Leica LED2000 – LED2500
Powerful Illumination Stands for Stereomicroscopes
Living up to Life
Powerful LED Illumination
The high quality Leica LED2000/LED2500 illumination stands are so robust they are suitable for almost
any environment.
The LED2000 stand suits all incident light applications to provide a cost effective solution where no
transmitted light is needed. With five illumination options available, you can choose exactly where
and how much incident light you want to apply to your sample. This can range from applying all
7 LED’s to achieve full brightness, a 4 point top light for shadow free illumination, 2 side LED’s for improved contrast or 1 oblique LED where a semi-dark illumination is required. Each illumination option
also provides a dimming control to allow brightness levels to be fully optimized to individual needs.
With the light manager touch panel, each setting can be selected and easily reproduced.
The Leica LED2500 includes both incident and transmitted light capabilities, which can either be
used together or controlled individually. With a 60mm active light diameter, the LED2500 is perfect
for performing detailed inspections with consistent light levels across samples with a large field of
view. The 5500° K color temperature also means that specimens can be examined with true color
reproduction.
Moveable Arc Illumination
The LED2000/LED2500 provides an adjustable arc illumination, which is perfect for increasing the
contrast level to exactly meet your requirements. This can be optimised for 1.0× (none), 1.6× and 2.0×
supplemental lenses to achieve the desired results.
Maintenance Free
LED’s have a lifespan of at least 25 000 hours and maintain a constant color temperature. The lightemitting diodes are preferable over traditional incandescent light. Due to intelligent heat dissipation, the Leica LED2000/LED2500 bases do not require a fan. This ensures that light vibrations do not
hinder the inspection of a sample.
Clear as Daylight
The Leica LED2000 and LED2500 use the latest LED technology that closely resembles the light spectrum of daylight. As a result of “Pulse Width Modulation” (PWM), the color temperature remains
constant during the complete dimming range. Thus, there is no need to readjust the white balance of
a camera making the complete system easier to handle.
Corrosion of metal Mouse (cross-section) Identity documents examination
• All-in-One Solution
- Easy for transportation
- Robust and compact design
- Built-in power supply (100 – 240V)
- Vibration free (no fan)
- Adjustable focus torque
• State-of-the-art LEDs
- 4-point top light
- Bright and homogeneous
- Shadow free
• Built-in LED illumination
- 25 000 hours service life time
- No bulb exchange needed
- Daylight quality at 6500K
- True color reproduction
- Constant color temperature
- Flicker free
- 5 programmed illumination
settings
- Reproducible light conditions
• 3-Point arc light
- Shows more structures
of an object
• Transmitted light
- Bright and homogeneous
- 60mm active light diameter
• Easy illumination control
- 5 different programmed settings
Technical data for the Leica LED2000/LED2500
Illumination System Leica LED2000/LED2500
Illumination source Power LED’s, 1.2Watt (4 LED for ring light, 3 for oblique)
Illumination types Incident light (4-point ring light and oblique illumination)
Transmitted light (LED2500 only)
Average LED lifetime 25 000 hours
Color temperture 6500°K (daylight), 5500 °K for transmitted light (LED2500 only)
Cooling Thermo-management for LED’s, silent and vibration free
Illumination control Incident and transmitted light independently switchable
Brightness control 10-step increments
Brightness (Lux) Incident light: 15500 lux
Transmitted light: 13700 lux (LED2500 only)
Built-in power supply unit, 100V … 240V ~ 50 / 60 Hz
Voltage sensing
Power consumption max. 30W
Conformity with standards CE
cUL
UL
ESD design antistatic
Equipment components
Order numbers
10 447 347 Leica LED2000
10 447 348 Leica LED2500
Power Cables
10 445 662 2m, EURO
10 445 661 2m, USA
10 280 636 2.5m, Switzerland
10 445 663 2m-2.5m, BS
10 447 346 2m, Japan
10 450 012 Power cable Argentina
10 450 013 Power cable Australia
10 450 014 Power cable China
10 450 015 Power cable Israel
10 450 016 Power cable Italy
10 450 017 Power cable South Africa
10M11886EN © Leica Microsystems (Schweiz) AG • CH-9435 Heerbrugg, 2008 • Printed in Switzerland – V.2009 – RDV – Illustrations, descriptions and technical data are not binding and may be changed without notice.
