ﬁrst time you start an app that requires one, such as Gmail or Play Store.

ţ When you sign in, you’re prompted to enter your username and password.

ţ After you sign in, your contacts, Gmail messages, Calendar events, and other

information from these apps and services on the web are synchronized with your phone.

department may have special instructions on how to sign in to that account.

The Basics

Setting up your Google Account

If you use Setup Wizard to set up your Google Account or launch an application that requires a Google Account (such as Play Store or Gmail), you're guided through the following steps.

1. Enter your email and tap NEXT.

NOTE If you don't already have a Google Account, tap Or create a new account and follow the

prompts to create your new account.

2. Enter your password and tap NEXT.

3. Follow the rest of the instructions on the screen.

Your Gmail, Google Contacts, and Google Calendar events will all be

synchronized with your phone automatically.

Anti-Theft Guide

You can set up your device to prevent other people from using it if it’s been reset to factory settings without your permission. For example, if your device is lost, stolen, or wiped, only someone with your Google Account or screen lock information can use the device.

All you need to make sure your device is protected is:

Set a screen lock: If your device is lost or stolen but you have a screen



lock set, the device can’t be erased using the Settings menu unless your screen is unlocked.

Add your Google Account on your device: If your device is wiped but



you have your Google Account on it, the device can’t ﬁnish the setup process until your Google Account information is entered again.

After your device is protected, you’ll need to either unlock your screen or enter your Google Account password if you need to perform a factory reset. This ensures that you or someone you trust is performing the reset.

NOTE Do not forget your Google Account and password you added to your device prior to

performing a factory reset. If you can't provide the account information during the setup process, you won't be able to use the device at all after performing the factory reset.

The Basics

Touch Screen

Your touch screen provides an excellent way to interact with and use your Android™ phone. With the touch of your ﬁnger, you can download and use available apps, make menu selections, and access data saved to your phone.

Touch or tap A single ﬁnger touch selects items. For example, tap an

icon (e.g., an app, widget, or folder), tap words (e.g., menu selection or to answer an on-screen question), or touch letters and numbers to type.

NOTE Don't press too hard on the screen. It's sensitive enough to detect a light, ﬁrm tap.

Touch and hold Touch an item on the screen and don't lift your ﬁnger

until an action occurs. For example, to open a context menu for a contact, touch and hold the contact entry until the menu pops up.

Drag Touch and hold an item for a moment and then, without lifting your

ﬁnger, move your ﬁnger on the screen until you reach the target position. For example, you can drag items on the Home screen to reposition them.

Swipe, slide, or ﬂick Move your ﬁnger quickly across the surface of the

screen, without pausing when you ﬁrst touch it (so you don’t drag an item instead). For example, you can browse through the Home screens by swiping left and right, slide the screen up or down to scroll through a list, or remove an app from the Recent Apps screen by ﬂicking its graphic off the screen.

Double-tap Tap the screen twice quickly to zoom, highlight text, or turn

the screen on/off. For example, quickly double-tap a section of a web page to zoom that section to ﬁt the width of the screen and control the zoom in Maps and in other apps. Double-tap a word to highlight it. Double-tap can also activate the KnockON feature to turn the screen on or off.

NOTE Triple-tap can also be used. For example, in the Calendar app a triple-tap will quickly

create a new event. Triple-tap is also used in the Accessibility settings shortcuts and Touch zoom accessibility features.

The Basics

Multi-touch Use your index ﬁnger and thumb in a pinch motion (to zoom

out) or spread motion (to zoom in) when using Chrome, a map, photos, the rear camera lens, the Contacts list, the Favorites list, the Groups list, and the Messaging list. Spread apart to make screen information larger (easier to see and read), or pinch together to view more area and information. The pinch gesture also changes the Home screen. Pinch in on the Home screen to change to mini panel view, then spread apart to return to the full screen view. Spread apart on the Home screen to hide all of your Home screen items, then pinch in to redisplay them.

Rotate the screen From many apps and menus, the orientation of the

screen adjusts to the phone’s physical orientation by rotating the screen. You can deactivate this function in the Display settings menu.

Getting to Know the Home Screen

The Home screen is your starting point to access all of the features on your phone using simple gestures on the screen. It’s comprised of multiple panels (swipe horizontally to switch). You can customize all of your Home screen panels with app shortcuts, icons, widgets, and other features.

Status Bar

Shows device status information, including the time, signal strength, battery status, and notiﬁcation icons.

App Icon

Tap an icon (app, widget, folder, etc.) to open and use it.

Quick Access Bar

Icons that provide easy, one-touch access to the functions used most often.

Apps Icon

Tap here to open the Applications screen to view all of your installed apps.

Home Touch Buttons

Displayed on all screens, these buttons allow you to easily navigate within the device software.

Quick Access Bar icons

The Quick Access Bar is located on all of your Home screen panels to allow quick and easy access to the apps you use most often.

The Basics

Modifying the Quick Access Bar icons

Rearrange: Touch and hold the icon to move, then drag it to another



position in the Quick Access Bar.

Add: Open the Applications screen, then drag the icon you want onto



the Quick Access Bar.

Delete: Touch and hold the icon to delete, then drag it to the Remove bar



that appears at the top of the screen.

Home Touch Buttons

The Home Touch Buttons are displayed in a bar at the bottom of all of the screens to provide easy navigation within the device software.

Back Button: Tap to back up one step at a time and close on-screen

items such as pop-up messages, the on-screen keyboard, etc.

Home Button: Tap to immediately return to the Home screen. Touch

and hold it to access the Google Now shortcut.

Recent Apps Button: Tap to display the apps you recently used as well as all of your open websites. Touch and hold it to access available options for the current screen or app.

Modifying the Home Touch Buttons

You can change which buttons are displayed in the Home Touch Buttons Bar, as well as how they’re displayed.

1. Tap the Home Button

Settings > Display > Home touch button combination.

2. Drag an icon to rearrange the Home touch buttons. You can add the

Notiﬁcation Button and/or the Capture+ Button and change each button's location within the bar.

> touch and hold the Recent Apps Button >

To return to the Home screen

Tap the Home Button



at any time, from any app.

The Basics

To view other Home screen panels

Swipe (or ﬂick) your ﬁnger left or right across the Home screen. The



Home screen is comprised of three sliding panels, but you can add up to ﬁve panels to allow more space for icons, widgets, shortcuts, and other items.

The white dot indicates the current Home screen panel.

Tap any of the Home screen panel indicator dots (above the Quick



Access Bar) to immediately jump to that panel.

Pinch in on the Home screen to change to mini panel view, then tap the



Home screen panel you want to access.

Home Screen Panel Indicator

Mini Panel View

Tap here to set this panel as the default Home screen.

Tap here to add another panel.

Full Screen View Mini Panel View

Mini panel view allows direct access to any of the Home screen panels and also allows you to manage them. You can add, delete, and rearrange the panel order as well as set the default Home screen panel.

The Basics

Pinch in on any of the Home screen panels to change from full screen view to mini panel view. From mini panel view you have the following options:

To go directly to any panel, simply tap the one you want.



To add another panel, tap the Add panel icon



To delete a panel, touch and hold the panel to delete, drag it to the



Remove bar at the top of the screen, then lift your ﬁnger.

To rearrange your panels, touch and hold the panel to move, drag it on



top of the panel position where you want it, then lift your ﬁnger. The

moved panel takes that position and the remaining panels shift accordingly.

To set another panel as the default Home screen, tap the Default icon



on the mini panel you want to be your default Home screen panel.

NOTE Changing the default Home screen panel does not change its position with the other

panels, but the mini panel and its Default icon turn blue.

To return to full screen view, pinch out on the screen, tap the Back



Button

NOTE The device automatically reverts to full screen view after screen timeout.

, or tap the Home Button .

Hiding items on the Home screen

Place two ﬁngers on the screen, then spread them apart to hide the items on your Home screen so that only your wallpaper, the Status Bar, the panel indicator dots, and the Home Touch Buttons Bar are displayed. To redisplay your Home screen with all of its icons and widgets, pinch in on the screen, tap the Back Button

NOTE The device automatically reverts to full screen view after screen timeout.

, or tap the Home Button .

The Basics

Using Dual View

Slide the screen right or left to view different Home screen panels.

Item List Touch and hold an icon, then drag it onto the panel where you want it.

Category Tabs Tap a category to display its available items.

Dual view allows you to easily add items to any of the Home screen panels. Touch and hold an empty spot on a Home screen panel to view your Home screen on top and selections (Apps tab, Widgets tab, or Wallpapers tab) on the bottom. Flick sideways to scroll through the Home screen panels to display the panel you want. Tap the type of item you want to add (from the category tabs at the bottom of the screen), then ﬂick sideways to scroll through the available choices. Simply tap the item you want to automatically add it to the panel viewed at the top of the screen.

NOTE The Quick Access Bar is not displayed while in Dual view.

To return to full screen view, tap the Back Button , the Home Button , or tap one of the Home screen panels.

NOTE The device automatically reverts to full screen view after screen timeout.

The Basics

Home screen version

EasyHome is a more simpliﬁed version of the Home screen that you can choose to use on your phone.

Tap the Home Button Home screen settings > Select Home > EasyHome.

The EasyHome Home screen has three panels.

Its main panel has 9 application icons that you can use with a single tap. Touch and hold one to remove or replace it (the Apps icon removed or replaced). The top right of the screen displays the date and time. Tap it to access the Clock app. The top left of the screen displays a Weather widget. Tap it to access the Weather app.

Swipe to the right on the main panel to access the communication panel



that you can customize with call/text message shortcuts for the contacts you set. It also provides access to the Phone app to dial other numbers. Tap one of the 9 Contact shortcut locations, then tap the contact you want to set. After a shortcut is set, tap it to use it (tap the name to dial the number or tap the middle to display communication choices). Tap

Dial to open the Dial tab to dial manually, tap Recent to open your Recent tab, or tap Contacts to open your Contacts list tab.

NOTE When you tap Dial, Recent, or Contacts, you have access to all of the Phone app

features.

Swipe to the left on the main panel to access a panel you can customize



with additional app shortcuts, open the Applications screen, and use the Google Search widget. To add a shortcut, tap the Add icon the app you want. Touch and hold an app shortcut icon to remove or replace it. To access all of your installed apps, tap the Apps icon .

To change back to the Android Home screen

Tap the Home Button > touch and hold the Recent Apps Button > System settings > Home screen > Select Home > Home.

> touch and hold the Recent Apps Button >

can't be

, then tap

The Basics

Apps: How to View, Open, and Switch

All of the apps on your phone, including any apps that you downloaded and installed from Play Store or other sources, are grouped together on the Applications screen, which you access from your Home screen. If you have more apps than can ﬁt on the Applications screen, you can slide the screen left or right to view more.

Tap the Apps icon open the Applications screen.

Home Screen

Tap these to select Apps, Widgets, Search, or the Options menu.

Slide the screen left or right to bring more icons into view.

Tap an app icon to open the app.

Applications Screen

Applications screen options

You can change the look of your Applications screen.

1. Tap the Home Button

> the Apps icon

The Basics

2. Tap the Options icon to access the following Applications screen

options:

 View apps by: Tap to sort your apps either in alphabetical order, by

downloaded date, or custom.

 Show small/large icons: Tap to change the size of the icons displayed

in the Applications screen.

 Hide/Show apps: Tap to set which app icons will be displayed in your

Applications screen. Checkmark the icons you want to hide, then tap the Done icon

 Edit/Uninstall apps: Tap to view app information, uninstall, or move

apps on the screen. Tap an app icon to view its information, then tap Uninstall or OK. Touch and hold an app, drag it to move it, then tap the Done icon

 Home screen settings: Tap to access the Home screen settings

menu.

Opening an app

Open an app simply by tapping its icon on the screen.

TIP You can customize your Home screen with the app icons you use most often. Apps are

located on the Applications screen, but you can copy any app icon to your Home screen for faster, more convenient access. No matter where the icon is, on the Applications screen or your Home screen, just tap it to open and use it.

Opening multiple apps

1. Tap an app icon to open it.

2. Tap the Home Button

NOTE If the app icon you want is on your Home screen, simply tap the icon to open and use it.

3. Tap the Apps icon .

4. Tap the icon for the other app you want to open.

The Basics

Switching between multiple apps

1. Tap the Recent Apps Button . A screen opens with screenshot tabs of

all of the apps (and websites) that are currently open.

2. Tap the app you want to use, tap the Close icon

it, or tap the Back Button

Swipe up or down to view the entire stack of open apps.

to return to the current screen.

Flick an app icon to the right or left to close the app and remove it from the list.

Tap an app to use it.

Tap here to close this app.

Recent Apps Screen

on the app to close

Adding items to the Home screen

1. Tap the Home Button > the Apps icon .

NOTE Tap the Widgets tab to place a widget on the Home screen.

2. Touch and hold the icon you want to add to your Home screen. The

Applications screen closes and the Home screen is displayed.

3. Drag the icon to where you want it on the screen (or onto another Home

screen panel), then lift your ﬁnger.

Moving apps to other Home screen panels

You can move app icons to any Home screen panel. Touch and hold, then drag the icon to the left or right edge of the screen to advance to the other panels before lifting your ﬁnger.

The Basics

Customizing an app icon on your Home screen

You can create your own custom app icon(s) using the images in your Gallery. Your customized app icon(s) are only applied to icons on your Home screen. The Applications screen is not affected.

Touch, hold, release, then tap an icon to edit it.

Icon change ScreenHome Screen

1. Touch and hold the icon you want to customize, then release the icon.

An editing icon

NOTE If an icon you placed can be resized, you'll see a blue box around the icon after you

touch, hold and release it. Drag the edges of the box to resize it.

2. Tap the app icon (while the edit icon is still displayed).

3. Tap the icon design you want from the available icon choices, then tap

OK.

㻃 Tap the Add new icon

the image you want to use for the app, crop the image (if necessary), then tap OK.

NOTE Your custom photo icons are saved so you can easily select them for any of your icon

images. Tap the Delete icon

appears on the app icon.

set the size for the icon, then tap OK. Select

to remove any of your custom photo icons.

The Basics

Changing an icon into a widget

Some app icons can be resized into a widget. Touch and hold the icon you want, then release the icon. A blue frame appears around the icon if it can be resized (if it can't, only the Edit icon is displayed). Drag the corners of the frame to size it as you want.

Text Input Methods

The on-screen keyboard displays automatically on the screen when you need to enter text. To manually display the on-screen keyboard, simply tap a text ﬁeld where you want to enter text.

Selection Box

Tap a displayed item to insert it in the text ﬁeld.

Tap to enter text by voice. Touch and hold for clip tray entry (or you can access keyboard settings).

Toggles between 123/SYM mode and ABC mode.

Modifying your LG keyboard characteristics

Tap the Home Button > touch and hold the Recent Apps Button > Settings > Language & input > LG Keyboard > Keyboard height and layout.

The QWERTY layout setting allows you to select the default buttons on



either side of the Space button.

The Keyboard height setting allows you to change the size ratio



between the keyboard (including the size of its buttons) and the screen.

Typing tips

Enter other characters

Enter one capital letter

Enter all capital letters

Highlight text

Cut or copy selected text

Paste cut or copied text

Delete a character

Accessing the Clip Tray and keyboard settings

Path input text entry

The Basics

Tap the Numbers/Symbols button its keyboard. Tap the Arrow buttons left side of the keyboard to view additional symbols. From the Numbers/Symbols keyboard, you can also tap the Graphics button graphics into your text. To enter foreign characters, touch and hold the associated button to display a pop-up of character choices (e.g., the “a” button also includes an accent mark “á”), drag your ﬁnger to the character you want, then lift your ﬁnger.

Tap the Shift button letter. The button changes to

Double-tap the Shift button The button changes to lowercase.

Double-tap a word to highlight it. To highlight a range of text, double-tap a word, then drag the blue highlight markers to highlight the text you want.

Highlight the desired text, then tap Select all, Cut or Copy in the action box that appears.

to capitalize the next

. Tap again to revert to

Tap the location where you want to paste the text, then tap the marker action box that appears.

Tap the Delete button

. Tap Paste in the

Touch and hold the Voice input button drag your ﬁnger to the Clip Tray icon Settings icon

Swipe your ﬁnger through all of the letters of the word you want to automatically enter it (instead of tapping each letter separately).

NOTE Enable the Path input setting to use this feature.

(in the pop-up that appears).

to display

on the

to enter

to set caps lock.

, then

or the

The Basics

Text input settings

To change your text input settings and see the dictionary of terms you’ve used, tap the Home Button

> Settings > Language & input. From this menu you can change the language for your phone's software, set your keyboard input (including setting multiple languages and how it reacts), set Google voice settings, set your voice search and text-to-speech output preferences, as well as set the pointer reaction time and set the primary mouse button. See the Settings section for more information about the keyboard settings.

> touch and hold the Recent Apps Button

Languages

You can set only one default language for your phone, but you can set multiple languages used for the on-screen keyboard.

To change the default language

Tap the Home Button



Settings > Language & input > Language > tap the language you want.

To add additional languages for your keyboard

Tap the Home Button



Settings > Language & input > LG Keyboard > Input language and keyboard layout, then checkmark the languages you want the keyboard

to be able to use.

> touch and hold the Recent Apps Button >

The Basics

Capturing a Screenshot

Press and hold the Volume Down Key and the Power/Lock Key at the same time for 2 seconds to capture a screenshot of the current screen.

To view the captured image, tap the Home Button

Gallery

> the Screenshots album.

Using Capture+ to capture a screenshot

On the screen you want to capture, drag the Status Bar downward and tap the Capture+ icon tap the Options icon want it saved.

(in the Quick settings bar). To save the screenshot,

, tap Done, then select the location where you

Screen pin

The Screen pin feature allows you to set just a single app that can be used until you deactivate the feature. This is helpful when allowing kids to use your device.

Screen pin set up

1. Set a secure unlock sequence (Knock Code, pattern, PIN, or password)

in the Lock screen settings.

2. Enable the Screen pin switch and the Pin with screen lock setting in

the Security menu.

3. Open the app you want used exclusively.

To activate the Screen pin feature

1. Tap the Recent Apps Button and swipe upward on the open apps

list. The Screen pin icon is displayed on your most recent app.

NOTE If the app you want to pin is not at the front of the open apps list, tap it to bring it to the

front, then repeat step 1.

2. Tap the Screen pin icon on the app, then tap YES.

To deactivate the Screen pin feature

1. Touch and hold the Back Button and Recent Apps Button at the

same time.

> the Apps icon >

The Basics

2. Enter your unlock sequence.

Phone’s Status Icons

The Status Bar appears at the top of every screen. It displays icons indicating that you’ve received notiﬁcations (on the left) and icons indicating the phone’s status (on the right), along with the current time.

Notiﬁcation Icons Status Icons

The following icons may appear in the Status Bar.

Call icons

In call Missed call

Speakerphone is on Microphone is muted

Video call

Sound icons

Interruptions - Priority only Vibrate mode

Silent mode Music is playing

Music is paused

Network icons

3G connected 3G in use

4G LTE connected 4G LTE in use

Wi-Fi connected Signal strength

No signal Roaming

Network Extender No SIM card

Unknown SIM card Airplane mode is activated

GPS is on App update is available

App update successful Downloading

Uploading Download successful

Emergency Alert

Connectivity icons

Syncing Problem with sign-in or sync

Mobile Hotspot is on USB connected

USB debugging mode USB tethering

Bluetooth device connected Bluetooth is on

Bluetooth headset full battery

Headset is connected

Internal storage is full

Bluetooth headset low battery

Headset with microphone is connected

Email and Messaging icons

New email New Gmail message

New message New Verizon message

New voice mail Email not sent

Message not sent

Calendar and Alarm icons

Alarm is set Upcoming event

The Basics

Battery icons

Full battery Charging battery

Low battery Empty battery

Not Charging

The Basics

Other icons

More notiﬁcations available Screenshot saved

Keyboard

Managing Notifications

Notiﬁcation icons report the arrival of new messages, calendar events, alarms, as well as ongoing events, such as when you’re on a call. When you receive a notiﬁcation, the notiﬁcation icon will be displayed in the Status Bar. You can open the Notiﬁcations panel to view a list of all of your recent notiﬁcations. Depending on your settings, you may hear a notiﬁcation sound and/or the phone may vibrate.

To open the Notifications panel

Touch and drag the Status Bar to the bottom of the screen.

The Notiﬁcations panel displays a list of your current notiﬁcations, organized into ongoing and event-based notiﬁcations. The Quick settings bar (at the top of the panel) allows you to quickly and easily change commonly used settings.

NOTE You can also access the complete Settings menu from this panel by tapping the Settings

icon

Settings Icon

Quick Settings Bar

Flick right or left to scroll through the list and tap an icon to change its setting.

Tap a notiﬁcation to open it.

Home Screen Notiﬁcations Panel

Clear Button

Tap here to clear your list of event-based notiﬁcations.

The Basics

To respond to a notification

1. Open the Notiﬁcations panel. Your current notiﬁcations are listed in the

panel, each with a brief description.

2. Tap a notiﬁcation to view it.

The Notiﬁcations panel will close and the app that corresponds to your

selection will open. For example, new voice mail notiﬁcations dial your voice mail box and Gmail notiﬁcations open the Gmail app so you can read your new messages.

Quick settings on the Notifications panel

The top of the Notiﬁcations panel includes a Quick settings bar. The icons in this bar provide a quick, convenient way to change settings without accessing any apps. If you set more than ﬁve icons on the bar, swipe left and right to scroll through the list.

Customizing the Quick settings bar icons

You can set the order of the icons displayed in the Quick settings bar as well as which icons are displayed.

1. Open the Notiﬁcations panel, then tap the Edit icon

settings bar).

 Drag one of the icon handles

the Quick settings bar.

 Checkmark each of the items you want to appear in the Quick

settings bar.

2. Tap the Back Button

to return to the Notiﬁcations panel.

to move its icon to another position in

(in the Quick

The Basics

Searching Your Phone and the Web

You can search for information on your phone and on the web using the Google app. Some apps, such as Gmail, Contacts, and Chrome, have the ability to search for contents within those speciﬁc apps. You can conduct the search by typing in the search terms or saying what you’re looking for. As you enter text, the search app can provide suggestions so you don’t necessarily have to type out your full request.

Phone and Web search using text entry

1. Tap the Google Search widget on the Home screen.

Google Now opens automatically and you can use the on-screen

keyboard to search or tap the Microphone icon looking for.

Voice Search Tap here to search by voice.

Search Box Tap here to type your search request.

Google Now App Tap here to open the Google Now App.

to say what you're

The Basics

2. Enter the text you’re searching for in the search box.

As you type, search results from your phone, previous search terms, and web search suggestions appear. Tap an item to activate that search result.

3. Tap one of the search results or tap the Search button on the

on-screen keyboard to search for the text you entered in the search box.

TIP The top of the search results screen includes a search category bar. You can scroll

horizontally through them, then tap one to display your results using only that category.

Google Search menu

From the Google app, tap the Menu icon to access Reminders, Customize, Settings, Send feedback, and Help.

Search preference settings

You can use your search preference settings to conﬁgure some aspects of web search and what phone features you want to include in your searches. To access these settings:

1. From the Google app, tap the Menu icon

2. Select Accounts & privacy, Search language, Voice, Phone search,

Now cards, or About then adjust the settings as necessary.

> Settings.

The Basics

Setting Your Lock Screen

There are several Lock screen types allowing you to lock your phone so that only you can unlock it to make calls, access your data, buy apps, and otherwise prevent unauthorized use.

Setting a Screen Lock for the First Time

1. Tap the Home Button > touch and hold the Recent Apps Button >

Lock screen settings.

2. Tap Select screen lock.

3. Tap Swipe, Knock Code, Pattern, PIN, or Password.

Swipe: A swipe motion in any direction on the screen will unlock the

screen. This is the default Lock screen that simply guards against unintentional actions.

Knock Code: Unlocks the screen using a tapping a sequence on the

screen's 2x2 grid. (When the screen is in timeout, your phone will recognize your correct pattern anywhere you tap it on the dark screen.) The ﬁrst time you set a Knock Code, you'll see a tutorial with instructions on how to create it. Tap a sequence on the 2x2 grid (from 3 to 8 taps), then tap DONE. Tap your sequence again and tap CONFIRM.

NOTE You're prompted to create a backup PIN as a safety measure in case you forget your

Knock Code unlock sequence.

Pattern: Unlocks the screen using a pattern you draw with your ﬁnger.

The ﬁrst time you set an unlock pattern, you'll see a tutorial with instructions on how to create it. Read the tutorial, then tap NEXT. Draw your pattern (connect at least 4 dots) and tap NEXT. Then redraw your pattern and tap CONFIRM.

PIN: Unlocks the screen with a number sequence. Enter a PIN (at least 4

digits) and tap NEXT. Re-enter your PIN and tap OK (or Done) to conﬁrm it.

Password: Unlocks the screen with an alphanumeric sequence. Enter a

password (at least 4 characters) and tap NEXT. Re-enter your password and tap OK (or Done) to conﬁrm it.

The Basics

From then on, any time you want to unlock the screen, you'll need to

perform the unlock action you set (swipe, Knock Code, pattern, PIN, or password) to gain access to it.

Changing Your Screen Lock

1. Tap the Home Button > touch and hold the Recent Apps Button >

Lock screen settings.

2. Tap Select screen lock.

3. Conﬁrm your unlock information (if necessary).

4. Tap the desired screen lock option.

5. You’re prompted to enter your screen unlock sequence (and backup PIN,

if necessary).

NOTES s If you've set up a Microsoft Exchange account, you might only be able to use a

s After 5 unsuccessful attempts to unlock your phone, you're prompted to enter a

s You have 10 opportunities to enter your unlock sequence. After 10 unsuccessful

password.

text phrase to conﬁrm that you're trying to unlock your phone.

attempts, your phone will automatically perform a factory data reset and all of your personal ﬁles will be erased. You'll be warned after the 9th unsuccessful attempt.

s If you've set a Knock Code, after 6 unsuccessful attempts, you're prompted to enter

your backup PIN to unlock your phone.

Security lock timer

If a security lock is enabled, you can set the delay time after the screen darkens due to inactivity before the screen automatically locks and requires you to enter your unlock sequence.

1. Tap the Home Button

Lock screen settings.

2. Tap Security lock timer, then tap the setting you want to use.

> touch and hold the Recent Apps Button >

The Basics

Power button instantly locks

If a security lock is enabled, checkmark the Power button instantly locks checkbox to override the Security lock timer setting and lock the screen as soon as you press the Power/Lock Key

1. Tap the Home Button

Lock screen settings.

2. Checkmark the Power button instantly locks checkbox.

> touch and hold the Recent Apps Button >

The Lock screen wallpaper

You can set the Lock screen wallpaper separately from your Home screen wallpaper.

1. Tap the Home Button

Lock screen settings.

2. Tap Wallpaper.

 Tap Wallpaper gallery to select one of the available wallpaper images.

 Tap Gallery to select an image from your Gallery.

> touch and hold the Recent Apps Button >

Smart Lock

If you set a secure unlock sequence, you can set up Smart Lock settings so you don't have to hassle with continually unlocking your phone when it's in a trusted situation. It allows your phone to recognize things like its proximity to your home, your Bluetooth system, your smartwatch, etc. You can set trusted devices, trusted places, trusted faces, trusted voice, and/or on-body detection.

Other Lock screen settings

You may see additional lock screen settings that depend on the type of unlock sequence you set. They include Screen swipe effect, Shortcuts,

Contact info for lost phone, Hidden pattern, Make pattern visible, Hidden PIN, Randomize PIN entry, and Hidden password.

The Basics

Lock screen notifications

After you set (or subsequently change) a secure unlock sequence, a screen is displayed for you to set the notiﬁcations that will be displayed on your Lock screen.

Connecting to Networks and Devices

Wi-Fi

With Wi-Fi, you can use high-speed Internet access within the coverage of the wireless access point (AP). Enjoy wireless Internet using Wi-Fi, without extra data charges.

Connecting to Wi-Fi networks

To use Wi-Fi on your phone you need to access a wireless access point or ‘hotspot’. Some access points are open and you can simply connect to them. Others are hidden or use security features. You must conﬁgure your phone to be able to connect to them. Turn off Wi-Fi when you’re not using it to extend the life of your battery.

Turning Wi-Fi on and connecting to a Wi-Fi network

1. Tap the Home Button > the Apps icon > Settings > Wi-Fi.

2. Tap the Wi-Fi switch

Wi-Fi networks.

3. Tap SEARCH to see a list of active and in-range Wi-Fi networks.

 Secured networks are indicated by a lock icon.

4. Tap a network to connect to it.

 If the network is secured, you're prompted to enter a password or

other credentials. (Ask your network administrator for details.)

The Status Bar displays icons that indicate your Wi-Fi status.

Wi-Fi Options menu

From the Wi-Fi settings screen, tap the Options icon to access Add Wi-Fi, Saved Wi-Fi, Advanced Wi-Fi, and Help.

to turn Wi-Fi on and start scanning for available

Wi-Fi context menu

Touch and hold a Wi-Fi network to open its context menu to connect to it, delete it, or modify it.

Connecting to Networks and Devices

Wi-Fi Direct

Wi-Fi Direct provides a direct connection between Wi-Fi enabled devices without requiring an access point.

Turning on Wi-Fi Direct

1. Tap the Home Button > the Apps icon > Settings > Wi-Fi.

2. Tap the Options icon

NOTE When in this menu, your device is visible to other visible Wi-Fi Direct devices nearby.

> Advanced Wi-Fi > Wi-Fi Direct.

Bluetooth

Your phone can use Bluetooth to send data, but it doesn’t use a Bluetooth menu as on most other mobile phones. Sharing data between Bluetooth devices is a simple matter of running a corresponding application, then pairing with the device you want right from the app (if necessary).

NOTES ţLG is not responsible for the loss, interception, or misuse of data sent or received via

    ţAlways ensure that you share and receive data with devices that are trusted and

    ţSome devices, especially those that are not tested or approved by Bluetooth SIG, may

Turning on Bluetooth and pairing your phone with a Bluetooth device

You must pair your device with a Bluetooth device before you connect to it.

1. Tap the Home Button

2. Tap the Bluetooth switch

3. Tap the device you want to pair with from the list.

Once pairing is successful, your device will connect to the device.

the Bluetooth wireless feature.

properly secured. If there are obstacles between the devices, the operating distance may be reduced.

be incompatible with your device.

> the Apps icon > Settings > Bluetooth.

to turn Bluetooth on, then tap SEARCH to

view the devices within your phone's range.

Connecting to Networks and Devices

Send data using the Bluetooth wireless feature

1. Open the item you want to send, then tap the Sharing icon .

Touch and hold the item you want to send, then select Share.

Open the item you want to send, then tap the Options icon

2. Tap Bluetooth to share via Bluetooth.

NOTE The method for selecting an option may vary by data type.

3. Search for and pair with a Bluetooth-enabled device.

Receive data using the Bluetooth wireless feature

1. Tap the Home Button > the Apps icon > Settings > Bluetooth.

2. Tap the Bluetooth switch

3. Tap ACCEPT when you receive a data request.

to turn Bluetooth on.

PC Connections with a USB Cable

You can connect your phone to your PC to charge it and transfer items to the PC from the phone (and vice versa).

Transferring music, photos, and videos using the Media device (MTP) mode

1. Connect your phone to a PC using the USB cable (power cord) included

with your phone.

2. You can now view the mass storage content on your PC and transfer

ﬁles.

> Share.

Connecting to Networks and Devices

Synchronize with Windows Media Player

Ensure that Windows Media Player is installed on your PC.

1. Use the USB cable to connect the phone to a PC on which Windows

Media Player has been installed.

2. Open the Settings menu on your phone, then tap Storage > the

Options icon

3. When connected, a pop-up window will appear on the PC. Select the

Windows Media Player option to synchronize music ﬁles.

4. Edit or enter your device’s name in the pop-up window (if necessary).

5. Select and drag music ﬁles to the sync list.

6. Start synchronization.

The following requirements must be satisﬁed to synchronize with



Windows Media Player.

Windows Media Player version Windows Media Player 10 or higher

> USB PC connection > Media sync (MTP).

Item Requirements

OS Microsoft Windows XP SP2, Vista or higher

PC Connections with a USB Cable for Mac OS X Users

You can transfer media contents to your Mac OS X PC from the phone and vice versa by setting up the Android File Transfer program.

1. Download and install the Android File Transfer program from the

android.com website for Mac Users (http://www.android.com/ﬁletransfer/).

2. Connect your phone to your computer and double click the AFT (Android

File Transfer program) application to start it up.

3. You can view the media contents, then drag and drop the media ﬁles(s)

to and from the phone (or PC).

Calls

Placing and Ending Calls

The Phone app allows you to dial phone numbers manually or make calls from your phone’s memory. Manually dial calls using the Dial tab. Dial from your phone’s memory using the Recent tab, the Contacts tab, the Favorites tab, or the Groups tab.

To open the Phone app

Tap the Home Button



Moving between the Phone app tabs

Tap any of the Phone app tabs (Dial, Recent, Contacts, Favorites, and Groups) to view that tab. You can also swipe the screen horizontally to scroll to the other tabs. The current tab is displayed in white.

Modifying the Phone app tabs

You can rearrange the order of the Phone app tabs and/or delete the Favorites and Groups tabs.

1. Tap the Home Button

2. Tap the Options icon

 Drag a tab handle

the list.

 Tap the Favorites or Groups checkbox (checkmark displays the tab,

no checkmark deletes it from the Phone app tabs bar).

3. When you're ﬁnished making changes, tap the Back Button

> the Phone icon .

, then tap Edit tabs.

to move it to the position where you want it in

To place a call by dialing

1. Tap the Home Button > the Phone icon > Dial tab.

Calls

Dial Tab

Displays the dialpad.

Call Button

Tap here to dial the number that you entered manually.

Voice Dialer Button

Tap here to dial by saying the number.

Delete Button

Tap here to delete incorrect number(s).

Touch and hold to enter the plus ( + ) symbol to dial an international number.

Message Button

Tap here to send a message instead.

Voice Mail Button

Tap here to call your voice mail.

2. Use the dialpad to enter the number you want to call.

 Tap the Delete button

to erase digits one by one.

 To erase the entire number, touch and hold the Delete button

To dial an international number, touch and hold the 0 button to enter



the plus ( + ) symbol. Then enter the international preﬁx for the country, followed by the full phone number.

3. Tap the Call button to dial the number that you entered.

 Press the Volume Keys to adjust the call volume.

 Use the on-screen buttons to enter additional numbers, place the call

on hold to take another incoming call, add another call, use the speakerphone, end the call, and other options.

 You can use other phone features while the call is underway. If you

open another app, the Ongoing call icon appears on the screen for the duration of the call. You can move the icon on the screen, if necessary.

NOTE If you opened other apps while on a call, you'll need to return to the Call screen to end

the call. To return to the Call screen, simply tap the Ongoing call icon. You can also tap the Home Button the Current call notiﬁcation on the Notiﬁcations panel.

TIP If necessary, you can drag the Ongoing call icon to move it somewhere else on the

screen while using other device functions.

, then tap the Phone icon or drag the Status Bar down and tap

Calls

To end a call

Simply tap the End button



If you accessed other device functions while the call was in progress, there are several ways to return to the Call screen to end the call.

Tap the Ongoing call icon.



Tap the Home Button



Drag the Status Bar down, then tap the Current call notiﬁcation on the



Notiﬁcations panel.

NOTE You can also press the Power/Lock Key to end the call, if you activated this feature in

the Call settings (tap the Options icon

on the Call screen to end the call.

, then tap the Phone icon .

in the Phone app).

Calling numbers in your phone’s memory

You can place calls using information stored in your phone. Anywhere you see a Dial icon

next to a number, tap it to automatically dial it.

Speed dialing

If you set up Speed dials in the Contacts app, you can dial a number by simply touching and holding the Speed dial number on the dialpad.

Tap the Home Button



hold the Speed dial number.

> the Phone icon > Dial tab, then touch and

Direct dialing

A Direct dial widget is like a speed dial button on your Home screen. Tap it to automatically call the number you set (for example, your home phone number).

Calls

To place a Direct dial widget on your Home screen

1. Touch and hold an empty area on your Home screen.

2. Tap the Widgets tab > Direct dial.

3. Tap the contact in your Contacts list.

TIP You can change the look of each Direct dial widget for easy identiﬁcation. Touch, hold,

and release the Direct Dial widget, then tap it. Select a theme icon or a photo icon, then tap OK.

Answering or Rejecting Calls

When you receive a phone call, the Incoming call screen opens with the caller ID and any additional information about the caller that you’ve saved in the Contacts list. All incoming calls are recorded in the Recent tab.

To answer a call

If the screen is unlocked, simply tap the Answer icon



If the screen is locked, swipe the Answer icon



answer the call.

If you were already on a call, tap the Answer icon



ﬁrst call on hold and connects the new call.

NOTE To silence the incoming call ringer, press either of the Volume Keys.

in any direction to

which places the

Tap the Answer icon to answer the call.

Swipe the Answer icon in any direction to answer the call.

Unlocked Screen Locked Screen

Calls

To ignore a call and divert it to voice mail

If the screen is unlocked, simply tap the Ignore icon



If the screen is locked, swipe the Ignore icon



ignore the call.

The caller is sent directly to your voice mail box to leave a message.



Tap the Ignore icon to ignore the call and send the caller directly to your voice mail box to leave a message.

Tap the Ignore with message icon to send a quick message to the caller and forward them to your voice mail.

NOTE To silence the incoming call ringer, press either of the Volume Keys.

Unlocked Screen Locked Screen

in any direction to

Swipe the Ignore with message icon in any direction to send a quick message to the caller and forward them to your voice mail.

Swipe the Ignore icon in any direction to ignore the call.

To ignore a call and send a text message

To display the Ignore with message option on the Incoming call screen, enable it in the Settings menu.

1. Tap the Home Button

Call settings.

2. Tap the Allow ignore with message switch to toggle it On (blue).

TIP Tap Allow ignore with message to manage your text message choices.

To use the Ignore with message option, select it (tap or swipe its icon) on the Incoming call screen, then tap the Send icon message you want to send in place of answering the call.

TIP If you tap one of the text messages instead, the Messaging app opens so you can

modify the text before sending it to the caller.

NOTE This feature can only be used to send a message to another mobile phone. It's not

applicable to incoming landline calls.

> the Phone icon > the Options icon >

next to the text

Calls

Working with the Recent Tab

The Recent tab records all of the calls you’ve dialed, received, or missed. It offers a convenient way to redial a number, return a call, or add a number to your Contacts.

To open the Recent tab

Tap the Home Button



The Recent tab lists your calls chronologically by phone number. The

number in parenthesis indicates the number of sequential calls recorded for that phone number and call type.

Recent Tab

Tap here to display the history of all of your calls.

Viewing call entry details

Open the Recent tab, then tap an entry to view its details. Calls are listed chronologically and each one includes the call type (received missed dialed calls will also display the duration of each call.

, and ignored ), the date, and the time of the call. Received and

> the Phone icon > the Recent tab.

Dial Icon

Tap here to call this phone number.

, dialed ,

Filtering your list of calls

To view a speciﬁc call list, from the Recent tab, tap the Options icon , then tap Filter. Tap the call type you want to view.

Tap the Back Button

to return to the Recent tab screen.

Calls

To dial a number in the Recent tab

From the Recent tab, tap the Dial icon



From the Recent tab, tap the image to the left of the call entry to view all



of the contact's numbers saved in your phone’s memory. Tap a phone number to dial it.

TIP To insert an area code when you're traveling, touch and hold the entry, then tap Copy call

number in the context menu. Change to the Dial tab, touch and hold the phone number

ﬁeld, tap Paste, then edit the number as necessary before tapping the Call button the keypad.

at the right of the call entry.

To add a number from the Recent tab to your Contacts

1. Open the Recent tab, then touch and hold the call entry.

2. Tap Add to Contacts in the context menu.

3. Tap New contact or Update contact and save it as necessary.

Clearing your Recent calls

You can delete the entire list of Recent calls at once or selectively delete entries.

1. Open the Recent tab.

2. Tap the Options icon

 Tap Clear to select entries to remove from the list. Checkmark the

entries to delete, tap CLEAR, then YES.

 Tap Clear all to remove all of the entries from the list. Tap YES to

conﬁrm you want to delete the entire list.

NOTE You can also select a speciﬁc number to be deleted. Touch and hold an entry in the

Recent tab. Tap Clear all logs of this number, then tap YES to conﬁrm.

Calls

Calling Your Contacts

Instead of manually dialing phone numbers using the dialpad, you can use your Contacts list to dial quickly and easily. You can also quickly call a contact using Quick Contact or Direct dial icons that you placed on your Home screen.

If you have contacts on the web, they’re synchronized with your phone when you ﬁrst synchronize with your Google™ Account.

To call a contact

1. Tap the Home Button > the Contacts icon .

2. Tap the contact you want to call, then tap the contact's phone number

you want to call.

TIP If the entry only has one phone number saved, simply tap the Dial icon next to the

entry to dial it.

To call a favorite contact

1. Tap the Home Button > the Contacts icon , then tap the Favorites

tab.

2. Tap the contact you want to call.

3. Tap the contact’s phone number you want to call.

Instant list

Instant list is displayed on the Dial tab to help you use the information stored in your phone without needing to search for it ﬁrst. Once you begin entering numbers, Instant list displays entries from your Contacts list or Recent calls that match the sequence you entered.

Sequence matches

Your phone searches for the entered sequence anywhere within the phone number. The matching number sequence is displayed within the number in blue text. The name and type of number (i.e., Mobile, Work, etc.) associated with the number you entered is displayed above the dialpad. When there are multiple matches, the Instant list displays the number of

Calls

matches in your phone's memory. Tap the Instant list icon on the right side of the screen to view the entire list of matching entries.

Selecting an Instant list entry

Tap an entry in the Instant list to insert it on the dialpad and tap the Call button

to dial it.

Options During a Call

Bluetooth Button

Tap here to switch between a Bluetooth device and the phone.

Speaker Button

Tap here to turn the speakerphone on or off.

Mute Button

Tap here to mute (and unmute) the microphone during a call.

Managing Multiple Calls

Contact your wireless service provider to ﬁnd out which call services are supported.

To set up a conference call

Contact your wireless service provider to ﬁnd out whether they support conference calls and how many participants you can include.

1. Place a call to the ﬁrst participant.

2. When you’re connected, tap the Add call button

3. Enter a phone number.

 Use the Phone app tabs to select a saved number, then tap the Dial

icon

on the Call screen.

Calls

 Use the buttons on the dialpad to manually enter a number, then tap

the Call button

4. After you are connected, tap the Merge calls button

screen). The participant is added to the conference call.

(on the Call

Merge Calls Button

Tap here to merge the separate calls into a conference call.

Bluetooth Button

Tap here to switch between a Bluetooth device and the phone.

Speaker Button

Tap here to turn the speakerphone on (or off).

Dialpad Button

Tap here to dial another number to participate in the conference call.

Mute Button

Tap here to mute (and unmute) the microphone during a call.

Web

Chrome

The Chrome app allows you to access the Internet from your phone. Access and selections within this feature are dependent upon your service provider. For speciﬁc information on Internet access through your phone, contact your service provider.

NOTES s You may incur additional charges for accessing the web and downloading media. For

Viewing web pages

1. Tap the Home Button > the Chrome icon directly on the Quick

2. Tap the URL input ﬁeld to access a web page. Enter the web address



NOTE You can change the search engine for your searches. From the Chrome app, tap the

details, contact your service provider.

s Chrome may differ from this user guide due to updates via Play Store.

Access Bar.

Tap the Home Button

> the Apps icon > the Google folder >

Chrome .

(URL) of the web page, then tap the Go button

on the on-screen

keyboard.

When you begin entering text in the URL input ﬁeld, suggestions appear

below the address bar.

Options icon

URL Input Field (address bar)

Tap here to enter a web address for the web page you want to access.

> Settings > Search engine. Tap the search engine you want to use.

Options Icon Tap here to access various options for Chrome.

Web

Search within a web page

1. While viewing the page, tap the Options icon > Find in page.

2. Type the text you’re looking for in the ﬁnd bar at the top of the screen.

Matches are highlighted on the page (current match in orange and other

found matches in yellow).

The ﬁnd bar displays the total number of matches. Tap the up



down

arrows in the ﬁnd bar to go to each match.

Found matches are also indicated in the scroll column along the right



side of the screen. Tap any of the highlights to jump directly to that match.

and

Searching the web by voice

Tap the address bar, tap the Close icon in the bar, tap the Microphone icon

, say a keyword, then tap one of the search results that appear.

Adding and viewing bookmarks

To add bookmarks, while viewing the page you want to bookmark, tap the Options icon

To open a bookmarked web page, tap the Options icon and select the desired page.

, then tap the Bookmark icon .

> Bookmarks

Browse with tabs

You can easily browse several web pages simultaneously. Create multiple tabs for the sites you want, then tap the Recent Apps Button the tab you want to access to switch between them.

and tap

Create a new tab

From the Chrome app, tap the Options icon then tap New tab (or New incognito tab).

The New Tab page

Tap an icon at the bottom of the new tab screen to help you open the page that you want quickly.

Web

Bookmarks The sites that you’ve bookmarked are listed here. Tap



one to visit the site using the new tab you created. Tap the Options icon

next to a bookmark to access Select, Edit, Move, or Delete.

TIP To select multiple bookmarks to move or delete them as a group, touch and hold each

bookmark you want, then tap the Move icon or the Delete icon in the Bookmark banner.

Recent tabs Your recent websites are listed here including the ones



on this device, recently closed, and on your other devices.

Download files

1. Touch and hold a download link.

2. In the context menu that appears, tap Save link.

To view downloaded files:

Tap the Home Button > the Apps icon > the Tools folder > Downloads

To open a downloaded ﬁle, tap it.



To view earlier downloads, tap the heading date you want to view.



To share downloads, tap the Share icon



share, then tap SHARE and choose a sharing method from the list.

To clear ﬁles from your download history, tap the List icon



checkmark the entries to clear, tap CLEAR, then YES to conﬁrm.

Tap the Menu icon



, checkmark the ones to

to switch the download ﬁle sort criteria.

Chrome Settings

To access the settings speciﬁc to the Chrome app:

1. From the Chrome app, tap the Options icon

2. Tap Settings.

Communication

Contacts

The Contacts app allows you to store names, phone numbers, and other information in your phone’s memory. Entries are listed alphabetically. You can scroll through the list, or select the Favorites tab or Groups tab.

Use the Contacts app to add, view, and communicate with your friends, acquaintances, and associates.

To open your Contacts app

Tap the



NOTE You can also tap the Contacts tab from the Phone app.

If you have a new phone and haven’t added any contacts yet, hints will be displayed to help you start adding contacts to your phone.

Home Button > the Contacts icon

Contacts list

When you open the Contacts app, your Contacts list is displayed. You can drag along the vertical alphabet on the right side of the screen to quickly scroll to the letter section you want (a blue letter displays your location as you scroll).

In case of Emergency contacts is displayed above your list of contacts. Add up to 5 emergency entries from your Contacts list. These are entries that someone can contact on your behalf in the event of an emergency, whether or not the phone is locked.

To add ICE entries

1. Tap the Home Button > the Contacts icon .

2. Tap In Case of Emergency contacts (at the top of the list).

3. Tap the Add entry icon

4. Checkmark the entry (or entries) to add to your ICE list, then tap DONE.

ICE Information

In addition to your emergency contacts, you can enter personal information about you (such as medical record number, allergies, medications, special

Communication

instructions, etc.) that can be accessed in case of an emergency. To add your personal information:

1. From the emergency contacts screen, tap the Information icon

2. Tap the Add icon

, enter your information, then tap SAVE.

To search for a contact

1. Tap the Home Button > the Contacts icon .

2. Tap the Search contacts box and enter the contact name. Matches are

displayed as you begin to type.

Searching your online contacts simultaneously

You can search for your contacts simultaneously from all of your online accounts.

To set your phone to allow you to search simultaneously, open the Contacts app, tap the Options icon the Online search checkbox.

> Contacts settings > checkmark

To open a list of your favorite contacts

Open the Contacts app and tap the Favorites tab.



Favorites lists the contacts you’ve designated as your favorites (at the

top of the screen) and entries you’ve contacted frequently (at the bottom of the screen). While viewing the Favorites tab, tap the Options icon then tap Grid view (or List view) to change how your favorites are displayed.

To open your groups list

Open the Contacts app and tap the Groups tab.



Groups displays your contacts by category (at the top of the screen) and

your accounts (at the bottom of the screen). While viewing the Groups tab, tap the Options icon delete, share, edit tabs, or access contacts settings).

to change the order of your groups (or

Communication

To view details about a contact

1. Open the Contacts app.

2. Tap the contact whose details you want to view.

3. The information you entered for the contact is displayed. The following

options are available (depending on the types of information saved).

 The Call icon

 The Message icon

 The Email icon

 The Options icon

Delete, Share, Forward, Merge, Separate, Set as default, Add to default group, Export, Add to Home screen, and All calls to voice mail.

places a call to the number.

starts a message.

starts an email.

accesses the following menu options: Refresh,

Adding Contacts

You can add contacts on your phone and synchronize them with the contacts in your Google™ Account, Microsoft Exchange account, or other accounts that support syncing contacts.

Since your contacts can come from a variety of sources, the Contacts app attempts to join new information with existing similar contact entries to create a single entry. You can also manage that process manually by joining or splitting entries (see page 65).

Communication

To add a new contact

1. Open the Contacts app.

2. Tap the New contact icon

3. If you have more than one account with contacts, select the account

where you want to save the contact by tapping the Accounts ﬁeld (at the top of the screen).

NOTE To change the account later, edit the entry, tap the account, tap the account you want it

assigned to, then tap YES.

4. Enter the contact’s name.

5. Tap a category of contact information, such as phone number or email

address, to enter that kind of information about your contact.

 Tap a category’s Add new icon

category. For example, in the phone number category, enter a work number and add a home number. Tap the label ﬁeld to the right of the entered information to select a label.

 Tap Add another ﬁeld

name, Organization, IM, Notes, Nickname, Website, and Events.

6. Personalize the contact entry.

 Set a ringtone to identify calls from this contact.

 Set the sound played to identify notiﬁcations from this contact.

 Tap the Image icon

Contacts list and in other apps.

7. When you’re ﬁnished, tap SAVE.

to add more than one entry for that

to add additional ﬁelds including Phonetic

to select a picture that will display in your

Editing a Contacts entry

1. Open the Contacts app, then tap the contact entry you want to edit.

2. Tap the Edit icon

3. Edit the entry as needed, then tap SAVE.

Communication

Favorites Contacts

The Favorites tab contains the contacts you communicate with most often to help streamline your communication.

Adding or removing contacts in your Favorites list

1. Open the Contacts app, then tap a contact to view its details.

2. Tap the star at the top right of the screen.

 A gold-colored star indicates a Favorite.

 A gray-colored star indicates a normal contact.

Merging and separating contacts

When you have two or more entries for the same contact, you can merge them into a single entry. You can also separate contacts that were merged.

1. Open the Contacts app, then tap the contact entry you want to join with

another entry.

2. Tap the Options icon

3. Tap Merge.

4. Tap a suggested entry or tap Show all contacts to select another entry.

NOTE Your entire Contacts list will be displayed if the phone does not detect any suggested

entries.

Separate is included in the Options menu of contact entries that have been merged to allow you to separate the joined entries.

1. Open the Contacts app, then tap the contact entry you want to separate.

2. Tap the Options icon

3. Tap Separate.

4. Tap YES.

Communication

Setting Speed Dials

Designating multiple speed dials

1. Open the Contacts app, then tap the Options icon .

2. Tap Speed dial.

3. Tap the speed dial number to assign, then tap the Contact entry for it.

4. Repeat selecting a speed dial number and the desired Contact entry as

necessary.

NOTE You can use the Speed dial icon in the contact's entry to set Speed dials

individually.

Transfer type

When you want to send your contacts entries, you can combine them all into one ﬁle or you can send separate vCard ﬁles.

To set the transfer type, from the Contacts app, tap the Options icon Contacts settings > Transfer type.

Send as one ﬁle: This setting combines all of your contacts into one ﬁle.



It allows a faster transfer, but some devices can't receive contact information sent using this option.

Send separately: This setting sends each contact as a separate vCard



ﬁle. It allows all devices to receive your ﬁles.

Contacts settings

To access the Contacts settings open the Contacts app, tap the Options icon

> Contacts settings. These settings allow you to choose how your contacts are displayed and sorted. You can also set sync, search, and transfer options.

Communication

Messaging

Three apps are preloaded on your phone that allow you to send messages. The Messaging app Only one can be set as your default messaging app. Tap the Home Button

> the Apps icon > Settings > More > Default messaging app to

set your choice.

To open the Messaging app

Tap the Home Button



Messaging .

NOTE The Messaging app must be set as the default messaging app in order to use it. If

Messaging is not your default app, a pop-up will appear. Tap YES to set it.

Using the Messaging app

To use the Messaging features, you must set it as the default messaging app.

NOTE You can view your messages in the Messaging app without setting it as your default

app, but you can't create a message.

Tap the New message icon



message.

, the Message+ app , and the Hangouts app .

> the Apps icon

the LG folder

to start a new text or multimedia

Tap here to open the Options menu.

Tap here to create a new message.

Tap an existing message thread to open it.



Tap the Options icon



NOTE Pinch in (or spread apart) on your list of messages to resize it for easier viewing or

navigation.

to access Search, Delete, and Settings.

Communication

To delete a message thread from the Messaging window

1. Touch and hold the message thread.

2. Tap Delete in the context menu that opens.

3. Tap YES to conﬁrm you want to delete the message thread.

To send a text message

1. Open the Messaging app (set it as your default, if necessary), then tap

the New message icon

2. Enter the recipient(s) in the To box.

 Tap the Contacts icon

Contacts list.

 Enter a name (or a partial number), then tap a suggestion displayed

from your Contacts list.

 Enter a number manually for phone numbers not in your Contacts list.

3. Tap the text box, then enter your message.

A character counter will be displayed to let you know how many more

characters you can type and also the number of pages in the message.

To Box

Tap here to enter the recipient(s) manually.

Message Box

Tap here to enter your message.

, then select one or more entries from your

Contacts Icon Tap here to enter the recipient(s) by selecting from entries in your Contacts list.

Attachment Icon

Tap here to add an attachment to your message.

You can tap the Options icon to insert quick message text, a smiley,

and/or a subject.

If you tap the Back Button

while composing a message, it’s

automatically saved as a draft. The Draft icon on the right side of the

Communication

message thread indicates a pending draft message to the recipient. Tap the message to resume composing it.

4. Tap the Send button to send the message.

Your message is displayed and responses appear in the same window, creating a message thread with that contact.

To create and send a multimedia message

1. Open the Messaging app (set it as your default messaging app, if

necessary), then tap the New message icon

2. Enter the recipient(s) in the To box.

 Tap the Contacts icon

Contacts list.

 Enter a name (or a partial number or email address), then tap a

suggestion displayed from your Contacts list.

 Enter a number or email address manually.

3. Tap the text box, then enter your message.

4. Tap the Options icon

The subject text appears above the body text in bold letters.

5. Tap the Attachment icon

the type of media ﬁle to attach to the message.

NOTE To delete an attachment, simply tap the Delete icon on the attached ﬁle.

6. Tap the Options icon to access additional options (e.g., text location,

amount of time each slide will be displayed, message preview, etc.).

7. Tap the Send MMS button to send the message.

, then select one or more entries from your

> Add subject to add a message subject.

to open a dialog box where you can choose

Receiving and viewing messages

If you’re working in a message window, messages that you receive from that contact are displayed. Otherwise, you receive a new message notiﬁcation and a new message icon you tap the new message notiﬁcation, the Message screen opens where you can reply to the message. If the New message pop-up setting is

appears in the Status Bar. When

Communication

enabled, you’ll receive a pop-up notiﬁcation on the current screen which you can use to directly reply.

If the Auto-retrieve setting is not checkmarked, tap Download to view the full message.

If the message contains a media ﬁle, tap the Play button to view, watch, or listen to it. Touch and hold the media ﬁle to open a context menu with additional options.

To respond to messages you receive

While viewing the received message, tap the text box at the bottom of the screen, complete your response as necessary, then tap the Send button.

Changing Messaging Settings

To change the Messaging settings, open the Messaging app (set it as



your default, if necessary), tap the Options icon

The Notiﬁcations settings menu includes the following options:

Notiﬁcations, New message pop-up, Preview, Notiﬁcation sound, Vibrate, and Repeat alert.

The Text messages menu includes the following options: Delivery

reports, Manage SIM card messages, Priority, Read reports, and Allow read reports.

The Multimedia messages menu includes the following options:

Delivery reports, Allow delivery reports, Auto-retrieve, Roaming auto-retrieve, and Priority.

Group Conversation: Allows you to enable/disable group

conversations.

The General settings menu includes the following options: Quick

messages, Send message with Enter key, Signature, Callback number, Delete old messages, Text message limit, Multimedia message limit, and Save to.

> Settings.

Communication

The Email app allows you to read email from services other than Gmail™. The following account types are supported: Microsoft Exchange, Outlook, Yahoo! Mail, AOL Mail, Verizon, and other accounts.

To open the Email app

Tap the Home Button



Tap the Home Button



If you didn't set up your email account(s) when you ﬁrst set up your new phone, the ﬁrst time you open the Email app, a setup wizard opens to help you add an email account. After the initial setup, the Email app displays the contents of your Inbox.

NOTE You can also add your email account(s) using the Accounts menu in the Settings app.

The Accounts list

The Accounts list in the Email Menu displays all of your email accounts.

Open the Email app. Tap the Menu icon email accounts and their folders. You can also swipe horizontally from the left side of the screen to open your Accounts list.

A identifying color is displayed on the left of each account. Tap an



account to toggle between displaying and hiding its folders. The number of unread mail is displayed next to each account's Inbox.

Using the Email app

Tap the Compose icon



Tap the Menu icon



folders.

Tap the Options icon



message(s) you want, then you can tap MARK AS READ/UNREAD or DELETE. You can also tap the Select all icon to select all of your

messages at once, then tap the action to apply to all of them.

> the Apps icon > Email .

> swipe to the left panel > tap Email .

to display a list of all of your

to compose a new message.

to switch between your email accounts and

> Select > tap the checkbox next to the

Communication

Tap the Favorite icon



important or favorite message.

Swipe a message off the screen to the left or right to delete the



message.

Tap the Options icon



Sort by, and Settings.

Drag downward from the top of the Inbox list to refresh the list.



next to an email message to designate it as an

to open the Options menu to access Select,

Message search

Tap the Search icon , enter the text you’re looking for, then tap one of the displayed results.

Reading Your Email

You can read your email from the Inbox or any other folder within each individual account. Tap a message entry to open it.

NOTE If you enable the Auto-rotate screen setting (in the Display menu) and the Split view

setting (in the Email settings), the Email app is displayed in a split-screen format when the phone is held horizontally. Your Inbox is displayed on the left side of the screen. Tap an email to open and display its contents on the right side of the screen.

To read an email

1. Open the Email app, then tap the Menu icon .

2. Tap Inbox under Combined view to display all of your messages from all

of your accounts together or tap Inbox under the account you want to view.

3. Tap a message to open and read it.

NOTE When new email arrives, a notiﬁcation appears in the Status Bar. Drag the Status Bar

downward and tap the email notiﬁcation.

To add an account

From the Email app, tap the Options icon



Then, conﬁgure the new email account settings as necessary.

> Settings > Add account.

Communication

Changing Email Settings

To change the Email settings, open the Email app, tap the Options icon



> Settings.

General settings

The General settings menu includes the following options: Email preview, Conversation view, Split view, Set default account, VIP settings, Save to, Ask before deleting, Auto-advance, and Load images.

Accounts

Tap an account in the list to modify the settings that apply only to that account including Account name, Your name, Signature, Edit signature,

Notiﬁcations, Notiﬁcation sound, Vibrate, Auto-sync email, Sync schedule, Folders to sync (Exchange account only), Email sync period, Message size limit, and Advanced settings.

Communication

Gmail

When you open the Gmail app, the most recent conversations are displayed at the top of your Inbox list. All of your conversations are displayed in your Inbox unless you delete, archive, or ﬁlter them.

To open the Gmail app

Tap the Home Button



Tap the Home Button



Gmail

Your Gmail Inbox

Primary is displayed in the Inbox header. If you have more than one account, you can switch accounts to view the messages in each Inbox. Tap the Menu icon and view all of your account Inboxes at the same time (Primary in the header changes to All inboxes).

Conversations with new messages are displayed with bold subject lines. To read a message in a conversation, tap its subject line text.

The letter icon (or contact photo) next to a Gmail message allows you to select it and choose an action from the icons at the top of the screen.

The Favorite icon a favorite message (select the Starred label to view them).

Gmail Inbox icons

Use the following icons while viewing a Gmail label.

Menu: Tap to change to another account or label, access Gmail



Settings, and view Help & feedback.

Compose: Tap to begin a new Gmail message.



Search: Tap to search within your Gmail messages.



NOTE You can also drag the screen downward from the top of the Gmail message list to

refresh and check for new messages.

> the Google folder > Gmail

> the Apps icon > the Google folder >

to select another account or tap All inboxes to combine

next to a Gmail message allows you to designate it as

Communication

Message search

Tap the Search icon , enter the text you’re looking for, then tap the Search button

on the on-screen keyboard.

Adding another Google Account

From the Gmail app, tap the Menu icon



Google > NEXT. Enter your Google Account information as necessary.

Tap the Home Button



Settings > Accounts > ADD ACCOUNT > Google. Enter your Google

> touch and hold the Recent Apps Button >

Account information, as necessary.

> Settings > Add account >

To switch accounts

If you added more than one Gmail Account on your phone, you can choose to combine all of your Inboxes together. Otherwise, Gmail will only display conversations and messages from one account at a time, but you can easily switch between your different Gmail Accounts.

From your Gmail Inbox, tap the Menu icon



then tap the account that you want to display.

NOTE The number of unread messages is displayed to the right of each account label.

Menu Icon

Tap here to open a list of account choices and account labels.

, tap the current account,

Gmail Inbox

Gmail Menu

(Accounts and Labels)

Communication

Navigating in the Gmail app

While viewing your Inbox:

Swipe the screen up and down to scroll through your list of messages.



Tap the Compose icon



Tap the Search icon



Swipe a Gmail message off the screen to the left or right to quickly and



easily archive the message. Tap UNDO to restore it to your Inbox.

Tap the letter icon (or contact photo) to the left of one or more



messages, then tap the Delete icon

Tap the letter icon (or contact photo) to the left of one or more



messages, then tap the Options icon labels, Add star, Mark important (or Mark not important), Mute, or Report spam.

While viewing a message, swipe the screen left and right to scroll through all of your messages and use the icons in the Gmail header:

Tap the Gmail icon



Tap the Delete icon



Tap the Mark unread icon



Tap the Options icon



important (or Mark not important), Mute, Print, and Report spam.

If you’re viewing a message or another label, tap the Back Button you return to your Inbox.

to start a new Gmail message.

to search within the Gmail app.

to delete the selected messages.

to select Move to, Change

to return to your Gmail Inbox.

to move the message to the trash folder.

to return the message to an unread state.

to access Move to, Change labels, Mark

until

Communication

Reading Your Messages

From your Gmail Inbox, tap a conversation that contains the message you want to read.

The conversation opens to the ﬁrst new (unread) message, or to the ﬁrst starred message, if you’ve previously starred a message in the conversation.

Tap to set labels for the message to help organize your messages.

Tap the Contact's picture to open Quick Contact.

While viewing a message, you can tap the message action icons on the Gmail Inbox header or in the message to access the following options:

Gmail Inbox header icons

The Gmail Inbox header icons include the Gmail Inbox icon , the Archive icon

, the Delete icon , the Mark unread icon , and the Options icon

Gmail message icons

Tap the Contact’s picture to open the Quick Contact options.



Tap the Favorite icon



Tap the Reply icon



Tap the Options icon



remove star from) the message, print the message, or block the sender.

to mark it as a favorite.

to reply to the sender.

to reply to all, forward the message, star (or

Gmail Inbox Header

Gmail Message Header

Communication

Message action icons

Tap an action icon (at the bottom of the message) to reply, reply to all, or forward the message.

To reread a message

When you open a conversation, messages that you’ve already read are minimized into a tab that indicates the number of hidden messages.

1. From your Gmail Inbox, tap the conversation you want to view.

2. Tap the contact name to view the details of that message, or tap the

circled number to view the all of the conversation messages.

While reading a message you can tap the Mark unread icon

a read message to the unread state. For example, to remind yourself to read it again later.

Composing and Sending a Message

You can compose and send a message to people or groups with Gmail addresses or other email addresses.

To compose and send a message

1. Tap the Home Button > the

Compose icon

NOTE If you set up more than one email account on your phone and want to send the

message from a different account, tap the current Google Account (at the top of the screen), then tap the account you want to use.

2. Enter a recipient’s address.

As you enter text, matching addresses are offered from your Contacts

list. You can tap a suggested address or continue entering text to enter a new one.

3. Tap the Arrow icon

can copy or blind copy additional recipients.

4. Enter a subject for the message in the Subject ﬁeld.

5. Enter your email text in the Compose email ﬁeld.

Google folder > Gmail > the

(in the To ﬁeld), to add Cc and Bcc ﬁelds so you

to return

Communication

6. Tap the Attachment icon , then tap Attach ﬁle to add an attachment

from your phone's memory. Tap Insert from Drive to insert ﬁles from Google Drive. Tap the Remove icon

on the attachment to remove it

from your message.

7. Tap the Send icon

NOTE If you aren't ready to send the message, tap the Options icon , then tap Save draft or

simply tap the Back Button

to send your message.

Replying to or Forwarding a Message

Continue an email conversation by replying to a message or by forwarding it without changing the Subject text. Change the Subject text to start a new conversation.

NOTE The conversation text and previous messages are also included in your reply (or

forwarded) message.

To reply to or forward a message

1. Open the message you want to reply to or forward.

2. Tap the Reply icon

 Add others to an ongoing conversation by replying to all and then

adding the new person’s address(es) to the reply.

3. Compose your Gmail message as necessary.

4. Tap the Send icon

NOTE You can change the message action after you've started the message. Simply tap the

current action (in the message header), then tap the one you want. For example, if you chose Reply but decide you want to Reply all instead.

Gmail account settings

1. Tap the Home Button > the

Menu icon .

2. Tap Settings.

3. Tap General settings to change the settings for all accounts. Tap an

account to change the settings that only apply to it.

, or Reply all or Forward.

to send your Gmail message.

Google folder > Gmail

> the

Communication

 The General settings menu includes the following options: Gmail

default action, Conversation view, Swipe actions, Sender image, Reply all, Auto-ﬁt messages, Auto-advance, Conﬁrm before deleting, Conﬁrm before archiving, and Conﬁrm before sending.

Tap the Options icon

in the General settings to access Manage

Accounts, Clear search history, Clear picture approvals, and Help & feedback.

 Speciﬁc Gmail account settings include the following options: Inbox

type, Inbox categories, Notiﬁcations, Inbox sound & vibrate, Signature, Vacation responder, Sync Gmail, Days of mail to sync, Manage labels, Download attachments, and Images.

NOTE Other email accounts may have additional speciﬁc settings.

Tap the Options icon in the account's settings to access Manage

Accounts and Help & feedback.

Communication

Hangouts

Use the Hangouts app to have real-time text conversations with your friends.

To open the Hangouts app

Tap the Home Button



To sign out of Hangouts

Tap the Hangouts Menu icon



out.

NOTE Closing the Hangouts app does not sign out your Google Account. When you open the

Hangouts app again, the same Google Account is displayed unless you signed out

before closing the app.

Navigating in Hangouts

Tap a Hangouts contact to display your chat messages with that contact.



Tap the Hangouts Menu icon



Contacts, Invites, Archived, Blocked people, Settings, and Help & feedback.

The main screen displays your conversations. Tap one to open it.



Tap

to start a new conversation.



Chatting with Friends

1. Tap the Home Button > the Google folder > Hangouts .

2. Tap the New icon

(New Video Call

3. Select a friend from the Chatting list.

 Tap the name of the person in your contacts list. If your friend is not

yet on Hangouts, your friend will receive an SMS inviting them to Hangouts.

 Tap the text ﬁeld to enter a name, email, number, or circle.

> the Google folder > Hangouts .

> Settings > tap your account > Sign

to access Status, Snooze notiﬁcations,

, then tap the type of Hangouts session you want

, New Group , or New Conversation ).

Communication

4. Tap the Send icon (on the right side of the message).

NOTE You can tap the Call icon to call the friend, or tap the Video icon to start a video

chat with your friend.

Continuing a Chat

1. Tap the Home Button > the Google folder > Hangouts .

2. Tap the Hangouts contact you want.

3. Enter your message.

4. Tap the Send icon

Managing chats

Touch and hold a name in the Hangouts screen to select the friend. Choose an action to apply to all of the friends you selected.

Tap the Notiﬁcations off icon



Notiﬁcations on icon to receive notiﬁcations again.

Tap the Options icon



messages or Delete to delete your chat messages.

to stop receiving notiﬁcations or tap the

, then tap Archive to archive your chat

Chat Options menu

While viewing a chat conversation, tap the Options icon to access the following options: People & options, New group conversation, Turn history off, Archive, Delete, and Help & feedback.

Blocking your Friends

To block a friend from exchanging messages with you, while viewing a



chat conversation with that friend, tap the Options icon options. Then tap Block next to the friend's name and BLOCK to

conﬁrm.

To remove a friend from the blocked list, tap the Menu icon



Blocked people, then tap Unblock next to the friend.

> People &

. Tap

Communication

Adding and Switching Google Accounts in Hangouts

You can sign in to multiple Google Accounts in the Hangouts app, but you can only access one account at a time.

1. Tap the Home Button

2. Tap the Menu icon

3. Tap Add account, tap the account you want to use.

4. Repeat steps 2-3 to sign in additional accounts.

5. Tap the Menu icon

6. Tap the account you want to switch to.

> the Google folder > Hangouts .

, then tap Settings.

, then tap your account.

Changing Hangouts Settings

To change the Hangouts settings, open the Hangouts app, tap the



Menu icon

Enable merged conversations enable this setting to merge your



contact conversations from both SMS and Hangouts together.

Tap SMS to change its settings including SMS enabled (or disabled),



Default SMS Messaging Account, Blocked people, Sound, Vibrate, Delete old messages, Delivery reports, Auto retrieve MMS, and Roaming auto-retrieve.

Tap your Google Account to access Proﬁle photo, Share your status,



Hangouts messages & invites, Video calls, Customize invites, Veriﬁed phone number(s), Hidden contacts, Sign out, and Improve Hangouts.

> Settings.

Entertainment

Camera

You can use the Camera app to take and share pictures and videos. The video feature is integrated on the camera viewﬁnder to take pictures and record video with a single tap. Your phone comes with a 5 megapixel camera that lets you capture sharp pictures and videos. It has many state-of-the-art features such as gesture shot, interval shot, burst shot, still photo capture while recording video, and much more. These features will allow you to easily and creatively capture your world.

NOTE Be sure to clean the protective lens cover with a microﬁber cloth before taking pictures.

A lens cover with smudges from ﬁngers can cause blurry pictures with a "halo" effect.

To open the Camera app

Tap Camera



Tap the Home Button



NOTES ţ If you've set a Lock screen other than Swipe, drag the Camera icon to the left to

The camera viewfinder icons

Lens Swap – Switches between the rear-facing camera lens and the front-facing camera lens.

Flash – Indicates the current ﬂash mode. Tap it to toggle through the ﬂash modes.

Menu – Toggles between displaying and hiding the viewﬁnder icons.

Settings – Displays the camera settings. See Additional settings.

on the Home screen.

> the Apps icon > Camera .

open the Camera. From the Swipe Lock screen, drag the Camera icon

ţ With the backlight off or from any Lock screen, press either of the Volume Keys

twice to open the Camera (enable this shortcut in the Settings app).

Gallery – Accesses your Gallery to view your saved

photos and videos. Tap it to display the last photo or video you captured.

Video Capture – Starts recording a video. Capture – Takes a picture.

Back – Closes the Settings or exits the Camera app.

upward.

Entertainment

Taking Pictures

Taking pictures with your phone’s built-in camera is as simple as choosing a subject, pointing the lens, and tapping a button icon. When you take a picture, the Multi-point Auto-focus (AF) function operates automatically to allow you to capture a clear image.

NOTE You can swipe across the screen to quickly swap between the front and rear camera

lenses.

1. Tap the Home Button > Camera .

2. Frame your subject on the screen.

 The green squares indicate that the camera has focused.

 Place two ﬁngers on the screen and spread them apart to zoom in (a

zoom bar indicates the zoom level) and pinch in to zoom back out.

3. Tap the Capture icon

, if available. Otherwise, tap the subject to take

the picture. Your picture will be automatically saved to the Gallery.

NOTE The captured image retains the orientation in which it was taken. If you hold the phone

both vertically and horizontally to take pictures, you'll need to rotate the phone to view full screen images in the Gallery app.

TIP While viewing a photo, you can tap the Options icon

(or Rotate right) to manually change its orientation.

, tap Rotate, then tap Rotate left

Specialized shots

Selﬁes Tap the Lens swap icon to activate the front camera lens, then tap the Capture icon

Gesture shot Activate the front camera lens, raise your open hand in front of you, then make a ﬁst to automatically take the shot after three seconds (making a ﬁst twice takes four selﬁe shots).

Interval shot Activate the front camera lens, then touch and hold the Capture icon

Burst shot Activate the rear camera lens, then touch and hold the Capture

to continually capture shots until you lift your ﬁnger.

icon

(or take a Gesture shot or an Interval shot).

to take four selﬁes in a row.

Entertainment

Record Videos

In addition to taking pictures, you can record, view, and send videos with your phone’s built-in video camera.

1. Tap the Home Button

2. Frame your subject on the screen.

3. Tap the Video Capture icon

 The length of the recording is displayed at the upper corner of the

screen.

 You can tap the Capture icon

recording video.

 You can use the pinch gesture to use the dynamic zoom feature while

you’re recording video. Spread your ﬁngers on the screen to zoom in and pinch to zoom back out.

 You can tap the Pause icon

resume your recording by tapping the Record icon

4. Tap the Stop icon

saved to the Gallery.

> Camera .

to start recording the video.

to take pictures while you’re

to pause your video recording. Then,

to stop recording. Your video will be automatically

Additional Settings

The camera is set to automatically take high quality photos and videos. The Settings provide some additional features to help you capture the images you want. Tap the Settings icon setting to change it. Tap the Settings icon

Indicates the aspect ratio set for the photo or video.

For photos, choose from 1:1, 4:3, and 16:9. For videos, you can only choose HD.

Indicates the Voice command function is enabled.

Indicates the Voice command function is disabled.

Indicates there will be a 3 second delay after the Capture icon is

tapped.

to display the current settings. Tap a

again to exit the settings.

Entertainment

Indicates there will be a 10 second delay after the Capture icon is

tapped.

Indicates the delay capture function is disabled.

Toggles between displaying and hiding an overlay grid to help you align

your photos and videos horizontally and/or vertically for better composition.

NOTE Tap the Help icon to view additional information to help you use the camera.

Viewing your pictures and videos

The Gallery is where you can access your gallery of stored camera images. You can view your photos in a slideshow, share your photos and videos with your friends, as well as manage them (delete, edit, etc.). You can access your photos and videos stored in your phone's internal memory and microSD card (external memory).

1. Tap the Home Button

 Swipe up or down to view more albums.

 Tap the Menu icon

view your images and videos.

2. Tap an album to open it and view its contents. (The pictures and videos

in the album are displayed in chronological order.)

3. Tap an image to view it. Then you can swipe horizontally to browse

through your images.

> the Apps icon > Gallery .

to access Albums, Videos and Favorites to

To share your pictures and videos

1. Open an album to view its contents, then tap the Share icon .

2. Tap each ﬁle you want to share. When the checkmarks are set, tap

SHARE, select how to share the ﬁle(s), then complete as necessary.

To delete pictures and videos

1. Open an album to view its contents, then tap the Delete icon .

2. Tap each ﬁle you want to delete. When the checkmarks are set, tap

DELETE, then tap YES to conﬁrm.

Entertainment

To play a video

1. Tap the Home Button > the Apps icon > Gallery .

 Scroll up or down to view more albums.

2. Tap a video in an album to play it.

NOTE If you set the default app for video playback in the pop-up, video playback will begin as

soon as you tap a video in an album. Otherwise, you'll need to choose the app each time you want to view a video.

 Tap the video while it’s playing to view the playback controls.

 While playing a video, the timeline allows you to jump to that part of

the video.

 While playing a video, press the Volume Keys

 When using the Video app, tap the Options icon

ratio, Subtitles, Share, Details, and Settings.

NOTE The recording retains the orientation in which it was taken. If you hold the phone both

vertically and horizontally to take pictures and record videos, you'll need to rotate the phone to view full screen images in the Gallery app.

to adjust the volume.

to access Screen

Entertainment

Gallery

Open the Gallery app to view albums of your pictures and videos.

To open the Gallery app

Tap the Home Button



Viewing your albums

The Gallery app presents all of the pictures and videos stored in your phone, including those you’ve taken with the Camera app and those you downloaded from the web or other locations. When another app saves a picture, it automatically creates a download album to contain the picture (e.g., capturing a screen shot creates the Screenshots album).

Tap an album to open it and view its contents, then tap a picture or video



to view it.

Touch and hold an album to access Share, Delete, and Details.



Tap the Options icon



preferred albums, and Settings.

Tap the Camera icon



Tap the Menu icon



Videos, and Favorites.

> the Apps icon > Gallery .

to access Cloud, New album, Delete, Set

to return to the Camera app.

to open the Gallery menu to access Albums,

Entertainment

To share an album

You can share the entire contents of your albums.

1. Tap the Home Button

2. Touch and hold the desired album, tap Share, select the app to use to

share your images, then complete the sending method as necessary.

> the Apps icon > Gallery .

Gallery Options

The Gallery app makes it easy to view and manage the images stored in your phone. Its icons make it easy to navigate, as well as manage and modify your ﬁles.

1. Tap the Home Button

images stored in your phone’s internal memory and on a microSD card (external storage).

 Drag up or down to view more albums.

2. Tap an album to open it and view its contents. (The pictures and videos

in the album are displayed in chronological order.)

3. Tap a picture in an album to view it.

> the Apps icon > Gallery to view the

Entertainment

 While viewing an album, use the following icons for navigation or

multi-selection ﬁle management.

Back: Goes back to the previous screen.

Camera: Opens the Camera app.

Share: Allows you to select one (or more) photos and/or videos to

share. After selecting the ﬁle(s), tap SHARE to open the available sharing options (such as Messaging or Bluetooth), then complete as necessary.

Delete: Allows you to select one (or more) photos and/or videos to

delete. After selecting the ﬁle(s), tap DELETE, then YES to delete them.

Options: Opens its Options menu which allows you to select one

(or more) photos and/or videos to Move, Copy, Slideshow, or Rotate.

 Tap a picture in an album, then tap the screen to display and use the

following icons for navigation and single ﬁle application.

Back: Goes back to the album view.

Edit: Opens the Edit function.

Camera: Opens the Camera app.

Share: Displays a sharing method pop-up.

Delete: Immediately deletes the image.

Options: Opens its Options menu which includes: Set image as,

Move, Copy, Copy to Clip Tray, Slideshow, Rotate, Crop, Add/ Remove location, Rename, Print, and Details.

Favorite: Sets it (or removes it) as a favorite displayed in your

Favorites album.

Assign Pictures

After taking a picture, assign it as a picture ID for a Contacts entry or as the background image (wallpaper) for your Home screen or Lock screen.

1. Tap the Home Button

> the Apps icon > Gallery .

Entertainment

2. Tap an album and tap an image to view it.

3. With the picture displayed, tap the Options icon

> Set image as.

4. Select an option.

 Home screen assigns the picture as the background image. Crop the

image as necessary.

 Contact photo assigns the picture to a Contact entry as a picture ID.

Tap an entry from Contacts, then crop the image as necessary.

 Lock screen wallpaper assigns the picture as the background image

for your Lock screen. Crop the image as necessary.

 Wallpaper assigns the picture as your background image. Tap SET

WALLPAPER to assign the picture.

NOTE The crop procedure depends on the app used. When using the Crop picture app, adjust

the crop box, then tap OK. When using the Photos app, adjust the crop box, apply the photo edits you want, tap the Checkmark icon

, then tap SAVE.

Working with photos

Use the Gallery app to view your pictures and edit them.

To view and browse photos

1. Tap the Home Button > the Apps icon > Gallery .

2. Open an album and tap a picture.

3. Tap the screen to display the icon bar and the Home Touch Buttons Bar.

The following options are available.

 Tap the Options icon

to Clip Tray, Slideshow, Rotate, Crop, Add/Remove location, Show on the map, Rename, Print, or Details.

 Tap the Delete icon

 Tap the Share icon

necessary to share the picture.

 Tap the Camera icon

to access Set image as, Move, Copy, Copy

to immediately delete the picture.

, tap the sharing method, then complete as

to switch to camera mode.

Entertainment

 Tap the Edit icon to open the editing screen which allows you to

change the picture (such as cropping, rotating, tuning, adding effects, and more).

 Tap the Favorites icon

to set (or remove) the picture to your

Favorites folder.

 Tap the Back icon

Camera Mode Icon Tap here to change to camera mode.

Back Icon

Tap here to return to the current album.

Favorites Icon

Tap here to add the photo to your Favorites album.

Edit Icon

Tap here to edit your picture.

to return to the current album.

Share Icon

Tap here to share the photo using the method you select.

Options Icon

Tap here to access the Options menu.

Delete Icon

Tap here to delete the photo.

Swipe horizontally to scroll through the photos in the current album.

Music

Your phone has a music player that lets you play all of your favorite tracks. To access the Music player, tap the Home Button

Music

Playing a song

1. Tap the Home Button > the Apps icon > Music .

2. Tap the Songs tab (Music tabs are displayed across the top of the

screen).

3. Tap the song you want to play.

TIP To ﬁnd a song, you can tap the Search icon or tap the letter the song begins with

using the alphabet listed along the right side of the screen.

> the Apps icon >

Entertainment

Music player icons

Tap to set the current song as a favorite (toggle it on or off).

Tap to see the current playlist.

Tap to access the Music player Options menu.

Tap to set the shufﬂe mode (toggle it on or off).

Tap to set the repeat mode (on, off, or same song).

Tap to manage the music volume. The pop-up window also allows you to modify all phone sounds using the Sounds icon Volume Keys will also to adjust the volume.

Tap to go back to the beginning of the song. Tap 2 times to return to the previous song. Touch and hold to rewind in 3 second increments.

Tap to pause playback.

. The

Tap to resume playback.

Tap to skip to the next track on the album or in the playlist. Touch and hold to fast-forward in 3 second increments.

Entertainment

Tap to see the last selected music list (Music library, Favorites, Playlists, or Folders).

Other Music app options

Touch and hold any song in the Music library to access its context menu



which can include: Play, Add to playlist, Delete, Share, Set as ringtone, and Search.

Tap the Options icon



which can include: Cloud, Select to play, Add to playlist, Delete, Share,

in the Music library to access its Options menu

and Settings.

Tap the Options icon



which can include: Search, Add to playlist, Delete, Share, Set as

in the Music player to access its Options menu

ringtone, Music video, and Details.

Turning the music player off

To stop the Music player, swipe the Status Bar downward, then tap the Close icon

NOTES ţ Some ﬁle formats are not supported, depending on the device software.

  ţ If the ﬁle size exceeds the available memory, an error can occur when you open ﬁles.

  ţ Music ﬁle copyrights may be protected by international treaties and national copyright

on the Music notiﬁcation.

laws. Therefore, it may be necessary to obtain permission or a license to reproduce or copy music. In some countries, national laws prohibit private copying of copyrighted material. Before downloading or copying the ﬁle, check the national laws of the relevant country concerning the use of such material.

To use a song as a ringtone

You can use a song as your phone ringtone, in place of one of the ringtones that come with the phone.

Touch and hold a song in the Music library list. In the context menu that



opens, tap Set as ringtone, then tap Phone ringtone or Caller ringtones.

On the Music player screen, tap the Options icon



ringtone, then tap Phone ringtone or Caller ringtones.

, tap Set as

Entertainment

Working with Playlists

You can create playlists to organize your music ﬁles into sets of songs, which you can play in the order you set or in a shufﬂe.

To create a playlist

1. From the Music library, tap the Menu icon , then tap Playlists.

2. Tap the New icon

3. Enter a name for the playlist and tap OK.

4. Select the songs you want to add to a playlist, then tap ADD. The new

playlist is added to the Playlist tab.

To add a song to a playlist

1. From the Music library, touch and hold the song you want to add to a

playlist.

2. In the context menu that opens, tap Add to playlist, then tap the name

of the playlist you want to add it to.

To remove a song from a playlist

1. Open your playlists using the Menu icon , then tap the playlist you

want.

2. Touch and hold the song you want to remove, then tap Remove from

playlist in the context menu that appears.

To delete a playlist

1. Open your playlists using the Menu icon .

2. Touch and hold the playlist, then tap Delete in the context menu that

appears.

3. Tap YES to conﬁrm.

To rename a playlist

1. Open your playlists using the Menu icon .

2. Touch and hold the playlist, then tap Rename in the context menu that

appears.

Entertainment

3. Enter a name, then tap OK.

To delete multiple songs

Open the Music library screen, tap the Songs tab, tap the Options icon



, then tap Delete. Checkmark each of the songs you want to delete, tap

DELETE, then tap YES to conﬁrm.

NOTE Tap the Options icon from another Music tab to delete one or more of the items in

that selected tab.

Play Store

Play Store allows you to browse and search for free and paid applications.

To open the Play Store app

Tap the Home Button



Tap the Home Button



To get help with Play Store

Play Store Help web pages are available from all Play Store screens.

Swipe from the left edge of the screen to the right, then tap Help &



Feedback.

The Chrome app opens to the Play Store Help page, with links to many

help topics.

To open a screen with details about an app

At any time while browsing in Play Store, tap an app to open its details



screen.

The App details screen includes a description, ratings, comments, and

related information about the app. From this screen, you can download, install, uninstall, rate the app, and more.

> Play Store on the Home screen.

> the Apps icon > Play Store .

Downloading and Installing Apps

When you ﬁnd an app you want, you can install it on your phone.

Entertainment

To download and install an app

NOTE Before you can download a paid app, you must set up a billing arrangement.

Price/Install button Indicates the cost or install for free apps.

1. Tap the Home Button > Play Store .

2. Tap a category from the Store home page or tap its search box to search

for the item you want.

NOTE To search from a category page, tap the Search icon .

3. Tap INSTALL or the Price button to download the app currently

displayed.

4. If you agree with the app's access requirements, tap ACCEPT.

5. The app will be downloaded and installed.

Play Store Menu

On the Play Store home page, drag the left edge of the screen to the right to access Apps & Games, Entertainment, Movies & TV, Music, Books,

Newsstand, My account, My wishlist, Redeem, People, Settings, Help & Feedback, Parent Guide, and About Google.

Your Wishlist

While viewing an app (or music, games, etc.), tap the Wishlist icon to the right of the app name to add it to your wishlist for future reference.

LG K4 LTE User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
