Important Safety Instructions

1. Warning: There are no user-serviceable parts inside. Refer
servicing to qualified personnel.

2. Warning: To prevent fire or electric shock hazard, do not
expose the unit to rain or moisture.

3. Do not expose the Adaptor and portable DVB-T to water
(dripping or splashing) and no objects filled with liquids, such as
vases, should be placed on the unit.

4. Keep the portable DVB-T away from direct sunlight and heat
source such as radiators or stoves.

5. Do not block the ventilation openings. Slots and openings on
the unit are provided for ventilation. The openings should never
be blocked by placing your portable DVB-T on a cushion, sofa or
other similar surface.

6. Do not place the portable DVB-T on unstable cart, stand,
tripod, bracket or table. The unit may fall, resulting in possible
damage or injury.

7. Never place heavy or sharp objects on the LCD panel or frame.

8. Only use the AC adapter included with portable DVB-T. Using
any other adapter will void your warranty.

9. The plug of AC adaptor is used as the disconnect device, the
disconnect device shall remain readily operable.

10. Unplug the power from the outlet when the unit is not in use.

11. Attention should be drawn to the environmental aspects of
battery disposal.

12. CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.

13. WARNNING: The battery (battery or batteries or battery pack)
shall not be exposed to excessive heat such as sunshine, fire or
the like.

14. WARNNING: Excessive sound pressure from earphones or
headphones can cause hearing loss.

15. WARNNING: Only use attachments/accessories specified
provided by the manufacturer, the portable DVB-T is supplied by
AC adapter, the AC adapter is used as disconnect device, the
disconnect device shall remain readily operable.

16.Caution: Danger of explosion if battery is incorrectly replaced,
replaced only with the same or equivalent type (Lithium battery)

Power supply ad aptor
Manufacture r：Shenzhen Mass P ower Electron ics L imited
Model number: S EF0900100E1 BA
Use only the powe r supply listed i n the user instru cti ons

This marking indicates that this product should not
be disposed with other household wastes
throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To
return your used device, please use the return and
collection systems or contact the retailer where
the product was purchased. They can take this
product for environmental safe recycling.

Safety Precautions

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

1. Warni ng: N ever stare d ire ctly into the las er beam.

2. Caution: Do no t install this pr oduct in a confin ed sp ace such
as a book case or sim ilar unit.

3. Warni ng: w hen the unit u sin g by child, paren ts must make sure
to let the child un derstand all co ntents in Instr uct ion book how
battery using t o guarantee usi ng battery corr ect ly all the time.

4. Warni ng: w hen find bat ter y overheat, swe ll or dour, please
stop using batt ery and contact s ervice centre f or ge tting
replacement .

5. Warni ng: d o not chargi ng ba ttery on the plac e of insufficient

ventilation s uch as: mattres s, sofa, cushio n , sof t mat......

6. Warni ng: w e will not tak e any r esponsibili ty if user incorr ect ly
use battery, not foll owi ng our warni ng in struction lab el on the
battery case.

7. Warni ng: m ore than 250 mm US B extension cor d is prohibited
to use for USB port

N

N

Notes on Copyrights:

It is forbidden b y law to copy, broadcas t, sh ow,broadc ast v ia
cable, play in pu blic, or rent cop yrighted mate ria l without
permission.

This product fe atures the copy p rotection fun cti on develop ed by
Macrovision .Copy protect ion signals are r eco rded on some d isc s.
When recordin g and playing the p ictures of thes e dis cs picture
noise will appe ar.This produc t incorporate s cop yright pro tec tion
technology th at is protected b y method claims o f cer tain U.S.
Patents and oth er intellectu al property rig hts o wned by Macr ovi sion
Corporation a nd other rights o wners.Use of th is co pyright pr ote ction
technology mu st be authorize d by Macrovisio n Cor poration , and i s
intended for ho me and other limi ted viewing use s onl y unless
otherwise aut horized by macr ovision Corpo rat ion. Rever se
engineering o r disassembly i s prohibited.

SERIAL NUMBER:

You can fin d the s erial numb er on t he back of the unit .This number
is unique to this u nit and not avail able to others. You should rec ord
requested inf ormation here a nd retain this gu ide a s a permanen t
record of your pu rchase.

Model No. _____ ___________ ___________ ___
Serial No. ____ ___________ ___________ ____
Date of Purchas e__________ ___________ ____

cha rge

str ong
imp act

ove r
hea t
40 C

Safety Precautions

Safety Precautions

Always read the safe ty inst ructions carefu lly

Keep this User s Manu al for fu ture reference

Keep this equipme nt away f rom humidity

Lay this equipmen t on a reli able flat surface before s etting it up.

Do not stand it on soft f urnis hings.

If any of the followi ng situ ation arises, get t he equi pment checked
by a service techni cian:

1.The equipment h as been e xposed to moisture.

2.The equipment h as been d ropped and damaged.

3.The equipment h as obvi ous sign of breakage.

4.The equipment h as not be en working well or you canno t get it
work according to U ser’s Man ual.

Warning

To prev ent the r isk of electric sho ck, do no t open the cover or the
back of the receive r.

Do not block the ventilati on holes of the device. Leav e appropriate
gap above and around it to all ow for adequate ventilat ion.

Do not place the device in an un ventilated cabinet or on t op of a
unit which emits heat.

Copyright Statement

No part of this publicatio n may be reproduced in any for m by any
means without the prior wr itten permission. Othe r trademarks or
brand names mentioned he re in are trademarks or regi stered
trademarks of the ir resp ective companies.

Before Use(Continued)

Disclaimer

Information in this docu ment is subject to change wi thout notice.
The manufacturer does no t make any representatio ns or warranties
(implied or otherwise) r egarding the accuracy an d completeness of
this document and shall in n o event be liable for any loss o f profit or
any commercial damage, i ncluding but not limited t o special,
incidental, conseque ntial, or other damage.

Introduction

This DVB-T player is a F ree-To-Air digi tal terrestri al receiver,
allowing y ou to a ccess free -to -air digit al te rrestria l TV chann els and radi o
broadcas ts. Its digita l rec eption cov ers V HF & UHF band.

Features

1.Mpeg-2 &Mp eg-4 DVB T receive

2.PVR func tio n (record TV program s to USB)

3.Teletext f unc tion

4.Multip le- language O SD

5.Suppor ts su btitle

6.Bandwi dth o f 7/8MHz sup por ted

7.Automa tic /manual ch ann el search

Identification of Controls

Main Unit

Panton e cool grey 8 C

23 .20 m m

5

7 mm

6 7 8

7 mm

3

4

1. / / /

Left/Right/Up/Down

2.OK
Used to confirm a selectio n within a menu.

3. MEDIA

4. MENU
Used to open the main menu win dow.

5.EXIT

1
2

used to return to the p revio us screen or menu.

6. HDMI

7.USB
USB jocks

8.ANT
Extra antenna connecto r

9. COAXIAL

10. AV OUT

11. He adpho ne out jacks

12. OFF/ON

13. DC IN 9-12V

9
10

11

12

13

4

Identification of Controls

Remote control unit

1

POWER

1 2

5

9 0

SUBTI TLE

REPEAT

MENU

GOTO

6

TTX FAV

ENTE R

EXIT

ZOOM

3

10

2

4

5
6

7

8

9

11

27

1. GOTO

Selects the play ti me of med ia.

2.POWER

Turn on or off the player

3. 0-9 (Numeric Buttons)

Selects a channel or setti ng .

RECAL L

AUDIO

MODE

MUTE

3

4

7

8

INFO

TV/RA DIO

VOL+VOL-

TIMER

16

18

21

23

25

12

14

22

17

19

20

24

26
28

15

13

4. TTX

Displays Teletext In forma tion.

5.SUBTITLE

Press SUBTITLE re peate dly during playback to hea r a differen t
subtitle languages.

6. Record

Recor d Video I mage.

7.ENTER

Confirms menu selectio n.

8.REPEAT

Press REPEAT dur ing pla yback to select a des ired re peat mode.

9. EXIT

Exits the c urrent Menu or returns to th e previous Menu.

10.MENU

turns on setup menu.

11.Zoom

Enlarges Video image.

12. MUTE

Disable Audio output.

5

13.MODE

Set LCD parameter(adju st bightness, contrast ,and saturation).

14. RECALL

Used to switch between the last two viewed channels.

15. INFO

Displays additional channel information.

16.AUDIO

DVB:Press AUDIO repeate dly during playback to hea r a differen t
audio language or audio tr ack, if avilable.

17.FAV

Turns on Favour ite Menu.

18.STOP

When this buttom is presse d once, the unit records the s topped
point,from where playb ack will resume if ENTER is pr essed after
wards. But if STOP button is pressd again ins tead of E NTER
button, there will be no res ume function.

19.PLAY/PAUSE

Press PLAY/ PAUS E once to pause playback, pr essin g PLAY/
PAUS E secon d time will resume th e playb ack.

20. TV/RADIO

Switches from TV function to Radio function and from Radio
to TV.

21.VOL -

Adjust VOLUME.

22. VOL +

Adjust VOLUME.

23.Reverse Skip

DVB: Red key in Teletext.

24.Forward Skip

DVB: Green key in Teletext.

25. BUTTON

Press BUTTON allow skipping b ack at 5- level speed
(X2->X4->X8->X20), p ress ENTER button return t o normal
playback.

26. BUTTON

Press BUTTON allow skipping a head at 5 -level speed
(X2->X4->X8->X20), p ress ENTER button return t o normal
playback.

27.COLOUR BUTTONS

Used to switch between the last two viewed channels.Switch
the product to on or standby.Operate different function in TEXT
screen.

28.

TIMER

Turns on Timer men u.

6

First Time Installation

After all c onnections have been made properly, switch on TV
and make sure the receiver is connected to the Main Power.
Press Power Button to sw itch receiver on. If you are using the
receiver for the first time or restor ed to Factory D efault, the
Main Menu will appear on your TV screen.

Basic Operation

(1) Program Manage Settings

To access the Menu, press the MENU button and select [Program].
The Menu provides options to adjust the Program Manage Settings.

Select an option and press OK or RIGHT to adjust that se tting.
Press the EXIT button to exit the Menu.

Installation Guide

OSD Language English

Country France

Channel Search

Exit

OK

ConfirmExit

(1) Select [OSD Language] and press RIGHT/LEFT key to select
an language
(2) Select [Country] and press RIGHT/LEFT key to select your
country of

residence
(3) Select [Channel Search] and press RIGHT or OK key to begin
Automatic

channel search
(4) Once channel tuning is complete, you are now ready to watch TV

Program

Program Edit
Sort By LCN
LCN On

Exit

(2) Progra m Edit

To edit your program prefere nces (lock, skip, favour ite, mo ve or delete), you

OK

ConfirmReturn

will need to enter the Progr am Edit Menu. This Menu requires a passw ord to
access. Enter the defaul t password '000000'.

Program Edit

ALL TV

003 ITV1

004 Channel 4
006 ITV2
010 ITV3
013 More 4
014 E4
030 ITV4
037 Quiz Call

LockMove

21:00-22:30 Secret Smile

22:30-22:50 ITV News

GOTO

FAV

DeleteSkip RenameFAV

7

Move a TV or Radio P rogra m/s

1. Select the preferred pr ogram t hen press the RED button. A move
symbol will appear

2. Press UP/DOWN to move the p rogra m

3. Press OK to confirm

4. Repeat the above steps to m ove mor e chann els

Lock Pr ogram /s

You can lock selected pro grams f or restricted view.
Lock a TV or Rad io Program:

1.Select the preferred p rogra m then press the YELL OW button. A
lock-shaped symbol is di splay ed. The prog ram is no w marked as locked

2. Repeat the previous ste p to sele ct more p rograms

3. To con firm an d exit the menu, press the EXIT button

4. Press the YELLOW button to disable th e locke d progr am

5. To vie w the loc ked program, you will be require to e nter ei ther the default
password '000000' or your last se t passw ord.

8

(4) Sor t

Sort your channels from th e follo wing op tions:
[LCN] - Sort the channels in a scend ing ord er

[Name] - Sort

the channels in alp habet ical order

[Service ID] - Sort t he chan nels according to t he station

(5) LCN ( Logic al chan nel num ber)

Set LCN on or off.

(6) Video Setting

To access the Menu, press MENU t hen sel ect [Pi cture]. Th e Menu
provides options to adjust the vi deo set tings. Press UP/DOWN to
select an option and press RIGHT/ LEFT to adju st that s etting.
Press EXIT to exit the menu.


Aspect Ratio 16:9 Wide Screen
Resolution 1080i
TV Format PAL

EXIT

(1). Aspec t Ratio

You must set the dis play fo rmat to either 4 :3 PanScan , 4:3 Let ter Box,
16:9 Full Screen or Auto to ge t the max imum display when watchi ng TV.

(2). Re solut ion

If the video does not appear c orrec tly, change the setting. T his setting
is to match the most common se tting f or HDMI.

[480i]: for NTSC system TV .
[480P]: for NTSC system TV .
[576i] for PAL system TV.
[576P]: for PAL system TV.
[720P]: for NTSC or PAL system TV.
[1080 I]: for NTSC or PAL system TV.

OK

ConfirmReturn

(3). TV f ormat

If the video does not appear correctly, yo u need to c hange the settings.
This should match the most common s ettin g for TVs i n your country.

[NTSC]: for NTSC system TV.
[PAL ]: for PAL system TV.

(7) Channel Search

To access the menu,pr ess MEN U and select [Searc h Chann el]. The
Menuprovides options t o adjust the Search Channe l settings.
Select an option and press R IGHT/LEFT to adjust the setti ngs.
Press EXIT to exit the Menu.

Channel Search

Auto Search
Manual Search
Country France
Antenna Power ON

EXIT

OK

ConfirmReturn

1 . Auto Se arch

Searc h and ins tall all channels automatically. Th is opti on overwrites all
prese t chann els.

1. Sele ct [Aut o Search] and press OK or RIGHT to start channel sea rch.

2. To cance l chann el search, press EXIT.

Channel Search

506.0MHz/8MHZ

DTV:009 Radio: 000

001 ITV1
002 ITV2
003 ITV3
004 ITV News
005 Channel 4
006 Quiz Call
007 E4
008 More 4
009 ITV4

Progress

EXIT

MENU

SkipExit

2. Manual Search

Install new channels man ually. This opti on adds n ew channels witho ut
changing the current cha nnels list.

1. Select [Manual S earch ] then press OK or RIGH T. The channel s earch
screen will appear

Manual Search

Frequency channel 21

Frequency(MHz) 474.0

Bandwidth: 8M

Quality

EXIT

EXIT

2. Press the RIGHT/LEFT key to select th e chann el frequency

3. Press OK to start searchi ng chan nels
If a channel is found, it is sav ed and ad ded to the channels list.
If channels cant be found, t hen exi t the menu.
(3) Country
Select your country of res idenc e.
(4) Antenna power

Enable Antenna Power if an e xtern al active antenna is conne cted.

(8) Time Setting

To access the Menu,press MEN U then se lect [Time]. The Menu provi des

optio ns to adjust the time settings.

Press UP/DOWN to s

elect an option and press RIGHT/LEFT to adjust

OK

Confirm

these ttings.Press EXIT to exit the menu.

Time

Time Offset Auto
Country Region London
Time Zore GMT +0

Sleep Off

EXIT

OK

ConfirmReturn

10

(1) Time offset

Select auto or manual for GM T offset adjustme nts.

(2) Country Region

Select the Country Region when [Time Offset] is set to Auto.

(3) Time Zone

Select the Time Z one Offset w hen [Time Offse t] is set to Manual.

(4) Sleep:

The function is use to select standby setting: OFF, 3 HOURS,
4 HOURS
OFF: No standby
3 HOURS: No remote control and panelkey operation within three
hours into standby
4 HOURS: No remote control and panelkey operation within four
hours into standby

(9) Option

To access the Menu,press MEN U and sel ect [Option]. The menu provides
options to adjust the OSD La nguag e, Subtitle Language and Au dio
Language.
Select an option and press R IGHT/ LEFT to adju st the setting.
Press EXIT to exit The Men u.

Option

OSD Language English
Subtitle Language English
Audio Language English
Digital Audio PCM

EXIT

OK

ConfirmReturn

(1). OSD Language

Select an OSD language

(2). Audio Language

Select the preferred audio language for watching TV channels.
If the language is not available, the default program language will
be used.

(3). Subtitle Language

Select the preferred subtitle language.

(10) System Setting

To access the Menu,press MENU and select [System].The menu
Provides options to adjust the system settings.
Press the UP/DOWN key to select an option and press
RIGHT/LEFT to adjust the setting.
Press EXIT to exit the Menu .

System

Parental Guidance
Set Password
Restore Factory Default
Information

EXIT

(1) Parental Guidance

You can restrict access to channels that are unsuitable for children.

OK

ConfirmReturn

To restrict/lock the channel you will need to enter either the
default password '000000' or your own password.

(2) Set Password

Set or change the password for Locked programs. Enter your old
Password or the default password '000000'. You will then be asked
to enter yo ur new password. To confirm re-enter your new password.
Once it is co nfirmed, press EXIT to exit the Menu.

(3) Restore Factory Default

Reset your Set Top Box to the Default Factor y Setti ngs.
In Main Menu select [Resto re Fact ory Default] and press OK or R IGHT to
select. Enter your passw ord or th e default password '0000 00' and p ress OK
to confirm. This option will delete al l prese t chann els and settings.

(4) Information
Vie w model , hardw are and software informa tion.

(5) Software update

If the status is set ''ON'', i t will be gin searching for new soft ware fr om
broadcast according to y our pre ferred time in ''Start Time ''.

(11)USB

To access the Menu, press the Me nu butt on and select USB.

USB

Multimedia
Photo Configure
Movie configure
PvR configure

EXIT

Multi-Media
Switch to USB mode and plug in U SB to vie w files.

OK

ConfirmReturn

11

SLAVE TFT MENU SETTING

PICTURE Page


BRIGHT

COLOR

ENGLISH

CONTRAST

RESET

Brightness

Adjust screen Bright Setting (level 0-100).

Contrast

Adjust screen Contrast Setting .(level 0-100)

Color

Adjust screen Color Setting .(level 0-100)

ENGLISH

Adjust Menu OSD Language.

Reset

Reset to default level. Press the top right button to
go to default setting.

OPTION Page

OPTION

SCREEN 16:9

SCREEN

Adjust screen ZOOM 16:9 or 4:3
Press Mode button twice fo r Screen Option.

Press top right button for 4 :3 ratio.
Press top left butt on for 16 :9 ratio.

50

50
50

TROUBLESHOOTING

Problem Potential Reasons What to do

No picture

Screen shows

No Signal

No sound from
speaker

Only sound, no
image on the
screen

Remote Control
is not responding

The image stopped
suddenly or mosaic

12

Power isn't connected

The power switch is not on Switch on the power

DVB-T cable not conn ected

Incorrect setting

No or incorrect connection
with audio cable

Sound on mute

Incorrect sound track Try another sound track

No or incorrect connection
with AV cable

The program is a radio
program

The battery is exhausted

Remote Control is not
facing or close enough
to the Set Top Box

The signal is too weak

Connect the power

Plug in the DVB- T cab le

Reset setting

Connect the audio cable
correctly

Turn off mute function

Make sure cables are
connected correctly

Press <TV/RADIO> key to
shift into TV mode

Change battery

Adjust the position of the
Remote Control and move
closer to the unit

Strengthen the signal

Identification of Controls

Technical Specifica tions

Item Sub Item Parameter

Tuner

Vid eo

Audio

Power

Input Frequency

RF Input level

IF Bandwidth

Modulation

Decoder Format

Output Format

Output Port

Decoder Format

Audio output

Voltage

Working Power

170~230MHz
470~860MHz

-25~-82dBm

7MHz and 8MHz

QPSK,16QAM,64QAM

MPEG4 AVC/H.264 HP@L4
MPEG2 [e-mail]

PAL/NTSC

CVBS

MPEG-1 (layer1&2&3)

Stereo

DC 9V (1.0A)

10W

Service and support

For information: www.lenco.com
For support: http://lencosupport.zendesk.com

Lenco helpdesk:

Germany 0900-1520530 (Local charges)
The Netherlands 0900-23553626 (Local charges + 1ct p/
Belgium 02-6200115 (Local charges)
France 03-81484280 (Local charges)

The helpdesk is accessible from Monday till Friday from 9 AM till 6 PM.
When contacting Lenco, you will always be asked for the model
and serial number of your product. The serial number can be found
on the back of the device. Please write down the serial number below:

Model: TFT-726

Serial number:_________________________________

Lenco offers service and warranty in accordance to European law,
which means that in case of repairs (both during and after the
warranty period) you should contact your local dealer.
Important note: It is not possible to send products that need repairs
to Lenco directly.

Important note: If this unit is opened or accessed by a non-official
service center in any way, the warranty expires.

This device is not suitable for professional use. In case of
professional use, all warranty obligations of the manufacturer will
be voided.

min)

13

This symbol indicates that the relevant electrical
product or battery should not be disposed of as
general household waste in Europe. To ensure the
correct waste treatment of the product and battery,
please dispose them in accordance to any applicable
local laws of requirement for disposal of electrical
equipment or batteries. In so doing, you will help to
conserve natural resources and improve standards
of environmental protection in treatment and disposal
of electrical waste (Waste Electrical and Electronic
Equipment Directive).

Products with the CE marking comply with the EMC
Directive (2004/108/EC) and the Low Voltage
Directive (2006/95/EC) issued by the Commission of
the European Community.

The declaration of conformity may be consulted at
http://www.lenco.eu/supportfiles/CE/48592058djs.pdf

WARNING: Prolonged exposure to loud sounds

from personal music players may lead to temporary
or permanent hearing loss.

®All rights reserved
