BLUETOOTH® Stereo Headset
HBS-730 User Manual
to prevent any damage to, or misuse of the
HBS-730, please read all of the information
Any modications or changes to this manual due to
typographical errors or inaccuracies of stated information
shall only be made by LG Electronics Inc.
English
简体中文
繁體中文
Rev 2.0 TW
All rights reserved.
LG Electronics Inc., 2013
Note: For the best performance and
carefully prior to using the HBS-730.
LG Electronics
BLUETOOTH® Stereo Headset
HBS-730 User Manual
to prevent any damage to, or misuse of the
HBS-730, please read all of the information
Any modications or changes to this manual due to
typographical errors or inaccuracies of stated information
shall only be made by LG Electronics Inc.
English
All rights reserved.
LG Electronics Inc., 2013
Note: For the best performance and
carefully prior to using the HBS-730.
Description of parts
Power Switch
VOLUME UP Button
VOLUME DOWN Button
CALL Button /
LED Indicator
Microphone
Earphone (L)
REW Button
FF Button
PLAY / PAUSE Button
Earphone (R)
Charging Port
Included in the Package
Earbuds (2 Sets)
USB Charging cable
User Manual
Specication
Item Description
Bluetooth® specication 3.0 (Headset / Hands-Free / A2DP Proles)
Battery Battery 3.7V / 195mAh Li-Polymer
Standby time / Talk time Up to 500Hrs / Up to 15Hrs
Music play time Up to 10 Hrs
Charging time < 2.0Hrs
Operation temperature -10°C ~ 60°C
Dimension / Weight 135.6mm(W) X 167.3mm(L) X 16.9mm(T) / 32g
ENG
1
How to Use
Pairing
ENG
- Before using the headset for the rst time, you must pair it with a Bluetooth-enabled
handset.
- To pair your headset with an additional handset, the headset must be placed in
Pairing Mode.
- There are 2 Pairing Mode Methods with the HBS-730.
Easy Pairing (First Time Pairing)
1. Move the power switch to the ‘ON’ side to turn on the HBS-730. When the headset
enters Pairing Mode, the LED indicator will show a solid blue light.
2. Using your handset, nd the Bluetooth Menu and “search for” or “add” new
devices.
• Select “LG HBS730” from the list of devices and pair it with your handset.
3. If asked for the Pass/PIN code please enter “0000” (4 Zeros).
* Note : If your handset supports Secure Simple Pairing (SSP), you will not need to
enter Pass/PIN code.
• Once pairing has completed successfully, you will hear “Your headset paired.”.
4. Some handsets might ask for permission to access the phone’s contact list. If you
receive a message from your handset, please select “OK” or “Allow access”
• The HBS-730 will automatically turn off if not paired within 3 minutes.
Manual Pairing (Pairing with another phone or re-pairing)
• With the Power off, press the CALL button and move the power switch to the ‘ON’
side at the same time for 1 second.
• When the headset enters Pairing Mode, the LED indicator will show a solid blue
light. After the procedure repeat Easy Pairing steps 2 through 4.
Multi-connection
Advanced Multipoint
The HBS-730 is capable of having two devices connected to the headset at the same
time. This will give you the freedom of using call waiting between calls on both of your
connected phones.
2
How to Use
Connection
- Pair the headset with one of your Bluetooth-enabled handsets. (per the pairing
instructions on page 2).
- Turn off the headset.
- With the Power off, press the CALL button and move the power switch to the ‘ON’
side at the same time for 1 second to enter Manual Pairing mode.
- Now, pair and connect the headset with your other Bluetooth-enabled handset. (this
will be your primary handset).
- Once this handset is paired and connected, go back and connect the originally
paired handset to the headset. This will now be your secondary handset.
* NOTE: When the HBS-730 is connected to two handsets at the same
time(Multipoint), the headset calling functions will work with the primary handset.
* NOTE: In case of failure to connect to the primary phone through Easy Pairing,
HBS-730 will enter pairing mode.
Auto Reconnect
- If the HBS-730 is turned off (either accidentally or intentionally) while connected to
a handset, the headset and handset will disconnect. The headset and handset will
automatically reconnect when the HBS-730 is turned back on while in range.
- Secondary handset need to be connected via selecting “LG HBS730” from the list of
devices at Bluetooth menu.
Out of range
- If the paired devices are separated by a range of 10 meters(33 feet) or more, the
headset and handset will disconnect and HBS-730 will vibrate to alert.
- If the headset and handset do not automatically reconnect when they are back
within the required range, briey press the CALL button on the HBS-730 to
reconnect manually.
* It is possible to use these functions only when your handset supports them. For
further information about using these features, please consult your handset’s user
manual.
- While in multi-connection and streaming, non-streaming paired device which is out
of range will be disconnected and HBS-730 will alert once and not try to reconnect.
Controls
Power on / Power off
- Move the power switch to the ‘ON’ or ‘OFF’ side.
ENG
3
How to Use
Volume Control
- Briey press the VOLUME button.
ENG
Charging
- When the charger is connected, with the power on or off, the headset will turn off.
- While charging, the LED indicator will show a solid red light.
- When charging is complete, the LED indicator will turn off.
Battery status check
- Press and hold the VOLUME DOWN button for 1 second.
- There are 3 levels of battery status
Battery status High Medium Low
Voice Prompt Battery High Battery Medium Battery Low
- HBS-730 battery status indicator will appear on the iPhone screen.
Low battery
- An announcement will be made once every 2 minutes.
- If the battery is not charged, the headset will turn off.
Answering a call / Ending a call
- When there is an incoming call, the headset will ring and vibrate.
- Briey press the VOLUME DOWN button to stop vibration.
- Briey press the CALL button.
Last number redial
- Press and hold the CALL button for 1second to activate “Last Number Redial”.
The headset will beep, and call the last number dialed.
Making a call
- If you ma ke a call from the handset, the call will (subject to phone settings)
automatically transfer to the headset. If the call is not automatically transferred, you
can manually transfer the call by press and hold VOLUME UP button for 3 seconds.
Voice dialing
- Briey press the CALL button to activate “Voice Command”.
Note: If the handset does not support Voice Dialing, it is possible that performing
this action will activate Last Number Redial.
Transferring a call
- While on a call on your handset, press and hold VOLUME UP button for 3 seconds
to transfer the audio either from headset to handset or from handset to headset.
Call waiting
- Answer a second call without hanging up the rst call by pressing the CALL button
for 1 second (you will hear a beep). Press the CALL button for 1second to turn to
the original call.
4
How to Use
- Briey press the CALL button to terminate the active call or both calls at once.
(subject to handset’s support)
Call Reject
- Press the CALL button for 1second when the handset rings.
Mic Mute
- Press and hold the VOLUME UP and VOLUME DOWN buttons simultaneously for 1
second to mute/unmute the Mic during conversation.
Audio streaming
- PLAY : Briey press the PLAY/PAUSE Button.
- PAUSE : Briey press the PLAY/PAUSE button.
- STOP : Press and hold the PLAY/PAUSE button.
- NEXT SONG : Briey press the FF button.
- PREVIOUS SONG : Briey press the REW button.
- FAST FORWARD : Press and hold the FF button.
- REWIND : Press and hold the REW button.
Equalizer
- While playing music, press and hold VOLUME UP and VOLUME DOWN buttons
simultaneously for 1 second to switch between EQ’s (Bass Boost(Default) g
Normal g Treble Boost).
- EQ is not changed if your handset supports aptX® code and is enabled.
- The bass coming from the speakers can vary as a result of the size of the Earbud
that is being used.
®
aptX
- HBS-730 features aptX® technology that ensures audio content transmitted over
Bluetooth is instant and crystal-clear.
- aptX® is automatically enabled as long as the source device supports it.
SMS Reader
The HBS-730 Bluetooth headset supports SMS reading on
Android TM based devices.
In Google Play™ Store search for the LG ‘BT Reader’
application and install on your device to use this function.
* The 2D barcode shown below helps you download the LG
‘BT Reader’ application from Google Play™ Store. Google
Play is a trademark of Google, Inc.
ENG
5
LED indication
Function HBS-730 Status Action
ENG
Power on The blue LED light ickers 4 times.
Power off
Pairing mode The blue LED light stays on.
Operating
Headset / hands-free
prole connected
Call connected
Charging The red LED stays on.
Charging
Charging complete
The blue LED light ickers 4 times and then
turns off.
The blue LED light ickers 2 times every 5
seconds.
The blue LED light ickers 2 times every 5
seconds.
LED turns off.
Troubleshooting
Issue Possible problem Resolution
Check whether the battery
of the HBS-730 is fully
charged.
Check whether the
handset supports the
headset or hands-free
Bluetooth proles.
Check whether the battery
of the HBS-730 is low.
Check and make sure the
headset is on.
Check and make sure
the headset is placed in
pairing mode.
Check the speaker
volume.
6
Does not turn on
Unable to
communicate with
the LG Bluetooth®
Headset HBS-730
Unable to pair the
HBS-730 with the
Bluetooth® device
Low sound
(speaker)
Charge the battery.
Determine whether your
handset supports the headset
or hands-free Bluetooth
proles.
Charge the battery.
Slide the power switch to
the ‘ON’ side to turn on the
headset.
With the Power off, press the
CALL button and move the
power switch to the ‘ON’ side
at the same time for 1 second
to manually place the headset
in pairing mode.
lncrease the volume level.
Precautions
Do not drop the unit from high places.
Do not modify, repair, or take apart.
Do not expose directly to water, alcohol, benzene, etc. for cleaning.
Do not expose directly to ammables.
Do not place or keep the unit near ammables.
Keep unit away from humidity & dust.
Do not place heavy objects on the unit.
Only use the headset with an original LG charger, otherwise it may be damaged.
• Changes or modications not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment.
• There is a risk of explosion if the battery is replaced by an incorrect type.
• Dispose of used batteries according to the instructions.
• The neck strap is made of a shape memory alloy. However, bending the neck strap
repeatedly is not recommended.
Declaration of Conrmation
FCC NOTICE TO USERS :
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
IMPORTANT NOTE :
To comply with the FCC RF exposure compliance requirements, no change to the
antenna or the device is permitted. Any change to the antenna or the device could result
in the device exceeding the RF exposure requirements and void user’s authority to
operate the device.
CE NOTICE TO USERS :
Hereby, LG Electronics Inc. declares that this HBS-730 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
1177
FCC ID: BEJHBS730
ENG
7
Additional Information
1. Radio frequency exposure
This Bluetooth® Headset, HBS-730, is a radio transmitter and receiver. When in operation,
it communicates with a Bluetooth® equipped mobile device by receiving and transmitting
ENG
radio frequency (RF) electromagnetic elds (microwaves) in the frequency range 2.4 to
2.4835 GHz.
Your Bluetooth® Headset is designed to operate in compliance with the RF exposure
guidelines and limits set by national authorities and international health agencies when used
any compatible LG Electronics mobile phone.
2. Potentially explosive atmosphere
Turn off your electronic device when in any area with a potentially explosive atmosphere. It
is rare, but your electronic device could generate sparks. Sparks in such areas could cause
an explosion or re resulting in bodily injury or even death. Areas with a potentially explosive
atmosphere are often, but not always, clearly marked.
3. Battery information
A rechargeable battery has a long service life if treated properly. A new battery or one that
has not been used for a long period of time could have reduced capacity the rst few times
it is used. Do not expose the battery to extreme temperatures, never above +60°(+140°F) or
under -20°(-4°F). For maximum battery capacity, use the battery in room temperature. If the
battery is used in low temperatures, the battery capacity will be reduced. The battery can
only be charged in temperatures between +10°(+50°F) and +45°(+113°F). For your safety,
do not remove the battery incorperated in the product.
If you need to replace the battery, take it to the nearest authorised LG Electronics service
point or dealer for assistance.
4. Recycling the battery in your Bluetooth® Headset
The battery in your Bluetooth® Headset must be disposed of properly and should never be
placed in municipal waste. The LG Electronics service partner removing battery will dispose
of it according to local regulations.
5. Conditions
- The warranty is valid only if the original receipt issued to the original purchaser by the
dealer, specifying the date of purchase and serial number, is presented with the product
to be repaired or replaced. LG Electronics reserves the right to refuse warranty service if
this information has been removed or changed after the original purchase of the product
from the dealer.
- If LG Electronics repairs or replaces the product, the repaired or replaced product shall
be warranted for the remaining time of the original warranty period or for ninety (90)
days from the date of repair, whichever is longer. Repair or replacement may involve
the use of functionally equivalent reconditioned units. Replaced parts or components
will become the property of LG Electronics.
8
- This Warranty does not cover any failure of the product due to normal wear and tear, or
due to misuse, including but not limited to use in other than the normal and customary
manner, in accordance with instructions for use and maintenance of the product. Nor
does this warranty cover any failure of the product due to accident, modication or
adjustment, acts of God or damage resulting from liquid.
- This warranty does not cover product failures due to improper repair installations,
modications or service performed by a non-LG Electronics authorized person.
Tampering with any of the seals on the product will void the warranty.
Limited Warranty
SUBJECT TO THE CONDITIONS OF THIS LIMITED WARRANTY, LG ELECTRONICS
WARRANTS THIS PRODUCT TO BE FREE FROM DEFECTS IN DESIGN,
MATERIAL AND WORKMANSHIP AT THE TIME OF ITS ORIGINAL PURCHASE BY
A CONSUMER, AND FOR A SUBSEQUENT PERIOD OF ONE (1) YEAR. SHOULD
YOUR PRODUCT NEED WARRANTY SERVICE, PLEASE RETURN IT TO THE
DEALER FROM WHOM IT WAS PURCHASED OR CONTACT YOUR LOCAL LG
ELECTRONICS CONTACT CENTER TO GET FURTHER INFORMATION.
Important safety information
Avoiding hearing damage
Permanent hearing loss may occur if you use your Handsfree car kit at a high volume.
Set the volume to a safe level. You can adapt over time to a higher volume of sound
that may sound normal but can be damaging to your hearing.
If you experience ringing in your ears or mufed speech, stop listening and have your
hearing checked. The louder the volume, the less time is required before your hearing
could be affected. Hearing experts suggest that to protect your hearing:
• Limit the amount of time you use Headset at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
Please refer to your handset user guide for more information on how to adjust listening
levels on your handset.
Using Headset safely
Use of Headset to listen to music while operating a vehicle is not recommended and
is illegal in some areas. Be careful and attentive while driving. Stop using this device if
you nd it disruptive or distracting while operating any type of vehicle or performing any
other activity that requires your full attention.
ENG
9
Low-power RF Precautions
Administrative Regulations on Low Power Radio Waves Radiated Devices warning:
Without permission granted by the NCC, any company, enterprise, or user is not allowed
to change frequency, enhance transmitting power or alter original characteristic as well as
ENG
performance to a approved low power radio-frequency devices.
The low power radio-frequency devices shall not inuence aircraft security and interfere
legal communications; If found, the user shall cease operating immediately until no
interference is achieved.
The said legal communications means radio communications is operated in compliance
with the Telecommunications Act.
The low power radio-frequency devices must be susceptible with the interference from legal
communications or ISM radio wave radiated devices.
For Reducing RF Inuence, Use Properly.
10
Loading...
