LG HCS6100R Setup Guide

HCS6100R CodePlus™

Series Card Frame with

Power Supply

Installation & Setup Guide

Warranty

© Copyright 2010, LG Electronics U.S.A., Inc.

Part No: 206-4114

For Customer Support/Service, please call: 1-888-865-3026

The latest product information and document revisions are available online at:

www.LGcommercial.com/products

WARNING

RISK OF ELECTRIC SHOCK
DO NOT OPEN

WARNING:

TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. ALL
CARDS USED IN THE HCS6100R MUST BE INSERTED AND REMOVED BY QUALIFIED
SERVICE PERSONNEL ONLY.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert

the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence

of important operating and maintenance (servicing) instructions in the literature accompanying
the appliance.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.

Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such

as vases, shall be placed on the apparatus.

L’appareil ne doit pas être exposé à des égouttements d’eau ou des éclaboussures et de plus
qu’aucun objet rempli de liquide tel que des vases ne doit être placé sur l’appareil.

REGULATORY INFORMATION:

This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec­tion against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio com­munications. Operation of this equipment in a residential area is likely to cause harmful interfer­ence in which case the user should be required to correct the interference at his own expense.

CAUTION:

Do not attempt to modify this product in any way without written authorization from LG Electronics
U.S.A., Inc. Unauthorized modification could void the user’s authority to operate this product.

NOTE TO SATELLITE DISH INSTALLER:

This reminder is provided to call your attention to articles 810 and 820 of the 2002 National

Electrical code. Refer to article 810, in particular 810-1 and 810-15, for required grounding of
the metal dish antenna. Refer also to the 810-2 which, by reference to article 820, requires
that the satellite dish coaxial cable shield be connected to the grounding system of the build­ing as close to the point of cable entry as practical.

COMPLIANCE:

The responsible party for this product’s compliance is: LG Electronics U.S.A., Inc.

2000 Millbrook Drive, Lincolnshire, IL 60069, USA • Phone: [phone]

Marketed and Distributed in the United States by LG Electronics U.S.A., Inc.

2000 Millbrook Drive, Lincolnshire, IL 60069

2

© Copyright 2010, LG Electronics U.S.A., Inc.

206-4114

IMPORTANT SAFETY INSTRUCTIONS

Important safeguards for you and your new product

THIS PRODUCT HAS BEEN MANUFACTURED AND TESTED WITH SAFETY IN
MIND. IMPROPER USE, HOWEVER, CAN RESULT IN POTENTIAL ELECTRICAL
SHOCK OR FIRE HAZARDS. TO AVOID DEFEATING THE SAFEGUARDS THAT
HAVE BEEN BUILT INTO THIS PRODUCT, PLEASE READ AND OBSERVE THE
FOLLOWING SAFETY POINTS WHEN INSTALLING AND USING THIS PRODUCT.

1. Read these instructions.

Read all the safety and operating instructions

before operating the product.

2. Keep these instructions.

Retain the safety and operating instructions

for future reference.

3. Heed all warnings.

Adhere to all warnings on the product and in

the operating instructions.

4. Follow all instructions.

Follow all operating and use instructions.

5. Do not use this apparatus near water.
Do not use this product near water or mois-

ture or in an area, such as a basement, that
might become flooded.

6. Clean only with dry cloth.
Unplug this product before cleaning. Do not

use liquid cleaners or aerosol cleaners.

7. Do not block any ventilation openings.
Install in accordance with the manufactur­er's instructions.

This product is designed to fit in a rack. The ven-

tilation slots and openings in the cabinet are pro­vided to ensure reliable operation of the product
and to protect it from overheating. These open­ings must not be blocked or covered.

This installation should be attempted only by

a qualified service technician and should con­form to all local codes. All cards used in the
HCS6100R must be inserted and removed by
qualified service personnel only.

8. Do not install near any heat sources, such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.

9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding-type
plug has two blades and a third ground­ing prong. The wide blade or the third
prong are provided for your safety. If the
provided plug does not fit into your out­let, consult an electrician for replacement
of the obsolete outlet.

10. Protect the power cord from being walked
on or pinched, particularly at plugs, con­venience receptacles, and the point
where it exits from the apparatus.

11. Only use attachments/accessories speci­fied by the manufacturer.

12. Use only with the cart, stand, tripod,
bracket, or table specified by the manu­facturer or sold with the apparatus. When
a cart is used, use caution when moving
the cart/apparatus combination in order
to avoid injury from tip-over.

13. Unplug this product during lightning
storms or when unused for long periods
of time.

14.

Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.

(Continued on next page)

206-4114

3

IMPORTANT SAFETY INSTRUCTIONS

(Continued from previous page)

15. Power Sources

This product should be operated only from

the type of power source indicated on the
marking label. If you are not sure of the type
of power supply to your INSTALLATION,
consult your product dealer or local power
company.

16. Overloading

Do not overload wall power outlets and

extension cords as this can result in a risk of
fire or electric shock.

17. Disconnect Device

The AC mains plug is used as the discon-

nect device. The disconnect device must
remain readily operable.

18. Object and Liquid Entry

Never push objects of any kind into this
product through openings as they may touch
dangerous voltage points or short-out parts
that could result in a fire or electric shock.
Never spill liquid of any kind on the product.

19. Outdoor Use
Warning: To prevent fire or shock

hazards, do not expose this product
to rain or moisture.

20. Wet Location
The apparatus shall not be exposed to drip-

ping or splashing and no objects filled with
liquids, such as vases, shall be placed on
the apparatus.

21. Test Equipment

In some cases, LG has supplied or recom­mended the use of test equipment and
devices for the setup and testing of the
equipment. The operation and maintenance
of test equipment is described in their asso­ciated instruction manuals. Please refer to
these manuals for explicit instructions
regarding the safe use and handling of the
equipment.

22. Replacement Parts

When replacement parts are required, be

sure the service technician uses replace-

ment parts specified by the manufacturer or
that have the same characteristics as the
original parts. Unauthorized substitutions
may result in fire, electric shock, or other
hazards.

23. Damage Requiring Service

Unplug this product from the wall power out­let and refer servicing to qualified service
personnel under the following conditions:

a. If the power-supply cord or plug is dam-

aged.

b. If liquid has been spilled, or objects have

fallen into the product.

c. If the product has been exposed to rain or

water.

d.

If the product does not operate normally

by following the operating instructions.
Adjust only those controls that are covered
by the operating instructions, as an
improper adjustment of other controls may
result in damage and will often require
extensive work by a qualified technician to
restore the product to its normal operation.

e. If the product has been dropped or the

cabinet has been damaged.

f. If the product exhibits a distinct change in

performance.

Caution: Refer all servicing to qualified
service personnel.

24. Servicing

25. Safety Check

Caution: These servicing instruc­tions are for use by qualified ser-

vice personnel only. To reduce the
risk of electrical shock, do not perform
any servicing other than that described in
the operating instructions unless you are
qualified to do so.

Upon completion of any service or repairs to
this product, ask the service technician to
perform safety checks to determine that the
product is in proper operating condition.

(Continued on next page)

4

206-4114

IMPORTANT SAFETY INSTRUCTIONS

(Continued from previous page)

HCS6100R Rack Installation (also see pages
1213)

To install the HCS6100R in a rack:

• Carefully slide the HCS6100R into a standard

19-inch equipment rack.

• When mounted in the rack, make sure appro-

priate hardware is used. ALL FOUR
MOUNTING SCREWS MUST BE USED.

• This equipment is not designed to support

other devices. Do not stack.

• Rear cabling must be dressed and supported

so that the weight of the cabling is not a strain
on the HCS6100R connectors.

• MOUNTING OF THE EQUIPMENT IN THE
RACK SHOULD BE SUCH THAT A
HAZARDOUS CONDITION IS NOT ACHIEVED
DUE TO UNEVEN MECHANICAL LOADING.

Rack-mount Temperature Considerations
A. Elevated Operating Ambient

If installed in a closed or multi-unit rack

assembly, the operating ambient temperature
of the rack environment may be greater than
room ambient. Therefore, consideration
should be given to installing the equipment in
an environment compatible with the maximum
ambient temperature (Tma) specified by the
manufacturer (see “Specifications” information
in this document).

B. Reduced Air Flow
Installation of the equipment in a rack should

be such that the amount of air flow required
for safe operation of the equipment is not
compromised. To ventilate the system nor­mally and avoid overheating, leave at least 1
inch (2.5 cm) on each side of the HCS6100R
unit. Do NOT stack other equipment on the
top of the HCS6100R unit.

C. Circuit Overloading
Consideration should be given to the connec-

tion of the equipment to the supply circuit and
the effect that overloading of the circuits
might have on overcurrent protection and
supply wiring.

D. Reliable Earthing

Maintain reliable earthing of rack-mounted

equipment. Particular attention should be
given to supply connections other than direct
connections to the branch circuit (e.g. use of

power strips).

E. Mains Outlet Earthing

The apparatus with Class I construction must

be connected to a mains socket outlet with a
protective earthing connection.

HCS6100R Installation on a Flat Surface

To install the HCS6100R on a level surface (table
top, shelf, stacked with other equipment, etc.):

• Carefully place the

face.

HCS6100R

on a level sur-

• Please note the operating temperature from the

specifications.

• Air flow is from bottom to top (when viewed

from the front).
ly and avoid overheating, leave at least 1 inch
(2.5 cm) on each side of the HCS6100R unit.
Do NOT stack other equipment on the top of
the HCS6100R unit.

To ventilate the system normal-

• If necessary, place spacers or rubber feet (not

provided) on top and bottom to avoid obstruct­ing vent holes.

206-4114

5

Table of Contents / Setup Checklist

Table of Contents

Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . 2

Important Safety Instructions. . . . . . . . . . . . 35

Table of Contents / Setup Checklist . . . . . . . . 6

Transcoder Product Description . . . . . . . . . . . 7

Back Panel Overview . . . . . . . . . . . . . . . . . 89

Installing CodePlus Transcoder Cards . . . . . 10

Front Panel Overview / Ventilation . . . . . . . . .11

Rack Installation . . . . . . . . . . . . . . . . . . . 1213

Troubleshooting / Specifications . . . . . . . . . . 14

Document Revision History / Notes . . . . . . . 15

Warranty . . . . . . . . . . . . . . . . . . . . . Back Cover

Setup Checklist

1. Unpack the HCS6100R unit and all accessories.

Accessories provided: Power Cord, Installation & Setup Guide.

2. Select the location for mounting the HCS6100R. Ensure that there is adequate ventilation

available

3. Obtain the necessary attachment hardware to mount the HCS6100R chassis in its targeted

location.

4. Plan and install the necessary cabling and AC power access for the HCS6100R, the CodePlus™

series transcoder cards, and, if applicable, the CodePlus feature card to be installed. (Refer to the
setup procedures for individual transcoder and feature cards for further information on cabling.

5. Carefully follow the installation procedures for the CodePlus series cards (see pages 810) and

the HCS6100R (see pages 1213).

6. Refer to the setup procedures for the individual CodePlus series transcoder cards and the feature

card (if applicable), and set up each card as required.

7. Plug the HCS6100R and all system equipment into convenient 120V 60Hz AC power outlets.

Make sure the fan is working and fan cooling vents are unobstructed.

.

6

206-4114

Transcoder Product Description

HCS6100R CodePlus Series Card Frame with Power Supply

The HCS6100R is a 19-inch rack-mountable card frame that provides the operating
environment for the LG CodePlus series transcoder cards. Using one or more
HCS6100R units containing appropriate transcoder cards, a variety of transcoding
systems can be realized.

Features

• Self-contained 180W power supply

• Slots for 13 CodePlus cards (12 transcoders plus 1 feature card)

• Built-in fan for active ventilation

• 19-inch rack-mountable

• Short 3U height profile to minimize rack-space usage

Note: Design and specifications subject to change without prior notice.

206-4114

7

Back Panel Overview

The following figure shows a typical installation with all the available card slots filled.

HCS6700

HCS6700

HCS6700

HCS6700

X PORT LINK

HCS6700

X PORT LINK

HCS6700

X PORT LINK

HCS6700

X PORT LINK

HCS6700

X PORT LINK

HCS6700

X PORT LINK

HCS6300

ETHERNET

HCS6700

X PORT LINK

HCS6700

X PORT LINK

HCS6700

X PORT LINK

X PORT LINK

X PORT LINK

X PORT LINK

ASI OUT

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

Slot 1

SERVICE

SERVICE

PORT

PORT

RESET

RESET

STATUS

STATUS

ASI OUT

S/N XXXXXXX

S/N XXXXXXX

MAC ADDRESS

MAC ADDRESS

XX XX XX XX XX

XX XX XX XX XX

Slot 2 Slot 3 Slot 4

ASI OUT

SERVICE
PORT

RESET

STATUS

ASI OUT

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

SERVICE
PORT

RESET

STATUS

ASI OUT

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

Slot 5

SERVICE
PORT

RESET

STATUS

ASI OUT

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

Slot 6

SERVICE
PORT

RESET

STATUS

CONTROLLER

Slot

RF OUT

SERVICE

PORT

RESET

STATUS

ASI OUT

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

Slot 7

SERVICE
PORT

RESET

STATUS

ASI OUT

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

Slot 8

SERVICE
PORT

RESET

STATUS

ASI OUT

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

Slot 9 Slot 10

SERVICE
PORT

RESET

STATUS

ASI OUT

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

SERVICE
PORT

RESET

STATUS

ASI OUT

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

Slot 11

SERVICE
PORT

RESET

STATUS

ASI OUT

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

Slot 12

SERVICE
PORT

RESET

STATUS

Disconnect Device

The AC mains plug is used as the disconnect device.
The disconnect device must remain readily operable.

Output/Terminal Marking

The following ratings must be observed when cards are added to the
HCS6100R.

Marking Location Voltage (VDC) Amperage (A)

AC Power Input
(AC Mains Plug)

For Card Slot numbers:
1, 2, 4, 5, 8, 9, 11, and 12

For Card Slot numbers:
3, 6, 7, and 10

12 1.2

12 0.7

For Card Slot: CONTROLLER 12 1.35

8

206-4114

Back Panel Overview (Cont.)

Important Card Slot Information

Note: The slot bus is proprietary and should only use CodePlus­compliant products.

Note: All cards used in the HCS6100R must be inserted and
removed by qualified service personnel only.

Note: The CodePlus series products are NOT designed to be hot­swappable!!! Power must be removed to the HCS6100R before any
CodePlus cards are inserted or removed.

Note: The card slots in the HCS6100R are NOT all identical!!!
Please refer to the “Front Panel Overview / Ventilation” section on
page 11 as well as the Installation & Setup Guide for the CodePlus
card(s) being installed for more information, and select the appro­priate card slot.

• Transcoder Slots 1 to 6 and 7 to 12 are designated for transcoder

cards (Example: HCS6700).

• The CONTROLLER slot between Slots 6 and 7 has different edge
connector locations and pinouts and is incompatible with transcoder
cards. The CONTROLLER slot is intended for optional feature cards
(Example: HCS6300).

Note: Do not try to force a CodePlus card into any slot that does
not allow it to be easily and fully seated using the installation pro­cedure on the following page.

206-4114

9

Installing CodePlus Transcoder Cards

HCS6700

Blank Cover Plates

As shipped, the HCS6100R has blank
cover plate port covers. Simply remove
the blank cover plates on ports that will
be used. For ports that will not be used,
leave the blank cover plates in place for
proper ventilation and FCC and safety
agency compliance.

HCS6700

X PORT LINK

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

HCS6700

HCS6700

X PORT LINK

X PORTLink

SERVICE

SERVICE

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

ASI OUT

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

ASI OUT

PORT

RESET

STATUS

Service

PORT

RESET

STATUS

ASI OUT

HCS6700

X PORT LINK

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

HCS6300

HCS6700

X PORT LINK

ETHERNET

SERVICE

SERVICE

PORT

RESET

STATUS

ASI OUT

SERVICE
PORT

PORT

RESET

RESET

STATUS

STATUS

RF OUT

ASI OUT

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

Note: All cards used in the HCS6100R
must be inserted and removed by quali­fied service personnel only.

Note: The CodePlus series products are
NOT designed to be hot-swappable!!!

Power must be removed to the
HCS6100R before any CodePlus cards are
inserted or removed

.

Note: The card slots in the HCS6100R

are NOT all identical!!! Refer to the

“Back Panel Overview” section on
pages 89. The CONTROLLER slot between
Slots 6 and 7 is dedicated for optional feature
cards and is not compatible with transcoder
cards.

1. Unpack the CodePlus transcoder unit(s) and

all accessories.

2. Select the slot(s) in the card frame in which to

install the card(s). Note: All cards must be

used in an LG-approved card frame for this
product.

3. Remove the AC power cord for the card
frame from the power outlet.

4. Remove the blank cover plate from each slot
into which a card is to be inserted.

5. Without using force, slide each new card into its
designated slot, and ensure it is fully inserted.

6. Engage and tighten the top and bottom
thumbscrews securely. Note that the thumb­screws should only be finger tight; overtight­ening may damage the assembly.

7. Refer to the Installation & Setup Guide for the
transcoder card(s) being installed for cabling
and setup information.

8. Repeat steps 1 to 6 to install a feature card
(optional) in the CONTROLLER slot. Then,
refer to the Installation & Setup Guide for the
feature card for cabling and setup information.

10

206-4114

Front Panel Overview / Ventilation

The following figure shows the HCS6100R front panel. Back panel features are described
on pages 89.

Top Back

Front

Bottom

Ventilation Holes

Air flow must not be obstructed. To ventilate the system normally and avoid
overheating, leave at least 1 inch (2.5 cm) on each side of the HCS6100R unit.
Do NOT stack other equipment on the top of the HCS6100R unit.

206-4114

11

Rack Installation

Typical HCS6100R Rack Mount Installation

To install head end equipment in the rack:

Install the card frame with cards and the satellite/cable Set-top
Boxes (STBs) in an appropriate rack. As needed, install the neces­sary modulators and upconverters.

HCS6700

X-PORT Link

HCS6700

HCS6700

X-PORT Link

HCS6700

Rear View
of Rack Cabinet

X PORT LINK

X-PORT Link

HCS6700

X PORT LINK

HCS6700

X PORT LINK

HCS6700

X PORT LINK

HCS6300

X PORT LINK

SERVICE
PORT

SERVICE

RESET

PORT

STATUS

RESET

STATUS

ASI OUT

ASI OUT

S/N XXXXXXX

MAC ADDRESS

S/N XXXXXXX

XX XX XX XX XX

MAC ADDRESS

XX XX XX XX XX

HCS6700

X PORT LINK

HCS6700

ETHERNET

SERVICE
PORT

SERVICE

RESET

PORT

STATUS

RESET

STATUS

ASI OUT

ASI OUT

S/N XXXXXXX

MAC ADDRESS

S/N XXXXXXX

XX XX XX XX XX

MAC ADDRESS

XX XX XX XX XX

HCS6700

X PORT LINK

HCS6700

X PORT LINK

SERVICE
PORT

SERVICE

RESET

PORT

STATUS

RESET

STATUS

ASI OUT

ASI OUT

S/N XXXXXXX

MAC ADDRESS

S/N XXXXXXX

XX XX XX XX XX

MAC ADDRESS

XX XX XX XX XX

HCS6700

X PORT LINK

HCS6700

X PORT LINK

SERVICE

X PORT LINK

PORT

SERVICE

X PORT LINK

PORT

RESET

SERVICE

RESET

PORT

SERVICE

STATUS

RESET

PORT

SERVICE

STATUS

RESET

PORT

SERVICE

RF OUT

STATUS

RESET

PORT

SERVICE

STATUS

RESET

PORT

STATUS

RESET

ASI OUT

STATUS

ASI OUT

ASI OUT

ASI OUT

S/N XXXXXXX

MAC ADDRESS

ASI OUT

S/N XXXXXXX

XX XX XX XX XX

MAC ADDRESS

ASI OUT

S/N XXXXXXX

XX XX XX XX XX

MAC ADDRESS

S/N XXXXXXX

XX XX XX XX XX

MAC ADDRESS

S/N XXXXXXX

XX XX XX XX XX

MAC ADDRESS

S/N XXXXXXX

XX XX XX XX XX

MAC ADDRESS

XX XX XX XX XX

Install HCS6100R
units in rack.

HCS6700

HCS6700

X PORT LINK

HCS6700

X PORT LINK

HCS6700

X PORT LINK

HCS6700

X PORT LINK

HCS6700

SERVICE
PORT

X PORT LINK

HCS6300

SERVICE

RESET

PORT

STATUS

X PORT LINK

RESET

STATUS

ASI OUT

ASI OUT

S/N XXXXXXX

MAC ADDRESS

S/N XXXXXXX

XX XX XX XX XX

MAC ADDRESS

XX XX XX XX XX

HCS6700

X-PORT Link

Service
Port

Reset

Status

ASI OUT

SN XXXXXXX

MAC ADDRESS

XX XX XX XX XX

HCS6700

SERVICE
PORT

ETHERNET

HCS6700

SERVICE

RESET

PORT

X PORT LINK

STATUS

RESET

STATUS

ASI OUT

ASI OUT

S/N XXXXXXX

MAC ADDR

S/N XXXXXXX

ESS

XX XX XX XX XX

MAC ADDRESS

XX XX XX XX XX

HCS6700

SERVICE
PORT

X PORT LINK

HCS6700

SERVICE

RESET

PORT

X PORT LINK

STATUS

RESET

STATUS

ASI OUT

ASI OUT

S/N XXXXXXX

MAC ADDRESS

S/N XXXXXXX

XX XX XX XX XX

MAC ADDRESS

XX XX XX XX XX

HCS6700

SERVIC

E

PORT

X PORT LINK

HCS6700

SERVICE

RESET

PORT

X PORT LINK

SERVICE

RESET

PORT

X PORT LINK

STATUS

SERVICE

RESET

PORT

RF OUT

STATUS

SERVICE

RESET

PORT

STATUS

SERVICE

RESET

PORT

ASI OUT

STATUS

SERVICE

RESET

PORT

ASI OUT

STATUS

RESET

ASI OUT

S/N XXXXXXX

MAC ADDRESS

XX XX XX XX XX

STATUS

ASI OUT

S/N XXXXXXX

MAC ADDRESS

ASI OUT

S/N XXXXXXX

XX XX XX XX XX

MAC ADDRESS

ASI OUT

S/N

XX XX XX XX XX

XXXXXXX
MAC ADDRESS

S/N XXXXXXX

XX XX XX XX XX

MAC ADDRESS

S/N XXXXXXX

XX XX XX XX XX

MAC ADDRESS

XX XX XX XX XX

12

SATELLITE IN

SATELLITE IN

SATELLITE IN

USB

S-VIDEO OUT

USB

S-VIDEO OUT

VIDEO OUT

VIDEO OUT

AUDIO OUT

AUDIO OUT

HDMI OUT

ETHERNET

HDMI OUT

PHONE JACK

ETHERNET

PHONE JACK

AC 100V-240V

50/60 Hz

AC 100V-240V

50/60 Hz

SATELLITE IN

SATELLITE IN

USB

S-VIDEO OUT

USB

S-VIDEO OUT

VIDEO OUT

VIDEO OUT

AUDIO OUT

AUDIO OUT

HDMI OUT

HDMI OUT

ETHERNET

PHONE JACK

ETHERNET

PHONE JACK

AC 100V-240V

50/60 Hz

AC 100V-240V

50/60 Hz

SATELLITE IN

USB

S-VIDEO OUT

USB

S-VIDEO OUT

VIDEO OUT

VIDEO OUT

AUDIO OUT

AUDIO OUT

HDMI OUT

HDMI OUT

ETHERNET

PHONE JACK

ETHERNET

PHONE JACK

Guide

Power

AC 100V-240V

50/60 Hz

AC 100V-240V

50/60 Hz

Disconnect Device

The AC mains plug is used
as the disconnect device.
The disconnect device must
remain readily operable.

Rack-mount Temperature Considerations
A. Elevated Operating Ambient

If installed in a closed or multi-unit rack assembly, the operating

ambient temperature of the rack environment may be greater than
room ambient. Therefore, consideration should be given to installing
the equipment in an environment compatible with the maximum
ambient temperature (Tma) specified by the manufacturer (see
“Specifications” information in this document).

(Continued on next page)

206-4114

(Continued from previous page)

Rack Installation (Cont.)

B. Reduced Air Flow
Installation of the equipment in a rack should be such that the

amount of air flow required for safe operation of the equipment is not
compromised. To ventilate the system normally and avoid overheat­ing, leave at least 1 inch (2.5 cm) on each side of the HCS6100R
unit. Do NOT stack other equipment on the top of the HCS6100R
unit.

C. Circuit Overloading
Consideration should be given to the connection of the equipment to

the supply circuit and the effect that overloading of the circuits might
have on overcurrent protection and supply wiring.

D. Reliable Earthing
Maintain reliable earthing of rack-mounted equipment. Particular

attention should be given to supply connections other than direct
connections to the branch circuit (e.g. use of power strips).

E. Mains Outlet Earthing
The apparatus with Class I construction must be connected to a

mains socket outlet with a protective earthing connection.

206-4114

Front View
of Rack Cabinet

1 inch

1 inch

13

Troubleshooting / Specifications

Troubleshooting

If you experience image freezes, audio freezes,
or a blank screen, refer to the installation manu­al for the receiver and/or transcoder card show­ing the problem.

You can also try the following:

1. If the problems persist, try unplugging the
power cord of the unit for 15 seconds, and
then plug it in again.

2. With the AC power cord unplugged, try
removing and then reinserting the CodePlus
transcoder card.

3. Check the CodePlus transcoder card plugged
into the HCS6100R; with AC power applied,
you should see LED activity on each card.

4. Check the exit vent area adjacent to the AC
power connector on the back panel. With AC
power applied, there should be a strong
airstream from the vent area.

Equipment Setup Review

• Make sure all connectors and connections are

tight and secure on all entertainment system
components.

• Check to make sure the device supplying the

signal to the transcoder card is functioning
properly.

Specifications

Dimensions

Height: 5.25 inches (133 mm)
Width: 19.0 inches (482.6 mm) (for EIA standard 19-inch rack mount)
Depth: 10.3 inches (262 mm)
Weight: 7.70 pounds (3.5 kgrms) rack-only weight

Environmental Storage Conditions
Temperature: -20° to 70° degrees Celsius

-4° to 158° degrees Fahrenheit
Humidity: 95% non-condensing

Environmental Operating Conditions

Temperature (Tma): 0° to 40° degrees Celsius
32° to 104° degrees Fahrenheit
Humidity: 95% non-condensing

Electrical

1. AC Input to Power Supply: 120V 3A 60Hz
Power Factor Corrected. Maximum Watts =180

2. Power Supply: +12V DC @ 15 Amps

Note: Design and specifications subject to change without prior notice.

14

206-4114

Document Revision History / Notes

Document Revision History

Date Description

December 2009 Revision A: New document
February 2010 Revision B: Feature card updates

Documentation is available online at: www.LGcommercial.com/products. From the Products page,
select Head End Systems, then CodePlus™ Transcoder Series, then the appropriate option for
Modular Systems, then HCS6100R. Click the Downloads & Images tab on the HCS6100R page,
and select the required document from the Downloads list.

Notes

206-4114

15

HCS6100R Card Frame with Power Supply Warranty

Broadcast Products Welcome to the LG family! We believe that you will be pleased with your new HCS6100R Card Frame with Power Supply.

Please read this warranty carefully, it is a “LIMITED WARRANTY” as defined under Federal Law. This warranty gives you
specific legal rights, and you may also have other rights that vary from state-to-state within the U.S.A.

LG’s RESPONSIBILITY

Warranty Term One year parts and labor from date of purchase or delivery date.

Parts New or remanufactured replacements for factory-defective parts may be used. Such replacement parts are warranted for

Warranty Service Warranty service is provided at LG. Customer pays for shipping charges to LG; LG pays for return shipping charges to

Not Covered This warranty covers manufacturing defects and does not cover installation, adjustment of customer controls, installation or

This warranty does not cover any missing or stolen access cards.

the remaining portion of the original warranty period.

return HCS6100R Card Frame with Power Supply to customer. Call 1-888-865-3026 for further information.

repair of antenna systems, cable converters or cable company-supplied equipment; it also does not cover damage due to
misuse, abuse, negligence, acts of God or other causes beyond the control of LG. Any alteration of the product after man­ufacture voids this warranty in its entirety.

THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND LG SHALL NOT BE
LIABLE FOR ANY CONSEQUENTIAL, INDIRECT, OR INCIDENTAL DAMAGES OF ANY KIND, INCLUDING LOST
REVENUES OR PROFITS IN CONNECTION WITH THIS PRODUCT. SOME STATES DO NOT ALLOW LIMITATIONS ON
HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.

OWNER’S RESPONSIBILITY

Effective Warranty Date Warranty begins on the date of delivery of the HCS6100R.

For your convenience, keep the dealer’s dated bill of sale or delivery ticket as evidence of the purchase date.

Installation Guide Read the Installation & Setup Guide carefully so that you will understand the operation of the HCS6100R Card Frame with

Antenna Reception problems caused by inadequate antenna or faulty antenna connections are the owner’s responsibility.

Warranty Service For warranty service information, call 1-888-865-3026. Parts and service labor that are LG’s responsibility (see above)

Power Supply and how to adjust the controls.

will be provided without charge. Other service is at the owner’s expense. If you have any problem in obtaining satisfactory
warranty service, call 1-888-865-3026.
You must provide the model number, serial number and date of purchase or date of original installation.

For Customer Support/Service, please call:

1-888-865-3026

www.LGcommercial.com

CodePlus is a trademark of LG Electronics U.S.A., Inc. All other trademarks or

registered trademarks are the property of their respective owners.

 Copyright 2010, LG Electronics U.S.A., Inc.

206-4114

Revision B
