Lenco LED-3901 User Manual
39” Ultra High Denition 4K2K LED TV
Installation & Operating Instructions - Please keep for future reference
LED-3901-4K
Important - Please read these instructions fully before installing or operating
These instrucitons contain important information which will help you get the best from your
television and ensure safe and correct installation and operation.
CONTENTS
Important Safety Instructions 4
Safety Information 5
Preparation 6
What is Included 6
Front View 7
Rear View 8
Installing the Base Stand 9
Removing the Stand for Wall-Mounting 9
Remote Control 10
Connecting External Devices 11
General Operation 12
Initial Setup 12
Selecting the Input Source 14
Channel Selection 14
Display Channel Information 14
Volume Adjustment 14
Customizing TV Settings 15
Channel Settings 15
Picture Settings 23
Sound Settings 24
Time Settings 25
Option Settings 26
Lock Settings 27
Using the Features 29
EPG (Electronic Programme Guide) (DTV Mode) 29
Teletext (ATV Mode) 31
Digital Teletext (DTV Mode) 32
PVR (Personal Video Recorder) 33
Time Shift Function (DTV Mode) 33
Recording DTV Programme onto a USB Storage Device 34
Timer Programming 35
Play Recorded Programme 36
Entertainment 38
Connecting a USB Storage Device 38
Viewing Photos 38
Listening to Music 40
Viewing Movies 41
My Text 42
Specications 43
EN 3
IMPORTANT SAFETY INSTRUCTIONS
• Read these instructions – All the safety and operating instructions should be read before this product is
operated.
• Keep these instructions – The safety and operating instructions should be retained for future reference.
• Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to.
• Follow all instructions – All operating and use instructions should be followed.
• Do not use this apparatus near water – The appliance should not be used near water or moisture – for
example, in a wet basement or near a swimming pool.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two blades with
one wider than the other. A grounding plug has two blades and a third grounding prong. The wide blade
or the third prong is provided for your safety. If the provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles,
and at the point where they exit from the apparatus.
• Only use attachments/accessories specied by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or
sold with the apparatus. When a cart or rack is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
• Unplug the apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to qualied personnel. Servicing is required when the apparatus has been damaged in
any way, such as the power supply cord or plug is damaged, liquid has been spilled, or objects have fallen
into the apparatus, or the apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
• Please keep the unit in a well-ventilated environment.
• WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture. The apparatus should not be exposed to dripping or splashing. Objects lled with liquids,
such as vases should not be placed on the apparatus.
• WARNING: The batteries shall not be exposed to excessive heat such as sunshine, re or the like.
• WARNING: The wall socket plug is used as disconnect device, the disconnect device shall remain
readily operable.
• This lightning ash with arrowhead symbol within an equilateral triangle is intended to
alert the user to the presence of non-insulated “dangerous voltage” within the product’s
enclosure that may be of sufcient magnitude to constitute a risk of electric shock.
• Warning: To reduce the risk of electric shock, do not remove cover (or back) as there
are no user-serviceable parts inside. Refer servicing to qualied personnel.
• The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance instructions in the literature
accompanying the appliance.
This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way
that it does not require a safety connection to electrical earth.
This product contains electrical or electronic materials. The presence of these materials may, if not disposed of
properly, have potential adverse effects on the environment and human health.
Presence of this label on the product means it should not be disposed of as unsorted waste and must be collected
separately. As a consumer, you are responsible for ensuring that this product is disposed of properly.
This TV incorporates High-Denition Multimedia Interface (HDMI™) technology. HDMI, the HDMI logo and High-
HDMI:
Denition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
EN 4
SAFETY INFORMATION
To ensure reliable and safe operation of this equipment, please carefully read all the instructions in
this user guide, especially the safety information below.
Electrical Safety
• The TV set should only be connected to a main power supply with voltage that matches the label
at the rear of the product.
• To prevent overload, do not share the same power supply socket with too many other electronic
components.
• Do not place any connecting wires where they may be stepped on or tripped over.
• Do not place heavy items on any connecting wire, which may damage the wire.
• Hold the main plug, not the wires, when removing from a socket.
• During a thunderstorm, or when not using the television for extended period of time, turn off the
power switch on the back of the television.
• Do not allow water or moisture to enter the TV or power adapter. Do NOT use in wet, moist areas,
such as bathrooms, steamy kitchens or near swimming pools.
• Pull the plug out immediately, and seek professional help if the main plug or cable is damaged,
liquid is spilled onto the set, if the TV set accidentally exposed to water or moisture, if anything
accidentally penetrates the ventilation slots or if the TV set does not work normally.
• Do not remove the safety covers. There are no user-serviceable parts inside. Trying to service the
unit yourself is dangerous and may invalidate the product’s warranty. Qualied personnel must
only service this apparatus.
• To avoid a battery leakage, remove batteries from the remote control, when the remote is not use
for long period, or when the batteries are exhausted.
• Do not break open or throw exhausted batteries into a re.
Physical Safety
• Do not block ventilation slots in the back cover. You may place the TV in a cabinet, but ensure at
least 5cm (2’’) clearance all around.
• Do not tap or shake the TV screen, or you may damage the internal circuits. Take good care of the
remote control.
• To clean the TV use a soft dry cloth. Do not use solvents or petroleum based uids.
• Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus
(including ampliers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding plug has two blades and a third grounding
prong. The wide blade, or the third prong is provided for your safety. If the provided plug does not
t into your outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs.
• Unplug the apparatus during lightning storms or when unused for long periods.
• Refer all servicing to a qualied service personnel. Servicing is required if the apparatus does not
operate normally or if the apparatus, including the power supply cord or plug, has been damaged
in any way.
• Servicing is also required if liquid has been spilled, or objects have fallen into the apparatus; when
the apparatus has been exposed to rain or moisture; or if the apparatus has been dropped.
• Always connect your television to a power outlet with protective ground connection.
EN 5
PREPARATION
What is Included
TV Set
Base Stand
User Manual
User Manual
Remote Control with Batteries
Five Screws
Quick
Start Guide
Quick Start Guide
EN 6
Front View
PREPARATION
1. POWER Indicator
Illuminates blue when the TV is turned on. Illuminates red when the TV is in standby mode.
2. IR (Infrared Receiver)
Receive IR signals from the remote control.
EN 7
PREPARATION
Rear View
16
15
14
13
12
11
1. POWER
Switch the TV between On/Standby
mode.
2. SOURCE
Press to select among different input
signal sources.
3. MENU
Display the OSD (on screen display)
menu.
4. CH
Press to select a channel.
5. VOL +/-
Press to adjust the volume.
6. Headphone Socket
Connect to the Headphones.
7. PC AUDIO Input
Connect to a computer audio output.
8. VGA Input
Connect to a computer or other devices
with a VGA interface.
9. SCART socket
Inputs or outputs for external devices.
Connect the SCART cable between the
SCART socket on the TV and the SCART
socket on the external device (decoder,
VCR or DVD player).
EN 8
10. RF(75Ω) Input
Connect to the antenna (75Ω VHF/UHF)
socket with the RF coaxial cable.
11. OPTICAL Digital Audio Output
Connect to the audio socket on the digital
audio system.
12. CI Slot
Used to insert a CI card. A CI card allows
you to view all the channels that you
subscribe to.
13. MINI YPBPR
Connect to AV devices with component
(Y/Pb/Pr) video and audio output sockets.
COMPONENT&VIDEO share with AUDIO
IN(L/R).
14. MINI AV
Connect to the composite VIDEO and
AUDIO (L/R) output sockets on external
video devices.
15. USB Port
Connect to a USB storage device to play
compatible audio and photo files. (USB
mode)
16. HDMI Inputs
Connect to a High-Denition (HD) signal
output device.
Installing the Base Stand
• 1. Lay the TV face-down on a flat,
• 2. Fix the Base Stand to the Base
Removing the Stand for Wall-Mounting
• 1. Lay the TV face-down on a flat,
• 2. Untighten the 6pcs screws holding
PREPARATION
cushioned surface to avoid damaging
or scratching.
Support using 5pcs provided screws.
cushioned surface to avoid damaging
or scratching.
the stand assembly and remove them.
• 3. Attach the wall-mount bracket to
the TV using the mounting holes on
the back of the TV. Mount this TV
according to the instructions included
in the wall-mount bracket.
WARNING: This apparatus is intended to be supported by UL Listed wall mount bracket.
EN 9
PREPARATION
Remote Control
EN 10
CONNECTING EXTERNAL DEVICES
U-Vision Cable:
HD Video Source
with HDMI output
(cable,DVD,Blu-ray,set-top-box)
4K Ultra HDTV
with HDMI input
USB Port
on TV
1.Designed for use with 4K Ultra HDTVs
2.Up-convert Full HD content into high-quality
4K Ultra HD
3.Improves picture quality of HD video content
4.Perfoms real-time detail enhancement,edge
restoration and noise reduction
EN 11
General Operation
CUSTOMIZING TV SETTINGS
Initial Setup
• Connect one end of the RF coaxial cable (not included) to the aerial socket on the
wall and the other end of the cable to the RF (75) socket at the rear right bottom
view of your TV.
• Connect the mains cable to the mains socket after you have completed all the
connections.
• In standby mode, press the button on the front right side panel of the TV or the
button on the remote control to turn the TV on. The red LED indicator will turn
blue.
• The rst time you turn the TV on, press the
mode setting.
buttons to select your desired
First Time Installation
Home Mode
Store Mode
Move
• Press the buttons to navigate the menu and change the settings.
OK
Select
EXIT
Quit
EN 12
Installation Guide
Please set the following options,then
press OK button to begin auto tuning.
General Operation
OSD
Language
OSD Language
DVB Select type
Country
Tune Type
Mode
Move
Selects your desired language to be displayed on the
menu. The default on-screen menu language is set as
English.
OK
Select
English
DVB-T
France
ATV+DTV
Home Mode
EXIT
Quit
DVB Select Type Selects the DVB type: DVB-T/DVB-C.
Country
Selects the country where you will operate the TV. The
default country is set as France.
Tune Type Selects the tune type: ATV+DTV/DTV/ATV.
Press the OK button to start auto tuning. Channel
Tuning will commence. This operation may take up to
several minutes. The display will show the progress of
the tuning and the number of channels found.
OK
Channel Tuning
TV : 0 Programme(s)
DTV : 0 Programme(s)
Radio : 0 Programme(s)
Data : 0 Programme(s)
5%
134.25 MHz
Skip
(TV)
EXITMENU
Quit
EN 13
General Operation
Selecting Input Source
Input Source
DTV
ATV
AV
SCART
YPBPR
HDMI1
HDMI2
HDMI3
PC
USB
Move
OK
Select
EXIT
Quit
• Press the SOURCE button on the front right side panel of the TV or the SOURCE
button on the remote control to display the Input Source list.
• Press the
buttons to select the input source that you want: DTV / ATV / AV /
SCART / YPBPR / HDMI1 / HDMI2 / HDMI3 / PC/ USB.
• Press the OK button to conrm your selection.
Channel Selection
• Press the CH
/ buttons on the remote control repeatedly or the 0-9 buttons to
select the channel.
Alternative:
Press the CH.LIST button to enter the Channel List. Then use the
buttons
to highlight and select the channel. Press the OK button to view the selected
channel.
Display Channel Information
• Press the DISPLAY button to view the current information.
Volume Adjustment
• Press the VOL + / - buttons on the side panel of the TV or on the remote control
to adjust the volume.
• If you wish to switch the sound off, press the
button. Press the button again
or the VOL + buttons to resume audio listening.
EN 14
Loading...
