Lenovo Tab E10 User Guide

Lenovo Tab E10

User Guide

Lenovo TB -X104F
Lenovo TB -X104F1
Lenovo TB -X104L
Lenovo TB -X104X

All information labeled with * in this guide refers only to the WLAN+LTE model (Lenovo
TB-X104L/Lenovo TB -X104X).

Basics

Before using this information and the product it supports, be sure to read the following:

Safety, Warranty & Quick Start Guide
Regulatory Notice

"Important safety and handling information" in "Appendix".
The Safety, Warranty & Quick Start Guide and the Regulatory Notice are available on the website
at http://support.lenovo.com.

Note: All pictures and illustrations in this document are for your reference only and may
differ from the final product.

Lenovo Help

Looking for help ? The Lenovo Help app can offer you support for getting direct access to Lenovo's
web assistance and forums*, frequent Q&A*, system upgrades*, hardware function tests, warranty
status checks*, service requests**, and repair status**.

Note:
* requires data network ac cess.
** is not available in some countries.

You have two ways to get this app:

Search for and download the app from Google Play.

Scan the following QR code wi th a Lenovo Android device.

Technical specifications

Model Lenovo TB-X104F/Lenovo TB- X104F1 Lenovo TB-X104L/Lenovo TB-X104X
CPU
Battery 4850mAh 4850mAh

Wireless
communication

Note: Lenovo TB -X104L/Lenovo TB- X104X supports LTE Bands 1 , 2, 3, 5, 7, 8, 20, 38, 40, but
in some countries LTE is not supported. To know if your device works with LTE networks in
your country, contact your carrier.

Qualcomm

Bluetooth 4.2;
WLAN 802.11 b/g/n; 2.4GHz; GPS

®Snapdragon™210 Qualcomm®Snapdragon™210

Bluetooth 4.2;
WLAN 802.11 b/g/n; 2.4GHz;
GPS/A-GPS;
FDD-LTE/TDD-LTE/UMTS/GSM

Home screen

The home screen is the starting point for using your device. For your convenience, the home
screen is already set up with some useful apps and widgets.

Note: Your device's features and the home screen may be different depending on your
location, language, carrier, and device model.

You can customize your home screen at any time.

Home screen

On the first home screen, there is a Google Search bar and some useful apps.

Preview screen

Press and hold anywhere on the home screen except the icons.

At the bottom of the screen are WALLPAPERS, WIDGETS and HOME SETTINGS .

Add a widget to a home screen

Tap

drag it to where you want to place it, and release.

Change the wallpapers

Press and hold anywhere on the home screen except the icons, select WALLPAPERS at the

bottom of the screen, and then choose your preferred wallpaper.

Go to Settings > Display > Advanced > Wallpaper and choose your preferred wallpaper.

Move an app to another screen

Press and hold an app that you want to move, drag it to where you want to place it, then

release.

Uninstall an app

1. Press and hold the app that you wan t to uninstall.

2. Drag to

Note: Some of the system apps cannot be uninstalled.

at the bo ttom of the preview screen, press and hold the widget you want to add, then

, and then release and tap OK.

Screen buttons

There are three buttons at the bottom of the screen.

Back button : Tap to return to the previous page.

Home button: Tap to return to the default home screen.

Recent button: Tap to view recent apps. Then you can do the following:

Tap an app to open it.
Swipe an app window right or left to close it.
Tap to stop running the app.
Tap to stop running all the apps.

Notifications and Quick Settings

The Notifications panel informs you of new messages, USB connection, and activities in progress
such as file downl oading. The Quick Settings pa nel allows you to access frequ ently-used settings

such as the WLAN switch.

You can do any of the following:

To see notifications, swipe down from the top of the screen.

To close the Notifications panel, swipe up from the bottom of the screen.

To dismiss a notification, swipe left or right across the notification.

To dismiss all notifications, tap CLEAR ALL at the bottom of the Notifications panel.

To open the Quick Settings panel, swipe down from the top of the screen twice.

To close the Quick Settings panel, swipe up from the bottom of the screen.

Force shutdown/reboot

Press and hold the power button for about 10 seconds until the device turns off. Then turn it on
again in the normal way.

Split screen mode

Using split screen mode

Method 1

1. Open an app then tap

2. Press and hold the first app, drag it to "Drag here to use split screen", the n release. This

app will be locked into position.

3. Tap

split screen mode.

Method 2

1. Open an app then press and hold

2. Tap

split screen mode.

Note: Not all applications support split screen mode.

> , choose the second app you want to open, the two apps will then be displayed in

> , choose the second app you want to open. The two apps will then be displayed in

.

. This app will be locked into position.

Split screen settings

In split screen mode you can do the following:

Replace the second app

Tap

Adjust the split screen size

Slide the "

> , to choose another app.

" in the middle of the two screens to adjust the split sreen si ze.

Exiting split screen mode

You can exit split screen mode by:

Choosing an app that doesn't supp ort split screen mode.

Pressing and holding to enter full screen mode.

Multi-User

Multi-User

There are three user types:

Owner: An o wner has full control over all user permissions and manages all u ser accounts.

Add guest: There is only one Guest account. A Guest has restricted access to the device.

New User: There can be multiple user accounts, including accounts for standard users and child

user. A standard user can manage child user accounts. In child user accoun ts, there are many

child-friendly apps available includin g videos, games, music and more content can be managed

in Parental Control.

Creating new user accounts

Tap Settings > Users & accounts > Users > ADD USER to create user accounts.

Tap > CONTINUE to create a standard user account.

Tap > CONTINUE to create a child user.

Note: Before you add a child us er account, you need to set up screen lock to protect your

apps and personal data.

Switching between user accounts

On the home screen, swipe down from the top of the screen, and then tap user photos to switch

between different user accounts.

On the lock screen interface, select the user photos you want to switch, then tap and swipe up to

switch to the user account.

Deleting a user account

Tap Settings > Users & accounts > Users, and tap the located beside the account you would
like to delete, then tap DELETE USER > DELETE.

Camera

To open the Camera app, go to Camera.

Taking photos and videos

You can take photos and record videos with your device's built-in camera.

Tap to take a photo.

Tap to record a video.

Tap to convert to panorama mode.

Tap / to switch between the front and the rear camera.

Tap / to open or close HDR.

Taking screenshots

Press and hold the Power button and the Volume down button at the same time.

Viewing pictures and videos

Photos and videos are stored in your device's internal storage. You can view your photos and
videos by using the followi ng methods:

Tap the thumbnail when using the Camera app.

Go to Photos.

Go to Files Go .
The screenshots are stored in your device's internal storage. You can view your screenshots by

using the following methods:

Go to Photos.

Go to Files Go .

Network

You need to set up a wireless network before con necting to the Internet.

Set up a WLAN network.

*Set up a mobile network.

Set up a VPN network.
You can also share your mobile network with others.

*Set up a hotspot.

Setting up a WLAN network

Go to Settings > Network & Internet > WLAN.
Turn on the WLAN switch and tap a WLAN hotspot in the list to connect to the Internet.
When you are connecting to a secure hotspot, you need to enter your login name and password to
connect.

Setting up a mobile network

Go to Settings > Network & Internet > Mobile Network > Data usage .

Note: You need a valid SIM card with a data service. If you don't have a SIM card, contact
your carrier.

Setting up a VPN network

VPNs are used within organ izations to allow you to communicate private information securely over
a non -private network. You may n eed to configure a VPN, for example, to access your work email.
Ask the network's administrator for the settings necessary to configure a VPN for your network.

Go to Settings > Network & Internet > VPN.

Tap to edit the VPN profile, including the server name, type, and the server address, and then

tap SAVE.

Tap the VPN server name, enter the username and password, and then tap CONNECT to

connect to the VPN network.

Tap to edit or delete the VPN.

Note: You need to set a lock screen pattern, PIN or password before using a VPN. Go to
Settings > Security & location > Screen lock to select a screen lock option and set up the
screen lock.

*Setting up a hotspot

You can use personal hotspot to share an Internet connection with a computer or other device.
Go to Settings > Network & Internet > Hotspot & Tethering and do the following:

Turn on WLAN hotspot .

Tap Set up WLAN hotspot to configure the hotspot.
You can also use Bluetooth tethering or USB tethering.

Note: Tell your friends the Network name and password, and then they can share your mobile
network.

Internet

You can browse the web if your device is connected to a wireless network or a cellular network.
To open the browser app, go to Chrome.

Visiting websites

You can use the Chrome app to visit websites.

Type a web address

You don't need to type the full web ad dress of an "http://" we bsite to access it.

To visit "http://www.lenovo.com", simply type "www.leno vo.com" into the address bar and tap Go.

Search for keywords

You can also type keywords into the address bar to search for webpages.

You can set a search engine in

Add a new webpage

Tap

Tap

Close a webpage

Tap

Refresh a webpage

Tap

Tap

Tap

> New tab to add a new webpage tab.
> New incognito tab to visit a website without lea ving any traces of your visit.

to close a webpage tab.

to refresh a webpage.
to return to the previous webpage.

to go forward to a recent webpage.

> Settings > Search engine .

Saving webpages

You can save images and webpages in your device's internal storage.

Save images

Press and hold the image, then tap Download image.

Bookmark webpages

Tap

Tap

to add a webpage to Bookmarks.

> Bookmarks to view bookmarks.

Setting accessibility preferences

Tap > Settings > Accessibility to set the text scaling and the webpage zoom.

Sync

You can transfer data between your device and computer such as music, pictures, videos,
documents, Android application package (APK) files, and so on.

Connecting your device to your computer

Connect your device and computer using a USB cable.
Slide down from the top of the screen. You will see "USB for file transfer" in the notifications bar.
Tap USB for file transfer to vi ew other options.

Selecting the computer connection mode

You can select one of the following options:

Media device (MTP) : Select this mode if you want to transfer media files such as photos, videos,

and ringtones between your tablet and computer.

Camera (PTP) : Select this mode if you only want to transfer only photos and videos betwee n

your tablet and computer.

Charge this device: Select this mode if you want to charg e your phone only.

MIDI: Select this mode i f you want MIDI -enabled apps on your device to work with MIDI software

on the computer.

Installing APKs

Follow these steps:

Set the device to allow the installation of apps obtained from unknown sources.

Go to Settings > Apps & notifications > Advanced > Special app access > Install unknown

apps, select the app to install apps, and tap Allow from this source.

Copy the APK file from the computer to the devi ce in "Media device (MTP)" mode.

Open the apps category in the Files Go.

Settings

Settings home screen

Tap Settings to enter into settings home.

When you are setting any other functi ons (except Google, Scheduled power on and off, and so

on) for the device, slide right across the screen or tap

Setting the language

Go to Settings > System > Languages & input > Languages > Add a language.

Select the language that you want to a dd.

Press and hold to drag the added language to the first line.

to open the setting shortcut panel.

Appendix

Important safety and handling information

To avoid personal injury, property damage, or acciden tal damage to the product, read all of the
information in this section before using the product. For additional tips to help you operate your
device safely, go to http://www.lenovo.com/safety.

Handle your device with care

Do not drop, bend , or puncture your device; do not insert foreign objects into or place heavy
objects on your device. Sensitive components inside migh t become damaged.
Your device screen is made of glass. The glass might break if the device is dropped on a hard
surface, is subjected to a high impact, or is crushed by a heavy object. If the glass chips or cracks,
do not touch the broken glass or attempt to re move it from the device. Stop using the device
immediately and contact Le novo technical support for repair, replacement, or disposal information.
When using your device, keep it away from hot or high- voltage environments, such as electrical
appliances, electrical heating equipment, or electrical cooking equipment. Use your device only in
the temperature range of 0°C (32°F) to 40°C (104°F) (storage - 20°C ( -4°F) to 60°C (140°F)) to
avoid damage.
Don't expose your device to water, rain, extreme humidity, sweat or other liquids.

Do not disassemble or modify your device

Your device is a sealed unit. There are no end -user serviceable parts inside. All internal repairs
must be done by a Lenovo-authorized repair facility or a Lenovo- authorized technician. Attempting
to open or modify your device will void the warranty.

Built- in rechargeable battery notice

Do not attempt to replace the internal rechargeable lithium ion battery. There is risk of explosion if
the battery is replaced with an incorrect type. Contact Lenovo Support for replaceme nt.

Plastic bag notice

DANGER:
Plastic ba gs can be dangerous. Keep plastic bags away from babies and children to avoid
danger of suffocation.

Adapter information

Prevent your device and AC adapter from getting wet.

Do not immerse your device in water or leave your device in a location where it can come into

contact with water or other liquids.

Use approved charging methods only.

Note: Please only use standard Lenovo power adapters. The use of third- party power adapte rs

will affect the chargi ng speed, resulting in abnormal charging and potential damage to the

equipment.

Connect a standard power adapter to a suitable power outlet.

Use a standard data cable to connect the device to a PC or a device that complies with USB

2.0 or higher.

Charging devices mig ht become warm during normal use . Ensure that you have adequate
ventilation around the charging device. Unplug the charging device if any of the following occurs:

The charging device has been exposed to rain, liquid, or excessive moisture.

The charging device shows signs of physical damage.

You want to clean the charging device.

Warning:
Lenovo is not responsible for the performance or safety of products not manufactured or
approved by Lenovo. Use only approved Lenovo ac adapters and batteries.

Caution about high volume usage

Warning: exposure to loud noise from any source for extended periods of time may affect your
hearing. The louder the sound, the less time is required before your hearing could be affected. To
protect your hearing:

Limit the amount of time you use headsets or headphones at high volume.

Avoid turning up the volume to block out noisy surroundings.

Turn the volume down if you can't hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness in your ears,
ringing in your ears or muffled speech, you should stop listening to the device through your headset
or headphones and have your hearing checked.

To prevent possible hearing damage, do not listen at high volume levels for long periods.

Take care when using your device in a motor vehicle or on a bicycle

Always prioritize you r safety and the safety of others. Follow the law. Local laws and regulations
might govern how you can use mobile electronic devices, such as your device, while you drive a
motor vehicle or ride a bicycle.

Dispose according to local laws and regulations

When your device reaches the end of its useful life, do not crush, incinerate, immerse in water, or
dispose of your device in any mann er contrary to local laws and reg ulations. Some internal parts
contain substances that can explode, leak, or have an adverse environmental effects if disposed of
incorrectly.
See "Recycling and environmental information" for additional informati on.

Keep your device and accessories away from small children

Your device contains small parts that can be a choking hazard to small children. Additionally, the
glass screen can break or crack if dropped on or thrown against a hard surface.

Protect your data and software

Do not delete unknown files or change the name of files or directories that were not created by you;
otherwise, your device software might fail to work.
Be a ware that accessing network resources can leave your device vulnerable to computer viruses,
hackers, spyware, and other mali cious activities th at might damage your device, software, or data.
It is your responsibili ty to ensure that you have adequate protection in the fo rm of firewalls,
antivirus software, and anti -spyware software and keep such software up to date .
Keep electrical appliances away from your device. These include electric fans, radios, high-powered
speakers, air- conditioners, and microwave ovens. The strong magnetic fields generated by
electrical appl iances can damage the screen and the data on the device.

Be a ware of heat generated by your device

When your device is turned on or the battery is charging, some parts might become hot. The
temperature that they reach depends on the amo unt of system activity and the battery charge leve l.
Extended contact with your body, even thro ugh clothing, could cause discomfort or even a skin
burn. Avoid keeping your hands, your lap, or any other p art of your body in contact with a hot
section of the device for any extended time.

Electronic emission notices

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. Thi s equipment generates, uses, and can
radiate radio frequency energy an d, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communicatio ns. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or te levision reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an o utlet on a circuit different from that to which the receiver is

connected.

Consult an authorized dealer or service representative for help.
Lenovo is not responsible for any radio or television interference caused by unauthorized changes
or modifications to this equipment. Unauthorized changes or modifications could void the user's
authority to operate the equipment.
This device complies wi th Part 15 of the FCC Rules. Operation is subject to the fol lowing two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Responsible Party:
Lenovo (United States) Incorporated
1009 Think Place - Buil ding One
Morrisville, NC 27560
Telephone: [phone]

ISED Caution

This device complies with Innovation, Science and Economic D evelopment Canada license- exempt
RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioéle ctrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.

Japanese VCCI Class B statement

この装置は、クラスB情報技術装置です。この装置は、家庭環境で使用することを目的としていますが、こ

の装置がラジオやテレビジョン受信機に近接して使用されると、受信障害を引き起こすことがあります。 取
扱説明書に従って正しい取り扱いをして下さい。VCCI-B

Japan compliance statement for products that connect to power mains rated at less than or equal to
20A per phase

日本の定格電流が 20A/相以下の機器に対する高調波電流規制
高調波電流規格 JIS C 61000-3-2 適合品

Environmental, recycling, and disposal information

General recycling statement

Lenovo encourages owners of information technology (IT) equipment to responsibly recycle their
equipment when it is no longer needed. Lenovo offers a variety of programs and services to assist
equipment owners in recycling their IT products. For information on recycling Lenovo products, go
to http://www.lenovo.com/recycling.

Important battery and WEEE information

Batteries and electrical and electronic equipment marked with the symbol of a crossed -out wheeled
bin may not be disposed as unsorted municipal waste. Batterie s and waste of electrical and
electronic equipment (WEEE) shall be treated separately using the collection framework available to
customers for the return, recycling, and treatment of batteries and WEEE. When possible, remove
and isolate batteries from WEEE prior to placing WEEE in the waste co llection stream. Batteries
are to be collected separately using the framework available for the return, recycling, and treatment
of batteries and accumulators.
Country -specific information is available at http://www.lenovo.com/recycling.

Battery recycling information for Brazil

Declarações de Reciclagem no Brasil

Descarte de um Produto Le novo Fora de Uso Equipamentos elétricos e eletrônicos não devem ser
descartados em lixo comum, mas enviados à pontos de coleta, autorizados pelo fabricante do
produto para que sejam encaminhados e processados por empresas especializada s no manuseio
de resíduos industriais, devidamente certificadas pelos orgãos ambientais, de acordo com a
legislação local. A Lenovo possui um canal específico para auxiliá- lo no descarte desses produtos.
Caso você possua um produto Lenovo em situação de descarte, ligue para o nosso SAC ou
encaminhe um e-mail para: [e-mail], informando o modelo, número de série e cidade,
a fim de enviarmos as instruções para o correto descarte do seu produto Lenovo.

Recycling information for Japan

Recycling and disposal information for Japan is available at http://www.lenovo.com/recyclin g/japan.

Recycling information for India

Recycling and disposal information for India is available at
http://www.lenovo.com/social_responsibility/us/en/sustainability/ptb_india.html.

Battery recycling marks

The battery recycling in formation of Taiwan

Battery recycling information for the United States and Canada

Battery recycling information for the European Union

ENERGY STAR model information

ENERGY STAR® is a joint program of the U.S. Environmental Protection Agency and the U.S.
Department of Energy aimed at saving money and protecting the environment through energy
efficient products and practices.
Lenovo is proud to offer our customers products with the ENERGY STAR qualified designation . You
might find an ENERGY STAR mark affi xed on the computer or displayed on the power settings
interface. Lenovo tablets of the following model name, if carry an EN ERGY STAR mark, have been
designed and tested to conform to the ENERGY STAR program requirements for tablets.
Lenovo TB-X104F
By using ENERGY STAR qualified products and taking advantage of the power -management
features of the tablet, you can help reduce the consumption of electricity. Redu ced electrical
consumption can contribute to potential financial savings, a cleaner environment, and the reduction
of greenhouse gas emissions.
For more information about ENERGY STAR, go to http://www.energystar.gov.

Export classification notice

This product is subject to the United States Export Administration Re gulations (EAR) and has an
Export Classification Control Number (ECCN) of 5A992.c. It can be re- exported except to any of the
embargoed countries in the EAR E1 country list.

Troubleshooting

Insufficient memory prompt appears during app installation

Please free up some memory and try to install again.

The touch screen does not work or is not sensitive

Please press and hold the On/Off button for more than 10 seconds until the device turns off. Then
switch it on again in normal way.

Device does not power on or system crashes

Please charge the battery for half an hour and then press and hold the On/Off button for more than
10 seconds until the device turns off. Then switch it on again in normal way.

The device cannot access the internet via a wireless network

Restart the wireless ro uter or go to Settings and restart WL AN.

The device cannot wake up from sleep mode

Please press and hold the On/Off button for more than 10 seconds until the device turns off. Then

switch it on again in normal way.
