LG 32PC5RVUB User Manual

Please read this manual carefully and completely before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this information to your dealer when you require service.

P/NO : MFL36546205(0707-REV00)

Printed in Korea

PLASMA TV OWNER’S MANUAL

32PC5RV

WARNING / CAUTION

To prevent fire or shock hazards, do not expose this product to rain or moisture.

FCC NOTICE

Class B digital device

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

CAUTION

Do not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized modification could void the user’s authority to operate this product

The lightning flash with arrowhead symbol, within an equilateral triangle,

is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equi-

lateral triangle is intended to alert the

user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the

appliance.

TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK). NO

USER SERVICEABLE PARTS INSIDE. REFER TO

QUALIFIED SERVICE PERSONNEL.

WARNING/CAUTION

TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRO-

DUCT TO RAIN OR MOISTURE.

NOTE TO CABLE/TV INSTALLER

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable

entry

as practical.

WARNING

IMPORTANT SAFETY INSTRUCTIONS

Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions.

Do not use this apparatus near water.

Clean only with dry cloth.

Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers)that produce heat.

Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong, The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

Important safety instructions shall be provided with each apparatus. This information shall be given in a separate booklet or sheet, or be located before any operating instructions in an instruction for installation for

use and supplied with the apparatus. This information shall be given in a language acceptable to the country where the apparatus is intended to

be used. The important safety instructions shall be entitled “Important Safety Instructions”. The following safety

instructions shall be included where applicable, and, when used, shall be verbatim as follows. Additional safety information may be included by adding statements after the end of the following safety instruction list. At the manufacturer’s option, a picture or drawing that illustrates the intent of a specific safety instruction may be placed immediately adjacent to that safety instruction :

ner M

anual

IMPORTANT SAFETY INSTRUCTIONS

WARNING

Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

Only use attachments/accessories specified by the manufacturer.

Unplug this apparatus when unused for long periods of time.

Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

Never touch this apparatus or antenna during a thunder or lighting storm.

Do not allow a impact shock or any objects to fall into the product, and do not drop onto the screen with something. (You may be injured or the product can be damaged.)

Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as powersupply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has exposed to rain or moisture, does not operate normally, or has been dropped.

Owner M

anual

WARNING

CAUTION concerning the Power Cord : Most appliances recommend they be placed upon a dedicated circuit; that is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner's manual to be certain.

Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized servicer. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance.

Outdoor Use Marking : WARNING - To Reduce The Risk Of Fire Or

Electric Shock, Do Not Expose This Appliance To Rain Or Moisture

Wet Location Marking : Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on or over apparatus.

GROUNDING

Ensure that you connect the earth ground wire to prevent possible electric shock. If grounding methods are not possible, have a qualified electrician install a separate circuit breaker.

Do not try to ground the unit by connecting it to telephone wires, lightening rods, or gas pipes.

DISCONNECTING DEVICE FROM MAINS Main plug is the disconnecting device. The

plug must remain readily operable.

er M

Power Supply

Short-circuit Breaker

r M

CONTENTS

WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

FEATURES OF THIS TV

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

PREPARATION

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . 8

Back Panel Information . . . . . . . . . . . . . . . . . . . . 9

Stand Installation . . . . . . . . . . . . . . . . . . . . . . . . .10

Back Cover for Wire Arrangement . . . . . . . . . . . 10

Attaching the TV to a Wall . . . . . . . . . . . . . . . . . 11

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Antenna or Cable connection . . . . . . . . . . . . . . . 13

EXTERNAL EQUIPMENT SETUP

HD Receiver Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

VCR Setup

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Other A/V Source Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

PC Setup

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

- Screen Setup For PC Mode . . . . . . . . . . . . . 24

AV Out Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

External Stereo

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

WATCHING TV / SETUP CONTROL

Turning on the TV . . . . . . . . . . . . . . . . . . . . . . . . 29

On Screen Menus Language Selection

. . . . . . . . .30

Volume Adjustment . . . . . . . . . . . . . . . . . . . . . . 30

Channel Adjustment . . . . . . . . . . . . . . . . . . . . . 30

On Screen Menus Selection and Adjustment . . 31

Remote Control Functions . . . . . . . . . . . . . . . . . .32

Channel Setup . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Auto tuning: Channel Search . . . . . . . . . . . 34

- Manual tuning: Adding/Deleting Channels .35

Fine tuning Adjustment . . . . . . . . . . . . . . . . . . .36

Favorite Channels Setup

. . . . . . . . . . . . . . . . . .37

SIMPLINK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

PICTURE CONTROL

PIP/Double Window . . . . . . . . . . . . . . . . . . . . . . .41

- Watching PIP/Double Window . . . . . . . . . 41

TV Program Selection for PIP

. . . . . . . . . . . 41

Selecting an Input Signal Source for the PIP/

Double Window

. . . . . . . . . . . . . . . . . .42

Sub Picture Size Adjustment (PIP mode only)

Moving the Sub Picture (PIP mode only)

. .42

Picture Mode Control . . . . . . . . . . . . . . . . . . . . . 43

Manual Picture Control (Picture mode-User option) . . 44

Color Temperature Control . . . . . . . . . . . . . . . .45

Manual

Color Temperature Control (User option) 46

XD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Advanced - Cinema Mode Setup . . . . . . . . . . . . 48

Advanced - Black Level . . . . . . . . . . . . . . . . . . . . 49

Aspect Ratio Control . . . . . . . . . . . . . . . . . . . . . 50

Picture Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

XD Demo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

AUDIO CONTROL

Sound Mode Control . . . . . . . . . . . . . . . . . . . . . 53

Sound Control Adjustment (User option) . . . . . 54

Auto Volume Leveler . . . . . . . . . . . . . . . . . . . . . . . . . 55

Balance Adjustment . . . . . . . . . . . . . . . . . . . . . . .56

TV Speakers On/Off Setup . . . . . . . . . . . . . . . . 57

Stereo/SAP Broadcast Setup . . . . . . . . . . . . . . . 58

TIME SETTING

Clock Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

On/Off Time Setup . . . . . . . . . . . . . . . . . . . . . . .60

Sleep Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

Auto Sleep . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

OPTION CONTROL

Key Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

Closed Captions . . . . . . . . . . . . . . . . . . . . . . . . 64

ISM (Image Sticking Minimization) Method . . .65 Low Power

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Factory Reset

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

APPENDIX

Troubleshooting Checklist

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Maintenance

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Product Specifications

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

FEATURES OF THIS TV

What is a Plasma TV ?

Using plasma is the best way to achieve flat panel displays with excellent image quality and large screen sizes that are easily viewable. The Plasma TV can be thought of as a descendant of the neon lamp and or a series of fluorescent lamps.

How does it work?

Plasma TV is an array of cells, known as pixels, which are comprised of three sub-pixels, corresponding to the colors red, green, and blue. Gas in a plasma state is used to react with phosphors in each sub-pixel to produce colored light (red, green, or blue). These phosphors are the same types used in Cathode Ray Tube (CRT) devices such as televisions and common computer monitors.

Plasma TV offers a rich, dynamic display because each sub-pixel is individually controlled by advanced electronics to produce over 16 million different colors. This means that you get perfect images that are easily viewable in a display that is fewer than five inches thick.

160° - Wide angle range of vision

Your flat panel plasma screen offers an exceptionally broad viewing angle of over 160 degrees. This means that the display is clear and visible to viewers anywhere in the room.

Wide Screen

The wide screen offers a theater-like experience in your own home.

Multimedia

Connect your plasma display to a PC and use it for conferencing, games, and Internet browsing. The Picture-inPicture feature allows you to view your PC and video images simultaneously.

Versatile

The light weight and thin size makes it easy to install your plasma display in a variety of locations where conventional TVs do not fit.

The Plasma TV Manufacturing Process: a few minute colored dots may be present on the Plasma TV screen

The Plasma TV is composed of 0.9 to 2.2 million cells. A few cell defects will normally occur in the Plasma TV manufacturing process. Several tiny, minute colored dots visible on the screen should be acceptable. This also occurs in other Plasma TV manufacturers' products. The tiny dots appearing does not mean that this Plasma TV is defective. Thus a few cell defects are not sufficient cause for the Plasma TV to be exchanged or returned. Our production technology minimizes these cell defects during the manufacture and operation of this product.

PREPARATION

ACCESSORIES

Ensure that the following accessories are included with your product. If an accessory is missing, please contact the dealer where you purchased the product.

Manual de Usuario

1.5V 1.5V

Owner’s Manual Batteries

ENTER

VOL

FAV

REVIEW

PIP INPUT

INPUT

MUTE

EXIT

RATIO

POWER

CH EDIT

PIP CH - PIP CH +

SLEEP

CAPTION

MTS

SIZE

POSITION

PIP

Remote Control Power Cord

2- TV Brackets,

2- Wall Brackets

2-Bolts

Polishing cloth

Polish the screen with the cloth.

* Slightly wipe stained spot on the exterior only with the cleans-

ing cloths for the product exterior if there is stain or fingerprint on surface of the exterior.

* Do not wipe roughly when removing stain. Please be cautious

of that excessive power may cause scratch or discoloration.

4-Bolts for stand assembly

(Refer to p.10)

Holder

(Refer to p.11)

Cover

PREPARATION

FRONT PANEL CONTROLS

PREPARATION

■

This is a simplified representation of the front panel. Here shown may be somewhat different from your TV.

■

If your product has a protection tape attached, remove the tape and then wipe the product with a cloth.

(If a polishing cloth is included with your product, use it.)

VOL

INPUT

ENTER

Power Standby Indicator

Illuminates red in standby mode. When the TV is turned on, the indicator blinks green and then illuminates green before the picture is displayed.

Remote Control Sensor

POWER Button

INPUT Button

MENU Button

ENTER Button

VOLUME (

FF,GG

)Buttons

CHANNEL (

EE,DD

)Buttons

PREPARATION

BACK PANEL INFORMATION

. Component Input 1/2

Connect a component video/audio device to these jacks.

Variable Output

Connect an external amplifier or add a subwoofer to your surround sound system.

Audio In (RGB/DVI)

Connect the monitor output from a PC (only Audio) to the appropriate input port.

AV OUT

Connect second TV or monitor to the AV OUT socket on the set

AV IN

Connect audio/video output from an external device to these jacks.

HDMI IN 1/2

Connect a HDMI signal to HDMI IN. Or DVI(VIDEO)signal to HDMI/DVI port with DVI

to HDMI cable.

RGB PC Input

Connect the monitor output from a PC to the appropriate input port.

Antenna In

Connect over-the-air signals to this jack.

Power Cord Socket

This TV operates on an AC power. The voltage is indicated on the Specifications page. Never attempt to operate the TV on DC power.

PREPARATION

STAND INSTALLATION

Carefully place the product screen side down on a cushioned surface that will protect product and screen from damage.

Assemble the product stand with the product as shown.

Install the 4 bolts securely, in the back of the product in the holes provided.

BACK COVER FOR WIRE ARRANGEMENT

Arrange the cables as shown picture.

ATTACHING THE TV TO A WALL

PREPARATION

■

Set it up close to the wall so the set doesn’t fall over when it is pushed backwards.

■

The instructions shown below is a safer way to set up the set, which is to fix it on the wall so the set doesn’t fall over when it is pulled in the forward direction. It will prevent the set from falling for-ward and hurting people. It will also prevent the set from damage caused by fall. Please make sure that children don’t climb on or hang from the set.

Use a sturdy rope (not provided as parts of the set, must purchase separately) to tie the set. It is safer to tie the rope so it becomes horizontal between the wall and the set.

Use the eye-bolts or set brackets/bolts to fix the set to the wall as shown in the picture. (If your set has the bolts in the eye-bolts or set brackets/bolts position before inserting the eye-bolts or set brackets/bolts, loosen the bolts.) * Insert the eye-bolts or set brackets/bolts and

tighten them securely in the upper holes.

Secure the wall brackets with the bolts (not provided as parts of the set, must purchase separately) on the wall. Match the height of the bracket that is mounted on the wall.

NOTE

When moving the set to another place undo the ropes first.

Use a set holder or a cabinet that is big and strong enough for the size and weight of the set.

To use the set safely make sure that the height of the bracket that is mounted on the wall is same as that of the set.

POEWR CORD ARRANGEMENT

After connecting the power cord to the AC input terminal, remove the bolt at the hole on the back cover and fix the power cord at the rear side of the TV by using the bracket for fixing the power cord.

PREPARATION

Desktop Pedestal Installation

For proper ventilation, allow a clearance of 4" on each side and from the wall.

Wall Mount: Horizontal installation

For proper ventilation, allow a clearance of 4" on each side and from the wall. Detailed installation instructions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation and Setup Guide.

GROUNDING

Ensure that you connect the earth ground wire to prevent possible electric shock. If grounding methods are not possible, have a qualified electrician install a separate circuit breaker. Do not try to ground the unit by connecting it to telephone wires, lightening rods, or gas pipes.

Power

Supply

Short-circuit

Breaker

■

The TV can be installed in various ways such as on a wall, or on a desktop etc.

■

The TV is designed to be mounted horizontally.

4 inches

INSTALLATION

PREPARATION

ANTENNA OR CABLE CONNECTION

Wall Antenna Socket or Outdoor Antenna without a Cable Box Connections. For optimum picture quality, adjust antenna direction if needed.

Multi-family Dwellings/Apartments (Connect to wall antenna socket)

Single-family Dwellings /Houses (Connect to wall jack for outdoor antenna)

Outdoor Antenna (VHF, UHF)

Wall Antenna Socket

RF Coaxial Wire (75 ohm)

Bronze Wire

Be careful not to bend the bronze wire when connecting the antenna.

The TV will let you know when the analog and cable scans are complete.

NOTE

Antenna

UHF

Signal Amplifier

VHF

■

To improve the picture quality in a poor signal area, please purchase a signal amplifier and install properly.

■

If the antenna needs to be split for two TV’s, install a 2-Way Signal Splitter.

■

If the antenna is not installed properly, contact your dealer for assistance.

PREPARATION

EXTERNAL EQUIPMENT SETUP

HD RECEIVER SETUP

Y L RPBP

When connecting with a component cable

1. How to connect

Connect the video outputs (Y, PB, PR

)

of the digital set

top box to the

CCOO MMPPOONNEENNTT IINN VVIIDDEEOO 11

jacks

on the set. Match the jack colors (Y = green, P

B = blue, and PR = red).

Connect the audio output of the digital set-top box to the

CCOO MMPPOONNEENNTT IINN AAUUDDIIOO 11

jacks on the set.

2. How to use

■

Turn on the digital set-top box. (

Refer to the owner’s manual for the digital set-top box.

)

■

Select

CCOO MMPPOONNEENNTT 11

input source with using the

IINNPP UUTT

button on the remote control.

■

If connected to

CCOO MMPPOONNEENNTT IINN22

input, select

CCOO MMPPOONNEENNTT 22

input source.

Signal

480i

480p/720p

10 8 0 i

Component 1/2

Yes

HDMI1/DVI,

HDMI2

Yes

1 2

■

To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment.

EXTERNAL EQUIPMENT SETUP

When connecting with a HDMI cable

Connect the digital set-top box to

HHDDMMII IINN 11((DD VVII ))

HHDDMMII IINN 22

jack on the set.

No separated audio connection is necessary.

1. How to connect

2. How to use

■

Turn on the digital set-top box. (

Refer to the owner’s manual for the digital set-top box.

)

■

Select

HHDDMMII11

HHDDMMII22

input source with using the

IINNPPUUTT

button on the remote control.

HD M I-DTV OUTPUT

TV can receive the video and audio signal simultaneously with using a HDMI cable.

NOTE

Resolution

720x480

1280x720

1920x1080i

Supported Display Resolution (HDMI-DTV mode)

Horizontal Vertical

Frequency(KHz) Frequency(Hz)

31.47 59.94

31.50 60.00

44.96 59.94

45.00 60.00

33.72 59.94

33.75 60.00

EXTERNAL EQUIPMENT SETUP

When connecting with a HDMI to DVI cable

L R

DVI-DTV OUTPUT

Connect the DVI output of the digital set-top box to the HHDDMMII IINN 11((DDVVII ))

jack on the set.

Connect the audio output of the digital set-top box to the

AAUUDDII OO((RRGGBB//DDVVII

))

jack on the set.

1. How to connect

2. How to use

■

Turn on the digital set-top box. (Refer to the owner’s manual for the digital set-top box.

)

■

Select

HHDDMMII11

input source with using the

IINNPPUUTT

button

on the remote control.

EXTERNAL EQUIPMENT SETUP

DVD SETUP

When connecting with a component cable

Y L RPBP

Component Input ports

To get better picture quality, connect a DVD player to the component input ports as shown below.

Component ports on the TV

YPB PR

Video output ports

on DVD player

B-Y

R-Y

Connect the video outputs (Y, PB, PR

)

of the DVD to

the

CCOO MMPPOONNEENNTT IINN VVIIDD EE OO11

jacks on the set.

Match the jack colors (

Y = green, P

B = blue, and PR = red

)

Connect the audio outputs of the DVD to the CCOO MMPPOONNEENNTT IINN AAUUDDII OO11

jacks on the set.

1. How to connect

2. How to use

■

Turn on the DVD player, insert a DVD.

■

Select

CCOO MMPPOONNEENNTT 11

input source with using the

IINNPPUUTT

button on the remote control.

■

If connected to

CCOO MMPPOONNEENNTT IINN 22

input, select

CC OOMM--

PPOONNEE NN TT 22

input source.

■

Refer to the DVD player's manual for operating instructions.

1 2

EXTERNAL EQUIPMENT SETUP

HDMI-DVD OUT PUT

When connecting HDMI cable

Connect the HDMI output of the DVD to the

HHDDMMII

IINN 11((DD VVII ))

HHDDMMII IINN 22

jack on the set.

No separated audio connection is necessary.

1. How to connect

2. How to use

■

Select

HHDDMMII11 orHHDDMMII22

input source with using the

IINNPPUUTT

button on the remote control.

■

Refer to the DVD player's manual for operating instructions.

TV can receive the video and audio signal simultaneously with using a HDMI cable.

NOTE

When connecting with a RCA cable

L/MONO

AUDIO

VIDEO

L R

S- VIDE OVI DE O

OUT P UT SWITCH

AN T IN

AN T OUT

Connect the

AAUUDDII OO/VVIIDDEE OO

jacks between TV and VCR. Match the jack colors (Video = yellow, Audio Left = white, and Audio Right = red)

1. How to connect

2. How to use

■

Select

AAVV II NN

input source with using the

IINNPPUUTT

button

on the remote control.

■

Turn on the DVD player, insert a DVD.

■

Refer to the DVD player's manual for operating instructions.

If you have a mono VCR, connect the audio cable from the VCR to the

AAUUDDII OO

LL //MMOO NN OO

jack of the set.

NOTE

EXTERNAL EQUIPMENT SETUP

VCR SETUP

When connecting with an antenna

■

To avoid picture noise (interference), leave an adequate distance between the VCR and TV

■

If the 4:3 picture format is used; the fixed images on the sides of the screen may remain visible on the screen. This phenomenon is common to all manufactures and in consequence the manufactures warranty does not cover the product bearing this phenomenon.

L/MONOL/MONO

AUDIOAUDIO

VIVIDEO

L R

S- VIDE O VIDE O

OUT P UT

SWITCH

AN T IN

AN T OUT

Wall Jack

Antenna

Connect the RF antenna out socket of the VCR to the

AAnntt eennnnaa

socket on the set.

Connect the antenna cable to the RF antenna in socket of the VCR.

1. How to connect

■

Set VCR output switch to 3 or 4 and then tune TV to the same channel number.

■

Insert a video tape into the VCR and press PLAY on the VCR. (Refer to the VCR owner’s manual.

)

2. How to use

EXTERNAL EQUIPMENT SETUP

When connecting with a RCA cable

L/MONO

AUDIO

VIDEO

L R

S- VIDE OVI DE O

OUT P UT SWITCH

AN T IN

AN T OUT

Connect the

AAUUDDII OO/VVIIDDEE OO

jacks between TV and VCR. Match the jack colors (Video = yellow, Audio Left = white, and Audio Right = red)

1. How to connect

2. How to use

■

Insert a video tape into the VCR and press PLAY on the VCR. (Refer to the VCR owner’s manual.

)

■

Select

AAVV11

input source with using the

IINNPPUUTT

but-

ton on the remote control.

If you have a mono VCR, connect the audio cable from the VCR to the

AAUUDDII OO

LL //MMOO NN OO

jack of the set.

NOTE

+ 51 hidden pages
